Tektronix H500, SA2500 Service

xx

H500 Spectrum Analyzer,

ZZZ

SA2500 Spectrum Analyzer

Service Manual

*P077078600*

077-0786-00

xx

H500 Spectrum Analyzer,

ZZZ

SA2500 Spectrum Analyzer

Service Manual

Revision A

www.tektronix.com

077-0786-00

Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries
or suppliers, and are protected by national copyright laws and international treaty provisions.

Tektronix products are c overed by U.S. and foreign patents, issued and pending. Information in this publication
supersedes that in all previously published material. Specifications and price change privileges rese rved.

TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.

NetTek is a registered trademark of Tektronix, Inc.

Contacting Tektronix

Tektronix, Inc.
14150 SW Karl Braun Drive
P.O . Bo x 50 0
Beaverton, OR 97077
USA

For product information, sales, service, and t echnical support:

In North America, call 1-800-833-9200.
Worl d wide , visi t www.tektronix.com to find contacts in your area.

Warranty

Tektronix warrants that this product will be free from defects in materials and workmanship for a period of one (1)
year from the date of shipment. If any such product proves defective during this warranty period, Tektronix, at its
option, either will repair the defective product without charge for parts and labor, or will provide a replacement
in exchange for the defective product. Parts, modules and replacement products used by Tektronix for warranty
work may be n
the property of Tektronix.

ew or reconditioned to like new performance. All replaced parts, modules and products become

In order to o
the warranty period and make suitable a rrangements for the performance of service. Customer shall be responsible
for packaging and shipping the defective product to the service center designated by Tektronix, with shipping
charges prepaid. Tektronix shall pay for the return of the product to Customer if the shipment is to a location within
the country in which the Tektronix service center is located. Customer shall be responsible for paying all shipping
charges, duties, taxes, and any other charges for products returned to any other locations.

This warranty shall not apply to any defect, failure or damage caused by improper use or improper or inadequate
maintenance and care. Tektronix shall not be obligated to furnish service under this warranty a) to repair damage
result
b) to repair damage resulting from improper use or connection to incompatible equipment; c) to repair any damage
or malfunction caused by the use of non-Tektronix supplies; or d) to service a product that has been modified or
integrated with other products when the effect of such modification or integration increases the time or difficulty
of servicing the product.

THIS WARRANTY IS GIVEN BY TEKTRONIX WITH RESPECT TO THE PRODUCT IN LIEU OF ANY
OTHER WARRANTIES, EXPRESS OR IMPLIED. TEKTRONIX AND ITS VENDORS DISCLAIM ANY
IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.

TRONIX' RESPONSIBILITY TO REPAIR OR REPLACE DEFECTIVE PRODUCTS IS THE SOLE

TEK
AND EXCLUSIVE REMEDY PROVIDED TO THE CUSTOMER FOR BREACH OF THIS WARRANTY.
TEKTRONIX AND ITS VENDORS WILL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL,
OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF WHETHER TEKTRONIX OR THE VENDOR HAS
ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.

[W2 – 15AUG04]

btain service under this warranty, Customer must notify Tektronix of the defect before the expiration of

ing from attempts by personnel other than Tektronix representatives to install, repair or service the product;

Table of Contents

General safety summary ...... ................................ ................................ .................... iv

Service safety summary........................................................................................... vi

Preface ............................................................................................................. vii

Manual Content ................... .................................. ................................ ......... vii

Manual Conventions.................................... ................................ ..................... vii

Related User Documents.................................................................................... viii

Installation........................................................................................................... 1

Operating Information ............................................................................................. 2

Performance Verification ............... ................................ .................................. ......... 3

Preparation................................. ................................ .................................. ... 3

Test Record ...................... ................................ ................................ ............... 4

Procedures ...................................................................................................... 6

Test Descriptions.......................... ................................ .................................. ... 7

Verify Performance ........................................................................................... 12

Theory of Operation..... ................................ ................................ .......................... 23

Platform............ ................................ ................................ ............................ 23

Measurement Module .... ................................ .................................. .................. 31

Adjustment Procedures ........................................................................................... 33

Cleaning .... ................................ .................................. ................................ ...... 35

Removal and Replacement Procedures ......................................................................... 36

Preparation................................. ................................ .................................. .. 36

Preventing Electrostatic Damage ........................................................................... 37

Removal Procedures.......................................................................................... 37

Troubleshooting.................................................................................................... 47

Power On Self Test ................... ................................ .................................. ...... 48

Display Does Not Operate......... .................................. ................................ ........ 48

Display Image Inverted (Rotated 180°) .................................................................... 49

Touch Screen Does Not Operate ........................ ................................ .................... 49

Signal and Connector Information.......................................................................... 49

Lithium-Ion Battery Maintenance ... ................................ ................................ ............ 58

H500 and SA2500 Instrument-Specific Battery Maintenance ............. .............................. 60

Repackaging for Shipment ....................................................................................... 64

Replaceable Parts.................................................................................................. 65

Parts Ordering Information .................................................................................. 65

Using the Replaceable Parts List............................................................................ 65

Specifications ................ .................................. ................................ .................... 73

H500 & SA2500 Service Manual i

Table of Contents

List of Figure

Figure 1: Processor and backlight inverter board input and output connections . ... ... . . .. . ... . . .. . ... ... . 47

Figure 2: Mo

Figure 3: Mainframe replaceable parts...................... ................................ .................... 68

Figure 4: H500 and SA2500 accessories ....... ................................ ................................ 71

dule and cover replaceable parts ............................... ................................ .. 66

s

ii H500 & SA2500 Service Manual

List of Tables

Table 1: DB- 9F serial loop-back connector pin-out ................ ................................ .......... 10

Table 2: Test voltages and limits................................................................................. 11

Table 3: External ports and buses............................ .................................. .................. 26

Table 4: Internal ports and buses .......... ................................ .................................. .... 26

Table 5: Platform voltage supplies to module.................................................................. 29

Table 6: Tools required ....... ................................ .................................. .................. 36

Table 7: Backlight-related voltages.............................................................................. 48

Table 8: PCMCIA interface connectors JR420, JR520........................................ ................ 49

Table 9: Application module connector JR170 ................................................................ 50

Table 10: Internal speaker connector J110.............................. ................................ ........ 51

Table 11: External microphone connector J200............................ ................................ .... 52

Table 12: Power connector J240............................. ................................ .................... 52

Table 13: Front-panel switch/LED connector J120............................................................ 53

Table 14: Serial port connector J500...... .................................. ................................ .... 53

Table 15: JTAG port connector J670 .......................... ................................ .................. 53

Table 16: PS/2 keyboard connector J700 ... ................................ ................................ .... 54

Table 17: Headphone connector J300........................................................................... 54

Table 18: TFT color display connector J660 ................................................................... 54

Table 19: TFT backlight connector CN2 (Backlight Inverter Board) ....................................... 55

Table 20: Touch screen connector J4 and J2 ......... ................................ .......................... 55

Table 21: Ethernet connector J400 .............................................................................. 55

Table 22: USB 1.1 series A host connector J701 .............................................................. 56

Table 23: USB 1.1 series B slave connector J800 ................. ................................ ............ 56

Table 24: Backlight connector JR1 .............................................................................. 56

Table 25: General performance characteristics............................... .................................. 73

Table 26: Spectrum analyzer characteristics.................................................................... 75

Table 27: DPX measurement processing characteristics...................................................... 77

Table 28: Spectrogram (Rising Raster) measurement processing characteristics .......................... 78

Table 29: General purpose RF measurement characteristics ..................... ............................ 78

Table 30: Amplitude vs. Time measurement characteristics ... ... ... .. .. . ... ... ... . ... ... ... . ... ... ... . ... .. 79

Table 31: Signal analysis and monitoring characteristics ................... .................................. 80

Table 32: Environmental characteristics ........................................................................ 81

Table 33: Physical characteristics ......................... .................................. .................... 81

Table 34: Miscellaneous characteristics ........................................................................ 81

Table of Contents

H500 & SA2500 Service Manual iii

General safety summary

General safet

To avoid fire or personal

injury

ysummary

Review the fo
this product or any products connected to it.

To avoid pot

Only qualified personnel should perform service procedures.

While using this product, you may need to access other parts of a larger system.
Read the safety sections of the other component manuals for warnings and
cautions r

Use proper power cord. Use only the power cord specified for this product and
certified for the country of use.

Observe all terminal ratings. To av o id fire or shock hazard, observe all ratings
and markings on the p roduct. Consult the product manual for further ratings
information before making connections to the product.

The inputs are not rated for connection to mains or Category II, III, or IV circuits.

Power disconnect. The power cord disconnects the product from the power source.
Donotblockthepowercord;itmustremain accessible to the user at all times.

llowing safety precautions to avoid injury and prevent damage to

ential hazards, use this product only as specified.

elated to operating the system.

Do not operate without covers. Do not operate this product with covers or panels
removed.

Do not operate with suspected failures. If you suspect that there is damage to this
product, have it inspected by qualified service personnel.

Avoid exposed circuitry. Do not touch exposed connections and components when
power is present.

Replace batteries properly. Replace batteries only with the specified type and
rating.

Recharge batteries properly. Recharge batteries for the recommended charge cycle
only.

Use proper AC adapter. Use only the AC adapter s pecified for this product.

Do not operate in an explosive atmosphere.

iv H500 & SA2500 Service Manual

General safety summary

Terms in this manual

Symbols and terms on the

product

These terms may

WAR N ING. Warning statements identify conditions or practices that could result

in injury or loss of life.

CAUTION. Caution statements identify conditions or practices that could result in

damage to this product or other property.

These terms may appear on the product:

DANGER in
the m arking.

WAR NI NG
read the marking.

CAUTIO

The following symbol(s) may appear on the product:

appear in this manual:

dicates an injury hazard immediately acc essible as you read

indicates an injury hazard not immediately a ccessible as you

N indicates a hazard to property including the product.

H500 & SA2500 Service Manual v

Service safety summary

Service safet

ysummary

Only qualifie
safety summary and the General safety summary before performing any service
procedures.

Do not service alone. Do not perform internal service or adjustments of this
product unless another person capable of rendering first aid and resuscitation is
present.

Disconnect power. To avoid electric shock, switch off the instrument power, then
disconnect the power cord from the mains power.

Use care when servicing with power on. Dangerous voltages or currents may exist
in this p
test leads before removing protective panels, soldering, or replacing components.

To avoi

d personnel should perform service procedures. Read this Service

roduct. Disconnect power, remove battery (if applicable), and disconnect

d electric shock, do not touch exposed connections.

vi H500 & SA2500 Service Manual

Preface

Preface

Manual Content

Manual Conventions

This service

This manual
of the H500 and SA2500 Spectrum Analyzers, and running a performance
verification on the whole instrument. The module part of the instrument has no
user-serviceable parts or adjustments. The entire instrument must be returned to
Tektronix if service is required.

For information related to installing and operating the instrument, or for a list of
instrument specifications, refer to the appropriate user document as described in
Related User Documents below.

Be sure to read the introductions to all procedures. These introductions provide
important information needed to perform the service correctly, safely, and
efficie

manual uses certain conventions that you should become familiar with

This
before attempting service.

manual is for servicing the H500 and SA2500 Spectrum Analyzers.

contains information related to servicing the mainframe part

ntly.

Module

Replaceable Parts

Safety

The term module refers to a collection of items that are replaceable as a unit. A

ule may contain electrical and mechanical assemblies, circuit boards, and

mod
interconnecting cables.

This manual refers to any field-replaceable assembly or mechanical part by its

ame or generically as a replaceable part. In general, a replaceable part is any

n
circuit board or assembly that is listed in the Replaceable Parts section.

Symbols and terms related to safety appear in the General Safety Summary found
at the beginning of this manual. Be sure to read both the General Safety Summary
and Service Safety Summary before performing any service to this instrument.

H500 & SA2500 Service Manual vii

Preface

Related User Documents

The following related English user documents are available if you need more
information about operating the instrument. The user manuals can be downloaded
from the Tektronix Web site (www.tektronix.com).

User manual. Tektronix part number 071-3115-xx (for the H500) and
Tektronix part number 071-XXXX-xx (for the SA2500) contain general
information about how to put the instrument into service, guides to user
interface

Online Help. The H500 and SA2500 Spectrum Analyzer applications contain
online he
the active screen or the selected help button.

controls, and application examples.

lp that is context sensitive, displaying information appropriate for

viii H500 & SA2500 Service Manual

Installation

The Specifications section contains information on instrument operation
environment requirements. (See Table 32 on page 81.)

H500 & SA2500 Service Manual 1

Operating Information

Operating Inf

ormation

Refer to the i

nstrument user manual for operation instructions.

2 H500 & SA2500 Service Manual

Performance Verification

Performance V

Preparation

erification

This section
warranted characteristics.

Before you perform the procedures in this manual, do the following steps:

Ensure tha
who have read the General Safety Summary at the front of this manual.

Ensure th
to the product user manual).

Obtain t
additional cables and adapters, depending on the actual test equipment you use.

