CONNECTING THE TRIMLINE II
Included with the TrimLine II are (one each):
• Handset • Coiled handset cord • User guide
• Base unit • 7-inch line cord
1) Located on the front of the TrimLine II (as the phone is facing
you) is a modular jack. Insert one end of the coiled handset cord
into this jack (you should hear the coil cord click when properly
inserted).
2) Insert the other end of the coiled handset cord into the modular
jack on the front of the handset.
3) Turn the telephone over so bottom is facing you. Insert either
end of the line cord into the jack on the bottom of the telephone.
4) Insert the other end of the line cord into a telephone wall outlet
jack.
SELECTING LINE 1 AND LINE 2
The TrimLine II utilizes mechanically latching line keys. To select a
line, press either key firmly until it is engaged.
PLACING A CALL
1) If a line is not selected, press the desired line key.
2) Lift the handset.
3) Listen for dial tone. Dial the desired number.
4) To end the call, hang up by placing the handset back in the cradle.
RECEIVING A CALL
An audible ring and flickering red Message Waiting Light will indicate an inbound call.
1) If the line key associated with the flickering LED is not
depressed, engage it.
2) Lift the handset.
3) To end the call hang up the handset.
INITIATING A NEW CALL
The TrimLine is equipped with a hook switch on the handset to facilitate new calls without having to return the handset to the base. To initiate a new call, simply depress the TELEDEX key on the handset.
REDIAL
To REDIAL the last telephone number dialed:
1) If a line is not selected, press the desired line key.
2) Lift the handset from the cradle.
3) Press the REDIAL key.
ADJUSTING THE RING VOLUME
Locate the “Line Ringing Volume” adjustment control on the back
of the telephone labeled RINGER LOW/HI (see diagram). Slide the
switch to the desired LOW or HI ring volume for each line.
ADJUSTING THE HANDSET VOLUME
The HANDSET VOLUME feature has two levels. When the handset
is first lifted, the handset volume is NORMAL.
Locate the VOL key below the keypad on the handset. Press the key
once and the volume level will increase to HIGH level. To return the
handset volume to NORMAL, press the handset volume key again.
The handset volume will always return to NORMAL when the
handset is returned to the cradle.
USING THE HOLD KEY
The HOLD key places the call on hold locally at the TrimLine II telephone.
TO PLACE A CALL ON HOLD
1) With a call active press the red HOLD key.
2) The red line LED will change from a solid green to solid red to a
indicating the call is on hold.
TO REMOVE A CALL ON HOLD
1) Press the line key of the call on hold. This will remove the call
from hold making the call active on the handset.
2) The red line LED will change to the green in-use condition
indication.
MUTE KEY
The TrimLine has a momentary mute key on the handset. To mute
microphone, press and hold the MUTE key. To resume speaking, simply release the key.
FLASH KEY
Pressing the FLASH key initiates a 600ms hookflash. Typical usage is
to access PBX features like call waiting.
MESSAGE WAITING LIGHT (optional)
The raised red lens is a message waiting light. Many telephone systems
turn on the red message waiting light to alert the user that there is a
message waiting.
BACKLIT KEYPAD
The Trimline II has a backlit keypad for easy of use in a dark environment. The backlighting is automatically turned on when the telephone is taken off hook.
DATA PORT
The TrimLine II is equipped with a standard RJ-11 data port on the
right side of the phone.
WALL MOUNTING
The TrimLine II can be easily wall mounted by simply placing it over
any standard wall mounting plate and pressing down.
RMA PROCEDURES
The following procedure should be followed with all Teledex
telephone products prior to sending the telephone to the factory
for repair.
1) Please perform the tests listed below:
a. Test the telephone on a different telephone jack.
b. Test telephone with a different line cord.
c. Test with a different handset cord (coiled cord).
d. For two line products, please ensure that one of the line
buttons is pressed (if both line buttons are in the UP position,
the telephone will not operate).
2) If the steps listed above do not provide a remedy for the suspect
telephone, please place a tag on the individual telephone
describing the defect. Next, call the Teledex Repair Department
at 1 (800) 875-8539 for an RMA number. You must have an
RMA number to return products to Teledex.
3) Kindly note: An RMA number is unique to each return
shipment. Do not duplicate this number on any future shipments.
SHIPPING INSTRUCTIONS:
Please print the RMA number clearly on the outside of your shipping
carton(s). Please ship to the following address:
Teledex LLC / RMA#___________
6311 San Ignacio Avenue
San Jose, CA 95119
FREIGHT CHARGES:
The Customer is responsible for shipping products for repair to
Teledex. After repair, Teledex will return telephone products to the
Customer freight prepaid in the same manner in which is was sent
(i.e. Freight sent to Teledex UPS Blue, will be returned via 2 day shipping).
**Please note: When telephones are returned for repair due to misuse
(i.e. liquid spills, abuse, or Customer modification - warranty label
broken), the Customer will be charged the standard repair fee, regardless of warranty status.
