Tektronix TMS708 Instruction Manual

Instruction Manual

TMS708 MSC8101 Microprocessor Software Support

071-1117-00

www.tektronix.com

Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this public ation supercedes that in all previously published material. Specifications and price c hange privileges reserved.

Tektronix, Inc., P.O. Box 500, Beaverton, OR 97077

TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.

SOFTWARE WARRANTY

Tektronix warrants that the media on which this software product is furnished and the encoding of the programs on the media will be free from defects in materials and workmanship for a period of three (3) months from the date of shipment. If a medium or encoding proves defective during the warranty period, Tektronix will provide a replacement in exchange for the defective medium. Except as to the media on which this software product is furnished, this software product is provided “as is” without warranty of any kind, either express or implied. Tektronix does not warrant that the functions contained in this software product will meet Customer’s requirements or that the operation of the programs will be uninterrupted or error-free.

In order to obtain service under this warranty, Customer must notify Tektronix of the defect before the expiration of the warranty period. If Tektronix is unable to provide a replacement that is free from defects in materials and workmanship within a reasonable time thereafter, Customer may terminate the license for this software product and return this software product and any associated materials for credit or refund.

THIS WARRANTY IS GIVEN BY TEKTRONIX IN LIEU OF ANY OTHER W ARRANTIES, EXPRESS OR IMPLIED. TEKTRONIX AND ITS VENDORS DISCLAIM ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. TEKTRONIX’ RESPONSIBILITY TO REPLACE DEFECTIVE MEDIA OR REFUND CUSTOMER’S PAYMENT IS THE SOLE AND EXCLUSIVE REMEDY PROVIDED TO THE CUSTOMER FOR BREACH OF THIS WARRANTY. TEKTRONIX AND ITS VENDORS WILL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF WHETHER TEKTRONIX OR THE VENDOR HAS ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.

Getting Started

Operating Basics

Preface vii...................................................

Manual Conventions vii..............................................

Contacting Tektronix viii.............................................

Support Package Description 1--1.......................................

Logic Analyzer Software Compatibility 1--1..............................

Logic Analyzer Configuration 1--2......................................

Requirements and Restrictions 1--2......................................

Timing Display Format 1--4...........................................

Functionality Not Supported 1--5.......................................

Functionality Supported But Not Tested 1--5..............................

Connecting the Logic Analyzer to a Target System 1--6.....................

Labeling P6434 Probes 1--6............................................

Setting Up the Support 2--1.....................................

Installing the Support Software 2--1.....................................

Channel Group Definitions 2--1.........................................

8101_SNG Support 2--2...........................................

8101_MLT Support 2--2...........................................

Clocking 2--3.......................................................

Acquisition Setup 2--3............................................

Clocking Options 2--3.............................................

Custom Cl ocking 2--3.............................................

Acquiring and Viewing Disassembled Data 2--5....................

Acquiring Data 2--5..................................................

Signal Acquisition 2--5............................................

Viewing Cycle Type Labels 2--8........................................

Hardware Display Format 2--9......................................

Changing How Labels are Displayed 2--13.................................

Optional Display Selections 2--14....................................

Micro-Specific Fields for 8101_SNG 2--14.............................

Micro-Specific Fields for 8101_MLT 2--17.............................

Marking Cycles 2--20..............................................

Displaying Exception Labels 2--21...................................

Viewing an Example of Cycle Type Labels 2--23............................

TMS708 MSC8101 Microprocessor Software Support

Table of Contents

Reference

Specifications

Replaceable Parts List

Reference: Symbol and Channel Assignment Tables 3--1.............

Symbol Tables 3--1..................................................

8101_SNG Support 3--1...........................................

8101_MLT Support 3--4...........................................

Channel Assignment Tables 3--7.......................................

8101_SNG Support 3--7...........................................

8101_MLT Support 3--13...........................................

CPU To Mictor Connections 3--20.......................................

8101_SNG Support 3--21...........................................

8101_MLT Support 3--26...........................................

Specification Tables 4--1..............................................

Parts Ordering Information 5--1.........................................

Using the Replaceable Parts List 5--1....................................

Index

TMS708 MSC8101 Microprocessor Software Support

List of Figures

Table of Contents

Figure 2--1: Bus timing d iagram for SDRAM memory 2--6...........

Figure 2--2: Bus timing d iagram for GPCM memory 2--6............

Figure 2--3: Bus timing diagram for Multi Master mode 2--7.........

Figure 2--4: Example of the Hardware Display format in the

Single Master Mode 2--12....................................

Figure 2--5: Example of the Hardware Display format in the

Multi Master Mode 2--13.....................................

TMS708 MSC8101 Microprocessor Software Support

iii

Table of Contents

List of Tables

Table 2--1: Channel groups for the Single Master Mode 2--2.........

Table 2--2: Channel groups for the Multi Master Mode 2--2.........

Table 2--3: Sample points in Single Master Mode 2--7...............

Table 2--4: Sample points in Multi Master Mode 2--8...............

T able 2--5: Description of special characters in display 2--9..........

Table 2--6: Cycle type label definitions for the 8101_SNG

support 2--9..............................................

Table 2--7: Cycle type label definitions for the 8101_MLT

support 2--10..............................................

Table 2--8: General cycle type labels 2--11..........................

Table 2--9: Logic analyzer disassembly display options 2--14..........

Table 2--10: Mark selections and definitions for 8101_SNG

support 2--21...............................................

Table 2--11: Mark selections and definitions for 8101_MLT

support 2--21...............................................

Table 2--12: Interrupt and exception lab els 2--21....................

Table 3--1: 8101_SNG_Control group symbol table definitions 3--1....

Table 3--2: 8101_SNG_Chip_Sel group symbol table definitions 3--2..

Table 3--3: 8101_SNG_Byte_Enb group symbol table

definitions 3--2............................................

Table 3--4: 8101_MLT_Control group symbol table definitions 3--4...

Table 3--5: 8101_MLT_Chip_Sel group symbol table definitions 3--4..

Table 3--6: 8101_MLT_T_Type group symbol table definitions 3--5...

Table 3--7: 8101_MLT_T_Size group symbol table definitions 3--5....

Table 3--8: 8101_MLT_T_Code group symbol table definitions 3--6...

Table 3--9: 8101_MLT_Req_Grant group symbol table

definitions 3--6............................................

Table 3--10: Address group channel assignments for 8101_SNG

support 3--7..............................................

Table 3--11: Hi_Data group channel assignments for 8101_SNG

support 3--8..............................................

Table 3--12: Lo_Data group channel assignments for 8101_SNG

support 3--9..............................................

Table 3--13: Control group channel assignments for 8101_SNG

support 3--11..............................................

TMS708 MSC8101 Microprocessor Software Support

Table of Contents

Table 3--14: Chip_Sel group channel assignments for 8101_SNG

support 3--11..............................................

Table 3--15: Byte_Enb group channel assignments for 8101_SNG

support 3--12..............................................

Table 3--16: Misc group channel assignments for 8101_SNG

support 3--12..............................................

Table 3--17: Address group channel assignments for 8101_MLT

support 3--13..............................................

Table 3--18: Hi_Data group channel assignments for 8101_MLT

support 3--14..............................................

Table 3--19: Lo_Data group channel assignments for 8101_MLT

support 3--15..............................................

Table 3--20: Control group channel assignments for 8101_MLT

support 3--16..............................................

Table 3--21: Chip_Sel group channel assignments for 8101_MLT

support 3--17..............................................

Table 3--22: T_Type group channel assignments for 8101_MLT

support 3--17..............................................

Table 3--23: T_Size group channel assignments for 8101_MLT

support 3--18..............................................

Table 3--24: T_Code group channel assignments for 8101_MLT

support 3--18..............................................

Table 3--25: Req_Grant group channel assignments for 8101_MLT

support 3--19..............................................

Table 3--26: Recommended pin assignments for a Mictor connector

(component side) 3--20.......................................

Table 3--27: CPU to Mictor connections for Mictor A pins for

8101_SNG support 3--21.....................................

Table 3--28: CPU to Mictor connections for Mictor C pins for

8101_SNG support 3--22.....................................

Table 3--29: CPU to Mictor connections for Mictor D pins for

8101_SNG support 3--23.....................................

Table 3--30: CPU to Mictor connections for Mictor E pins for

8101_SNG support 3--24.....................................

Table 3--31: CPU to Mictor connections for Mictor A pins for

8101_MLT support 3--26....................................

Table 3--32: CPU to Mictor connections for Mictor C pins for

8101_MLT support 3--27.....................................

Table 3--33: CPU to Mictor connections for Mictor D pins for

8101_MLT support 3--28.....................................

Table 3--34: CPU to Mictor connections for Mictor E pins for

8101_MLT support 3--29.....................................

TMS708 MSC8101 Microprocessor Software Support

Table of Contents

T able 4--1: Electrical specifications 4--1...........................

TMS708 MSC8101 Microprocessor Software Support

Preface

This instruction manual contains information specific to the TMS708 MSC8101 microprocessor support package and is part of a set of information on how to operate this product on compatible Tektronix logic analyzers.

If you are familiar with operating microprocessor support packages on the logic analyzer for which the TMS708 MSC8101 support was purchased, you will probably only need this instruction manual to set up and run the support.

If you are not familiar with operating microprocessor support packages, you will need to supplement this instruction manual with information on basic operations to set up and run the support.

Information on basic operations of microprocessor support packages is included with each product. Each logic analyzer includes basic information that describes how to perform tasks common to s upport packages on that platform. This information can be in the form of online help, an installation manual, or a user manual.

This manual provides detailed information on the following topics:

H Connecting the logic analyzer to the target system

Manual Conventions

H Setting up the logic analyzer to acquire data from the target system

H Acquiring and viewing cycle type labels

This manual uses the following conventions:

H The term “disassembler” refers to the software that decodes bus cycles and

displays cycle types.

H The phrase “information on basic operations” refers to the logic analyzer

online help, an installation manual, or a user manual covering the basic operations of the microprocessor support.

H The term “logic analyzer” refers to the Tektronix logic analyzer for which

this product was purchased.

TMS708 MSC8101 Microprocessor Software Support

vii

Preface

Contacting Tektronix

Phone 1-800-833-9200*

Address Tektronix, Inc.

Department or name (if known) 14200 SW Karl Braun Dri ve P.O. Box 500 Beaverton, OR 97077 USA

Web site www.tektronix.com

Sales support 1-800-833-9200, select option 1*

Service support 1-800-833-9200, select option 2*

Technical support Email: techsupport@tektronix.com

1-800-833-9200, select option 3*

6:00 a.m. -- 5:00 p.m. Pacific time

* This phone number is toll free in North America. After office hours, please leave a

voice mail message. Outside North America, contact a Tektronix sales office or distributor; see the Tektronix web site for a list of offices.

viii

TMS708 MSC8101 Microprocessor Software Support

Getting Started

This section contains information on the TMS708 MS C8101 microprocessor support, and information on connecting your logic analyzer to your target system.

Support Package Description

The TMS708 microprocessor support package displays the Cycle Type labels, marks the Idle Cycles, and validates the data bus and the address bus. The TMS708 does not display the instructions nor identify the Fetch cycles. The Motorola MSC8101 16-bit Digital Signal Processor (DSP) is the first member of the family of DSPs based on the Starcore SC140 DS P core.

The TMS708 installs two support packages 8101_SNG and 8101_MLT.

H 8101_SNG supports the Single Master mode of MSC8101 processor.

H 8101_MLT supports the Multi Master mode of MSC8101 processor. You can

use the 8101_MLT support for Internal and External Arbiter configurations. In the Internal Arbiter configuration, the software supports three more external masters on the same system bus. In the External Arbiter configuration, the software supports up to four masters. The software decodes the cycles of all the masters.

The TMS708 microprocessor support package decodes the Cycle Types, validates the data bus and identifies the Idle Cycles. The support does not decode Instructions.

Refer to information on basic operations to determine how many modules and probes your logic analyzer needs to meet the minimum channel requirements for the TMS708 microprocessor support.

To use this support efficiently, you need the items listed in the information on basic operations as well as the MSC8101 Microprocessor User Manual (Motorola, April 2001, and Revision 0, MSC8101RM/D).

Logic Analyzer Software Compatibility

The label on the microprocessor support floppy disk states which version of logic analyzer software this support is compatible with.

TMS708 MSC8101 Microprocessor Software Support

1- 1

Getting Started

Logic Analyzer Configuration

The TMS708 MSC8101 microprocessor support requires the following minimum module configuration:

H One 136-channel, 100 MHz module for 8101_SNG support

H One 136-channel, 100 MHz module for 8101_MLT support

Requirements and Restrictions

Review the electrical specifications in the Specifications section in this manual as they pertain to your target system, as well as the following descriptions of other MSC8101 support requirements and restrictions.

Hardware Reset. If a hardware reset occurs in your MSC8101 system during an acquisition, the disassembler application might acquire invalid samples.

System Clock Rate CLKOUT. The support can acquire data from the MSC8101 microprocessor operating at speeds of up to 100 MHz has been tested for speeds up to 50 MHz and the 8101_MLT support up to 66MHz.

