Tektronix TMS164 Instruction Manual

Instruction Manual

TMS 164
i960 Hx Microprocessor Support

070-9818-00

There are no current European directives that
apply to this product. This product provides
cable and test lead connections to a test object of
electronic measuring and test equipment.

Warning

The servicing instructions are for use by
qualified personnel only. To avoid personal
injury, do not perform any servicing unless you
are qualified to do so. Refer to all safety
summaries prior to performing service.

Copyright  T ektronix, Inc. All rights reserved. Licensed software products are owned by Tektronix or its suppliers and are
protected by United States copyright laws and international treaty provisions.

Use, duplication, or disclosure by the Government is subject to restrictions as set forth in subparagraph (c)(1)(ii) of the
Rights in T echnical Data and Computer Software clause at DFARS 252.227-7013, or subparagraphs (c)(1) and (2) of the
Commercial Computer Software – Restricted Rights clause at F AR 52.227-19, as applicable.

T ektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supercedes
that in all previously published material. Specifications and price change privileges reserved.

Printed in the U.S.A.

T ektronix, Inc., P.O. Box 1000, Wilsonville, OR 97070–1000
TEKTRONIX and TEK are registered trademarks of T ektronix, Inc.

SOFTWARE WARRANTY

T ektronix warrants that the media on which this software product is furnished and the encoding of the programs on
the media will be free from defects in materials and workmanship for a period of three (3) months from the date of
shipment. If a medium or encoding proves defective during the warranty period, T ektronix will provide a
replacement in exchange for the defective medium. Except as to the media on which this software product is
furnished, this software product is provided “as is” without warranty of any kind, either express or implied.
T ektronix does not warrant that the functions contained in this software product will meet Customer’s
requirements or that the operation of the programs will be uninterrupted or error-free.

In order to obtain service under this warranty, Customer must notify Tektronix of the defect before the expiration
of the warranty period. If T ektronix is unable to provide a replacement that is free from defects in materials and
workmanship within a reasonable time thereafter, Customer may terminate the license for this software product
and return this software product and any associated materials for credit or refund.

THIS WARRANTY IS GIVEN BY TEKTRONIX IN LIEU OF ANY OTHER WARRANTIES, EXPRESS
OR IMPLIED. TEKTRONIX AND ITS VENDORS DISCLAIM ANY IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. TEKTRONIX’
RESPONSIBILITY TO REPLACE DEFECTIVE MEDIA OR REFUND CUSTOMER’S PAYMENT IS
THE SOLE AND EXCLUSIVE REMEDY PROVIDED TO THE CUSTOMER FOR BREACH OF THIS
WARRANTY. TEKTRONIX AND ITS VENDORS WILL NOT BE LIABLE FOR ANY INDIRECT,
SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF WHETHER
TEKTRONIX OR THE VENDOR HAS ADVANCE NOTICE OF THE POSSIBILITY OF SUCH
DAMAGES.

HARDWARE WARRANTY

T ektronix warrants that the products that it manufactures and sells will be free from defects in materials and
workmanship for a period of one (1) year from the date of shipment. If a product proves defective during this
warranty period, T ektronix, at its option, either will repair the defective product without charge for parts and labor,
or will provide a replacement in exchange for the defective product.

In order to obtain service under this warranty, Customer must notify Tektronix of the defect before the expiration
of the warranty period and make suitable arrangements for the performance of service. Customer shall be
responsible for packaging and shipping the defective product to the service center designated by T ektronix, with
shipping charges prepaid. Tektronix shall pay for the return of the product to Customer if the shipment is to a
location within the country in which the T ektronix service center is located. Customer shall be responsible for
paying all shipping charges, duties, taxes, and any other charges for products returned to any other locations.

This warranty shall not apply to any defect, failure or damage caused by improper use or improper or inadequate
maintenance and care. T ektronix shall not be obligated to furnish service under this warranty a) to repair damage
resulting from attempts by personnel other than T ektronix representatives to install, repair or service the product;
b) to repair damage resulting from improper use or connection to incompatible equipment; c) to repair any
damage or malfunction caused by the use of non-T ektronix supplies; or d) to service a product that has been
modified or integrated with other products when the effect of such modification or integration increases the time
or difficulty of servicing the product.

THIS WARRANTY IS GIVEN BY TEKTRONIX IN LIEU OF ANY OTHER WARRANTIES, EXPRESS
OR IMPLIED. TEKTRONIX AND ITS VENDORS DISCLAIM ANY IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. TEKTRONIX’
RESPONSIBILITY TO REPAIR OR REPLACE DEFECTIVE PRODUCTS IS THE SOLE AND
EXCLUSIVE REMEDY PROVIDED TO THE CUST OMER FOR BREACH OF THIS WARRANTY.
TEKTRONIX AND ITS VENDORS WILL NOT BE LIABLE FOR ANY INDIRECT , SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF WHETHER TEKTRONIX OR
THE VENDOR HAS ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.

Table of Contents

Getting Started

Operating Basics

General Safety Summary v. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Service Safety Summary vii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Preface: Microprocessor Support Documentation ix. . . . . . . . . . . . . . . .

Manual Conventions ix. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Logic Analyzer Documentation x. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Contacting T ektronix x. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Product Description 1–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Logic Analyzer System Software Compatibility 1–2. . . . . . . . . . . . . . . . . . . . . . . . .

Logic Analyzer Configuration 1–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Requirements and Restrictions 1–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Configuring the Probe Adapter 1–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Connecting to a System Under T est 1–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Applying and Removing Power 1–8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Setting Up the Support 2–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Channel Group Definitions 2–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Clocking Options 2–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Symbols 2–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Acquiring and Viewing Disassembled Data 2–7. . . . . . . . . . . . . . . . . . . . .

Acquiring Data 2–7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Viewing Disassembled Data 2–7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Hardware Display Format 2–8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Software Display Format 2–10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Control Flow Display Format 2–11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Subroutine Display Format 2–12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Changing How Data is Displayed 2–12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Optional Display Selections 2–12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Marking Cycles 2–13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Viewing an Example of Disassembled Data 2–14. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Specifications

Probe Adapter Description 3–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Configuring the Probe Adapter 3–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Specifications 3–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Channel Assignments 3–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

How Data is Acquired 3–10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Custom Clocking 3–10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Clocking Options 3–13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Alternate Microprocessor Connections 3–14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Signals Not on the Probe Adapter 3–14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TMS 164 i960 HX Microprocessor Support Instruction Manual

i

Table of Contents

Maintenance

Probe Adapter Circuit Description 4–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Replacing Signal Leads 4–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Replacing Protective Sockets 4–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Replacing the Fuse 4–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Replaceable Electrical Parts

Parts Ordering Information 5–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Using the Replaceable Electrical Parts List 5–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Replaceable Mechanical Parts

Parts Ordering Information 6–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Using the Replaceable Mechanical Parts List 6–1. . . . . . . . . . . . . . . . . . . . . . . . . . .

Index

ii

TMS 164 i960 HX Microprocessor Support Instruction Manual

List of Figures

Table of Contents

Figure 1–1: Location of the DIP switches on the probe adapter 1–3. . . . .

Figure 1–2: Placing a microprocessor into a PGA probe adapter 1–6. . .

Figure 1–3: Placing a PGA probe adapter onto the SUT 1–7. . . . . . . . . .

Figure 1–4: Connecting the LO cable to an LAHDP2 probe 1–8. . . . . . .

Figure 1–5: Location of the power jack 1–9. . . . . . . . . . . . . . . . . . . . . . . . .

Figure 2–1: Hardware display format 2–10. . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 3–1: Minimum clearance of the standard probe adapter 3–4. . . .

Figure 3–2: i960 Hx bus timing 3–11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 4–1: Location of the fuse 4–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6–1: i960 Hx probe adapter exploded view 6–4. . . . . . . . . . . . . . . .

TMS 164 i960 HX Microprocessor Support Instruction Manual

iii

Table of Contents

List of Tables

Table 1–1: Product support 1–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 1–2: PMCON register entry and DIP switch settings 1–4. . . . . . . .

Table 1–3: Address region and DIP switch assignments 1–4. . . . . . . . . . .

Table 2–1: Control Group symbol table definitions 2–2. . . . . . . . . . . . . .

Table 2–2: Initialization Boot record (IBR) symbol table 2–3. . . . . . . . .

Table 2–3: Process Control Block (PRCB) symbol table 2–4. . . . . . . . . .

Table 2–4: Control Table symbol table* 2–4. . . . . . . . . . . . . . . . . . . . . . . .

Table 2–5: Interrupt Table symbol table 2–5. . . . . . . . . . . . . . . . . . . . . . .

Table 2–6: Fault Table symbol table 2–6. . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 2–7: Meaning of special characters in the display 2–8. . . . . . . . . .

Table 2–8: Cycle type definitions 2–8. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 2–9: Interrupt or Exception label definitions 2–9. . . . . . . . . . . . . .

Table 2–10: Optional display selections 2–12. . . . . . . . . . . . . . . . . . . . . . . .

Table 2–11: Refetch behavior example 2–13. . . . . . . . . . . . . . . . . . . . . . . . .

Table 3–1: Electrical specifications 3–2. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3–2: Environmental specifications* 3–3. . . . . . . . . . . . . . . . . . . . . .

Table 3–3: Certifications and compliances 3–3. . . . . . . . . . . . . . . . . . . . . .

Table 3–4: Address group channel assignments 3–5. . . . . . . . . . . . . . . . .

Table 3–5: Data group channel assignments 3–6. . . . . . . . . . . . . . . . . . . .

Table 3–6: Control group channel assignments 3–8. . . . . . . . . . . . . . . . . .

Table 3–7: ByteEnbl group channel assignments 3–8. . . . . . . . . . . . . . . .

Table 3–8: Aux group channel assignments 3–9. . . . . . . . . . . . . . . . . . . . .

Table 3–9: Misc group channel assignments 3–9. . . . . . . . . . . . . . . . . . . .

Table 3–10: Clock channel assignments 3–10. . . . . . . . . . . . . . . . . . . . . . . .

