Tektronix TLA715 Data Sheet

Tektronix Logic Analyzers

TLA7000 Series Mainframes

Breakthrough Solutions for Real-time Digital Systems Analysis

Tektronix provides breakthrough digital
systems analysis tools that enable digital
hardware and software designers to
capture and analyze the source of elusive
problems that threaten product develop­ment schedules. The TLA7000 Series
provides the speed you need to capture
the source of those elusive problems,
plus the visibility you want with large
displays and fast system data throughput,
while protecting your investment with
compatibility with all TLA modules.
The TLA7012 Portable and TLA7016
Benchtop mainframes are modular main­frames that accept TLA logic analyzer and
pattern generator modules. The TLA7012
and TLA7016 can be configured as either
master or expansion mainframes to provide
solutions for large numbers of buses
and high channel count requirements.
The TLA7012 Portable Mainframe
and TLA7016 Benchtop Mainframe
with TLA7PC1 Benchtop Controller
are built on a Microsoft Windows XP
Professional PC platform that offers a
familiar work environment for the TLA
application software.
The TLA7012 Portable and TLA7016
Benchtop Mainframe with TLA7PC1
Benchtop Controller are available with

multiple display capability for extended
desktop viewing, in addition to an internal
DVD-RW, hard drive and multiple USB2.0
ports for expansion. A replaceable hard
drive is standard on both mainframes, ideal
for security or enabling individual team
members to store personal setups and
data. Trigger in/out connections provide an
interface to other external instrumentation,
such as TDS oscilloscopes, for correlating
measurement results.

Flat-Fee Installation and
Configuration Service Option

Make the most of your TLA7000 Series with
comprehensive installation and configura­tion services from a TLA Certified Customer
Service Engineer (CCSE). The flat-fee
option includes installation and configura­tion of a single mainframe and its respective
module(s). There are two options available,
dependent upon the number of modules
to be installed.

Features & Benefits

Modular Mainframes Provide
Flexibility and Expandability

Utilize TLA Logic Analyzer or
Pattern Generator Modules

Supports Up to 6,528 Logic
Analyzer Channels, 48
Independent Buses

All Measurement Modules
are Fully Interchangeable
Between Portable and
Benchtop Mainframes

Integrated View (iView™)
Capability Provides up to
15 GHz, 40 GS/s and 64 Mb
Analog Acquisition with a
Stand-alone Tektronix TDS
Digital Storage Oscilloscope

Microsoft Windows XP
Professional PC Platform
Provides Familiar User Interface
With Network Connectivity

View Data in Waveform,
Listing, Source Code, Histogram
(Performance Analysis) Displays
to Perform Cross-domain Analysis

Remotely Control and Monitor
the TLA Over the Network Using
Either Hosted Mode or Via Built­in Windows XP Remote Desktop

Remote Control Using Microsoft
.NET and COM/DCOM Technology
Supports Advanced Data Analysis

Broad Processor and Bus Support

Worldwide Service Centers
Offer Consistent Quality and
Technical Expertise

Applications

Hardware Debug and Verification

Processor/Bus Debug and
Verification

Embedded Software Integration,
Debug and Verification

Tektronix Logic Analyzers

TLA7000 Series Mainframes

Characteristics

General (TLA7012, TLA7016)

Instrument Slots –

TLA7012: Holds 2 TLA modules.
TLA7016: Holds 6 TLA modules.

Expansion Capability –

The TLA7000 Series Mainframes can be used as
either master or expansion mainframes (TL708EX
8-port Instrument Hub and Expander is required for
3 to 8 mainframes connected together using

™

cable).

TekLink
TLA7012: Up to eight TLA7012 mainframes can be
used providing support for up to 16 TLA modules.
TLA7016: Up to eight TLA7016 mainframes can be
used providing support for up to 48 TLA modules.

Mainframe LA PG

Max channels 136 ch. 64 ch.
per module

TLA7012 2,176 1,024
TLA7016 6,528 3,072

For configurations beyond eight TLA7012/7016
mainframes, please contact your local Tektronix
representative.

TLA7012 PC Characteristics

Operating System –

Microsoft Windows XP Professional and
Multi-Lingual User Interface Pack.

Processor – 2 GHz Intel Pentium M-760.
Chipset – Intel 915GM.
Memory –

1 GB DDR PC 533 MHz (SODIMM), expandable to
2 GB DDR memory.

Sound – Line In and Mic Out connectors.
Removable Hard Drive –

3.5 in., 80 GB Serial ATA, 7200 RPM.