T_Code Group in 8101_MLT Group. The T_Code channel group consists of signals TC0/BR0~, TC1/BG0~, and TC2/DBG0~. By default, this group is hidden in the support package. If you want to use the support for Internal Arbiter Configuration, you must connect the signals TC0, TC1, and TC2 to the logic analyzer channels C0:1, C0:0 and C2:6. To view the activities of TC[0-2] signals, add the T_Code group to the listing using CTRL+L. If you want to use the support for External Arbiter configuration, connect the signals BR0~, BG0~, and DBG0~ to the logic analyzer channels C0:1,C0:0, and C2:6. The T_Code group is not valid in External Arbiter Configuration.

Triggering on Address in a Burst Transaction. The signals BADDR[31--27] generate the address increments to memory devices for burst accesses and these are not visible when signals A[31--27] are connected to the logic analyzer channels A0:[0--4]. You can trigger on an address within a burst transaction only if signals BADDR[31--27] are connected to the logic analyzer channels A0:[0--4]. The disassembler displays the address increments for burst transactions even though signals A[31--27] are probed.

. The 8101_SNG support

1- 2

Specification at time of printing. Contact your Tektronix sales representative for current information on the fastest devices supported.

TMS708 MSC8101 Microprocessor Software Support

Getting Started

Signals Not Required in t he Channel Assignment. The TMS708 MSC8101 support package decodes cycle types, validates address and data bus, and identifies the idle cycles acquired by clock-by-clock acquisition. It does not decode instructions. The channel assignment contains signals that are not required to support cycle type decoding, validate address and data bus, or identify idle cycles. If you include the P6434 high-density probe interface in your design, we recommend that you use these signals.

EAV Bit Setting in 8101_SNG Support. Set the EAV (Enable Address Visibility) bit of the Bus Configuration Register (BCR) to 1 for correct disassembly. When the EAV is set to 1, the Bank Select signals are not driven on the address bus. During READ and WRITE commands to SDRAM devices, the full address is driven on bus address lines. Therefore, when the EAV bit is set to 1, the full address is valid at PSDCAS~ asserted and PSDRAS~ deasserted for SDRAM accesses.

Qualifiers Used in 8101_MLT Support. The Multi Master support uses the internal memory controller signals for validating Address and Data. The support uses the ALE signal to qualify a valid Address and the PSDVAL~ signal to qualify a valid data on the bus. The external masters connected to the system may be an MSC8101 or a non-MSC8101processor. For an MSC 8101 processor, the ALE and PSDVAL~ signals are the qualifiers. For a non-MSC8101 processor, the ALE and TA~ signals are the qualifiers.

Address Pipelining. The TMS708 support is designed to support pipelining up to one level. While acquiring data from systems with pipelining, you may at the beginning acquire data tenures without any corresponding address tenures. The support, by default, starts associating the first data with the first acquired address tenure. This may cause incorrect Cycle Type decoding. In that case, you must associate the first acquired address with the correct data tenure using the ‘Invalid Data’ marking option. You must mark as ‘Invalid Data’ the first data tenure without any corresponding address. Once you mark the Invalid Data, the support package adjusts itself to associate the address and data correctly.

Nonintrusive Acquisition. Acquiring microprocessor bus cycles is nonintrusive to the target system. That is, the TMS708 MSC8101 microprocessor does not intercept, modify, or present back signals to the target system.

TMS708 MSC8101 Microprocessor Software Support

1- 3

Getting Started

Channel Groups. The channel groups required for clocking and cycle type decoding in the 8101_SNG support are:

Address Hi_Data Lo_Data Control Chip_Sel Byte_Enb Misc

The channel groups required for clocking and cycle type decoding in the 8101_MLT support are:

Address Hi_Data Lo_Data Control Chip_Sel T_Type T_Size T_Code Req_Grant

Timing Display Format

The support has a Timing Display Format file. It sets up the display to show the following waveforms:

For 8101_SNG Support:

CLKOUT Address Hi_Data Lo_Data PSDRAS~/POE~ PSDCAS~ PSDVAL~ Control Chip_Sel Byte_Enb Misc

NOTE. The Address, Hi_Data, Lo_Data, Control, Chip_Sel, Byte_Enb, and Misc groups are displayed in busform.

1- 4

TMS708 MSC8101 Microprocessor Software Support

For 8101_MLT S upport:

CLKOUT Address Hi_Data Lo_Data TS~ ALE TA~ TEA~ AACK~ PSDVAL~ T_Type T_Size T_Code Control Chip_Sel Req_Grant

Getting Started

NOTE. The Address,Hi_Data, Lo_Data, T_Type, T_Size, T_Code, Control, Chip_Sel, and Req_Grant groups are displayed in busform.

Functionality Not Supported

The TMS708 software does not support the following functionalities:

H UPM cycles

H DMA cycles

H HDI16 cycles

H Multiple master mode with multiple memory controllers

H PowerPC

local bus cycles

Functionality Supported But Not Tested

The TMS708 software supports the following features, but are not tested.

H 60X system bus interface of the MSC8102 processor

H External Arbiter Configuration in 8101_MLT support

H Atomic bus operations (RAWA, WARA) in 8101_SNG support

TMS708 MSC8101 Microprocessor Software Support

1- 5

Getting Started

Connecting the Logic Analyzer to a Target System

You can use the channel probes, clock probes, and leadsets with a commercial test clip (or adapter) to make the connections between the logic analyzer and your target system.

To connect the probes to MSC8101 signals in the target system using a test clip, follow the steps:

1. Power off your target system. You do not need to power off the logic

analyzer.

CAUTION. To prevent static damage, handle the microprocessor, probes, and the logic analyzer module in a static-free environment. Static discharge can damage these components.

Always wear a grounding wrist strap, heel strap, or similar device while handling the microprocessor.

Labeling P6434 Probes

2. To discharge your stored static electricity, touch the ground connector

located on the back of the logic analyzer. If you are using a test clip, touch any of the ground pins on the clip to discharge stored electricity from the test clip.

CAUTION. To prevent permanent damage to the pins on the microprocessor, place the target system on a horizontal surface before connecting the test clip.

3. Place the target system on a horizontal, static-free surface.

4. Use Tables 3--27 through 3--34 starting on page 3--21 to connect the channel

probes to MSC8101 signal pins on the test clip or in the target system.

5. Use leadsets to connect at least one ground lead from each channel and the

ground lead from each clock probe to the ground pins on your test clip.

The TMS708 MSC8101 software support package relies on the channel mapping and labeling scheme for the P6434 Probes. Apply labels using the instructions described in the P6434 Probe Instructions manual.

1- 6

TMS708 MSC8101 Microprocessor Software Support

Operating Basics

Setting Up the Support

This section provides information on how to set up the support and covers the following topics:

H Installing the support software

H Channel group definitions

H Clocking options

The information in this section is specific to the operations and functions of the TMS708 MSC8101 support on any Tektronix logic analyzer for which the support can be purchased. Information on basic operations describes general tasks and functions.

Before you acquire and display cycle type labels, you need to load the support and specify the setups for clocking and triggering as described in the information on basic operations. The support provides default values for each of these setups, but you can change the default values as needed.

Installing the Support Software

NOTE. Before you install any software, you should verify that the microprocessor support software is compatible with the logic analyzer software.

To install the TMS708 MSC8101 software on your Tektronix logic analyzer, follow these steps:

1. Insert the floppy disk in the disk drive.

2. Click the Windows Start button, point to Settings, and click Control Panel.

3. In the Control Panel window, double-click Add/Remove Programs.

4. Follow the instructions on the screen for installing the software from the

To remove or uninstall software, follow the above instructions and select Uninstall. You need to close all windows before you uninstall any software.

Channel Group Definitions

The software automatically defines channel groups for the support.

floppy disk.

TMS708 MSC8101 Microprocessor Software Support

2--1

Setting Up the Support

8101_SNG Support

8101_MLT Support

The channel groups for the TMS708 8101_SNG support are: Address, Hi_Data, Lo_Data, Control, Chip_Sel, Byte_Enb, and Misc. Table 2--1 shows the channel groups and the display radix for the 8101_SNG support.

Table 2--1: Channel groups for the Single Master Mode

Group name Display radix

Address HEX

Hi_Data HEX

Lo_Data HEX

Mnemonics NONE (disassembler generated text)

Control SYM

Chip_Sel SYM

Byte_Enb SYM

Misc HEX (hidden by default)

The channel group for the TMS708 8101_MLT support are: Address, Hi_Data, Lo_Data, T_Type, T_Size, T_Code, Control, Chip_Sel, and Req_Grant. Table 2--2 shows the channel groups and the display radix for the 8101_MLT support.

NOTE. The T_Code group is applicable only in Internal Arbiter Mode.

Table 2--2: Channel groups for the Multi Master Mode

Group name Display radix

Address HEX

Hi_Data HEX

Lo_Data HEX

Mnemonics NONE (disassembler generated text)

Control SYM (hidden by default)

Chip_Sel SYM

T_Type SYM

T_Size SYM

T_Code SYM (hidden by default)

Req_Grant SYM

2--2

TMS708 MSC8101 Microprocessor Software Support

Clocking

Setting Up the Support

If you want to know which signal is in which group, refer to the channel assignment tables beginning on page 3--7.

Acquisition Setup

Clocking Options

Custom Clocking

The TMS708 MSC8101 affects the logic analyzer setup menus (and submenus) by modifying existing fields and adding micro-specific fields.

On the logic analyzer, the TMS708 MSC8101 support adds the selection ‘8101_SNG’ and ‘8101_MLT’ to the Load Support Package dialog box, under the File pulldown menu. Once ‘TMS708 MSC8101 support’ is loaded, the ‘Custom’ clocking mode selection in the logic analyzer module Setup menu is also enabled.

The TMS708 support offers a microprocessor-specific clocking mode for the MSC8101 microprocessor. This clocking mode is the default selection whenever you load the MSC8101 support.

The disassembly will not be correct when using the Internal or External clocking modes. Information on basic operations describes how to use these clock selections for general purpose analysis.

A special clocking program is loaded to the module every time you load the 8101_SNG or 8101_MLT support. This special clocking is called Custom.

With Custom Clocking, the module logs in signals from the multiple channel groups at every clock on the TMS708 MSC8101 bus. The module then sends all the logged-in signals to the trigger machine and stores the signals in the acquisition memory of the module.

When Custom is selected, the Custom Clocking Options menu adds the subtitle: ‘8101_SNG Microprocessor Clocking Support’ or ‘8101_MLT Microprocessor Clocking Support’, and displays the clocking option—Standard. This is the only custom clocking option available for this support.

TMS708 MSC8101 Microprocessor Software Support

2--3

Setting Up the Support

2--4

TMS708 MSC8101 Microprocessor Software Support

Acquiring and Viewing Disassembled Data

This section describes how to acquire and view data. The following information covers these topics and tasks:

H Acquiring data

H Viewing cycle type labels

H Changing the way labels are displayed

H Timing diagrams

Acquiring Data

The TMS708 MSC8101 software package installs the 8101_SNG support for the MSC8101 processor working in Single Master mode and the 8101_MLT for

MSC8101 processor working in Multi Master mode (for up to four masters on the target system). Once you load the support, by default, the custom clocking option is selected. Specify the trigger, if any, and you are ready to acquire and disassemble data.

Signal Acquisition

If you have any problems acquiring data, refer to information on basic operations in your online help or Appendix A: Error Messages and Disassembly Problems in the user manual.

8101_SNG Support. The Custom Clock uses the falling edge of the CLKOUT signal.

TMS708 MSC8101 Microprocessor Software Support

2--5

Acquiring and Viewing Disassembled Data

Figures 2--1 and 2--2 show the Bus Timing diagrams for SDRAM memory and GPCM memory in the Single Master mode.

CLKOUT

ALE

SDRAS

SDCAS

MA[0--11]

DQM

Data

Z Column2

MMMMMMMMMMM

Column1

D0 D1 D0 D1

Figure 2--1: Bus timing diagram for SDRAM memory

CLKOUT

Address

PSDVAL

CSx

CSy

BCTLx

POE

Data

MM MM

Figure 2--2: Bus timing diagram for GPCM memory

2--6

TMS708 MSC8101 Microprocessor Software Support

Acquiring and Viewing Disassembled Data

Table 2--3 describes the sample points in 8101_SNG support.

Table 2--3: Sample points in Single Master Mode

Sample point Signals

Master sample point, M A[0--31], D[0--31], D[32--63], CS~[0--7],

PWE~[0--7], PSDCAS~, PSDRAS~/POE~, PSDVAL~, CLKOUT, PSDWE~, PSDA10, PGTA~, PSDAMUX, BCTL0~, BCTL1~, NMI_OUT, HRESET~, SRESET~, PORESET~, NMI~, DP6~/DACK3~, DP7~/DACK4~, IRQ7~/INT_OUT~

The only sample point is M (Master). All the signals are logged and mastered at every falling edge of the CLKOUT signal.

8101_MLT Support. The Custom Clock uses the rising edge of the CLKOUT.

