Measurement Software Options for RSA3408A • RSA3303A • RSA3308A
Features & Benefits
Trigger
– Tektronix Exclusive Frequency
Mask Trigger Makes Eventbased Capture of Transient
RF Signals Easy by Triggering
on Any Change in the
Frequency Domain
Capture
– All Input Signals up to 36 MHz
Spans are Seamlessly Captured
Into Memory
– Long Record Length Enables
Complete Analysis Over Time
Without Making Multiple
Trigger, Capture, Analyze
See frequency, amplitude and modulation
change over time. With only a single
acquisition, Real-Time Spectrum
Analyzers (RTSA) capture a continuous
time record of changing RF events and
enable time-correlated analysis in the
Frequency, Time and Modulation
domains. You get the functionality of
a vector signal analyzer, a wide band
RSA3303/8ARSA3408A
General Purpose ModulationOpt. 21Opt. 21
W-CDMA UplinkOpt. 23
GSM/EDGEOpt. 24
CDMA 1X Forward/Reverse LinkOpt. 25
1X EVDO Forward/Reverse LinkOpt. 26
3GPP Release 5 Downlink (HSDPA)Opt. 27
3GPP Release 6 (HSUPA)
TD-SCDMAOpt. 28
WLAN 802.11a/b/g/nOpt. 29
*2
For 3GPP Release 6 (HSUPA) analysis, Opt. 23 and 27 are required in addition to Opt. 40.
*2
spectrum analyzer, plus the unique
trigger-capture-analyze capability of
RTSA – in one package. Optional
application-focused software allows
you to tailor the advanced characterization and troubleshooting tools of
the RTSA to meet the needs of your
specific application.
Opt. 40
Acquisitions
– Interfaces with TekConnect
Probes for RF and Baseband
Probing
Analyze
– Analyze Frequency, Amplitude
and Modulation Over Time
– Multi-domain Analysis Enables
Fast, Complete Signal Analysis
in Frequency, Time, Code and
Modulation Domains
– General Purpose Digital
Modulation Analysis
– 802.11a/b/g/n Measurement
Suite
– Codogram Provides a Simple,
Graphical Means of Analyzing
Individual Code Powers
versus Time
– Key Signaling Analysis Over
Air Interface Enables Checking
Interaction between Base
Station and UE
– Signal Source Analysis
Simplifies Phase Noise, Jitter
and Frequency Settling
Measurements
Symbol Display, Frequency Error and Origin
Offset Measurement.
Eye Diagram Display Format –
I/Q/Trellis Display (1 to 16 symbols).
Error Vector Diagram Display Format –
EVM, Magnitude Error, Phase Error, Waveform
Quality (ρ), Frequency Error and Origin Offset
Measurement.
Coding Format –
NRZ-L (8 periods), NRZ-L (4 periods), NRZ-L (2
periods), PWM, Bit Cell, Miller, Modified Miller, Miller
(M_2), Miller (M_4), Miller (M_8), Manchester, NRZ.
Symbol Table Display Format –
Binary, Octal, Hexadecimal.
Signal Source Analysis –
Phase Noise, Jitter and Automated Frequency
Settling Measurement.
RFID Standards –
ISO/IEC 18000 Part 4 Mode 1.
ISO/IEC 18000 Part 6 Type A, B, C.
ISO/IEC 18092.
ISO/IEC 14443 Part 2 Type A, B.
EPC Global Generation 1 Class 0, Class 1.
Measurement Software Options for RSA3408A • RSA3303A • RSA3308A
STABILITY
RSA3308A/3303A
Noise Sidebands, dBc/Hz
OffsetAt 1 GHz CFAt 2 GHz CFAt 6 GHz CF
SpecTypicalSpecTypicalSpecTypical
1 kHz–100–107–96–99–87–90
10 kHz–105–112–104–107–104–107
20 kHz–105–112–105–108–105–108
30 kHz–105–112–105–108–105–108
100 kHz–112–115–112–115–112–115
1 MHz–132–135–132–135–128–131
5 MHz–135–140–135–138–130–133
7 MHz–135–140–135–138–130–133
Frequency Settling Time
RSA3408A (typical).
Input Power – –5 dBm.
RF Attenuator – 0 dB.
Smoothing Factor – 1.
Span – ≥10 MHz.
Input Frequency – 100 MHz to 101 MHz.
Frequency Settling Threshold – 100 kHz.
Span – 100 kHz.
Input Frequency – 10 MHz to 10.01 MHz.
RSA3300A Series (typical)
Input Power – –5 dBm.
RF Attenuator – 0 dB.
Smoothing Factor – 1.
Span – ≥10 MHz.
Input Frequency – 100 MHz to 101 MHz.
Frequency Settling Threshold – 100 KHz.
Span – 100 kHz.
Input Frequency – 10 MHz to 10.01 MHz.