Table 3–11: Synthesized signals 3–13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3–12: Signals not on the probe adapter 3–14. . . . . . . . . . . . . . . . . . .

iv

TMS 164 i960 HX Microprocessor Support Instruction Manual

General Safety Summary

Review the following safety precautions to avoid injury and prevent damage to
this product or any products connected to it. To avoid potential hazards, use this
product only as specified.

Only qualified personnel should perform service procedures.

While using this product, you may need to access other parts of the system. Read
the General Safety Summary in other system manuals for warnings and cautions
related to operating the system.

To Avoid Fire or
Personal Injury

Use Proper Power Cord. Use only the power cord specified for this product and

certified for the country of use.
Connect and Disconnect Properly . Do not connect or disconnect probes or test

leads while they are connected to a voltage source.
Observe All Terminal Ratings. To avoid fire or shock hazard, observe all ratings

and marking on the product. Consult the product manual for further ratings
information before making connections to the product.

Do not apply a potential to any terminal, including the common terminal, that
exceeds the maximum rating of that terminal.

Use Proper AC Adapter. Use only the AC adapter specified for this product.
Do Not Operate Without Covers. Do not operate this product with covers or panels

removed.

Use Proper Fuse. Use only the fuse type and rating specified for this product.
Avoid Exposed Circuitry. Do not touch exposed connections and components

when power is present.
Do Not Operate With Suspected Failures. If you suspect there is damage to this

product, have it inspected by qualified service personnel.

Do Not Operate in Wet/Damp Conditions.
Do Not Operate in an Explosive Atmosphere.
Keep Product Surfaces Clean and Dry .
Provide Proper Ventilation. Refer to the manual’s installation instructions for

details on installing the product so it has proper ventilation.

TMS 164 i960 HX Microprocessor Support Instruction Manual

v

General Safety Summary

Symbols and Terms

T erms in this Manual. These terms may appear in this manual:

WARNING. Warning statements identify conditions or practices that could result
in injury or loss of life.

CAUTION. Caution statements identify conditions or practices that could result in
damage to this product or other property.

T erms on the Product. These terms may appear on the product:
DANGER indicates an injury hazard immediately accessible as you read the

marking.
WARNING indicates an injury hazard not immediately accessible as you read the

marking.
CAUTION indicates a hazard to property including the product.
Symbols on the Product. The following symbols may appear on the product:

WARNING

High Voltage

Protective Ground

(Earth) T erminal

CAUTION

Refer to Manual

Double

Insulated

vi

TMS 164 i960 HX Microprocessor Support Instruction Manual

Service Safety Summary

Only qualified personnel should perform service procedures. Read this Service
Safety Summary and the General Safety Summary before performing any service

procedures.
Do Not Service Alone. Do not perform internal service or adjustments of this

product unless another person capable of rendering first aid and resuscitation is
present.

Disconnect Power. To avoid electric shock, disconnect the main power by means
of the power cord or, if provided, the power switch.

Use Care When Servicing With Power On. Dangerous voltages or currents may
exist in this product. Disconnect power, remove battery (if applicable), and
disconnect test leads before removing protective panels, soldering, or replacing
components.

To avoid electric shock, do not touch exposed connections.

TMS 164 i960 HX Microprocessor Support Instruction Manual

vii

Service Safety Summary

viii

TMS 164 i960 HX Microprocessor Support Instruction Manual

Preface: Microprocessor Support Documentation

This instruction manual contains specific information about the TMS 164 i960
Hx microprocessor support and is part of a set of information on how to operate
this product on compatible Tektronix logic analyzers.

If you are familiar with operating microprocessor supports on the logic analyzer
for which the TMS 164 i960 Hx support was purchased, you will probably only
need this instruction manual to set up and run the support.

If you are not familiar with operating microprocessor supports, you will need to
supplement this instruction manual with information on basic operations to set up
and run the support.

Information on basic operations of microprocessor supports is included with each
product. Each logic analyzer has basic information that describes how to perform
tasks common to supports on that platform. This information can be in the form
of online help, an installation manual, or a user manual.

This manual provides detailed information on the following topics:
H Connecting the logic analyzer to the system under test

Manual Conventions

H Setting up the logic analyzer to acquire data from the system under test
H Acquiring and viewing disassembled data
H Using the probe adapter

This manual uses the following conventions:
H The term disassembler refers to the software that disassembles bus cycles

into instruction mnemonics and cycle types.

H The phrase “information on basic operations” refers to online help, an

installation manual, or a basic operations of microprocessor supports user
manual.

H In the information on basic operations, the term XXX or P54C used in field

selections and file names must be replaced with i960 Hx. This is the name of
the microprocessor in field selections and file names you must use to operate
the i960 Hx support.

H The term system under test (SUT) refers to the microprocessor-based system

from which data will be acquired.

TMS 164 i960 HX Microprocessor Support Instruction Manual

ix

Preface: Microprocessor Support Documentation

H The term logic analyzer refers to the Tektronix logic analyzer for which this

product was purchased.

H The term module refers to a 102/136-channel or a 96-channel module.
H i960 Hx refers to all supported variations of the i960 Hx microprocessor

unless otherwise noted.

H A pound sign (#) following a signal name indicates an active low signal.

Logic Analyzer Documentation

A description of other documentation available for each type of Tektronix logic
analyzer is located in the corresponding module user manual. The manual set
provides the information necessary to install, operate, maintain, and service the
logic analyzer and associated products.

Contacting Tektronix

Product
Support

Service
Support

For other
information

To write us Tektronix, Inc.

For application-oriented questions about a Tektronix measure­ment product, call toll free in North America:
1-800-TEK-WIDE (1-800-835-9433 ext. 2400)
6:00 a.m. – 5:00 p.m. Pacific time

Or, contact us by e-mail:
[e-mail]

For product support outside of North America, contact your
local Tektronix distributor or sales office.

Contact your local Tektronix distributor or sales office. Or, visit
our web site for a listing of worldwide service locations.

http://www.tek.com
In North America:

1-800-TEK-WIDE (1-800-835-9433)
An operator will direct your call.

P.O. Box 1000
Wilsonville, OR 97070-1000

x

TMS 164 i960 HX Microprocessor Support Instruction Manual

Getting Started

Getting Started

Product Description

This chapter provides information on the following topics:

H The TMS 164 i960 Hx microprocessor support product
H Logic analyzer system software compatibility
H Your i960 Hx system requirements
H i960 Hx support product restrictions
H How to configure the probe adapter
H How to connect to the system under test (SUT)
H How to apply power to and remove power from the probe adapter

The TMS 164 microprocessor support product disassembles data from systems
that are based on the Intel, Inc. i960 Hx microprocessor. The TMS 164 runs on a
compatible Tektronix logic analyzer equipped with a a 102/136-channel module
or a 96-channel module.

Refer to information on basic operations to determine how many modules and
probes your logic analyzer needs to the meet the minimum channel requirements
for the TMS 164 microprocessor support.

Table 1–1 shows which microprocessors, packages, and speeds the TMS 164
supports.

T able 1–1: Product support

Microprocessor Package Maximum speed

i960 HA PGA 40 MHz
i960 HD PGA 33 MHz
i960 HT PGA 25 MHz

A complete list of accessories and options is provided at the end of the parts list
in the Replaceable Mechanical Parts chapter.

To use this product efficiently, you need to have the items listed in the basic
operations user manual as well as the i960 Hx Microprocessor User’s Manual,
Intel, August, 1995.

TMS 164 i960 HX Microprocessor Support Instruction Manual

1–1

Getting Started

The basic operations user manual also contains a general description of support
products.

Logic Analyzer System Software Compatibility

The label on the application floppy disk states which version of logic analyzer
system software the application is compatible with.

Logic Analyzer Configuration

To use the i960 Hx support product, the logic analyzer must be equipped with
either a 102/136-channel module or a 96-channel module at a minimum. The
module must be equipped with enough probes to acquire clock and channel data
from signals in your i960HX-based system.

The basic operations user manual contains information on how to configure the
logic analyzer under Configuring the Logic Analyzer in the Getting Started
chapter.

Requirements and Restrictions

You should review the general requirements and restrictions of microprocessor
support products in the Getting Started chapter in the basic operations user
manual as they pertain to your SUT:

You should also review electrical, environmental, and mechanical specifications
in the Specifications chapter in this manual as they pertain to your system under
test, as well as the following descriptions of other i960 Hx support product
requirements and restrictions.

System Clock Rate. The microprocessor support product supports the i960 Hx
microprocessor at speeds of up to 40 MHz

1

.

1–2

1

Specification at time of printing. Contact your Tektronix sales representative for
current information on the fastest devices supported.

TMS 164 i960 HX Microprocessor Support Instruction Manual

SUT Power. Whenever the SUT is powered off, be sure to remove power from the
probe adapter. Refer to Applying and Removing Power at the end of this chapter
for information on how to remove power from the probe adapter.

Disabling the Data, Instruction, and Vector Caches. You must disable the internal
Data, Instruction, and Vector caches. Disabling the caches make most instruc­tions visible on the bus so the logic analyzer can acquire and disassemble them.

Configuring the Probe Adapter

The i960 Hx microprocessor uses the high-order four address lines to define 16
memory regions. The characteristics of each region is set up by software at
power-up. You must set the DIP switches on the probe adapter to match the
software settings of each memory region.

All the switches are open when the probe adapter is shipped; READY# and
BTERM# are always monitored in all the memory regions until you change the
settings. Figure 1–1 shows the location of the DIP switches on the probe adapter.

Getting Started

S420

S440

Figure 1–1: Location of the DIP switches on the probe adapter

To configure the probe adapter, follow these steps:

1. Determine how the i960 Hx system is configured in each of its regions.

Compare bits 29, 28, and 24 in PMCON register to the bit values in Table
1–2 to determine how to set the DIP switch on the probe adapter.

