Tektronix MTSA-HW, MTSA-PC User manual

Download

MTSA-HW and MTSA-PC MPEG Test Systems

ZZZ

Analyzer Applications

User Manual

*P077160000*

077-1600-00

MTSA-HW and MTSA-PC MPEG Test Systems

ZZZ

Analyzer Applications

User Manual

This manual supports the MTSA Application Installer v. 3.3.1.

www.tek.com

077-1600-00

Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries or suppliers, and are protected by national copyright laws and international treaty provisions.

Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supersedes that in all previously published material. Speciﬁcations and price change privileges reserved.

TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.

CaptureVu® and FlexVu® Plus are registered trademarks of Tektronix, Inc.

Contacting Tektronix

Tektronix, Inc. 14150 SW Karl Braun Drive P.O . Bo x 50 0 Beaverton, OR 97077 USA

For product information, sales, service, and technical support:

In North America, call 1-800-833-9200. Worldwide, visit www.tek.com to ﬁnd contacts in your area.

TEKTRONIX SOFTWARE LICENSE AGREEMENT

THE PROGRAM, OR PROGRAMS, ENCODED OR INCORPORATED WITHIN EQUIPMENT OR ACCOMPANYING THIS AGREEMENT, IS FURNISHED SUBJECT TO THE TERMS AND CONDITIONS OF THIS AGREEMENT. RETENTION OF THE PROGRAM FOR MORE THAN THIRTY DAYS OR USE OF THE PROGRAM IN ANY MANNER WILL BE CONSIDERED ACCEPTANCE OF THE AGREEMENT TERMS. IF THESE TER DOCUMENTATION SHOULD BE RETURNED PROMPTLY TO TEKTRONIX FOR A FULL REFUND OF THE LICENSE FEE PAID. (FOR INFORMATION REGARDING THE RETURN OF PROGRAMS ENCODED OR INCORPORATED WITHIN EQUIPMENT, CONTACT THE NEAREST TEKTRONIX SALES OFFICE.)

DEFINITIONS.

"Tektronix" means Tektronix, Inc., an Oregon corporation, or local Tektronix’ legal entity that is supplying the equipment.

"Program" means the Tektronix software product (executable program and/or data) enclosed with this Agreement or included within the equipment with which this Agreement is packed.

"Customer" means the person or organization in whose name the Program was ordered.

MS ARE NOT ACCEPTABLE, THE UNUSED PROGRAM AND ANY ACCOMPANYING

LICENS

Customer may:

1. UsetheProgramonasinglemachineatanyonetime;

2. Copy the Program for archival or backup purposes, provided that no more than one (1) such copy is permitted

Each copy of the Program made by Customer must include a reproduction of any copyright notice or restrictive rights legend appearing in or on the copy of the Program as received from Tektronix;

Customer may not:

1. Use the Program on more than one machine at any one time;

2. Transfer the Program to any person or organization outside of Customer or the corporation of which Customer

3. Export or reexport, directly or indirectly, the program, any associated documentation, or the direct product

4. Modify the Program, create derivative works, or merge the Program with another program;

to exist at any one time;

is a part without the prior written consent of Tektronix, except in connection with the transfer of the equipment within which the programs are encoded or incorporated;

thereof, to any country to which such export or reexport is restricted by law or regulation of the United States or any foreign government having jurisdiction without the prior authorization, if required, of the Ofﬁce of Export Administration, Department of Commerce, Washington, D.C. and the corresponding agency of such foreign government;

5. Reverse compile or disassemble the Program for any purpose, beyond the extent that such activity is expressly permitted by applicable open source licenses or applicable law notwithstanding this limitation, or

6. Copy the documentation accompanying the Program.

For Programs designed to reside on a single-machine and support one or more additional machines, either locally or remotely, without permitting the Program to be transferred to an additional machine for local execution, the additional ma Program to be transferred to an additional machine for local execution, a separate license shall be required for each such machine with which the Program may be used.

Title to the Program and all copies thereof, but not the media on which the Program or copies may reside, shall be and remain with Tektronix or others for whom Tektronix has obtained a respective licensing right.

Customer shall pay when due all property taxes that may now or hereafter be imposed, levied or assessed with respect to the possession or use of the Program or this license and shall ﬁle all reports required in connection with such taxes.

If the Program or any related documentation is acquired by or for an agency of the U.S. Government, the Program and documentation shall be considered “commercial computer software” or “commercial computer software documentation” respectively, as those terms are used in 48 CFR §12.212, 48 CFR §227.7202, or 48 CFR §252.227-7014, and are licensed with only those rights as are granted to all other licensees as set forth in this Agreement.

THE PROGRAM MAY NOT BE USED, COPIED, MODIFIED, MERGED, OR TRANSFERRED TO ANOTHER EXCEPT AS EXPRESSLY PERMITTED BY THESE TERMS AND CONDITIONS. UPON TRANSFER OF ANY COPY, MODIFICATION, OR MERGED PORTION OF THE PROGRAM, THE LICENSE GRANTED HEREIN IS AUTOMATICALLY TERMINATED WITH RESPECT TO THE PARTY THAT TRANSFERS THE PROGRAM.

TERM.

chines shall be considered within the deﬁnition of "single machine." For programs permitting the

The license granted herein is effective upon acceptance by Customer, and shall remain in effect until terminated as provided herein. The license may be terminated by Customer at any time upon written notice to Tektronix. The license may be terminated by Tektronix or any third party from whom Tektronix may have obtained a respective licensing right if Customer fails to comply with any term or condition and such failure is not remedied within thirty (30) days after notic return to Tektronix or destroy, the Program and all associated documentation, together with all copies in any form.

LIMITED WARRANTY.

The Program is provided "as is" without warranty of any kind, either express or implied. Tektronix does not warrant that the functions contained in the Program will meet Customer's requirements or that the operation of the Program will be uninterrupted or error-free.

TEKTRONIX AND ITS VENDORS DISCLAIM ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.

LIMITATION OF LIABILITY, IN NO EVENT SHALL TEKTRONIX OR OTHERS FROM WHOM TEKTRONIX HAS OBTAINED A LICENSING RIGHT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES ARISING OUT OF OR CONNECTED WITH CUSTOMER'S POSSESSION OR USE OF THE PROGRAM, EVEN IF TEKTRONIX OR SUCH OTHERS HAS ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.

THIRD-PARTY DISCLAIMER.

Except as expressly agreed otherwise, third parties from whom Tektronix may have obtained a licensing right do not warrant the program, do not assume any liability with respect to its use, and do not undertake to furnish any support or information relating thereto.

e hereof from Tektronix or such third party. Upon termination by either party, Customer shall

GENERAL.

This Agreement contains the entire agreement between the parties with respect to the use, reproduction, and transfer of the Program. Neither this Agreement nor the license granted herein is assignable or transferable by Customer without the prior written consent of Tektronix.

This Agreement and the license granted herein shall be governed by the laws of the state of Oregon.

All questions regarding this Agreement or the license granted herein should be directed to the nearest Tektronix Sales Ofﬁce.

Table of Contents

Important safety information..................................................................................... xi

General safety summary ..................................................................................... xi

Service safety summary..................................................................................... xiii

Terms in this manual ........................................................................................ xiv

Symbols and terms on the product......................................................................... xiv

Preface .............................................................................................................. xv

Product documentation..................................................................................... xvii

TSCA - Getting started............................................................................................. 1

TSCA features.................................................................................................. 2

File Analysis and RealTime modes ......................................................................... 2

Technical background ......................................................................................... 3

User interface................................................................................................... 3

CaptureVu feature ............................................................................................. 5

Triggered recording............................................................................................ 5

Starting the TSCA software .................................................................................. 6

Interface card overview ...................................................................................... 15

Setting up the IP interface .. .. . .. .. .. . .. .. . .. .. .. . .. .. .. . .. .. .. . .. ........................................... 17

Starting analysis............................................................................................... 23

Setting the stream content font .. . .. .. . .. .. .. .. . .. .. ... .. .. .. . .. .. ........................................... 24

TSCA – Understanding the TSCA window .................................................................... 27

TSCA top level displays ..................................................................................... 28

TSCA window components ................................................................................. 29

Error status LEDs............................................................................................. 33

Context menus ................................................................................................ 34

TSCA – Using the Program view................................................................................ 35

Program navigation - transport stream node............................................................... 37

Program navigation - program nodes....................................................................... 43

Program navigation - elementary stream node ............................................................ 45

TSCA – Using the Testsview.................................................................................... 48

Tests navigation - all tests.................................................................................... 52

Test navigation - test nodes.................................................................................. 53

Test navigation - PID nodes ................................................................................. 54

TSCA – Using the Tables view .................................................................................. 55

Table summary pane.......................................................................................... 56

Tables detail view - Section view ........................................................................... 57

Tables detail view - SI repetition graphs . .. .. . .. .. .. . .. .. .. . .. .. .. . ........................................ 59

Export SI/PSI as XML ....................................................................................... 59

TSCA – Using the PID view ..................................................................................... 60

PID view - all PIDs........................................................................................... 61

MTSA-HW and MTSA-PC Analyzer Applications User Manual i

Table of Contents

PIDview-detai

PID view - detail view (PIDs)............................................................................... 63

TSCA – Using the Packets view................................................................................. 65

Packet navigation bar......................................................................................... 66

Packet navigation - ﬁlter nodes.............................................................................. 67

Packet Detail view............................................................................................ 68

TSCA – Using the Interface view................................................................................ 70

Detail view tabs............................................................................................... 71

Readings and controls........................................................................................ 71

SDR RFinterface views ..................................................................................... 72

TSCA – Common user interface concepts...................................................................... 78

Windows management ....................................................................................... 79

Icons............................................................................................................ 80

Graph management........................................................................................... 83

Timing graphs................................................................................................. 89

Bit rate graphs................................................................................................. 92

PIT graph ...................................................................................................... 92

RTP Loss distribution graph................................................................................. 93

Thumbnail views.............................................................................................. 95

Parameter edit................................................................................................. 97

Event log....................................................................................................... 99

Bit rates ...................................................................................................... 103

EPG view .................................................................................................... 108

MPE views .................................................................................................. 112

CaptureVu feature .......................................................................................... 113

Triggered recording......................................................................................... 116

Menu bar and options ...................................................................................... 121

Conﬁguration................................................................................................ 122

Script ﬁles ................................................................................................... 128

TSCA – Task examples......................................................................................... 133

Which tests have failed in an analyzed stream .......................................................... 134

How many PIDs are there in a stream? How many PIDs are referenced? How many are

unreferenced?........................................................................................... 136

What tests have been applied to a program PID? ....................................................... 137

Establish the stream typeofa PID........................................................................ 138

How many programs are there in the Stream?........................................................... 139

What are the contents of the Programs? And what Pids are they on? . .. .. .. . .. ...................... 140

What isthe bit rate ofeachPID in a program?.......................................................... 141

What is the latest version number of the Program Association Table (PAT) in the SI?............. 144

Examine a transport packet................................................................................ 145

l view (All PID and PID Group)......................................................... 62

ii MTSA-HW and MTSA-PC Analyzer Applications User Manual

Table of Contents

TSCA – SI/PSI no

PES Analyzer – Getting started .. . .. .. .. . .. .. .. . .. .. .. . .. .. .. ... .. .. ........................................... 153

Starting the program........................................................................................ 154

Options....................................................................................................... 158

Opening a ﬁle ............................................................................................... 161

PES Analyzer – Menus and controls .......................................................................... 165

Toolbar ....................................................................................................... 165

Status bar .................................................................................................... 166

Slider bar..................................................................................................... 167

Menus and options.......................................................................................... 169

PES Analyzer – Packet Hex view.............................................................................. 171

Packet header................................................................................................ 172

PES Analyzer – Event log...................................................................................... 174

Packet selection............................................................................................. 175

PES Analyzer – Packet header interpretation ................................................................ 177

PES Analyzer – Program structure ............................................................................ 179

The diagram ................................................................................................. 180

Selecting a packet type..................................................................................... 181

PES Analyzer – PTS/DTS timing analysis . .. .. ... .. .. . .. .. .. . .. .. . .. .. ...................................... 182

Access unit selection ....................................................................................... 185

Scrolling the view. . .. .. .. . .. .. .. . .. .. .. . .. .. .. .. . .. .. .. . .. .. .. .............................................. 185

Video streams ............................................................................................... 186

Audio streams............................................................................................... 190

