Tektronix TLA720 Data Sheet

Features & Benefits

MagniVu™Technology Provides
500 ps Timing Resolution on All
Channels All the Time Through
the Same Probe

Up to 200 MHz State
Acquisition with 400 MHz Data
Rate for Advanced Processors
and Buses

Simultaneous State and High
Speed Timing Analysis Through
the Same Probes Pinpoints
Elusive Faults

500 MHz Deep Timing Analysis
with Up to 128 Mb Per Channel

Broad Processor and Bus
Support

Universal Source Code Support
for Correlating High-level
Language Source with Real­time Trace

Performance Analysis Support
for Optimizing Target System

Remote Control Using
Microsoft COM/DCOM
Technology Supports Advanced
Data Analysis

Microsoft Windows 2000
Professional PC Platform
Provides Familiar User Interface
With Network Connectivity

All Probes, Software and
Accessories Fully
Interchangeable Between all
TLAs

Applications

Hardware Debug and
Verification

Processor/Bus Debug and
Verification

Embedded Software
Integration, Debug and
Verification

Logic Analyzers

TLA Family

Breakthrough Solutions for Real-time Digital
Systems Analysis

Today’s digital design engineers face daily pres­sures to speed new products to the marketplace.
The TLA answers the need with breakthrough solu­tions for the entire design team, providing the ability
to quickly monitor,capture and analyze real-time
system operation in order to debug, verify, optimize
and validate digital systems.
Hardware developers, Hardware/Software integra­tors and embedded software developers will appre­ciate the range of capabilities of the TLA.Its broad
feature set includes capturing and correlating elu­sive hardware and software faults; providing simul­taneous state and high-speed timing analysis; using

deep state acquisition to find the cause of complex
problems; generating the digital stimulus for func­tional verification, debugging and stress testing;
and offering non-intrusive real-time software execu­tion tracing that correlates to the source code and
to the hardware events.
This kind of performance is matched by value.
Productivity and connectivity features such as the
open Microsoft Windows platform make all TLA logic
analyzers easy to use and easily networked into the
design environment. Modularity and flexibility fea­tures help you protect your current investment.

TLA Family • Logic Analyzers • www.tektronix.com/LA

1

The TLA family of logic analyzers consists of the TLA600 Series and the TLA700 Series. The TLA600 offers a
selection of standalone logic analyzer instruments at prices that make 500 ps timing resolution available to
designers of today’s mainstream embedded systems.The TLA700 Series offers the highest performance for
today’s demanding applications and consists of portable and benchtop modular mainframes with expansion
mainframe capability.Instrument modules include logic analyzer,pattern generator and digitizing oscillo­scope.A full line of complementary support products for popular processors and buses is available for the
entire TLA family.

Logic Analyzers

TLA Family

Characteristics

TLA Logic Analyzers

General

Number of Channels (all channels are acquired includ­ing clocks) –

TLA601/611/621,TLA7N1: 34 channels (2 are clock
channels).
TLA602/612/622,TLA7N2,TLA7P2: 68 channels (4 are
clock channels).
TLA603/613/623,TLA7N3: 102 channels (4 are clock and
2 are qualifier channels).
TLA604/614/624,TLA 7N4,TLA 7P4: 136 channels (4 are
clock and 4 are qualifier channels).
Channel Grouping – No limit to number of groups or num­ber of channels per group (all channels can be reused in
multiple groups).

TLA700 Module “Merging”– Three 102 channel or 136
channel modules can be “merged”to make up to a 408
channel module. Merged modules exhibit the same depth
as the lesser of the three individual modules.
Word/range/setup-and-hold/glitch/transition recognizers
span all three modules. Only one set of clock connections
is required.

Time Stamp – 50-Bits at 500 ps resolution (6.5 day
range).

Clocking/Acquisition Modes – State, timing, 2x timing,
simultaneous.

Number of Mainframe Slots Required per TLA700
Module – 2.

Input Characteristics (with P6417,
P6418 or P6434 Probes)

Capacitive Loading – 1.4 pF typical data; 2 pF typical
clock (P6418).
2 pF typical data and clock (P6417 & P6434).

Threshold Selection Range – From +5.0 V to –2.0 V in
50 mV increments.

Threshold Selection Channel Granularity – Separate
selection for clock (1) and data (16) for each 17 channel
probe connector.

Threshold Accuracy (including probe)– ±100 mV.
Input Voltage Range – Operating: 6.5 V

p-p

centered
around the programmed threshold.
Non-destructive: ±15 V.

Input Signal Swing (probe overdrive) – ±250mV or
±25% of signal swing, whichever is greater (P6417 &
P6418).
±300 mV or ±25% of signal swing (P6434).

Input Signal Minimum Slew Rate – 200 mV/ns typical.

State Acquisition Characteristics
(with P6417, P6418 or P6434
Probes)

State Clock Rate – 100 MHz standard, 200 MHz optional.
State Data Rate (half/full channels) –

400 MHz/200 MHz, typical. Requires 200 MHz state
option.

State Memory Depth with Timestamps – 64 Kb,
256 Kb, 1 Mb, 4 Mb, 16 Mb or 64 Mb Bits per channel
(4 Mb, 16 Mb and 64 Mb available only on TLA700).

Setup Time Selection Range– From 8.5 ns before, to

7.0 ns after clock edge.

Setup-and-hold Window – 2.0ns typical.
Minimum Clock Pulse Width– 2 ns.
Active Clock Edge Separation – 5 ns.
Demux Channel Selection – Channels can be demulti-

plexed to other channels through user interface with 8
channel granularity.