Description Minimum requirements Examples

Signal generator

Frequency standard

Power meter with head 0.009 to 6200 MHz, -52 dBm

Oscilloscope

10 dB fixed attenuator

50 ohm N-type RF cable 0.009 to 6200 MHz

50 ohm BNC cables

N-type barrel
female-to-female adapter

enables you to verify that the instrument performs according to its

t the procedures are performed only by qualifie d service personnel

at the s ervice personnel are familiar with system operation (refer

he equipment described in the following table. You may also need

0.009 to 6200 MHz,
phase noise better than

-110 dBc/Hz at 10 kHz offset

10 MHz (or any frequency in
therange1MHzto20MHz
in 1 MHz increments), ±0.05
ppm

to +3 dBm

300MHz band width

0.009 to 6200 MHz

None Tektronix part number

0.009 MHz to 6200 MHz

Anritsu MG3692B with
option 22 (low frequency),
option 3 (low phase noise,
main band), and option 4
(low phase noise, low band)

Fluke 910/910R GPS
Controlled Frequency
Standards

Agilent E4418B

Agilent E9304A

Tektronix TDS3034B

RLC Electronics A-8-10-N

Florida RF Labs NMS ­290 AN - 36.0 - NMS

012-0482-00

SRI Connector Gage Co.
P/N 53-953-0003-00

H500 & SA2500 Service Manual 3

Performance Verification

Test Record

Serial number Procedure performed by

Date

Test Passed Failed

Self Test

Performance checks

Carrier Frequency
and Timebase Error

External Lock Time

RF Channel Power
Accuracy

Tested at 6 GHz

10 MHz (typical) Reference Freq

50 MHz, -5 dBm Input - 1.2 dB +1.2 dB

3200 MHz, -5 dBm Input - 1.2 dB +1.2 dB

Low limit Test result High limit

-3010 Hz

-9010 Hz

-15010 Hz

1

2

3

-

5000 MHz, -5 dBm Input -1.8 dB +1.8 dB

6199 MHz, -5 dBm Input -1.8 dB +1.8 dB

50 MHz, -20 dBm Input -1.2 dB +1.2 dB

3200 MHz, -20 dBm Input -1.2 dB +1.2 dB

5000 MHz, -20 dBm Input -1.8 dB +1.8 dB

6199 MHz, -20 dBm Input -1.8 dB +1.8 dB

50 MHz, -35 dBm Input -1.2 dB +1.2 dB

3200 MHz, -35 dBm Input -1.2 dB +1.2 dB

5000 MHz, -35 dBm Input -1.8 dB +1.8 dB

6199 MHz, -35 dBm Input -1.8 dB +1.8 dB

Phase Noise

Displayed Average
Noise Level

100 MHz Input, 10 kHz, offset

3000 MHz Input, 10 kHz offset

5000 MHz Input, 10 kHz offset

6000 MHz Input, 10 kHz offset

1MHzto4GHz

1

2 GHz to 4 GHz

-

-

-

-

4 GHz to 5 GHz

5GHzto6.2GHz

Residual Spurious,
Preamp On

1

Use this limit if testing shortly after instrument calibration.

2

Use this limit if testing one year after instrument calibration.

3

Use this limit if testing two years after instrument calibration.

4

The following are exception frequencies (not warranted to specification):

9 MHz to 19 MHz center frequency

5374 MHz to 5378 MHz center frequency

4

-60 dBm ref level

3010 Hz

9010 Hz

15010 Hz

15 s

-95 dBc/Hz

-95 dBc/Hz

-95 dBc/Hz

-95 dBc/Hz

-153 dBm

-152 dBm

-151 dBm

-145 dBm

-105 dBm

4 H500 & SA2500 Service Manual

Performance Verification

Instrument Warmup

Equipment Setup

Before perform
operating continuously for at least twenty (20) minutes in an environment that
meets the operating range specifications for temperature and humidity:

The H500 or SA2500 under test

All test equ

Setup the test equipment as follows:

1. Reset all the test instruments to their factory default settings before starting a
test.

2. Connect the RF cable to the output of the Signal Generator; all test instructions
make this assumption.

3. Connect the AC adapter to the H500 or SA2500 instrument. Do not attempt to
do the procedure steps while the instrument is powered from the batteries.

ing these procedures, the following equipment must have been

ipment

H500 & SA2500 Service Manual 5

Performance Verification

Procedures

A test record table is provided. (See page 4, Tes t Re cord .) You can photocopy the
page and record your test results in the table.

Diagnostic Tests

This section contains procedures to verify that the instrument platform is
functioning properly.

1. Select Start > Programs > Tektronix Utilities > Diagnostics.

2. Tap t he Dia

3. To view the test selections, tap the + symbol in front of All Modules, All
Tes ts.Th

4. Select the test(s) to run. The default selection runs all tests. However,

some diagnostic tests require special equipment or custom fixtures (such as
aDB­PS/2-compatible keyboard, Microphone, USB Flash Memory Device, and a
network interface connected to a DHCP-enabled network server). Clear the
box next to any test that requires equipment or custom fixtures that you do not
have available for the tests, o therwise these tests will indicate that they fail.

gnostics tab.

en tap the + symbol in front of Platform.

9F serial loopback connector, PCMCIA ATA flash memory cards,

5. Select one of the test run options:

Loop. Use the up/down arrows to set how many times to repeat the test(s).

Until Fail. Run the selected test(s) until a failure occurs or the user selects

Stop.

Continuous. Run the selected test(s) until the user selects Stop.

6. Tap Run to begin the tests.

6 H500 & SA2500 Service Manual

Performance Verification

Test Descr

Vertica

iptions

lLineTest

Test Results Re

report the results of each test.

The Last Resul

The Fail Count column lists the number of times a test failed.

The Loop Count field reports the number of times the test ran.

To see details on failed tests, select the Failure Log tab and read the Message
column.

Some diagnostic tests require special equipment or custom fi xtures. These
requirements are noted under each description.

Observe a full screen of moving vertical lines.

1. Look for inconsistent line w idths and lengths.

2. Report a Pass or Fail when prompted.

A Test
response when prompted.

failed is recorded in the F ailure Log if the user does not enter a pass/fail

porting. The Diagnostics window contains columns and fields to

t column lists the Pass or Fail status of each test.

Horizontal Line Test

Color Range Test

Observe a full screen of moving horizontal lines.

1. Look for inconsistent line w idths and lengths.

2. Report a Pass or Fail.

A Test failed is recorded in the Failure Log if the user does not enter a pass/fail
response when prompted.

Observe two different color test patterns.

attern 1, look for color fading and inconsistencies while observing red,

1.P

green, and blue color bands on a white background.

2. Pattern 2, look for color inconsistencies (failed pixels) while observing three
different full color screens (red, green, blue).

3. Report a Pass or Fail when prompted.

A Test failed is recorded in the Failure Log if the user does not enter a pass/fail
response when prompted.

H500 & SA2500 Service Manual 7

Performance Verification

Brightness Test

LED Test

Touch S

creen Test

Observe a full s

1. Look for adequate brightness at each level.

2. Report a Pass or Fail when prompted.

A Test failed is recorded in the Failure Log if the user does not enter a pass/fail
response when prompted.

The display returns to its original brightness at test completion.

Observe a series of front-panel LED color cycles.

1. Look for t

2. Report a Pass or Fail when prompted.

A Test failed is recorded in the Failure Log if the user does not enter a pass/fail
response when prompted.

Observe a crosshair cursor that moves from screen center to top-left, top-right,
bottom-right, and bottom-left.

1. At each position, press on the center of the crosshair icon until it moves.
Use the stylus or your finger.

creen checkerboard pattern that changes brightness.

he color and position indicated: left-right, green, red, and amber.

Keyboard Test

Pass is reported if the sequence is completed within the allotted time.

Test failed is recorded in the Failure Log if no user interaction is detected or the
user presses outside of the crosshair area.

Check the keyboard cable connection to the instrument; check the function of
each key.

NOTE. This test requires an external PS/2 keyboard.

1. Connect a PS/2-compatible keyboard to the keyboard port. Refer to the user
manual for port location.

2. Select Keyboard Test; then select Run.

3. Enter the requested text on the keyboard when prompted; then select OK.

The text must be duplicated exactly or the test will fail.

This test reports a Fail if a keyboard is not connected or the user misspells the
message.

8 H500 & SA2500 Service Manual

Performance Verification

Audio Test

PCMCIA Slot 1 Test

Check the exter

1. Plug a microphone into the external microphone jack.

2. Select Audio Test; then select Run.

3. When prompted, speak into the microphone for approximately 5 seconds.

The device will then automatically play back your message.

4. Listen to the playback and verify its accuracy. The test fails if there is no
output or if the audio is significantly distorted.

5. Report a Pass or Fail when prompted.

A Test fai
response when prompted.

CheckthePCMCIAcontrollerconnectiontoanATAflash card in Slot 1. The test
uses sta
read the file back, and validate the data.

NOTE. This test requires two PCMCIA ATA flash memory cards. Both cards must

be installed for the test to run successfully.

ndard API functions to create a file on the device, write data to the file,

nal microphone and speaker operation.

led is recorded in the F ailure Log if the user does not enter a pass/fail

PCMCIA Slot 2 Test

1. Install two PCMCIA ATA flash memory cards, one in each of the PCMCIA
card slots.

2. Select PCMCIA Slot 1 Test,thentapRun.

A Test failed is recorded in the Failure Log if a memory card is not installed
when prompted.

eck the PCMCIA controller connection to an ATA flash card in Slot 2. Uses

Ch
standard API functions to create a file on the device, write data to the file, read the
file back, and validate the data.

NOTE. NOTE. This test requires two PCMCIA ATA flash memory cards. Both

cards must be installed for the test to run successfully.

1. Install two PCMCIA ATA flash memory cards in the PCMCIA card slots.

2. Select PCMCIA Slot 2 Test; then select Run.

A Test failed is recorded in the Failure Log if a memory card is not installed
when prompted.

H500 & SA2500 Service Manual 9

Performance Verification

Network Port Test

Serial Port Test

Checks the Ethe

rnet network port. Requires a network connection with a DHCP

server.

1. Connect the Ne

tTek Analyzer Platform RJ45 Ethernet port to a DHCP-enabled

network server.

2. Select Netw

ork Port Test; then select Run.

A Test failed is recorded in the Failure Log if the NetTek Analyzer cannot obtain
an I.P. addr

ess from the DHCP-enabled network server.

Check the serial port signal lines by setting the output control lines and reading
the corresponding status lines. Writes, reads, and validates a data pattern at
varying b

aud rates.

NOTE. This test requires a custom DB-9F serial loop-back connector.

Table 1: DB- 9F serial loop-back connector pin-out

Connect pin

1 (DCD) 4 (DTR)

6 (DSR) 4 (DTR)

2(RX) 3(TX)

5(SGND) NC

8(CTS) 7(RTS)

9(RI) 7(RTS)

To pi n

1. Install the custom DB-9 loop-bac k connector on the RS-232 serial port. Refer
to the user manual for port location.

2. Select Serial Port Test; then select Run.

A Test failed is recorded in the Failure Log if the loop-back connector is not
installed when prompted.

10 H500 & SA2500 Service Manual

Performance Verification

USB Flash Memory Device

Test

SPI Test

Tests the USB po

NOTE. This test requires a USB Flash Memory Device inserted into the USB slot.

If a Flash Memory Device is not installed when the test is initiated, the user is
prompted to insert a Flash Memory Drive or fail the test. The test consists of
the following:

Creating a data file

Writing a fixed size pattern to the file

Closing the file

If an error occurs during any portion of the test, the test terminates and reports a
Test failed in the Failure Log. A Test failedisalsorecordedifaFlashMemory
Drive is not install

Check the external connectivity and function by setting the instrument module
interface port to loop back mode and sending, receiving, and validating device
selects and frequency changes.

No user interaction required. Select Run.

rtusingaFlashMemorydrive.

ed when prompted.

SMBus Te

st

Flash File System Test

Power Test

Verify communications between the host and power management processor.

No user interaction required. Select Run.

Check the read/write function and data integrity of the internal flash file system.
The test uses standard API functions to create a file, write a data pattern to the
file, read the file, and validate the data.

Verify the instrument platform processor board and application module voltages
are within their nominal range. See Table 3-2 for voltage limits.

NOTE. The Power Test does not check battery voltages.

This test uses internal voltage sensing. No user interaction required. Select Run.

Table 2: Test voltages and limits

Source Voltage (VDC) Limits (VDC)

Processor board +1.5

Processor board +3.3

10%

10%

H500 & SA2500 Service Manual 11

Performance Verification

Table 2: Test voltages and limits (cont.)

Verify Performance

Processor board

Application module +3.4

Application module +13

Application module -13

+5

10%

10%

10%

10%

This test reports a fail if the detected voltages exceed ±10% of their nominal
values.

Before continuing these procedures, warm up the instrument and all other test
equipment for at least twenty (20) minutes in an environment that meets the
operating range specifications for temperature and humidity.

To warm up the instrument:

1. Connect the AC adapter to the H500 or SA2500 instrument. Do not attempt to
do the procedure steps while powered from the batteries.

2. Power on the instrument. Wait until it completes the power-on sequence.

3. Double-tap the H500 or SA2500 application icon on the screen to open and

run the instrument application. Leave the application running.

Check Carrier Frequency

and Time-base

This test checks the accuracy of the carrier frequency measurement and the
accuracy of its internal time-base.

1. Remove any cable attached to instruments Freq Ref BNC.

2. Reset the instrument application:

a. Select Tools > Factory Reset.

b. Tap Reset All.

3. Connect the Signal Generator output to the H500 under test RF IN PUT

connector through the RF cable.

4. Set the Signal Generator as follows:

a. Reset the Signal Generator.

b. Connect the Frequency Standard output to the frequency reference input

of the Signal Generator marked REF.

c. Set the Signal Generator lock to the external reference input.

d. Verify that the Signal Generator displays is locked to the external

reference.

12 H500 & SA2500 Service Manual

Performance Verification

e. Set frequency t

f. Set the amplitude to 10dBm.

5. On the H500 or SA2500 application:

a. Tap the Spectrum drawer.

b. Tap the Freq button to open the Meas Freq form and enter 6GHz.

c. Ta p th e Auto Level button.

d. If you don'

increase the signal span.

e. Ta p the Me

ensure the red triangle is the selected marker; the red triangle will be
displayed on the marker button in the Spectrum drawer.

f. Using the marker drop-down box in the Spectrum drawer, select "Marker

to max p eak" then select "Marker to center freq".

g. Reduce the displayed signal span by tapping the arrow icon on the left of

the Span: field.

h. Repeat steps g through h until the signalpeakiscenteredinthedisplay

and the span is 0.010 MHz.

o 6 GHz.

t see the signal, tap on the Span: field right arrow button to

as Freq marker readout box just above the Start button to

i. Read the marker frequency value from the Meas Freq marker readout box.

j. Writ

k. Subtract 6 GHz from the measured frequency. Check that the result is

edowntheFREQ: measurement.

hin the limits listed in the Test Record.

wit

H500 & SA2500 Service Manual 13

Performance Verification

Check External Lock Time

This test check

1. Reset the H500 or SA2500 application:

a. Select Tools > Factory Reset.

b. Tap Reset All.

