Teledyne PMC2PCI-64 User Manual

Active Extenders

PCI532/PCI332

PCIX6432/PCIX6466-3

PMC2PCI-64

Hot Swap PCI Bus Extender Boards

PCI

User Manual

Revision 6.1

December 2002

90 Great Oaks Blvd, Ste 102

San Jose, CA 95119

[phone]

Fax: [phone]

Email [e-mail]

© 1996-2002

P/N 400-0014-002

TABLE OF CONTENTS

INTRODUCTION....................................................................................................................................................................2

INSTALLATION......................................................................................................................................................................2

OPERATION............................................................................................................................................................................3

ON-OFF............................................................................................................................................................................3

POWER-ON RESET......................................................................................................................................................3

BANK SWITCHES .........................................................................................................................................................3

CURRENT MEASUREMENT......................................................................................................................................4

CURRENT LIMIT CIRCUITRY....................................................................................................................................4

CURRENT LIMIT ADJUSTMENTS............................................................................................................................4

PMC BUS MODE SIGNALS........................................................................................................................................6

EXTERNAL POWER SUPPLY................................................................................................................................... 6

PCI HOT SWAP UTILITIES.........................................................................................................................................8

5V=>3V TRANSITION...................................................................................................................................................8

3.3V INPUT...................................................................................................................................................................... 8

TABLES....................................................................................................................................................................................8

LED TABLE......................................................................................................................................................................8

JUMPER TABLE.............................................................................................................................................................9

SPECIFICATIONS: PCI532 & PCI332.........................................................................................................................10

SPECIFICATIONS: PCIX6432-5, PCIX6466-3...........................................................................................................11

SPECIFICATIONS: PMC2PCI-64..................................................................................................................................12

AUXILIARY PINOUT...........................................................................................................................................................13

MAIN, 32 BIT SIGNALS..............................................................................................................................................13

EXTENSION, 64 BIT SIGNALS................................................................................................................................15

BOARD LAYOUT, PCI532 & PCI332.............................................................................................................................16

BOARD LAYOUT, PCIX6432-5 & PCIX6466-3............................................................................................................17

BOARD LAYOUT, PMC2PCI-64......................................................................................................................................18

INTRODUCTION

These PCI Active Extender boards allow HOT SWAPPING or LIVE INSERTION of Unit-Under-Test into
PCI bus. The PCI extender series supports the entire range of the PCI bus (32-bit, 64-bit, 3.3V, 5V, 66 Mhz
and even PCI Mezzanine). The “HOT SWAPPING” feature of these extenders eliminates the need for turning
the PC Off and On and repeated rebooting. This feature speeds up rework, characterization and test of Unit­Under-Test in the development phase as well as production test. The elimination of the repeated power cycling
also helps prolong the system life and the hard disc operation. These Active Extenders use a new CMOS
technology for switching the signals On and Off (known as "Quick Switch"). These switches have a very fast
propagation delay, typically about 250 picoseconds, resulting in no timing degradation between the bus and
the Unit- Under-Test. The switches are also bidirectional allowing the entire address range to be supported for
both target and master type operation.

These Active Extender boards isolate all signals and voltages to the Unit-Under-Test, when the On-Off switch
is in the Off position. All voltages are ramped down and ramped up during the power down and power up in
order to eliminate any spikes. During the power down the signals to the bus become isolated as soon as the
main supply, +5V, reaches down to +3.0V. During the power up the signals stay isolated until the main
voltage is at least +3.0V.

These Active Extenders also allow for voltage margin testing of the Unit-Under-Test by allowing external
power supplies to replace the bus supplies as inputs to the Unit-Under-Test.

An on-board current-to-voltage converters allow measurement of the current drawn by the UUT at any time,
using just a voltmeter at the appropriate test points.

INSTALLATION

To install the Active Extender board, make sure to turn the PC power off. Insert the Active Extender in any
available slot and secure it's bracket to the main chassis. You are now ready to use your new extender board.

NOTE: If you are planning to use an external I/O signal to control the board, the On-Off switch must

be in the Off position and the dip switch must be in the CLOSED (ON) position.

