About this manual
This document is common to several television models. Therefore, certain functions or settings may not apply to
the model you have purchased
About the switch
The position of the ON/OFF switch differs depending on the model. It may be located on the front or on the
right-hand side of your set (see the drawing inside the cover page of your manual).
About safety
To ensure your own safety and safe operation of the equipment, observe the following instructions
thoroughly.
TV sets require sufficient ventilationtoprevent their componentsfrom overheating, whichwill cause failure. Do not
block the ventilation openings at therear. If you place your TV set in a special piece of furniture, make sure there
is enough space for unhindered air circulation. Do not place the TV set in the close vicinity of a heater.
The TV set has been designed for usein dry rooms. Should you useit, in exceptional circumstances in the open
air (example: on the balcony, in the veranda or tent), you must absolutely protect it against moisture (dew, rain,
splash water). Before switching on a cold TV set in a warm room, you should wait until any condensation in the
screen has dried by itself.
Maximum ambient temperature: 35°C
Maximum humidity: 85%
By the end of your TV evening or when away from home for a longer period, we recommendthat you turn off the
TV set with the On/Off-switch.
The mains plug must be easily accessible.
In the following cases, we recommend that you pull out the mains connector:
1. During athunderstorm. In such a case,it is advisablethat youalsodisconnect the TV setfromthe aerial socket.
2. When odour or smoke emanates from the set.
Never attempt to open your TV set yourself.
Further information:
The TV set shielding is sufficient to prevent X-radiation to the exterior.
Any operation performed by a non skilled person, change of high voltage or replacement of the picture tube by a
model not complying withthe manuf acturer specification are likely to cause considerable increase in X-radiation.
A TV set modified in such a way no longer complies withthe manufacturers’ specification and must not be used.
GB
About cleaning
The screen is to be cleaned with liquid glass cleaners.
:
Never use abrasive products.
:
Clean the cabinet with a soft cloth soaked with neutral cleaner. Do not use solvents, such as white spirit or
alcohol-based cleaning products since they may damage your television.
:
At regular intervals, clean the ventilation grids at the rear of the TV set.
About degaussing
The terrestrial magnetic field may have an influence on your TV set. This influence is revealed by the coloured
spots, which appear on the screen.
Should this be the case:
:
Turn the equipment off by means of the On/Off-switch.
:
Wait about one hour before switching the set on again.
This procedure performs automatic degaussingof the screen.Should there still be colouredspots on the screen,
repeat the operation.
The pages of this publication are printed on recycled paper.
1
Contents
GB
Using the remote control
and fitting the batteries.
Page 4
About this manual 1...................
About the switch 1.....................
About safety 1........................
About cleaning 1......................
About degaussing 1...................
Basic connections 3....................
Installation
Remote control 4.......................
Navigation principles 5.................
Calling up the INSTALLATION
MAIN MENU 5........................
Calling up t he SUMMARY 5.............
Calling up a Menu 5...................
Navigating within the Menus 5...........
Installing your television for
the first time 6.........................
How to call up a menu
and how to select a
function, a setting or an
option.
Page
Daily viewing 12.......................
Picture Adjustment 12................
Sound Settings 12....................
Time 13.............................
List of Channels 14...................
Selecting Programmes 15.............
Scrolling the Programmes 15...........
Audio-visual (AV) Programmes 15......
Volume Control 15....................
Muting the Sound 15..................
Zoom (16/9 models only) 15...........
Instructions for Use
Displaying Information 15..............
Television Lock 15....................
Switching Off the Television 15.........
Teletext 16............................
5
Automatic installation 7.................
Programme organisation 8..............
Manual programming 9.................
Personal settings 10...................
Preferences 11........................
2
Standard Functions 16................
Other Connections 17..................
Other Possibilities 17.................
Connecting a HiFi or AV amplifier 17....
/I6.3/B
GB-TBA
/
100
/
BASIC
C17 /
Basic connections
Basic connectio ns
The mains plug (1) supplies power to the television. The
television must only be plugged in to a 220-240 V - 50 Hz
power supply. It must never be plugged in to a DC source. If
the plug comes awa y from the lead, never attempt to plug it
in: this could cause electrocution.
