Instructions
P6109B
100 MHz 10X Passive Probe
With Readout
070-7849-06
Copyright T ektronix, Inc. All rights reserved.
T ektronix products are covered by U.S. and foreign patents, issued and
pending. Information in this publication supercedes that in all previously
published material. Specifications and price change privileges reserved.
Printed in the U.S.A.
T ektronix, Inc., P.O. Box 1000, Wilsonville, OR 97070–1000
TEKTRONIX and TEK are registered trademarks of T ektronix, Inc.
General Safety Summary
Review the following safety precautions to avoid injury and prevent
damage to this product or any products connected to it. T o avoid
potential hazards, use this product only as specified.
To Avoid Fire or Personal Injury
Observe Maximum Working Voltage. Do not use the P6109B probe
above 300 V
page 11.
Do Not Elevate the Common Terminal. The common terminal is at
ground potential. Do not connect the common terminal to elevated
voltages.
Do Not Operate With Suspected Failures. If you suspect there is damage
to this product, have it inspected by qualified service personnel.
Do Not Operate in Wet/Damp Conditions.
Do Not Operate in an Explosive Atmosphere.
Keep Product Surfaces Clean and Dry.
Safety Terms and Symbols
Terms in This Manual. These terms may appear in this manual:
, CAT II. Refer to the derating chart, Figure 2, on
RMS
WARNING. Warning statements identify conditions or practices that
could result in injury or loss of life.
CAUTION. Caution statements identify conditions or practices that
could result in damage to this product or other property.
P6109B Instructions
1
Features and Accessories
The P6109B probe is compatible with most general purpose
oscilloscopes that have a 1 MW input impedance and bandwidth up
to 100 MHz. The probe is also compatible with T ektronix oscilloscopes that automatically detect probe attenuation and adjust the
scale readout accordingly.
NOTE. Remove and discard the protective cover on the tip of the
probe before attempting to connect a probe tip accessory.
BNC-to-probe tip adapter . To install the adapter,
push the wide end firmly into a BNC connector.
Then insert the probe tip firmly into the adapter.
Retractable hook tip. Use the retractable hook tip to
make hands-free measurements.
NOTE.
For a solid connection, firmly push and
twist the hook tip onto the probe tip before using.
Readout pin. The P6109B is compatible with Tektronix oscilloscopes that automatically detect and
display the attenuation factor of the probe.
Readout Pin
2
P6109B Instructions
Features and Accessories
Marker rings. Attach the matching colored rings
onto the probe cable and tip as shown.
Adjustment tool. Use the adjustment tool for probe
compensation adjustments.
P6109B Instructions
3
Features and Accessories
Guard
WARNING. To avoid electric shock when using the probe, keep
fingers behind the guard on the probe body.
Guard. The guard provides a finger barrier for
protection from electric shock.
Ground Lead. Use the alligator clip to attach the
probe to a ground reference.
Long Ground Lead
Short Ground Lead
T o see the best signal, use the shortest possible ground lead and
signal path.
4
P6109B Instructions
Maintenance
This section describes how to maintain the probe.
Low-Frequency Probe Compensation
Before taking any measurements using a probe, first check the
compensation of the probe and adjust it to match the channel inputs.
Most oscilloscopes have a square wave reference signal available at
a terminal on the front panel used to compensate the probe. Connect
the probe to the signal source to display a 1 kHz test signal on your
oscilloscope.
Compensate the probe by adjusting L on the probe so that the
corners of the square wave are square.
L
1 kHz
Adjust trimmer L until you see a flat-top square wave on the display .
P6109B Instructions
5
Maintenance
High-Frequency Probe Compensation
The probe high-frequency compensation should seldom require
adjustment; however, your probe may require high-frequency
adjustment if any of the following are true:
the probe has high-frequency aberrations
the probe does not perform at the rated bandwidth
you have installed the probe on an oscilloscope having an input
capacitance near the limits of the probe compensation range (See
T able 1.)
T o perform the high-frequency compensation adjustment you will
need a signal source that has all of the following characteristics:
tr<1 ns
>1 V
1 MHz
p-p
90%
10%
square-wave output at 1 MHz
fast rise output with rise time less than 1 ns
output properly terminated
6
P6109B Instructions
Maintenance
Connect the probe to the signal source to display a 1 MHz test signal
on your oscilloscope. The display should be similar to that shown in
Figure 1(a).