2

OPERATION

ON-OFF

To insert or remove any Unit-Under-Test into and out of the Active Extender, make sure that the Active
Extender is turned Off, if the PC power is to stay On. There are two ways to turn the Active Extender power
On and Off. 1) The mechanical toggle switch. 2) External control signal connected to JP3.

External control can be used if remote controlling is desired for turning the power On and Off. Leave the
mechanical switch in the Off position, then use a CMOS or TTL level signal to control turning the power On
via JP3. The left connector of JP3 is ground and the right connector is the control signal. A Low level, less
than 1.5V , will turn the switch ON.

Software control is also possible using the external control with a custom interfacing between the parallel port
and the board. Consult the factory if you need additional help for implementing this feature.

NOTE: During the power Off, all signals become isolated between the bus and the Unit-Under-Test when the
+5V to the Unit-Under-Test becomes less than 3.0V.

NOTE: If you are running a software that relies on a response from the Unit-Under-Test, do not turn off the
Active Extender board unless the handshaking has taken place, Otherwise you may experience a system hang­up. It may be a good practice to stop the software from running, before isolating the power and the signals to
the Unit-Under-Test.

POWER-ON RESET

Each time the Active Extender board is turned Off and then On, reset signal will be generated from the
extender to the Unit-Under-Test automatically. The duration of this reset is 200 milliseconds. The reset to the
Unit-Under-Test is also activated every time there is a reset from the bus.

BANK SWITCHES

In a normal operation, the bank switches should be left in the closed position. In this case when the power to
the extender is turned on, all of the bus signals will be active to and from the Unit-Under-Test. However,
when there is a problem with the signals from the Unit-Under-Test, the signals can be activated in a smaller
group.

NOTE: The bank switch number 1 controls U1, bank switch 2 controls U2, ... , and the final bank

switch 8 controls U8. For 64 bit extenders, switch 9 controls the ICs U12 and U13 (all 64 bit
signals on the B side) and switch 10 controls ICs U14 and U15 (all 64 bit signals on the A side).
For the signal names and grouping by the U number see the section on the auxiliary pinout.

3

CURRENT MEASUREMENT

When using the PCI532, the user can measure the +5V current being drawn by the Unit-Under-Test, by just
connecting a voltmeter to J3.

When using the PMC2PCI and PCIX6432 (Rev. C and below), the user can measure the +5V current being
drawn by the UUT using a voltmeter at J3, the current draw for the +12V can be measured by using a voltage
meter at J4 and the current draw for the +3.3V can be measured using voltmeter at J5.

When using the PCIX6432 (Rev. D or higher), the user can measure the current draw on the +5V using a
voltmeter between J3.1 and J3.2. To measure the current draw on the +3.3V measure using a voltmeter
between J3.1 and J3.3, and the measure the current draw on the +12V, measure using a voltmeter between
J3.1 and J3.4.

Every Volt read by the meter represents One Amp. So if the voltmeter reads 0.35, it represents that the Unit­Under-Test is drawing 350 milliamps of current from +5V supply.

NOTE: If the VIO and +5V are on the same plane on your board, you need to remove JP10 jumper, located
on the extender board, in order to get an accurate current measurement.

CURRENT LIMIT CIRCUITRY

Red LEDs, when illuminated, indicate a short or a very low voltage at the output for their corresponding
voltages. Green LEDs when illuminated, indicate voltages at their corresponding outputs. In the case of the
+5V short from the Unit-Under-Test, the Active Extender will automatically switch the current limit down to
about 200 milliamps and will continue to deliver this current for troubleshooting purposes. On the PCIX-6432
and PMC2PCI boards this feature is extended to cover the +12V and +3.3V as well. In the case of shorts or
excessive current draw for the other voltages the resetable fuses will open up until the problem is corrected.

The current limit value for the +5V is set to 5 Amps with JP8 not installed and 1 Amp with JP8 installed.

CURRENT LIMIT ADJUSTMENTS

FOR PCI532/PCI332

To increase the +5v current limit you must reduce the gain of the current measurement circuitry.
Perform the following reworks:

• To change the current limit to 7.5A install a 200k Resistor on top of R19 and R22, this will cause

the current measurement circuit gain to be reduced by a factor 0.66 (I.e. 1 volt will represent 1.5
A current draw.)

