Read This First
MTS300 MPEG Test System
Software Version 6.1
071-0666-06
www.tektronix.com
*P071066606*
071066606
Copyright © Tektronix, Inc. All rights reserved. Licensed software products are owned by Tektronix or its suppliers and
are protected by United States copyright laws and international treaty provisions.
Use, duplication, or disclosure by the Government is subject to restrictions as set forth in subparagraph (c)(1)(ii) of the
Rights in Technical Data and Computer Software clause at DFARS 252.227-7013, or subparagraphs (c)(1) and (2) of the
Commercial Computer Software -- Restricted Rights clause at FAR 52.227-19, as applicabl e.
Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supercedes
that in all previously published material. Specifications and price change privileges reserved.
Tektronix, Inc., P.O. Box 500, Beaverton, OR 97077
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
Read This First
Read This First contains release information about the Tektronix MTS300
MPEG Test System software version 6.1 and associated components. This
document is organized as follows:
H CD-ROM Directories page 2
H Demonstration License page 3
H Standard and Optional Applications page 4
H Hardware Upgrades page 5
H Software Version Numbers page 6
H New Applications and Features page 6
H Performance and Release Issues page 10
Version 6.1 of the MTS300 MPEG Test System now supports various configurations of the optional input formats. These changes are documented in the
MTS300 MPEG Test System Hardware and Software Installation Technical
Reference that is included with each MTS300 MPEG Test System and with each
hardware upgrade kit.
CAUTION. If it is necessary to reinstall the MTS300 Application software or
operating system, use only the CD that w as shipped with your MTS300 system.
Applying the software on the CD to an instrument with a different controller
board may damage the software on that instrument. (Tektronix part number
063-3650-XX has been created to support the DTI LBC8926A controller. The
previous controller, LBC8525, was supported by Tektronix disc part number
063-3325-XX.) To find out which controller is installed in your instrument,
observe the display as the system boots; the BIOS displays the version of
controller board installed.
MTS300 MPEG Test System Software Version 6.1
1
Read This First
CD-ROM Directories
The following directories are provided on the MTS300 MPEG Test System
Application Software Recovery CD-ROM supplied with your MTS300 system:
AVDelay
Manuals
PerformanceVerification
Sp6a
This directory contains audio and video elementary streams and configuration
files so that you can create transport streams that can be used to measure
audio/video delay using the Tektronix VM700 or VM700A instruments.
This directory contains user manuals for all of the MTS300 MPEG Test System
applications in Adobe Acrobat (.pdf) format. You can read and print the manuals
using Acrobat Reader, which is also supplied in this directory.
The PDF files on the CD-ROM apply to the 6.1 release of the MTS300 MPEG
Test System. To order new printed manuals, see your Tektronix representative.
This directory contains a transport stream file and utility that can be used to
verify the rate specifications of the MTS300 system, and to verify the accuracy
of transport stream recording and play back. The Readme.txt file in this directory
provides instructions for using the verification stream and utility.
This directory contains the Windows NT Service Pack 6a upgrade installation
file (sp6I386.exe). Service Pack 6a is standard on all MTS300 systems. Refer to
the MTS300 MPEG Test System Hardware and Software Installation Technical
Reference (Tektronix part number 071-0667-XX) for installation instructions.
UpgradeWizard
JRE
Tools
2
This directory contains the MTS300 upgrade program file (mts3wiz.exe).
NOTE. You must use the Upgrade Wizard program to order upgrades for your
MTS300 system.
The Java Run-Time Environment (version 1.3) is required to use the Java clients
that are included with this V6.1 release. This directory (JRE) contains the
executable file you use to install this run-time environment. The upgrade kit
includes installation instructions.
This directory contains an automated logon configuration program, which can be
used to enable, disable, or change the auto logon configuration.
MTS300 MPEG Test System Software Version 6.1
Demonstration License
Read This First
MTS300 MPEG Test Systems are manufactured with files, icons, and menu
items for all MTS300 applications that work with the installed hardware, even
though some applications may not be licensed for use with your test system.