TMS 164 i960 HX Microprocessor Support Instruction Manual

1–3

Getting Started

T able 1–2: PMCON register entry and DIP switch settings

READY# and

#

BTERM
Enable

0 0 0 Closed Normal cycles; READY# and BTERM# disabled
0 0 1 Closed Pipelined Read cycles enabled; normal write cycles. READY# and

0 1 0 Closed READY# and BTERM# disabled; burst cycles enabled.
0 1 1 Closed READY# and BTERM# inputs disabled; pipelined burst read

1 0 0 Open READY# and BTERM# inputs are enabled; burst and read

1 0 1 Open READY# and BTERM# inputs ignored for pipelined read, valid for

1 1 0 Open READY# and BTERM# inputs enabled; burst cycle enabled and

1 1 1 Open READY# and BTERM# inputs ignored for pipelined burst read, but

Burst
Enable

Pipeline
Enable

DIP
switch
setting

Definition

BTERM# disabled.

enabled, burst write cycles enabled.

pipelining mode disabled.

write; burst mode disabled.

pipeline mode disabled.

valid for burst write.

2. Use Table 1–3 to determine which DIP switch to set for each memory region.

T able 1–3: Address region and DIP switch assignments

Address region
(A31-A28)

0 (0000) S420-S0 8 (1000) S440-S8
1 (0001) S420-S1 9 (1001) S440-S9
2 (0010) S420-S2 A (1010) S440-S10
3 (0011) S420-S3 B (1011) S440-S11
4 (0100) S420-S4 C (1100) S440-S12
5 (0101) S420-S5 D (1101) S440-S13
6 (0110) S420-S6 E (1110) S440-S14
7 (0111) S420-S7 F (1111) S440-S15

Switch

Address region
(A31-A28)

Switch

1–4

TMS 164 i960 HX Microprocessor Support Instruction Manual

Connecting to a System Under Test

Before you connect to the SUT, you must connect the standard probes to the
module. Your SUT must also have a minimum amount of clear space surround­ing the microprocessor to accommodate the probe adapter. Refer to the Specifica-
tions chapter in this manual for the required clearances.

The clock and channel probes shown in the connection figures are for the 92A96
module. If you are using a different module, your probes will look different than
those shown.

The Requirements and Restrictions description in the basic operations user
manual shows the vertical dimensions of an acquisition probe connected to
square pins on a circuit board.

If a probe adapter has one or two high-density cables (probe adapter does not
have pins to which the clock and channel probes connect), it requires an
LAHDP2 probe to make connections between the logic analyzer and a SUT.

To connect the logic analyzer to a SUT using a PGA probe adapter and an
LAHDP2 probe, follow these steps:

Getting Started

1. Turn off power to your SUT. It is not necessary to turn off power to the logic

analyzer.

CAUTION. Static discharge can damage the microprocessor, the low-profile probe
adapter, the acquisition probes, or the module. To prevent static damage, handle
all of the above only in a static-free environment.

Always wear a grounding wrist strap or similar device while handling the
microprocessor and low-profile probe adapter.

2. To discharge your stored static electricity, touch the ground jack located on

the back of the logic analyzer. Then, touch the black foam on the underside
of the probe adapter to discharge stored static electricity from the probe
adapter.

3. Remove the microprocessor from the SUT.

4. Line up the pin A1 indicator on the probe adapter board with the pin A1

indicator on the microprocessor.

CAUTION. Failure to correctly place the microprocessor into the probe adapter
may permanently damage the microprocessor once power is applied.

TMS 164 i960 HX Microprocessor Support Instruction Manual

1–5

Getting Started

5. Place the microprocessor into the probe adapter as shown in Figure 1–2.

Microprocessor

Pin A1

Figure 1–2: Placing a microprocessor into a PGA probe adapter

6. Remove the black foam from the underside of the probe adapter.

7. Line up the pin A1 indicator on the probe adapter board with the pin A1

indicator on the SUT.

8. Place the probe adapter onto the SUT as shown in Figure 1–3.

NOTE. You may need to stack one or more replacement sockets between the SUT
and the probe adapter to provide sufficient vertical clearance from adjacent
components. However, keep in mind this may increase loading, which can reduce
the electrical performance of the probe adapter.

1–6

TMS 164 i960 HX Microprocessor Support Instruction Manual

Figure 1–3: Placing a PGA probe adapter onto the SUT

Getting Started

SUT socket

Pin A1

9. Connect the clock and channel probes to the LAHDP2 probe as shown in the

basic operations user manual.

10. Align pin 1 on the LO cable connector, the end on the narrowest cable strip

of the cable, with pin 1 on the LO connector on the LAHDP2 probe. Connect
the cable to the connector as shown in Figure 1–4.

TMS 164 i960 HX Microprocessor Support Instruction Manual

1–7

Getting Started

Probe adapter

Pin 1 side

SUT

LAHDP2 probe

Figure 1–4: Connecting the LO cable to an LAHDP2 probe

Applying and Removing Power

A power supply for the TMS 164 i960 Hx probe adapter is included with the
product. The power supply provides +5 V power to the probe adapter. When the
power supply is on, the LED indicator is lit. The center connector of the power
jack connects to Vcc.

NOTE. Whenever the SUT is powered off, be sure to remove power from the probe
adapter.

1–8

TMS 164 i960 HX Microprocessor Support Instruction Manual

Getting Started

To apply power to the i960 Hx probe adapter and SUT, follow these steps:

CAUTION. Failure to use the +5 V power supply provided by Tektronix may
permanently damage the probe adapter and i960 Hx microprocessor. Do not
mistake another power supply that looks similar for the +5 V power supply.

1. Connect the +5 V power supply to the jack on the probe adapter. Figure 1–5

shows the location of the jack on the adapter board.

CAUTION. Failure to apply power to the probe adapter before applying power to
your SUT may permanently damage the i960 Hx microprocessor and SUT.

2. Plug the power supply for the probe adapter into an electrical outlet. The

power LED should light up.

3. Power on the SUT.

Figure 1–5: Location of the power jack

Power jack

TMS 164 i960 HX Microprocessor Support Instruction Manual

1–9

Getting Started

To remove power from the SUT and i960 Hx probe adapter, follow these steps:

CAUTION. Failure to power down your SUT before removing the power from the
probe adapter may permanently damage the i960 Hx microprocessor and SUT.

1. Power down the SUT.

2. Unplug the power supply for the probe adapter from the electrical outlet.

1–10

TMS 164 i960 HX Microprocessor Support Instruction Manual

Operating Basics

Setting Up the Support

This section provides information on how to set up the support. Information
covers the following topics:

H Channel group definitions
H Clocking options
H Symbol table files

Remember that the information in this section is specific to the operations and
functions of the TMS 164 i960 Hx support on any Tektronix logic analyzer for
which it can be purchased. Information on basic operations describes general
tasks and functions.

Before you acquire and disassemble data, you need to load the support and
specify setups for clocking and triggering as described in the information on
basic operations. The support provides default values for each of these setups,
but you can change them as needed.

Channel Group Definitions

Clocking Options

The software automatically defines channel groups for the support. The channel
groups for the i960 Hx support are Address, Data, Control, ByteEnable, Aux, and
Misc. If you want to know which signal is in which group, refer to the channel
assignment tables beginning on page 3–5.

The TMS 164 support offers a microprocessor-specific clocking mode for the
i960 Hx microprocessor. This clocking mode is the default selecton whenever
you load the i960 Hx support.

A description of how cycles are sampled by the module using the support and
probe adapter is found in the Specifications chapter.

The clocking for the TMS 164 support is DMA cycles.

TMS 164 i960 HX Microprocessor Support Instruction Manual

2–1

Setting Up the Support

DMA Cycles

This option field in the Clock menu lets you choose whether to Include or
Exclude DMA cycles.

A description of how cycles are sampled by the acquisition module using the
application and probe adapter is found in the Specifications chapter.

Disassembly will not be correct with the Internal or External clocking modes.
The basic operations user manual contains information on how to use these other
clock selections iwth any microprocessor support package in the Reference
chapter under General Purpose Analysis.

Symbols

The TMS 164 application supplies one pattern symbol table file. The i960
Hx_Ctrl file replaces specific Control channel group values with symbolic values
when SYM or PATTERN is the radix for the channel group.

Table 2–1 shows the name, bit pattern, and meaning for the symbols in the file
i960 Hx_Ctrl, the Control channel group symbol table.

T able 2–1: Control Group symbol table definitions

Control Group value

LOCK# D/C# CT3

HOLD BOFF# CT2

Symbol

FETCH 10X0 01 XXXX An opcode fetch
READ 1000 11 XXXX A read from memory
WRITE 1001 11 XXXX A write to memory
L_READ 00X0 11 XXXX The read portion of an atomic memory access
L_WRITE 00X1 11 XXXX The write portion of an atomic memory access
DMA_READ X1X0 X1 XXXX A DMA read from memory
DMA_WRITE X1X1 X1 XXXX A DMA write to memory
BURST_RD 1010 11 XXXX A burst read from memory
BURST_WR 1011 11 XXXX A burst write to memory
BACK_OFF XXXX X0 XXXX The BOFF# signal is asserted
UNKNOWN

BLAST# CT1

W/R# CT0

  

Meaning

Invalid group value

Information on basic operations describes how to use symbolic values for
triggering and displaying other channel groups symbolically, such as the Address
channel group.

2–2

TMS 164 i960 HX Microprocessor Support Instruction Manual

Setting Up the Support

Symbols Used for

Symbolic Addressing

The i960 Hx architecture defines a set of system tables that are read by the
microprocessor during initialization and software execution. The i960 Hx
microprocessor support supplies data structure symbol tables to provide symbolic
address representation for these i960 Hx system data structures.

If you are using only a single data structure symbol table during disassembly, you
can directly specify that symbol table in either the Channel menu, or the State or
Disassembly Format Definition overlays. You must first use the Symbol Editor to
set the base address of the symbol table to the base address of the corresponding
system data structure in your system. The Initialization Boot Record symbol
table is always located at the same address so you do not have to set the base.

Only one symbol table can be used with each channel group. This means that if
you want to use more than one of these data structure symbol tables, you must
merge them together to make one symbol table.

Merging Symbol T ables. You do not have to recreate a new table each time you
move the tables in your system as long as the relative difference in address
locations doesn’t change. If you move the tables in your system without changing
the relative difference in address locations, you only need to redefine the base
address for the symbol table.

