PP006C
Passive Probe
Operator’s
Manual
700 Chestnut Ridge Road
Chestnut Ridge , NY, 10977-6499
Tel: 845-425-2000, Fax: 845-578-5985
teledynelecroy.com
PP006C Passive Probe Operator’s Manual
© 2014 Teledyne LeCroy, Inc. All rights reserved.
Unauthorized duplication of Teledyne LeCroy documentation materials other than for
internal sales and distribution purposes is strictly prohibited. However, clients are
encouraged to distribute and duplicate Teledyne LeCroy documentation for their own
internal educational purposes.
Teledyne LeCroy is a trademark of Teledyne LeCroy, Inc. Other product or brand names
are trademarks or requested trademarks of their respective holders. Information in this
publication supersedes all earlier versions. Specifications are subject to change without
notice.
924498-00 v2
August, 2014
Operator’s Manual
Attenuation
Impedance
B/W
Length
Range
R (MΩ)
C (pF)
(MHz)
(m)
(pF)
10x ±2%
10
12
500
1.2
13 - 23
Introduction
The Teledyne LeCroy PP006C is a passive probe with a wide range of probing
accessories. It is designed to give high-impedance probing capability to a circuit
when attached to a Teledyne LeCroy oscilloscope.
Specifications
System
Input
Cable
Compensation
Attenuation Ratio .....................10:1 ± 2%
Max. Rated Input Voltage
(1)
Measurement Category I: 350 Vrms
1400 V transient overvoltage
Measurement Category II: 300 Vrms
Pollution Degree
(1)
...................2
Operating Altitude ....................Up to 3000 meters
Max. Operating Te mp ...............5° C to 40° C (41° F to 104° F)
Humidity ...................................< 80% non-condensing
RH not controlled below 10° C
(1) As defined in IEC/EN 61010-031. Also see def initions below.
Definitions:
Measurement Category I (CA T I): measurements performed on c ircuits not directly co nnected to mains.
Measurement Category II (CAT II): measurements performed on circuits directly connected to the
low-voltage installation.
Pollution Degree 2: operating environment where normally only dry, non-conductive pollutio n occurs.
Temporary conductivity caused by condens ation must be expected.
1
PP006C Passive Probe
Input Impedance Profile
2
Voltage vs. Frequency Derating Curve
Operator’s Manual
3
PP006C Passive Probe
General Safety Information
Observe generally accepted safety procedures in addition to those listed
here to avoid personal injury or damage to equipment. The overall safety
assembler of the system.
Connect only to grounded instruments. Use only with compatible Teledyne LeCroy
oscilloscopes that have their BNC input connected to an earth ground. Do not
connect the probe reference lead to any point which is at a potential other than
earth ground.
Connect and disconnect properly. Connect probe to the oscilloscope before
connecting it to the test circuit. Disconnect the probe input and reference lead
from the test circuit before disconnecting from the oscilloscope. Do not connect
or disconnect probes while they are connected to a voltage source.
Do not overload. Do not apply any potential to the probe leads that exceeds the
maximum rating of the probe.
Always comply with the Voltage vs. Frequency Derating Curve.
Observe all terminal ratings. Observe all markings on the oscilloscope before
connecting. Consult the oscilloscope product manual for further ratings
information.
Do not remove probe casing. Touching exposed connections may result in
electric shock.
Do not excessively bend cables.
Use indoors only within operational environment listed. Do not use in wet or
explosive atmospheres. Keep product surfaces clean and dry.
Handle with care. Probe tips are extremely sharp and may puncture skin or
cause other bodily injury if not handled properly.
Keep fingers behind the finger guard of probe body and accessories.
of any system incorporating this accessory is the responsibility of the
4
Operator’s Manual
Do not operate with suspected failures. Before each use, inspect the probe and
accessories for any potential damage such as tears or other defects in the probe
body, cable jacket, accessories, etc. If any part is damaged, cease operation
immediately and sequester the probe from inadvertent use.
EC Declaration of Conformity
The product is marked with this symbol to indicate that it conforms to
the applicable European Union requirements per Low Voltage
Directive (LVD) 2006/95/EC. Compliance was demonstrated to the
following specification as listed in the Official Journal of the European
Communities:
IEC/EN 61010-031/A1:2008 Safety requirements for electrical equipment for
measurement, control and laboratory use – Part 031: Safety requirements for
handheld probe assemblies for electrical measurement and test.
EU RoHS Compliance
The probe and its accessories conform to the 2011/65/EU RoHS2 Directive, as
they have been classified as Industrial Monitoring and Control Equipment (per
Article 3, Paragraph 24) and are exempt from RoHS compliance until 22 July 2017
(per Article 4, Paragraph 3).