2. On the Signal Generator:

a. RESET the Signal Generator.

b. Connect a B

generator.

3. On the H50

a. Make sure that the reference oscillator indicator, near the upper right

corner o

b. Connect the BNC cable from the signal generator's 10 MHz Reference

Out to t

time.

c. Wa tch

Ext, record the time.

s the lock time o f the external frequency reference input.

NC cable to the external reference output of the Signal

0 or SA2500:

f the screen, is indicating FInt.

he H500 FREQUENCY REF ERENCE INPUT andrecordthe

the reference oscillator indicator; when it changes from FIntto F

Check RF Channel Power

racy

Accu

d. The di

This test checks the accuracy of the RF channel power measurement.

1. Reset the H500 or SA2500 application:

a. Select Tools > Factory Reset.

b. Tap Reset All.

2. Set the H500 or SA2500 application to read channel power:

a.D

b. Tap t he RF Measure drawer.

c. Select Channel Power from the Measurement drop-down list, tap the

3. Connect a 10 dB attenuator to the RF cable. (The attenuator improves the

impedance match between the Signal Generator and the H500/SA2500 under
test.)

4. Connect an N-type bar rel adapter (female-to-female) to the attenuator.

fference between the two times is the result of the test. The time

should be 15 seconds or less.

isplay a Spectrum measurement.

Meas BW field, tap the keypad icon on the Meas BW dialog box, and
enter 10 kHz.

14 H500 & SA2500 Service Manual

Performance Verification

5. Set the Signal G

a. Reset the Signal Generator.

b. Set the frequency to 50 MHz.

c. Set the output level to +5 dBm.

6. Push the ZERO buttononthepowermeter.

7. Connect the power meter head to t

8. Perform a power measurement using the power meter:

a. Set the power meter correction factor for 50 MHz.

b. Read the power.

9. Adjust the output level of the Signal Generator until the power meter reads

-5 dBm.

10. Disconnect the power meter head and the barrel adapter from the cable/10 dB

attenuator assembly.

11. Connect the RF cable with the 10 dB attenuator to the RF INPUT of the
H500 or SA2500 under test.

12. On the H500 or SA2500:

enerator as follows:

he barrel adapter.

a. Tap the Freq buttontoopentheMeas Freq dialog and enter 50 MHz.

b. If you don't see the signal, tap on the Span: field right arrow button to

increase the signal span.

c. Ta p th e Auto Level button.

d. Tap the Meas Freq marker readout box (just above the Windows CE

Start button) to set the red measurement triangle as the selected (active)

marker. The red triangle will be displayedontheMarker-Tobuttonin
the Spectrum drawer.

e. Ta p the Spectrum drawer button.

f. Tap the down arrow button next to the Marker-To button and select

Marker to max peak.ThenselectMarker to center freq to move the

peak of the test signal to the center of the display.

g. Reduce the displayed signal span by tapping the arrow icon on the left of

the Span: field.

h. Repeat steps f through g until the signalpeakiscenteredinthedisplay

and the span is 10 kHz.

i. Read the Channel Power in dBm; the Channel Power is displayed in the

trace area if the Spectrum drawer is open or displayed on the Channel
Power tab if the RF Measure drawer is open.

H500 & SA2500 Service Manual 15

Performance Verification

j. Subtract the no

write it down in the Test Record; this is the result of the test.

k. Disconnect th

of the H500 or SA2500 under test.

13. Repeat step
Record.

minal power (-5 dBm) from the measurement value and

e RF cable with the 10 dB attenuator from the RF INPUT

s3through12forallfrequenciesandlevelslistedintheTest

16 H500 & SA2500 Service Manual

Performance Verification

Check Phase Noise

This test deter
Signal Generator used in the test should have significantly less phase noise than
the H500 or SA2500 under test.

NOTE. The peak detector is used to measure narrowband signals such as the

CW signal from the signal source and the average detector is used to measure
wideband signals such as noise floor.

Signal Generator setup.

1. Reset the signal generator.

2. Set the frequency to 100 MHz (center frequency).

3. Set the output power level to +10 dBm.

4. Connect the RF cable from the signal generator output to the H500 or SA2500
under test RF INPUT connector.

H500/SA2500 setup.

1. Disconnect the cable from the H500/SA2500 FREQ REF connector if present.

2. Select Tools > Factory Reset

mines the phase noise of the H500 or SA2500 under test. The

3. Tap Reset All.

Phase noise verification.

Do the following steps from the H500/SA2500:

1. Tap the Spectrum drawer.

2. Tap the More buttonintheSpectrumdrawer.

3. Tap the Freq/Span tab and set Span to 100.000 kHz and Center Freq to

100.000 MHz.

4. Tap the Tr ac e tab and set the following:

Type to Avera g e

Number of Averages to 20 (default)

Detector to +Peak

5. Tap the AutoLevel button.

6. Tap the Meas Freq marker readout box (just above the Windows CE Start

button) to set the red measurement triangle as the selected (active) marker.
The application also updates the Marker-To button in the Spectrum drawer
to show the red measurement triangle icon, indicating that the Marker-To
button will act on the Meas Freq marker.

H500 & SA2500 Service Manual 17

Performance Verification

7. Tap the down arr

ow button next to the Marker-To button and select Marker
to max peak. ThentapthedownarrowbuttonnexttotheMarker-Tobutton
again and select Marker to center freq to move the peak of the test signal
to the center of the display.

8. Verify that the Span is still 100 kHz and the Meas Freq marker box and center
frequency readouts are both 100 MHz.

9. Write down the level of the signal as shown in the Meas Freq marker readout
box; this is the carrier level value L

.

c

10. Tap the Tra ce tab and set the following:

Type to Avera g e

Number of

Average s to 100

Detector to Avg (VR M S)

11. Write down the center frequency.

12. Tap t he M1 marker readout box on the bottom of the screen to open the M1

input control.

13. Tap the keypad icon in the M1 control and enter the center frequency
minus 10 kHz (offset). For example, a minus 10 kHz offset for 100 MHz
is 99.990 MHz.

14. Tap t he M2 marker readout box on the bottom of the screen to open the M2
input control.

15. Tap the keypad icon in the M2 control and enter the center frequency
plus 10 kHz (offset). For example, a plus 10 kHz o ffset for 100 MHz is

0.010 MHz.

10

16. Determine the total sideband noise level:

a. Tap the Reset display-control button (the X button located along the right

side of the waveform plot) to reset the measurement, then wait until the

nstrument averages the 100 measurements.

i

b. Write down the M1 marker value; this is the lower sideband noise level

LN

.

ssb1

c. Write down the M2 marker value; this is the upper sideband noise level

LN

ssb2

.

17. Determine the noise floor l evels:

a. Turn off the signal generator.

b. Tap the Reset display-control button (the X button located along the right

side of the waveform plot) to reset the measurement, then wait until the
instrument averages the 100 measurements.

18 H500 & SA2500 Service Manual

Performance Verification

c. Write down the M

LNF

ssb1

.

d. Write down the

LNF

18. Obtain the s

output (LN

.

ssb2

ignal generator phase noise level at 10 kHz offset for 100 MHz

). This may be the typical phase noise performance stated in the

sg

1 marker value; this is the lower sideband noise floor

M2 marker value; this is the upper sideband noise floor

signal generator user manual or specification sheet, or it may be the actual
measured phase noise data for the signal generator. The signal generator’s
guaranteed specification limit should not be usedsincethatmayleadtoan
underestimate of the H500 or SA2500 phase noise.

For the Agilent signal generator shown in the Required Equipment list, use the
following values for the signal generator phase noise level LN

:

sg

100 MHz: -143 dBc

3to6GHz: -113dBc

19. Write down the Resolution Bandwidth displayed in the Spectrum drawer
below RBW, in H z. Use this RBW value, and values obtained earlier in this
procedure, to calculate the phase noise by using the following formulas:

[in dBc/Hz]

[in dBc/Hz]

20. Verify that the phase noise is less than -95 dBc/Hz.

21. Repeat Phase Noise Verification steps 1 through 20, readjusting the signal

generator for all center frequencies noted in the Test Record.

H500 & SA2500 Service Manual 19

Performance Verification

Check GPS function

This test deter

NOTE. The GPS antenna should be placed so that it has an unobstructed view of

the sky. If the antenna is inside a building, it may not be able to locate any GPS
signals due to signal attenuation caused by the building.

1. Reset the H500 or SA2500 application:

a. Select Tools > Factory Reset.

b. Tap Reset A

2. Connect the GPS antenna to the GPS connector on the i nstrument and position

the anten

a. Tap t h e GPS button on the main screen.

b. Roll down the menu and select Tek Internal GPS from the GPS Receiver

c. Wait until five or more green bars show in the Satellite Signal Strength

d. Check that the GPS Lock icon turns green.

mines if the H500 or SA2500 built-in GPS functions properly.

ll.

na so that it has a clear view of the sky.

drop-down list.

window.

e. Check that the Satellites in Use status field readout is ≥ 5 .

20 H500 & SA2500 Service Manual

Performance Verification

Check Displayed Average

Noise Level (DANL)

This test check
bandwidth).

NOTE. The DANL measurement is a measure of average noise and does not

include spurious signals. If the marker is placed on a spurious signal, it should be
moved slightly to the left or right to avoid the spurious signal.

1. Reset the H500 or SA2500 application:

a. Select Tools > Factory Reset.

b. Tap Reset All.

2. Connect a 50 Ω RF terminator to the H500 or SA2500 under test RF INPUT

connector. Disconnect the external reference.

a. Tap the Freq button and enter 1000 MHz.

b. Set the SPAN to 10 kHz.

c. Set the

d. Tap the Spectrum drawer.

e. Ta p th e More button.

s the H500 or SA2500 DANL with 10 Hz RBW (resolution

Ref Level to -60 dBm.

f. Tap the Trac e tab.

g. Change the detector to Aver a g e mode.

h. Select Average from the Tr a ce 1 t yp e : drop-down men.

i. Tap

j. Place a marker near the center frequency and read the marker dBm value.

3. Change the Freq to 3200 MHz, 5000 MHz and 6199 MHz and repeat step j.

the x button to close the tabs.

the marker is on a spurious signal, the marker should be moved slightly

If
to the left or right to avoid the spurious signal. Record this value in the
test record.

H500 & SA2500 Service Manual 21

Performance Verification

Check Residual Spurs

This test check
manual test, it is simplified to look for gross defects instead of a more rigorous
check.

1. Reset the H500 or SA2500 application:

a. Select To ol

b. Tap Reset All.

2. Connect a 50 Ohm RF terminator to the H500 or SA2500 under test RF
INPUT connector. Disconnect the external reference.

a. Tap t h e Spectrum drawer.

b. Tap the More button.

c. Ta p the Tra c e tab.

d. Change Type to Av e ra ge .

e. Change

f. Tap the Ampl tab.

g. Set the Ref Level to -60 dBm.

h. Tap the Freq/Span tab.

s for residual spur signals with the preamp on. Because this is a

s > Factory Reset.

the detector to Ave r a ge mode.

i. Set the Start frequency to 10 MHz.

j. Set the Stop frequency to 6200 MHz.

k. Set

3. Note any single frequencies that extend more than about 5 dB above the

ad

a. For any single frequencies found, adjust the span and center frequency to

b. If this single frequency exceeds the residual spur high limit of the test

c. Repeat steps a and b for any other suspect frequencies.

End of performance verification procedures.

the RBW to 100 KHz.

jacent noise floor.

duce the span to 20 MHz centered around the suspect frequency.

re

ecord, write the frequency and amplitude of this spur in the test record.

r

22 H500 & SA2500 Service Manual

Theory of Operation

This section of the manual describes the theory of operation for the instrument
platform. As the instrument module is not user-serviceable, there is no theory
of operation

Platform

for the module.

Refer to th

e following figure while reading this section.

Display

H500 & SA2500 Service Manual 23

The color display is a TFT type transflective with backlight. The display inverter

mplemented on the Processor board. The color display has the following

is i
characteristics:

.4 inch diagonal size, 640 x 480 resolution, 256-color display

10

Transflective backing for indoor and outdoor viewability

Power consumption: logic 1.98 W, backlight: 5.76 W (dual cold cathode
fluorescent lamps)

Theory of Operation

Touch Screen

LCD Controls

Processor System

The 8-wire, 10.
to the graphical user interface. It functionally replaces a mouse for Windows
navigation, substituting point and click with a touch. The touch screen has an
anti-reflective coating that reduces glare when the platform is used outdoors.

Backlighting is used for indoor viewing, and a combination of backlighting and
ambient light is used for outdoor viewing. To control brightness, use the soft keys
available on the Control Panel (Start > Settings > Control Panel > Backlight),
or double tap the backlight icon (lower-right corner of display).

Backlighting is continuously adjustable, with the default level set to 66%. The
backlight is extinguished during screen saver, suspend, and power down modes.

The instrument processor architecture is similar to that of a handheld PC with the
following exceptions:

640 x 480 TFT color display

8-wire touch screen

SPI bu

SMBus battery interface that supports two rechargeable battery packs

4 in, resistive touch-screen module provides a touch-based access

s

Expanded power management system

USB slave/host ports

Dual PCMCIA ports standard

PS/2 keyboard port

ash file system ROM for optional software and system backup

Fl

Automatic Windows CE registry restoration during cold boot up

Instrument module power management system and additional power supplies

Foreign language support

Network support

Processor Bus. The PXA255 processor external bus width is 32 bits and operates
at 100 MHz.

Temperature Sensor. The Processor board has a n internal temperature sensor to
monitor the temperature of the platform.

