Tektronix MSO44, MSO46 Performance Verification

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification

Technical Reference

Warning: The servicing instructions are for use by qualified personnel only. To avoid personal injury, do not perform any servicing unless you are qualified

to do so. Refer to all safety summaries prior to performing service.

*P077154603*

077-1546-03

Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries or suppliers, and are protected by national copyright laws and international treaty provisions. Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supersedes that in all previously published material. Specifications and price change privileges reserved.

TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.

Contacting Tektronix

Tektronix, Inc.

14150 SW Karl Braun Drive

P.O. Box 500

Beaverton, OR 97077

USA

For product information, sales, service, and technical support:

• In North America, call 1-800-833-9200.

• Worldwide, visit www.tek.com to find contacts in your area.

Table of Contents

List of Figures................................................................................................................................................................................5

List of Tables................................................................................................................................................................................. 6

Important safety information..........................................................................................................................................................7

General safety summary........................................................................................................................................................7

To avoid fire or personal injury........................................................................................................................................7

Probes and test leads..................................................................................................................................................... 9

Service safety summary.........................................................................................................................................................9

Terms in this manual............................................................................................................................................................ 10

Terms on the product........................................................................................................................................................... 10

Symbols on the product....................................................................................................................................................... 10

Specifications.............................................................................................................................................................................. 11

Analog channel input and vertical specification....................................................................................................................11

Trigger system..................................................................................................................................................................... 20

Serial Trigger specifications.................................................................................................................................................23

Digital acquisition system.....................................................................................................................................................23

Digital volt meter (DVM).......................................................................................................................................................23

Trigger frequency counter....................................................................................................................................................24

Arbitrary Function Generator system................................................................................................................................... 24

Display system.....................................................................................................................................................................26

Processor system................................................................................................................................................................ 26

Data storage specifications..................................................................................................................................................28

Power supply system........................................................................................................................................................... 28

Safety characteristics...........................................................................................................................................................28

Mechanical specifications.................................................................................................................................................... 29

Performance verification procedures.......................................................................................................................................... 30

Test records......................................................................................................................................................................... 30

Instrument information, self test record.........................................................................................................................30

Input Impedance test record......................................................................................................................................... 31

DC Gain Accuracy test record...................................................................................................................................... 31

DC Offset Accuracy test record.................................................................................................................................... 34

Analog Bandwidth test record.......................................................................................................................................40

Random Noise High Res acquisition mode test record................................................................................................ 60

Long term sample rate through AFG DC offset accuracy test records......................................................................... 68

Performance tests................................................................................................................................................................76

Prerequisites........................................................................................................................................................................ 76

Self test................................................................................................................................................................................ 77

Check input impedance....................................................................................................................................................... 77

Check DC gain accuracy..................................................................................................................................................... 78

Check DC offset accuracy....................................................................................................................................................81

Check analog bandwidth......................................................................................................................................................82

Check random noise ........................................................................................................................................................... 84

Check long term sample rate............................................................................................................................................... 85

Check digital threshold accuracy......................................................................................................................................... 86

Check AUX Out output voltage levels..................................................................................................................................88

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 3

Table of Contents

Check DVM voltage accuracy (DC)..................................................................................................................................... 89

Check DVM voltage accuracy (AC)..................................................................................................................................... 90

Check trigger frequency accuracy and maximum input frequency...................................................................................... 91

Arbitrary function generator................................................................................................................................................. 91

Check AFG sine and ramp frequency accuracy........................................................................................................... 91

Check AFG square and pulse frequency accuracy.......................................................................................................92

Check AFG signal amplitude accuracy.........................................................................................................................93

Check AFG DC offset accuracy....................................................................................................................................95

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 4

List of Figures

Figure 1: Frequency/period test.................................................................................................................................................. 92

Figure 2: Frequency/period test.................................................................................................................................................. 93

Figure 3: 50 Ω terminator accuracy.............................................................................................................................................94

Figure 4: Amplitude test.............................................................................................................................................................. 94

Figure 5: 50 Ω terminator accuracy.............................................................................................................................................95

Figure 6: DC offset tests..............................................................................................................................................................96

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 5

List of Tables

Table 1: Expected gain worksheet.............................................................................................................................................. 80

Table 2: CF (Calibration Factor) = 1.414 × ((50 / Measurement Ω) + 1).....................................................................................94

Table 3: CF (Calibration Factor) = 0.5 × (( 50 / Measurement Ω) + 1)........................................................................................95

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 6

Important safety information

This manual contains information and warnings that must be followed by the user for safe operation and to keep the product in a safe condition.

To safely perform service on this product, see the Service safety summary that follows the General safety summary.

General safety summary

Use the product only as specified. Review the following safety precautions to avoid injury and prevent damage to this product or any products connected to it. Carefully read all instructions. Retain these instructions for future reference.

This product shall be used in accordance with local and national codes.

For correct and safe operation of the product, it is essential that you follow generally accepted safety procedures in addition to the safety precautions specified in this manual.

The product is designed to be used by trained personnel only.

Only qualified personnel who are aware of the hazards involved should remove the cover for repair, maintenance, or adjustment.

Before use, always check the product with a known source to be sure it is operating correctly.

This product is not intended for detection of hazardous voltages.

Use personal protective equipment to prevent shock and arc blast injury where hazardous live conductors are exposed.

While using this product, you may need to access other parts of a larger system. Read the safety sections of the other component manuals for warnings and cautions related to operating the system.

When incorporating this equipment into a system, the safety of that system is the responsibility of the assembler of the system.

To avoid fire or personal injury

Use proper power cord.

Use only the power cord specified for this product and certified for the country of use. Do not use the provided power cord for other products.

Ground the product.

This product is grounded through the grounding conductor of the power cord. To avoid electric shock, the grounding conductor must be connected to earth ground. Before making connections to the input or output terminals of the product, ensure that the product is properly grounded. Do not disable the power cord grounding connection.

Power disconnect.

The power cord disconnects the product from the power source. See instructions for the location. Do not position the equipment so that it is difficult to operate the power cord; it must remain accessible to the user at all times to allow for quick disconnection if needed.

Connect and disconnect properly.

Do not connect or disconnect probes or test leads while they are connected to a voltage source.

Use only insulated voltage probes, test leads, and adapters supplied with the product, or indicated by Tektronix to be suitable for the product.

Observe all terminal ratings.

To avoid fire or shock hazard, observe all rating and markings on the product. Consult the product manual for further ratings information before making connections to the product.

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 7

Important safety information

Do not exceed the Measurement Category (CAT) rating and voltage or current rating of the lowest rated individual component of a product, probe, or accessory. Use caution when using 1:1 test leads because the probe tip voltage is directly transmitted to the product.

Do not apply a potential to any terminal, including the common terminal, that exceeds the maximum rating of that terminal.

Do not float the common terminal above the rated voltage for that terminal.

The measurement terminals on this product are not rated for connection to Category III or IV circuits.

Do not operate without covers.

Do not operate this product with covers or panels removed, or with the case open. Hazardous voltage exposure is possible.

Avoid exposed circuitry.

Do not touch exposed connections and components when power is present.

Do not operate with suspected failures.

If you suspect that there is damage to this product, have it inspected by qualified service personnel.

Disable the product if it is damaged. Do not use the product if it is damaged or operates incorrectly. If in doubt about safety of the product, turn it off and disconnect the power cord. Clearly mark the product to prevent its further operation.

Before use, inspect voltage probes, test leads, and accessories for mechanical damage and replace when damaged. Do not use probes or test leads if they are damaged, if there is exposed metal, or if a wear indicator shows.

Examine the exterior of the product before you use it. Look for cracks or missing pieces.

Use only specified replacement parts.

Do not operate in wet/damp conditions.

Be aware that condensation may occur if a unit is moved from a cold to a warm environment.

Do not operate in an explosive atmosphere.

Keep product surfaces clean and dry.

Remove the input signals before you clean the product.

Provide proper ventilation.

Refer to the installation instructions in the manual for details on installing the product so it has proper ventilation.

Slots and openings are provided for ventilation and should never be covered or otherwise obstructed. Do not push objects into any of the openings.

Provide a safe working environment

Always place the product in a location convenient for viewing the display and indicators.

Avoid improper or prolonged use of keyboards, pointers, and button pads. Improper or prolonged keyboard or pointer use may result in serious injury.

Be sure your work area meets applicable ergonomic standards. Consult with an ergonomics professional to avoid stress injuries.

Use care when lifting and carrying the product. This product is provided with a handle or handles for lifting and carrying.

Warning:

product.

Warning: The product is heavy. Use a two-person lift or a mechanical aid.

Use only the Tektronix rackmount hardware specified for this product.

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 8

The product is heavy. To reduce the risk of personal injury or damage to the device get help when lifting or carrying the

Important safety information

Probes and test leads

Before connecting probes or test leads, connect the power cord from the power connector to a properly grounded power outlet.

Keep fingers behind the protective barrier, protective finger guard, or tactile indicator on the probes. Remove all probes, test leads and accessories that are not in use.

Use only correct Measurement Category (CAT), voltage, temperature, altitude, and amperage rated probes, test leads, and adapters for any measurement.

Beware of high voltages.

Understand the voltage ratings for the probe you are using and do not exceed those ratings. Two ratings are important to know and understand:

• The maximum measurement voltage from the probe tip to the probe reference lead.

• The maximum floating voltage from the probe reference lead to earth ground.

These two voltage ratings depend on the probe and your application. Refer to the Specifications section of the manual for more information.

Warning: To prevent electrical shock, do not exceed the maximum measurement or maximum floating voltage for the oscilloscope input BNC connector, probe tip, or probe reference lead.

Connect and disconnect properly.

Connect the probe output to the measurement product before connecting the probe to the circuit under test. Connect the probe reference lead to the circuit under test before connecting the probe input. Disconnect the probe input and the probe reference lead from the circuit under test before disconnecting the probe from the measurement product.

De-energize the circuit under test before connecting or disconnecting the current probe.

Connect the probe reference lead to earth ground only.

Do not connect a current probe to any wire that carries voltages or frequencies above the current probe voltage rating.

Inspect the probe and accessories.

Before each use, inspect probe and accessories for damage (cuts, tears, or defects in the probe body, accessories, or cable jacket). Do not use if damaged.

Ground-referenced oscilloscope use.

Do not float the reference lead of this probe when using with ground-referenced oscilloscopes. The reference lead must be connected to earth potential (0 V).

Floating measurement use.

Do not float the reference lead of this probe above the rated float voltage.

Service safety summary

The Service safety summary section contains additional information required to safely perform service on the product. Only qualified personnel should perform service procedures. Read this Service safety summary and the General safety summary before performing any service procedures.

To avoid electric shock.

Do not touch exposed connections.

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 9

Important safety information

Do not service alone.

Do not perform internal service or adjustments of this product unless another person capable of rendering first aid and resuscitation is present.

Disconnect power.

To avoid electric shock, switch off the product power and disconnect the power cord from the mains power before removing any covers or panels, or opening the case for servicing.

Use care when servicing with power on.

Dangerous voltages or currents may exist in this product. Disconnect power, remove battery (if applicable), and disconnect test leads before removing protective panels, soldering, or replacing components.

Verify safety after repair.

Always recheck ground continuity and mains dielectric strength after performing a repair.

Terms in this manual

These terms may appear in this manual:

Warning: Warning statements identify conditions or practices that could result in injury or loss of life.

CAUTION: Caution statements identify conditions or practices that could result in damage to this product or other property.

Terms on the product

These terms may appear on the product:

• DANGER indicates an injury hazard immediately accessible as you read the marking.

• WARNING indicates an injury hazard not immediately accessible as you read the marking.

• CAUTION indicates a hazard to property including the product.

Symbols on the product

When this symbol is marked on the product, be sure to consult the manual to find out the nature of the potential hazards and any actions which have to be taken to avoid them. (This symbol may also be used to refer the user to ratings in the manual.)

The following symbols(s) may appear on the product.

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 10

Specifications

This chapter contains specifications for the instrument. All specifications are guaranteed unless noted as "typical." Typical specifications are provided for your convenience but are not guaranteed. Specifications that are marked with the symbol are checked in Performance Verification.

All specifications apply to all models unless noted otherwise. To meet specifications, two conditions must first be met:

• The instrument must have been operating continuously for twenty minutes within the specified operating temperature range.

• You must perform the Signal Path Compensation (SPC) operation described in the Self test on page 77 procedure in Performance Verification section. If the operating temperature changes by more than 10 °C (18 °F), you must perform the SPC operation again.

Analog channel input and vertical specification

Number of input channels MSO44: 4 BNC

MSO46: 6 BNC

Input coupling DC, AC

Input resistance selection 1 MΩ or 50 Ω

✓Input impedance 1 MΩ DC coupled 1 MΩ ±1%

Input capacitance 1 MΩ DC coupled, typical

✓Input impedance 50 Ω, DC coupled 50 Ω ±1% (VSWR ≤1.5:1, typical)

Maximum input voltage, 1 MΩ 300 V

Maximum input voltage, 50 Ohm 5 V

Number of digitized bits 8 bits at 6.25 GS/s

13 pF ±1.5 pF

at the BNC

RMS

Derate at 20 dB/decade between 4.5 MHz and 45 MHz; derate 14 dB/decade between 45 MHz and 450 MHz. Above 450 MHz, 5.5 V

Maximum peak input voltage at the BNC: ±425 V

, with peaks ≤ ±20 V (DF ≤6.25%)

RMS

12 bits at 3.125 GS/s

13 bits at 1.25 GS/s

14 bits at 625 MS/s

15 bits at 312.5 MS/s

16 bits at 125 MS/s

Displayed vertically with 25 digitization levels (DL 1) per division, (8-bits only) 10.24 divisions dynamic range.

RMS

Sensitivity range, coarse

1 MΩ 500 µV/div to 10 V/div in a 1-2-5 sequence

DL is the abbreviation for digitization level. A DL is the smallest voltage level change that can be resolved by an 8-bit A-D Converter. This value is also known as an LSB (least significant bit).

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 11

50 Ω 500 µV/div to 1 V/div in a 1-2-5 sequence

Note: 500 μV/div is a 2X digital zoom of 1 mV/div or a 4x digital zoom of 2 mV/div, depending on the instrument bandwidth configuration

Sensitivity range, fine

Allows continuous adjustment from 1 mV/div to 10 V/div, 1 MΩ and from 1 mV/div to 1 V/div, 50 Ω

1 MΩ 500 µV/div to 10 V/div

50 Ω 500 µV/div to 1 V/div

Sensitivity resolution, fine ≤1% of current setting

✓ DC gain accuracy

Step Gain, 50 Ω ±1.0%, (±2.5% at 1 mV/div and 500 µV/div settings), de-rated at 0.100%/ °C above 30 °C

Step Gain, 1 MΩ ±1.0%, (±2.0% at 1 mV/div and 500 µV/div settings), de-rated at 0.100%/ °C above 30 °C

Variable gain ±1.5%, derated at 0.100%/ °C above 30 °C.

Note: 500 μV/div is a 2X digital zoom of 1 mV/div or a 4x digital zoom of 2 mV/div, depending on the instrument bandwidth

configuration. As such, it is guaranteed by testing the nonzoomed setting.

Offset ranges, maximum Input signal cannot exceed maximum input voltage for the 50 Ω input path.

Specifications

Volts/div Setting Maximum offset range, 50 Ω Input

500 µV/div - 99 mV/div ±1 V

100 mV/div - 1 V/div ±10 V

Volts/div Setting Maximum offset range, 1 MΩ Input

500 µV/div - 63 mV/div ±1 V

64 mV/div - 999 mV/div

1 V/div - 10 V/div ±100 V

Note: 500 μV/div is a 2X digital zoom of 1 mV/div or a 4x digital zoom of 2 mV/div, depending on the instrument bandwidth configuration. As such, it is guaranteed by testing the nonzoomed setting.

Position range ±5 divisions

Offset accuracy ±(0.005 X | offset - position | + 0.2 div (0.4 div in 500 μV/div))

Number of waveforms for average acquisition mode

DC voltage measurement accuracy, Average acquisition mode

2 to 10,240 Waveforms, default 16 waveforms

Measurement Type DC Accuracy (In Volts)

Average of ≥ 16 waveforms ±((DC Gain Accuracy) * |reading - (offset -

Table continued…

±10 V

position)| + Offset Accuracy + 0.1 * V/div setting)

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 12

Measurement Type DC Accuracy (In Volts)

Delta volts between any two averages of ≥ 16 waveforms acquired with the same oscilloscope setup and ambient conditions

±(DC Gain Accuracy * |reading| + 0.05 div)

Specifications

DC voltage measurement accuracy, sample acquisition mode, typical

Bandwidth selections 50 Ω: 20 MHz, 250 MHz, and the full bandwidth value of your model

✓Analog bandwidth 50 Ω DC coupled

1.5 GHz models

1 GHz models

Measurement Type DC Accuracy (In Volts)

Any Sample ±(DC Gain Accuracy * |reading - (offset -

position)| + Offset Accuracy + 0.15 div + 0.6 mV)

Delta Volts between any two samples acquired with the same scope setup and ambient conditions

1 MΩ: 20 MHz, 250 MHz, 500 MHz

Volts/Div Setting Bandwidth

1 mV/div - 1 V/div DC - 1.50 GHz

500 µV/div - 995 µV/div DC - 250 MHz

Volts/Div Setting Bandwidth

1 mV/div - 1 V/div DC - 1.00 GHz

500 µV/div - 995 µV/div DC - 250 MHz

±(DC Gain Accuracy * |reading| + 0.15 div +

1.2 mV)

500 MHz models

350 MHz models

200 MHz models

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 13

Volts/Div Setting Bandwidth

1 mV/div - 1 V/div DC - 500 MHz

500 µV/div - 995 µV/div DC - 250 MHz

Volts/Div Setting Bandwidth

1 mV/div - 1 V/div DC - 350 MHz

500 µV/div - 995 µV/div DC - 250 MHz

Volts/Div Setting Bandwidth

1 mV/div - 1 V/div DC - 200 MHz

500 µV/div - 995 µV/div DC - 200 MHz

Analog bandwidth, 1 MΩ, typical

Specifications

All model bandwidths except 350 MHz, 200 MHz

350 MHz models

200 MHz models

Analog bandwidth with TPP0500, TPP1000 and TPP0250 probes, typical

The limits stated above are for ambient temperature of ≤30 °C and the bandwidth selection set to FULL. Reduce the upper bandwidth frequency by 1% for each °C above 30 °C.

Volts/Div Setting Bandwidth

1 mV/div - 10 V/div DC - 500 MHz

500 µV/div - 995 µV/div DC - 250 MHz

Volts/Div Setting Bandwidth

1 mV/div - 10 V/div DC - 350 MHz

500 µV/div - 995 µV/div DC - 250 MHz

Volts/Div Setting Bandwidth

1 mV/div - 10 V/div DC - 200 MHz

500 µV/div - 995 µV/div DC - 200 MHz

The limits are for ambient temperature of ≤30 °C and the bandwidth selection set to FULL. Reduce the upper bandwidth frequency by 1% for each °C above 30 °C.

Instrument Volts/Div Setting Bandwidth

1.5 GHz, 1 GHz 5 mV/div - 100 V/div DC - 1 GHz (TPP1000 Probe)

500 MHz 5 mV/div - 100 V/div DC - 500 MHz (TPP0500

Probe)

350 MHz 5 mV/div - 100 V/div DC - 350 MHz (TPP0500

Probe)

200 MHz 5 mV/div - 100 V/div DC - 200 MHz (TPP0250

Probe)

Lower frequency limit, AC coupled, typical

Upper frequency limit, 250 MHz bandwidth limited, typical

Upper frequency limit, 20 MHz bandwidth limited, typical

Calculated rise time, typical

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 14

<10 Hz when AC 1 MΩ coupled. The AC coupled lower frequency limits are reduced by a factor of 10 (<1 Hz) when 10X passive probes are used.