Table 2–2 shows the name and address range for the symbols in the file
960HX_IBR, the Initialization Boot Record symbol table. This symbol table can
only be merged with other symbol tables that have already had the base address
added into their values.

T able 2–2: Initialization Boot record (IBR) symbol table

Symbol name Lower address boundary Upper address boundary

IBR_BCON0 FEFFFF30 FEFFFF33
IBR_BCON1 FEFFFF34 FEFFFF37
IBR_BCON2 FEFFFF38 FEFFFF3B
IBR_BCON3 FEFFFF3C FEFFFF3F
IBR_FSTIP FEFFFF40 FEFFFF43
IBR_PRCB FEFFFF44 FEFFFF47
IBR_CHK_W FEFFFF48 FEFFFF5F

TMS 164 i960 HX Microprocessor Support Instruction Manual

2–3

Setting Up the Support

Table 2–3 shows the name and address range for the symbols in the file
960HX_PRCB, the Process Control Block symbol table.

T able 2–3: Process Control Block (PRCB) symbol table

Symbol name Lower address boundary Upper address Boundary

PRCB_FTB 0 3
PRCB_CTB 4 7
PRCB_ACR 8 B
PRCB_FCW C F
PRCB_ITB 10 13
PRCB_SPB 14 17
PRCB_ISP 1C 1F
PRCB_ICC 20 23
PRCB_RCC 24 27

Table 2–4 shows the name and address range for the symbols in the file
960HX_CTBL, the Control Table symbol table.

T able 2–4: Control Table symbol table*

Symbol name Lower address boundary Upper address boundary

IMAP0 10 13
IMAP1 14 17
IMAP2 18 1B
ICON 1C 1F
PMCON0 20 23
PMCON1 24 27
PMCON2 28 2B
PMCON3 2C 2F
PMCON4 30 33
PMCON5 34 37

2–4

TMS 164 i960 HX Microprocessor Support Instruction Manual

T able 2–4: Control Table symbol table* (cont.)

Symbol name Upper address boundaryLower address boundary

PMCON6 38 3B
PMCON7 3C 3F
PMCON8 40 43
PMCON9 44 47
PMCON10 48 4B
PMCON1 1 4C 4F
PMCON12 50 53
PMCON13 54 57
PMCON14 58 5B
PMCON15 5C 5F
BPCON 64 67
TC 68 6B

Setting Up the Support

BCON 6C 6F

*

Do not confuse this table with the Control Group symbol table.

Table 2–5 shows the name and address range for the symbols in the file
960HX_IBR, the Interrupt Table symbol table.

T able 2–5: Interrupt Table symbol table

Symbol name Lower address boundary Upper address boundary

PEND_PRI 0 3
PEND_INT 4 23
INT_VECT 24 403

TMS 164 i960 HX Microprocessor Support Instruction Manual

2–5

Setting Up the Support

Table 2–6 shows the name and address range for the symbols in the file
960HX_FAULT, the Fault Table symbol table.

T able 2–6: Fault Table symbol table

Symbol name Lower address boundary Upper address boundary

PAR_FAULT 0 7
TR_FAULT 8 F
OP_FAULT 10 17
AR_FAULT 18 1F
CON_FAULT 28 2F
PRO_FAULT 38 3F
MAC_FAULT 40 47
TYP_FAULT 50 5F
OVR_FAULT 80 8F

Information on basic operations describes how to use symbolic values for
triggering and for displaying other channel groups symbolically, such as the
Address channel group.

2–6

TMS 164 i960 HX Microprocessor Support Instruction Manual

Acquiring and Viewing Disassembled Data

This section describes how to acquire data and view it disassembled. Information
covers the following topics and tasks:

H Acquiring data
H Viewing disassembled data in various display formats
H Cycle type labels
H Changing the way data is displayed
H Changing disassembled cycles with the mark cycles function

Acquiring Data

Once you load the i960 Hx support, choose a clocking mode, and specify the
trigger, you are ready to acquire and disassemble

If you have any problems acquiring data, refer to information on basic operations
in your online help or Appendix A: Error Messages and Disassembly Problems in
the basic operations user manual.

data.

Viewing Disassembled Data

You can view disassembled data in four display formats: Hardware, Software,
Control Flow, and Subroutine. The information on basic operations describes
how to select the disassembly display formats.

NOTE. Selections in the Disassembly property page (the Disassembly Format
Definition overlay) must be set correctly for your acquired data to be disas­sembled correctly. Refer to Changing How Data is Displayed on page 2–12.

The default display format shows the Address, Data, Control, and Byte Enable
channel group values for each sample of acquired data.

The disassembler displays special characters and strings in the instruction
mnemonics to indicate significant events. Table 2–7 shows these special
characters and strings, and gives a definition of what they represent.

TMS 164 i960 HX Microprocessor Support Instruction Manual

2–7

Acquiring and Viewing Disassembled Data

T able 2–7: Meaning of special characters in the display

Character or string displayed Meaning

******** Indicates there is insufficient data available for complete

** Indicates there is insufficient data available for complete

>> or m The instruction was manually marked by the user

disassembly of the instruction. The number of asterisks
displayed indicates the width of the data that is unavailable.
Two asterisks represent one byte.

disassembly of the instruction. “**” indicates one register
number that is unavailable.

Hardware Display Format

In Hardware display format, the disassembler displays certain cycle type labels in
parentheses. Table 2–8 shows these cycle type labels and gives a definition of the
cycle they represent. Reads to interrupt and exception vectors will be labeled
with the vector name.

T able 2–8: Cycle type definitions

Cycle type Definition

( READ ) A basic read cycle
( WRITE ) A basic write cycle
( BURST_READ ) A burst mode read cycle
( BURST_WRITE ) A burst mode write cycle
( LOCKED_READ ) The read portion of atomic read/write cycle
( LOCKED_WRITE ) The write portion of atomic read/write cycle
( DMA_READ ) A DMA read from memory.
( DMA_WRITE ) A DMA write to memory.
( STEST FAIL ) Processor has failed in self test.
( RESET LOCATION ) Processor has RESET and started fetching at address

FEFF FF30.

2–8

TMS 164 i960 HX Microprocessor Support Instruction Manual

T able 2–8: Cycle type definitions (cont.)

Cycle type Definition

( FLUSH )[

An instruction fetch that the processor did not use

Acquiring and Viewing Disassembled Data

( EXTENSION )[
( PREFETCH BYTE )[

( PREFETCH HALF-WORD )[
* ILLEGAL INSTRUCTION * Not a valid instruction
UNKNOWN Not a valid cycle type

[

Calculated cycle type.

The second word of the two-word instruction
The 2nd, 3rd and 4th byte of an instruction in an 8-bit memory

region
The 2nd 16-bit word of an instruction in a 16-bit memory region

Interrupts and fault tables will be displayed in parentheses in the disassembly as
shown below in Table 2–9.

T able 2–9: Interrupt or Exception label definitions

Interrupt or Exception type Definition

( INTR n VECTOR READ ) The vector entry read from the interrupt table; n

indicates the number of the interrupt.
( INTR PROC ENTRY ) Entry to the interrupt handling procedure.
( FAULT TABLE READ ) READ from the fault table occurs to get the

procedure address in case of local call, or proc entry

in case of system call.
( OPERATION FAULT PROC: LOCAL )

( ARITHMETIC FAULT PROC: LOCAL )

Entry to the fault handling procedure in Local call.

( OPERATION FAULT PROC: SYSTEM )
( ARITHMETIC FAULT PROC: SYSTEM )

TMS 164 i960 HX Microprocessor Support Instruction Manual

Entry to the fault handling procedure in System call.

2–9

Acquiring and Viewing Disassembled Data

Figure 2–1 shows an example of the Hardware display.

1 2 3 4 5 6

Sample Address Data Mnemonics Control Timestamp

-------------------------------------------------------------------------------------­123 A000D058 20000000 ( BURST_READ ) BURST_RD 60 ns
124 A000D05C 30000000 ( BURST_READ ) READ 60 ns
125 A000D068 00000000 ( BURST_READ ) BURST_RD 680 ns
126 A000D06C 00000000 ( BURST_READ ) READ 60 ns

TāāāĂ 127 A0008040--65250D80--ICCTL-00,-G4,-R4---------FETCH------------------3.040-us-

128 A0008044 65250E00 ( FLUSH ) FETCH 70 ns
129 A0008048 64401084 ( FLUSH ) FETCH 60 ns
130 A000804C 8C803000 ( FLUSH ) FETCH 60 ns
131 A0008040 65250D80 ( FLUSH ) FETCH 750 ns
132 A0008044 65250E00 DCCTL 00, G4, R4 FETCH 60 ns
133 A0008048 64401084 ( FLUSH ) FETCH 60 ns
134 A000804C 8C803000 ( FLUSH ) FETCH 60 ns
135 A0008048 64401084 SCANBIT R4, R8 FETCH 810 ns
136 A000804C 8C803000 LDA A0008900, G0 FETCH 60 ns
137 A0008050 A0008900 ( EXTENSION ) FETCH 190 ns
138 A0008054 5CB01614 MOV G4, G6 FETCH 60 ns
139 A0008058 58D6831A XOR G10, G10, G10 FETCH 60 ns
140 A000805C 58C60318 XOR G8, G8, G8 FETCH 60 ns
141 A0008060 B0803000 LDQ FEFFFF40, G0 FETCH 190 ns
142 A0008064 FEFFFF40 ( EXTENSION ) FETCH 60 ns
143 A0008068 58CE4318 XOR G8, G9, G9 FETCH 60 ns

Software Display Format

Figure 2–1: Hardware display format

1

Sample Column. Lists the memory locations for the acquired data.

2

Address Group. Lists data from channels connected to the i960 Hx address
bus.

3

Data Group. Lists data from channels connected to the i960 Hx data bus.

4

Mnemonics Column. Lists the disassembled instructions and cycle types.

5

Control Group. Lists data from channels connected to i960 Hx
microprocessor control signals ( shown symbolically).

6

Timestamp. Lists the timestamp values when a timestamp selection is made.
Information on basic operations describes how you can select a timestamp.

