MDO4000C Series Mixed Domain Oscilloscopes

ZZZ

Speciﬁcations and Performance Veriﬁcation

Technical Reference

*P077117801*

077-1178-01

MDO4000C Series Mixed Domain Oscilloscopes

ZZZ

Speciﬁcations and Performance Veriﬁcation

Technical Reference

Revision B

August 26, 2019 This document supports ﬁrmware version 1.02 and above for MDO4000C Series instruments.

Warning

The servicing instructions are for use by qualiﬁed personnel only. To avoid personal injury, do not perform any servicing unless you are qualiﬁed to do so. Refer to all safety summaries prior to performing service.

www.tek.com

077-1178-01

Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries or suppliers, and are protected by national copyright laws and international treaty provisions.

Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supersedes that in all previously published material. Speciﬁcations and price change privileges reserved.

TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.

Contacting Tektronix

Tektronix, Inc. 14150 SW Karl Braun Drive P.O . B ox 50 0 Beaverto USA

For product information, sales, service, and technical support:

n, OR 97077

In North America, call 1-800-833-9200. Worldwide, visit www.tek.com to ﬁnd contacts in your area.

Table of Contents

Important safety information..................................................................................... iv

General safety summary ..................................................................................... iv

Servicesafety summary..................................................................................... vii

Terms in thismanual ........................................................................................ viii

Symbols and terms on the product......................................................................... viii

Speciﬁcations ....................................................................................................... 1

Analog Signal Acquisition System Speciﬁcations . ... . ... . ... . ... . ... . .................................... 1

Time Base System Speciﬁcations............................................................................ 8

TriggeringSystem Speciﬁcations........................................................................... 11

Digital Acquisition System Speciﬁcations .. .. ... . ... . ... . ... . ... . ......................................... 16

P6616 Digital Probe Input Speciﬁcations.................................................................. 17

RF Input Speciﬁcations ...................................................................................... 18

Arbitrary Function Generator Characteristics ............................................................. 22

Digital Voltmeter/Counter ................................................................................... 24

Display System Speciﬁcations .............................................................................. 24

Interfaces and Input/Output Port Speciﬁcations........................................................... 25

Data Handling Speciﬁcations................................................................................ 27

Power Supply System Speciﬁcations....................................................................... 27

Environmental Speciﬁcations ............................................................................... 28

Mechanical Speciﬁcations ................................................................................... 29

TPA-N-PRE Speciﬁcations .................................................................................. 30

PerformanceVeriﬁcation ......................................................................................... 33

Test Record.................................................................................................... 35

Performance Veriﬁcation Procedures....................................................................... 84

Self Test................................................................................................... 85

Check Input Impedance (Resistance).................................................................. 86

Check DC Balance....................................................................................... 88

Check DC Gain Accuracy............................................................................... 90

Check DC Offset Accuracy............................................................................. 94

Check Analog Bandwidth............................................................................... 96

Check Random Noise, Sample Acquisition Mode .. . ... . ... .. ... . ... .. ... . .......................... 99

Check Reference Frequency Error (Cumulative)................................................... 101

Check Delta Time MeasurementAccuracy ......................................................... 103

Check Digital Threshold Accuracy .................................................................. 105

Check Phase Noise..................................................................................... 109

Check Displayed Average Noise Level (DANL)................................................... 112

Check Absolute Amplitude Accuracy ............................................................... 118

Check Third OrderIntermodulation Distortion..................................................... 122

Check ResidualSpurious Response.................................................................. 126

MDO4000C Series Speciﬁcations and Performance Veriﬁcation i

Table of Contents

Check Crosstal

Check Trigger Out ..................................................................................... 130

With TPA-N-PRE Attached: Check Displayed Average Noise Level (DANL).. . .............. 134

k to RFChannel from Analog Channels........................................... 128

ii MDO4000C Series Speciﬁcations and Performance Veriﬁcation

List of Tables

Table 1: Analog signal acquisition system speciﬁcations . ... . ... . ... . ......................................... 1

Table 2: Time base system speciﬁcations........................................................................ 8

Table 3: Delta-time measurement accuracy formula .......................................................... 10

Table 4: Tri

Table 5: Digital acquisition speciﬁcations .. .. ... .. ... . ... . ... . ... . ............................................. 16

Table 6: P6616 digitalprobeinput speciﬁcations.............................................................. 17

Table 7: RF input speciﬁcations ................................................................................. 18

Table 8: AFG Characteristics .................................................................................... 22

Table 9: Digital Voltmeter/Counter.............................................................................. 24

Table 10

Table 11: Interfaces and Input/Output port speciﬁcations . . ... . .... .......................................... 25

Table 12: Data handling speciﬁcations.......................................................................... 27

Table 13: Power supply system speciﬁcations ................................................................. 27

Table 14: Environmental speciﬁcations......................................................................... 28

Table 15: Mechanical speciﬁcations............................................................................. 29

e 16: TPA-N-PRE speciﬁcations............................................................................ 30

Tabl

Table 17: Required equipment................................................................................... 34

Table 18: Gain expectedworksheet ............................................................................. 92

Table 19: Maximum bandwidth frequency worksheet ........................................................ 97

gger speciﬁcations................................................................................... 11

: Display system speciﬁcations ........................................................................ 24

MDO4000C Series Speciﬁcations and Performance Veriﬁcation iii

Important safety information

Important saf

ety information

This manual c for safe operation and to keep the product in a safe condition.

To safely perform service on this product, additional information is provided at the end of this section. (See page vii, Service safety summary.)

General safety sum mary

Use the product only as speciﬁed. Review the following safety precautions to avoid injury and prevent damage to this product or any products connected to it. Carefully read all instructions. Retain these instructions for future reference.

Comply with local and national safety codes.

For correct and safe operation of the product, it is essential that you follow generally accepted safety procedures in addition to the safety precautions speciﬁed in this manual.

The product is designed to be used by trained personnel only.

Only qualiﬁed personnel who are aware of the hazards involved should remove the cover for repair, maintenance, or adjustment.

ontains information and warnings that must be followed by the user

To avoid ﬁre or personal

injury

Before use, always check the product with a known source to be sure it is operating correctly.

This product is not intended for detection of hazardous voltages.

Use personal protective equipment to prevent shock and arc blast injury where hazardous live conductors are exposed.

While using this product, you may need to access other parts of a larger system. Read the safety sections of the other component manuals for warnings and cautions related to operating the system.

When incorporating this equipment into a system, the safety of that system is the responsibility of the assembler of the system.

Use proper power cord. Use only the power cord speciﬁed for this product and certiﬁed for the country of use.

Do not use the provided power cord for other products.

Ground the product. This product is grounded through the grounding conductor of the power cord. To avoid electric shock, the grounding conductor must be connected to earth ground. Before making connections to the input or output terminals of the product, make sure that the product is properly grounded.

iv MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Important safety information

Do not disable t

Power disconnect. The power cord disconnects the product from the power source. See instructions for the location. Do not position the equipment sothat it is difﬁcult to operate the power cord; it must remain accessible to the user at all times to allow for quick disconnection if needed.

Connect and disconnect properly. Do not connect or disconnect probes or test leads while they are connected to a voltage source.

Use only insulated voltage probes, test leads, and adapters supplied with the product, or indicated by Tektronix to be suitable for the product.

Observe all terminal ratings. To avoid ﬁre or shock hazard, observe all ratings and markings on the product. Consult the product manual for further ratings information before making connections to the product. Do not exceed the Measurement Category (CAT) rating and voltage or current rating of the lowest rated individual component of a product, probe, or accessory. Use caution when using 1:1 test leads because the probe tip voltage is directly transmitted to the product.

Do not apply a potential to any terminal, including the common terminal, that exceeds the maximum rating of that terminal.

he power cord grounding connection.

Do not ﬂoat the common terminal above the rated voltage for that terminal.

Do not operate without covers. Do not operate this product with covers or panels removed, or with the case open. Hazardous voltage exposure is possible.

Avoid exposed circuitry. Do not touch exposed connections and components when power is present.

Do not operate with suspected failures. If you suspect that there is damage to this product, have it inspected by qualiﬁed service personnel.

Disable the product if it is damaged. Do not use the product if it is damaged or operates incorrectly. If in doubt about safety of the product, turn it offand disconnect the power cord. Clearly mark the product to prevent its further operation.

Before use, inspect voltage probes, test leads, and accessories for mechanical damage and replace when damaged. Do not use probes or test leads if they are damaged, if there is exposed metal, or if a wear indicator shows.

Examine the exterior of the product before you use it. Look for cracks or missing pieces.

Use only speciﬁed replacement parts.

Use proper fuse. Use only the fuse type and rating speciﬁed for this product.

MDO4000C Series Speciﬁcations and Performance Veriﬁcation v

Important safety information

Do not operate i

a unit is moved from a cold to a warm environment.

Do not operate in an explosive atmosphere.

Keep product surfaces clean and dry. Remove the input signals before you clean

the product.

Provide proper ventilation. Refer to the installation instructions in the manual for details on installing the product so it has proper ventilation.

Slots and openings are provided for ventilation and should never be coveredor otherwise obstructed. Do not push objects into any of the openings.

Provide a safe working environment. Always place the product in a location convenient for viewing the display and indicators.

Avoid improper or prolonged use of keyboards, pointers, and button pads. Improper or prolonged keyboard or pointer use may result in serious injury.

Be sure your work area meets applicable ergonomic standards. Consult with an ergonomics professional to avoid stress injuries.

Use only the Tektronix rackmount hardware speciﬁed for this product.

n wet/damp conditions. Be aware that condensation may occur if

Probes and test leads

Before connecting probes or test leads, connect the power cord from the power connector to a properly grounded power outlet.

Keep ﬁngers behind the ﬁnger guards on the probes.

Remove all probes, test leads and accessories that are not in use.

Use only correct Measurement Category (CAT), voltage, temperature, altitude, and amperage rated probes, test leads, and adapters for any measurement.

Beware of high voltages. Understand the voltage ratings for the probe you are using and do not exceed those ratings. Two ratings are important to know and understand:

The maximum measurement voltage from the probe tip to the probe reference lead.

The maximum ﬂoating voltage from the probe reference lead to earth ground

These two voltage ratings depend on the probe and your application. Refer tothe Speciﬁcations section of the manual for more information.

WARNING. To prevent electrical shock, do not exceed the maximum measurement

or maximum ﬂoating voltage for the oscilloscope input BNC connector, probe tip, or probe reference lead.

vi MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Important safety information

Connect and dis

product before connecting the probe to the circuit under test. Connect the probe reference lead to the circuit under test before connecting the probe input. Disconnect the probe input and the probe reference lead from the circuit under test before disconnecting the probe from the measurement product.

Connect and disconnect properly. De-energize the circuit under test before connecting or disconnecting the current probe.

Connect the probe reference lead to earth ground only.

Do not connect a current probe to any wire that carries voltages above the current probe voltage rating.

Inspect the probe and accessories. Before each use, inspect probe and accessories for damage (cuts, tears, or defects in the probe body, accessories, or cable jacket). Do not use if damaged.

Ground-referenced oscilloscope use. Do not ﬂoat the reference lead of this probe when using with ground-referenced oscilloscopes. The reference lead mustbe connected to earth potential (0 V).

Floating measurement use. Do not ﬂoat the reference lead of this probe above the rated ﬂoat voltage.

connect properly. Connect the probe output to the measurement

Servicesafetysummary

The Service safety summary section contains additional information required to safely perform service on the product. Only qualiﬁed personnel should perform service procedures. Read this Service safety summary and the General safety summary before performing any service procedures.

To avoid electric shock. Do not touch exposed connections.

Do not service alone. Do not perform internal service or adjustments of this

product unless another person capable of rendering ﬁrst aid and resuscitation is present.

Disconnect power. To avoid electric shock, switch off the product power and disconnect the power cord from the mains power before removing any covers or panels, or opening the case for servicing.

Use care when servicing with power on. Dangerous voltages or currents may exist in this product. Disconnect power, remove battery (if applicable), and disconnect test leads before removing protective panels, soldering, or replacing components.

Verify safety after repair. Always recheck ground continuity and mains dielectric strength after performing a repair.

MDO4000C Series Speciﬁcations and Performance Veriﬁcation vii

Important safety information

Termsinthismanual

These terms may appear in this manual:

WARNING. Warning statements identify conditions or practices that could result

in injury or loss of life.

CAUTION. Caution statements identify conditions or practices that could result in

damage to this product or other property.

Symbols and terms on the product

These ter

The following symbol(s) may appear on the product:

ms may appear on the product:

DANGER indicates an injury hazard immediately accessible as you read the mark

WARNING indicates an injury hazard not immediately accessible as you read th

CAUTION indicates a hazard to property including the product.

ing.

e marking.

When this symbol is marked on the product, be sure to consult the manual to ﬁnd out the nature of the potential hazards and any actions which have to betakentoavoidthem. (Thissymbolmayalsobeusedtorefertheuserto ratings in the manual.)

viii MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Speciﬁcations

This chapter contains speciﬁcations for the MDO4000C Series oscilloscopes. All speciﬁcations are guaranteed unless noted as "typical." Typical speciﬁcations are provided for marked with the

your convenience but are not guaranteed. Speciﬁcations that are

symbol are checked in Performance Veriﬁcation.

All speciﬁc

ations apply to all MDO4000C models unless noted otherwise. To

meet speciﬁcations, two conditions must ﬁrst be met:

The oscill

oscope must have been operating continuously for twenty minutes

within the speciﬁed operating temperature range. (See Table 14 on page 28.)

You m ust p

erform the Signal Path Compensation (SPC) operation described instep2oftheSelf Test before evaluating speciﬁcations. (See page 85, Self Test.) If the operating temperature changes by more than 10 °C (18 °F), you must perform the SPC operation again.

Analog Signal A cquisition System Speciﬁcations

The following table shows the speciﬁcations for the analog signal acquisition system.

Table 1: Analog signal acquisition system speciﬁcations

Characteristic Description

Number of input channels

Input coupling

Input resistance selection

Input impedance, DC coupled

Input Capacitance, 1M DC coupled, typical

4 analog channels, digitized simultaneously

DC or AC

1M or 50  250 k  (to be selected for performance veriﬁcation only).

1M 1M ±1%

50 

13 pF ± 2 pF

50  ±1%

MDO4104C VSWR 1.5:1 from DC to 1 GHz, typical

MDO4054C VSWR 1.5:1 from DC to 500 MHz, typical

MDO4034C VSWR 1.5:1 from DC to 350 MHz, typical

MDO4024C VSWR 1.5:1 from DC to 200 MHz, typical

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 1

Speciﬁcations

Table 1: Analog signal acquisition system speciﬁcations (cont.)

Characteristic Description

Maximum input voltage

DC Balance 0.1 div with the input DC coupled, set to 50  termination, and input terminated with 50  BNC

Number of digitized bits

(coarse)

Sensitivity range (ﬁne)

Sensitivity resolution (ﬁne), typical

1M 300 V

at the BNC

RMS

Installation Category II

Derate at 20 dB/decade between 4.5 MHz and 45 MHz

Derate 14 dB/decade between 45 MHz and 450 MHz

Above 450 MHz, 5 V

RMS

Maximum peak input voltage at the BNC, ±424 V

250 K 75 V

at the BNC

RMS

Installation Category II

Derate at 20 dB/decade between 1.3 MHz and 13 MHz

Derate 10 dB/decade between 13 MHz and 130 MHz

Above 130 MHz, 5 V

RMS

Maximum peak input voltage at the BNC, ±106 V

50  5V

with peaks ±20 V (Duty Factor  6.25%)

RMS

Overvoltage trip is intended to protect against overloads that might damage termination resistors. A sufﬁciently large impulse might cause damage regardless of the overvoltage protection circuitry because of the ﬁnite time required to detect and respond.

terminator

0.2 div at 1 mV/div with the input DC coupled, set to 50  termination, and input terminated with 50  BNC terminator

0.2 div with the input DC coupled, set to 1 M termination, and input terminated with 50  BNC terminator

0.225 div at 1 mV/div with the input DC coupled, set to 1 M termination, and input terminated with 50  BNC terminator

8 bits

Displayed vertically with 25 digitization levels (DL) per division, 10.24 divisions dynamic range.

"DL" is the abbreviation for "digitization level." A DL is the smallest voltage level change that can be resolved by an A-D Converter. This value is also known as the least signiﬁcant bit (LSB).

1MΩ 1 mV/div to 10 V/div in a 1-2-5 sequenceSensitivity range

50 Ω 1 mV/div to 1 V/div in a 1-2-5 sequence

1MΩ

1 mV/div to 5 V/div < –50% to > +50% of selected setting

10 V/div < –50% to 0%

Allows continuous adjustment from 1 mV/div to 10 V/div

50 Ω

1mV/divto

< –50% to > +50% of selected setting

500 mV/div

1 V/div < –50% to 0%

Allows continuous adjustment from 1 mV/div to 1 V/div

1% of current setting

2 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Table 1: Analog signal acquisition system speciﬁcations (cont.)

Characteristic Description

DC gain accuracy For 5 0 Ω,1MΩ, and 250 kΩ (250 kΩ checked indirectly):

±1.5%, derated at 0.100%/°C above 30 °C

±2.0%, derated at 0.100%/°C above 30 °C, 1 mV/Div setting

±3.0% variable gain, derated at 0.100%/°C above 30 °C

Speciﬁcations

Offset ranges, minimum

Position range ±5 divisions

Offset accuracy ±[0.005 × | offset – position | + DC Balance]

Number of waveforms for average acquisition mode

DC voltage measurement accuracy

average acquisition mode

Volts/div setting

1mV/divto50mV/div

50.5 m V/div to 99.5 mV/div

100 mV/div to 500 mV/div

505 mV/div to 995 mV/div

1 V/div to 5 V/div

5.05 V/div to 10 V/div

For 50  path, 1 V/div is the maximum vertical setting. The input signal cannot exceed Max Input Voltage for the 50  input path. Refer to the Max Input

Voltage speciﬁcation for more information.

Both the position and the constant offset term must be converted to volts by multiplying by the appropriate volts/div setting.

2 to 512 waveforms Default of 16 waveforms

Measurement type

Average of  16 waveforms ±[DC Gain Accuracy × | reading – (offset -

Delta Volts between any two averages of 16 waveforms acquired with the same oscilloscope setup and ambient conditions

Offset, position, and the constant offset term must be converted to volts by multiplying by the appropriate volts/div setting.

The basic accuracy speciﬁcation applies directly to any sample and to the following measurements: High, Low, Max, Min, Mean, Cycle Mean, RMS, and Cycle RMS. The delta volt accuracy speciﬁcation applies to subtractive calculations involving two of these measurements.

The delta volts (difference voltage) accuracy speciﬁcation applies directly to the following measurements: Positive Overshoot, Negative Overshoot, Pk-Pk, and Amplitude.

Offset range

1M input 50  input

±1 V ±1 V

±0.5 V ±0.5 V

±10V ±10V

±5 V ±5 V

±100 V ±5 V

±50 V Not applicable

DC Accuracy (in Volts)

position) | + offset accuracy + 0.1 division ]

Refer to DC Gain Accuracy for temperature derating information.

