OPAL 1010S
The Teledex one-line
speakerphone specifically
designed for the international
hospitality industry.
MANUAL
OWNER’S
INCLUDED IN YOUR P ACKAGE
Handset Base Unit Coiled Handset Cord
Line Cord Clear Plastic Overlay User Guide
CONNECTING THE OPAL 1010S
1. Located on the left side of the Opal 1010S (as the phone is facing you) is
a modular jack. Insert one end of the coiled handset cord into this jack (you
should hear the coil cord click when properly inserted).
2. Insert the other end of the coiled handset cord into the modular jack on
the handset.
3. Turn the telephone so the back panel is facing you. Insert either end of
the line cord into the jack on the back of the telephone labeled LINE.
4. Insert the other end of the line cord into a telephone wall outlet jack.
5. Once your telephone is connected, remove the plastic overlay and place
the paper faceplate over the keys. Replace the plastic overlay by hooking the
tabs on the overlay into the recessed slots located on both sides. The overlay
is easiest to insert when; the left or right side tabs are inserted first, and the
middle of the overlay is slightly bowed to allow for insertion of the other
tabs.
PLACING A CALL
USING THE HANDSET
1. Lift the handset.
2. Listen for dial tone. Dial the desired number, or press an AUTO DIAL key
to automatically dial a number.
3. To end the call, hang up by placing the handset back in the cradle.
USING THE SPEAKERPHONE
1. With the handset in the cradle, press the SPEAKER key. The Opal will
engage the open line.
NOTE: The red SPEAKER LED will indicate that the speakerphone is active.
2. Listen for dial tone, dial the desired number, or press an AUTO DIAL key
to automatically dial a number.
3. To end call the call press the SPEAKER key again.
RECEIVING A CALL
An audible ring and flickering red LED indicate an inbound call.
USING THE HANDSET
1. Lift the handset. The Opal will select the ringing line.
2. To end the call hang up the handset.
1
USING THE SPEAKERPHONE
With the handset in the cradle, press the SPEAKER key. The Opal will
select the ringing line and answer with the speakerphone active.
Note: The red SPEAKER LED will indicate that the speakerphone is active.
ADJUSTING SPEAKERPHONE VOLUME
Locate the slide switch (labeled SPKR VOL) on the right side of the telephone.
To increase speaker volume, slide the switch towards the back of the telephone.
To decrease speaker volume, slide the switch towards the front of the telephone.
ADJUSTING THE RING VOLUME
Locate the adjustment control on the back of the telephone labeled RINGER
LOW/HI (see diagram on page 6). Slide the switch to the desired LOW or HI
ring volume.
SPEAKERPHONE TIPS
TO ACTIVATE THE HANDSET FROM SPEAKERPHONE MODE:
1. Lift the handset from the cradle.
2. The red SPEAKER LED will go out.
TO ACTIVATE THE SPEAKERPHONE FROM HANDSET MODE:
1. Press the SPEAKER key.
2. The red SPEAKER LED will indicate speakerphone selection.
3. Place the handset back into the cradle.
USING THE HOLD KEY
The HOLD key places the call on hold locally at the Opal telephone.
TO PLACE A CALL ON HOLD
1. With a call active press the red HOLD key.
2. The red line LED will change to a slow blink indicating the call is on
hold.
TO REMOVE A CALL FROM HOLD
1. Lift the handset from the cradel. This will remove the call from hold
making the call active on the handset.
OR
With the handset in the cradle, press the SPEAKERPHONE key. This will
remove the call from hold making the call activate the speakerphone.
2. The red line LED will return to steady in-use condition.
2
TO CHANGE PHONES AFTER PLACING A CALL ON HOLD
1. Place the call on hold at the Opal.
2. Pickup the call at another telephone. The Opal will detect the pickup and
remove the hold condition at the original Opal.
TO MUTE SPEAKERPHONE AND HANDSET CALLS
1. Press the MUTE key, the red LED below the MUTE key will light. The
party on the other end will not hear you when the MUTE key is depressed.
2. Press the MUTE key again to turn off the mute feature, the MUTE LED will
go out.
REDIAL
TO REDIAL THE LAST TELEPHONE NUMBER DIALED:
1. Lift the handset from the cradle, or press the SPEAKERPHONE key.
2. Press the REDIAL key.
NOTE: Some PBX’s require a pause after the first digit to access an outside
line. The REDIAL function will automatically insert a pause if the dialed
number is 7 digits or more. The inserted pause will be of the same duration
as set in the pause timing.