• To change the current limit to 10A install a 100k Resistor on top of R19 and R22, this will cause

the current measurement circuit gain to be reduced by a factor 0.50 (I.e. 1 volt will represent 2 A
current draw.)

To increase the +3.3v current limit you must place an additional fuse across F4 which will increase
the current limit to 2A.

4

FOR PCIX6432/PCIX6466-3 (Rev. C and below)

To increase the +5v current limit you must cut the trace between the pads of R23 and perform the
following reworks:

• To change the current limit to 8A install a 10k resistor at location R22 and a 6.2k resistor at location

R23. This does not affect the current measurement reading.

• To change the current limit to 10A install a 10k resistor at location R22 and R23. This does not

affect the current measurement reading.

To increase the +3.3v current limit must supply the +3.3v from the mother board or an external power
supply, and reduce the gain of the current measurement circuitry. Perform the following rework:

• To change the current limit to 5A install a 100k Resistor on top of R33 and R34, this will cause the

current measurement circuit gain to be reduced by a factor 0.50 (I.e. 1 volt will represent 2 A current
draw.)

FOR PCIX6432/PCIX6466-3 (Rev. D and above)

To increase the +5v current limit you must remove R23 and perform the following reworks:

• To change the current limit to 8A install a 10k resistor at location R22 and a 6.2k resistor at location

R23. This does not affect the current measurement reading.

• To change the current limit to 10A install a 10k resistor at location R22 and R23. This does not

affect the current measurement reading.

To increase the +3.3v current limit must supply the +3.3v from the mother board or an external power
supply, and reduce the gain of the current measurement circuitry. Perform the following rework:

• To change the current limit to 5A remove resistor installed at R60, install a 40K resistor, This

does not affect the current measurement reading.

FOR PMC2PCI-64

To increase the +5v current limit you must remove the resistor at R29 and perform the following
reworks:

• To change the current limit to 8A install a 10k resistor at location R30 and a 6.2k resistor at location

R29. This does not affect the current measurement reading.

• To change the current limit to 10A install a 10k resistor at location R30 and R29. This does not

affect the current measurement reading.

To increase the +3.3v current limit you must supply the +3.3v from the mother board or an external
power supply, and reduce the gain of the current measurement circuitry. Perform the following reworks:

• To change the current limit to 5A install a 100k Resistor on top of R39 and R38, this will cause the

current measurement circuit gain to be reduced by a factor 0.50 (I.e. 1 volt will represent 2 A current
draw.)

5

PMC BUS MODE SIGNALS

The 4 bus mode signals for the PMC bus are selectable on the PMC2PCI-64 extender board. These signals
BUSMODE1, BUSMODE2, BUSMODE3 and BUSMODE4 are connected to 3 push-on jumpers JPN2, JPN3
and JPN4 respectively. These jumpers are pulled up to VCC with a 10K resistor each. If the jumper is not in
place the signal will go HI, and if the jumper is in place the signal will be grounded and represents a LOW.

BUSMODE1 is an output signal, represented by an LED which indicates when this output is low, asserted.
When the PMC card asserts this output the LED will illuminate.

For the PMC2PCI-64, the signals PRSNT1# and PRSNT2# on the PCI bus side of the extender board,
are hard wired to represent 25 Watts of power requirement, PRSNT1# = GND and PRSNT2# = OPEN.

EXTERNAL POWER SUPPLY

On the PCI532/332 the terminal VINEX is used and J6 terminal is used on other cards for the external power
supply input. However remember never to connect any supply to these inputs so long as you have JP4, JP5,
JP6 and JP7 installed.

In case you want to use the external supply as an input you must remove these 4 jumpers in order not to cause
any conflict with the bus voltages. These jumpers are, however, independent from each other.

For instance if you would want to bring in only a +5V from the external supply and continue to use the bus
voltages for +12V, -12V, and +3.3V, you would only need to remove JP6. The list below identifies which
jumper is for which supply:

JP4 = +12V, Next to Q5 pin 3 (left side of the board).
JP5 = -12V, Next to Q7 pin 3 (left side of the board).
JP6 = +5V, Next to Q6 pin 3, also JP10 for +VIO, if connected to +5V on your board.
JP7 = +3.3V, Next to Q9 pin 3.