Real-time Clock. The Processor board real-time clock operates from a separate
Lithium coin cell battery. The battery life expectancy is 7 years.

24 H500 & SA2500 Service Manual

Theory of Operation

Built-in Drive

Windows CE drivers for all ports. You can reinstall these drivers by reloading
the operating system.

Flash ROM. The Processor board has the following flash ROM:

32 MB Flash R OM for the operating system and built-in drivers

32 MB Flash ROM for the nonvolatile file system memory (\BuiltInDisk)

SDRAM. The Processor board has 64 MB of DRAM. The Windows CE Control
panel provides SDRAM allocation of program and data storage memory (Start
> Setting

NOTE. When entering the Suspend state, registry information is automatically

backeduptotheflash ROM file system from SDRAM. During the suspend state,
the SDRAM retains its contents. After approximately 2 hours, the analyzer
powers down the SDRAM and enters the Shutdown (power down) state. User
application data is lost when entering the shutdown state unless previously stored
in nonv

Firmware Upgrade. You can upgrade platform firmware over the RS-232 and
USB p

rs. The Processor board is configured with vendor supplied

s > Control Panel > System > Memory).

olatile memory.

orts,aswellasbyusingaPCMCIAflashmemorycard.

Hardware and Software Configuration Data. To check the hardware and software
configurations of the platform, do the following:

1. Select Start > Programs > Tektronix Utilities > System Configuration.

2. Open the Software or Hardware tab.

lect the item of interest from the list and then select Properties.

3. Se

Electronic Keying. The platform supports electronic k eying from the instrument
modules to maintain the registry. The registry is updated at each power up.
Registry information includes module name, module type, module description,
and HW/SW/FW v ersion numbers and location. If the platform detects
configuration incompatibilities, the user is notified.

Firmware Backup. The platform backs up the the system registry to flash memory
during the power down process.

H500 & SA2500 Service Manual 25

Theory of Operation

External I/O Ports and

Buses

All external po

rts are protected against electrostatic discharge and their power

supplies against shorts.

Table 3: External ports and buses

External por
bus Description

RS-232 port EIA/TIA-574 compliant DTE interface with modem control

USB slave, host ports Standard USB slave and host ports that support USB 1.1

Ethernet port

PCMCIA ports Supports a single type III or dual type II PCMCIA cards. Any

Keyboar

DC supp

Headphone jack A 3.5 mm jack. Inserting a headphone disables the internal

Microphone jack

t, signal, or

d port

ly jack

lines. The Baud Rate is 115.2 kbps.

standard.

Standard R
100BaseT Ethernet standards.

application software must be H500 & SA2500 platform and
Windows
5 V PC cards.

Supports PS/2 keyboards with Mini DIN connectors.
Keyboards can be plugged in without shutting down the
platfo

Accept
operation or to charge the internal batteries. Nominal supply
voltage is 24 VDC "10%.

speaker and microphone in the platform.

A 3.5 mm jack. 1.5 V bias supply, for 2 kΩ electret-type
micr

J-45 connector that supports 10BaseT and

CE compatible. This port accepts both 3.3 V and

rm.

s power from the AC power adapter for normal

ophone.

Internal I/O Ports and

Buses

internal ports are used to interface with the instrument module, display

The
modules, and development ports.

Table 4: Internal ports and buses

Internal port, sig nal, or
bus Description

Color LCD Port Interface: 3.3 V, 9-bit data (8 bits used), Red, Green, and Blue

LCD Connector: 15 pin
Backlight Connector: 4 pin

Touch screen port

SMBus port Interfaces to two SMART Li-Ion battery packs. Compatible

Supports 8-wire, resistive, touch-screen panel with firmw are
calibration
Touch-Screen connector: 8 pin

with Smart battery Interfaces from Inspired Energy and
others. This bus is not available to the instrument module.
(See page 28, Po wer System.) (See page 58, Lithium-Ion
Battery Maintenance.)

26 H500 & SA2500 Service Manual

Table 4: Internal ports and buses (cont.)

Internal port, sig nal, or
bus Description

Speaker port

Application interface port

Interrupt signals

Audio input signal

Audio output signal

-3 dB bandwidth: 100 Hz to 15 kHz
Speaker: 28 mm diameter, 8 W, 1 W nominal, water resistant
Connector: 2-pin header

Connects to the internal speaker. Outputs platform and
instrument module generated audio. A volume control is
available on the Control Panel (Start > Settings > Volum e &
Sounds).

Logic Levels: 3.3 V signals, 5 V tolerant

Connector: 80-pin blind mate, Molex type

SPI bus signal lines: SPIMISO (master-in-slave-out),
SPIMOSI (master-out-slave-in), SPICLK<6... 1> (SPI clock),
and SPISE L<6... 1> (instrument module select, active low).

The Application Interface port is a full duplex Serial Peripheral
Interface (SPI) bus interface between the platform and the
instrument module.

SPIMISO and SPIMOSI signals are tied together. SPISEL
and SPICLK signals are unique for a module. The platform
signals are always master; all other signals are slave.

The platform addresses the module with a unique SPISEL
signal. The instrument module picks up its SPISEL signal
from the lowest numbered SPISEL pin o f the interface
connector on its front case.

The instrument modules use MODINTR<4... 1> signals for
requesting service from the platform. These signals are
open collector 3.3 V, active low, TTL-level. The instrument
module generates the MODINTR1 signal on the Processor
board. All module interrupt signals are OR-logic wired to form
one interrupt to the CPU. The CPU can then decode which
module asserted the interrupt. Pull-up resistors for these
signals are located on the Processor board.

Signals: AUDIP, AUDIN
Level: 1 Vrms, maximum
Load: 10 kW
Bandwidth: -3 dB, 100 Hz to 15 kHz

A differential analog audio output signals from the instrument
module input to the platform volume control.

Signals: AUDOP, AUDON
Level: 1 Vrms, maximum
Load: 40 kW per module, 10 kW minimum impedance
Bandwidth: -3 dB, 100 Hz to 15 kHz

A differential analog output signal from the platform built-in
microphone to the input of an instrument modules.

Theory of Operation

H500 & SA2500 Service Manual 27

Theory of Operation

Table 4: Internal ports and buses (cont.)

Internal port, sig nal, or
bus Description

Power bus

System clock 5 MHz, 3.3 V, TTL-level (SYSCLK) for use by the instrument

Timer signal 3.3 V, TTL-level, implemented in hardware only.

Supplies power and controls the shut down of individual
instrument modules to conserve battery power.

MODON<4... 1>: 3.3 V CMOS-level signals. An active high
turns on the corresponding instrument module. The module
is MODON1. Only one CMOS load per line is allowed. A low
level on this signal isolates all supplies from the instrument
module. The s ignal must be active before addressing a
module.

module.

Programmable from 25 ms to 500 ms in 25 ms intervals.
This signal can be used to synchronously accumulate
measurement results to derive time correlated data.

Power System

The power system consists of an internal battery charger a nd power supplies for
the internal boards and instrument module. The Processor board implements
all power management operations. The battery board controls battery charging,
battery selection, and the V

r Management. The platform processor system, peripheral devices, and I/O

Powe

main

value.

implement power management techniques similar to those used in hand-held
HPCs. This includes powering down I/O ports, power supplies, and peripherals
to a shutdown state while running the CPU in sleep mode; power to all circuits
except the real-time clock and the power system micro-controller is turned off.
The power management strategy also includes a screen-saver mode. In this

ate, power to the LCD logic and backlight are shut down while maintaining

st
operation of the I/Os.

he platform uses a non-latching type power switch on the front-panel to

T
implement power on/off and suspend/resume operations similar to an HPC.
Unlike the HPC however, the platform manages power to the instrument module.

The platform shuts down power to the instrument module by pulling their
respective MODON control signals low and then cutting the power. During power
on from the suspend or shutdown state, the instrument module power supplies are
turned on first and then the module is turned on using the MODON signals.

28 H500 & SA2500 Service Manual

Theory of Operation

The power modes

are:

Suspend mode. The platform automatically enters shutdown mode to save
battery power

following a period of instrument inactivity, or when you press
the front panel power button. You can set the length of this inactivity from the
Start > Settings > Control Panel > Power Management > Power Saver
tab. Before entering this mode, registry information and nonvolatile memory
are backed up and all nonessential power supplies shut down. LCD backlights
are turned off and the touch-screen display is inactivated. The instrument
module wil

l also be shut down.

During suspend mode, the real-time clock and SDRAM refresh remain active.
To return

from this state, you must press the front-panel pow er switch to

power up the platform, which takes approximately one minute.

Display

Power Saver mode. The front-panel status indicator changes from

Green to Amber to indicate the display Power Saver mode. In this state, the
display and backlight are turned off to save power. Instrument modules
remain powered on. Pressing the front-panel power switch cancels the Power
Saver mode and returns the platform to an active state. Measurements that are
running when you enter this mode continue to run.

Automatic Shutdown mode. If a voltage is present o n fine-pitched
component pins under humid conditions, c orrosion can occur over time.

ing the internal circuitry in shutdown mode when not in use can minimize

Plac
this problem. If the platform remains in shutdown mode for more than two
hours, the processor system, with the exception of the real-time clock, is
completely powered off.

Transition to the power-down state occurs when the shutdown state timer
times-out or the internal batteries becomes critically low. Pressing the
front-panel power switch reactivates the internal circuitry and returns the
platform to an active state.

Internal Supplies to Module. In addition to the power requirements of the internal
circuit boards, the platform provides the following voltages to the instrument
module.

Table 5: Platform voltage supplies to module

Characteristic Description

Voltages

Instrument Power Supply
Noise (peak-to-peak) for
1 Megahertz bandwidth

+3.4 V DC ± 0.14 V, 5 A at 17 W
–13 V DC ±0.5 V, 1 A at 13 W
+13VDC±0.5V,1Aat13W

< 250 mV for ±13 V
< 100 mV for +3.4 V

1

H500 & SA2500 Service Manual 29

Theory of Operation

Table 5: Platform voltage supplies to module (cont.)

Characteristic Description

Transient Response

Supply Monitoring The built-in diagnostics verify the instrument module power

1

The 3.4 V s
to account for the voltage drops across the connectors and Power FET switch used to control power to the
instrument module.

upply may also be referred to as the 3.3 V supply in the rest of this document. 3.4 V is specified

For 50% to 75% step load, the initial transients are ≤10% of
the initial voltage set point. Recovery is ≤2% of the set value
within 0.5 ms.

supply status while running power diagnostics. If a problem
is detected, the platform displays an out-of-tolerance warning
message.

Power Sources. The platform and module can operate from the following
supplies:

Batteries. Powers the instrument using up to two Inspired Energy type
NI2020HD24 10.8 V, 7200 mAH, Li-ion batteries.

External Supply (DC or AC): Powers the instrument from a 24 VDC ±10%
external source. If the external supply is connected while the platform is

ting, the internal batteries will be disconnected without interrupting

opera
service. If the external supply is disconnected during service, the internal
batteries are connected without disrupting service.

Fuse Protection is provided by an automatic resetting fuse device. This fuse is
located in the external DC supply line on the Battery board. Requires no user
intervention.

Internal Charger. The sequential internal charger will charge a single 7200 mAH

ttery in approximately 4.5 hrs (two batteries requires approximately 9 hrs) if the

ba
platform is in shutdown mode. If the platform is operating, charging takes place
at a reduced rate in order to maintain internal temperatures within limits and to
avoid exceeding the capacity of the external supply. The charger is capable of
determining the battery technology type and appropriate charging sequence, and
is optimized for battery packs with nominal terminal voltages of between 7.2 and
12 volts. The maximum charging current is approximately 1.8 A in shutdown
mode and 0.8 A in the power on mode.

If the Desktop Power Supply or In-Vehicle Power Adapter is connected, the
internal batteries will charge if their capacity is low.

Charge Status Indicator. Low Battery Warning: Red indicates a low battery (less
than 20% remaining capacity). Green indicates battery charging. The platform
backs up current data and executes an orderly shutdown before complete loss
of battery power.

30 H500 & SA2500 Service Manual

Theory of Operation

Each Li-Ion bat
level. To check the battery status, remove the battery from the analyzer. Then
press the PUSH button on the side of the battery and note the charge value on the
LED charge indicator.

Taskbar Power Status Icon. A battery icon appears in the taskbar when the
instrument
in 10% increments. If two batteries are installed, the icon displays the average
charge level of the two combined batteries. When the instrument operates from
AC power (from the Desktop Power Supply) a plug icon appears in the Taskbar
status area.

Battery S

10.8 V, 7200 mAH, Li-ion batteries. You do not need special tools to replace the
batteries. (See page 58, Lithium-Ion B attery Maintenance.)

Battery operation characteristics include:

The bat
watts load) from two Li-Ion batteries and approximately 4.5 hrs from a single
battery. Run time for the platform plus application varies depending on the
applications being run.

Only one of two batteries will be in use at any given time when two batteries
are installed.

tery pack has an internal microprocessor that monitors its charge

operates from battery power. The icon displays the battery charge level

ystem. The instrument uses up to two Inspired Energy type NI2020HD24

tery power system operates the platform for approximately 9 hrs (12

Measurement Module

If two batteries are installed, you can remove and replace either battery
without disrupting service.

If a second battery is installed, the platform automatically switches operation
to the second battery when the first battery reaches cut off capacity (5%
reserve) or is removed. The transition is transparent and does not interrupt
service.

Battery Power Management Utility. The Batteries tab in the Power Management
dialog box provides general information on battery status. This is the most
accurate information to determine battery charge status and probable manufacture
dates. (See page 60, H500 and SA2500 Instrument-Specific Battery Maintenance.)

The Measurement module contains no user-servicable parts. There are also no user
adjustments on the Measurement module. The entire instrument must be returned
for service. Service for the measurement module is not independently available.

H500 & SA2500 Service Manual 31

Theory of Operation

32 H500 & SA2500 Service Manual

Adjustment Procedures

There are no manual or software adjustment procedures for the H500 or SA2500
Spectrum Analyzer instruments.