Timing Acquisition Characteristics
(with P6417, P6418 or P6434
Probes)

MagniVu™ Timing – 500 ps.
MagniVu Timing Memory Depth– 2 Kb (2048) per

channel.
Deep Timing Resolution (half/full channels)– 2 ns,

4 ns to 50 ms.

Deep Timing Resolution with Glitch Storage Enabled–

10 ns to 50 ms.

Deep Timing Memory Depth (half/full channels with
timestamps and with or without transitional storage) –

128/64 Kb, 512/256 Kb, 2/1 Mb, 8/4 Mb, 32/16 Mb,
128/64 Mb per channel (8/4 Mb, 32/16 Mb and
128/64 Mb available only on TLA700).

Deep Timing Memory Depth with Glitch Storage
Enabled – Half of default main memory depth.

Channel-to-channel Skew – ≤1 ns typical.
Minimum Recognizable Pulse Width (single channel)–

2 ns.

Minimum Recognizable Glitch Width (single channel)–

2 ns.

Minimum Recognizable Multi-channel Trigger Event –

Sample period + 2 ns.

Trigger Characteristics

Independent Trigger States – 16.
Maximum Independent If/then Clauses per State – 16.
Maximum Number of Events per If/then Clause – 8.
Maximum Number of Actions per If/then Clause – 8.
Maximum Number of Trigger Events – 18

(2 counter/timers plus any 16 other resources).

Number of Word Recognizers– 16.
Number of Range Recognizers – 4.
Number of Counter/Timers – 2.
Trigger Event Types– Word,group, channel, transition,

range, anything, counter value,timer value, signal, glitch,
setup-and-hold violation.

Trigger Action Types – Trigger module, trigger all, store,
don’t store, start store, stop store,increment counter,
reset counter,start timer, stop timer, reset timer, goto
state, set/clear signal, do nothing.

Trigger Sequence Rate– DC to 250 MHz (4 ns).
Counter/Timer Range – 51-Bits each (>100 days @

4 ns).

Counter Rate – DC to 250 MHz (4 ns).
Timer Clock Rate – 250 MHz (4 ns).
Counter/Timer Latency – None (can be tested or reset

immediately after starting).
Range Recognizers – Double bounded (can be as wide

as any group, must be grouped according to specified
order of significance).

Setup-and-hold Violation Recognizer Setup Time
Range – From 8 ns before to 7 ns after clock edge in

0.5 ns increments.

Setup-and-hold Violation Recognizer Hold Time
Range – From 7ns before to 8 ns after clock edge in

0.5 ns increments.

Trigger Position– Any data sample.
MagniVu T rigger Position – MagniVu data is centered

around the module trigger.
Storage Control (data qualification) – Global (condition-

al), by state (start/stop), by trigger action,or transitional.
Storage Window Granularity – Single sample or block-

of-31 samples before and after.

TLA Family • Logic Analyzers • www.tektronix.com/LA

2

Logic Analyzers

TLA Family

P6417 Probe Cable Length – 1.8 m (6 ft.).
P6418 Probe Cable Length – 1.9 m (6.25 ft.).
P6434 Probe Cable Length – 1.5 m (5 ft.).

All three probes have the same electrical length.

TLA700 Pattern
Generator Modules

General

Data Width –

64 Channel full channel mode.
32 Channel half channel mode.

Module “Merging”– Five modules can be “merged”to
make up to a 320 channel module. Merged modules
exhibit the same depth as the lesser of the 5 individual
modules.

Number of mainframe slots required – 2.
Data Rate –

Internal Clock:

0.5 Hz to 134 MHz full channel mode.

1.0 Hz to 268 MHz half channel mode.

External Clock:

DC to 134 MHz full channel mode.
DC to 268 MHz half channel mode.

External Clock Input –

Polarity: positive or negative.
Threshold: –2.56 V to +2.54 V,nominal; programmable in
20 mV increments.
Sensitivity: ≤500 mV

p-p

.

Impedance: 1 kΩ terminated to ground.

Data Depth –

256 K full channel/512 K half channel.
1 M full channel/2 M half channel (optional).

Pattern Sequencing
Characteristics

Blocks – Separate sections of pattern program that are
output in a user definable order by the Sequencer.Block
pattern depth can be from 40 sequences (full channel
mode) or 80 sequences (half channel mode) up to the
entire depth of the TLA7PG2.A maximum of 4,000 Blocks
may be defined.

Sequencer – A 4000 line memory that allows the user to
pick the output order of individual Blocks. Each line in the
sequencer allows the definition of a Block to be output, a
Repeat Count for that Block,A Wait For event condition for
the Block, the Signal state for that Block (asserted or
unasserted), and a Jump If event condition, with a
sequence line to jump to if the condition is satisfied.

Sub-sequences – Up to 50 contiguous lines of the
Sequencer memory may be defined as a Sub-sequence.
A Sub-sequence can then be treated like a block.
(Example: 15 Sequences of Blocks are defined as Sub­sequence A1.Now any line in the Sequencer can output
A1. Five calls to Sub-sequence A1 will be flattened out to
75 sequences at run time.)

Jump If – Jumps to the specified sequence if a user
defined event is true.The user defined event is a boolean
combination of the eight external event input lines and
the one-of-four intermodule signals.The user defined
Event is selectable between level and edge (event going
from false to true). One Jump If may be defined for every
Block.The Jump If command works at all clock rates,
including the maximum half channel mode rate of
268 MHz.

