IConnect® and MeasureXtractor™
Signal Integrity, TDR, and S-parameter
ZZZ
Analysis Software
Installation
*P071267601*
071-2676-01
Copyright © Tektronix. All rights reserved. Licensed software products are
owned by Tektronix or its subsidiaries or suppliers, and are protected by national
copyright laws and international treaty provisions.
Tektronix products are covered by U.S. and foreign patents, issued and pending.
Information in this publication supersedes that in all previously published
material. Specifications and price change privileges reserved.
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
IConnect is a registered trademark of Tektronix, Inc.
MeasureXtractor is a trademark of Tektronix, Inc.
Contacting Tektronix
Tektronix, Inc.
14150 SW Karl Braun Drive
P.O. Box 500
Beaverton, OR 97077
USA
For product information, sales, service, and technical support:
In North America, call 1-800-833-9200.
Worldwide, visit www.tektronix.com to find contacts in your area.
Installing IConnect®, MeasureXtractor™ Version 6.0.1.X and Above
This CD includes all IConnect and MeasureXtractor software installation
packages. All software packages include the Sentinel hardware key drivers and
the S-parameter Wizard tool. There are four software packages to choose from:
IConnect Evaluation
The evaluation package is a free and fully functional IConnect and
MeasureXtractor™ software package with a limited number of uses and time
window of operation from its installation.
IConnect S-parameters and Z-line (80SSPAR)
The 80SSPAR is the minimum IConnect software package and includes all
application features except MeasureXtractor, modeling, and Eye Diagram
Viewer.
IConnect w/o MeasureXtractor (80SICON)
The 80SICON is the standard IConnect software package and includes all
application features except MeasureXtractor.
IConnect and MeasureXtractor (80SICMX)
The 80SICMX is the full IConnect software package and includes
MeasureXtractor, modeling, S-parameters, Eye Diagram Viewer, standards
compliance testing and more.
1
Installing IConnect®, MeasureXtractor™ Version 6.0.1.X and Above
Minimum System Requirements
Supported Tektronix sampling oscilloscope: DSA8300 (recommended),
DSA/CSA/TDS8200, CSA/TDS8000B, or CSA/TDS8000.
Microsoft Windows 7 Ultimate (32- and 64-bit) or XP on supported
oscilloscopes or PC.
TekVISA software: Required to run the S-parameter Wizard tool, or to
communicate with an oscilloscope over a local area network (LAN). (See
page 6.)
National Instruments GPIB board or a USB to GPIB adaptor: Not required
when running IConnect on supported Tektronix sampling oscilloscopes, or
when using TekVISA to connect a PC to a supported sampling oscilloscope
over a LAN).
External 1024 x 768 resolution monitor: Required when running IConnect on
all Tektronix 8000 series sampling oscilloscopes except the DSA8300.
2
Installing IConnect®, MeasureXtractor™ Version 6.0.1.X and Above
Installing the IConnect Software
You can install a newer version of an IConnect program over an existing version of
NOTE.
the same IConnect p rogram. However, if there are multiple IConnect programs installed
(such as IConnect and MeasureXtractor, IConnect Evaluation, and IConnect without
MeasureXtractor), use the Microsoft Windows
to uninstall all IConnect programs other than the one you are installing.
Do not use the Add/Remove Programs tool to uninstall the S-parameter Wizard
NOTE.
program; S-parameter Wizard is automatically uninstalled when you uninstall the parent
IConnect software program.
1.
Insert the IConnect software CD in the CD-ROM drive of a PC or a
Control Panel > Add/Remove Programs
supported Tektronix oscilloscope. The IConnect setup program should start
automatically. If you are upgrading to a newer version of IConnect, you do not
need to uninstall the existing version before installing the new version. The
install process does not delete any existing IConnect settings or results.
If the setup program does not start, access the CD-ROM drive and double-click
setup.exe
.
tool
3
Installing IConnect®, MeasureXtractor™ Version 6.0.1.X and Above
2.
4
Click
Next
on the installation startup screen.
Installing IConnect®, MeasureXtractor™ Version 6.0.1.X and Above
3.
Select the software item appropriate for your purchased IConnect product and
Next
click
with your software only functions with the purchased software product.
. You can only install one software item. The hardware key provided
4.
Read the License Agreement. Accept the terms and click
Follow on-screen prompts to install the IConnect software, S-parameter
Wizard tool, and Sentinel hardware key drivers.
5.
If prompted, restart the oscilloscope or PC to complete the installation.
Next
to continue.
5
Installing IConnect®, MeasureXtractor™ Version 6.0.1.X and Above
Install TekVISA for Remote Access
If you plan to run IConnect on a PC and acquire waveforms from an oscilloscope
connected to a LAN, or run the S-parameter Wizard function (on the oscilloscope
or remotely from a PC), you must install TekVISA software on your PC.
TekVISA is already installed on Tektronix DSA8300 oscilloscopes. Legacy Tektronix
NOTE.
sampling oscilloscopes will need to have the current version of TekVISA installed to
correctly operate with this version of IConnect.
Check which version of TekVISA is installed on your oscilloscope and PC (open
the TekVISA tool and click
go to the Tektronix Web site (www.tektronix.com/software), search for
Help > About
). If the version is earlier than 3.3.4.6,
tekvisa
,
and download version 3.3.4.6.
Follow the installation instructions provided with the TekVISA download file.