FLASH
The Flash key, when programmed behind an autodial key provides a timed
line interrupt typically used for accessing PBX/CO features like transfer and
conference. The timing of the hookflash is programmable with the factory
default timing set to 600 milliseconds. Some PBX’s may require you to
change the hookflash timing from the default to 600ms.To change the
hookflash timing;
1. Lift the handset.
2. Press the STORE key (see diagram on page 6 for key location).
3. Press the FLASH key (see diagram on page 6 for key location).
4. Select 1 - 9 on the DTMF pad. The number selected will be the new flash
timing in milliseconds (ie: “3” = 300 milliseconds).
5. Press the STORE key.
ADJUSTING THE HANDSET VOLUME
The HANDSET VOLUME key has three levels. When the handset is first
lifted, the handset volume is NORMAL.
Locate the HANDSET VOLUME key below the keypad. Press the key
once and the volume level will increase one level (to MEDIUM volume).
Press the key once more and the volume level will increase an additional
level (to HIGH volume). To return the handset volume to NORMAL, press
the handset volume key again. The handset volume will always return to
NORMAL when the handset is returned to the cradle.
3
PAUSE KEY
The Pause key, when programmed behind an autodial key can be used to
provide a timed pause between dialed digits within an autodial key. The
timing of the pause is programmable with the factory default set to zero (0)
seconds. To change the pause timing;
1. Lift the handset.
2. Press the STORE key (see diagram on page 6 for key location).
3. Press the PAUSE key (see diagram on page 6 for key location).
4. Select 1 - 9 on the DTMF pad. The number selected will be the new pause
timing in seconds (ie: “3” = 3 seconds).
5. Press the STORE key.
AUTO DIAL KEYS
The Opal 1010S has ten (10) programmable AUTO DIAL keys. These keys
can be programmed to automatically dial telephone numbers, or activate
telephone system features.
PROGRAMMING AUTO DIAL KEYS:
The telephone must be connected to a telephone line.
1. Remove the plastic overlay.
2. Lift the handset from the cradle or press the SPEAKERPHONE key.
3. Press the recessed STORE key and release it. (Please see diagram on page
6 for key location).
4. Enter the telephone number including PAUSE* as required. The sequence
can be up to 15 digits.
5. Press the AUTO DIAL key where the number is to be stored.
6. Place the handset back in the cradle or press the SPEAKERPHONE key to
disconnect.
4
CONVERTING FROM DESK TO WALL MOUNT
The Opal 1010S can be changed for wall mounting applications. The conversion is easiest when the handset and line cords are not connected.
1. Located on the top of the telephone above the speaker grill is the wall/
desk mount clip. Remove this clip by firmly pushing upward (towards the
hookswitch).
2. Flip the clip over (top to bottom) so that the protruding edge is towards
the top of the phone. This edge will hold the handset.
3. Turn the Opal 1010S over so the bottom is up facing you. Place the Opal
on a nonabrasive surface to prevent scratching.
4. Locate and remove the mounting bracket, firmly push back and pull up to
remove two of the four retaining tabs.
5. Rotate the mounting bracket 180 degrees clockwise so that the mounting
eyelet on the bracket is facing in the same direction as the other mounting
eyelet located on the bottom of the telephone.
6. Insert the top two retaining tabs of the mounting brackets into the mounting bracket slots (located near the middle of the telephone). Then firmly push
down to insert the retaining tabs on the opposite side of the mounting
bracket.
7. Connect a short modular line cord into the jack on the back of the phone
(labeled LINE). Route the line cord through the line cord channel. Connect
the other end of line cord to the phone jack on the wall mounting plate.
8. Turn the telephone over, and slide the Opal 1010S down onto the mounting posts in downward direction. Both eyelets should line up with the
mounting posts.