Theaerialsocket(2),located ontherearof the television,can
be used to connect an external aerial or other appliance
equipped with a modulator suchas a VCR, satellitereceiver,
etc.
Continental
Europe
GB
If you connect an appliance to the aerial jack, you must give
it achannel number. To dothis, switch on the appliance,then
use the television to find the modulator channel (see the
appliance manual). Now give it a programme number and
memorise it (see Manual Programming of channels). Then,
when you wish to use the appliance, simply select its
programme number on the television. This procedure is not
required for VCR’s not equipped with a modulator.
The SCART socket AV1 (3), located on the rear of the
television, is intended to connect a VCR or a camcorder
(VHS, 8 mm), a Canal+ decoder, a video games console or
RGB-signal emitting appliances.
The SCART socket AV2 (3), located on the rear of the
television, is intended to connect a VCR or a camcorder
(VHS, 8 mm, S-VHS or Hi-8).
We strongly recommend the use of this type of connection,
which gives a better picture quality. To use the peripheral
appliance that youhave connected,press the AVkey onyour
remote control (press once to select AV1; twice to select
AV2; three times for AV3: see ”Other Connections”). This
selection is automatic for some appliances. Pressing “”play”
on a VCR, or switching on a satellite receiver connected to
AV1 or AV2 will automatically switch on your television.
When you stop the VCR, if you have not changed channels
while watching the VCR, the television automatically
switchesbacktothe channel youwere watching beforehand.
If the television has been switched on from the VCR, it
switches to standby when the VCR is switched off. The
television automatically switches to 16/9 format if the
connected appliance delivers the corresponding signal.
United Kingdom
The plug is fittedwith a fuse which pr otects your
television.Ifyour televisiondoes not work , the fuse may
be blown.In thiscase, replace itwith an identical 5 Amp
ASTA or lr BSI (BS 1362) c ertified fuse.
$
Note: the mains lead of your televisionis fittedwith a
moulded plug. This lead contains all the safety equipment,
so you are adv ised when replacing it not to us e a
non-specific commercially-available model.
2
3
Remote control
Display of channel, time, sound (yellow
button) (and zoom for models with zoom)
Remote control
This key is active only when using
the Teletext
(bluekey)
GB
Call up programme list
(green button)
Reminder of picture
preferences
Confirm an action or validate a
To leave a menu or Teletext
Volume adjustment
Selecting appliances
connected to the television
The red, green, yellow and
blue keys are also used for
the Teletext.
(red button)
menu option
Sound mute
(AV1, AV2 ...)
Standby
Call up Teletext / Toptext /
Fastext function
Right/Left Selection within
menus and
Zoom Function (for models with
this function)
Go to adjustment function MENU
Move Up/Down in menus
Change programme
8
Go to programmes and enter
numerical values
For programme numbers higher
than 10, press the
remote control: ”- -” appears on
the screen. Now use the
number keys on the remote
control to enter first the tens
digit then the units digit.
(purple button)
in menus
0
key on the
Please respect the environment! Before throwing any batteries away, consult your
distributor who may be able to take them back for specific recycling.
4
Navigation principles
Navigationprinciples
Calling up the INSTALLATION MAIN MENU
If there is no menu displayed on the screen,
press and hold the
control. The settings SUMMARY is displayed
first, followed by the INSTALLATION MAIN
MENU which you can use to operate your
television.
Calling up the SUMMARY
Press and release the
remote control to display the list of menus
available for using your television functions or
adjusting your television
Calling up a Menu
SelectthemenuyouwishusingtheUp/Down
keys. Press the
key to validate..
key on the remote
key on the
INSTALLATION MAIN MENU
Exit
Manual programming
Auto installation
Programme organisation
Personal settings
SUMMARY
Exit
Teletext
Sound
List
Time
Preferences
GB
Navigating within the Menus
Use the Up/Down keys 1 to select a line.