10 ns
H
H
(a) Area Of Waveform Affected By
Adjustment
Figure 1: HF Compensation
Adjust trimmer H until the waveform is flat on top and has a square
leading edge.
Cleaning
T o prevent damage to probe materials, avoid using chemicals that
contain benzine, benzene, toluene, xylene, acetone, or similar
solvents.
Do not immerse the probe or use abrasive cleaners.
Dirt may be removed with a soft cloth dampened with a mild
detergent and water solution, or isopropyl alcohol.
(b) Location of Adjustment
P6109B Instructions
7
Maintenance
Replacing Probe Parts
Other than accessories, only the probe tip is replaceable.
Replacement probe tips are available as optional accessories. Refer
to the replaceable parts list at the end of this manual for more
information.
T o remove a tip assembly, firmly grasp the pointed tip with pliers
and withdraw the assembly from the barrel.
No tools are required to install a replacement tip. Insert a new probe
tip into the probe barrel as far as possible using finger pressure. If
necessary, seat the plastic portion of the tip against the probe barrel
by pressing the tip gently but firmly against a hard surface, such as a
wood block or table top.
8
P6109B Instructions
Specifications
Table 1
aracter
These characteristics apply to a P6109B probe installed on a
T ektronix 2252 oscilloscope. When used with another instrument,
the instrument must have an input impedance of 1 M and a
bandwidth not less than 100 MHz or more than 115 MHz.
The instrument must have a warm-up period of at least 20 minutes
and be in an environment that does not exceed the limits described in
T able 2.
: Electrical Ch
Attenuation (system) 10X1.3% at DC
Input Resistance (system)
Input Capacitance 11.8 pF to 14.8 pF
Compensation Range 15 pF to 35 pF
System Bandwidth (–3 dB) DC to 100 MHz
Maximum Working
Input Voltage
istics
10 M1.3%
(13.3 pF nominal)
300 V, CAT II
(See Figure 2 on page 11)
P6109B Instructions
9
Specifications
Table 2
ronmental
aracter
: Physical and Envi
Net Weight
(including accessories)
Cable Length 2 meters
Temperature Range
Operating
Nonoperating
Humidity
1
Tektronix Standard 062-2847-00, class 3. Refer to MIL-E-16400F, paragraph 4.5.9
1
1
Ch
t320 g (0.7 lb)
–15° C to +65°C
(+5° F to +149°F)
–62° C to +85°C
(–80° F to +185°F)
95% to 97% Relative Humidity
(30°C to 60°C)
istics
through 4.5.9.5.1, class 4.
Table 3: Certifications and compliances
EC Declaration of
Conformity – Low
Voltage
Approvals UL3111-1 – Standard for electrical measuring and test equipment
Compliance was demonstrated to the following specification as
listed in the Official Journal of the European Communities:
Low Voltage Directive 73/23/EEC, as amended by 93/68/EEC:
EN 61010-1/A2:1995
Safety requirements for electrical equipment for
measurement, control, and laboratory use
EN 61010-2-031:1994
Particular requirements for hand-held probe assemblies for
electrical measurement and test equipment
10
IEC 1010-2-031 – Particular requirements for hand-held probe
assemblies for electrical measurement and test
CAN/CSA-C22.2 No. 1010.1-92 and CAN/CSA-C22.2 No.
1010.2.031-94 – Safety requirements for electrical equipment for
measurement, control, and laboratory use
P6109B Instructions
Table 3: Certifications and compliances (Cont.)
Specifications
Installation Category
Descriptions
Terminals on this product may have different installation category
designations. The installation categories are:
CAT III Distribution-level mains (usually permanently
connected). Equipment at this level is typically
in a fixed industrial location
CAT II Local-level mains (wall sockets). Equipment at
this level includes appliances, portable tools,
and similar products. Equipment is usually
cord-connected
CAT I Secondary (signal level) or battery operated
circuits of electronic equipment
Pollution Degree 2 Do not operate in environments where conductive pollutants may
be present.