AC-3 audio streams......................................................................................... 191

AAC audio streams......................................................................................... 192

E-AC3 audio streams....................................................................................... 193

T-STD Buffer Analyzer – Getting started . .. .. .. ... .. .. . .. .. .. .. . .. .. ......................................... 195

Suitable streams............................................................................................. 196

Table handling............................................................................................... 196

Starting the program........................................................................................ 197

Settings. .. . .. .. .. . .. .. .. .. . .. .. .. . .. .. .. .. . .. .. .. . .. .. .. .. . .. ................................................. 199

Opening an MPEG ﬁle ..................................................................................... 204

Opening a BMR ﬁle ........................................................................................ 205

Window layout.............................................................................................. 206

Initial processing of MPEG ﬁles .. . .. .. ... .. .. ... .. .. . .. .. .. . .. .. ... ...................................... 207

Initial processing of BMR ﬁles.. ... .. .. . .. .. .. . .. .. . .. .. .. . .. .. ... ........................................ 207

T-STD Buffer Analyzer – Menus and controls............................................................... 208

Toolbar ....................................................................................................... 208

Status bar .................................................................................................... 210

Menu options................................................................................................ 211

des ........................................................................................... 146

MTSA-HW and MTSA-PC Analyzer Applications User Manual iii

Table of Contents

T-STD Buffer An

Selecting streams ........................................................................................... 215

Processing streams.......................................................................................... 216

T-STD Buffer Analyzer – Event and message logs.......................................................... 219

Global event log ............................................................................................ 219

PID event log................................................................................................ 220

Trace ......................................................................................................... 221

T-STD Buffer Analyzer – Results graphs..................................................................... 225

Common features ........................................................................................... 225

Elementary Buffer graph................................................................................... 234

Multiplex or Main Buffer graph. .. . .. .. .. . .. .. .. . .. .. .. . .. .. .. .. . .. ....................................... 235

Transport Buffer graph..................................................................................... 236

ES Analyzer – Getting started. .. .. .. . .. .. .. . .. .. . .. .. .. . .. .. ... .. .. ............................................ 237

Starting the ESAnalyzer................................................................................... 239

Opening anMPEG stream ................................................................................. 241

Understanding the main window and icons.............................................................. 243

Tree view and navigation .................................................................................. 245

Header, extension and hex displays....................................................................... 248

ES Analyzer – Error testing methods and outputs ........................................................... 251

Run Through Stream test mode ........................................................................... 251

Error ﬁltering................................................................................................ 253

Status bar .................................................................................................... 259

Regression testing and error log ﬁles..................................................................... 260

Reports and ﬁeldselection................................................................................. 262

Demultiplexing transport streams to PES or elementary output ﬁles . .. . .. ........................... 265

ES Analyzer – Working with transport and PES streams ................................................... 266

Using Packet view .......................................................................................... 266

UnderstandingPES......................................................................................... 267

ES Analyzer – Working with video streams.................................................................. 268

Viewing the sequence header.............................................................................. 269

Viewing the GOP and picture header..................................................................... 270

Displaying the slice and macroblock ..................................................................... 275

Analyzing picture quality .. . .. .. ... .. .. ... .. .. . .. .. .. ... .. .. . .. .. .......................................... 277

Using the video viewer for picture analysis.............................................................. 290

ES Analyzer – Working with audio streams.................................................................. 293

UnderstandingMPEG audio streams ..................................................................... 293

Audio Player ................................................................................................ 294

UnderstandingDolby Digital (AC-3) audio streams.................................................... 299

ES Analyzer – Working with Program streams .............................................................. 303

Viewing pack and system headers ........................................................................ 304

Viewing the program stream map......................................................................... 305

alyzer – Stream list ......................................................................... 214

iv MTSA-HW and MTSA-PC Analyzer Applications User Manual

Table of Contents

ES Analyzer – Wo

VBI (enhanced teletext support) .......................................................................... 308

ES Analyzer – Advanced audio compression ................................................................ 311

ADIF stream forms ......................................................................................... 313

ADTS stream forms ........................................................................................ 320

ES Analyzer – Closed caption analysis ....................................................................... 321

Enabling cl

Selecting closed caption analysis standard............................................................... 322

CC-EIA608 support ........................................................................................ 322

CC-EIA708 support ........................................................................................ 324

Dumping closed caption statistics......................................................................... 327

ES Analyzer – DVB subtitle stream analysis. .. . .. .. ... .. .. .. . .. .. .. . .. ...................................... 330

DVB Subt

Page view tab................................................................................................ 335

Index

rking with teletext.......................................................................... 307

osed caption analysis.......................................................................... 321

itle Data tab .. .. . .. .. .. ... .. .. . .. .. .. ... .. .. . .. .. .. ... .. .. . .. .. .................................. 332

MTSA-HW and MTSA-PC Analyzer Applications User Manual v

Table of Contents

List of Figure

Figure 1: TSCA Program view - deferred analysis............................................................. 1

Figure 2: TSCA startup ofﬂine ﬁle analysis ..................................................................... 7

Figure 3: TSCA startup real time analysis....................................................................... 8

Figure 4: Stream Interpretation dialog box...................................................................... 9

Figure 5: TSCA OpenFileAnalysis (Ofﬂine) dialog box .................................................... 11

Figure 6: TSCA Real time Interface dialog box ............................................................... 14

Figure 7: ‘Browse for UDP ﬂow’ window ..................................................................... 19

Figure 8: ‘Browse Device’ dropdown to

Figure 9: ‘UDP ﬂow’ selection in ‘Browse for UDP’ ﬂow window......................................... 22

Figure 10: Flow information “copied/pasted” to ‘Selected Preset’ ﬁeld . . .................................. 22

Figure 11: TSCA window showing analysis progress......................................................... 23

Figure 12: Selecting a display font from the Conﬁguration dialog box ... .. ................................ 25

Figure 13: FlexVuPlus window.................................................................................. 27

Figure 14: Analyzer window..................................................................................... 28

Figure 15: Analyzer window - noﬁle........................................................................... 32

Figure 16: Context menu (example)............................................................................. 34

Figure 17: Program view......................................................................................... 35

Figure 18: Program viewnodes.................................................................................. 36

Figure 19: Historical Multiplex Graph.. ... .. .. . .. .. .. . .. .. . .. .. .. . ............................................. 39

Figure 20: Event log .............................................................................................. 40

Figure 21: PCR Graphs view..................................................................................... 47

Figure 22: Tests Navigation view................................................................................ 48

Figure 23: Testviewnodes....................................................................................... 49

Figure 24: Testﬁltering buttons.................................................................................. 51

Figure 25: Test Failures screen .................................................................................. 52

Figure 26: Tables view............................................................................................ 55

Figure 27: Tables v

Figure 28: Section payload....................................................................................... 58

Figure 29: PID Summary view .................................................................................. 62

Figure 30: PID Information view................................................................................ 63

Figure 31: Packet view - ISDB detail -IIP .. . .. .. ... .. .. .. . .. .. . .. .. .. .......................................... 69

Figure 32: Interface view - example............................................................................. 70

Figure 33: ‘SDR Interface for QAM Annex B’................................................................ 72

Figure 34: Window size adjustments............................................................................ 79

Figure 35: Timing graphs......................................................................................... 85

Figure 36: Graph toolbar ......................................................................................... 86

Figure 37: Graph context menu.................................................................................. 87

Figure 38: Out of range indicator................................................................................ 88

select right NIC .................................................... 20

iew - Programs (example) ................................................................. 56

vi MTSA-HW and MTSA-PC Analyzer Applications User Manual

Table of Contents

Figure 39: Bit r

Figure 40: Thumbnail view - Thumbnail view................................................................. 95

Figure 41: Now Playing - Summary view...................................................................... 96

Figure 42: Now Playing - Detail view .......................................................................... 96

Figure 43: Test parameters ....................................................................................... 97

Figure 44: PID test parameters................................................................................... 98

Figure 45: Parameter value - default icon ...................................................................... 99

Figure 46: Event log - color coding ........................................................................... 101

Figure 47: Event log - context menu - color.................................................................. 101

Figure 48: Event log - color dialog boxes .................................................................... 102

Figure 49: Bit Rate display selection.......................................................................... 103

Figure 50: Bar chart............................................................................................. 104

Figure 51: Pie chart ............................................................................................. 106

Figure 52: EPG Summary view................................................................................ 108

Figure 53: EPG nodes........................................................................................... 109

Figure 54: MPE view ........................................................................................... 112

Figure 55: Record Settings dialog box . . .. .. .. . .. .. .. . .. .. .. . .. .. .. . .......................................... 117

Figure 56: Record Settings dialog box - Recording in progress. .. .. . .. .. .................................. 119

Figure 57: PID selection........................................................................................ 120

Figure 58: Conﬁguration - Test Parameters .................................................................. 123

Figure 59: PCR parameters - Filter settings . . .. .. ... .. .. . .. .. .. . .. .. . ........................................ 124

Figure 60: Conﬁguration - PCR Filters ... .. . .. .. .. . .. .. .. . .. .. .. . .. .. ........................................ 124

Figure 61: Conﬁguration - Preferences ....................................................................... 126

Figure 62: Conﬁguration - Preferences - Font................................................................ 127

Figure 63: Conﬁguration – Preferences – Dcode ............................................................ 127

Figure 64: Stream Interpretation dialog box.................................................................. 129

Figure 65: Failed tests - example.............................................................................. 134

Figure 66: Program count ...................................................................................... 139

Figure 67: PID count............................................................................................ 140

Figure 68: Program PID bit rate - bar chart .................................................................. 141

Figure 69: Program PID bit rate - pie chart................................................................... 142

Figure 70: Bit rate graph........................................................................................ 143

Figure 71: Table Identity and Version (summary view) . .. .. .. . .. .. .. . .. .................................... 144

Figure 72: Table Identity and Version (section view) . ... .. .. . .. .. .. . .. ..................................... 144

Figure 73: Primary SI/PSI nodes (DVB example)........................................................... 146

Figure 74: Icon function availability (enabled/disabled) Menu bar equivalent........................... 245

Figure 75: ADIF header Information.......................................................................... 313

Figure 76: ADIF raw data Information ....................................................................... 314

Figure 77: Single channel element Information.............................................................. 315

Figure 78: Coupling pairelement information............................................................... 315

Figure 79: Coupling channel element information .......................................................... 316

ate graph.......................................................................................... 92

MTSA-HW and MTSA-PC Analyzer Applications User Manual vii

Table of Contents

Figure 80: Low f

Figure 81: Data stream element information................................................................. 317

Figure 82: Program conﬁguration element information..................................................... 317

Figure 83: Fill element information ........................................................................... 318

Figure 84: ADIF channels (non-standard) information ..................................................... 318

Figure 85: ADIF channels (standard) information........................................................... 319

Figure 86: A

requency element channel information ................................................... 316

DTS header information......................................................................... 320

viii MTSA-HW and MTSA-PC Analyzer Applications User Manual

List of Tables

Table i: Overview of the MTSA Analyzer Applications...................................................... xv

Table 1: Toolbar icons ............................................................................................ 29

Table 2: Field descriptions,fromleftto right .................................................................. 30

Table 3: Program viewtabs ...................................................................................... 36

Table 4: Event log buttons........................................................................................ 40

Table 5: QAM(B) Settings:. .. . .. .. . .. .. .. . .. .. ... .. .. . .. .. .. . .. .. ................................................ 74

Table 6: QAM(B) Readings: ..................................................................................... 75

Table 7: Object identiﬁcation icons ............................................................................. 8

Table 8: Interface management icons ........................................................................... 81

Table 9: Quick link icons......................................................................................... 83

Table 10: Timing measurement graphs ......................................................................... 89

Table 11: Record settings .. . .. .. .. . .. .. . .. .. .. . .. .. .. . .. .. .. . .. .. . .............................................. 117

Table 12: Analysis menu options.............................................................................. 121

Table 13: View menuoptions .................................................................................. 121

Table 14: Navigation menu options ........................................................................... 121

Table 15: Settings menu options .. . .. .. .. . .. .. ... .. .. ... .. .. . .. .. .. . ........................................... 122

Table 16: CaptureVu menuoptions............................................................................ 122

Table 17: Record menu options................................................................................ 122

Table 18: Help menu options................................................................................... 122

Table 19: PCRsettling times................................................................................... 125

Table 20: Bitrate views......................................................................................... 141