±[DC gain accuracy × | reading | + 0.05 div]

Refer to DC Gain Accuracy for temperature derating information.

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 3

Speciﬁcations

Table 1: Analog signal acquisition system speciﬁcations (cont.)

Characteristic Description

DC voltage measurement accuracy

Sample acquisition mode, typical

Measurement type

Any sample

Delta v olts between any two samples acquired with the same oscilloscope setup and ambient conditions

Offset, position, and the constant offset term must be converted to volts by multiplying by the appropriate volts/div setting.

DC Accuracy (in volts)

±[DC gain accuracy × | reading – (offset – position) | + Offset Accuracy + 0.15 div + 0.6 mV]

Refer to DC Gain Accuracy for temperature derating information.

±[DC gain accuracy × | reading | + 0.15 div +

1.2 mV]

Refer to DC Gain Accuracy for temperature derating information.

4 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Table 1: Analog signal acquisition system speciﬁcations (cont.)

Characteristic Description

Analog bandwidth selections

Analog bandwidth, DC coupled

Lower frequency limit, AC coupled, typical

Upper frequency limit, 250 MHz bandwidth limited, typical

Upper frequency limit, 20 MHz bandwidth limited, typical

MDO4104C, MDO4054C, MDO4034C: 20 MHz, 250 MHz, and Full

MDO4024C: 20 MHz and Full

These limits are for ambient temperature of 30°C and the bandwidth selection set to FULL. Reduce the upper bandwidth frequency by 1% for each °C above 30°C

Volts/Div setting

50 Ω

1MΩ, typical

< 10 Hz when AC, 1 M coupled

The AC coupled lower frequency limits are reduced by a factor of 10 when 10X passive probes are used.

250 MHz, ±20%, all models except MDO4024C

20 MHz, ±20%

MDO4104C

MDO4054C

MDO4024C

MDO4104C

MDO4054C (without option SA3 or SA6)

MDO4054C (option SA3 or SA6)

MDO4024C

5 mV/div — 1 V/div DC to 1.00 GHz

2 mV /div — 4.98 mV/div DC to 350 MHz

1 mV /div — 1.99 mV/div DC to 175 MHz

5 mV/div — 1 V/div DC to 500 MHz

2 mV /div — 4.98 mV/div DC to 350 MHz

1 mV /div — 1.99 mV/div DC to 175 MHz

2 mV/div — 1 V/div DC to 350 MHzMDO4034C

1 mV /div — 1.99 mV/div DC to 175 MHz

2 mV/div — 1 V/div DC to 200 MHz

1 mV /div — 1.99 mV/div DC to 175 MHz

5 m V/div — 10 V/div DC to 500 MHz

2 mV /div — 4.98 mV/div DC to 350 MHz

1 mV /div — 1.99 mV/div DC to 175 MHz

5 m V/div — 10 V/div DC to 500 MHz

2 mV /div — 4.98 mV/div DC to 350 MHz

1 mV /div — 1.99 mV/div DC to 175 MHz

5 m V/div — 10 V/div DC to 380 MHz

2 mV /div — 4.98 mV/div DC to 350 MHz

1 mV /div — 1.99 mV/div DC to 175 MHz

2 m V/div — 10 V/div DC to 350 MHzMDO4034C

1 mV /div — 1.99 mV/div DC to 175 MHz

2 m V/div — 10 V/div DC to 200 MHz

1 m V/div — 1.99 V/div DC to 175 MHz

Speciﬁcations

Bandwidth

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 5

Speciﬁcations

Table 1: Analog signal acquisition system speciﬁcations (cont.)

Calculated rise time at 0.350/BW = t

typical

Peak Detect or Envelope mode pulse response, typical

The formula is calculated by measuring the –3 dB bandwidth of the oscilloscope. The formula accounts for the rise time contribution of the oscilloscope independent of the rise time of the signal source.

Model

50  1mV/divto

1.99 mV/div

MDO4104C

MDO4054C

MDO4034C

MDO4024C

2ns 1ns 350 ps

2ns 1ns 700 ps

2ns 1ns 1ns

2ns 1.75 ns 1.75 ns

Model TPP1000 probe

10 mV/div to

19.9 m V/div

MDO4104C

MDO4054C

MDO4034C

MDO4024C

2ns 1ns 350 ps

2ns 1ns 700 ps

2ns 1ns 1ns

2ns 1.75 ns 1.75 ns

Model TPP0500 probe

10 mV/div to

19.9 m V/div

MDO4104C

MDO4054C

MDO4034C

MDO4024C

2ns 1ns 700 ps

2ns 1ns 1ns

2ns 1.75 ns 1.75 ns

50  2mV/divto

4.98 mV/div

TPP1000 probe 20 mV/div to

49.8 mV/div

TPP0500 probe 20 mV/div to

49.8 mV/div

50  5 mV/div to 1 V/div

TPP1000 probe 50 mV/div to 10 V/div

TPP0500 probe 50 mV/div to 10 V/div

Model Minimum pulse width

MDO4104C (option SA3 or SA6 and 2 channels

>800 ps (5 GS/s)

enabled)

MDO4104C without options SA3 or SA6

MDO4104C (option SA3 or SA6 and 3 channels

>1.6 ns (2.5 GS/s) enabled), MDO4054C, MDO4034C, MDO4024C

6 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Table 1: Analog signal acquisition system speciﬁcations (cont.)

Speciﬁcations

Random Noise

Delay between channels, full bandwidth, typical

Deskew range

Crosstalk (channel isolation), typical

TekVPI Interface The probe interface allows installing, powering, compensating, and controlling a wide range of probes

Total probe power

Probe power per channel

Vertical scale setting

1mV/div

100 mV/div

1V/div

Vertical scale setting

1 mV 0.14 0.21 0.21

2 mV 0.20 0.29 0.29

5 mV 0.38 0.53 0.53

10 mV 0.68 0.93 0.93

20 mV 1.28 1.73 1.73

50 mV 3.08 4.13 4.13

100 mV 6.08 8.13 8.13

200 mV 12.08 16.13 16.13

500 mV 30.08 40.13 40.13

1 V 60.08 80.13 80.13

100 ps between any two analog channels with input impedance set to 50 , DC coupling, with equal volts/division setting or above 10 mV/div

All settings in the instrument can be manually time aligned using the Probe Deskew function from –125 ns to +125 ns with a resolution of 20 ps

This speciﬁcation does not pertain to the RF channel. For RF channel delay, see the RF Input Speciﬁcations.

–125 ns to +125 ns with a resolution of 20 ps

100:1 at 100 MHz and 30:1 at >100 MHz up to the rated bandwidth for any two channels having equal Volts/Div settings

offering a variety of features.

The interface is available on all front panel inputs. (RF channel requires TPA-N-VPI adapter.)

Five Tektronix VPI-compliant probe interfaces (one per channel). (RF channel requires TPA-N-VPI adapter.)

50 W maximum internal probe power (total for all 5 VPI ports)

Voltage Max Amperage Voltage Tolerance

12 V

50 ,RMS,typical

MDO4104C (all conﬁgurations)

 0.093 mV  0.084 mV  0.163 mV

 3.31 mV  2.37 mV  2.01 mV

 24.27 mV  20.62 mV  20.51 mV

50 ,FullBW(mV)

MDO4104C MDO40X4C (with

60 mA (300 mW) ±10%

2 A (24 W) ±10%

MDO4054C, MDO4034C, MDO4024C (with option SA3 or SA6)

option SA3 or SA6)

MDO4054C, MDO4034C, MDO4024C (without option SA3 or SA6)

MDO40X4C (without RF)

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 7

Speciﬁcations

Time Base Syst

em Speciﬁcations

The following table shows the horizontal and acquisition system speciﬁcations for the MDO4000C Series oscilloscopes.

Table 2: Tim

Characteristic Description

Sample-rate range

Record L

Seconds

Maximum triggered acquisition rate

Aperture Uncertainty

e base system speciﬁcations

MDO4104C (no SA3 or SA6) 2.5 S/s – 5 GS/s (1 – 4 analog channels enabled)

MDO4104C (options SA3 or SA6)

MDO4054C MDO4034C MDO4024C

ength Range

/Division range

20 M, 10 M

Instrument 1 k 10 k 100 k – 20 M

MDO4104C (option SA3 or SA6, 2 c MDO4104C (no SA3 or SA6, all channels enabled)

MDO4104C (option SA3 or SA6, 

MDO4054C

MDO4034C

MDO4

Bandwidth FastAcq

1GH

Bandwidth

200 MHz

350 MHz

1GHz

, 1 M, 100 k, 10 k, 1 k

hannels enabled)

3 channels enabled)

024C

GHz

00 MHz

2.5 S/s – 5 GS/s (1 – 2 analog channels enabled)

2.5 S/s – 2.5 GS/s (3 – 4 analog channels enabled)

2.5 S/s – 2.5 GS/s

400 ps – 40 s 400 ps – 400 s 400 ps – 1 ,000 s

1 ns – 40 s 1 ns – 400 s 1 ns – 1,000 s

1 and 2 channels 3 and 4 channels

FastAcq

>270,000

wfm

>270,000

m/s

>340,000

wfm

>270,000

m/s

DPO

,000 wfm/s

>80

0,000 wfm/s

erture Uncertainty Max. (record length of 100,000)

7ps

5ps

3ps

DPO

,000 wfm/s

>50

0,000 wfm/s

8 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Table 2: Time base system speciﬁcations (cont.)

Characteristic Description

Reference frequency error (cumulative)

Model Description

Instruments with option SA3 or SA6

Instruments without option SA3 or S

Reference frequency calibration accuracy

Cumulative error

Temperature stability

Crystal aging

Factory tolerance

Temperature stability

Crystal aging ±1.0PPM/Year

±0.5 × 1 0-6for options SA3 or SA6 when operated within 23 °C ± 5 °C, after 30 minute warm-up

1.5 ppm for m 30 minute warm-up

Accuracy at time of factory calibration. Recommended accuracy at beginning of calibration interval.

Speciﬁcations

Spec CRI

±1.6 x 10

±25 x 10 total from 0°Cto +50 °C

Aging Per Year: ±1.0 x 10

±1.5PPM

±2.5PPM Tested at oper

odels without options SA3 or SA6, when operated within 23 °C ± 5 °C, after

–6

Includes allowanc

es for Aging per Year, Reference Frequency Calibration Accuracy, and Temperature Stabi

lity

Valid over the recommended 1 year calibration interval, from 0 °C to + 50 °C.

-9

–6

At Calibratio

n, 25 °C ambient, over

any ≥1 m s interval.

ating temperatures.

Frequency to

lerance change at 25

°C over a period of 1 year

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 9

Speciﬁcations

Table 2: Time base system speciﬁcations (cont.)

Characteristic Description

Delta-time measurement accuracy

The formula to calculate the delta-time measurement accuracy (DTA) for a given instrument setting and input signal is given in the following table. (See Table 3.) The formula assumes insigniﬁcant signal content above Nyquist and insigniﬁcant error due to aliasing. The abbreviations used in the formula are as follows:

= slew rate around 1st point in measurement (1stedge)

= slew rate around 2nd point in measurement (2ndedge)

N = input-referred noise (V speciﬁcations.)

TBA = time base accuracy (±1.6x 10 models without option SA3 or SA6)(RefertoReference Frequency Error (Cumulative) speciﬁcations.)

= delta-time measurement duration (sec)

RD = (record length)/(sample rate)

= 1/(sample rate)

assume edge shape that results from Gaussian ﬁlter response

The term under the squareroot sign is the stability and is due to TIE (Time Interval Error). The errors due to this term occur throughout a single-shot measurement. The second term is due to both the absolute center-frequency accuracy and the center-frequency stability of the time base and varies between multiple single-shot measurements over the observation interval (the amount of time from the ﬁrst single-shot measurement to the ﬁnal single-shot measurement).

)(RefertoRandom Noise and Sample Acquisition Mode

RMS

-6

for models with option SA3 or S A6, ±5.0 x 10-6for

Table 3: Delta-time measurement accuracy formula

erms used in these formulas are deﬁned under Delta-time measurement accuracy, in the preceding table. (See Table 2.)

The t

10 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Speciﬁcations

Triggering Sy

stem Speciﬁcations

The following table shows the trigger speciﬁcations for analog and digital channels on the MDO4000C Series oscilloscopes. These speciﬁcations do not applytotheR

NOTE. For RF, see the RF input speciﬁcations. (See page 18.)

Table 4: Tr

Characteristic Description

AUX IN (external) trigger

Trigge

ger bandwidth, Pulse and Logic,

Trig typical

Edge-type trigger sensitivity, DC coupled, typical

Trigger jitter, typical

igger speciﬁcations

r bandwidth, Edge, typical

Input imp

Maximum i

Bandwid

MDO4104C 1 GHz

MDO4054C

MDO4034C

MDO4024C

MDO4104C 1 GHz

MDO4054C

MDO4034C

MDO4024C

Trigger Source Sensitivity

Aux In (External) (Not available for MDO4XX4C on products with option SA3 or SA6)

Line Fixed

10 ps 100 ps

edance

ny input channel

RMS

F input channel.

1MΩ ±1% in parallel with 13 pF ± 2 pF.

nput voltage

for edge-type trigger

for non edge-type trigger modes

The maximum input voltage at the BNC, 300 V RMS. Installation Category II (CAT II). Derate a 30 MHz, 10 dB/decade above 30 MHz.

250 MHz ±20%

500 MH

350 MH

200 M

MHz

500

MHz

350

0MHz

t 20 dB/decade above 3 MHz to 30 V RMS at

1mV/divto4.98mV/div:1.8div.

5 mV/div to 9.98 mV/div: : 1.2 div.

10 mV/div to 19.98 mV /div: 0.6 div. ≥20 mV/div: 0.5 div.

200 mV from DC to 50 MHz, increasing to 500 mV at 250 MHz.

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 11

Speciﬁcations

Table 4: Trigger speciﬁcations (cont.)

Characteristic Description

Edge-type trigger sensitivity, not DC coupled, typical

Video-type trigger formats and ﬁeld rates

Video-type trigger sensitivity, typical

Lowest frequency for successful operation of "Set Level to 50%" function, typical

Logic-type or logic qualiﬁed trigger or events-delay sensitivities, DC coupled, typical

Pulse-type runt trigger sensitivities, typical

Pulse-type trigger width and glitch sensitivities, typical

Logic-type triggering, minimum logic or rearm time, typical

Minimum clock pulse widths for setup/hold time violation trigger, typical

Trigger Coupling Typical Sensitivity

AC Coupling 1 div for frequencies above 45 Hz.

NOISE REJ 2.5 times the DC-coupled limits

HF REJ

LF REJ

Triggers from negative sync composite video, ﬁeld 1, or ﬁeld 2 for interlaced systems, on any ﬁeld, speciﬁc line, or any line for interlaced or noninterlaced systems. Supported systems include NTSC, PAL, and SECAM.

Delayed and main trigger.

Not supported through Aux In on models with option SA3 or SA6.

Source Sensitivity

Any input channel

45 Hz

1.0 vertical division from DC to maximum bandwidth without exceeding pulse width requirements speciﬁed for logic triggering.

1.0 vertical division from DC to maximum bandwidth without exceeding the pulse width requirements speciﬁed for pulse type triggering.

1.0 division

For all vertical settings, the minimums are:

Trigger type Pulse width Re-arm time Time between channels

Logic Not applicable 2 ns 1.5 ns

Time Qualiﬁed Logic

For logic, the time between channels refers to the length of time a logic state derived from more than one channel must exist to be recognized. For events, the time is the minimum time between a main and delayed event that will be recognized if more than one channel is used.

For all vertical settings, the minimums are:

Clock active C lock inactive

User hold time + 2.5 ns 2 ns

An active pulse width is the width of the clock pulse from its active edge (as deﬁned in the Clock Edge lower-bezel menu item) to its inactive edge. An inactive pulse width is the width of the pulse from its inactive edge to its active edge.

The user hold time is the number selected by the user.

Attenuates signals below 45 Hz.

1.0 times the DC-coupled limits from DC to 50 kHz. Attenuates signals above 50 kHz

1.5 times the DC-coupled limits for frequencies above 50 kHz. Attenuates signals below 50 kHz

0.6 to 2.5 divisions of video sync tip

4 ns 2 ns 1.5 ns

12 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Table 4: Trigger speciﬁcations (cont.)

Speciﬁcations

Setup/hold violation trigger, setup and hold time ranges

Pulse type trigger, minimum pulse, rearm time, transition time

Transition time trigger, delta time range

Time range for glitch, pulse width, timeout, o r time-qualiﬁed runt triggering

Time Accuracy for pulse width or timeout triggering

B trigger after events, minimum pulse width and maximum event frequency, typical

B trigger, minimum time between arm and trigger, typical

B trigger after time, time range

B trigger after events, event range

Feature Min Max

Setup time

Hold time 1 ns 1.0 ms

Setup + Hold time

Input coupling on clock and data channels must be the same.

For Setup time, positive numbers mean a data transition before the clock.

For Hold time, positive numbers mean a data transition after the clock edge.

Setup + Hold time is the algebraic sum of the Setup Time and Hold Time that you programmed.

Pulse class Minimum

Glitch

Runt 4 ns 2 ns

Time-qualiﬁed runt

Width 4 ns

Slew rate (transition time)

For the trigger class width and the trigger class runt, the pulse width refers to the width of the pulse being measured. The rearm time refers to the time between pulses.

For the trigger class slew rate, the pulse width refers to the delta time being measured. The rearm time refers to the time it takes the signal to cross the two trigger thresholds again.

4nsto8s

Time Range Accuracy

1 ns to 500 ns

520 ns to 1 s

4 ns, 500 MHz

4ns

For trigger after time, this is the time between the end of the time period and the B trigger event.

For trigger after events, this is the time between the last A trigger event and the ﬁrst B trigger event.

4 ns to 8 seconds

1 to 4,000,000

–0.5 n s 1.0 ms

0.5 ns 2.0 ms

Minimum rearm time

pulse width

4ns

±(20% of setting + 0.5 ns)

±(0.01% of setting + 100 ns)

2 ns + 5% of glitch width setting

8.5 ns + 5% of width setting

2 ns + 5% of width upper limit setting

8.5 ns + 5% of delta time setting

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 13

Speciﬁcations

Table 4: Trigger speciﬁcations (cont.)

Trigger level ranges

Trigger level accuracy, DC coupled, typical

Trigger holdoff range

Maximum serial trigger bits 128 bits

Optional serial bus interface triggering

I2C Address Triggering: 7 and 10 bit user speciﬁed addresses, as well as G eneral Call, START

SPI Data Trigger: 1 to 16 bytes of user-speciﬁed data

CAN Data Trigger: 1 to 8 bytes of user-speciﬁed data, including qualiﬁers of equal to (=), not equal

LIN

Source

Any input channel

Aux In for instruments without option SA3 or SA6

Line Not applicable

Line trigger level is ﬁxed at about 50% of the line voltage.

This speciﬁcation applies to logic and pulse thresholds.

