Getting Started

This manual explains the use of commands for remotely controlling your oscilloscope. With this information, you can write computer programs to perform func

tions, such as setting the front-panel controls, taking measurements, performing statistical calculations, and exporting data for use in other programs. You can use these commands with these oscilloscope models:

MSO3054, MSO3034, MSO3032, MSO3014, MSO3012 , DPO3054, DPO3052, DPO3034, DPO3032, DPO3014, DPO3012

Instrument Function

ality Updates that Impact the Programmatic Command Set

The following lists some of the instrument functionality updates that impact the p rogrammatic command set, along with links to some of the corresponding commands:

Feature Use these commands

Support for the MIL-STD-1553 bus (requires the DPO3AERO application module)

Support for the FlexRay bus (requires the DPO3FLEX application module)

Ability to trigger and search on pulse width r anges

Support for timeout trigger and search TRIGger:A:TYPe, SEARCH:SEARCH<x>:TRIGger:A:TYPe

Ability to query instrument conﬁguration settings

Ability to turn waveform display persistence off or on DISplay:PERSistence OFF

Support for choosing the number of waveforms included in an envelope for envelope acquisition mode

Ability to import .CSV w aveform ﬁles RECAll:WAVEform

Support for socket server interface

Ability to select solid graticule

Ability to transfer licenses between modules and oscilloscope APPLication:LICENSE:SLOT<x>:LOCation?, APPLication:

Ability to press and hold front panel buttons (only the Cursors button is currently supported)

(See page 2-13,

(See page 2-57,

(See page 2-45,

(See page 2-13,

(See page 2-57,

(See page 2-45,

TRIGger:A:PULSEWidth:WHEn, TRIGger:A:PULSEWidth: LOWLimit, TRIGger:A:PULSEWidth:HIGHLimit

SEARCH:SEARCH<x>:TRIGger:A:PULSEWidth:WHEn, SEARCH:SEARCH<x>:TRIGger:A:PULSEWidth:HIGHLimit, SEARCH:SEARCH<x>:TRIGger:A:PULSEWidth:LOWLimit

(See page 2-17,

ACQuire:NUMEnv

(See page 1-2,

Hardware

DISplay:GRAticule

LICENSE:SLOT<x>:TRANSFER, APPLication:LICENSE: SLOT<x>:TYPe?

FPAnel:HOLD

Bus Command Group.) Trigger Command Group.) Search Command Group.)

Conﬁguration Command Group.)

Setting Up Remote Communications

MSO3000 and DPO3000 Series Programmer Manual 1-1

Getting Started

Setting Up Rem

Ethernet

ote Communications Hardware

You can remotely communicate between your oscilloscope and PC via Ethernet, USB, GPIB, or v ia a socket server.

If you are using Ethernet, start by connecting an appropriate Ethernet cable to the Ethernet port (RJ-45 connector) on the rear panel of your oscilloscope. This connects the oscilloscope to a 10/100 Base-T local area network.

To change the Ethernet settings on your oscilloscope, do the following:

USB

1. On the front panel, push Utility.

2. Push Utility Page.

3. Select I/O with the Multipurpose knob.

4. Push

5. On the side menu, if you are on a DHCP Ethernet network and using a through

6. If you are using a cross-over cable, set DHCP/BOOTP to Off, and push

If you are using USB, start by connecting the appropriate USB cable to the USB

2.0 high-speed (HS) device port on the rear panel of your oscilloscope. This ort requires that the cable connected from the port to the host computer meets

p the USB 2.0 speciﬁcation for high speed connections. Typically, such cables should be 3 feet or shorter in length, but this is determined by the quality of the cable and, with higher quality cables, this length can be extended. (It is also dependent upon the drive capability of the host USB port to which the instrument is connected.) The use of high quality short cables is recommended to avoid USB connection problems.

Ethernet Network Settings.

le, set DHCP/BOOTP to On.

cab

ange Instrument Settings to set a hard coded IP address.

1-2 MSO3000 and DPO3000 Series Programmer Manual

Getting Started

With USB, the system automatically conﬁgures itself. To verify that the USB is enabled:

1. On the front panel, push Utility.

2. Push Utility Page.

3. Select I/O with the Multipurpose knob.

4. Push USB/Computer, and verify that USB is enabled.

5. If USB is disabled, push Connect to computer on the side menu.

After connection, the host, with appropriate software, can list the oscilloscope as a USB device with the following parameters.

Table 1-1: USB Device Parameters

Parameter Value

Manufacturer ID 0x0699 (decimal 1689)

Product ID

Serial number Serial number

Manufacturer description

Interface description “USBTMC-USB488”

0x0410 (decimal 1040) DPO3012

0x0411 (decimal 1041) DPO3014

0x0412 (decimal 1042) DPO3032

0x0413 (decimal 1043) DPO3034

0x0414 (decimal 1044) DPO3052

0x0415 (decimal 1045) DPO3054

0x0420 (decimal 1056) MSO3012

0x0421 (decimal 1057) MSO3014

0x0422 (decimal 1058) MSO3032

0x0423 (decimal 1059) MSO3034

0x0425 (decimal 1061) MSO3054

“Tektronix”

MSO3000 and DPO3000 Series Programmer Manual 1-3

Getting Started

GPIB

To u se GPI B , s t a

rt by connecting an appropriate USB cable to the USB 2.0 high-speed device port on the rear panel of your oscilloscope. Connect the other end to the TEK-USB-488 Adapter host port. Then connect a GPIB cable from the TEK-USB-488 Adapter to your PC.

Supply power to the Adapter in either of these two ways:

1. Use the optional 5 V

power adapter connected to the 5 VDCpower input

on the Adapter.

2. Use an appropriate USB cable connected to a powered USB host port on your

PC and the Device port on the TEK-USB-488 Adapter.

The oscilloscope has a USB 2.0 high-speed device port to control the oscilloscope through USBTMC or GPIB with a TEK-USB-488 Adapter. The USBTMC protocol allows USB devices to communicate using IEEE488 style messages. This lets you run your GPIB software applications on USB hardware.

Before setting up the oscilloscope for remote communication using the electronic (physical) GPIB interface, you should familiarize yourself with the following GPIB requirements:

A unique device address must be assigned to each device on the bus. No two devices can share the same device address.

No more than 15 devices can be connected to a ny one line.

One device should be connected for every 6 feet (2 meters) of cable used.

No more than 65 feet (20 meters) of cable should be used to connect devices to a bus.

At least two-thirds of the devices on the network should be powered on while using the network.

Connect the devices on the network in a star or linear conﬁguration. Do not use loop or parallel conﬁgurations.

To function correctly, your oscilloscope must have a unique device address. The default setting for the GPIB conﬁguration is GPIB Address 1.

1-4 MSO3000 and DPO3000 Series Programmer Manual

Getting Started

To chan g e the GP

1. On the front panel, push Utility.

2. Push Utility Page.

3. Select I/O with the Multipurpose knob.

4. Push GPIB.

5. Enter the GPIB address on the side menu, using the multipurpose knob. This

will set the GPIB address on an attached TEK-USB-488 Adapter.

The oscilloscope is now set up for bidirectional communication with your controller.

IB address settings, do the following:

Setting Up Remote Communications Software

Connect your oscilloscope directly to a computer to let the PC analyze your data, collect screen images, or to control the oscilloscope using a program of your own creation. Three ways to connect your oscilloscope to a computer are through the VISA drivers, the e*Scope Web-enabled tools, or via a socket server.

Using

VISA

VISA lets you use your MS-Windows computer to acquire data from your oscilloscope for use in an analysis package that runs on your PC, such as Microsoft Excel, National Instruments LabVIEW, Tektronix OpenChoice Desktop

ware, or your own custom software. You can use a common communications

soft connection, such as USB, Ethernet, or GPIB, to connect the computer to the oscilloscope.

To set up VISA communications between your oscilloscope and a computer:

MSO3000 and DPO3000 Series Programmer Manual 1-5

Getting Started

1. Load the VISA dr

as OpenChoice Desktop. You will ﬁnd the drivers and OpenChoice Desktop software on the appropriate CD that comes with your oscilloscope or at the Tektronix software ﬁnder Web page (www.tektronix.com).

2. Connect the oscilloscope to your computer with the appropriate USB or

Ethernet cable. You will ﬁnd the drivers and OpenChoice Desktop software on the appropriate CD that comes with your oscilloscope or at the Tektronix software ﬁ nder Web page (www.tektronix.com/downloads).

3. On the front panel, push Utility.

4. Push Utility Page on the lower menu.

5. Turn multipurpose knob a and select I/O.

6. If you are using USB, the system sets itself up automatically for you, if USB is

enabled. Check USB on the lower menu to be sure that USB is enabled. If it is not enabled, push USB. Then push Connect to Computer on the side menu.

7. To use Ethernet, push Ethernet Network Settings on the lower menu. Use

the side menu buttons to adjust your network settings, as needed. For more information, see the e*Scope setup information below.

8. If you want to change socket server parameters, push Socket Server and enter

new values through the resulting side menu.

ivers on your computer. Also, load your application, such

Quick Tips

Using e*Scope

9. If you are using GPIB, push GPIB. Enter the GPIB address on the side menu,

using multipurpose knob a.

10. Run your application software on your computer.

Your oscilloscope shipped with a CD containing a variety of Windows-based software tools for efﬁcient connectivity between your oscilloscope and your computer. These include toolbars that speed connectivity with Microsoft Excel a nd Word. There are also two standalone acquisition programs called NI LabVIEW SignalExpress™, Tektronix Edition and Tektronix OpenChoice

esktop.

The rear-panel USB 2.0 device port is the correct USB port for computer connectivity. Use the rear- and front-panel USB 2.0 host ports to connect your oscilloscope to USB ﬂash drives, printers and keyboards. Use the USB Device port to connect your oscilloscope to a PC or a PictBridge printer.

With e*Scope, you can use a web browser on your computer to send and receive commands using any connected MSO/DPO3000 Series oscilloscope. To set up e*Scope communications between your oscilloscope and a Web browser running onaremotecomputer:

1-6 MSO3000 and DPO3000 Series Programmer Manual

Getting Started

1. Connect the osc Ethernet cable.

2. On the front panel, push Utility.

3. Push Utility P age on the lower menu.

4. Turn multipurpose knob a and select I/O.

5. Push Ethernet Network Settings.

6. Push Change Instrument Settings to display and change the instrument

setup on your oscilloscope. Optional: enter an Instrument IP address if you’d like to manually conﬁgure it.

7. Push Test Connection to check if your oscilloscope can ﬁnd an attached network.

8. Start y our browser on your remote computer. In the browser address line, enter the host name, a dot, and the domain name together. Alternatively, just enter the IP address of the instrument. Either way, you should then see the e*Scope page on your Web browser on your computer screen.

9. ClickontheDatatabonthee*Scopepage.UnderTalk/Listen, you may enter and send commands to the connected oscilloscope.

illoscope to your computer network with an appropriate

Using a Socket Server

ket server provides two-way communication over an Internet Protocol-based

Asoc computer network. You can use your oscilloscope’s socket server feature to let your oscilloscope talk to a remote-terminal device or computer.

To set up and use a socket server between your oscilloscope and a remote terminal or computer:

1. Connect the oscilloscope to your computer network with an appropriate Ethernet cable.

2. Push Utility.

3. Push Utility Page.

4. Turn multipurpose knob a and select I/O.

5. Push Socket Server.

6. On the resulting Socket Server side menu, push the top entry to highlight Enabled.

7. Choose whether the protocol should be None or Term i na l . A communication

session run by a human at a keyboard typically uses a terminal protocol. An automated session might h andle its own communications without using such a protocol.

8. If required, change the port number by rotating multipurpose knob a.

9. If required, press OK to set the new port number.

MSO3000 and DPO3000 Series Programmer Manual 1-7

Getting Started

10. After setting u

p the socket server parameters, you can now have the computer talk to the oscilloscope. If you are running an MS Windows PC, you could run its default client with its command-like interface. One way to do this is by typing “

Telnet ” in the Run window. The Telnet window will open on

the PC.

NOTE. On MS Windows 7, you must ﬁrst enable Telnet for it to work.

11. Start a terminal session between your computer and your oscilloscope by typing in an open command with the oscilloscope's LAN a ddress and port #.

You can obtain the LAN address by pushing the Ethernet Network Settings bottom menu item and then Change Instrument Settings on the

ng side menu.

resulti

You can obtain the port number by pushing the Socket Server bottom menu ite

For example, if the oscilloscope IP address was port # w

m and viewing the Current Port side menu item.

123.45.67.89 and the

as the default of

4000, you could open a session by writing into

the MS Windows Telnet screen:

o 123.

45.67.89 4000

12. You can now type in a standard query, as found in the programmer manual,

such

*idn?

The Telnet session window will respond by displaying a character string

cribing your instrument.

des

You can type in more queries and view more results on this Telnet session

ndow. You can ﬁnd the syntax for relevant queries and related status

wi codes in other sections of this manual.

NOTE. Do not use the computer’s backspace key during an MS Windows' Telnet

session with the oscilloscope.

Socket Server Terminal Protocol Mode Commands. Following are Tektronix Instrument Control Terminal Session Control commands:

!t <timeout> : set the response timeout in milliseconds.

!d : send device clear to the instrument.

!r : read response from instrument.

!h : print this usage info.

1-8 MSO3000 and DPO3000 Series Programmer Manual

Getting Started

Documentation

NOTE. Commands

read automatically.

The followin site at www.tektronix.com/downloads:

MSO3000 and

and operating the oscilloscope.

Getting St

from your oscilloscope into any one of several available analysis tools.

MSO3000 a

and a performance veriﬁcation procedure.

TekV ISA

implementation of the VISA Application Programming Interface (API). TekVISA is industry-compliant software for writing interoperable oscilloscope drivers in a variety of Application Development Environments (ADEs).

arted with OpenChoice ™ Solutions Manual. Options for getting data

nd DPO3000 Series Technical Reference. Oscilloscope speciﬁcations

Programmer Manual. Description of TekVISA, the Tektronix

containing a ? are treated as queries, and the responses are

g documents are available for download on the Manuals Finder Web

DPO3000SeriesUserManual. Information about installing

MSO3000 and DPO3000 Series Programmer Manual 1-9

Getting Started

1-10 MSO3000 and DPO3000 Series Programmer Manual

Command Syntax

You can control the operations and functions of the oscilloscope through the Ethernet port or the USB 2.0 device port using commands and queries. The related topi The topics also describe the conventions that the oscilloscope uses to process them. See the Command Groups topic in the table of contents for a listing o f the commands by command group, or use the index to locate a speciﬁc command.

cs listed below describe the syntax of these commands and queries.

Backus-Naur Form

Notation

This documentation describes the commands and queries using Backus-Naur Form (BNF) notation. Refer to the following table for the symbols that are used.

Table 2-1: Symbols for Backus-Naur Form

Symbol Meaning

| Exclusive OR

{ } Group; one element is required

[] .. .

( ) Comment

Command and Query Structure

mmands consist of set commands and query commands (usually called

Co commands and queries). Commands modify oscilloscope settings or tell the oscilloscope to perform a speciﬁc action. Queries cause the oscilloscope to return data and status information.

Deﬁned element

Is deﬁned as

Optional; can be omitted

Previous element(s) may be repeated

Most commands have both a set form and a query form. The query form of the command differs from the set form by its question mark at the end. For example, the set command commands have both a set and a query form. Some commands have set only and some have query only.

Messages

MSO3000 and DPO3000 Series Programmer Manual 2-1

A command message is a command or query name followed by any information the oscilloscope needs to execute the command or query. Command messages may c ontain ﬁve element type s, deﬁned in the following table.

ACQuire:MODe has a query form ACQuire:MODe?.Notall

Command Syntax

Commands

Table 2-2: Comm

Symbol Meaning

<Argument

<Comma> A single c

<Space>

Comman

ds cause the oscilloscope to perform a speciﬁc function or change one of

and Message Elements

This is the basic command name. If the header ends with a question mark, the command is a query. The header may begin with a colon (:) characte the beginning colon is required. Never use the beginning colon with command headers beginning with a star (*).

This is a header subfunction. Some command headers have only one mnemonic. I character always separates them from each other.

This is a qu Some commands have no arguments while others have multiple arguments. A <space> separates arguments from the header. A <comma> se

commands. Optionally, there may be white space characters before and after the comma.

A white space character is used between a command header and the related argument. Optionally, a white space may consist of multiple white sp

r. If the command is concatenated with other commands,

f a command header has multiple mnemonics, a colon (:)

antity, quality, restriction, or limit associated with the header.

parates arguments from each other.

omma is used between arguments of multiple-argument

ace characters.

the settings. Commands have the structure:

eader>[<Space><Argument>[<Comma> <Argument >]...]

[:]<H

A command header consists of one or more mnemonics arranged in a hierarchical

ee structure. The ﬁrst mnemonic is the base or root of the tree and each

or tr subsequent mnemonic is a level or branch off the previous one. Commands at a higher level in the tree may affect those at a lower level. The leading colon (:) always returns you to the base of the command tree.

2-2 MSO3000 and DPO3000 Series Programmer Manual

Command Syntax

Queries

Headers

Queries cause t have the structure:

[:]<Header>

[:]<Header>[<Space><Argument> [<Comma><Argu ment>]...]

You can specify a query command at any level within the command tree unless otherwise noted. These branch queries return information about all the mnemonics below the speciﬁed branch or level.

Use the HEADer command to control whether the oscilloscope returns headers as part of the query response. If header is on, the query response returns command headers, then formats itself as a valid set command. When header is off, the response includes only the values. This may make it easier to parse and extract the information from the response. The table below shows the difference in responses.

Table 2-3: Comparison of Header Off and Header On R esponses

Query Header Off Header On

TIME?

ACQuire:NUMAVg?

he oscilloscope to return status or setting information. Queries

14:30:00 :TIME “14:30:00”

100

:ACQUIRE:NUMAVG 100

Clearing the oscilloscope

You can clear the Output Queue and reset the oscilloscope to accept a new command or query by using the selected Device Clear (DCL) function.

Command Entry

The following rules apply when entering commands:

You can enter commands in upper or lower case.

You can precede any command with white space characters. White space characters include any combination of the ASCII control characters 00 through 09 and 0B through 20 hexadecimal (0 through 9 and 11 through 32 decimal).

The oscilloscope ignores commands consisting of any combination of white space characters and line feeds.

MSO3000 and DPO3000 Series Programmer Manual 2-3

Command Syntax

Abbreviating

Concatenating

You can abbrevi

ate many oscilloscope commands. Each command in this documentation shows the minimum acceptable abbreviations in capitals. For example, you can enter the command ACQuire:NUMAvg simply as ACQ:NUMA or acq:numa.

Abbreviation rules may change over time as new oscilloscope models are introduced. Thus, for the most robust code, use the full spelling.

If you use the HEADer command to have command headers included as part of query responses, you can further control whether the returned headers are abbreviated or are full-length with the VERBose command.

You can concatenate any combination of set commands and queries using a semicolon (;). The oscilloscope executes concatenated commands in the order received.

When concatenating commands and queries, you must follow these rules:

1. Separate completely different headers by a semicolon and by the beginning

colon on all commands except the ﬁrst one. For example, the commands

TRIGger:MODe NORMal and ACQ uire:NUMAVg 8, can be concatenated

into the following single command:

TRIGger:MODe NORMal;:ACQuire:NUMAVg 8

2. If concatenated commands have headers that differ by only the last mnemonic,

you can abbreviate the second command and eliminate the beginning colon. For example, you can concatenate the commands

ACQuire:MODe ENVelope

and ACQuire:NUMAVg 8 into a single command:

ACQuire:MODe ENVelope; NUMAVg 8

The longer version works equally well:

ACQuire:MODe ENVelope;:ACQuire:NUMAVg 8

3. Never precede a star (*) command with a colon:

ACQuire:STATE 1;*OPC

Any commands that follow will be processed as if the star command was not there so the commands,

ACQuire:MODe ENVel

ope;*OPC;NUMAVg 8

will set the acquisition mode to envelope and set the number of acquisitions for averaging to 8.

4. When you concatenate queries, the responses to all the queries are

concatenated into a single response message. For example, if the display graticule is set to Full and the display style is set to dotsonly, the concatenated query

DISplay:GRAticule?;STYle:DOTsonly? will return the following.

Iftheheaderison:

DISPLAY:GRATICULE FULL;:DISPLAY:STYLE:DOT SONLY 1

2-4 MSO3000 and DPO3000 Series Programmer Manual

Command Syntax

If the header is

FULL;1

off:

5. Set commands and queries may be concatenated in the same message. For example,

ACQuire:MODe SAMple;NUMAVg?;STATE?

is a valid message that sets the acquisition mode to sample. The message then queries the number of acquisitions for averaging and the acquisition state. Concatenated comma nds and queries are executed in the order received.

Here are some invalid concatenations:

DISPlay:STYle:NORMal;ACQuire:NUMAVg 8 (no colon before ACQuire)

DISPlay:GRAticule FULL;:DOTSONLY OFF (extra colon before DOTSonly. You could use DISPlay:DOTsonly OFF instead)

DISPlay:GRAticule FULL;:*TRG (colon before a star (*) command)

MATH:HORizontal:SCAle 1.0e-1;HORizontal:P OSition 5.0el

(levels of the mnemonics are different; either remove the second use of

HORizontal: or place :MATH in front of HORizontal:POSition)

Terminating

This documentation uses <EOM> (End of Message) to represent a message terminator.