NOTE. The Demonstration License applies to all unlicensed applications
concurrently and cannot be renewed. Be sure to try all applications of interest
within thirty days of activating the license.
To try optional applications, use the following procedure to activate the
Demonstration License, which enables all unlicensed applications for thirty days:
1. Consult the password document supplied with your MPEG Test System
product and identify the eight-digit Demonstration Password.
2. Start any unlicensed application. The License Management dialog box
opens.
3. Enter the password in the License Management dialog box and then click
OK. After you have correctly entered the password, all unlicensed or
optional applications are available for the following thirty days.
MTS300 MPEG Test System Software Version 6.1
3
Read This First
Standard and Optional Applications
Table 1 lists the standard and optional applications available with the MTS300
system. You can upgrade your existing MTS300 system with the optional
applications listed below.
Table 1: MTS300 standard and optional applications
Instrument Licensed applications
MTS300 (st andard) Master Client
MTS300 Option DA
Expert Client
Configuration Client
Stream Recorder
Stream Player
Private Syntax Interpreter
Error Injector
TMCC Expert Client
TMCC Configuration Client
1
MPEG-2 DVB/ATSC/ISDB System Analyzer (deferred time)
ATSC Table Editor
ISDB/ARIB Table Editor
DVB Channel Coder/Decoder
DVB Table Editor
Jitter Adder
Multiplexer (deferred-time)
TMCC Analyzer (deferred time)
MTS300 Option ES MPEG Audio Stream Analyzer
MPEG Video Stream Analyzer
MTS300 Option OC None
MTS300 Option OM OpenMux
MTS300 Option PS Program Stream Analyzer
MTS300 Option AC-3 Dolby Digital Audio St ream Analyzer
MTS300 Option TM TMCC Combiner
1
Option DA is the nomenclature for the Deferred-Time System Analyzer, formally
known as Option DT. The option nomenclature changed because the STRM1XX
Elementary Streams, which was included with Option DT, is no longer available.
4
MTS300 MPEG Test System Software Version 6.1
Hardware Upgrades
Read This First
You can add one of the following upgrade kits to your MTS300 system for an
additional signal-format, I/O interface:
H MTS3FLV. This kit adds two I/O ports using the SPI (LVDS parallel)
interface.
H MTS3FDE. This kit adds two I/O ports using the DHEI (GI Digicipher II)
interface.
H MTS3FSS. This kit adds two I/O ports using the SMPTE310M interface.
H MTS3FAC. This kit adds two I/O ports using the ASI/M2S interface.
NOTE. Certain interface combinations are not supported. Refer to the MTS300
MPEG Test System Hardware and Software Installation Technical Reference for
information about which interface combinations are supported.
MTS300 MPEG Test System Software Version 6.1
5
Read This First
Software Version Numbers
The version numbers for the MTS300 system applications supported by this
manual are listed in a Readme.txt file located in the following two locations:
H In the root directory of the MTS300 application CD-ROM (063-3650-XX)
H In the C:\MTS300 directory on the hard drive of the MTS300 system
To verify an application version number, select About from the Help menu of
the application.
New Applications and Features
This section describes the new application and features that were added for the
version 6.1 release of the MTS300 MPEG Test System.
One major improvement with this version 6.1 release of the MTS300 MPEG
Test System is support for ISDB-S/ARIB transport streams in addition to
existing support for MPEG-2, DVB, and ATSC standards. ARIB stands for the
Association of Radio Industries and Business. The ISDB-S/AR IB standard
defines elements (carried in table structures) for managing ARIB-compliant
transport streams. These are the ARIB structures analyzed by the MTS300
system:
H Broadcaster Information Table (BIT)
H Download Control Table (DCT)
H Download Table (DLT)
H Software Download Trigger Table (SDTT)
ISDB-S/ARIB transport streams are MPEG-2 compliant streams that conform to
the ITU-R standard for ISDB-S (Integrated Service Digital Broadcasting,
Satellite) multiplexing. An ISDB stream uses TMCC (Transmission and
Multiplexing Configuration Control) data multiplexed in the first eight bytes of
the 16 Reed-Solomon bytes of 204 byte MPEG-2 transport streams. TMCC
information is used to manage the modulation parameters of the transponders in
digital broadcast environments that include multiple broadcasters and types of
services with different transmission requirements.
