Preface
The DDA-06 External DAS Driver allows you to use Keithley MetraByte
DDA-06 and µ CDDA-04 boards with the following Keithley MetraByte
data acquisition and analysis software:
VIEWDAC
●
●
EASYEST LX
●
EASYEST AG
ASYST
●
This manual provides the information needed to use the DDA-06 External
DAS Driver with data acquisition and analysis software. Use this manual
in conjunction with your board user’s guide and with the documentation
for the data acquisition software you are using.
Note:
The DDA-06 External DAS Driver may support options your
software does not; likewise, your software may support options this
external driver does not.
v
If you need help, contact your local sales office or the Keithle y MetraByte
Applications Engineering Department between 8 am and 6 pm (Eastern
Time), Monday through Friday:
Keithley MetraByte
Applications Engineering
440 Myles Standish Boulevard
Taunton, Massachusetts 02780
Telephone 508/880-3000
Telex 503989
FAX 508/880-0179
vi
Table of Contents
Preface
Supported Hardware. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Options Supported . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Files on Disk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Quick Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Setting up the Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Running the Configuration Program. . . . . . . . . . . . . . . . . . . . . 2
Loading the DDA-06 External DAS Driver . . . . . . . . . . . . . . . 4
Accessing the DDA-06 External DAS Driver. . . . . . . . . . . . . . 5
Using the Configuration Program . . . . . . . . . . . . . . . . . . . . . . . . . 5
Menu Items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Special Purpose Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Exiting the DDA-06 Configuration Program . . . . . . . . . . . . . . 8
Configuring the DDA-06 External DAS Driver from DOS . . . . . . 8
DDA-06 External DAS Driver Characteristics . . . . . . . . . . . . . . 10
Analog Output. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Multiple-Point Data Transfers. . . . . . . . . . . . . . . . . . . . . . . . . 10
Digital I/O Port/Channel Numbering . . . . . . . . . . . . . . . . . . . 10
Software Interrupt Vectors. . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
DDA-06 External DAS Driver Error Messages . . . . . . . . . . . . . . 12
List of Tables
Table 1. Configuration Program Menu Items . . . . . . . . . . . . 6
Table 2. Digital I/O Port Configuration Modes. . . . . . . . . . . 6
Table 3. Configuration Menu Special Keys. . . . . . . . . . . . . . 7
Table 4. Command Line Options. . . . . . . . . . . . . . . . . . . . . . 9
Table 5. Digital I/O Port/Channel Configuration
Numbering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Table 6. Example of a Port/Channel Configuration Mode 2 11
Table 7. Interrupts and Environment Strings. . . . . . . . . . . . 12
Table 8. Error Messages from the DDA-06 External DAS
Driver. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
iii
Table 1. Configuration Program Menu Items . . . . . . . . . . . . 6
Table 2. Digital I/O Port Configuration Modes. . . . . . . . . . . 6
Table 3. Configuration Menu Special Keys. . . . . . . . . . . . . . 7
Table 4. Command Line Options. . . . . . . . . . . . . . . . . . . . . . 9
Table 5. Digital I/O Port/Channel Configuration Numbering .
11
Table 6. Example of a Port/Channel Configuration Mode 2 11
Table 7. Interrupts and Environment Strings. . . . . . . . . . . . 12
Table 8. Error Messages from the DDA-06 External DAS
Driver 13
µ
Using the DDA-06
External DAS Driver
The DDA-06 External DAS Driver allows your VIEWDAC,
EASYEST LX, EASYEST AG, or ASYST application program to
exchange data with the DDA-06 boards. This document describes how to
use the DDA-06 External DAS Driver.