Table 2-4: End of Message Terminator

Symbol Meaning

<EOM>

Th concurrently with the last data byte). The last data byte may be an ASCII line feed (LF) character.

This oscilloscope does not support ASCII LF only message termination. The oscilloscope always terminates outgoing messages with LF and EOI.

Constructed Mnemonics

Some header mnemonics specify one of a range of mnemonics. For example, a channel mnemonic can be CH1, CH2, CH3, or CH4. You use these mnemonics in the command just as you do any other mnemonic. For example, there is a CH1:POSition command, and there is also a CH2:POSition command. In the command descriptions, this list of choices is abbreviated as CH<x>.

Message terminator

e end-of-message terminator must be the END message (EOI asserte d

MSO3000 and DPO3000 Series Programmer Manual 2-5

Command Syntax

Math Spe

Cursor Position

Mnemonics

ciﬁer Mnemonics

When cursors ar

e displayed, commands may specify which cursor of the pair to

use.

Table 2-5: Channel Mnemonics

Symbol Meaning

CH<x> A channel speciﬁer; <x> is 1 through 4.

Table 2-6: Cursor Mnemonics

Symbol Meaning

CURSOR<x>

POSITION<x>

HPOS<x>

A cursor selector; <x> is either 1 or 2.

Commands can specify the mathematical waveform to use as a mnemonic in the header.

Table 2-7: Math Speciﬁer Mnemonics

Symbol Meaning

Math<x>

A math waveform speciﬁer; <x> is 1.

Measurement Speciﬁer

Mnemonics

hannel Mnemonics

Reference Waveform

Mnemonics

Commands can specify which measurement to set or query as a mnemonic in the header. Up to four automated measurements may be displayed.

Table 2-8: Measurement Speciﬁer Mnemonics

Symbol Meaning

MEAS<x> A measurement speciﬁer; <x> is 1 through 4.

Commands specify the channel to use as a mnemonic in the header.

Commands can specify the reference waveform to use as a mnemonic in the header.

Table 2-9: Reference Waveform Mnemonics

Symbol Meaning

REF<x>

A reference waveform speciﬁer; <x> is 1, 2, 3, or 4 for 4-channel oscilloscopes and 1 or 2 for 2-channel oscilloscopes.

2-6 MSO3000 and DPO3000 Series Programmer Manual

Argument Types

Command Syntax

Commands use arguments such as enumeration, numeric, quoted string and block. Each of these arguments are listed in detail below.

Enumeration

Numeric

Enter these arguments as unquoted text words. Like key words, enumeration arguments follow the same convention where the portion indicated in uppercase is required and that in lowercase is optional.

For example:

Many osci

SAVe:WAVEform:FILEFormat INTERNal

lloscope commands require numeric arguments. The syntax shows the format that the oscilloscope returns in response to a query. This is also the preferred format when sending the command to the oscilloscope though any of the formats will be accepted. This documentation represents these arguments as described below.

Table 2-10: Numeric Arguments

Symbol Meaning

<NR1>

<NR2> Floating point value without an exponent

<NR3> Floating point value with an exponent

<bin>

Signed integer value

Digital data in binary format

Most numeric arguments will be automatically forced to a valid setting, by either rounding or truncating, when an invalid number is input, unless otherwise noted

the command description.

Quoted String

Some commands accept or return data in the form of a quoted string, which is simply a group of ASCII characters enclosed by a single quote (') or double quote

"). The following is an example of a quoted string:

(

string"

. This documentation represents these arguments as follows:

"This is a quoted

Table 2-11: Quoted String Argument

Symbol Meaning

<QString> Quoted string of ASCII text

MSO3000 and DPO3000 Series Programmer Manual 2-7

Command Syntax

A quoted string

can include any character deﬁned in the 7-bit ASCII character

set. Follow these rules when you use quoted strings:

1. Use the same ty example:

2. You can mix q previous rule. For example:

3. You c an i nc l example:

4. Strings ca

pe of quote character to open and close the string. For

"this is a valid string".

uotation marks within a string as long as you follow the

"this is an 'acceptabl e' string ".

ude a quote character within a string by repeating the quote. For

"here is a "" mark".

n have upper or lower case characters.

5. If you use a GPIB network, you cannot terminate a quoted string with the END messa

ge before the closing delimiter.

6. A carriage return or line feed embedded in a quoted string does not terminate the s tri

ng. The return is treated as another character in the string.

7. The maximum length of a quoted string returned from a query is 1000

ters.

charac

Here are some invalid strings:

"Invalid string argument' (quotes are not of the same type)

Block

"test<EOI>" (termination character is embedded in the string)

Several oscilloscope commands use a block argument form, as deﬁned in the table below.

Table 2 -12: Block Argument

Symbol Meaning

<NZDig>

<Dig>

<DChar> A character with the hexadecimal equivalent of 00 through FF (0

<Block>

A nonzero digit character i n the range of 1–9

A digit character, in the range of 0–9

through 255 decimal)

A block of data bytes deﬁned as: <Block> ::= {#<NZDig><Dig>[<Dig>...][<DChar>...] |#0[<DChar>...]<terminator>}

<NZDig> speciﬁes the number of <Dig> elements that follow. Taken together, the <NZDig> and <Dig> elements form a decimal integer that speciﬁes how many <DChar> elements follow.

2-8 MSO3000 and DPO3000 Series Programmer Manual

Command Syntax

MSO3000 and DPO3000 Series Programmer Manual 2-9

Command Syntax

2-10 MSO3000 and DPO3000 Series Programmer Manual

Command Groups

This manual lists the MSO/DPO3000 Series IEEE488.2 commands in two ways. First, it presents them by functional groups. Then, it lists them alphabetically. The functional g command. (See page 2-93, Commands Listed in Alphabetical Order.)

Acquisition Command Group

Use the commands in the Acquisition Command Group to set up the modes and functions that control how the oscilloscope acquires signals input to the channels, and processes them into waveforms.

Using the commands in this group, you can do the following:

Start and stop acquisitions.

roup list starts below. The alphabetical list provides detail on each

Control

whether each waveform is simply acquired, averaged, or enveloped

over successive acquisitions of that waveform.

Set the

controls or conditions that start and stop acquisitions.

Control acquisition of channel waveforms.

Set acquisition parameters.

Table 2-13: Acquisition Commands

Command Description

ACQuire?

ACQuire:MAGnivu Sets or returns the MagniVu feature

ACQuire:MAXSamplerate?

ACQuire:MODe Sets or returns the acquisition mode

ACQuire:NUMACq? Returns the number of acquisitions that have

ACQuire:NUMAVg Sets or returns the number of acquisitions for

ACQuire:NUMEnv This command controls the number of

ACQuire:STATE Starts or stops the acquisition system

ACQuire:STOPAfter Sets or returns whether the acquisition is

Returns the acquisition parameters

Returns the maximum real-time sample rate

occurred

an averaged waveform

envelopes (when acquisition mode has been set to ENVelope using ACQuire:MODe). The number of envelopes can be set from 1 to 2000 in increments of 1, or to INFInite.

continuous or single sequence

MSO3000 and DPO3000 Series Programmer Manual 2-11

Command Groups

Alias Command

Group

Use the Alias commands to deﬁne new commands as a sequence of standard commands. You may ﬁnd this useful when repeatedly using the same commands to perform ce

rtain tasks like setting up measurements.

Aliases are similar to macros but do not include the capability to substitute parameters

into alias bodies. The alias mechanism obeys the following rules:

The alias name must consist of a valid IEEE488.2 message unit, which may not appear

in a message preceded by a colon, comma, or a command or query

program header.

The a lias

name may not appear in a message followed by a colon, comma,

or question mark.

An alias

name must be distinct from any keyword or keyword short form.

An alias name cannot be redeﬁned without ﬁrst b eing deleted using one of

as deletion functions.

the ali

Alias names do not appear in response messages.

2-14: Alias Commands

Table

Command Description

ALIa

ALIas:CATalog? Returns a list of the currently deﬁned alias

ALIas:DEFine

ALIas:DELEte

ALIas:DELEte:ALL Deletes all existing aliases

ALIas:DELEte[:NAMe]

ALIas[:STATE] Sets or returns the alias state

Sets or returns the alias state

labels

Assigns a sequence of program messages

n alias label

to a

moves a speciﬁed alias

Removes a speciﬁed alias

2-12 MSO3000 and DPO3000 Series Programmer Manual

Command Groups

Bus Command Gr

oup

Use the Bus commands when working with serial or parallel bus measurements.

Install the DPO3EMBD application module when working with I2CorSPI bus signals.

Install the DPO3AUTO module when working with CAN or LIN bus signals.

Install the DPO3COMP module when working with RS-232, RS-422, RS-485, and UART bus signals.

Install the DPO3AUDIO module when working with I2S, Left Justiﬁed (LJ), Right Justiﬁed (RJ), and TDM bus signals.

Install the DPO3AERO module when working with MIL-STD-1553 bus signals.

Install the DPO3FLEX module when working with FlexRay bus signals.

NOTE. Parallel bus trigger and analysis functionality is included standard with

the MSO Series.

NOTE.

The Search Command Group and the Trigger Command Group also

contain bus-related commands.

Table2-15:BusCommands

Commands Description

BUS Returns the parameters for each bus

BUS:B<x>:AUDio:BITDelay Sets or returns the number of delay bits for

the AUDIO bus

BUS:B<x>:AUDio:BITOrder Sets or returns the bit order for the AUDIO

bus

BUS:B<x>:AUDio:CHANnel:SIZe Sets or returns the number of bits per

channel for the AUDIO bus

BUS:B<x>:AUDio:CLOCk:POLarity Sets or returns the clock polarity for the

AUDIO bus

BUS:B<x>:AUDio:CLOCk:SOUrce Sets or returns the clock source waveform

for the AUDIO bus

BUS:B<x>:AUDio:DATa:POLarity Sets or returns the data polarity for the

AUDIO bus

BUS:B<x>:AUDio:DATa:SIZe Sets or returns the number of bits per word

for the AUDIO bus

BUS:B<x>:AUDio:DATa:SOUrce Sets or returns the data source waveform for

the AUDIO bus

MSO3000 and DPO3000 Series Programmer Manual 2-13

Command Groups

Table2-15: BusCommands(cont.)

Commands Description

BUS:B<x>:AUDio:DISplay:FORMat Sets or returns the display format for the

AUDIO bus

BUS:B<x>:AUDio:FRAME:SIZe Sets or returns the number of channels in

each frame for the AUDIO bus

BUS:B<x>:AUDio:FRAMESync:POLarity Sets or returns the frame sync polarity for

the AUDIO bus

BUS:B<x>:AUDio:FRAMESync:SOUrce Sets or returns the frame sync source

waveform for the AUDIO bus

BUS:B<x>:AUDio:TYPe Sets or returns the audio format (type) for

the AUDIO bus

BUS:B<x>:AUDio:WORDSel:POLarity Sets or returns the word select polarity for

the AUDIO bus

BUS:B<x>:AUDio:WORDSel:SOUrce Sets or returns the word s elect source

waveform for the AUDIO bus

BUS:B<x>:CAN:BITRate Sets or returns the bit rate for the CAN bus

BUS:B<x>:CAN:PRObe Sets or returns the probing method used to

probe the C AN bus

BUS:B<x>:CAN:SAMPLEpoint Sets or returns the sample point (in %) to

sample during each bit period

BUS:B<x>:CAN:SOUrce Sets or returns the CAN data source

BUS:B<x>:DISplay:FORMAt Sets the display format for the numerical

information in the speciﬁed bus waveform

BUS:B<x>:DISplay:TYPe Sets the display type for the speciﬁed bus

BUS:B<x>:FLEXray:BITRate This command speciﬁes the bit rate for

FlexRay

BUS:B<x>:FLEXray:CHannel This command speciﬁes the FlexRay ID

format

BUS:B<x>:FLEXray:SIGnal Speciﬁes which FlexRay standard to use:

BDIFFBP, BM or TXRX.

BUS:B<x>:FLEXray:SOUrce This command speciﬁes the FlexRay data

source

BUS:B<x>:I2C:ADDRess:RWINClude Sets and returns whether the read/write bit is

included in the address

BUS:B<x>:I2C{:CLOCK|:SCLK}:SOUrce Sets or returns the I2C SCLK source

BUS:B<x>:I2C{:DATA|:SD ATA}:SOUrce Sets or returns the I2C SDATA source

BUS:B<x>:LABel Sets or returns the waveform label for the

speciﬁed bus

BUS:B<x>:LIN:BITRate Sets or returns the bit rate for LIN

BUS:B<x>:LIN:IDFORmat Sets or returns the LIN ID format

BUS:B<x>:LIN:POLARity Sets or returns the LIN polarity

2-14 MSO3000 and DPO3000 Series Programmer Manual

Command Groups

Table 2-15: Bus Commands (cont.)

Commands Description

BUS:B<x>:LIN:SAMPLEpoint Sets or returns the sample point (in %) at

which to sample during each bit period

BUS:B<x>:LIN:SOUrce Sets or returns the LIN data source

BUS:B<x>:LIN:STANDard Sets or returns the LIN standard

BUS:B<x>:MIL1553B:POLarity This command sets the MIL-STD-1553 bus

polarity to normal or inverted.

BUS:B<x>:MIL1553B:RESPonsetime: MAXimum

BUS:B<x>:MIL1553B:RESPonsetime: MINimum

BUS:B<x>:MIL1553B:SOUrce This command speciﬁes the M IL-STD-1553

BUS:B<x>:PARallel:BIT<x>:SOUrce Sets or returns the parallel bit source for the

BUS:B<x>:PARallel:CLOCK:EDGE Sets or returns the parallel clock edge for the

BUS:B<x>:PARallel:CLOCK:ISCLOCKed Sets or returns the parallel bus clock function

BUS:B<x>:PARallel:CLOCK:SOUrce Sets or returns the parallel clock source for

BUS:B<x>:PARallel:WIDth Sets or returns the width of the parallel bus

BUS:B<x>:POSition Sets or returns the position of the speciﬁed

BUS:B<x>:RS232C:BITRate Sets or returns the RS-232 bit rate for the

BUS:B<x>:RS232C:DATABits Sets or returns the number of bits for the

BUS:B<x>:RS232C:DELIMiter Sets or returns the R S-232 delimiting value

BUS:B<x>:RS232C:DISplaymode Sets or returns the display mode for the

BUS:B<x>:RS232C:PARity Sets or returns the parity for RS-232 data

BUS:B<x>:RS232C:POLarity Sets or returns the RS-232C polarity for the

BUS:B<x>:RS232C:RX:SOUrce Sets or returns the RS-232 RX source

BUS:B<x>:RS232C:TX:SOUrce Sets or returns the RS-232 TX Source

BUS:B<x>:SPI{:CLOCK|:SCLK}:POLARity Sets or returns the SPI SCLK polarity

BUS:B<x>:SPI{:CLOCK|:SCLK}:SOUrce Sets or returns the SPI SCLK source

BUS:B<x>:SPI:DATA{:IN|:MISO}:POLARity Sets or returns the SPI MISO polarity

BUS:B<x>:SPI:DATA{:IN|:MISO}:SOUrce Sets or returns the SPI MISO source

This command speciﬁes the maximum response time to a valid command issued.

This command speciﬁes the minimum response time to a valid command issued.

bus source for differential input.

speciﬁed bus

for the speciﬁed bus

the speciﬁed bus

bus waveform

speciﬁed bus

data frame

for a packet on the speciﬁed bus

speciﬁed bus display and event table

speciﬁed bus

MSO3000 and DPO3000 Series Programmer Manual 2-15

Command Groups

Table2-15: BusCommands(cont.)

Commands Description

BUS:B<x>:SPI:DATA{:OUT|:MOSI}: POLARity

BUS:B<x>:SPI:DATA{:OUT|:MOSI}:SOUrce Sets or returns the SPI MOSI source

BUS:B<x>:SPI{:SELect|:SS}:POLARity Sets or returns the SPI SS polarity

BUS:B<x>:SPI{:SELect|:SS}:SOUrce Sets or returns the SPI SS source

BUS:B<x>SPI:FRAMing Sets or returns the type of SPI framing

BUS:B<x>:STATE Turns the speciﬁed bus on and off

BUS:B<x>:TYPE Sets or returns the speciﬁed bus type

BUS:LOWerthreshold:CH<x> Sets or returns the lower threshold for each

BUS:THReshold:D<x> Sets or returns the threshold for a digital

BUS:UPPerthreshold:CH<x> Sets or returns the upper threshold for each

Sets or returns the SPI MOSI polarity

channel

2-16 MSO3000 and DPO3000 Series Programmer Manual

Command Groups

Calibration a

nd Diagnostic Command Group

The Calibration and Diagnostic commands provide information about the current state of oscilloscope calibration. They also initiate internal signal path calibration (SPC) or exec calibration are not described in this manual. They are described in the Service manual, located on the DPO3000 Documentation CD-ROM in PDF format. You can also order a printed copy.

Table 2-16: Calibration and Diagnostic Commands

Command

*CAL? Instruct

CALibrate:FACtory:STATus? Returns the factory calibration status value

ate:INTERNal

CALibr

rate:INTERNal:STARt

CALib

rate:INTERNal:STATus?

CALib

CALibrate:RESults? Returns the status of all calibration

ibrate:RESults:FACtory?

CAL

CALibrate:RESults:SPC? Returns the results o f the last S P C operation

DIAg:LOOP:OPTion Sets the self-test loop option

DIAg:LOOP:OPTion:NTIMes Sets the self-test loop option to run N times

DIAg:LOOP:STOP Stops the self-test at the end of the current

DIAg:RESUlt:FLAg? Returns the pass/fail status from the last

DIAg:RESUlt:LOG? Returns the internal results log from the last

DIAg:SELect:<function> Selects one of the available s elf-test areas

DIAg:STATE Sets the oscilloscope operating state

DIAg:SELect Sets the type of diagnostics grouping

ute diagnostic tests. Commands that are speciﬁctofactory

Description

s the oscilloscope to perform self-calibration and returns the oscilloscope self calibration status

saved in

Starts

Start

Retur signal path calibration

subsystems without performing an SPC oper

Ret calibration

loop

self-test sequence execution

nonvolatile memory

a signal path compensation

s the internal signal path calibration

ns the current status of the internal

ation

urns the status of internal and factory

Conﬁguration Command Group

Use the queries in the Conﬁguration Command Group to determine whether a particular feature is present.

MSO3000 and DPO3000 Series Programmer Manual 2-17

Command Groups

Table 2-17: Con

Command

CONFIGuration:ADVMATH?

CONFIGuration:ANALOg:GNDCPLG?

CONFIGurat

CONFIGura MAXSAMPLERate?

CONFIGuration:ANALOg:NUMCHANnels? This query returns the number of analog

CONFIGuration:ANALOg:RECLENS?

CONFIGu

CONFIGuration:APPLications:LIMITMask?

CONFIGuration:APPLications:POWer?

CONF

CONFIGuration:BUSWAVEFORMS:AUDIO?

CONFIGuration:BUSWAVEFORMS:CAN?

CO ETHERNET?

CONFIGuration:BUSWAVEFORMS: FLEXRAY?

ration:ANALOg:VERTINVert?

IGuration:AUXIN?

NFIGuration:BUSWAVEFORMS:

ﬁguration Commands

ion:ANALOg:MAXBANDWidth?

tion:ANALOg:

Description

This query ret indicate whether the advanced math feature is present.

This query returns a boolean value to indicate whether the ground coupling feature for analog ch

This query returns the maximum bandwidth for analog c

This query returns the maximum sample rate for analog

channels.

This query returns a comma-separated list of supported record lengths for the analog channels

This query returns a boolean value to indicat analog channels is present.

This qu indicate whether the optional mask/limit test application feature is present. As the MSO/DP not support this feature, this query always returns 0.

This query returns a boolean value to indicate whether the optional power application

re is present.

featu

This query returns a boolean value to

cate whether the instrument has an

indi auxiliary input.

query returns a boolean value to

This indicate whether the optional audio bus triggering and analysis feature is present.

This query returns a boolean value to indicate whether the optional CAN bus triggering and

lysis feature is present.

ana

This query returns a boolean value to

dicate whether the optional Ethernet

in triggering and analysis feature is present. As the MSO/DPO3000 Series oscilloscopes do

t support this feature, this query always

no returns 0.

his query returns a boolean value to

T indicate whether the optional FlexRay bus triggering and analysis feature is present.

urns a boolean value to

annels is present.

hannels.

channels.

e whether the vertical invert feature for

ery returns a boolean value to

O3000 Series oscilloscopes do

2-18 MSO3000 and DPO3000 Series Programmer Manual

Tabl e 2-17: Conﬁguration Commands (cont.)

Command Groups

Command

CONFIGuration:BUSWAVEFORMS:I2C?

CONFIGuration:BUSWAVEFORMS:LIN?

CONFIGuration:BUSWAVEFORMS: MIL1553B?

CONFIGuration:BUSWAVEFORMS: NUMBUS?

CONFIGuration:BUSWAVEFORMS: PARALLEL?

CONFIGuration:BUSWAVEFORMS:RS232?

CONFIGuration:BUSWAVEFORMS:SPI?

