Tektronix OM5110 Datasheet

46 GBaud Multi-Format Optical Transmitter

OM5110 Datasheet

100G / 400G / 1Tb/s Coherent Optical Test System

The OM5110 Multi-Format Optical Transmitter is a C-and L-Band transmitter capable of modulating the most common coherent optical modulation formats such as PM-QPSK and PM-16QAM up to 46 GBaud. When combined with a signal source, such as the Tektronix AWG70001A

The OM5110 Multi-Format Optical Transmitter is a C-and L-Band transmitter capable of providing the most common coherent optical modulation formats such as PM-QPSK and PM-16QAM up to 46 GBaud. When combined with a signal source, such as the Tektronix AWG70001A Arbitrary Waveform Generator or the Tektronix PPG3204 32 Gb/s Programmable Pattern Generator, the OM5110 offers a complete coherent optical test signal generation system.

Features and benefits

Multi-format optical transmitter supports modulation of formats such as BPSK, PM-QPSK, and PM-16QAM

Excellent linearity supports modulation of multi-level signals

Modulates single or dual-polarization signals

Built-in C or L-band lasers for setup convenience

Supports external laser sources

Arbitrary Waveform Generator or the Tektronix PPG3204 32 Gb/s Programmable Pattern Generator, the OM5110 offers a complete coherent optical test signal generation system.

For coherent optical transmitter or transceiver manufacturers, the OM5110 may be used as a golden reference against which to compare module designs. The OM4106D optical modulation analyzer can be used to measure the performance of a transmitter under development and then compared against the OM5110 reference transmitter. The flexibility to automatically or manually set all amplifier and modulator bias points provides the user the freedom to simulate less-than-ideal performance of their own device.

Coherent optical receiver manufacturers can also use the OM5110 as the ideal transmitter with which to test their receiver’s performance and prove functionality under best-case conditions. Then, using an instrument such as the AWG70001A Arbitrary Waveform Generator, optical impairments can be added to the signal to test the receiver under a wide range of real-world scenarios.

Supports manual and automatic bias control of amplifiers and modulator

Remotely control all setup and operations over Ethernet

Applications

Testing coherent optical receivers

Golden reference coherent optical transmitter

Transmitter for multi-carrier superchannel systems

www.tektronix.com 1

OM5110

As the demand for network bandwidth has increased, new transmission schemes such as multi-carrier “superchannels” are under investigation. The OM5110 can function as the heart of a superchannel system. Multiple optical carriers can be externally combined and used as the laser source to the OM5110 using the external signal input. Tektronix offers external laser sources, such as the OM2012 Tuneable Laser Source, which can be used to create a superchannel system. With such a configuration, systems with aggregate data rates such as 400G, 1Tb/s, and beyond, can be created.

The OM5110 offers the convenience of built-in laser sources, either C-band or L-band. Setup and operation of the laser, such as wavelength and optical power, can all be controlled remotely over Ethernet. Alternatively, an external laser source may be connected to the front panel of the instrument in place of the built-in lasers.

2 www.tektronix.com

Datasheet

The data from the external signal generator is first amplified by four, highlinearity amplifiers. The bias points for these amplifiers can be monitored and automatically controlled by the included Tektronix control software. The user may also take control of the bias points and set the amplifier bias voltages manually. The high-linearity of these amplifiers makes them ideal for multi-level signals such as 16QAM. For two-level signals, such as QPSK, the amplifiers can be can be driven into saturation so that the modulator drive is less sensitive to input drive level variations due to external rf cable losses.

The output of either the on-board laser, or a customer-supplied external laser is passed through a beam splitter and then fed to each of the four internal Mach-Zehnder modulators. Like the amplifiers, each Mach-Zehnder modulator has bias controls that can be automatically controlled or manually set by the user. The amplified signals feed these four modulators whose outputs are optically combined to create a complex, dual-polarized optical signal available on the front-panel of the instrument.

www.tektronix.com 3

OM5110

Coherent optical signal generation system

The OM5110 is a key part of a coherent optical signal generation system. The other major component is the signal generator itself. The Tektronix PPG3000 series programmable pattern generators and theTektronix AWG70000 Series Arbitrary Waveform Generators (AWG) offer the flexibility to choose the type of signal generation instrument suited to the test requirements.

The PPG3000 Series can generate patterns up to 32 Gb/s and offers 1, 2, or 4 channels in a single instrument. The patterns may be standard PRBS patterns or user-defined. Using a 4-channel pattern generator makes creating dual-polarization I-Q waveforms very simple.

Coherent optical signal generation is one of the more demanding applications for an AWG. The requirements in terms of number of channels sampling rate, bandwidth, record length, and timing and synchronization quality can be only met by the highest performance instruments, such as the Tektronix AWG70000 Series. The unique capability of generating ideal or distorted signals and the ease to add new modulation schemes and signal processing algorithms without the need to add any extra hardware make AWGs an ideal tool for coherent optical communication research and development.