REQUIREMENTS OF PART 68 - FCC RULES
This device has been granted a registration number by the Federal Communications Commission,
under Part 68 rules and regulations for direct connection to the telephone lines. In order to comply
with these FCC rules, the following instructions must be carefully read and applicable portions followed completely:
1. Direct connection to the telephone lines may be made only through the standard modular cord
furnished, to the utility installed jack. No connection may be made to party or coin phone lines.
On the bottom of the phone is a label that contains among other information, the FCC
TRIMLINE II
GUESTROOM TELEPHONE
USERS GUIDE
Registration Number and the Ringer Equivalence number (REN) for this equipment. If requested
this information must be provided to the telephone company. The USOC Jack for this equipment
is RJ11C.
2. The telephone company, under certain circumstances, may temporarily discontinue and make
changes in facilities and services which may affect the operation of the users' equipment: however, the user shall be given adequate notice in writing to allow the user to maintain uninterrupted
service.
3. In certain circumstances, it may be necessary for the telephone company to request information
from you concerning the equipment which you have connected to your telephone line. Upon
request of the telephone company, provide the FCC registration number and the ringer equivalence number of the equipment which is connected to your line; this information will be found on
the device.
4. If any of your telephone equipment is not operating properly, you should immediately remove it
from the telephone line. It may cause harm to the telephone network.
5. If the telephone company notes a problem, they may temporarily discontinue service. When practical, they will notify you in advance disconnection. If advance notice is not feasible, the telephone
company must; promptly notify you of such temporary discontinuance; afford the opportunity to
correct the condition; inform you of your rights to bring a complaint to the FCC under their rules.
6. Repairs to the device may be made only by the manufacturer or an authorized service agency.
This applies at any time during and after warranty. If unauthorized repair is performed, registration, connection to the telephone lines and remainder of warranty period all become null and void.
7. This equipment is hearing aid compatible.
8. This telephone must be connected behind a PBX.
REQUIREMENTS OF PART 15 - FCC RULES
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance with the instruction,
may cause harmful interference to radio communications. However, there is not a guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following measures: Move the telephone away from the receiver. -Consult the dealer or an experienced radio/TV technician for help. Any changes made by the user not approved by the manufacturer can void the user's
authority to operate the telephone.
INDUSTRY OF CANADA REQUIREMENTS
NOTICE: The Industry Canada label identifies certified equipment. This certification means that the
equipment meets certain telecommunications network protective operational and safety requirements
as prescribed in the appropriate Terminal Equipment Technical Requirements documents. The
department does not guarantee the equipment will operate to the users satisfaction.
Before installing this equipment, users should ensure that it is permissible to be connected to the
facilities of the local telecommunications company. The equipment must also be installed using an
acceptable method of connection.
The customer should be aware that compliance with the above conditions may not prevent degradation of service in some situations.
Repairs to certified equipment should be coordinated by a representative designated by the supplier.
Any repairs or alterations made by the user to this equipment, or equipment malfunctions, may give
the telecommunications company cause to request the user to disconnect the equipment.
Users should ensure for their own protection that the electrical ground connections of the power utility, telephone lines, and internal metallic water pipe systems, if present, are connected together. This
precaustion may be particularly important in rural areas.
Caution: Users should not attempt to make such connections themselves, but should contact the
appropriate electric inspection authority or electrician, as appropriate.
The Ringer Equivalence Number (REN) of this device is Z.
Notice: The Ringer Equivalence Number (REN) assigned to each terminal device provides an indica-
tion of the maximum number of terminals allowed to be connected to a telephone interface. The termination on an interface may consist of any combination of devices subject only to the requirement
that the sum of the Ringer Equivalence Numbers of all the devices does not exceed 5. This telephone connects to the telephone network under the connecting arrangement code CA11A.
IMPORTANT SAFETY INSTRUCTIONS
WHEN USING YOUR TELEPHONE EQUIPMENT, BASIC SAFETY PRECAUTIONS SHOULD
ALWAYS BE FOLLOWED TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK AND INJURY TO
PERSONS. INCLUDING THE FOLLOWING:
1. READ AND UNDERSTAND ALL INSTRUCTIONS.
2. FOLLOW ALLWARNINGS AND INSTRUCTIONS MARKED ON THE PRODUCT.
3. UNPLUG THE PRODUCTFROM THE WALLOUTLETBEFORE CLEANING. DO NOT USE
LIQUID CLEANER OR AEROSOLCLEANERS. USE ADAMPCLOTH FOR CLEANING.
4. DO NOTUSE THIS PRODUCT NEAR WATER FOR EXAMPLE NEAR A BATHTUB, WASH
BOWL, KITCHEN SINK OR LAUNDRY TUB, IN AWETBASEMENT, OR NEAR ASWIMMING
POOL.
