Telefunken 10401 User Guide

User

guide

Model 10401

INDEX

I. Contents of the box..………………………………..…....…….06

II. Description of the frame.............……………………….……...06

III. Description of the remote control………......………....….……10

IV. Installing the frame..…………………………………...……..…11

V. Starting up........…………………………………..……….……..12

1. Which images are read by the DIGICADRE................................12

2. Inserting a card…………........……………………………..….……12

3. Switching on…….........…………………………………..….………13

4. Choosing the image source…….…………………….….………...13

5. Selecting a fixed image………….....…………..…..…….….….….14

6. Selecting a slide show………………......…..…….……..…….…...15

3

Non binding document, subject to modification in the event
of misprint(s) – MKG0207

INDEX

Fig.8

VI. Using the menu………………………………………………...16

1. Choosing the language………………………………..….………...16

2. Selecting the display type…………………….......………..……….17

3. Transitions between images…………………..........……..……….19

4. Display duration of the photos…..………..……….……….……….20

5. Slide show type…………………………………………..........…….21

6. Image operations..........……………………………….……........…23

a. Copying photos………………………………………………..………...…23

b. Deleting photos….............………………….…………………..….……..25

c. Rotating images…………........……………………………..……….……27

d. Zoom………………………….…………………………….……….……...29

4

Non binding document, subject to modification in the event
of misprint(s) – MKG0207

INDEX

e. Selecting favourite images ………………..........……………..…………………..…30

f. Reinitialising…………………………………..............………....……………….……32

g. Brightness adjustment..…………………………..…..........……..….……….………33

h. Contrast adjustment……………………………..…………..........…………….…….34

i. Colour adjustment………………………………….…..………….........…………….35

j. Hue adjustment…………………………….…………..……………..…...........…….36

VII. Connecting to a computer…….................……………….…..…37

1. Transferring images from the computer to the Digicadre…............39

2. Transferring images from the Digicadre to the computer………….39

VIII. Removing the back cover and cleaning...........…..…….….......40

IX. F.A.Q………….…………………….….......…………….….…….41

X. Safety…………..........……………………………………………..42

XI. Warranty…………….....………………………….………....…….44

XII. Technical properties…….....................…………….…..….……47

5

Non binding document, subject to modification in the event
of misprint(s) – MKG0207

Congratulations on your purchase of the TELEFUNKEN Digicadre 10.4’’. Please read the

n

instructions and advice contained in this manual carefully before using the digital photo
frame.
Important: keep the packaging and all objects contained therein.
Also keep this user manual for your own reference when needed.

I. CONTENTS OF THE BOX

• One digital photo frame

• One black acrylic back cover

• One mains voltage adaptor

• One remote control

• One user manual

• One USB lead

• One cleaning swab

II. DESCRIPTION OF THE FRAME

6

Your TELEFUNKEN Digicadre includes an acrylic back cover that can be removed, a mai
voltage adaptor, a remote control and an LCD screen equipped with 2 USB ports, and
multiple card reader that is compatible with most memory cards available on the market.

Non binding document, subject to modification in the event
of misprint(s) – MKG0207

7

.

Lecteur de

Card reader

cartes

USB HOST port

Port USB HOST

Mini port USB

USB mini port

Memory stick card

Emplacement 3 - cartes

- slot 3

Memory stick

SD cards, mini SD cards –

Emplacement 1- cartes SD,

Emplacement 2 - Cartes CF

slot 1

mini SD

CF cards – slot 2

Prise pour alimentation

Mains voltage socket

secteur

Non binding document, subject to modification in the event
of misprint(s) – MKG0207

Dos du cadre

Back of the frame

8

Menu access buttons

Touches d’accès au menu

On/off button

Bouton On/Off

Adjustable support

Support ajustable

Non binding document, subject to modification in the event
of misprint(s) – MKG0207

Touches du

Frame’s buttons

cadre

Backward/Forward

Touches de

défilement

buttons

9

Accès au

Menu

menu

access

Touche

Exit button

d’échappement

Touche de

Confirmation

validation

button

Bouton

On/off button

ON/OFF

Non binding document, subject to modification in the event
of misprint(s) – MKG0207

10

III. D escription de la télécommande

DESCRIPTION OF THE REMOTE CONTROL

Zoom

Zoom

Sortie

Exit

Rotation

Play

Touche lecture

Touche Haut

Up

Touche Gauche

Left

Launch the Slide

Lancement du

Show

Diaporama

Stop the Slide Show

Arrêt du

Diaporama

Touche d’accès au menu

Menu access

Touche de mise en fonction

On/off button

Touche de validation

Confirmation button

Right

Touche Droite

Down

Touche Bas

Non binding document, subject to modification in the event
of misprint(s) – MKG0207

IV. INSTALLING DIGICADRE

1. Inclining the frame

Your Digicadre’s inclination can be adjusted by bringing the adjustable support down.
Choose the inclination that suits you best among the 4 different levels (fig. 1). by pressing
and holding the button located on the support, and pulling the support down. Set the black
mark (white circle in fig. 1) to be facing marks numbered 1 or 2.
To set the frame in the vertical (portrait) position, unscrew the 4 thumb-wheels that are
found at the base, and turn the support set one quarter of a revolution. Screw the thumb­wheels back on and set the support on the marks numbered 3 or 4.