3
2 to:
Aerial
Cable
key to:
Use the Left/Right keys
- Increase or decrease a value:
for example:
Fine tuning
- Select an option:
for example: Reception
Reception
- Activate or deactivate an option:
for example: Decoder
- Access a sub-menu:
for example: Picture preferences
You can use the
- Activate or deactivate an option:
for example: Decoder
- Access a sub-menu:
for example: Picture preferences
- Validate an action:
for example: Store on PR number
Use the
key to exit a menu.
4
MANUAL PROGRAMMING
Return
Standard
Reception
Autosearch
Fine tuning
Store on PR number
Name
Decoder
External sound path
Enter channel number or start
autosearch with < or >.
EURO BG
Aerial
CH- -
--
----
5
Installing your television for the first time
Installing yourt elev is ionfor the firstt ime
First plug the televisionintoa mains power outlet and to the externalaerial or a cable network, then switch on using
the ON/OFF switch
Whenyouswitchon yourtelevision forthefirst time,the languageselectionmenu* is displayed(Fig. 1). If this does
not happen,setthe televisiontostandby thenpressand holdthe
Installation Instructions (start)
located on the front or the side of your set.
keyon thetele visionuntilthis menuappears.
1. Use the Up/Down keys to select the
GB
language in whichyou wishthe menus tobe
displayed.
2. Then validate using
3. A list of countries* is now displa y ed(Fig. 2).
Select the country in which you live, or the
country from which you wish to receive the
broadcasts if you live in a border area.
4. Then validate using
5. A welcome message is display ed.
6. Run the automatic installation sequence
using
7. A message appears to inf orm you that
automatic installation has started (Fig. 3).
Wait for a few minutes.
A new message will inform you when
automatic installation is completed.
8. If you wish to check or modify the channel
organisation, press
Programme organisation chapter.
If you do not wish to modify the channel
organisation, you can exit the menu by
pressing
your choice. Choose the desired channel
using the number keys (1, 2, 3, ...) and the
If you have a decoder, see the Manual
programming chapter.
.
then watch the channel of
/ keys.
.
.
and see the
(Fig. 1)(Fig. 1)
English
Français OK
Deutsch
Italiano
Español
Português
Nederlands
Svenska
Dansk
Norwisch
(Fig. 2)
Exit
United Kingdom
Eire
France
Germany
Italy
Spain
Portugal
Holland
Belgium and Luxembourg
Switzerland
Austria
Sweden
Denmark
Norway
COUNTRY SELECTION
Your television will only search for channels
corresponding to the country you have
selected. See the Manual channel
programming chapter to install any channels
not found.
For cable networks, read the Automatic
channel installation chapter to install any
channels not found.
*The list of languages and countries may vary
from one model to another.
Installation Instructions (end)
6
Other
Select your country and press OK
(Fig. 3)
SEARCHING
AUTO INSTALLATION
03 STATIONS FOUND
Searching for TV stations.
Please wait. To cancel press EXIT.
Automatic installation
Automaticinstallation
The Automatic installation function is useful if you have to go through the installation procedure again, such as
when moving house. This function deletes all previously memorised programmes. T o install a new channel, you
should use the Manual programming function.
Before running AUTO INSTALLATION, check the PERSONAL SETTINGS menu to ensure that the country
displayed is correct.
Your television will only search for channels corresponding to the selected country, so see the Manual
programming chaptertoinstall any channels not found. For cablenetworks, if youhavenot foundcertain
Other
channels, select
installation again.
instead ofa country name inthe
PERSONALSETTINGS
INSTALLATION MAIN MENU
menu,thenrunautomatic
GB
1. Press and hold the key on the remote
control to display the INSTALLATION MAIN
MENU (The SUMMARY appears first,
followed by the INSTALLATION MAIN
MENU).
2. Select the Auto installation line.
3. Validate using
A message will inform you that Automatic
installation has begun.
Wait for a few minutes.
A new message will inform you when
Automatic installation is completed.
If you wish to check or reorganizeyourchannel
display, press the
Programme organisation chapter.
If you do not wish to reorganize your
programmes, you can exit this menu by
pressing
your choice. Choose the desired programme
usingthe numberkeys(1,2, 3, ...) andthe
/ keys.
.
key and see the
, then watch the programme of
Exit
Manual programming
Auto installation
Programme organisation
Personal settings
SEARCHING
AUTO INSTALLATION
03 STATIONS FOUND
Searching for TV stations.