Wait For – Pattern output is paused until the user
defined Event is true. One Wait For may be defined for
every Block.

Assert Signal – One of the four inter-module signals is
selected to be controlled from the pattern generator pro­gram. Signals may be asserted and unasserted allowing
true interaction with the logic analyzer modules and with
other pattern generator modules. Signal action (assert or
unassert) may be defined for every Block.

Repeat Count – The sequence is repeated from 1 to
65,536 times. Infinite may also be selected. One Repeat
Count may be defined for every Block. Note that a Repeat
value of 10,000 takes one sequence line in memory,not
10,000.

Step – While in Step mode, the TLA7PG2,the user can
manually satisfy (i.e., click an icon) Wait For and Jump
conditional events.This allows the user to debug the logic
flow of the program’s sequencing.

Initialization Block – The unconditional Jump command
allows the user to implement an equivalent function.

Common to P6470 TTL/CMOS &
P6471 ECL Probes

Number of Data Outputs – 16 in Full Channel Mode. 8 in
Half Channel Mode.

Number of Clock Outputs – 1. (Only one of Clock Output
and Strobe Output can be enabled.)

Number of Strobe Outputs – 1. (Only one of Clock
Output and Strobe Output can be enabled.)

Number of External Event Input – 2.
Clock Output Polarity – Positive.
Strobe Type– RZ only.
Strobe Delay – Zero or Trailing Edge.

P6470 TTL/CMOS Probe

Output Type–

HD74LVC541A for Data Output.
HD74LVC244A for Clock/Strobe Output.

Rise/Fall Time (20% to 80%)–

Timing values Timing values

measured using measured using

75 Ω termination 75 Ω termination

(internal to probe), (internal to probe),

1 MΩ + <1 pF 510Ω + 51 pF

load and V

OH

load and V

OH

set to 5.0 V. set to 5.0 V.

Clock/Strobe Output:

Rise: 640 ps typical. 6.5ns typical.

Fall: 1.1 ns typical. 6.3 ns typical.

Data Output:

Rise: 680 ps typical. 5.2ns typical.

Fall: 2.9 ns typical. 4.5 ns typical.

Output Voltage (nominal, load: 1 MΩ)–

VOH: 2.0 V to 5.5 V,tri-stateable,programmable in 25 mV
increments.
VOL:0V.

Data Output Skew –

<510 ps typical between all data output pins of all mod­ules in the mainframe after inter-module skew is adjusted
manually.
<480 ps typical between all data output pins of single
probe.

Data Output to Strobe Output Delay – 1.7 ns typical
when strobe delay set to zero.

Data Output to Clock Output Delay – 2.4 ns typical.
External Clock Input to Clock Output Delay –

Full Channel mode: 61.5 ns typical.
Half Channel mode: 61.5 ns typical.

Number of External Inhibit Input – 1.
External Inhibit Input to Output Enable Delay – 34 ns

typical for Data Output.
External Inhibit Input to Output Disable Delay – 86 ns

typical for Data Output.

Probe D Data Output to Output Enable Delay –

(for Internal Inhibit) 7 ns typical for Data Output.

Probe D Data Output to Output Disable Delay –

(for Internal Inhibit) 8 ns typical for Data Output.

TLA Family • Logic Analyzers • www.tektronix.com/LA

3

Logic Analyzers

TLA Family

External Event Input to Clock Output Setup (for inhibit)
(event-filter: off) –

Full Channel mode: 1.5 clocks + 150 ns typical.
Half Channel mode: 2 clocks + 150 ns typical.

External Event Input and Inhibit Input –

Input Type:74LVC14A.
Minimum Pulse Width:100 ns.

P6471 ECL Probe

Output Type–

100E151 for data output.
100EL16 for strobe output.
100EL04 for clock output.
All outputs are unterminated.

Rise/Fall Time (20% to 80%)–

Timing values

measured using
51 Ωs to –2.0 V.

Clock Output:

Rise: 320 ps typical.
Fall: 330 ps typical.

Data Output:

Rise: 1200 ps typical.
Fall: 710 ps typical.

Strobe Output:

Rise: 290 ps typical.
Fall: 270 ps typical.

Data Output Skew –

<170 ps typical between all data output pins of all mod­ules in the mainframe after inter-module skew is adjusted
manually.
<140 ps typical between all data output pins of single
probe.

Data Output to Strobe Output Delay – 2.94 ns typical
when strobe delay set to zero.

Data Output to Clock Output Delay – 780 ps typical.
External Clock Input to Clock Output Delay – 51 ns

typical.

External Event Input –

Input Level: ECL.
Input Type:10H116.
Minimum Pulse Width:50 ns.

P6470 Probe Cable Length – 1.6 m (5 ft.)
P6471 Probe Cable Length – 1.6 m (5 ft.)

TLA700 Digitizing
Oscilloscope Modules

General

Number of Channels per Module –

TLA7D2,TLA7E2: 4 channels.
TLA7D1,TLA7E1: 2 channels.

Sample Rate –

TLA7E1,TLA7E2: 5 GS/s on all channels.
TLA7D1,TLA7D2: 2.5 GS/s on all channels.

Bandwidth (at probe tips) –

TLA7E1,TLA7E2:

100 mV to 10 V range: 1 GHz.
50 mV to 99.8 mV range: 900 MHz.
20 mV to 49.8 mV range: 600 MHz.

All others:

500 MHz.
TLA7D1,TLA7D2: 500 MHz on all channels in all
ranges.

Memory Depth – 15,000 samples per channel in all
modes.

