The PWR-55B is a Volt linear regulated supply intended for use with one MB-01, MB-02, or MB-05 series backplane. Com­pared to the PWR-55A (a switching power supply), it provides lower noise and ripple on its output and is suitable for more
sensitive measurement requirements.

PWR-55B Supply for MB Modules

Installation and Usage Instructions

Installation

The recommended method of installation follows. Alternate methods of installation may provide equally acceptable results, b ut
are at the user’s own risk.

1. The power supply can only be used in dry areas. The supply is designed to be integrated into a larger device that prevents
access to the main power connection terminals so that users are unlikely to contact them during use. The preferred method
is to mount the MB backplane in a 19 inch equipment rack using the RMT -MBBP adapter , with the supply mounted on the
back face of the RMT-MBBP.

17.475 (444)

Location of

Power Supply

on Rear Face

NOTE The power supply mounting holes are threaded for 8-32 machine screws. Maximum incursion of

screws into mounting holes is 5/16 in. (0.312 in.). It may be necessary to drill additional mounting
holes in the RMT-MBBP.

Location

of MB-0x

3.62 (92)

3.47
(88)

Front Face

of Rack

PA-764 Rev. A / 12-00

2. Make the following connections to the power supply, running the wires so that they will not be pinched or chafed during
equipment use:

Connections to the MB-0x backplane

Minimum wire specifications: 14 AWG, 150v insulation.

OUT+ to +5 VDC terminal Preferred color: Red
OUT- to PWR COM or - terminal Preferred color: Black

Connections to power source (105-125 VAC, 50-400Hz)

Minimum wire specifications: 18 AWG, 600v insulation.

L AC LINE (live) side of the AC power Black
N AC NEUTRAL (grounded) side of the AC power White
(GRND) PROTECTIVE GROUND of the AC power Green with yellow tracer

NOTE Use of a switched source of power is recommended so that the power supply can be electrically

disconnected when not in use.

3. Ensure that there is sufficient airflow for the supply not to become overheated. Space at least one inch away from sur­rounding objects and allow at least 3/16 in. clearance around perforated ventilation openings.

NOTE The supply is rated to drive up to 16 of the MB modules with the highest current dr aw even at max-

imum operating temperature, so typical users will have no problems as long as air can circulate.

4. Use the supply with only one MB rack and no additional 5 volt loads. Doing so may exceed the power supply’s rating or
introduce additional noise into your measurements.

Usage

The AC power to the supply may be turned on either simultaneously with or subsequently to the power of the computer system
containing the device that the MB modules are connected to.

WARNING To prevent electric shock, mains connections must be arranged to prevent operator

access. The panels and doors of the rack must be closed and locked. The power supply
must be mounted in locations free from the chance of liquid spill or splash; the unit must
be kept dry . Protective ground of the power supply must be connected to a safety ground
capable of carrying entire fault current.

Installations should follow the requirements of the “National Electric Code (NFPA-70)
or other applicable national standards.

It is the responsibility of the installer to make sure the installation is safe and all codes
are followed.