MTS300 version 6.1 software adds a new Data Logging function for real-time
analysis. This new function allows you to specify which transport stream events
will be recorded into tab-delimited text files for further analysis.
6
MTS300 MPEG Test System Software Version 6.1
Read This First
Master Client
Expert Client
Configuration Client
TMCC Expert Client
You will start the new TMCC Expert and TMCC Configuration Clients from the
Port Manager Panel of the Master Client.
When analyzing in ISDB transport stream, the Expert Client will display the
ISDB specific tables BIT, DCT, DLT, and SDTT in addition to other tables
common with the MPEG-2/DVB/ATSC standards. Section analysis, rate errors,
and reports are displayed for the ISDB transport stream as with other
DVB tables.
The Configuration Client allows you to specify to which standard you are testing
an input: MPEG-2, DVB, ATSC, or ISDB.
A new Data Logging configuration panel allows you to enable or disable the
function, select the types of events that will be logged, and set the size and
time-period of the data files.
The new TMCC (Transmission and Multiplexing Configuration Control) Expert
Client is a new application included with version 6.1 of the Tektronix MTS300
MPEG Test System. This client allows you to analyze the TMCC data of an
ARIB-compliant transport stream input real time. You can also analyze an
ARIB-compliant transport stream file stored on your local disk using the TMCC
Deferred-Time Client.
The TMCC Expert client has the following characteristics:
H Indicates the presence of sync bytes (0x47 for TMCC basic streams and W1,
W2, or W3 sync bytes for TMCC data streams)
H Displays the syntax of TMC C data
H Displays Slot, TSID, TS Name, and Modulation mode information
H Displays information, warning, and error messages
H Indicates the presence of TMCC alarm and update flags in the transport
stream
H Displays the overall stream rate
H Provides access to the Stream Recorder client, enabling you to capture all or
part of a TMCC transport stream input
When you use the TMCC client to analyze local transport stream files, the
TMCC Configuration Client is automatically started, allowing you to specify the
file you need to analyze. The toolbar for the Deferred-Time Client provides
buttons with which you can navigate transitions in the TMCC data. Finally, the
stream capture buttons are replaced with buttons that you can use to save all or a
specific part of the transport stream file to a disk.
MTS300 MPEG Test System Software Version 6.1
7
Read This First
TMCC Configuration
Client
The new TMCC (Transmission Multiplexing Configuration Control) Configuration client is a new application included with this version of the Tektronix
MTS300 MPEG Test System. This client allows you to set the monitoring,
analysis, and reporting parameters of the TMCC Analysis Servers.
The TMCC Configuration client has the following characteristics:
H Configures the TMCC Analysis Servers to operate in either TMCC basic or
TMCC data stream modes
H Enables you to specify a transport stream ID to analyze using the MPEG-2
Analysis Server (only in the TMCC data stream mode)
H Sets parameters for the following TMCC probes:
H Frame size
H Super frame size
H Modulation mode and slot consistency
H TMCC syntax
H TMCC update counter (only in TMCC data stream mode)
Using these real-time applications, you can continuously monitor an input
bitstream for compliance with the MPEG-2, DVB, ATSC, and ISDB-S/ARIB
digital television standards. You can monitor an array of stream parameters to
ensure decodability, or you can concentrate on just a few parameters for closer
examination.
TMCC Combiner
8
The new TMCC Combiner is a wizard-like application that helps you configure
TMCC information that you want added to the Reed-Solomon area of 204 byte
transport stream packets. Once you specify this information, the TMCC
Combiner re-multiplexes your transport stream file with the added information,
creating a valid TMCC stream.