Number of Mainframe Slots Required – 2.

Vertical System

Input Sensitivity Range – 10 mV to 100 V full scale.
Vertical Resolution – 8-Bits (256 levels).
DC Gain Accuracy– ±1.5% of full scale range.
Analog Bandwidth Selections – 20 MHz, 250 MHz, and

Full.

Input Coupling – AC, DC, or GND.
Input Impedance Selections – 1 MΩ in parallel with

10 pF,or 50 Ω.
AC Coupled Lower Frequency Limit – ≤10 Hz when AC

1 MΩ coupled, ≤200 kHz when AC 50 Ω coupled.

Maximum Input Voltage at Probe Connector–

300 V

RMS

, but no greater than ± 420 V peak (1 MΩ or

ground input coupling).

Probe Input Characteristics

Probe Input Interface – TEKPROBE™probe interface.
Input Loading – Less than 1 pF in parallel with 1 MΩ

with either P6243 or P6245.
Usable Input Voltage Range at Probe Tip – P6243

Probe: ± 8 V.P6245 Probe:±18 V.

Acquisition System

Sample Rate Range – 200 ps to 200 ms in 1, 2.5, 5
sequence.

Timebase Accuracy– ±100ppm over any interval
≥1ms.

Record Length Range – 512 to 15,000 samples per
channel in all modes.

Acquisition Modes – Single-shot, repetitive.

Trigger System

Trigger Modes– Normal, auto.
Trigger Position– Anywhere in the acquired record (pre-

fill can be set anywhere from 0% to 100%).
Trigger Types – Edge, pulse width, timeout, glitch, runt,

slew rate, logic pattern, setup-and-hold violation.
Trigger Actions– Trigger,trigger all, set signal, arm,

immediate, wait for system trigger.
Edge Trigger– Conventional level driven trigger,positive

or negative slope, on any channel or external trigger input.
Coupling Selections: DC, AC, noise reject, HF reject, LF
reject.

Pulse Width Trigger– Trigger on width of positive or neg­ative pulse, either within or not within selectable time lim­its; settable from 2 ns to 1 s.

Timeout T rigger– Triggers when a pulse fails to complete
when specified; settable from 2 ns to 1 s.

Glitch Trigger– Trigger on (or reject) glitches of positive,
negative, or either polarity; settable from 2 ns to 1 s.
Minimum glitch width: 2.0 ns, with 200 ps resolution (2 ns
to 10 ns settings).

Runt Pulse Trigger – Trigger on a pulse that crosses one
threshold but fails to cross a second threshold before
crossing the first again; settable from 2 ns to 1 s.

Slew Rate Trigger – Trigger on pulse edge rates that are
either faster or slower than a set rate, edges can be rising,
falling, or either; settable from 2 ns to 1 s.

Logic Pattern Trigger – Triggers when a logical combina­tion (AND, OR) of all the input channels (Hi, Lo, Don’t Care)
stays true or false for a specified period of time; settable
from 2 ns to 1 s.

Setup-and-hold Trigger– Trigger on violations of both
setup time and hold time between clock and data which
are on separate input channels; setup time settable
from –100 ns to +100 ns in 200 ps increments; hold
time settable from –1 ns to +102 ns; minimum settable
window of setup time + hold time is 2 ns.

P6243 Probe Cable Length – 1.3 m (51 in.).
P6245 Probe Cable Length – 1.3 m (51 in.).

TLA Family • Logic Analyzers • www.tektronix.com/LA

4

Logic Analyzers

TLA Family

TLA700 Mainframes

General (TLA714, TLA720,
TLA7XM)

Instrument Slots –

TLA714: Holds 4 single-wide or 2 double-wide modules.
TLA720: Holds 10 single-wide or 5 double-wide modules.
TLA7XM: Holds 12 single-wide or 6 double-wide modules.

Ten TLA7XMs

TLA714 – 24 Dual/48 Single*

2,3

TLA720 – 60 Dual/120 Single*

2,3

Mainframe LA*1PG*1DSO*

1

Max channels 136 ch 64 ch 4 ch
per module
TLA714 3,264 1,536 96
TLA720 8,160 3,840 240

*1All logic analyzer (LA), pattern generator (PG) and digitizing oscillo-

scope (DSO) modules are dual-wide or occupy two single-wide slots.

*

2

TLA7XM Expansion Module occupies one single-wide slot in both the
TLA714/TLA720 mainframe and the TLA7XM expansion mainframe.

*

3

Using a TLA7XM expansion mainframe with an existing
TLA714/TLA720 mainframe requires Version 4.0 or higher TLA appli­cation software.TLA720 benchtop mainframes,S/N:B019999 and
lower,require TLA7UP Option 09 TLA720 Benchtop Mainframe
Upgrade. Please refer to the TLA Upgrade Guide for further details.

For configurations beyond ten TLA7XM expansion
mainframes, please contact your local Tektronix account
manager.

TLA700 PC Characteristics
(TLA714 and TLA720)

Operating System – Microsoft Windows 2000
Professional.

Processor – Pentium.
DRAM –

TLA714: 64 MB SDRAM (128 MB with Opt. 1S).
TLA720: 128 MB SDRAM.

Display Memory – 2 MB.
Sound – Built-in PC speaker transducer; multimedia

sound can be added via PC Card interface.

Replaceable Hard Disk Drive –

TLA714: 10 GB (30 GB with Opt. 1s).
TLA720: 30 GB.
A second internal fixed hard disk is available for both
mainframes with TLA7UP Opt.10.

