Tektronix MPI2-10 Assembly/installation Instructions

MPI2-10 Front Panel Assembly Installation Instructions
CAUTION. Replacement of the front-panel assembly should be performed only by
qualied personnel. The instrument hardware can be damaged performing this procedure.
Servicesafetysummary
The Service safely perform service on the product. Read this Service safety summary before performing any service procedures.
To avoid electric shock. Do not touch exposed connections.
Do not se
product unless another person capable of rendering first aid and resuscitation is present.
Disconnect power. To avoid electric shock, switch off the product power and disconnect the power cord from the mains power before removing any covers or
s, or opening the case for servicing.
panel
Use care when servicing with power on. Dangerous voltages or currents may exist in this product. Disconnect power, remove battery (if applicable), and disconnect test leads before removing protective panels, soldering, or replacing components.
ify safety after repair. Always recheck ground continuity and mains dielectric
Ver
strength after performing a repair.
safety summary section contains additional information required to
rvice alone. Do not perform internal service or adjustments of this
Terms in this manual
www.tek.com Copyright © Tektronix
*P075110800*
075-1108-00
These terms may appear in this manual:
WAR N I NG. Warning statements identify conditions or practices that could result
in injury or loss of life.
CAUTION. Caution statements identify conditions or practices that could result in
damage to this product or other property.
MPI2-10 Front Panel Assembly Installation Instructions
Kit parts list
The following table lists the parts that are supplied with the front panel assembly installation kit.
Quantity Part Number Description
1 850-0336-XX
4 211-0734-XX
1 075-1108-XX
FRONT PANEL ASSY
SCREW, MACHINE; 6-32 X 0.250, FLH100, STEEL, ZINC FINISH,T-10TORXDR
PRISM FIELD UPGRADE INSTRUCTIONS
Recommended tool list
Table 1: Recommended tool list
Name Description
Screwdriver handle
T-10 TORX tip Used for removing instrument screws.
Torque driver
Remove and replace the front panel assembly
These instructions are for personnel who are familiar with servicing the product. Contact your nearest Tektronix, Inc., Service Center or Tektronix Factory Service for installation assistance.
Accepts Torx-driver bits
TORX-driver bit for T-10 size screw heads.
Used to apply precisely a specic torque to a fastener.
NING. Dangerous voltages may be present. To prevent electrical shock,
WAR
disconnect the power cord from the unit before starting the upgrade procedure. Failure to do so could cause serious injury or death.
CAUTION. Many components within the instrument are susceptible to static-static
discharge damage. To prevent static discharge damage, service the product only in a static-free environment. Observe standard handling precautions for static-sensitive devices while installing this kit. Always wear a grounded wrist strap, grounded foot strap, and static resistant apparel while installing this kit.
2 MPI2-10 Front Panel Assembly Installation Instructions
MPI2-10 Front Panel Assembly Installation Instructions
1. Set the instrum
CAUTION. Dislodging or cracking the bezel can cause damage to the display. To
prevent damage to the display, do not put excessive pressure on the bezel when removing, replacing or installing modules.
2. Remove the top cover as follows:
a. Use a TORX-driver with a T-10 TORX tip to remove the twelve screws
securing the cover to the instrument.
b. Slide the cover back and then lift it from the back to remove it from the
instrument; set the cover aside.
ent so that the bottom is down on a static-free work surface.
3. UseaTORXdriverwithaT-10TORXtiptoremovethetwoscrewsoffeach side of instrument.
MPI2-10 Front Panel Assembly Installation Instructions 3
MPI2-10 Front Panel Assembly Installation Instructions
4. Tip the instrum connector is disconnected.
ent up on the back panel and pull the Display up until the
5. To reinstall the display, reverse the steps.
CAUTION. The touch display will not operate correctly if connector is not lined
up. To avoid this issue, line up the connectors before engaging.
4 MPI2-10 Front Panel Assembly Installation Instructions