Supported Hardware
The DDA-06 External DAS Driver supports the following Keithley
MetraByte data acquisition (DAS) boards:
●
DDA-06 (standard architecture)
●
CDDA-04 (Micro Channel
Options Supported
The DDA-06 External DAS Driver supports the following options:
●
Analog output operations
– Six 12-bit analog output channels on the DDA-06
– Four 12-bit analog output channels on the µ CDDA-04
– Internal clocking
– Internal triggering
Digital I/O operation
●
– 24 bits of digital I/O
– Internal clocking
architecture)
– Internal triggering
1
Files on Disk
Quick Start
The driver disk contains the file DDA06.EXE. DDA06.EXE controls the
boards and allows communication between an application program and
the DDA-06 and
CDDA-04 boards. DDA06.EXE executes as a
µ
terminate-and-stay-resident (TSR) program that occupies a small amount
of memory in your computer.
This section briefly describes how to configure, load, and access the
DDA-06 External DAS Driver.
Setting up the Board
Refer to your board user’s guide for information on setting the
jumpers/switches for the base address and the DAC (digital-to-analog
converter) output ranges. Remember these settings when you use the
DDA-06 External DAS Driver configuration program.
Running the Configuration Program
The DDA-06 External DAS Driver is set up for the following default
configuration:
Base address = 300h
●
●
DAC output range = ±10 V
●
Digital I/O port configuration mode = three 8-bit digital input
channels; no digital output channels
●
Number of boards = 1
Board type = DDA-06
●
2 Using the DDA-06 External DAS Driver
You must run the configuration program or configure the driver from
DOS if your board’s settings differ from these default settings. In
addition, whenever you change the hardware or software settings, you
must run the configuration program or reconfigure the driver from DOS in
order for the external DAS driver to function properly.
Notes:
For the
µ
CDDA-04 board, you must run this configuration
program in addition to the PS/2 configuration program for the board.
Each memory resident image of the DDA-06 External DAS Driver can
support two DDA-06 or
one DDA-06 or
µ
CDDA-04 board, you must configure the parameters for
µ
CDDA-04 boards. If you are using more than
each board, ensuring that the base address does not conflict between the
two boards.
Perform the following steps to run the configuration program:
1. Create a DDA06 subdirectory on your hard disk. For example, at the
DOS prompt, enter the following:
MKDIR DDA06
2. Copy DDA06.EXE from the driver disk into the DDA06 directory.
3. Enter the following at the DOS prompt:
CD \DDA06
DDA06 –MENU
Configure the board parameters using the configuration program, as
described in “Using the Configuration Program” on page 5.
Note:
If you wish, you can also configure the DDA-06 External DAS
Driver from DOS instead of using the configuration program; refer to
page 8 for more information.
3
Loading the DDA-06 External DAS Driver
You must load the DDA-06 External DAS Driver each time you start up
your computer in order for an application program to recognize it. The
external DAS driver remains in memory until the computer is turned off
or rebooted.
To load the DDA-06 External DAS Driver, access the directory
containing DDA06.EXE and enter the following at the DOS prompt:
DDA06
Notes:
automatically whenever you start the computer by adding the preceding
line to your AUTOEXEC.BAT file.
If you want to access more than two boards, load the driver multiple times
and use configuration files to recall the configurations.
For example, to access three DDA-06 boards you could create two
configuration files: DDA061.CFG and DDA062.CFG. DDA061.CFG
contains the configuration data for two boards at addresses 300h and
310h, and DDA062.CFG contains the configuration data for a single
DDA-06 board at address 340h. To load these drivers, use the @
command line option, as follows:
DDA06 @DDA061.CFG
DDA06 @DDA062.CFG
You can also load the DDA-06 External DAS Driver
4 Using the DDA-06 External DAS Driver
Accessing the DDA-06 External DAS Driver
Some application programs access the DDA-06 External DAS Driver
automatically . For information on accessing e xternal D AS dri vers, see the
documentation for your application program.
If you are using the ASYST program, perform the following steps to
access the DDA-06 External DAS Driver.
1. After loading the DDA-06 External DAS Driver, boot ASYST 2.10 or
greater and permanently load the Ext DAS Driver Support system
overlay from the Data Acquisition menu. ASYST automatically
searches for and creates a DAS device called DDA06.
2. Enter the following at the OK prompt to make DDA-06 the current
device:
DDA06
Using the Configuration Program
This section describes the configuration program’s menu items and
special purpose keys, and how to exit from the configuration program.