H500 & SA2500 Service Manual 33

Adjustment Procedures

34 H500 & SA2500 Service Manual

Cleaning

To clean the instrument, c lose or cover all instrument connectors, connector doors,
and battery doors. Then use a soft cloth dampened with a solution of water and
mild deterge
display touch screen.

CAUTION. To prevent damage to external surfaces, avoid using chemicals that

contain benzene, toluene, xylene, acetone, or similar solvents. Do not use bleach
or ammonia solutions for cleaning.

To prevent damage to internal components, do not allow moisture to get into
the instrument.

nt to clean the instrument. Do not apply heavy pressure or scrub the

H500 & SA2500 Service Manual 35

Removal and Replacement Procedures

Removal and Replacement Procedures

This subsection contains procedures for the removal and replacement of all
replaceable mechanical and electrical modules.

Preparation

NOTE. The in

strument does not require calibration after removal and replacement

of the indicated parts.

WARNING.

Before doing this or any other procedure in this manual, read the
Safety Summary found at the beginning of this manual. Also, to prevent possible
damage to the instrument components, read Preventing ESD in this section. (See
page 37.)

This subsection contains the following items:

This preparatory information that you need to properly do the procedures
that follow.

List of tools required to remove and disassemble all modules.

dures for removal and reinstallation of the electrical and mechanical

Proce
modules.

CAUTION. Disconnect the power adapter and remove all batteries from the

instrument before disassembling the instrument.

Equipment Required

Table 6: Tools required

Item
no. Name Description General Tool number

1.

2. T-9 Torx tip

3. T-10 Torx tip

4. T-15 Torx tip

5.

Screwdriver handle

P0 Pozi tip

Accepts Torx-driver and
Pozi bits

Used for removing
instrument screws

Used for removing
instrument screws

Used for removing
instrument screws

Used for removing
instrument screws

620-440

640-234

640-235

640-247

640-234

36 H500 & SA2500 Service Manual

Table 6: Tools required (cont.)

Item
no. Name Description General Tool number

6.

7.

1/4 inch nut driver

Torque driver Accepts Torx tips, Pozi

Preventing Electrostatic Damage

Electrostatic discharge (ESD) can damage components in the instrument. To
prevent, ESD:

Do not touch exposed components or connector pins unless you are using
ESD protective measures, such as wearing a properly grounded antistatic
wrist strap.

Handle boards and modules little as possible.

Removal and Replacement Procedures

Used to remove
standoffs

tips, and open-end
wrenches

Standard tool

Standard tool

Removal Procedures

Do not slide boards or modules across work surfaces.

port and store boards and modules in a static-protected bag or container.

Trans

NOTE. Unless directed otherwise, installation is the reverse of the removal

procedure. Note cable routing when disassembling so that you can route the
cables correctly during assembly.

NOTE. The instrument does not require calibration after removal and replacement

of the indicated parts.

H500 & SA2500 Service Manual 37

Removal and Replacement Procedures

Remove Module F

Platform

rom

1. Remove the four 1/4” standoff posts.

When reinstalling these standoffs, torque them to 8 in/lb.

2. Remove the cosmetic cover.

3. Remove the four 1/4” standoff posts that secure the module to the mainframe

chassis.

When reinstalling these standoffs, torque them to 12 in/lb.

4. Remove the module from the platform.

CAUTION. Do not open the module. There are no user-serviceable parts. If

the module is opened, you m ust return the entire instrument to Tektronix for
calibration.

38 H500 & SA2500 Service Manual

Removal and Replacement Procedures

Remove Platfor

m Rear

Cover

1. Remove th

When reinstalling these screws, torque them to 8 in/lb.

2. Remove the five screws from the bottom, side, and top edge of the rear case.

When reinstalling these screws, torque them to 8 in/lb.

e three screws from the side of the rear case above the battery area.

3. Remove the four screws from the battery compartment area.

When reinstalling these screws, torque them to 8 in/lb.

4. Lift c

ase one to two inches and remove the carrying strap and strap pins. Also

remove the strap pins from the other corners of the case.

H500 & SA2500 Service Manual 39

Removal and Replacement Procedures

Separate Front

and Rear

Cases

Separa
Disconnect J110 and J240.

te the front and back instrument cases enough to access connecting cables.

40 H500 & SA2500 Service Manual

Removal and Replacement Procedures

Rear Case: Remo

ve

Battery Compartment

H500 & SA2500 Service Manual 41

Removal and Replacement Procedures

1. Remove the five s

the battery compartment towards the bottom of the instrument to access
connecting cables

When reinstalling these screws, torque them to 8 in/lb.

crews from the battery compartment. Lift and pivot

2. Remove the two screws and remove the battery connector board from the

battery panel chassis. Disconnect the cable that comes from the DC power
jack.

When reinstalling these screws, torque them to 8 in/lb.

CAUTION. Do not remove the angle bracket with the foam thermal pad from the

ttery panel chassis, as it is set to a specific position.

ba

3. Remove the two screws and remove the battery retainer hinge assembly.

When reinstalling these screws, torque them to 8 in/lb.

4. Remove the two screws and remove the speaker bracket.

42 H500 & SA2500 Service Manual

Removal and Replacement Procedures

Front Case: Remove CPU

Board Assembly

When reinstall

5. Remove the two screws and remove the DC power jack and bracket.

When reinstalling these screws, torque them to 8 in/lb.

ing these screws, torque them to 8 in/lb.

1. Disconnect JR1, J2, J120,andJ660. Disconnect the cables from the le ft
end of the backlight inverter board.

2. RemovetheninescrewsandremovetheCPUboardassembly.

n reinstalling these screws, torque them to 8 in/lb.

Whe

H500 & SA2500 Service Manual 43

Removal and Replacement Procedures

Front Case: Rem

ove

Display Components and

Power Switch

1. Disco

2. Remo

3. Remove the 14 screws from the display assembly.

4. Remove the drive bay cover bracket from the front case. This is a pressure-fit

44 H500 & SA2500 Service Manual

nnect the cable from the right end of the backlight inverter board.

Untape the cable from the plate.

ve the 2 screws from the backlight inverter board and remove the board.

When reinstalling these screws, torque them to 2.5 in/lb.

When reinstalling these screws, torque them to 8 in/lb.

bracket.

Removal and Replacement Procedures

H500 & SA2500 Service Manual 45

Removal and Replacement Procedures

Front Case : Remove the

Touch Panel and Power

Switch Board

5. Lift the displa

y assembly components from the front case.

1. Remove the two screws and remove the front panel board assembly.

When reinstalling these screws, torque them to 4 in/lb.

2. Remove the touch panel assembly.

46 H500 & SA2500 Service Manual

Troubleshooting

Troubleshooting

WAR N ING. Before doing this or any other procedure in this manual, read

theSafetySu
possible injury to service personnel or damage to the instrument components,
read Installation in the product user manual, available on the Web at
www.tektronix.com, and Preventing ESD in this document.(See page 37.)

This section contains information and procedures designed to help you isolate
faulty modules in the H500 or SA2500 Spectrum Analyzer.

This section assumes that service personnel have the prerequisite skills required to
work on this instrument. Details of instrument operation are no t in this manual.

The following diagram shows the processor and backlight inverter board
connections. Use this diagram while doing the troubleshooting steps in this
section.

mmary found at the beginning of this manual. Also, to prevent

Figure 1: Processor and backlight inverter board input and output connections

H500 & SA2500 Service Manual 47

Troubleshooting

Power On Self T

Display

Does Not Operate

Display Cable

Disconnected

est

Press the large oval button in the lower-left corner to power on the platform.
The power status indicator illuminates immediately. Allow several seconds for
the self test

to complete.

NOTE. The Batteries indicator briefly illuminates red if the batteries are too low to

power on the analyzer. Connect the external power supply or charge the batteries.

If the platform does not begin to boot at power up (no power up sound), try
removing the CMOS battery backup from the Processor board (BT520). Wait
approximately 15 seconds and reinsert the battery into its socket; then press the
power switch again. If the platform still does not boot, replace the Processor board.

If the display does not operate try the following procedures.

Do the following:

1. Verify that both ends of the LCD display cable are properly oriented and
fully seated in their connectors.

Backlight Does Not

Illuminate

2. Remove and reinstall the backlight cable connectors.

ese steps do not resolve the problem, replace the display.

If th

Verify the following backlight-related voltages.

RNING. To avoid electrical shock or burn, do not touch the backlight

WA

connectors on the backlight inverter board.

able 7: Backlight-related voltages

T

oard

B
location Pin Location

acklight

B
Inverter board

CPU board

,3

2

1, 2 JR 1

6JR1

3, 4 J660

CN2

easured

M
voltage Frequency

10 Vrms

5

+12 VDC

0 V to +2.4 VDC

3.3 VDC

4kHz

5

48 H500 & SA2500 Service Manual

Troubleshooting

Display Image

Inverted (Rotated 180°)

Disconnect and then reconnect the LCD cable connectors. To open connector
J660, insert your thumbnail beneath the dark brown part (hinge) and the cable.
Carefully li

ft up the hinged brown part to release the cable. Reseat the cable and

close the hinge. J660 pin 1 must supply +3.3 VDC for correct display orientation.

Touch Screen Does Not Operate

Try the following:

Disconnect and then reconnect the touch scre en cable connectors.

J4 pins 1-8: verify that pins 1, 2, 3, and 4 of connector J1 are at +3 VDC
when the touch panel is not pressed. Verify that pins 1 through 8 toggle their
value when the touch panel is pressed.

If these do not resolve the problem, replace the touch screen panel.

Signal and Connector Information

The following tables list pin, signal name, and signal information for the main
platform connectors.

Table 8: PCMCIA interface connectors JR420, JR520

Signal

Pin Signal nam e

1

2D3 36

3D4 37D11

4D5 38D12

5

6D7 40D14

7

8 A10 42

9

10 A11 44

11 A9 45

12 A8 46 A17

13 A13 47 A 18

14 A14 48 A 19

15 -WE 49 A20

16

GND

D6 39 D13

-CEL

-OE

-IREQ/READY

information Pin Signal name

35

41 D15

43

50 A21

GND

-CD1

-CEH

REF/-VSI

-IORD

-IOWR

Signal
information

H500 & SA2500 Service Manual 49

Troubleshooting

Table 8: PCMCIA interface connectors JR420, JR520 (cont.)

Signal

Pin Signal name

17

18 VPP

19 A16 53 A22

20 A15 54 A23

21 A12

22 A7 56 A25

23 A6

24 A5 58

25 A4 59 -WAIT

26 A3 60

27 A2 61

28 A1 62

29 A0 63

30 D0 64 D8

31 D1 65 D9

32 D2 66 D10

33

34

VCC 0.4 VDC

-IOIS16/WP

GND

information Pin Signal name

0.4 VDC

51

52 VPP

55

57

67

68

VCC 0.4 VDC

A24

RSVD/-VS2

-RESET

-INPACK

-REG

SPKR/BVD2

-STSCHG/BVD1

-CD2

GND

Signal
information

0.4 VDC

able 9: Application module connector JR170

T

Signal

Pin

1 -13 V 41 -13 V

2-13V 42

3 +3.4 V 43

4 +3.4 V 44

5

6

7

8

9

10

11

12

13

14

name

NC1

GND

SYSCLK

GND

RSVD

RSVD

GND

AUDIOUT-

AUDIOUT+

GND

Signal
information Pin

45

46 +3.4 V

+5 V high 47 +3.4 V

48

49 +13 V

50 +13 V

51

52 +13. V

53 +13. V

54

Signal
name

GND

RSVD

RSVD

GND

GND

GND

GND

Signal
information

50 H500 & SA2500 Service Manual

Table 9: Application module connector JR170 (cont.)

Troubleshooting

Signal

Pin

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29 TIMER 500 mV,

30 +3.4 V 70

31 +3.4 V 71

32

33 +3.4 V 73

34 +3.4 V 74

35

36 +3.4 V 76

37 +3.4 V

38

39

40

name

MODON6 GND

MODON5 GND

MODON4

MODON3

MODON2

MODON1

-RESET

SPISEL6

SPISEL5

SPISEL4

SPISEL3

SPISEL2

SPISEL1

NC2

STST

TXTRIG

RXTRIG

GND

EXTRIG

Signal
information Pin

55

56

57

58

59

60

61

+5 V High 62

+5 V High 63

+5 V High 64

+5 V High 65

+5 V High 66

+5 V High 67

68

69

2.5 μs/
300 ns
pulse

72

75

77

78

79

80

Signal
name

AUDIOIN-

AUDIOIN+

GND

-MODIRQ6

-MODIRQ5

-MODIRQ4

-MODIRQ3

-MODIRQ2

-MODIRQ1

GND

SPICLK6 GND

GND

SPICLK5 GND

GND

SPICLK4

GND

SPICLK3

GND

SPICLK2

GND

SPICLK1

GND

SPIRXD

GND

SPITXD

GND

Signal
information

+5 V hig h

+5 V hig h

+5 V hig h

+5 V hig h

+5 V hig h

+5 V hig h

+5 V hig h

+5 V hig h

+5 V hig h

+5 V hig h

+5 V hig h

+5 V hig h

Table 10: Internal speaker connector J110

Pin Signal name Signal information

1

2

VO1 2.4 VDC nominal

VO2 2.4 VDC

H500 & SA2500 Service Manual 51

Troubleshooting

Table 11: Exter

Pin Signal name Signal information

1

2TIP

3

4

5

6

7

nal microphone connector J200

GND

MICPWR

NC

NC

NC

NC

Table 12: Power connector J240

Pin Signal name Signal information

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15 LED4_RED

16

17

18

19

20

21

22

23

24

25

26

GND

DC IN 7 - 24 VDC

DC IN 7 - 24 VDC

DC IN 7 - 24 VDC

DC IN 7 - 24 VDC

DC IN 7 - 24 VDC

GND

GND

GND

VCC_EN

GND

RESUME*

BB_PWR_SW

GND

LED4_GRN Charge LED

GND

HOST_PWR

PIC_INT*

GND

SYS_PWR_DET 3.3 VDC

GND

GNDBB_SCL Serial clock

GND

BB_SDA Serial data

GND

Enables V regulators

Power button

Digital

Charge LED

Digital

Digital

52 H500 & SA2500 Service Manual

Troubleshooting

Table 13: Front

Pin Signal name Signal information

1+3.3V

2 -LED1_RED

3

4 -LED2_RED

5

6 -LED3_RED

7

8 -LED4_R

9

10

11

12

-panel switch/LED connector J120

-LED1_GRN 3.3 to 1.3 VDC (on/off)

-LED2_GRN 3.3 to 1.3 VDC (on/off)

-LED3_GRN 3.3 to 1.3 VDC (on/off)

ED

-LED4_GRN 3.3 to 1.3 VDC (on/off)

-RESUME 5 VDC (normal position)

-RESET 3.3 VDC (normal position)

GND

3.3 VDC

3.3 to 1.3 VDC (on/off)

3.3 to 1.3 VDC (on/off)

3.3 to +.3 VDC (on/off)

3.3 to 1.3 VDC (on/off)

Table 14: Serial port connector J500

Pin Signal name Signal information

1

2-RXD

3-TXD

4DTR

5

6

7

8

9RI

DCD

GND

DSR

RTS

CTS

Table 15: JTAG port connector J670

Pin Signal name Pin Signal name

1+3.3V11

2 +3.3 V 12

3

4

5

6

7

8

9

10

ICE_TRST*

GND

PX_TDI 15

GND

PX_TMS

GND

PX_TCK

GND

13

14

16

17

18

19

20

GND

GND

PX_TDO

GND

ICE_SRST*

GND

N.C.