For signals having rise and fall times 10 ns.

Source

Any input channel ±0.20 div

Aux In for instruments without option SA3 or SA6

Line Not applicable

20 ns minimum to 8 s maximum

byte, HS-mode, EEPROM, and CBUS

Data Trigger: 1 to 5 bytes of user speciﬁed data

Trigger On: Start, Repeated Start, Stop, Missing Ack, Address, Data, or Address and Data

Maximum Data Rate: 10 Mbps

Trigger On: SS Active, MOSI, MISO, or MOSI & MISO

Maximum Data Rate: 50 Mbps

to (<>), less than (<), greater than (>), less than or equal to (<=), greater than or equal to (>=)

Trigger On: Start of Frame, Type of Frame, Identiﬁer, Data, Identiﬁer and Data, End of Frame, Missing Ack, or Bit Stufﬁng Errors

Frame Type: Data, Remote, Error, Overload

Identiﬁer: Standard (11 bit) and Extended (29 bit) identiﬁers

Maximum Data Rate: 1 Mbps

Identiﬁer Trigger: 6bitsofuser-speciﬁed data, equal to (=)

Data Trigger: 1 to 8 bytes of user-speciﬁed data, including qualiﬁers of equal to (=), not

equal to (<>), less than (<), greater than (>), less than or equal to (<=), greater than or equal to (>=), inside range, or outside range

Error: Sync, Identiﬁer Parity, Checksum

Trigger On: Sync, Identiﬁer, Data, Identiﬁer & Data, Wakeup Frame, Sleep Frame, or Error

Maximum Data Rate: 100 kbps

Range

±8 divisions from center of screen

±8 divisions from 0 V when vertical LF reject trigger coupling is selected

±8V

Range

± (10% of setting + 25mV)

14 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Table 4: Trigger speciﬁcations (cont.)

Speciﬁcations

FlexRay

Audio

I2S Data Trigger: 32 bits of user-speciﬁed data in a left word, right word, or either, including

Left Justiﬁed Da ta Trigger: 32 bits of user-speciﬁed data in a left word, right word, or either, including

Right Justiﬁed Data Trigger: 32 bits of user-speciﬁed data in a left word, right word, or either, including

TDM

RS-232

Indicator bits: Normal Frame, Payload Frame, Null Frame, Sync Frame, Startup Frame

Identiﬁer Trigger: 11 bits of user-speciﬁed data, equal to (=), not equal to (<>), less than (<),

greater than (>), less than or equal to (<=), greater than or equal to (>=), Inside Range, or Outside Range

Cycle Count Trigger: 6 bits of user-speciﬁed data, equal to (=)

Header Fields Trigger:40bitsofuser-speciﬁed data comprising Indicator Bits, Identiﬁer,

Payload Length, Header CRC, Cycle Count, equal to (=)

Data Trigger: 1 to 16 Bytes of user-speciﬁed data, with 0 to 253, or "don't care" bytes of data offset, including qualiﬁers of equal to (=), not equal to <>, less than (<), greater than (>), less than or equal to (<=), greater than or equal to (>=), Inside Range, Outside Range

End Of Frame: User-chosen types Static, Dynamic (DTS), and All

Error: Header CRC, Trailer CRC, Null Frame-static, Null Frame-dynamic, Sync Frame,

Startup Frame

Trigger On: Start of Frame, Type of Frame, Indicator Bits, Identiﬁer, Cycle Count, Header Fields, Data, Identiﬁer & Data, End of Frame, or Error

Maximum Data Rate: 100 Mbps

qualiﬁers of equal to (=), not equal to <>, less than (<), greater than (>), less than or equal to (<=), greater than or equal to (>=), inside range, outside range

Trigger on: Word Select, Data

Maximum Data Rate: 12.5 Mbps

qualiﬁers of equal to (=), not equal to <>, less than (<), greater than (>), less than or equal to (<=), greater than or equal to (>=), inside range, outside range

Trigger on: Word Select, Data

Maximum Data Rate: 12.5 Mbps

qualiﬁers of equal to (=), not equal to <>, less than (<), greater than (>), less than or equal to (<=), greater than or equal to (>=), inside range, outside range

Trigger on: Word Select, Data

Maximum Data Rate: 12.5 Mbps

Data Trigger: 32 bits of user-speciﬁed data in a channel 0-7, including qualiﬁers of equal to

(=), not equal to <>, less than (<), greater than (>), less than or equal to (<=), greater than or equal to (>=), inside range, outside range

Trigger on: Frame Sync, Data

Maximum Data Rate: 25 Mbps

Bit Rate: 50 bps to 10 Mbps

Data Bits: 7, 8, or 9

Parity: None, Odd, or Even

Trigger on: Tx Start bit, Rx Start bit, Tx End of Packet, Rx End of Packet, Tx Data, Rx

Data,TxParityError,RxParityError

End of Packet: 00 (NUL), OA (LF), OD (CR), 20 (SP), FF

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 15

Speciﬁcations

Table 4: Trigger speciﬁcations (cont.)

MIL-STD-1553 Bit Rate: 1Mb/s

Trigger on: Sync, Word Type (Command, Status, Data), Command Word (set RT Address

(=, ,<,>,, , inside range, outside range), T/R, Sub-address/Mode, Data Word Count/Mode Code, and Parity individually), Status Word (set RT Address ((=, ,<,>,, , inside range, outside range), Message Error, Instrumentation, Service Request Bit, Broadcast Command Received, Busy, Subsystem Flag, Dynamic Bus Control Acceptance (DBCA), Terminal Flag, and Parity individually) Data Word (user-speciﬁed 16-bit data value) Error (Sync, Parity, Manchester, Non-contiguous data) Idle Time (minimum time selectable from 4 s to 100 s; maximum time selectable from 12 s to 100 s; trigger on < minimum, > maximum, inside range, outside range)

Trigger selection of Command Word will trigger on Command and ambiguous Command/Status words. Trigger selection of Status Word will trigger on Status and ambiguous Command/Status words.

USB Data Rates Supported: HS: 480 Mbps, Full: 12 Mbps, Low: 1.5 Mbps

Trigger On: Sync, Reset, Suspend, Resume, End of Packet, Token (Address) Packet, Data Packet, Handshake Packet, Special Packet, Error

Ethernet

NOTE.

Bit R ate: 10BASE-T, 10 Mbps; 100BASE-TX, 100 Mbps

Trigger On: Start Frame Delimiter (SFD), MAC Address, MAC Length/Type, IP Header, TCP

Header, TCP/IPv4/MAC Client Data, End of P acket, Idle, FCS (CRC) Error, MAC Q-Tag Control Information.

HIGH SPEED support available only on the MDO4104C oscilloscope.

Digital Acquisition System Speciﬁcations

The following table shows the digital acquisition speciﬁcations for the MDO4000C Series oscilloscopes.

Table 5: Digital acquisition speciﬁcations

Characteristic Description

Threshold voltage range –40 V to +40 V

Digital channel timing resolution

Logic threshold accuracy

Minimum detectable pulse width, typical

2 ns main memory, 60.6 ps for MagniVu memory

±(100 mV + 3% of threshold setting after calibration)

Requires valid SPC, as described in step 2 of the Self Test. (See page 85, Self Test.)

1ns

Using MagniVu memory. Requires the use of 342-1140-00 ground clip on each channel.

16 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Speciﬁcations

P6616 Digital

Probe Input Speciﬁcations

The following table shows the P6616 Digital Probe speciﬁcations.

Table 6: P6616 digital probe input speciﬁcations

Characteristic Description

Number of channels

Input resistance, typical

Input capacitance, typical 3.0 pF

Minimum input signal swing, typical 400 mV

Maximum input signal swing, typical

Maximum Input Toggle Rate, typical 500 MHz

Absolute maximum input voltage, typical

Channel-to-channel skew, typical

16 digital inputs

100 k to ground

Measured at the podlet input. Requires the use of 342-1140-00 ground clip on each channel

p-p

Requires the use of 342-1140-00 ground clip on each channel

30 V

for fin 200 MHz (centered around the DC threshold voltage) at the P6616

p-p

probe tip.

10 V

for fin>200 MHz (centered around the DC threshold voltage) at the P6616

p-p

probe tip.

Failure to meet this input signal requirement will compromise the AC performance of the digital channel. It might also damage the input circuitry. See the Absolute maximum input voltage speciﬁcation.

Maximum frequency sine wave input (at the minimum signal swing amplitude) that can accurately be reproduced as a logic square wave.

Requires the use of a 342-1140-00 ground clip on each channel.

Higher toggle rates can be achieved with higher amplitudes.

±42 V peak at the P6616 input (not at the instrument input)

Probe input voltages beyond this limit could permanently damage the instrument and the P6616 probe.

200 ps

Digital c hannel to digital channel only.

This is the propagation path skew and ignores skew contributions due to threshold inaccuracies (see Threshold accuracy) and sample binning (see Digital channel timing resolution). Factory calibration/deskew is required to achieve this number.

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 17

Speciﬁcations

RF Input Speci

ﬁcations

The following table shows the RF input speciﬁcations for the MDO4000C Series oscilloscopes with option SA3 or SA6.

Table 7: RF i

Characteristic Description

Frequency

Span MDO4XX4C

Resolut

Input

Level

Ref

nput speciﬁcations

measurement resolution

ion bandwidth (RBW) range

vertical range

display range

erence level

rtical position

ximum operating input level

MDO4XXXC option SA6 9 kHz to 6 GHzCenter frequency range

MDO4XXXC option SA3 9 kHz to 3 GHz

1Hz

MDO4XX4C option SA3 Span: 1 kHz to 3 GHz

Span adjustable in 1-2-5 sequence

Variabl

Adjustable in 1-2-3-5 sequence.

RBW ran

Kaiser, Blackman-Harris RBW shape factor: 60 dB / 3 dB shape factor:  4:1 ratio

Verti

Vertical setting of 1 dB/div to 20 dB/div in a 1-2-5 sequence

Log sc

Measurement points: 1000

Marker level readout resolution: Log scale: 0.1 dB

Maxi

Trace functions: maximum hold, average, minimum hold, normal, spectrogram slice

(uses normal trace)

Det

Set

Default setting: 0dBm

–100 divisions to +100 divisions (displayed in dB)

Average continuous power: +30 dBm (1 W) for reference levels  -20 dBm

Average continuous power: +24 dBm (0.25 W) for reference levels < -20 dBm

D Maximum “no damage”: 32 dBm (1.6 W) CW for reference levels  -20 dBm

25 dBm (0.32 W) for reference levels of < -20 dBm

Peak pulse power: +45dBm(32W)

Peak Pulse Power is deﬁned as: <10 us pulse width, <1% duty cycle, and a reference level of  +10 dBm.

option SA6 S pan: 1 kHz to 6 GHz

e resolution = 1% of the next span setting

ges for the Windowing functions are as follows:

Kaiser (default), Blackman-Harris: 20 Hz – 200 MHz

Rectangular, Hamming, Hanning: 10 Hz – 200 MHz

op: 30 Hz – 200 MHz

Flat-T

cal measurement range +30 dBm to DANL.

ale and units: dBm, dBmV, dBµV, dBµW, dBmA, dBµA

mum number of RF traces: 4

ection methods: positive-peak, negative-peak, sample, average

ting range: –140 dBm to +30 dBm, in steps of 1 dB

C maximum before damage: ±40 V

18 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Table 7: RF input speciﬁcations (cont.)

Characteristic Description

Marker frequency measurement accuracy

Phase noise at 1 GHz 1 kHz: (< -104 dBc/Hz, typical)

Displayed average noise level (DANL)

Absolute amplitude accuracy

±((Reference Frequency Error x MarkerFrequency) + (0.001 x s pan + 2)) Hz Marker Frequency with Span/RBW  1000:1

Reference Frequency Error with Marker level to displayed noise level > 30 dB

10 kHz offset: < –108 dBc/Hz (< –111 dBc/Hz, typical)

100 k Hz offset: < –110 dBc/Hz (< –113 dBc/Hz, typical)

1 M Hz offset: < –120 dBc/Hz (< –123 dBc/Hz, typical)

Max RBW % Error = (0.5/(25 x WF)) * 100Resolution bandwidth (RBW) accuracy

WF =

Rectangular: 0.89

Hamming: 1.30

Hanning: 1.44

Blackman-Harris: 1.90

Kaiser: 2.23

Flat-Top: 3.77

Frequency range DANL

9kHz–50kHz

50kHz–5MHz

5MHz–400MHz

400 MHz – 3 GHz < –147 dBm/Hz (< –150 dBm/Hz, typical)

3 GHz – 4 GHz (MDO4XX4C option SA6 models only)

4 GHz – 6 GHz (MDO4XX4C option SA6 models only)

< ±1.0 dB, (< ±0.5 dB, typical), 18 ⁰C–28⁰C temperature range, 50 kHz to 6 GHz frequency range, reference levels –25, -20, –15, –10, –5, 0, 5, 10 dBm.

< ±1.0 dB, typical, 50 kHz to 6 GHz, all other reference levels, 18 ⁰C–28⁰C temperature range:

< ±1.5 dB, typical, 50 kHz to 6 GHz, all reference levels, 0 ⁰Cto50⁰C temperature range

< ± 2.0 dB, typical, 9 kHz to 50 kHz, all reference levels, 18 ⁰Cto28⁰C temperature range

< ±3.0 dB, typical, 9 kHz to 50 kHz, all reference levels, 0 ⁰Cto50⁰C temperature range

Speciﬁcation applies to signal to noise ratios > 40 dB.

Accuracy of power level measurements at the center frequency. At frequencies away from center frequency, add Channel Response to the Absolute Amplitude Accuracy.

Speciﬁcations

< –116 dBm/Hz (< –123 dBm/Hz, typical)

< –130 dBm/Hz (< –141 dBm/Hz, typical)

< –146 dBm/Hz (< –150 dBm/Hz, typical)

< –148 dBm/Hz (< –151 dBm/Hz, typical)

< –140 dBm/Hzz (< –145 dBm/Hz, typical)

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 19

Speciﬁcations

Table 7: RF input speciﬁcations (cont.)

Characteristic Description

Channel response, typical

Measurement center frequency range

15 MHz – 6GHz

60 MHz – 6GHz

170 MHz – 6GHz

510 MHz – 6GHz

Any, (for Start Frequency > 10 MHz)

Valid over 18 ⁰C–28⁰C temperature range

Speciﬁcation applies to signal to noise ratios >40 dB.

Span

10 MHz 0.3 dB 0.15 dB

100 M Hz 0.75 dB 0.27 dB

320 M Hz 0.85 dB 0.27 dB

1000 MHz 1.0 dB 0.3 dB

>1000 MHz 1.2 dB

Amplitude ﬂatness, pk-pk, typical

Amplitude ﬂatness, RMS, typical

N/A N/A

Phase linearity, RMS, typical

1.5°

2.5°

3.0°

20 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Table 7: RF input speciﬁcations (cont.)

Characteristic Description

Spurious response

Residual spurious response

2nd and 3rd harmonic distortion >100 MHz: < –60 dBc (< –65 dBc typical)

with auto settings on and signals 10 dB below reference level

2nd and 3rd harmonic distortion: 9 k Hz to 100 MHz: < –57 dBc (< –60 dBc typical) with auto settings on, signals 10 dB below reference level, and reference l evel 

–15 dBm

2nd order intermodulation distortion: >200 MHz: < –60 dBc (< –65 dBc typical)

with auto settings on and signals 10 dB below reference level

2nd order intermodulation distortion: > 100 MHz to ≤ 200 MHz: < –57 dBc (< –60 dBc, typical)

with auto settings on, signals 10 dB below reference level, and reference l evel  –15 dBm

2nd order intermodulation distortion: 10 MHz to 100 MHz: < –60 dBc (< –65 dBc, typical)

with auto settings on, signals 10 dB below reference level, and reference l evel  –15 dBm

< –62 dBc, (<–65 dBc, typical),

with a

3rd order interm od ulation distortio n: 9 kHz to 10 MHz

< –55

for reference levels < –15 dBm, with auto settings on and signals 10 dB below reference level

A/D spurs

<–6

with auto settings on, signals 5 dB below reference level. Excludes A/D aliasing spurs

A/D aliasing spurs:

at (5 GHz – F

IF Rejection (All input frequencies except: 1.00 GHz to 1.25 GHz and 2 GHz to

2.4 GHz): (< –55 dBc, typical)

I –50 dBc, typical)

IF spurs at (6.5 GHz –F typical)

Image Rejection: < –50 dBc (for input frequencies from 5.5 GHz to 9.5 GHz)

< –85 dBm at all points except 2.5 GHz, 3.75 GHz, 4.0 GHz, 5.0 GHz, and 6.0 GHz

< –78 dBm at 3.75 GHz, 4.0 GHz, and 5.0 GHz (6.0 GHz is typically < –78 dBm)

< –73 dBm at 2.5 GHz  –25 dBm reference level and RF input terminated with 50 

3rd order intermodulation distortion: > 10 MHz

uto settings on and signals 10 dB below reference level

dBc (<–60 dBc, typical),

0 dBc (< –65 dBc typical)

) and at (8 GHz - Fin): < –55 dBc (< –60 dBc, typical)

th auto settings on and signals 5 dB below reference level

peciﬁcations that apply only to MDO4XX4C option SA6 models

F spurs at (5.0 GHz – F

) for input frequencies from 1.00 GHz to 1.25 GHz: (<

) for input frequencies from 2.0 GHz to 2.4 GHz: (< –50 dBc,

Speciﬁcations

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 21

Speciﬁcations

Table 7: RF input speciﬁcations (cont.)

Characteristic Description

RF input level trigger frequency and amplitude range

Power level trigger minimum pulse duration

RF to analog channel skew, typical

Crosstalk to RF channel from analog channels

Occupied bandwidth accuracy, typical ± Span/1000

Adjacent channel power ratio, typical

Frequency range:

Amplitude range:

Minimum pulse duration: 10 s ON time with a minimum settling OFF time of 10 s.

<5ns

< –68 dB from reference level (1 GHz oscilloscope input frequencies)

< –48 dB from reference level (>1 GHz to 2 GHz oscilloscope input frequencies)

Full scale amplitude with 50  input and 100 mV/div vertical setting with direct input (no probes).

W–CDMA: –57 dBc

W–CDMA with test model 1, Reference level 30 dBm to –10 dBm, with signal level at 1 dB below A/D overrange.

1 MHz to 3 GHz (MDO4XX4C option SA3 models)

1 MHz to 3.75 GHz (MDO4XX4C option SA6 models)

2.75 GHz to 4.5 GHz (MDO4XX4C option SA6 models)

3.5 GHz to 6.0 GHz (MDO4XX4C option SA6 models)

RF Level Trigger Amplitude Operating Level: 0 dB to –30 dB from Reference Level

RF Level Trigger Amplitude Adjustment Range: +10 dB to –40 dB from Reference Level and within the range of –65 dBm to +30 dBm

Arbitrary Function Generator Characteristics

Table 8: AFG Characteristics

Characteristic Description

Sine waveform

Frequency range: 0.1 Hz to 50 MHz

Frequency setting resolution: 0.1 Hz

Amplitude ﬂatness (typical):

±0.5 dB at 1 kHz

±1.5 dB for <20 mVpp amplitudes

Total harmonic distortion (typical): 1% at 50 

Spurious free dynamic range (typical): –40 dB (Vpp  0.1 V); 30 dB (Vpp <0.1 V), 50  load

22 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Table 8: AFG Characteristics (cont.)