250 MHz, ± 25%

20 MHz, ± 25 %

Model 50 Ω TP1000 Probe TPP0500 Probe TPP0250 Probe

500 µV-1 V 5 mV-10 V 5 mV-10 V 5 mV-10 V

1.5 GHz 333ps 450ps 900ps 1.8ns

1 GHz 450ps 450ps 900ps 1.8ns

Table continued…

Specifications

Model 50 Ω TP1000 Probe TPP0500 Probe TPP0250 Probe

500 µV-1 V 5 mV-10 V 5 mV-10 V 5 mV-10 V

500 MHz 900ps 900ps 900ps 1.8ns

350 MHz 1.3ns 1.3ns 1.3ns 1.8ns

200 MHz 2.3ns 2.3ns 2.3ns 2.3ns

Peak Detect or Envelope mode pulse response, typical

Effective bits (ENOB), typical

Typical effective bits for a 9-division p-p sine-wave input, 50 mV/div, 50-ohm

Sample mode, 50 Ω, 50 mV/div

Minimum pulse width is >640 ps (6.25 GS/s)

Bandwidth Input frequency ENOB at 6.25 GS/s

1.5 GHz 10 MHz 6.80

1.5 GHz 300 MHz 6.80

1 GHz 10 MHz 7.10

1 GHz 300 MHz 7.10

500 MHz 10 MHz 7.40

500 MHz 150 MHz 7.40

350 MHz 10 MHz 7.60

350 MHz 100 MHz 7.60

250 MHz 10 MHz 7.60

250 MHz 100 MHz 7.60

200 MHz 10 MHz 7.60

200 MHz 100 MHz 7.60

20 MHz 10 MHz 7.70

High Res mode, 50 Ω, 50 mV/div

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 15

Bandwidth Input frequency ENOB at 6.25 GS/s

1.5 GHz 10 MHz 7.10

1.5 GHz 300 MHz 7.10

1 GHz 10 MHz 7.60

1 GHz 300 MHz 7.60

500 MHz 10 MHz 7.90

500 MHz 150 MHz 7.90

350 MHz 10 MHz 8.20

350 MHz 100 MHz 8.20

250 MHz 10 MHz 8.20

250 MHz 100 MHz 8.20

Table continued…

Bandwidth Input frequency ENOB at 6.25 GS/s

200 MHz 10 MHz 8.20

200 MHz 100 MHz 8.20

20 MHz 10 MHz 8.90

Random noise, Sample and High Res Acquisition modes, 50 Ω and 1 MΩ, 6.25 Gs/s

Specifications

✓1.5 GHz models, Sample mode (RMS), 50 Ω

All models, Sample mode (RMS), 50 Ω, typical

V/div 1.5 GHz

1 mV/div 635 μV

2 mV/div 635 μV

5 mV/div 817 μV

10 mV/div 843 μV

20 mV/div 920 μV

50 mV/div 1.582 mV

100 mV/div 3.686 mV

1 V/div 23.753 mV

V/div 1.5 GHz 1 GHz 500 MHz 350 MHz 250/200

MHz

1 mV/div 490 μV 300 μV 220 μV 145 μV 120 μV 80 μV

2 mV/div 490 μV 350 μV 220 μV 150 μV 130 μV 80 μV

5 mV/div 630 μV 380 μV 230 μV 175 μV 160 μV 110 μV

10 mV/div 650 μV 400 μV 280 μV 220 μV 215 μV 155 μV

20 mV/div 710 μV 510 μV 410 μV 340 μV 340 μV 260 μV

50 mV/div 1.220 mV 980 μV 890 μV 760 μV 760 μV 630 μV

100 mV/div 2.84 mV 2.23 mV 1.93 mV 1.61 mV 1.61 mV 1.25 mV

1 V/div 18.3 mV 19.0 mV 17.3 mV 15.0 mV 15.0 mV 12.5 mV

20 MHz

✓All models except 1.5 GHz, High Res mode (RMS), 50 Ω

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 16

V/div 1 GHz 500 MHz 350 MHz 250/200 MHz 20 MHz

1 mV/div 336 μV 259 μV 194 μV 161 μV 96 μV

2 mV/div 363 μV 259 μV 194 μV 161 μV 96 μV

Table continued…

Specifications

V/div 1 GHz 500 MHz 350 MHz 250/200 MHz 20 MHz

5 mV/div 394 μV 304 μV 239 μV 174 μV 96 μV

10 mV/div 434 μV 356 μV 284 μV 206 μV 103 μV

20 mV/div 551 μV 466 μV 349 μV 298 μV 141 μV

50 mV/div 1.038 mV 1.038 mV 739 μV 596 μV 259 μV

100 mV/div 2.102 mV 1.596 mV 1.349 mV 1.349 mV 609 μV

1 V/div 16.874 mV 12.850mV 11.617 mV 11.617 mV 4.906 mV

All models except 1.5 GHz, High Res mode (RMS), 50 Ω, typical

All models, Sample mode (RMS), 1 MΩ, typical

V/div 1 GHz 500 MHz 350 MHz 250/200 MHz 20 MHz

1 mV/div 260 μV 200 μV 150 μV 125 μV 75 μV

2 mV/div 280 μV 200 μV 150 μV 125 μV 75 μV

5 mV/div 305 μV 235 μV 185 μV 135 μV 75 μV

10 mV/div 335 μV 275 μV 220 μV 160 μV 80 μV

20 mV/div 425 μV 360 μV 270 μV 230 μV 110 μV

50 mV/div 800 μV 800 μV 570 μV 460 μV 200 μV

100 mV/div 1.62 mV 1.23 mV 1.04 mV 1.04 mV 470 μV

1 V/div 13.00 mV 9.90 mV 8.95 mV 8.95 mV 3.78 mV

V/div 500 MHz 350 MHz 250/200 MHz 20 MHz

1 mV/div 210 μV 140 μV 120 μV 78 μV

2 mV/div 210 μV 140 μV 120 μV 78 μV

5 mV/div 230 μV 160 μV 135 μV 96 μV

10 mV/div 270 μV 200 μV 190 μV 135 μV

20 mV/div 370 μV 300 μV 300 μV 240 μV

50 mV/div 760 μV 600 μV 650 μV 750 μV

100 mV/div 1.75 mV 1.350 mV 1.45 mV 1.22 mV

1 V/div 19.00 mV 15.25 mV 15.70 mV 11.20 mV

All models, High Res mode (RMS), 1 MΩ, typical

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 17

V/div 500 MHz 350 MHz 250/200 MHz 20 MHz

1 mV/div 200 μV 140 μV 120 μV 75 μV

2 mV/div 200 μV 140 μV 120 μV 75 μV

Table continued…

Specifications

V/div 500 MHz 350 MHz 250/200 MHz 20 MHz

5 mV/div 210 μV 150 μV 130 μV 75 μV

10 mV/div 230 μV 160 μV 150 μV 80 μV

20 mV/div 280 μV 200 μV 200 μV 100 μV

50 mV/div 520 μV 370 μV 410 μV 180 μV

100 mV/div 1.24 mV 880 μV 930 μV 460 μV

1 V/div 14.30 mV 10.20 mV 10.30 mV 5.45 mV

✓All models, High Res mode (RMS), 1 MΩ

Delay between analog channels, full bandwidth, typical

Deskew range -125 ns to +125 ns with a resolution of 40 ps

Crosstalk (channel isolation), typical ≥ 200:1 up to the rated bandwidth for any two channels having equal Volts/div settings

V/div 500 MHz 350 MHz 250/200 MHz 20 MHz

1 mV/div 259 μV 181 μV 155 μV 96 μV

2 mV/div 259 μV 181 μV 155 μV 96 μV

5 mV/div 271 μV 194 μV 168 μV 96 μV

10 mV/div 298 μV 206 μV 194 μV 103 μV

20 mV/div 363 μV 259 μV 259 μV 129 μV

50 mV/div 674 μV 479 μV 531 μV 233 μV

100 mV/div 1.609 mV 1.141 mV 1.206 mV 596 μV

1 V/div 18.561 mV 13.239 mV 13.369 mV 7.074 mV

≤ 100 ps for any two channels with input impedance set to 50 Ω, DC coupling with equal Volts/div or above 10 mV/div

Total probe power TekVPI+ Compliant probe interfaces: (4 per MSO44, 6 per MSO46) and 1 TekVPI interface for

Aux In

MSO46: 80 W maximum (40 W maximum for channels 1-3, 40 W maximum for channels 4-6 and Aux In)

MSO44: 80 W maximum (40 W maximum for channels 1-3, 40 W maximum for channel 4 and Aux In)

Probe power per channel

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 18

Voltage Max Amperage Voltage Tolerance

5 V 60 mA ±10%

12 V 1.67 A (20 W maximum

software limit)

±10%

TekVPI interconnect All analog channel inputs on the front panel conform to the TEKVPI specification.

Timebase system

Specifications

Sample rate

Max HW Capability Number of Channels

6.25 GS/s 1-6

Interpolated waveform rate range 500 GS/sec, 250 GS/sec, 125 GS/sec, 62.5 GS/sec, 25 GS/sec, and 12.5 GS/sec

Record length range

Standard 1 kpoints to 31.25 Mpoints in single sample increments

Optional 62.5 Mpoints

Seconds/Division range

Maximum triggered acquisition rate, typical

Model 1 K 10 K 100 K 1 M 10 M 31.25 M 62.5 M

MSO4X Standard

31.25 M

MSO4X Option

62.5 M

200 ps 64 s

200 ps 640 s

200 ps - 1000 s N/A

200 ps - 1000 s

Analog or digital channels: single channel [Analog or Digital 8-bit channel] on screen, measurements and math turned off. >20 wfm/sec

FastAcq Update Rate (analog only): >500 K/second with one channel active and >100 K/ second with all channels active.

Aperture uncertainty

✓Timebase accuracy

Delta-time measurement accuracy, nominal

Digital channel: >20/second with one channel (8-bits) active. There is no FastAcq for digital channels, but they do not slow down FastAcq for active analog channels.

≤ 0.450 ps + (10

-11

* Measurement Duration)

, for measurements having duration ≤ 100 ms

RMS

±2.5 x 10-6 over any ≥1 ms time interval

Description Specification

Factory Tolerance

±5.0 x10

-7

At calibration, 25 °C ambient, over any ≥1 ms interval

Temperature stability, typical

Crystal aging

±5.0 x10

Tested at operating temperatures

±1.5 x 10

-7

-6

Frequency tolerance change at 25 °C over a period of 1 year

The formulas to calculate the peak-to-peak or rms nominal delta-time measurement accuracy (DTA) for a given instrument setting and input signal is as follows (assumes insignificant signal

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 19

content above Nyquist frequency):

Where:

Specifications

Trigger system

Trigger bandwidth (edge, pulse, and logic), typical

N = input-referred guaranteed noise limit (V

SR 1 = Slew Rate (1st Edge) around 1st point in measurement

SR 2 = Slew Rate (2nd Edge) around 2nd point in measurement

t p = delta-time measurement duration (sec)

TBA = timebase accuracy or Reference Frequency Error ±0.5 ppm

(Assumes insignificant error due to aliasing or over-drive.)

The term under the square root sign is the stability and is due to TIE (Time Interval Error). The errors due to this term occur throughout a single-shot measurement. The second term is due to both the absolute center-frequency accuracy and the center-frequency stability of the timebase and varies between multiple single-shot measurements over the observation interval (the amount of time from the first single-shot measurement to the final single-shot measurement).

The formulas assume negligible errors due to measurement interpolation, and

Note:

apply only when the interpolated sample rate is 25 GS/s or higher.

1.5 GHz models, Edge 1.5 GHz

1.5 GHz models, Pulse and Logic 1 GHz

1 GHz models 1 GHz

500 MHz models 500 MHz

350 MHz models 350 MHz

200 MHz models 200 MHz

RMS

)

Edge-type trigger sensitivity, DC coupled, typical

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 20

Path Range Specification

1 MΩ path (all models)

Table continued…

0.5 mV/div to

0.99 mV/div

≥ 1 mV/div The greater of 5 mV or 0.7 div

4.5 div from DC to instrument bandwidth

Path Range Specification

50 Ω path, all models

The greater of 5.6 mV or 0.7 div from DC to the lesser of 500 MHz or instrument BW, & 7 mV or 0.8 div from > 500 MHz to instrument bandwidth

Line Fixed

Specifications

Trigger jitter, typical ≤ 7 ps

Edge-type trigger sensitivity, not DC coupled, typical

Trigger Coupling Typical Sensitivity

NOISE REJ 2.5 times the DC Coupled limits

HF REJ 1.0 times the DC Coupled limits from DC to 50 kHz. Attenuates

LF REJ 1.5 times the DC Coupled limits for frequencies above 50 kHz.

Logic-type triggering, minimum logic or rearm time, typical

Triggering type Pulse width Rearm time Time skew needed for

Logic 160 ps + t

Time qualified logic 320 ps + t

is rise time of the instrument.

rise

Minimum clock pulse widths for setup/hold time violation trigger, typical

Minimum pulsewidth, clock active

320 ps + t

RMS

rise

signals above 50 kHz.

Attenuates signals below 50 kHz.

160 ps + t

320 ps + t

rise

Minimum pulsewidth, clock inactive

rise

320 ps +t

rise

100% and no triggering

>360 ps / <150 ps

is rise time of the instrument.

rise

Setup/hold violation trigger, setup and hold time ranges, typical

Feature Min Max

Setup Time 0 ns 20 s

Hold Time 0 ns 20 s

Setup + Hold Time 320 ps 22 s

Input coupling on clock and data channels must be the same.

For Setup Time, positive numbers mean a data transition before the clock.

For Hold Time, positive numbers mean a data transition after the clock edge.

For Logic, time between channels refers to the length of time a logic state derived from more than one channel must exist to be recognized. For Events, the time is the minimum time between a main and delayed event that will be recognized if more than one channel is used.

Active pulsewidth is the width of the clock pulse from its active edge (as defined in the Clock Edge menu item) to its inactive edge.

Inactive pulsewidth is the width of the pulse from its inactive edge to its active edge.

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 21

Specifications

Setup + Hold Time is the algebraic sum of the Setup Time and the Hold Time programmed by the user.

Pulse type trigger, minimum pulse, rearm time, transition time

Transition time trigger, delta time range

Pulse class Minimum pulse width Minimum rearm time

Runt 160 ps + t

Time-Qualified Runt 160 ps + t

Width 160 ps + t

Slew Rate (minimum

160 ps + t

rise

160 ps + t

rise

transition time)

For trigger class width, pulse width refers to the width of the pulse being measured. Rearm time refers to the time between pulses.

For trigger class runt, pulse width refers to the width of the pulse being measured. Rearm time refers to the time between pulses.

For trigger class slew rate, pulse width refers to the delta time being measured. Rearm time refers to the time it takes the signal to cross the two trigger thresholds again.

is rise time of the instrument.

rise

Active pulsewidth is the width of the clock pulse from its active edge (as defined in the Clock Edge menu item) to its inactive edge

Inactive pulsewidth is the width of the pulse from its inactive edge to its active edge.

160 ps to 20 s.

Time range for glitch, pulse width, timeout, time-qualified runt, or timequalified window triggering

Time accuracy for pulse, glitch, timeout, or width triggering

B trigger after events, minimum pulse width and maximum event frequency, typical

B trigger, minimum time between arm and trigger, typical

160 ps to 20 s.

Time Range Accuracy

1 ns to 500 ns ±(160 ps +Time Base Error * Setting).

520 ns to 1 s ±(160 ps +Time Base Error * Setting).

Minimum pulse width: 160 ps + t

rise

Maximum event frequency: Instrument bandwidth.

is rise time of the instrument.

rise

320 ps

For trigger after time, this is the time between the end of the time period and the B trigger event.

For trigger after events, this is the time between the last A trigger event and the first B trigger event.

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 22

B trigger after time, time range 160 ps to 20 seconds

B trigger after events, event range 1 to 65,471

Specifications

Trigger level ranges

Trigger holdoff range 0 ns to 20 seconds

Source Range

Any Channel ±5 divs from center of screen

Aux In Trigger, typical ±8 V

Line Fixed at about 50% of line voltage

This specification applies to logic and pulse thresholds.

Serial Trigger specifications

Maximum serial trigger bits 128 bits

Optional serial bus interface triggering

Please refer to the Serial Triggering and Analysis 3 Series MDO, 4/5/6 Series MSO Applications Datasheet (part number 61W-61101-x), located on the Tektronix Web site, for

information on available serial triggering options and their triggering capabilities.

Digital acquisition system

Digital channel maximum sample rate 6.25 GS/s

Transition detect (digital peak detect) Displayed data at sample rates less than 6.25 GS/s (decimated data), that contains multiple

transitions between sample points will be displayed with a bright white colored edge.

Digital-To-Analog trigger skew 3 ns

Digital to digital skew 3 ns from bit 0 of any TekVPI channel to bit 0 of any TekVPI channel.

Digital skew within a FlexChannel 160 ps within any TekVPI channel

Digital volt meter (DVM)

Measurement types DC, AC

Voltage resolution 4 digits

✓Voltage accuracy

DC: ±((1.5% * |reading - offset - position|) + (0.5% * |(offset - position)|) + (0.1 * Volts/div))

De-rated at 0.100%/°C of |reading - offset - position| above 30 °C

Signal ± 5 divisions from screen center

AC: ± 2% (40 Hz to 1 kHz) with no harmonic content outside 40 Hz to 1 kHz range

AC, typical: ± 2% (20 Hz to 10 kHz)

RMS

+DC, AC

RMS

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 23

Specifications

For AC measurements, the input channel vertical settings must allow the VPP input signal to cover between 4 and 10 divisions and must be fully visible on the screen

Trigger frequency counter

✓Accuracy ±(1 count + time base accuracy * input frequency)

The signal must be at least 8 mVpp or 2 div, whichever is greater.

✓ Maximum input frequency 10 Hz to maximum bandwidth of the analog channel

The signal must be at least 8 mVpp or 2 div, whichever is greater.

Resolution 8-digits

Arbitrary Function Generator system

Function types Arbitrary, sine, square, pulse, ramp, triangle, DC level, Gaussian, Lorentz, exponential rise/fall,

sin(x)/x, random noise, Haversine, Cardiac

Amplitude range Values are peak-to-peak voltages

Waveform 50 Ω 1 MΩ

Arbitrary 10 mV to 2.5 V 20 mV to 5 V

Sine 10 mV to 2.5 V 20 mV to 5 V

Square 10 mV to 2.5 V 20 mV to 5 V

Pulse 10 mV to 2.5 V 20 mV to 5 V

Ramp 10 mV to 2.5 V 20 mV to 5 V

Triangle 10 mV to 2.5 V 20 mV to 5 V

Gaussian 10 mV to 1.25 V 20 mV to 2.5 V

Lorentz 10 mV to 1.2 V 20 mV to 2.4 V

Exponential Rise 10 mV to 1.25 V 20 mV to 2.5 V

Exponential Fall 10 mV to 1.25 V 20 mV to 2.5 V

Sine(x)/x 10 mV to 1.5 V 20 mV to 3.0 V

Random Noise 10 mV to 2.5 V 20 mV to 5 V

Haversine 10 mV to 1.25 V 20 mV to 2.5 V

Cardiac 10 mV to 2.5 V 20 mV to 5 V

Maximum sample rate 250 MS/s

Arbitrary function record length 128 K Samples

Sine waveform

Frequency range 0.1 Hz to 50 MHz

Frequency setting resolution 0.1 Hz

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 24

Frequency accuracy 130 ppm (frequency ≤ 10 kHz), 50 ppm (frequency > 10 kHz)

This is for Sine, Ramp, Square and Pulse waveforms only.

Amplitude range 20 mVpp to 5 Vpp into Hi-Z; 10 mVpp to 2.5 Vpp into 50 Ω

Amplitude flatness, typical ±0.5 dB at 1 kHz

±1.5 dB at 1 kHz for < 20 mVpp amplitudes

Total harmonic distortion, typical 1% for amplitude ≥ 200 mVpp into 50 Ω load

2.5% for amplitude > 50 mV AND < 200 mVpp into 50 Ω load

This is for Sine wave only.

Specifications

Spurious free dynamic range,

40 dB (Vpp ≥ 0.1 V); 30 dB (Vpp ≥ 0.02 V), 50 Ω load

typical

Square and pulse waveform

Frequency range 0.1 Hz to 25 MHz

Frequency setting resolution 0.1 Hz

Duty cycle range 10% - 90% or 10 ns minimum pulse, whichever is larger

Minimum pulse time applies to both on and off time, so maximum duty cycle will reduce at higher frequencies to maintain 10 ns off time

Duty cycle resolution 0.1%

Minimum pulse width, typical 10 ns. This is the minimum time for either on or off duration.