Table 21: MPEG SI/PSI ........................................................................................ 147

Table 22: DVBSI/PSI .......................................................................................... 147

Table 23: ATSC SI/PSI ......................................................................................... 148

Table 24: ISDB-S SI/PSI nodes................................................................................ 149

Table 25: ISDB-T and -TB SI/PSI nodes ..................................................................... 150

Table 26: File menu

Table 27: View menuoptions .................................................................................. 157

Table 28: Settings menu options .. . .. .. .. . .. .. ... .. .. ... .. .. . .. .. .. . ........................................... 157

Table 29: Options menu options............................................................................... 157

Table 30: File menu options.................................................................................... 169

Table 31: Edit menu options ................................................................................... 169

Table 32: View menuoptions .................................................................................. 169

Table 33: Options menu options............................................................................... 170

Table 34: Window menu options .............................................................................. 170

Table 35: Help menu options................................................................................... 170

Table 36: File menu options.................................................................................... 199

Table 37: View menuoptions .................................................................................. 199

Table of Contents

options.................................................................................... 157

MTSA-HW and MTSA-PC Analyzer Applications User Manual ix

Table of Contents

Table 38: File m

Table 39: Edit menu options ................................................................................... 211

Table 40: View menu options .................................................................................. 211

Table 41: Options menu options ............................................................................... 212

Table 42: Process menu options ............................................................................... 212

Table 43: Trace menuoptions.................................................................................. 212

Table 44: Wi

Table 45: Help menu options................................................................................... 213

Table 46: Tool bar icons ........................................................................................ 244

Table 47: Navigation icons..................................................................................... 246

Table 48: Header icons.......................................................................................... 248

Table 49: Hex Headers display ................................................................................ 250

enu options.................................................................................... 211

ndow menu options .............................................................................. 213

x MTSA-HW and MTSA-PC Analyzer Applications User Manual

Important safety information

This manual contains information and warnings that must be followed by the user for safe operation and to keep the product in a safe condition.

To safely perform service on this product, additional information is provided at the end of this section. (See page xiii, Service safety summary.)

General safety summary

Use the product only as speciﬁed. Review the following safety precautions to avoid inj Carefully read all instructions. Retain these instructions for future reference.

ury and prevent damage to this product or any products connected to it.

Comply wi

For correct and safe operation of the product, it is essential that you follow general in this manual.

The pro

Only qualiﬁed personnel who are aware of the hazards involved should remove the co

Before use, always check the product with a known source to be sure it is oper

This product is not intended for detection of hazardous voltages.

Use personal protective equipment to prevent shock and arc blast injury where hazardous live conductors are exposed.

While using this product, you may need to access other parts of a larger system. Read the safety sections of the other component manuals for warnings and

autions related to operating the system.

When incorporating this equipment into a system, the safety of that system is the

esponsibility of the assembler of the system.

th local and national safety codes.

ly accepted safety procedures in addition to the safety precautions speciﬁed

duct is designed to be used by trained personnel only.

ver for repair, maintenance, or adjustment.

ating correctly.

MTSA-HW and MTSA-PC Analyzer Applications User Manual xi

Important safety information

To avoid ﬁre or

personal

injury

Use proper powe

certiﬁed for the country of use. Do not use the provided power cord for other products.

Ground the product. This product is grounded through the grounding conductor of the power cord. To avoid electric shock, the grounding conductor must be connected to earth ground. Before making connections to the input or output terminals of the product, make sure that the product is properly grounded. Do not disable the power cord grounding connection.

Power disconnect. The power switch disconnects the product from the power source. See instructions for the location. Do not position the equipment sothatit is difﬁcult to disconnect the power switch; it must remain accessible to theuserat all times to allow for quick disconnection if needed.

Observe all terminal ratings. To avoid ﬁre or shock hazard, observe all ratings and markin information before making connections to the product.

Do not apply a potential to any terminal, including the common terminal, that exceeds the maximum rating of that terminal.

The measuring terminals on this product are not rated for connection to mains or Category II, III, or IV circuits.

r cord. Use only the power cord speciﬁed for this product and

gs on the product. Consult the product manual for further ratings

Do not operate without covers. Do not operate this product with covers or panels removed, or with the case open. Hazardous voltage exposure is possible.

Avoid exposed circuitry. Do not touch exposed connections and components when power is present.

Do not operate with suspected failures. If you suspect that there is damage to this product, have it inspected by qualiﬁed service personnel.

Disable the product if it is damaged. Do not use the product if it is damaged or operates incorrectly. If in doubt about safety of the product, turn it offand disconnect the power cord. Clearly mark the product to prevent its further operation.

Examine the exterior of the product before you use it. Look for cracks or missing pieces.

Use only speciﬁed replacement parts.

Use proper fuse. Use only the fuse type and rating speciﬁed for this product.

Wear eye protection. Wear eye protection if exposure to high-intensity rays or

laser radiation exists.

Do not operate in wet/damp conditions. Be aware that condensation may occur if a unit is moved from a cold to a warm environment.

xii MTSA-HW and MTSA-PC Analyzer Applications User Manual

Important safety information

Do not operate i

Keep product surfaces clean and dry. Remove the input signals before you clean

the product.

Provide proper ventilation. Refer to the installation instructions in the manual for details on installing the product so it has proper ventilation.

Slots and openings are provided for ventilation and should never be coveredor otherwise obstructed. Do not push objects into any of the openings.

Provide a safe working environment. Always place the product in a location convenient for viewing the display and indicators.

Avoid improper or prolonged use of keyboards, pointers, and button pads. Improper or prolonged keyboard or pointer use may result in serious injury.

Be sure your work area meets applicable ergonomic standards. Consult with an ergonomics professional to avoid stress injuries.

Use care when lifting and carrying the product. This product is provided with handles for lifting and carrying.

n an explosive atmosphere.

Servicesafetysummary

The Service safety summary section contains additional information required to safe service procedures. Read this Service safety summary and the General safety summary before performing any service procedures.

To avoid electric shock. Do not touch exposed connections.

product unless another person capable of rendering ﬁrst aid and resuscitation is present.

Disconnect power. To avoid electric shock, switch off the product power and disconnect the power cord from the mains power before removing any covers or panels, or opening the case for servicing.

Use care when servicing with power on. Dangerous voltages or currents may exist in this product. Disconnect power, remove battery (if applicable), and disconnect test leads before removing protective panels, soldering, or replacing components.

Verify safety after repair. Always recheck ground continuity and mains dielectric strength after performing a repair.

ly perform service on the product. Only qualiﬁed personnel should perform

not service alone. Do not perform internal service or adjustments of this

MTSA-HW and MTSA-PC Analyzer Applications User Manual xiii

Important safety information

Termsinthismanual

These terms may appear in this manual:

WARNING. Warning statements identify conditions or practices that could result

in injury or loss of life.

CAUTION. Caution statements identify conditions or practices that could result in

damage to this product or other property.

Symbols and terms on the product

These ter

The following symbol(s) may appear on the product:

ms may appear on the product:

DANGER indicates an injury hazard immediately accessible as you read the mark

WARNING indicates an injury hazard not immediately accessible as you read th

CAUTION indicates a hazard to property including the product.

ing.

e marking.

When this symbol is marked on the product, be sure to consult the manual to ﬁnd out the nature of the potential hazards and any actions which have to betakentoavoidthem. (Thissymbolmayalsobeusedtorefertheuserto ratings in the manual.)

xiv MTSA-HW and MTSA-PC Analyzer Applications User Manual

Preface

The MTSA MPEG system applications are described in the following three user manuals:

Analyzer applications

Generator applications

Carousel applications

NOTE. To view the full list of applications, ﬁnd the MTSA-HW and MTSA-PC

Quick Start User Manual at https//www.tek.com.

The MTSA can be delivered to you as a rack mountable 1RU full rack instrument (MTSA-HW), or as a standalone software (MTSA-PC). For product ordering purposes, the following naming conventions are used in this manual:

MTSA-HW, which is used for information that only applies to the MTSA-HW instrument

MTSA-PC, which is used for information that only applies to the standalone software.

MTSA: Used for information that applies to both MTSA-HW and MTSA-PC products

Table i: O verview of the MTSA Analyzer Applications

Application Desktop icon

Transport Stream Compliance Analyzer (TSCA) – Real time and deferred transport stream analysis with user-selectable MPEG-2, DVB, ATSC and ISDB conformance tests. Shows transport structure, header contents, hexadecimal packet contents, PCR timing /transport rate graphs and error message logs.

Packetized Elementary Stream (PES) Analyzer – PES analysis with selectable test options. Shows PES program structure, header contents, packet contents, PTS/DTS timing graphs and analysis reports.

MTSA-HW and MTSA-PC Analyzer Applications User Manual xv

Preface

Table i: Overview of the MTSA Analyzer Applications (cont.)

Application Desktop icon

Transport Stream - System Target Decoder (T-STD) Buffer Analyzer – Analyzes program streams modeling their behavior in, and their conformance to, the MPEG-2 T-STD Buffer Model. Includes a trace facility.

Elementary Stream Analyzer – Elementary S tream analysis at video picture and audio level. This includes vector graphs and macroblock picture quality.

xvi MTSA-HW and MTSA-PC Analyzer Applications User Manual

Product documentation

Preface

The following table lists the documentation available for your MTSA-HW and MTSA-PC product:

Language

English

Document title Part numbers Purpose

MTSA-HW and MTSA-PC Quick Start User Manual

MTSA-HW and MTSA-PC Analyzer Applications User Manual

MTSA-HW and MTSA-PC Generator Applications User Manual

MTSA-HW and MTSA-PC Carousel Applications User Manual

MTSA-HW and MTSA-PC Release Notes

MTS4EA HEVC / AVC Video and Compressed Audio Analyzer User Manual

PQA600C and PQASW Picture Quality Analyzer User Manual

071-3661-xx Describes how to install

and get started using the test systems.

077-1600-xx Describes the operation

of the following analyzer applications: TSCA, PES Analyzer, T-STD Buffer Analyzer, and ES Analyzer.

077-1601-xx Describes the operation

of the following generator applications: Multiplexer, MPEG Player, TS Editor, ISDB-T Remux, Make Seamless Wizard, Transport Stream Cutter, and Script Pad.

077-1602-xx Data analysis showing

structure, bit rate, repetition rate, syntax and semantics of data items.

077-1604-xx Describes known issues

with the test systems.

077-1134-xx Describes the operation

of the advanced elementary stream software.

077-1137-xx Describes the operation

of the PQA application software.

MTSA-HW and MTSA-PC Analyzer Applications User Manual xvii

Preface

xviii MTSA-HW and MTSA-PC Analyzer Applications User Manual

TSCA - Getting started

The MTSA MPEG Transport Stream Compliance Analyzer (TSCA) enables you to monitor and interpret the contents of real time, previously recorded, or synthesized standards.

transport streams using the latest MPEG, DVB, ATSC, and ISDB

The TSCA is s problems within a transport stream using a minimum number of clicks.

By quickly time during the development and test of equipment, networks, and services.You can conﬁgure the TSCA software to display stream information in user-selected fonts. This feature enables you to view stream information in your local language or to use custom fonts.

The TSCA software will run standalone on computers with the Microsoft Window

peciﬁcally designed to enable you to quickly locate and identify

identifying the problem areas, the TSCA software helps you save

s 10 Pro operating system:

Figure 1: TSCA Program view - deferred analysis

MTSA-HW and MTSA-PC Analyzer Applications User Manual 1

TSCA - Getting started

TSCA features

Industry's fastest analysis engine enables reduced analysis time, rapid development, evaluation, deployment, and diagnostics of next generation DTV and IPTV s

Support for a wide range of DTV standards, including MPEG, DVB, ATSC, including A for terrestrial, cable, and satellite, plus regional variations of these standards are also supported

A range of interfaces and analysis capabilities provide the necessary connectivity to diagnose problems anywhere in the network environment, whether that is in transmission links (RF or IP layer) or content processing (TS layer)

Connection to both IP version 4 and 6 networks, including those using IGMP and MLD multicast protocols respectively

Constant bit rate stream analysis (CBR)

CaptureVu technology captures and analyzes system events in real time and deferred time to debug the intermittent and complex problems that traditional analyzers miss

ystems and services

78 and SCTE 142, and ISDB. Speciﬁc service information (SI)

Multi input monitoring

Innovative program-centric user interface brings expert power to the novice user

File Analysis and Real Time modes

The TSCA can be run in ofﬂine (or deferred) File Analysis or Real Time Analysis mode.