Please wait. To cancel press EXIT.
7
Programme organisation
Programmeorganisation
During automatic installation, your television will search for the channel name and assign it a programme number
according to the selected country. You can use thePROGR AMME ORGANISATION menu to name any channel
name not found, to changethe order in whichthe channelsaredisplayed,or todelete channelsfor which reception
is too poor. Follow the messages at the bottom of the screen. For further details, read the information below.
If you wish to access the
PROGRAMME ORGANISATION
menu thereafter, first press and hold
the
GB
display the
MENU
first, followed by the
MAINMENU
organisation
- Todeleteaprogrammefor whichreception
is too poor:
1. Select the line marked Select program.
2. Use the
your channels.
3. Whenyouget to achannelyouwishto delete,
select the line marked Delete program.
4. Press
5. .Validate using
- To organize your channels to suit you:
1. Select the line marked Select program..
2. Use the
the programmes logos tofind theprogramme
to which you wish to give the No.1.
Its present number appears on the line
markedSelect program..
3. Select the line marked Swap with PR.
4. Enter 01.
5. Press
position and the desired programme
becomes N°1.
6. Repeat the above procedure for the other
channels.
key on the remote controlto
INSTALLATION MAIN
(the
SUMMARY
)thenselect
is displayed
INSTALLATION
Programme
and validate using .
/ or Left/Right keys to list
to delete the programme.
.
/ or Left/Right keys and
. The two programmes swap
,
INSTALLATION MAIN MENU
Exit
Manual programming
Auto installation
Programme organisation
Personal settings
PROGRAMME ORGANISATION
Return
Select program.
Swap with PR.
Change pr. name
Delete program.
Select programme number using
PR-/PR+ or </> or 0 to 9 keys.
Select the line marked Return to return to the previous
menu.
13
-EURO
13
10 MTV
11 FR2
12 TF1
13 EURO
14 CH40
15 CC01
16 ARTE
17 CART
18 ---19 ARD
- To name your channels:
1. Select the line marked Change pr. name
2. Selectthe characteryou wish to modifyusing
the Left/Right keys.
3. Use the
require.
The name you have entered will be
memorised when you move to another lineor
exit the menu.
and keys todisplaythe letter you
If you wishto change the orderinwhich
your programmes are displayed or if
you wish to name other programmes,
repeat the procedures described
above.
When you have finished organizing the
programmes, exit the menu using
8
.
Manual programming
Manualprogramming
The manual installation function is useful if some programmes have not been installed even after AUTOMATIC
INSTALLATION.
1. Press and hold
displayed first, followed by the
INSTALLATION MAIN MENU.
2. Select the line marked Manual
programming.
3. Display the menu using
4. Now continue by following the messages at
the bottom of the screen. For further details,
read the information below.
Standard :
Select the standard using Left/Right keys that
corresponds to your country from the list of
standards.
The number of standards proposed will differ
,theSUMMARY is
.
INSTALLATION MAIN MENU
Exit
Manual programming
Auto installation
Programme organisation
Personal settings
MANUAL PROGRAMMING
Return
from one model to another.
France for France and Luxemburg
DKK’ eg. for Eastern Europe and
the Middle-East
I for the United Kingdom and
Ireland
Euro BG for Western Europe
Reception :
Your television can pick up channels either via
an aerial (RF channels) or via a cable network.
Certain cable networks use the same
frequencies as the RF channels. If this is the
case, you must select Aerial instead of Cable.
Autosearch :
Enter the programme number if you know it. If
not, search using the Left/Right keys. Your
television will stop at the first channel it tunes
into. If you wish to memorize it, go to t he line
marked Store on PR number. If not, resume
the search using the Left/Right keys.
Fine tuning :
You can use this to improve the picture if the transmitter frequency is out of adjustment. Use the Left/Right keys
to obtain the best possible picture and sound.
Store on PR number :
Enter the programme number you wish to give the channel (e.g.: 01 for BBC1). Memorise using
Name :
If the station has been identified by the transmitter , its name will be inscribed automatically. You can changethe
proposed name or enter it if it has not already been identified. Select the character you wish to modify using the
Left/Right keys. Use the
Decoder :
Use the Left/Right keys to tick the box if the channel is coded and if a decoder is connected to the AV1 jack.