Characteristic Description

Square/pulse waveform

Ramp/Triangle waveform

Random noise waveform Amplitude range: 20 mVppto 5 Vppin to Hi-Z; 10 mVppto 2.5 Vpp into 50 

Sine and ramp frequency accuracy 130 ppm (frequency 10 kHz); 50 ppm (frequency > 10 kHz)

Square and pulse frequency accuracy

Signal amplitude resolution 500 V(50)

Signal amplitude accuracy +/-[ (1.5% of peak-to-peak amplitude setting) + (1.5% of absolute DC offset setting) +

DC offset range

DC offset resolution 500 V(50)

DC offset accuracy ±[ (1.5% of offset setting) + 1 mV ]

Frequency range: 0.1 Hz to 25 MHz

Frequency setting resolution: 0.1 Hz

Duty cycle range: 10% - 90% or 10 ns minimum pulse, whichever is larger

Duty cycle resolution: 0.1%

Minimum pulse width (typical): 10 ns

Rise/fall time (typical): 5 ns, 10% to 90%

Pulse width resolution: 100 ps

Overshoot (typical): <9% for signal steps greater than 100 mV

Asymmetry (typical): ±1% ±5 ns, a t 50% duty cycle

Frequency range: 0.1 Hz to 500 kHz

Frequency setting resolution: 0.1 Hz

Variable symmetry: 0% to 100%

Symmetry resolution: 0.1%

DC level range (typical): ±2.5 V in to Hi-Z; ±1.25 V into 50 

Gaussian Pulse, Lorentz Pulse, Haversine Maximum Frequency (typical): 5 MHz

Exponential rise/fall maximum frequency (typical): 5 MHz

Sine(x)/x maximum frequency (typical): 2 MHz

130 ppm (frequency 10 kHz); 50 ppm (frequency > 10 kHz)

1mV(HiZ)

1mV ] (frequency = 1kHz)

Add 3 mV of uncertainty per 10 °C change from 25 °C ambient

±2.5 V into Hi- Z ±1.25 V into 50 

1mV(HiZ)

Add 3 mV of uncertainty per 10 °C change from 25 °C ambient

Speciﬁcations

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 23

Speciﬁcations

Digital Voltm

eter/Counter

Table 9: Digital Voltmeter/Counter

Characteris

Measurement types

Voltage resolution 4 digits

Voltage accuracy

Frequency resolution 5 digits

Frequency accuracy

Frequency counter source Any analog input channel

Frequency counter maximum input frequency

tic

Description

AC+DC

DC voltage: ±(1.5% |reading - offset - position|) + (0.5% |(offset - position)|) + (0.1 * Volts/div

De-rated at 0.100% / °C of |reading - offset - position| above 30 °C

DC example: an input channel set up with -2 V offset and 1 V/div measuring a -5 V signal would have or 3.1% of the input voltage.

AC:±2%(40Hzto1kHz)

AC (typic

For AC measurements, the input channel vertical settings must allow the V to cover between 4 and 10 divisions and must be fully visible on the screen.

For AC me

±(10 µHz/Hz + 1 count)

The sig

150 MHz for all models

Trigg

,DC

rms

))

±(1.5% of |(-5 V - (-2 V) - 0 V)|) + (0.5% of |(-2 V - 0 V)|) + 0.1 V) = ±155 mV

al): ±2% (20 Hz to 10 kHz)

asurements, speciﬁcations are only valid for sinewaves.

nal must be at least 6 mV or 2 div, whichever is greater.

er Sensitivity limits must be observed for reliable frequency measurements.

rms

,AC

, frequency count

rms

input signal

Display System Speciﬁcations

The following table shows the display speciﬁcations for the MDO4000C Series oscilloscopes.

Table 10: Display system speciﬁcations

aracteristic

Display type

isplay resolution

uminance, typical

Waveform display color scale The TFT display can support up to 262,144 colors. A subset of these colors is used for the

scription

splay area: 210.4 mm (8.28 in) (H) x 157.8 mm (6.21 in) (V), 264 mm (10.4 in) diagonal,

Di 6-bit RGB full color, XGA (1024 x 768) TFT liquid crystal display (LCD).

1024 X 768 XGA display resolution

400 cd/m

oscilloscope display. The colors that are used are ﬁxed and not changeable by the user.

24 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Speciﬁcations

Interfaces an

d Input/Output Port Speciﬁcations

The following table shows the interfaces and input/output port speciﬁcations for the MDO4000C Series oscilloscopes.

Table 11: In

Characteristic Description

Ethernet interface Standard on all models: 10/100/1000 Mbps

GPIB interface Available as an optional accessory (TEK-USB-488 GPIB to USB Adapter), which

Video signal output

USB inte

Probe compensator output voltage and frequency, typical

Auxi

External Reference nominal input frequency

terfaces and Input/Output port speciﬁcations

connects to the USB Device and USB Host port.

The contr

A 15-pin D

rface

liary output (AUX OUT)

Trigger Out or

Reference C lock Out

4 USB hos

1 USB device connector (2.0 HS), on the instrument rear panel.

All are standard on all models.

Output Voltage

t: 0 – 2.5 V amplitude, ± 2% (Source Impedance of 1k)

Defaul TPPXX00 Cal Mode: 0 – 2.5 V amplitude, ± 5% (Source Impedance of 25)

Frequency

± 25%

1kHz,

n set the Auxiliary output to Trigger Out, Event, R eference Clock Out or AFG.

You c a

Reference Clock Out: Outputs the 10 MHz oscilloscope reference clock.

Trigger Out: A H IGH to LOW transition indicates that the trigger occurred.

t Out: A High to Low transition indicates that an event occurred.

Even

AFG: The trigger output frequency is dependent on the frequency of the AFG signal.

AFG frequency Trigger output frequency

9MHz

 4.

.9 MHz to 14.7 MHz

4.7 MHz to 24.5 MHz

24.5 MHz to 34.3 MHz

34.3 MHz to 44.1 MHz

>44.1 MHz to 50 MHz

Trigger output logic levels

Characteristic

Vout (HI)

Vout (LO) 0.7 V into a load of 4mA

10 MHz

You must select either the internal reference (default) or 10 MHz external.

ol interface is incorporated into the instrument user interface.

-sub VGA connector.

t connectors (2.0 HS), two on the instrument front and two on the rear.

Signal frequency

Signal frequency / 3

Signal frequency / 5

Signal frequency / 7

Signal frequency / 9

Signal frequency / 11

Limits

2.5 V open circuit 1.0Vintoa50 load to ground

0.25 V into a 50  load to ground

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 25

Speciﬁcations

Table 11: Interfaces and Input/Output port speciﬁcations (cont.)

Characteristic Description

External Reference input frequency variation tolerance, typical

External Reference input sensitivity, typical

External Reference input maximum input signal

External Reference input impedance, typical

 ±2 x 10-6for m odels with option SA3 or SA6.

9.9 MHz to 10.1 MHz for models without options SA3 or SA6.

You must run SPC, described in step 2 of the Self Test, whenever the external reference is more than 0.2% (2000 ppm) different than the nominal reference frequency or reference at w hich SPC was last run. The time base changes in correspondence to the ﬂuctuations in the external reference.

1.5 V

p-p

Rin=1.5k ±20% in parallel with 15 pF ±5 pF at 10 MHz

26 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Speciﬁcations

Data Handling

Speciﬁcations

The following table shows the data handling speciﬁcations for the MDO4000C Series oscilloscopes.

Table 12: Da

Characteristic Description

Nonvolatil typical

Real-time clock A programmable clock providing time in years, months, days, hours, minutes, and seconds

ta handling speciﬁcations

e memory retention time,

No time limit for front-panel settings, saved waveforms, setups, or calibration constants.

10 M and 20 M records saved as Reference waveforms are not saved in the nonvolatile memory and

they will not be saved across a power cycle.

Power Supply System Speciﬁcations

The foll MDO4000C Series oscilloscopes.

Table 13: Power supply system speciﬁcations

Characteristic Description

Operating line frequency and voltage range

Maximum power consumption, typical 250 W

Source voltage 100 V to 240 V ±10%

Source frequency (85 to 264 V) 45 Hz to 66 Hz

Fuse rating

owing table shows the power supply system speciﬁcations for the

Volts: 100 – 240; Hz: 50 – 60

Volts: 115: Hz: 400

(100 V to 132 V) 360 Hz to 440 Hz

T6.3AH, 250 VAC

fuse cannot be replaced by the user.

The

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 27

Speciﬁcations

Environmenta

lSpeciﬁcations

The following table shows the environmental speciﬁcations for the MDO4000C Series oscilloscopes.

Table 14: En

Characteristic Description

Temperatur

Humidity

Altitud

Pollution Degree Pollution Degree 2, indoor, dry location use only

vironmental speciﬁcations

Operating: 0 °C to +50 °C (32 °F to +122 °F)

Nonoperating: –30 °C to +70 °C (–22 °F to +158 °F)

Operating:

High: 40 ° Low: 0 °C to 40 °C (32 °F to 104 °F), 10% to 90% relative humidity

Nonoperating:

High: 40 ° Low: 0 °C to 40 °C (32 °F to 104 °F), 5% to 90% relative humidity

Operating: 3,000 m (9,843 ft)

Nonoperating: 12,000 m (39,370 ft)

C to 50 °C (104 °F to 122 °F), 10% to 60% relative humidity

C to 60 °C (104 °F to 140 °F), 5% to 55% relative humidity

28 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Speciﬁcations

Mechanical Sp

eciﬁcations

The following table shows the mechanical speciﬁcations for the MDO4000C Series oscilloscopes.

Table 15: Me

Characteristic Description

Weight

Dimens

Clearance Requirements 0 mm (0 in), top

chanical speciﬁcations

without option SA3 or SA

with opt or SA6

ions

ion SA3

Benchtop conﬁguration (oscilloscope only)

Requirements that follow are nominal:

11.0 lbs (5

18.8 lbs (8.5 kg), instrument with rackmount, without front cover

23.6 lbs (10.7 kg), when packaged for domestic shipment (without rackmount)

Net

Shipping

Net 5.1 11.2Instruments

Shipping

Benchtop conﬁguration (oscilloscope only)

Requirements that follow are nominal and unboxed Height

9.0 in (229 mm) feet folded in, handle folded down

9.8 in (249 mm) feet folded out, handle folded down

11. 5 i

12.3 in (312 mm) feet folded out, handled folded up

Width:

17.3

Depth:

5.8 in (147 mm) from back of feet to front of knobs

6.1 i

9.8 in (249 mm) from handle to front of knobs (handle folded to back side of unit)

Box Dimensions: Hei Width: 15.6 in (396 mm) Length: 22.2 in (564 mm)

Rac

Requirements that follow are nominal and unboxed (5U rack sizes): Height: 8.6 in ( 218 mm) Wi Depth: 15.1 in (384 mm), from outside of handle to back of slide

0 in (0 mm), bottom, on feet, with ﬂip stands down

in (50.8 mm), left side (facing the front of the instrument)

0 in (0 mm), right side (facing the front of the instrument)

2 in (50.8 mm), rear (where the power cord is plugged in)

.0 kg), stand-alone instrument, without front cover.

n (292 mm) feet folded in, handle folded up

in (439 mm) from handle hub to handle hub

n (155 mm) from back of feet to front of front cover

ght: 15.7 in (399 mm)

kmount conﬁguration

dth: 19.2 in (488 mm), from outside of handle to outside of handle

kg lb

5.5

11.2 24.8

10.8 23.8

12.2Instruments

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 29

Speciﬁcations

TPA-N-PRE Spe

ciﬁcations

The following table shows the TPA-N-PRE Preampliﬁer speciﬁcations.

Table 16: TPA-N-PRE speciﬁcations

Characteristic Description

Frequency range

Input vertical range

Preamp gain

Displayed average noise level (DANL) of the MDO4000C with the preamp attached to the MDO’s RF input

Absolute amplitude accuracy and channel response, typical

Preamp: 9 kHz to 6 GHz

MDO4XX4C option SA6 with preamp: 9 kHz to 6 G Hz

MDO4XX4C option SA3 with preamp: 9 kHz to 3 G Hz

MDO4000C with preamp attached (Amplifying state): –30 dBm to DANL

MDO4000C with preamp attached (Bypass state): +30 dBm to DANL

Gain of preamp in Amplifying state: +12 dB (nominal)

Gain of preamp in Bypass state: –1.5 dB (nominal)

This refers to the amount of gain of the preamp alone, or in other words, the amount of gain that the preamp will add to the beginning of the MDO RF input when attached.

With the preamp mode set to “Auto” and the reference level set to –40 dBm

MDO4XX4C option SA6:

9 kHz to 50 kHz: < –119 dBm/Hz (Max), (–123 dBm/Hz, typical)

50 kHz to 5 MHz: < –140 dBm/Hz (Max), (–146 dBm/Hz, typical)

5 MHz to 400 MHz: < –156 dBm/Hz (Max), (–160 dBm/Hz, typical)

400 MHz to 3 GHz: < –157 dBm/Hz (Max), (–160 dBm/Hz, typical)

3 GHz to 4 GHz: < –158 dBm/Hz (Max), (–161 dBm/Hz, typical)

4 GHz to 6 GHz: < –150 dBm/Hz (Max), (–155 dBm/Hz, typical)

MDO4XX4C option SA3:

9 kHz to 50 kHz: < –119 dBm/Hz (Max), (–125 dBm/Hz, typical)

50 kHz to 5 MHz: < –140 dBm/Hz (Max), (–146 dBm/Hz, typical)

5 MHz to 400 MHz: < –156 dBm/Hz (Max), (–160 dBm/Hz, typical)

400 MHz to 3 GHz: < –157 dBm/Hz (Max), (–160 dBm/Hz, typical)

This speciﬁcation applies to the MDO4000C series oscilloscope RF channel with the preamp attached to the RF input of the M DO .

Absolute amplitude accuracy (AAA): Accuracy of power level measurements at the center frequency.

Channel Response (CR): Accuracy of power level measurements over the whole span relative to the accuracy at the center frequency. Add AAA and CR to ﬁnd total power level measurement accuracy.

AAA:  ±1.5 dB, typical, 18 ⁰C–28⁰C temperature range, either preamp state. AAA:  ±2.3 dB, typical, over full operating range, either preamp state.

CR: 0.0 dB

Speciﬁcations exclude mismatch error at the preamp input.

Preamp mode set to “Auto”. Reference level 10 dBm to –40 dBm. Input level ranging from reference l evel to 30 dB below reference level.

30 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Characteristic Description

Maximum opera

Connector type SMA – female (outside threads)

Temperatu

Humidity

Altitud

Recommended oscilloscopes

ting input level

The maximum vo or damaging the input.

Average continuous power: +30 dBm (1 W)

DC maximum bef

Maximum power before damage: +30 dBm (1 W) CW.

Peak Pulse Power: +45 dBm (32 W)

Peak Pulse Po of  +10 dBm.

Operating: 0 °C to +50 °C

Non-operating: –20 °C to +60 °C

Operating:

High: 40 °

Low: 0 °C to 40 °C (32 °F to 104 °F), 10% to 90% RH

Non-operating:

High: 40

Low: 0 °C to 40 °C (32 °F to 104 °F), 5% to 90% RH

Operating: Up to 3,000 meters

Non-operating: Up to 12,000 meters

MDO4000C Mixed Domain Oscilloscopes

ltage that the preamp input can withstand without creating a shock hazard

ore damage: ±20 V DC

wer deﬁned as <10 us pulse width, <1% duty cycle, and reference level

C to 50 °C (104 °F to 122 °F), 10% to 60% RH

°C to 60 °C (104 °F to 140 °F), 5% to 60% RH

Speciﬁcations

NOTE.

ﬁrmware from www.tektronix.com

For best probe support, download and install the latest version of the oscilloscope

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 31

Speciﬁcations

32 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Performance Veriﬁcation

The performance veriﬁcation procedures verify the performance of your instrument. They do not adjust your instrument. If your instrument fails any of the performa adjustment performed. See the contact information on the back of the title page of this manual.

This section contains performance veriﬁcation procedures for the speciﬁcations marked with the Series models. Please ignore checks that do not apply to the speciﬁc model you are testing.

Print the test record on the following pages and use it to record the performance test results for your oscilloscope.

NOTE. Completion of the performance veriﬁcation procedure does not update the

stored updated only when the instrument is adjusted by Tektronix.

nce veriﬁcation tests, you should contact Tektronix to have a factory

time and date of the latest successful adjustment. The date and time are

symbol. These procedures cover all MDO4000C

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 33

Performance Veriﬁcation

The following e

quipment, or a suitable equivalent, is required to complete these procedures. You might need additional cables and adapters, depending on the actual test equipment you use.

Table 17: Required equipment

Description Minimum requirements Examples

DC voltage source 3 mV to 4 V, ±0.1% accuracy

Leveled sine wave generator

Time mark generator 80 ms period, ±1 x 10–6accuracy, rise

Signal generator Frequency: to at least 6 GHz

Hybrid coupler (power combiner) Connects the output of two generators to

Logic probe Low capacitance digital probe, 16

BNC-to-0.1 inch pin adapter to connect the logic probe to the signal source.

Digital multimeter (DMM) 0.1% accuracy or better

Frequency counter

Power meter

Power head

Power splitter

Male N-N adapter For connecting between the power splitter

One 50  terminator Impedance 50 ; connectors: female

One 50  terminator Impedance 50 ; Male N connector

One 50  BNC coaxial cable

One 50  SMA coaxial cable N connector to SMA

Three SMA cables With the correct connector to ﬁt your

50 kHz to 1000 MHz, ±4% amplitude accuracy

time < 50 ns

Frequency accuracy: 5 ppm

Low phase noise

the oscilloscope RF input

channels.

BNC-to-0.1 inch pin adapter; female BNC to 2x16. 01 inch pin headers.

Frequency range at least 50 kHz – 6 GHz Agilent E9304A Average Power Sensor

BNC input, male BNC output

Male-to-male connectors Tektronix part number 012-0057-01

generator output.

Fluke 9500B Oscilloscope Calibrator with a 9510 Output Module

Anritsu MG3692C Options 2A, 4 , 6, 15A, 16, 22, SM6452

Rohde & Schwarz SMT06

(Two generators are needed for checking Third Order Intermodulation Distortion)

Krytar 3005070

P6616 probe; standard accessory shipped with MDO4000C Series oscilloscopes.

Tektronix adapter part number 679-6240-00; to connect the Fluke 9500B to the P6616 probe.