6

The following diagram indicates the interconnection of the Unit-Under-Test voltages to bus voltages and the
external voltages:

+5VE to Unit-Under-Test

ON-OFF
Circuitry +5BV

+VIOB

JP6
JP10

+5V from the Bus ON-OFF
Circuitry

+VIO from bus (+5v plane)

As you can see, there will be a conflict in case the external supply is connected while the jumper is still in
place. This circuit is repeated for each of the 4 voltages.

If you are using external power supplies do not forget to connect the Ground (GND) signals. If your external
power supply outputs are not isolated, make sure the ground of the PC (containing the extender board) and the
ground of the power supply are at the same voltage level with respect to a common point, before connecting
the GND signal.

Note: Be sure to remove JP10 if the VIO and +5V on your board are on the same voltage plane.

7

PCI HOT SWAP UTILITIES

The purpose of the utilities is to provide the user with the knowledge and application of Hot Swap utility software
and extender cards for purposes of swapping PCI cards while the system power stays on. These utilities will allow
the user to perform various functions with the Catalyst Enterprises, PCI Active extenders. The software allows the
user to read, save and reload the configuration space data and allow the user to control the power of to the UUT
during testing via the test program. For more information see the Hot Swapping PCI Cards document, located on
our web site http://www.catalyst-ent.com under the documents page.

5V=>3V TRANSITION

The PCIX6432/PCIX6466-3 and PMC2PCI-64 Active Extender cards are capable of translating the incoming
5-volt signals to 3.3 volts for the UUT without any timing degradation. Therefore cards or components
needing 3-volt environment can be tested or operated on a 5-volt system using these extender cards.

If JP9 (PCIX6432/PCIX6466-3) or JPX (PMC2PCI-64) is installed the UUT signals will be the same as the
bus signals, most likely 5V. If not installed the signals to the UUT will be translated down to 3.3V.

To use this feature with the PCI532, performing the follow reworks:

• Remove R32

• Install a 191 Ohm resistor at R32

3.3V INPUT

The PCIX6432/PCIX6466-3 Active Extender cards have an on-board 3.3 volt regulator (PCIX6432 Rev C and
higher).

JP7 selects the source of the 3.3V to the UUT.
JP7 1-2 3.3V from the on-board regulator.

JP7 2-3 3.3V from the system bus.

JP7 no shunts 3.3V from the external supply.

TABLES

LED TABLE

LED Purpose PCI532/PCI332 PCIX6432/PCIX6466-3 PMC2PCI-64

+5V Present D1 D12 D1
+12V Present D3 D11 D3

-12V Present D5 D9 D5
VIO Present D7 D18 D7
+3.3V Present D12 D13 D12
+12V Problem D4 D15 D4

-12V Problem D6 D10 D6
VIO Problem D8 N/A D8
+5V Problem D9 D16 D9
+3.3V Problem D11 D14 D11
BUS MODE 1 N/A N/A D20

8

JUMPER TABLE

JUMPER Function PCI532/PCI332 PCIX6432/PCIX6466-3 PMC2PCI-64
Isolate +5V JP6 JP6 JP6
Isolate +12V JP4 JP4 JP4
Isolate +3.3V JP7 JP7 (Change source)* JP7
Isolate –12V JP5 JP5 JP5
Isolate VIO JP10 JP10 JP10
Change +5V Current
Limit to 1A
+5V Current
Measurement
+12V Current
Measurement
+3.3V Current
Measurement
External Control JP3 JP3 JP3
5V=> 3V Signal
Level Conversion
BUS MODE N/A N/A JPN2, JPN3, JPN4
AUX3.3 N/A JP12 N/A
PME N/A JP11 N/A

JP8 JP8 JP8

J3 J3 J3

N/A J4 J4

N/A J5 J5

N/A JP9 JPX

AUXILIARY POWER CONNECTOR PIN-OUT

PCI532 and PCI332 power connector for the external power supply is different than the one used for
PMC2PCI and PCIX-6432. The PCI532 connector is marked as indicated, but the other connectors are
intended for use with ribbon cable and are not marked on the board. The following pin-out can be used if the
user wants to arrange his own interface. Please note that each signals is divided and placed symmetrically on
both sides of the connector, this will allow the connector to be plugged in either direction and make proper
connection.