The ofﬂine File Analysis mode is available on any recommended platform (including the your own PC). In ofﬂine File Analysis mode, a static stream can be analyzed and displayed; the content can then be inspected at leisure.

2 MTSA-HW and MTSA-PC Analyzer Applications User Manual

Technical background

TSCA - Getting started

The analyzer has a client-server architecture. Every time the analyzer opens, it starts two processes: tsca.exe, which is the client, and MpegCore.exe, which is the MPEG analysis engine.

Additionally, when the analyzer opens for the ﬁrst time, another single process, CoreManager.exe, is started. CoreManager.exe forms an intermediary between TSCA clients and MPEG cores. The tsca.exe, MpegCore.exe, and CoreManag and HTTP (Hypertext Transfer Protocol) to communicate. The port numbers used for communication are read from a conﬁguration ﬁle, CoreInfo.xml. In a default installation, the path to the ﬁle is:

C:\program files (x86)\tektronix\mpeg\mtsa\apps\tsca\xml\

The default port range is 15700-15800. You can change these values if they conﬂict with other applications. You must have local administrator rightstobe able to use IP analysis. If you need to change your rights, please consult your system administrator.

er.exe processes use SNMP (Simple Network Management Protocol)

User i

nterface

Program view

The TSCA software displays two primary views selected using tabs: FlexVu® Plus and Analysis.

Using the FlexVu® Plus window, you can assemble up to four views that you select from the Analysis window. This allows you to customize the view by selecting

views that are most relevant to the analysis task. The FlexVu® Plus window is

the describedindetailintheMTSA-HW and MTSA-PC Quick Start User Manual.

e Analysis window uses a single main program summary window with different

Th context sensitive views contained within tabbed frames. This provides the maximum amount of useful information, while keeping the screen from appearing cluttered. From the main window, you can access the following views: Program, Tests, Tables, PID, Packets, and Interface.

The Program view provides a fast overview of the transport stream contents in terms of program content, bit rate use by each program, and TR 101 290 test results.

Red, amber, and green LEDs highlight errors associated with each program, or element of a program, within the transport stream. Red LEDs indicate that there are current errors in the stream, amber LEDs indicate that errors have occurred but are now clear, and green LEDs indicate that no errors have been detected.

MTSA-HW and MTSA-PC Analyzer Applications User Manual 3

TSCA - Getting started

Tests view

SI/PSI (Tables) view

Errors that are up to the highest level. This allows you to monitor all of the programs in the stream at a high level and then quickly go to lower levels as necessary to locate a problem.

The Tests view enables you to isolate errors to the speciﬁc tests that have been applied to the transport stream. The error log is automatically ﬁltered by the selected test, and can also be ﬁltered by Packet Identiﬁer (PID).

In addition to the standard ﬁrst, second, and third priority tests includedin TR 101 290 standard, tests are available for Program Clock Reference (PCR) jitter and program/PID bit rate.

A variability test enables you to test the changes in the bit rate of a speciﬁcPID, and there are many tests that are speciﬁc to ISDB-T and ISDB-S streams.

The SI/PSI (Tables) view displays the service information tables that have occurred in the analyzed stream that comply with the selected digital video standard. This includes MPEG-speciﬁc program information, DVB service information, and ATSC, ISDB program, and system protocol information.

The tables are grouped together by function and hyperlinks enable you to quickly access related information within other tables.

detected at lower levels in the program stream hierarchy propagate

iew

PID v

Packets view

The PID view displays information about all of the PIDs found in the transport stream. When you select the transport stream, the associated summary view provides a PID-oriented overview of the transport stream, displaying the relative

ta rates of all of the PIDs contained within the stream.

The information can be displayed as either a bar chart or as a pie chart. Pop up

nus enable fast limit selection and links. Each PID is associated with a number

me of tests. When one or more tests fail, each failed test will be listed under the relevant PID. Select a speciﬁc PID to display a summary of all the associatedtests.

Select a speciﬁc test to display the Event Log and Parameters for only that test.

The Packets view displays information about all of the packets found in the transport stream grouped according to content. These groups include PID value, SFN mega-initialization packets (MIPs) (DVB only), and ISDB-T and ISDB-TB information packets (IIPs).

When you select a speciﬁc PID or MIP, only packets carrying that particular PID or MIP are displayed. A section view is also available. Deferred analysis of PCAP ﬁles allows you to see the Ethernet packets. The Packets view is not available in real time mode. However, you can examine packets in a real time stream by using the CaptureVu feature.

4 MTSA-HW and MTSA-PC Analyzer Applications User Manual

TSCA - Getting started

Interface view

CaptureVu feature

The Interface v and IP interface cards (where installed):

Test results

Graphical representation of speciﬁc RF and IP readings

RF and IP readings and control settings

The graphical views display a selection of graphs of instantaneous measurements and measurement trends. Also available is an Event Log.

The Interface tab is displayed only when an interface is installed.

The CaptureVu feature captures a snapshot of system events in real and deferred time, and allows you to debug the intermittent and complex problems that traditional analyzers miss.

You can initiate CaptureVu either manually or automatically by associating a CaptureVu Breakpoint with any test event.

When a breakpoint is detected, either manual or automatic, the stream is paused and an in-depth deferred time analysis can be performed on stored data. This

ful debug mode enables fast debugging of troublesome intermittent

power problems.

iew provides a central location for information related to the RF

Triggered recording

During real time analysis, stream information can only be held for a ﬁnite time

- eventually it will be overwritten by more up-to-date information. Triggered recording allows a portion of a stream to be recorded and subsequently analyzed in detail.

The following trigger sources and conditions apply:

Any test event

Date and time

Recorded ﬁle size can be speciﬁed

Pretrigger buffer size can be speciﬁed as a percentage of the overall ﬁle size range from 0 - 100%

MTSA-HW and MTSA-PC Analyzer Applications User Manual 5

TSCA - Getting started

Starting the T

Opening the TSCA

SCA software

The TSCA can analyze transport streams in either real time or ﬁle analysis mode.

From the Windows Desktop, select Start > Tektronix MTSA > TS Compliance Analyzer, or double click the Deferred Time Analyzers folder from your desktop to then open the TSCA – Compliance Analyzer:

6 MTSA-HW and MTSA-PC Analyzer Applications User Manual

TSCA - Getting started

The TSCA is opened, initially overlaid with either the Open File Analysis orthe Select Real time Interface dialog box as shown in the following ﬁgures. The application opens the dialog box that was last opened.

Figure 2: TSCA startup ofﬂine ﬁle analysis

MTSA-HW and MTSA-PC Analyzer Applications User Manual 7

TSCA - Getting started

Figure 3: TSCA startup real time analysis

The opening dialog boxes allow you to:

Select the interpretation standard to be used for analysis. See step 2 in the Interpreting a Stream section in this publication. You should always set the stream interpretation standard before starting analysis.

and

Identify a stream ﬁle for ofﬂine analysis. See step 1 in the Off-Line File Analysis section in this publication. Files can be selected either directly from the disk drive or using shortcuts that you have deﬁned.

Identify an input (IP, RF, ASI) receiving a stream and start real time analysis.

8 MTSA-HW and MTSA-PC Analyzer Applications User Manual

TSCA - Getting started

Interpreting a stream

You can set up th

1. Click Change in the opening dialog box to open the Standard dialog box.

NOTE. The TSC

standards deﬁned by the digital television authorities: DVB (Digital Video Broadcasting), ATSC (Advanced Television Systems Committee), and ISDB (Integrated Services Digital Broadcasting).

The TSCA software uses preloaded scripts that establish the expected content and syntax of the analyzed stream. The analyzer is supplied with a comprehensive range of scripts, which, in different combinations, can interpret the full range of digital television standards.

2. Select the Base Standards and then (if available) select the Region.The analysis scripts that will be used are displayed in the Script Files pane.

e stream interpretation standard in the following way:

A software analyzes streams in strict accordance with the

Figure 4: Stream Interpretation dialog box

MTSA-HW and MTSA-PC Analyzer Applications User Manual 9

TSCA - Getting started

3. Select OK.

4. The stream interpretation is now set. Select OK to close the Standard dialog

box and return

NOTE. The selected stream interpretation standard is not implemented until

stream analysis is started. If the Open Transport Stream dialog box is closed without starting analysis, the stream interpretation settings are lost; they revert to the settings that were in effect when the application was last closed.

to the opening dialog box. (See page 128, Script ﬁles.)

10 MTSA-HW and MTSA-PC Analyzer Applications User Manual

TSCA - Getting started

Ofﬂine ﬁle analysis

Perform the fol

1. In the Open File Analysis dialog box, browse to a transport stream ﬁle. If necessary, se two types are available: MPEG Transport Stream ﬁles and PCAP ﬁles:

MPEG transp

identiﬁers, which separate the programs and the elementary streams within the programs.

PCAP ﬁles contain raw packets of network data. A PCAP may contain

more than one session. You will need to select a session using the Browse dialog box.

2. When you select a stream, the stream name appears in the File Name ﬁeld at the bottom of the window.

lowing steps to start analyzing a transport stream ﬁle:

lect a ﬁle type from the Files of type dropdown list. Currently,

ort stream ﬁles contain interlinked tables and coded

Figure 5: TSCA Open File Analysis (Ofﬂine) dialog box

MTSA-HW and MTSA-PC Analyzer Applications User Manual 11

TSCA - Getting started

3. Calculating th

you must do one of the following:

Calculate the

the stream

NOTE. When the TSCA software analyzes a transport stream, it compares the

bit rate of the stream to the expected rate. Errors are reported based on the expected rate of the stream. To analyze a stream correctly, it is necessary to know the original bit rate of the stream or to calculate the bit rate from PCRs (Program C stable clock reference and are added to the stream during its generation. During analysis, the PCRs are extracted and synchronized with a local clock reference.

Know the original bit rate and enter it manually

Use timestamps included with the stream

e stream bit rate: To analyze a transport stream correctly,

bit rate from PCRs (Program Clock Reference) carried in

lock Reference) carried in the stream. PCRs are generated as a

12 MTSA-HW and MTSA-PC Analyzer Applications User Manual

TSCA - Getting started

4. After you selec calculating the rate of the transport stream:

Prescan ﬁrst n

stream by prescanning the stream for embedded PCRs. The entry box lists the number of PCRs that the TSCA software recommends are necessary to determine the stream rate. You can use the entry box to enter a different number.

Prescan all PCRs in a ﬁle. The TSCA software calculates the rate of the

stream by prescanning the stream for all of the embedded PCRs.

Manually set nnnn Mbps. The TSCA software uses the absolute value (in

Mbps) that you enter as the expected stream rate.

NOTE. If 'Use Arrival Timestamps' is selected, timestamps, which may have been

added wh

Using timestamps will override the PCR options ('Prescan ﬁrst nnn PCRs' and 'Presc

A manually entered bit rate will override both PCRs and timestamps in the stream.

5. If the TSCA software cannot calculate the bit rate from the embedded PCRs,

en the stream was generated, will be used, in the analysis of the stream.

an all PCR in ﬁle').

or timestamps, a message box is displayed. You must enter an estimated bit

before the TSCA software can analyze the stream.

rate

t the desired stream, select one of the following methods for

nn PCRs. The TSCA software calculates the rate of the

6. If the CaptureVu feature is to be used, the whole ﬁle can be captured or

lysis can be paused either by a previously set CaptureVu breakpoint or at a

ana speciﬁc packet.

7. To

W analysis. (See page 23, Starting analysis.)

pause analysis at a speciﬁc packet, enable Pause Analysis at Packet

Index and enter a packet number.

ith a ﬁle selected and the transport rate calculation set up, you can start the

MTSA-HW and MTSA-PC Analyzer Applications User Manual 13

TSCA - Getting started

Real time analysis

To start analyz interface, select Real time from the toolbar and, in the Select Real time Interface dialog box, select an interface from the Interfaces dropdown list.

Only installed interfaces will be shown in the dropdown list. For standalone installations, only the IP interface is available.

ing a transport stream received through an IP or a hardware (RF)

Figure 6 : TSCA Real time Interface dialog box

Real time analysis will not be available if the appropriate software key permissions

not found. A warning message is displayed when real time analysis is not

are available.

ke any necessary interface settings. Either select and apply a preset (a

Ma predeﬁned set of interface settings) or modify the individual interface settings. During analysis, the interface selected will be shown in the status bar. (See page 17, Setting up the IP interface.)