The AWG70000 Series can reach sampling rates as high as 50 GS/s with 10 bits vertical resolution. Such level of performance allows for the direct generation of IQ basebands signals required by modern coherent optical communication systems. The arbitrary waveform generation capabilities of the AWG70000 Series makes it possible to create multi-level signals such as 16QAM, add impairments to a signal, or to create waveforms that are precompensated for the real-world effects of the test system.

4 www.tektronix.com

Specifications

Values stated in the following tables are typical unless stated otherwise.

System characteristics

Maximum symbol rate 46 GBaud: for binary formats such as BPSK, QPSK

34 GBaud: for multi-level formats such as 16QAM

Modulation formats 3-State OOK, BPSK, PM-BPSK, QPSK, PM-QPSK, 16QAM, PM-16QAM

Higher order formats are possible depending on baud rate and frequency compensation available.

Absolute maximum ratings

Input Optical Power 18 dBm

Datasheet

Input Electrical Signal, AC 6 V

Input Electrical Signal, DC 5 V

p-p

Electrical characteristics

3 dB bandwidth relative to 2 GHz 23 GHz

6 dB bandwidth relative to 2 GHz (specification)

Modulation percent of 2π at 1 V 23 GHz input

EVM, 25 GBaud 16QAM <10%

p-p

> 30 GHz

> 90%

Optical characteristics

External input wavelength range 1526.6 nm to 1609.6 nm

Modulator insertion loss (specification)

DC extinction ratio > 20 dB

< 14 dB

Optical return loss > 27 dB

PDL (typical) < 0.8 dB

Power readout accuracy ± 2 dB

www.tektronix.com 5

OM5110

Internal laser optical characteristics

Internal laser wavelength range

C-Band 1526.6 nm to 1567.5 nm

L-Band 1567. 5 nm to 1609.6 nm

Output power > 13 dBm

Minimum grid spacing 10 GHz

Minimum frequency step 100 MHz

Absolute wavelength accuracy 10 pm

Linewidth (short term) 100 kHz

Sidemode suppression ratio 55 dB

Power requirements

Power requirements 100 - 240 V

Fuse rating Slo-Blo 3.15 A, 250 V

±10%, 50/60 Hz, 100 W

RMS

Physical characteristics

Dimensions

Height 89 mm, 3.5 in.

Width 432 mm, 17 in.

Depth 298.5 mm 11.75 in.

Weight

Net 7.4 kg, 16.3 lb.

Shipping 14.6 kg, 32.2 lb.

Environmental characteristics

Temperature

Operating +10 °C to +35 °C

Non-operating -20 °C to +60 °C

Humidity

Operating 10% to 85% RH up to +35 °C, noncondensing

Non-operating 10% to 85% RH up to +35 °C, noncondensing

10% to 45% RH up to +60 °C, noncondensing

Altitude

Operating 3000 meters; derate maximum operating temperature by 1 °C per 300 meters above 1500 meters altitude

Non-operating 12,000 meters

6 www.tektronix.com

Environmental characteristics

Vibration

Operating Sine: 0.33 mm pk-pk (0.013 inch p-p) constant displacement, 5-55 Hz, 3 axes

Random: 0.24 GRMS, 5-500 Hz, 10 minutes per axis

Non-operating Random: 2.22 GRMS, 5-500 Hz, 10 minutes per axis

Mechanical shock Half-sine mechanical shocks, 30g peak amplitude, 11 second duration, 3 drops in each direction of each axis

EMC, environment, and safety

Immunity IEC61326, IEC61000-4-2/3/4/5/6/11

Emissions CISPR11, Class A, EN 61000-3-2,EN61000-3-3

Safety UL61010-1, CAN/CSA-22.2, No.61010-1, EN61010-1, IEC61010-1, 21

Laser Safety: CFR1040.10 except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007. IEC60825-1-1

Datasheet

www.tektronix.com 7

OM5110

Ordering information

Models

OM5110 46 GBaud Multi-Format Optical Transmitter

Instrument options

OM5110 options

Opt. C Built-in C-band laser

Opt. L Built-in L-band laser

Opt. NL No built-in lasers. Requires external laser source

Power plug options

Opt. A0 North America power plug (115 V, 60 Hz)

Opt. A1 Universal Euro power plug (220 V, 50 Hz)

Opt. A2 United Kingdom power plug (240 V, 50 Hz)

Opt. A3 Australia power plug (240 V, 50 Hz)

Opt. A5 Switzerland power plug (220 V, 50 Hz)

Opt. A6 Japan power plug (100 V, 110/120 V, 60 Hz)

Opt. A10 China power plug (50 Hz)

Opt. A11 India power plug (50 Hz)

Opt. A12 Brazil power plug (60 Hz)

User manual options

Opt. L0 English manual

Service options

Opt. C3 Calibration Service 3 Years

Opt. C5 Calibration Service 5 Years

Opt. R3 Repair Service 3 Years (including warranty)

Opt. R5 Repair Service 5 Years (including warranty)

Installation options

OMINSTALL AMR On-site OM-series install for the Americas

OMINSTALL JPN On-site OM-series install for Japan

OMINSTALL EMEA On-site OM-series install for Europe, Middle East, and Africa

OMINSTALL APAC On-site OM-series install for the Asia Pacific