The Software display format shows only the first fetch of executed instructions.
Flushed cycles and extensions are not shown, even though they are part of the
executed instruction. Read extensions will be used to disassemble the instruction,
but will not be displayed as a separate cycle in the Software display format. Data
reads and writes are not displayed.

2–10

TMS 164 i960 HX Microprocessor Support Instruction Manual

Acquiring and Viewing Disassembled Data

The Software display format also shows the following cycles:

H Reset vector, Interrupt vector
H Reads from the vector table that appear due to servicing exceptions
H Illegal instructions
H ( UNKNOWN ) cycle types; the disassembler does not recognize the Control

group value

Control Flow Display

Format

The Control Flow display format shows only the first fetch of instructions that
change the flow of control. Instructions that do not actually change the control
flow are not displayed, such as a conditional branch that is not taken.

Instructions that generate a change in the flow of control in an i960 Hx micropro­cessor are as follows:

CALL B BX
CALLS BAL FMARK
CALLX BALX RET

Instructions that can generate a change in the flow of control based on a
condition or setting in the control register in an i960 Hx microprocessor are as
follows:

BBC CMPIBGE FAULTE
BBS CMPIBL FAULTG
BE CMPIBLE FAULTGE
BG CMPIBNE FAULTL
BGE CMPIBNO FAULTLE
BL CMPIBO FAULTNE
BLE CMPOBE FAULTNO
BNE CMPOBG FAULTO
BNO CMPOBGE MARK
BO CMPOBL
CMPIBE CMPOBLE
CMPIBG CMPOBNE

TMS 164 i960 HX Microprocessor Support Instruction Manual

2–11

Acquiring and Viewing Disassembled Data

Subroutine Display

Format

The Subroutine display format shows only the first fetch of subroutine call and
return instructions. It will display conditional subroutine calls if they are
considered to be taken.

Instructions that generate a subroutine call or return in an i960 Hx microproces­sor are as follows:

CALL CALLX
CALLS RET

Changing How Data is Displayed

There are common fields and features that allow you to further modify displayed
data to suit your needs. You can make common and optional display selections in
the Disassembly property page (the Disassembly Format Definition overlay).

You can make selections unique to the i960 Hx support to do the following tasks:

H Change how data is displayed across all display formats
H Change the interpretation of disassembled cycles
H Display exception vectors

Optional Display

You can make optional selections for disassembled

data.

Selections

In addition to the common display options (described in the basic operations user
manual), you can change the displayed data in the following ways:

H Specify the base address of the Interrupt table.
H Specify the base address of the Fault table.
H Specify the Byte order.

The i960 Hx microprocessor support product has three additional fields: Interrupt
table base, Fault table base, and Byte order. These fields appear in the area
indicated in the basic operations user manual. Table 2–10 below lists the three
additional display options and their ranges and default settings.

T able 2–10: Optional display selections

Display selection Description Range Default

Interrupt table base This field is necessary to compute the interrupt vector number. 00000800–FEFFFFFF 00000800
Fault table base This field is necessary to identify the fault and its occurrence. 00000900–FEFFFFFF 00000900
Byte Order This field is used to select Byte ordering. Default setting is Little

Endian, with option of Big Endian.

— Little Endian

2–12

TMS 164 i960 HX Microprocessor Support Instruction Manual

Acquiring and Viewing Disassembled Data

Marking Cycles

The disassembler has a Mark Opcode function that allows you to change the
interpretation of a cycle type. Using this function, you can select a cycle and
change it to one of the following cycle types:

H Opcode (the first word of an instruction)
H Extension (a subsequent word of an instruction)
H Flush (an opcode or extension that is fetched but not executed)

You can mark word-aligned address sequences, but not the second, third, or
fourth bytes in the 8-bit memory region, or the second byte in the 16-bit region.
If you mark the word-aligned sequence in the 8- or 16-bit region, the same mark
is applied to the next three or one bytes, respectively.

If the target of branch is not double word-aligned, then the word prior to the
nonaligned double word target is also fetched but not executed. When the target
is not explicitly known in the instruction, the disassembler can not identify the
target. You will need to identify and flush such sequences.

Mark selections are as follows:

Opcode
Extension
Flush
Undo Mark

Microcoded Instructions

The basic operations user manual contains more information on marking cycles.

A microcoded instruction is an instruction that takes more than one cycle to
execute. Execution of these instructions results in refetch behavior. Automatic
dequeueing is provided for all microcoded instructions in REG format. Automat­ic dequeueing is not provided for microcoded instructions in COBR, CTRL, or
MEM formats.

Table 2–11 below shows an example of refetch behavior and how the sequence is
disassembled.

T able 2–11: Refetch behavior example

Sequence Disassembled

A000B000 : FLUSHREG A000B000 : FLUSHREG
A000B004 : MOV R4,G4 A000B004 : FLUSH
A000B008 : XOR R2,R6,R10 A000B008 : FLUSH
A000B00C : NAND G4,G6,G8 A000B00C : FLUSH
A000B000 : FLUSHREG /* refetched because

FLUSHREG is a microcoded inst*/

A000B000 : FLUSH

TMS 164 i960 HX Microprocessor Support Instruction Manual

2–13

Acquiring and Viewing Disassembled Data

T able 2–11: Refetch behavior example (cont.)

Sequence Disassembled

A000B004 : MOV R4,G4 A000B004 :MOV R4,G4
A000B008 : XOR R2,R6,R10 A000B008 : XOR R2,R6,R10
A000B00C : NAND G4,G6,G8 A000B00C : NAND G4,G6,G8

Viewing an Example of Disassembled Data

A demonstration system file (or demonstration reference memory) is provided so
you can see an example of how your i960 Hx microprocessor bus cycles and
instruction mnemonics look when they are disassembled. Viewing the system file
is not a requirement for preparing the module for use and you can view it without
connecting the logic analyzer to your SUT.

Information on basic operations describes how to view the file.

2–14

TMS 164 i960 HX Microprocessor Support Instruction Manual

Specifications

Specifications

This chapter contains the following information:

H Probe adapter description
H Specification tables
H Dimensions of the probe adapter
H Channel assignment tables
H Description of how the module acquires i960 Hx signals
H List of other accessible microprocessor signals and extra probe channels

Probe Adapter Description

The probe adapter is nonintrusive hardware that allows the logic analyzer to
acquire data from a microprocessor in its own operating environment with little
effect, if any, on that system. Information on basic operations contains a figure
showing the logic analyzer connected to a typical probe adapter. Refer to that
figure while reading the following description.

Configuring the Probe

Adapter

The probe adapter consists of a circuit board and a socket for a i960 Hx
microprocessor. The probe adapter connects to the microprocessor in the SUT.
Signals from the microprocessor-based system flow from the probe adapter to the
channel groups and through the probe signal leads to the module.

All circuitry on the probe adapter is powered from the supplied power adapter.
The probe adapter accommodates the Intel, Inc. i960 Hx microprocessor in a

168-pin PGA package.

You can set up each memory region in the i960 Hx system through software. The
probe adapter DIP switches must be set up to match your system’s memory
region setup. To configure the probe adapter, follow these steps:

1. Determine how the i960 Hx system is configured in each of its regions.

Compare bits 29, 28, and 24 in PMCON register of each region to the bit
values in Table 1–2 to determine how to set the DIP switch on the probe
adapter.

2. Use Table 1–3 to determine which DIP switch to set for each memory region.

TMS 164 i960 HX Microprocessor Support Instruction Manual

3–1

Specifications

Specifications

These specifications are for a probe adapter connected between a compatible
Tektronix logic analyzer and a SUT. Table 3–1 shows the electrical requirements
the SUT must produce for the support to acquire correct data.

In Table 3–1, for the 102/136-channel module, one podlet load is 20 k in
parallel with 2 pF. For the 96-channel module, one podlet load is 100 k in
parallel with 10 pF.

T able 3–1: Electrical specifications

Characteristics Requirements

Probe adapter power supply requirements

Voltage 90-265 VAC
Current 1.1 A maximum at 100 VAC
Frequency 47-63 Hz
Power 25 W maximum

SUT clock

Minimum setup time required

Minimum hold time required

Measured typical SUT signal loading AC load DC load

*

i960 HA clock rate 40 MHz
i960 HD clock rate 33 MHz
i960 HT clock rate 25 MHz

[

BTERM#, READY# 8.5 ns
All other signals 5 ns

[

All signals 0 ns

CLKIN 12 pF 2 74FCT162244ET

1 PAL22V10

A31:A28, BTERM#, READY# 8.5 pF 1 74FCT162244ET

1 PAL22V10/PAL16L8
WAIT# 7.0 pF 2 74FCT162244ET
A27:A2, D31:D0, DP3:DP0, CT3:CT0,

BE#3:BE#0, BOFF#, HOLD, W/R#, LOCK#,
NMI#, SUP#, ADS#, DEN#, BLAST#, D/C#,
BREQ, RESET#, HOLDA, PCHK#, DT/R#,
BST ALL

3.5 pF 1 74FCT162244

3–2

* Maximum measured Clock frequency is 33 MHz.

[

Setup and hold times are with respect to the CLKIN signal from the probe adapter.

TMS 164 i960 HX Microprocessor Support Instruction Manual

Table 3–2 shows the environmental specifications.

T able 3–2: Environmental specifications*

Characteristic Description

Temperature

Specifications

Maximum operating
Minimum operating 0° C (+32° F)

Non-operating –55° C to +75° C (–67° F to +167° F)
Humidity 10 to 95% relative humidity
Altitude

Operating 4.5 km (15,000 ft) maximum

Non-operating 15 km (50,000 ft) maximum
Electrostatic immunity The probe adapter is static sensitive

* Designed to meet Tektronix standard 062-2847-00 class 5.

[

Not to exceed i960 Hx microprocessor thermal considerations. Forced air cooling
might be required across the CPU.

+50° C (+122° F)[

Table 3–3 shows the certifications and compliances that apply to the probe
adapter.

T able 3–3: Certifications and compliances

EC Compliance There are no current European Directives that apply to this product.

TMS 164 i960 HX Microprocessor Support Instruction Manual

3–3

Specifications

Figure 3–1 shows the dimensions of the probe adapter.