14 MTSA-HW and MTSA-PC Analyzer Applications User Manual

TSCA - Getting started

Interface car

doverview

This section describes the conﬁguration and interpretation of results of the RF and IP Video interface cards that you can install in an MTSA MPEG test system. The cards all upgrading.

The interfa

ASI: Ports 1 to 4 for input or output

SDR: RF for 8VSB, QAM A/B/C, DVB-T, or ISDB-T/Tb

DS2: RF for DVB-S or DVB-S2

10GS: Dual IP NIC for 1Gb or 10Gb Ethernet using 850 nm SFP+

Refer to the MTSA-HW and MTSA-PC Speciﬁcation and Performance Veriﬁcation Technical Reference, for the interface technical speciﬁcations.

The RF interface measurements and graphs include a constellation diagram with Input Power, MER, and BER measurements. A constellation diagram with MER rings is also available with the QAM-B and 8VSB from the SDR card. The installed interface cards can be used simultaneously with the internalNIC (Network Interface Card) input. All interfaces have dual-level warning and failure

ms, and graphs for long term trend monitoring.

alar

use a common interface protocol for data handling and ﬁrmware

ce settings described are as follows:

The input card screen and conﬁguration of the card depend on which interface

ds are installed. (See the following pages.)

car

MTSA-HW and MTSA-PC Analyzer Applications User Manual 15

TSCA - Getting started

Interface card set up

The interface c the Real time icon.

The settings c view.

ard conﬁguration is set up when analysis is started by clicking

an subsequently be changed during the analysis from the Interface

When real time analysis is selected and an interface is selected from the Interfaces dropdown list.

1. Select Real time Analysis.

2. Select the interface from the Interfaces dropdown list.

3. Ent

4. Se

The name of the selected interface is displayed in the TSCA status bar.

16 MTSA-HW and MTSA-PC Analyzer Applications User Manual

er the interface settings required for Descriptions of the settings for each

interface card. (See page 72, SDR RF interface views.)

lect OK to start the analysis.

TSCA - Getting started

Settingupthe

IP interface

Two Ethernet interfaces are standard on the network interface cards installedinan MTSA-HW system; both are 10/100/1000 Base-T.

NOTE. This p

Analyzer screen. Otherwise, you must double click the Real Time Analyzers folder on your desktop and click the “TSCA with real time capabilities” application. This action opens the MPEG TS Compliance Analyzer screen.

To set up the IP interface, you must:

1. From the MPEG TS Compliance Analyzer screen, click the Real time

2. From the Select Real Time Interface window that appears, go to the

3. Still in the Select Real time Interface window, go to the Presets ﬁeld under

rocedure assumes you have accessed the MPEG TS Compliance

button on the toolbar.

Interfaces section (located in the middle of the window) and select the IP option from the Select from the available interfaces dropdown menu.

Interface Settings , located at the left of the window, and then click the

+ (plus) sign.

MTSA-HW and MTSA-PC Analyzer Applications User Manual 17

TSCA - Getting started

Clicking the + ( the Selected Preset ﬁeld and use the Browse (button) feature.

plus) sign indicated above enables you to make a selection in

18 MTSA-HW and MTSA-PC Analyzer Applications User Manual

TSCA - Getting started

4. Click the Brows Browse for UDP ﬂow screen.

e button to browse the network for a stream and obtain the

Figure 7: ‘Browse for UDP ﬂow’ window

MTSA-HW and MTSA-PC Analyzer Applications User Manual 19

TSCA - Getting started

5. From the Browse (on the top of the window) to select your device from the dropdown.

for UDP ﬂow window that appears, click Browse Device

Figure 8: ‘Browse Device’ dropdown to select right NIC

20 MTSA-HW and MTSA-PC Analyzer Applications User Manual

TSCA - Getting started

6. From the Browse NIC in the Browse Device dropdown. Change or leave the IGMP in IGMP Group Membership ﬁeld.

for UDP ﬂow window, select the device with the right

NOTE. If you have the option 10GS installed in your system, then you will have 4

NIC in the dropdown.

MTSA-HW and MTSA-PC Analyzer Applications User Manual 21

TSCA - Getting started

7. From the Browse the UDP ﬂow listing window. Clicking the selected ﬂow andthentheOK button will copy/paste the chosen UDP ﬂow onto the Selected Preset ﬁeld in the Select Real time interface window. Note that the parameters from the selected ﬂow now show in the Selected Preset ﬁeld. Click OK to start the Real-time analysis

for UDP ﬂow window, highlight the target ﬂow from

Figure 9: ‘UDP ﬂow’ selection in ‘Browse for UDP’ ﬂow window

Figure 10: Flow information “copied/pasted” to ‘Selected Preset’ ﬁeld

22 MTSA-HW and MTSA-PC Analyzer Applications User Manual

TSCA - Getting started

Starting anal

ysis

To start the analysis, follow these steps:

1. After you have selected the ﬁle for analysis or set up the real time interface, click OK to continue.

The TSCA software starts analyzing the selected stream. During deferred analysis, a results. (See Figure 11.)

progress bar is displayed. The TSCA starts reporting analysis

Figure 11: TSCA window showing analysis progress

2. When sufﬁcient data has been gathered and the display has stabilized, you can start using the TSCA to view the analysis.

3. To restart analysis of a stream, select Analysis > Restart Analysis.

4. To analyze another stream, open the Open File Analysis dialog box or to

select another real time interface, open the Select Real time Interface dialog box.

MTSA-HW and MTSA-PC Analyzer Applications User Manual 23

TSCA - Getting started

Setting the st

ream content font

Selecting the display font

You can conﬁgure the TSCA software to display stream content information ina user-deﬁned font style or language, such as Japanese or Chinese.

NOTE. How th

dictated by the TSCA font setting and by the interpretation standard that is used during the analysis.

How the TSCA d isplays entries in the Event Log is dictated by the TSCA font setting and fonts used by a your local computer. For example, if the default language of the TSCA computer is Japanese, the event log will be displayed in Japanese characters. You must choose a suitable font for the characters to display correctly.

Perform the following steps to set the font that will be used by the TSCA software to display stream content. You can conﬁgure the TSCA software to display stream

t using any font that is installed on your computer.

conten

1. Select Settings > Conﬁguration to open the Conﬁguration dialog box.

2. Select Preferences > Font in the conﬁguration navigation tree to display the Font pane. (See Figure 12.)

e TSCA displays the text strings carried in the stream itself is

3. The dialog box lists the default font that is used by your computer for the Log Entries and Stream Content displays in the TSCA UI. Use Font Name and

tSizedropdown boxes to select a desired font style and size.

Fon

4. Click OK to accept and save any changes.

24 MTSA-HW and MTSA-PC Analyzer Applications User Manual

TSCA - Getting started

Loading a custom

extension font

Figure 12: Selecting a display font from the Conﬁguration dialog box

The ARI standard Unicode character set [0xE000-0xF8FF]. These extensions allow you to add additional characters and nonstandard proprietary characters to an existing font. The extension sets are provided as TrueType Extension ﬁles (*.tte). Any extension sets should be installed using the Private Character Editor, supplied as part of the standard MS Windows installation.

To install a font extension set on your computer:

1. Open the MS Windows Private Character Editor.

2. Af

3. Select Font Links… from the File menu.

4. In the Font Links dialog box, select Link with Selected Fonts.

NOTE. If you select Link with All Fonts, the following actions will overwrite

any existing font extension sets.

B speciﬁcations for the ISDB standards use private extensions to the

a. Select Run from the Start menu.

b. Enter eudcedit in the Run dialog box and click OK.

ter the Private Character Editor opens, close the Select Code dialog box.

MTSA-HW and MTSA-PC Analyzer Applications User Manual 25

TSCA - Getting started

5. In the Select Fo the extension. This font should be the one you selected in the TSCA font

preferences dialog box.

6. After you select the font to which you are adding the extension, click Save As.

7. In the Modif TrueType extension ﬁle that you are adding (*.tte) and click Save.

8. In the Font L

9. Close the Private Character Editor window.

10. To verify that the font extension has been successfully installed, open the

Character Map application.

a. Select Run from the Start menu.

b. Enter charmap in the Run dialog box and click OK.

11. Browse through the font list for the name of the font to which you added the

extension. The term "Private Characters" should follow the font name. When you select the font name in the list, you can view the extended character set.

12. Close the Character Map application.

The new font extension you installed should now appear as a font selection inthe Conﬁguration dialog box. You must select the new font in the Conﬁguration dialog box before the new font will be used to display stream content.

nts box, ﬁnd and highlight the font to which you are adding

y Private Character Filename dialog box, browse to the

inks dialog box, click OK.

26 MTSA-HW and MTSA-PC Analyzer Applications User Manual

TSCA – Understanding the TSCA window

TSCA – Underst

anding the TSCA window

On start up, y page 6, Starting the TSCA software.)

ou can immediately open and analyze a transport stream. (See

Figure 13: FlexVuPlus window

MTSA-HW and MTSA-PC Analyzer Applications User Manual 27

TSCA – Understanding the TSCA window

The analyzer wi the Analyzer tab is selected.

ndow as shown in the following ﬁgure will be displayed when

Figure 1

4: Analyzer window

TSCA top level displays

The TSCA has two top level tabs: FlexVu Plus and Analysis.

exVu Plus display enables the TSCA to perform like a 4-in-1 monitor on a

The Fl single incoming stream. The display allows you to select up to four concurrent views of a monitored stream and provides the ability to conﬁgure each of the four views independently. Setting up and conﬁguring the FlexVu Plus display is described in the MTSA-HW and MTSA-PC Quick Start User Manual.

The remainder of this section describes elements in the Analyzer window.

28 MTSA-HW and MTSA-PC Analyzer Applications User Manual

TSCA – Understanding the TSCA window

TSCA window co

Menu bar

Toolbar

mponents

The TSCA window contains the following components:

The Menu bar provides access to a selection of system options using dropdown menus. (See page 121, Menu bar and options.)

The buttons displayed on the toolbar provide shortcuts to often-used menu options. Additional buttons displayed during real time analysis are shownin the following table:

Table 1: Toolbar icons

Deferred and Real time Analysis

Opens the Open Transport Stream dialog box.

Restarts analysis.

User actions are recorded during a session. The forward and back buttons allow you to step through the actions in order to

w or repeat them.

revie

CaptureVu

Real time analysis

Opens the Preferences dialog box from which you can set your preferences.

View CaptureVu status.

Resume ﬁle analysis.

Stop and capture analysis.

View record setting.

Arm record feature.

Start recording.

Stop recording.

MTSA-HW and MTSA-PC Analyzer Applications User Manual 29

TSCA – Understanding the TSCA window

Progress bar

Navigation view

Detail view/panes(s)

The progress ba

r indicates the progress of processing during deferred analysis

of a stream.

To stop the analysis process, click the Stop button on the toolbar.

Theleftsidepaneinthemainwindowis the navigation view and provides the main analysis information for the transport stream in a number of forms: Programs, Tests, SI/PSI, PID, Packets and Interface. Views are selected using the tabs at the top of the pane. The background of each view is color-coded to aid identiﬁcation.

The right side pane in the main window is the detail view and provides details related to the selection made in the current navigation view. The overall view may be subdivided into one or more panes; you can access individual views in multiple pane views using tabs.

Status bar

The status bar, when not hidden, is displayed at the bottom of the main window and shows a summary of stream statistics.

Table 2: Field descriptions, from left to right

Field Description

TS Availability Indicates either that the stream bit rate has fallen below the

minimum value or that synchronization has been lost. (See page 30.) T he minimum stream bit rate is set using th stream bit rate for processing" parameter.

(See page 97, Parameter edit.)

Sync Shows the status of the MPEG sync loss test. Loss of sync

during analysis of a stream may mean that analy complete stream was not possible.

Bit rate

Packet Size

Stream Interpretation, Base Standard

Total bit rate of the transport stream. The packet value (188 or

204) is set using the Preferences feature.

(See page 103, Bit rates.)

Packets in a stream can be either 188 or 204 bytes long. This is detected automatically.

This is the set of tests that is being used to

analyze the stream.

e"Min

sisofthe

30 MTSA-HW and MTSA-PC Analyzer Applications User Manual

TSCA – Understanding the TSCA window

Table 2: Field descriptions, from left to right (cont.)