DMM4020 Digital Multimeter

FCA3000 Frequency Counter

Agilent N1913A S ingle-Channel Power Meter

Agilent 11667A Power Splitter

and the oscilloscope RF Input

Tektronix part number 011-0049-02

For terminating the RF Input

Tektronix part number 174-6025-00 (6 ft)

Tektronix part number 174-6026-00 (2 ft)

34 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Performance Veriﬁcation

Test Record

Model Serial Procedure performed by Date

Test Passed Failed

Self Test

Input Impedance

Performance checks Vertical scale Low limit Test result High limit

Channel 1 Input Impedance, 1 M

Channel 1 Input Impedance, 250 k

Impedance, 50 

Channel 2 Input Impedance, 1 M

Channel 2 Input Impedance, 250 k

Impedance, 50 

Channel 3 Input Impedance, 1 M

Channel 3 Input Impedance, 250 k

Impedance, 50 

Channel 4 Input Impedance, 1 M

Channel 4 Input Impedance, 250 k

Impedance, 50 

Aux In Input Impedance, 250 kΩ

10 mV/div 990 k 1.01 M

100 mV/div 990 k 1.01 M

1 V/div 990 k 1.01 M

100 mV/div 245 k 255 k

10 mV/div 49.5  50.5 Channel 1 Input

100 mV/div 49.5  50.5 

10 mV/div 990 k 1.01 M

100 mV/div 990 k 1.01 M

1 V/div 990 k 1.01 M

100 mV/div 245 k 255 k

10 mV/div 49.5  50.5 Channel 2 Input

100 mV/div 49.5  50.5 

10 mV/div 990 k 1.01 M

100 mV/div 990 k 1.01 M

1 V/div 990 k 1.01 M

100 mV/div 245 k 255 k

10 mV/div 49.5  50.5 Channel 3 Input

100 mV/div 49.5  50.5 

10 mV/div 990 k 1.01 M

100 mV/div 990 k 1.01 M

1 V/div 990 k 1.01 M

100 mV/div 245 k 255 k

10 mV/div 49.5  50.5 Channel 4, Input

100 mV/div 49.5  50.5 

245 k 255 k

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 35

Performance Veriﬁcation

DC Balance

Performance checks Vertical scale Low limit Test result High limit

Channel 1 DC Balance, 50 ,20MHz BW

Channel 1 DC Balance, 1 M,

zBW

20 MH

Channel 1 DC Balance, 50 , 250 MHz BW

Channel 1 DC Balance, 1 M, 250 MHz BW

Channel 1 DC Balance, 50 ,Full BW

Channel 1 DC Balance, 1 M,Full BW

1mV/div

2mV/div

5mV/div

10 mV/div

20 mV/div

49.8 mV/div

50 mV/div

100 mV/div

200 mV/div

500 mV/div

1V/div

1mV/div

2mV/div

5mV/div

10 mV/div

20 mV/div

100 mV/div

500 mV/div

1V/div

10 V/div

20 mV/div

–0.2 mV 0.2 mV

–0.5 mV 0.5 mV

–1 mV 1 mV

–2 mV 2 mV

–4.98 mV 4.98 mV

–5 mV 5 mV

–10 mV 10 mV

–20 mV 20 mV

–50 mV 50 mV

–100 m

5mV

–0.22

–0.4

–1 mV 1 mV

–2 m

–4

0mV

–2

100 mV

–

200 mV

–

–2 V 2 V

–2 mV 2 mV

–4 mV 4 mV

–2 mV 2 mV

–4 mV 4 mV

100 mV

0.225

0.4 m

2mV

00 mV

36 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Performance Veriﬁcation

DC Balance

Performance checks Vertical scale Low limit Test result High limit

Channel 2 DC Balance, 50 ,20MHz BW

Channel 2 DC Balance, 1 M,

zBW

20 MH

Channel 2 DC Balance, 50 , 250 MHz BW

Channel 2 DC Balance, 1 M, 250 MHz BW

Channel 2 DC Balance, 50 ,Full BW

Channel 2 DC Balance, 1 M,Full BW

1mV/div

2mV/div

5mV/div

10 mV/div

20 mV/div

49.8 mV/div

50 mV/div

100 mV/div

200 mV/div

500 mV/div

1V/div

1mV/div

2mV/div

5mV/div

10 mV/div

20 mV/div

100 mV/div

500 mV/div

1V/div

10 V/div

20 mV/div

–0.2 mV 0.2 mV

–0.5 mV 0.5 mV

–1 mV 1 mV

–2 mV 2 mV

–4.98 mV 4.98 mV

–5 mV 5 mV

–10 mV 10 mV

–20 mV 20 mV

–50 mV 50 mV

–100 m

5mV

–0.22

–0.4

–1 mV 1 mV

–2 m

–4

0mV

–2

100 mV

–

200 mV

–

–2 V 2 V

–2 mV 2 mV

–4 mV 4 mV

–2 mV 2 mV

–4 mV 4 mV

100 mV

0.225

0.4 m

2mV

00 mV

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 37

Performance Veriﬁcation

DC Balance

Performance checks Vertical scale Low limit Test result High limit

Channel 3 DC Balance, 50 ,20MHz BW

Channel 3 DC Balance, 1 M,

zBW

20 MH

Channel 3 DC Balance, 50 , 250 MHz BW

Channel 3 DC Balance, 1 M, 250 MHz BW

Channel 3 DC Balance, 50 ,Full BW

Channel 3 DC Balance, 1 M,Full BW

1mV/div

2mV/div

5mV/div

10 mV/div

20 mV/div

49.8 mV/div

50 mV/div

100 mV/div

200 mV/div

500 mV/div

1V/div

1mV/div

2mV/div

5mV/div

10 mV/div

20 mV/div

500 mV/div

100 mV/div

1V/div

10 V/div

20 mV/div

–0.2 mV 0.2 mV

–0.5 mV 0.5 mV

–1 mV 1 mV

–2 mV 2 mV

–4.98 mV 4.98 mV

–5 mV 5 mV

–10 mV 10 mV

–20 mV 20 mV

–50 mV 50 mV

–100 m

5mV

–0.22

–0.4

–1 mV 1 mV

–2 m

–4

00 mV

–1

20 mV

–

200 mV

–

–2 V 2 V

–2 mV 2 mV

–4 mV 4 mV

–2 mV 2 mV

–4 mV 4 mV

100 mV

0.225

0.4 m

2mV

0mV

00 mV

38 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Performance Veriﬁcation

DC Balance

Performance checks Vertical scale Low limit Test result High limit

Channel 4 DC Balance, 50 ,20MHz BW

Channel 4 DC Balance, 1 M,

zBW

20 MH

Channel 4 DC Balance, 50 , 250 MHz BW

Channel 4 DC Balance, 1 M, 250 MHz BW

Channel 4 DC Balance, 50 ,Full BW

Channel 4 DC Balance, 1 M,Full BW

1mV/div

2mV/div

5mV/div

10 mV/div

20 mV/div

49.8 mV/div

50 mV/div

100 mV/div

200 mV/div

500 mV/div

1V/div

1mV/div

2mV/div

5mV/div

10 mV/div

20 mV/div

500 mV/div

100 mV/div

1V/div

10 V/div

20 mV/div

–0.2 mV 0.2 mV

–0.5 mV 0.5 mV

–1 mV 1 mV

–2 mV 2 mV

–4.98 mV 4.98 mV

–5 mV 5 mV

–10 mV 10 mV

–20 mV 20 mV

–50 mV 50 mV

–100 m

5mV

–0.22

–0.4

–1 mV 1 mV

–2 m

–4

00 mV

–1

20 mV

–

200 mV

–

–2 V 2 V

–2 mV 2 mV

–4 mV 4 mV

–2 mV 2 mV

–4 mV 4 mV

100 mV

0.225

0.4 m

2mV

0mV

00 mV

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 39

Performance Veriﬁcation

DC Gain Accuracy

Performance checks Bandwidth Vertical scale Low limit Test result High limit

All models

Channel 1 DC Gain Accuracy, 0 V offset, 0 V vertical position, 5

Ch DC Gain Accuracy, 0 V offset, 0 V vertical po

0 

annel 2

sition, 50 

20 MHz

250 MHz (not applicable for the

024C)

MDO4

Full

20 MHz

250 MHz (not applicable for the MDO4024C)

Full

1 mV/div –2.0% 2.0%

2 mV/div –1.5% 1.5%

5 mV/div –1.5% 1.5%

10 mV/div –1.5% 1.5%

20 mV/div –1.5% 1.5%

/div

V/div

div

/div

–3.0% 3.0%

–1.5% 1.5%

–1.5

–1.

–2

–1

1.5%

–

1.5%

–

.0%

.5%

1.5%

1.5

.5%

49.8 mV/d

50 mV/di

100 mV/

200 mV/

500 mV

1V/di

20 mV

20 m

mV/div

0mV/div

20 mV/div –1.5% 1.5%

49.8 mV/div –3.0% 3.0%

50 mV/div –1.5% 1.5%

100 mV/div –1.5% 1.5%

200 mV/div –1.5% 1.5%

500 mV/div –1.5% 1.5%

1 V/div –1.5% 1.5%

20 mV/div –1.5% 1.5%

40 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Performance Veriﬁcation

DC Gain Accuracy

Performance checks Bandwidth Vertical scale Low limit Test result High limit

All models

Channel 3 DC Gain Accuracy, 0 V offset, 0 V vertical position, 5

Ch DC Gain Accuracy, 0 V offset, 0 V vertical po

0 

annel 4

sition, 50 

20 MHz

250 MHz (not applicable for the

024C

MDO4

Full

20 MHz

250 MHz (not applicable for the MDO4024C)

Full

1 mV/div –2.0% 2.0%

2 mV/div –1.5% 1.5%

5 mV/div –1.5% 1.5%

10 mV/div –1.5% 1.5%

20 mV/div –1.5% 1.5%

/div

V/div

div

/div

–3.0% 3.0%

–1.5% 1.5%

–1.5

–1.

–2

–1

1.5%

–

1.5%

–

.0%

.5%

1.5%

1.5

.5%

49.8 mV/d

50 mV/di

100 mV/

200 mV/

500 mV

1V/di

20 mV

20 m

mV/div

0mV/div

20 mV/div –1.5% 1.5%

49.8 mV/div –3.0% 3.0%

50 mV/div –1.5% 1.5%

100 mV/div –1.5% 1.5%

200 mV/div –1.5% 1.5%

500 mV/div –1.5% 1.5%

1 V/div –1.5% 1.5%

20 mV/div –1.5% 1.5%

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 41

Performance Veriﬁcation

DC Gain Accuracy

Performance checks Bandwidth Vertical scale Low limit Test result High lim it

All Models

Channel 1 DC Gain Accuracy, 0 V offset, 0 V vertical position, 1

Ch DC Gain Accuracy, 0 V offset, 0 V vertical

osition, 1 M

M

annel 2

20 MHz

250 MHz

(Not applicable for the

4024C)

MDO

FULL

20 MHz

250 MHz

(Not applicable for the MDO4024C)

FULL

1 mV/div –2.0% 2.0%

2 mV/div –1.5% 1.5%

5 mV/div –1.5% 1.5%

10 mV/div –1.5% 1.5%

20 mV/div –1.5% 1.5%

50 mV/div –1.5% 1.5%

/div

mV/div

V/div

mV/div

div

/div

div

–3.0% 3.0%

–1.5% 1.5%

–1.5

–1

–2

1.5%

–

1.5%

–

.5%

.0%

1.5%

.5%

63.5 mV/

100 mV/

200 mV/

500 mV

1V/di

5V/d

20 mV

10 mV/div –1.5% 1.5%

20 mV/div –1.5% 1.5%

50 mV/div –1.5% 1.5%

63.5 mV/div –3.0% 3.0%

100 mV/div –1.5% 1.5%

200 mV/div –1.5% 1.5%

500 mV/div –1.5% 1.5%

1 V/div –1.5% 1.5%

5 V/div –1.5% 1.5%

20 mV/div –1.5% 1.5%

42 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Performance Veriﬁcation

DC Gain Accuracy

Performance checks Bandwidth Vertical scale Low limit Test result High limit

All Models

Channel 3 DC Gain Accuracy, 0 V offset, 0 V vertical position, 1

annel 4

Ch DC Gain Accuracy, 0 V offset, 0 V vertical

osition, 1 M

M

20 MHz

250 MHz

(Not applicable for the

4024C)

MDO

FULL

20 MHz

250 MHz

(Not applicable for the MDO4024C)

FULL

1 mV/div –2.0% 2.0%

2 mV/div –1.5% 1.5%

5 mV/div –1.5% 1.5%

10 mV/div –1.5% 1.5%

20 mV/div –1.5% 1.5%

50 mV/div –1.5% 1.5%

/div

mV/div

V/div

mV/div

div

/div

–3.0% 3.0%

–1.5% 1.5%

–1.5

–1

–2

1.5%

–

1.5%

–

.5%

.0%

1.5%

.5%

63.5 mV/

100 mV/

200 mV/

500 mV

1V/di

5V/d

20 mV

10 mV/div –1.5% 1.5%

20 mV/div –1.5% 1.5%

50 mV/div –1.5% 1.5%

63.5 mV/div –3.0% 3.0%

100 mV/div –1.5% 1.5%

200 mV/div –1.5% 1.5%

500 mV/div –1.5% 1.5%

1 V/div –1.5% 1.5%

5 V/div –1.5% 1.5%

20 mV/div –1.5% 1.5%

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 43

Performance Veriﬁcation

DC Offset Accuracy

Performance checks Vertical scale Vertical offset

All models:

Channel 1 DC Offset Accuracy, 20 MHz BW, 50 

Channel 1 DC Offset Accuracy, 20 MHz BW, 1 M

hannel 2

C DC Offset Accuracy, 20 MHz BW, 50 

Channel 2 DC Offset Accuracy, 20 MHz BW, 1 M

1mV/div

100 mV/div

1mV/div

100 mV/d

100 mV/

500 mV/

500 mV

1.01 V

1.01

3V/d

3V/

div

/div

V/div

div

/div

mV/div

100 mV/div

1mV/div

100 mV/div

500 mV/div

1.01 V/div

3V/div

5V/div

900 mV 895.3 mV 904.7 m V

–900 mV –904.7 mV –895.3 mV

5.0 V 4.965 V 5.035 V

–5.0 V –5.035 V –4.965 V

900 mV 895.3 mV 904.7 m V

–900 mV –904.7 mV –895.3 mV

9.0 V 8.935 V 9.065 V

–9.0 V –9.065 V –8.935 V

9.0 V 8.855 V 9.145 V

–9.0 V –9.145 V –8.855 V

99.5 V 98.80 V 100.2 V

–99.5 V –100.2 V –98.80 V

99.5 V 98.40 V 100.6 V

–99.5 V –100.6 V -98.4 V

99.5 V 98.00 V 101.0 V

–99.5 V -101.0 V –98.00 V

900 mV 895.3 mV 904.7 m V

–900 mV –904.7 mV –895.3 mV

5.0 V 4.965 V 5.035 V

–5.0 V –5.035 V –4.965 V

900 mV 895.3 mV 904.7 m V

–900 mV –904.7 mV –895.3 mV

9.0 V 8.935 V 9.065 V

–9.0 V –9.065 V –8.935 V

9.0 V 8.855 V 9.145 V

– 9.0 V –9.145 V –8.855 V

99.5 V 98.80 V 100.2 V

–99.5 V –100.2 V –98.80 V

99.5 V 98.40 V 100.6 V

–99.5 V –100.6 V –98.4 V

99.5 V 98.00 V 101.0 V

–99.5 V –101.0 V –98.00 V

Low limit Test result High limit

44 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

DC Offset Accuracy

Performance checks Vertical scale Vertical offset

Channel 3 DC Offset Accuracy, 20 MHz BW, 50 

1mV/div

100 mV/div

Channel 3 DC Offset Accuracy, 20 MHz BW,

1M

1mV/div

100 mV/div

500 mV/div

1.01 V/div

3V/div

5V/div

Channel 4 DC Offset Accuracy,

0MHzBW,50

1mV/div

100 mV/div

Channel 4 DC Offset Accuracy, 20 MHz BW, 1 M

1mV/div

100 mV/div

500 mV/div

1.01 V/div

3V/div

5V/div

Use this value for both the calibrator output and the oscilloscope offset setting.

900 mV 895.3 mV 904.7 mV

–900 mV –904.7 mV -895.3 mV

5.0 V 4.965 V 5.035 V

–5.0 V –5.035 V –4.965 V

900 mV 895.3 mV 904.7 mV

–900 mV –904.7 mV –895.3 mV

9.0 V 8.935 V 9.065 V

–9.0 V –9.065 V –8.935 V

9.0 V 8.855 V 9.145 V

– 9.0 V –9.145

99.5 V 98.80

–99.5

99.5

–99.

99.

9.5 V

–9

0mV

900 mV

–

.0 V

–5.0 V –5.035 V –4.965 V

900 mV 895.3 mV 904.7 mV

–900 mV –904.7 mV –895.3 mV

9.0 V 8.935 V 9.065 V

–9.0 V –9.065 V –8.935 V

9.0 V 8.855 V 9.145 V

–9.0 V –9.145 V –8.855 V

99.5 V 98.80 V 100.2 V

–99.5 V –100.2 V –98.80 V

99.5 V 98.40 V 100.6 V

–99.5 V –100.6 V –98.4 V

99.5 V 98.00 V 101.0 V

–99.5 V –101.0 V –98.00 V

Performance Veriﬁcation

Low limit Test result High limit

–100.

98.4

.6 V

–100

00 V

98.

01.0 V

–1

5.3 mV

904.7 mV

–

.965 V

–8.855

100.2

–98.8

100.

–98.

