Passive High Voltage Probes
P5100 * P5102 * P6015A
Characteristics
P6015A/P5100/P5102
Probe Nominal
Length
Attenuation Bandwidth Risetime Loading Max. Input V
DC or RMS
Comp. Range
in pF
Readout
P6015A 10 ft. 1000X 75 MHz 4.0 ns 100 megaohm/3 pF 20 kV 7 to 49 No
P6015A
Opt. 1R
10 ft. 1000X 75 MHz 4.0 ns 100 megaohm/3 pF 20 kV 7 to 49 Yes
P6015A
Opt. 25
25 ft. 1000X 25 MHz 14 ns 100 megaohm/4 pF 20 kV 7 to 49 No
P6015A
Opt. 2R
25 ft. 1000X 25 MHz 14 ns 100 megaohm/4 pF 20 kV 7 to 49 Yes
P5100 10 ft. 100X 250 MHz 1.75 ns 10 megaohm/2.75 pF 2.5 kV 7 to 30 Yes
P5102 2 m 10X 100 MHz 3.5 ns 5 megaohm/11.2 pF 1,000 V
RMS
CATII
24 to 28 No
Top of Page
Features
Specs
Ordering Information
Pricing Information
Request a Quote
Tektronix Measurement products are
manufactured in ISO registered facilities.
P5100/5102 Only
49A-10733-4p555, 06/1997, 08/03/2000