Opt. 23 – W-CDMA
Uplink Analysis
Perform key measurements for 3GPP
TS34.121 including PRACH analysis capability.
Supports the Following Measurements –
Constellation, EVM, Eye Diagram, Symbol Table, CDP
Spectrogram, CDP vs. Short Code, CDP vs. Symbol,
CDP vs. Time Slot, Symbol Constellation, Symbol
EVM, Symbol Eye Diagram.
Supports W-CDMA Uplink Signals –
DPDCH 9 Dedicated Physical Data Channel/DPCCH
(Dedicated Physical Control Channel), PRACH
(Physical Random Access Data Channel), PCPCH
(Physical Common Packet Channel).
Measurement Software Options for RSA3408A • RSA3303A • RSA3308A
Opt. 24 – GSM/EDGE Analysis Software
Perform key measurements for ETSI TS 100 910 and 3GPP TS45.005.
Burst Type: Normal
CharacteristicsDescription
Modulation Accuracy Measurement
Carrier Power Range–30 to +30 dBm
Phase Error Measurement Accuracy for GMSK Modulation (typical)≤0.8º (RMS)
≤1.8º (Peak)
Phase Error Resolution0.01º
EVM Measurement Accuracy for 8-PSK Modulation (typical)≤0.9% (RMS)
EVM Resolution0.01%
Time Resolution0.15625 µs at 5 MHz span
Burst Count1000 maximum
Mean Power Measurement
RF Input Range–50 dBm to +30 dBm
Absolute Power Measurement Accuracy for GSM900 ±0.5 dB
at 20 ºC to 30 ºC, Excluding Mismatch Error (typical)Signal frequency: 880 MHz to 960 MHz, Signal power: +10 dBm to –30 dBm,
Absolute Power Measurement Accuracy for DCS1800/PCS1900 ±0.6 dB
at 20 ºC to 30 ºC, Excluding Mismatch Error (typical)Signal frequency: 1710 MHz to 1990 MHz, Signal power: +10 dBm to –30 dBm,
Resolution0.01 dB
Burst Count1000 maximum
Power Versus Time Measurement
RF Input Range–50 dBm to +30 dBm
Power Ramp Relative Accuracy (typical)±0.2 dB at 0 dBfs to –40 dBfs
Time Resolution (typical)0.15625 µs at 5 MHz span
Marker Amplitude Resolution0.001 dB
Burst Count1000 maximum
RF attenuator: 0 dB –20 dB, after auto level is performed at 5 MHz span
RF attenuator: 0 dB to 20 dB, after auto level is performed at 5 MHz span
Measurement Software Options for RSA3408A • RSA3303A • RSA3308A
Opt. 25 – cdma2000 1x Signal Analysis Software
Perform key measurements for cdma2000 forward link (3GPP2 C.S0010) and reverse link (3GPP2 C.S0011).
cdma2000 1x Forward Link
CharacteristicsDescription
Channel Power
Minimum Power at RF Input–50 dBm
Absolute Power Measurement Accuracy (at 20 ºC to 30 ºC,±0.6 dB at conditions below:
excluding mismatch error), TypicalSignal frequency: 824 to 960 MHz or 1750 to 2170 MHz, Signal power:
Relative Power Measurement Accuracy (at 20 ºC to 30 ºC,±0.2 dB at conditions below:
excluding mismatch error), TypicalSignal frequency: 824 to 960 MHz or 1750 to 2170 MHz, Signal power:
Resolution0.01 dB
ACPR
Minimum Carrier Power at RF Input–40 dBm
Dynamic RangeAt –5 dBm signal input
765 kHz Offset76 dB (30 kHz BW)
1.995 MHz Offset 81 dB (30 kHz BW)
3.125 MHz Offset 81 dB (30 kHz BW)
4 MHz Offset 82 dB (30 kHz BW)
CCDF
Histogram Resolution0.01 dB
Intermodulation Distortion
Measurement FilterRectangular, Root Nyquist, Nyquist and Gaussian
Occupied Bandwidth
Minimum Carrier Power at RF Input–50 dBm
Measurement Accuracy0.2%
Spectrum Emission Mask
Minimum Carrier Power at RF Input–5 dBm
Dynamic Range82 dB (30 kHz BW)
1.995 MHz Offset
Code Domain Power
Relative Code Domain Power Accuracy±0.15 dB/±0.075 dB (typical)
QPSK EVM
Minimum Carrier Power at RF Input–40 dBm
EVM Floor, Typical2.0%
Modulation Accuracy (composite)
Minimum Carrier Power at RF Input-40 dBm
Composite EVM Floor, Typical2.0%
Rho (ρ)0.999
Frequency Error Accuracy±10 Hz + center frequency accuracy
Timing Accuracy (τ)±250 ns
0 dBm to –50 dBm after auto level is performed at 10 MHz span