.0 V

101

8.00 V

–9

4.7 mV

895.3 mV

–

.035 V

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 45

Performance Veriﬁcation

Analog Bandwid

Performance c

hecks

Bandwidth at Channel Impedance

All Models

Channel 1 50 

MDO4104C

Channel 1 1 M

Vertical scale

Horizontal scale V

1 mV/div 4 ns/div

(175 MHz for all models)

2 mV/div 2 ns/div

(Full BW for the MDO4024C 350 MHz for other models)

5 mV/div 1 ns/div

(Full BW)

10 mV/div 1 ns/div

(Full BW)

50 mV/div 1 ns/div

BW)

(Full

/div

100 mV

1ns/d (Full BW)

1 V/div 1 ns/div

(Full BW)

1 mV/div 4 ns/div

5MHz)

(17

V/div

s/div

(350 MHz)

5 mV/div 1 ns/div

(500 MHz)

10 mV/div 1 ns/div

(500 MHz)

50 mV/div 1 ns/div

(500 MHz)

100 mV/div 1 ns/div

(500 MHz)

1 V/div 1 ns/div

(500 MHz)

Test result Gain =

in-pp

bw-pp

Limit

bw-pp/Vin-pp

 0.707

 0.7

 0.707

.707

 0

 0.707

46 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Performance Veriﬁcation

Analog Bandwid

Performance c

Bandwidth at Channel Impedance

hecks

Vertical scale

MDO4054C option SA3 or SA6

Channel 1 1 M

1 m V/div 4 ns/div

2 m V/div 2 ns/div

5 m V/div 1 ns/div

10 mV/div 1 n s/div

50 mV/div 1 n s/div

100 mV/

1 V/div 1 ns/div

All other models with option SA3 or SA6

Channel 1 1 M

1 m V/div 4 ns/div

/div

2mV

mV/div

10 mV/div 1 n s/div

50 mV/div 1 n s/div

100 mV/div 1 ns/div

1 V/div 1 ns/div

div

Horizontal scale V

(175 MHz)

(350 MHz)

(380 MHz)

(380 MHz

1ns/di

)

(380 MHz)

MHz)

(175

/div

2ns (Full BW for the

4024C,

MDO 350 MHz for other

dels)

ns/div

1 (Full BW)

(Full BW)

in-pp

bw-pp

Limit

 0.707

 0.70

 0.707

0.707



 0.707

Test result Gain = V

bw-pp/Vin-pp

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 47

Performance Veriﬁcation

Analog Bandwid

Performance c

hecks

Bandwidth at Channel Impedance

All Models

Channel 2 50 

MDO4104C

Channel 2 1 M

Vertical scale

Horizontal scale V

1 mV/div 4 ns/div

(175 MHz for all models)

2 mV/div 2 ns/div

(Full BW for the MDO4024C 350 MHz for other models)

5 mV/div 1 ns/div

(Full BW)

10 mV/div 1 ns/div

(Full BW)

50 mV/div 1 ns/div

BW)

(Full

/div

100 mV

1ns/d (Full BW)

1 V/div 1 ns/div

(Full BW)

1 mV/div 4 ns/div

5MHz)

(17

V/div

s/div

(350 MHz)

5 mV/div 1 ns/div

(500 MHz)

10 mV/div 1 ns/div

(500 MHz)

50 mV/div 1 ns/div

(500 MHz)

100 mV/div 1 ns/div

(500 MHz)

1 V/div 1 ns/div

(500 MHz)

Test result Gain =

in-pp

bw-pp

Limit

bw-pp/Vin-pp

 0.707

 0.7

 0.707

.707

 0

 0.707

48 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Performance Veriﬁcation

Analog Bandwid

Performance c

Bandwidth at Channel Impedance

hecks

Vertical scale

MDO4054C with option SA3 or SA6

Channel 2 1 M

1 m V/div 4 ns/div

2 m V/div 2 ns/div

5 m V/div 1 ns/div

10 mV/div 1 n s/div

50 mV/div 1 n s/div

100 mV/

1 V/div 1 ns/div

All other models with option SA3 or SA6

Channel 2 1 M

1 m V/div 4 ns/div

/div

2mV

mV/div

10 mV/div 1 n s/div

50 mV/div 1 n s/div

100 mV/div 1 ns/div

1 V/div 1 ns/div

div

Horizontal scale V

(175 MHz)

(350 MHz)

(380 MHz)

(380 MHz

1ns/di

)

(380 MHz)

MHz)

(175

/div

2ns (Full BW for the

4024C,

MDO 350 MHz for other

dels)

ns/div

1 (Full BW)

(Full BW)

in-pp

bw-pp

Limit

 0.707

 0.70

 0.707

0.707



 0.707

Test result Gain = V

bw-pp/Vin-pp

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 49

Performance Veriﬁcation

Analog Bandwid

Performance c

hecks

Bandwidth at Channel Impedance

All Models

Channel 3 50 

MDO4104C

Channel 3 1 M

Vertical scale

Horizontal scale V

1 mV/div 4 ns/div

(175 MHz for all models)

2 mV/div 2 ns/div

(Full BW for the MDO4024C 350 MHz for other models)

5 mV/div 1 ns/div

(Full BW)

10 mV/div 1 ns/div

(Full BW)

50 mV/div 1 ns/div

BW)

(Full

/div

100 mV

1ns/d (Full BW)

1 V/div 1 ns/div

(Full BW)

1 mV/div 4 ns/div

5MHz)

(17

V/div

s/div

(350 MHz)

5 mV/div 1 ns/div

(500 MHz)

10 mV/div 1 ns/div

(500 MHz)

50 mV/div 1 ns/div

(500 MHz)

100 mV/div 1 ns/div

(500 MHz)

1 V/div 1 ns/div

(500 MHz)

Test result Gain =

in-pp

bw-pp

Limit

bw-pp/Vin-pp

 0.707

 0.7

 0.707

.707

 0

 0.707

50 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Performance Veriﬁcation

Analog Bandwid

Performance c

Bandwidth at Channel Impedance

hecks

Vertical scale

MDO4054C with option SA3 or SA6

Channel 3 1 M

1 m V/div 4 ns/div

2 m V/div 2 ns/div

5 m V/div 1 ns/div

10 mV/div 1 n s/div

50 mV/div 1 n s/div

100 mV/

1 V/div 1 ns/div

All other models with option SA3 or SA6

Channel 3 1 M

1 m V/div 4 ns/div

/div

2mV

mV/div

10 mV/div 1 n s/div

50 mV/div 1 n s/div

100 mV/div 1 ns/div

1 V/div 1 ns/div

div

Horizontal scale V

(175 MHz)

(350 MHz)

(380 MHz

(380 MHz)

(380 MHz

1ns/di

)

(380 MHz)

MHz)

(175

/div

2ns (Full BW for the

4024C,

MDO 350 MHz for other

dels))

ns/div

1 (Full BW)

(Full BW)

in-pp

bw-pp

Limit

 0.707

 0.70

 0.707

0.707



 0.707

Test result Gain = V

bw-pp/Vin-pp

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 51

Performance Veriﬁcation

Analog Bandwid

Performance c

hecks

Bandwidth at Channel Impedance

All Models

Channel 4 50 

MDO4104C

Channel 4 1 M

Vertical scale

Horizontal scale V

1 mV/div 4 ns/div

(175 MHz for all models)

2 mV/div 2 ns/div

(Full BW for the MDO4024C 350 MHz for other models)

5 mV/div 1 ns/div

(Full BW)

10 mV/div 1 ns/div

(Full BW)

50 mV/div 1 ns/div

BW)

(Full

/div

100 mV

1ns/d (Full BW)

1 V/div 1 ns/div

(Full BW)

1 mV/div 4 ns/div

5MHz)

(17

V/div

s/div

(350 MHz)

5 mV/div 1 ns/div

(500 MHz)

10 mV/div 1 ns/div

(500 MHz)

50 mV/div 1 ns/div

(500 MHz)

100 mV/div 1 ns/div

(500 MHz)

1 V/div 1 ns/div

(500 MHz)

Test result Gain =

in-pp

bw-pp

Limit

bw-pp/Vin-pp

 0.707

 0.7

 0.707

.707

 0

 0.707

52 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Performance Veriﬁcation

Analog Bandwid

Performance c

Bandwidth at Channel Impedance

hecks

Vertical scale

MDO4054C with option SA3 or SA6

Channel 4 1 M

1 m V/div 4 ns/div

2 m V/div 2 ns/div

5 m V/div 1 ns/div

10 mV/div 1 n s/div

50 mV/div 1 n s/div

100 mV/

1 V/div 1 ns/div

All other models with option SA3 or SA6

Channel 4 1 M

1 m V/div 4 ns/div

/div

2mV

mV/div

10 mV/div 1 n s/div

50 mV/div 1 n s/div

100 mV/div 1 ns/div

1 V/div 1 ns/div

div

Horizontal scale V

(175 MHz)

(350 MHz)

(380 MHz)

(380 MHz

1ns/di

)

(380 MHz)

MHz)

(175

/div

2ns (Full BW for the

4024C,

MDO 350 MHz for other

dels)

ns/div

1 (Full BW)

(Full BW)

in-pp

bw-pp

Limit

 0.707

 0.70

 0.707

0.707



 0.707

Test result Gain = V

bw-pp/Vin-pp

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 53

Performance Veriﬁcation

Random Noise, Sample Acquisition Mode

Vertical scale = 100 mV/div

Performance checks 1 MΩ 50 Ω

Bandwidth Test result (mV) High limit (mV) Test result (mV) High limit (mV)

MDO4104C

Channel 1

Channel 2

Channel 3

Channel 4

her models

All ot

Full 8.30 6.08

250 MHz limit 5.10 4.05

20 MHz limit 5.10 4.05

Full 8.30 6.08

250 MHz limit 5.10 4.05

20 MHz limit 5.10 4.05

Full 8.30 6.08

250 MHz limit 5.10 4.05

20 MHz limit 5.10 4.05

Full 8.30 6.08

250 MHz limit 5.10 4.05

20 MHz limit 5.10 4.05

MDO4x04C without option SA3 or SA6:

Channel 1

Channel 2

Channel 3

Channel 4

MDO4x04C with option SA3 or SA6:

Channel 1

Channel 2

Full 8.13 8.13

250 MHz limit 6.10 6.10

20 MHz limit 4.10 4.10

Full 8.13 8.13

250 MHz limit 6.10 6.10

20 MHz limit 4.10 4.10

Full 8.13 8.13

250 MHz limit 6.10 6.10

20 MHz limit 4.10 4.10

Full 8.13 8.13

250 MHz limit 6.10 6.10

20 MHz limit 4.10 4.10

Full 8.30 8.13

250 MHz limit 6.10 6.10

20 MHz limit 4.10 4.10

Full 8.30 8.13

250 MHz limit 6.10 6.10

20 MHz limit 4.10 4.10

54 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Performance Veriﬁcation

Random Noise, Sample Acquisition Mode

Vertical scale = 100 mV/div

Performance checks 1 MΩ 50 Ω

Bandwidth Test result (m V) High limit (mV) Test result (mV) High limit (mV)

Channel 3

Channel 4

Check R eferen ce Frequency Error (Cumulative) for models with option SA3 or SA6

Performance checks Low limit Test result High limit

Check R

Perfor

eference Frequency Error (Cumulative) for models without option SA3 or SA6

mance checks

Full 8.30 8.13

250 MHz limit 6.10 6.10

20 MHz limit 4.10 4.10

Full 8.30 8.13

250 MHz limit 6.10 6.10

20 MHz limit 4.10 4.10

–640 ns +640 ns

Low limit Test result High limit

–2 s+2s

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 55

Performance Veriﬁcation

DeltaTimeMeas

Performance c

MDO4104C with

urement Accuracy

hecks

option SA3 or SA6

Channel 1

MDO = 4 ns/di

MDO V/div Source V

5mV 40mV 118ps

100 mV 800 mV 117 ps

500 mV 4 V 117 ps

1 V 4 V 122 ps

v, Source freq = 240 MHz

Test result High limit

MDO = 40 ns/div, Sou rce freq = 24 MHz

1 mV 8 mV 463 ps

5 mV 40 mV 275 ps

100 mV 800 mV 233 ps

500 mV 4 V 231 ps

1 V 4 V 415 ps

MDO = 4

00 ns/div, Source freq = 2.4 MHz

1 mV 8 mV 4.49 ns

5mV 40mV 2.50ns

100 m

500 mV 4 V 2.13 ns

1 V 4 V 4.00 ns

800 m

MDO = 4 μs/div, Source freq = 240 kHz

5mV 40mV 25.0ns

100 mV 800 mV 20.3 ns

00 mV

1V 4V 40.0ns

MDO = 40 μs/div, Source freq = 24 kHz

1 mV 8 mV 449 ns

5 mV 40 mV 250 ns

100 mV 800 mV 203 ns

500 mV 4 V 201 ns

1 V 4 V 400 ns

MDO = 400 μs/div, Source freq = 2.4 kHz

1 mV 8 mV 4.49 s

5mV 40mV 2.50s

100 mV 800 mV 2.03 s

500 mV 4 V 2.01 s

1 V 4 V 4.00 s

2.03

.9 ns

0.1 ns

56 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Performance Veriﬁcation

Delta Time Meas

MDO4104C with

urement Accuracy

option SA3 or S A6

Channel 2

MDO = 4 ns/div

MDO V/div Source V

5mV 40mV 118ps

100 mV 800 mV 117 ps

500 mV 4 V 117 ps

1 V 4 V 122 ps

, Source freq = 240 MHz

Test result High limit

MDO = 40 ns/div, Source freq = 24 MHz

1 mV 8 mV 463 ps

5 mV 40 mV 256 ps

100 mV 800 mV 233 ps

500 mV 4 V 231 ps

1 V 4 V 415 ps

MDO = 4

00 ns/div, Source freq = 2.4 MHz

1 mV 8 mV 4.49 ns

5mV 40mV 2.50ns

100 m

500 mV 4 V 2.01 ns

1 V 4 V 4.00 ns

800 m

MDO = 4 μs/div, Source freq = 240 kHz

1 mV 8 mV 44.

5mV 40mV 25.0ns

100 mV 800 mV 20.3 ns

0mV

1 V 4 V 40.0 ns

4V 20

MDO = 40 μs/div, Source freq = 24 kHz

1 mV 8 mV 449 ns

5 mV 40 mV 250 ns

100 mV 800 mV 203 ns

500 mV 4 V 201 ns

1 V 4 V 400 ns

MDO = 400 μs/div, Source freq = 2.4 kHz

1 mV 8 mV 4.49 s

5mV 40mV 2.50s

100 mV 800 mV 2.03 s

500 mV 4 V 2.01 s

1 V 4 V 4.00 s

2.03

9ns

.1 ns

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 57

Performance Veriﬁcation

DeltaTimeMeas

MDO4104C with

urement Accuracy

option SA3 or SA6

Channel 3

MDO = 4 ns/div

MDO V/div Source V

5mV 40mV 118ps

100 mV 800 mV 118 ps

500 mV 4 V 117 ps

1 V 4 V 122 ps

, Source freq = 240 MHz

Test result High limit

MDO = 40 ns/div, Sou rce freq = 24 MHz

1 mV 8 mV 463 ps

5 mV 40 mV 275 ps

100 mV 800 mV 233 ps

500 mV 4 V 231 ps

1 V 4 V 415 ps

MDO = 4

00 ns/div, Source freq = 2.4 MHz

1 mV 8 mV 4.49 ns

5mV 40mV 2.50ns

100 m

500 mV 4 V 2.03 ns

1 V 4 V 4.01 ns

800 m

MDO = 4 μs/div, Source freq = 240 kHz

1 mV 8 mV 44.

5mV 40mV 25.0ns

100 mV 800 mV 20.3 ns

0mV

1V 4V 40.0ns

4V 20

MDO = 40 μs/div, Source freq = 24 kHz

1 mV 8 mV 449 ns

5 mV 40 mV 250 ns

100 mV 800 mV 203 ns

500 mV 4 V 201 ns

1 V 4 V 400 ns

MDO = 400 μs/div, Source freq = 2.4 kHz

1 mV 8 mV 4.49 s

5mV 40mV 2.50s

100 mV 800 mV 2.03 s

500 mV 4 V 2.01 s

1 V 4 V 4.00 s

2.02

9ns

.1 ns

58 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Performance Veriﬁcation

Delta Time Meas

MDO4104C with

urement Accuracy

option SA3 or S A6

Channel 4

MDO = 4 ns/div

MDO V/div Source V

5mV 40mV 118ps

100 mV 800 mV 117 ps

500 mV 4 V 117 ps

1 V 4 V 122 ps

, Source freq = 240 MHz

Test result High limit

MDO = 40 ns/div, Source freq = 24 MHz

1 mV 8 mV 463 ps

5 mV 40 mV 275 ps

100 mV 800 mV 233 ps

500 mV 4 V 231 ps

1 V 4 V 415 ps

MDO = 4

00 ns/div, Source freq = 2.4 MHz

1 mV 8 mV 4.49 ns

5mV 40mV 2.50ns

100 m

500 mV 4 V 2.01 ns

1 V 4 V 4.00 ns

800 m

MDO = 4 μs/div, Source freq = 240 kHz

1 mV 8 mV 44.

5mV 40mV 25.0ns

100 mV 800 mV 20.3 ns

0mV

1 V 4 V 40.0 ns

4V 20

MDO = 40 μs/div, Source freq = 24 kHz

1 mV 8 mV 449 ns

5 mV 40 mV 250 ns

100 mV 800 mV 203 ns

500 mV 4 V 201 ns

1 V 4 V 400 ns

MDO = 400 μs/div, Source freq = 2.4 kHz

1 mV 8 mV 4.49 s

5mV 40mV 2.50s

100 mV 800 mV 2.03 s

500 mV 4 V 2.01 s

1 V 4 V 4.00 s

2.03

9ns

.1 ns

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 59

Performance Veriﬁcation

DeltaTimeMeas

MDO4104C with

urement Accuracy

out option SA3 or SA6

Channel 1

MDO = 4 ns/div

MDO V/div Source V

5mV 40mV 118ps

100 mV 800 mV 118 ps

500 mV 4 V 117 ps

1 V 4 V 122 ps

, Source freq = 240 MHz

Test result High limit

MDO = 40 ns/div, Sou rce freq = 24 MHz

1 mV 8 mV 464 ps

5 mV 40 mV 276 ps

100 mV 800 mV 234 ps

500 mV 4 V 232 ps

1 V 4 V 417 ps

MDO = 4

00 ns/div, Source freq = 2.4 MHz

1 mV 8 mV 4.50 ns

5mV 40mV 2.52ns

100 m

500 mV 4 V 2.03 ns

1 V 4 V 4.01 ns

800 m

MDO = 4 μs/div, Source freq = 240 kHz

1 mV 8 mV 45.

5mV 40mV 25.2ns

100 mV 800 mV 20.5 ns

0mV

1V 4V 40.1ns

4V 20

MDO = 40 μs/div, Source freq = 24 kHz

1 mV 8 mV 450 ns

5 mV 40 mV 252 ns

100 mV 800 mV 205 ns

500 mV 4 V 203 ns

1 V 4 V 401 ns

MDO = 400 μs/div, Source freq = 2.4 kHz

1 mV 8 mV 4.50 s

5mV 40mV 2.52s

100 mV 800 mV 2.05 s

500 mV 4 V 2.03 s

1 V 4 V 4.01 s

2.05

0ns

.3 ns

60 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Performance Veriﬁcation

Delta Time Meas

MDO4104C with

urement Accuracy

out option SA3 or SA6

Channel 2

MDO = 4 ns/div

MDO V/div Source V

5mV 40mV 118ps

100 mV 800 mV 118 ps

500 mV 4 V 117 ps

1 V 4 V 122 ps

, Source freq = 240 MHz

Test result High limit

MDO = 40 ns/div, Source freq = 24 MHz

1 mV 8 mV 464 ps

5 mV 40 mV 276 ps

100 mV 800 mV 234 ps

500 mV 4 V 232 ps

1 V 4 V 417 ps

MDO = 4

00 ns/div, Source freq = 2.4 MHz

1 mV 8 mV 4.50 ns

5mV 40mV 2.52ns

100 m

500 mV 4 V 2.03 ns

1 V 4 V 4.01 ns

800 m

MDO = 4 μs/div, Source freq = 240 kHz

1 mV 8 mV 45.