Rise/Fall time, typical 5.5 ns, 10% - 90%

Pulse width resolution 100 ps

Overshoot, typical < 4 % for signal steps greater than 100 mV

This applies to overshoot of the positive-going transition (+overshoot) and of the negative-going (-overshoot) transition

Asymmetry, typical ±1% ±5 ns, at 50% duty cycle

Jitter, typical < 60 ps TIE

, ≥ 100 mVpp amplitude, 40%-60% duty cycle

RMS

Ramp and triangle waveform

Frequency range 0.1 Hz to 500 kHz

Frequency setting resolution 0.1 Hz

Variable symmetry 0% - 100%

Symmetry resolution 0.1%

DC level range ±2.5 V into Hi-Z

±1.25 V into 50 Ω

Gaussian pulse, Haversine, and Lorentz pulse

Maximum frequency 5 MHz

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 25

Specifications

Exponential rise fall maximum frequency

Sin(x)/x

Maximum frequency 2 MHz

Random noise amplitude range 20 mVpp to 5 Vpp into Hi-Z

✓Sine and ramp frequency accuracy

✓Square and pulse frequency

accuracy

Signal amplitude resolution 1 mV (Hi-Z)

✓Signal amplitude accuracy ±[ (1.5% of peak-to-peak amplitude setting) + (1.5% of absolute DC offset setting) + 1 mV ]

5 MHz

10 mVpp to 2.5 Vpp into 50 Ω

For both isolated noise signal and additive noise signal.

1.3 x 10-4 (frequency ≤10 kHz)

5.0 x 10-5 (frequency >10 kHz)

1.3 x 10-4 (frequency ≤10 KHz);

5.0 x 10-5 (frequency >10 KHz)

500 μV (50 Ω)

(frequency = 1 kHz)

DC offset range ±2.5 V into Hi-Z

±1.25 V into 50 Ω

DC offset resolution 1 mV (Hi-Z)

500 μV (50 Ω)

✓DC offset accuracy ±[ (1.5% of absolute offset voltage setting) + 1 mV ]

Add 3 mV of uncertainty per 10 °C change from 25 °C ambient. Refer DC Offset Accuracy test

record on page 34

Display system

Display type Display area - 11.38 inches (289 mm) (H) x 6.5 inches (165 mm) (V), 13.3 inches (338 mm)

diagonal, 6-bit RGB color, (1920 X 1080) TFT liquid crystal display (LCD) with capacitive touch

Resolution 1,920 horizontal × 1,080 vertical pixels

Luminance, typical

400 cd/m2, (Minimum: 320 cd/m2 )

Display luminance is specified for a new display set at full brightness.

Processor system

Host processor Texas Instruments AM5728

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 26

Operating system Closed Linux

Input_Output port specifications

Ethernet interface An 8-pin RJ-45 connector that supports 10/100/1000 Mb/s

Video signal output A 29-pin HDMI connector

Recommended resolution: 1920 x 1080 @ 60 Hz. Note that video out may not be hot pluggable. HDMI cable may need to be attached before power up for dual display functions to work depending upon the instrument firmware revision

USB interface (Host, Device ports) Front panel USB Host ports: Three USB 2.0 Hi-Speed ports

Rear panel USB Host ports: Two USB 2.0 Hi-Speed ports

Rear panel USB Device port: One USB 2.0 Hi-Speed Device port providing USBTMC support

Specifications

Probe compensator signal output voltage and frequency, typical

Auxiliary output, AUX OUT, Trigger Out, Event, or Reference Clock Out

Selectable output Acquisition Trigger Out

Acquisition Trigger Out User selectable transition from HIGH to LOW, or LOW to HIGH, indicates the trigger occurred. The

Acquisition trigger jitter 380 ps (peak-to-peak)

Reference Clock Out Reference clock output tracks the acquisition system and can be referenced from either the

AFG Trigger Out The output frequency is dependent on the frequency of the AFG signal as shown in the following

Characteristic Value

Output Voltage Default: 0-2.5 V amplitude

Impedance 1 kΩ

Frequency 1 kHz

Reference Clock Out

AFG Trigger Out

signal returns to its previous state after approximately 100 ns

internal clock reference or the external clock reference

table:

AFG signal frequency AFT trigger frequency

≤ 4.9 MHz Signal frequency

> 4.9 MHz to 14.7 MHz Signal frequency / 3

> 14.7 MHz to 24.5 MHz Signal frequency / 5

> 24.5 MHz to 34.3 MHz Signal frequency / 7

> 34.3 MHz to 44.1 MHz Signal frequency / 9

> 44.1 MHz to 50 MHz Signal frequency / 11

AUX OUT Output Voltage

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 27

Characteristic Limits

Vout (HI) ≥ 2.5 V open circuit; ≥ 1.0 V into a 50 Ω load to ground

Table continued…

Characteristic Limits

Vout (LO) ≤ 0.7 V into a load of ≤ 4 mA; ≤0.25 V into a 50 Ω load to

ground

External reference input

Nominal input frequency 10 MHz

Frequency Variation Tolerance

Sensitivity, typical Vin 1.5 V

Maximum input signal 7 V

Impedance 1.2 K Ohms ±20% in parallel with 18 pf ±5 pf at 10 MHz

9.99996 MHz to 10.00004 MHz (±4.0 x 10-6)

using a 50 Ω termination

p-p

Data storage specifications

Specifications

Nonvolatile memory retention time, typical

Real-time clock A programmable clock providing time in years, months, days, hours, minutes, and seconds.

Nonvolatile memory capacity

32 GB Primary MMC Stores the operating system, application software and factory data. No user data

32 GB Secondary MMC Stores saved setups and waveforms, Ethernet settings, log files, user data and user settings

2 Kbit EEPROM Memory on the main board that stores the instrument serial number, instrument start up count, total

1 Kbit EEPROM Memory on the main board that stores power management controller factory data

1 KB Flash Memory Memory on the main board that stores the SODIMM memory configuration data (SPD). Two to four

32 KB Flash Memory Memory on the main board that stores microcontroller firmware. Two pieces

64 KB Flash Memory Memory on the main board that stores microcontroller firmware. Two pieces

No time limit for front panel settings, saved waveforms, setups, product licensing, and calibration constants.

uptime factory data, security option passwords, and user-settable security option passwords

pieces depending on model

Power supply system

Power

Power consumption 400 Watts maximum

Source voltage 100 - 240 V ±10% (50 Hz to 60 Hz)

Source frequency 50 Hz to 60 Hz ±10%, at 100 - 240 V ±10%

400 Hz at 115 V ±10%

Fuse Rating 12.5 A, 250 V

Safety characteristics

Safety certification US NRTL Listed - UL61010-1 and UL61010-2-030

Canadian Certification - CAN/CSA-C22.2 No. 61010.1 and CAN/CSA-C22.2 No 61010.2.030

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 28

EU Compliance - Low Voltage Directive 2014-35-EU and EN61010-1.

International Compliance - IEC 61010-1 and IEC61010-2-030

Pollution degree Pollution degree 2, indoor, dry location use only

Environmental specifications

Temperature

Operating +0 °C to +50 °C (32 °F to 122 °F)

Non-operating -30 °C to +70 °C (-22 °F to 158 °F)

Humidity

Operating 5% to 90% relative humidity (% RH) at up to +40 °C

5% to 50% RH above +40 °C up to +50 °C, noncondensing, and as limited by a maximum wet-bulb temperature of +39 °C

Non-operating 5% to 90% relative humidity (% RH) at up to +40 °C

5% to 50% RH above +40 °C up to +50 °C, noncondensing, and as limited by a maximum wet-bulb temperature of +39 °C

Specifications

Altitude

Operating Up to 3,000 meters (9,843 feet)

Non-operating Up to 12,000 meters (39,370 feet)

Mechanical specifications

Dimensions Height: 11.299 in (286.99 mm), feet folded in, handle to back

Height: 13.8 in (351 mm) feet folded in, handle up

Width: 15.9 in (405 mm) from handle hub to handle hub

Depth: 6.1 in (155 mm) from back of feet to front of knobs, handle up

Depth: 10.4 in (265 mm) feet folded in, handle to the back

Weight < 16.8 lbs (7.6 kg)

Cooling The clearance requirement for adequate cooling is 2.0 in (50.8 mm) on the right side of the

instrument (when viewed from the front) and on the rear of the instrument

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 29

Performance verification procedures

This chapter contains performance verification procedures for the specifications marked with the symbol. The following equipment, or a suitable equivalent, is required to complete these procedures.

The performance verification procedures verify the performance of your instrument. They do not adjust your instrument. If your instrument fails any of the performance verification tests, repeat the failing test, verifying that the test equipment and settings are correct. If the instrument continues to fail a test, contact Tektronix Customer Support for assistance.

These procedures cover all 4 Series MSO instruments (MSO44, MSO46) .

Print the test records on the following pages and use them to record the performance test results for your oscilloscope. Disregard checks and test records that do not apply to the specific model you are testing.

Note: Completion of the performance verification procedure does not update the instrument time and date.

Required equipment:

Required equipment Minimum requirements Examples

DC voltage source 3 mV to 4 V, ±0.1% accuracy Fluke 9500B Oscilloscope Calibrator with a

9530 Output Module

Leveled sine wave generator 50 kHz to 2 GHz, ±4% amplitude accuracy

Time mark generator

Logic probe Low capacitance digital probe, 8 channels. TLP058 probe

BNC-to-0.1 inch pin adapter to connect the logic probe to the signal source.

Digital multimeter (DMM) 0.1% accuracy or better Tektronix DMM4020

One 50 Ω terminator Impedance 50 Ω; connectors: female BNC

One 50 Ω BNC cable Male-to-male connectors Tektronix part number 012-0057-01

Optical mouse USB, PS2 Tektronix part number 119-7054-00

RF vector signal generator Maximum bandwidth of instrument Tektronix TSG4100A

80 ms period, ±1.0 x 10-6 accuracy, rise time <50 ns

BNC-to-0.1 inch pin adapter; female BNC to 2x16 .01 inch pin headers.

input, male BNC output

Tektronix adapter part number 878-1429-00; to connect the Fluke 9500B to the TLP058 probe.

Tektronix part number 011-0049-02

You might need additional cables and adapters, depending on the actual test equipment you use.

Test records

Instrument information, self test record

Model Serial # Procedure performed by Date

Test Passed Failed

Self Test

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 30

Input Impedance test record

Input Impedance

Performance checks

All models

Channel 1 Input Impedance, 1 MΩ

Channel 1 Input Impedance, 50 Ω

Channel 2 Input Impedance, 1 MΩ

Channel 2 Input Impedance, 50 Ω

Channel 3 Input Impedance, 1 MΩ

Channel 3 Input Impedance, 50 Ω

Vertical scale Low limit Test result High limit

100 mV/div 990 kΩ 1.01 MΩ

10 mV/div 49.5 Ω 50.5 Ω

100 mV/div 49.5 Ω 50.5 Ω

100 mV/div 990 kΩ 1.01 MΩ

10 mV/div 49.5 Ω 50.5 Ω

100 mV/div 49.5 Ω 50.5 Ω

100 mV/div 990 kΩ 1.01 MΩ

10 mV/div 49.5 Ω 50.5 Ω

100 mV/div 49.5 Ω 50.5 Ω

Performance verification procedures

Channel 4 Input Impedance, 1 MΩ

Channel 4, Input Impedance, 50 Ω

MSO46

Channel 5 Input Impedance, 1 MΩ

Channel 5 Input Impedance, 50 Ω

Channel 6 Input Impedance, 1 MΩ

Channel 6 Input Impedance, 50 Ω

100 mV/div 990 kΩ 1.01 MΩ

10 mV/div 49.5 Ω 50.5 Ω

100 mV/div 49.5 Ω 50.5 Ω

100 mV/div 990 kΩ 1.01 MΩ

10 mV/div 49.5 Ω 50.5 Ω

100 mV/div 49.5 Ω 50.5 Ω

100 mV/div 990 kΩ 1.01 MΩ

10 mV/div 49.5 Ω 50.5 Ω

100 mV/div 49.5 Ω 50.5 Ω

DC Gain Accuracy test record

DC Gain Accuracy

Performance checks

Table continued…

Bandwidth Vertical scale Low limit Test result High limit

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 31

DC Gain Accuracy

Channel 1 DC Gain Accuracy, 0 V offset, 0 V vertical position, 50 Ω

Channel 1 DC Gain Accuracy, 0 V offset, 0 V vertical position, 1 MΩ

Channel 2 DC Gain Accuracy, 0 V offset, 0 V vertical position,50 Ω

Table continued…

Performance verification procedures

20 MHz 1 mV/div -2.5% 2.5%

2 mV/div -1% 1%

5 mV/div -1% 1%

10 mV/div -1% 1%

20 mV/div -1% 1%

50 mV/div -1% 1%

100 mV/div -1% 1%

200 mV/div -1% 1%

500 mV/div -1% 1%

1 V/div -1% 1%

250 MHz 20 mV/div -1% 1%

FULL 20 mV/div -1% 1%

20 MHz 1 mV/div -2% 2%

2 mV/div -1% 1%

5 mV/div -1% 1%

10 mV/div -1% 1%

20 mV/div -1% 1%

50 mV/div -1% 1%

100 mV/div -1% 1%

200 mV/div -1% 1%

500 mV/div -1% 1%

1 V/div -1% 1%

250 MHz 20 mV/div -1% 1%

FULL 20 mV/div -1% 1%

20 MHz 1 mV/div -2.5% 2.5%

2 mV/div -1% 1%

5 mV/div -1% 1%

10 mV/div -1% 1%

20 mV/div -1% 1%

50 mV/div -1% 1%

100 mV/div -1% 1%

200 mV/div -1% 1%

500 mV/div -1% 1%

1 V/div -1% 1%

250 MHz 20 mV/div -1% 1%

FULL 20 mV/div -1% 1%

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 32

DC Gain Accuracy

Channel 2 DC Gain Accuracy, 0 V offset, 0 V vertical position,1 MΩ

Channel 3 DC Gain Accuracy, 0 V offset, 0 V vertical position,50 Ω

Channel 3 DC Gain Accuracy, 0 V offset, 0 V vertical position,1 MΩ

Table continued…

Performance verification procedures

20 MHz 1 mV/div -2% 2%

2 mV/div -1% 1%

5 mV/div -1% 1%

10 mV/div -1% 1%

20 mV/div -1% 1%

50 mV/div -1% 1%

100 mV/div -1% 1%

200 mV/div -1% 1%

500 mV/div -1% 1%

1 V/div -1% 1%

250 MHz 20 mV/div -1% 1%

FULL 20 mV/div -1% 1%

20 MHz 1 mV/div -2.5% 2.5%

2 mV/div -1% 1%

5 mV/div -1% 1%

10 mV/div -1% 1%

20 mV/div -1% 1%

50 mV/div -1% 1%

100 mV/div -1% 1%

200 mV/div -1% 1%

500 mV/div -1% 1%

1 V/div -1% 1%

250 MHz 20 mV/div -1% 1%

FULL 20 mV/div -1% 1%

20 MHz 1 mV/div -2% 2%

2 mV/div -1% 1%

5 mV/div -1% 1%

10 mV/div -1% 1%

20 mV/div -1% 1%

50 mV/div -1% 1%

100 mV/div -1% 1%

200 mV/div -1% 1%

500 mV/div -1% 1%

1 V/div -1% 1%

250 MHz 20 mV/div -1% 1%

FULL 20 mV/div -1% 1%

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 33

DC Gain Accuracy

Channel 4 DC Gain Accuracy, 0 V offset, 0 V vertical position,50 Ω

Channel 4 DC Gain Accuracy, 0 V offset, 0 V vertical position,1 MΩ

Performance verification procedures

20 MHz 1 mV/div -2.5% 2.5%

2 mV/div -1% 1%

5 mV/div -1% 1%

10 mV/div -1% 1%

20 mV/div -1% 1%

50 mV/div -1% 1%

100 mV/div -1% 1%

200 mV/div -1% 1%

500 mV/div -1% 1%

1 V/div -1% 1%

250 MHz 20 mV/div -1% 1%

FULL 20 mV/div -1% 1%

20 MHz 1 mV/div -2% 2%

2 mV/div -1% 1%

5 mV/div -1% 1%

10 mV/div -1% 1%

20 mV/div -1% 1%

50 mV/div -1% 1%

100 mV/div -1% 1%

200 mV/div -1% 1%

500 mV/div -1% 1%

1 V/div -1% 1%

250 MHz 20 mV/div -1% 1%

FULL 20 mV/div -1% 1%

DC Offset Accuracy test record

Offset Accuracy

Performance

Vertical scale

Vertical offset

checks

All models

Channel 1 DC Offset Accuracy, 20 MHz BW, 50 Ω

1 mV/div 900 mV 895.3 mV 904.7 mV

1 mV/div 0 V -0.2 mV 0.2 mV

1 mV/div -900 mV -904.7 mV -895.3 mV

100 mV/div 5.0 V 4.955 V 5.045 V

100 mV/div 0 V -20 mV 20 mV

100 mV/div -5.0 V -5.045 V -4.955 V

Table continued…

Use this value for both the calibrator output and the oscilloscope offset setting.

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 34

Low limit Test result High limit

Offset Accuracy

Performance checks

Channel 1 DC Offset Accuracy, 20 MHz BW, 1 MΩ

Channel 2 DC Offset Accuracy, 20 MHz BW, 50 Ω

Table continued…

Performance verification procedures

Vertical scale

Vertical offset

Low limit Test result High limit

1 mV/div 900 mV 895.3 mV 904.7 mV

1 mV/div 0 V -0.2 mV 0.2 mV

1 mV/div -900 mV -904.7 mV -895.3 mV

100 mV/div 1.0 V 0.975 V 1.025 V

100 mV/div 0 V -20 mV 20 mV

100 mV/div -1.0 V -1.025 V -0.975 V

500 mV/div 9.0 V 8.855 V 9.145 V

500 mV/div 0 V -100 mV 100 mV

500 mV/div -9.0 V -9.145 V -8.855 V

1.01 mV/div 10 V 9.748 V 10.252 V

1.01 mV/div 0 V -202 mV 202 mV

1.01 mV/div -10 V -10.252 V -9.748 V

5 mV/div 10 V 8.95 V 11.05 V

5 mV/div 0 V -1000 mV 1000 mV

5 mV/div -10 V -11.05 V -8.95 V

1 mV/div 900 mV 895.3 mV 904.7 mV

1 mV/div 0 V -0.2 mV 0.2 mV

1 mV/div -900 mV -904.7 mV -895.3 mV

100 mV/div 5.0 V 4.955 V 5.045 V

100 mV/div 0 V -20 mV 20 mV

100 mV/div -5.0 V -5.045 V -4.955 V

Use this value for both the calibrator output and the oscilloscope offset setting.

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 35

Offset Accuracy

Performance checks

Channel 2 DC Offset Accuracy, 20 MHz BW, 1 MΩ

Channel 3 DC Offset Accuracy, 20 MHz BW, 50 Ω

Table continued…

Performance verification procedures

Vertical scale

Vertical offset

Low limit Test result High limit

1 mV/div 900 mV 895.3 mV 904.7 mV

1 mV/div 0 V -0.2 mV 0.2 mV

1 mV/div -900 mV -904.7 mV -895.3 mV

100 mV/div 1.0 V 0.975 V 1.025 V

100 mV/div 0 V -20 mV 20 mV

100 mV/div -1.0 V -1.025 V -0.975 V

500 mV/div 9.0 V 8.855 V 9.145 V

500 mV/div 0 V -100 mV 100 mV

500 mV/div -9.0 V -9.145 V -8.855 V

1.01 mV/div 10 V 9.748 V 10.252 V

1.01 mV/div 0 V -202 mV 202 mV

1.01 mV/div -10 V -10.252 V -9.748 V

5 mV/div 10.0 V 8.95 V 11.05 V

5 mV/div 0 V -1000 mV 1000 mV

5 mV/div -10.0 V -11.05 V -8.95 V

1 mV/div 900 mV 895.3 mV 904.7 mV

1 mV/div 0 V -0.2 mV 0.2 mV

1 mV/div -900 mV -904.7 mV -895.3 mV

100 mV/div 5.0 V 4.955 V 5.045 V

100 mV/div 0 V -20 mV 20 mV

100 mV/div -5.0 V -5.045 V -4.955 V

Use this value for both the calibrator output and the oscilloscope offset setting.