0 dBm to –30 dBm after auto level is performed at 10 MHz span, 0 dBm input
Measurement Software Options for RSA3408A • RSA3303A • RSA3308A
cdma2000 1x Reverse Link
CharacteristicsDescription
Channel Power
Minimum Power at RF Input–50 dBm
Absolute Power Measurement Accuracy (at 20 ºC to 30 ºC,±0.6 dB at conditions below:
excluding mismatch error), TypicalSignal frequency: 824 to 960 MHz or 1750 to 2170 MHz, Signal power:
Relative Power Measurement Accuracy (at 20 ºC to 30 ºC,±0.2 dB at conditions below:
excluding mismatch error), TypicalSignal frequency: 824 to 960 MHz or 1750 to 2170 MHz, Signal power:
Resolution0.01 dB
ACPR
Minimum Carrier Power at RF Input–40 dBm
Dynamic RangeAt –5 dBm signal input
900 kHz Offset76 dB (30 kHz BW)
1.995 MHz Offset81 dB (30 kHz BW)
3.125 MHz Offset81 dB (30 kHz BW)
4 MHz Offset 82 dB (30 kHz BW)
CCDF
Histogram Resolution0.01 dB
Intermodulation Distortion
Measurement FilterRectangular, Root Nyquist, Nyquist and Gaussian
Occupied Bandwidth
Minimum Carrier Power at RF Input–50 dBm
Measurement Accuracy0.2%
Spectrum Emission Mask
Minimum Carrier Power at RF Input–5 dBm
Dynamic Range82 dB (30 kHz BW)
1.995 MHz Offset
Code Domain Power
Relative Code Domain Power Accuracy±0.15 dB/±0.075 dB (typical)
QPSK EVM
Minimum Carrier Power at RF Input–40 dBm
EVM Floor, Typical2.0%
Modulation Accuracy (composite)
Minimum Carrier Power at RF Input–40 dBm
Composite EVM Floor, Typical2.0%
Rho (ρ)0.999
Frequency Error Accuracy±10 Hz + center frequency accuracy
0 dBm to –50 dBm after auto level is performed at 10 MHz span
0 dBm to –30 dBm after auto level is performed at 10 MHz span, 0 dBm input
Measurement Software Options for RSA3408A • RSA3303A • RSA3308A
Opt. 26 – 1xEV-DO Signal Analysis Software
Perform key measurements for 1xEV-DO forward link (3GPP2 C.S0032) and reverse link (3GPP2 C.S0033).
1xEV-DO Forward Link
CharacteristicsDescription
Channel Power
Minimum Power at RF input–50 dBm
Absolute Power Measurement Accuracy (at 20 ºC to 30 ºC,±0.6 dB at conditions below:
excluding mismatch error), TypicalSignal frequency: 824 to 960 MHz or 1750 to 2170 MHz
Relative Power Measurement Accuracy (at 20 ºC to 30 ºC,±0.2 dB at conditions below:
excluding mismatch error), TypicalSignal frequency: 824 to 960 MHz or 1750 to 2170 MHz, Signal power:
Resolution0.01 dB
CCDF
Histogram Resolution0.01 dB
Intermodulation Distortion
Measurement FilterRectangular, Root Nyquist, Nyquist and Gaussian
Occupied Bandwidth
Minimum Carrier Power at RF Input–50 dBm
Measurement Accuracy0.2%
ACPR
Minimum Carrier Power at RF Input–40 dBm
Dynamic RangeAt –5 dBm signal input
765 kHz Offset76 dB (30 kHz BW)
1.995 MHz Offset81 dB (30 kHz BW)
3.125 MHz Offset81 dB (30 kHz BW)
4 MHz Offset 82 dB (30 kHz BW)
Spectrum Emission Mask
Minimum Carrier Power at RF Input–5 dBm
Dynamic Range
1.995 MHz Offset82 dB (30 kHz BW)
Code Domain Power
Relative Code Domain Power Accuracy±0.15 dB/±0.075 dB (typical)
QPSK EVM
Minimum Carrier Power at RF Input–40 dBm
EVM Floor, Typical2.0%
Modulation Accuracy (composite)
Minimum Carrier Power at RF Input–40 dBm
Composite EVM Floor, Typical2.0%
Rho (ρ)0.999
Frequency Error Accuracy±10 Hz + center frequency accuracy
Timing Accuracy (τ)±250 ns
Signal power: 0 dBm to –50 dBm after auto level is performed at 10 MHz span
0 dBm to –30 dBm after auto level is performed at 10 MHz span, 0 dBm input
Measurement Software Options for RSA3408A • RSA3303A • RSA3308A
1xEV-DO Reverse Link
CharacteristicsDescription
Channel Power
Minimum Power at RF Input-50 dBm