600V
500V
400V
300V
200V
100V
0
10MHz 100MHz1MHz
Figure 2: Maximum Working V oltage Derating Curve (V
P6109B Instructions
RMS
)
11
Replaceable Parts
2
1
3
Standard Accessories
7
Optional Accessories
Figure 3: P6109B replaceable parts
4
5
8
6
9
12
P6109B Instructions
P6109B Instructions 13
Replaceable Parts List
Fig. &
Index
Number
2– ––––––––––– 1 PROBE,PASSIVE:P6109B
–1 013–0107–08 1 TIP,PROBE:MINIATURE/COMPACT SIZE TK2565 013–0107–08
–2 See Opt. Acc 1 CONTACT,ELEC:PROBE TIP W/INSULATOR ASSY
–3 196–3120–01 1 LEAD,ELECTRICAL:PROBE GND,6.0 L 80009 196–3120–01
–4 016–0633–00 1 MARKER SET,CA:2 EA VARIOUS COLORS 80009 016–0633–00
–5 See Opt. Acc. 1 SCREWDRIVER:ADJUSTMENT TOOL
–6 013–0277–00 1 ADAPTER,CONN:BNC TO MINIATURE PROBE TIP 24931 33A129–1
–2 131–4997–01 1 CONTACT,ELEC:2 TIP–INSULATOR W/INFO CARD 80009 131–4997–01
–5 003–1433–01 1 SCREWDRIVER:ADJUSTMENT TOOL,PKG OF 5 80009 003–1433–01
–7 196–3120–21 1 LEAD,ELECTRICAL:PROBE GND,28.0 L 80009 196–3120–21
–8 196–3121–01 1 LEAD,ELECTRICAL:PROBE GND,12.0 L 80009 196–3121–01
–9 015–0201–07 1 TIP,PROBE:IC TEST,PKG OF 10 80009 015–0201–07
Tektronix
Part Number
020–2134–01 1 ACCESSORY KIT:MINIATURE SIZE
070–7849–06 1 MANUAL,TECH:INSTR, P6109B, DP 80009 070–7849–06
Serial No.
Effective
Serial No.
Discont’d
Qty Name & Description Mfr. Code Mfr. Part Number
STANDARD ACCESSORIES
(Includes items 1, 3, 4, 5, & 6)
OPTIONAL ACCESSORIES
80009 020–2134–01
Replaceable Parts
Manufacturers Cross Index
Mfr.
Code
24931 BERG ELECTRONICS INC BERG ELECTRONICS RF/COAXIAL DIV
80009 TEKTRONIX INC 14150 SW KARL BRAUN DR
TK2565 VISION PLASTICS INC 26000 SW PARKWAY CENTER DRIVE WILSONVILLE, OR 97070
P6109B Instructions14
Manufacturer Address City, State, Zip Code
FRANKLIN, IN 46131
2100 EARLYWOOD DR
PO BOX 547
BEAVERT ON, OR 97077–0001
PO BOX 500
Replaceable Parts
WARRANTY
Tektronix warrants that the products that it manufactures and sells will be free from defects
in materials and workmanship for a period of one (1) year from the date of shipment. If a
product proves defective during this warranty period, Tektronix, at its option, either will
repair the defective product without charge for parts and labor, or will provide a
replacement in exchange for the defective product.
In order to obtain service under this warranty, Customer must notify Tektronix of the
defect before the expiration of the warranty period and make suitable arrangements for the
performance of service. Customer shall be responsible for packaging and shipping the
defective product to the service center designated by Tektronix, with shipping charges
prepaid. Tektronix shall pay for the return of the product to Customer if the shipment is to
a location within the country in which the Tektronix service center is located. Customer
shall be responsible for paying all shipping charges, duties, taxes, and any other charges for
products returned to any other locations.
This warranty shall not apply to any defect, failure or damage caused by improper use or
improper or inadequate maintenance and care. Tektronix shall not be obligated to furnish
service under this warranty a) to repair damage resulting from attempts by personnel other
than Tektronix representatives to install, repair or service the product; b) to repair damage
resulting from improper use or connection to incompatible equipment; c) to repair any
damage or malfunction caused by the use of non-Tektronix supplies; or d) to service a
product that has been modified or integrated with other products when the effect of such
modification or integration increases the time or difficulty of servicing the product.
THIS WARRANTY IS GIVEN BY TEKTRONIX IN LIEU OF ANY OTHER
WARRANTIES, EXPRESS OR IMPLIED. TEKTRONIX AND ITS VENDORS
DISCLAIM ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE. TEKTRONIX’ RESPONSIBILITY
TO REPAIR OR REPLACE DEFECTIVE PRODUCTS IS THE SOLE AND
EXCLUSIVE REMEDY PROVIDED TO THE CUSTOMER FOR BREACH OF
THIS WARRANTY. TEKTRONIX AND ITS VENDORS WILL NOT BE LIABLE
FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL
DAMAGES IRRESPECTIVE OF WHETHER TEKTRONIX OR THE VENDOR
HAS ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.
Loading...