SIGNAL PIN SIGNAL

+5EV 1 2 +5EV
+5EV 3 4 +5EV
+5VS 5 6 +3VS
+3EV 7 8 +3EV

+12VS 9 10 -12EV

N.U. 11 12 SW

-12EV 13 14 +12EV
SW 15 16 N.U.

-12EV 17 18 +12VS

+3EV 19 20 +3EV
+3VS 21 22 +5VS
+5EV 23 24 +5EV
+5EV 25 26 +5EV

The EV signals are the voltage signals, remember not to bring in any external voltages until you reconfigure
the jumpers for external supply mode. The VS signals are sense signals for compensating any voltage lose in
the cable. The SW is an open collector signal and it is the sane as the switch or jumper JP3 to turn the board
on and off.

9

SPECIFICATIONS: PCI532 & PCI332

Bus:

PCI-332, 32-bit PCI, 3V and universal.

Voltages:

Inputs From PC bus or the external input, configurable by jumpers per voltage.

Input Requirement 5V @ 20 mA, +/- 12V @ 50 mA

Output Ratings +5V, Jumper selectable to 5 Amp or 1 Amp limit, higher than 5 Amp

Drop Across the Switches 40 millivolts drop for every 1 Amp drawn for +5V, +3.3V and +VIO

Propagation Delay:

Controls:

On-Off SPST switch on-board or the external logic input (system parallel port).

Bus Signals Bus signals can be turned on all at once or selectively groups of 10 via the

Outputs:

J3 +5V current draw by the UUT can be measured at a two-point terminal, J3,

JP1 JP1-1 to JP1-59, all odd pins on the B side, 100 mil centers.
JP1 JP1-2 to JP1-60, all even pins on the B side, 100 mil centers.
JP2 JP2-1 to JP2-59, all odd pins on the A side, 100 mil centers.
JP2 JP2-2 to JP2-60, all even pins on the A side, 100 mil centers.

NOTE: The signals at JP1 and JP2 are active when the extender power is on and tri-Stated when the

power is off.

Mechanical Dimensions:

Height 1.6 inches; This dimension is kept less than 2 inches to assure this product is

Length 9.6 inches

PCI-532, 32-bit PCI, 5V and universal.

current limit can be accommodated per user request.
+3.3V, +VIO and +/- 12V at 1 Amp.

30 millivolts drop for every 1 Amp drawn for -12V.
30 millivolts drop for every 100 milliampere drawn for +12V

Less than 500 pico-seconds from the PC bus to the UUT.
The switch propagation delay is rated at only 250 pico-seconds.

dip switch or an external I/O control.

by a voltmeter. Each volt represents 1 Amp.

in compliance with PCI Rev. 2 specifications.

10

SPECIFICATIONS: PCIX6432-5, PCIX6466-3

Bus:
Voltages:

Inputs From PC bus, an external power supply, configurable by jumpers.

Input Requirements 5V @ 20 mA, +/- 12V @ 50 mA

Output Ratings +5V, Jumper selectable to 5 Amp or 1 Amp limit.

Drop Across the Switches 40 millivolts drop for every 1 Amp drawn for +5V, +3.3V and +VIO.
30 millivolts drop for every 1 Amp drawn for -12V.
30 millivolts drop for every 100 milliampere drawn for +12V.

Propagation Delay:

Controls:

On-Off SPST switch on-board or external logic input

Bus Signals Bus signals can be turned on all at once or selectively in groups, via the dip

Outputs:

J3.2 (J3 for Rev C and below) +5V current measurement, each Volt represents 1 Amp.

J3.4 (J4 for Rev C and below) +12V current measurement, each Volt represents 1 Amp.

J3.3 (J5 for Rev C and below) +3.3V current measurement, each Volt represents 1 Amp.

JP1 JP1-1 to JP1-32, all pins on the B side, 64-bit extension, 100 mil centers.

JP2 JP2-1 to JP2-32, all pins on the A side, 64-bit extension, 100 mil centers.

JP13 JP13-1 to JP13-62, all pins on the B side, 32-bit main bus, 100 mil centers.

JP14 JP14-1 to JP14-62, all pins on the A side, 32-bit main bus, 100 mil centers.