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 36

Offset Accuracy

Performance checks

Channel 3 DC Offset Accuracy, 20 MHz BW, 1 MΩ

Channel 4 DC Offset Accuracy, 20 MHz BW, 50 Ω

Table continued…

Performance verification procedures

Vertical scale

Vertical offset

Low limit Test result High limit

1 mV/div 900 mV 895.3 mV 904.7 mV

1 mV/div 0 V -0.2 mV 0.2 mV

1 mV/div -900 mV -904.7 mV -895.3 mV

100 mV/div 1.0 V 0.975 V 1.025 V

100 mV/div 0 V -20 mV 20 mV

100 mV/div -1.0 V -1.025 V -0.975 V

500 mV/div 9.0 V 8.855 V 9.145 V

500 mV/div 0 V -100 mV 100 mV

500 mV/div -9.0 V -9.145 V -8.855 V

1.01 mV/div 10.0 V 9.748 V 10.252 V

1.01 mV/div 0 V -202 mV 202 mV

1.01 mV/div -10.0 V -10.252 V -9.748 V

5 mV/div 10 V 8.95 V 11.05 V

5 mV/div 0 V -1000 mV 1000 mV

5 mV/div -10 V -11.05 V -8.95 V

1 mV/div 900 mV 895.3 mV 904.7 mV

1 mV/div 0 V -0.2 mV 0.2 mV

1 mV/div -900 mV -904.7 mV -895.3 mV

100 mV/div 5.0 V 4.955 V 5.045 V

100 mV/div 0 V -20 mV 20 mV

100 mV/div -5.0 V -5.045 V -4.955 V

Use this value for both the calibrator output and the oscilloscope offset setting.

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 37

Offset Accuracy

Performance checks

Channel 4 DC OffsetAccuracy, 20 MHz BW, 1 MΩ

MSO46

Channel 5 DC Offset Accuracy, 20 MHz BW, 50 Ω

Table continued…

Performance verification procedures

Vertical scale

Vertical offset

Low limit Test result High limit

1 mV/div 900 mV 895.3 mV 904.7 mV

1 mV/div 0 V -0.2 mV 0.2 mV

1 mV/div -900 mV -904.7 mV -895.3 mV

100 mV/div 1.0 V 0.975 V 1.025 V

100 mV/div 0 V -20 mV 20 mV

100 mV/div -1.0 V -1.025 V -0.975 V

500 mV/div 9.0 V 8.855 V 9.145 V

500 mV/div 0 V -100 mV 100 mV

500 mV/div -9.0 V -9.145 V -8.855 V

1.01 mV/div 10.0 V 9.748 V 10.252 V

1.01 mV/div 0 V -202 mV 202 mV

1.01 mV/div -10.0 V -10.252 V -9.748 V

5 mV/div 10 V 8.95 V 11.05 V

5 mV/div 0 V -1000 mV 1000 mV

5 mV/div -10 V -11.05 V -8.95 V

1 mV/div 900 mV 895.3 mV 904.7 mV

1 mV/div 0 V -0.2 mV 0.2 mV

1 mV/div -900 mV -904.7 mV -895.3 mV

100 mV/div 5.0 V 4.955 V 5.045 V

100 mV/div 0 V -20 mV 20 mV

100 mV/div -5.0 V -5.045 V -4.955 V

Use this value for both the calibrator output and the oscilloscope offset setting.

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 38

Offset Accuracy

Performance checks

Channel 5 DC Offset Accuracy, 20 MHz BW, 1 MΩ

Channel 6 DC Offset Accuracy, 20 MHz BW, 50 Ω

Table continued…

Performance verification procedures

Vertical scale

Vertical offset

Low limit Test result High limit

1 mV/div 900 mV 895.3 mV 904.7 mV

1 mV/div 0 V -0.2 mV 0.2 mV

1 mV/div -900 mV -904.7 mV -895.3 mV

100 mV/div 1.0 V 0.975 V 1.025 V

100 mV/div 0 V -20 mV 20 mV

100 mV/div -1.0 V -1.025 V -0.975 V

500 mV/div 9.0 V 8.855 V 9.145 V

500 mV/div 0 V -100 mV 100 mV

500 mV/div -9.0 V -9.145 V -8.855 V

1.01 mV/div 10.0 V 9.748 V 10.252 V

1.01 mV/div 0 V -202 mV 202 mV

1.01 mV/div -10.0 V -10.252 V -9.748 V

5 mV/div 10.0 V 8.95 V 11.05 V

5 mV/div 0 V -1000 mV 1000 mV

5 mV/div -10.0 V -11.05 V -8.95 V

1 mV/div 900 mV 895.3 mV 904.7 mV

1 mV/div 0 V -0.2 mV 0.2 mV

1 mV/div -900 mV -904.7 mV -895.3 mV

100 mV/div 5.0 V 4.955 V 5.045 V

100 mV/div 0 V -20 mV 20 mV

100 mV/div -5.0 V -5.045 V -4.955 V

Use this value for both the calibrator output and the oscilloscope offset setting.

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 39

Offset Accuracy

Performance checks

Channel 6 DC Offset Accuracy, 20 MHz BW, 1 MΩ

Performance verification procedures

Vertical scale

Vertical offset

Low limit Test result High limit

1 mV/div 900 mV 895.3 mV 904.7 mV

1 mV/div 0 V -0.2 mV 0.2 mV

1 mV/div -900 mV -904.7 mV -895.3 mV

100 mV/div 1.0 V 0.975 V 1.025 V

100 mV/div 0 V -20 mV 20 mV

100 mV/div -1.0 V -1.025 V -0.975 V

500 mV/div 9.0 V 8.855 V 9.145 V

500 mV/div 0 V -100 mV 100 mV

500 mV/div -9.0 V -9.145 V -8.855 V

1.01 mV/div 10.0 V 9.748 V 10.252 V

1.01 mV/div 0 V -202 mV 202 mV

1.01 mV/div -10.0 V -10.252 V -9.748 V

5 mV/div 10.0 V 8.95 V 11.05 V

5 mV/div 0 V -1000 mV 1000 mV

5 mV/div -10.0 V -11.05 V -8.95 V

Analog Bandwidth test record

Analog Bandwidth performance checks

Bandwidth at Channel

1.5 GHz models

Channel 1 50 Ω 1 mV/div 5 ns/div (Full

Table continued…

Impedance Vertical scale Horizontal

scale

BW)

2 mV/div 2.5 ns/div (Full

BW)

5 mV/div 1 ns/div (Full

BW)

10 mV/div 1 ns/div (Full

BW)

50 mV/div 1 ns/div (Full

BW)

100 mV/div 1 ns/div (Full

BW)

1 V/div 1 ns/div (Full

BW)

in-pp

bw-pp

Limit Test result

Gain = V V

in-pp

≥ 0.707

bw-pp

Use this value for both the calibrator output and the oscilloscope offset setting.

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 40

Analog Bandwidth performance checks

Channel 1 1 MΩ, typical 1 mV/div 5 ns/div (500

MHz)

2 mV/div 2.5 ns/div (500

MHz)

5 mV/div 1 ns/div (500

MHz)

10 mV/div 1 ns/div (500

MHz)

50 mV/div 1 ns/div (500

MHz)

100 mV/div 1 ns/div (500

MHz)

1 V/div 1 ns/div (500

MHz)

Channel 2 50 Ω 1 mV/div 5 ns/div (Full

BW)

2 mV/div 2.5 ns/div (Full

BW)

5 mV/div 1 ns/div (Full

BW)

10 mV/div 1 ns/div (Full

BW)

50 mV/div 1 ns/div (Full

BW)

100 mV/div 1 ns/div (Full

BW)

1 V/div 1 ns/div (Full

BW)

Channel 2 1 MΩ, typical 1 mV/div 5 ns/div (500

MHz)

2 mV/div 2.5 ns/div (500

MHz)

5 mV/div 1 ns/div (500

MHz)

10 mV/div 1 ns/div (500

MHz)

50 mV/div 1 ns/div (500

MHz)

100 mV/div 1 ns/div (500

MHz)

1 V/div 1 ns/div (500

MHz)

Table continued…

Performance verification procedures

≥ 0.707

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 41

Analog Bandwidth performance checks

Channel 3 50 Ω 1 mV/div 5 ns/div (Full

BW)

2 mV/div 2.5 ns/div (Full

BW)

5 mV/div 1 ns/div (Full

BW)

10 mV/div 1 ns/div (Full

BW)

50 mV/div 1 ns/div (Full

BW)

100 mV/div 1 ns/div (Full

BW)

1 V/div 1 ns/div (Full

BW)

Channel 3 1 MΩ, typical 1 mV/div 5 ns/div (500

MHz)

2 mV/div 2.5 ns/div (500

MHz)

5 mV/div 1 ns/div (500

MHz)

10 mV/div 1 ns/div (500

MHz)

50 mV/div 1 ns/div (500

MHz)

100 mV/div 1 ns/div (500

MHz)

1 V/div 1 ns/div (500

MHz)

Channel 4 1 mV/div 5 ns/div (Full

BW)

2 mV/div 2.5 ns/div (Full

BW)

5 mV/div 1 ns/div (Full

BW)

10 mV/div 1 ns/div (Full

BW)

50 mV/div 1 ns/div (Full

BW)

100 mV/div 1 ns/div (Full

BW)

1 V/div 1 ns/div (Full

BW)

Table continued…

Performance verification procedures

≥ 0.707

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 42

Analog Bandwidth performance checks

Channel 4 1 MΩ, typical 1 mV/div 5 ns/div (500

MHz)

2 mV/div 2.5 ns/div (500

MHz)

5 mV/div 1 ns/div (500

MHz)

10 mV/div 1 ns/div (500

MHz)

50 mV/div 1 ns/div (500

MHz)

100 mV/div 1 ns/div (500

MHz)

1 V/div 1 ns/div (500

MHz)

1.5 GHz MSO46

Channel 5 50 Ω 1 mV/div 5 ns/div (Full

BW)

2 mV/div 2.5 ns/div (Full

BW)

5 mV/div 1 ns/div (Full

BW)

10 mV/div 1 ns/div (Full

BW)

50 mV/div 1 ns/div (Full

BW)

100 mV/div 1 ns/div (Full

BW)

1 V/div 1 ns/div (Full

BW)

Channel 5 1 MΩ, typical 1 mV/div 5 ns/div (500

MHz)

2 mV/div 2.5 ns/div (500

MHz)

5 mV/div 1 ns/div (500

MHz)

10 mV/div 1 ns/div (500

MHz)

50 mV/div 1 ns/div (500

MHz)

100 mV/div 1 ns/div (500

MHz)

1 V/div 1 ns/div (500

MHz)

Table continued…

Performance verification procedures

≥ 0.707

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 43

Analog Bandwidth performance checks

Channel 6 50 Ω 1 mV/div 5 ns/div (500

MHz)

2 mV/div 5 ns/div (Full

BW)

5 mV/div 2.5 ns/div (Full

BW)

10 mV/div 1 ns/div (Full

BW)

50 mV/div 1 ns/div (Full

BW)

100 mV/div 1 ns/div (Full

BW)

1 V/div 1 ns/div (Full

BW)

Channel 6 1 MΩ, typical 1 mV/div 5 ns/div (500

MHz)

2 mV/div 2.5 ns/div (500

MHz)

5 mV/div 1 ns/div (500

MHz)

10 mV/div 1 ns/div (500

MHz)

50 mV/div 1 ns/div (500

MHz)

100 mV/div 1 ns/div (500

MHz)

1 V/div 1 ns/div (500

MHz)

1 GHz models

Channel 1 50 Ω 1 mV/div 5 ns/div (Full

BW)

2 mV/div 2.5 ns/div (Full

BW)

5 mV/div 1 ns/div (Full

BW)

10 mV/div 1 ns/div (Full

BW)

50 mV/div 1 ns/div (Full

BW)

100 mV/div 1 ns/div (Full

BW)

1 V/div 1 ns/div (Full

BW)

Table continued…

Performance verification procedures

≥ 0.707

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 44

Analog Bandwidth performance checks

Channel 1 1 MΩ, typical 1 mV/div 5 ns/div (500

MHz)

2 mV/div 2.5 ns/div (500

MHz)

5 mV/div 1 ns/div (500

MHz)

10 mV/div 1 ns/div (500

MHz)

50 mV/div 1 ns/div (500

MHz)

100 mV/div 1 ns/div (500

MHz)

1 V/div 1 ns/div (500

MHz)

Channel 2 50 Ω 1 mV/div 5 ns/div (500

MHz)

2 mV/div 5 ns/div (Full

BW)

5 mV/div 2.5 ns/div (Full

BW)

10 mV/div 1 ns/div (Full

BW)

50 mV/div 1 ns/div (Full

BW)

100 mV/div 1 ns/div (Full

BW)

1 V/div 1 ns/div (Full

BW)

Channel 2 1 MΩ, typical 1 mV/div 5 ns/div (500

MHz)

2 mV/div 2.5 ns/div (500

MHz)

5 mV/div 1 ns/div (500

MHz)

10 mV/div 1 ns/div (500

MHz)

50 mV/div 1 ns/div (500

MHz)

100 mV/div 1 ns/div (500

MHz)

1 V/div 1 ns/div (500

MHz)

Table continued…

Performance verification procedures

≥ 0.707

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 45

Analog Bandwidth performance checks

Channel 3 50 Ω 1 mV/div 5 ns/div (Full

BW)

2 mV/div 2.5 ns/div (Full

BW)

5 mV/div 1 ns/div (Full

BW)

10 mV/div 1 ns/div (Full

BW)

50 mV/div 1 ns/div (Full

BW)

100 mV/div 1 ns/div (Full

BW)

1 V/div 1 ns/div (Full

BW)

Channel 3 1 MΩ, typical 1 mV/div 5 ns/div (500

MHz)

2 mV/div 2.5 ns/div (500

MHz)

5 mV/div 1 ns/div (500

MHz)

10 mV/div 1 ns/div (500

MHz)

50 mV/div 1 ns/div (500

MHz)

100 mV/div 1 ns/div (500

MHz)

1 V/div 1 ns/div (500

MHz)

Channel 4 50 Ω 1 mV/div 5 ns/div (Full

BW)

2 mV/div 2.5 ns/div (Full

BW)

5 mV/div 1 ns/div (Full

BW)

10 mV/div 1 ns/div (Full

BW)

50 mV/div 1 ns/div (Full

BW)

100 mV/div 1 ns/div (Full

BW)

1 V/div 1 ns/div (Full

BW)

Table continued…

Performance verification procedures

≥ 0.707

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 46

Analog Bandwidth performance checks

Channel 4 1 MΩ, typical 1 mV/div 5 ns/div (500

MHz)

2 mV/div 2.5 ns/div (500

MHz)

5 mV/div 1 ns/div (500

MHz)

10 mV/div 1 ns/div (500

MHz)

50 mV/div 1 ns/div (500

MHz)

100 mV/div 1 ns/div (500

MHz)

1 V/div 1 ns/div (500

MHz)

1 GHz MSO46

Channel 5 50 Ω 1 mV/div 5 ns/div (Full

BW)

2 mV/div 2.5 ns/div (Full

BW)

5 mV/div 1 ns/div (Full

BW)

10 mV/div 1 ns/div (Full

BW)

50 mV/div 1 ns/div (Full

BW)

100 mV/div 1 ns/div (Full

BW)

1 V/div 1 ns/div (Full

BW)

Channel 5 1 MΩ, typical 1 mV/div 5 ns/div (500

MHz)

2 mV/div 2.5 ns/div (500

MHz)

5 mV/div 1 ns/div (500

MHz)

10 mV/div 1 ns/div (500

MHz)

50 mV/div 1 ns/div (500

MHz)

100 mV/div 1 ns/div (500

MHz)

1 V/div 1 ns/div (500

MHz)

Table continued…

Performance verification procedures

≥ 0.707

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 47

Analog Bandwidth performance checks

Channel 6 50 Ω 1 mV/div 5 ns/div (Full

BW)

2 mV/div 2.5 ns/div (Full

BW)

5 mV/div 1 ns/div (Full

BW)

10 mV/div 1 ns/div (Full

BW)

50 mV/div 1 ns/div (Full

BW)

100 mV/div 1 ns/div (Full

BW)

1 V/div 1 ns/div (Full

BW)

Channel 6 1 MΩ, typical 1 mV/div 5 ns/div (500

MHz)

2 mV/div 2.5 ns/div (500

MHz)

5 mV/div 1 ns/div (500

MHz)

10 mV/div 1 ns/div (500

MHz)

50 mV/div 1 ns/div (500

MHz)

100 mV/div 1 ns/div (500

MHz)

1 V/div 1 ns/div (500

MHz)

500 MHz models

Channel 1 50 Ω 1 mV/div 5 ns/div (Full

BW)

2 mV/div 2.5 ns/div (Full

BW)

5 mV/div 1 ns/div (Full

BW)

10 mV/div 1 ns/div (Full

BW)

50 mV/div 1 ns/div (Full

BW)

100 mV/div 1 ns/div (Full

BW)

1 V/div 1 ns/div (Full

BW)

Table continued…

Performance verification procedures

≥ 0.707

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 48

Analog Bandwidth performance checks

Channel 1 1 MΩ, typical 1 mV/div 5 ns/div (500

MHz)

2 mV/div 2.5 ns/div (500

MHz)

5 mV/div 1 ns/div (500

MHz)

10 mV/div 1 ns/div (500

MHz)

50 mV/div 1 ns/div (500

MHz)

100 mV/div 1 ns/div (500

MHz)

1 V/div 1 ns/div (500

MHz)

Channel 2 50 Ω 1 mV/div 5 ns/div (Full

BW)

2 mV/div 2.5 ns/div (Full

BW)

5 mV/div 1 ns/div (Full

BW)

10 mV/div 1 ns/div (Full

BW)

50 mV/div 1 ns/div (Full

BW)

100 mV/div 1 ns/div (Full

BW)

1 V/div 1 ns/div (Full

BW)

Channel 2 1 MΩ, typical 1 mV/div 5 ns/div (500

MHz)

2 mV/div 2.5 ns/div (500

MHz)

5 mV/div 1 ns/div (500

MHz)

10 mV/div 1 ns/div (500

MHz)

50 mV/div 1 ns/div (500

MHz)

100 mV/div 1 ns/div (500

MHz)

1 V/div 1 ns/div (500

MHz)

Table continued…

Performance verification procedures

≥ 0.707

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 49

Analog Bandwidth performance checks

Channel 3 50 Ω 1 mV/div 5 ns/div (Full

BW)

2 mV/div 2.5 ns/div (Full

BW)

5 mV/div 1 ns/div (Full

BW)

10 mV/div 1 ns/div (Full

BW)

50 mV/div 1 ns/div (Full

BW)

100 mV/div 1 ns/div (Full

BW)

1 V/div 1 ns/div (Full

BW)

Channel 3 1 MΩ, typical 1 mV/div 5 ns/div (500

MHz)

2 mV/div 2.5 ns/div (500

MHz)

5 mV/div 1 ns/div (500

MHz)

10 mV/div 1 ns/div (500

MHz)

50 mV/div 1 ns/div (500

MHz)

100 mV/div 1 ns/div (500

MHz)

1 V/div 1 ns/div (500

MHz)

Channel 4 1 mV/div 5 ns/div (Full

BW)

2 mV/div 2.5 ns/div (Full

BW)

5 mV/div 1 ns/div (Full

BW)

10 mV/div 1 ns/div (Full

BW)

50 mV/div 1 ns/div (Full

BW)

100 mV/div 1 ns/div (Full

BW)

1 V/div 1 ns/div (Full

BW)

Table continued…

Performance verification procedures

≥ 0.707

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 50

Analog Bandwidth performance checks

Channel 4 1 MΩ, typical 1 mV/div 5 ns/div (500

MHz)