5mV 40mV 25.2ns

100 mV 800 mV 20.5 ns

0mV

1 V 4 V 40.1 ns

4V 20

MDO = 40 μs/div, Source freq = 24 kHz

1 mV 8 mV 450 ns

5 mV 40 mV 252 ns

100 mV 800 mV 205 ns

500 mV 4 V 203 ns

1 V 4 V 401 ns

MDO = 400 μs/div, Source freq = 2.4 kHz

1 mV 8 mV 4.50 s

5mV 40mV 2.52s

100 mV 800 mV 2.05 s

500 mV 4 V 2.03 s

1 V 4 V 4.01 s

2.05

0ns

.3 ns

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 61

Performance Veriﬁcation

DeltaTimeMeas

MDO4104C with

urement Accuracy

out option SA3 or SA6

Channel 3

MDO = 4 ns/div

MDO V/div Source V

5mV 40mV 118ps

100 mV 800 mV 118 ps

500 mV 4 V 117 ps

1 V 4 V 122 ps

, Source freq = 240 MHz

Test result High limit

MDO = 40 ns/div, Sou rce freq = 24 MHz

1 mV 8 mV 464 ps

5 mV 40 mV 276 ps

100 mV 800 mV 234 ps

500 mV 4 V 232 ps

1 V 4 V 417 ps

MDO = 4

00 ns/div, Source freq = 2.4 MHz

1 mV 8 mV 4.50 ns

5mV 40mV 2.52ns

100 m

500 mV 4 V 2.03 ns

1 V 4 V 4.01 ns

800 m

MDO = 4 μs/div, Source freq = 240 kHz

1 mV 8 mV 45.

5mV 40mV 25.2ns

100 mV 800 mV 20.5 ns

0mV

1V 4V 40.1ns

4V 20

MDO = 40 μs/div, Source freq = 24 kHz

1 mV 8 mV 450 ns

5 mV 40 mV 252 ns

100 mV 800 mV 205 ns

500 mV 4 V 203 ns

1 V 4 V 401 ns

MDO = 400 μs/div, Source freq = 2.4 kHz

1 mV 8 mV 4.50 s

5mV 40mV 2.52s

100 mV 800 mV 2.05 s

500 mV 4 V 2.02 s

1 V 4 V 4.01 s

2.05

0ns

.3 ns

62 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Performance Veriﬁcation

Delta Time Meas

MDO4104C with

urement Accuracy

out option SA3 or SA6

Channel 4

MDO = 4 ns/div

MDO V/div Source V

5mV 40mV 118ps

100 mV 800 mV 118 ps

500 mV 4 V 117 ps

1 V 4 V 122 ps

, Source freq = 240 MHz

Test result High limit

MDO = 40 ns/div, Source freq = 24 MHz

1 mV 8 mV 464 ps

5 mV 40 mV 276 ps

100 mV 800 mV 234 ps

500 mV 4 V 232 ps

1 V 4 V 417 ps

MDO = 4

00 ns/div, Source freq = 2.4 MHz

1 mV 8 mV 4.50 ns

5mV 40mV 2.52ns

100 m

500 mV 4 V 2.03 ns

1 V 4 V 4.01 ns

800 m

MDO = 4 μs/div, Source freq = 240 kHz

1 mV 8 mV 45.

5mV 40mV 25.2ns

100 mV 800 mV 20.5 ns

0mV

1 V 4 V 40.1 ns

4V 20

MDO = 40 μs/div, Source freq = 24 kHz

1 mV 8 mV 450 ns

5 mV 40 mV 252 ns

100 mV 800 mV 205 ns

500 mV 4 V 203 ns

1 V 4 V 401 ns

MDO = 400 μs/div, Source freq = 2.4 kHz

1 mV 8 mV 4.50 s

5mV 40mV 2.52s

100 mV 800 mV 2.05 s

500 mV 4 V 2.03 s

1 V 4 V 4.01 s

2.05

0ns

.3 ns

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 63

Performance Veriﬁcation

DeltaTimeMeas

MDO40X4C with

urement Accuracy

out option SA3 or SA6

Channel 1

MDO = 4 ns/div

MDO V/div Source V

5 mV 40 mV 234 ps

100 mV 800 mV 233 ps

500 mV 4 V 233 ps

1 V 4 V 237 ps

, Source freq = 240 MHz (except for the MDO4024C)

Test result High limit

MDO = 40 ns/div, Sou rce freq = 24 MHz

1 mV 8 mV 736 ps

5 mV 40 mV 423 ps

100 mV 800 mV 357 ps

500 mV 4 V 354 ps

1 V 4 V 581 ps

MDO = 4

00 ns/div, Source freq = 2.4 MHz

1 mV 8 mV 6.99 ns

5mV 40mV 3.54ns

100 m

500 mV 4 V 2.69 ns

1 V 4 V 5.34 ns

800 m

MDO = 4 μs/div, Source freq = 240 kHz

1 mV 8 mV 69.

5mV 40mV 35.4ns

100 mV 800 mV 27.3 ns

0mV

1V 4V 53.4ns

4V 26

MDO = 40 μs/div, Source freq = 24 kHz

1 mV 8 mV 699 ns

5 mV 40 mV 354 ns

100 mV 800 mV 273 ns

500 mV 4 V 269 ns

1 V 4 V 534 ns

MDO = 400 μs/div, Source freq = 2.4 kHz

1 mV 8 mV 6.99 s

5mV 40mV 3.54s

100 mV 800 mV 2.73 s

500 mV 4 V 2.69 s

1 V 4 V 5.34 s

2.73

9ns

.9 ns

64 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Performance Veriﬁcation

Delta Time Meas

MDO40X4C with

urement Accuracy

out option SA3 or SA6

Channel 2

MDO=4ns/div

MDO V/div Source V

5 mV 40 mV 234 ps

100 mV 800 mV 233 ps

500 mV 4 V 233 ps

1 V 4 V 237 ps

, Source freq = 240 MHz (except for the MDO4024C)

Test result High limit

MDO = 40 ns/div, Source freq = 24 MHz

1 mV 8 mV 736 ps

5 mV 40 mV 423 ps

100 mV 800 mV 357 ps

500 mV 4 V 354 ps

1 V 4 V 581 ps

MDO = 4

00 ns/div, Source freq = 2.4 MHz

1 mV 8 mV 6.99 ns

5mV 40mV 3.54ns

100 m

500 mV 4 V 2.69 ns

1 V 4 V 5.34 ns

800 m

MDO = 4 μs/div, Source freq = 240 kHz

1 mV 8 mV 69.

5mV 40mV 35.4ns

100 mV 800 mV 27.3 ns

0mV

1 V 4 V 53.4 ns

4V 26

MDO = 40 μs/div, Source freq = 24 kHz

1 mV 8 mV 699 ns

5 mV 40 mV 354 ns

100 mV 800 mV 273 ns

500 mV 4 V 269 ns

1 V 4 V 534 ns

MDO = 400 μs/div, Source freq = 2.4 kHz

1 mV 8 mV 6.99 s

5mV 40mV 3.54s

100 mV 800 mV 2.73 s

500 mV 4 V 2.69 s

1 V 4 V 5.34 s

2.73

9ns

.9 ns

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 65

Performance Veriﬁcation

DeltaTimeMeas

MDO40X4C with

urement Accuracy

out option SA3 or SA6

Channel 3

MDO = 4 ns/div

MDO V/div Source V

5 mV 40 mV 234 ps

100 mV 800 mV 233 ps

500 mV 4 V 233 ps

1 V 4 V 237 ps

, Source freq = 240 MHz (except for the MDO4024C)

Test result High limit

MDO = 40 ns/div, Sou rce freq = 24 MHz

1 mV 8 mV 736 ps

5 mV 40 mV 423 ps

100 mV 800 mV 357 ps

500 mV 4 V 354 ps

1 V 4 V 581 ps

MDO = 4

00 ns/div, Source freq = 2.4 MHz

1 mV 8 mV 6.99 ns

5mV 40mV 3.54ns

100 m

500 mV 4 V 2.69 ns

1 V 4 V 5.34 ns

800 m

MDO = 4 μs/div, Source freq = 240 kHz

1 mV 8 mV 69.

5mV 40mV 35.4ns

100 mV 800 mV 27.3 ns

0mV

1V 4V 53.4ns

4V 26

MDO = 40 μs/div, Source freq = 24 kHz

1 mV 8 mV 699 ns

5 mV 40 mV 354 ns

100 mV 800 mV 273 ns

500 mV 4 V 269 ns

1 V 4 V 534 ns

MDO = 400 μs/div, Source freq = 2.4 kHz

1 mV 8 mV 6.99 s

5mV 40mV 3.54s

100 mV 800 mV 2.73 s

500 mV 4 V 2.69 s

1 V 4 V 5.34 s

2.73

9ns

.9 ns

66 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Performance Veriﬁcation

Delta Time Meas

MDO40X4C with

urement Accuracy

out option SA3 or SA6

Channel 4

MDO=4ns/div

MDO V/div Source V

5 mV 40 mV 234 ps

100 mV 800 mV 233 ps

500 mV 4 V 233 ps

1 V 4 V 237 ps

, Source freq = 240 MHz (except for the MDO4024C)

Test result High limit

MDO = 40 ns/div, Source freq = 24 MHz

1 mV 8 mV 736 ps

5 mV 40 mV 423 ps

100 mV 800 mV 357 ps

500 mV 4 V 354 ps

1 V 4 V 581 ps

MDO = 4

00 ns/div, Source freq = 2.4 MHz

1 mV 8 mV 6.99 ns

5mV 40mV 3.54ns

100 m

500 mV 4 V 2.69 ns

1 V 4 V 5.34 ns

800 m

MDO = 4 μs/div, Source freq = 240 kHz

1 mV 8 mV 69.

5mV 40mV 35.4ns

100 mV 800 mV 27.3 ns

0mV

1 V 4 V 53.4 ns

4V 26

MDO = 40 μs/div, Source freq = 24 kHz

1 mV 8 mV 699 ns

5 mV 40 mV 354 ns

100 mV 800 mV 273 ns

500 mV 4 V 269 ns

1 V 4 V 534 ns

MDO = 400 μs/div, Source freq = 2.4 kHz

1 mV 8 mV 6.99 s

5mV 40mV 3.54s

100 mV 800 mV 2.73 s

500 mV 4 V 2.69 s

1 V 4 V 5.34 s

2.73

9ns

.9 ns

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 67

Performance Veriﬁcation

DeltaTimeMeas

MDO40X4C with

urement Accuracy

option SA3 or SA6

Channel 1

MDO = 4 ns/div

MDO V/div Source V

5 mV 40 mV 234 ps

100 mV 800 mV 233 ps

500 mV 4 V 233 ps

1 V 4 V 237 ps

, Source freq = 240 MHz (except for the MDO4024C)

Test result High limit

MDO = 40 ns/div, Sou rce freq = 24 MHz

1 mV 8 mV 734 ps

5mV 40mV 421ps

100 mV 800 mV 356 ps

500 mV 4 V 353 ps

1 V 4 V 580 ps

MDO = 4

00 ns/div, Source freq = 2.4 MHz

1 mV 8 mV 6.97 ns

5mV 40mV 3.53ns

100 m

500 mV 4 V 2.68 ns

1 V 4 V 5.32 ns

800 m

MDO = 4 μs/div, Source freq = 240 kHz

1 mV 8 mV 69.

5mV 40mV 35.3ns

100 mV 800 mV 27.1 ns

0mV

1V 4V 53.2ns

4V 26

MDO = 40 μs/div, Source freq = 24 kHz

1 mV 8 mV 697 ns

5 mV 40 mV 353 ns

100 mV 800 mV 271 ns

500 mV 4 V 268 ns

1 V 4 V 532 ns

MDO = 400 μs/div, Source freq = 2.4 kHz

1 mV 8 mV 6.97 s

5mV 40mV 3.53s

100 mV 800 mV 2.71 s

500 mV 4 V 2.68 s

1 V 4 V 5.32 s

2.71

7ns

.8 ns

68 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Performance Veriﬁcation

Delta Time Meas

MDO40X4C with

urement Accuracy

option SA3 or SA6

Channel 2

MDO=4ns/div

MDO V/div Source V

5 mV 40 mV 234 ps

100 mV 800 mV 233 ps

500 mV 4 V 233 ps

1 V 4 V 237 ps

, Source freq = 240 MHz (except for the MDO4024C)

Test result High limit

MDO = 40 ns/div, Source freq = 24 MHz

1 mV 8 mV 734 ps

5mV 40mV 421ps

100 mV 800 mV 356 ps

500 mV 4 V 353 ps

1 V 4 V 580 ps

MDO = 4

00 ns/div, Source freq = 2.4 MHz

1 mV 8 mV 6.97 ns

5mV 40mV 3.53ns

100 m

500 mV 4 V 2.68 ns

1 V 4 V 5.32 ns

800 m

MDO = 4 μs/div, Source freq = 240 kHz

1 mV 8 mV 69.

5mV 40mV 35.3ns

100 mV 800 mV 27.1 ns

0mV

1 V 4 V 53.2 ns

4V 26

MDO = 40 μs/div, Source freq = 24 kHz

1 mV 8 mV 697 ns

5 mV 40 mV 353 ns

100 mV 800 mV 271 ns

500 mV 4 V 268 ns

1 V 4 V 532 ns

MDO = 400 μs/div, Source freq = 2.4 kHz

1 mV 8 mV 6.97 s

5mV 40mV 3.53s

100 mV 800 mV 2.71 s

500 mV 4 V 2.68 s

1 V 4 V 5.32 s

2.71

7ns

.8 ns

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 69

Performance Veriﬁcation

DeltaTimeMeas

MDO40X4C with

urement Accuracy

option SA3 or SA6

Channel 3

MDO = 4 ns/div

MDO V/div Source V

5 mV 40 mV 234 ps

100 mV 800 mV 233 ps

500 mV 4 V 233 ps

1 V 4 V 237 ps

, Source freq = 240 MHz (except for the MDO4024C)

Test result High limit

MDO = 40 ns/div, Sou rce freq = 24 MHz

1 mV 8 mV 734 ps

5mV 40mV 421ps

100 mV 800 mV 356 ps

500 mV 4 V 353 ps

1 V 4 V 580 ps

MDO = 4

00 ns/div, Source freq = 2.4 MHz

1 mV 8 mV 6.97 ns

5mV 40mV 3.53ns

100 m

500 mV 4 V 2.68 ns

1 V 4 V 5.32 ns

800 m

MDO = 4 μs/div, Source freq = 240 kHz

1 mV 8 mV 69.

5mV 40mV 35.3ns

100 mV 800 mV 27.1 ns

0mV

1V 4V 53.2ns

4V 26

MDO = 40 μs/div, Source freq = 24 kHz

1 mV 8 mV 697 ns

5 mV 40 mV 353 ns

100 mV 800 mV 271 ns

500 mV 4 V 268 ns

1 V 4 V 532 ns

MDO = 400 μs/div, Source freq = 2.4 kHz

1 mV 8 mV 6.97 s

5mV 40mV 3.53s

100 mV 800 mV 2.71 s

500 mV 4 V 2.68 s

1 V 4 V 5.32 s

2.71

7ns

.8 ns

70 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Performance Veriﬁcation

Delta Time Meas

MDO40X4C with

urement Accuracy

option SA3 or SA6

Channel 4

MDO=4ns/div

MDO V/div Source V

5 mV 40 mV 234 ps

100 mV 800 mV 233 ps

500 mV 4 V 233 ps

1 V 4 V 237 ps

, Source freq = 240 MHz (except for the MDO4024C)

Test result High limit

MDO = 40 ns/div, Source freq = 24 MHz

1 mV 8 mV 734 ps

5mV 40mV 421ps

100 mV 800 mV 356 ps

500 mV 4 V 353 ps

1 V 4 V 580 ps

MDO = 4

00 ns/div, Source freq = 2.4 MHz

1 mV 8 mV 6.97 ns

5mV 40mV 3.53ns

100 m

500 mV 4 V 2.68 ns

1 V 4 V 5.32 ns

800 m

MDO = 4 μs/div, Source freq = 240 kHz

1 mV 8 mV 69.

5mV 40mV 35.3ns

100 mV 800 mV 27.1 ns

0mV

1 V 4 V 53.2 ns

4V 26

MDO = 40 μs/div, Source freq = 24 kHz

1 mV 8 mV 697 ns

5 mV 40 mV 353 ns

100 mV 800 mV 271 ns

500 mV 4 V 268 ns

1 V 4 V 532 ns

MDO = 400 μs/div, Source freq = 2.4 kHz

1 mV 8 mV 6.97 s

5mV 40mV 3.53s

100 mV 800 mV 2.71 s

500 mV 4 V 2.68 s

1 V 4 V 5.32 s

2.71

7ns

.8 ns

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 71

Performance Veriﬁcation

Digital Thresh

Performance c

old Accuracy

hecks:

Digital channel Threshold V

0 V –0.1 V 0.1 VD0

4 V 3.78 V 4.22 V

0 V –0.1 V 0.1 VD1

4 V 3.78 V 4.22 V

0 V –0.1 V 0.1 VD2

4 V 3.78 V 4.22 V

0 V –0.1 V 0.1 VD3

4 V 3.78 V 4.22 V

0 V –0.1 V 0.1 VD4

4 V 3.78 V 4.22 V

0 V –0.1 V 0.1 VD5

4 V 3.78 V 4.22 V

0 V –0.1 V 0.1 VD6

4 V 3.78 V 4.22 V

0 V –0.1 V 0.1 VD7

4 V 3.78 V 4.22 V

0 V –0.1 V 0.1 VD8

4 V 3.78 V 4.22 V

0 V –0.1 V 0.1 VD9

4 V 3.78 V 4.22 V

0 V –0.1

4 V 3.78 V 4.22 V

0 V –0.1 V 0.1 VD11

4V 3.7

0 V –0.1 V 0.1 VD12

4 V 3.78 V 4.22 V

0V –0

4 V 3.78 V 4.22 V

0 V –0.1 V 0.1 VD14

0 V –0.1 V 0.1 VD15

4 V 3.78 V 4.22 V

slow

shigh

Low limit Test result High limit

.78 V

.1 V

0.1 VD10

4.2

.22 V

72 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Phase Noise at 1 GHz

Performance checks Offset

Center Frequency 1GHz

Displayed Average N oise Level (DANL)