Optical Drive – Internal 4.7 GB DVD±R/RW.
External Display Port Type –

One (1) DVD-D (primary – digital only) and one (1)
DVD-I (secondary – digital and analog) connectors
(includes one DVI-I-to-analog DB-15 adapter).

External Display Resolution –

Up to 1600x1200 non-interlaced at 32-bit color,
each for both primary and secondary displays.

Network Port –

One (1) 10/100/1000 LAN with RJ-45 connector.

USB 2.0 Port –

Seven (7); three (3) in front and four (4) in rear.

TLA7012 Integral Controls

Front-Panel Display –

Size: 15 in. (38.1 cm) diagonal.
Type: Active-matrix color TFT LCD with backlight.
Resolution: 1024x768.

Simultaneous Display Capability –

Both the front-panel and one external display can be
used simultaneously at 1024x768 resolution.

Front-panel –

General-purpose knob with dedicated hot-keys and
knobs for horizontal and vertical scaling and scrolling.
Touchscreen – Available with Option 18.

TLA7PC1 Benchtop Controller
Characteristics

Operating System –

Microsoft Windows XP Professional and
Multi-Lingual User Interface Pack.

Processor – 3 GHz Intel Pentium 4.
Chipset – Intel 865G.
Memory –

1 GB dual channel DDR, PC 800 MHz (DIMM),
expandable to 4 GB DDR memory.

Sound – Line In and Mic Out connectors.
Removable Hard Drive –

3.5 in., 80 GB Serial ATA, 7200 RPM. Supports
second Serial ATA Removable Hard Drive (includes
second removable hard drive assembly only – user
supplies second hard drive).

Optical Drive – Internal 4.7 GB DVD±R/RW.
External Display Port Type –

One (1) analog DB-15 connector.

External Display Resolution –

Up to 1600x1200 non-interlaced at 65,536 colors.

Network Port –

One (1) 10/100/1000 LAN with RJ-45 connector.

USB 2.0 Port –

Six (6); two (2) in front and four (4) in rear.

PS/2 Ports –

Three (3); one (1) in front and two (2) in rear.

Enhanced Parallel Port –

Standard DB25 female connector; supports
EPP/SPP/ECP.

Serial Port – Standard DB9 male connector.
PCI Bus –

Three full-size PCI slots, 32-bit, 33 MHz. Can be
used to add up to three additional optional PCI Video
Display cards, available from third-parties, for a total
of four displays.

Integrated View (iView™)
Capability

TLA Mainframe Configuration Requirements –

TLA7012/7016 Series mainframes, TLA714/720/
715/721 Series mainframes, TLA520x instruments,
and TLA6XX instruments.
TLA App S/W V 4.1 or greater.
256 MB DRAM Minimum, 512 MB recommended.

TDS Configuration Requirements –

The iView cable does not fully connect to the
TDS1000/2000 Series oscilloscopes without a GPIB
extender.Tektronix recommends a standard GPIB
cable as an extender, or order a cable extender
(National Instruments part number 181638-1).
TDS2CMAX Communications Extension Module is
required for iView capability on any TDS1000/2000
Series. TDS3GM GPIB/RS232 Interface Module
required for iView capability on any TDS3000 series.

TDS3GV GPIB/RS232/VGA Interface Module
required for iView capability on any TDS3000B
series. If using TLA7Axx iConnect with a TDS oscillo­scope with TCA input connectors, four TCA-BNC
connectors are required to be compatible with BNC
cables from the TLA7Axx module.

Number of TDS oscilloscopes that can be
connected to a TLA system – 1.
External Oscilloscopes Supported –

For a complete list of currently supported TDS
oscilloscopes, please visit our website
http://www.tektronix.com/iview.

TLA Connections –

USB, Trigger In, Trigger Out, Clock Out.

TDS Connections –

GPIB, Trigger In, Trigger Out, Clock In (when available).
Setup – iView external oscilloscope wizard auto­mates setup.

Data Correlation –

After TDS oscilloscope acquisition is complete, the
data is automatically transferred to the TLA and time
correlated with the TLA acquisition data.

Deskew –

TDS and TLA data is automatically deskewed and
time correlated when using the iView external
oscilloscope cable.
iView External Oscilloscope Cable Length – 2m.