NOTE: The signals at JP1, JP2, JP3 and JP4 are active when the extender power is on, and

tri-stated when the power is off.

Mechanical Dimensions:

Height 1.6 inches
Length 9.6 inches

PCIX6432-5; PCI, 32-bit or 64-bit, 5 Volt and Universal, 33 Mhz.
PCIX6466-3; PCI, 32-bit or 64-bit, 3 Volt and Universal, 66 Mhz.

+3.3V at 2.5 Amp.
+/- 12V at 1 Amp.

Less than 500 pico-seconds from the PC bus to the UUT.
The switch propagation delay is rated at only 250 pico-seconds.

switch or an external I/O control.

11

SPECIFICATIONS: PMC2PCI-64

Input Bus:
Output Bus:
Voltage:

Inputs 5V @ 20 mA, +/- 12V @ 50 mA

Output Ratings +5V, Jumper selectable to 5 Amp or 1 Amp limit.
+3.3V at 2.5 Amp.
+/- 12V at 1 Amp.

Drop Across the Switches 40 millivolts drop for every 1 Amp drawn for +5V, +3.3V and +VIO
30 millivolts drop for every 1 Amp drawn for -12V.
30 millivolts drop for every 100 milliampere drawn for +12V.

Propagation Delay: Less than 500 picoseconds from the system bus to the Mezzanine board.

Controls:

On-Off SPST switch on-board or the external logic input.

Bus Signals Bus signals can be turned on all at once or selectively in groups, via the dip

Outputs:

J3 +5V current measurement, each Volt represents 1 Amp.
J4 +12V current measurement, each Volt represents 1 Amp.
J5 +3.3V current measurement, each Volt represents 1 Amp.

JP14 JP14-1 to JP14-32, all pins on the B side, 64-bit extension.
JP13 JP13-1 to JP13-32, all pins on the A side, 64-bit extension.
JP1 JP1-1 to JP1-62, all pins on the B side, 32-bit main bus.
JP2 JP2-1 to JP2-62, all pins on the A side, 32-bit main bus.

NOTE: The signals at JP1, JP2, JP13 and JP14 are active when the extender power is on and tri-

stated when the power is off.

Mechanical Dimensions:

Height 2.2 inches
Length 9.6 inches

PCI, 32 or 64-bit.

PMC, PCI Mezzanine cards, 32 or 64-bit.

switch or an external I/O control.

12

AUXILIARY PINOUT

MAIN, 32 BIT SIGNALS

JP2 FOR SIDE A

Controlling Switch Signal Name Header Pin Header Pin Signal Name Controlling Switch

N/A +12BV 2 1 TRST#B S2-5
S2-5 TDIB 4 3 TMSB S2-5
S2-5 INTA#B 6 5 +5BV N/A
N/A +5BV 8 7 INTC#B S2-5
N/A +VIOB 10 9 RES71B S2-5
N/A 12 11 RES73B S2-1
S2-5 RES76B 14 13 N/A
N/A +VIOB 16 15 RST#B N/A
N/A GND 18 17 GNT#B S2-6
S2-6 AD30B 20 19 RES81B S2-6
S2-6 AD28B 22 21 +3.3VB N/A
N/A GND 24 23 AD26B S2-6
S2-6 IDSELB 26 25 AD24B S2-6
S2-6 AD22B 28 27 +3.3VB N/A
N/A GND 30 29 AD20B S2-6
S2-7 AD16B 32 31 AD18B S2-7
S2-7 FRAME#B 34 33 +3.3VB N/A
S2-7 TRDY#B 36 35 GND N/A
S2-7 STOP#B 38 37 GND N/A
S2-7 SDONEB 40 39 +3.3VB N/A
N/A GND 42 41 SBO#B S2-7
S2-7 AD15B 44 43 PARB S2-8
S2-8 AD13B 46 45 +3.3VB N/A
N/A GND 48 47 AD11B S2-8
N/A 50 49 AD09B S2-8
S2-8 CBE0#B 52 51 N/A
S2-8 AD06B 54 53 +3.3VB N/A
N/A GND 56 55 AD04B S2-8
S2-8 AD00B 58 57 AD02B S2-8
S2-8 REQ64#B 60 59 +VIOB N/A
N/A +5BV 62 61 +5VB N/A