MTS300 MPEG Test System Software Version 6.1
Read This First
ARIB Table Editor
The MTS300 ARIB Table Editor allows you to create and change PSI and ARIB
table structures and parameters.
ARIB tables that you can edit using the ARIB Table Editor include the following:
H Broadcaster Information Table (BIT)
The BIT provides name and ID parameters and descriptions of the services
encoded in the transport stream for each broadcaster.
H Download Control Table (DCT)
The DCT provides a list of modules available in the transport stream for
download.
H Download Table (DLT)
The DLT is used to download code to set top boxes.
H Software Download Trigger Table (SDTT)
The SDTT is used to define the service, group, and schedule for items
encoded in the transport stream that can be downloaded.
Deferred-Time System
Analyzer
Deferred-Time TMCC
Analyzer
The Deferred-Time System Analyzer supports ISDB-S/ARIB transport streams.
The ISDB specific tables BIT, DCT, DLT, and SDTT are handled in the same
manner as other tables common with the MPEG-2/DVB/ATSC standards.
The TMCC (Transmission and Multiplexing Configuration Control) DeferredTime Analyzer application allows you analyze the TMCC data of an ISDB-S/
ARIB-compliant transport stream stored on your local disk. The TMCC
Deferred-Time Analyzer has the following characteristics:
H Indicates the presence of sync bytes (0x47 for TMCC basic streams and W1,
W2, or W3 sync bytes for TMCC data streams)
H Displays the syntax of TMC C data
H Displays Slot, TSID, TS Name, and Modulation mode information
H Displays information, warning, and error messages
H Indicates the presence of TMCC alarm and update flags in the transport
stream
H Displays the overall stream rate
MTS300 MPEG Test System Software Version 6.1
9
Read This First
Performance and Release Issues
This section describes known issues at the time of the MTS300 MPEG Test
System release.
Thomcast Name Change
Real-Time Analysis
Thomcast, Inc. has changed its name to Thales, Inc. The software was completed
before the name change was announced. Some of the opening screens for the
different applications still refer to Thomcast, Inc.
Configuration Profiles (Reference CSEdb19930). To save, load (restore), or delete
Real-Time Analysis configuration profiles, you must be logged in to Windows
NT as a user that is a member of either the Administrators user group or the
Backup Operators user group. To restore or delete a profile, you must be logged
in as the user who saved the profile.
The default user in the standard MTS300 system configuration, MTS300,isa
member of the Backup Operators group. To add a user or change the group
memberships of a user, log in as the administrator (password = MPEG2)and
select the User Manager application from the Windows NT Start/Programs/Administrative Tools (common) subdirectory. Refer to the Windows NT documentation for additional information about the User Manager application.
PID Bit Rate Limitation. Each PID of the stream is limited to a bit rate of
98 566 144 bits/s. The bit rates of any PID with bit rates over this limit will be
reported by subtracting 98 566 144 bits/s from the actual value. Therefore, a Null
packet rate of 150 Mbps is reported in the Expert client as 51 433 856 bits/s.
Deferred-Time System
10
Analyzer
Analysis of Large Files (Reference N/A). While analyzing large transport stream
files, the analyzer can appear to be busy with no indication of progress; in
addition, the message window can obscure the “Press Escape to abort” reminder.
Analysis of large transport stream files can take many minutes; press
suspend or abort most MPEG-2 S ystem Analyzer operations.
Fonts (Reference CSEdb03373). When displaying a large font, some characters are
displayed badly (or not at all) in the packet views. Use a smaller font.
MTS300 MPEG Test System Software Version 6.1
ESC to
Read This First
Buffer Overflow using Dynamic Analysis (Reference CSEdb17277). Streams
generated with the MPEG Test System Multiplexer application can cause buffer
overflow during Dynamic Analysis with the MPEG-2 System Analyzer. This can
occur because the Dynamic Analysis algorithm uses the “Leak method” to
transfer video elementary stream data from the main buffer (MBn)tothe
elementary stream buffer (EBn); therefore, buffer overflow can occur when
analyzing streams, such as those created with the Multiplexer application, that
require “VBV delay method” data transfer.