91 mm

(3.600 in)

25.4 mm

(1.00 in)

Pin 1A

48 mm

(1.900 in)

114 mm

(4.500 in)

7. mm (.26 in)

Figure 3–1: Minimum clearance of the standard probe adapter

3–4

TMS 164 i960 HX Microprocessor Support Instruction Manual

Specifications

Channel Assignments

Channel assignments shown in Table 3–4 through Table 3–10 use the following
conventions:

H All signals are required by the support unless indicated otherwise.
H Channels are shown starting with the most significant bit (MSB) descending

to the least significant bit (LSB).

H Channel group assignments are for all modules unless otherwise noted.
H A pound sign (#) following a signal name indicates an active low signal
H An equals sign (=) following a signal name indicates that it is double probed.
H If there are two modules (such as used to form 96-channels), the module in

the higher-numbered slot is referred to as the HI module and the module in
the lower-numbered slot is referred to as the LO module.

Table 3–4 shows the probe section and channel assignments for the Address
group and the microprocessor signal to which each channel connects. By default,
this channel group is displayed in hexadecimal.

T able 3–4: Address group channel
assignments

Bit
order

31 A3:7 A31
30 A3:6 A30
29 A3:5 A29
28 A3:4 A28
27 A3:3 A27
26 A3:2 A26
25 A3:1 A25
24 A3:0 A24
23 A2:7 A23
22 A2:6 A22
21 A2:5 A21
20 A2:4 A20
19 A2:3 A19
18 A2:2 A18
17 A2:1 A17
16 A2:0 A16
15 A1:7 A15
14 A1:6 A14

Section:channel i960 Hx signal name

TMS 164 i960 HX Microprocessor Support Instruction Manual

3–5

Specifications

T able 3–4: Address group channel
assignments (cont.)

Bit
order

13 A1:5 A13
12 A1:4 A12
11 A1:3 A11
10 A1:2 A10
9 A1:1 A9
8 A1:0 A8
7 A0:7 A7
6 A0:6 A6
5 A0:5 A5
4 A0:4 A4
3 A0:3 A3
2 A0:2 A2
1 A0:1 A1*
0 A0:0 A0*

* Signal grounded on the TMS 164 probe adapter;

this is not an i960 Hx signal.

i960 Hx signal nameSection:channel

Table 3–5 shows the probe section and channel assignments for the Data group
and the microprocessor signal to which each channel connects. By default, this
channel group is displayed in hexadecimal.

T able 3–5: Data group channel
assignments

Bit
order

31 D3:7 D31
30 D3:6 D30
29 D3:5 D29
28 D3:4 D28
27 D3:3 D27
26 D3:2 D26
25 D3:1 D25
24 D3:0 D24
23 D2:7 D23

Section:channel i960 Hx signal name

3–6

TMS 164 i960 HX Microprocessor Support Instruction Manual

T able 3–5: Data group channel
assignments (cont.)

Bit
order

22 D2:6 D22
21 D2:5 D21
20 D2:4 D20
19 D2:3 D19
18 D2:2 D18
17 D2:1 D17
16 D2:0 D16
15 D1:7 D15
14 D1:6 D14
13 D1:5 D13

i960 Hx signal nameSection:channel

Specifications

12 D1:4 D12
11 D1:3 D1 1
10 D1:2 D10
9 D1:1 D9
8 D1:0 D8
7 D0:7 D7
6 D0:6 D6
5 D0:5 D5
4 D0:4 D4
3 D0:3 D3
2 D0:2 D2
1 D0:1 D1
0 D0:0 D0

TMS 164 i960 HX Microprocessor Support Instruction Manual

3–7

Specifications

Table 3–6 shows the probe section and channel assignments for the Control
group, and the microprocessor signal to which each channel connects. The
default display radix is Symbolic for the 102/136-channel module and SYM for
the 96-channel module.

T able 3–6: Control group channel
assignments

Section:
channel

C2:5 LOCK#
C2:1 HOLDA
C2:2 BLAST#
C3:2 W/R#
C2:4 D/C#
C2:6 BOFF#
C3:5 CT3
C3:1 CT2

i960 Hx signal name

C3:4 CT1
C3:0 CT0

Table 3–7 shows the probe section and channel assignments for the ByteEnbl
group, and the microprocessor signal to which each channel connects. By default,
this channel group is displayed in binary.

T able 3–7: ByteEnbl group channel assignments

Bit
order

3 C3:7 BE3#
2 C3:3 BE2#
1 C2:3 BE1#
0 C2:7 BE0#

Section:
channel

i960 Hx signal name

3–8

TMS 164 i960 HX Microprocessor Support Instruction Manual

Specifications

Table 3–8 shows the probe section and channel assignments for the Aux group,
and the microprocessor signal to which each channel connects. By default, this
channel group is not visible.

T able 3–8: Aux group channel assignments

Bit
order

1 C2:3 DEN#
0 C2:0 ADS#

Section:
channel

i960 Hx g signal name

Table 3–9 shows the section and channel assignments for the Misc group, and the
microprocessor signal to which each channel connects. By default, this channel
group is not visible.

T able 3–9: Misc group channel assignments

Section:
channel

C0:0 NMI#
C1:7 DP3
C1:3 DP2
C1:6 DP1
C1:2 DP0
C1:4 WAIT#
C1:1 READY#
C1:0 BTERM#
C1:5 CLKIN
C0:1 DT/R#
C0:5 SUP#
C0:4 RESET#
C0:7 PCHK#

i960 Hx signal name

C0:6 BREQ
C0:3 BST ALL
C0:2 HOLD

TMS 164 i960 HX Microprocessor Support Instruction Manual

3–9

Specifications

Table 3–10 shows the section and channel assignments for the clock channels
(not part of any group), and the microprocessor signal to which each channel
connects. These channels are used only to clock in data; they are not acquired or
displayed.

T able 3–10: Clock channel assignments

Section:
channel

CLK0 CLKIN=
CLK1 P_BTERM#
CLK2 P_READY#
CLK3 WAIT#=

i960 Hx signal name

These channels are used only to clock in data; they are not acquired or displayed.
To acquire data from any of the signals shown in Table 3–10, you must connect
another channel probe to the signal, a technique called double probing. An equals
sign (=) following a signal name indicates that it is already double probed.

How Data is Acquired

Custom Clocking

This part of this chapter explains how the module acquires i960 Hx signals using
the TMS 164 software and probe adapter. This part also provides additional
information on microprocessor signals accessible on or not accessible on the
probe adapter, and on extra probe channels available for you to use for additional
connections.

A special clocking program is loaded to the module every time you load the i960
Hx support. This special clocking is called Custom.

With Custom clocking, the module logs in signals from multiple groups of
channels at different times as they become valid on the i960 Hx bus. The module
then sends all the logged-in signals to the trigger machine and to the memory of
the module for storage.

In Custom clocking, the module clocking state machine (CSM) generates one
master sample for each microprocessor bus cycle, no matter how many clock
cycles are contained in the bus cycle.

3–10

TMS 164 i960 HX Microprocessor Support Instruction Manual

Specifications

CLKIN

A31:A2

ADS*

A3, A2

D31: D0

BLAST*

DEN*

Burst read cycle Pipelined Burst read cycle

Ta Td Td Td Ta,’ Td’ Td’ Td’ Ta Td

00 01 10 11

D D D D D’ D’ D

Single Data cycle

Figure 3–2 shows the sample points and the master sample point.

HOLDA

AC,DC

Figure 3–2: i960 Hx bus timing

DC DC DC DC DCAC,DC AC,DCAC,DC

Master sample points

The CSM has the states START, DMA, DATA, and BURST which handle all the
states of processor address, data, wait, and hold.

The sampling is done at the rising edge of the CLKIN signal. The CSM enters
the DATA state from the START state if ADS# is asserted, which is identified as
the start of valid bus cycle. To do this, it also requires the HOLDA signal to be
deasserted if DMA is excluded. If DMA is included, CSM goes to DMA state
from START state if HOLDA is asserted.

TMS 164 i960 HX Microprocessor Support Instruction Manual

3–11

Specifications

If it is a single data transfer, CSM goes from the DATA state back to the START
state and BLAST# is asserted low to indicate the end of the bus cycle. If the
cycle is terminated which is indicated by assertion of P_BTERM#, the CSM also
goes to the START state. If a burst cycle has occurred, BLAST# indicates
deassertion. For this, the CSM goes to the BURST state. For all these the
address, data, and control signals will be strobed and a master strobe will also be
given. The ADS# will be deasserted for all of these.

If P_BTERM# is asserted the cycle is terminated and the CSM goes back to
START state after logging the address, data, and control signals. A pipelined
non-burst access may also occur when in DATA cycle which is identified by the
assertion of both ADS# and BLAST#. The CSM keeps logging in address, data,
and control signals and keeps waiting in DATA state.

When the CSM is in BURST state it remains in that state until the end of the bus
cycle, which is indicated by the assertion of BLAST#. A3:2 data and control
signals are logged until it remains in the BURST state. When BLAST# is
asserted, CSM goes to START state. If P_BTERM# is asserted, the cycle is
terminated and CSM goes back to START state after logging the address, data,
and control signals. A pipelined burst occurs when BLAST# and ADS# are
asserted at the same time, indicating that the valid address is put for next data; in
this case, CSM goes to DATA state.

After the acquisition is complete, the disassembler reads the acquisition memory.
Since each memory location contains i960 Hx data for a complete bus cycle, the
disassembler is able to deduce the kind of bus activity that took place. For
example, if an opcode fetch occurred, the disassembler converts the data bus into
the opcode the data bus represents.

3–12

TMS 164 i960 HX Microprocessor Support Instruction Manual

Specifications

Clocking Options

The clocking algorithm for the i960 Hx microprocessor has two variations:
DMA cycles included or DMA cycles excluded.

If HOLDA is active, then the i960 Hx microprocessor has given up the bus to
another device. The design of the i960 Hx hardware affects what data will be
logged in. The logic analyzer only samples signals at the i960 Hx pins. To
properly log in bus activity, any buffers between the i960 Hx and the alternate
bus driver must be enabled and pointed towards the i960 Hx. Possible i960 Hx
hardware and clocking interactions are as follows:

H If the alternate device drives the same control lines as the i960 Hx and the

i960 Hx sees these signals, alternate bus activity is logged in just like normal
bus cycles except that HOLDA will be asserted.