CONFIGuration:BUSWAVEFORMS:USB?

CONFIGuration:BUSWAVEFORMS:USB: HS?

CONFIGuration:DIGITAl:MAGNIVU?

CONFIGuration:DIGITAl: MAXSAMPLERate?

CONFIGuration:DIGITAl:NUMCHANnels? This query returns the number of digital

CONFIGuration:EXTVIDEO?

Description

This query returns a boolean value to indicate whether the optional I analysis feature is present.

This query returns a boolean value to indicate whether the optional LIN bus triggering and analysis feature is present.

This query returns a boolean value to indicate whether the optional MIL-STD-1553 bus triggering and analysis feature is present.

This query returns the number of bus waveforms.

This query returns a boolean value to indicate whether the parallel bus triggering and analysis feature is present.

This query returns a boolean value to indicate whether the optional RS232 bus triggering and analysis feature is present.

This query returns a boolean value to indicate whether the optional SPI bus triggering and analysis feature is present.

This query returns a boolean value to indicate whether the USB bus triggering and analysis feature is present. As the MSO/DPO3000 Series oscilloscopes do not support this feature, this query always returns 0.

This query returns a boolean value to indicate whether the high-speed USB bus triggering and analysis feature is present. As the MSO/DPO3000 Series oscilloscopes do not support this feature, this query always returns 0.

This query returns a boolean value to indicate whether the instrument supports the MagniVu feature for digital channels. If there are no digital channels, the value returned is 0.

This query returns the maximum sample rate for digital channels, in samples per second. If there are no digital channels, the value returned is 0.

channels.

This query returns a boolean value to indicate whether the optional extended video trigger features are present.

C bus triggering and

MSO3000 and DPO3000 Series Programmer Manual 2-19

Command Groups

Table 2-17: Conﬁguration Commands (cont.)

Command

CONFIGuration:HISTOGRAM?

CONFIGuration:NETWORKDRIVES?

CONFIGuration:NUMMEAS? This query returns the number of periodic

CONFIGuration:REFS:NUMREFS? This query returns the number of reference

CONFIGuration:RF:ADVTRIG?

CONFIGuration:RF:MAXBANDWidth?

CONFIGuration:RF:NUMCHANnels? This query returns the number of RF

CONFIGuration:ROSC?

Description

This query returns a boolean value to indicate whether the histogram feature is present. As the MSO/DPO3000 Series oscilloscopes do not support this feature, this query always returns 0.

This query returns a boolean value to indicate whether network drives are present. As the MSO/DPO3000 Series oscilloscopes do not support this feature, this query always returns 0.

measurements.

waveforms.

This query returns a boolean value to indicate whether the advanced RF trigger feature is present. As the MSO/DPO3000 Series oscilloscopes do not support this feature, this query always returns 0.

This query returns the maximum bandwidth, in Hertz, for RF channels. As the MSO/DPO3000 Series oscilloscopes do not support this feature, this query always returns 0.

channels present. As the MSO/DPO3000 Series oscilloscopes do not support this feature, this query always returns 0.

This query returns a boolean value to indicate whether the external reference oscillator (ROSC) input is present.

2-20 MSO3000 and DPO3000 Series Programmer Manual

Command Groups

Cursor Comman

dGroup

Use the commands in the Cursor Command Group to control the cursor display and readout. You can use these commands to control the setups for cursor 1 and cursor 2, suc

You can also use the commands to select one of the following cursor functions:

Table 2-18: Cursor Commands

Command

CURSor?

CURSor:DDT? Returns the cursor deltaY/deltaT (dY/dT)

CURSor:FUNCtion Sets or returns the cursor type

CURSor:HBArs?

CURSor:HBArs:DELTa? Returns the hbars c ursors vertical difference

CURSor:HBArs:POSITION<x> Sets o r returns the hbar cursor<x> vertical

CURSor:HBArs:UNIts

CURSor:HBArs:USE Sets the horizontal bar cursor measurement

CURSor:MODe Sets or returns whether cursors move in

CURSor:VBArs? Sets or returns the position of vertical bar

CURSor:VBArs:ALTERNATE<x>? Returns the alternate readout for the

CURSor:VBArs:DELTa? Returns the horizontal difference between

CURSor:VBArs:HPOS<x>? Returns the vertical value of the speciﬁed

CURSor:VBArs:POSITION<x> Sets or returns the vbar cursor<x> horizontal

CURSor:VBArs:UNIts Sets or returns the horizontal units for vbar

CURSor:VBArs:USE Sets the vertical bar cursor measurement

h as cursor position.

Off. Turns off the display of all cursors.

Waveform Cursors. Consists of two cursors. Waveform cursors enable you to conveniently measure waveform amplitude and time.

Screen Cursors. Consists of two pairs of independent horizontal and vertical cursors. You can use these cursors to indicate an arbitrary position within the waveform display area.

Description

Returns the cursor settings

readout

Returns the hbar cursor settings

position

Returns the hbar cursor units

scale, for use with ratio cursors

unison or separately

cursors

waveform (Vbar) cursors

vbar cursors

vertical bar tick

position

cursors

scale

MSO3000 and DPO3000 Series Programmer Manual 2-21

Command Groups

Table 2-18: Cursor Commands (cont.)

Command

CURSor:VBArs:VDELTa? Returns the vertical difference between the

CURSor:XY:POLar:RADIUS:DELta? Returns the difference between the cursors

CURSor:XY:POLar:RADIUS:POSITION<x>? Returns the polar radius of the speciﬁed

CURSor:XY:POLar:RADIUS:UNIts?

CURSor:XY:POLar:THETA:DELta?

CURSor:XY:POLar:THETA:POSITION<x>?

CURSor:XY:POLar:THETA:UNIts?

CURSor:XY:PRODUCT:DELta? Returns the difference between the cursors

CURSor:XY:PRODUCT:POSITION<x>? Returns the position of the X or Y cursor used

CURSor:XY:PRODUCT:UNIts?

CURSor:XY:RATIO:DELta? Returns the ratio of the difference between

CURSor:XY:RATIO:POSITION<x>? Returns the X or Y position for the speciﬁed

CURSor:XY:RATIO:UNIts? Returns the X and Y c ursor units for the ratio

CURSor:XY:READOUT Sets or returns the XY cursor readout

CURSor:XY:RECTangular:X:DELta?

CURSor:XY:RECTangular:X:POSITION<x> Sets or returns the cursor X rectangular

CURSor:XY:RECTangular:X:UNIts?

CURSor:XY:RECTangular:Y:DELta?

CURSor:XY:RECTangular:Y:POSITION<x>> Sets or returns the cursor Y rectangular

CURSor:XY:RECTangular:Y:UNIts?

Description

two vertical bar cursor ticks

X radius and the cursor Y radius

cursor

Returns the polar radius units

Returns the XY cursor polar coordinate delta

Returns the cursor X or cursor Y polar coordinate

Returns the cursor polar coordinate units

X position and cursor Y position

to calculate the X × Y cursor measurement

Returns the XY cursor product units

the cursor X position and cursor Y position

cursor

measurement

selection

Returns the X delta value in rectangular coordinates

coordinates

Returns the cursor X rectangular units

Returns the cursor Y delta value in rectangular coordinates

coordinate

Returns the cursor Y rectangular units

Display Command Group

Use the commands in the Display Command Group to change the graticule style, the display intensities, and to set the characteristics of the waveform display. Also, use it to send messages to the display.

2-22 MSO3000 and DPO3000 Series Programmer Manual

Command Groups

NOTE. Your sett

ings globally affect all displayed waveforms.

Table 2-19: Display Commands

Command

DISplay?

DISplay:CLOCk Sets or returns the d isplay of the date/time

DISplay:DIGital:HEIght Sets or returns the number of available digital

DISplay:GRAticule This command speciﬁes the type of graticule

DISplay:INTENSITy?

DISplay:INTENSITy:BACKLight Sets or returns the backlight intensity for the

DISplay:INTENSITy:GRAticule Sets or returns the graticule intensity for the

DISplay:INTENSITy:WAVEform Sets or returns the intensity of the waveforms

DISplay:PERSistence Sets or returns the display persistence

DISplay:STYle:DOTsonly Sets a dots-only display

DISplay:XY This command turns on or off the XY display

MESSage Sets or queries message box (screen

MESSage:BOX Sets or returns the coordinates of the

MESSage:CLEAR Clears the contents of the message box

MESSage:SHOW Sets or returns the contents of the message

MESSage:STATE Controls the display of the message box

Description

Returns the current display settings

stamp

waveform position slots

the oscilloscope displays.

Returns all the display intensity settings

display

setting

mode.

annotation) parameters

message box

box

Ethernet Command Group

Use the commands in the Ethernet Command Group to set up the Ethernet remote interface.

Table 2-20: Ethernet Commands

Command

ETHERnet:DHCPbootp Sets o r returns the network initialization

MSO3000 and DPO3000 Series Programmer Manual 2-23

Description

search for a DHCP/BOOTP server

Command Groups

Table 2-20: Ethernet Commands (cont.)

Command

ETHERnet:DNS:IPADDress Sets or r eturns the network Domain Name

ETHERnet:DOMAINname Sets or returns the network domain name

ETHERnet:ENET:ADDress?

ETHERnet:GATEWay:IPADDress Sets or returns the remote interface gateway

ETHERnet:HTTPPort

ETHERnet:IPADDress

ETHERnet:NAME

ETHERnet:PASSWord Sets or returns the Ethernet access password

ETHERnet:PING Causes the oscilloscope to ping the gateway

ETHERnet:PING:STATUS? Returns the results from pinging the gateway

ETHERnet:SUBNETMask Sets or returns the remote interface subnet

Description

Server (Dns) IP address

Returns the Ethernet address value assigned to the o scillos cope

IP address

Sets or returns the remote interface HTTP port value

Sets or returns the IP address assigned to the oscilloscope

Sets or returns the network name assigned to the o scillos cope

IP address

mask value

File System Command Group

Use the commands in the File System Command Group to help you use USB

edia. You can use the commands to do the following:

List the contents of a directory

Create and delete directories

Create,read,rename,ordeleteaﬁle

Format media

When using these commands, keep the following points in mind:

File arguments are always enclosed within double quotes: "E:/MYDIR/TEK00001.SET"

File names follow the non-case sensitive, MSDOS format: [DRIVE:][\PATH\]ﬁlename

Path separators may be either forward slashes (/) or back slashes (\)

2-24 MSO3000 and DPO3000 Series Programmer Manual

Command Groups

NOTE. Using bac

k slash as a path separator may produce some unexpected results, depending on how your application treats escaped characters. Many applications recognize the sequence of back slash followed by an alphabetic character as an escaped character, and, as such, interpret that alphabetic character as a control character. For example, the sequence "\n" may be interpreted as a newline character; "\t" may be interpreted as a tab character. To ensure that

this interpretation does not occur, you can use double back slashes.

For example, "E:\\testﬁle.txt".

Tabl e 2-21

Command

FILESystem? Returns the directory listing of the current

FILESys

FILESystem:DELEte Deletes a named ﬁle or directory

FILESystem:DIR? Returns a list of directory contents

FILESystem:FORMat

FILESystem:FREESpace? Returns the number of bytes of free space

FILESystem:MKDir Creates a new directory

FILESystem:READFile Writes the contents of the speciﬁed ﬁle to the

LESystem:REName

LESystem:RMDir

ILESystem:WRITEFile

: File System Commands

tem:CWD

Descripti

working directory and the number of bytes of free spa

Sets or r for FILESystem commands

Forma

on the current drive

spe

Deletes a named directory

W oscilloscope current working directory

ce available

eturns the current working directory

ts a named drive

ciﬁed interface

signs a new name to an existing ﬁle

rites the speciﬁed block data to the

Hard Copy Command Group

Use the commands in the Hard Copy Command Group to make hard copies. PictBridge commands belong to a separate group. (See page 2-35, PictBridge Command Group.)

Table 2-22: Hard Copy Commands

Command

HARDCopy Sends a copy of the screen display to the

HARDCopy:ACTIVeprinter Sets or returns the c urrently active printer

HARDCopy:INKSaver Changes hard copy output to print color

MSO3000 and DPO3000 Series Programmer Manual 2-25

Description

selected printer

traces and graticule on a white background

Command Groups

Table 2-22: Hard Copy Commands (cont.)

Command

HARDCopy:LAYout Sets or returns the page orientation for hard

HARDCopy:PREVIEW

HARDCopy:PRINTer:ADD Adds a network printer to the list of available

HARDCopy:PRINTer:DELete Removes a network printer from the list of

HARDCopy:PRINTer:LIST? Returns the list of currently attached printers

HARDCopy:PRINTer:REName Renames a network printer in the list of

Description

copy

Previews the current screen contents with the InkSaver palette applied

printers

available printers

2-26 MSO3000 and DPO3000 Series Programmer Manual

Command Groups

Horizontal Co

mmand Group

Use the commands in the Horizontal Command Group to control the oscilloscope horizontal parameters.

Tabl e 2-23:

Command

HORizontal? Returns settings for the horizontal commands

HORizontal:DELay:MODe Sets or returns the horizontal delay mode

HORizontal:DELay:TIMe Sets or returns the horizontal delay time

HORizontal:DIGital:RECOrdlength: MAGnivu

HORizon

HORizontal:DIGital:SAMPLERate: MAGnivu?

HORizontal:DIGital:SAMPLERate:MAIN? Returns the sample rate of the main digital

zontal:POSition

HORi

HORizontal:PREViewstate?

HORizontal:RECOrdlength Sets or returns the record length

HORizontal:SAMPLERate Sets or returns the sample rate

HORizontal:SCAle Sets or returns the horizontal scale

HORizontal:DIGital:RECOrdlength: MAGnivu?

HORizontal:DIGital:RECOrdlength:MAIN? Returns the record length of the main digital

HORizontal:DIGital:SAMPLERate: MAGnivu?

HORizontal:DIGital:SAMPLERate:MAIN? Returns the sample rate of the main digital

Horizontal Commands

tal:DIGital:RECOrdlength:MAIN?

Descriptio

(position) that is used when delay is on

Returns the record length of the MagniVu digital

Returns acquisition

Returns the sample rate of the Magnivu digital acquisition

acqui

Sets percent, that is used when delay is off

Retu

Returns the record length of the MagniVu digital acquisition

acquisition

Returns the sample rate of the Magnivu digital acquisition

acquisition

the record length of the main digital

sition

or returns the horizontal position, in

rns the display system preview state

Mark Command Group

Use the commands in the Mark Command Group to identify areas of the acquired waveform that warrant further investigation.

MSO3000 and DPO3000 Series Programmer Manual 2-27

Command Groups

Table 2-24: Mar

Command Description

MARK

MARK:CREAT

MARK:DELEt

MARK:FREE? Returns how many marks are free to be used

MARK:SELected:END? Returns the end of the selected mark, in

MARK:SE

MARK:SELected:MARKSINCOLumn?

MARK:SELected:OWNer? Returns the owner of the selected mark

MARK:SELected:SOURCE? Returns the source waveform of the selected

MARK:SELected:STARt? Returns the start of the selected mark, in

MARK

MARK:SELected:ZOOm:POSition? Returns the position of the selected mark, in

MARK:TOTal?

Lected:FOCUS?

:SELected:STATe?

k Commands

Moves to the next or previous reference mark on the waveform. Returns the current mark positio

Creates a ma all waveforms in a c olumn

Deletes a mark on a particular waveform, all waveforms in a colum n, or all marks

terms of 0

Returns terms of 0 to 100% of the waveform

Returns zoom pixel column

mark

term

Retu mark

terms of 0 to 100% of the upper window

Returns how many marks are used

rk on a particular w aveform or

to 100% of the waveform

the focus of the selected mark, in

how many marks are in the current

s of 0 to 100% of the waveform

rns the on or off state of the selected

2-28 MSO3000 and DPO3000 Series Programmer Manual

Command Groups

Math Command G

roup

Use the commands in the Math Command Group to create and deﬁne a math waveform. Use the available math functions to deﬁne your math waveform.

The math waveform you create depends on sources listed in the math expression. If you change these sources, the math waveform you previously deﬁned will be affected.

Math expressions can be simple, containing no mathematical computation, such as CH1, whi

ch speciﬁes that a waveform shows the signal source of Channel 1. Math expressions can also be complex, consisting of up to 128 characters and comprising many sources, functions, and operands.

When a live waveform is updated or a reference waveform is altered, math waveforms containing those w aveforms as sources are also updated to reﬂect the changes. Remember that sources must exist, but do not need to be displayed, to be used in and to update math waveforms.

Table 2 -25: Math Commands

Command

MATH[1]? Returns the deﬁnition of the math waveform

MATH[1]:DEFine

MATH[1]:HORizontal:SCAle Sets or returns the math horizontal display

MATH[1]:HORizontal:UNIts Returns the math waveform horizontal unit

{MATH|MATH1}:LABel Sets or queries the waveform label for the

MATH[1]:SPECTral:MAG Sets or returns the units of spectral

MATH[1]:SPECTral:WINdow Sets or returns the window function for math

MATH[1]:VERTical:POSition Sets or returns the vertical position of the

MATH[1]:VERTical:SCAle Sets or returns the vertical scale of the

MATH[1]:VERTical:UNIts

MATH[1]:HORizontal:POSition Sets or returns the math horizontal display

MATH[1]:TYPe

Description

Sets or returns the current math function as atextstring

scale for FFT or for Dual Math waveforms

value

math waveform

magniﬁcation in the math string

waveform spectral input data

currently selected math type

Returns the math waveform vertical units

position for FFT or (non-live) math reference waveforms

Sets or returns the math waveform mode type

MSO3000 and DPO3000 Series Programmer Manual 2-29

Command Groups

Table 2-25: Math Commands (cont.)

Command

MATHVAR?

MATH VAR:VAR<x>

Measurement Command Group

Use the commands in the Measurement Command Group to control the automated measurement system.

Up to four automated measurements can be displayed on the screen. In the commands, these measurement readouts are named MEAS<x>, where <x> is the measurement number.

In addition to the four displayed measurements, the measurement commands let you specify an additional measurement, IMMed. The immediate measurement has no Because they are computed only when needed, immediate me asurements slow the waveform update rate less than displayed measurements.

Whether you use displayed or immediate measurements, use the VALue query to obtain measurement results.

front-panel equivalent. Immediate measurements are never displayed.

Description

Returns all numerical values used within math expressions

Sets or returns numerical values you can use within math expressions

Measurement commands can set and query measurement parameters. You can assign some parameters, such as waveform sources, differently for each measurement. Other parameters, such as reference levels, have only one value, which applies to all measurements.

Table 2-26: Measurement Commands

Command

MEASUrement?

MEASUrement:CLEARSNapshot

MEASUrement:GATing Sets or returns the measurement gating

MEASUrement:IMMed?

MEASUrement:IMMed:DELay? Returns information about the immediate

MEASUrement:IMMed:DELay:DIRection Sets or returns the search direction to use for

MEASUrement:IMMed:DELay:EDGE<x> Sets or returns the slope of the edge used for

Description

Returns all measurement parameters

Removes the measurement snapshot display

Returns all immediate m easurement setup parameters

delay measurement

immediate delay measurements

immediate delay “from” and “to” waveform measurements

2-30 MSO3000 and DPO3000 Series Programmer Manual

Table 2-26: Measurement Commands (cont.)

Command Groups

Command

MEASUrement:IMMed:SOUrce<x> Sets or returns the source for the current

MEASUrement:IMMed:SOUrce1 Sets or returns the “from” source for all single

MEASUrement:IMMed:SOUrce2 Sets or returns the source to measure “to” for

MEASUrement:IMMed:TYPe Sets or returns the type of the immediate

MEASUrement:IMMed:UNIts? Returns the units of the immediate

MEASUrement:IMMed:VALue? Returns the value of the immediate

MEASUrement:INDICators?

MEASUrement:INDICators:HORZ<x>? Returns the position of the speciﬁed

MEASUrement:INDICators:NUMHORZ? Returns the number of horizontal

MEASUrement:INDICators:NUMVERT? Returns the number of vertical measurement

MEASUrement:INDICators:STATE Sets or returns the state of visible

MEASUrement:INDICators:VERT<x>? Returns the value of the speciﬁed vertical

MEASUrement:MEAS<x>?

MEASUrement:MEAS<x>:COUNt? Returns the number of values accumulated

MEASUrement:MEAS<x>:DELay?

MEASUrement:MEAS<x>:DELay:DIRection Sets or returns the search direction to use for

MEASUrement:MEAS<x>:DELay:EDGE<x> Sets or returns the slope of the edge to

MEASUrement:MEAS<x>:MAXimum? Returns the maximum value found since the

MEASUrement:MEAS<x>:MEAN?

MEASUrement:MEAS<x>:MINImum? Returns the minimum v alue found since the

Description

single channel measurement

channel immediate measurements

phase or delay immediate measurements

measurement

Returns all measurement indicator parameters

horizontal measurement indicator

measurement indicators currently being displayed

indicators currently being displayed

measurement indicators

measurement indicator

Returns all measurement parameters

since the last statistical reset

Returns the delay measurement parameters for the speciﬁed measurement

delay measurements

use for delay “from” and “to” waveform measurements

last statistical reset

Returns the mean value accumulated since the last statistical reset

last statistical reset

MSO3000 and DPO3000 Series Programmer Manual 2-31

Command Groups

Table 2-26: Measurement Commands (cont.)