External sound path :
Switchon your decoder. If the sound is coded or if you haveno sound, activate or deactivate thebox as required
using the Left/Right keys.
or keys to display the character you desire.
Standard
Reception
Autosearch
Fine tuning
Store on PR number
Name
Decoder
External sound path
Enter channel number or start
autosearch with < or >.
Select the line marked Return to return to the previous
menu.
EURO BG
Aerial
CH- -
--
----
.
GB
Once you have made alltheadjustmentsyou wish to a programme, go to
to memorise these. Then move on to the next channel.
Once you have completed your Manual Programming, exit the menu using .
Store on PR number
andpress
9
Personalsettings
1. Press and hold the key: the
SUMMARY is displayedf irst , followed by the
INSTALLATION MAIN MENU.
2. Select the line marked Personal settings.
3. Display the menu using
4. Continue by following the messages at the
bottom of the screen.
For further details, read the information below.
GB
Menu l anguage :
Select the language in which the menus are to
be displayed.
Country :
Indicatethecountry in which you areif you wish
to rerun Automatic Programming.
.
For cable networks,if certainchannels
have not been found, select
instead ofthecountry name beforerunning automatic installation again.
Youmayfindthat thecharacters of certain teletext languages are inaccessible for the selected country.
Personal settings
Exit
Manual programming
Auto installation
Programme organisation
Personal settings
PERSONAL SETTINGS
Return
Menu l anguage
Country
Other
Auto volume level
AV1 name
AV2 name
AV3 name
INSTALLATION MAIN MENU
English
UK
VCR
---CAMC
Auto volume level :
This is a sound control
equalise the volume level between different
channels, and between different programmes
on the same channel.
Activate or deactivate the auto volume level as
required.
function which aims to
OnmodelsequippedwithVirtual Dolby
Surround, this function remains
inactive if
Dolby Virtual
selected in the
SOUND
has been
menu (see
Volume Control).
AV1, AV2, AV3 name :
Usethesetogiveanametoeachofyour
audio-visual programmes. Select the character
youwishtomodifyusingtheLeft/Right keys.
Use the
character.
Prog. to be used for reference time :
To displaythe time usingthe
the alarm function, the televisionclock must be
set to the correct time. Select the line marked
Prog. to be used forreferencetimeandselect
a channel which broadcasts teletext. The time
is set automatically and is displayed after the
channel number.
or keys to display the desired
key or to use
Prog. to be used
for reference time
Select a station from which you want
to get the reference time.
Select the line marked Return to return to the previous
menu.
06
13:15
Exit the menu using
.
10
Preferences
Preferen ces
1. Display the SUMMARY b y pressing and
releasing the
control .
2. Select the line marked Preferences.
3. Display the menu using
Make your choice from the proposed
options. Usetheinformationbelow to help
you.
Show program. number :
If you wish to permanently display the number
of the programme youarewatching,tick the box
using the Left/Rightkeys. Press the Left/Right
keys again to deactivate this function.
AV2 video input :
Use the Left/Right keys to select the type of video signal received at the AV2SCART socket (Video or S-Video).
AV3 video input :
Use the Left/Right keys to select the type of video signal received at the AV3sockets (these sockets are located
on the front or the side of the television).
Format control :
Use the Left/Right keys to select the desired picture format:
Auto : if the transmitter (for 16/9format TV’s)or the appliance connectedtoone of theperipheral jacks delivers
the switching signal, the tele vision automatically adapts to the transmitted picture format.
16/9 : manually selects widescreen picture format.
4/3 : manually selects this picture format.
If you have selected
switch off.
key on the remote
.
16/9or4/3
, the televisionwill switchback to
PREFERENCES
Return
Show program. number
AV2 video input
AV3 video input
Format control
Picture preferences
Auto
Video
S-Video
Auto
when you change channels or you
GB
Picture preferences :
To access the PICTURE PREFERENCES
menu, press
.