H If none of the control lines are driven or if the i960 Hx cannot see them, the

logic analyzer still logs in a DMA cycle. The information present on the bus
one clock period prior to the deassertion of HOLDA is logged in as the DMA
bus cycle.

H If some of the i960 Hx control signals are visible, but not all of them, the

logic analyzer logs in what it determines is valid from the visible control
signals and logs in the information previously present on the remaining bus
signals one clock period prior to the deassertion of HOLDA. In all cases,
HOLDA is logged in as high.

Synthesized Signals

DMA Cycles Excluded. Whenever the logic analyzer is about to log in the first

sample of a bus cycle and it detects that HOLDA is high, no data is logged in. No
DMA cycles caused by HOLDA are logged in with this selection.

The probe adapter must synthesize four signals in order to acquire valid data.
Table 3–11 describes them. Refer to the previous discussions on including and
excluding DMA cycles for a description of how these signals are used.

T able 3–11: Synthesized signals

Signal Description

P_BTERM# Derived from the DIP switches on the probe adapter. If the

switch is open, P_BTERM# is the same as BTERM#. If the
switch is closed, P_BTERM# is deasserted (high).

P_READY# Derived from the DIP switches on the probe adapter. If the

switch is open, P_READY# is the same as READY#. If the

switch is closed, P_READY# is asserted (low).
A1 Grounded on the probe adapter
A0 Grounded on the probe adapter

TMS 164 i960 HX Microprocessor Support Instruction Manual

3–13

Specifications

Alternate Microprocessor Connections

You can connect to microprocessor signals that are not required by the support so
that you can do more advanced timing analysis. These signals might or might not
be accessible on the probe adapter board. The following paragraphs and tables
list signals that are or are not accessible on the probe adapter board.

For a list of signals required or not required for disassembly, refer to the channel
assignment tables beginning on page 3–5. Remember that these channels are
already included in a channel group. If you do connect these channels to other
signals, you should set up another channel group for them.

Signals Not on the Probe

Adapter

Table 3–12 lists signals not accessible on the probe adapter.

T able 3–12: Signals not on the probe adapter

FAIL# TDO XINT0# XINT4#
ONCE# TDI XINT1# XINT5#
STEST TMS XINT2# XINT6#
TCK TRST# XINT3# XINT7#

3–14

TMS 164 i960 HX Microprocessor Support Instruction Manual

WARNING

The following servicing instructions are for use only by qualified personnel. To
avoid injury, do not perform any servicing other than that stated in the operating
instructions unless you are qualified to do so. Refer to all Safety Summaries
before performing any service.

Maintenance

Maintenance

This chapter contains information on the following topics:

H Probe adapter circuit description
H How to replace a fuse

Probe Adapter Circuit Description

A 22V10 PAL, two 8-wide DIP switches, the upper four address lines A31–A28,
and CLKIN are used to generate a signal named P_RDY_EN. The i960 Hx uses
its upper four address lines to map its memory into 16 memory regions. Each
region is software programmable.

The READY# and BTERM# inputs may be masked out in each of the regions.
The user must open the DIP switch(s) that corresponds to region(s) where
READY# and BTERM# are enabled. This causes P_RDY_EN to be high
whenever the address is in a region where READY# and BTERM# are active.
P_RDY_EN is combined with READY# and BTERM# to create P_READY#
and P_BTERM#. In a region where READY# is enabled P_READY# will be the
same as READY#. In regions where READY# is not enabled P_READY# will
be low regardless of the value of READY#. In regions where BTERM# is
enabled P_BTERM# will be the same as BTERM#. In regions where BTERM#
is not enabled P_BTERM# will be high regardless of the value of BTERM#.

The 22V10 PAL is programmed for 21 inputs and one output. The PAL is
programmed to decode the four address lines into 16 internal signals. Each signal
is AND-ed with a DIP switch, then all of the AND gate outputs are OR-ed
together. The OR output is clocked into a flip flop whose output becomes
P_RDY_EN. When the DIP switch is open the input to the AND gate is high.
When the DIP switch is closed the input to the AND gate is low.

The signal P_RDY_EN is combined with BTERM# in a 16L8PAL to generate
P_BTERM#. P_RDY_EN is also combined with READY# in 16L8PAL to
generate P_READY#.

Replacing Signal Leads

Information on basic operations describes how to replace signal leads (individual
channel and clock probes).

TMS 164 i960 HX Microprocessor Support Instruction Manual

4–1

Maintenance

Replacing Protective Sockets

Information on basic operations describes how to replace protective sockets.

Replacing the Fuse

If the fuse on the i960 Hx probe adapter opens (burns out), you can replace it
with a 5 A, 125 V fuse. Figure 4–1 shows the location of the fuse on the probe
adapter.

Fuse

4–2

Figure 4–1: Location of the fuse

TMS 164 i960 HX Microprocessor Support Instruction Manual

Replaceable Electrical Parts

Replaceable Electrical Parts

This chapter contains a list of the replaceable electrical components for the
TMS 164 i960 Hx microprocessor support. Use this list to identify and order
replacement parts.

Parts Ordering Information

Replacement parts are available through your local Tektronix field office or
representative.

Changes to Tektronix products are sometimes made to accommodate improved
components as they become available and to give you the benefit of the latest
improvements. Therefore, when ordering parts, it is important to include the
following information in your order:

H Part number
H Instrument type or model number
H Instrument serial number
H Instrument modification number, if applicable

If you order a part that has been replaced with a different or improved part, your
local Tektronix field office or representative will contact you concerning any
change in part number.

Change information, if any, is located at the rear of this manual.

Using the Replaceable Electrical Parts List

The tabular information in the Replaceable Electrical Parts List is arranged for
quick retrieval. Understanding the structure and features of the list will help you
find all of the information you need for ordering replacement parts. The
following table describes each column of the electrical parts list.

TMS 164 i960 HX Microprocessor Support Instruction Manual

5–1

Replaceable Electrical Parts

Parts list column descriptions

Column Column name Description

1 Component number The component number appears on diagrams and circuit board illustrations, located in the diagrams

section. Assembly numbers are clearly marked on each diagram and circuit board illustration in the
Diagrams section, and on the mechanical exploded views in the Replaceable Mechanical Parts list
section. The component number is obtained by adding the assembly number prefix to the circuit
number (see Component Number illustration following this table).

The electrical parts list is arranged by assemblies in numerical sequence (A1, with its subassemblies
and parts, precedes A2, with its subassemblies and parts).

Chassis-mounted parts have no assembly number prefix, and they are located at the end of the

electrical parts list.
2 Tektronix part number Use this part number when ordering replacement parts from Tektronix.
3 and 4 Serial number Column three indicates the serial number at which the part was first effective. Column four indicates

the serial number at which the part was discontinued. No entry indicates the part is good for all serial

numbers.
5 Name & description An item name is separated from the description by a colon (:). Because of space limitations, an item

name may sometimes appear as incomplete. Use the U.S. Federal Catalog handbook H6-1 for

further item name identification.
6 Mfr. code This indicates the code number of the actual manufacturer of the part.
7 Mfr. part number This indicates the actual manufacturer’s or vendor’s part number.

Abbreviations

Component Number

List of Assemblies

Chassis Parts

Mfr. Code to Manufacturer

Cross Index

Abbreviations conform to American National Standard ANSI Y1.1–1972.

Component number

A23A2R1234 A23 R1234

Assembly number Circuit number

Read: Resistor 1234 (of Subassembly 2) of Assembly 23

A2

Subassembly number

(optional)

A list of assemblies is located at the beginning of the electrical parts list. The
assemblies are listed in numerical order. When a part’s complete component
number is known, this list will identify the assembly in which the part is located.

Chassis-mounted parts and cable assemblies are located at the end of the
Replaceable Electrical Parts List.

The table titled Manufacturers Cross Index shows codes, names, and addresses of
manufacturers or vendors of components listed in the parts list.

5–2

TMS 164 i960 HX Microprocessor Support Instruction Manual

Replaceable Electrical Parts

Manufacturers cross index

Mfr.
code

00779 AMP INC. CUSTOMER SERVICE DEPT

09353 C & K COMPONENTS CORP 15 RIVERDALE AVENUE NEWTON, MA 02158
0LXM2 LZR ELECTRONICS INC 8051 CESSNA AVENUE GAITHERSBURG, MD 20879
61857 SAN–O INDUSTRIAL CORP 91–3 COLIN DRIVE HOLBROOK, NY 11741
63058 MCKENZIE TECHNOLOGY 910 PAGE AVE FREMONT, CA 945387340
80009 TEKTRONIX INC 14150 SW KARL BRAUN DR

Manufacturer Address City , state, zip code

HARRISBURG, PA 17105–3608

PO BOX 3608

BEAVERT ON, OR 97077–0001

PO BOX 500

Replaceable electrical parts list

Component
number

A01 671-3931-00 CIRCUIT BD ASSY:I960HX,PGA-168, SOCKETED,

A01F100 159-0059-00 FUSE,WIRE LEAD:5A,125V, FAST 61857 SP1-5A
A01J100 131-5527-00 JACK,POWER DC:PCB,MALE,RTANG,2MM PIN,11MM

A01J510 131-5947-00 CONN,BOX:PCB,MICRO–STRIP,FEMALE,STR,100

A01S420 260-5000-00 SWITCH,SLIDE:SPST,DIP8 POSITION,GOLD OVER

A01S440 260-5000-00 SWITCH,SLIDE:SPST,DIP8 POSITION,GOLD OVER

A01U330 136-1250-00 SOCKET,PGA:PCB,168 POS,17 X 17 MATRIX,0.1

Tektronix
part number

Serial no.
effective

Serial no.
discont’d

Name & description Mfr. code Mfr. part number

389-2157-00 WIRED,32/92DM19

H(0.433) X 3.5MM(0.137) TAIL,9MM(0.354) W,TIN,W/SWI

POS,0.05 CTR,W/GRD PLANE,0.320 H X 0.125 TAIL,LAT

NICKEL,3A,2PF ,SEALED,90HBW08S,44MM T&R

NICKEL,3A,2PF ,SEALED,90HBW08S,44MM T&R

CTR,0.173 H X 0.183 TAIL,GOLD,PHOS BRZ,PAT 1706 W

80009 671-3931-00

0LXM2 DJ005A

00779 121289–7

09353 LD08HOSK1

09353 LD08HOSK1

63058 PGA–168H–101B–176

9

TMS 164 i960 HX Microprocessor Support Instruction Manual

5–3

Replaceable Electrical Parts

5–4

TMS 164 i960 HX Microprocessor Support Instruction Manual

Replaceable Mechanical Parts

Replaceable Mechanical Parts

This chapter contains a list of the replaceable mechanical components for the
TMS 164 i960 Hx microprocessor support. Use this list to identify and order
replacement parts.