Command

MEASUrement:MEAS<x>:SOUrce<x> Sets or returns the source for the speciﬁed

MEASUrement:MEAS<x>:SOURCE[1] Sets or returns the channel from which

MEASUrement:MEAS<x>:SOURCE2 Sets or returns the channel to which

MEASUrement:MEAS<x>:STATE Sets or returns whether the speciﬁed

MEASUrement:MEAS<x>:STDdev? Returns the standard deviation of values

MEASUrement:MEAS<x>:TYPe Sets or returns the measurement<x> type

MEASUrement:MEAS<x>:UNIts?

MEASUrement:MEAS<x>:VALue? Returns the value of measurement<x>

MEASUrement:METHod Sets or returns the method used for

MEASUrement:REFLevel? Returns the current reference level

MEASUrement:REFLevel:ABSolute:HIGH Sets or returns the top reference level for

MEASUrement:REFLevel:ABSolute:LOW Sets or returns the low reference level for

MEASUrement:REFLevel:ABSolute:MID Sets or returns the mid reference level for

MEASUrement:REFLevel:ABSolute:MID<x> Sets or returns the mid reference level in

MEASUrement:REFLevel:ABSolute:MID2 Sets or returns the mid reference level for

MEASUrement:REFLevel:METHod Speciﬁes or returns the reference level units

MEASUrement:REFLevel:PERCent:HIGH Sets or returns the top reference percent

MEASUrement:REFLevel:PERCent:LOW Sets or returns the low reference percent

MEASUrement:REFLevel:PERCent:MID Sets or returns the mid reference percent

MEASUrement:REFLevel:PERCent:MID<x> Sets or returns the mid reference level for

MEASUrement:REFLevel:PERCent:MID2 Sets or returns the mid reference percent

MEASUrement:SNAPShot

Description

measurement

measurements are taken

measurements are sent

measurement slot is computed and displayed

accumulated since the last statistical reset

Returns measurement<x> units

calculating reference levels

parameters

rise and fall time

measurements

absolute units (e.g. volts)

delay "to" measurements

used for measurement calculations

level for rise and fall time

level for waveform measurements

the speciﬁed channel in percent

level for second waveform measurements

Displays the measurement snapshot list

2-32 MSO3000 and DPO3000 Series Programmer Manual

Table 2-26: Measurement Commands (cont.)

Command Groups

Command

MEASUrement:STATIstics:MODE Turns measurement statistics on or off

MEASUrement:STATIstics Clears or returns all of the statistics

MEASUrement:STATIstics:WEIghting Controls the responsiveness of the mean

Miscellaneous Command Group

Use the commands in the Miscellaneous Command Group to perform actions that do not ﬁt into other categorie s.

Several commands

488.2-1987 standard deﬁnes these commands. The common commands begin with an asterisk (*) character.

Table 2-27: Miscellaneous Commands

Command

APPLication:LICENSE:SLOT<x>:LOCation?

APPLication:LICENSE:SLOT<x>: TRANSFER

APPLication:LICENSE:SLOT<x>:TYPe?

AUTOSet Sets the vertical, horizontal, and trigger

AUTOSet:ENAble Enables or disables the autoset feature

CLEARMenu Clears the current menu from the display

DATE

*DDT Sets or returns the commands that will be

FPAnel:HOLD

Description

accumulated for all period measurements (MEAS1 through MEAS4)

and standard deviation to waveform changes

and queries are common to all 488.2-1987 devices. The

Description

This query returns the application license location. < x> can be slot number 1–4.

You can use this command to transfer an application license from the module to internal memory in the oscilloscope, and transfer it back.

This query returns the application license type of the module that is currently inserted in the speciﬁed application module slot.

controls of the oscilloscope to automatically acquire and display the appropriate waveform(s). This is equivalent to pressing the front panel Autoset button

Sets or returns the date displayed by the oscilloscope

executed by the group execute trigger

This command is used to emulate the button push-and-hold feature. Presently, only the Cursors button is supported by this command.

MSO3000 and DPO3000 Series Programmer Manual 2-33

Command Groups

Table 2-27: Miscellaneous Commands (cont.)

Command

FPAnel:PRESS Simulates the action of pressing a speciﬁed

FPAnel:TURN

GPIBUsb:ADDress? Returns the current GPIB address

GPIBUsb:ID? Returns the identiﬁ cation string of the

HEADer

ID? Returns identifying information about the

*IDN? Returns the same information as the ID?

LANGuage Sets or returns the user interface display

LOCk Sets or returns the front panel lock state

*LRN? Returns a listing of oscilloscope settings

MESSage Sets or queries message parameters

NEWpass

PASSWord Enables the *PUD and NEWpass set

REM

SET? Returns a listing of osc ill oscope settings

TEKSecure Initializes both waveform and setup

TIME

TOTaluptime? Returns the total number of hours that the

*TRG Performs the group execute trigger (GET)

*TST? Tests the interface and returns the status

UNLock

USBTMC? Returns the USBTMC information used by

Description

front-panel button

Duplicates the action of turning a speciﬁed front-panel control knob

connected adaptor module and ﬁrmware version

Sets or returns the Response H eader Enable State

oscilloscope and its ﬁrmware

command except the data is formatted according to Tektronix Codes & Formats

language

Changes the password for user protected data

commands

Speciﬁes a comment, which is ignored by the oscilloscope

memories

Sets or returns the time displayed by the oscilloscope

oscilloscope has been turned on since the nonvolatile memory was last programmed

Unlocks front panel

the USB hosts to determine the instrument interfaces

2-34 MSO3000 and DPO3000 Series Programmer Manual

Table 2-27: Miscellaneous Commands (cont.)

Command Groups

Command

USBTMC:PRODUCTID:DECimal? Returns the product ID of the USBTMC

USBTMC:PRODUCTID:HEXadecimal? Returns the product ID of the USBTMC

USBTMC:SERIALnumber? Returns the serial number of the USBTMC

USBTMC:VENDORID:DECimal? Returns the vendor ID of the USBTMC

USBTMC:VENDORID:HEXadecimal? Returns the vendor ID of the USBTMC

VERBose

PictBridge Command Group

Use the commands in the PictBridge Command Group to store printer settings.

e 2-28: PictBridge Commands

Tabl

Command

PICTBridge:DATEPrint

PICTBridge:DEFault Sets the arguments for all PICTBridge

PICTBridge:IDPrint

PICTBridge:IMAGESize Sets or returns the image print size

PICTBridge:PAPERSize Sets the output print paper size

PICTBridge:PAPERType Sets or returns the paper type

PICTBridge:PRINTQual Sets or returns the output print quality

USBDevice:CONFigure Enables or disables the rear USB port for

Description

device in decimal format

device in hexadecimal format

device

device in decimal format

device in hexadecimal format

Sets or returns the verbose state

ription

Desc

bles or disables printing the date on the

Ena print output

commands to their default values

Enables or disables printing the oscilloscope model and serial number on the print output

use with Pictbridge printers

Power Command Group

Use the commands in the Power Command Group for power analysis. The power measurements include:

MSO3000 and DPO3000 Series Programmer Manual 2-35

Command Groups

Power quality

Switching loss

Safe operating area

Harmonics

Ripple

Modulation analysis

This command group is available when the DPO3PWR application module is installed.

Table 2 -29: Power Commands

Command Description

POWer:CURRENTSOurce Sets or returns the current source for the

power application

POWer:DISplay Sets or returns the display state for the

power application

POWer:GATESOurce Sets or returns the gate source for the power

application

POWer:GATing Sets or returns the power application gating

POWer:HARMonics:DISPlay:SELect Sets or returns the harmonics to be displayed

when the harmonics standard is None

POWer:HARMonics:DISPlay:TYPe Sets or returns the display type for harmonics

tests

POWer:HARMonics:FREQRef Sets or returns the frequency reference

waveform for harmonics tests

POWer:HARMonics:FREQRef: FIXEDFREQValue

POWer:HARMonics:IEC:CLAss Sets or returns the ﬁltering class for IEC

POWer:HARMonics:IEC:FILter Sets or returns the enabled state for ﬁ lter ing

POWer:HARMonics:IEC:FUNDamental Sets or returns the fundamental current for

POWer:HARMonics:IEC:GROUPing Sets or returns the enabled state for grouping

POWer:HARMonics:IEC:INPUTPOWer Sets of returns the class D input power for

POWer:HARMonics:IEC:LINEFREQuency Sets or returns the line frequency for the IEC

POWer:HARMonics:IEC:OBSPERiod Sets or returns the IEC observation period

POWer:HARMonics:IEC:POWERFACtor Sets or returns the power factor for IEC

Sets or returns the ﬁxed reference frequency value for harmonics measurements

harmonics

of IEC harmonics

IEC harmonics

of IEC harmonics

IEC harmonics

standard

harmonics

2-36 MSO3000 and DPO3000 Series Programmer Manual

Command Groups

Table 2-29: Power Commands (cont.)

Command Description

POWer:HARMonics:MIL:FUNDamental: CALCmethod

POWer:HARMonics:MIL:FUNDamental: USER:CURRent

POWer:HARMonics:MIL:LINEFREQuency Sets or returns the line frequency for

POWer:HARMonics:MIL:POWERLEVel Sets or returns the power level for

POWer:HARMonics:NR_HARMonics Sets of returns the number of harmonics (a

POWer:HARMonics:RESults:HAR<1-400>: FREQuency?

POWer:HARMonics:RESults:HAR<1-400>: IECMAX?

POWer:HARMonics:RESults:HAR<1-400>: LIMit?

POWer:HARMonics:RESults:HAR<1-400>: PHASe?

POWer:HARMonics:RESults:HAR<1-400>: RMS:ABSolute?

POWer:HARMonics:RESults:HAR<1-400>: RMS:PERCent?

POWer:HARMonics:RESults:HAR<1-400>: TEST:IEC:CLASSALIMit?

POWer:HARMonics:RESults:HAR<1-400>: TEST:IEC:NORMAL?

Sets or returns the measurement method for the MIL harmonics fundamental frequency

Sets or returns RMS amperes for User calculation method

MIL-STD-1399 harmonics tests

value in the range of 20 to 400) when the harmonics standard is NONe

Returns the frequency of the harmonic

The IEC standard speciﬁes harmonics measurements to be computed in windows of time, with each time window being nominally 200 ms. This returns the maximum of the RMS magnitude of the harmonic, computed across successive 200 ms time windows within an observation period entered by the user

The IEC and MIL standards specify a limit for each harmonic magnitude. Returns the limit in absolute units, or as a percentage of the fundamental as speciﬁed by the standard. IEC Class C (Table 2) and MIL standards specify the limit as a percentage of the fundamental

Returns the phase of the harmonic in degrees. The phase is measured relative to the zero-crossing of the reference waveform. When there is no reference waveform, the phase is relative to the fundamental component

Returns the RMS magnitude of the harmonic expressed in absolute units

Returns the RMS magnitude of the harmonic expressed as a percentage of the fundamental

Returns PASS, FAIL or NA. Speciﬁes if the IEC Class A higher harmonic limit (and conditions) are met

Returns PASS, FAIL or NA. Speciﬁes if the Normal IEC harmonic limits are met

MSO3000 and DPO3000 Series Programmer Manual 2-37

Command Groups

Table 2-29: Power Commands (cont.)

Command Description

POWer:HARMonics:RESults:HAR<1-400>: TEST:IEC:POHCLIMit?

POWer:HARMonics:RESults:HAR<1-400>: TEST:MIL:NORMAL?

POWer:HARMonics:RESults:IEC: FUNDamental?

POWer:HARMonics:RESults:IEC: HARM3ALTernate?

POWer:HARMonics:RESults:IEC: HARM5ALTernate?

POWer:HARMonics:RESults:IEC:POHC? Returns the IEC POHC measurement

POWer:HARMonics:RESults:IEC:POHL? Returns the IEC POHL measurement

POWer:HARMonics:RESults:IEC:POWer? Returns the IEC input power measurement

POWer:HARMonics:RESults:IEC: POWERFactor?

POWer:HARMonics:RESults:PASSFail?

POWer:HARMonics:RESults:RMS? Returns the root mean square value of the

POWer:HARMonics:RESults:SAVe Saves the harmonic results to the speciﬁed

POWer:HARMonics:RESults:THDF? Returns the Total Harmonic Distortion (THD)

POWer:HARMonics:RESults:THDR? Returns the Total Harmonic Distortion (THD)

POWer:HARMonics:SOURce Sets or returns the source waveform for

POWer:HARMonics:STANDard Sets o r returns the standard for harmonics

POWer:INDICators Sets or returns the state of the measurement

POWer:MODulation:SOUrce Sets or returns the source waveform for

POWer:MODulation:TYPe Sets or returns the m odulation type

POWer:QUALity:APPpwr?

POWer:QUALity:DISplay:APPpwr Sets or returns the display state for the

Returns PASS, FAIL or NA. Speciﬁes if the higher harmonic limit (and conditions) for the 21st and higher order odd harmonics are met

Returns the test result for the speciﬁed harmonic for the MIL-STD-1399 testing standard

Returns the IEC fundamental frequency

Returns the IEC harmonics test result for the 3rd harmonic: PASS, FAIL or NA

Returns the IEC harmonics test result for the 5th harmonic: PASS, FAIL or NA

Returns the IEC power factor measurement

Returns the overall harmonics test result: PASS, FAIL or N A

source waveform

ﬁle in CSV format

in percentage, measured as a ratio to the RMS value of the fundamental component of the source waveform

in percentage, measured as a ratio to the RMS value of the source waveform

harmonics tests

tests

indicators for the power application

modulation tests

Returns the apparent power measurement

apparent power readout

2-38 MSO3000 and DPO3000 Series Programmer Manual

Command Groups

Table 2-29: Power Commands (cont.)

Command Description

POWer:QUALity:DISplay:FREQuency Sets or returns the d isplay state for the

frequency readout

POWer:QUALity:DISplay:ICRESTfactor Sets or returns the display state for the

current crest factor readout

POWer:QUALity:DISplay:IRMS Sets or returns the display state for the RMS

current (IRMS) readout

POWer:QUALity:DISplay:PHASEangle Sets or returns the display state for the

phase angle readout

POWer:QUALity:DISplay:POWERFACtor Sets or returns the display state for the

power factor readout

POWer:QUALity:DISplay:REACTpwr Sets or returns the display state for the

reactive power readout

POWer:QUALity:DISplay:TRUEpwr Sets or returns the display state for the true

power readout

POWer:QUALity:DISplay:VCRESTfactor Sets or returns the display state for the

voltage crest factor readout

POWer:QUALity:DISplay:VRMS Sets or returns the display state for the RMS

voltage (VRMS) readout

POWer:QUALity:FREQREFerence Sets or returns the power quality frequency

reference

POWer:QUALity:FREQuency? Returns the frequency measurement

POWer:QUALity:ICRESTfactor? Returns the current crest factor measurement

POWer:QUALity:IRMS? Returns the RMS current measurement

POWer:QUALity:PHASEangle?

POWer:QUALity:POWERFACtor? Returns the power factor measurement

POWer:QUALity:REACTpwr?

POWer:QUALity:TRUEpwr?

POWer:QUALity:VRMS? Returns the RMS voltage measurement

POWer:REFLevel:ABSolute Sets the reference levels to their default unit

POWer:REFLevel:ABSolute:HIGH Sets or returns the top reference level for

POWer:REFLevel:ABSolute:LOW Sets or returns the low reference level for

POWer:REFLevel:ABSolute:MID<1-3> Sets or returns the mid reference level for

POWer:REFLevel:HYSTeresis Sets or returns the measurement reference

POWer:REFLevel:METHod Sets or returns the method used to calculate

Returns the phase angle measurement

Returns the reactive power measurement

Returns the true power measurement

values

rise time

measurements

level hysteresis value

the 0% and 100% reference level

MSO3000 and DPO3000 Series Programmer Manual 2-39

Command Groups

Table 2-29: Power Commands (cont.)

Command Description

POWer:REFLevel:PERCent Sets the reference levels to the default

percentage values

POWer:REFLevel:PERCent:HIGH Sets or returns the top reference percent

level for rise time

POWer:REFLevel:PERCent:LOW Sets or returns the low reference percent

level for rise time

POWer:REFLevel:PERCent:MID<1-3> Sets or returns the mid reference percent

level for waveform measurements

POWer:RIPPle Sets the vertical offset of the source

waveform

POWer:RIPPle:RESults:AMPLitude?

POWer:RIPPle:RESults:MAX? Returns the maximum of the peak-to-peak

POWer:RIPPle:RESults:MEAN? Returns the mean of the peak-to-peak ripple

POWer:RIPPle:RESults:MIN? Returns the minimum of the peak-to-peak

POWer:RIPPle:RESults:STDdev? Returns the standard deviation of the

POWer:RIPPle:SOUrce Sets or returns the source waveform for

POWer:SOA:LINear:XMAX Sets or returns the user XMAX value for use

POWer:SOA:LINear:XMIN Sets or returns the user XMIN value for use

POWer:SOA:LINear:YMAX Sets or returns the user YMAX value for use

POWer:SOA:LINear:YMIN Sets or returns the user YMIN value for use

POWer:SOA:LOG:XMAX Sets or r eturns the user XMAX value for use

POWer:SOA:LOG:XMIN Sets or returns the user X MIN value for use

POWer:SOA:LOG:YMAX Sets or r eturns the user YMAX value for use

POWer:SOA:LOG:YMIN Sets or returns the user Y MIN value for use

POWer:SOA:MASK:DEFine Sets or returns the X (Volts) and Y (Amps)

POWer:SOA:MASK:MAXAmps Sets or returns the maximum current applied

Returns the peak-to-peak ripple measurement

ripple measurements

measurements

ripple measurement

peak-to-peak ripple measurements

ripple tests

in linear SOA calculations

in log SOA calculations

coordinates of the current SOA mask

to SOA mask testing

2-40 MSO3000 and DPO3000 Series Programmer Manual

Command Groups

Table 2-29: Power Commands (cont.)

Command Description

POWer:SOA:MASK:MAXVolts Sets or returns the maximum voltage applied

to SOA mask testing

POWer:SOA:MASK:MAXWatts Sets or returns the maximum power applied

to SOA mask testing

POWer:SOA:MASK:NR_PT? Returns the number of mask points deﬁned

POWer:SOA:MASK:STATe Sets or returns the state of the mask for SOA

calculations

POWer:SOA:MASK:STOPOnviol Sets or returns the enabled state of the mask

stop on violation condition

POWer:SOA:PLOTTYPe Sets or returns the SOA plot type

POWer:SOA:RESult:FAILures:QTY? Returns the number of failures in the test

POWer:SOA:RESult:NUMACq? Returns the number of acquisitions in the test

POWer:SOA:RESult:STATe? Returns the pass/fail state of the SOA test

POWer:STATIstics Clears all the accumulated statistics of all

measurements

POWer:STATIstics:MODE Enables or disables the display of the

measurement statistics

POWer:STATIstics:WEIghting Sets the number of samples which are

included for the statistics computations for mean and the standard deviation

POWer:SWLoss:CONDCALCmethod Sets or returns the power application

switching loss conduction calculation method

POWer:SWLoss:CONDuction:ENERGY: MAX?

POWer:SWLoss:CONDuction:ENERGY: MEAN?

POWer:SWLoss:CONDuction:ENERGY: MIN?

POWer:SWLoss:CONDuction:POWER: MAX?

POWer:SWLoss:CONDuction:POWER: MEAN?

POWer:SWLoss:CONDuction:POWER: MIN?

POWer:SWLoss:DISplay Sets or returns the display selection for

POWer:SWLoss:GATe:POLarity Sets or returns the switching loss gate

POWer:SWLoss:GATe:TURNON Sets or returns the gate turn on level for

Returns the maximum conduction energy for the switching loss calculation

Returns the mean conduction energy for the switching loss calculation

Returns the minimum conduction energy for the switching loss calculation

Returns the maximum conduction power for the switching loss calculation

Returns the mean conduction power for the switching loss calculation

Returns the minimum conduction power for the switching loss calculation

switching loss results

polarity

switching loss power measurements

MSO3000 and DPO3000 Series Programmer Manual 2-41

Command Groups

Table 2-29: Power Commands (cont.)

Command Description

POWer:SWLoss:NUMCYCles? Returns the number of cycles counted for the

switching loss calculation

POWer:SWLoss:RDSon Sets or returns RDSON value for use

in switching loss calculations when the conduction calculation method is RDSON

POWer:SWLoss:REFLevel:ABSolute: GATEMid

POWer:SWLoss:REFLevel:ABSolute: LOWCurrent

POWer:SWLoss:REFLevel:ABSolute: LOWVoltage

POWer:SWLoss:REFLevel:PERCent: GATEMid

POWer:SWLoss:REFLevel:PERCent: LOWCurrent

POWer:SWLoss:REFLevel:PERCent: LOWVoltage

POWer:SWLoss:TOFF:ENERGY:MAX? Returns the maximum Toff energy for the

POWer:SWLoss:TOFF:ENERGY:MEAN? Returns the mean Toff energy for the

POWer:SWLoss:TOFF:ENERGY:MIN? Returns the minimum Toff energy for the

POWer:SWLoss:TOFF:POWER:MAX? Returns the number of maximum Toff power

POWer:SWLoss:TOFF:POWER:MEAN? Returns the mean Toff power for the

POWer:SWLoss:TOFF:POWER:MIN? Returns the minimum Toff power for the

POWer:SWLoss:TON:ENERGY:MAX? Returns the maximum Ton energy for the

POWer:SWLoss:TON:ENERGY:MEAN? Returns the mean Ton energy for the

POWer:SWLoss:TON:ENERGY:MIN? Returns the minimum Ton energy for the

POWer:SWLoss:TON:POWER:MAX? Returns the maximum Ton power for the

Sets or returns the mid voltage reference level used in switching loss power measurements in volts

Sets or returns the low current reference level used in switching loss power measurements in amperes

Sets or returns the low voltage reference level used in switching loss power measurements in volts

Sets or returns the mid voltage reference level used in switching loss power measurements in percentage

Sets or returns the low current reference level used in switching loss power measurements in percentage

Sets or returns the low voltage reference level used in switching loss power measurements in percentage

switching loss calculation

2-42 MSO3000 and DPO3000 Series Programmer Manual

Command Groups

Table 2-29: Power Commands (cont.)