2 mV/div 2.5 ns/div (500

MHz)

5 mV/div 1 ns/div (500

MHz)

10 mV/div 1 ns/div (500

MHz)

50 mV/div 1 ns/div (500

MHz)

100 mV/div 1 ns/div (500

MHz)

1 V/div 1 ns/div (500

MHz)

500 MHz models (MSO46)

Channel 5 50 Ω 1 mV/div 5 ns/div (Full

BW)

2 mV/div 2.5 ns/div (Full

BW)

5 mV/div 1 ns/div (Full

BW)

10 mV/div 1 ns/div (Full

BW)

50 mV/div 1 ns/div (Full

BW)

100 mV/div 1 ns/div (Full

BW)

1 V/div 1 ns/div (Full

BW)

Channel 5 1 MΩ, typical 1 mV/div 5 ns/div (500

MHz)

2 mV/div 2.5 ns/div (500

MHz)

5 mV/div 1 ns/div (500

MHz)

10 mV/div 1 ns/div (500

MHz)

50 mV/div 1 ns/div (500

MHz)

100 mV/div 1 ns/div (500

MHz)

1 V/div 1 ns/div (500

MHz)

Table continued…

Performance verification procedures

≥ 0.707

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 51

Analog Bandwidth performance checks

Channel 6 50 Ω 1 mV/div 5 ns/div (Full

BW)

2 mV/div 2.5 ns/div (Full

BW)

5 mV/div 1 ns/div (Full

BW)

10 mV/div 1 ns/div (Full

BW)

50 mV/div 1 ns/div (Full

BW)

100 mV/div 1 ns/div (Full

BW)

1 V/div 1 ns/div (Full

BW)

Channel 6 1 MΩ, typical 1 mV/div 5 ns/div (500

MHz)

2 mV/div 2.5 ns/div (500

MHz)

5 mV/div 1 ns/div (500

MHz)

10 mV/div 1 ns/div (500

MHz)

50 mV/div 1 ns/div (500

MHz)

100 mV/div 1 ns/div (500

MHz)

1 V/div 1 ns/div (500

MHz)

350 MHz models

Channel 1 50 Ω 1 mV/div 5 ns/div (Full

BW)

2 mV/div 2.5 ns/div (Full

BW)

5 mV/div 1 ns/div (Full

BW)

10 mV/div 1 ns/div (Full

BW)

50 mV/div 1 ns/div (Full

BW)

100 mV/div 1 ns/div (Full

BW)

1 V/div 1 ns/div (Full

BW)

Table continued…

Performance verification procedures

≥ 0.707

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 52

Analog Bandwidth performance checks

Channel 1 1 MΩ, typical 1 mV/div 5 ns/div (500

MHz)

2 mV/div 2.5 ns/div (500

MHz)

5 mV/div 1 ns/div (500

MHz)

10 mV/div 1 ns/div (500

MHz)

50 mV/div 1 ns/div (500

MHz)

100 mV/div 1 ns/div (500

MHz)

1 V/div 1 ns/div (500

MHz)

Channel 2 50 Ω 1 mV/div 5 ns/div (Full

BW)

2 mV/div 2.5 ns/div (Full

BW)

5 mV/div 1 ns/div (Full

BW)

10 mV/div 1 ns/div (Full

BW)

50 mV/div 1 ns/div (Full

BW)

100 mV/div 1 ns/div (Full

BW)

1 V/div 1 ns/div (Full

BW)

Channel 2 1 MΩ, typical 1 mV/div 5 ns/div (500

MHz)

2 mV/div 2.5 ns/div (500

MHz)

5 mV/div 1 ns/div (500

MHz)

10 mV/div 1 ns/div (500

MHz)

50 mV/div 1 ns/div (500

MHz)

100 mV/div 1 ns/div (500

MHz)

1 V/div 1 ns/div (500

MHz)

Table continued…

Performance verification procedures

≥ 0.707

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 53

Analog Bandwidth performance checks

Channel 3 50 Ω 1 mV/div 5 ns/div (Full

BW)

2 mV/div 2.5 ns/div (Full

BW)

5 mV/div 1 ns/div (Full

BW)

10 mV/div 1 ns/div (Full

BW)

50 mV/div 1 ns/div (Full

BW)

100 mV/div 1 ns/div (Full

BW)

1 V/div 1 ns/div (Full

BW)

Channel 3 1 MΩ, typical 1 mV/div 5 ns/div (500

MHz)

2 mV/div 2.5 ns/div (500

MHz)

5 mV/div 1 ns/div (500

MHz)

10 mV/div 1 ns/div (500

MHz)

50 mV/div 1 ns/div (500

MHz)

100 mV/div 1 ns/div (500

MHz)

1 V/div 1 ns/div (500

MHz)

Channel 4 50 Ω 1 mV/div 5 ns/div (Full

BW)

2 mV/div 2.5 ns/div (Full

BW)

5 mV/div 1 ns/div (Full

BW)

10 mV/div 1 ns/div (Full

BW)

50 mV/div 1 ns/div (Full

BW)

100 mV/div 1 ns/div (Full

BW)

1 V/div 1 ns/div (Full

BW)

Table continued…

Performance verification procedures

≥ 0.707

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 54

Analog Bandwidth performance checks

Channel 4 1 MΩ, typical 1 mV/div 5 ns/div (500

MHz)

2 mV/div 2.5 ns/div (500

MHz)

5 mV/div 1 ns/div (500

MHz)

10 mV/div 1 ns/div (500

MHz)

50 mV/div 1 ns/div (500

MHz)

100 mV/div 1 ns/div (500

MHz)

1 V/div 1 ns/div (500

MHz)

Six channel models (MSO46)

Channel 5 50 Ω 1 mV/div 5 ns/div (Full

BW)

2 mV/div 2.5 ns/div (Full

BW)

5 mV/div 1 ns/div (Full

BW)

10 mV/div 1 ns/div (Full

BW)

50 mV/div 1 ns/div (Full

BW)

100 mV/div 1 ns/div (Full

BW)

1 V/div 1 ns/div (Full

BW)

Channel 5 1 MΩ, typical 1 mV/div 5 ns/div (500

MHz)

2 mV/div 2.5 ns/div (500

MHz)

5 mV/div 1 ns/div (500

MHz)

10 mV/div 1 ns/div (500

MHz)

50 mV/div 1 ns/div (500

MHz)

100 mV/div 1 ns/div (500

MHz)

1 V/div 1 ns/div (500

MHz)

Table continued…

Performance verification procedures

≥ 0.707

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 55

Analog Bandwidth performance checks

Channel 6 50 Ω 1 mV/div 5 ns/div (Full

BW)

2 mV/div 2.5 ns/div (Full

BW)

5 mV/div 1 ns/div (Full

BW)

10 mV/div 1 ns/div (Full

BW)

50 mV/div 1 ns/div (Full

BW)

100 mV/div 1 ns/div (Full

BW)

1 V/div 1 ns/div (Full

BW)

Channel 6 1 MΩ, typical 1 mV/div 5 ns/div (500

MHz)

2 mV/div 2.5 ns/div (500

MHz)

5 mV/div 1 ns/div (500

MHz)

10 mV/div 1 ns/div (500

MHz)

50 mV/div 1 ns/div (500

MHz)

100 mV/div 1 ns/div (500

MHz)

1 V/div 1 ns/div (500

MHz)

200 MHz

Channel 1 50 Ω 1 mV/div 5 ns/div (Full

BW)

2 mV/div 2.5 ns/div (Full

BW)

5 mV/div 1 ns/div (Full

BW)

10 mV/div 1 ns/div (Full

BW)

50 mV/div 1 ns/div (Full

BW)

100 mV/div 1 ns/div (Full

BW)

1 V/div 1 ns/div (Full

BW)

Table continued…

Performance verification procedures

≥ 0.707

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 56

Analog Bandwidth performance checks

Channel 1 1 MΩ, typical 1 mV/div 5 ns/div (500

MHz)

2 mV/div 2.5 ns/div (500

MHz)

5 mV/div 1 ns/div (500

MHz)

10 mV/div 1 ns/div (500

MHz)

50 mV/div 1 ns/div (500

MHz)

100 mV/div 1 ns/div (500

MHz)

1 V/div 1 ns/div (500

MHz)

Channel 2 50 Ω 1 mV/div 5 ns/div (Full

BW)

2 mV/div 2.5 ns/div (Full

BW)

5 mV/div 1 ns/div (Full

BW)

10 mV/div 1 ns/div (Full

BW)

50 mV/div 1 ns/div (Full

BW)

100 mV/div 1 ns/div (Full

BW)

1 V/div 1 ns/div (Full

BW)

Channel 2 1 MΩ, typical 1 mV/div 5 ns/div (500

MHz)

2 mV/div 2.5 ns/div (500

MHz)

5 mV/div 1 ns/div (500

MHz)

10 mV/div 1 ns/div (500

MHz)

50 mV/div 1 ns/div (500

MHz)

100 mV/div 1 ns/div (500

MHz)

1 V/div 1 ns/div (500

MHz)

Table continued…

Performance verification procedures

≥ 0.707

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 57

Analog Bandwidth performance checks

Channel 3 50 Ω 1 mV/div 5 ns/div (Full

BW)

2 mV/div 2.5 ns/div (Full

BW)

5 mV/div 1 ns/div (Full

BW)

10 mV/div 1 ns/div (Full

BW)

50 mV/div 1 ns/div (Full

BW)

100 mV/div 1 ns/div (Full

BW)

1 V/div 1 ns/div (Full

BW)

Channel 3 1 MΩ, typical 1 mV/div 5 ns/div (500

MHz)

2 mV/div 2.5 ns/div (500

MHz)

5 mV/div 1 ns/div (500

MHz)

10 mV/div 1 ns/div (500

MHz)

50 mV/div 1 ns/div (500

MHz)

100 mV/div 1 ns/div (500

MHz)

1 V/div 1 ns/div (500

MHz)

Channel 4 50 Ω 1 mV/div 5 ns/div (Full

BW)

2 mV/div 2.5 ns/div (Full

BW)

5 mV/div 1 ns/div (Full

BW)

10 mV/div 1 ns/div (Full

BW)

50 mV/div 1 ns/div (Full

BW)

100 mV/div 1 ns/div (Full

BW)

1 V/div 1 ns/div (Full

BW)

Table continued…

Performance verification procedures

≥ 0.707

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 58

Analog Bandwidth performance checks

Channel 4 1 MΩ, typical 1 mV/div 5 ns/div (500

MHz)

2 mV/div 2.5 ns/div (500

MHz)

5 mV/div 1 ns/div (500

MHz)

10 mV/div 1 ns/div (500

MHz)

50 mV/div 1 ns/div (500

MHz)

100 mV/div 1 ns/div (500

MHz)

1 V/div 1 ns/div (500

MHz)

Six channel models (MSO46)

Channel 5 50 Ω 1 mV/div 5 ns/div (Full

BW)

2 mV/div 2.5 ns/div (Full

BW)

5 mV/div 1 ns/div (Full

BW)

10 mV/div 1 ns/div (Full

BW)

50 mV/div 1 ns/div (Full

BW)

100 mV/div 1 ns/div (Full

BW)

1 V/div 1 ns/div (Full

BW)

Channel 5 1 MΩ, typical 1 mV/div 5 ns/div (500

MHz)

2 mV/div 2.5 ns/div (500

MHz)

5 mV/div 1 ns/div (500

MHz)

10 mV/div 1 ns/div (500

MHz)

50 mV/div 1 ns/div (500

MHz)

100 mV/div 1 ns/div (500

MHz)

1 V/div 1 ns/div (500

MHz)

Table continued…

Performance verification procedures

≥ 0.707

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 59

Analog Bandwidth performance checks

Channel 6 50 Ω 1 mV/div 5 ns/div (Full

BW)

2 mV/div 2.5 ns/div (Full

BW)

5 mV/div 1 ns/div (Full

BW)

10 mV/div 1 ns/div (Full

BW)

50 mV/div 1 ns/div (Full

BW)

100 mV/div 1 ns/div (Full

BW)

1 V/div 1 ns/div (Full

BW)

Channel 6 1 MΩ, typical 1 mV/div 5 ns/div (500

MHz)

2 mV/div 2.5 ns/div (500

MHz)

5 mV/div 1 ns/div (500

MHz)

10 mV/div 1 ns/div (500

MHz)

50 mV/div 1 ns/div (500

MHz)

100 mV/div 1 ns/div (500

MHz)

1 V/div 1 ns/div (500

MHz)

Performance verification procedures

≥ 0.707

Random Noise High Res acquisition mode test record

Random Noise, High Res acquisition mode unless otherwise noted: 1.5 GHz models

Performance checks 50 Ω

V/div Bandwidth (Sample

acq.mode)

Table continued…

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 60

Test result (mV) High limit (mV)

Performance verification procedures

Random Noise, High Res acquisition mode unless otherwise noted: 1.5 GHz models

Channel 1 1 mV/div 1.5 GHz 0.635

2 mV/div 1.5 GHz 0.635

5 mV/div 1.5 GHz 0.817

10 mV/div 1.5 GHz 0.843

20 mV/div 1.5 GHz 0.920

50 mV/div 1.5 GHz 1.582

100 mV/div 1.5 GHz 3.686

1 V/div 1.5 GHz 23.753

Channel 2 1 mV/div 1.5 GHz 0.635

2 mV/div 1.5 GHz 0.635

5 mV/div 1.5 GHz 0.817

10 mV/div 1.5 GHz 0.843

20 mV/div 1.5 GHz 0.920

50 mV/div 1.5 GHz 1.582

100 mV/div 1.5 GHz 3.686

1 V/div 1.5 GHz 23.753

Channel 3 1 mV/div 1.5 GHz 0.635

2 mV/div 1.5 GHz 0.635

5 mV/div 1.5 GHz 0.817

10 mV/div 1.5 GHz 0.843

20 mV/div 1.5 GHz 0.920

50 mV/div 1.5 GHz 1.582

100 mV/div 1.5 GHz 3.686

1 V/div 1.5 GHz 23.753

Channel 4 1 mV/div 1.5 GHz 0.635

2 mV/div 1.5 GHz 0.635

5 mV/div 1.5 GHz 0.817

10 mV/div 1.5 GHz 0.843

20 mV/div 1.5 GHz 0.920

50 mV/div 1.5 GHz 1.582

100 mV/div 1.5 GHz 3.686

1 V/div 1.5 GHz 23.753

Six channel models (MSO46)

Table continued…

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 61

Performance verification procedures

Random Noise, High Res acquisition mode unless otherwise noted: 1.5 GHz models

Channel 5 1 mV/div 1.5 GHz 0.635

2 mV/div 1.5 GHz 0.635

5 mV/div 1.5 GHz 0.817

10 mV/div 1.5 GHz 0.843

20 mV/div 1.5 GHz 0.920

50 mV/div 1.5 GHz 1.582

100 mV/div 1.5 GHz 3.686

1 V/div 1.5 GHz 23.753

Channel 6 1 mV/div 1.5 GHz 0.635

2 mV/div 1.5 GHz 0.635

5 mV/div 1.5 GHz 0.817

10 mV/div 1.5 GHz 0.843

20 mV/div 1.5 GHz 0.920

50 mV/div 1.5 GHz 1.582

100 mV/div 1.5 GHz 3.686

1 V/div 1.5 GHz 23.753

Random Noise, High Res acquisition mode: 1 GHz models

Performance checks 50 Ω

V/div Bandwidth (Sample

acq.mode)

Channel 1 1 mV/div 1 GHz 0.336

2 mV/div 1 GHz 0.363

5 mV/div 1 GHz 0.394

10 mV/div 1 GHz 0.434

20 mV/div 1 GHz 0.551

50 mV/div 1 GHz 1.038

100 mV/div 1 GHz 2.102

1 V/div 1 GHz 16.847

Channel 2 1 mV/div 1 GHz 0.336

2 mV/div 1 GHz 0.363

5 mV/div 1 GHz 0.394

10 mV/div 1 GHz 0.434

20 mV/div 1 GHz 0.551

50 mV/div 1 GHz 1.038

100 mV/div 1 GHz 2.102

1 V/div 1 GHz 16.847

Table continued…

Test result (mV) High limit (mV)

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 62

Performance verification procedures

Random Noise, High Res acquisition mode: 1 GHz models

Channel 3 1 mV/div 1 GHz 0.336

2 mV/div 1 GHz 0.363

5 mV/div 1 GHz 0.394

10 mV/div 1 GHz 0.434

20 mV/div 1 GHz 0.551

50 mV/div 1 GHz 1.038

100 mV/div 1 GHz 2.102

1 V/div 1 GHz 16.847

Channel 4 1 mV/div 1 GHz 0.336

2 mV/div 1 GHz 0.363

5 mV/div 1 GHz 0.394

10 mV/div 1 GHz 0.434

20 mV/div 1 GHz 0.551

50 mV/div 1 GHz 1.038

100 mV/div 1 GHz 2.102

1 V/div 1 GHz 16.847

Six channel models (MSO46)

Channel 5 1 mV/div 1 GHz 0.336

2 mV/div 1 GHz 0.363

5 mV/div 1 GHz 0.394

10 mV/div 1 GHz 0.434

20 mV/div 1 GHz 0.551

50 mV/div 1 GHz 1.038

100 mV/div 1 GHz 2.102

1 V/div 1 GHz 16.847

Channel 6 1 mV/div 1 GHz 0.336

2 mV/div 1 GHz 0.363

5 mV/div 1 GHz 0.394

10 mV/div 1 GHz 0.434

20 mV/div 1 GHz 0.551

50 mV/div 1 GHz 1.038

100 mV/div 1 GHz 2.102

1 V/div 1 GHz 16.847

Random Noise, High Res acquisition mode: 500 MHz models

Performance checks 1 MΩ 50 Ω

V/div Bandwidth Test result (mV) High limit (mV) Test result (mV) High limit (mV)

Table continued…

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 63

Performance verification procedures

Random Noise, High Res acquisition mode: 500 MHz models

Channel 1 1 mV/div 500 MHz 0.259 0.259

2 mV/div 500 MHz 0.259 0.259

5 mV/div 500 MHz 0.271 0.304

10 mV/div 500 MHz 0.298 0.356

20 mV/div 500 MHz 0.363 0.466

50 mV/div 500 MHz 0.674 1.038

100 mV/div 500 MHz 1.609 1.596

1 V/div 500 MHz 18.561 12.85

Channel 2 1 mV/div 500 MHz 0.259 0.259

2 mV/div 500 MHz 0.259 0.259

5 mV/div 500 MHz 0.271 0.304

10 mV/div 500 MHz 0.298 0.356

20 mV/div 500 MHz 0.363 0.466

50 mV/div 500 MHz 0.674 1.038

100 mV/div 500 MHz 1.609 1.596

1 V/div 500 MHz 18.561 12.85

Channel 3 1 mV/div 500 MHz 0.259 0.259

2 mV/div 500 MHz 0.259 0.259

5 mV/div 500 MHz 0.271 0.304

10 mV/div 500 MHz 0.298 0.356

20 mV/div 500 MHz 0.363 0.466

50 mV/div 500 MHz 0.674 1.038

100 mV/div 500 MHz 1.609 1.596

1 V/div 500 MHz 18.561 12.85

Channel 4 1 mV/div 500 MHz 0.259 0.259

2 mV/div 500 MHz 0.259 0.259

5 mV/div 500 MHz 0.271 0.304

10 mV/div 500 MHz 0.298 0.356

20 mV/div 500 MHz 0.363 0.466

50 mV/div 500 MHz 0.674 1.038

100 mV/div 500 MHz 1.609 1.596

1 V/div 500 MHz 18.561 12.85

Six channel models (MSO46)