Parts Ordering Information

Replacement parts are available through your local Tektronix field office or
representative.

Changes to Tektronix products are sometimes made to accommodate improved
components as they become available and to give you the benefit of the latest
improvements. Therefore, when ordering parts, it is important to include the
following information in your order:

H Part number
H Instrument type or model number
H Instrument serial number
H Instrument modification number, if applicable

If you order a part that has been replaced with a different or improved part, your
local Tektronix field office or representative will contact you concerning any
change in part number.

Change information, if any, is located at the rear of this manual.

Using the Replaceable Mechanical Parts List

The tabular information in the Replaceable Mechanical Parts List is arranged for
quick retrieval. Understanding the structure and features of the list will help you
find all of the information you need for ordering replacement parts. The
following table describes the content of each column in the parts list.

TMS 164 i960 HX Microprocessor Support Instruction Manual

6–1

Replaceable Mechanical Parts

Parts list column descriptions

Column Column name Description

1 Figure & index number Items in this section are referenced by figure and index numbers to the exploded view illustrations

that follow.
2 Tektronix part number Use this part number when ordering replacement parts from Tektronix.
3 and 4 Serial number Column three indicates the serial number at which the part was first effective. Column four

indicates the serial number at which the part was discontinued. No entries indicates the part is

good for all serial numbers.
5 Qty This indicates the quantity of parts used.
6 Name & description An item name is separated from the description by a colon (:). Because of space limitations, an

item name may sometimes appear as incomplete. Use the U.S. Federal Catalog handbook H6-1

for further item name identification.
7 Mfr. code This indicates the code of the actual manufacturer of the part.
8 Mfr. part number This indicates the actual manufacturer’s or vendor’s part number.

Abbreviations

Chassis Parts

Abbreviations conform to American National Standard ANSI Y1.1–1972.

Chassis-mounted parts and cable assemblies are located at the end of the
Replaceable Electrical Parts List.

Mfr. Code to Manufacturer

Cross Index

The table titled Manufacturers Cross Index shows codes, names, and addresses of
manufacturers or vendors of components listed in the parts list.

Manufacturers cross index

Mfr.
code

00779 AMP INC. CUSTOMER SERVICE DEPT

09353 C & K COMPONENTS CORP 15 RIVERDALE AVENUE NEWTON, MA 02158
0LXM2 LZR ELECTRONICS INC 8051 CESSNA AVENUE GAITHERSBURG, MD 20879
61857 SAN–O INDUSTRIAL CORP 91–3 COLIN DRIVE HOLBROOK, NY 11741
63058 MCKENZIE TECHNOLOGY 910 PAGE AVE FREMONT, CA 945387340
80009 TEKTRONIX INC 14150 SW KARL BRAUN DR

Manufacturer Address City , state, zip code

HARRISBURG, PA 17105–3608

PO BOX 3608

BEAVERT ON, OR 97077–0001

PO BOX 500

6–2

TMS 164 i960 HX Microprocessor Support Instruction Manual

Replaceable Mechanical Parts

Replaceable parts list

Fig.
&index
number

6–1 010-0600-00 1 PROBE ADAPTER:i960HX,SOCKETED 80009 010-0600-00
–1 174-3418-00 1 CA ASSY,RF:TLC,MICRO–STRIP,TLC,50 OHM 00779 1-340014-0
–2 159-0059-00 1 FUSE,WIRE LEAD:5A,125V , FAST 61857 SP1–5A
–3 131-5527-00 1 JACK,POWER DC:PCB,MALE,RTANG,2MM PIN,1 1MM

–4

–5 671-3931-00 1 CIRCUIT BD ASSY:I960HX,PGA–168, SOCKETED,

–6 136-1250-00 2 SOCKET,PGA:PCB,168 POS,17 X 17 MATRIX,0.1

–7 131-5947-00 1 CONN,BOX:PCB,MICRO–STRIP,FEMALE,STR,100

Tektronix
part number

260-5000

00

Serial no.
effective

Serial no.
discont’d

Qty Name & description Mfr. code Mfr. part number

H(0.433) X 3.5MM(0.137) TAIL,9MM(0.354)
W,TIN,W/SWI

2 SWITCH,SLIDE:SPST,DIP8 POSITION,GOLD OVER

NICKEL,3A,2PF ,SEALED,90HBW08S,44MM T&R

389-2157-00 WIRED,32/92DM19

CTR,0.173 H X 0.183 TAIL,GOLD,PHOS BRZ,PAT
1706 W

POS,0.05 CTR,W/GRD PLANE,0.320 H X 0.125
TAIL,LAT

0LXM2 DJ005A

09353 LD08HOSK1

80009 671-3931-00

63058 PGA-168H-101B-1769

00779 121289–7

STANDARD ACCESSORIES

070-9818-00 1 MANUAL,TECH:INSTRUCTION,i960HX 80009 070-9818-00
070-9365-01 1 MANUAL, TECH:BASIC OPS MICRO SUP ON

DAS/TLA

119-5061-01 1 POWER SUPPLY:25W;5V 5A,CONCENTRIC 2MM

(NOT SHOWN)

161-0104-00 1 CA ASSY,PWR 3,18 AWG,98 L, 250V/10AMP,98 IN.,

RTANG, IEC 320,RCPT X STR NEMA 15 –5P,W/
CORD GRIP,US

80009 070-9365-01

14310 SW106KA002F01

OB445 MC6–3CG86

TMS 164 i960 HX Microprocessor Support Instruction Manual

6–3

Replaceable Mechanical Parts

1

2

7

3

4

5

6

6–4

Figure 6–1: i960 Hx probe adapter exploded view

TMS 164 i960 HX Microprocessor Support Instruction Manual

Index

Index

A

about this manual set, ix
acquiring data, 2–7
Address group

channel assignments, 3–5

display column, 2–10
Alternate Bus Master cycles, 3–13
alternate connections, to other signals, 3–14
Aux group, channel assignments, 3–9

B

basic operations, where to find information, ix
bus cycles, displayed cycle types, 2–8
bus timing, 3–11
ByteEnbl group, channel assignments, 3–8

C

certifications, 3–3
channel assignments

Address group, 3–5

Aux group, 3–9

ByteEnbl group, 3–8

clocks, 3–10

Control group, 3–8

Data group, 3–6

Misc group, 3–9
channel groups, 2–1
clock channel assignments, 3–10
clock rate, 1–2
clocking, Custom, how data is acquired, 3–10
compliances, 3–3
connections

other microprocessor signals, 3–14

probe adapter to SUT, PGA, with an LAHDP2 probe,

1–5
Control Flow display format, 2–11
Control group

channel assignments, 3–8
display column, 2–10

symbol table, 2–2
Custom clocking, how data is acquired, 3–10
cycle types, 2–8

D

data

acquiring, 2–7
disassembly formats

  
 
 
 

how it is acquired, 3–10
data display , changing, 2–12
Data group

channel assignments, 3–6

display column, 2–10
demonstration file, 2–14
disassembled data

cycle type definitions, 2–8

viewing, 2–7

viewing an example, 2–14
disassembler

definition, ix

logic analyzer configuration, 1–2

setup, 2–1
Disassembly Format Definition overlay, 2–12
Disassembly property page, 2–12
display formats

Control Flow, 2–11

Hardware, 2–8

Software, 2–10

special characters, 2–7

Subroutine, 2–12

E

electrical specifications, 3–2
environmental specifications, 3–3

F

fuse, replacing, 4–2

H

Hardware display format, 2–8

cycle type definitions, 2–8

TMS 164 i960 HX Microprocessor Support Instruction Manual

Index–1

Index

I

installing hardware. See connections
instruction, microcoded, 2–13

refetch behavior, 2–13

L

leads (podlets). See connections
logic analyzer

configuration for disassembler, 1–2
software compatibility, 1–2

M

manual

conventions, ix

how to use the set, ix
Mark Cycle function, 2–13
Mark Opcode function, 2–13
marking cycles, definition of, 2–13
microcoded instruction, 2–13

refetch behavior, 2–13
microprocessor

package types supported, 1–1

specific clocking and how data is acquired, 3–10
Misc group, channel assignments, 3–9
Mnemonics display column, 2–10

P

power

alternate source, applying, 1–8

for the probe adapter, removing, 1–10

SUT, 1–3
power adapter, 1–8
power jack, 1–9
probe adapter

circuit description, 4–1

clearance, 1–5

  

 

configuring, 1–3, 3–1
hardware description, 3–1
jumper positions, 3–1
placing the microprocessor in, 1–7
replacing the fuse, 4–2

R

reference memory, 2–14
refetch behavior, 2–13

S

service information, 4–1
setups, disassembler, 2–1
signals, active low sign, x
Software display format, 2–10
special characters displayed, 2–7
specifications, 3–1

certifications, 3–3
channel assignments, 3–5
compliances, 3–3
electrical, 3–2

environmental, 3–3
Subroutine display format, 2–12
support setup, 2–1
SUT, definition, ix
SUT power, 1–3
symbol table, Control channel group, 2–2
synthesized signals, 3–13
system file, demonstration, 2–14

T

terminology, ix
Timestamp display column, 2–10

V

viewing disassembled data, 2–7

Index–2

TMS 164 i960 HX Microprocessor Support Instruction Manual