Figure 2--3 shows the Bus Timing diagram for Multi Master mode.

CLKOUT

ADDR + ATTR

AACK

DBG

PSDVAL

D[0--63]

MMMMM M MM MMMM

D1 D2 D3

Figure 2--3: Bus timing diagram for Multi Master mode

TMS708 MSC8101 Microprocessor Software Support

2--7

Acquiring and Viewing Disassembled Data

Table 2--4 describes the sample points in 8101_MLT support.

Table 2--4: Sample points in Multi Master Mode

Sample point Signals

Master sample point, M A[0--31], D[0--31], D[32--63], CS~[0--7], TS~,

The only sample point is M (Master). All the signals are logged and mastered at every rising edge of the CLKOUT signal.

CLKOUT, PSDVAL~, AACK~, ABB~, BG~, DP0~/EXT_BR2~, BR~, ALE, DBG~, DBB~, TC0/BR0~, TC1/BG0~, TC2/DBG0~, TT[0--4], TSIZ[0--3], DP3~/EXT_BR3~, DP1~/EXT_BG2~, DP2~/EXT_DBG2~, DP4~/EXT_BG3~, TBST~, ARTRY~, DP5~/EXT_DBG3~, TA~, TEA~

Viewing Cycle Type Labels

You can view cycle type labels only in the Hardware display format. The information on basic operations describes how to select the disassembly display formats.

NOTE. You must set the selections in the Disassembly property page (the Disassembly Format Definition overlay) correctly for your acquired data to be disassembled correctly. Refer to Changing How Labels are Displayed on page 2--13.

For the 8101_SNG support, the default display format shows the Address, Hi_Data, Lo_Data, Mnemonics, Control, Chip_Sel, Byte_Enb channel group values for each sample of acquired data.

For the 8101_MLT support, the default display format shows the Address, Hi_Data, Lo_Data, Mnemonics, T_Type, T_Size, Chip_Sel channel group values for each sample of acquired data.

If a channel group is not visible, you can add the required column by pressing Ctrl + L and selecting the group of interest.

2--8

TMS708 MSC8101 Microprocessor Software Support

Acquiring and Viewing Disassembled Data

Table 2--5 shows the special characters and gives a definition of what they represent.

Table 2--5: Description of special characters in display

Character or string displayed Description

>> The sample was manually marked

Hardware Display Format

In the Hardware display format, the support displays all cycle type labels in parentheses.

In Hardware display format, all cycle type labels are displayed. This is the default format for viewing the data.

Tables 2--6 and 2--7 show the cycle type labels and their descriptions that the support recognizes and displays.

Table 2--6: Cycle type label definitions for the 8101_SNG support

Cycle type Definition

( SDRAM-Activate Cycle ) Indicates a SDRAM Activate command

( SDRAM-Precharge Cycle ) Indicates a SDRAM Precharge command

( SDRAM-Refresh Cycle ) Indicates a SDRAM Refresh command

( Row Address ) Indicates the presence of Row Address on the Address

bus

( Column Address ) Indicates the presence of Column Address on the

Address bus

( SDRAM-Read Cycle ) Indicates a SDRAM Read cycle

( SDRAM-Write Cycle ) Indicates a SDRAM Write cycle

( Hardware Reset Cycle ) Indicates a Hardware Reset Operation

( Software Reset Cycle ) Indicates a Software Reset Operation

( Power On Reset Cycle ) Indicates a Power On Reset Operation

( SDRAM Fetch ) Indicates a Fetch Cycle

(Data) Indicates a Data Cycle (can be a Read Data or a Burst

( GPCM-Read Cycle ) Indicates a GPCM Read Cycle

( GPCM-Write Cycle ) Indicates a GPCM Write Cycle

( GPCM-Wait Cycle ) Indicates a GPCM Wait Cycle

(NoDeviceSelectedforCS0) Indicates that Chip Select 0 (CS0~) disassembly option is

TMS708 MSC8101 Microprocessor Software Support

Read Data or a Write Data or a Burst Write Data)

not selecting any device *

2--9

Acquiring and Viewing Disassembled Data

Table 2--6: Cycle type label definitions for the 8101_SNG support (cont.)

Cycle type Definition

(NoDeviceSelectedforCS1) Indicates that Chip Select 1 (CS1~) disassembly option is

(NoDeviceSelectedforCS2) Indicates that Chip Select 2 (CS2~) disassembly option is

(NoDeviceSelectedforCS3) Indicates that Chip Select 3 (CS3~) disassembly option is

(NoDeviceSelectedforCS4) Indicates that Chip Select 4 (CS4~) disassembly option is

(NoDeviceSelectedforCS5) Indicates that Chip Select 5 (CS5~) disassembly option is

(NoDeviceSelectedforCS6) Indicates that Chip Select 6 (CS6~) disassembly option is

(NoDeviceSelectedforCS7) Indicates that Chip Select 7 (CS7~) disassembly option is

The support displays this label when the CSn~ Disassembly option selected is ‘No_Device’.

not selecting any device *

Table 2--7: Cycle type label definitions for the 8101_MLT support

Cycle type Definition

( Transfer Start )

( Transfer Error ) Indicates TEA~ is asserted

( Address ) Indicates a valid Address

( Address Bus Busy ) Indicates ABB~ is asserted

( Address Acknowledge ) Indicates AACK~ is asserted

( Address Retry ) Indicates ARTRY~ is asserted

(Data) Indicates valid data

( Burst Data ) Indicates TBST~ is asserted for Burst Data

(DataBusBusy) Indicates DBB~ is asserted

( Transfer Acknowledge ) Indicates TA~ is asserted

( Bus Grant ) Indicates BG0~ or BG~ or EXT_BG2~ or EXT_BG3~ is

(NoDeviceSelectedforCS0) Indicates that Chip Select 0 (CS0~) disassembly option is

(NoDeviceSelectedforCS1) Indicates that Chip Select 1 (CS1~) disassembly option is

Indicates TS~ is asserted

asserted

not selecting any device *

2--10

TMS708 MSC8101 Microprocessor Software Support

Acquiring and Viewing Disassembled Data

Table 2--7: Cycle type label definitions for the 8101_MLT support (cont.)

Cycle type Definition

(NoDeviceSelectedforCS2) Indicates that Chip Select 2 (CS2~) disassembly option is

not selecting any device *

(NoDeviceSelectedforCS3) Indicates that Chip Select 3 (CS3~) disassembly option is

not selecting any device *

(NoDeviceSelectedforCS4) Indicates that Chip Select 4 (CS4~) disassembly option is

not selecting any device *

(NoDeviceSelectedforCS5) Indicates that Chip Select 5 (CS5~) disassembly option is

not selecting any device *

(NoDeviceSelectedforCS6) Indicates that Chip Select 6 (CS6~) disassembly option is

not selecting any device *

(NoDeviceSelectedforCS7) Indicates that Chip Select 7 (CS7~) disassembly option is

not selecting any device *

The support displays this label when the CSn~ Disassembly option selected is ‘No_Device’.

A unique label is attached to the cycle type labels that identifies the cycles corresponding to every processor.

H For the main master (internal arbiter) or processor0 (external arbiter) cycles,

the support indicates ‘--> Processor_0 Cycle’

H For the second processor cycles, the support indicates ‘--> Processor_1’

H For the third processor cycles, the support indicates ‘--> Processor_2’

H For the fourth processor cycles, the support indicates ‘--> Processor_3’

For example: A ‘Transfer Start’ Cycle of the second processor is labeled as ( Transfer Start ) --> Processor_1

Table 2--8 shows the general cycle type labels and their descriptions that the support recognizes and displays.

Table 2--8: General cycle type labels

Cycle type Definition

( Idle Cycle ) Indicates the cycle that is in between two valid cycles

( Unknown Cycle ) Indicates the cycle that is not yet identified and decoded

***Un-Associated Data*** Indicates that no address is available for associating with a data

TMS708 MSC8101 Microprocessor Software Support

beat (because of incomplete acquisition of the complete cycle) or when the address is re-tried and data tenure already exists

2--11

Acquiring and Viewing Disassembled Data

NOTE. The label ‘Idle Cycle’ is common for both supports. The label ‘Unknown Cycle’ is used in 8101_SNG support and the label ***Un-Associated Data*** is used in 8101_MLT support.

Use the Micro Specific Fields in the 8101_MLT support to view the cycle type labels of all the processors simultaneously or of one processor at a time.

Figure 2--4 shows an example of the Hardware Display format in the Single Master Mode.

Figure 2--4: Example of the Hardware Display format in the Single Master Mode

2--12

TMS708 MSC8101 Microprocessor Software Support

Acquiring and Viewing Disassembled Data

Figure 2--5 shows an example of the Hardware Display format in the Multi Master Mode.

Figure 2--5: Example of the Hardware Display format in the Multi Master Mode

Changing How Labels are Displayed

There are common fields and features that allow you to further modify displayed data to suit your needs. You can make common and optional display selections in the Disassembly property page (the Disassembly Format Definition overlay).

You can make selections unique to the TMS708 support to do the following tasks:

H Change the interpretation of cycle type labels

H Display exception cycles

TMS708 MSC8101 Microprocessor Software Support

2--13

Acquiring and Viewing Disassembled Data

Optional Display

Selections

Micro-Specific Fields for

8101_SNG

You can make optional selections for disassembled data. In addition to the common selections (described in the information on basic operations), you can change the displayed data as shown in Table 2--9:

Table 2--9: Logic analyzer disassembly display options

Description Option

Show: Hardware (Default)

Highlight: None

Disassemble Across Gaps: Yes

No (Default)

The following micro-specific fields are available in the Disassembly options page.

This submenu has the title: 8101_SNG Controls. For the 8101_SNG Support package the micro-specific fields are:

Idle Cycles. Use this option to show or suppress the idle cycles in the hardware display format. Select one of the following options:

Idle Cycles: Show (default)

Suppress

CAS Latency. Select the CAS Latency value for correct disassembly. The CAS Latency option represents the CL field of the SDRAM configuration register (PSDMR).

CAS Latency: 1 (default)

2 3

Vector Base Address. Input the base address for the vector table. The vector base address reflects the value set in the VBA register. The vector base address is a five digit field that forms the 20-bit MSB of the vector address.

2--14

TMS708 MSC8101 Microprocessor Software Support

Acquiring and Viewing Disassembled Data

CS0~. Select the port size and memory device for CS0~ by selecting one of the following options.

CS0~: SDRAM-64 Bit (default)

SDRAM-32 Bit SDRAM-16 Bit SDRAM-8 Bit GPCM-64 Bit GPCM-32 Bit GPCM-16 Bit GPCM-8 Bit No_Device

CS1~. Select the port size and memory device for CS1~ by selecting one of the following options.

CS1~: SDRAM-64 Bit (default)

SDRAM-32 Bit SDRAM-16 Bit SDRAM-8 Bit GPCM-64 Bit GPCM-32 Bit GPCM-16 Bit GPCM-8 Bit No_Device

CS2~. Select the port size and memory device for CS2~ by selecting one of the following options.

CS2~: SDRAM-64 Bit (default)

SDRAM-32 Bit SDRAM-16 Bit SDRAM-8 Bit GPCM-64 Bit GPCM-32 Bit GPCM-16 Bit GPCM-8 Bit No_Device

TMS708 MSC8101 Microprocessor Software Support

2--15

Acquiring and Viewing Disassembled Data

CS3~. Select the port size and memory device for CS3~ by selecting one of the following options.

CS3~: SDRAM-64 Bit (default)

CS4~. Select the port size and memory device for CS4~ by selecting one of the following options.

CS4~: SDRAM-64 Bit (default)

SDRAM-32 Bit SDRAM-16 Bit SDRAM-8 Bit GPCM-64 Bit GPCM-32 Bit GPCM-16 Bit GPCM-8 Bit No_Device

CS5~. Select the port size and memory device for CS5~ by selecting one of the following options.

CS5~: SDRAM-64 Bit (default)

SDRAM-32 Bit SDRAM-16 Bit SDRAM-8 Bit GPCM-64 Bit GPCM-32 Bit GPCM-16 Bit GPCM-8 Bit No_Device

2--16

TMS708 MSC8101 Microprocessor Software Support

Acquiring and Viewing Disassembled Data

CS6~. Select the port size and memory device for CS6~ by selecting one of the following options.

CS6~: SDRAM-64 Bit (default)

SDRAM-32 Bit SDRAM-16 Bit SDRAM-8 Bit GPCM-64 Bit GPCM-32 Bit GPCM-16 Bit GPCM-8 Bit No_Device

CS7~. Select the port size and memory device for CS7~ by selecting one of the following options.

CS7~: SDRAM-64 Bit (default)

SDRAM-32 Bit SDRAM-16 Bit SDRAM-8 Bit GPCM-64 Bit GPCM-32 Bit GPCM-16 Bit GPCM-8 Bit No_Device

Micro-Specific Fields for

8101_MLT

This submenu will have the title: 8101_MLT Controls. For the 8101_MLT Support package the micro-specific fields are:

Idle Cycles. Use the Idle Cycles option to show or suppress the idle cycles in the hardware display format. Select one of the following options:

Idle Cycles: Show (default)

Suppress

Arbiter. Use the Arbiter option to identify the multi-master configuration (Internal or External Arbiter) in the target system. Select one of the following options:

Arbiter: Internal (default)

External

Selecting Internal or External changes the definition of the next option ‘Show Cycles Of’.