Table continued…

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 64

Performance verification procedures

Random Noise, High Res acquisition mode: 500 MHz models

Channel 5 1 mV/div 500 MHz 0.259 0.259

2 mV/div 500 MHz 0.259 0.259

5 mV/div 500 MHz 0.271 0.304

10 mV/div 500 MHz 0.298 0.356

20 mV/div 500 MHz 0.363 0.466

50 mV/div 500 MHz 0.674 1.038

100 mV/div 500 MHz 1.609 1.596

1 V/div 500 MHz 18.561 12.85

Channel 6 1 mV/div 500 MHz 0.259 0.259

2 mV/div 500 MHz 0.259 0.259

5 mV/div 500 MHz 0.271 0.304

10 mV/div 500 MHz 0.298 0.356

20 mV/div 500 MHz 0.363 0.466

50 mV/div 500 MHz 0.674 1.038

100 mV/div 500 MHz 1.609 1.596

1 V/div 500 MHz 18.561 12.85

Random Noise, High Res acquisition mode: 350 MHz models

Performance checks 1 MΩ 50 Ω

V/div Bandwidth Test result (mV) High limit (mV) Test result (mV) High limit (mV)

Channel 1 1 mV/div 350 MHz 0.181 0.194

2 mV/div 350 MHz .0181 0.194

5 mV/div 350 MHz 0.194 0.239

10 mV/div 350 MHz 0.206 0.284

20 mV/div 350 MHz 0.259 0.349

50 mV/div 350 MHz 0.479 0.739

100 mV/div 350 MHz 1.141 1.349

1 V/div 350 MHz 13.239 11.617

Channel 2 1 mV/div 350 MHz 0.181 0.194

2 mV/div 350 MHz .0181 0.194

5 mV/div 350 MHz 0.194 0.239

10 mV/div 350 MHz 0.206 0.284

20 mV/div 350 MHz 0.259 0.349

50 mV/div 350 MHz 0.479 0.739

100 mV/div 350 MHz 1.141 1.349

1 V/div 350 MHz 13.239 11.617

Table continued…

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 65

Performance verification procedures

Random Noise, High Res acquisition mode: 350 MHz models

Channel 3 1 mV/div 350 MHz 0.181 0.194

2 mV/div 350 MHz .0181 0.194

5 mV/div 350 MHz 0.194 0.239

10 mV/div 350 MHz 0.206 0.284

20 mV/div 350 MHz 0.259 0.349

50 mV/div 350 MHz 0.479 0.739

100 mV/div 350 MHz 1.141 1.349

1 V/div 350 MHz 13.239 11.617

Channel 4 1 mV/div 350 MHz 0.181 0.194

2 mV/div 350 MHz .0181 0.194

5 mV/div 350 MHz 0.194 0.239

10 mV/div 350 MHz 0.206 0.284

20 mV/div 350 MHz 0.259 0.349

50 mV/div 350 MHz 0.479 0.739

100 mV/div 350 MHz 1.141 1.349

1 V/div 350 MHz 13.239 11.617

Six channel models (MSO46)

Channel 5 1 mV/div 350 MHz 0.181 0.194

2 mV/div 350 MHz .0181 0.194

5 mV/div 350 MHz 0.194 0.239

10 mV/div 350 MHz 0.206 0.284

20 mV/div 350 MHz 0.259 0.349

50 mV/div 350 MHz 0.479 0.739

100 mV/div 350 MHz 1.141 1.349

1 V/div 350 MHz 13.239 11.617

Channel 6 1 mV/div 350 MHz 0.181 0.194

2 mV/div 350 MHz .0181 0.194

5 mV/div 350 MHz 0.194 0.239

10 mV/div 350 MHz 0.206 0.284

20 mV/div 350 MHz 0.259 0.349

50 mV/div 350 MHz 0.479 0.739

100 mV/div 350 MHz 1.141 1.349

1 V/div 350 MHz 13.239 11.617

Random Noise, High Res acquisition mode: 200 MHz models

Performance checks 1 MΩ 50 Ω

V/div Bandwidth Test result (mV) High limit (mV) Test result (mV) High limit (mV)

Table continued…

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 66

Performance verification procedures

Random Noise, High Res acquisition mode: 200 MHz models

Channel 1 1 mV/div 200 MHz 0.181 0.194

2 mV/div 200 MHz 0.181 0.194

5 mV/div 200 MHz 0.194 0.239

10 mV/div 200 MHz 0.206 0.284

20 mV/div 200 MHz 0.259 0.349

50 mV/div 200 MHz 0.479 0.739

100 mV/div 200 MHz 1.141 1.349

1 V/div 200 MHz 13.239 11.617

Channel 2 1 mV/div 200 MHz 0.181 0.194

2 mV/div 200 MHz 0.181 0.194

5 mV/div 200 MHz 0.194 0.239

10 mV/div 200 MHz 0.206 0.284

20 mV/div 200 MHz 0.259 0.349

50 mV/div 200 MHz 0.479 0.739

100 mV/div 200 MHz 1.141 1.349

1 V/div 200 MHz 13.239 11.617

Channel 3 1 mV/div 0.181 0.194

2 mV/div 0.181 0.194

5 mV/div 0.194 0.239

10 mV/div 0.206 0.284

20 mV/div 0.259 0.349

50 mV/div 0.479 0.739

100 mV/div 1.141 1.349

1 V/div 13.239 11.617

Channel 4 1 mV/div 0.181 0.194

2 mV/div 0.181 0.194

5 mV/div 0.194 0.239

10 mV/div 0.206 0.284

20 mV/div 0.259 0.349

50 mV/div 0.479 0.739

100 mV/div 1.141 1.349

1 V/div 13.239 11.617

Six channel models (MSO46)

Table continued…

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 67

Performance verification procedures

Random Noise, High Res acquisition mode: 200 MHz models

Channel 5 1 mV/div 0.181 0.194

2 mV/div 0.181 0.194

5 mV/div 0.194 0.239

10 mV/div 0.206 0.284

20 mV/div 0.259 0.349

50 mV/div 0.479 0.739

100 mV/div 1.141 1.349

1 V/div 13.239 11.617

Channel 6 1 mV/div 0.181 0.194

2 mV/div 0.181 0.194

5 mV/div 0.194 0.239

10 mV/div 0.206 0.284

20 mV/div 0.259 0.349

50 mV/div 0.479 0.739

100 mV/div 1.141 1.349

1 V/div 13.239 11.617

Long term sample rate through AFG DC offset accuracy test records

Long Term Sample Rate

Performance checks Low limit Test result High limit

Long Term Sample Rate -2 divisions +2 divisions

Digital Threshold Accuracy, typical

Performance checks:

Digital channel Threshold V

s–

All models

Channel 1

D0 0 V -0.1 V 0.1 V

D1 0 V -0.1 V 0.1 V

D2 0 V -0.1 V 0.1 V

D3 0 V -0.1 V 0.1 V

D4 0 V -0.1 V 0.1 V

D5 0 V -0.1 V 0.1 V

D6 0 V -0.1 V 0.1 V

D7 0 V -0.1 V 0.1 V

Channel 2

Table continued…

Low limit Test result High limit

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 68

Performance verification procedures

Digital Threshold Accuracy, typical

D0 0 V -0.1 V 0.1 V

D1 0 V -0.1 V 0.1 V

D2 0 V -0.1 V 0.1 V

D3 0 V -0.1 V 0.1 V

D4 0 V -0.1 V 0.1 V

D5 0 V -0.1 V 0.1 V

D6 0 V -0.1 V 0.1 V

D7 0 V -0.1 V 0.1 V

Channel 3

D0 0 V -0.1 V 0.1 V

D1 0 V -0.1 V 0.1 V

D2 0 V -0.1 V 0.1 V

D3 0 V -0.1 V 0.1 V

D4 0 V -0.1 V 0.1 V

D5 0 V -0.1 V 0.1 V

D6 0 V -0.1 V 0.1 V

D7 0 V -0.1 V 0.1 V

Channel 4

D0 0 V -0.1 V 0.1 V

D1 0 V -0.1 V 0.1 V

D2 0 V -0.1 V 0.1 V

D3 0 V -0.1 V 0.1 V

D4 0 V -0.1 V 0.1 V

D5 0 V -0.1 V 0.1 V

D6 0 V -0.1 V 0.1 V

D7 0 V -0.1 V 0.1 V

MSO46 models

Channel 5

D0 0 V -0.1 V 0.1 V

D1 0 V -0.1 V 0.1 V

D2 0 V -0.1 V 0.1 V

D3 0 V -0.1 V 0.1 V

D4 0 V -0.1 V 0.1 V

D5 0 V -0.1 V 0.1 V

D6 0 V -0.1 V 0.1 V

D7 0 V -0.1 V 0.1 V

Channel 6

Table continued…

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 69

Performance verification procedures

Digital Threshold Accuracy, typical

D0 0 V -0.1 V 0.1 V

D1 0 V -0.1 V 0.1 V

D2 0 V -0.1 V 0.1 V

D3 0 V -0.1 V 0.1 V

D4 0 V -0.1 V 0.1 V

D5 0 V -0.1 V 0.1 V

D6 0 V -0.1 V 0.1 V

D7 0 V -0.1 V 0.1 V

AUX Out output voltage levels

Performance checks Vout Low limit Test result High limit

Output levels, 1 MΩ input impedance

Output levels, 50 Ω Input Impedance,

Max ≥ 2.5 V n/a

Min n/a ≤ 700 mV

Max ≥ 2.5 V n/a

Min n/a ≤ 250 mV

DVM voltage accuracy (DC)

Channel 1

Vertical Scale Input Voltage Offset Voltage Low limit Test result High limit

1 –5 –5 -5.125 -4.875

0.5 –2 –2 -2.06 -1.94

0.5 –1 –0.5 -1.06 -0.94

0.2 –0.5 –0.5 -0.5225 -0.4775

0.01 0.002 0 0.00097 0.00303

0.2 0.5 0.5 0.4775 0.5225

0.5 1 0.5 0.94 1.06

0.5 2 2 1.94 2.06

1 5 5 4.875 5.125

Channel 2

Vertical Scale Input Voltage Offset Voltage Low limit Test result High limit

1 –5 –5 -5.125 -4.875

0.5 –2 –2 -2.06 -1.94

0.5 –1 –0.5 -1.06 -0.94

0.2 –0.5 –0.5 -0.5225 -0.4775

0.01 0.002 0 0.00097 0.00303

Table continued…

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 70

Performance verification procedures

DVM voltage accuracy (DC)

0.2 0.5 0.5 0.4775 0.5225

0.5 1 0.5 0.94 1.06

0.5 2 2 1.94 2.06

1 5 5 4.875 5.125

Channel 3

Vertical Scale Input Voltage Offset Voltage Low limit Test result High limit

1 -5 -5 -5.125 -4.875

0.5 -2 -2 -2.06 -1.94

0.5 -1 -0.5 -1.06 -0.94

0.2 -0.5 -0.5 -0.5225 -0.4775

0.01 0.002 0 0.00097 0.00303

0.2 0.5 0.5 0.4775 0.5225

0.5 1 0.5 0.94 1.06

0.5 2 2 1.94 2.06

1 5 5 4.875 5.125

Channel 4

Vertical Scale Input Voltage Offset Voltage Low limit Test result High limit

1 -5 -5 -5.125 -4.875

0.5 -2 -2 -2.06 -1.94

0.5 –1 -0.5 -1.06 -0.94

0.2 -0.5 -0.5 -0.5225 -0.4775

0.01 0.002 0 0.00097 0.00303

0.2 0.5 0.5 0.4775 0.5225

0.5 1 0.5 0.94 1.06

0.5 2 2 1.94 2.06

1 5 5 4.875 5.125

DVM voltage accuracy (DC)

MSO46 models

Channel 5

Vertical Scale Input Voltage Offset Voltage Low limit Test result High limit

1 -5 -5 -5.125 -4.875

0.5 -2 -2 -2.06 -1.94

0.5 -1 -0.5 -1.06 -0.94

0.2 -0.5 -0.5 -0.5225 -0.4775

0.01 0.002 0 0.00097 0.00303

0.2 0.5 0.5 0.4775 0.5225

Table continued…

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 71

Performance verification procedures

DVM voltage accuracy (DC)

0.5 1 0.5 0.94 1.06

0.5 2 2 1.94 2.06

1 5 5 4.875 5.125

Channel 6

Vertical Scale Input Voltage Offset Voltage Low limit Test result High limit

1 -5 -5 -5.125 -4.875

0.5 -2 -2 -2.06 -1.94

0.5 -1 -0.5 -1.06 -0.94

0.2 -0.5 -0.5 -0.5225 -0.4775

0.01 0.002 0 0.00097 0.00303

0.2 0.5 0.5 0.4775 0.5225

0.5 1 0.5 0.94 1.06

0.5 2 2 1.94 2.06

1 5 5 4.875 5.125

DVM voltage accuracy (AC)

All models

Channel 1

Vertical Scale Input Signal Low limit Test result High limit

5 mV 20 mVpp at 1 kHz 9.800 mV 10.200 mV

10 mV 50 mVpp at 1 kHz 24.5 mV 25.500 mV

100 mV 0.5 Vpp at 1 kHz 245.000 mV 255.000 mV

200 mV 1 Vpp at 1 kHz 490.000 mV 510.000 mV

1 V 5 Vpp at 1 kHz 2.450 mV 2.550 mV

Channel 2

Vertical Scale Input Signal Low limit Test result High limit

5 mV 20 mVpp at 1 kHz 9.800 mV 10.200 mV

10 mV 50 mVpp at 1 kHz 24.5 mV 25.500 mV

100 mV 0.5 Vpp at 1 kHz 245.000 mV 255.000 mV

200 mV 1 Vpp at 1 kHz 490.000 mV 510.000 mV

1 V 5 Vpp at 1 kHz 2.450 mV 2.550 mV

Channel 3

Vertical Scale Input Signal Low limit Test result High limit

5 mV 20 mVpp at 1 kHz 9.800 mV 10.200 mV

10 mV 50 mVpp at 1 kHz 24.5 mV 25.500 mV

Table continued…

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 72

Performance verification procedures

DVM voltage accuracy (AC)

100 mV 0.5 Vpp at 1 kHz 245.000 mV 255.000 mV

200 mV 1 Vpp at 1 kHz 490.000 mV 510.000 mV

1 V 5 Vpp at 1 kHz 2.450 mV 2.550 mV

Channel 4

Vertical Scale Input Signal Low limit Test result High limit

5 mV 20 mVpp at 1 kHz 9.800 mV 10.200 mV

10 mV 50 mVpp at 1 kHz 24.5 mV 25.500 mV

100 mV 0.5 Vpp at 1 kHz 245.000 mV 255.000 mV

200 mV 1 Vpp at 1 kHz 490.000 mV 510.000 mV

1 V 5 Vpp at 1 kHz 2.450 mV 2.550 mV

MSO46 models

Channel 5

Vertical Scale Input Signal Low limit Test result High limit

5 mV 20 mVpp at 1 kHz 9.800 mV 10.200 mV

10 mV 50 mVpp at 1 kHz 24.5 mV 25.500 mV

100 mV 0.5 Vpp at 1 kHz 245.000 mV 255.000 mV

200 mV 1 Vpp at 1 kHz 490.000 mV 510.000 mV

1 V 5 Vpp at 1 kHz 2.450 mV 2.550 mV

Channel 6

Vertical Scale Input Signal Low limit Test result High limit

5 mV 20 mVpp at 1 kHz 9.800 mV 10.200 mV

10 mV 50 mVpp at 1 kHz 24.5 mV 25.500 mV

100 mV 0.5 Vpp at 1 kHz 245.000 mV 255.000 mV

200 mV 1 Vpp at 1 kHz 490.000 mV 510.000 mV

1 V 5 Vpp at 1 kHz 2.450 mV 2.550 mV

Trigger frequency accuracy and trigger frequency counter maximum input frequency

All models

Table continued…

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 73

Performance verification procedures

Trigger frequency accuracy and trigger frequency counter maximum input frequency

Channel 1 Hz Low limit Test result High limit

100 Hz 99.99974 Hz 100.00026 Hz

1 kHz 999.9974 Hz 1.0000026 KHz

10 kHz 9.999974 KHz 10.000026 kHz

100 kHz 99.99974 kHz 100.00026 kHz

1 MHz 999.9974 kHz 1.0000026 MHz

10 MHz 9.999974 kHz 10.000026 MHz

100 MHz 99.99974 MHz 100.00026 MHz

1 GHz

1.5 GHz

999.9974 MHz 1.0000026 GHz

1.499994 GHz 1.5000051 GHz

Channel 2 Hz Low limit Test result High limit

100 Hz 99.99974 Hz 100.00026 Hz

1 kHz 999.9974 Hz 1.0000026 KHz

10 kHz 9.999974 KHz 10.000026 kHz

100 kHz 99.99974 kHz 100.00026 kHz

1 MHz 999.9974 kHz 1.0000026 MHz

10 MHz 9.999974 kHz 10.000026 MHz

100 MHz 99.99974 MHz 100.00026 MHz

1 GHz

1.5 GHz

999.9974 MHz 1.0000026 GHz

1.499994 GHz 1.5000051 GHz

Channel 3 Hz Low limit Test result High limit

100 Hz 99.99974 Hz 100.00026 Hz

1 kHz 999.9974 Hz 1.0000026 KHz

10 kHz 9.999974 KHz 10.000026 kHz

100 kHz 99.99974 kHz 100.00026 kHz

1 MHz 999.9974 kHz 1.0000026 MHz

10 MHz 9.999974 kHz 10.000026 MHz

100 MHz 99.99974 MHz 100.00026 MHz

1 GHz

1.5 GHz

999.9974 MHz 1.0000026 GHz

1.499994 GHz 1.5000051 GHz

Table continued…

1 GHz models only.

1.5 GHz models only.

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 74

Performance verification procedures

Trigger frequency accuracy and trigger frequency counter maximum input frequency

Channel 4 Hz Low limit Test result High limit

100 Hz 99.99974 Hz 100.00026 Hz

1 kHz 999.9974 Hz 1.0000026 KHz

10 kHz 9.999974 KHz 10.000026 kHz

100 kHz 99.99974 kHz 100.00026 kHz

1 MHz 999.9974 kHz 1.0000026 MHz

10 MHz 9.999974 kHz 10.000026 MHz

100 MHz 99.99974 MHz 100.00026 MHz

1 GHz

1.5 GHz

999.9974 MHz 1.0000026 GHz

1.499994 GHz 1.5000051 GHz

Trigger frequency accuracy and trigger frequency counter maximum input frequency

MSO46 models

Channel 5 Hz Low limit Test result High limit

100 Hz 99.99974 Hz 100.00026 Hz

1 kHz 999.9974 Hz 1.0000026 KHz

10 kHz 9.999974 KHz 10.000026 kHz

100 kHz 99.99974 kHz 100.00026 kHz

1 MHz 999.9974 kHz 1.0000026 MHz

10 MHz 9.999974 kHz 10.000026 MHz

100 MHz 99.99974 MHz 100.00026 MHz

1 GHz

1.5 GHz

999.9974 MHz 1.0000026 GHz

1.499994 GHz 1.5000051 GHz

Channel 6 Hz Low limit Test result High limit

100 Hz 99.99974 Hz 100.00026 Hz

1 kHz 999.9974 Hz 1.0000026 KHz

10 kHz 9.999974 KHz 10.000026 kHz

100 kHz 99.99974 kHz 100.00026 kHz

1 MHz 999.9974 kHz 1.0000026 MHz

10 MHz 9.999974 kHz 10.000026 MHz

100 MHz 99.99974 MHz 100.00026 MHz

1 GHz

1.5 GHz

999.9974 MHz 1.0000026 GHz

1.499994 GHz 1.5000051 GHz

AFG sine and ramp frequency accuracy

Performance checks

Table continued…

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 75

AFG sine and ramp frequency accuracy

Waveform type Minimum Test result Maximum

Sine 0.999950 MHz 1.000050 MHz

Ramp 499.975 kHz 500.025 kHz

AFG square and pulse frequency accuracy

Performance checks

Waveform type Minimum Test result Maximum

Sine 0.999950 MHz 1.000050 MHz

Pulse 0.999950 MHz 500.025 kHz

AFG signal amplitude accuracy

Performance checks

Amplitude Minimum Test result Maximum

30.0 mV

300.0 mV

800.0 mV

1.500 V

2.000 V

2.500 V

28.55 mV

294.5 mV

787.0 mV

1.4765 V

1.9690 V

2.4615 V

Performance verification procedures

31.45 mV

305.5 mV

813.0 mV

1.5235 V

2.0310 V

2.5385 V

AFG DC offset accuracy

Performance checks

Offset Minimum Test result Maximum

1.25 V 1.23025 Vdc 1.26975 Vdc

0 V -0.001 Vdc +0.001 Vdc

-1.25 V -1.26975 -1.23025 Vdc

Performance tests

This section contains a collection of manual procedures for checking that the instrument performs as warranted. They check all the characteristics that are designated as checked in Specifications. (The characteristics that are checked appear with a in Specifications).