GND

N.C.

GND

H500 & SA2500 Service Manual 53

Troubleshooting

Table16: PS/2k

Pin Signal name Signal information

1DATA

2

3

4+5V

5

6

eyboard connector J700

NC

GND

CLK

NC

Table 17: Headphone connector J300

Pin Signal name

1

2

3

4

5

6

7

GND

SPKR

SPRR

HS

-HS

NC

NC

Table 18: TFT color display connector J660

Pin Signal name Signal information

1

2

3

4

5

6

7

8

9 RED-3 +3 V data, mostly high

10 RED-4 +3 V data, mostly high

11 RED-5 +3 V data, mostly high

12

13

14

15

16

17

18

GND

DOT CLK

HSYNC

VSYNC

GND

GND

GND

GND

GND

GND

GND

GND

GRN-3

GRN-4

GRN-5

+3 V, 4.8 MHz

1 ms pulse, +3 V over 38 μs

1 ms pulse every 8 ms

+3 V data

+3 V data

+3 V data

54 H500 & SA2500 Service Manual

Troubleshooting

Table 18: TFT color display connector J660 (cont.)

Pin Signal name Signal information

19

20

21

22

23 BLU-3 +3 V data

24 BLU-4 +3 V data

25 BLU-5 +3 V data

26

27 DEPV

28

29

30

31

GND

GND

GND

GND

GND

LCD_3V

LCD_3V

NC

RVRSE

+3.3 V

Table 19: TFT backlight connector CN2 (Backlight Inverter Board)

Pin Signal name Signal information

1

2

3

GND

AC-HV1

AC-HV2

510 V

510 V

,54kHz

rms

,54kHz

rms

Table 20: Touch screen connector J4 and J2

J4 Pin J2 Pin Signal name Signal information

1

28

3

46

5

63

7

81

5

XEXCITEL Excite left

XSENSEL Sense left

7

4

XSENSER Sense right

XEXCITER

YEXCITEB

Excite right

Excite bottom

YSENSEB Sense bottom

2

YSENSET Sense top

YEXCITET

Excite top

Table 21: Ethernet connector J400

Pin Signal name Signal information

1 TX+ Transmit +

2 TX- Transmit -

3RX+Receive

H500 & SA2500 Service Manual 55

Troubleshooting

Table 21: Ethernet connector J400 (cont.)

Pin Signal name Signal information

4

5

6RX-Receive

7

8

9

10

11

12

13

14 3.3V

15

16 3.3V

NC

NC

NC

NC

GND Ground

GND Ground

NC

NC

LINKLED*

LANLED*

LED cathode

LED anode (resistor)

LED cathode

LED anode (resisitor)

Table 22: USB 1.1 series A host connector J701

Pin Signal name Signal information

1

2

3

4

5

6

USB_CONNECTED VBUS

USB_HDN

USB_HDP

GNDS Signal ground

CGND Case ground

CGND Case ground

DATA-

DATA+

Table 23: USB 1.1 series B slave connector J800

Pin Signal name Signal information

1

2

3

4

5

6

USB_HPWR VBUS

USB_N

USB_P

GNDS Signal ground

CGND Case ground

CGND Case ground

DATA-

DATA+

Table 24: Backlight connector JR1

Pin Signal name Signal information

1 +12BL +12 V supply

2 +12BL +12 V supply

56 H500 & SA2500 Service Manual

Troubleshooting

Table 24: Backlight connector JR1 (cont.)

Pin Signal name Signal information

3

4

5

6

7

8

GND Ground

GND Ground

+5V Not used

BL_CTRL

GND

NC

Intensity control

Not used

Not used

H500 & SA2500 Service Manual 57

Lithium-Ion Battery Maintenance

Lithium-Ion Battery Maintenance

Lithium-Ion rechargeable batteries require routine maintenance and care in their
use and handling. Read and follow the informationinthisdocumenttosafelyuse
Lithium-Ion

batteries and achieve the maximum battery life span.

Key Information

Battery Maintenance

Use only Tektronix-approved batteries in your Tektronix products.

Do not leave batteries unused for extended periods of time, either in the product
or in storage. When a battery has not been used for six months, check the charge
status and charge or dispose of the battery as appropriate.

The typical estimated life of a Lithium-Ion battery is about two to three years or
300 to 500 charge cycles, whichever occurs first. Onechargecycleisaperiod
of use fr
two to three year life expectancy for batteries that do not run through complete
charge cycles.

Rechargeable Lithium-Ion batteries have a limited life and will gradually lose
their capacity to hold a charge. This loss of capacity (aging) is irreversible. As
the battery loses capacity, the length of time it will power the product (run time)
decreases.

Lithium-Ion batteries continue to slowly discharge (self-discharge) when not in
use or while in storage. Routinely check the battery’s charge status. The product
user manual typically includes information on how to check battery status, as
wel
www.tektronix.com/manuals.

om fully charged, to fully discharged, and fully recharged again. Use a

l as battery charging instructions. The latest product manuals are available at

Observe and note the run time that a new fully-charged battery provides for

wering your product. Use this new battery run time as a basis to compare

po
run times for older batteries. The run time of your battery will vary depending
on the product's configuration and the applications that you run.

Routinely check the battery’s charge status.

Carefully monitor batteries that are approaching the end of their estimated life.

Consider replacing the battery with a new one if you note either of the
following conditions:

The battery run time drops below about 80% of the original run time.

The battery charge time increases significantly.

58 H500 & SA2500 Service Manual

Lithium-Ion Battery Maintenance

Charging

Storage

Always follow t
your product’s user manual and/or online help for detailed information about
charging its battery. The latest version of your Tektronix product user manual is
available at www.tektronix.com.

NOTE. When you troubleshoot battery issues for dual battery configurations,

test one battery and one battery slot at a time. A defective battery can prevent
the battery
batteries.

Charge or discharge the battery to approximately 50% of capacity before
storage.

Remove the battery and store it separately from the product.

Store the battery at temperatures between 5 °C and 20 °C (41 °F and 68 °F).

Charge the battery to approximately 50% of capacity at least once every six
months.

NOTE. The battery self-discharges during storage. Higher temperatures (above

20 °C or 68 °F) reduce the battery storage life.

he charging instructions provided with your product. Refer to

in the opposite slot from charging, leaving you with two uncharged

Handling Precautions

CAUTION. If a battery is stored or otherwise unused for an extended period

without following these instructions, and the battery has no charge remaining
when you check it, consider it to be damaged. Do not attempt to recharge it or to

it. Replace it with a new battery.

use

Do not disassemble, open, crush, bend, deform, puncture, or shred a battery.

Do not drop a battery or expose the battery to excessive shock or vibration.

Do not short circuit a battery or allow metallic or conductive objects to contact
the battery terminals.

Do not dispose of a battery in fire or water.

Do not use the battery to power any devices other than the instrument for
which it was designed.

Keep the battery away from personnel that are not trained to use the
instrument.

Do not expose a battery to temperatures above 60 °C (140 °F).

H500 & SA2500 Service Manual 59

Lithium-Ion Battery Maintenance

Transportation

Disposal and Recycling

Keep the batter

Do not use a damaged battery.

If a battery pack is leaking fluids, do not touch any fluids. Properly dispose of
a leaking battery pack (see Disposal and Recycling in this document).

WARNING. In

flush eyes thoroughly with water for at least 15 minutes, lifting upper and lower
lids, until no evidence of the fluid remains. Seek medical attention.

Always check all applicable local, national, and international regulations
before transporting a Lithium-Ion battery.

Transporting an end-of-life, damaged, or recalled battery may, in certain
cases, be specifically limited or prohibited.

Lithium-Ion batteries are subject to disposal and recycling regulations that
vary by country and region. Always check and follow your applicable
regulations before disposing of any battery. Contact Rechargeable Battery
Recycling Corporation (www.rbrc.org) for U.S.A. and Canada, or your local
battery recycling organization.

y away from children.

case of eye contact with battery fluids, do not rub eyes. Immediately

Many countries prohibit the disposal of waste electronic equipment in
standard waste receptacles.

Place only discharged batteries in a battery collection container. Use electrical
tape or other approved covering over the battery connection points to prevent

rt circuits.

sho

H500 and SA2500 Instrument-Specific Battery Maintenance

he instrument run time depends on power consumption, which in turn depends

Instrument Run Time

T
on the instrument measurement mode. For example, DPX™ Spectrum Display,
Spectrum analyzer, and audio demodulation measurements consume more power
than other measurements because they are continuously acquiring data.

With two new, fully charged batteries, you can run the DPX Spectrum
Display measurement for approximately four hours, or the Spectrum analyzer
measurement for five to six hours. Both of these run times are with the instrument
power management mode disabled. Enabling instrument power management
increases the instrument run time.

60 H500 & SA2500 Service Manual

Lithium-Ion Battery Maintenance

Battery Charge Time

Checking the Battery

Charge Status

Battery aging a
battery charge capacity to decrease, which in turn decreases the instrument run
time.

The instrument uses one battery at a time. The battery with the lowest remaining
capacity is used first.

With the ins
two batteries from a fully discharged state. The exact charge time depends on
which measurements are running. When the instrument is powered off, it will take
about 10 hours to fully charge two b atteries.

1. Double-tap the Power Management icon in the system tray to open the
Power Management dialog box. The system tray shows the battery icon

when the instrument is operating from batteries, and a power plug icon when
the instrument is operating from an external power supply.

nd the increasing number of charge/discharge cycles causes the

trument powered on, it can take more than 20 hours to fully charge

2. Tap the Batteries tab. This tab shows the charge level of each battery,
the estimated remaining run time for the in-use battery (with the current

urement settings), and the battery calibration status. The instrument

meas
uses one battery at a time: the battery with the lowest remaining capacity
is used first.

Each battery contains circuitry that monitors the charge level and estimated
remaining run time. This circuit becomes uncalibrated after a number of
partial discharge and charge cycles. When the Cal Status is Uncalibrated,
the reported level and remaining time are not accurate, which means that

H500 & SA2500 Service Manual 61

Lithium-Ion Battery Maintenance

Calibrating a Battery

the battery is n
document.

3. Tap the Proper
Design Capacity, Serial Number and the Manufacturer Date. Use the serial
number to identify and keep track of each battery's charge and capacity history.

To calibr
fully charge the battery to reset the internal battery monitoring circuitry.

Fully Charging a Battery.

NOTE. During charging, keep the instrument environment temperature between

0 °C and 45 °C (32 °F and 113 °F), and the relative humidity between 0% and
80%.

ate a battery, you must first fully charge, then fully discharge, and finally

ot calibrated. See the Calibrating a Battery sectioninthis

ties button adjacent to a battery listing to show that battery's

1. Install the single battery that you want to charge.

2. Connect the external power adaptor, but do not power up the instrument. The

BATTERIES CHARGER LED on the front panel should be lit, indicating that
the instrument is charging the battery. If the BATTERIES CHARGER LED

the front panel is not lit, check the following:

on

The external power adaptor plug is fully seated in the instrument external

wer connector

po

There is power being supplied to the external power adaptor

The battery is fully seated in the instrument battery compartment

3. When the battery is fully charged, the BATTERIES CHARGER LED on the
front panel turns off.

4. Power on the instrument and double-tap the Power Management icon in
the system tray.

5. Verify that the Level field shows Fully Charged for the installed battery.

62 H500 & SA2500 Service Manual

Lithium-Ion Battery Maintenance

Fully Discharg

NOTE. During battery discharge, keep the instrument environment temperature

between –10 °C and 50 °C (14 °F and 122 °F), and the relative humidity between
0% and 80%.

1. Disconnect the external power adaptor.

2. Install th

3. Power on the instrument and a measurement application.

4. Double-tap the Power Management icon in the system tray.

5. Tap the Power Saver tab and select No Power Saver actions.

6. Set the instrument to a high-power-consumption measurement such as DPX

Spectrum.

7. Let the instrument and measurement run. The instrument automatically shuts
down when the battery is fully discharged. The battery is now completely
discharged.

ing a Battery.

e single battery that you want to discharge.

When to Replace a Battery

Record the date, battery serial number, charge time and run time when you start
using a new instrument, or when you install new batteries. Set up a schedule to
check and record the battery charge and calibration status. See the Checking the
Battery Charge Status section in this document.

