Programmable DC Power Supplies
Tektronix PWS4000 Series Data Sheet
Available Functions and Features
Output Voltage, Current, and Limits Displayed Simultaneously on a
Bright Display
Up to 40 User-defined Setup Memories
Direct Parameter Entry using Numeric Keypad
Features & Benefits
Key Performance Specifications
Linear Regulation
Up to 72 V Output Voltage
0.03% Basic Voltage Accuracy
0.05% Basic Current Accuracy
Less than 5 mV
Ripple and Noise
p-p
Adjustable
List Mode for Stepping through Stored Test Sequences
Remote Sense to Compensate for Lead Resistance
Connectivity
Rear Outputs and Trigger/Status Lines
USB Device
Programming
Includes N
Edition Software for Connecting Your Bench
3-year Warranty
Overvoltage Protection
Port on Rear Panel for Quick PC Connectivity and Remote
ational Instrument’s LabVIEW SignalExpress™ Tektronix
Data Sheet
Choose Your Voltage and Current –
Quickly, Precisely
A wide current and voltage range, and flex ible features, make the PWS4000
Power Supply Series a versatile addition to your bench. With 0.03% basic
voltage accuracy and 0.05% basic current accuracy, you can be confident
in the power su
the effect of voltage drop in your lead wires and noise of less than 5 mV
further ensures accurate power delivery. List mode and a USB port for
remote programming accelerate complex test develop ment. The PWS4000
Power Supply Series generates the power you need for your application –
quickly and precisely.
pply’s output value. Remote sense capability to eliminate
p-p
Total Control Over Your Output
All models of the PWS4000 Series include an overvoltage protection circuit
that reduces the output voltage if it exceeds a user-specified threshold for
any reason. The PWS4000 Series also allows you to prevent the voltage
from being accidentally adjusted above a limit that you specify.
Setting an appropriate current limit can be critical for preventing da m age to
your device under test. With the PWS4000 numeric keypad, you can quickly
and precisel
limit is always visible on the display to keep you aware of this important
setting. A user-definable password allows you to lock the front panel to
prevent unwanted adjustments during critical tests.
y specify a current limit before you start your test. The current
Designed to Ma ke Your Work Easier
The PWS4000
familiar operation you expect from Tektronix.
Intuitive Operation
A rotary kno
response to changing voltage or current. The direct-entry numeric keypad
simplifies setting precise voltage and current values.
Bright Display
A bright vacuum fluorescent display provides excellent readability at a
distance, at an angle, or under dim lighting conditions. Meter readings and
limits are always visible. You don’t need to push buttons just to see your
limits.
Power Supply Series is designed with the ease-of-use and
b, with user-selectable step size, make s it easy to check circuit
Setup Memories
To save time when repeating tests, you can save your instrument settings in
one of the 40 internal memory locations by simply pressing the Save button.
Each time you want to recall that setting, just push the Recall button and
choose the desired setup.
Accelerate Comple x Test Development
The built-in List mode allows you to define a custom sequence of voltage
and current steps for your test. You can define up to 7 lists, and each list can
have up to 80 steps. Lists can be configured to step through the sequence
based on external triggers or front-panel button presses. Alternatively, you
can specify a duration for each step and the instrument will automatically
step through the sequence. For even more flexibility, a USB device port on
the back panel makes it easy to connect the power supply to your PC for
remote programming.
Connect Your Bench for Intelligent Debug
You can use your preferred programming enviro nment to control the
PWS4000 using a USBTMC-compliant device port, or you can get quick
results with the special Tektronix Edition of National Instrument’s LabVIEW
SignalExpress™ software. The PWS4000 Power Supply Series includes
the Tektronix Edition of SignalExpress f or basic instrument control, data
logging, and analysis. The opt ional Professional Edition offers over 200
built-in functions that provide additional signal processing, advanced
analysis, sweeping, limit testing, and user-defined step capabilities.
SignalExpress supports the range of Tektronix bench instruments*
enabling you to connect your entire test bench. You can then access the
feature-rich tools packed into each instrument from one intuitive software
interface. This allows you to automate complex measurements re quiring
multiple instruments, and easily capture and analyze your results, all
from your PC. Only Tektronix offers a connected test ben ch of intelligent
instruments to simplify and sp eed debug of your complex design.
1
,
Performance You Can Count On
In addition to industry-leading service and support, the PWS40 00 Power
Supply Series comes backed with a three-year standard warranty.
*1For a complete listing of Tektronix instruments supported by NI LabVIEW SignalExpress, visit
www.tektronix.com/signalexpress.