2. Electrical connection

11

Fig.1

Plug the end of the mains adaptor into its socket and then connect the other end to the
wall-socket.

Non binding document, subject to modification in the event
of misprint(s) – MKG0207

12

V. STARTING UP

1. Which images can be read by DIGICADRE?

DIGICADRE reads JPEG images, i.e. images from digital cameras.
If you use image editing software (Photoshop, Paint shop pro, etc.), make sure to save
only as an entry-level JPEG and not as a progressive JPEG, or any other type of JPEG.
If you want to view images in black and white on your DIGICADRE, make sure that they

3
2
1

are in RGB format and not in grey-level format. If they are saved in grey-level format,
you can display these as thumbnail images, but not in full-screen
DIGICADRE’s screen resolution is 1024 x 768 pixels. You can read images with a

higher resolution but the display time may be slowed down.

2. Inserting a memory card

Insert the memory card containing images to be read into its intended slot.
Slot 1: for SD, mini SD or MMC cards
Slot 2: for Compact Flash or MD cards

Fig.2

Slot 3: for Memory Stick, Memory Stick Pro, Memory Stick Duo or Memory Stick Pro
Duo cards.

Non binding document, subject to modification in the event
of misprint(s) – MKG0207

l

l

Fig.3

Fig.4

3. Switching on

With the remote contro

The slide show begins after a few seconds

With the frame

The slide-show begins after a few seconds

4. Choosing the image source

With the remote contro

When the frame is in slide-show mode and photos are being displayed, point the remote
control (fig.3) at the frame and then press EXIT twice. The screen on the left appears
(fig.4). Select the desired source (memory card or internal memory) with the left and right
arrows of the remote control (fig 3), then press the remote control’s "ENTER" button to
confirm your choice. Press “ENTER” again to launch the slide show that you have
chosen.

13

Non binding document, subject to modification in the event
of misprint(s) – MKG0207

l

Fig.4

14

With the frame

When the frame is in slide-show mode and photos are being displayed, press twice.
The screen on the left appears (fig. 4). Select the desired slide-show (card or internal

memory) with the buttons; then press twice (fig. 5)

5. Selecting a fixed image

With the remote contro

When the frame is in slide-show mode and photos are being displayed, point the remote
control at the frame and then press EXIT once. The frame then displays the image’s
thumbnails. Select the desired photo using the remote control’s arrow buttons (left, right,
up and down), then press ENTER. The selected image is displayed and doesnot change.
If you press ENTER once more, the slide show begins again.

Fig.5

Non binding document, subject to modification in the event
of misprint(s) – MKG0207

l

15

With the frame

When the frame is in slide-show mode and photos are being displayed, press once:
the images are displayed in thumbnail form. Select the desired photo using the

buttons, and then press ENTER. The selected image is displayed and does not

change. To return to the slide show, press and the slide show begins again.

6. Selecting a slide show

With the remote contro

When the frame is in thumbnail display mode, press the remote control’s “Slide show”
button once.

With the frame

When the frame is in thumbnail display mode, press the button twice.

Non binding document, subject to modification in the event
of misprint(s) – MKG0207

l

Fig.6

USING THE MENU

VI.

1. Choosing the language

The default language is French. To choose another one, the menu must first be
accessed.

With the remote contro

When the frame is in slide show mode and photos are being displayed, press the EXIT
button to leave the slide show, and then press SETUP to display the menu screen. On the
thirteenth line, the language is displayed (fig. 6). If you would like to change it, use the
remote control’s UP or DOWN buttons, until the language line is highlighted (in blue), then
press ENTER. Every time this button is pressed, a different language is displayed.
(French, Spanish, Portuguese, Dutch, English, Italian, German). Once the menu is
displayed in the desired language, press EXIT followed by ENTER.

16

With the frame

When the frame is in slide show mode and photos are being displayed, press once.
The menu screen is displayed.

Non binding document, subject to modification in the event
of misprint(s) – MKG0207