Command Description

POWer:SWLoss:TON:POWER:MEAN? Returns the mean Ton power for the

switching loss calculation

POWer:SWLoss:TON:POWER:MIN? Returns the minimum Ton power for the

switching loss calculation

POWer:SWLoss:TOTal:ENERGY:MAX? Returns the maximum total energy for the

switching loss calculation

POWer:SWLoss:TOTal:ENERGY:MEAN? Returns the mean total energy for the

switching loss calculation

POWer:SWLoss:TOTal:ENERGY:MIN? Returns the minimum total energy for the

switching loss calculation

POWer:SWLoss:TOTal:POWER:MAX? Returns the maximum total power for the

switching loss calculation

POWer:SWLoss:TOTal:POWER:MEAN? Returns the mean total power for the

switching loss calculation

POWer:SWLoss:TOTal:POWER:MIN? Returns the minimum total power for the

switching loss calculation

POWer:SWLoss:VCEsat Sets or returns VCESAT value for use

in switching loss calculations when the conduction calculation method is VCESAT

POWer:TYPe Sets or returns the power application

measurement type

POWer:VOLTAGESOurce Sets or returns the voltage source for the

power application

Save and Recall Command Group

Use the commands in the Save and Recall Command Group to store and retrieve waveforms and settings. When you save a setup, you save all the settings of the oscilloscope. When you recall a setup, the oscilloscope restores itself to the state it was in when you originally saved the setting.

Table 2-30: Save and Recall Commands

Command

FACtory Resets the oscilloscope to factory default

*RCL

RECAll:SETUp

MSO3000 and DPO3000 Series Programmer Manual 2-43

Description

settings

Recalls saved oscilloscope settings

Command Groups

Table 2-30: Save and Recall Commands (cont.)

Command

RECAll:WAVEform This command (no query form) recalls a

*SAV Stores the state of the oscilloscope to a

SAVe:ASSIgn:TYPe Sets or returns the assignment of the Save

SAVe:EVENTtable:BUS<x> Saves event table data from bus<x> to a

SAVe:IM AGe Saves a capture of the screen image to the

SAVe:IMAGe:FILEFormat Sets or returns the ﬁle format to use for

SAVe:IMAGe:INKSaver Sets or returns the current inksaver setting

SAVe:IMAGe:LAYout Sets or returns the layout to use for saved

SAVe:SETUp Saves the state of the oscilloscope to a

SAVe:WAVEform Saves a waveform to one of the reference

SAVe:WAVEform:FILEFormat Sets or returns the format for saved

SAVe:WAVEform:GATIng Speciﬁes whether save waveform operations

SETUP<x>:DATE? Returns the date when the speciﬁed

SETUP<x>:LABEL Sets or returns the speciﬁed oscilloscope

SETUP<x>:TIME? Returns the time when the speciﬁed

Description

stored waveform to a reference location. Only the ﬁrst w aveform in a .CSV ﬁle is recalled for multiple waveform .CSV ﬁles. Recall of digital waveforms (D0 through D15) is not supported.

speciﬁed memory location

button

speciﬁed ﬁle

saving screen images. The ﬁle format is not automatically determined by the ﬁle name extension. You need to choose a ﬁle name with an extension which is consistent with the selected ﬁle format

for the SAVe:IMAGe command

screen images

speciﬁed memory location or ﬁle

memory locations or a ﬁle

waveforms

should save the entire waveform or a speciﬁed portion of the waveform

oscilloscope setup was saved

setup label

oscilloscope setup was saved

2-44 MSO3000 and DPO3000 Series Programmer Manual

Command Groups

Search Comman

dGroup

The search commands let you analyze your source waveform record for conditions speciﬁed by a search’s criteria. Once these criteria are matched, the oscilloscope places a sear navigate or save the marks. (See page 2-27, Mark Command Group.)

When perfor search, you can use only one waveform at a time.

When perfo displayed waveform at the same time. For example, with a logic search, you can search for instances when CH1 is high and CH2 is low.

With pulse width searching, the oscilloscope can search for pulses with widths less than, greater than, equal to, or not equal to a speciﬁed time. Additionally, it can search for pulses with widths within, or outside of a range of two different speciﬁed times. Searching can take place on either positive or negative pulses.

NOTE. Although it is possible to trigger using a video signal, it is not possible to

do a se

To see example command sequences showing different searches and triggers, see Appe

ch mark at that location in the waveform record. You can then

ming an edge, pulse width, runt, rise/fall time, time-out, or bus

rming a logic or a setup/hold search, you can use more than one

arch using a video signal.

ndixG.(SeepageE-1,Search and Trigger Command Sequence Examples.)

Searching using

Thresholds

All search types except bus searches use thresholds, which are vertical values that the source waveform must cross in order for a mark to be placed. For example, if

set the search type to EDGE, and the search source to CH1, the search’s slope

you to RISE, and the search’s threshold value to 1.5V, then that search will ﬁnd all places where CH1 transitions from below 1.5 volts to above 1.5 volts.

Each individual search source waveform has two threshold values: a low threshold and a high threshold. Note that if you change the search source waveform, you must explicitly set the thresholds. For example, if you set the search’s CH1 lower threshold to 1.5 volts, and then decide to change the search’s source waveform to CH2, you must then explicitly set CH2’s lower threshold value to the value you would like (it will not automatically be 1.5 volts). If you h ave an edge search set up on CH1 with the threshold you’d like, then decide to change to a logic search and change the threshold on CH1 to ﬁt your logic search, and then change back to an edge search, your initial threshold setting on the edge search will be lost.

MSO3000 and DPO3000 Series Programmer Manual 2-45

Command Groups

Install the DPO

3EMBD a pplication module when w orking with I

C o r SPI

bus signals.

Install the DP

O3AUTO module when working with CAN or LIN bus signals.

Install the DPO3COMP module when working with RS-232, RS-422, RS-485, and

UART bus signals.

Install the DPO3AUDIO module when working with I2S, Left Justiﬁed (LJ), Right Justi

ﬁed (RJ), and TDM bus signals.

Install the DPO3AERO module when working with MIL-STD-1553 bus signals.

Install the DPO3FLEX module when working with FlexRay bus signals.

Search C

Command Description

SEARCH?

SEARCH:SEARCH<x>:COPy Copies the search criteria to the trigger, or

SEARCH:SEARCH<x>:STATE Sets the search state to on or off

SEARCH:SEARCH<x>:TOTAL? Returns the total number of matches for

SEAR

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:AUDio:DATa:HIVALue

SEARCH:SEARCH<x>:TRIGger:A:BUS:

<x>:AUDio:DATa:OFFSet

EARCH:SEARCH<x>:TRIGger:A:BUS:

S B<x>:AUDio:DATa:QUALiﬁer

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:AUDio:DATa:VALue

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:AUDio:DATa:WORD

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:CAN:CONDition

ommands

CH:SEARCH<x>:TRIGger:A:BUS?

>:AUDio:CONDition

Returns

the trigger criteria to the search.

sear

This command returns the bus type being used RS-232, MIL-STD-1553, LIN, audio, FlexRay or Parallel).

This command sets the condition (start of fra on audio bus data.

Th be used to search on audio bus data.

This commands sets the data offset value to b

T >=, not =, in range, out of range) to be used to search on audio bus data.

This command sets the lower word value to be used to search on audio bus data.

This command sets the alignment of the data (left, right or either) to be used to search on audio bus data.

This command sets the condition (start of frame, frame type, identiﬁer, matching data, EOF, missing ACK ﬁeld, bit-stufﬁng error) to be used to search on CAN bus data.

all search-related settings

ch <x>

in a search operation (CAN, I

me or matching data) to be used to search

is command sets the upper word value to

e used to search on audio bus data.

his command sets the qualiﬁer(<,>,=,<=,

C, SPI,

2-46 MSO3000 and DPO3000 Series Programmer Manual

Search Commands (cont.)

Command Description

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:CAN:DATa:DIRection

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:CAN:DATa:QUALiﬁer

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:CAN:DATa:SIZe

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:CAN:DATa:VALue

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:CAN:FRAMEtype

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:CAN{:IDentiﬁer|:ADDRess}:MODe

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:CAN{:IDentiﬁer|:ADDRess}:VALue

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:FLEXray:CONDition

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:FLEXray:CYCLEcount:HIVALue

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:FLEXray:CYCLEcount:QUALiﬁer

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:FLEXray:CYCLEcount:VALue

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:FLEXray:DATa:HIVALue

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:FLEXray:DATa:OFFSet

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:FLEXray:DATa:QUALiﬁer

This command sets the data direction (read, writeoreither)tobeusedtosearchonCAN bus data.

This command sets the qualiﬁer (<, >, =, not =, <=) to be used to search on CAN bus data.

This command sets the length of the data string, in bytes, to be used to search on CAN bus data.

This command sets the binary data value to be used to search on CAN bus data.

This command sets the frame type (data, remote, error or overload) to be used to search on CAN bus data.

This command sets the addressing mode (standard or extended format) to be used to search on CAN bus data.

This command sets the binary address value to be used to search on CAN bus data.

This command speciﬁes the condition to use when searching on FlexRay bus data (start of frame, frame type, ID, cycle count, header, data, ID and data, EOF, error).

This command speciﬁes the upper data value of the range to be used when searching on the FlexRay bus cycle count ﬁeld.

This command speciﬁes the qualiﬁer (<, >, =, <=, >=, not =, in range, out of range) to use when searching on the FlexRay bus cycle count ﬁeld.

This command speciﬁes the low data value to be used when searching on the FlexRay bus cycle count ﬁeld.

This command speciﬁes the high value to use when searching on the FlexRay bus data ﬁeld.

This command speciﬁes the offset of the data stringinbytestobeusedwhensearchingon the FlexRay bus data ﬁeld.

This command speciﬁes the qualiﬁer (<, >, =, <=, >=, not =, in range, out of range) to use when searching on the FlexRay bus data ﬁeld.

Command Groups

MSO3000 and DPO3000 Series Programmer Manual 2-47

Command Groups

Search Commands (cont.)

Command Description

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:FLEXray:DATa:SIZe

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:FLEXray:DATa:VALue

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:FLEXray:EOFTYPE

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:FLEXray:ERRTYPE

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:FLEXray:FRAMEID:HIVALue

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:FLEXray:FRAMEID:QUALiﬁer

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:FLEXray:FRAMEID:VALue

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:FLEXray:FRAMEType

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:FLEXray:HEADER:CRC

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:FLEXray:HEADER:CYCLEcount

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:FLEXray:HEADER:FRAMEID

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:FLEXray:HEADER:INDBits

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:FLEXray:HEADER:PAYLength

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:I2C:ADDRess:MODe

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:I2C:ADDRess:TYPe

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:I2C:ADDRess:VALue

This command speci ﬁes the length of the data string, in bytes, to use when searching on the FlexRay bus data ﬁeld.

This command speciﬁesthelowvaluetouse when searching on the FlexRay bus data ﬁeld.

This command speciﬁes which end of ﬁle type to use (static, dynamic or any) when searching on the FlexRay bus EOF ﬁeld.

This command speciﬁes the error type to use when searching on the FlexRay bus signal.

This command speciﬁes the high value to use when searching on the FlexRay bus frame ID ﬁeld.

This command speciﬁes the qualiﬁer to use when searching on the FlexRay bus frame ID ﬁeld.

This command speciﬁesthelowvaluetouse when searching on the FlexRay bus frame ID ﬁeld.

This command speciﬁes the frame type (normal, payload, null, sync or startup) to use when searching on FlexRay bus data.

This command speciﬁes the CRC portion of the binary header string to be used when searching on FlexRay bus data.

This command speciﬁes to use the cycle count portion of the binary header string when searching on the FlexRay bus header.

This command speciﬁes to use the frame ID portion of the binary header string when searching on the FlexRay bus header.

This command speciﬁes to use the indicator bits portion of the binary header string when searching on the FlexRay bus header.

This command speciﬁes to use the payload length portion of the binary header string when searching on the FlexRay bus header.

Sets or returns the I2C address mode to 7 or 10-Bit

Sets or returns the I2C address type to I2C special addresses

Sets or returns the binary address string to be used for I2C search

2-48 MSO3000 and DPO3000 Series Programmer Manual

Search Commands (cont.)

Command Description

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:I2C:CONDition

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:I2C:DATa:DIRection

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:I2C:DATa:SIZe

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:I2C:DATa:VALue

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:LIN:CONDition

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:LIN:DATa:HIVALue

Sets or returns the search condition for I2C search

Sets or returns the I2C search condition to be valid on a READ, WRITE or either

Sets or returns the length of the data string inbytestobeusedforI2Csearch

Sets or returns the binary data string to be used for I2C search

Sets o r returns the search condition for a LIN search

Sets or returns the binary data string to be used for LIN searches if the search condition is ID or IDANDDATA

SEARCH:SEARCH<x>:TRIGger:A:BUS:

Sets or returns the LIN data quali ﬁer

B<x>:LIN:DATa:QUALiﬁer

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:LIN:DATa:SIZe

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:LIN:DATa:VALue

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:LIN:ERRTYPE

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:LIN:IDentiﬁer:VALue

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:MIL1553B:COMMAND:ADDRess: HIVALue

Sets or returns the length of the data string in bytes

Sets or returns the binary data string used for a LIN search

Sets or returns the error type used for a LIN Search

Sets or returns the binary address string used for LIN search

When the MIL-STD-1553 bus search condition is set to qualiﬁer is set to this command speciﬁes the upper limit of the range for the remote terminal address ﬁeld.

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:MIL1553B:COMMAND:ADDRess: QUALiﬁer

When the MIL-STD-1553 bus search condition is set to speciﬁes the qualiﬁer to be used with the remote terminal address ﬁeld.

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:MIL1553B:COMMAND:ADDRess: VALue

When the MIL-STD-553 bus search condition is set to is set to

EQual, UNEQual, LESSEQual MOREEQual, this command speciﬁes the

COMMAND, and the qualiﬁer LESSthan, MOREthan,

value of the 5–bit remote terminal address to be used in the search.

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:MIL1553B:COMMAND:COUNt

When the MIL-STD-1553 bus search condition is set to speciﬁes the bit pattern for the 5–bit Word Count/Mode Code sub-address ﬁeld that is to be used in the search.

Command Groups

COMMAND, and the

INrange or OUTrange,

COMMAND, this command

MSO3000 and DPO3000 Series Programmer Manual 2-49

Command Groups

Search Commands (cont.)

Command Description

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:MIL1553B:COMMAND:PARity

When the MIL-STD-1553 bus search condition is set to speciﬁes the Command word parity that is to be used in the search.

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:MIL1553B:COMMAND:SUBADdress

When the MIL-STD-1553 bus search condition is set to speciﬁes the 5 bit sub-address that is to be used in the search.

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:MIL1553B:COMMAND:TRBit

When the MIL-STD-1553 bus search condition is set to speciﬁes that the transmit/receive bit (bit 9) is to be used in the search.

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:MIL1553B:CONDition

This command speciﬁes the condition to use (sync, command, status, data, time, or error) when searching on MIL-STD-1553 bus data.

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:MIL1553B:DATa:PARity

When the MIL-STD-1553 bus search condition is set to speciﬁes the data parity bit to be used in the search.

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:MIL1553B:DATa:VALue

When the MIL-STD-1553 bus search condition is set to speciﬁes the data binary pattern to be used in the search.

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:MIL1553B:ERRTYPE

When the MIL-STD-1553 bus search condition is set to speciﬁes the signaling error type to be used in the search: Parity, Sync, Manchester or Data.

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:MIL1553B:STATus:ADDRess:HIVALue

When the MIL-STD-1553 bus search condition is set to is set to

INrange or OUTrange,this

command speciﬁes the upper limit for the 5 bit remote terminal address ﬁeld of the Status word.

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:MIL1553B:STATus:ADDRess:VALue

When the MIL-STD-1553 bus search condition is set to is set to

EQual, UNEQual, LESSEQual MOREEQual, this command speciﬁes the

LESSthan, MOREthan,

value of the 5–bit remote terminal address to be used in the search.

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:MIL1553B:STATus:ADDRess: QUALiﬁer

When the MIL-STD-1553 bus search condition is set to specifies the qualiﬁer to be used with the address ﬁeld.

COMMAND, this command

DATa, this command

ERRor, this command

STATus, and the qualiﬁer

STATus, this command

2-50 MSO3000 and DPO3000 Series Programmer Manual

Search Commands (cont.)

Command Description

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:MIL1553B:STATus:BIT:BCR

When the MIL-STD-1553 bus search condition is set to speciﬁes the status word broadcast command received (BCR) bit value (bit 15) to be used in the search.

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:MIL1553B:STATus:BIT:BUSY

When the MIL-STD-1553 bus search condition is set to speciﬁes the status word busy bit value (bit

16) to be used in the search.

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:MIL1553B:STATus:BIT:DBCA

When the MIL-STD-1553 bus search condition is set to speciﬁes the status word dynamic bus control acceptance (DBCA) bit value (bit 18) to be used in the search.

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:MIL1553B:STATus:BIT:INSTR

When the MIL-STD-1553 bus search condition is set to speciﬁes the status word instrumentation bit value (bit 10) to be used in the search.

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:MIL1553B:STATus:BIT:ME

When the MIL-STD-1553 bus search condition is set to speciﬁes the status word message error bit value (bit 9) to be used in the search.

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:MIL1553B:STATus:BIT:SRQ

When the MIL-STD-1553 bus search condition is set to speciﬁes the status word service request (SRQ) bit value (bit 11) to be used in the search.

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:MIL1553B:STATus:BIT:SUBSF

When the MIL-STD-1553 bus search condition is set to speciﬁes the status word subsystem ﬂag bit value (bit 17) to be used in the search.

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:MIL1553B:STATus:BIT:TF

When theMIL-STD-1553 bus search condition is set to speciﬁes the status word terminal ﬂag bit value (bit 19) to be used in the search.

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:MIL1553B:STATus:PARity

When the MIL-STD-1553 bus search condition is set to speciﬁes the status parity bit value to be used in the search.

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:MIL1553B:TIMe:LESSLimit

When the MIL-STD-1553 bus search condition is set to speciﬁes either the minimum remote terminal response time (RT) limit for the amount of time the terminal has to transmit, or it speciﬁes the m inimum inter-message gap (IMG).

Command Groups

STATus, this command

TIMe, this command

MSO3000 and DPO3000 Series Programmer Manual 2-51

Command Groups

Search Commands (cont.)

Command Description

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:MIL1553B:TIMe:MORELimit

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:MIL1553B:TIMe:QUALiﬁer

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:PARallel:VALue

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:RS232C:CONDition

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:RS232C:RX:DATa:SIZe

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:RS232C:RX:DATa:VALue

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:RS232C:TX:DATa:SIZe

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:RS232C:TX:DATa:VALue

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:SPI:CONDition

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:SPI:DATa{:MISO|:IN}:VALue

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:SPI:DATa{:MOSI|:OUT}:VALue

SEARCH:SEARCH<x>:TRIGger:A:BUS: B<x>:SPI:DATa:SIZe

SEARCH:SEARCH<x>:TRIGger:A:BUS: SOUrce

SEARCH:SEARCH<x>:TRIGger:A:EDGE: SLOpe

SEARCH:SEARCH<x>:TRIGger:A:EDGE: SOUrce

SEARCH:SEARCH<x>:TRIGger:A:LEVel Sets or returns the level for an edge search

When the MIL-STD-1553 bus search condition is set to speciﬁes either the maximum remote terminal response time (RT) limit for the amount of time the terminal has to transmit, or it speciﬁes the maximum inter-message gap (IMG).

When the MIL-STD-1553 bus search condition is set to speciﬁes the trigger data time qualiﬁer.

Sets or returns the binary data string to be used for a Parallel search

Sets or returns the trigger condition for an RS-232 trigger

Sets or returns the length of the data string for an RS-232 trigger, if the trigger condition is RX

Sets or returns the binary data string for an RS-232 trigger, if the condition involves RX

Sets or returns the length of the data string to be used for an RS-232 Trigger, if the Trigger condition is TX

Sets or returns the binary data string to be used for an RS-232 trigger, if the condition involves RX

Sets or returns the s earch condition for SPI search

Sets or returns the binary data string to be used for SPI search if the search condition is MISO or MISOMOSI

Sets or returns the binary data string for an SPI search if the search condition is MISO or MISOMOSI

Sets or returns the length of the data string in bytes to be used for SPI search

Sets or returns a bus serial search. <x> is the search number

Sets or returns the slope for an edge search

Sets or returns the source waveform for an edge search

TIMe, this command

2-52 MSO3000 and DPO3000 Series Programmer Manual

Search Commands (cont.)