2 www.tektronix.com
Programmable DC Power Supplies — Tektronix PWS4000 Series
Characteristics
Electrical
Specifications PWS4205 PWS4305 PWS4323 PWS4602 PWS4721
DC Output Rating
Voltage 0 to 20 V 0 to 30 V 0 to 32 V 0 to 60 V 0 to 72 V
Current
Maximum Power 100 W 150 W 96 W 150 W 86 W
Load Regulation
Voltage
Current <0.05% + 0.1 mA <0.05% + 1.5 mA <0.05% + 0.1 mA <0.05% + 0.5 mA <0.05% + 0.1 mA
Line Regulation
Voltage
Current <0.05％ +0.1mA <0.05％ + 0.1 mA <0.05％ + 0.1 mA <0.05％ + 0.05 mA <0.05％ +0.1mA
RippleandNoise(20Hzto7MHz)
Voltage <1 mV
Current
Setting Resolution
Voltage 1 mV 1 mV 1 mV 1 mV 2 mV
Current
Setting Accuracy (using remote sense, 25 °C ± 5 °C)
Voltage
Current ±0.05% + 2 mA ±0.05% + 2.5 mA ±0.05% + 2 mA ±0.05% + 1.5 mA ±0.05% + 1 mA
Readback Resolution
Voltage 1mV
Current
Readback Accuracy (25 °C ± 5 °C)
Voltage
Current ±0.05% + 2 mA ±0.05% + 2.5 mA ±0.05% + 2 mA ±0.05% + 1.5 mA ±0.05% + 1 mA
Overvoltage Protection
Range (typical)
Accuracy
Response time (typical)
0to5A 0to5A 0to3A 0to2.5A 0to1.2A
<0.01% + 2 mV
<0.01％ +1mV <0.01％ +1mV <0.01％ +1mV <0.01％ +2mV <0.01％ +1mV
<3 mV
<3 mA
RMS
RMS
<1 mV
RMS
p-p
<4 mV
<4 mA
p-p
RMS
<1 mV
<4 mV
<3 mA
RMS
RMS
<1 mV
RMS
p-p
<5 mV
<3 mA
p-p
RMS
<1 mV
<3 mV
<3 mA
RMS
p-p
RMS
0.1 mA
±0.03% + 3 mV ±0.03% + 3 mV ±0.03% + 3 mV ±0.03% + 6 mV ±0.03% + 6 mV
0.1 mA
±0.02% + 3 mV ±0.02% + 2.5 mV ±0.02% + 3 mV ±0.02% + 6 mV ±0.02% + 5 mV
1Vto19V 1Vto29V 1Vto31V 1Vto59V 1Vto71V
±0.5% + 0.5 V
<10 ms
Display
Vacuum fluorescent display.
Memory
40 setup memories.
List Mode
Up to 7 lists can be defined,eachwithupto80steps. Eachstepincludesa
voltage limit and a current limit. For continuous sequences each step also
includes a duration.
www.tektronix.com 3
Data Sheet
Rear-panel Connections
Characteristic
Description
Communications USB Device Port, Type B connector, USBTMC
compatible
GPIB, optional (requires TEK-USB-488 GPIB to USB
adapter)
Output,Sense,Status,
and Control
Removable screw terminal block carries the following
signals:
Output channel Duplicates the front-panel outputs
Remote sense lines
Connection for remote sense
Control input Multifunction TTL input which can function as a trigger
input, output control line, or digital input
Status output Multifunction TTL output which can function as a fault
indication, or digital output
Power Source
Characteristic
110 V AC Se ttin g
220 V AC Setting
Description
99 V
to 132 V
RMS
198 V
to 264 V
RMS
RMS
RMS
Frequency 47 Hz to 63 Hz
Power Consumption
PWS4205/4323/4721
PWS4305/4602
250 VA
350 VA
Physical Characteristics
Dimension
mm
in.
Height 88 3.47
Width 214 8.45
Depth 355 13.9
Weight kg lb.
PWS4205
PWS4305
PWS4323
PWS4602
PWS4721
9.0 19.8
9.6 21.2
9.0 19.8
9.6 21.2
9.0 19.8
Environmental and Safety
Characteristic
Description
Temperature
Operating 0 °C to +40 °C
Storage –20 °C to +70 °C
Relative Humidity (Noncondensing)
Operating 5% to 95% relative humidity at up to +40 °C
Storage 5% to 95% relative humidity at up to +40 °C
5% to 60% RH above +40 °C up to +70 °C
Altitude
Operating
Storage
Electromagnetic
Compatibility
Up to 2,000 m
Up to 4,000 m
European Union: EN 55011, Class A; IEC 61000-3-2;
IEC 61000-3-3, IEC 61000-4-2, IEC 61000-4-3,
IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC
61000-4-8, IEC 61000-4-11
USA: FCC, CFR Title 47, Part 15, Subpart B, Class A
Australia: EMC Framework, demonstrated per Emission
Standard AS/NZS 2064 (Industrial, Scientific, and
Medical Equipment)
Safety European Union: Low Voltage directive 2006/95/EC;
EN61010-1 2001
USA: Nationally recognized testing laboratory listing
UL61010-1-2004
Canada: CAN/CSA C22.2 No. 61010-1 2004
Warran
ty
Three years.