Symbolic Support

Number of Symbols/Ranges –

Unlimited (limited only by amount of virtual memory
available on TLA).

Object File Formats Supported –

IEEE 695, OMF 51, OMF 86, OMF 166, OMF 286,
OMF 386, COFF, Elf/Dwarf 1 and 2, Elf/Stabs, TSF
(if your software development tools do not generate
output in one of the above formats, TSF or the
Tektronix symbol file, a generic ASCII file format is
supported. The generic ASCII file format is documented
in the TLA User Manual). If a format is not listed,
please contact your local Tektronix representative.

External Instrumentation
Interfaces

System Trigger Output –

Asserted whenever a system trigger occurs (TTL­compatible output, back-terminated into 50 Ω).

System Trigger Input –

Forces a system trigger (triggers all modules) when
asserted (adjustable threshold between 0.5 V and

1.5 V, edge-sensitive, falling-edge latched).

External Signal Output –

Can be used to drive external circuitry from a
module’s trigger mechanism (TTL-compatible
output, back-terminated into 50 Ω).

External Signal Input –

Can be used to provide an external signal to arm or
trigger any or all modules (adjustable threshold
between 0.5 V and 1.5 V, level-sensitive).

Logic Analyzers • www.tektronix.com/logic_analyzers

2

Tektronix Logic Analyzers

TLA7000 Series Mainframes

Power

TLA7012 –

Voltage range/frequency: 90 to 250 VAC at
45 to 66 Hz. 100 to 132 VAC at 360 to 440 Hz.
Input current: 7 A maximum at 90 VAC (70 A surge).
Power consumption: 750 W maximum.

TLA7016 –

Voltage range/frequency: 90 to 250 VAC at
45 to 66 Hz, 100 to 132 VAC at 360 to 440 Hz.
Input current: 16.5 A maximum at 90 VAC (70 A surge).
Power consumption: 1,450 W maximum.

TLA7PC1 –

Voltage range/frequency: 100 to 240 VAC at 50 to 60 Hz.
Input current: 3 A maximum at 100 VAC.
Power consumption: 300 W maximum.

TL708EX –

Voltage range/frequency: 100 to 240 VAC at 50 to 60 Hz.
Input current: 2 A maximum at 100 VAC.
Power consumption: 200 W maximum.

Physical Characteristics

TLA7012 Portable
Dimensions mm in.

Height 295 11.6
Width 451 17.75
Depth 460 18.1

Weight kg lb.

Net (without modules) 14 30
Shipping (typical) 27 59

TLA7016 Benchtop
Dimensions mm in.

Height 350 13.7
Width 425 16.7
Depth 673 26.5

Weight kg lb.

Net (without modules) 25 55
Shipping (typical) 51.8 115

TLA7PC1 Benchtop Controller
Dimensions mm in.

Height 89 3.5
Width 432 17
Depth 483 19

Weight kg lb.

Net 9 19
Shipping 15 33

TL708EX 8-Port Instrument Hub and Expander
Dimensions mm in.

Height 51 2
Width 445 17.5
Depth 305 12

Weight kg lb.

Net 3 6
Shipping 5 11

Environmental

Temperature –

Operating: +5 ºC to +45 ºC.
Nonoperating: –20 ºC to +60 ºC.

Humidity –

20% to 80%.
Operating: ≤30 ºC; 80% relative humidity (29 ºC
maximum wet bulb temperature).
Nonoperating: 8% to 80% (29 ºC maximum wet
bulb temperature).

Altitude –

Operating: –1,000 ft. to 10,000 ft. (–305 meters
to 3,050 meters).

Safety –

UL3111-1, CSA1010.1, EN61010-1, IEC61010-1.

Ordering Information

TLA7012

Portable Logic Analyzer Mainframe, holds two TLA
modules.

Includes: Mini Keyboard, USB ( 119-7083-00),
Optical Wheel Mouse, USB (119-7054-xx), TekLink
cable (174-5019-xx), LAN cable, straighthrough,
RJ-45 (174-5225-xx), front-panel cover (200-4939-xx),
accessory pouch (016-1441-xx), DVI-to-Analog
Video Adapter (013-0346-xx), two dual-wide panel
fillers for empty slots (333-4206-xx), Mouse Pad
(016-1524-xx), TLA7000 Series Product Software
CD (063-3881-xx), TLA7012 Series Recovery
Media (063-3876-xx), TLA Documentation CD
(063-3671-xx), TLA Quick Start User Manual
(071-1575-xx), TLA7000 Installation Manual
(071-1747-xx) and Certificate of Traceable
Calibration. Please specify power cord, language
and service options when ordering.