5. DO NOTPLACE THIS PRODUCT ON AN UNSTABLE CART, STAND OR TABLE. THE PRODUCT MAY FALL, CAUSING SERIOUS DAMAGE TO THE PRODUCT.
6. SLOTS AND OPENINGS IN THE CABINETAND THE BACK OF BOTTOM ARE PROVIDED
FOR VENTILATION, TO PROTECTITFROM OVERHEATING, THESE OPENINGS MUST
NOT BE BLOCKED OR COVERED. THE OPENINGS SHOULD NEVER BE BLOCKED BY
PLACING THE PRODUCT ON THE BED, SOFA, RUG OR ANYOTHER SIMILAR SURFACE.
THIS PRODUCT SHOULD NEVER BE PLACED NEAR OR OVER ARADIATOR OR HEAT
REGISTER. THIS PRODUCT SHOULD NOT BE PLACED IN A BUILT-IN INSTALLATION
UNLESS PROPER VENTILATION IS PROVIDED.
7. NEVER PUSH OBJECTS OF ANYKIND INTO THIS PRODUCTTHROUGH CABINETSLOTS
AS THEY MAYTOUCH DANGEROUS VOLTAGE POINTS OR SHORTOUTPARTS THAT
COULD RESULTIN ARISK OF FIRE OR ELECTRIC SHOCK. NEVER SPILLLIQUID OF ANY
KIND ON THE PRODUCT.
8. TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT DISASSEMBLE THIS PRODUCT
BUT TAKE ITTO AQUALIFIED SERVICEMEN WHEN SOME SERVICE OR REPAIR WORK
IS REQUIRED. OPENING OR REMOVING COVERS MAYEXPOSE YOU TO DANGEROUS
VOLTAGES OR OTHER RISKS. INCORRECT REASSEMBLE CAN CAUSE ELECTRIC
SHOCK WHEN THE APPLIANCE IS SUBSEQUENTLY USED.
9. UNPLUG THIS PRODUCTFROM THE WALLOUTLETAND REFER SERVICING TO QUALIFIED SERVICE PERSONNEL UNDER THE FOLLOWING CONDITIONS.
· WHEN THE POWER SUPPLY CORD OR PLUG IS DAMAGED OR FRAYED
· IF LIQUID HAS BEEN SPILLED INTO THE PRODUCT.
· IF THE PRODUCT HAS BEEN EXPOSED TO RAIN OR WATER.
· IF THE PRODUCT DOES NOT OPERATE NORMALLY BY FOLLOWING THE OPERATING
INSTRUCTIONS. ADJUSTONLYTHOSE CONTROLS THAT ARE COVERED BY THE
OPERATING INSTRUCTIONS BECAUSE IMPROPER ADJUSTMENT OF OTHER CONTROLS MAYRESULTIN DAMAGE AND WILL OFTEN REQUIRE EXTENSIVE WORK BY A
QUALIFIED TECHNICIAN TO RESTORE THE PRODUCT TO NORMAL OPERATION.
· IF THE PRODUCT HAS BEEN DROPPED OR THE CABINET HAS BEEN DAMAGED.
· IF THE PRODUCT EXHIBITADISTINCT CHANGE IN PERFORMANCE.
10. AVOID USING ATELEPHONE (OTHER THAN ACORDLESS TYPE) DURING AN ELECTRICAL STORM. THERE MAYBE AREMOTE RISK OF ELECTRIC SHOCK FROM LIGHTING.
11. DO NOT USE THE TELEPHONE TO REPORTAGAS LEAK IN THE VICINITYOF THE LEAK.
SAVE THESE INSTRUCTIONS
TELEDEX TRIMLINE II DIAGRAM
RING VOLUME
Adjusts the ringer volume
to Low or High setting
.
DATA PORT
LINE 1 KEY
LINE 2 KEY
HOLD KEY
HANDSET VOLUME KEY
Changes handset volume by
pressing repeatedly.
REDIAL KEY
To automatically redial
last number dialed
MESSAGE WAITING LIGHT (optional)
Signals that a message is waiting for retrieval.
See your system administrator for instructions
on retrieving messages.
HEARING AID COMPATIBLE HANDSET
DIAL KEYS (DTMF PAD)
For dialing phone numbers.
FOR CUSTOMER SERVICE CALL
1-800-783-8353
Teledex, LLC
6311 San Ignacio Avenue
San Jose, CA
95119
Telephone: (408) 363-3100
Fax: (408) 363-3136
email: sales@teledex.com
Internet: www.teledex.com
LED Red/Flashing = Ringing Line
LED Red/solid = Line on HOLD
LED Green = Active Line
Part Number 606-2520-00A
FLASH KEY
For programming of FLASH duration.
See instructions for programming details.
HOOK SWITCH
MUTE KEY
Deactivates handset/speakerphone
microphone for privacy during calls.
Loading...