TMS708 MSC8101 Microprocessor Software Support

2--17

Acquiring and Viewing Disassembled Data

Show Cycles Of. You can view either the cycles of any one master at a time, or all the masters by selecting one of the following options.

Show Cycles Of: All (default)

NOTE. When you set the Arbiter option to Internal , the definitions of 0, 1, 2, and 3 are as follows:

0 represents the MSC8101 main master (or the Internal Arbiter) 1, 2, and 3 represent the other three external masters connected on the same bus BR~, BG~, DBG~ reflect the status of Main master and Processor 1 BR2~, BG2~, DBG2~ reflect the status of Processor 2 BR3~, BG3~, DBG3~ reflect the status of Processor 3

When you set the Arbiter option to External, the definitions of 0, 1, 2, and 3 are as follows:

0 1 2 3

1, 2, 3, and 4 represent the four external masters connected to the bus TC0/BR0~, TC1/BG0~, TC2/DBG0~ reflects the status of Processor 0 BR~, BG~, DBG~ reflect the status of Processor 1 BR2~, BG2~, DBG2~ reflect the status of Processor 2 BR3~, BG3~, DBG3~ reflect the status of Processor 3

Signals Connected Are. For burst transactions in the multi master mode, address increments are visible if signals BADDR[31-27] are connected to logic analyzer channels A0[0-4]. If signals A[31--27] are connected to logic analyzer channels A0[0-4], the software performs the address increments. Select one of the following options.

Signals Connected Are: A[27--31] (default)

BADDR[27--31]

2--18

TMS708 MSC8101 Microprocessor Software Support

Acquiring and Viewing Disassembled Data

CS0~. Select the port size for CS0~ by selecting one of the following options.

CS0~: 64 Bit (default)

32 Bit 16 Bit 8Bit No_Device

CS1~. Select the port size for CS1~ by selecting one of the following options.

CS1~: 64 Bit (default)

32 Bit 16 Bit 8Bit No_Device

CS2~. Select the port size for CS2~ by selecting one of the following options.

CS2~: 64 Bit (default)

32 Bit 16 Bit 8Bit No_Device

CS3~. Select the port size for CS3~ by selecting one of the following options.

CS3~: 64 Bit (default)

32 Bit 16 Bit 8Bit No_Device

CS4~. Select the port size for CS4~ by selecting one of the following options.

CS4~: 64 Bit (default)

32 Bit 16 Bit 8Bit No_Device

TMS708 MSC8101 Microprocessor Software Support

2--19

Acquiring and Viewing Disassembled Data

CS5~. Select the port size for CS5~ by selecting one of the following options.

CS5~: 64 Bit (default)

CS6~. Select the port size for CS6~ by selecting one of the following options.

CS6~: 64 Bit (default)

CS7~. Select the port size for CS7~ by selecting one of the following options.

CS7~: 64 Bit (default)

32 Bit 16 Bit 8Bit No_Device

Marking Cycles

The support has a Mark Opcode function that allows you to change the interpretation of a cycle type. Using this function, you can select a cycle and change it.

Marks are placed by using the Mark Opcode button. The Mark Opcode button is always available. If the sample being marked is not a Data cycle in 8101_MLT or an Address cycle in 8101_SNG of the potential bus master, the Mark Opcode selections are replaced by a note indicating that ‘An Opcode Mark cannot be placed at the selected data sample.’

When a cycle is marked, the character ‘>>’ is displayed immediately to the left of the Mnemonics column. Cycles can be unmarked by using the ‘Undo Mark’ selection, which removes the character ‘>>’. Tables 2--10 and 2--11 show the mark selections and definitions for the Single and Multi Master support.

2--20

TMS708 MSC8101 Microprocessor Software Support

Acquiring and Viewing Disassembled Data

The mark selections listed in Table 2--10 are available only for address sequences.

Table 2--10: Mark selections and definitions for 8101_SNG support

Mark selections Definition

Read --> Fetch Read can be marked as Fetch

Undo Mark Removes all marks from the current sequence

The mark selections listed in Table 2--11 are available only for data sequences.

Table 2--11: Mark selections and definitions for 8101_MLT support

Mark selections Definition

Invalid Data Any of the Data Cycles can be marked as Invalid Data

bits. No address is associated for this data.

Undo Mark Removes all marks from the current sequence

Displaying Exception

Labels

The support can display MSC8101 exception labels. The exception table must reside in external memory for interrupt and exception cycles to be visible to the disassembler.

You can enter the table prefix in the Vector Base Address field. The Vector Base Address field provides the support with the address. Enter a 5-digit hexadecimal value corresponding to the prefix of the exception table.

These fields are located in the Disassembly property page (Disassembly Format Definition overlay).

Table 2--12 lists the MSC8101 interrupt and exception labels.

Table 2--12: Interrupt and exception labels

Offset in hex Displayed interrupt or exception name

000 ( Internal (TRAP) Exception )

040 ( Reserved Exception )

080 ( Illegal Instruction or Set Exception )

0C0 ( Debug (EOnCE) Exception )

100 ( Reserved Exception )

140 ( Overflow (DALU) Exception )

180 ( Auto-NMI Exception )

1C0 ( Auto-IRQ Exception )

TMS708 MSC8101 Microprocessor Software Support

2--21

Acquiring and Viewing Disassembled Data

Table 2--12: Interrupt and exception labels (cont.)

Offset in hex Displayed interrupt or exception name

200-7C0 ( Reserved Exception )

800 ( EFCOP(0):Input FIFO Not Full Exception )

840 ( EFCOP(1):Input FIFO Empty Exception )

880 ( EFCOP(2):Output FIFO Full Exception )

8C0 ( EFCOP(3):Output FIFO Not Empty Exception )

900 ( EFCOP(4):Update Done Exception )

940 ( HDI16(0):Receive FIFO Full Exception )

980 ( HDI16(1):Receive FIFO Not Empty Exception )

9C0 ( HDI16(2):Transmit FIFO Empty Exception )

A00 ( HDI16(3):Transmit FIFO Not Full Exception )

A40 ( HDI16(4):External HOST Command Exception )

A80 ( Bus Controller (x-y contention) Exception )

AC0 ( Bus Controller (Level 1 Contention) Exception )

B00 ( Bus Controller (p-x Contention) Exception )

B40 ( Bus Controller (Non-Aligned Data Error) Exception )

B80 ( PIC Interrupt Request )

BC0 ( External IRQ2 Exception )

C00 ( SIC Interrupt )

C40 ( External IRQ3 Interrupt )

C80 ( DMA Interrupt )

CC0 ( Reserved Exception )

D00 ( EOnCE Interrupt )

D40-DC0 ( Reserved Exception )

E00 ( HDI16:External HOST NMI Interrupt )

E40 ( Reserved Exception )

E80 ( Bus Controller (Memory Write Error) Exception )

EC0 ( Bus Controller (Non-Aligned Error) Exception )

F00 ( Bus Controller (Bus Error) Exception )

2--22

F40-F80 ( Reserved Exception )

FC0 ( SIC NMI Exception )

TMS708 MSC8101 Microprocessor Software Support

Viewing an Example of Cycle Type Labels

A demonstration system file (or demonstration reference memory) for the support package is provided on your software disk to show an example of how your MSC8101 microprocessor bus cycles look when they are decoded. Viewing the system file is not a requirement for preparing the module for use and you can view it without connecting the logic analyzer to your target system.

Information on basic operations describes how to view the file.

Acquiring and Viewing Disassembled Data

TMS708 MSC8101 Microprocessor Software Support

2--23

Acquiring and Viewing Disassembled Data

2--24

TMS708 MSC8101 Microprocessor Software Support

Reference

Reference: Symbol and Channel Assignment Tables

This section lists the symbol tables and channel assignment tables for disassembly and timing.

Symbol Tables

The TMS708 support supplies nine symbol-table files. In the 8101_SNG support, the 8101_SNG_Control file replaces specific Control group values with symbolic values. In the 8101_MLT support, the 8101_MLT_Control file replaces specific Control group values with symbolic values. Symbol files can be applied to a group when the radix Symbolic is chosen.

Symbol tables are generally not for use in timing or MSC8101_T support cycle type decoding.

8101_SNG Support

Tables 3--1 through 3--3 show the definitions for name, bit pattern, and meaning of the group symbols in the files 8101_SNG_Control, 8101_SNG_Chip_Sel, and 8101_SNG_Byte_Enb for 8101_SNG support.

Table 3 - 1: 8101_SNG_Control group symbol table definitions

Control group value

HRESET~ PSDCAS~ PSDA10 GBL~

SRESET~ PSDVAL~ PGTA~

Symbol

SDRAM_PRECHARGE 1 1 1 0 1 X0 X XXXX X #SDRAM Precharge

SDRAM_ACTIVATE/ GPCM_WAIT

SDRAM_REFRESH 1 1 1 0 0 X1 X XXXX X #SDRAM Refresh Command

SDRAM_W_ADDR_DATA 1 1 1 1 0 0 0 X XXXX X #SDRAM Write Address +

SDRAM_R_ADDR_DATA 1 1 1 1 0 0 1 X XXXX X #SDRAM Read Address Cycle

SDRAM_ADDR 1 1 1 1 0 1 1 X XXXX X #SDRAM Read Address Cycle

GPCM_R_ADDR_DATA 1 1 1 0 1 0 1 X XXXX X #GPCM Read Address + Data

GPCM_W_ADDR_DATA 1 1 1 1 1 0 0 X XXXX X #GPCM Write Address + Data

PORESET~ PSDWE~ BCTL1~

PSDRAS~/POE~~ PSDAMUX BCTL0~

1 1 1 0 1 1 1 X XXXX X #SDRAM Activate Command

Description

Command

or GPCM Wait Cycle

Data Cycle

+ Data for previous transaction

Cycle

TMS708 MSC8101 Microprocessor Software Support

3- 1

Reference: Symbol and Channel Assignment Tables

Table 3 - 1: 8101_SNG_Control group symbol table definitions (cont.)

Control group value

HRESET~ PSDCAS~ PSDA10 GBL~

SRESET~ PSDVAL~ PGTA~

Symbol Description

SDRAM_ROW_ADDR 1 1 1 0 XXXX XXXX X #SDRAM Row Address

SDRAM_COL_ADDR 1 1 1 X 0 XXX XXXX X #SDRAM Column Address

DATA 1 1 1 X X0 XX XXXX X #Data Cycle

IDLE_CYCLE 1 1 1 1 1 1 XX XXXX X #Idle Cycle (SDRAM CAS

HRESET 0 XXX XXXX XXXX X #Hardware Reset Cycle

SRESET X0 XX XXXX XXXX X #Software Reset Cycle

PORESET XX0 X XXXX XXXX X #Power On Reset Cycle

PORESET~ PSDWE~ BCTL1~

PSDRAS~/POE~~ PSDAMUX BCTL0~

Latency or GPCM Wait State)

Table 3 - 2: 8101_SNG_Chip_Sel group symbol table definitions

Chip_Sel group value

CS0~ CS4~

CS1~ CS5~

Symbol

CS2~ CS6~

CS3~ CS7~

Description

CS0~ 0111 1111 #Device 0 Selected

CS1~ 1011 1111 #Device 1 Selected

CS2~ 1101 1111 #Device 2 Selected

CS3~ 1110 1111 #Device 3 Selected

CS4~ 1111 0111 #Device 4 Selected

CS5~ 1111 1011 #Device 5 Selected

CS6~ 1111 1101 #Device 6 Selected

CS7~ 1111 1110 #Device 7 Selected

- 1111 1111 #No Devices Selected

Table 3 - 3: 8101_SNG_Byte_Enb group symbol table definitions

Byte_Enb group value

PWE0~ PWE4~

PWE1~ PWE5~

Symbol

D [0-7] 0111 1111 #Byte Lane 0 Selected

D [8-15] 1011 1111 #Byte Lane 1 Select ed

PWE2~ PWE6~

PWE3~ PWE7~

Description

3- 2

TMS708 MSC8101 Microprocessor Software Support

Reference: Symbol and Channel Assignment Tables

Table 3 - 3: 8101_SNG_Byte_Enb group symbol table definitions (cont.)