4 www.tektronix.com
Ordering Information
Programmable DC Power Supplies — Tektronix PWS4000 Series
Models
Model Description
PWS4205 Programmable DC Power Supply, 20 V, 5 A
PWS4305 Programmable DC Power Supply, 30 V, 5 A
PWS4323 Programmable DC Power Supply, 32 V, 3 A
PWS4602 Programmable DC Power Supply, 60 V, 2 A
PWS4721 Programmable DC Power Supply, 72 V, 1.2 A
PWS4000 Includes: Power supply, line cord, Quick Start User Manual, Traceable
Certificate of Calibration, documentation CD (includes user manuals, programmer’s
manual, and technical reference), and National Instruments LabVIEW SignalExpress
Tektronix Edition CD.
Please specify power plug and preferred language option when ordering.
Instrument Options
Power Plug Options
Option
A0 North America
A1 Universal Euro
A2 United Kingdom
A3 Australia
A5
A10
A11 India
A12 Brazil
Description
Switzerland
China
Language Options
Option
L0 English
L1 French
L2 Italian
L3
L4
L6 Portuguese
L7
L8
L9 Korean
L10 Russian
Service Op
Option
C3 Calibration Service 3 Years
C5 Calibration Service 5 Years
CA1 Provides a single calibration event, or coverage for the
D1
D3
D5
R5
tions
Product(s) are manufactured in ISO registered facilities.
Description
German
Spanish
Simplified Chinese
Traditional Chinese
Description
designated calibration interval, whichever comes first
Calibration Data Report
Calibration Data Report 3 Years (with Option C3)
Calibration Data Report 5 Years (with Option C5)
Repair Service 5 Years
www.tektronix.com 5
Data Sheet
6 www.tektronix.com
Programmable DC Power Supplies — Tektronix PWS4000 Series
www.tektronix.com 7
Data Sheet
Contact Tektronix:
ASEAN / Australa
Balkans, Israel, South Africa and other ISE Countries +41 52 675 3777
Central East Eu
Mexico, Central/South America & Caribbean (52) 56 04 50 90
* European toll-free number. If not accessible, call: +41 52 675 3777
rope, Ukraine, and the Baltics +41 52 675 3777
Central Europe & Greece +41 52 675 3777
Middle E as t,
Asia, and North Africa +41 52 675 3777
The Netherlands 00800 2255 4835*
People’s Rep
Republic of
United K ingdom & Ireland 00800 2255 4835*
sia (65) 6356 3900
Austria 00800 2255 4835*
Belgium 00800 22
Brazil +55(11)37597600
Canada 1 800 833 9200
Denmark +4580881401
Finland +41526
France 00800 2255 4835*
Germany 00800 2255 4835*
Hong Kong 400 8
India 000 800 650 1835
Italy 00800 2255 4835*
Japan 81 (3) 67
Luxembourg +41526753777
ublic of China 400 820 5835
Poland +41 52 675 3777
Korea 001 800 8255 2835
Russia & CIS +7 (495) 7484900
South Africa +41526753777
Spain 00800
Sweden 008 00 2255 4835*
Switzerland 00800 2255 4835*
Tai wa n 886 (
55 4835*
75 3777
20 5835
14 3010
Norway 800 16098
Portugal 80 08 12370
2255 4835*
2) 2722 9622
USA 1 800 833 9200
Updated 25 May 2010
www.tektronix.com
For Further Information. Tektronix maintains a comprehensive, constantly expanding
collection of application notes, technical briefs and other resources to help engineers working
on the cutting edge of technology. Please visit www.tektronix.com
t © Tektronix, Inc. All rights reserved. Tektronix products are covered by U.S. and foreign patents,
Copyrigh
d pending. Information in this publication supersedes that in all previously published material.
issued an
tion and price change privileges reserved. TEKTRONIX and TEK are registered trademarks of
Specifica
x, Inc. All other trade names referenced are the service marks, trademarks, or registered trademarks
Tek t ro n i
espective companies.
of their r
15 Oct 2010 3GW-25253-0
Loading...