CD ROM – 24x, Internal.
Floppy Disk Drive – Built-in 3.5 in. 1.44 MB drive.
Year 2000 Compliant– Yes.

TLA700 Integral Controls (TLA714
only)

Front-Panel Display –

Size: 10.4 in. diagonal.
Type:Active-matrix color TFT LCD with backlight.
Resolution: 800 x 600.
Colors: 16.8 M (true color).

Simultaneous Display Capability – Both the front-panel
and external displays can be used simultaneously at
800 x 600 resolution.

Front-panel Knobs – Special function knobs for instru­ment control.

Front-panel Qwerty Keypad – Mini-QWERTY keypad
and Hex keypad.

Front-panel Pointing Device – Glidepoint finger pad.

TLA700 External Peripheral
Interfaces (TLA714 and TLA720)

External Display Port Type – Female DB15 SVGA
connector.

External Display Resolution – Up to 1600 x 1200 non­interlaced @ 256 colors.

External Display Compatibility – DDC2B (Dynamic
Display Configuration 2).

External Keyboard Port Type – PS2 mini-DIN.
External Mouse Port Type – PS2 mini-DIN.
Parallel Interface Port Type – IEEE 1284-C connector

(comes standard with adapter to female DB25 connector).
Parallel Interface Modes – Centronics mode, EPP

(Extended Parallel Port), ECP (Microsoft high-speed
mode).

Serial Interface Port Type – Male DB9.
PC Card (CardBus) Slot Types – Two slots, two PC Card

Type I/II or one PC Card Type III.
USB Port – Two (2).

TLA600 PC Characteristics

Operating System – Microsoft Windows 2000
Professional.

Processor – Celeron®.
DRAM – 64 MB SDRAM (128 MB with Opt. 1J).
Sound – Built-in PC speaker transducer; 16-Bit I/O and

Mic In port.

Hard Disk Drive – 10 GB (30 GB with Opt. 1J).
CD ROM – 40x, Internal.
Floppy Disk Drive – Built-in 3.5 in. 1.44 MB drive.
Year 2000 Compliant– Yes.

TLA600 Integral Controls
(TLA61X/62X only)

Front-Panel Display –

Size: 10.4 in. diagonal.
Type:Active-matrix color TFT LCD with backlight.
Resolution: 800 x 600.
Colors: 16.8 M (true color).

Simultaneous Display Capability – Both the front-panel
and external displays can be used simultaneously,each
with independent resolutions.

Front-panel Knobs – Special function knobs for instru­ment control.

Front-panel Qwerty Keypad – Mini-QWERTY keypad.

TLA600 External Peripheral
Interfaces

External Display Port Type – Female DB15 SVGA
connector.

External Display Resolution – Up to 1280 x 1024 non­interlaced @ 16 M colors.

LAN Port Type – 10/100-BaseT,RJ-45.
External Keyboard Port Type – PS2 mini-DIN.
External Mouse Port Type – PS2 mini-DIN.
Parallel Interface Port Type – Female DB25.
Parallel Interface Modes – Centronics mode, EPP

(Extended Parallel Port), ECP (Microsoft high-speed
mode).

Serial Interface Port Type – Male DB9.
Audio Out Port Type – Stereo minijack.
Mic In Port Type – Minijack.
PC Card (CardBus) Slot Types – Two slots, two PC Card

Type I/II or one PC Card Type III.
USB Port – One (1).

Symbolic Support (All TLA Logic
Analyzers)

Number of Symbols/Ranges – Unlimited (limited only by
amount of virtual memory available on TLA).

TLA Family • Logic Analyzers • www.tektronix.com/LA

5

Logic Analyzers

TLA Family

Object File Formats Supported –

IEEE695
OMF 51, OMF 86, OMF 166, OMF 286, OMF 386
COFF
Elf/Dwarf 1 and 2
Elf/Stabs
TSF (if your software development tools do not

generate output in one of the above formats,TSF
or the Tektronix symbol file, a generic ASCII file
format is supported.The generic ASCII file format
is documented in the TLA User Manual).If a format
is not listed, please contact your local Tektronix
representative.

External Instrumentation
Interfaces (all TLA logic analyzers)

System Trigger Output – Asserted whenever a system
trigger occurs (TTL-compatible output, back-terminated
into 50 Ω).

System Trigger Input – Forces a system trigger (triggers
all modules) when asserted (TTL-compatible, edge-sensi­tive, falling-edge latched).

External Signal Output – Can be used to drive external
circuitry from a module’s trigger mechanism (TTL-com­patible output, back-terminated into 50 Ω).

External Signal Input – Can be used to provide an exter­nal signal to arm or trigger any or all modules (TTL-com­patible, level-sensitive).

P6041 External Signal Cable Length – (SMB to BNC
adapter cable, two each TLA720 only) 1.1 m (42 in.).

Power

TLA60X/61X/62X –

Voltage range/frequency:90-250 VAC @ 45-66 Hz.
100-132 VAC @ 360-440 Hz.
Input current: 6 A maximum at 90 VAC (70A surge).
Power consumption: 400 W maximum.

TLA714 –

Voltage range/frequency:90-250 VAC @ 45-66 Hz.
100-132 VAC @ 360-440 Hz.
Input current: 6 A maximum at 90 VAC (70A surge).
Power consumption: 600 W maximum.

TLA720 and TLA7XM –

Voltage range/frequency:90-250 VAC @ 45-66 Hz,100­132 VAC @ 360-440 Hz.
Input current: 16.5 A maximum at 90 VAC (70A surge).
Power consumption: 1450 W maximum.