Byte_Enb group value

PWE0~ PWE4~

PWE1~ PWE5~

Symbol Description

D [16-23] 1101 1111 #Byte Lane 2 Selected

D [24-31] 1110 1111 #Byte Lane 3 Selected

D [32-39] 1111 0111 #Byte Lane 4 Selected

D [40-47] 1111 1011 #Byte Lane 5 Selected

D [48-55] 1111 1101 #Byte Lane 6 Selected

D [56-63] 1111 1110 #Byte Lane 7 Selected

D [0-15] 0011 1111 #Byte Lane 0-1 Selected

D [8-23] 1001 1111 #Byte Lane 1-2 Selected

D [16-31] 1100 1111 #Byte Lane 2-3 Selected

D [32-47] 1111 0011 #Byte Lane 4-5 Selected

D [40-55] 1111 1001 #Byte Lane 5-6 Selected

D [48-63] 1111 1100 #Byte Lane 6-7 Selected

D [0-23] 0001 1111 #Byte Lane 0-1-2 Selected

D [8-31] 1000 1111 #Byte Lane 1-2-3 Selected

D [32-55] 1111 0001 #Byte Lane 4-5-6 Selected

D [40-63] 1111 1000 #Byte Lane 5-6-7 Selected

D [0-31] 0000 1111 #Byte Lane 0-1-2-3 Selected

D [32-63] 1111 0000 #Byte Lane 4-5-6-7 Selected

D [0-63] 0000 0000 #All Byte Lanes Selected

- 1111 1111 #No Byte Lanes Selected

PWE2~ PWE6~

PWE3~ PWE7~

Information on basic operations describes how to use symbolic values for triggering and for displaying other channel groups symbolically, such as for the Address channel group.

TMS708 MSC8101 Microprocessor Software Support

3- 3

Reference: Symbol and Channel Assignment Tables

8101_MLT Support

Tables 3--4 through 3--9 show the definitions for name, bit pattern, and meaning of the group symbols in the files 8101_MLT_Control, 8101_MLT_Chip_Sel, 8101_MLT_T_Type, 8101_MLT_T_Size, 8101_MLT_T_Code, and 8101_MLT_Req_Grant for 8101_MLT support.

Table 3 - 4: 8101_MLT_Control group symbol table definitions

Control group value

TS~ PSDVAL~ ARTRY~

ALE DBB~

Symbol

TRANSFER_ERROR XXXX XXX0 X #Transfer Error Cycle

TRANSFER_START 0XXX 1X1X X #Transfer Start Cycle

ADDRESS_RETRY XXXX XXXX 0 #Address Retry Cycle

DATA XXXX 0 XXX X #Data

ADDRESS_LATCH X1 XX XXXX X #Address Latch Cycle

ADDRESS_ACK. XXX0 XXXX X #Address Acknowledge Cycle

TRANSFER_ACK. XXXX XX0 X X #Transfer Acknowledge Cycle

ADDR._BUS_BUSY XX0 X XXXX X #Address Bus Busy Cycle

DATA_BUS_BUSY XXXXX0XXX #Data Bus Busy Cycle

ABB~ TA~

AACK~ TEA~

Description

Table 3 - 5: 8101_MLT_Chip_Sel group symbol table definitions

Chip_Sel group value

CS0~ CS4~

CS1~ CS5~

Symbol

CS0~ 0111 1111 #Device 0 Selected

CS1~ 1011 1111 #Device 1 Selected

CS2~ 1101 1111 #Device 2 Selected

CS3~ 1110 1111 #Device 3 Selected

CS4~ 1111 0111 #Device 4 Selected

CS5~ 1111 1011 #Device 5 Selected

CS6~ 1111 1101 #Device 6 Selected

CS7~ 1111 1110 #Device 7 Selected

- 1111 1111 #No Devices Selected

CS2~ CS6~

CS3~ CS7~

Description

3- 4

TMS708 MSC8101 Microprocessor Software Support

Reference: Symbol and Channel Assignment Tables

Table 3 - 6: 8101_MLT_T_Type group symbol table definitions

T_Type group value

TS~ TT3

TT0 TT4

Symbol

RESERVED 0001 01 Reserved

RESERVED_FOR_CUSTOMER 01XX 01 Reserved for Customer

WRITE 0000 10 Write Transaction (Single

READ 0010 10 Read Transaction (Single

RESERVED 0101 10 Reserved

RESERVED 0000 11 Reserved

RESERVED 0001 11 Reserved

RESERVED 0011 11 Reserved

RESERVED_FOR_CUSTOMER 01XX 11 Reserved for Customer

TT1

TT2

Description

Beat or Burst)

Table 3 - 7: 8101_MLT_T_Size group symbol table definitions

T_Size group value

TS~ TSIZ2

TBST~ TSIZ3

Symbol

BYTE 0100 01 1 Byte Transaction

HALF_WORD 0100 10 2 Bytes Transaction

TRIPLE_BYTE 0100 11 3 Bytes Transaction

WORD 0101 00 4 Bytes Transaction

EXTENDED_5_BYTES 0101 01 Extended 5 Bytes

EXTENDED_6_BYTES 0101 10 Extended 6 Bytes

EXTENDED_7_BYTES 0101 11 Extended 7 Bytes

DOUBLE_WORD 0100 00 8 Bytes Transaction

BURST 00XX XX Burst Transaction

TSIZ0

TSIZ1

Description

Transaction

TMS708 MSC8101 Microprocessor Software Support

3- 5

Reference: Symbol and Channel Assignment Tables

Table 3 - 8: 8101_MLT_T_Code group symbol table definitions

Symbol

RESERVED 0000 Reserved

RESERVED 0001 Reserved

RESERVED 0010 Reserved

RESERVED 0011 Reserved

DMA 0100 DMA Source

SC140_CORE/DMA 0101 SC140 or DMA Source

SDMA_FUNCTION_CODE_0 0110 SDMA Function Code 0

SDMA_FUNCTION_CODE_1 0111 SDMA Function Code 1

T_Code group

value

TS~

TC0/BR0~

TC1/BG0~

TC2/DBG0~

Description

Source

NOTE. The T_Code group is applicable only in Internal Arbiter Mode.

Table 3 - 9: 8101_MLT_Req_Grant group symbol table definitions

Req_Grant group value

TCO/BR0~ TC1/BG0~ TC2/DBG0~

BR~ BG~ DBG~

Symbol

BG0_ADDRESS XXXX 0111 1111 #BG0~ Asserted

BG_ADDRESS XXXX 1011 1111 #BG~ Asserted

BG2_ADDRESS XXXX 1101 1111 #BG2~ Asserted

BG3_ADDRESS XXXX 1110 1111 #BG3~ Asserted

DBG0_DATA XXXX 1111 0111 #DBG0~ Asserted

DBG_DATA XXXX 1111 1011 #DBG~ Asserted

DBG2_DATA XXXX 1111 1101 #DBG2~ Asserted

DBG3_DATA XXXX 1111 1110 #DBG3~ Asserted

DP0~/EXT_BR2~ DP1/EXT_BG2~ DP2~/EXT_DBG2~

DP3~/EXT_BR3~ DP4~/EXT_BG3~ DP5~/EXT_DBG3~

Description

3- 6

TMS708 MSC8101 Microprocessor Software Support

Channel Assignment Tables

Channel assignments shown in Tables 3--10 through 3--25 use the following conventions:

H All signals are required by the support unless indicated otherwise.

H Channels are shown starting with the most significant bit (MSB) descending

to the least significant b it (LSB).

H Channel group assignments are for all modules unless otherwise noted.

H A tilde (~) following a signal name indicates an active low signal.

Reference: Symbol and Channel Assignment Tables

8101_SNG Support

Table 3--10 shows the probe section and channel assignments for the logic analyzer Address group and the microprocessor signal to which each channel connects. By default, this channel group is displayed in hexadecimal.

Table 3 - 10: Address group channel assignments for 8101_SNG support

Bit order MSC8101 signal name

A3:7 (MSB) A0

A3:6 A1

A3:5 A2

A3:4 A3

A3:3 A4

A3:2 A5

A3:1 A6

A3:0 A7

A2:7 A8

A2:6 A9

A2:5 A10

A2:4 A11

A2:3 A12

A2:2 A13

A2:1 A14

A2:0 A15

A1:7 A16

A1:6 A17

A1:5 A18

TMS708 MSC8101 Microprocessor Software Support

3- 7

Reference: Symbol and Channel Assignment Tables

Table 3 - 10: Address group channel assignments for 8101_SNG support (cont.)

Bit order MSC8101 signal name

A1:4 A19

A1:3 A20

A1:2 A21

A1:1 A22

A1:0 A23

A0:7 A24

A0:6 A25

A0:5 A26

A0:4 A27

A0:3 A28

A0:2 A29

A0:1 A30

A0:0 (LSB) A31

Table 3--11 shows the probe section and channel assignments for the Hi_Data group and the microprocessor signal to which each channel connects. By default, this channel group is displayed in hexadecimal.

Table 3 - 11: Hi_Data group channel assignments for 8101_SNG support

Bit order MSC8101 signal name

E3:7 (MSB) D0

E3:6 D1

E3:5 D2

E3:4 D3

E3:3 D4

E3:2 D5

E3:1 D6

E3:0 D7

3- 8

E2:7 D8

E2:6 D9

E2:5 D10

E2:4 D11

TMS708 MSC8101 Microprocessor Software Support

Reference: Symbol and Channel Assignment Tables

Table 3 - 11: Hi_Data group channel assignments for 8101_SNG support (cont.)

Bit order MSC8101 signal name

E2:3 D12

E2:2 D13

E2:1 D14

E2:0 D15

E1:7 D16

E1:6 D17

E1:5 D18

E1:4 D19

E1:3 D20

E1:2 D21

E1:1 D22

E1:0 D23

E0:7 D24

E0:6 D25

E0:5 D26

E0:4 D27

E0:3 D28

E0:2 D29

E0:1 D30

E0:0 D31

Table 3--12 shows the probe section and channel assignments for the Lo_Data group and the microprocessor signal to which each channel connects. By default, this channel group is displayed in hexadecimal.

Table 3 - 12: Lo_Data group channel assignments for 8101_SNG support

Bit order MSC8101 signal name

D3:7 D32

D3:6 D33

D3:5 D34

D3:4 D35

D3:3 D36

TMS708 MSC8101 Microprocessor Software Support

3- 9

Reference: Symbol and Channel Assignment Tables

Table 3 - 12: Lo_Data group channel assignments for 8101_SNG support (cont.)

Bit order MSC8101 signal name

D3:2 D37

D3:1 D38

D3:0 D39

D2:7 D40

D2:6 D41

D2:5 D42

D2:4 D43

D2:3 D44

D2:2 D45

D2:1 D46

D2:0 D47

D1:7 D48

D1:6 D49

D1:5 D50

D1:4 D51

D1:3 D52

D1:2 D53

D1:1 D54

D1:0 D55

D0:7 D56

D0:6 D57

D0:5 D58

D0:4 D59

D0:3 D60

D0:2 D61

D0:1 D62

D0:0 (LSB) D63

3- 10

TMS708 MSC8101 Microprocessor Software Support

Reference: Symbol and Channel Assignment Tables

Table 3--13 shows the probe section and channel assignments for the Control group and the microprocessor signal to which each channel connects. By default, this channel group is displayed as symbols.

Table 3 - 13: Control group channel assignments for 8101_SNG support

Bit order MSC8101 signal name

C1:1 HRESET~

C1:0 SRESET~

C0:6 PORESET~

C0:1 PSDRAS~/POE~

CLK:3 PSDCAS~

CLK:0 PSDVAL~

C1:7 PSDWE~

C1:4 PSDAMUX

C1:6 PSDA10

C1:5 PGTA~

C0:2 BCTL1~

C1:3 BCTL0~

C0:7 GBL~

Table 3--14 shows the probe section and channel assignments for the Chip_Sel group and the microprocessor signal to which each channel connects. By default, this channel group is displayed as symbols.

Table 3 - 14: Chip_Sel group channel assignments for 8101_SNG support

Bit order MSC8101 signal name

QUAL:3 CS0~

QUAL:2 CS1~

QUAL:0 CS2~

CLK:2 CS3~

C2:7 CS4~

C2:6 CS5~

C2:5 CS6~

C2:4 CS7~

TMS708 MSC8101 Microprocessor Software Support

3- 11

Reference: Symbol and Channel Assignment Tables

Table 3--15 shows the probe section and channel assignments for the Byte_Enb group and the microprocessor signal to which each channel connects. By default, this channel group is displayed as binary.

Table 3 - 15: Byte_Enb group channel assignments for 8101_SNG support

Bit order MSC8101 signal name

C3:7 PWE0~

C3:6 PWE1~

C3:5 PWE2~

C3:4 PWE3~

C3:3 PWE4~

C3:2 PWE5~

C3:1 PWE6~

C3:0 PWE7~

Table 3--16 shows the probe section and channel assignments for the logic analyzer Misc group and the microprocessor signal to which each channel connects. By default, this channel group is not visible.

Table 3 - 16: Misc group channel assignments for 8101_SNG support

Bit order MSC8101 signal name

CLK:1 CLKOUT

C0:5 NMI~

C1:2 NMI_OUT~

QUAL:1 IRQ7~/INT_OUT~

C0:4 DP6~/EXT_DACK3~

C0:3 DP7~/EXT_DACK4~

3- 12

TMS708 MSC8101 Microprocessor Software Support

Reference: Symbol and Channel Assignment Tables

8101_MLT Support

Table 3--17 shows the probe section and channel assignments for the logic analyzer Address group and the microprocessor signal to which each channel connects. By default, this channel group is displayed in hexadecimal.