Absolute Power Measurement Accuracy (at 20 to 30 ºC,±0.6 dB at conditions below:
excluding mismatch error), TypicalSignal frequency: 824 - 960 MHz or 1750 - 2170 MHz
Relative Power Measurement Accuracy (at 20 to 30 ºC,±0.2 dB at conditions below:
excluding mismatch error), TypicalSignal frequency: 824 - 960 MHz or 1750 - 2170 MHz, Signal power:
Resolution0.01 dB
CCDF
Histogram Resolution0.01 dB
Intermodulation Distortion
Measurement FilterRectangular, Root Nyquist, Nyquist and Gaussian
Occupied Bandwidth
Minimum Carrier Power at RF Input–50 dBm
Measurement Accuracy0.2%
ACPR
Minimum Carrier Power at RF Input–40 dBm
Dynamic RangeAt –5 dBm signal input
765 kHz Offset74 dB (30 kHz BW)
1.995 MHz Offset83 dB (30 kHz BW)
3.125 MHz Offset83 dB (30 kHz BW)
4 MHz Offset 84 dB (30 kHz BW)
Spectrum Emission Mask
Minimum Carrier Power at RF Input–5 dBm
Dynamic Range82 dB (30 kHz BW)
1.995 MHz Offset
Code Domain Power
Relative Code Domain Power Accuracy±0.15 dB/±0.075 dB (typical)
QPSK EVM
Minimum Carrier Power at RF Input–40 dBm
EVM Floor, Typical2.0%
Modulation Accuracy (composite)
Minimum Carrier Power at RF Input–40 dB
Composite EVM Floor, Typical2.0%
Rho (ρ)0.999
Frequency Error Accuracy±10 Hz + center frequency accuracy
Signal power: 0 dBm to -50 dBm after auto level is performed at 10 MHz span
0 dBm to -30 dBm after auto level is performed at 10 MHz span, 0 dBm input.
Measurement Software Options for RSA3408A • RSA3303A • RSA3308A
Opt. 28 – 3GPP Release 4 Downlink and Uplink (TD-SCDMA)
Perform key measurements for TS25.102 (UL), 3GPP TS25.142 (DL)
CharacteristicsDescription
General
Frequency Range1850 to 2050 MHz
Minimum Power at RF Input–60 dBm
Channel Power Measurement
Absolute Power Measurement Accuracy (typical, after auto-±0.6 dB (Signal power +10 dBm to –30 dBm, 20 to 30 ºC)
level performed, excluding mismatch error, 5 MHz span)
Relative Power Measurement Accuracy (typical, after auto-±0.2 dB (Signal power +0 dBm to –30 dBm, 20 to 30 ºC)
level performed, excluding mismatch error, 5 MHz span)
Resolution0.01 dB
ACLR Measurement
Dynamic Range(8 active DPCH, Timeslots 4, 5, 6), input power >–20 dBm
60 dB, 1.6 MHz offset
61 dB, 3.2 MHz offset
CCDF Measurement
Histogram Resolution0.01 dB
Code Domain Analysis
Relative Code Domain Power AccuracyInput power >–40 dBm
±0.15 dB (±0.075 typical) at code power >–10 dBc
±0.30 dB (±0.15 typical) at code power >–25 dBc
Code Domain Residual Error<–40 dB (Input power >–40 dBm)
Modulation and Frequency Related
Modulation FormatQPSK
Residual EVM Floor≤1.5%, input level >–40 dBm (1 DPCH in timeslots 4, 5 and 6)
Residual Origin Offset≤–40 dB, input level >–40 dBm (1 DPCH in timeslots 4, 5 and 6)
Frequency Error Accuracy±10 Hz + (center frequency accuracy)
Frequency Lock Range±4 kHz from defined carrier frequency (input level >–40 dBm)
Other MeasurementsOccupied BW (OBW)
Spectrum Emissions Mask (offset from carrier and inband, ungated)
Measurement Software Options for RSA3408A • RSA3303A • RSA3308A
Opt. 29 - WLAN 802.11 a/b/g/n Analysis
CharacteristicsDescription
Residual EVM for IEEE 802.11a/g/n 54 Mb/s OFDM (typical)≤–44 dB at 2.447 MHz center frequency, ≤
–42 dB at 5.5 GHz center frequency
Residual EVM for IEEE 802.11b 11 Mbps CCK with Raised Cosine Filter (typical)≤0.7% at 2.447 MHz center frequency
Residual EVM Against Frequency Offset (±10 MHz), OFDM Signal Conforming ≤–41 dB, Center Frequency of the Analyzer is 5.0 to 6.0 GHz, Carrier
to IEEE 802.11g, 16.6 MHz BW, 52 Sub Carriers, 64 QAM, 54 Mb/s, with Long Center is ±10 MHz apart from the Center Frequency setting
Training Symbol Correction (typical)