Disposal
The probe is marked with this symbol to indicate that it complies
with the applicable European Union requirements to Directives
2002/96/EC and 2006/66/EC on Waste Electrical and Electronic
Equipment (WEEE) and Batteries.
This electronic product is subject to disposal and recycling
regulations that vary by country and region. Many countries
waste receptacles. For more information about proper disposal and recycling of
your Teledyne LeCroy product, visit teledynelecroy.com/recycle.
5
prohibit the disposal of waste electronic equipment in standard
PP006C Passive Probe
Probe Compensation
Proper compensation of the probe is required to assure amplitude accuracy of
the waveform being measured by matching the probe to the oscilloscope’s input
capacitance. Compensation should be adjusted whenever the probe is connected
to or transferred between oscilloscopes.
1. Connect the sprung hook to the oscilloscope’s CAL OUT terminal and the
ground lead to the GND terminal. Connect the cable to any input channel.
2. Turn on the input channel and press AUTO SETUP.
3. Adjust the time base and channel Volts/div settings until the signal contains
two cycles as shown below.
4. Use the trimmer tool to adjust the low-frequency trimmer located on the
BNC Compensation Box until you achieve a flat-topped square wave like the
center illustration in the figure below.
CAUTION: Do not apply excessive pressure. The tip of the trimmer
is made of plastic and can break easily.
Over-compensated, correct, and under-compensated waveforms
6
Operator’s Manual
Cleaning
• Clean only the exterior of the probe, cables, and accessories. Use a soft
cotton cloth moistened with a mild detergent and water solution. Do not
allow any portion of the probe to be submerged at any time.
• Dry the probe and accessory thoroughly before attempting to make any
voltage measurement.
• Do not subject the probe to solvents or solvent fumes as these can cause
deterioration of the probe body, cables, and accessories.
Service
Refer all repairs to qualified service personnel. Contact Teledyne LeCroy at the
following address to arrange to return the probe for service:
Teledyne LeCroy, Inc.
700 Chestnut Ridge Road
Chestnut Ridge, NY, 10977-6499
Ph: 800-553-2769 or 845-425-2000
Fax: 845-578-5985
contact.corp@teledynelecroy.com
7
PP006C Passive Probe
1
Sprung Hook
1
2
Ground Lead, 11 cm
1
3
Ground Lead on probe tip
1
4
IC Insulating Tip
1
5
Color Bands (yellow, red, blue, green)
4 x 2
6
Trimmer Tool
1
Replaceable Parts
Item Description Quantity
All replacement parts contained in Standard Accessory Replacement Kit PK116.
8
Operator’s Manual
Warranty
NOTE: THE WARRANTY BELOW REPLAC ES ALL OTHER WARRANTIES, EXPRESSED OR
IMPLIED, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF
MERCHANTABILITY, FITNESS , OR ADEQUACY FOR ANY PARTICULAR PURPOSE OR USE.
TELEDYNE LECROY SHALL NOT BE LIABLE FOR ANY SPECIAL, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES, WHETHER IN CONTRACT OR OTHERWISE. THE CUSTOMER IS
RESPONSIBLE FOR THE TRANSPORTATION AND INSURANCE CHARGES FOR THE RETURN
OF PRODUCTS TO THE SERVICE FACILITY. TELEDYNE LECROY WILL RETURN ALL PRODUCTS
UNDER WARRANTY WITH TRANSPORT PREPAID.
Teledyne LeCroy warrants this oscilloscope accessory for normal use and
operation within specification for a period of one year from the date of
shipment. Spare parts, replacement parts and repairs are warranted for
90 days.
In exercising its warranty, Teledyne LeCroy, at its option, will either repair or
replace any assembly returned within the warranty period to the Customer
Service Department of an authorized service center. However, this will be
done only if the product is determined by Teledyne LeCroy’s examination to
be defective because of workmanship or materials, and the defect is not
caused by misuse, neglect, accident, abnormal conditions of operation; or,
damaged by attempted repair or modifications by a non-authorized service
facility.
The customer will be responsible for the transportation and insurance charges
for the return of products to the service facility. Teledyne LeCroy will return all
products under warranty with transportation charges prepaid.
This warranty replaces all other warranties, expressed or implied, including,
but not limited to, any implied warranty of merchantability, fitness, or
adequacy for any particular purposes or use. Teledyne LeCroy shall not be
liable for any special, incidental, or consequential damages, whether in
contract or otherwise.
9
924498-00 v2