9. Complete the wall mounting by installing the handset and handset cord.
5
OPAL 1010S DIAGRAM
MESSAGE WAITING LIGHT
RING VOLUME
MODULAR PHONE
LINE JACK
DATA PORT
FLASH KEY
(RECESSED)
STORE KEY
(RECESSED)
SPEAKER VOLUME
AUTO DIAL KEYS
AUTO DIAL KEYS
HANDSET
VOLUME
REDIAL
SPEAKER PHONEHOLD
MUTE
6
REQUIREMENTS OF PAR T 68 - FCC RULES
This device has been granted a registration number by the Federal Communications Commission, under Part 68
rules and regulations for direct connection to the telephone lines. In order to comply with these FCC rules, the
following instructions must be carefully read and applicable portions followed completely:
1. Direct connection to the telephone lines may be made only through the standard modular cord furnished, to the
utility installed jack. No connection may be made to party or coin phone lines. On the bottom of the phone is a
label that contains among other information, the FCC Registration Number and the Ringer Equivalence number
(REN) for this equipment. If requested this information must be provided to the telephone company. The USOC
Jack for this equipment is RJ11C.
2. The telephone company, under certain circumstances, may temporarily discontinue and make changes in
facilities and services which may affect the operation of the users' equipment: however, the user shall be given
adequate notice in writing to allow the user to maintain uninterrupted service.
3. In certain circumstances, it may be necessary for the telephone company to request information from you
concerning the equipment which you have connected to your telephone line. Upon request of the telephone
company, provide the FCC registration number and the ringer equivalence number of the equipment which is
connected to your line; this information will be found on the device.
4. If any of your telephone equipment is not operating properly, you should immediately remove it from the
telephone line. It may cause harm to the telephone network.
5. If the telephone company notes a problem, they may temporarily discontinue service. When practical, they will
notify you in advance disconnection. If advance notice is not feasible, the telephone company must; promptly
notify you of such temporary discontinuance; afford the opportunity to correct the condition; inform you of your
rights to bring a complaint to the FCC under their rules.
6. Repairs to the device may be made only by the manufacturer or an authorized service agency. This applies at any
time during and after warranty. If unauthorized repair is performed, registration, connection to the telephone lines
and remainder of warranty period all become null and void.
7. This equipment is hearing aid compatible.
8. This telephone must be connected behind a PBX.
REQUIREMENTS OF PAR T 15 - FCC RULES
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instruction, may cause harmful interference to radio
communications. However, there is not a guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures: -Move the telephone away from the receiver. -Consult the dealer or an experienced radio/TV
technician for help. Any changes made by the user not approved by the manufacturer can void the user's authority
to operate the telephone.
INDUSTRY OF CANADA REQUIREMENTS
NOTICE: The Industry Canada label identifies certified equipment. This certification means that the equipment
meets certain telecommunications network protective operational and safety requirements as prescribed in the
appropriate Terminal Equipment Technical Requirements documents. The department does not guarantee the
equipment will operate to the users satisfaction.
Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the
local telecommunications company. The equipment must also be installed using an acceptable method of
connection.
The customer should be aware that compliance with the above conditions may not prevent degradation of service
in some situations.
Repairs to certified equipment should be coordinated by a representative designated by the supplier. Any repairs
or alterations made by the user to this equipment, or equipment malfunctions, may give the telecommunications
company cause to request the user to disconnect the equipment.
Users should ensure for their own protection that the electrical ground connections of the power utility,
telephone lines, and internal metallic water pipe systems, if present, are connected together. This precaustion may
be particularly important in rural areas.
Caution: Users should not attempt to make such connections themselves, but should contact the appropriate
electric inspection authority or electrician, as appropriate.
The Ringer Equivalence Number (REN) of this device is Z.
Notice: The Ringer Equivalence Number (REN) assigned to each terminal device provides an indication of the
maximum number of terminals allowed to be connected to a telephone interface. The termination on an interface
may consist of any combination of devices subject only to the requirement that the sum of the Ringer Equivalence
Numbers of all the devices does not exceed 5. This telephone connects to the telephone network under the
connecting arrangement code CA11A.
7
IMPORTANT SAFETY INSTRUCTIONS
WHEN USING YOUR TELEPHONE EQUIPMENT, BASIC SAFETY PRECAUTIONS SHOULD AL WAYS
BE FOLLOWED TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK AND INJURY TO PERSONS.
INCLUDING THE FOLLOWING:
1. READ AND UNDERST AND ALL INSTRUCTIONS.
2. FOLLOW ALL WARNINGS AND INSTRUCTIONS MARKED ON THE PRODUCT .
3. UNPLUG THE PRODUCT FROM THE WALL OUTLET BEFORE CLEANING. DO NOT USE LIQUID
CLEANER OR AEROSOL CLEANERS. USE A DAMP CLOTH FOR CLEANING.