If you wish, you can personalize certain
picture settings. Select and set the
proposed options. Use the information
below to help you.
Settings :
Select Standard or Personal.
Standardcorrespondstothefactory settings.
Personalcorresponds to the settingsthatyou
have entered yourself.
The lines
Contrast
selected
Select each line one after the other and enter
your required settings. You can recall these
picture settings by pressing the red key on the
remote control.
Exit the menu using
Brightness,Colour
and
are displayed only if you have
Personal
on the
.
Settings
line.
PICTURE PREFERENCES
Return
Settings
Brightness
Colour
Contrast
Select the line marked Return to return to the previous
menu.
Personal
11
Dailyviewing
Picture Adjustment
Display the SUMMARY using the key on
the remote control. Select Picture. Validate
using
.The PICTURE menu is display ed.
Select and set the proposed options. Use
the information below to help you.
Brightness, Colour, Contrast, Sharpness:
Select eachof these lines one afterthe otherand
GB
set as required.
Contrast expand :
Select thislinethen choose the desired Contrast
expand setting (High or Low).
Tone :
Select this line then choose the desired colour
tone (Warm, Neutral or Cold).
Exit the menu using
.
Sound Settings
Display the SUMMARY using the key on
the remote control. Select the line marked
Sound
is displayed.
Sound type :
Select thisline,then selectthetypeof sound you
desire.
Sound mode :
Select this line, then choose the desired mode
using the Left/Right keys.
Balance L/R :
Select this line,thenbalancethe soundbetween
the Left and Right loudspeakers.
Treble, Bass :
Select each of theselines and adjustto suit you.
Surround effect :
Select this lineand adjust the surround effect to
suit you.
Exit the menu using
. Validate using .The SOUND menu
Select and set the proposed options. Use
the information below to help you.
The choices available to you depend on
your television model and the broadcast.
Stereo, Dual or NICAM reception and the
corresponding choices are only available
on Stereo or NICAM Stereo televisions.
The choices available to you depend on
your television model and the type of
sound.
Magic
and
Dolby Virtual
are only available in stereo on TV’s
equipped with Virtual Dolby Surround.
Stereo wide
is only availableon Stereo or
Nicam televisions not equipped with
Virtual Dolby Surround.
This line appears only ifyou have selected
Dolby Virtual
on the
Sound mode
.
Daily viewing
Return
Brightness
Colour
Contrast
Sharpness
Contrast expand
Tone
Select the line marked Return to return to the previous
menu.
Return
Sound type
Sound mode
Balance L/R
Treble
Bass
Surround effect
Broadcast
mono
stereo
dual
NICAM-3
AV
Mode Effect
modes
line.
Normal : reproduces the original sound (
Wide : gives a stereo effect on mono sounds.
Stereo wide : accentuates the stereo effect.
Magic : accentuates the stereo effects and
Dolby Virtual : Virtual Dolby Surround.
Virtual Dolby Surround is based on Dolby Pro Logic
decoding forthe reproduction of the Left, Right, Centre and
Virtual Surround sound channels using two loudspeakers.
“”Dolby”, “”Pro Logic” and the double -D symbol are trademarks of the
Dolby Laboratories Lic ensing Corporation.
Manufactured under licence from Dolby Laboratories Licensing
Corporation.
Neutral
Cold
SOUND
Automatic
Normal
Choice
automatic - mono
mono - stereo
sound 1 - sound 2
sound 1 - sound 2 - sound 3
stereo - sound 1 - sound 2
mono or stereo).
adds echo.
12
Time
Daily viewing
You can use this menu to switch your
televisionon oroff automaticallyat a set
time.
Display theSUMMARY using the keyon
the remote control. Select the line marked
Time. Validate using
displayed.
Sleep timer :
Use theLeft/Right keysto choosehowlongyou
wish to view before the television switches off.
Thetelevisionwillswitchoffautomatically atthe
end of this period. To cancel, set to 00:00.
Oneminute before switchingoff,a messagewill
inform you that the television is about to go off.
If you wish to keep it on, press any key on the
remote control or the local keyboard.
Thetelevisionswitches to Childlockmodeafter
an automatic stop. It can only be switched on
again from the remote control.
