Logic Analyzer Technical Report

Date: July 1, 2005
Subject: Memory Erasure & Parts in TLA7AA1, TLA7AA2, TLA7AA3, TLA7AA4,

TLA7AB2, TLA7AB4, TLA7NA1, TLA7NA2, TLA7NA3, TLA7NA4, TLA7N1, TLA7N2,
TLA7N3, TLA7N4, TLA7P2, TLA7P4, TLA7Q2, TLA7Q4, TLA7XM, TLA7PG2, TLA7D1,

TLA7D2, TLA7E1, TLA7E2

MEMORY ERASURE PROCEDURE

Turn the power off for at least 20 seconds to clear volatile memory.
NVRAM does not contain any acquisition data (only cal constants, etc.).
If you have any questions, contact the Tektronix Technical Support Center at 1-800-833-9200*3.

MEMORY PARTS – TLA7AA1, TLA7AA2, TLA7AA3, TLA7AA4, TLA7AB2, TLA7AB4, TLA7NA1,

TLA7NA2, TLA7NA3, TLA7NA4

.

671-5312-01 – LPU Board

Part Number Reference designator Description Qty

156-3870-00 U612 IC, Memory, CMOS, NVRAM; 32K X 8,

Integral Battery, Safety Controlled

156-7366-00 U810 U820 U831 U840 IC, Memory, DRAM, CMOS, 1MEG X 16 4
156-8036-00 U830 IC, Memory, CMOS, Flash, 2M X 8 1
156-8971-00 U541 IC, Memory, BICMOS 1

1

1

Logic Analyzer Technical Report

MEMORY PARTS – TLA7AA1

671-5351-02 – Acquisition Board

Part Number Reference designator Description Qty

156-9033-00 U0470 U0481 U0571 U0580

U0631 U0633 U0641 U0643
U0651 U0653 U0661 U0663

U471 U480 U570 U581
U630 U632 U640 U642
U650 U652 U660 U662

IC, Memory; CMOS, SDRAM; 4MB X 16 24

MEMORY PARTS – TLA7AA2

671-5350-02 – Acquisition Board

Part Number Reference designator Description Qty

156-9033-00 U0470 U0481 U0571 U0580

U0631 U0633 U0641 U0643
U0651 U0653 U0661 U0663
U0671 U0682 U0770 U0781

U471 U480 U570 U581
U630 U632 U640 U642
U650 U652 U660 U662
U670 U681 U771 U780

IC, Memory; CMOS, SDRAM; 4MB X 16 32

2

Logic Analyzer Technical Report

MEMORY PARTS – TLA7AA3

671-5349-02 – Acquisition Board

Part Number Reference designator Description Qty

156-9033-00 U0470 U0481 U0571 U0580

U0612 U0621 U0631 U0633
U0641 U0643 U0651 U0653
U0661 U0663 U0671 U0682
U0711 U0721 U0770 U0781

U471 U480 U570 U581
U611 U620 U630 U632
U640 U642 U650 U652
U660 U662 U670 U681
U710 U720 U771 U780

IC, Memory; CMOS, SDRAM; 4MB X 16 40

MEMORY PARTS – TLA7AA4

671-5311-02 – Acquisition Board

Part Number Reference designator Description Qty

156-9033-00 U0411 U0421 U0470 U0481

U0511 U0521 U0571 U0580
U0612 U0621 U0631 U0633
U0641 U0643 U0651 U0653
U0661 U0663 U0671 U0682
U0711 U0721 U0770 U0781

U410 U420 U471 U480
U510 U520 U570 U581
U611 U620 U630 U632
U640 U642 U650 U652
U660 U662 U670 U681
U710 U720 U771 U780

IC, Memory; CMOS, SDRAM; 4MB X 16 48

3

Logic Analyzer Technical Report

MEMORY PARTS – TLA7AB2

671-5441-02 – Acquisition Board

Part Number Reference designator Description Qty

156-9193-00 U0470 U0481 U0571 U0580

U0631 U0633 U0641 U0643
U0651 U0653 U0661 U0663
U0671 U0682 U0770 U0781

U471 U480 U570 U581
U630 U632 U640 U642
U650 U652 U660 U662
U670 U681 U771 U780

IC, Memory; CMOS, SDRAM; 4MB X 16 32

MEMORY PARTS – TLA7AB4

671-5442-02 – Acquisition Board

Part Number Reference designator Description Qty

156-9193-00 U0411 U0421 U0470 U0481

U0511 U0521 U0571 U0580
U0612 U0621 U0631 U0633
U0641 U0643 U0651 U0653
U0661 U0663 U0671 U0682
U0711 U0721 U0770 U0781

U410 U420 U471 U480
U510 U520 U570 U581
U611 U620 U630 U632
U640 U642 U650 U652
U660 U662 U670 U681
U710 U720 U771 U780

IC, Memory; CMOS, SDRAM; 4MB X 16 48