Table 3 - 17: Address group channel assignments for 8101_MLT support

Bit order MSC8101 signal name

A3:7 (MSB) A0

A3:6 A1

A3:5 A2

A3:4 A3

A3:3 A4

A3:2 A5

A3:1 A6

A3:0 A7

A2:7 A8

A2:6 A9

A2:5 A10

A2:4 A11

A2:3 A12

A2:2 A13

A2:1 A14

A2:0 A15

A1:7 A16

A1:6 A17

A1:5 A18

A1:4 A19

A1:3 A20

A1:2 A21

A1:1 A22

A1:0 A23

A0:7 A24

A0:6 A25

A0:5 A26

A0:4 BADDR27/A27*

A0:3 BADDR28/A28*

TMS708 MSC8101 Microprocessor Software Support

3- 13

Reference: Symbol and Channel Assignment Tables

Table 3 - 17: Address group channel assignments for 8101_MLT support (cont.)

Bit order MSC8101 signal name

A0:2 BADDR29/A29*

A0:1 BADDR30/A30*

A0:0 (LSB) BADDR31/A31*

You can trigger on Burst Address increments only if BADDR[31-27] is connected to logic analyzer channels A0:[0-4]. For more details, refer to Triggering on Address in a Burst Transaction on page 1- 2.

Table 3--18 shows the probe section and channel assignments for the Hi_Data group and the microprocessor signal to which each channel connects. By default, this channel group is displayed in hexadecimal.

Table 3 - 18: Hi_Data group channel assignments for 8101_MLT support

Bit order MSC8101 signal name

E3:7 (MSB) D0

E3:6 D1

E3:5 D2

E3:4 D3

E3:3 D4

E3:2 D5

E3:1 D6

E3:0 D7

E2:7 D8

E2:6 D9

E2:5 D10

E2:4 D11

E2:3 D12

E2:2 D13

E2:1 D14

E2:0 D15

E1:7 D16

3- 14

E1:6 D17

E1:5 D18

TMS708 MSC8101 Microprocessor Software Support

Reference: Symbol and Channel Assignment Tables

Table 3 - 18: Hi_Data group channel assignments for 8101_MLT support (cont.)

Bit order MSC8101 signal name

E1:4 D19

E1:3 D20

E1:2 D21

E1:1 D22

E1:0 D23

E0:7 D24

E0:6 D25

E0:5 D26

E0:4 D27

E0:3 D28

E0:2 D29

E0:1 D30

E0:0 D31

Table 3--19 shows the probe section and channel assignments for the Lo_Data group and the microprocessor signal to which each channel connects. By default, this channel group is displayed in hexadecimal.

Table 3 - 19: Lo_Data group channel assignments for 8101_MLT support

Bit order MSC8101 signal name

D3:7 D32

D3:6 D33

D3:5 D34

D3:4 D35

D3:3 D36

D3:2 D37

D3:1 D38

D3:0 D39

D2:7 D40

D2:6 D41

D2:5 D42

D2:4 D43

TMS708 MSC8101 Microprocessor Software Support

3- 15

Reference: Symbol and Channel Assignment Tables

Table 3 - 19: Lo_Data group channel assignments for 8101_MLT support (cont.)

Bit order MSC8101 signal name

D2:3 D44

D2:2 D45

D2:1 D46

D2:0 D47

D1:7 D48

D1:6 D49

D1:5 D50

D1:4 D51

D1:3 D52

D1:2 D53

D1:1 D54

D1:0 D55

D0:7 D56

D0:6 D57

D0:5 D58

D0:4 D59

D0:3 D60

D0:2 D61

D0:1 D62

D0:0 (LSB) D63

Table 3--20 shows the probe section and channel assignments for the Control group and the microprocessor signal to which each channel connects. By default, this channel group is displayed as symbols.

Table 3 - 20: Control group channel assignments for 8101_MLT support

Bit order MSC8101 signal name

CLK:3 TS~

3- 16

C3:1 ALE

C3:6 ABB~

QUAL:1 AACK~

TMS708 MSC8101 Microprocessor Software Support

Reference: Symbol and Channel Assignment Tables

Table 3 - 20: Control group channel assignments for 8101_MLT support (cont .)

Bit order MSC8101 signal name

CLK:0 PSDVAL~

C2:7 DBB~

C0:3 TA~

C0:2 TEA~

C1:6 ARTRY~

Table 3--21 shows the probe section and channel assignments for the Chip_Sel group and the microprocessor signal to which each channel connects. By default, this channel group is displayed as symbols.

Table 3 - 21: Chip_Sel group channel assignments for 8101_MLT support

Bit order MSC8101 signal name

QUAL:3 CS0~

QUAL:2 CS1~

QUAL:0 CS2~

CLK:2 CS3~

C3:7 CS4~

C3:3 CS5~

C2:4 CS6~

C2:3 CS7~

Table 3--22 shows the probe section and channel assignments for the T_Type group and the microprocessor signal to which each channel connects. By default, this channel group is displayed as symbols.

Table 3 - 22: T_Type group channel assignments for 8101_MLT support

Bit order MSC8101 signal name

CLK:3 TS~

C1:0 TT0

C0:7 TT1

TMS708 MSC8101 Microprocessor Software Support

3- 17

Reference: Symbol and Channel Assignment Tables

Table 3 - 22: T_Type group channel assignments for 8101_MLT support (cont .)

Bit order MSC8101 signal name

C0:6 TT2

C0:5 TT3

C0:4 TT4

Table 3--23 shows the probe section and channel assignments for the T_Size group and the microprocessor signal to which each channel connects. By default, this channel group is displayed as symbols.

Table 3 - 23: T_Size group channel assignments for 8101_MLT support

Bit order MSC8101 signal name

CLK:3 TS~

C1:7 TBST~

C1:4 TSIZ0

C1:3 TSIZ1

C1:2 TSIZ2

C1:1 TSIZ3

Table 3--24 shows the probe section and channel assignments for the T_Code group and the microprocessor signal to which each channel connects. By default, this channel group is displayed as symbols.

Table 3 - 24: T_Code group channel assignments for 8101_MLT support

Bit order MSC8101 signal name

CLK:3 TS~

C0:1 TC0/BR0~

C0:0 TC1/BG0~

C2:6 TC2/DBG0~

3- 18

TMS708 MSC8101 Microprocessor Software Support

Reference: Symbol and Channel Assignment Tables

NOTE. The T_Code group is applicable only in Internal Arbiter Mode. For more details refer to T_Code Group in 8101_MLT Group on page 1--2.

Table 3--25 shows the probe section and channel assignments for the Req_Grant group and the microprocessor signal to which each channel connects. By default, this channel group is displayed as symbols.

Table 3 - 25: Req_Grant group channel assignments for 8101_MLT support

Bit order MSC8101 signal name

C0:1 TC0/BR0~*

C3:2 BR~

C3:4 DP0~/EXT_BR2~

C2:5 DP3~/EXT_BR3~

C0:0 TC1/BG0~*

C3:5 BG~

C2:2 DP1~/EXT_BG2~

C2:0 DP4~/EXT_BG3~

C2:6 TC2/DBG0~*

C3:0 DBG~

C2:1 DP2~/EXT_DBG2~

C1:5 DP5~/EXT_DBG3~

When you use the 8101_MLT support for Internal Arbiter configuration, connect the signals TC0-TC2 to C0:1, C0:0, and C2:6. For External Arbiter configuration, connect the signals BR0~, BG0~, and DBG0~ (request and grant signals from the fourth external master that is connected to the bus) to C0:1, C0:0, and C2:6.

TMS708 MSC8101 Microprocessor Software Support

3- 19

Reference: Symbol and Channel Assignment Tables

CPU To Mictor Connections

This section contains information about Mictor connections.

For design purposes, you may need to make connections between the CPU and the Mictor pins of the P6434 Mass Termination Probe. Refer to the P6434 Mass Termination Probe manual, Tektronix part number 070-9793-XX, for more information on mechanical specifications.

NOTE. To preserve signal quality in the target system, you should connect a 180

Ω resistor in series between each ball pad of the CPU and each pin of the Mictor connector. The resistor must be within 1/2 inch of the ball pad of the CPU.

The recommended pin assignment is the AMP pin assignment, because the AMP circuit board layout model and other commercial CAD packages use the AMP numbering scheme. See Table 3--26.

Table 3- 26: Recommended pin assignments for a Mictor connector (component

side)

Type of pin assignment Comments

Recommended. This pin assignment is the industry

Recommended

Pin 1

Pin 37

AMP Pin Assignment

Pin 2

Pin 38

standard and is what we recommend that you use.

3- 20

TMS708 MSC8101 Microprocessor Software Support

Reference: Symbol and Channel Assignment Tables

8101_SNG Support

Tables 3--27 through 3--30 show the mictor pin connections for the logic analyzer and the AMP mictors for the 8101_SNG support.

Table 3 - 27: CPU to Mictor connections for Mictor A pins for 8101_SNG support

Logic analyzer

AMP mictor pin number

Mictor A pin 05 CLOCK:0 PSDVAL~ Required

Mictor A pin 07 A3:7 A0 (MSB) Required

Mictor A pin 09 A3:6 A1 Required

Mictor A pin 11 A3:5 A2 Required

Mictor A pin 13 A3:4 A3 Required

Mictor A pin 15 A3:3 A4 Required

Mictor A pin 17 A3:2 A5 Required

Mictor A pin 19 A3:1 A6 Required

Mictor A pin 21 A3:0 A7 Required

Mictor A pin 23 A2:7 A8 Required

Mictor A pin 25 A2:6 A9 Required

Mictor A pin 27 A2:5 A10 Required

Mictor A pin 29 A2:4 A11 Required

Mictor A pin 31 A2:3 A12 Required

Mictor A pin 33 A2:2 A13 Required

Mictor A pin 35 A2:1 A14 Required

Mictor A pin 37 A2:0 A15 Required

Mictor A pin 38 A0:0 A31 Required

Mictor A pin 36 A0:1 A30 Required

Mictor A pin 34 A0:2 A29 Required

Mictor A pin 32 A0:3 A28 Required

Mictor A pin 30 A0:4 A27 Required

Mictor A pin 28 A0:5 A26 Required

Mictor A pin 26 A0:6 A25 Required

Mictor A pin 24 A0:7 A24 Required

Mictor A pin 22 A1:0 A23 Required

Mictor A pin 20 A1:1 A22 Required

Mictor A pin 18 A1:2 A21 Required

Mictor A pin 16 A1:3 A20 Required

Mictor A pin 14 A1:4 A19 Required

Mictor A pin 12 A1:5 A18 Required

acquisition channel

MSC8101 support package channel name

Required/Not required for disassembly

TMS708 MSC8101 Microprocessor Software Support

3- 21

Reference: Symbol and Channel Assignment Tables

Table 3 - 27: CPU to Mictor connections for Mictor A pins for 8101_SNG support (cont.)

Logic analyzer

AMP mictor pin number

Mictor A pin 10 A1:6 A17 Required

Mictor A pin 08 A1:7 A16 Required

Mictor A pin 06 CLOCK:1 CLKOUT Required

acquisition channel

MSC8101 support package channel name

Required/Not required for disassembly

Table 3 - 28: CPU to Mictor connections for Mictor C pins for 8101_SNG support

Logic analyzer

AMP mictor pin number

Mictor C pin 05 CLOCK:3 PSDCAS~ Required

Mictor C pin 07 C3:7 PWE0~ Required

Mictor C pin 09 C3:6 PWE1~ Required

Mictor C pin 11 C3:5 PWE2~ Required

Mictor C pin 13 C3:4 PWE3~ Required

Mictor C pin 15 C3:3 PWE4~ Required

Mictor C pin 17 C3:2 PWE5~ Required

Mictor C pin 19 C3:1 PWE6~ Required

Mictor C pin 21 C3:0 PWE7~ Required

Mictor C pin 23 C2:7 CS4~ Required

Mictor C pin 25 C2:6 CS5~ Required

Mictor C pin 27 C2:5 CS6~ Required

Mictor C pin 29 C2:4 CS7~ Required

Mictor C pin 31 C2:3 No connection Not required

Mictor C pin 33 C2:2 No connection Not required

Mictor C pin 35 C2:1 No connection Not required

Mictor C pin 37 C2:0 No connection Not required

Mictor C pin 38 C0:0 No connection Not required

Mictor C pin 36 C0:1 PSDRAS~/POE~ Required

Mictor C pin 34 C0:2 BCTL1~ Not required

Mictor C pin 32 C0:3 DP7~/DACK4~ Not required

Mictor C pin 30 C0:4 DP6~/DACK3~ Not required

Mictor C pin 28 C0:5 NMI~ Not required

Mictor C pin 26 C0:6 PORESET~ Required

Mictor C pin 24 C0:7 GBL~ Not required

Mictor C pin 22 C1:0 SRESET~ Required

acquisition channel

MSC8101 support package channel name

Required/Not required for disassembly

3- 22

TMS708 MSC8101 Microprocessor Software Support

Reference: Symbol and Channel Assignment Tables

Table 3 - 28: CPU to Mictor connections for Mictor C pins for 8101_SNG support (cont.)

