Preface
This document helps customers with data security concerns to sanitize or remove
memory devices from the listed products. These products have data storage
(memory) devices and data output devices (USB ports). These instructions tell
you how to clear or sanitize the memory devices, and also tell you how to
declassify an instrument that is not functioning.
Instrument code and calibration settings reside in nonvolatile flash memory.
Instrument setups and reference waveforms may also be stored in flash memory
or on USB drives connected to the instrument.
If you have any questions, contact the Tektronix Technical Support Center at
www.tektronix.com/support.
Reference
The procedures in this document are written to meet the requirements specified
in:
■
NISPOM, DoD 5220.22–M, Chapter 8
■
ISFO Process Manual for Certification & Accreditation of Classified Systems
under NISPOM
Products
The following Tektronix products are covered by this document:
■
TBS1000 Series. TBS1022, TBS1042, TBS1062, TBS1102, TBS1152
■
TBS1000B Series. TBS1052B, TBS1072B, TBS1102B, TBS1152B,
TBS1202B
■
TBS1000B-EDU Series. TBS1052B-EDU, TBS1072B-EDU, TBS1102BEDU, TBS1152B-EDU, TBS1202B-EDU
■
TDS1000B Series. TDS1001B, TDS1002B, TDS1012B
■
TDS2000B Series. TDS2002B, TDS2004B, TDS2012B, TDS2014B,
TDS2022B,TDS2024B
■
TDS1000C-EDU Series. TDS1001C-EDU, TDS1002C-EDU, TDS1012CEDU
■
TDS2000C-EDU Series. TDS2001C, TDS2002C, TDS2004C, TDS2012C,
TDS2014C, TDS2022C, TDS2024C
■
TPS2000B Series. TPS2012B, TPS2014B, TPS2024B
Declassification and Security Instructions iii
Preface
Required documents
To perform the procedures in this document, you will need to have access to the
manuals listed below. These manuals are available on the Tektronix Web site at
www.tektronix.com/downloads.
■
TBS1000 Series Digital Storage Oscilloscope Service Manual (Tektronix
part number, 077-0772-xx)
■
TBS1000B Series Digital Storage Oscilloscope Service Manual (Tektronix
part number, 077-0897-xx)
■
TDS1000B and TDS2000B Series Digital Storage Oscilloscope Service
Manual (Tektronix part number, 077-1828-xx)
■
TDS2000C and TDS1000C-EDU Series Digital Storage Oscilloscope Service
Manual (Tektronix part number, 077-0446-xx)
■
TPS2000B Series Digital Storage Oscilloscope Service Manual (Tektronix
part number, 077-0447-xx)
iv Declassification and Security Instructions
Preface
Terms used in this document
The following terms may be used in this document:
■
Clear. This removes data on media/memory before reusing it in a secured
area. All reusable memory is cleared to deny access to previously stored
information by standard means of access.
■
Erase. This is equivalent to clear.
■
Instrument Declassification. A term that refers to procedures that must be
undertaken before an instrument can be removed from a secure environment.
Declassification procedures include memory sanitization and memory
removal, and sometimes both.
■
Media storage/data export device. Any of several devices that can be used
to store or export data from the instrument, such as a USB port.
■
Nonvolatile memory. Data is retained when the instrument is powered off.
■
Power off. Some instruments have a “Standby” mode, in which power is still
supplied to the instrument. For the purpose of clearing data, putting the
instrument in Standby mode does not qualify as powering off. For these
products, you will need to either press a rear-panel OFF switch or remove the
power source from the instrument.
■
Remove. This is a physical means to clear the data by removing the memory
device from the instrument. Instructions are available in the product Service
Manual.
■
Sanitize. This eradicates the data from media/memory so that the data cannot
be recovered by other means or technology. This is typically used when the
device will be moved (temporarily or permanently) from a secured area to a
non-secured area.
■
Scrub. This is equivalent to sanitize.
■
User Accessible. User is able to directly retrieve the memory device
contents.
■
User-modifiable. User can write to the memory device during normal
instrument operation, using the instrument interface or remote control.
■
Volatile memory. Data is lost when the instrument is powered off.
Declassification and Security Instructions v
Preface
Device terms
The following terms are used with the memory devices in this document:
■
User data. Describes the type of information stored in the device. Refers to
waveforms or other measurement data representing signals connected to the
instrument by users.
■
User settings. Describes the type of information stored in the device. Refers
to instrument settings that can be changed by the user.
■
Both. Describes the type of information stored in the device. It means that
both user data and user settings are stored in the device.
■
None. Describes the type of information stored in the device. It means that
neither user data nor user settings are stored in the device.
■
Directly. Describes how data is modified. It means that the user can modify
the data.
■
Indirectly. Describes how data is modified. It means that the instrument
system resources modify the data and that the user cannot modify the data.
vi Declassification and Security Instructions
Memory devices
Volatile memory devices
The volatile memory devices for the TBS1000B and TBS1000B-EDU products
are listed in the Volatile memory devices (TBS1000B & TBS1000B-EDU) on
page 3 section.