Performance checks

All models

10 kHz

100 kHz

1MHz

9kHz–50kHz

50kHz–5MHz

Performance Veriﬁcation

Low limit Test result High limit

N/A –108 dBc/Hz

N/A –110 dBc/Hz

N/A –120 dBc/Hz

Low limit Test result High limit

N/A < –116 dB m/Hz

N/A < –130 dBm/Hz

5 MHz – 400 MHz

400 MHz – 3 GHz N/A < – 147 dBm/Hz

3 GHz – 4 GHz N/A < – 148 dBm/HzOption SA6

4 GHz – 6 GHz N/A < – 140 dBm/Hz

Absolute Amplitude Accuracy

Performance checks

+10 dBm

0dBm

–15 dBm

All m odels

Option SA6 only >3 GHz – 6 GHz

All m odels

Option SA6 only > 3 G Hz – 6 GHz

All m odels

Option SA6 only >3 GHz – 6 GHz

N/A < –146 dBm/Hz

Low limit Test result High limit

50 kHz – 950 kHz –1 dBm +1 dBm

1MHz–9MHz –1dBm +1dBm

10 MHz – 90 MHz –1 dBm +1 dBm

100 MHz – 3 GHz

50 kHz – 950 kHz –1 dBm +1 dBm

1MHz–9MHz –1dBm +1dBm

10 MHz – 90 MHz –1 dBm +1 dBm

100 MHz – 3 GHz

50 kHz – 950 kHz –1 dBm +1 dBm

1MHz–9MHz –1dBm +1dBm

10 MHz – 90 MHz –1 dBm +1 dBm

100 MHz – 3 GHz

–1 dBm +1 dBm

-1 dB m +1 dBm

–1 dBm +1 dBm

Third Order Intermodulation Distortion

Performance checks

Center Frequency

2.745 GHz

Option SA6 Center Frequency

4.5 GHz

Intermod spur 1

Intermod spur 2

Intermod spur 1

Intermod spur 2

Low limit Test result High limit

N/A

–62 dBcAll models

–62 dBc

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 73

Performance Veriﬁcation

Residual Spurious Response

Performance checks

All models

Option SA6

Low limit Test result High limit

9kHzto50kHz

50kHzto3GHz

2.5 GHz N/A

2.75 G Hz to 4.5 GHz N/A

3.5 GHz to 5.99 GHz N/A

3.75 GHz N/A

4 GHz N/A

5 GHz N/A

N/A

–85 dBm

–73 dBm

–85 dBm

–78 dBm

74 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Crosstalk to RF channel from analog channels

Performance checks

Channel 1 crosstalk

Generator signal frequency and Oscilloscope Center Frequency setting

105 MHz

205 MHz

305 MHz

405 MHz

505 MHz

605 MHz

705 MHz

805 MHz

905 MHz

1.005 GHz N/A

1.105 GHz N/A

1.205 GHz N/A

1.305 GHz N/A

1.405 GHz N/A

1.505 GHz N/A

1.605 GHz N/A

1.705 GHz N/A

1.805 GHz N/A

1.905 GHz N/A

2.005 GHz N/A

Performance Veriﬁcation

Low limit Test result High limit

N/A

–68 dBm

–48 dB

–48 d

dBm

–48

8dBm

–4

8dBm

–4

48 dBm

–

48 dBm

–

–48 dBm

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 75

Performance Veriﬁcation

Crosstalk to RF channel from analog channels

Channel 2 crosstalk

Generator signal frequency and Oscilloscope Center Frequency setting

105 MHz

205 MHz

305 MHz

405 MHz

505 MHz

605 MHz

705 MHz

805 MHz

905 MHz

1.005 GHz N/A

1.105 GHz N/A

1.205 GHz N/A

1.305 GHz N/A

1.405 GHz N/A

1.505 GHz N/A

1.605 GHz N/A

1.705 GHz N/A

1.805 GHz N/A

1.905 GHz N/A

2.005 GHz N/A

Low limit Test result High limit

N/A

–68 dBm

–48 dB

–48 d

dBm

–48

8dBm

–4

8dBm

–4

48 dBm

–

48 dBm

–

–48 dBm

76 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Crosstalk to RF channel from analog channels

Channel 3 crosstalk

Generator signal frequency and Oscilloscope Center Frequency setting

105 MHz

205 MHz

305 MHz

405 MHz

505 MHz

605 MHz

705 MHz

805 MHz

905 MHz

1.005 GHz N/A

1.105 GHz N/A

1.205 GHz N/A

1.305 GHz N/A

1.405 GHz N/A

1.505 GHz N/A

1.605 GHz N/A

1.705 GHz N/A

1.805 GHz N/A

1.905 GHz N/A

2.005 GHz N/A

Performance Veriﬁcation

Low limit Test result High limit

N/A

–68 dBm

–48 dB

–48 d

dBm

–48

8dBm

–4

8dBm

–4

48 dBm

–

48 dBm

–

–48 dBm

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 77

Performance Veriﬁcation

Crosstalk to RF channel from analog channels

Channel 4 crosstalk

Generator signal frequency and Oscilloscope Center Frequency setting

105 MHz

205 MHz

305 MHz

405 MHz

505 MHz

605 MHz

705 MHz

805 MHz

905 MHz

1.005 GHz N/A

1.105 GHz N/A

1.205 GHz N/A

1.305 GHz N/A

1.405 GHz N/A

1.505 GHz N/A

1.605 GHz N/A

1.705 GHz N/A

1.805 GHz N/A

1.905 GHz N/A

2.005 GHz N/A

Low limit Test result High limit

N/A

–68 dBm

–48 dB

–48 d

dBm

–48

8dBm

–4

8dBm

–4

48 dBm

–

48 dBm

–

–48 dBm

Auxiliary (Trigger) Output

Performance checks

Trigger Output

High 1 M

Low 1 M

High 50 

Low 50 

Low limit Test result High limit

 2.5 V –

 1.0 V –

–

 0.7 V –

 0.25 V

78 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Performance Veriﬁcation

With TPA-N-PRE

With TPA-N-PRE attached: Displayed Average Noise Level (DANL)

Performance checks

All models (with TPA-N-PRE attached)

SA6 only (with TPA-N-PRE attached)

Attached

Low limit Test result High limit

9kHz–50kHz

50kHz–5MHz

5 MHz – 400 MHz

5 MHz – 3 GHz N/A –157 dBm/Hz

3 GHz – 4 GHz N/A –158 dBm/HzMDO4XX4C option

4 GHz – 6 GHz N/A –150 dBm/Hz

N/A –119 dBm/Hz

N/A –140 dBm/Hz

N/A –156 dBm/Hz

AFG Sine and Ramp

Frequen

AFG Sine and Ramp Frequency Accuracy Tests

Performance checks

All models

cy Accuracy Tests

Sine Wave at 10 kHz,

2.5 V, 50 

Sine Wave at 50 MHz,

2.5 V, 50 

Low limit Test result High limit

9.9987 kHz 10.0013 kHz

49.9975 MHz 50.0025 MHz

AFG Square and Pulse

uency Accuracy Tests

Freq

AFG Square and Pulse Frequency Accuracy Tests

Performance checks

All models

Square Wave at 25 kHz, 2.5 V, 50 

Square Wave at 25 MHz, 2.5 V, 50 

Low limit Test result High limit

24.99875 kHz 25.00125 kHz

24.99875 MHz 25.00125 MHz

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 79

Performance Veriﬁcation

AFG Signal Ampl

itude

Accuracy Tests

AFG Signal Amplitude Accuracy Tests

Performance checks

All models

Square Wave20 mVpp @ 1 kHz, 50 ,0V Offset

Square Wave 1 Vpp @ 1 kHz, 50 ,0.2V Offset

AFG DC Offset Accuracy

Tests

AFG DC Offset Accuracy Tests

Performance checks

All models

20 mV DC @ 50 

1VDC@50

Low limit Test result High limit

9.35 mV 10.65 mV

490.5 mV 509.5 mV

Low limit Test result High limit

18.7 mV 21.3 mV

0.984 V 1.016 V

DVM Vol

tage Accuracy

Tests (DC)

DVM Voltage Accuracy (DC)

Channel 1

Vertical Scale

0.5 –2 –2 -2.06 -1.94

0.5 –1 –0.5 -1.06 -0.94

0.2 –0.5 –0.5 -0.5225 -0.4775

0.01 0.002 0 0.00097 0.00303

0.2 0.5 0.5 0.4775 0.5225

0.5 1 0.5 0.94 1.06

0.5 2 2 1.94 2.06

Channel 2

Vertical Scale

0.5 –2 –2 -2.06 -1.94

0.5 –1 –0.5 -1.06 -0.94

0.2 –0.5 –0.5 -0.5225 -0.4775

Input Voltage

–5 –5

Input Voltage

–5 –5

Offset Voltage

Low limit Test result High limit

-5.125 -4.875

4.875 5.125

Low limit Test result High limit

-5.125 -4.875

80 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Performance Veriﬁcation

0.01 0.002 0 0.00097 0.00303

0.2 0.5 0.5 0 .4775 0.5225

0.5 1 0.5 0.94 1.06

0.5 2 2 1.94 2.06

Channel 3

Vertical Scale

0.5 –2 –2 -2.06 -1.94

0.5 –1 –0.5 -1.06 -0.94

0.2 –0.5 –0.5 -0.5225 -0.4775

0.01 0.002 0 0.00097 0.00303

0.2 0.5 0.5 0 .4775 0.5225

0.5 1 0.5 0.94 1.06

0.5 2 2 1.94 2.06

Channel 4

Vertical Scale

0.5 –2 –2 -2.0

0.5 –1 –0.5 -1.06 -0.94

0.2 –0.5 –0.5 -0.5225 -0.4775

0.0

0.2 0.5 0.5 0 .4775 0.5225

0.5 1 0.5 0.94 1.06

Input Voltage

–5 –5

Input Voltage

–5 –5

0.0

221.

Offset Voltage

00.0

4.875 5.125

Low limit Test result High limit

-5.125 -4.875

4.875 5.125

Low limit Test result High limit

-5.125 -4.875

0097

4.875 5.125

-1.9

0.0

0303

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 81

Performance Veriﬁcation

DVM Voltage Acc

uracy

Tests (AC)

DVM Voltage Accuracy (AC)

Channel 1

Vertical Scale Input Signal

5mV 20mVppat 1 kHz 9.800 mV 10.200 mV

10 mV 50 mVppat 1 kHz 24.5 mV 25.500 mV

100 mV 0.5 Vppat 1 kHz 245.000 mV 255.000 mV

200 mV 1 Vppat 1 kHz 490.000 mV 510.000 mV

1V 5Vppat 1 kHz 2.450 mV 2.550 mV

Channel 2

Vertical Scale Input Signal

5mV 20mVppat 1 kHz 9.800 mV 10.200 mV

10 mV 50 mVppat 1 kHz 24.5 mV 25.500 mV

100 mV 0.5 Vppat 1 kHz 245.000 mV 255.000 mV

200 mV 1 Vppat 1 kHz 490.000 mV 510.000 mV

1V 5Vppat 1 kHz 2.450 mV 2.550 mV

Channel 3

Vertical Scale Input Signal

5mV 20mVppat 1 kHz 9.800 mV 10.200 mV

10 mV 50 mVppat 1 kHz 24.5 mV 25.500 mV

100 mV 0.5 Vppat 1 kHz 245.000 mV 255.000 mV

200 mV 1 Vppat 1 kHz 490.000 mV 510.000 mV

1V 5Vppat 1 kHz 2.450 mV 2.550 mV

Channel 4

Vertical Scale Input Signal

5mV 20mVppat 1 kHz 9.800 mV 10.200 mV

10 mV 50 mVppat 1 kHz 24.5 mV 25.500 mV

100 mV 0.5 Vppat 1 kHz 245.000 mV 255.000 mV

200 mV 1 Vppat 1 kHz 490.000 mV 510.000 mV

1V 5Vppat 1 kHz 2.450 mV 2.550 mV

Low limit Test result High limit

82 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Performance Veriﬁcation

DVM Frequency A

ccuracy

Tests and Maximum Input

Frequency

DVM Frequency Accuracy

Channel 1

Hz Low limit Test result High limit

10 Hz 9.9989 Hz 10.001 Hz

100 Hz 99.989 Hz 100.01 Hz

1 kHz 999.89 Hz 1.0001 kHz

100 kHz 99.989 kHz 100.01 kHz

1 MHz 999.89 kHz 1.0001 MHz

180 MHz 149.98 MHz 150.02 MHz

Channel 2

Hz Low limit Test result High limit

10 Hz 9.9989 Hz 10.001 Hz

100 Hz 99.989 Hz 100.01 Hz

1 kHz 999.89 Hz 1.0001 kHz

100 kHz 99.989 kHz 100.01 kHz

1 MHz 999.89 kHz 1.0001 MHz

180 MHz 149.98 MHz 150.02 MHz

Channel 3

Hz Low limit Test result High limit

10 Hz 9.9989 Hz 10.001 Hz

100 Hz 99.989 Hz 100.01 Hz

1 kHz 999.89 Hz 1.0001 kHz

100 kHz 99.989 kHz 100.01 kHz

1 MHz 999.89 kHz 1.0001 MHz

180 MHz 149.98 MHz 150.02 MHz

Channel 4

Hz Low limit Test result High limit

10 Hz 9.9989 Hz 10.001 Hz

100 Hz 99.989 Hz 100.01 Hz

1 kHz 999.89 Hz 1.0001 kHz

100 kHz 99.989 kHz 100.01 kHz

1 MHz 999.89 kHz 1.0001 MHz

180 MHz 149.98 MHz 150.02 MHz

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 83

Performance Veriﬁcation

Performance V

eriﬁcation Procedures

The Performance Veriﬁcation Procedures consist of a self test and several check steps, which check the oscilloscope performance to speciﬁcations. The following three condit

1. The oscilloscope must have been operating continuously for twenty (20)

minutes in a temperature and humidity.

2. You m ust p e

in step 2 of the Self Test before evaluating speciﬁcations. (See page 85, Self Tes t .) If the operating temperature changes by more than 10 °C (18 °F), you must perform the SPC operation again.

3. You must connect the oscilloscope and the test equipment to the same AC

power circuit. Connect the oscilloscope and test instruments to a common power strip if you are unsure of the AC power circuit distribution. Connecting the oscilloscope and test instruments to separate AC power circuits can result performance veriﬁcation procedure.

The ti ensure instrument performance to the Absolute Amplitude Accuracy speciﬁcation, it is necessary to check at many points, which can add signiﬁcant time to the procedure.

ions must be met before performing these procedures:

n environment that meets the operating range speciﬁcations for

rform the Signal Path Compensation (SPC) operation described

in offset voltages between the equipment, which can invalidate the

me required to complete the entire procedure is approximately ten hours. To

WARNING. Some procedures use hazardous voltages. To prevent electrical

shock, always set voltage source outputs to 0 V before making or changing any

nnections.

84 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Performance Veriﬁcation

Self Test

This procedure passes its internal self tests. No test equipment or hookups are required.

1. Run the System

a. Disconnect everything from the oscilloscope inputs.

b. Push the front-panel Default Setup button.

c. Push the Utility menu button.

d. Push the Utility Page lower-bezel button.

e. Select Self Test.

f. Push the S

menu will be set to Loop 1 Times.

g. Push the

h. Wait. The internal diagnostics perform an exhaustive veriﬁcation of

proper

i. Verify that the status of all tests on the readout is Pass.

j. Push the Menu button twice to clear the dialog box and Self Test menu.

k. Cycle the power on the oscilloscope.

uses internal routines to verify that the oscilloscope functions and

Diagnostics (may take several minutes):

elf Test lower-bezel button. The Loop X Times side-bezel

OK Run Self Test side-bezel button.

instrument function. This veriﬁcation may take several minutes.

2. Run the signal path compensation routine (may take 5 to 15 minutes):

a. Push the front-panel Default Setup button.

b. Pus

c. Push the Utility Page lower-bezel button.

d. Select Calibration.

e. Push the Signal Path lower-bezel button.

f. Push the OK-Compensate Signal Paths side bezel button.

g. When the signal path compensation is complete, push the Menu button

h. Check the lower-bezel Signal Path button to verify that the status is Pass.

htheUtility menu button.

twice to clear the dialog box and Self Test menu.

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 85

Performance Veriﬁcation

Check Input Impedance

(Resistance)

This test check

1. Connect the output of the oscilloscope calibrator (for example, the Fluke

9500) to the os

WARNING. The generator is capable of providing dangerous voltages. Be sure to

set the generator to off or 0 volts before connecting, disconnecting, and/or moving the test hookup during the performance of this procedure.

2. Set the calibrator impedance to 1 MΩ.

3. Push the front-panel Default Setup button.

s the Input Impedance.

cilloscope channel 1 input, as shown below.

4. Set the oscilloscope impedance to 1 MΩ as follows:

a. Push t

b. Set the Termination (input impedance) to 1MΩ.

5. Set the Vertical Scale to 10 mV/division.

6. Measure the input resistance of the oscilloscope with the calibrator. Record

this value in the test record.

7. Repeat steps 5 and 6 for each vertical scale setting in the test record.

8. Repeat the tests at 250 kΩ as follows:

a. Set the calibrator impedance to 1 MΩ.

b.P

c. Push the Utility Page lower-bezel button.

d. Select Self Test.

e. Push the 250 kΩ Termination Veriﬁcation lower-bezel button to set the

f. Push the channel 1 side-bezel button to enable channel 1.

he channel 1 button.

ush the Utility front-panel button.

oscilloscope input impedance to 250 kΩ.

86 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Performance Veriﬁcation

g. Set the Vertica

h. Measure the input resistance of the oscilloscope with the calibrator.

Record this va

9. Repeat the tests at 50 Ω as follows (this step does not need to be done for products wi

a. Set the calibrator impedance to 50 Ω.

b. Set the oscilloscope impedance to 50 Ω as follows: Push the channel 1

button. Set the Termination (input impedance) to 50 Ω.

c. Repeat steps 5 through 7.

10. Repeat the procedure for all remaining channels as follows:

a. Push the front-panel channel button to deselect the channel that you

already tested.

b. Connect the calibrator to the input for the next channel to be tested.

c. Starting from step 4, repeat the procedure for each channel and AUX IN

input (models without the SA3 or SA6 option).

l Scale to 100 mV/division.

lue in the test record.

th the AUX IN input):

MDO4000C Series Speciﬁcations and Performance Veriﬁcation 87

Performance Veriﬁcation

Check DC B alance

This test check than a 50Ω terminator) to the oscilloscope to perform this check.

1. Attach a 50 Ω terminator to the oscilloscope channel 1 input.

2. Push the front-panel Default Setup button.

3. Set the input impedance to 50 Ω as follows:

a. Push the channel 1 button.

b. Set the Termination (input impedance) to 50 Ω.

4. Set the bandwidth to 20 MHz:

a. Push the lower-bezel Bandwidth button.

s the DC balance. You do not need to connect any equipment (other

b. Push the side-bezel button for 20 MHz.

5. Set the Horizontal Scale to 1msper division.

6. Set the Acquisition mode to Average as follows:

a. Push the front-panel Acquire button.

b. Push the Aver a g e side-bezel button.

c. Make sure that the number of averages is 16.

7. Set the trigger source to AC line as follows:

a. Push the Trigger Menu front-panel button.

b. Select the AC Line trigger source.

8. Set the Vertical Scale to 1mVper division.

9. Select the mean measurement (if not already selected) as follows:

a. Push the front-panel Wave Inspector Measure button.

b. Push the Add Measurement lower-bezel button.

c. Select the Mean measurement.

d. Push the OK Add Measurement side-bezel button.

e. View the Mean measurement value in the display.

88 MDO4000C Series Speciﬁcations and Performance Veriﬁcation

Tektronix MDO4024C, MDO4034C, MDO4054C, MDO4104C Performance Verification

Specifications and Main Features

Frequently Asked Questions

User Manual