Compare the charge time and instrument run times with those for new batteries at
least every six months. When any of the following behaviors occur, you should

nsider replacing your batteries:

co

It takes significantly longer (>150%) to charge used batteries than it does to

harge new batteries.

c

The BATTERIES CHARGER LED on the front panel does not stay on
continuously while the batteries are charging.

After the battery is fully charged, the instrument run time is significantly
shorter (<80%) with older fully-charged batteries than it is with new batteries.

A charge cycle never completes.

The Power Management Batteries tab does not show a Fully Charged status
after a charge cycle.

The battery is more than three years old.

H500 & SA2500 Service Manual 63

Repackaging for Shipment

Repackaging f

or Shipment

CAUTION. Remove rechargeable battery packs from the instrument before

shipping and store the batteries in an approved area. (See page 58, Lithium-Ion
Battery Maintenance.)

To ship the instrument for repair, use the original packaging container if possible.
If the container is unfit for use or not available, use the metal carrying case if
available, or, repackage the instrument as follows:

1. Useacartonwithateststrengthofnolessthan80kg(175lbs).

2. Surround the instrument with protective polyethylene sheeting.

3. Cushion the instrument on all sides with at least two inches of tightly packed

urethane foam or other packing material.

4. Seal the c arton with shipping tape or an industrial stapler.

64 H500 & SA2500 Service Manual

Replaceable Parts

This section contains a list of the replaceable parts for the H500 and the SA2500
Spectrum Analyzers. Use this list to identify and order replacement parts.

Parts Ordering Information

Changes to Tektronix products are sometimes made to accommodate improved
components as they become available and to give you the benefit of the latest
improvements. Therefore, when ordering parts, it is important to include the
following

Using the Replaceable Parts List

information in your order:

Part number

Instrument type or model number

Instrument serial number

Instrument modification number, if applicable

This section contains a list of the mechanical and/or electrical components that
are replaceable for the H500 and the SA2500 Spectrum Analyzer. Use this list
to identify and order replacement parts. The following table describes each
column in the parts list.

Column Column name Description

1

2 Part number

3 and 4

5

6 Name and description

Abbreviations

Fig. & index number Items in this section are referenced by figure and index numbers to the

exploded view illustrations that follow.

Use this part number when ordering replacement parts from Tektronix.

Serial number Column three indicates the serial number at which the part was first

effective. Column four indicates the serial number at which the part was
discontinued. No entry indicates the part is good for all serial numbers.

Qty This indicates the quantity of parts used.

An item name is separated from the description by a colon (:). Because
of space limitations, an item name may sometimes appear as incomplete.
Use the U.S. Federal Catalog handbook H6-1 for further item name
identification.

Abbreviations conform to American Abbreviations National Standard ANSI
Y1.1-1972.

H500 & SA2500 Service Manual 65

Replaceable Parts

Figure 2: Module and cover replaceable parts

66 H500 & SA2500 Service Manual

Replaceable Parts

Fig. &
Index
number

5-1

Part
number

-1 129-1650-xx 4

-2 200-5048-xx 1

-3 129-1649-xx 4

Serial
number
effective

Serial
number
discont'd Qty Description

Module and mainframe

SPACER, POST; 8-32 X .975 LG

COVER,COSMETIC; MODULE CHASSIS; SAFETY CONTROLLED

SPACER, POST; 8-32, 2.350 LG

H500 & SA2500 Service Manual 67

Replaceable Parts

Figure 3: Mainframe replaceable parts

68 H500 & SA2500 Service Manual

Replaceable Parts

Fig. &
index
number

5-2-1 202-0370-02 1

-2 211-0530-xx 3

-3 335-1928-xx 1

-4 211-0628-xx

-5

-6 211-1095-xx 4

-7

-8 407-4924-xx 1

-9 671-5609-xx 1

-10 174-4776-xx 1

-11 119-6806-xx 1

-12 211-0069-xx 2

-13 407-4926-xx 1

-14 211-0722-xx 29

-15 174-5592-xx 1

-16 119-7495-xx 1

-17 407-4994-xx 1

-18 119-6948-xx 1

-19 211-0324-xx 2

-20 671-4682-xx 1

-21 407-4923-xx 1

-22 344-0568-xx 2

-23 202-0405-xx 1

-24 334-9863-xx 1

-25 260-2716-xx 1

-26 335-3082-xx 1 MARKER, IDENT, H500

-27 367-0516-xx 1

-28 174-4777-xx 1

-29 664-5633-xx 1

-30 386-7408-xx 1 PANEL, BATTERY: 4.600 X 8.835,0.063 AL

-31 407-4610-xx 1

-32 119-6811-xx 1

-33 211-0722-xx

-34 407-5007-xx 1

-35 342-1127-xx 1

-36 211-0722-xx 4

-37 174-4774-xx 1

-38 407-4686-xx 1

Tektronix
part
number

131-6867-xx 1

211-0747-xx 9

348-1942-xx 1

335-3083-xx 1

Serial
no.
effective

Serial
no.
discont'd Qty. Name & description

CASE,REAR:OVERMOLD ASSY,13.494 X 11.381 X 3.529

SCREW,MACHINE:6-32 X 1.750,PNH,STL CD PL,POZ

MARKER,IDENT:REAR PANEL SAFETY LABEL

5

7

SCREW,MACHINE:6-32 X 1.125,PNH,SST POZ

CONN,HDR:SMD,MALE,RTANG,68 POS,PCMCIA,DUAL

SCREW, MACHINE:2-56 X 0.625L, PNH, PHL, STL, ZN PL

SCREW, MACHINE; 6-32 X 0.188, PNH, STL, CDPL

BRACKET; DRIVE MODULE, 0.040 AL

RF ABSORBER, 3.320 X 2.625

(Attaches to back of 407-4924–xx)

CIRCUIT BD ASSY:CPU,TESTED

CABLE ASSY, BACKLIGHT INVERTER

CIRCUIT BD ASSY, BACKLIGHT INVERTER

SCREW,MACHINE; 2-56 X 0.125,PNH,STL CRM PL,POZ

BRACKET,DISPLAY COVER; AL

SCREW,MACHINE; 6-32 X 0.250,PNH,STL,CDPL,T-15 TORX

CABLE ASSEMBLY; DISPLAY

DISPLAY MODULE; LCD;640 X 480,10.4 IN DIAGONAL

BRACKET:LCD COLOR,8.5 X 10.65,0.300 AL

TOUCH SCREEN:TOUCH PANEL ASSEMBLY, 8-WIRE

SCR,ASSEM WSHR; 4-40 X 0.188,PNH,SST,PASS,T-9 TORX

CIRCUIT BD ASSY; FRONT, TESTED

BRACKET; FLOPPY BAY,BLACK ANODIZE, 0.040 AL

CLIP:ACCESSORY CASE,16 GA WIRE,BLACK OXIDE COAT

CASE,FRONT:OVER MOLD ASSY,12.786 X 9.903 X 1.2,BLACK

MARKER,IDENT:LABEL,MKD RESET,FRONT,LEXAN

SWITCH, KEYPAD: FRONT ELASTOMER MAT, PLASTIC

MARKER,IDENT, SA2500

HANDLE, STRAP: HOLDING,W/VELCRO ADJUSTMENT

CA ASSY,SP:FLAT FLEX,IDC,12 CON,0.039 CTR

CKT BD SUBASSY: BATTERY CONNECTOR

BRACKET:SPEAKER,1.45 X 1.45 L,0.050 AL

SPEAKER: DYNAMIC,28MM DIA,8 OHM,600-7KHZ

SCREW, MACHINE; 6-32 X 0.250,PNH,STL,CDPL,T-15 TORX

BRACKET; ANGLE, THERMAL PAD

INSULATOR, MISC,THERMAL; BATTERY, 0 .125 THICK

SCREW, MACHINE; 6-32 X 0.312,FLH100,STL,CDPL,T-10

CABLE ASSY: DISCRETE, CPD,3,22 AWG, (DC JACK)

BRACKET:DC JACK,1.175 X 1.675 X 1.130,0.050 AL

H500 & SA2500 Service Manual 69

Replaceable Parts

Fig. &
index
number

-39 214-4951-xx 1

-40 211-0718-00 4

Tektronix
part
number

Serial
no.
effective

Serial
no.
discont'd Qty. Name & description

HINGE ASSEMBLY: 0.024 THK, SSTL, NICKEL PLATE

SCREW, MACHINE; 6-32 X 0.312, FLH100, STEEL, ZINC FINISH, T-10 TORX DR

70 H500 & SA2500 Service Manual

Replaceable Parts

Figure 4: H500 and SA2500 accessories

H500 & SA2500 Service Manual 71

Replaceable Parts

Fig. &
index
number

5-3-1 146-0151-0x 1

-2 119-6030-00 1

-3 119-7288-0x 1

-4 367-0518-00 1

-5

——–

-6 348-1661-00 1

-7

-8 119-6107-00 1

-9 016-1882-00

——–

——–

——–

——–

——–

——–

——–

——–

——–

——–

——–

——–

——–

——–

——–

——–

Tektronix
part
number

016-1775-00 1

016-1889-00 1

118-9402-00 1

012-1588-00 1

012-1379-00 1

174-4401-00 1

077-0786-XX 1

116-0996-00 1

116-0997-00 1

116-0998-00 1

116-0999-00 1

161-0310-00 1

161-0311-00 1

161-0312-00 1

161-0313-00 1

161-0314-00 1

161-0315-00 1

161-0318-00 1

436-0416-00 1

Serial
no.
effective

Serial
no.
discont'd Qty. Name & description

BATTERY; LITHIUM ION, RECHARGEABLE; 10.8V, 7200MAH, SMBUS, RECESSED
TERMINALS

BATTERY CHARGER: 2-SLOT EXTERNAL CHARGER, 10MA-3A SMBUS, SBS3002

POWER SUPPLY; EXTERNAL; 65W, 90-264 VAC, 47-63HZ IN; 24 VDC, 2.7A OUT

HANDLE, STRAP: SHOULDER, W/CLIPS

CASE, CARRYING: TRANSPORTATION SOFT SHELL

CASE, CARRYING: HAND, POLYETHYLENE, 24L X 16W X 13H EXTERIOR, 17L X 13W
X 9H INTERIOR, FOAM DICE CUT LAYER PADS

STAND, TILT: ACRYLIC/ALUMINUM COVERED W/CORDURA,W/ACCESSORY POUCH

KEYBOARD ASSY: 83 KEY NOTEBOOK KEYBOARD, IBM AT OR PS/2 COMPATIBLE,
GRAY

STYLUS: STYLUS FOR TOUCH SCREEN, T1100

5

COVER: PROTECTIVE, TOUCH PANEL, 3M POLYTHYLENE TAPE, CLEAR

CABLE, ELEC: PC INTERFACE

CABLE ASSEMBLY:RS232, 76.0 L ,9, 24 AWG DB9 FEMALE X DB9 FEMALE, SERIAL
NULL MODEM

CABLE ASSY,I/O; USB, 26 AWG, 3 FT, A TO B, MALE, BLACK

MANUAL, TECH; SERVICE, H500 & SA2500, PDF ONLY

DISK DRIVE;PCMCIA;128MB, TYPE II, ATA FLASH CARD, 2.5MS ACCESS, CARD BUS

MODEM:V.90,PC CARD 56K-GLOBAL-FREEDOM,5660

ETHERNET CARD:STANDARD LP-E LOW POWER ETHERNET CARD,EA0911-101

PRINTER:HP DESKJET 340CBI PORTABLE PRINTER,PARALLEL INTERFACE,C2671A

CA ASSY,PWR:3,18 AWG,BLACK,250V/2.5A,STR,118L,RECP IEC320 C5 X NEMA
5-15P,US

CA ASSY,PWR:3,250V/2.5A,STR,IEC320 C5,EUROPEAN,BLACK

CABLE ASSY,PWR:3,1.0MM SQ,250V/2.5A,STR,RECP IEC320 C5,UNITED
KINGDOM,BLACK

CA ASSY, PWR:3,0.75MM SQ,BLACK,250V/2.5A,STR,RECP IEC320 C5, AUSTRALIAN

CA ASSY,PWR:3,0.75MM SQ,BLACK,250V/2.5A,STR, RECP IEC320 C5,SWISS

CA ASSY, PWR:3,1.25MM SQ,250V/2.5A,STR,RECP IEC320
C5,JAPANESE,T-MARK,BLACK

CABLE ASSY,PWR; 3,18 AWG,BLACK,250V,7.5A,STR,IEC320 C5,3C
CERTIFICATION,CHINA

SHELF,UTILITY; MAGNETIC,11.5 H X 15.0 W X 0.25 D,SAFETY CONTROLLED

72 H500 & SA2500 Service Manual

Specifications

This section lists the electrical, environmental, and physical specifications for the
H500 and SA2500 Spectrum Analyzers. All specifications are guaranteed unless
labeled “Typ

ical.” Typical specifications are provided for your convenience and

are not guaranteed.

Table 25: General performance characteristics

Characteristic

RF Input

Operating
Frequency
Range

Maximum
Operating
Input Level

Maximum
Input Power
without
Damage

IF Output

Output
Impedance

IF Center
Frequency

IF 3 dB
Bandwidth

IF Output Level –12 dBm @ 1.0 GHz

IF Output Level
Accuracy, Typical

IF Output
Flatness, Typical

Internal Timebase

Error, Factory
Calibration
Corrected

Description

10 kHz – 6.2 GHz

Operating Range for some features may be restricted. If so, the
restricted range is defined with the relevant feature.

+20 dBm peak envelope power

This is the maximum input level at which the instrument will meet its
performance specifications.

For a signal without any amplitude variation, peak envelope power
=RMS.