Field Description

Stream Interpretation, Region

Physical Interface The current interface for real time analysis.

Partial Reception

lity

Availabi

Processing Throttle

Indicator

System Log Status

This subset of tests modiﬁes the base standard; it may add tests or modify existing ones.

(Available only for ISDB-T streams.) This icon indicates the presence of partial reception data in the stream. The colors indicate the status as follows:

Gray:

Green:

Gray + red cross:

This icon consists of three adjacent LED indicators which show the status of the TSCA processing engine. The left indicator shows the "strained" status (whether throttling is being applied to cut down on the information being processed). The central indicator shows the "overwhelmed" status (whether the processing engine is able to cope with the amount of information in the stream even after throttling). The right indicator shows the status of the processing of SI tables even after throttling. The colors indicate the status as follows:

(See page 33, Error status LEDs.)

Green: OK

Amber:

Red: Processing is currently

White: Processor state is unknown

Gray:

Shows the status of the system log, which records system-wide events, for example, scripting errors. The color of the LED (in the body of the icon) indicates the most serious event state in the log. When the top surface of the icon is gray, it indicates that all entries in the log have been viewed. Double-click the icon to view the log.

Gray:

Amber: There are entries in the log, but none

Red: There are new entries in the log

Partial reception availability is unknown.

Partial reception data is available.

Partial reception data is not available.

Processing was strained/overwhelmed, but is currently OK

strained/overwhelmed

Test disabled

The log is empty

since the log was last viewed

MTSA-HW and MTSA-PC Analyzer Applications User Manual 31

TSCA – Understanding the TSCA window

Analyzer window - no

stream available

If you choose no the following ﬁgure. The analysis structure is present, but with no stream content.

t to select and analyze a stream, the screen will appear as shown in

Figure 1 5: Analyzer window - no ﬁle

32 MTSA-HW and MTSA-PC Analyzer Applications User Manual

Error status LEDs

TSCA – Understanding the TSCA window

Error status LEDs are used throughout the TSCA interface to represent the status of the tests applied to associated items, such as programs, tests, and PIDs.Colors used are as follows:

(Red) Error; test failed

(Yellow) Tr since last reset)

(Green) No error; test passed

(Dark Blu e

(Light Blue) Transient warning (warning not current, but has been detected since last reset) (Interface tab only)

(Gray): Test disabled

(White) Test not applicable or unknown state

(Red) PID referenced but not found in the stream

(Green) PID referenced but not found in the stream. Applicable test disabled.

ansient error (error not currently being detected but has been seen

) Warning (Interface tab only)

When an LED represents a parent node in a tree (for example, a program node is the parent of elementary stream nodes), the color represents the worst caseofall of its tests and the worst case of all of the tests represented by its child nodes.

Similarly, when an LED representing a parent node in a tree is disabled or enabled, all subsidiary (or child) nodes are also disabled or enabled to reﬂect the state of the parent node. When an LED representing a parent node is reset, all the child nodes are also reset.

E. The color scheme described here is used throughout the TSCA interface,

NOT

for example, the bit rate bars in the navigation views.

ests can be disabled and enabled as required using the context menu associated

Test management context

menu options

T with the LED icon. However, it is important to note that the extent of the action depends on the hierarchical level of the icon chosen. For example, choosing Disable from a program node context menu will disable all tests in the program group.

NOTE. In ofﬂine ﬁle analysis, if any disabled events are reenabled at the end of

analysis, the LEDs will become green. You will have to restart the analysis to see the status of the test when the test is enabled.

MTSA-HW and MTSA-PC Analyzer Applications User Manual 33

TSCA – Understanding the TSCA window

Context menus

Context menus provide an important way of navigating around the TSCA application. They are available on most displayed objects, for example, program tree nodes. T example, after failure, all tests associated with a node can be reset, by selecting the context menu option Reset All Tests. The context menu options provide both actions (for example, enable and disable a function) and quick links to associated objects in other views.

hese menus provide options relevant to the selected object. For

e 16: Context menu (example)

Figur

w context menus, right-click an object. The menus are associated with node

To vie types (for example, a PID node). Node types can be displayed in more than one view; for example, PID nodes are displayed in the Program view and the PID view. All context menus have a title bar that indicates the selected node.

34 MTSA-HW and MTSA-PC Analyzer Applications User Manual

TSCA – Using the Program view

TSCA – Using th

e Program view

The Program v tabbed pane. The navigation view initially displays the top node of the program tree, which represents the analyzed transport stream from a program perspective.

iew is displayed when the Program tab is selected in the navigation

e 17: Program view

Figur

etail view shows details of the node highlighted in the navigation view.

The d

MTSA-HW and MTSA-PC Analyzer Applications User Manual 35

TSCA – Using the Program view

Table 3: Program view tabs

With the tree ex

panded, the navigation view shows the makeup of the stream. (See Figure 17.) The stream display consists of the nodes as shown in the following ﬁgure.

Figure 18: Program view nodes

The foll

owing table shows which information is available for each node.

Tab s / Node Summary

Transport Stream

Program

Elementary Stream

----

Now Playing

Summary

/ IP Graphs

-- -

MPE Sessions

Associated

Tests

Graph Bit Rate

-- -

Graph Timing

Event Log Parameters

In DVB analysis mode, the MPE tab is always present. However, the MPE view will be populated only when MPE data is present in the stream. (See page 112, MPE views.)

Pressing the F3 key on the keyboard (or selecting Go to the next red LED in current tree from one of the shortcut menus) will highlight the next red LED in the curre

nt view. Only the lowest level nodes will be considered and highlighted in

the search since the parent nodes simply reﬂect the state of the lowest level nodes.

36 MTSA-HW and MTSA-PC Analyzer Applications User Manual

Program navigation - transport stream node

The transport stream node represents the entire transport stream in terms of the programs that it contains. The adjacent LED icon represents the status of the entire transport stream; any status error in the stream will be represented by this LED. When this node is selected, the detail view displays the transport stream summary.

TSCA – Using the Program view

The associa transport stream, allowing you to see the relative data rates of all of the programs contained within the transport. A summary of the overall stream is also displayed. The information can be displayed as either a bar chart or as a pie chart.

ted detail view provides a program-orientated overview of the

data rate of a program is the cumulative data rate of all the PIDs that are

The associated with that particular program, including PCR and ECM PIDs.

NOTE. Components can be shared between programs, so the overall data rate

of all of the programs may appear to be greater than the total data rate of the transport stream as shown in the status bar.

MTSA-HW and MTSA-PC Analyzer Applications User Manual 37

TSCA – Using the Program view

Bar chart

You can display

Each program identiﬁed in the stream is allocated one row of the table. Related information includes the overall program status (icon), the program name, program number, and the maximum, minimum and average bit rates.

In addition to the basic display, you can associate a maximum and minimum threshold value with each program in the bar chart. (See page 103, Bar charts.) For deferred analysis, where these values are set after analysis, the stream must be reanalyzed for the new values to be applied. In real time analysis, the new values will take effect immediately. The color of the bit rate bar indicatesthatthe program has stayed within the bit rate limits (green) or exceeded the limits (red).

the transport stream bar chart by selecting the bar chart icon.

Pie chart

You can display the transport stream pie chart by selecting the pie chart icon.

38 MTSA-HW and MTSA-PC Analyzer Applications User Manual

TSCA – Using the Program view

Historical multiplex graph

The pie chart vi and the legend on the right provides a list of the component programs. Each program is color-coded. The overall program status (icon), the program name and number, and the bit rate are also provided. The values given in the pie chart labels are bit rates expressed as percentages of the overall bit rate. The Null PID isshowninthisview.

The color of the bit rate labels (and the bit rate values in the legend) reﬂects the status of the bit rate measurement, for example, green indicates that the program ha has exceeded the limits.

Click and label. Double-click anywhere in the pie chart to toggle the display of all ofthe segment labels.

The his the historical multiplex graph, and the legend on the right provides a list of the component programs. Each program is color-coded. Related information given includes the overall program status, the program name and number.

torical multiplex view is divided into two panes. The left pane shows

ew is divided into two panes. The left pane shows the pie chart,

s stayed within the bit rate limits, and red indicates that the bit rate

hold one of the pie chart segments to temporarily display an information

Figure 19: Historical Multiplex Graph

The Time Period dropdown list allows you to select a range of X-axis time periods.

MTSA-HW and MTSA-PC Analyzer Applications User Manual 39

TSCA – Using the Program view

Test status panes

Event log

The lower view p

ane allows you to see a summary of the states of all the associated tests as well as the event log for the entire transport stream (an unﬁltered event log). The test tabs that are available will depend on the interpretation standard that you choose. For example, with the DVB interpretation standard, the available tabs are TR 101 209 and Other. Other interpretation standards will generate different tabs and different sets of tests. (See page 146, TSCA – SI/PSI nodes.)

When any test in the transport stream has failed (and has not been reset), youcan identify which individual tests have failed by observing the red LEDs.

You can use the shortcut menus to reset and disable tests, to set alarms, CaptureVu Breakpoints and record ﬂags, and to jump to associated tests.

The Event Log screen displays the log entries as shown in the following ﬁgure for the whole transport stream. In deferred mode, the packet generating the error report can be inspected by highlighting the error and selecting Go to packet from the shortcut menu. Similarly, in real time analysis mode, and where an event concerns a PID carrying a PCR, you can use the shortcut menu to jump to the relevant PCR graph. Deferred PCAP ﬁle analysis enables a shortcut that allows Ethernet packets to be viewed.

Figure 20: Event log

Three buttons are available in the Error Log toolbar: (See page 99, Event log.)

Table 4: Event log buttons

Icon Description

Pin log / Log is pinned

Export log

Clear log

40 MTSA-HW and MTSA-PC Analyzer Applications User Manual

TSCA – Using the Program view

MTSA-PC IP Graphs

The IP graphs, w

Packet Interarrival Time (PIT): Shows the mean interarrival time of IP packets.

PIT histogram: Shows the distribution of packet arrival intervals. The X axis contains accumulators where interval times are collected. The Y axis corresponds to number of intervals that collect in each accumulator. (PIT histogram g

Ethernet ﬂow rate: Bit rate of the Ethernet ﬂow being analyzed.

The availa Unavailable graph names will be grayed out in the selection menu.

here available, are as follows:

raphs are only available when analyzing PCAP ﬁles.)

ble graphs vary, depending on which IP interface option is being used.

NOTE. Graph management and timing graphs are described in more detail in the

mon User Interface Concepts section of this manual. (See page 83, Graph

Com management.) (See page 89, Timing graphs.)

MTSA-HW and MTSA-PC Analyzer Applications User Manual 41

TSCA – Using the Program view

MTSA-HW IP Graphs

MTSA-HW hardwa previously list with the MTSA-PC product. The additional IP measurements are shown in the MTSA-HW IP Graphs ﬁgure:

Packet Interarrival Time (PIT)

PIT Histogr

RTP Dropped Packet Rate

IP Errored Packet Rate

RTP Ou t Of Order Rate

re provides additional IP measurements beyond those

42 MTSA-HW and MTSA-PC Analyzer Applications User Manual

Program navigation - program nodes

Each of the program nodes in the transport stream represents a single program referenced within the stream. When a program node is selected in the navigation view, the detail pane displays the details of the program. The LED adjacent to the program node represents the status of its child nodes (elementary streams)and the related

tests.

TSCA – Using the Program view

The program detail view provides you with an overview of the selected program, allowing you to see the relative data rates and stream types of all of the PIDsthat are associated with the program (including PCR and ECM PIDs). If the program contains an MPEG2, H.264, H.265 (HEVC), or JPEG2000 video stream, it is

oded to produce a thumbnail picture of the content; this is updated during real

dec time analysis. Similarly, where EPG information is associated with the program, a summary (Now and Next program) is displayed. PID content is indicated using icons. (See page 80, Icons.) Bar chart and pie chart views are available.

MTSA-HW and MTSA-PC Analyzer Applications User Manual 43

TSCA – Using the Program view

VLC Media Player

PID related inf

The Thumbnails tab displays thumbnails and details of the streams for each of the programs (whe

The Program Tests tab shows tests related to the program. Similarly, the Bitrate Graphs tab d

Many tests have associated parameters; these parameters are set by the selected standard, b

The Event Log shows the errors for the highlighted test. When no tests are selected, elementary stream selected in the program tree.