Prerequisites

The tests in this section comprise an extensive, valid confirmation of performance and functionality when the following requirements are met:

• The instrument must be in its normal operating configuration (no covers removed).

• You must have performed and passed the procedures under Self Test. (See Self test on page 77.)

• A signal-path compensation must have been done within the recommended calibration interval and at a temperature within ±5 ºC (±9 ºF) of the present operating temperature. (If the temperature was within the limits just stated at the time you did the prerequisite

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 76

Performance verification procedures

Self Test, consider this prerequisite met). A signal-path compensation must have been done at an ambient humidity within 25% of the current ambient humidity and after having been at that humidity for at least 4 hours.

• The instrument must have been last adjusted at an ambient temperature between +18 ºC and +28 ºC (+64 ºF and +82 ºF), must have been operating for a warm-up period of at least 20 minutes, and must be operating at an ambient temperature as listed in the specifications. The warm-up requirement is usually met in the course of meeting the Self Test prerequisites listed above.

• The instrument must be powered from a source maintaining voltage and frequency within the limits described in the Specifications section.

• The instrument must be in an environment with temperature, altitude, humidity, and vibration within the operating limits described in the Specifications section.

Self test

This procedure verifies that the instrument passes the internal diagnostics and performs signal path compensation. No test equipment or hookups are required.

Equipment required Prerequisites

None Power on the instrument and allow a 20 minute warm-up period

before performing this procedure.

1. Run the System Diagnostics (may take a few minutes):

a. Disconnect all probes and/or cables from the oscilloscope inputs.

b. Tap Utility > Self Test. This displays the Self Test configuration menu.

c. Tap the Run Self Test button.

d. The internal diagnostics perform an exhaustive verification of proper instrument function. This verification may take several

minutes. When the verification is finished, the status of each self test is shown in the menu.

e. Verify that the status of all tests is Pass.

f. Tap anywhere outside the menu to exit the menu.

2. Run the signal-path compensation routine (may take 5 to 15 minutes per channel):

a. Tap Utility > Calibration. This displays the Calibration configuration menu.

b. Tap the Run SPC button to start the routine.

c. Signal-path compensation may take 5 to 15 minutes to run per channel.

d. Verify that the SPC Status is Passed.

3. Return to regular service: Tap anywhere outside the menu to exit the Calibration menu.

The self test procedures are completed. If any of the above tests failed, run the tests again. If there are still failures, contact Tektronix Customer Support.

You cannot run the remaining performance tests until the self tests pass and the SPC has successfully run.

Note:

Check input impedance

This test checks the input impedance on all channels.

1. Connect the output of the oscilloscope calibrator (for example, Fluke 9500) to the oscilloscope channel 1 input, as shown in the following illustration.

Warning:

during the performance of this procedure. The generator is capable of providing dangerous voltages.

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 77

Be sure to set the generator to Off or 0 volts before connecting, disconnecting, and/or moving the test hookup

Performance verification procedures

Note: Impedance measuring equipment that produces a voltage across the channel that exceeds the measurement range of the instrument may report erroneous impedance results. A measurement voltage exceeds the measurement range of the instrument when the resulting trace is not visible on the graticule.

2. Set the calibrator to measure 1 MΩ impedance.

3. Tap File > Default Setup.

4. Test 1 MΩ input impedance as follows:

a. Tap the channel 1 button on the Settings bar.

b. Double tap the Ch 1 badge to open its menu.

c. Set Termination to 1 MΩ.

d. Set the Vertical Scale to the value to test in the test record (first value is 10 mV/div).

5. Use the calibrator to measure the input impedance of the oscilloscope and enter the value in the test record.

6. Repeat steps 4.d on page 78 and 5 on page 78 for all vertical scale settings in the test record for the channel.

7. Test 50 Ω input impedance as follows:

a. Set the calibrator impedance to measure 50 Ω impedance.

b. Double-tap the Ch 1 badge and set Termination to 50 Ω.

c. Repeat steps 4.d on page 78 through 6 on page 78 for all vertical scale settings in the test record for the channel.

8. Repeat the procedures for all remaining channels as follows:

a. Turn the calibrator output Off.

b. Move the calibrator connection to the next channel to test.

c. Double-tap the channel badge of the channel that you have finished testing and set Display to Off.

d. Tap the channel button on the Settings bar of the next channel to test.

e. Starting from step 2 on page 78, repeat the procedures until all channels have been tested.

Check DC gain accuracy

This test checks the DC gain accuracy.

1. Connect the oscilloscope to a calibrated DC voltage source. If you are using the Fluke 9500 calibrator, connect the calibrator head to

the oscilloscope channel to test.

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 78

Warning: Set the generator output to Off or 0 volts before connecting, disconnecting, and/or moving the test hookup during the performance of this procedure. The generator is capable of providing dangerous voltages.

2. Tap File > Default Setup.

3. Double-tap the Acquisition badge and set Acquisition Mode to Average.

4. Set the Number of Waveforms to 16.

5. Tap outside the menu to close the menu.

6. Double-tap the Trigger badge and set the trigger Source to AC line.

7. Tap outside the menu to close it.

8. Add the Mean measurement to the Results bar:

Performance verification procedures

a. Tap the Add New... Measure button to open the Add Measurements menu.

b. Set the Source to Ch 1.

c. In the Amplitude Measurements panel, double-tap the Mean button to add the Mean measurement badge to the Results bar.

9. Tap outside the menu to close it.

10. Double-tap the Mean results badge.

11. Tap Show Statistics in Badge.

12. Tap FILTER/LIMIT RESULTS to open the panel.

13. Tap Limit Measurement Population to toggle it to On.

14. Tap outside the menu to close it.

15. Tap the channel button of the channel to test, to add the channel badge to the Settings bar.

16. Double tap the channel to test badge to open its menu and set the channel settings:

a. Set Vertical Scale to 1 mV/div.

b. Set Termination to 50 Ω.

c. Tap Bandwidth Limit and set to 20 MHz.

d. Tap outside the menu to close it.

17. Record the negative-measured and positive-measured mean readings in the Expected gain worksheet as follows:

a. On the calibrator, set the DC Voltage Source to the V

value as listed in the 1 mV row of the worksheet.

negative

b. Double-tap the Acquisition badge and tap Clear to reset the measurement statistics.

c. Enter the Mean reading in the worksheet as V

negative-measured

d. On the calibrator, set the DC Voltage Source to V

positive

value as listed in the 1 mV row of the worksheet.

e. Double-tap the Acquisition badge (if not open) and tap Clear.

f. Enter the Mean reading in the worksheet as V

positive-measured

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 79

Table 1: Expected gain worksheet

Performance verification procedures

Oscilloscope

diffExpected

vertical scale setting

1 mV/div

2 mV/div

5 mV/div

10 mV/div

20 mV/div

50 mV/div

100 mV/div

200 mV/div

500 mV/div

1.0 V/div

20 mV/div at 250 MHz

20 mV/div at Full BW

18. Calculate Gain Accuracy as follows:

a. Calculate V

as follows:

diff

negative

positive

negative-

measured

positive-

measured

diff

Test result (Gain accuracy)

= | V

diff

b. Enter V

negative-measured

in the worksheet.

diff

- V

positive-measured

c. Calculate Gain Accuracy as follows:

Gain Accuracy = ((V

diff

- V

diffExpected

)/V

diffExpected

) × 100%

d. Enter the Gain Accuracy value in the worksheet and in the test record.

19. Repeat steps 16 on page 79 through 18 on page 80 for all vertical scale settings in the work sheet and the test record.

20. Repeat tests at 1 MΩ impedance as follows:

a. Set the calibrator to 0 volts and 1 MΩ output impedance.

b. Double-tap the badge of the channel being tested.

c. Set the Termination to 1 MΩ

d. Repeat steps 16 on page 79 through 19 on page 80 for all vertical scale settings in the test record.

21. Repeat the procedure for all remaining channels:

a. Set the calibrator to 0 volts and 50 Ω output impedance.

b. Move the calibrator output to the next channel input to be tested.

c. Double-tap the channel badge of the channel that you have finished testing and set Display to Off.

d. Double-tap the Mean measurement badge.

e. Tap the Configure panel.

f. Tap the Source 1 field and select the next channel to test.

g. Starting from step16 on page 79, set the values from the test record for the channel under test, and repeat the above steps until

all channels have been tested.

22. Touch outside a menu to close the menu.

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 80

Performance verification procedures

Check DC offset accuracy

This test checks the offset accuracy at 50 Ω and 1 MΩ input impedances.

1. Connect the oscilloscope to a calibrated DC voltage source. If you are using the Fluke 9500B calibrator as the DC voltage source,

connect the calibrator head to the oscilloscope channel 1.

Warning: Set the generator output to Off or 0 volts before connecting, disconnecting, or moving the test hookup during the performance of this procedure. The generator is capable of providing dangerous voltages.

2. Tap File > Default Setup.

3. Double-tap the Acquisition badge and set Acquisition Mode to Average.

4. Set the Number of Waveforms to 16.

5. Tap outside the menu to close the menu.

6. Double-tap the Trigger badge and set the trigger Source to AC line.

7. Add the Mean measurement to the Results bar:

a. Tap the Add New... Measure button to open the Add Measurements menu.

b. Set the Source to Ch 1.

c. In the Amplitude Measurements panel, double-tap the Mean button to add the Mean measurement badge to the Results bar.

8. Tap outside the menu to close it.

9. Double-tap the Mean results badge.

10. Tap Show Statistics in Badge.

11. Tap FILTER/LIMIT RESULTS to open the panel.

12. Tap Limit Measurement Population to toggle it to On.

13. Tap outside the menu to close it.

14. Tap the channel button on the Settings bar to add the channel under test to the Settings bar.

15. Double-tap the channel under test badge to open its configuration menu and change the vertical settings:

a. Set Vertical Scale to 1 mV/div.

b. Set Offset to 900 mV.

c. Set Position to 0 by tapping Set to 0.

d. Set Termination to 50 Ω.

e. Tap Bandwidth Limit and set to 20 MHz.

f. Tap outside the menu to close it.

16. Set the calibrator output to +900 mV, as shown in the test record, and turn the calibrator output On.

17. Enter the Mean measurement value in the test record.

18. Double-tap the channel under test badge to open its configuration menu and change the Offset to -900 mV.

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 81

Performance verification procedures

19. Set the calibrator output to -900 mV, as shown in the test record.

20. Enter the Mean measurement value in the test record.

21. Repeat step 15 on page 81 through 20 on page 82, changing the channel vertical settings and the calibrator output as listed in the

test record for the channel under test.

22. Repeat the channel tests at 1 MΩ impedance as follows:

a. Set the calibrator output to Off or 0 volts.

b. Change the calibrator impedance to 1 MΩ and voltage to +900 mV.

c. Turn the calibrator output On.

d. Repeat steps 15 on page 81 through 20 on page 82, changing the channel Termination to 1 MΩ and the vertical Offset value

and the calibrator output as listed in the 1 MΩ test record for the channel under test.

23. Repeat the procedure for all remaining channels as follows:

a. Double-tap the Mean measurement badge.

b. Tap the Configure panel.

c. Tap the Source 1 field and select the next channel to test.

d. Set the calibrator to 0 volts and 50 Ω output impedance.

e. Move the calibrator output to the next channel input to test.

f. Double-tap the channel badge of the channel that you have finished testing and set Display to Off.

g. Tap the channel button on the oscilloscope Settings bar of the next channel to test.

h. Starting from step , repeat the procedure until all channels have been tested.

Check analog bandwidth

This test checks the bandwidth at 50 Ω and 1 MΩ terminations for each channel. The typical bandwidth at 1 M Ω termination is checked on the products as a functional check.

1. Connect the output of the calibrated leveled sine wave generator to the oscilloscope channel 1 input as shown in the following

illustration.

Warning:

performance of this procedure. The generator is capable of providing dangerous voltages.

2. Tap File > Default Setup to reset the instrument and add the channel 1 badge and signal to the display.

3. Add the peak-to-peak measurement as follows:

Set the generator to off or 0 volts before connecting, disconnecting, and/or moving the test hookup during the

a. Tap the Add New. Measure button.

b. Set the Source to the channel under test.

c. In the Amplitude Measurements panel, double-tap the Peak-to-Peak measurement button to add the measurement badge to

the Results bar.

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 82

Performance verification procedures

d. Tap outside the menu to close it.

e. Double-tap the Peak-to-Peak results badge.

f. Tap Show Statistics in Badge.

g. Tap FILTER/LIMIT RESULTS to open the panel.

h. Tap Limit Measurement Population to toggle it to On.

i. Tap outside the menu to close it.

4. Set the channel under test settings:

a. Double-tap the badge of the channel under test to open its configuration menu.

b. Set Vertical Scale to 1 mV/div.

c. Set Termination to 50 Ω.

d. Tap outside the menu to close it.

5. Adjust the leveled sine wave signal source to display a waveform of 8 vertical divisions at the selected vertical scale with a set

frequency of 10 MHz. For example, at 5 mV/div, use a ≥40 mV

signal; at 2 mV/div, use a ≥16 mV

p-p

signal.

Note: At some V/div settings, the generator may not provide 8 vertical divisions of signal. Set the generator output to obtain as many vertical divisions of signal as possible.

6. Double-tap the Horizontal badge in the Settings bar.

7. Set the Horizontal Scale to 1 ms/division.

8. Tap outside the menu to close it.

9. Record the Peak-to-Peak measurement in the V

entry of the test record.

in-pp

10. Double-tap the Horizontal badge in the Settings bar.

11. Set the Horizontal Scale to 4 ns/division .

12. Adjust the signal source to the maximum bandwidth frequency for the bandwidth and model being tested.

13. Record the peak-to-peak measurement as follows:

a. Record the Peak-to-Peak measurement at the new frequency in the V

entry of the test record.

bw-pp

14. Use the values of V bw-pp and V in-pp recorded in the test record, and the following equation, to calculate the Gain at bandwidth:

Gain = Vbw-pp / Vin-pp.

To pass the performance measurement test, Gain should be ≥ 0.707. Enter Gain in the test record.

15. Repeat steps 4 on page 83 through 14 on page 83 for all combinations of Vertical Scale settings listed in the test record.

16. Repeat the tests at 1 MΩ impedance as follows:

a. Set the calibrator output to Off or 0 volts.

b. Change the calibrator impedance to 1 MΩ.

c. Double-tap the badge of the channel under test to open its menu.

d. Set the Termination to 1 MΩ.

e. Repeat steps 4 on page 83 through 16 on page 83 , but leave the termination set to 1 MΩ .

17. Repeat the test for all remaining channels as follows:

a. Set the calibrator to 0 volts and 50 Ω output impedance.

b. Move the calibrator output to the next channel input to be tested.

c. Double-tap the channel badge of the channel that you have finished testing and set Display to Off.

d. Tap the channel button on the oscilloscope Settings bar of the next channel to test.

e. Double-tap the Peak-to-Peak measurement badge.

f. Tap the Configure panel.

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 83

Performance verification procedures

g. Tap the Source 1 field and select the next channel to test.

h. Starting from step 4 on page 83, repeat the procedure until all channels have been tested.

Check random noise

This test checks random noise at 1 M Ω and 50 Ω for each channel, in HiRes acquisition mode. You do not need to connect any test equipment to the oscilloscope for this test.

1. Disconnect everything from the oscilloscope inputs.

2. Tap File > Default Setup.

3. Turn on HiRes Mode except for 1.5`GHz instruments. 1.5`GHz instruments must be tested in Sample mode.

4. Add the AC RMS measurement:

a. Tap the Add New... Measure button.

b. Set the Source to the channel being tested.

c. In the Amplitude Measurements panel, double-tap the AC RMS measurement button to add the measurement badge to the

Results bar.

d. Tap outside the menu to close it.

e. Double-tap the AC RMS measurement badge and tap Show Statistics in Badge to display statistics in the measurement badge.

f. Tap the Filter / Limit Results panel.

g. Turn on Limit Measurement Population.

h. Set the limit to 100.

i. Tap outside the menu to close it.

5. Set up the Horizontal mode:

a. Double-tap the Horizontal setting badge.

b. Set Horizontal Mode to Manual.

c. Set the Record Length to 2 Mpts.

d. Tap outside the menu to close it.

6. Double-tap the Channel badge of the channel being tested.

7. Set the Vertical Scale value to 1 mV.

8. Check 1 M Ω termination as follows:

a. In the Channel badge menu, tap 1 M Ω termination.

b. Tap the Bandwidth Limit field and select the highest frequency listed.

c. Set the channel Position value to 340 mdivs.

d. Once the measurement count (N) in the AC RMS measurement badge reaches 100, record the AC RMS Mean value (the µ

readout).

e. Set the channel vertical Position value to 360 mdivs.

f. Once the measurement count (N) in the measurement badge reaches 100, record the AC RMS Mean value (the µ readout).

g. Average the two values and record the result in the 1 mV/div > Full row of the 1 MΩ column of the Test Result record.

h. In the channel badge menu, tap the Bandwidth Limit field and select 250 MHz.

i. Set the channel vertical Position value to 340 mdivs.

j. Once the measurement count (N) in the measurement badge reaches 100, record the AC RMS Mean value (the µ readout).

k. Set the channel vertical Position value to 360 mdivs.

l. Once the measurement count (N) in the measurement badge reaches 100, record the AC RMS Mean value (the µ readout).

m. Average the two values and record the result in the 1 mV/div > 250MHz limit row of the 1 MΩ column of the Test Result record.

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 84

Performance verification procedures

n. Tap the Bandwidth Limit field and select 20 MHz.

o. Set the channel vertical Position value to 340 mdivs.

p. Once the measurement count (N) in the measurement badge reaches 100, record the AC RMS Mean value (the µ readout).

q. Set the channel vertical Position value to 360 mdivs.

r. Once the measurement count (N) in the measurement badge reaches 100, record the AC RMS Mean value (the µ readout).

s. Average the two values and record the result in the 1 mV/div > 20MHz limit row of the 1 MΩ column of the Test Result record.

9. Check 50 Ω termination as follows:

a. In the Channel badge, set Termination to 50 Ω.

b. Tap the Bandwidth Limit field and select the highest frequency listed.

c. Set the channel vertical Position value to 340 mdivs.

d. Once the measurement count (N) in the measurement badge reaches 100, record the AC RMS Mean value (the µ readout).

e. Set the channel vertical Position value to 360 mdivs.

f. Once the measurement count (N) in the measurement badge reaches 100, record the AC RMS Mean value (the µ readout).

g. Average the two values and record the result in the 1 mV/div > Full row of the 50 Ω column of the Test Result record.

h. Tap the Bandwidth Limit field and select 250 MHz.

i. Set the channel vertical Position value to 340 mdivs.

j. Once the measurement count (N) in the measurement badge reaches 100, record the AC RMS Mean value (the µ readout).

k. Set the channel vertical Position value to 360 mdivs.

l. Once the measurement count (N) in the measurement badge reaches 100, record the AC RMS Mean value (the µ readout).

m. Average the two values and record the result in the 1 mV/div > 250MHz limit row of the 50 Ω column of the Test Result record.

n. Tap the Bandwidth Limit field and select 20 MHz.

o. Set the channel vertical Position value to 340 mdivs.

p. Once the measurement count (N) in the measurement badge reaches 100, record the AC RMS Mean value (the µ readout).

q. Set the channel vertical Position value to 360 mdivs.

r. Once the measurement count (N) in the measurement badge reaches 100, record the AC RMS Mean value (the µ readout).

s. Average the two values and record the result in the 1 mV/div > 20MHz limit row of the 50 Ω column of the Test Result record.

10. Repeat 1 MΩ and 50 Ω tests at all V/div settings for the current channel:

a. In the Channel badge, set the Vertical Scale setting to the next value in the test record (2 mV, 5 mV, and so on, up to 1 V/div).

b. Repeat steps 8 on page 84 through 9 on page 85.