Logic analyzer

AMP mictor pin number

Mictor C pin 20 C1:1 HRESET~ Required

Mictor C pin 18 C1:2 NMI_OUT~ Not required

Mictor C pin 16 C1:3 BCTL0~ Not required

Mictor C pin 14 C1:4 PSDAMUX Not required

Mictor C pin 12 C1:5 PGTA~ Not required

Mictor C pin 10 C1:6 PSDA10 Required

Mictor C pin 08 C1:7 PSDWE~ Required

Mictor C pin 06 QUAL:1 IRQ7~/INT_OUT~ Not required

acquisition channel

MSC8101 support package channel name

Required/Not required for disassembly

Table 3 - 29: CPU to Mictor connections for Mictor D pins for 8101_SNG support

Logic analyzer

AMP mictor pin number

Mictor D pin 05 QUAL:0 CS2~ Required

Mictor D pin 07 D3:7 D32 Required

Mictor D pin 09 D3:6 D33 Required

Mictor D pin 11 D3:5 D34 Required

Mictor D pin 13 D3:4 D35 Required

Mictor D pin 15 D3:3 D36 Required

Mictor D pin 17 D3:2 D37 Required

Mictor D pin 19 D3:1 D38 Required

Mictor D pin 21 D3:0 D39 Required

Mictor D pin 23 D2:7 D40 Required

Mictor D pin 25 D2:6 D41 Required

Mictor D pin 27 D2:5 D42 Required

Mictor D pin 29 D2:4 D43 Required

Mictor D pin 31 D2:3 D44 Required

Mictor D pin 33 D2:2 D45 Required

Mictor D pin 35 D2:1 D46 Required

Mictor D pin 37 D2:0 D47 Required

Mictor D pin 38 D0:0 D63 Required

Mictor D pin 36 D0:1 D62 Required

Mictor D pin 34 D0:2 D61 Required

Mictor D pin 32 D0:3 D60 Required

acquisition channel

MSC8101 support package channel name

Required/Not required for disassembly

TMS708 MSC8101 Microprocessor Software Support

3- 23

Reference: Symbol and Channel Assignment Tables

Table 3 - 29: CPU to Mictor connections for Mictor D pins for 8101_SNG support (cont.)

Logic analyzer

AMP mictor pin number

Mictor D pin 30 D0:4 D59 Required

Mictor D pin 28 D0:5 D58 Required

Mictor D pin 26 D0:6 D57 Required

Mictor D pin 24 D0:7 D56 Required

Mictor D pin 22 D1:0 D55 Required

Mictor D pin 20 D1:1 D54 Required

Mictor D pin 18 D1:2 D53 Required

Mictor D pin 16 D1:3 D52 Required

Mictor D pin 14 D1:4 D51 Required

Mictor D pin 12 D1:5 D50 Required

Mictor D pin 10 D1:6 D49 Required

Mictor D pin 08 D1:7 D48 Required

Mictor D pin 06 CLOCK:2 CS3~ Required

acquisition channel

MSC8101 support package channel name

Required/Not required for disassembly

Table 3 - 30: CPU to Mictor connections for Mictor E pins for 8101_SNG support

Logic analyzer

AMP mictor pin number

Mictor E pin 05 QUAL:3 CS0~ Required

Mictor E pin 07 E3:7 D0 (MSB) Required

Mictor E pin 09 E3:6 D1 Required

Mictor E pin 11 E3:5 D2 Required

Mictor E pin 13 E3:4 D3 Required

Mictor E pin 15 E3:3 D4 Required

Mictor E pin 17 E3:2 D5 Required

Mictor E pin 19 E3:1 D6 Required

Mictor E pin 21 E3:0 D7 Required

Mictor E pin 23 E2:7 D8 Required

Mictor E pin 25 E2:6 D9 Required

Mictor E pin 27 E2:5 D10 Required

Mictor E pin 29 E2:4 D11 Required

Mictor E pin 31 E2:3 D12 Required

Mictor E pin 33 E2:2 D13 Required

Mictor E pin 35 E2:1 D14 Required

acquisition channel

MSC8101 support package channel name

Required/Not required for disassembly

3- 24

TMS708 MSC8101 Microprocessor Software Support

Reference: Symbol and Channel Assignment Tables

Table 3 - 30: CPU to Mictor connections for Mictor E pins for 8101_SNG support (cont.)

Logic analyzer

AMP mictor pin number

Mictor E pin 37 E2:0 D15 Required

Mictor E pin 38 E0:0 D31 Required

Mictor E pin 36 E0:1 D30 Required

Mictor E pin 34 E0:2 D29 Required

Mictor E pin 32 E0:3 D28 Required

Mictor E pin 30 E0:4 D27 Required

Mictor E pin 28 E0:5 D26 Required

Mictor E pin 26 E0:6 D25 Required

Mictor E pin 24 E0:7 D24 Required

Mictor E pin 22 E1:0 D23 Required

Mictor E pin 20 E1:1 D22 Required

Mictor E pin 18 E1:2 D21 Required

Mictor E pin 16 E1:3 D20 Required

Mictor E pin 14 E1:4 D19 Required

Mictor E pin 12 E1:5 D18 Required

Mictor E pin 10 E1:6 D17 Required

Mictor E pin 08 E1:7 D16 Required

Mictor E pin 06 QUAL:2 CS1~ Required

acquisition channel

MSC8101 support package channel name

Required/Not required for disassembly

TMS708 MSC8101 Microprocessor Software Support

3- 25

Reference: Symbol and Channel Assignment Tables

8101_MLT Support

Tables 3--31 through 3--34 show the mictor pin connections for the logic analyzer and the AMP mictors for the 8101_MLT support.

Table 3 - 31: CPU to Mictor connections for Mictor A pins for 8101_MLT support

Logic analyzer

AMP mictor pin number

Mictor A pin 05 CLOCK:0 PSDVAL~ Required

Mictor A pin 07 A3:7 A0 (MSB) Required

Mictor A pin 09 A3:6 A1 Required

Mictor A pin 11 A3:5 A2 Required

Mictor A pin 13 A3:4 A3 Required

Mictor A pin 15 A3:3 A4 Required

Mictor A pin 17 A3:2 A5 Required

Mictor A pin 19 A3:1 A6 Required

Mictor A pin 21 A3:0 A7 Required

Mictor A pin 23 A2:7 A8 Required

Mictor A pin 25 A2:6 A9 Required

Mictor A pin 27 A2:5 A10 Required

Mictor A pin 29 A2:4 A11 Required

Mictor A pin 31 A2:3 A12 Required

Mictor A pin 33 A2:2 A13 Required

Mictor A pin 35 A2:1 A14 Required

Mictor A pin 37 A2:0 A15 Required

Mictor A pin 38 A0:0 BADDR31/A31* Required

Mictor A pin 36 A0:1 BADDR30/A30* Required

Mictor A pin 34 A0:2 BADDR29/A29* Required

Mictor A pin 32 A0:3 BADDR28/A28* Required

Mictor A pin 30 A0:4 BADDR27A27* Required

Mictor A pin 28 A0:5 A26 Required

Mictor A pin 26 A0:6 A25 Required

Mictor A pin 24 A0:7 A24 Required

Mictor A pin 22 A1:0 A23 Required

Mictor A pin 20 A1:1 A22 Required

Mictor A pin 18 A1:2 A21 Required

Mictor A pin 16 A1:3 A20 Required

Mictor A pin 14 A1:4 A19 Required

Mictor A pin 12 A1:5 A18 Required

acquisition channel

MSC8101 support package channel name

Required/Not required for disassembly

3- 26

TMS708 MSC8101 Microprocessor Software Support

Reference: Symbol and Channel Assignment Tables

Table 3 - 31: CPU to Mictor connections for Mictor A pins for 8101_MLT support (cont.)

Logic analyzer

AMP mictor pin number

Mictor A pin 10 A1:6 A17 Required

Mictor A pin 08 A1:7 A16 Required

Mictor A pin 06 CLOCK:1 CLKOUT Required

acquisition channel

MSC8101 support package channel name

Required/Not required for disassembly

Table 3 - 32: CPU to Mictor connections for Mictor C pins for 8101_MLT support

Logic analyzer

AMP mictor pin number

Mictor C pin 05 CLOCK:3 TS~ Required

Mictor C pin 07 C3:7 CS4~ Required

Mictor C pin 09 C3:6 ABB~ Required

Mictor C pin 11 C3:5 BG~ Required

Mictor C pin 13 C3:4 DP0~/EXT_BR2~ Not required

Mictor C pin 15 C3:3 CS5~ Required

Mictor C pin 17 C3:2 BR~ Not required

Mictor C pin 19 C3:1 ALE Required

Mictor C pin 21 C3:0 DBG~ Required

Mictor C pin 23 C2:7 DBB~ Required

Mictor C pin 25 C2:6 TC2/DBG0~* Required

Mictor C pin 27 C2:5 DP3~/EXT_BR3~ Not required

Mictor C pin 29 C2:4 CS6~ Required

Mictor C pin 31 C2:3 CS7~ Required

Mictor C pin 33 C2:2 DP1~/EXT_BG2~ Required

Mictor C pin 35 C2:1 DP2~/EXT_DBG2~ Required

Mictor C pin 37 C2:0 DP4~/EXT_BG3~ Required

Mictor C pin 38 C0:0 TC1/BG0~* Required

Mictor C pin 36 C0:1 TC0/BR0~* Required for Internal Arbi-

Mictor C pin 34 C0:2 TEA~ Required

Mictor C pin 32 C0:3 TA~ Required

Mictor C pin 30 C0:4 TT4 Required

acquisition channel

MSC8101 support package channel name

Required/Not required for disassembly

ter Mode Not Required for External Arbiter Mode

TMS708 MSC8101 Microprocessor Software Support

3- 27

Reference: Symbol and Channel Assignment Tables

Table 3 - 32: CPU to Mictor connections for Mictor C pins for 8101_MLT support (cont.)

Logic analyzer

AMP mictor pin number

Mictor C pin 28 C0:5 TT3 Required

Mictor C pin 26 C0:6 TT2 Required

Mictor C pin 24 C0:7 TT1 Required

Mictor C pin 22 C1:0 TT0 Required

Mictor C pin 20 C1:1 TSIZ3 Required

Mictor C pin 18 C1:2 TSIZ2 Required

Mictor C pin 16 C1:3 TSIZ1 Required

Mictor C pin 14 C1:4 TSIZ0 Required

Mictor C pin 12 C1:5 DP5~/EXT_DBG3~ Required

Mictor C pin 10 C1:6 ARTRY~ Required

Mictor C pin 08 C1:7 TBST~ Required

Mictor C pin 06 QUAL:1 AACK~ Required

When you use the 8101_MLT support for Internal Arbiter configuration, connect the signals TC0-TC2 to C0:0, C0:0, and C2:6. For External Arbiter configuration, connect the signals BR0~, BG0~, and DBG0~ (request and grant signals from the fourth external master that is connected to the bus) to C0:1, C0:0, and C2:6.

acquisition channel

MSC8101 support package channel name

Required/Not required for disassembly

Table 3 - 33: CPU to Mictor connections for Mictor D pins for 8101_MLT support

Logic analyzer

AMP mictor pin number

Mictor D pin 05 QUAL:0 CS2~ Required

Mictor D pin 07 D3:7 D32 Required

Mictor D pin 09 D3:6 D33 Required

Mictor D pin 11 D3:5 D34 Required

Mictor D pin 13 D3:4 D35 Required

Mictor D pin 15 D3:3 D36 Required

Mictor D pin 17 D3:2 D37 Required

Mictor D pin 19 D3:1 D38 Required

Mictor D pin 21 D3:0 D39 Required

Mictor D pin 23 D2:7 D40 Required

Mictor D pin 25 D2:6 D41 Required

Mictor D pin 27 D2:5 D42 Required

Mictor D pin 29 D2:4 D43 Required

Mictor D pin 31 D2:3 D44 Required

acquisition channel

MSC8101 support package channel name

Required/Not required for disassembly

3- 28

TMS708 MSC8101 Microprocessor Software Support

Reference: Symbol and Channel Assignment Tables

Table 3 - 33: CPU to Mictor connections for Mictor D pins for 8101_MLT support (cont.)

