USB Mercury T2C

Quick Start

1

Introduction

The Teledyne LeCroy USB Mercury T2C™ USB 2.0 Protocol Analyzer is a verification system
for USB development and testing. It supports USB 2.0 and the Power Delivery Protocol that
runs over the Type-C(TM) connector. It is designed to record USB traffic and graphically
present the logical transactions and events. It connects to a laptop or desktop PC via USB

2.0. The Mercury T2C is powered by the USB cable, so no additional power cord is needed.

Please see the Readme file on the installation DVD for the latest information on
PC requirements and supported operating systems.

The system can monitor USB 2.0 traffic (Hi Speed, Full Speed, and Low Speed) using
compliant USB 2.0 cables, as well as Power Delivery 2.0 traffic over the USB Type-C to
Type-C cables. It will work with all existing USB 2.0 devices and hosts (using the supplied
Adapters), as well as new ones incorporating the Type-C connectors.

The total length of the cables between the Host under test and the Device under test should
be kept to < 4 feet.

Components

2

The Teledyne LeCroy Mercury T2C Analyzer package includes the following items:

• One Teledyne LeCroy USB Mercury T2C Analyzer

• Five USB cables (A to C, C to C, C to B, C to uB, C to A Receptacle)

• Installation DVD-ROM, including documentation

• Quick Start Guide

Please see the USB Protocol Suite User Manual on the installation DVD for
component specifications.