Command Description

SEARCH:SEARCH<x>:TRIGger:A:LEVel: CH<x>

SEARCH:SEARCH<x>:TRIGger:A:LEVel: MATH

SEARCH:SEARCH<x>:TRIGger:A:LEVel: REF<x>

SEARCH:SEARCH<x>:TRIGger:A:LOGIc: FUNCtion

SEARCH:SEARCH<x>:TRIGger:A:LOGIc: INPut:CH<x>

SEARCH:SEARCH<x>:TRIGger:A:LOGIc: INPut:CLOCk:EDGE

SEARCH:SEARCH<x>:TRIGger:A:LOGIc: INPut:CLOCk:SOUrce

SEARCH:SEARCH<x>:TRIGger:A:LOGIc: INPut:D<x>

SEARCH:SEARCH<x>:TRIGger:A:LOGIc: INPut:MATH

SEARCH:SEARCH<x>:TRIGger:A:LOGIc: INPut:REF<x>

SEARCH:SEARCH<x>:TRIGger:A:LOGIc: PATtern:INPut:CH<x>

SEARCH:SEARCH<x>:TRIGger:A:LOGIc: PATtern:INPut:D<x>

SEARCH:SEARCH<x>:TRIGger:A:LOGIc: PATtern:INPut:MATH

SEARCH:SEARCH<x>:TRIGger:A:LOGIc: PATtern:INPut:REF<x>

SEARCH:SEARCH<x>:TRIGger:A:LOGIc: PATtern:WHEn

SEARCH:SEARCH<x>:TRIGger:A:LOGIc: PATtern:WHEn:LESSLimit

SEARCH:SEARCH<x>:TRIGger:A:LOGIc: PATtern:WHEn:MORELimit

SEARCH:SEARCH<x>:TRIGger:A:LOGIc: THReshold:CH<x>

SEARCH:SEARCH<x>:TRIGger:A:LOGIc: THReshold:MATH

SEARCH:SEARCH<x>:TRIGger:A:LOGIc: THReshold:REF<x>

Sets or returns the level for a n edge search of the speciﬁed channel

Sets or returns the math waveform level for edge search

Sets or returns the reference waveform level for edge search

Sets or returns the logic operator for the logic search

Sets or returns the Boolean logic criteria for the logic search

Sets or returns whether the clock edge is rise or fall for a logic search

Sets or returns the clock source deﬁnition for logic search

Sets or returns the criteria for a logic search to determine where to place a mark for digital channel <x>

Sets or returns the Boolean logic criteria for the logic search

Sets or returns the criteria for a pattern search to determine wheretoplaceamark for digital channel <x>

Sets or returns the Boolean logic criteria for the logic search

Sets or returns the condition for generating a logic pattern search

Sets or returns the maximum time that the selected pattern may be true

Sets or returns the minimum time that the selected pattern may be true

Sets or returns the channel threshold level for an logic search

Sets or returns the math waveform threshold level for logic search

Sets or returns the reference waveform threshold level for logic search

Command Groups

MSO3000 and DPO3000 Series Programmer Manual 2-53

Command Groups

Search Commands (cont.)

Command Description

SEARCH:SEARCH<x>:TRIGger:A: LOWerthreshold:CH<x>

SEARCH:SEARCH<x>:TRIGger:A: LOWerthreshold:MATH

SEARCH:SEARCH<x>:TRIGger:A: LOWerthreshold:REF<x>

SEARCH:SEARCH<x>:TRIGger:A: PULSEWidth:HIGHLimit

SEARCH:SEARCH<x>:TRIGger:A: PULSEWidth:LOWLimit

SEARCH:SEARCH<x>:TRIGger:A: PULSEWidth:POLarity

SEARCH:SEARCH<x>:TRIGger:A: PULSEWidth:SOUrce

SEARCH:SEARCH<x>:TRIGger:A: PULSEWidth:WHEn

SEARCH:SEARCH<x>:TRIGger:A: PULSEWidth:WIDth

SEARCH:SEARCH<x>:TRIGger:A:RUNT: POLarity

SEARCH:SEARCH<x>:TRIGger:A:RUNT: SOUrce

SEARCH:SEARCH<x>:TRIGger:A:RUNT: WHEn

SEARCH:SEARCH<x>:TRIGger:A:RUNT: WIDth

Sets or returns the lower waveform threshold level for all channel waveform searches

Sets or returns the lower waveform threshold level for all math waveform searches

Sets or returns the lower waveform threshold level for all reference waveform searches

This command speciﬁes the upper limit, in seconds, when searching the record for pulses whose widths are within or outside of a speciﬁed range of two values. (Use SEARCH:SEARCH<x>:TRIGger:A:

PULSEWidth:LOWLimit to specify the lower

limit of the range.)

This command speciﬁes the lower limit, in seconds, when searching the record for pulses whose widths are within or outside of a speciﬁed range of two values. (Use SEARCH:SEARCH<x>:TRIGger:A:

PULSEWidth:HIGHLimit to specify the upper

limit of the range.)

Sets or returns the polarity for a pulse search

Sets or returns the source waveform for a pulse search

This command speciﬁes to search the waveform record for pulses with a width (duration) that is less than, greater than, equal to, or unequal to a speciﬁed value (set using SEARCH:SEARCH<x>:TRIGger:A:

PULSEWidth:WIDth), OR whose widths fall

outside of or within a speciﬁed range of two values (set using SEARCH:SEARCH<x>:

TRIGger:A:PULSEWidth:LOWLimit and SEARCH:SEARCH<x>:TRIGger:A: PULSEWidth:HIGHLimit).

Sets or returns the pulse width setting for a pulse width search

Sets or returns the polarity setting for a runt search

Sets or returns the source setting for a runt search

Sets or returns the condition setting for a runt search

Sets or returns the width setting for a runt search

2-54 MSO3000 and DPO3000 Series Programmer Manual

Search Commands (cont.)

Command Groups

Command Description

SEARCH:SEARCH<x>:TRIGger:A: SETHold:CLOCk:EDGE

SEARCH:SEARCH<x>:TRIGger:A: SETHold:CLOCk:SOUrce

SEARCH:SEARCH<x>:TRIGger:A: SETHold:CLOCk:THReshold

SEARCH:SEARCH<x>:TRIGger:A: SETHold:DATa:SOUrce

SEARCH:SEARCH<x>:TRIGger:A: SETHold:DATa:THReshold

SEARCH:SEARCH<x>:TRIGger:A: SETHold:HOLDTime

SEARCH:SEARCH<x>:TRIGger:A: SETHold:SETTime

SEARCH:SEARCH<x>:TRIGger:A: SETHold:THReshold:CH<x>

SEARCH:SEARCH<x>:TRIGger:A: SETHold:THReshold{:MATH|:MATH1}

SEARCH:SEARCH<x>:TRIGger:A: SETHold:THReshold:REF<x>

SEARCH:SEARCH<x>:TRIGger:A{: TRANsition|:RISEFall}:DELTatime

SEARCH:SEARCH<x>:TRIGger:A{: TRANsition|:RISEFall}:POLarity

SEARCH:SEARCH<x>:TRIGger:A{: TRANsition|:RISEFall}:SOUrce

SEARCH:SEARCH<x>:TRIGger:A{: TRANsition|:RISEFall}:WHEn

SEARCH:SEARCH<x>:TRIGger:A:TYPe Sets or returns the trigger type setting for a

SEARCH:SEARCH<x>:TRIGger:A: UPPerthreshold:CH<x>

SEARCH:SEARCH<x>:TRIGger:A: UPPerthreshold:MATH

SEARCH:SEARCH<x>:TRIGger:A: UPPerthreshold:REF<x>

Sets or returns the clock slope setting for a setup/hold search

Sets or returns the clock source setting for an setup/hold search

Sets or returns the clock threshold setting for an setup/hold search

Sets or returns the data source setting for an setup/hold search

Sets or returns the data threshold setting for an setup/hold search

Sets or returns the hold time setting for an setup/hold search

Sets or returns the setup time setting for an setup/hold search

Sets or returns the trigger search setup and hold threshold for the selected channel

Sets or returns the trigger search setup and hold threshold for the math waveform

Sets or returns the trigger search setup and hold threshold for the selected reference waveform

Sets or returns the transition time setting for an transition search

Sets or returns the polarity setting for an transition search

Sets or returns the source setting for an transition search

Sets or returns the condition setting for an transition search

Sets or returns the waveform upper threshold level for all channel waveform searches

Sets or returns the waveform upper threshold level for all math waveform searches

Sets or returns the waveform upper threshold level for all reference waveform searches

MSO3000 and DPO3000 Series Programmer Manual 2-55

Command Groups

Status and Err

or Command Group

Use the commands in the Status and Error Command Group to determine the status of the oscilloscope and control events.

Several commands and queries used with the oscilloscope are common to all IEEE488.2 compliant devices. The IEEE Std 488.2-1987 deﬁnes these commands and queries

Table 2-31: Status and Error Commands

Command

ALLEv?

BUSY?

*CLS Clears status

DESE Sets or returns the bits in the Device Event

*ESE Sets or returns the bits in the Event Status

*ESR? Returns the contents of the Standard Event

EVENT? Returns event code from the event queue

EVMsg? Returns event code, message from the event

EVQty? Return number of events in the event queue

*OPC Generates the operation complete message

*PSC Sets or returns the power on status ﬂag

*PUD Sets or returns a string of protected user data

*RST Resets the oscilloscope to factory default

*SRE Sets or returns the bits in the Service

*STB? Returns the contents of the Status Byte

*WAI Prevents the oscilloscope from executing

. The common commands begin with an asterisk (*) character.

Description

Returns all events and their messages

Returns oscilloscope status

Status Enable Register

Enable Register

Status Register

queue

in the standard event status register when all pending operations are ﬁnished

Or returns "1" when all current operations are ﬁnished

settings

Request Enable Register

further commands until all pending operations ﬁnish

2-56 MSO3000 and DPO3000 Series Programmer Manual

Command Groups

Trigger Comma

nd Group

Use the commands in the Trigger Command Group to control all aspects of triggering for the oscilloscope.

There are two triggers: A and B. Where appropriate, this command set has parallel construction between triggers.

You can set the A or B triggers to edge mode. Edge triggering lets you display a w aveform at or near the point where the signal passes through a voltage level of your cho

You can also set the A trigger to pulse width, logic, video, runt, timeout, rise/fall time (als

With pulse width triggering, the oscilloscope triggers whenever it detects a pulse that is l Additionally, it can trigger when the pulse width is within, or outside of a range of two different speciﬁed times. You can trigger on either positive or negative pulses.

Logic triggering lets you logically combine the signals on one or more channels; the oscilloscope then triggers when it detects a certain combination of signal levels.

Video triggering enables you to trigger on the most common Standard Deﬁnition video standards.

osing.

o called transition), setup and hold and bus modes.

ess than, greater than, equal to, or not equal to a speciﬁed duration (width).

Runt triggering lets you trigger on a pulse amplitude that crosses one threshold but fails to cross a second threshold before recrossing the ﬁrst.

Timeout triggering causes a trigger whenever no pulse has been detected within a speciﬁed amount of time.

Rise/fall time (also called transition) triggering causes a trigger on pulse edges that traverses between two thresholds at a rate faster than or slower than the speciﬁed time.

Setup and Hold causes a trigger when a logic data input changes state inside of the setup or hold time relative to a clock edge.

You can use your oscilloscope to trigger on a variety of data buses, if you have the appropriate application module installed. (The exception is the parallel bus trigger and analysis functionality, which is included standard with the MSO Series.) Once you specify which bus (1–4) to trigger on, you must then set the appropriate trigger criteria according to the bus type (i.e., parallel, I

NOTE. When performing a setup/hold or logic trigger or search, you can use

more than one displayed waveform at the same time. When performing an edge, pulse width, runt, rise/fall time, time-out or bus trigger or search, you can use only one waveform at a time.

C, etc.)

MSO3000 and DPO3000 Series Programmer Manual 2-57

Command Groups

To see example c

ommand sequences showing different triggers and searches, see

Appendix G. (See page E-1, Search and Trigger Command Sequence Examples.)

Install the DP

O3EMBD application module when working with I

C o r SPI

bus signals.

Install the

DPO3AUTO module when working with CAN or LIN bus signals.

Install the DPO3COMP module when working with RS-232, RS-422, RS-485, and

UART bus signals.

Install the DPO3AUDIO module when working with I2S, Left Justiﬁed (LJ), Right Just

iﬁed (RJ), and TDM bus signals.

Install the DPO3AERO module when working with MIL-STD-1553 bus signals.

Install the DPO3FLEX module when working with FlexRay bus signals.

Table 2

Command

TRIGger

TRIGger:A Sets A trigger level to 50%

TRIG

TRIGger:A:BUS:B<x>:AUDio:CONDition

TRIGger:A:BUS:B<x>:AUDio:DATa:HIVALue

TRIGger:A:BUS:B<x>:AUDio:DATa:OFFSet

TRIGger:A:BUS:B<x>:AUDio:DATa:QUALiﬁer

-32: Trigger Commands

ger:A:BUS

ption

Descri

a trigger event to

Forces occur

or returns c urrent A trigger

eters

param

command speciﬁes

This the bus type to be used in a trigger operation

(CAN MIL-STD-1553, LIN, audio, FlexRay or Parallel).

This command sets the condition (start of frame or ma when triggering on audio bus data.

This command sets the upper word value to be used w data.

T offset value to be used when triggering on audio bus data.

This command sets the qualiﬁer (<, >, =, <=, >=, not =, in range, out of range) to be used when triggering on audio bus data.

C, SPI, RS-232,

tching data) to be used

hen triggering on audio bus

his command sets the data

2-58 MSO3000 and DPO3000 Series Programmer Manual

Table 2-32: Trigger Commands (cont.)

Command Groups

Command

TRIGger:A:BUS:B<x>:AUDio:DATa:VALue

TRIGger:A:BUS:B<x>:AUDio:DATa:WORD

TRIGger:A:BUS:B<x>:CAN:CONDition

TRIGger:A:BUS:B<x>:CAN:DATa:DIRection

TRIGger:A:BUS:B<x>:CAN:DATa:QUALiﬁer

TRIGger:A:BUS:B<x>:CAN:DATa:SIZe

TRIGger:A:BUS:B<x>:CAN:DATa:VALue

TRIGger:A:BUS:B<x>:CAN:FRAMEtype

TRIGger:A:BUS:B<x>:CAN{:IDentiﬁer|:ADDRess}:MODe

TRIGger:A:BUS:B<x>:CAN{:IDentiﬁer|:ADDRess}:VALue

Description

This command sets the lower wordvaluetobeusedwhen triggering on audio bus data.

This command sets the alignment of the data (left, right or either) to be used to search on audio bus data.

This command sets the condition (start of frame, frame type, identiﬁer, matching data, EOF, missing ACK ﬁeld, bit-stufﬁng error) to be used when triggering on CAN bus data.

This command sets the data direction (read, write or nocare) to be used to search on CAN bus data.

This command sets the qualiﬁer(<,>,=,not=,<=) to be used when triggering on CAN bus data.

This command sets the length of the data string, in bytes, to be used when triggering on CAN bus data.

This command sets the binary data value to be used when triggering on CAN bus data.

This command sets the frame type (data, remote, error or overload) to be used when triggering on CAN bus data.

This command sets the addressing mode (standard or extended format) to be used when triggering on CAN bus data.

This command sets the binary address value to be used when triggering on CAN bus data.

MSO3000 and DPO3000 Series Programmer Manual 2-59

Command Groups

Table 2-32: Trigger Commands (cont.)

Command

TRIGger:A:BUS:B<x>:FLEXray:CONDition This command speciﬁes

TRIGger:A:BUS:B<x>:FLEXray:CYCLEcount:HIVALue This command speciﬁes the

TRIGger:A:BUS:B<x>:FLEXray:CYCLEcount:QUALiﬁer This command speciﬁes the

TRIGger:A:BUS:B<x>:FLEXray:CYCLEcount:VALue This command speciﬁes the

TRIGger:A:BUS:B<x>:FLEXray:DATa:HIVALue This command speciﬁes the

TRIGger:A:BUS:B<x>:FLEXray:DATa:OFFSet This command speciﬁes

TRIGger:A:BUS:B<x>:FLEXray:DATa:QUALiﬁer This command speciﬁes the

TRIGger:A:BUS:B<x>:FLEXray:DATa:SIZe This command speciﬁes the

TRIGger:A:BUS:B<x>:FLEXray:DATa:VALue This command speciﬁes the

Description

the condition to use when triggering on the FlexRay bus signal (start of frame, frame type, ID, cycle count, header, data, ID and data, EOF, error).

high value when triggering on the FlexRay bus cycle count ﬁeld.

qualiﬁer (<, >, =, <=, >=, not =, in range, out of range) to use when triggering on the FlexRay bus cycle count ﬁeld.

low value when triggering on the FlexRay bus cycle count ﬁeld.

high value when triggering on the FlexRay bus data ﬁeld.

the offset of the data string, to use, in bytes, when triggering on the FlexRay bus data ﬁeld.

qualiﬁer (<, >, =, <=, >=, not =, in range, out of range) to use when triggering on the FlexRay bus data ﬁeld.

length of the data string, in bytes, when triggering on the FlexRay bus data ﬁeld.

low value when triggering on the FlexRay bus data ﬁeld.

2-60 MSO3000 and DPO3000 Series Programmer Manual

Table 2-32: Trigger Commands (cont.)

Command Groups

Command

TRIGger:A:BUS:B<x>:FLEXray:EOFTYPE This command speciﬁes

TRIGger:A:BUS:B<x>:FLEXray:ERRTYPE This command speciﬁes the

TRIGger:A:BUS:B<x>:FLEXray:FRAMEID:HIVALue This command speciﬁes the

TRIGger:A:BUS:B<x>:FLEXray:FRAMEID:QUALiﬁer This command speciﬁes the

TRIGger:A:BUS:B<x>:FLEXray:FRAMEID:VALue This command speciﬁes the

TRIGger:A:BUS:B<x>:FLEXray:FRAMEType This command speciﬁes the

TRIGger:A:BUS:B<x>:FLEXray:HEADER:CRC This command speciﬁes the

TRIGger:A:BUS:B<x>:FLEXray:HEADER:CYCLEcount This command speciﬁes the

TRIGger:A:BUS:B<x>:FLEXray:HEADER:FRAMEID This command speciﬁes

TRIGger:A:BUS:B<x>:FLEXray:HEADER:INDBits This command speciﬁes the

Description

which end of ﬁle type to use (static, dynamic or any) when triggering on the FlexRay bus EOF ﬁeld.

error type when triggering on the FlexRay bus signal.

binary data string to be used for FlexRay frame ID high value

qualiﬁer when triggering on the FlexRay bus frame ID.

binary data string to be used for FlexRay frame ID low value

frame type (normal, payload, null, sync or startup) when triggering on the FlexRay bus signal.

CRC portion of the binary header string when triggering on the FlexRay bus signal.

cycle count portion of the binary header string when triggering on the FlexRay bus header.

the frame ID portion of the binary header string when triggering on the FlexRay bus header.

indicator bits portion of the binary header string when triggering on the FlexRay bus header.

MSO3000 and DPO3000 Series Programmer Manual 2-61

Command Groups

Table 2-32: Trigger Commands (cont.)

Command

TRIGger:A:BUS:B<x>:FLEXray:HEADER:PAYLength This command speciﬁes the

TRIGger:A:BUS:B<x>:LIN:CONDition Sets or returns the trigger

TRIGger:A:BUS:B<x>:LIN:DATa:HIVALue Sets or returns the binary

TRIGger:A:BUS:B<x>:LIN:DATa:QUALiﬁer Sets or returns the L IN data

TRIGger:A:BUS:B<x>:LIN:DATa:SIZe Sets or returns the length of

TRIGger:A:BUS:B<x>:LIN:DATa:VALue Sets or returns the binary

TRIGger:A:BUS:B<x>:LIN:ERRTYPE Sets or returns the error type

TRIGger:A:BUS:B<x>:LIN:IDentiﬁer:VALue Sets or returns the binary

TRIGger:A:BUS:B<x>:I2C:ADDRess:MODe Sets or returns the I2C

TRIGger:A:BUS:B<x>:I2C:ADDRess:TYPe Sets or returns the I2C

TRIGger:A:BUS:B<x>:I2C:ADDRess:VALue Sets or returns the binary

TRIGger:A:BUS:B<x>:I2C:CONDition Sets or returns the trigger

TRIGger:A:BUS:B<x>:I2C:DATa:DIRection Sets or returns the I2C

TRIGger:A:BUS:B<x>:I2C:DATa:SIZe Sets or returns the length of

TRIGger:A:BUS:B<x>:I2C:DATa:VALue Sets or returns the binary

Description

payload length portion of the binary header string when triggering on the FlexRay bus header.

condition for LIN

datastringtobeusedforLIN trigger

qualiﬁer

thedatastringinbytestobe used for LIN trigger

data string

address string used for LIN trigger

address mode to 7 or 10-bit

address type to USER

address string used for the I2C trigger

condition for I2C trigger

trigger condition valid on a READ, WRITE, or either

thedatastringinbytestobe used for I2C trigger

datastringusedforI2C triggering

2-62 MSO3000 and DPO3000 Series Programmer Manual

Table 2-32: Trigger Commands (cont.)