Refer to ISO/IEC 13818-1 for additional information about leak method and
VBV delay method buffering.
Timing Analysis using the System Analyzer (Reference N/A). When using the
System Analyzer to examine a partial, filtered transport stream captured with the
Expert and/or Configuration Clients, timing analysis is not advised for the
following reasons:
H The System Analyzer cannot compute the bit rate if the first PMT declared
in the PAT has no PCR information, which occurs when the corresponding
PID has been filtered by the Expert Client.
H Even if you input the correct overall bit rate, all information related to timing
(PCR, PTS/DTS, section rates, and dynamic analyses) can be incorrect
because the time distribution of the packets repartition is lost when filtered
data is captured. PCRs, for example, will be incorrect because they are
computed at the source on the complete stream, not on a filtered part of it.
If you intend to perform in-depth timing analysis of a captured stream, always
select No PID filtered on the Data Storage Configuration tab of the Configuration Client Settings window.
M-TMCC Transport Streams. F or M-TMCC transport streams compliant with the
ISDB-S/ARIB standard, the Deferred-Time System Analyzer is not able to
determine the rate of the transport stream. Use the Deferred-Time TMCC
Analyzer to determine the rate of the transport stream, and then enter the
observed rate in the Analysis/Multiplex Characteristics/Rate dialog before
performing other timing-related analysis.
AC-3 Audio in ATSC Mode. In ATSC analysis mode, if the first AC-3 audio packet
appears more than 3000 packets from the beginning of a transport stream file,
the Deferred-Time System Analyzer is not able to recognize the AC-3 elementary stream correctly. The reason is that the PMT itself cannot determine the
elementary stream type from the ATSC standard. The Deferred-Time System
Analyzer must look into the actual packets containing the AC-3 audio to
recognize the AC-3 audio, but the searching is limited to only the first
3000 packets.
MTS300 MPEG Test System Software Version 6.1
11
Read This First
Analysis Server
Open Mux Server
Stream Player
SPI (LVDS) Interface Input
Some MPEG2 and ATSC compliant transport streams use packets with PID 16
to carry video elementary streams. Do not try to analyze transport streams with
video in packets with PID 16 while in the DVB mode. In the DVB mode, the
analysis server expects packets with PID 16 to be NIT sections, complying with
the DVB standard.
In ATSC mode, when the configuration is one PSI/ATSC input and one ES
video only input, the video descriptor and smoothing descriptor may be missing.
The Stream Player is not able to determine the rate of M-TMCC transport
streams. To work around this problem, you can use the Deferred-Time TMCC
Analyzer to determine the rate of the transport stream, and then enter the
observed rate into the Stream Player before you play back the transport stream.
The SPI (LVDS) input (Option LV or MTS3FLV) does not support the use of the
Data Valid signal. If you need to use this signal, the Data Valid signal can be
enabled by performing the work-around procedure described in the DValid.doc
file on the MTS300 Application Software CD-ROM in the Tools directory.
However, this work-around setup will be lost when the instrument is rebooted.
You will have to perform the work-around procedure each time you reboot the
instrument.
Rackmount Installation Kit
ATSC Corrigendum
The kit instructions included with the rackmount kit for the MTS300 system
indicates that the kit is for RFA300 instruments. The rackmount kit is correct for
all instruments using the mainframe common to a number of Tektronix instruments, including the MTM300, RFA300, and PQM300.
The MTS300 system is compliant to the Corrigendum for Program and System
Information Protocol for Terrestrial Broadcast and Cable (A65). The corrigendum is an amendment to the A65 standard that replaces the 2-bit zero field
taking the value 00 with the reserved field taking the value 11 in all P SIP tables.
Disregard syntax errors reported in the Expert client related to this field because
the transport stream being analyzed may not be compliant to the corrigendum.
12
MTS300 MPEG Test System Software Version 6.1
Loading...