Current time :
The current time is given by the Teletext (see PERSONALSETTINGS menu). You can also set the timemanually
using the number keys (0 to 9) on your remote control.
Wake-up timer :
If you wish to be woken up by your televisionon thechannel of your choice,youmust firstset the television
clock to the correct time (see above).
.TheTIME menu is
Return
Sleep timer
Current time
Wake-up timer
Wake-up time
Programme number
Daily
Select the line marked Return to return to the previous
menu.
TIME
00 : 00
11 : 28
07 : 07
01 BBC1
GB
Use the Left/Right keys to tick the box and display the Wake-up timer menu.
The
lines Wake-up time, Programme number and Daily only appear if you have ticked the box on the
line marked Wake-up timer.
Wake-up time :
Use the number keys (0 to 9) on the remote control to set the time at which you wish to be woken.
Programme number :
Selecttheprogrammeyouwishtobewokenby.
Daily :
Tickthis boxif youwish tobe awakenedat this timeeveryday.
Exit the menu using
Set the television to standb y using the
flashes.
The tele vision will come on automatically at the programmed time and will go off one hour later if you do not use
the remote control.
.
key on the remote control. The red indicator light on the tele vision
13
Daily viewing
List of Channels
This list contains up to 10 pages. The number of pages depends on
the number of programmes memorized. For each programme, the list
indicates the station name or type and the programme number. The
3 AV programmes are listed on page 11.
To displa y the list, press the ke y on the remote control
or
GB
Display the SUMMARY usingthe
line marked List. Validate using
The page displayed is the page containing the programme you are watching.
It is identified in the list by the symbol TV.
To displa y the next page, press the Right key.
To displa y the previous page, press the Left key.
If you wish to watch one of the programmes on the page display ed:
Enter the last digitof the programme number (e.g. for 25 simply enter 5) on the
remote control. The list disappears and your programme is selected.
Or ,
- Select the programme using the Up/Down keys.
- Validate using
- Exit the menu using
.
.
key on the remote control. Select the
.
LIST
Exit
01 BBC 1
02 BBC 2
03 FR 3
04 CC19
05 ARTE TV
06 M6
07 CNN
08 PREM
09 EURO
Page -/+
Programme:0-9
14
Daily viewing
Selecting Programmes
For channels 1 to 9, press the number key corresponding to the desired channel on the remote control. For
programme numbers higher than 10, press the
the number keys on the remote control to enter first the tens digit then the units digit.
If you press while ”--” is already displayed, the display returns to 0- , in which case you can only select
programmes 1 to 9.
keyon the remote control: ”--” appears on thescreen.Now use
Scrolling the Programmes
You can scroll through the programmes using the / keys.
Audio-visual (AV) Programmes
Press the k eytocall the last audio-visual(AV) programme watched. Pressrepeatedly to scroll theaudio-visual
(AV) programmes on the screen.
Volume Control
Use the volume +/- keys to increase or decrease the volume.
Muting the Sound
Press the key to mute the sound. Press again to restore the sound.
Zoom
(16/9 models only)
This function is useful for 4/3 or letterbox pictures (black bands at the top and bottom of the screen).
Use the Left/Right keys to select the desired zoom position:
ZOOM 0: 4/3 picture (black bands at the sides).
FULL SCREEN: for a 4/3 picture that fills the screen.
ZOOM 1: for letterbox pictures.
Displaying Information
GB
Press the keytodisplay the following informationon the screen:channel number andname,time,zoom,type
of sound.
Television Lock
You can use this function to prevent anyone from switching on the television using the buttons on the
television set.
The buttons on the television set are locked in the following cases:
- If you switch off the set by pressing and holding the
- After a programmed stop,
- If the television is set to standby when the alarm has been set.
When the television is locked the red power will be light flashing.
The television can now only be operated from the remote control.
To release the lock, press any number key on the remote control.
key on the remote control for more than 3 seconds,
Switching Off the Television
To switch off the television, press the Standby key on the remote control or press the ON/OFF switch on the
television set.
15
Teletext
Teletext
Certainchannelsbroadcast an electronicnews page servicewith arangeof differentinformationservices.
