RSA5100B Series Real-Time Signal Analyzers
ZZZ
RSA5BUP Option 300 High Performance R eal Time Upgrade
Instructions
www.tektronix.com
P075105800*
*
075-1058-00
Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries
or suppliers, and are protected by national copyright laws and international treaty provisions.
Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication
supersedes that in all previously published material. Specifications and price change privileges reserved.
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
Contacting Tektronix
Tektronix, Inc.
14150 SW Karl Braun Drive
P.O. B o x 5 0 0
Beaverto
USA
For product information, sales, service, and technical support:
n, OR 97077
In North America, call 1-800-833-9200.
Worl dwid e, v isit www.tektronix.com to find contacts in your area.
Table of Contents
Service Safety Summary.......................................... ................................ ................. 1
Kit description . .................................. ................................ ................................ ... 2
Products ................................ ................................ ................................ ......... 2
Kit parts li
Installation instructions ............................................................................................ 3
Minimum tool and equipment list............................. ................................ ............... 3
Update instrument software .................................................................................. 3
Remove cosmetic covers and shield ......................................................................... 4
Replace the existing DPX board ............................................................................. 6
Reinsta
Install the option key .......................................................................................... 9
Attach labels................................................................................................... 10
st................................ .................................. ................................ ... 2
ll top shield and cosmetic covers.................................................................... 8
RSA5100B Series RSA5BUP Option 300 Upgrade i
Table of Contents
ii RSA5100B Series RSA5BUP Option 300 Upgrade
Service Safety Summary
Only qualified personnel should perform service p rocedures. Read this Service
Safety Summary and the General Safety Summary located in the RSA5100B
Service manu
service procedures.
Do not service alone. Do not perform internal service or adjustments of this
product unless another person capable of rendering first aid and resuscitation is
present.
Disconnect power. To avoid electric shock, switch off the instrument power, then
disconnect the power cord from the mains power.
Use care when servicing with power on. Dangerous voltages or currents may exist
in this product. Disconnect power, remove battery (if applicable), and disconnect
ads before removing protective panels, soldering, or replacing components.
test le
To avoid electric shock, do not touch exposed connections.
al (Tektronix part number 077-0903-XX) before performing any
RSA5100B Series RSA5BUP Option 300 Upgrade 1