Command Groups

Command

TRIGger:A:BUS:B<x>:MIL1553B:COMMAND:ADDRess: HIVALue

Description

When the MIL-STD-1553 bus trigger condition is set to

COMMAND, and the qualiﬁer

is set to

OUTrange, this c ommand

INrange or

speciﬁes the upper limit of the range for the remote terminal address ﬁeld.

TRIGger:A:BUS:B<x>:MIL1553B:COMMAND:ADDRess: QUALiﬁer

When the MIL-STD-1553 bus trigger condition is set to

COMMAND, this command

speciﬁes the qualiﬁ er to be used with the r emote terminal address ﬁeld.

TRIGger:A:BUS:B<x>:MIL1553B:COMMAND:ADDRess: VALue

When the MIL-STD-1553 bus trigger condition is set to

COMMAND, and the qualiﬁer

is set to

MOREthan, EQual, UNEQual, LESSEQual

LESSthan,

or MOREEQual,this command speciﬁes the value of the 5–bit remote terminal address to be used in the trigger.

TRIGger:A:BUS:B<x>:MIL1553B:COMMAND:COUNt When the MIL-STD-1553

bus trigger condition is set to

COMMAND, this command

speciﬁes the bit pattern for the 5–bit Word Count/Mode Code sub-address ﬁeld that is to be used in the trigger.

TRIGger:A:BUS:B<x>:MIL1553B:COMMAND:PARity When the MIL-STD-1553

bus trigger condition is set to

COMMAND, this command

speciﬁes the Command word parity that is to be used in the trigger.

TRIGger:A:BUS:B<x>:MIL1553B:COMMAND:SUBADdress When the MIL-STD-1553

bus trigger condition is set to

COMMAND,this

command speciﬁes the 5 bit sub-address that is to be used in the trigger.

MSO3000 and DPO3000 Series Programmer Manual 2-63

Command Groups

Table 2-32: Trigger Commands (cont.)

Command

Description

TRIGger:A:BUS:B<x>:MIL1553B:COMMAND:TRBit When the MIL-STD-1553

bus trigger condition is set to

COMMAND,this

command speciﬁes that the transmit/receive bit (bit 9) is to be used in the trigger.

TRIGger:A:BUS:B<x>:MIL1553B:CONDition This command speciﬁes the

condition (sync, command, status, data, time, or error) to use when triggering on a MIL-STD-1553 bus signal.

TRIGger:A:BUS:B<x>:MIL1553B:DATa:PARity When the MIL-STD-1553

bus trigger condition is set to

DATa, this command

speciﬁes the data parity bit to be used in the trigger.

TRIGger:A:BUS:B<x>:MIL1553B:DATa:VALue When the MIL-STD-1553

bus trigger condition is set to

DATa, this command

speciﬁes the data binary pattern to be used in the trigger.

TRIGger:A:BUS:B<x>:MIL1553B:ERRTYPE When the MIL-STD-1553

bus trigger condition is set to

ERRor, this command

speciﬁes the signaling error type to be used in the trigger: Parity, Sync, Manchester or Data.

TRIGger:A:BUS:B<x>:MIL1553B:STATus:ADDRess: HIVALue

When the MIL-STD-1553 bus trigger condition is set to

STATus, and the qualiﬁer

is set to

OUTrange, this command

INrange or

speciﬁes the upper limit for the 5 bit remote terminal address ﬁeld of the Status word.

TRIGger:A:BUS:B<x>:MIL1553B:STATus:ADDRess: QUALiﬁer

When the MIL-STD-1553 bus trigger condition is set to

STATus, this command

speciﬁes the qualiﬁer to be used with the address ﬁeld.

2-64 MSO3000 and DPO3000 Series Programmer Manual

Table 2-32: Trigger Commands (cont.)

Command Groups

Command

Description

TRIGger:A:BUS:B<x>:MIL1553B:STATus:ADDRess:VALue When the MIL-STD-1553

bus trigger condition is set to

STATus, and the qualiﬁer

is set to

MOREthan, EQual, UNEQual, LESSEQual

LESSthan,

or MOREEQual,this command speciﬁes the value of the 5–bit remote terminal address to be used in the trigger.

TRIGger:A:BUS:B<x>:MIL1553B:STATus:BIT:BCR When the MIL-STD-1553

bus trigger condition is set to

STATus, this command

speciﬁes the status word broadcast command received (BCR) bit value (bit 15) to be used in the trigger.

TRIGger:A:BUS:B<x>:MIL1553B:STATus:BIT:BUSY When the MIL-STD-1553

bus trigger condition is set to

STATus, this command

speciﬁes the status word busy bit value (bit 16) to be used in the trigger.

TRIGger:A:BUS:B<x>:MIL1553B:STATus:BIT:DBCA When the MIL-STD-1553

bus trigger condition is set to

STATus,this

command speciﬁes the status word dynamic bus control acceptance (DBCA) bit value (bit 18) to be used in the trigger.

TRIGger:A:BUS:B<x>:MIL1553B:STATus:BIT:INSTR When the MIL-STD-1553

bus trigger condition is set to

STATus, this command

speciﬁes the status word instrumentation bit value (bit

10) to be used in the trigger.

TRIGger:A:BUS:B<x>:MIL1553B:STATus:BIT:ME When the MIL-STD-1553

bus trigger condition is set to

STATus, this command

speciﬁes the status word message error bit value (bit

9) to be used in the trigger.

MSO3000 and DPO3000 Series Programmer Manual 2-65

Command Groups

Table 2-32: Trigger Commands (cont.)

Command

Description

TRIGger:A:BUS:B<x>:MIL1553B:STATus:BIT:SRQ When the MIL-STD-1553

bus trigger condition is set to

STATus, this command

speciﬁes the status word service request (SRQ) bit value (bit 11) to be used in the trigger.

TRIGger:A:BUS:B<x>:MIL1553B:STATus:BIT:SUBSF When the MIL-STD-1553

bus trigger condition is set to

STATus, this command

speciﬁes the status word subsystem ﬂag bit value (bit

17) to be used in the trigger.

TRIGger:A:BUS:B<x>:MIL1553B:STATus:BIT:TF When the MIL-STD-1553

bus trigger condition is set to

STATus, this command

speciﬁes the status word terminal ﬂag bit value (bit 19) to be used in the trigger.

TRIGger:A:BUS:B<x>:MIL1553B:STATus:PARity When the MIL-STD-1553

bus trigger condition is set to

STATus, this command

speciﬁes the status parity bit value to be used in the trigger.

TRIGger:A:BUS:B<x>:MIL1553B:TIMe:LESSLimit When the MIL-STD-1553

bus trigger condition is set to

TIMe, this command

speciﬁes either the minimum remote terminal response time (RT) limit for the amount of time the terminal has to transmit, or it speciﬁes the minimum inter-message gap (IMG).

TRIGger:A:BUS:B<x>:MIL1553B:TIMe:MORELimit When the M IL-STD-1553

bus trigger condition is set to

TIMe, this command

speciﬁes either the maximum remote terminal response time (RT) limit for the amount of time the terminal has to transmit, or it speciﬁes the maximum inter-message gap (IMG).

2-66 MSO3000 and DPO3000 Series Programmer Manual

Table 2-32: Trigger Commands (cont.)

Command Groups

Command

TRIGger:A:BUS:B<x>:MIL1553B:TIMe:QUALiﬁer When the MIL-STD-1553

TRIGger:A:BUS:B<x>:PARallel:VALue Sets or returns the binary

TRIGger:A:BUS:B<x>:RS232C:CONDition Sets or returns the condition

TRIGger:A:BUS:B<x>:RS232C:RX:DATa:SIZe Sets or returns the length of

TRIGger:A:BUS:B<x>:RS232C:RX:DATa:VALue Sets or returns the binary

TRIGger:A:BUS:B<x>:RS232C:TX:DATa:SIZe Sets or returns the length

TRIGger:A:BUS:B<x>:RS232C:TX:DATa:VALue Sets or returns the binary

TRIGger:A:BUS:B<x>:SPI:CONDition Sets or returns the trigger

TRIGger:A:BUS:B<x>:SPI:DATa{:IN|:MISO}:VALue Sets or returns the binary

TRIGger:A:BUS:B<x>:SPI:DATa{:OUT|:MOSI}:VALue Sets or returns the binary

TRIGger:A:BUS:B<x>:SPI:DATa:SIZe Sets or returns the length of

TRIGger:A:BUS:SOUrce Sets or returns the source

TRIGger:A:EDGE?

Description

bus trigger condition is set to

TIMe, this command

speciﬁes the trigger data time qualiﬁer.

datastringtobeusedfora Parallel trigger

for an RS-232C trigger

thedatastringinBytesfor an RX RS-232 Trigger

data string for an RX RS-232 trigger

of the data string for a TX RS-232 trigger

data string for an RS-232 trigger if the trigger condition involves TX

condition for SPI triggering

datastringtobeused for a SPI trigger if the trigger condition is MISO or MISOMOSI

datastringtobeused for a SPI trigger if the trigger condition is MOSI or MISOMOSI

the data string in bytes to be used for SPI trigger if the trigger condition is MISO, MOSI, or MISOMOSI

for a Serial bus trigger

Returns the source, coupling and source for the A edge trigger

MSO3000 and DPO3000 Series Programmer Manual 2-67

Command Groups

Table 2-32: Trigger Commands (cont.)

Command

TRIGger:A:EDGE:COUPling Sets or returns the type

TRIGger:A:EDGE:SLOpe Sets or returns the slope for

TRIGger:A:EDGE:SOUrce Sets or returns the source

TRIGger:A:HOLDoff? Returns the A trigger holdoff

TRIGger:A:HOLDoff:TIMe Sets or returns the A trigger

TRIGger:A:LEVel Sets or returns the trigger

TRIGger:A:LEVel:AUXin Sets or returns the trigger

TRIGger:A:LEVel:CH<x> Speciﬁes or returns the

TRIGger:A:LEVel:D<x> Sets or returns the trigger

TRIGger:A:LOGIc?

TRIGger:A:LOGIc:CLAss

TRIGger:A:LOGIc:FUNCtion Sets or returns the logical

TRIGger:A:LOGIc:INPut?

TRIGger:A:LOGIc:INPut:CH<x> Speciﬁes or returns the

TRIGger:A:LOGIc:INPut:CLOCk:EDGE Sets the polarity of the clock

TRIGger:A:LOGIc:INPut:CLOCk:SOUrce Sets or returns the channel

Description

of coupling for the A edge trigger

the A edge trigger

for the A edge trigger

parameters

holdoff time

level for the A trigger

level for the AUXIN port

trigger level for the speciﬁed trigger channel

level for the speciﬁed digital channel

Returns all A trigger logic settings

This command sets the class of the logic trigger (logic or setup/hold). This command is used in conjunction with the TRIGger:A:TYPe command.

combination of the input channels for the A logic trigger

Returns the logic input values for all channels

logic setting for the speciﬁed channel

channel

to use as the clock source

2-68 MSO3000 and DPO3000 Series Programmer Manual

Table 2-32: Trigger Commands (cont.)

Command Groups

Command

TRIGger:A:LOGIc:INPut:D<x> Sets or returns the logic

TRIGger:A:LOGIc:PAT tern? Returns the conditions for

TRIGger:A:LOGIc:PAT tern:DELTatime Sets or returns the pattern

TRIGger:A:LOGIc:PATtern:INPut:D<x> Sets or returns the A logic

TRIGger:A:LOGIc:PATtern:WHEn Sets or returns the pattern

TRIGger:A:LOGIc:PATtern:WHEn:LESSLimit Sets or returns the maximum

TRIGger:A:LOGIc:PAT tern:WHEn:MORELimit Sets or returns the minimum

TRIGger:A:LOGIc:THReshold:CH<x> Sets or queries the trigger

TRIGger:A:LOGIc:THReshold:D<x> Sets or returns the trigger A

TRIGger:A:LOWerthreshold:CH<x> Sets or returns the lower

TRIGger:A:LOWerthreshold:D<x> Sets the A trigger lower

TRIGger:A:LOWerthreshold{:EXT|:AUX} Sets or returns the lower

TRIGger:A:MODe Sets or returns the A trigger

TRIGger:A:PULse?

Description

pattern for a trigger on digital channel<x>

generating an A logic pattern trigger

trigger delta time value

trigger pattern for a trigger on digital channel<x>

logic condition on which to trigger the oscilloscope

time that the selected pattern may be true and still generate an A logic pattern trigger

A logic threshold voltage for the speciﬁed channel

logic threshold level for the speciﬁed digital channel

threshold for the channel selected

threshold for the d igital channel selected

threshold for the Auxiliary input.

mode

Returns the A pulse trigger parameters

MSO3000 and DPO3000 Series Programmer Manual 2-69

Command Groups

Table 2-32: Trigger Commands (cont.)

Command

TRIGger:A:PULse:CLAss

TRIGger:A:PULSEWIDth?

TRIGger:A:PULSEWidth:HIGHLimit This command speciﬁes

TRIGger:A:PULSEWidth:LOWLimit This command speciﬁes the

TRIGger:A:PULSEWidth:POLarity Sets or returns the polarity

TRIGger:A:PULSEWidth:SOUrce Sets or returns the source

TRIGger:A:PULSEWidth:WHEn This command speciﬁes

Description

This command sets the type of pulse on which to trigger (runt, width, transition or timeout). This command is used in conjunction with the

TRIGger:A:TYPe command.

Returns the trigger A pulse width parameters

the upper limit to use, in seconds, when triggering on detection of a pulse whose duration is inside or outside a range of two values. (Use

TRIGger:A:PULSEWidth: LOWLimit to specify the

lower value of the range.)

lower limit to use, in seconds, when triggering on detection of a pulse whose duration is inside or outside a range of two values. (Use TRIGger:

A:PULSEWidth:HIGHLimit to

specify the upper limit of the range.)

for the A pulse width trigger

for the pulse width trigger

to trigger when a pulse is detected with a width (duration) that is less than, greater than, equal to, or unequal to a speciﬁed value (set using TRIGger:

A:PULSEWidth:WIDth), OR

whose width falls outside of or within a speciﬁed range of two values (set using

TRIGger:A:PULSEWidth: LOWLimit and TRIGger:A: PULSEWidth:HIGHLimit).

2-70 MSO3000 and DPO3000 Series Programmer Manual

Table 2-32: Trigger Commands (cont.)

Command Groups

Command

TRIGger:A:PULSEWidth:WIDth Sets or returns the width

TRIGger:A:RUNT?

TRIGger:A:RUNT:POLarity Sets or returns the polarity

TRIGger:A:RUNT:SOUrce Sets or returns the source

TRIGger:A:RUNT:WHEn Sets or returns the type

TRIGger:A:RUNT:WIDth Sets or returns the minimum

TRIGger:A:SETHold? Returns settings for setup

TRIGger:A:SETHold:CLOCk?

TRIGger:A:SETHold:CLOCk:EDGE Sets or returns the clock

TRIGger:A:SETHold:CLOCk:SOUrce Sets or returns the clock

TRIGger:A:SETHold:CLOCk:THReshold Sets or returns the clock

TRIGger:A:SETHold:DATa?

TRIGger:A:SETHold:DATa:SOUrce Sets or returns the data

TRIGger:A:SETHold:DATa:THReshold Sets or returns the data

TRIGger:A:SETHold:HOLDTime Sets or returns the hold

Description

setting for the pulse width trigger

Returns the current A runt pulse trigger logic parameters

for the A pulse runt trigger

for the A runt trigger

of pulse width the trigger checks for when it uncovers a runt

width for A pulse runt trigger

and hold violation triggering

Returns clock edge polarity, voltage threshold and source input for setup/hold triggering

edge polarity for setup and hold triggering

source for the A logic trigger setup and hold input

voltage threshold for setup and hold trigger

Returns the voltage threshold and data source for the setup/hold trigger

source for the setup and hold trigger

voltage threshold for setup and hold trigger

time for the setup and hold violation triggering

MSO3000 and DPO3000 Series Programmer Manual 2-71

Command Groups

Table 2-32: Trigger Commands (cont.)

Command

TRIGger:A:SETHold:SETTime Sets or returns the setup

TRIGger:A:SETHold:THReshold:CH<x> Sets or queries the threshold

TRIGger:A:SETHold:THReshold:D<x> Sets the A trigger setup

TRIGger:A:UPPerthreshold:CH<x> Sets the upper threshold for

TRIGger:A{:TRANsition|:RISEFall}?

TRIGger:A{:TRANsition|:RISEFall}:DELTatime Sets or returns the delta

TRIGger:A{:TRANsition|:RISEFall}:POLarity Sets or r eturns the polarity

TRIGger:A{:TRANsition|:RISEFall}:SOUrce Sets or returns the source

TRIGger:A{:TRANsition|:RISEFall}:WHEn Sets or returns the

TRIGger:A:TYPe

Description

time for setup and hold violation triggering

for the channel

and hold threshold for the selected digital channel

the channel selected

Returns the delta time, polarity, and both upper and lower threshold limits for the transition time trigger

time used in calculating the transition value

for the A pulse transition trigger

for transition trigger

relationship of delta time to transitioning signal

This command sets the type of A trigger (edge, logic, pulse, bus or video). If you set the trigger type to LOGIc, you also need to set the logic trigger class (logic or setup/hold) using the command TRIGger:A:

LOGIc:CLAss.Ifyousetthe

trigger type to PULSe, you also need to set the pulse trigger class (runt, width, transition or timeout), using the command TRIGger:A:

PULse:CLAss.Ifyouset

the trigger type to BUS, you also need to set the bus type

(CAN, I MIL-STD-1553, LIN, audio, FlexRay or parallel) using the command TRIGger:A:BUS.

C, SPI, RS-232,

2-72 MSO3000 and DPO3000 Series Programmer Manual

Table 2-32: Trigger Commands (cont.)

Command Groups

Command

TRIGger:A:VIDeo?

TRIGger:A:VIDeo:CUSTom:FORMat

TRIGger:A:VIDeo:CUSTom:LINEPeriod

TRIGger:A:VIDeo:CUSTom:SYNCInterval

TRIGger:A:VIDeo:HOLDoff:FIELD

TRIGger:A:VIDeo:LINE

TRIGger:A:VIDeo:POLarity

TRIGger:A:VIDeo:SOUrce

TRIGger:A:VIDeo:STANdard

TRIGger:A:VIDeo{:SYNC|:FIELD}

TRIGger:B Sets the B trigger level to

TRIGger:B:BY Sets or returns B trigger time

TRIGger:B:EDGE?

Description

Returns the video parameters for the A trigger

This command sets the video trigger format (either interlaced or progressive) to use for triggering on video signals.

This command sets the line period for the standard under test.

This command sets the sync interval for the standard under test to use for triggering on video signals. This is only required for BiLevel Custom.

This command sets the video trigger holdoff, in terms of video ﬁelds, to use for triggering on video signals.

This command sets the video line number to use for triggering on video signals.

This command sets the polarity to use for triggering on video signals.

This command sets the source channel to use for triggering on video signals.

This command sets the standard to use for triggering on video signals (NTSC, PAL, SECAM, HDTV, bi-level custom or tri-level custom).

This command sets the video ﬁeldorlinetousefor triggering on video signals.

50% or returns the B trigger parameters

or event qualiﬁers

Returns B trigger edge type parameters

MSO3000 and DPO3000 Series Programmer Manual 2-73

Command Groups

Table 2-32: Trigger Commands (cont.)

Command

TRIGger:B:EDGE:COUPling Sets or returns the type of B

TRIGger:B:EDGE:SLOpe Sets or returns the B edge

TRIGger:B:EDGE:SOUrce Sets or returns the B edge

TRIGger:B:EVENTS?

TRIGger:B:EVENTS:COUNt Sets or returns the number

TRIGger:B:LEVel Sets or returns the level for

TRIGger:B:LEVel:CH<x> Sets or returns the level for

TRIGger:B:LEVel:D<x> Sets or returns the B trigger

TRIGger:B:LOWerthreshold:CH<x> Sets or returns the B trigger

TRIGger:B:LOWerthreshold:D<x> Sets or queries the B trigger

TRIGger:B:STATE Returns the current state of

TRIGger:B:TIMe Sets or returns the B trigger

TRIGger:B:TYPe Sets or returns the type of B

TRIGger:B:UPPerthreshold:CH<x> Sets or returns the B trigger

TRIGger:EXTernal?

TRIGger:EXTernal:PRObe Sets or returns the

TRIGger:EXTernal:YUNIts?

Description

trigger coupling

trigger slope

trigger source

Returns the current B trigger events parameter

of events that must occur before the B trigger occurs

the B trigger

the B trigger for a speciﬁc channel

level for digital channel<x>

lower threshold for the channel selected

lower threshold for the digital channel selected

the B trigger

delay time

trigger

upper threshold for the channel selected

Returns external trigger parameters

attenuation factor value of the external probe connector

Returns the external trigger vertical (Y) units value

2-74 MSO3000 and DPO3000 Series Programmer Manual

Table 2-32: Trigger Commands (cont.)