The VLC Media Player is a portable multimedia player for various audio and video fo thumbnails to be played in a larger window. The media player is automatically accessed from the TSCA when you choose to view or listen to the video and audio content of program streams.

NOTE. The VLC Media Player is not installed as part of the MTSA system.

Installation of the player is described in the MTSA-HW and MTSA-PC Quick

t User Manual (Tektronix part number: 071-3661-00). You can ﬁnd full

Star documentation of VLC on the Videolan Web site, http://www.videolan.org.

ormation is available under the Summary tab.

re available). (See page 95, Thumbnail views.)

isplays the program bit rate in graph form.

ut you can modify the settings. (See page 97, Parameter edit.)

the event log will show the events related to all tests associated with the

rmats. The player allows program content displayed in the TSCA

tart the media player, click the start button (below the thumbnail) in the

To s Program Summary view.

The VLC Media Player opens and the selected program content (video and/or audio) plays. To close the player, click the stop button (below the thumbnail).

NOTE. The VLC Media Player may open behind the TSCA window. Use the

Windows controls to bring it forward.

44 MTSA-HW and MTSA-PC Analyzer Applications User Manual

TSCA – Using the Program view

Elementary stream

Program n

streams in the selected program can be examined in more detail

analysis

The elementary using the MTS4EA HEVC/AVC Video and Compressed Audio Analyzer. Select the ES icon below each thumbnail picture.

avigation - elementary stream node

Each of the elementary stream nodes in the program tree represents a single elementary stream referenced by the parent program. When this node is selected, the view

pane displays the Elementary Stream summary view.

MTSA-HW and MTSA-PC Analyzer Applications User Manual 45

TSCA – Using the Program view

When you hold th stream type and description.

An LED associated with each elementary stream node indicates the status of the tests relating to the elementary stream.

When the selected elementary stream PID contains timing information, PCR trend analysis views are also available, allowing you to display graphs of PCR accuracy and PCR interval data. When the transport stream contains timestamps data, th drift rate graphs are also available.

NOTE. Graph management and timing graphs are described in more detail in the

Common User Interface Concepts section of this manual. (See page 83, Graph management.) (See page 89, Timing graphs.)

e PCR overall jitter, PCR frequency offset, PCR arrival time, and PCR

e cursor over the elementary stream node, a tooltip provides the

46 MTSA-HW and MTSA-PC Analyzer Applications User Manual

TSCA – Using the Program view

Figure 21: PCR Graphs view

The Associated Tests tab shows tests related to the elementary stream node.

Many tests have associated parameters; these parameters are set by the selected standard, but you can modify the settings. (See page 97, Parameter edit.)

Similarly, the Event Log shows the errors for the highlighted test. When no tests are selected, the event log will show the events related to all tests associated with the elementary stream that is selected in the program tree.

MTSA-HW and MTSA-PC Analyzer Applications User Manual 47

TSCA – Using the Tests view

TSCA – Using th

eTestsview

The Tests vie being analyzed. The view is displayed when the Tests tab is selected in the Navigation tabbed pane. (See Figure 22.)

w displays test information that is relevant to the transport stream

e 22: Tests Navigation view

Figur

48 MTSA-HW and MTSA-PC Analyzer Applications User Manual

TSCA – Using the Tests view

The view displa the analyzed transport stream. The following ﬁgure shows the nodes available in the navigation view.

ys a test tree, which represents all tests that have been applied to

Figure 23: Test view nodes

MTSA-HW and MTSA-PC Analyzer Applications User Manual 49

TSCA – Using the Tests view

Test structure

The test tree st stream complying with a particular digital video standard: MPEG, DVB, ATSC, and ISDB. The standard must be selected before beginning analysis. The testtree contains nodes for each test that the analyzer can implement.

An example of a tree structure for a selected standard is the TR 101 290 group of tests for DVB transport streams. (See Figure 23.) The Group node is split into priority gr priority groups contains a number of individual tests.

ructure represents all of the tests that can be applied to a transport

oups: First Priority, Second Priority, and Third Priority. Each of these

Test grouping differs between digital video standards. However, all of the currently implemented standards contain a subset of relevant TR 101 290 tests.

e that in standards other than DVB, the tests are not numbered.

Not

Where relevant, PIDs will be associated with a test in the test tree when the test

s either been disabled, or when it has failed.

The LED associated with each node indicates the status of the node and its child

de tests. (See page 33, Error status LEDs.) Total entries in the Event Log for

no each group of tests and for each test are indicated in parenthesis; resetting a group of tests or a test restarts the count in parenthesis.

50 MTSA-HW and MTSA-PC Analyzer Applications User Manual

TSCA – Using the Tests view

Test ﬁltering

Interpreting t the top of the Tests navigation view:

Figure 24: Test ﬁltering buttons

When a button is selected, it hides a category of tests in the test tree display, as follows:

Grey - hides disabled tests

White - hides tests with unknown or not applicable status

Green - hides tests with OK status

he display of tests can be made easier using the three ﬁlter buttons at

MTSA-HW and MTSA-PC Analyzer Applications User Manual 51

TSCA – Using the Tests view

Tests navigation - all tests

The detail view when the All Tests node is selected. (See Figure 22.) In addition to a summary of all tests, the event log shows the most recent 10000 events that have occurred during analysis of the stream.

Test Failures view

Figure 25: Test Failures screen

The Test Failures view provides an overview of the tests that have failed during stream analysis. The view is divided into two panes. The left panes shows those tests that have failed in the last second. The right pane shows those tests that have failed, not including those that have failed in the last second, and are displayed on the left side.

If a test fails, it will be displayed on the left side. When it no longer fails, it will be removed from the left side and listed ontherightsideasatestthathaspreviously

iled. If the test fails again, it will be removed from the left side and redisplayed

fa on the right side until it no longer fails.

ditionally, tests that have been listed (in either pane) in the last second are

Ad displayed at the top of the list and shaded.

52 MTSA-HW and MTSA-PC Analyzer Applications User Manual

Test navigation - test nodes

When you select a test node, the Associated PIDs pane displays a summary of all of the PIDs and an event log listing all events that are associated with the test. Where parameters are applicable to the test, you can modify them under the Parameters tab.

TSCA – Using the Tests view

MTSA-HW and MTSA-PC Analyzer Applications User Manual 53

TSCA – Using the Tests view

Test navigation - PID nodes

Where tests have failed, the PIDs affected are listed under the test node in the Tests navigation view. Selecting a PID will display the Event Log in the detail view.

NOTE. The screenshot also shows the Edit Parameters dialog box, which is

available from the PID node context menu. (See page 97, Parameter edit.)

54 MTSA-HW and MTSA-PC Analyzer Applications User Manual

TSCA – Using the Tables view

TSCA – Using th

e Table s view

TheTablesvi other navigation views. The tree represents the service information tables that have occurred in the analyzed stream and which comply with the selected digital video standard. This includes MPEG program speciﬁc information, DVB service information, ATSC and ISDB program information, and system information protocol. The tree contains nodes for each table that is found; tables/nodes are grouped to Table navigation view with DVB stream interpretation selected.

ew (SI/PSI tab) displays service information in tree form, as in the

gether by functionality. The following ﬁgure shows an example of the

Figure 26: Tables view

Every node within the service informationtreehasacorrespondingsummary

ew. Nodes that represent tables will also provide you with access to the table

vi structure and hex data. (See page 57, Tables detail view - Section view.) (See page 59, Tables detail view - SI repetition graphs.)

Some of the nodes that represent less common tables or table groups may not have speciﬁc summary views available in the analyzer. In these cases, a generic summary view is used.

MTSA-HW and MTSA-PC Analyzer Applications User Manual 55

TSCA – Using the Tables view

Table summary pane

The table summary view provides a summary of the table related information for the analyzed transport stream. There is a table summary view for every node of the service information. The content is dictated by the selected node.

All summary views for nodes that represent an individual table or subtable will display the table identity and version number of the table from which the information is extracted. Where relevant, links (underlined text) are provided to associate the individual program summary views. Similarly, arrow icons provide links to the electronic program guide (EPG) tables. (See Figure 27.) Where the section is carried on a PID, a link is also provided to the PID view.

The following shows an example of the summary pane with the PMT PIDs node selected in the navigation view.

d objects, for example, in the programs summary, links are provided to

Figure 27: Tables view - Programs (example)

speciﬁc departure from the Table Summary view described previously is the

EPG views

56 MTSA-HW and MTSA-PC Analyzer Applications User Manual

A EPG view that is displayed when a section of the EPG table is highlighted. For a description of the general presentation of the EPG view. (See page 108, EPG view.)

TSCA – Using the Tables view

Tables detail

view - Section view

The detailed section view is available when the selected node in the service information tree represents a table or subtable in the transport stream. During real time analysi

The subtable identity, version, and section are displayed at the top of the table pane.

NOTE. In deferred mode, where two or more subtables, versions or sections are

found in the stream, the relevant ﬁeld is active, and an alternative selection can be made from the dropdown list.

In real time mode, only the latest version and section can be viewed.

s, the view is continually updated.

The table pane shows all ﬁelds that make up a section (for example, PMT). The ﬁelds are arranged in a hierarchical order. The presence of subordinate ﬁelds is indicated using { } bracket symbols adjacent to the container ﬁeld. The container can be expanded or collapsed by clicking the + or - icon.

MTSA-HW and MTSA-PC Analyzer Applications User Manual 57

TSCA – Using the Tables view

Below the table bytes (in both hexadecimal number format and ASCII character format) for the selected table, version, and section. When a node is selected in the table pane, the bytes that make up the selected node (including the subordinate nodes) are highlighted in the hexadecimal data pane as shown in the following ﬁgure.

pane, the data source is displayed. The data pane shows the data

Figure 28: Section payload

If the section is corrupt or empty, the hexadecimal view background is red instead

ue.

of bl

The pause button in the detail window title bar allows real time section datatobe

sed (or frozen), so that it can be examined in detail. The play button resumes

pau the real time display of section data.

58 MTSA-HW and MTSA-PC Analyzer Applications User Manual

TSCA – Using the Tables view

Tables detail

Export

SI/PSI as XML

view - SI repetition graphs

The section graph view is available when the selected node in the service information tree represents a table or subtable in the transport stream. You can view graphs o

Section repetition interval: This graph displays the interval between two sections of

Subtable intersection gap: This graph displays the interval between sections in a partic

Subtable repetition interval: This graph displays the time between receiving one compl

NOTE. Not all of the above graph types are relevant to all table types. (See

page 83, Graph management.)

The export control in the top left corner of the SI/PSI navigation pane opensthe Export SI/PSI as XML dialog box. Enter an output ﬁle name (and path) and

t the required options.

selec

f the following data:

a table on a particular PID.

ular subtable.

ete subtable and receiving the next complete subtable.

MTSA-HW and MTSA-PC Analyzer Applications User Manual 59

TSCA – Using the PID view

TSCA – Using th

ePIDview

The PID view d stream being analyzed. The navigation view contains the PID tree structure representing all of the PIDs that have occurred within the transport stream.

isplays information about all of the PIDs found in the transport

In DVB analysis mode, the MPE tab is always present. However, the MPE view will only be populated when MPE data is present in the stream. (See page 112, MPE views.)

60 MTSA-HW and MTSA-PC Analyzer Applications User Manual

PID view - all PIDs

TSCA – Using the PID view

In the navigation view, PIDs are grouped under the following subordinate nodes:

Reserved PIDs

Referenced P

Unreferenced PIDs

SI/PSI PIDs

User PIDs

Obsolete PIDs (deferred analysis only)

The number of PIDs in each group is shown adjacent to the node. The root node label shows the total number of PIDs found and the Network Name.

When highlighted, the All PIDs node displays in the detail pane all of the PIDs that are found in the analyzed stream.

Each of these subordinate nodes contains PIDs belonging to that group. PIDsare allocated during analysis, and the number of PIDs is identiﬁed for each node. You can also allocate PID numbers to the User PID node, although User PIDs may not necessarily have been found in the stream. This feature allows you to compare the properties of one or more PIDs more easily.

The associated summary view provides a PID-oriented overview of the transport stream, allowing you to see the relative data rates of all of the PIDs contained

hin the transport stream. The information can be displayed as either a bar chart,

wit or as a pie chart. Columns in the summary views can be sorted in ascending or descending order by clicking on the column header. PID related informationis available under the PID Information tab.