Menu Items
When you run the configuration program, the configuration menu is
displayed. The menu options, choices, and default values are listed in
Table 1.
5
Table 1. Configuration Program Menu Items
Menu Item Choices Default Value
Base I/O Address 200h to 3F0h (in multiples of 10h) 300h
DAC Output Range 0 = ±10 V 0 (±10 V)
1 = ±5 V
2 = ±2.5 V
3 = 0 to 10 V
4 = 0 to 5 V
5 = 4 to 20 mA
Digital I/O Port
Configuration Mode
Number of Boards 1, 2 1
Board T ype
0 to 12; see T able 2 for a description of
the available digital I/O port
configuration modes
DDA-06, µ
CDDA-04
Table 2 lists the the digital I/O port configuration modes available.
Table 2. Digital I/O Port Configuration Modes
Mode Input Output
0 three 8-bit channels —
1 two 8-bit channels one 8-bit channel
2 one 8-bit channels two 8-bit channels
3 — three 8-bit channels
4 two 12-bit channels —
5 one 12-bit channel one 12-bit channel
0 (three 8-bit digital
input channels; no
digital output channels)
DDA-06
6 — two 12-bit channels
7 one 16-bit channel one 8-bit channel
8 one 8-bit channel one 16-bit channel
6 Using the DDA-06 External DAS Driver
Table 2. Digital I/O Port Configuration Modes (cont.)
Mode Input Output
9 one 20-bit channel one 4-bit channel
10 one 4-bit channel one 20-bit channel
11 one 24-bit channel —
12 — one 24-bit channel
Special Purpose Keys
Table 3 describes the keys used for special purposes in the configuration
program.
Table 3. Configuration Menu Special Keys
Keys Description
[w] Write a response file. A response file is an ASCII file
containing the command line options for the current
configuration of the driver.
[q] Quit the configuration program without loading the
driver.
[d] Reset the driver settings to their default values.
[Esc] Exit the configuration menu with the option of saving
the current settings and loading the driver into memory.
[Tab] Toggle between boards 1 and 2 when two boards are
being configured.
[?] Invoke help on the current menu item.
7
Exiting the DDA-06 Configuration Program
To exit the configuration program without saving any changes, press [q].
Otherwise, to exit the configuration program press [Esc]. The following
prompt is displayed:
Do you want to permanently save this configuration?
[Y/N]
T ype [Y] to sa ve the configuration; type [N] if you do not w ant to sav e the
configuration settings. If the configuration is saved, the program displays
the message:
Remembering...
Then, you are prompted with the following message:
Exit Configuration Program? [Y/N]
T ype [Y] to exit from the configuration program; type [N] to remain in the
configuration program.
Configuring the DDA-06 External DAS Driver from DOS
If you wish, you can also change the configuration of the DDA-06
External DAS Driver using DOS command line options instead of using
the configuration program. The command line syntax is as follows:
DDA06 [
The command line options are described in Table 4.
bd #1 options
],[
bd #2 options
] [-menu ]
8 Using the DDA-06 External DAS Driver
Table 4. Command Line Options
Option Function
-a
###
-dio #
-DAC0 #
-DAC1 #
-DAC2 #
-DAC3 #
-DAC4 #
-DAC5 #
-4 Specify board type as µ CDDA-04
-6 Specify board type as DDA-06
? Help
-def Recall default driver settings
-menu Invoke menu-driven setup
@ filename
Board I/O address = ### (in hexadecimal);
see Table 1 on page 6
Digital I/O Port Configuration Mode = # ;
see Table 2 on page 6
DAC 0 output range = # ; see Table 1 on page 6
DAC 1 output range = # ; see Table 1 on page 6
DAC 2 output range = #; see Table 1 on page 6
DAC 3 output range = #; see Table 1 on page 6
DAC 4 output range = # ; see Table 1 on page 6
DAC 5 output range = #; see Table 1 on page 6
Indicates use of response file filename . A response
file is an ASCII file containing the command line options
for the driver.