TABLE 1

13

Controlling Switch

Signal Name

Header Pin

Header Pin

Signal Name

Controlling Switch

JP1 FOR SIDE B

S2-1 TCKB 2 1 -12BV N/A
S2-1 TDOB 4 3 GND N/A
N/A +5BV 6 5 +5BV N/A
S2-1 INTD#B 8 7 INTB#B S2-1
S2-1 RES10B 10 9 PRSNT1#B S2-1
N/A 12 11 PRSNT2#B S2-1
S2-1 RES14B 14 13 N/A
S2-1 CLKB 16 15 GND N/A
S2-2 REQ#B 18 17 GND N/A
S2-2 AD31B 20 19 +VIOB N/A
N/A GND 22 21 AD29B S2-2
S2-2 AD25B 24 23 AD27B S2-2
S2-2 CBE3#B 26 25 +3.3VB N/A
N/A GND 28 27 AD23B S2-2
S2-2 AD19B 30 29 AD21B S2-2
S2-3 AD17B 32 31 +3.3VB N/A
N/A GND 34 33 CBE2#B S2-3
N/A +3.3VB 36 35 IRDY#B S2-3
N/A GND 38 37 DEVSEL#B S2-3
S2-3 PERR#B 40 39 LOCK#B S2-3
S2-3 SERR#B 42 41 +3.3VB N/A
S2-3 CBE1#B 44 43 +3.3VB N/A
N/A GND 46 45 AD14B S2-3
S2-4 AD10B 48 47 AD12B S2-4
N/A 50 49 M66ENB S2-4
S2-4 AD08 52 51 N/A
N/A +3.3VB 54 53 AD07B S2-4
S2-4 AD03B 56 55 AD05B S2-4
S2-4 AD01B 58 57 GND N/A
S2-4 ACK64#B 60 59 +VIOB N/A
N/A +5BV 62 61 +5VB N/A

TABLE 2

14

Controlling S

witch

Signal Name

Header Pin

Header Pin

Signal Name

Controlling Switch

Controlling Switch

Signal Name

Header Pin

Header Pin

Signal Name

Controlling Switch

EXTENSION, 64 BIT SIGNALS

S2-9 RES1B 1 2 GND N/A
S2-9 CBE6#B 3 4 CBE4#B S2-9
N/A GND 5 6 AD63B S2-9
S2-9 AD61B 7 8 +VIOB N/A
S2-9 AD59B 9 10 AD57B S2-9
N/A GND 11 12 AD55B S2-9
S2-9 AD53B 13 14 GND N/A
S2-9 AD51B 15 16 AD49B S2-9
N/A +VIOB 17 18 AD47B S2-9
S2-9 AD45B 19 20 GND N/A
S2-9 AD43B 21 22 AD41B S2-9
N/A GND 23 24 AD39B S2-9
S2-9 AD37B 25 26 +VIOB N/A
S2-9 AD35B 27 28 AD33B S2-9
N/A GND 29 30 RES2B S2-9
N/A 31 32 GND N/A

JP13 FOR SIDE B

TABLE 3

JP14 FOR SIDE A

N/A GND 1 2 CBE7#B S2-10
S2-10 CBE5#B 3 4 +VIOB N/A
S2-10 PAR64B 5 6 AD52B S2-10
N/A GND 7 8 AD60B S2-10
S2-10 AD58B 9 10 GND N/A
S2-10 AD56B 11 12 AD54B S2-10
N/A +VIOB 13 14 AD52B S2-10
S2-10 AD50B 15 16 GND N/A
S2-10 AD48B 17 18 AD46B S2-10
N/A GND 19 20 AD44B S2-10
S2-10 AD42B 21 22 +VIOB N/A
S2-10 AD40B 23 24 AD38B S2-10
N/A GND 25 26 AD36B S2-10
S2-10 AD34B 27 28 GND N/A
S2-10 AD32B 29 30 RES5B S2-10
N/A GND 31 32 N/A

TABLE 4

15

BOARD LAYOUT, PCI532 & PCI332

16

BOARD LAYOUT, PCIX6432-5 & PCIX6466-3

17

BOARD LAYOUT, PMC2PCI-64

18