IDs

Each PID is associated with a number of tests. If one or more tests fail, they will be listed under the relevant PID node in the navigation view. Selecting the PID node will display a summary, in the detail view, of all associated tests thathave been found. Selecting a speciﬁc test in the Associated Tests pane will display the

vent Log and Parameters for only that test.

MTSA-HW and MTSA-PC Analyzer Applications User Manual 61

TSCA – Using the PID view

PID view - deta

il view (All PID and PID Group)

The All PID and PID Group detail view provides you with a PID-oriented overview of the transport stream. This view is displayed when any of the main nodes is Unreferenced PIDs, or User PIDs.

The view shows the relative data rates of all of the PIDs contained within the selected node. You can display the information in either a bar chart or a pie format. The associated test states are shown in all views.

selected in the navigation pane: All PIDs, Referenced PIDs,

Figure 29: PID Summary view

The PID Information view provides PID related information, for example, PID type stream type, scrambled status and the presence of PCRs. Layer information is also shown when analyzing ISDB streams. (See Figure 30.) The icons provide

indication of the PID content. (See page 80, Icons.)

Where a PID carries video or audio, thumbnails are displayed under the Now

laying tab.

62 MTSA-HW and MTSA-PC Analyzer Applications User Manual

TSCA – Using the PID view

In deferred mod carrying a PID by highlighting the PID, and selecting the Go To Packets view from the shortcut menu. The packet will be added to the PIDs list (in the Packets view).

e (or during CaptureVu analysis), you can view the packets

PID vi

Figure 30: PID Information view

ew - detail view (PIDs)

The individual PID detail view provides you with information about the selected PID. This view will be visible when you select an individual PID node in the PID t nodes of the PID.

combination and detail of the views vary depending on the selected PID

The type and node.

ring deferred or captured analysis, the packets carrying the PID can be

Du examined in more detail by highlighting a PID, and selecting the Go to Packets view from the shortcut menu.

ree. If a PID has failed a test, one or more test nodes are displayed as child

MTSA-HW and MTSA-PC Analyzer Applications User Manual 63

TSCA – Using the PID view

Ordinary PID selected

PCR PID selected

When a PID does n Associated Tests view. This view lists the tests associated with the selected PID. The status of the individual tests is indicated with LED icons. Also available are Bit rate Graphs, which show the bit rate of the selected PID in graphical form.

Also on the Associated Tests tab is an event log and a parameters pane. The event log shows all PID related events. If a test is selected in the PID pane, only the events associated with that test on that PID are shown. Similarly, when a test is selected, the Parameters pane shows the parameters associated withthat test (when

When the selected PID contains PCR information, PCR inaccuracy and PCR interval data graphs will be displayed in addition to a bit rate graph. When the transpo frequency offset, and the PCR drift rate graphs will also be available. For real time IP analysis, the Packet Interval Timing (PIT) graph is also available.(See page 92, PIT graph.)

applicable).

rt stream contains time stamped data, the PCR overall jitter, the PCR

ot contain PCRs, the main view in the PID pane is the

Presentation Time Stamp (PTS) graph may also be available on PIDs carrying

A audio and video information. And a PTS-PCR graph showing the variation between the PTS and PCR values; this can help detect buffering issues.

(See page 83, Graph management.) (See page 89, Timing graphs.)

64 MTSA-HW and MTSA-PC Analyzer Applications User Manual

TSCA – Using the Packets view

TSCA – Using th

e Packets view

NOTE. The Packets view is available only during deferred analysis and CaptureVu

analysis.

Data in the stream is carried in 188- or 204-byte packets. The Packets view allows you to examine the contents of each packet in the analyzed stream.

Thepacketnavigationviewshowsatreestructure which represents the packets

hin a stream grouped according to content, including PID value, SFN

wit mega-initialization packets (MIPs) (DVB only), and ISDB-T information packets (IIPs).

The All Packets, MIP and IIP nodes do not have any child nodes. The All Packets node represents all of the packets in the transport stream. The MIP node represents all of the DVB SFN MIPs in the transport stream. The IIP node represents all of the ISDB-T information packets in the transport stream.

The PIDs node represents all of the PIDs that are of interest. You can add PIDs in the transport stream to this node, and to PIDs that are contained within the user PID list.

MTSA-HW and MTSA-PC Analyzer Applications User Manual 65

TSCA – Using the Packets view

Packet nav

igation bar

Selecting any l packets. For example, selecting a PID node will only allow packets carrying that particular PID to be displayed in the associated summary view. Similarly, selecting the MIP node will only allow MIP information to be displayed in the associated summary view.

Double-clicking the Custom Packet Search node opens a dialog box in which you can specify strings to search for.

In the packet summary view, you can use the top bar to navigate the packets in the stream.

The pac

eaf node in the packet tree will apply a packet ﬁlter to the associated

ket position bar shows the position of the selected packet in the stream.

The navigation bar functionality depends on the selection in the packet navigation view. If you select All Packets, the controls will operate on all packets. If you select a single PID, a ﬁlter is in operation, and the controls will work only for those packets carrying that PID.

Selects the ﬁrst available packet (in the stream or carrying the selected PID)

Selects the previous available packet (in the stream or carrying the selected PID)

Selects the next available packet (in the stream or carrying the selected PID)

Selects the last available packet (in the stream or carrying the selected PID)

Opens the G o To Packet dialog box

You can also use the packet position bar to navigate through the stream. To doso, use the cursor to point to and click the next packet to be displayed. Double-click the packet number in the bar to open the Go To Packet dialog box. Enter the required packet number and select OK. For both methods, remember that the destination packet is dependent on the node selected in the navigation view.

66 MTSA-HW and MTSA-PC Analyzer Applications User Manual

TSCA – Using the Packets view

Packet naviga

tion - ﬁlter nodes

Adding a PID in the Packet

view

The packet ﬁlters allow you to view packets carrying PID.

To inspect the sequence of packets carrying a particular PID, you must add the PID to the PID Filters node in the Packet Navigation view. PIDs carrying sections can also be viewed. You can add as many PIDs as are required. There are a number of ways to add a

1. In the Packet view, expand the PIDs node by doing one of the following:

2. In the Add PID... dialog box, expand the nodes, locate and select the required

PID.

3. Click OK.

up the

ttings

The selected PID is added to the PIDs node, and the ﬁrst occurrence of a packet

ing the selected PID is displayed in the summary view.

carry

Added PIDs will be stored when the application is closed. They will be reinstated

the application is reopened. However, if a different stream is analyzed, the

when stored PIDs may not be used.

PID to the node, as described in the following paragraphs.

Double-click the child node (double-click to add a PID).

Select Add PID... from the PIDs node shortcut menu.

Removing PIDs

All PIDs previously added to the PID node can be removed by selecting Remove

l from the PIDs node shortcut menu.

MTSA-HW and MTSA-PC Analyzer Applications User Manual 67

TSCA – Using the Packets view

Packet Detail view

The detail view shows the ﬁelds and data that are contained in a packet. The ﬁelds are arranged in a hierarchical order. The presence of subordinate ﬁelds is indicated using { } bracket symbols adjacent to the container ﬁeld. To expand or collapse the container, click the + or - icon.

Below the ta bytes (in both hexadecimal number format and ASCII character format) for the selected packet. When you select a node in the table pane, the bytes that make up the selected node (including the subordinate nodes) are highlighted in the hexadecimal data pane.

ble pane, the data source is displayed. The data pane shows the data

packet transport header bytes are displayed in red. Similarly, bytes greater

The than 188 are displayed in gray. The adaptation ﬁeld, where present, is displayed in blue.

If the section is corrupted or empty, the background of the hex view is red instead of blue.

68 MTSA-HW and MTSA-PC Analyzer Applications User Manual

TSCA – Using the Packets view

ISDB streams

The following ﬁ ISDB-T stream. Note the IIP tab and the additional TMCC and IIP nodes.

gure shows an example of the packet detail view with an analyzed

31: Packet view - ISDB detail -IIP

Figure

MTSA-HW and MTSA-PC Analyzer Applications User Manual 69

TSCA – Using the Interface view

TSCA – Using th

e Interface view

If real time a displayed in the Navigation view of the TSCA window.

NOTE. The Interface view is available only if an interface card is selected for

real time analysis.

nalysis using an interface card is invoked, the Interface tab is

Figure 3 2: Interface view - example

Two interface card test nodes are displayed in the navigation view: Interface Errors and Interface Warnings. Each collection contains a range of tests. (See Figure 32.)

The detail of the interface view is different for each interface type.

70 MTSA-HW and MTSA-PC Analyzer Applications User Manual

Detail view tabs

TSCA – Using the Interface view

The detail view contains two tabs: Graphs and Interface Event Log. This section describes the tabs in general terms. The following sections describe in detail the tabs associated with each interface type.

Graphs

Interface event log

Readings and controls

The Graphs tab contains instantaneous graphs and trend graphs.

The instantaneous graphs display instantaneous measurements in graphical form. The trend graphs display trends in measurements in graphical form.

The inter

face event log displays a history of the events related to the item selected

in the navigation view.

The right panel contains Readings and Controls. The Readings area displays values received from the card itself.

The RF Lock LED conveys different types of information. If full lock onto the channel is acquired and it is receiving the signal correctly, the LED will light up green. When a signal is present but no lock is achieved, the indicator is red.When no signal is found, the indicator is gray.

In the Readings area, the LED colors are as follows:

Green On

Red

Gray Off or not applicable

Out of range or failed test

The Readings background colors are as follows:

White In range

Red

Yellow Not recently updated

Gray Not applicable; for example, out of order packets not being

Out of range; for example, too much or too little power or out of

rder packets per second being greater than zero

available when the UDP protocol is selected

The Controls area contains user controls. Values entered here will be applied to the card and will affect its performance. These controls correspond exactly with those on the Open Transport Stream dialog box.

MTSA-HW and MTSA-PC Analyzer Applications User Manual 71

TSCA – Using the Interface view

SDR RF interfa

RF interface

QAM (Annex B)

ce views

This section describes the settings and displays associated with the SDR interface cards.

The settings and displays of the SDR interface card for QAM-B: QAM (B) Interface Settings, QAM (B) Instantaneous Graphs, and QAM (B) Trend Graphs.

Figure 33: ‘SDR Interface for QAM Annex B’

72 MTSA-HW and MTSA-PC Analyzer Applications User Manual

TSCA – Using the Interface view

Editing the QAM

icon. The Select Real-time Interface window appears. Enter your desired parameters and click OK.

-B Interface Settings window. Start by selecting the Real-time

While r

unning the Real-time Interface, select Edit to change the RF parameters.

MTSA-HW and MTSA-PC Analyzer Applications User Manual 73

TSCA – Using the Interface view

The following Q

AM (Annex B) settings are available on the Transport Stream Real Time Analysis dialog box, and also in the Interface tab - Controls area: Tuner Frequency, Modulation format, and Symbol rate.

Table 5: QAM(B) Settings:

Field Description

Tuner Frequency (kHz) This value, set in kHz units, is the center frequency of the channel to

be received. Any frequency can be entered. There is no need to follow a channel plan.

Modulation Type

Symbol Rate Add or select it based on the modulation type. E.g. 64–QAM uses

QAM(B) Instantaneous graphs

Trend Graphs (minute, 10 minutes, hour, day, or week)

RF Constellation I and Q data are collected from the QAM front end and displayed as a

This drop down list allows 64 QAM or 256 QAM operation to be selected. Note that SCTE07 and ITU-Tj83 annex B specify exact symbol rates for the two modulation formats, so there is no dialog box to enter the symbol rate separately.

5,056,941; 256–QAM uses 5,360,537

conventional constellation. The samples collected are not real time, so there is some dwell (delay) before a complete constellation is displayed. The persistence of the display can be varied using the tool icon in the upper right corner of the graph.

MER (Modulation Error Ratio) calculations are performed on the constellation data according to the formulas in TR 101 290.

The trend graphs extend the principle of the instantaneous graphs by graphing measurements over longer periods.

Each graph is associated with a measurement that is also displayed in the Readings panel on the right side of the display. The measurements have status LEDs associated with them.

Individual trend graphs can be opened by making a selection from the dropdown menu of the Add graph icon.

The following trend graphs are available for the QAM B interface card:

RF Lock

MER

Pre-RS BER

Input Level

Carrier Offset

74 MTSA-HW and MTSA-PC Analyzer Applications User Manual

Tektronix MTSA-HW, MTSA-PC User manual

Specifications and Main Features

Frequently Asked Questions

User Manual