Opt. 18 – Add touchscreen (TLA7012 only).

Opt. 1C – Add iView

interface kit (012-1614-xx).

Opt. 1K – Add LACART logic analyzer cart.

TLA7016

Benchtop Logic Analyzer Mainframe, holds six
TLA modules.

Includes: Six (6) dual-wide panel fillers for empty
slots (333-4206-xx), TekLink cable(174-5019-xx),
LAN cable, straighthrough, RJ-45 (174-5225-xx),
Benchtop System Mounting Brackets (left-hand
(407-5127-xx) and right-hand (407-5132-xx)),
TLA7000 Series Product Software CD (063-3881-xx),
TLA Documentation CD (063-3671-xx), TLA Quick
Start User Manual (071-1575-xx), TLA7000
Installation Manual (071-1747-xx) and Certificate
of Traceable Calibration. Please specify power cord,
language and service options when ordering.

Opt. 1C – Add iView external oscilloscope interface
kit (012-1614-xx).

Opt. 1K – Add LACART logic analyzer cart.

™

external oscilloscope

TLA7PC1

Controller for TLA7016 Benchtop Logic
Analyzer Mainframe.

Includes: Mini Keyboard, USB ( 119-7083-00),
Optical Wheel Mouse, USB (119-7054-xx), LAN
cable, straighthrough, RJ-45 (174-5225-xx),
Mouse Pad (016-1524-xx), TLA7000 Series
Product Software CD (063-3881-xx), TLA7PC1
Series Recovery Media (063-3888-xx), TLA
Documentation CD (063-3671-xx), TLA Quick Start
User Manual (071-1575-xx), TLA7000 Installation
Manual (071-1747-xx), and Statement of
Compliance. Please specify power cord, language
and service options when ordering.

TL708EX

TekLink 8-port Instrument Hub and Expander
(used for connecting 3-to-8 TLA7012 or
TLA7016 mainframes).

Includes: Instruction sheet (071-1765-xx, English
only). Please specify power cord and service
options when ordering.

Power Cord Options

Opt. A0 – North America power.
(TLA7012/TLA7PC1/TL708EX: 161-0104-00;
TLA7016: 161-0213-00 [15A], 161-0218-00 [20A].)

Opt. A1 – Universal EURO power.
(TLA7012/TLA7PC1/TL708EX: 161-0104-06;
TLA7016: 161-0209-00.)

Opt. A2 – United Kingdom power.
(TLA7012/TLA7PC1/TL708EX: 161-0104-07;
TLA7016: 161-0210-00.)

Opt. A3 – Australia power.
(TLA7012/TLA7PC1/TL708EX: 161-0104-14;
TLA7016: 161-0211-00.)

Opt. A4 – 240 V, North America power.
(TLA7012/TLA7PC1/TL708EX: 161-0104-08;
TLA7016: 161-0208-00.)

Opt. A5 – Switzerland power.
(TLA7012/TLA7PC1/TL708EX: 161-0167-00;
TLA7016: 161-0212-00.)

Opt. A6 – Japan power.
(TLA7012/TLA7PC1/TL708EX: 161-A005-00;
TLA7016: 161-0218-00.)

Opt. A10 – China power.
(TLA7012/TLA7PC1/TL708EX: 161-0306-00;
TLA7016: 161-0320-00.)

Opt. A99 – No power cord or AC adapter.

Logic Analyzers • www.tektronix.com/logic_analyzers

3

Tektronix Logic Analyzers

TLA7000 Series Mainframes

Language Options

Opt. L0 – English Manuals.

Opt. L5 – Japanese Manuals.

Opt. L10 – Russian Manuals.

Opt. L99 – No Manuals.

Service Options

Opt. CA1 – Provides a single calibration or
functional verification event.

Opt. C3 – Calibration Service 3 Years.

Opt. C5 – Calibration Service 5 Years.

Opt. D1 – Calibration Data Report.

Opt. D3 – Calibration Data Report 3 Years

(with Opt. C3).

Opt. D5 – Calibration Data Report 5 Years
(with Opt. C5).