Logic analyzer

AMP mictor pin number

Mictor D pin 33 D2:2 D45 Required

Mictor D pin 35 D2:1 D46 Required

Mictor D pin 37 D2:0 D47 Required

Mictor D pin 38 D0:0 D63 Required

Mictor D pin 36 D0:1 D62 Required

Mictor D pin 34 D0:2 D61 Required

Mictor D pin 32 D0:3 D60 Required

Mictor D pin 30 D0:4 D59 Required

Mictor D pin 28 D0:5 D58 Required

Mictor D pin 26 D0:6 D57 Required

Mictor D pin 24 D0:7 D56 Required

Mictor D pin 22 D1:0 D55 Required

Mictor D pin 20 D1:1 D54 Required

Mictor D pin 18 D1:2 D53 Required

Mictor D pin 16 D1:3 D52 Required

Mictor D pin 14 D1:4 D51 Required

Mictor D pin 12 D1:5 D50 Required

Mictor D pin 10 D1:6 D49 Required

Mictor D pin 08 D1:7 D48 Required

Mictor D pin 06 CLOCK:2 CS3~ Required

acquisition channel

MSC8101 support package channel name

Required/Not required for disassembly

Table 3 - 34: CPU to Mictor connections for Mictor E pins for 8101_MLT support

Logic analyzer

AMP mictor pin number

Mictor E pin 05 QUAL:3 CS0~ Required

Mictor E pin 07 E3:7 D0 (MSB) Required

Mictor E pin 09 E3:6 D1 Required

Mictor E pin 11 E3:5 D2 Required

Mictor E pin 13 E3:4 D3 Required

Mictor E pin 15 E3:3 D4 Required

Mictor E pin 17 E3:2 D5 Required

Mictor E pin 19 E3:1 D6 Required

Mictor E pin 21 E3:0 D7 Required

acquisition channel

MSC8101 support package channel name

Required/Not required for disassembly

TMS708 MSC8101 Microprocessor Software Support

3- 29

Reference: Symbol and Channel Assignment Tables

Table 3 - 34: CPU to Mictor connections for Mictor E pins for 8101_MLT support (cont.)

Logic analyzer

AMP mictor pin number

Mictor E pin 23 E2:7 D8 Required

Mictor E pin 25 E2:6 D9 Required

Mictor E pin 27 E2:5 D10 Required

Mictor E pin 29 E2:4 D11 Required

Mictor E pin 31 E2:3 D12 Required

Mictor E pin 33 E2:2 D13 Required

Mictor E pin 35 E2:1 D14 Required

Mictor E pin 37 E2:0 D15 Required

Mictor E pin 38 E0:0 D31 Required

Mictor E pin 36 E0:1 D30 Required

Mictor E pin 34 E0:2 D29 Required

Mictor E pin 32 E0:3 D28 Required

Mictor E pin 30 E0:4 D27 Required

Mictor E pin 28 E0:5 D26 Required

Mictor E pin 26 E0:6 D25 Required

Mictor E pin 24 E0:7 D24 Required

Mictor E pin 22 E1:0 D23 Required

Mictor E pin 20 E1:1 D22 Required

Mictor E pin 18 E1:2 D21 Required

Mictor E pin 16 E1:3 D20 Required

Mictor E pin 14 E1:4 D19 Required

Mictor E pin 12 E1:5 D18 Required

Mictor E pin 10 E1:6 D17 Required

Mictor E pin 08 E1:7 D16 Required

Mictor E pin 06 QUAL:2 CS1~ Required

acquisition channel

MSC8101 support package channel name

Required/Not required for disassembly

3- 30

TMS708 MSC8101 Microprocessor Software Support

Specifications

Specification Tables

This section contains the specifications for the support.

Table 4--1 lists the electrical requirements the target system must produce for the support to acquire correct data.

Table 4 - 1: Electrical specifications

Characteristics Requirements

Target system clock rate

8101_SNG specified clock rate Maximum 100 MHz

8101_SNG tested clock rate Maximum 50 MHz

8101_MLT specified clock rate Maximum 100 MHz

8101_MLT tested clock rate Maximum 66 MHz

Minimum setup time required 2.5 ns

Minimum hold time required 0ns

TMS708 MSC8101 Microprocessor Software Support

4- 1

Specifications

4- 2

TMS708 MSC8101 Microprocessor Software Support

Replaceable Parts List

Replaceable Parts Lists

This section contains a list of the replaceable components and modules for the TMS708 MSC8101 support. Use this list to identify and order replacement parts.

Parts Ordering Information

Replacement parts are available through your local Tektronix field office or representative.

Changes to Tektronix products are sometimes made to accommodate improved components as they become available and to give you the benefit of the latest improvements. Therefore, when ordering parts, it is important to include the following information in your order:

H Part number

H Instrument type or model number

H Instrument serial number

H Instrument modification number, if applicable

If you order a part that has been replaced with a different or improved part, your local Tektronix field office or representative will contact you concerning any change in part number.

Using the Replaceable Parts List

The tabular information in the Replaceable Parts List is arranged for quick retrieval. Understanding the structure and features of the list will help you find all of the information you need for ordering replacement parts. The following table describes the content of each column in the parts list.

TMS708 MSC8101 Microprocessor Software Support

5- 1

Replaceable Parts List

Parts list column descriptions

Column Column name Description

1 Figure & index number Items in this section are referenced by figure and index numbers to the exploded view

illustrations that follow.

2 Tektronix part number Use this part number when ordering replacement parts from Tektronix.

3 and 4 Serial number Column three indicates the serial number at which the part was first effective. Column four

indicates the serial number at which the part was discontinued. No entry indicates the part is good for all serial numbers.

5 Qty This indicates the quantity of parts used.

6 Name & description An item name is separated from the description by a colon (:). Because of space limitations, an

item name may sometimes appear as incomplete. Use the U.S. Federal Catalog handbook H6-1 for further item name identification.

7 Mfr. code This indicates the code of the actual manufacturer of the part.

8 Mfr. part number This indicates the actual manufacturer’s or vendor’s part number.

Abbreviations

Chassis Parts

Mfr. Code to Manufacturer

Cross Index

Abbreviations conform to American National Standard ANSI Y1.1--1972.

Chassis-mounted parts and cable assemblies are located at the end of the Replaceable Parts List.

The table titled Manufacturers Cross Index shows codes, names, and addresses of manufacturers or vendors of components listed in the parts list.

5- 2

TMS708 MSC8101 Microprocessor Software Support

Replaceable Parts List

Manufacturers cr oss index

Mfr. code

80009 TEKTRONIX, INC. P.O. BOX 500 BEAVERTON, OR, 97077-0001

Manufacturer Address City, state, zip code

Replaceable parts list

Fig. & index number

Tektronix part number

071-1117-00 1 MANUAL,TECH INSTRUCTIONS,MSC8101;TMS708 80009 071-1117-00

Serial no. effective

Serial no. discont’d

Qty Name & description

STANDARD ACCESSORIES

Mfr. code

Mfr. part number

TMS708 MSC8101 Microprocessor Software Support

5- 3

Replaceable Parts List

5- 4

TMS708 MSC8101 Microprocessor Software Support

Index

About this manual set, vii Acquiring data, 2--5 Acquisition setup, 2--3 Address, Tektronix, viii Address group, channel assignments, 3--7, 3--13 Address Pipelining, 1 --3 AMP, pin assignment recommended, 3--20 Application, logic analyzer configuration, 1--2 Arbiter, 2--17

Basic operations, where to find information, vii Bus cycles, displayed cycle types, 2--9 Byte_Enb group

channel assignments, 3--12 symbol table, 3--2

CAS latency, 2--14 Channel assignments

Address group, 3--7, 3--13 Byte_Enb group, 3--12 Chip_Sel group, 3--11, 3--17 Control group, 3--11, 3--16 Hi_Data group, 3--8, 3--14 Lo_Data group, 3--9, 3--15 Misc group, 3--12 Req_Grant group, 3--19 T_Code group, 3--18 T_Size group, 3--18 T_Type group, 3--17

Channel groups, 2--1

8101_MLT support, 2--2 8101_SNG support, 2--2 visibility, 2-- 8

Chip_Sel group

channel assignments, 3--11, 3--17

symbol table, 3--2, 3--4 Channel Groups, 1--4 Clock rate, 1--2

target system, 4--1 Clocking

custom, how data is acquired, 2--3

options, 2--3 Connecting to a target system, 1--6

Connections, CPU to Mictor, 3--20 Contacting Tektronix, viii Control group

channel assignments, 3--11, 3--16 symbol table, 3--1, 3--4

CPU to Mictor connections, 3--20

for 8101_MLT support, 3--26

for 8101_SNG support, 3--21 CS0~, 2--15, 2-- 19 CS1~, 2--15, 2-- 19 CS2~, 2--15, 2-- 19 CS3~, 2--16, 2-- 19 CS4~, 2--16, 2-- 19 CS5~, 2--16, 2-- 20 CS6~, 2--17, 2-- 20 CS7~, 2--17, 2-- 20 Custom clocking, how data is acquired, 2--3 Custom options, 2--3 Cycle type labels, viewing, 2--8 Cycle types

8101_MLT support, 2--10

8101_SNG support, 2--9

general , 2--11

Data

acquiring, 2--5

disassembly formats, Hardware, 2--9 Data display, changing, 2--13 Decoded cycle type labels, viewing an example, 2--23 Definitions

disassembler, vii

information on basic operations, vii

logic analyzer, vii Demonstration file, 2--23 Disassembled data, cycle type definitions, 2--9 Disassembler

definition, vii

logic analyzer configuration, 1--2

setup, 2--1 Display formats

Hardware, 2-- 9

Special characters, 2 --9 DMA cycles, Functionality not supported, 1--5

EAV bit setting in 8101_SNG support, 1--3

TMS708 MSC8101 Microprocessor Software Support

Index- 1

Index

Electrical specifications, 4--1

clock rate, 4--1

Exception labels, 2--21

Functionality not supported, 1--5

DMA cycles, 1--5 HDI16 cycles, 1--5 local bus cycles, 1--5 multiple master mode, 1--5 UPM cycles, 1--5

Functionality supported but not tested, 1--5

Hardware display format, 2--9

cycle type definitions, 2--9 HDI16 cycles, Functionality not supported, 1--5 Hi_Data group, channel assignments, 3--8, 3--14 Hold time, minimum, 4 --1

CS3~, 2--16, 2-- 19 CS4~, 2--16, 2-- 19 CS5~, 2--16, 2-- 20 CS6~, 2--17, 2-- 20 CS7~, 2--17, 2-- 20 Idle Cycles, 2--14, 2--17 Show Cycles Of, 2--18 Signals Connected Are, 2--18 Vector Base Address, 2--14, 2--18

Microprocessor, specific clocking and how data is

acquired, 2--3

Mictor to CPU connections, 3--20

for 8101_MLT support, 3--26

for 8101_SNG support, 3--21 Misc group, channel assignments, 3--12 Multiple master mode, Functionality not supported, 1--5

Nonintrusive acquisition, 1--3

Optional display selections, 2--14

Idle Cycles, 2--14, 2--17

Lo_Data group, channel assignments, 3--9, 3--15 Local bus cycles, Functionality not supported, 1--5 Logic analyzer

configuration for application, 1--2 configuration for disassembler, 1--2 software compatibility, 1--1

Logic analyzer, definition, vi i

Manual

conventions, vii

how to use the set, vii Marking cycles, 2--20 Micro specific fields

8101_MLT support, 2--17

8101_SNG support, 2--14

Arbiter, 2--17

CAS latency, 2--14

CS0~, 2--15, 2-- 19

CS1~, 2--15, 2-- 19

CS2~, 2--15, 2-- 19

P6434 probes, 1--6 Phone number, Tektronix, viii Pin assignment, AMP recommended, 3--20 Product support, contact information, viii

Qualifiers used in 8101_MLT support, 1--3

Reference memory, 2--23 Req_Grant group

channel assignments, 3--19

symbol table, 3--6 Reset, target system hardware, 1--2 Restrictions, 1--2

Service support, contact information, viii Set up time, minimum, 4--1

Index- 2

TMS708 MSC8101 Microprocessor Software Support

Index

Setups

disassembler, 2--1

support, 2--1 Show Cycles Of, 2--18 Signal acquisition

8101_MLT support, 2--7

8101_SNG support, 2--5 Signals Connected Are, 2--18 Signals not required, 1--3 Special characters displayed, 2--9 Specifications, electrical, 4 --1 Support, setup, 2--1 Support setup, 2--1 Symbol table

Byte_Enb channel group, 3--2

Chip_Sel channel group, 3--2, 3--4

Control channel group, 3--1, 3--4

Req_Grant channel group, 3--6

T_Code channel group, 3--6

T_Size channel group, 3--5

T_Type channel group, 3--5 System file, demonstration, 2--23

T_Code group in 8101_MLT support, 1--2 T_Size group

channel assignments, 3--18 symbol table, 3--5

T_Type group

channel assignments, 3--17

symbol table, 3--5 Table conventions, channel assignments, 3--7 Target system hardware reset, 1--2 Technical support, contact information, viii Tektronix, contacting, viii Timing Display Format, 1--4 Triggering, Burst transaction, 1--2

UPM cycles, Functionality not supported, 1--5 URL, Tektronix, viii

Vector Base Address, 2--14, 2--18 Viewing cycle type labels, 2--8

T_Code group

channel assignments, 3--18 symbol table, 3--6

Web site address, Tektronix, viii

TMS708 MSC8101 Microprocessor Software Support

Index- 3

Index

Index- 4

TMS708 MSC8101 Microprocessor Software Support

Tektronix TMS708 Instruction Manual