SDRAM 512 K
Type and size 512 K X 32
Function Acquisition memory for holding and processing waveforms, and processor system RAM
Type of user information
stored
Backed up by battery? No
Method of modification Indirect
Data input method Firmware operations, user input
Location Main Acquisition board
User accessible No
To clear Remove power from the instrument for at least 20 seconds.
Process to sanitize Remove power from the instrument for at least 20 seconds.
Both user data and user settings
SRAM 128 K
Type and size SRAM, 128 K X 8
Function Shared memory between the acquisition system and the USB processor
Type of user information
stored
Backed up by battery? No
Method of modification Indirect
Data input method Firmware operations
Location Main Acquisition board. TBS and TDS models only.
User accessible No
To clear Remove power from the instrument for at least 20 seconds.
Process to sanitize Remove power from the instrument for at least 20 seconds.
Real-time clock
Type and size Real-time clock, which contains battery backed-up memory
Function Holds date/time data
Type of user information
stored
Backed up by battery? Yes
Method of modification Indirect
Both user data and user settings
None
Declassification and Security Instructions 1
Memory devices Volatile memory devices (cont.)
Data input method User input
Location Main Acquisition board
User accessible No
To clear Remove the battery from the board.
Process to sanitize Remove the battery from the board.
USB2
Type and size USB 2.0 OTG host/peripheral controller, 8 K X 16 RAM
Function Contains USB controller program and data memory
Type of user information
stored
Backed up by battery? No
Method of modification Indirect
Data input method Firmware operations
Location Main Acquisition board. TBS and TDS models only.
User accessible No
To clear Remove power from the instrument for at least 20 seconds.
Process to sanitize Remove power from the instrument for at least 20 seconds.
None
SRAM 64 K
Type and size SRAM, 64 K X 16
Function Data memory for the USB processor
Type of user information
stored
Backed up by battery? No
Method of modification Indirect
Data input method Firmware operations
Location Main Acquisition board. TBS and TDS models only.
User accessible No
To clear Remove power from the instrument for at least 20 seconds.
Process to sanitize Remove power from the instrument for at least 20 seconds.
None
2 Declassification and Security Instructions
Volatile memory devices (cont.) Memory devices
Volatile memory devices (TBS1000B & TBS1000B-EDU)
This section lists the volatile memory devices for the TBS1000B and TBS1000BEDU products. These products have a different hardware platform than the
TBS1000, TDS1000B/TDS2000B, TDS1000C-EDU/TDS2000C, and TPS2000B
Series.
SDRAM 4 M bit
Type and size 4 Mbit, 512 K X 16
Function Acquisition memory
Type of user information
stored
Backed up by battery? No
Method of modification Indirect
Data input method Firmware operations, user input
Location Main Acquisition board
User accessible No
To clear Remove power from the instrument for at least 20 seconds.
Process to sanitize Remove power from the instrument for at least 20 seconds.
Both user data and user settings
LPDDR SDRAM
Type and size 1 g bit, (16 M X 16 bit) X four banks
Function Holding and processing waveforms and processor system RAM
Type of user information
stored
Backed up by battery? No
Method of modification Indirect
Data input method Firmware operations
Location Main Acquisition board
User accessible No
To clear Remove power from the instrument for at least 20 seconds.
Process to sanitize Remove power from the instrument for at least 20 seconds.
Both user data and user settings
Declassification and Security Instructions 3
Memory devices
Nonvolatile memory devices
The nonvolatile memory devices for the TBS1000B and TBS1000B-EDU
products are listed in the Nonvolatile memory devices container (TBS1000B &
TBS1000B-EDU) on page 5 section.
Flash
Type and size FLASH, 8 M X 8, 4 M X 16
Function Holds instrument firmware, current setup, saved setups, saved reference waveforms, hard copy
image files, and calibration constants
Type of user information
stored
Method of modification Indirect
Data input method Factory configurations, firmware operations, user input, and USB disk upgrade
Location Main Acquisition board
User accessible No
To clear Perform the procedure Clear the flash memory.
Process to sanitize Perform the procedure Clear the flash memory.
Both user data and user settings
EEPROM
Type and size EEPROM, SERIAL, 1 M
Function Program memory for the USB processor
Type of user information
stored
Method of modification Indirect
Data input method Factory configurations, USB disk upgrade
Location Main Acquisition board. TBS and TDS models only.
User accessible No
To clear Not applicable, does not contain user data or settings. Cleaning would disable instrument
Process to sanitize Not applicable, does not contain user data or settings. Sanitizing would disable instrument
None
functionality.
functionality.
4 Declassification and Security Instructions
Nonvolatile memory devices (cont.) Memory devices
Nonvolatile memory devices container (TBS1000B & TBS1000B-EDU)
This section lists the nonvolatile memory devices for the TBS1000B and
TBS1000B-EDU products. These products have a different hardware platform
than the TBS1000, TDS1000B/TDS2000B, TDS1000C-EDU/TDS2000C, and
TPS2000B Series.