Physical Characteristics

TLA714 Portable
Dimensions mm in.

Height 235 9.25
Width 432 17
Depth 455 17.5

Weight kg lb.

Net (w/o modules) 11.4 25
Shipping (typical) 25.5 56

TLA720 Benchtop & TLA7XM Expansion
Dimensions mm in.

Height 346 13.65
Width 425 16.7
Depth 673 26.5

Weight kg lb.

Net (w/o modules) 22.7 50
Shipping (typical) 51.8 114

TLA60X
Dimensions mm in.

Height 281.94 11.10
Width 457.20 18.00
Depth 414.02 16.30

Weight kg lb.

Net (w/o probes) 16.8 37
Shipping (typical) 38.6 85

TLA61X/62X
Dimensions mm in.

Height 281.94 11.10
Width 457.20 18.00
Depth 414.02 16.30

Weight kg lb.

Net (w/o probes) 17.3 38
Shipping (typical) 39.1 86

Environmental

Temperature–

Operating: +5°C to +50°C.
Nonoperating: –20°C to +60°C.

Humidity –

20% to 80%.
Operating: ≤30°C; 80% relative humidity (29°C maximum
wet bulb temperature).
Nonoperating: 8% to 80% (29°C maximum wet bulb tem­perature).

Altitude –

Operating: –1,000 ft to 10,000 ft. (–305 meters to 3,050
meters).

Safety – UL3111-1, CSA1010.1,EN61010-1,
IEC61010-1.

Ordering Information

TLA60X

Logic Analyzer with External Display.
Includes: Mouse, Keyboard, Front-panel Cover,Accessory

Pouch, Probe retainer bracket, Probe manual,Power Cord
(North American 120 VAC, 60 Hz), Software, User
Manual, Certificate of Calibration, and One-year Warranty
(return to Tektronix), and your choice of probes. Display is
not included – order Opt. 1M or Opt. 2M or use any
SVGA monitor.

TLA601 – 34 channel Logic Analyzer,2 GHz timing,
100 MHz state, 64 K depth (must select one probe option
below). Options for up to 256 K depth and/or 200 MHz
state. Requires external display.

TLA602 – 68 channel Logic Analyzer,2 GHz timing,
100 MHz state, 64 K depth (must select one probe option
below). Options for up to 256 K depth and/or 200 MHz
state. Requires external display.

TLA603 – 102 channel Logic Analyzer,2 GHz timing,
100 MHz state, 64 K depth (must select one probe option
below). Options for up to 256 K depth and/or 200 MHz
state. Requires external display.

TLA604 – 136 channel Logic Analyzer,2 GHz timing,
100 MHz state, 64 K depth (must select one probe option
below). Options for up to 256 K depth and/or 200 MHz
state. Requires external display.

TLA61X

Logic Analyzer with Internal Display.
Includes: Mouse, Keyboard, Front-panel cover,Accessory

Pouch, Probe Retainer Bracket, Probe Manual,Power
Cord (North American 120 VAC, 60 Hz), Software, User
Manual, Certificate of Calibration, and One-year Warranty
(return to Tektronix), and your choice of probes.

TLA611 – 34 channel Logic Analyzer,2 GHz timing,
100 MHz state, 64 K depth (must select one probe option
below). Options for up to 256 K depth and/or 200 MHz
state.

TLA612 – 68 channel Logic Analyzer,2 GHz timing,
100 MHz state, 64 K depth (must select one probe option
below). Options for up to 256 K depth and/or 200 MHz
state.

TLA613 – 102 channel Logic Analyzer,2 GHz timing,
100 MHz state, 64 K depth (must select one probe option
below). Options for up to 256 K depth and/or 200 MHz
state.

TLA614 – 136 channel Logic Analyzer,2 GHz timing,
100 MHz state, 64 K depth (must select one probe option
below). Options for up to 256 K depth and/or 200 MHz
state.

TLA Family • Logic Analyzers • www.tektronix.com/LA

6

Logic Analyzers

TLA Family

TLA62X

Logic Analyzer with Internal Display.
Includes: Mouse, Keyboard, Front-panel cover,Accessory

Pouch, Probe Retainer Bracket, Probe Manual,Power
Cord (North American 120VAC,60 Hz), Software, User
Manual, Certificate of Calibration, and One-year Warranty
(return to Tektronix), and your choice of probes.

TLA621 – 34 channel Logic Analyzer,2 GHz timing,
100 MHz state, 1 M depth (must select one probe option
below). Option for up to 200 MHz state.

TLA622 – 68 channel Logic Analyzer,2 GHz timing,
100 MHz state, 1 M depth (must select one probe option
below). Option for up to 200 MHz state.

TLA623 – 102 channel Logic Analyzer,2 GHz timing,
100 MHz state, 1 M depth (must select one probe option
below). Option for up to 200 MHz state.

TLA624 – 136 channel Logic Analyzer,2 GHz timing,
100 MHz state, 1 M depth (must select one probe option
below). Option for up to 200 MHz state.

Logic Analyzer Probe Options

Opt. 1P – Add P6418 17 channel general-purpose
probes (each includes two 8 channel leadsets, one 1
channel leadset, 20 SMT KlipChip™grabber tips).

Opt. 2P – Add P6434 34 channel high-density probe(s).
Opt. 3P – Add P6417 17 channel general-purpose

probes (each includes two 8 channel leadsets, one 1
channel leadset, 20 SMT KlipChip grabber tips). Quantity
of probes per option.