9
DDA-06 External DAS Driver Characteristics
The following sections describe the various attributes of the DDA-06
External DAS Driver and the restrictions imposed by the external DAS
driver on various modes of operations and resources.
Analog Output
The DDA-06 external DAS driver supports simultaneous update of any or
all of the analog output channels.
For the DDA-06, set the jumper block marked “X” and “N” in the “X”
position for simultaneous update. For the µ CDDA-04, you select
simultaneous update through the PS/2 configuration program.
The maximum number of scans for this driver is one.
Multiple-Point Data Transfers
The DDA-06 External DAS Driver does not support clocked,
multiple-point data transfers. The driver can input or output only one
point per channel each time it is called. The driver returns an error if it
receives a request for more than one conversion per channel.
Digital I/O Port/Channel Numbering
Table 5 shows the possible port/channel configurations as well as the
assignment of digital channel numbers to the hardware digital ports.
10 Using the DDA-06 External DAS Driver
Table 5. Digital I/O Port/Channel Configuration Numbering
Input Output
Mode Channel 0 Channel 1 Channel 2 Channel 0 Channel 1 Channel 2
0 A B C – – –
1BC–A– –
2 C – – A B –
3–––ABC
4 A,C(0-3) B,C(4-7) – – – –
5 A,C(0-3) – – B,C(4-7) – –
6 – – – B,C(4-7) A,C(0-3) –
7A,C––B––
8 A – – B,C – –
9 A,B,C(0-3) – – C(4-7) – –
10 C(4-7) – – A,B,C(0-3) – –
11 A,B,C –––––
12 – – – A,B,C – –
For example, consider the configuration shown in Table 6 using
configuration mode 2.
Table 6. Example of a Port/Channel Configuration Mode 2
Input/
Output
Port
A Output – 0
B Output – 1
Configuration
Input
Channel#
Output
Channel#
C Input 0 –
11
When configured as shown in Table 6, a request to the driver to perform a
digital output operation on channel 0 means that the value is written to
port A. Writing to digital output channel 1 means that the value is written
to port B. A request to the driver to perform a digital input operation on
channel 0 means that the value is read from port C.
Software Interrupt Vectors
The DDA-06 External DAS Driver uses two software interrupt vectors to
communicate with the application program. The interrupt vectors used are
two of the MS-DOS “user interrupts” (interrupts 60h to 67h). To ensure
that conflicts with other devices, hardware, or programs do not exist, you
can set each of the interrupt vectors to use an interrupt number that is
different than from the default.
You can change the interrupt vector numbers by using the SET command
from DOS. This command saves a string in the DOS environment that the
driver searches for on loading. These strings are specified in Table 7.
Table 7. Interrupts and Environment Strings
Interrupt Default Interrupt
Number
Device linking vector 66h DAS DS=xx
Critical error vector 65h DAS CE=xx
Notes
1
xx is between 60h and 67h.
Environment
String
DDA-06 External DAS Driver Error Messages
Table 8 lists the error messages that may occur during operation of the
DDA-06 External DAS Driver.
1
12 Using the DDA-06 External DAS Driver
Table 8. Error Messages from the DDA-06 External DAS Driver
Error
Error Message Description
Number
0 No error No error message.
1 Function not supported A function was requested that is not supported by the
DDA-06 External DAS Driver.
2 Function out of bounds A function number not defined by the DDA-06
External DAS Driver was requested.
3 Non-valid board number A board number that is out of the range of configured
boards was requested. This driver supports a
maximum of two boards.
4 Non-valid error number A non-valid error number was detected by the external
DAS driv er function “REPORT ERROR MESSAGE.”
A request was made for an error message string that is
not defined.
5 D/A not initialized An analog output conversion was requested before the
DAC was initialized.
6 Digital input not
initialized
7 Digital output not
initialized
A digital I/O process was started before the digital
ports were initialized.
A digital I/O process was started before the digital
ports were initialized.
8 Too many conversions
requested
More than one conversion per channel was requested.
13
Loading...