Nand flash
Type and size 2 G bit (256 X 8)
Function Kernel code, application code, waveform data, backup data, and user stored data
Type of user information
stored
Backed up by battery? No
Method of modification Indirect
Data input method Firmware operations
Location Main Acquisition board
User accessible No
To clear Remove power from the instrument for at least 20 seconds.
Process to sanitize Remove power from the instrument for at least 20 seconds.
Both user data and user settings
SPI flash
Type and size 16 M bit
Function U-boot, FPGA configurable code and constant parameters
Type of user information
stored
Backed up by battery? No
Method of modification Indirect
Data input method Firmware operations
Location Main Acquisition board
User accessible No
To clear Remove power from the instrument for at least 20 seconds.
Process to sanitize Remove power from the instrument for at least 20 seconds.
Both user data and user settings
Declassification and Security Instructions 5
Memory devices
Data export devices
USB host port
Type and size USB host port
Function Supports removable USB flash drive. User storage of reference waveforms, screen images, and
instrument setups.
Method of modification Directly
Data input method Save
Location Front panel
To disable Files can be deleted or overwritten on the oscilloscope or a PC; USB flash drive can be removed
and destroyed. The USB host port cannot be disabled.
USB device port
Type and size USB device port
Function Supports remote control and data transfer to a PC
Method of modification Directly
Data input method Remote control via USBTMC
Location Rear panel
To disable The USB device port cannot be disabled.
Compact flash card
Type and size Compact flash card (TPS only)
Function User storage of reference waveforms, screen images, and instrument setups
Method of modification Directly
Data input method By system resources
Location Front panel
To disable The Compact Flash port cannot be disabled.
6 Declassification and Security Instructions
Clear and sanitize procedures
Clear the flash memory
This procedure does not erase or change factory calibration constants.
1. Push the front panel DEFAULT SETUP button to recall the default setup.
2. Push the front panel SAVE/RECALL button.
3. Push the Action option (side bezel) button until Save Setup is selected.
4. Push the Save To option button until Setup is selected.
5. Push the Setup option button until 1 is selected.
6. Push the Save option button to overwrite setup 1 with the default setup.
7. Push the Setup and Save option buttons again to overwrite the next setup
with the default setup. Repeat this step until setup 1 is selected again.
8. Push the front panel CH 1 MENU button, and then push the Coupling option
button until Ground is selected.
9. Push the front panel SAVE/RECALL button.
10. Push the Action option button until Save Waveform is selected. Push the
Save To option button until Ref is selected. Push the Source option button
until CH1 is selected.
11. Push the To option button until RefA is selected. Push the Save option button
to overwrite reference waveform RefA with the null waveform.
12. Push the To and the Save option buttons again to overwrite the next reference
waveform with the null waveform. Repeat this step until reference RefA is
selected again.
13. For TBS and TDS oscilloscopes, insert a USB flash drive into the USB Flash
Drive port on the front of the oscilloscope. For TPS oscilloscopes, insert a
compact flash card into the Compact Flash slot on the front of the
oscilloscope.
14. Push the front panel UTILITY button.
15. Push the Options option button.
16. Push the Printer Setup option button.
17. Push the PRINT Button option until Saves Image To File is selected.
18. For TBS and TDS oscilloscopes, push the File Format option button until
JPG is selected. For TPS oscilloscopes, select BMP instead of JPG.
19. Remove any probes from the BNC front panel connectors.
Declassification and Security Instructions 7
Clear and sanitize procedures
20. Push the front panel PRINT button to overwrite the hard copy image file with
an image that does not contain any useful information.
21. Power off the oscilloscope, and then power on the oscilloscope to complete
the process.
8 Declassification and Security Instructions
Clear or sanitize a non-functional instrument
If your instrument is not functioning and you need to clear or sanitize it, complete
the following procedures.
Acquisition board
Remove the Acquisition board and return the product to Tektronix. A new
Acquisition board will be installed, and the instrument will be repaired and
adjusted as necessary.
For removal instructions, refer to your product service manual (manual part
numbers are listed under Required documents near the front of this manual.
After removal of the Acquisition board, refer to your company's internal policies
regarding handling or disposal of the board.
Compact flash card (TPS oscilloscopes only)
Remove the compact flash card and return the instrument to Tektronix for repair.
After removal of the compact flash card, refer to your company's internal policies
regarding handling or disposal of the compact flash card.
USB flash drive (TBS and TDS oscilloscopes only)
Remove the USB flash drive and return the instrument to Tektronix for repair.
After removal of the USB flash drive, refer to your company's internal policies
regarding handling or disposal of the flash drive.
Charges
Replacement of any missing hardware will be charged according to the rate at the
time of replacement.
Declassification and Security Instructions 9
Clear or sanitize a non-functional instrument
10 Declassification and Security Instructions
Loading...