50 W rms below 3.2 GHz

15 W rms between 3.2 GHz and 6.2 G Hz

50 Ω

140 MHz, non-inverted

24 MHz nominal

–12 dBm @ 1.2 GHz
–10 dBm @ 1.6 GHz
–11 dBm @ 4.35 GHz
–16 dBm @ 5.0 GHz
–22 dBm @ 5.75 GHz

0 dBm CW signal applied to the input, instrument reference level set to
0 dBm, room temperature.

± 3.5 dB for a CW input signal, 0 dBm input, 1 GHz input frequency,
0 dBm reference level, room temperature

± 1.5 dB up to ± 3 MHz from center frequency
± 3 dB up to ± 10 MHz from center frequency

± 0.5 PPM from 0 °C to 50 °C
± 1.0 PPM aging/year

Twenty minute warm-up period required to meet accuracy specification

H500 & SA2500 Service Manual 73

Specifications

Table 25: General performance characteristics (cont.)

Characteristic

Error, GPS
corrected, Typical

External Reference Input

Impedance

Frequency
Range

Input Level
Range

Trigger

Timing/Trigger
External
Trigger Input
Characteristics

Acquisition Mode

Trigger Source IF Level or Timing/Trigger Input

Trigger Types

Trigger Delay Range: 0 to 60 seconds

Trigger Position

IF Level Trigger The IF Level trigger compares the digitized time-domain data-stream

Description

± (10 Hz + 0.01 ppm)

1500 Ω

1 MHz up to 20 MHz ± 1 PPM in 1 MHz steps

–15 dBm to +15 dBm, 1 MHz to 15 MHz
–10 dBm to +15 dBm, 16 MHz to 20 MHz

dBm levels assume 50 Ω source

Impedance: 10 kΩ
Minimum High Threshold: 2.0 V
Maximum Low Threshold: 0.8 V
Minimum High Time: 10 ns
Minimum Low Time: 10 ns
Maximum Input Level without Damage: ±5 V peak continuous
Coupling: DC

Single or Continuous, Free Run or Triggered

Trigger disabled during Audio Demod, Signal Strength, and DPX
measurements

Trigger on rising edge, falling edge, above threshold level, or below
threshold level

Resolution: 1 μs

Range: 0 to 100%

Resolution: 1%

level against the threshold level setting.

74 H500 & SA2500 Service Manual

Table 25: General performance characteristics (cont.)

Specifications

Characteristic

Trigger
Threshold

Trigger
Bandwidth
Range

Description

Range: –160 dBm to +20 dBm

Resolution: 1 dB

5 kHz to 20 MHz in 1-2-5 sequence
10 MHz < Span ≤ 20 MHz: trigger BW = 20 M Hz
5 MHz < Span ≤ 10 MHz: trigger BW = 10 MHz
2 MHz < Span ≤ 5 MHz: trigger BW = 5 MHz
1 MHz < Span ≤ 2 MHz: trigger BW = 2 MHz
500 kHz < Span ≤ 1 MHz: trigger BW = 1 MHz
200 kHz < Span ≤ 500 kHz: trigger BW = 500 kHz
100 kHz < Span ≤ 200 kHz: trigger BW = 200 kHz
50 kHz < Span ≤ 100 kHz: trigger BW = 100 kHz
20 kHz < Span ≤ 50 kHz: trigger BW = 50 kHz
10 kHz < Span ≤ 20 kHz: trigger BW = 20 kHz
5 kHz < Span ≤ 10 kHz: trigger BW = 10 kHz

2.5 kHz < Span ≤ 5 kHz: trigger BW = 5 kHz

Spectrum mode only: Span ≤ 2.5 kHz: trigger BW = 2.5 kHz

Table 26: Spectrum analyzer characteristics

Characteristic

Center Frequency

Range

ing

Sett
Resolution

Span

ge

Ran

Setting
Resolution

Swept Spans (Wide Scanning)

Span Range 20 MHz to 6 GHz

Spectrums
per Second

Scan Speed

Resolution Bandwidth

Range

Setting
Resolution

Spectral Purity

Description

10 kHz to 6.2 GHz, preamp off

z to 6.2 G Hz, preamp on

10 MH

1Hz

1kHzto6.2GHz

z

1H

61, typical

1240 MHz per second, typical

10 Hz to 3 MHz (Manual RBW)
10 Hz to 1 MHz (Auto RBW)

1Hz

H500 & SA2500 Service Manual 75

Specifications

Table 26: Spectrum analyzer characteristics (cont.)

Characteristic

Displayed
Average
Noise Level,
Preamp On

Phase Noise

Residual
Spurious,
Preamp Off

Residual
Spurious,
Preamp On

Third Order
IMD

Second
Harmonic

Input Related
Spurious

Input Related
Spurious,
exception
frequencies,
Typical

Third Order
Intercept

Description

–153 dBm, 10 MHz to 2 GHz, 10 Hz RBW
–152 dBm, 2 G Hz to 4 GHz, 10 Hz RBW
–151 dBm, 4 to 5 GHz, 10 Hz RBW
–145 dBm, 5 to 6.2 GHz, 10 Hz RBW
Reference Level ≤ (DANL + 90 dB)

≤ –95 dBc/Hz @ 10 kHz offset
≤ –95 dBc/Hz @ 20 kHz offset
≤ –95 dBc/Hz @ 30 kHz offset
≤ –97 dBc/Hz @ 100 kHz offset
≤ –110 dBc/Hz @ 1 MHz offset

≤ –90 dBm, 0 dBm attenuator setting

Exception frequencies:
9 MHz to 19 MHz center frequency
3464 MHz center frequency
4592 MHz center frequency
5374 MHz to 5378 MHz center frequency
6160 MHz center frequency

≤ –105 dBm, 0 dBm attenuator setting

Exception frequencies:
9 MHz to 19 MHz center frequency
5374 MHz to 5378 MHz center frequency

≤ –70 dBc for two tones at or below the reference level, preamp off, all
gain settings Auto-coupled

≤ –60 dBc for a single tone at or below the reference level, preamp
off, all gain settings Auto-coupled

≤–70 dBc except for F

= 2.282 GHz ± 20 MHz

in

The reference for 'dB c' for this specification is the total power of all
signals present at the input of the instrument regardless of the current
span

≤ –55 dBc except for F

= 2.282 GHz ± 20 MHz

in

The reference for “dBc” for this specification is the total power of all
signals present at the input of the instrument regardless of the current
span

≥ +7 dBm, 0 dB Input Attenuation, Preamp Off

76 H500 & SA2500 Service Manual

Table 26: Spectrum analyzer characteristics (cont.)

Specifications

Characteristic

Spectral Display Amplitude

Reference
Level Range
and Units

Marker
Power
Accuracy

Display

Display
Modes

Number of
Averages

Description

Range: +20 dBm to –160 dBm

Units: dBm, dBmV, dBuV, dBV, dBW, V, W

±1.75 dB, –50 dBm ≤ input ≤ +20 dBm, preamp off

±3.0 dB, –80 dBm ≤ input < –50 dBm, preamp on, above 10 MHz

±3.75 dB, –120 dBm ≤ input < –80 dBm, preamp on, above 10 MHz

Use peak detector for CW signals

Accuracy guaranteed for CW signals and span set to 20 MHz or less

Normal - updates display with each new result
Max Hold - updates displayed point only if new point > old
Min H old - updates displayed point only if new point < old
Max/MinHold-displaysavertical bar between Max Hold and Min Hold
Average - displays average of N (specified by user) acquisitions

Average is calculated as follows:

Last N values are saved in memory; when a new result is available,
the earliest result of the N stored values is discarded, the new result
is added to the stored values, and a new average is calculated from
the stored values
If the number of results is less than N, then all of the results are
averaged together

1 ≤ N ≤ 200

Table 27: DPX measurement processing characteristics

racteristic

Cha

ectrum

Sp
Processing Rate,
Typical

Minimum Signal

uration for 100%

D
Probability of
Intercept, Typical

Span Range

RBW Settings RBW = Span/200

Description

00 (or SA2500 with Option EP1): 10,000 per second (span

H5
independent)
SA2500: 2,500 per second (span independent)

H500 (or SA 2500 with Option EP1): 125 μs

A2500: 500 μs

S

5kHzto20MHz

H500 & SA2500 Service Manual 77

Specifications

Table 28: Spect

Characteristic

Spectrum
Processing Rate

Minimum Signal
Duration fo
Measurement

Span Range

rogram (Rising Raster) measurement processing characteristics

Description

20 spectrums p

20 ms typical

rTime

5kHzto20MH

er second nominal

z

Table 29: General purpose RF measurement characteristics

Characteristic

General Purpose RF Channel Power Measurement

Measurement
Bandwidth
Range

Accuracy ≤1.2 dB; +20 dBm to –60 dBm; Resolution BW < 100 kHz

Occupied Bandwidth Measurement

Percent
Power
Inclusion
Range

RF Field Strength

Channel
Bandwidth
Range

Accuracy

Description

1kHz–20MHz

+20 dBm to –40 dBm; Resolution BW ≥ 100 kHz
1 MHz to 3.2 GHz , preamp off

≤2 .4 dB; –60 dBm to –75 dBm; Resolution BW < 100 kHz
–40 dBm to –55 dBm; Resolution BW ≥ 100 kHz
10 MHz to 3.2 GHz , preamp on

≤1.8 dB; +20 dBm to –50 dBm; Resolution BW < 100 kHz
+20 dBm to –40 dBm; Resolution BW ≥ 100 kHz

3.2 GHz to 6.2 GHz , preamp off

≤3 dB; –50 dBm to –75 dBm; Resolution BW < 100 kHz
–40 dBm to –55 dBm; Resolution BW ≥ 100 kHz

3.2 GHz to 6.2 GHz , preamp on

Specifications apply for default c ontrol settings (Auto RBW, Auto Level)

50% - 100% in 1% steps

Same as Channel Power

Same as Channel Power

78 H500 & SA2500 Service Manual

Specifications

Table 30: Ampli

Characteristic Description

Center Frequency

Range

Resolution 1 Hz

Span

Range 5 kHz to 20 MHz in 1-2-5 sequence

Acquisition Length

Range 1024 to 10

Time Dis

Refere
Range and Units

Marker Power
Accur

Displ

Detector Types

Tra

Number of
Averages

Export I/Q Data I/Q data from can be exported in the following formats:

play Amplitude

nce Level

acy

ay

ce Types

tude vs. Time measurement characteristics

Minimum center frequency = 10 kHz + Span / 2, preamp off

Minimum center frequency = 10 MHz, preamp on

Maximum cen

Sample rate is automatically set based on the span selection

36 μs to 149 seconds, depending on span and number of samples

Span setting and number of samples selected determine the acquisition
length

Sample rate is automatically set based on span selection

+20 dBm to –160 dBm

dBm, dB

±1.8 d

± 3.0 dB, –75 dB m ≤ input < –40 dBm, preamp on, above 10 MHz

age: One display point represents the average value of a group of

Aver
data points
+Peak: One display point represents the maximum value of a group of

points

data
–Peak: One display point represents the minimum value of a group of
data points

ak/–Peak: One vertical bar represents the maximum and minimum

+Pe
values of a group of data points

mal: updates display with each new result

Nor
Max Hold: updates displayed point only if new point > old

Min Hold: updates displayed point only if new point < old

x/Min Hold: displays a vertical bar between Max Hold and Min Hold

Ma
Average: displays average of N (specified by user) acquisitions

N ≤ 200

1 ≤

QT: in-phase and quadrature phase data for post-processing with

I
RSAVu
CSV: comma-separated values in ASCII format
MAT: Matlab®-compatible file format

ter frequency = 6.2 GHz

24000 samples

mV, dBuV, dBV, dBW, V, W

B, –50 dBm ≤ input ≤ +20 dBm, preamp off

H500 & SA2500 Service Manual 79

Specifications

Table 31: Signa

Characteristic

AM
Demodulation

Measurement
Frequency

Minimum
Input Signal
Level,
Typical

Audio
Measurement
Bandwidth

FM
Demodulation

Measurement
Frequenc

Minimum
Signal L
Typical

Maximu
Signal
Deviation

Audio
Measurement
Bandw

Maximum
Audio
Bandwidth

Signal Strength
Indicator

Input Signal
Lev

Measurement
Fr

Measurement
Ba

Tone Type

Update Rate,
T

y

evel,

m

idth

Output

el

equency

ndwidth

ypical

l analysis and monitoring characteristics

Description

Provides an audio output signal after AM demodulation of the
user-selected signal

As previously selected

-100 dBm

8kHz

Provides an audio output signal after FM demodulation of the

ected signal

user-sel

As previously selected

-100 dBm

Up to 10

8kHz,15kHz,75kHz,or200kHz

15 kHz

Prov
strength of the user selected signal

-120 dBm, minimum

As previously selected

Up to 20 MHz, dependent upon span and RBW setting

V

10 per second

0kHz

ides both an audio tone and a visual display that are related to the

ariable beep rate or variable frequency

80 H500 & SA2500 Service Manual

Specifications

Tabl e 32: Envir

Characteristic Description

Temperature

Humidity

Altitude

onmental characteristics

Operating: 0 °C to +50 °C specifi ed performance, –10 °C to +50 °C,
typical

Nonoperatin

The temperature specs above are modified with the following options
installed:

Li-Ion Batt

Operating a
+30 ° C, 5% to 45% RH above +30 °C up to +50 °C, noncondensing

Operating: Up to 4,600 meters (15,092 feet)

Nonoperating: Up to 12,192 meters (40,000 feet)

g: –40 °C to +60 ° C

eries: Charge 0 °C to +45 °C, Storage –20 °C to +60 °C

nd Nonoperating: 5% to 95% relative humidity (RH) at up to

Table 33: Physical characteristics

Characteristic Description

Dimensions

Weight

Height: 25.5 cm. (10.0 in)

Width: 33 cm. (13 in)

Depth: 12.5 cm. (4.8 in)

6.0 kg (13.25 lbs): instrument and 1 battery

Table 34: Miscellaneous characteristics

cteristic

Chara

Recommended

rument

Inst
Calibration
Interval

Descr

1 year

iption

H500 & SA2500 Service Manual 81