TLA60X/61X Logic Analyzer
Options

(Base configuration is 64 K depth @ 100 MHz state)

1S – Increase to 256K depth @ 100 MHz state.
4S – Increase to 64 K depth @ 200 MHz state.
5S – Increase to 256K depth @ 200 MHz state.

TLA62X Logic Analyzer Option

(Base configuration is 1 M depth @ 100 MHz state)
6S – Increase to 1 M depth @ 200 MHz state.

TLA60X/61X/62X Options

Opt. 1J – 128 MB DRAM/30 GB hard disk.
Opt. 1K – Add LACART logic analyzer cart.
Opt. 1M – Add 17 in. monitor (119-5700-00).
Opt. 2M – Add 21 in. monitor (119-5798-00).

TLA714

Portable Color Mainframe.
Includes: Mouse, Keyboard, Front-panel Cover,Accessory

Pouch,Two Dual-wide Panel Fillers for Empty Slots,
Printer Adapter, Power Cord (North American
120 VAC,60 Hz),Software, User Manual, Certificate of
Calibration, and One-year Warranty (return to Tektronix).

TLA720

Benchtop Color Mainframe.
Includes: Mouse, Keyboard, Five Dual-wide Panel Fillers

for Empty Slots, Printer Adapter,Two P6041 SMB to BNC
Adapter Cables; Power Cord (North American 120 VAC,
60 Hz), Software, User Manual, Certificate of Calibration,
and One-year Warranty (return to Tektronix).Display is not
included – order Opt. 1M or Opt. 2M or use any SVGA
monitor.

TLA7XM

Expansion Mainframe.
Includes: Two expansion modules,Three expansion

cables, Six dual-wide panel fillers for empty slots, One
single-wide panel filler for empty slot, manual, Power
Cord (North American 120 VAC, 60 Hz), Statement of
Compliance, and One-year Warranty (return to Tektronix).

If installing a TLA7XM expansion mainframe into a
TLA704/TLA711 or TLA714/TLA720 mainframe,please
consult the TLA Family Upgrade Guide for upgrade
information.

TLA714/720 Options

Opt. 1S – 128 MB DRAM/30 GB replaceable hard disk
(TLA714 only).

Opt. 1A – Add LAN PC Card (119-6072-00).
Opt. 1K – Add LACART logic analyzer cart.
Opt. 1M – Add 17 in. monitor (119-5700-00).
Opt. 2M – Add 21 in. monitor (119-5798-00).

Logic Analyzer Modules

Includes: Probe retainer bracket, Probe Manual, User
Manual, Certificate of Calibration, One-year Warranty
(return to Tektronix), and your choice of probes.

TLA7N1 – 34 channel Logic Analyzer module, 2 GHz tim­ing, 100 MHz state, 64 K depth (must select one probe
option below). Options for up to 4 M depth and/or
200 MHz state.

TLA7N2 – 68 channel Logic Analyzer module, 2 GHz tim­ing, 100 MHz state, 64 K depth (must select one probe
option below). Options for up to 4 M depth and/or
200 MHz state.

TLA7N3 – 102 channel Logic Analyzer module, 2 GHz
timing, 100 MHz state, 64 K depth (must select one
probe option below). Options for up to 4 M depth and/or
200 MHz state.

TLA7N4 – 136 channel Logic Analyzer module, 2 GHz
timing, 100 MHz state, 64 K depth (must select one
probe option below). Options for up to 4 M depth and/or
200 MHz state.

TLA7P2 – 68 channel Logic Analyzer module, 2 GHz tim­ing, 100 MHz state, 16 M depth (must select one probe
option below). Option for up to 200 MHz state.

TLA7P4 – 136 channel Logic Analyzer module, 2 GHz
timing, 100 MHz state, 16 M depth (must select one
probe option below). Option for up to 200 MHz state.

TLA7Q2 – 68 channel Logic Analyzer module, 2 GHz tim­ing, 100 MHz state, 64 M depth (must select one probe
option below). Option for up to 200 MHz state.

TLA7Q4 – 136 channel Logic Analyzer module, 2 GHz
timing, 100 MHz state, 64 M depth (must select one
probe option below). Option for up to 200 MHz state.

TLA Family • Logic Analyzers • www.tektronix.com/LA

7

Quantity of Probes per Option

Option TLA7N1 TLA7N2 TLA7N3 TLA7N4 TLA7P2 TLA7P4 TLA7Q2 TLA7Q4

1P Add P6418 Probes 2 4 6 8 4 8 4 8
2P Add P6434 Probes 1 2 3 4 2 4 2 4
3P Add P6417 Probes 2 4 6 8 4 8 4 8

Option TLA601/611/621 TLA602/612/622 TLA603/613/623 TLA604/614/624

1P Add P6418 Probes 2 4 6 8
2P Add P6434 Probes 1 2 3 4
3P Add P6417 Probes 2 4 6 8

Please refer to the “Logic Analyzer Probe Selection Guidelines”for further details on the probe which is best for
your application.

Logic Analyzers

TLA Family

For other areas,contact:Tektronix,Inc.

Export Sales, P.O.Box 500,M/S 50-255,

Beaverton, Oregon 97077-0001, USA 1 [phone]

For the most up-to-date product information

visit our web site at

www.tektronix.com

Copyright © 2000, Tektronix, Inc. All rights reser ved. Tektronix products are
covered by U.S. and foreign patents, issued and pending.Information in this publi­cation supersedes that in all previously published material. Specification and price
change privileges reserved. TEKTRONIX and TEK are registered trademarks of
Tektronix, Inc. All other trade names referenced are the service marks, trademarks
or registered trademarks of their respective companies.