4. DO NOT USE THIS PRODUCT NEAR WATER FOR EXAMPLE NEAR A BATHTUB, WASH BOWL,
KITCHEN SINK OR LAUNDR Y TUB, IN A WET BASEMENT, OR NEAR A SWIMMING POOL.
5. DO NOT PLACE THIS PRODUCT ON AN UNST ABLE CART, STAND OR TABLE. THE PRODUCT MAY
FALL, CAUSING SERIOUS DAMAGE TO THE PRODUCT .
6. SLOTS AND OPENINGS IN THE CABINET AND THE BACK OF BOTTOM ARE PROVIDED FOR
VENTILATION, TO PROTECT IT FROM OVERHEA TING, THESE OPENINGS MUST NOT BE BLOCKED
OR COVERED. THE OPENINGS SHOULD NEVER BE BLOCKED BY PLACING THE PRODUCT ON THE
BED, SOFA, RUG OR ANY OTHER SIMILAR SURF ACE. THIS PRODUCT SHOULD NEVER BE PLACED
NEAR OR OVER A RADIA TOR OR HEAT REGISTER. THIS PRODUCT SHOULD NOT BE PLACED IN A
BUILT-IN INST ALLATION UNLESS PROPER VENTILATION IS PROVIDED.
7. NEVER PUSH OBJECTS OF ANY KIND INTO THIS PRODUCT THROUGH CABINET SLOTS AS THEY
MAY TOUCH DANGEROUS VOL TAGE POINTS OR SHORT OUT PARTS THAT COULD RESULT IN A RISK
OF FIRE OR ELECTRIC SHOCK. NEVER SPILL LIQUID OF ANY KIND ON THE PRODUCT .
8. TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT DISASSEMBLE THIS PRODUCT BUT T AKE IT
TO A QUALIFIED SERVICEMEN WHEN SOME SERVICE OR REP AIR WORK IS REQUIRED. OPENING
OR REMOVING COVERS MAY EXPOSE YOU TO DANGEROUS VOL TAGES OR OTHER RISKS.
INCORRECT REASSEMBLE CAN CAUSE ELECTRIC SHOCK WHEN THE APPLIANCE IS SUBSEQUENTLY USED.
9. UNPLUG THIS PRODUCT FROM THE WALL OUTLET AND REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL UNDER THE FOLLOWING CONDITIONS.
· WHEN THE POWER SUPPL Y CORD OR PLUG IS DAMAGED OR FRAYED
· IF LIQUID HAS BEEN SPILLED INT O THE PRODUCT.
· IF THE PRODUCT HAS BEEN EXPOSED TO RAIN OR WATER.
· IF THE PRODUCT DOES NOT OPERATE NORMALL Y BY FOLLOWING THE OPERATING
INSTRUCTIONS. ADJUST ONL Y THOSE CONTROLS THAT ARE COVERED BY THE OPERATING
INSTRUCTIONS BECAUSE IMPROPER ADJUSTMENT OF OTHER CONTROLS MAY RESUL T IN
DAMAGE AND WILL OFTEN REQUIRE EXTENSIVE WORK BY A QUALIFIED TECHNICIAN TO
RESTORE THE PRODUCT TO NORMAL OPERATION.
· IF THE PRODUCT HAS BEEN DROPPED OR THE CABINET HAS BEEN DAMAGED.
· IF THE PRODUCT EXHIBIT A DISTINCT CHANGE IN PERFORMANCE.
10. AVOID USING A TELEPHONE (OTHER THAN A CORDLESS TYPE) DURING AN ELECTRICAL
STORM. THERE MAY BE A REMOTE RISK OF ELECTRIC SHOCK FROM LIGHTING.
11. DO NOT USE THE TELEPHONE TO REPORT A GAS LEAK IN THE VICINITY OF THE LEAK.
SAVE THESE INSTRUCTIONS
8
THANK YOU
FOR PURCHASING A TELEDEX PRODUCT!
Teledex Corporation, 6311 San Ignacio Avenue, San Jose, CA 95119
www.teledex.com For Customer Service Call +408-363-3100
Loading...