Opt. R3 – Repair Service 3 Years.

Opt. R5 – Repair Service 5 Years.

Opt. S1 – On-site Service 1 Year.

Opt. S3 – On-site Service 3 Years (with R or

C Option).

TLA7000 Series
Installation Service

LAINSTAL-SM – Installation of single mainframe
and up to 3 modules or 1 to 3 modules in existing
mainframe.

LAINSTAL-LG – Installation of single mainframe
and 4 to 6 modules.

TLA7012/TLA7016
Factory Configuration

Opt. 88 – Install modules in mainframe at factory
(excludes merging of Logic Analyzer modules).

TLA7012/7016 Optional
Accessories

TLA Logic Analyzer Cart – LACART, K4000.

TLA7012 Additional Removable Hard Drive
Assembly (no SW) – Order 650-4815-xx.

TLA7PC1 Additional Removable Hard Drive
Assembly (no SW) – Order 650-4834-xx.

TLA7012 Rackmount Kit – Order 020-2664-xx.

TLA7012 Wheeled Transport Case – Order

016-1522-xx.

TLA7016 Rackmount Kit – Order 020-2369-xx.

TLA7016 Wheeled Transport Case – Order

016-1651-xx.

Gigabit LAN (GbE) Switch

16-port Gigabit LAN (GbE) Switch with
U.S. Standard (120 V, 60 Hz) Power Cord
– Order 020-2666-xx.

Flat-panel Display

21 in. 1600x1200 Flat-panel Display
with U.S. Standard (120 V, 60 Hz) Power
Cord – Order 020-2665-xx.

Power Cords for Gigabit
LAN (GbE) Switch and
Flat-panel Display

Power Cord, IEC320 C13, North
American, Straight – Order 161-0066-00.

Power Cord, IEC320 C13 Universal Euro,
Straight – Order 161-0066-09.

Power Cord, IEC320 C13, Universal Euro,
Straight – Order 161-0066-10.

Power Cord, IEC320 C13 Australian,
Straight – Order 161-0066-11.

Power Cord, IEC320 C13, North American,
S Straight – Order 161-0066-12.

Power Cord, IEC320 C13 Switzerland,
Straight – Order 161-0154-00.

Power Cord, IEC320 C13, Japan, Straight –

Order 161-0298-00.

Power Cord, IEC320 C13, China, Straight –

Order 161-0304-00.

TLA700 Series
Mainframe Upgrades

You can add new capabilities to your
existing TLA7012/7016 mainframe.

Please refer to the TLA Family Upgrade
Guide for further details.

Contact Tektronix:

ASEAN / Australasia (65) 6356 3900

Austria [phone]

Balkan, Israel, South Africa and other ISE Countries [phone]

Belgium 07 81 60166

Brazil & South America (11) 40669400

Canada 1 [phone]

Central East Europe, Ukraine and the Baltics [phone]

Central Europe & Greece [phone]

Denmark [phone]

Finland [phone]

France [phone]

Germany [phone]

Hong Kong (852) 2585-6688

India (91) 80-22275577

Italy [phone]

Japan 81 (3) 6714-3010

Luxembourg [phone]

Mexico, Central America & Caribbean 52 (55) 5424700

Middle East, Asia and North Africa [phone]

The Netherlands 090 02 021797

Norway 800 16098

People’s Republic of China 86 (10) 6235 1230

Poland [phone]

Portugal 80 08 12370

Republic of Korea 82 (2) 528-5299

Russia & CIS [phone]

South Africa [phone]

Spain ([phone]

Sweden 020 08 80371

Switzerland [phone]

Taiwan 886 (2) 2722-9622

United Kingdom & Eire [phone]

USA 1 [phone]

For other areas contact Tektronix, Inc. at: 1 [phone]

Updated 15 September 2006

Our most up-to-date product information is available at:

www.tektronix.com

Product(s) are manufactured

in ISO registered facilities.

Copyright © 2006, Tektronix. All rights reserved. Tektronix products are covered
by U.S. and foreign patents, issued and pending. Information in this publication
supersedes that in all previously published material. Specification and price
change privileges reserved. TEKTRONIX and TEK are registered trademarks of
Tektronix, Inc. All other trade names referenced are the service marks, trade­marks or registered trademarks of their respective companies.

11/06 HB/WOW 52W-15053-5