09/00 HB/XBS 52W-14259-0

Contact Tektronix:

ASEAN Countries

(65) 356-3900

Australia & New Zealand

61 (2) 9888-0100

Austria, Central Eastern Europe,

Greece,Turkey, Malta & Cyprus

[phone]

Belgium

[phone]

Brazil and South America

55 (11) 3741-8360

Canada

1 [phone]

Denmark

[phone]

Finland

[phone]

France & North Africa

[phone]

Germany

[phone]

Hong Kong

(852) 2585-6688

India

(91) 80-2275577

Italy

[phone]

Japan (Sony/Tektronix Corporation)

81 (3) 3448-3111

Mexico, Central America, & Caribbean

52 (5) 666-6333

The Netherlands

[phone]

Norway

[phone]

People’s Republic of China

86 (10) 6235 1230

Poland

(48) 22 521 5340

Republic of Korea

82 (2) 528-5299

South Africa

(27 11) 651-5222

Spain & Portugal

[phone]

Sweden

[phone]

Switzerland

[phone]

Taiwan

886 (2) 2722-9622

United Kingdom & Eire

[phone]

USA

1 [phone]

Logic Analyzer “N, P & Q” Module
Probe Options

Opt. 1P – Add P6418 17 channel general-purpose
probes (each includes two 8 channel leadsets, one 1
channel leadset, 20 SMT KlipChip™grabber tips).

Opt. 2P – Add P6434 34 channel high-density probe(s).
Opt. 3P – Add P6417 17 channel general-purpose

probes (each includes two 8 channel leadsets, one 1
channel leadset, 20 SMT KlipChip™grabber tips).

Logic Analyzer “N” Module Options

(Base configuration is 64 K depth @ 100 MHz state)

1S – Increase to 256 K depth @ 100 MHz state.
2S – Increase to 1 M depth @ 100 MHz state.
3S – Increase to 4 M depth @ 100 MHz state.
4S – Increase to 64 K depth @ 200 MHz state.
5S – Increase to 256 K depth @ 200 MHz state.
6S – Increase to 1 M depth @ 200 MHz state.
7S – Increase to 4M depth @ 200 MHz state.

Logic Analyzer “P” Module Options

(Base configuration is 16 M depth @ 100 MHz state)
1S – Increase to 16 M depth @ 200 MHz state.

Logic Analyzer “Q” Module Options

(Base configuration is 64 M depth @ 100 MHz state)
1S – Increase to 64 M depth @ 200 MHz state.

Pattern Generator Module

TLA7PG2 – 64 channel Pattern Generator Module, 134
MHz data rate, 256 K depth (please select probe option
below).

Includes: Four probe cables, User Manual, Certificate of
Calibration and one year warranty (return to Tektronix).

Opt. 1M – Increase to 1 M depth.
Opt. 1P – Add four P6470 TTL/CMOS probes (each

includes two 8 channel leadsets and one 5 channel lead­set).

Opt. 2P – Add four P6471 ECL probes (each includes
two 8 channel leadsets and one 5 channel leadset).

Opt. 1C – Add 168 SMT KlipChip grabber tips.

Digitizing Oscilloscope Modules

Includes: Probes, User Manual, Certificate of Calibration,
and One-year Warranty (return to Tektronix).

TLA7D1 – 2 channel DSO module,500 MHz bandwidth,

2.5 GS/s sample rate, 15 K depth (includes two P6243

1.0 GHz active FET probes, probe calibration adapter,and
manual).

TLA7D2 – 4 channel DSO module,500 MHz bandwidth,

2.5 GS/s sample rate, 15 K depth (includes four P6243

1.0 GHz active FET probes, probe calibration adapter,and
manual).

TLA7E1 – 2 channel DSO module,1 GHz bandwidth,
5 GS/s sample rate, 15 K depth (includes two P6245

1.5 GHz active FET probes, probe calibration adapter,and
manual).

TLA7E2 – 4 channel DSO module, 1 GHz bandwidth,
5 GS/s sample rate, 15 K depth (includes four P6245

1.5 GHz active FET probes, probe calibration adapter,and
manual).

TLA Family International Power
Plugs

Opt. A1 – Universal Euro 220 VAC; 50 Hz.
Opt. A2 – UK 240 VAC; 50 Hz.
Opt. A3 – Australian 240 VAC; 50 Hz.
Opt. A4 – North American 240 VAC; 60 Hz.
Opt. A5 – Switzerland 220 VAC; 50 Hz.
Opt. A99 – No Power Cord.

TLA Family Service Options

Opt. IN – Product installation ser vice (on-site configura­tion and user familiarization; excluding network integra­tion).

Opt. R3 – Extends depot repair warranty ser vice period to
three years.

Opt. S1 – Uplifts standard one-year warranty ser vice of
mainframe and installed modules to on-site service.

Opt. S3 – Uplifts Opt. C3 and/or R3 of mainframe and
installed modules to on-site service (must be ordered
with Opt. C3 and/or R3).

Opt. C3 – Three years of Calibration Service (includes ini­tial calibration and two annual calibrations).

Add calibration test data report.

Opt. D1 – Add calibration test data report.
Opt. D3 – Provides test data for each calibration (must

be ordered with Opt. C3).

TLA Family • Logic Analyzers • www.tektronix.com/LA

8