Command Groups

Command

TRIGger:FREQuency? Returns the trigger frequency

TRIGger:STATE? Returns the current state of

Vertical Command Group

Use the commands in the Vertical Command Group to control the vertical setup of all live (channel) waveforms for acquisition and display of channel, reference, and math waveforms.

Use the command CH<x>:YUNits to set the vertical units for each channel. The vertical units affect the “Probe Type” that is shown in the “Probe Setup” menu:

Description

in Hertz. This command

the triggering system

Setting CH<x>:YUNits to “V” causes the probe type to be displayed as “Voltage”.

When CH1:AMSVIAVOLTs:ENAble is set to OFF, setting CH<x>:YUNits to

“A” causes the probe type to be displayed as “Current”.

Setting CH<x>:YUNits to anything else causes the probe type not to be displayed (neither “Voltage” nor “Current” are highlighted).

Table 2-33: Vertical Commands

Command Description

AUXin?

AUXin:PRObe Returns all information concerning the probe

AUXin:PRObe:AUTOZero Sets the TekVPI probe attached to the

AUXin:PRObe:COMMAND Sets the state of the speciﬁed probe control

AUXin:PRObe:DEGAUss Starts a degauss/autozero cycle on a TekVPI

AUXin:PRObe:DEGAUss:STATE? Returns the degauss state of the TekVPI

AUXin:PRObe:FORCEDRange Sets or returns the range of the TekVPI probe

AUXin:PRObe:GAIN Sets or returns the gain factor of the probe

AUXin:PRObe:ID:SERnumber? Returns the serial number of the probe that

AUXin:PRObe:ID:TYPE? Returns the type of probe that is attached to

Returns auxiliary input parameters

attached to auxiliary input

auxiliary input to autozero

current probe attached to the auxiliary input

attached to the auxiliary input

that is attached to the auxiliary input

is attached to the auxiliary input

the auxiliary input

MSO3000 and DPO3000 Series Programmer Manual 2-75

Command Groups

Table 2-33: Vertical Commands (cont.)

Command Description

AUXin:PRObe:RESistance? Returns the resistance of the probe that is

attached to the Auxiliary input

AUXin:PRObe:SIGnal Sets or returns the input bypass setting on

VPI probes that support input bypass

AUXin:PRObe:UNIts? Returns the units of measure of the probe

that is attached to the auxiliary input

CH<x>? Returns vertical parameters for the speciﬁed

channel

CH<x>:AMPSVIAVOLTs:ENAble Sets or returns the state of the amps via

volts feature

CH<x>:AMPSVIAVOLTs:FACtor Sets or returns the amps via volts factor

CH<x>:BANdwidth Sets or returns the bandwidth of the speciﬁed

channel

CH<x>:COUPling Sets or returns the coupling setting for the

speciﬁed channel

CH<x>:DESKew Sets or returns the deskew time for the

speciﬁed channel

CH<x>:INVert Sets or returns the invert function for the

speciﬁed channel

CH<x>:LABel Sets or returns the waveform label for

channel <x>

CH<x>:OFFSet Sets or returns the channel offset

CH<x>:POSition Sets or returns the channel vertical position

CH<x>:PRObe?

CH<x>:PRObe:AUTOZero Sets the TekVPI probe attached to the

CH<x>:PRObe:COMMAND Sets the state of the speciﬁed probe control

CH<x>:PRObe:DEGAUss Starts a degauss/autozero cycle on a TekVPI

CH<x>:PRObe:DEGAUss:STATE? Returns the state of the probe degauss

CH<x>:PRObe:FORCEDRange Sets or returns the range on a TekVPI probe

CH<x>:PRObe:GAIN Sets or returns the gain factor of the probe

CH<x>:PRObe:ID? Returns the type and serial number of

CH<x>:PRObe:ID:SERnumber? Returns the serial number of the probe that

Returns the gain, resistance, units, and ID of the probe that is attached to the speciﬁed channel

speciﬁed channel input to autozero

current probe attached to the speciﬁed channel input

attached to the speciﬁed channel

that is attached to the speciﬁed channel

the probe that is attached to the speciﬁed channel

is attached to the speciﬁed channel

2-76 MSO3000 and DPO3000 Series Programmer Manual

Command Groups

Table 2-33: Vertical Commands (cont.)

Command Description

CH<x>:PRObe:ID:TYPE? Returns the type of probe that is attached to

the speciﬁed channel

CH<x>:PRObe:MODel Sets or returns the probe model for the

speciﬁed channel

CH<x>:PRObe:PROPDELay Sets or returns the propagation delay for the

probe connected to the speciﬁed channel

CH<x>:PRObe:RECDESkew? Returns the recommended deskew for the

probe connected to the speciﬁed channel

CH<x>:PRObe:RESistance? Returns the resistance of the probe that is

attached to the speciﬁed channel

CH<x>:PRObe:SIGnal Sets or returns the input bypass setting of

channel <x>TekVPI probe

CH<x>:PRObe:UNIts? Returns the units of measure of the probe

that is attached to the speciﬁed channel

CH<x>:SCAle Sets or returns the vertical scale of the

speciﬁed channel

CH<x>:TERmination Sets or returns channel input termination

CH<x>:YUNits Sets or returns the units for the speciﬁed

channel

D<x>

D<x>:LABel

D<x>:POSition Sets or returns the vertical position for digital

D<x>:THREshold

DESkew Causes the deskew values for all channels

DESkew:DISPlay Sets or returns the state of the deskew table

REF<x>? Returns reference waveform settings for

REF<x>:DATE? Returns the date that a reference waveform

REF<x>:HORizontal:DELay:TIMe Sets or returns the horizontal delay time

REF<x>:HORizontal:SCAle Sets or returns the horizontal scale for a

Returns parameters for digital channel<x>

Sets or returns the waveform label for digital channel<x>

channel<x>

Sets or returns the logical threshold for digital channel<x>

to be set to the recommended values

display

waveform reference <x>

was stored

for reference waveform <x>, where x is the reference channel number. The delay time is expressed in seconds and is limited to ± 5 times the reference horizontal scale

reference waveform

MSO3000 and DPO3000 Series Programmer Manual 2-77

Command Groups

Table 2-33: Vertical Commands (cont.)

Command Description

REF<x>:LABel

REF<x>:TIMe? Returns the time that a reference waveform

REF<x>:VERTical:POSition Sets or returns the vertical position of the

REF<x>:VERTical:SCAle Sets or returns the reference waveform

SELect Returns information on which waveforms are

SELect:BUS<x> Turns on or off the speciﬁed bus waveform

SELect:CH<x> Turnsonoroffthespeciﬁed waveform or

SELect:CONTROl Sets or returns the waveform that is selected

SELect:D<x> Turns on the display of digital channel<x>

SELect:MATH[1] Turns on or off the math waveform or returns

SELect:REF<x> Turnsonoroffthespeciﬁed reference

Sets or returns the speciﬁed reference waveform label

was stored

speciﬁed reference waveform

vertical scale in vertical units/div

on or off and which waveform is selected

or returns whether the speciﬁed bus channel is on or off

returns whether the speciﬁed channel is on or off

as the implied recipient of channel-related commands

and resets the acquisition

whether the math waveform is on or off

waveform or returns whether the speciﬁed reference waveform is on or o ff

Waveform Transfer Command Group

The CURVe and other commands and queries in the Waveform Transfer Command Group are used to transfer waveform data points to and from the oscilloscope. The waveform data points are a collection of values that represent the amplitude of the waveform samples. One data value usually represents one data point in the waveform record. Only one waveform can be transferred at a time.

Each waveform you transfer has an associated waveform preamble, which contains information such as data format, horizontal scale, vertical scale, and the other settings in effect when the waveform was created. When you transfer a waveform, you need to specify at least some of the general and preamble settings (using the raw data point information (using the

2-78 MSO3000 and DPO3000 Series Programmer Manual

DATa, WFMInpre or WFMOutpre commands) before you specify the

CURVe command or query.)

Command Groups

Waveform data c

an be transferred to or from the oscilloscope using the Ethernet or USBTMC interfaces in binary or ASCII format. Binary data transfer is considerably more efﬁcient than ASCII data transfer. Binary data is transferred to and from the oscilloscope using the IEEE488.2 arbitrary block format (7.7.6 of the IEEE488.2 spec) which we refer to in this document as “binary block format”. A binary block is represented as:

#N<N-Digits><binary data>

Where:

The “#” is the arbitrary block token.

N is a single hexadecimal digit specifying how many decimal digits immediately follow.

<N-Digits> is a decimal number N digits long, that speciﬁes the number of binary data bytes to follow.

<binary data> is the binary data which should be exactly N-Digits bytes in length.

NOTE. If you would like to save or recall a waveform to or from a ﬁle, use the

SAVe:WAVEform and RECAll:WAVEform commands.

sferring a Waveform

Tran

From an Oscilloscope to a

Computer

Use the DATa commands and WFMOutpre commands to specify the attributes of the waveform being transferred from the oscilloscope. You must, at a minimum, specify the waveform source (using the

ing the

(us

Then, use the

e waveform data points. Finally, use the

DATa:ENCdg and DATa:WIDth commands).

WFMOutpre? query, which provides the context needed to interpret

data points. (You can also use the

WFMOutpre? and CURVe? queries. )

NOTE. In order to guarantee that the waveform data returned from

DATa:SOUrce command) a nd data format

CURVE? query to transfer the waveform

WAVFrm? query, which concatenates the

CURVE?

queries of multiple waveforms are correlated to the same acquisition, you should use single sequence acquisition mode to acquire the waveform data from a single acquisition. Single sequence acquisition mode is enabled using

ACQuire:STOPAfter

NOTE. The

WFMOutpre:BYT_Nr

SEQuence

and

WFMOutpre:BIT_Nr

settings are directly related; setting one causes the other to be set accordingly. For example, 16 (2 * 8 bits/byte). Similarly, setting

WFMOutpre:BYT_Nr

WFMOutpre:BYT_Nr 2

to be set to 2.

causes

WFMOutpre_BIT_Nr

WFMOutpre:BIT_Nr

to be set to

to 16 causes

MSO3000 and DPO3000 Series Programmer Manual 2-79

Command Groups

Following is an

example command sequence that illustrates how to transfer

waveform data from the oscilloscope to the computer.

In this case, l

et’s say you’d like to transfer 10,000 points from channel 1, in ASCii

format with 1 byte per point, to your computer program.

Table 2-34: Example Command Sequence for Transferring Waveform Data From Oscilloscope to Computer

Item Description

:DATa:SOUrce CH1 Sets the source waveform to be transferred to Channel 1.

:DATa:STARt 1 This, along with DATa:STOP, speciﬁes the portion of the waveform record that will

be transferred .

:DATa:STOP 10000

:DATa:ENCdg ASCIi Sets the data format to ASCII. (This command replaces WFMOutpre:ENCdg,

WFMOutp

:DATa:WIDth 1

:HEADer 1 Turning on HEADer and VERBose will allow you to view the WFMOutp re?

:VERBose 1

:WFMOutpre? The WFMOutpre? query provides the information needed to interpret the waveform

:HEADer 0

:CURVe? Transfers the data points.

Sets 1 by

parame

data p

You ma the header on, a a space and the ASCII waveform data.

re:BN_Fmt

te per point (same as

ters in context.

oint information that will be returned from the

y want to turn the header off before doing the

and WFMOutpre:BYT_Or with a single command.)

WFMOutpre:BYT_Nr).

CURVe query.

CURVe query, because with

CURVe query will return the CURVe command header followed by

NOTE. For more command sequence examples as well as several comprehensive

examples of what the

WFMOutpre?

query might return using different data sources, see Appendix D. (See page D-1, Waveform Transfer (WFMOutpre and CURVe Query) Examples.)

Example 1: Analog Waveform (channel 1 - 4)

Example 2: Digital Waveform (channel DO-D15)

Example 3: The Digital Collection with 4 Bytes Per Point with MagniVu Off

Example 4: The Digital Collection with 8 Bytes Per Point with MagniVu Off

Example 5: The Digital Collection with 4 Bytes Per Point with MagniVu On

Example 6: The Digital Collection with 8 Bytes Per Point with MagniVu On

NOTE. Whenyoudoa

WFMOutpre?

query in an interactive session during program development, it’s a good idea to ﬁrst turn on the header and verbose features (using the

HEADer

and

VERBose

commands) in order to see the returned

values in context.

2-80 MSO3000 and DPO3000 Series Programmer Manual

Command Groups

Waveform Sourc

oscilloscope (using the

CH1 – CH4 –Anal

es. Valid waveform sources that can be transferred from the

DATa:SOUrce command) include:

og channels. When

DATa:SOUrce is set to one of these

sources, the data points represent digitizing levels. There are 25 digitizing levels per vertical division for 1-byte data, and 6400 digitizing levels per vertical division for 2-byte data. These data points can be transferred in signed or unsigned integer formats.

D0–D15— The digital input channels (MSO models only). When

DATa:SOUrce

is set to one of these, the data points are binary states (0 or 1). These data points can be transferred in widths of 1 or 2 bytes, as signed or unsigned integers.

DIGital — The Digital Collection. These data points are binary states (0 or 1) that can be transferred in widths of 4 or 8 bytes, as signed or unsigned integers. For ASCII en suppressed. When

coding, the data is transferred as hexadecimal values with leading zeroes

DATa:SOUrce is set to DIGital, this represents a collection

of information that differs depending on the data width (set using either the

DATa:WIDth or WFMOutpre:BYT_Nr command.)

When the data width is set to 4 bytes, the Digital Collection is the states of digital channels D0 – D15, plus the digital representations of analog channels 1 – 4, plus the trigger state.

When the data width is set to 8 bytes, the Digital Collection is the transition state information for digital channels D0 – D15, plus the digital representations of analog channels 1 – 4. For more information, see the section below

rther Explanation of Digital Collection Data”. (MSO models only.)

“Fu

MATH — The format of MATH data is dependent upon the sources for the math

veform. For analog channel sources, the format is that for the analog channels

wa described above.

EF1-REF4 — The format of REF data is dependent upon the sources from

which the reference waveform was created. For analog channel sources, the format is that for the analog channels described above.

NOTE. When you change the

for the waveform preamble (

DATa:SOUrce

WFMOutpre

setting, all of the associated settings

commands) are automatically adjusted for the speciﬁed source waveform. The speciﬁed source waveform must be turned on.

Data Encoding and Widths. Data transferred from the oscilloscope using the

CURVe query can be sent in either ASCII or binary formats. ASCII data is sent as

a comma-separated list of decimal values. Binary data is sent with the IEEE488.2 binary block header, immediately followed by the binary data.

You can specify the format for waveform transfers from the oscilloscope using the combination of

WFMOutpre:ENCdg, WFMOutpre:BN_Fmt and

MSO3000 and DPO3000 Series Programmer Manual 2-81

Command Groups

_Or

WFMOutpre:BYT

commands. Or else you can simply use the DATa:ENCdg

command, which combines all three.

ASCII data is represented by s igned integer values for analog and digita l channels. The range of the values depends on the data width (speciﬁed using the

WFMOutpre:BYT-Nr or DATa:WIDth command). One byte wide data

ranges from -128 to 127. Two byte wide data ranges from -32768 to 32767. For digital channels D0 through D15, the values returned are 0 or 1. For the Digital Collection, ASCII data is returned in hexadecimal format with any leading zeroes omitted.

Transferring a Waveform

From a Computer to an

Oscilloscope’s Internal

Reference Memory

Waveforms sent from a computer program TO the oscilloscope are always stored in one of the internal reference memory locations (REF1-4). Use

DATa:DESTination to specify the reference memory location, as well other DATa commands to specify record start and stop points. Next, use the WFMInpre

commands to specify the waveform’s data format, scale, domain and other attributes that will be used to convert raw data points into the scope's internal waveform points. Then, use

CURVe command to transfer the raw data points.

WFMInpre? to verify your settings. Finally, use the

Following is an example command sequence that illustrates how to transfer waveform data to the oscilloscope’s internal reference memory.

In this case, let’s say you have created a waveform on your computer and would like to transfer 10,000 data points of it,

in ASCii format w ith 1 byte per point, to

your oscilloscope’s internal reference memory location REF2.

NOTE. The

WFMInpre:BYT_Nr

and

WFMInpre:BIT_Nr

settings are directly

related; setting one causes the other to be set accordingly. For example,

WFMInpre:BYT_Nr 2

Similarly, setting

causes

WFMInpre:BIT_Nr

WFMInpre_BIT_Nr

to 16 causes

tobesetto16(2*8bits/byte).

WFMInpre:BYT_Nr

set to 2.

Table 2-35: Example Command Sequence for Transferring Waveform Data From Computer to Oscilloscope

to be

Item Description

:DATa:DESTination REF2 Selects REF 2 as the internal reference memory location that the incoming

waveform will be transferred to.

:DATa:STARt 1 This, along with DATa:STOP, speciﬁes the starting and ending points of the

waveform record that will be trans

:DATa:STOP

:WFMInpre:BYT_Nr 1

:WFMInpre:BIT_Nr 8

:WFMInpre:ENCdg ASCII Speciﬁes that the incoming w aveform uses the ASCII format.

:WFMInpre:NR_Pt 10000

10000

Sets the number of bytes per data to REF2 to 1.

Sets the number of bits per binary data point to 8.

Sets the number of data points that are being sent to REF2 to 10000.

ferred to REF2.

point in the waveform data to be sent

2-82 MSO3000 and DPO3000 Series Programmer Manual

Command Groups

Table 2-35: Example Command Sequence for Transferring Waveform Data From Computer to Oscilloscope (cont.)

Item Description

:WFMInpre:PT_Fmt Y

:WFMInpre:XUNit "S" Sets the horizontal units of the x-axis of the data points to seconds.

:WFMInpre:XINcr 4.0000E-9

:WFMInpre:XZERo -20.0000E-6

:WFMInpre:YUNit "V"

:WFMInpre:YMUlt 4.0000E-3

:WFMInpre:YOFf 0.0E+0 Speciﬁes that the vertical position in digitizing levels of the incoming reference

:WFMInpre:YZEro 0.0E+0

:HEADer 1 Turning on HEADer and VERBose will allow the WFMInpre? parameters

:VERBose 1

:WFMInpre? Do this query to verify your settings.

:CURVe <10,000 ASCIi data points, each separated by a comma>

Speciﬁes that the incoming waveform is a normal one, where one ASCII or binary data point is transmitted for each point in the waveform record (as opposed to envelope).

Sets the horizontal interval between the incoming waveform points, using the units speciﬁed above.

Sets the position value of the ﬁrst data point in the incoming waveform record.

Speciﬁes that Volts are the vertical units of the data points being sent.

Speciﬁes the vertical scale multiplying factor used to convert the incoming data points from digitizing levels into the units speciﬁed above.

waveform is 0.

Speciﬁes that the vertical offset of the incoming waveform is 0.

to be viewed in context.

Sends the data points to REF2.

Scaling Waveform Data

Once you transfer waveform data from an oscilloscope to a computer, you can convert the data points (which are digitizing levels) into engineering units such as Volts or Amps for analysis using information from the waveform preamble.

The following is an example for converting transferred data into the appropriate engineering units. The transfer data is from an analog waveform in YT (single point) format. (See WFMInpre:PT_Fmt for the deﬁnition of the point formats.) The data points returned from the

CURVE? query for analog channel data are in

digitizing levels. The YMULT value is in vertical units (e.g. volts) per digitizing level.

Formula for computing horizontal (time) point value:

= XZEro + XINcr * (i - 1)

Formula for computing vertical (amplitude) point value:

= YZEro + (YMUlt * DataPointi)

where:

i is the index of a curve data point (1–based: ﬁrst data point is point number 1)

is the ith horizontal value in XUNits

is the ith vertical value in YUNits

MSO3000 and DPO3000 Series Programmer Manual 2-83

Command Groups

DataPointiis t

he waveform data point value, in digitizing levels.

Commands used:

:DATa:SOUrce CH1

:DATa:START 1

:DATa:STOP 1000

:WFMOutpre:NR_pt? 1000

:WFMOutpre:XUNit? “s”

:WFMOutpre:XZEro? -500.000E-3

:WFMOutpre:XINcr? 1.0000E-3

:WFMOutpre:YUNit? “V”

:WFMOutpre:YZEro? 0.0E+0

:WFMOutpre:YMUlt? 4.0000E-3

:WFMOutpre:BYT_nr? 1

Horizontal (time) values:

= XZEro + XINcr * (i - 1)

= -500ms + 1ms * (i – 1)

= -500ms + 1ms * (1 - 1)

= -500ms

= -500ms + 1ms * (2 - 1)

= -499ms

.. .

= -500ms + 1ms * (1000 - 1) = 499ms

1000

Vertical (amplitude) values:

=YZEro+(YMUlt*DataPointi)

= 0.0V + (0.004 * DataPoint

YZERO is

in vertical units; in this example, 0.0 Volts.

)

YMULT is in vertical units per digitizing level (DL), in this example,

0.004 Volts per digitizing level.

From

CURVe query:

DataPoint

=-10

DataPoint

=-11

2-84 MSO3000 and DPO3000 Series Programmer Manual

Tektronix DPO3012, DPO3014, DPO3032, DPO3034, DPO3052 Programmer

Specifications and Main Features

Frequently Asked Questions

User Manual
