AWG70BUP Option D01 & D02
AWG70CUP Option D01 & D02
AWG50BUP Option D01 & D02
AWG50CUP Option D01 & D02
ZZZ
Hard Disk Drive Upgrade Kit
Instructions
www.tektronix.com
P075104400*
*
075-1044-00
Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries
or suppliers, and are protected by national copyright laws and international treaty provisions.
Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication
supersedes that in all previously published material. Specifications and price change privileges reserved.
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
Contacting Tektronix
Tektronix, Inc.
14150 SW Karl Braun Drive
P.O . Bo x 50 0
Beaverto
USA
For product information, sales, service, and technical support:
n, OR 97077
In North America, call 1-800-833-9200.
Worl d wide , visi t www.tektronix.com to find contacts in your area.
Service Safety Summary
Only qualified personnel should perform service procedures. Read this Service
Safety Summary before performing any service procedures.
Do Not Service Alone. Do not perform internal service or adjustments of this
product unless another person capable of rendering first aid and resuscitation is
present.
Disconnect Power. To avoid electric shock, switch off the instrument power, then
disconnec
UseCareWhenServicingWithPowerOn. Dangerousvoltagesorcurrentsmay
exist in this product. Disconnect power, remove battery (if applicable), and
disconnect test leads before removing protective panels, soldering, or replacing
components.
To avoid electric shock, do not touch exposed connections.
t the power cord from the mains power.
Option D01 & D02 Upgrade Kit Instructions 1
Service Safety Summary
2 Option D01 & D02 Upgrade Kit Instructions
Upgrade Kit Overview
This kit provides parts and instructions for upgrading your AWG5000 and
AWG7000 series instrument with either a new solid state hard disk drive or with a
new mechanic
solid state disk drive as it is with the mechanical hard disk drive.
al hard disk drive. The instrument features are the same with the
Instruments
Option D01 u
hard disk drive.
Option D02
hard disk drive.
The hard d
and application software.
For a lis
your Tektronix representative.
These instructions support the following products:
AWG5000C Series Arbitrary Waveform Generator
AWG7000C Series Arbitrary Waveform Generator
AWG5000B Series Arbitrary Waveform Generator
AWG7000B Series Arbitrary Waveform Generator
E. Verify that you have received the correct version of the hard disk drive
NOT
for your instrument. The AWG5000B and AWG7000B Series instruments
have different operating systems than the AWG5000C and AWG7000C Series
instruments.
pgrades your Arbitrary Waveform Generator with a new solid state
upgrades your Arbitrary Waveform Generator with a new mechanical
isk drives come preprogrammed with the instrument operating system
t of available options, see the Tektronix Web site (www.tektronix.com) or
All m odels supported
All m odels supported
All m odels supported
All m odels supported
Minimum Tool and Equipment List
No special tools are required to install the upgrades.
Option D01 & D02 Upgrade Kit Instructions 3
Upgrade Kit Overview
Kit Contents
The upgrade kit contains the following items.
A solid state hard disk drive (Option D01) or a mechanical hard disk drive
(Option D02)
These instructions
Replace the Old Hard Disk Drive with a New Hard Disk Drive
These instructions are for qualified service personnel who are familiar
with servicing the product. If you need further details for disassembling or
reassembling the product, refer to the appropriate service manual. Contact
your near
installation assistance.
NOTE. Before replacing the hard disk drive, use an external back-up device to
back up any files on your instrument for use on the new hard disk drive.
est Tektronix, Inc., Service Center or Tektronix Factory Service for
The upgrade instructions are identical for both types of hard disk drives.
Install the hard disk drive using the following procedure:
1. Powe
2. Loosen the thumb screws and remove the old hard disk drive as shown.
3. Install the new hard drive as shown, and then tighten the thumb screws to
r off the instrument.
secure the drive in the instrument.
The following illustration shows the procedure for removing the old
mechanical hard disk drive and replacing it with a new solid state hard disk
ive. The process is similar for replacing an old mechanical hard disk drive
dr
with a new mechanical hard disk drive.
4 Option D01 & D02 Upgrade Kit Instructions
Upgrade Kit Overview
Option D01 & D02 Upgrade Kit Instructions 5