11. Repeat all tests for the remaining input channels:

a. Double-tap the AC RMS measurement badge.

b. Tap the Configure panel.

c. Tap the Source 1 field and select the next channel to test.

d. Double-tap the channel badge of the channel that you have finished testing and set Display to Off.

e. Tap the channel button on the oscilloscope Settings bar of the next channel to test.

f. Double-tap the channel badge for the channel being tested.

g. Starting at step 7 on page 84, repeat these procedures for each input channel.

Check long term sample rate

This test checks the sample rate and delay time accuracy (time base).

1. Connect the output of a time mark generator to the oscilloscope channel 1 input using a 50 Ω cable, as shown in the following

illustration.

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 85

Performance verification procedures

Warning: Set the generator output to off or 0 volts before connecting, disconnecting, and/or moving the test hookup during the performance of this procedure. The generator is capable of providing dangerous voltages.

2. Set the time mark generator period to 80 ms. Use a time mark waveform with a fast rising edge.

3. If it is adjustable, set the time mark amplitude to approximately 2 V

4. Tap File > Default Setup.

5. Tap the channel 1 button on the Settings bar.

6. Double-tap the Channel 1 badge to open its Configuration menu.

7. Set Termination to 50 Ω.

8. Set Vertical Scale to 500 mV.

9. Set the Position value to center the time mark signal on the screen.

10. Tap outside the menu area to close it.

11. Double-tap the Horizontal settings badge.

12. Set the Horizontal Scale to 100 ns/div.

13. Tap outside the menu area to close it.

14. Double-tap the Trigger settings badge.

15. Set Source to the channel being tested.

16. Set the Level as necessary for a triggered display.

17. Tap outside the menu area to close it.

18. Double-tap the Horizontal settings badge.

19. Adjust the Position value to move the trigger point to the center of the screen.

20. Turn Delay to On and set Position to 80 ms.

21. Set the Horizontal Scale to 100 ns/div.

22. Observe where the rising edge of the marker crosses the center horizontal graticule line. The rising edge should cross within ±2

divisions of the vertical center graticule. Enter the deviation in the test record.

P-P

Note: A 2.5 x 10-6 time base error is 2 divisions of displacement.

Check digital threshold accuracy

This test checks the threshold accuracy of the TLP058 logic probe digital channels D0-D7 at 0 V and 25 °C, for all oscilloscope input channels.

Threshold Accuracy is a function of the logic probe only. It is a typical specification. The Threshold Accuracy test checks the

Note:

typical logic probe performance, and may be considered a functional check of the oscilloscope digital input.

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 86

1. Connect a TLP058 digital probe to channel 1.

2. Connect the DC voltage source to digital channel D0.

Performance verification procedures

If you are using the Fluke 9500 calibrator as the DC voltage source, connect the calibrator head to the digital channel D0, using the BNC-to-0.1 inch pin adapter listed in the table. Be sure to connect channel D0 to both the corresponding signal pin and to a ground pin on the adapter.

3. Tap File > Default Setup. This resets the instrument and adds the channel 1 badge and signal to the display.

4. Display the digital channels and set the thresholds as follows:

a. Double-tap the badge of the channel under test on the Settings bar.

b. Double-tap the Threshold field at the bottom of the menu and set the value to 0 V.

c. Tap Set All Thresholds. All thresholds are now set for the 0 V threshold check.

d. Tap outside the menu to close it.

5. Double-tap the Horizontal badge in the Settings bar.

6. Set the Horizontal Scale to 10 ns/div.

7. Tap outside the menu to close it.

8. Set the calibrator DC voltage output (Vs) to -400 mV.

9. Wait 1 second. Verify that the logic level is low on D0.

10. Increment Vs by +10 mV. Wait 1 second and check the logic level of the channel D0 signal display.

If the signal level is a logic low or is alternating between high and low, continue to increment Vs by +10 mV, wait 1 second, and check the logic level until the logic state is a steady high.

11. Record this Vs value as Vs- for D0 of the test record.

12. Double-tap the Trigger badge and set the Slope to Falling edge.

13. Set the DC voltage source (Vs) to +400 mV.

14. Wait 1 second. Verify that the logic level is high.

15. Decrement Vs by -10 mV. Wait 1 second and check the logic level of the channel D0 signal display.

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 87

Performance verification procedures

If the signal level is a logic high or is alternating between high and low, continue to decrement Vs by -10 mV, wait 1 second, and check the logic level until the logic state is a steady low.

16. Record this Vs value as Vs+ for D0 of the test record.

17. Find the average using this formula: V

18. Record the average as the test result for D0 in the test record. The test result should be between the low and high limits.

19. Repeat the procedure for all remaining digital channels as follows:

a. Connect the next digital channel to be tested (D1, D2, and so on) to the DC voltage source.

b. Repeat steps 8 on page 87 through 19 on page 88, until all digital channels have been tested for this input channel.

20. Repeat the procedure for all remaining input channels as follows:

a. Move the TLP058 digital probe from channel 1 to channel 2.

b. Set the generator output to 0 volts and Off.

c. Repeat steps starting at 2 on page 87 for the channel being tested (channel 2, channel 3, and so on).

= (Vs- + Vs+)/2.

sAvg

Check AUX Out output voltage levels

This test checks the output voltage levels from the AUX Out connector.

1. Use a 50 Ω cable to connect the AUX Out signal from the rear of the instrument to the channel 1 input of the same instrument, as

shown in the following illustration.

2. Tap File > Default Setup. This resets the instrument and adds the channel 1 badge and signal to the display.

3. Double-tap the badge of the channel 1 badge to open its configuration menu.

4. Set the Vertical Scale to 1 V/div.

5. Tap outside the menu to close it.

6. Double-tap the Horizontal badge in the Settings bar.

7. Set the Horizontal Scale to 400 ns/div.

8. Tap outside the menu to close it.

9. Record the Maximum and Minimum measurements at 1 MΩ termination as follows:

a. Tap the Add New... Measure button.

b. In the Amplitude Measurements panel, set the Source to Ch 1.

c. Double-tap the Maximum button to add the measurement badge to the Results bar.

d. Double-tap the Minimum button to add the measurement badge to the Results bar.

e. Tap outside the menu to close it.

f. Double-tap the Maximum results badge.

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 88

g. Tap Show Statistics in Badge.

h. Tap FILTER/LIMIT RESULTS to open the panel.

i. Tap Limit Measurement Population to toggle it to On.

j. Tap outside the menu to close it.

k. Double-tap the Minimum results badge.

l. Tap Show Statistics in Badge.

m. Tap FILTER/LIMIT RESULTS to open the panel.

n. Tap Limit Measurement Population to toggle it to On.

o. Tap outside the menu to close it.

p. Enter the Maximum and Minimum measurement readings in the 1 MΩ row of the test record.

10. Record the Maximum and Minimum measurements at 50 Ω termination as follows:

a. Double-tap the Ch 1 badge to open its configuration menu.

b. Set Termination to 50 Ω.

c. Tap outside the menu to close it.

d. Enter the Maximum and Minimum measurement readings in the 50 Ω row of the test record.

Check DVM voltage accuracy (DC)

Performance verification procedures

This test checks the DC voltage accuracy of the Digital Volt Meter (DVM) option. The DVM option is available for free when you register the instrument at tek.com.

Procedure

1. Connect the oscilloscope to a DC voltage source to run this test. If using the Fluke 9500 calibrator as the DC voltage source, connect

the calibrator head to the oscilloscope channel to test.

Warning:

performance of this procedure. The generator is capable of providing dangerous voltages.

2. Set the calibrator impedance to 1 MΩ.

3. Tap File > Default Setup. This resets the instrument and adds the channel 1 badge and signal to the display.

4. Set the channel settings:

a) Double tap the badge of the channel under test to open its menu.

b) Check that Position is set to 0 divs. If not, set the position to 0 divisions.

c) Confirm that Termination is set to 1 MΩ.

d) Set the Bandwidth Limit to 20 MHz.

5. Set the calibrator impedance to 1 MΩ.

Set the generator output to Off or 0 volts before connecting, disconnecting, or moving the test hookup during the

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 89

Performance verification procedures

6. Double-tap the Horizontal badge and set Horizontal Scale to 1 ms/div.

7. Tap outside the menu to close it.

8. Double-tap the Acquisition badge and set the Acquisition Mode to Average.

9. Verify or set the Number of Waveforms to 16.

10. Tap outside the menu to close it.

11. Double-tap the Trigger badge and set the Source to AC Line.

12. Tap outside the menu to close it.

13. Tap the DVM button to add the DVM badge to the Results bar.

14. In the DVM menu, set Source to the channel to be tested.

15. Set Mode to DC.

16. Tap outside the menu to close it.

17. Set the calibrator to the input voltage shown in the test record (for example, –5 V for a 1V/div setting).

18. In the channel under test menu, set the Offset value to that shown in the test record (for example, –5 V for –5 V input and 1 V/div

setting).

19. Set the Vertical Scale field to match the value in the test record (for example, 1 V/div).

20. Enter the measured value on the DVM badge into the DVM Voltage Accuracy Tests record.

21. Repeat the procedure (steps 17 on page 90, 18 on page 90, 19 on page 90 and 20 on page 90) for each volts/division setting shown

in the test record.

22. Repeat all steps, starting with step 4 on page 89, for each oscilloscope channel to check. To set the next channel to test:

a) Double tap the badge of the channel under test to open its menu.

b) Set Display to Off.

c) Tap the channel button in the Settings bar of the next channel to test to add that channel badge and signal to the display.

Check DVM voltage accuracy (AC)

This test checks the AC voltage accuracy of the Digital Volt Meter (DVM) option. The DVM option is available for free when you register the instrument at tek.com.

Procedure

1. Connect the output of the leveled square wave generator (for example, Fluke 9500) to the oscilloscope channel 1 input.

Warning:

performance of this procedure. The generator is capable of providing dangerous voltages.

2. Set the generator to 50 Ω output impedance (50 Ω source impedance).

3. Set the generator to produce a square wave of the amplitude and frequency listed in the test record (for example, 20 mVpp at 1 kHz).

4. Tap File > Default Setup to reset the instrument and add the channel 1 badge and signal to the display.

5. Tap the DVM button to add the DVM badge to the Results bar.

6. Set the DVM Mode to AC RMS.

7. In the DVM menu, set Source to the channel to be tested.

8. Double-tap the channel badge of the channel being tested to open its configuration menu.

9. Set Termination to 50 Ω.

10. Use the Vertical Scale controls to set the signal height so that the signal covers between 4 and 8 vertical divisions on the screen.

11. Enter the DVM measured value in the test record.

12. Repeat steps 10 on page 90 and 11 on page 90 for each voltage and frequency combination shown in the record.

13. Repeat all steps to test all remaining oscilloscope channels. To set the next channel to test:

a) Double tap the badge of the channel under test to open its menu.

Set the generator output to Off or 0 volts before connecting, disconnecting, or moving the test hookup during the

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 90

Performance verification procedures

b) Set Display to Off.

c) Tap the channel button in the Settings bar of the next channel to test to add that channel badge and signal to the display.

Check trigger frequency accuracy and maximum input frequency

This test checks trigger frequency counter accuracy. The trigger frequency counter is part of the free DVM and trigger frequency option that is available when you register the instrument at tek.com.

Procedure

1. Tap File > Default Setup to reset the instrument and add the channel 1 badge and signal to the display.

2. Connect the 10 MHz Reference out from the time mark generator to the Ref In connector on the back of the oscilloscope.

3. Connect the output of the time mark generator to the oscilloscope channel input being tested using a 50 Ω cable.

Set the time mark generator to a 50 Ω source and a fast rising edge waveform (≥ 3 mV/ns).

4. Set the time mark generator frequency to the first value shown in the test record, starting at 100 Hz.

5. Set the mark amplitude to 1 V pp, which makes a 2 divisions high waveform.

6. Double-tap the channel badge being tested (starting with channel 1) and set Termination to 50 Ω.

7. Set the channel Vertical Scale to 500 mV/div.

8. Tap outside the menu to close it.

9. Double-tap the Acquisition badge and set the Timebase Reference Source to .

10. Tap outside the menu to close it.

11. Double-tap the Horizontal badge and use the Horizontal Scale controls to display at least 2 cycles of the waveform.

12. Tap outside the menu to close it.

13. Double-tap the Trigger badge to open its menu.

a) Set the Source field to the input channel being tested.

b) Tap the Set to 50% button to obtain a stable display.

c) Tap the Mode & Holdoff panel to open the Mode & Holdoff configuration menu.

d) In the Mode & Hold Off menu, set the Trigger Frequency Counter to On. The trigger frequency readout is at the bottom of the

Trigger badge.

e) Tap outside the menu to close it.

14. Double-tap the channel badge being tested (starting with channel 1) and use the Position controls to vertically center the time mark

in the waveform graticule.

15. Enter the value of the trigger frequency (F readout in the Trigger badge) in the test record for that frequency.

16. Repeat this procedure for each frequency setting shown in the record. Make sure to adjust the Horizontal scale after each calibrator

frequency change to show at least two cycles of the waveform on the screen.

17. Repeat all these steps to test each oscilloscope channel.

Arbitrary function generator

Check AFG sine and ramp frequency accuracy

This test verifies the frequency accuracy of the arbitrary function generator. All output frequencies are derived from a single internally generated frequency. Only one frequency point of channel 1 is required to be checked.

1. Connect a 50 Ω cable from the AFG Out connector to the frequency counter input as shown in the following figure.

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 91

Figure 1: Frequency/period test

2. Tap File > Default Setup to set the instrument to the factory default settings.

3. Tap the AFG button to open the AFG menu.

4. Set the arbitrary function generator output as follows:

Select menu Setting

Output On

Waveform Type Sine

Frequency 1.000000 MHz

Amplitude 1.00 V

5. Turn on the frequency counter:

Performance verification procedures

a. Double-tap the Trigger badge to open its menu.

b. Set the Source field to the input channel being tested.

c. Tap the Set to 50% button to obtain a stable display.

d. Tap the Mode & Holdoff panel to open the Mode & Holdoff configuration menu

e. In the Mode & Hold Off menu, set the Trigger Frequency Counter to On. The trigger frequency readout is at the bottom of the

Trigger badge.

f. Tap outside the menu to close it.

6. Check that the reading of the frequency counter is between 0.999950 MHz and 1.000050 MHz. Enter the value in the Test record.

7. Set the arbitrary function generator output as follows:

Select menu Setting

Waveform Type Ramp

Frequency 500 kHz

8. Check that reading of the frequency counter is between 499.975 kHz and 500.025 kHz. Enter the value in the Test record.

Check AFG square and pulse frequency accuracy

1. Connect the arbitrary function generator to the frequency counter as shown in the following figure.

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 92

Figure 2: Frequency/period test

2. Tap File > Default Setup to set the instrument to the factory default settings.

3. Tap the AFG button to open the AFG menu.

4. Set the arbitrary function generator as follows:

Select menu Setting

Waveform Type Square

Frequency 1.000000 MHz

Amplitude 1.00 V

Output On

5. Turn on the frequency counter:

Performance verification procedures

a. Double-tap the Trigger badge to open its menu.

b. Set the Source field to the input channel being tested.

c. Tap the Set to 50% button to obtain a stable display.

d. Tap the Mode & Holdoff panel to open the Mode & Holdoff configuration menu

e. In the Mode & Hold Off menu, set the Trigger Frequency Counter to On. The trigger frequency readout is at the bottom of the

Trigger badge.

f. Tap outside the menu to close it.

6. Check that the frequency counter readout is between 0.999950 MHz and 1.00005 MHz. Enter the value in the Test record.

7. Set up the arbitrary function generator as follows:

Select menu Setting

Waveform Type Pulse

8. Check that reading of the frequency counter is between 0.999950 MHz and 1.000050 MHz. Enter the value in the Test record.

Check AFG signal amplitude accuracy

This test verifies the amplitude accuracy of the arbitrary function generator. All output amplitudes are derived from a combination of attenuators and 3 dB variable gain. Some amplitude points are checked. This test uses a 50 Ω terminator. It is necessary to know the accuracy of the 50 Ω terminator in advance of this amplitude test. This accuracy is used as a calibration factor.

1. Connect the 50 Ω terminator to the DMM as shown in the following figure and measure the resistance value.

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 93

Performance verification procedures

Figure 3: 50 Ω terminator accuracy

2. Calculate the 50 Ω calibration factor (CF) from the reading value and record as follows:

Table 2: CF (Calibration Factor) = 1.414 × ((50 / Measurement Ω) + 1)

Measurement (reading of the DMM) Calculated CF

Examples:

For a measurement of 50.50 Ω, CF = 1.414 ( 50 / 50.50 + 1) = 2.814.

For a measurement of 49.62 Ω, CF = 1.414 ( 50 / 49.62 + 1) = 2.839.

3. Connect the arbitrary function generator output to the DMM as shown in the following figure. Be sure to connect the 50 Ω terminator to the AFG Out connector.

Figure 4: Amplitude test

4. Tap the AFG button and set up the arbitrary function generator output as follows:

Select menu Setting

Waveform Type Sine

Frequency 1.000000 kHz

Amplitude 30 mV

Load Impedance 50 Ω

Output On

5. Measure the AC RMS voltage readout on the DMM.

6. Multiply the DMM voltage by the calculated CF to get the corrected peak to peak voltage. Enter the resulting value in the Measurement

field in the following table.

7. Change the AFG output amplitude to the next value in the table.

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 94

Performance verification procedures

8. Repeat steps 5 on page 94 through 7 on page 94 for each amplitude value. Check that the peak to peak voltages are within the limits in the table below. Enter the values in the test record.

Waveform Type Frequency Amplitude Measurement Range

Sine 1.000 kHz 30.0 mV

Sine 1.000 kHz 300.0 mV

Sine 1.000 kHz 800.0 mV

Sine 1.000 kHz 1.500 V

Sine 1.000 kHz 2.000 V

Sine 1.000 kHz 2.500 V

28.55 mVPP - 31.45 mV

294.5 mVPP - 305.5 mV

787.0 mVPP - 813.0 mV

1.4765 VPP - 1.5235 V

1.969 VPP - 2.031 V

2.4615 VPP - 2.5385 V

Check AFG DC offset accuracy

This test verifies the DC offset accuracy of the arbitrary function generator. This test uses a 50 Ω terminator. It is necessary to know the accuracy of the 50 Ω terminator in advance of this test. This accuracy is used as a calibration factor.

1. Connect the 50 Ω terminator to the DMM as shown in the following figure and measure the resistance value.

Figure 5: 50 Ω terminator accuracy

2. Calculate the 50 Ω calibration factor (CF) from the reading value and record as follows:

Table 3: CF (Calibration Factor) = 0.5 × (( 50 / Measurement Ω) + 1)

Measurement (reading of the DMM)

Examples:

• For a measurement of 50.50 Ω, CF = 0.5 ( 50 / 50.50 + 1) = 0.9951.

• For a measurement of 49.62 Ω, CF = 0.5 ( 50 / 49.62 + 1) = 1.0038.

3. Connect the arbitrary function generator output to the DMM as shown in the following figure. Be sure to connect the 50 Ω terminator to the arbitrary function generator AFG Output connector.

Calculated CF

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 95

Performance verification procedures

Figure 6: DC offset tests

4. Tap the AFG button and set up the arbitrary function generator as follows:

Select menu Setting

Waveform Type DC

Offset + 1.25 V

Output On

5. Measure the voltage readout on the DMM.

6. Multiply the DMM voltage by the calculated CF to get the corrected offset voltage. Enter the resulting value in the Measurement field in

the following table.

Function Offset Measurement Range

DC + 1.25 Vdc Vdc 1.23025 Vdc to 1.26975 Vdc

DC 0.000 Vdc Vdc - 0.001 Vdc to + 0.001 Vdc

DC - 1.25 Vdc Vdc -1.26975 Vdc to -1.23025 Vdc

7. Change the AFG output amplitude to the next value in the table, measure the voltage readout on the DMM, multiply the DMM readout by the calculated CF to get the corrected offset voltage, and enter the resulting value in the Measurement field in the table.

8. Verify that the corrected offset measurements are within the range.

4 Series MSO (MSO44, MSO46) Specifications and Performance Verification Technical Reference 96