The presentation and use of the Teletext differ from one country to anotherand from one programme to
another (Teletext, Fastext or Toptext).
Press the key to display the Teletext Index (page 100).
A message will inform you if the programme you are watching has no Teletext service.
To call up a page:
Enter the 3 digits of the page number you wish to consult (for example, 150 or 170).
After a moment, the page appears.
GB
Use the Left/Right keys to consult the next or the previous page.
Standard Functions
Rolling pages:
Some information is displayed over several sub-pages. It is scrolled on your screen as it is received.
To stop scrolling, select STOP using the Up/Down keys and validate using
scrolling.
Masked text:
To reveal a hidden answer (for example in a quiz programme), select ??? using the Up/Down keys and validate
using
.Press again to hide the answers.
Zoom :
Select ZOOM using the Up/Down keys then press the key once to magnify the top of the screen, twice to
magnify the bottom of the screen (the page will scroll from top to bottom)and a third time to returnto the normal
display.
Display:
You can superpose the T eletext page over the TV picture. To do this, select MIX using the Up/Down keys then
validate by pressing the
key. Press again to return to the normal display.
Sub-code:
You can use this to access a sub-page directly.
Select “----”usingtheUp/Down keys. Then enter the four digits of the required sub-page number.
Certain programmeshave Alarm pages that you can set to appear at the time you require. For example:
for 15h30 enter 1530 as thesub-page number then press
. You must of course leave thetelevision
on the programme which is to transmit the Alarm page.
Index:
To call up the index page, select 100 using the Up/Down keys then validate using
Direct access:
You canusetheyellowand blue keys todirectly access the pages indicatedin thebar at the bottomof the screen.
Fastext functions:
If theT eletextyoureceive is F astext, a sub-menuat the bottom of the screenappears whichyou can useto select
from the 4 headings according to its colour.
To select a heading, press the key of the corresponding colour.
Toptext functions:
If the Teletext you receive is TOPte xt, the pages are arranged into headings and sub-headings by subject.
You can select the first page of a heading directly by pressing the blue key, or the first page of a sub-heading by
pressing the yellow key.
Other functions:
With certainTeletext channels, it is possib letohavesub-titlesoverlaid on the screen for certainbroadcasts as well
as certain news flash updates.
The corresponding page number is indicated in the Telextext index.
Once you have found the page, the sub-title or the news flash will be overlaid onto the TV picture.
The navigation status bar disappears after a few seconds. To display it again, press the
To exit Teletext, press
or .
.Press again to continue
.
key.
16
Other Connections
CAL
L
OtherConnections
The CINCH Video and Audio sockets (1)* are provided to
connect a VHS or 8mm camcorder.
TheSandCINCHAudio sockets (1)* are provided toconnect
a S-VHS or Hi-8 camcorder .
Tousetheappliance you have connected,press the
key several times until the AV3 programme is
selected on the screen. When you switch off the
connected appliance, the television will remain on
theAV3programmeandyou mustuse thenumerical
keys on the remote control to select a programme.
The headphone socket (2)* is provided to connect a
headphone or earphones.
Connecting headphones mute the sound from the
television loudspeakers.
GB
* on models equipped with this function
Other Possibilities
Copying a cassette:
Plugthe VCRyou wishto record to into the SCARTsocket
AV2.
Plug the appliance youwishtocopyfromas follows: into
the peripheral jackAV1for a VCR; into the CINCH AV3 jacks
for a camcorder (see table below).
PLAY
Appliance SCART Socket Appliance SCART Socket
VCR
Peripheral
AV1
Camcorder
Cinches or
S-Video
AV3
VCR
ou
Camcorder
VCR
ou
Camcorder
* on models equipped with this function
RECORD
Connecting a HiFi or AV amplifier
If you wish to connect a HiFi or AV amplifier, plug it into the
peripheral jack AV2 using a SCART-CINCH type lead.
CALL
PROGRAMME
AV2
AV2 AV3
AV1
17
THOMSON multimedia
46/47 Quai A. Le Gal lo 92648 Bo ulogn e Cedex France
RCS Nanter re B 3220194 64
10 - 98 - 253 534 60
Loading...
