1 Introduction to RT-Eye FB-DIMM Compliance Module
This document provides the procedures for making FB-DIMM compliance measurements with
Tektronix TDS6604B, TDS6804B, TDS7704B, TDS6124C, and TDS6154C oscilloscopes. The
FB-DIMM Compliance Module (
Data Compliance and Analysis application (
Module provides amplitude, timing, and jitter measurements described in Section 3 of Revision 0.7 of
the FB-DIMM Draft Specification dated May 10, 2005. (For Compliance testing of FB-DIMM signals
(3.2 Gb/s, 4.0 Gb/s and 4.8 Gb/s) a minimum oscilloscope BW of 12 GHz is required. Using an
8 GHz BW oscilloscope, you can test the 3.2 GB/s FB-DIMM signals for compliance)
All references to the Draft Specification are to Revision 0.7 of the FB-DIMM Draft Specification. In
the subsequent sections, step-by-step procedures are described to help you perform FB-DIMM
measurements. Each measurement is described as a Method of Implementation (MOI). For further
information, refer the Compliance checklists offered to JEDEC members at
Opt. FBD) is an optional software plug-in to the RT-Eye Serial
Opt. RTE-Version 2.0). The FB-DIMM Compliance
www.jedec.org.
2 FB-DIMM Compliance Measurements
Electrical Specifications for FB-DIMM are provided in Section 3 of the Draft Specification. Most of
the measurements are available in the FB-DIMM Compliance Module.
2.1 Common Specifications between Transmitter and Receiver
The TX and RX PLLs shall obey the bandwidth and jitter peaking specifications in the following
table for continuous transmission operation.
Table 1: PLL Specification for TX and RX
Fully Buffered DIMM (FB-DIMM) 1
Methods of Implementation
2.2 Differential Transmitter (TX) Output Specifications
See the Draft Specification for additional notes and a test definition.
Table 2: Summary of Differential Transmitter Output Specifications (Sheet 1 of 2)
2 Fully Buffered DIMM (FB-DIMM)
Methods of Implementation
Table 2: Summary of Differential Transmitter Output Specifications (Sheet 2 of 2)
NOTES:
1. Specified at the package pins into a timing and voltage compliance test load. Common-mode measurements to be
performed using a 101010 pattern.
2. The transmitter designer should not artificially elevate the common mode in order to meet this specification.
3. This is the ratio of the VTX-DIFFp-p of the second and following bits after a transition divided by the VTX-DIFFp-p of
the first bit after a transition.
4. De-emphasis will be disabled in the calibration state.
5. Includes all sources of AC common mode noise.
6. Single-ended voltages below this value that are simultaneously detected on D+ and D- are interpreted as the electrical
idle condition.
7. Specified at the package pins into a voltage compliance test load. Transmitters must meet both single-ended and
differential output EI specifications.
Fully Buffered DIMM (FB-DIMM) 3
Methods of Implementation
8. This specification, considered with VRX-IDLE-SE-DC, implies a maximum 15 mV single-ended DC offset between TX
and RX pins during the electrical idle condition. This in turn allows a ground offset between adjacent FB-DIMM agents
of 26 mV when worst case termination resistance matching is considered.
9. The maximum value is specified to be at least (VTX-DIFFp-p L / 4) + VTX-CM L + (VTX-CM-ACp-p / 2)
10. This number does not include the effects of SSC or reference clock jitter.
11. Defined as the Dual-Dirac deterministic jitter as described in Section 4.
12. Pulse width measured at 0 V differential.
13. One of the components that contribute to the deterioration of the return loss is the ESD structure, which needs to be
carefully designed.
14. The termination small signal resistance; tolerance across voltages from 100 mV to 400 mV shall not exceed ± 5 and
with regard to the average of the values measured at 100 mV and at 400 mV for that pin.
15. Lane to lane skew at the transmitter pins for an end component.
16. Lane to lane skew at the transmitter pins for an intermediate component (assuming zero Lane to Lane skew at the
receiver pins of the incoming PORT).
17. This is a static skew. An FB-DIMM component cannot change its lane to lane phase relationship after initialization.
18. Measured from the reference clock edge to the center of the output eye. This specification must be met across
specified voltage and temperature ranges for a single component. Drift rate of change is significantly below the
tracking capability of the receiver.
19. BER per differential lane. Refer to Section 4 for a complete definition of Bit Error Ratio.
2.3 Differential Transmitter (TX) Compliance Eye Diagrams
Refer Section 3.3.1 of the Draft Specification for eye diagram definition.
Figure 1: Transmitter output eye specifications, with and without de-emphasis
4 Fully Buffered DIMM (FB-DIMM)
2.4 Differential Receiver (RX) Input Specifications
See the Draft Specification for additional notes and test definitions.
Table 3: Summary of Differential Receiver Input Specification (Sheet 1 of 2)
Methods of Implementation
Fully Buffered DIMM (FB-DIMM) 5
Methods of Implementation
Table 3: Summary of Differential Receiver Input Specification (Sheet 2 of 2)
NOTES:
1. Specified at the package pins into a timing and voltage compliant test setup. Note that signal levels at the pad will be
lower than at the pin.
2. Single-ended voltages below that value that are simultaneously detected on D+ and D- is interpreted as the Electrical
Idle condition. Worst case margins are determined by comparing EI levels with common mode levels during normal
operation for the case with transmitter using small voltage swing. See Figure 3-16 and Figure 3-17.
3. Multiple lanes need to detect the EI condition before the device can act upon the EI detection.
4. Specified at the package pins into a timing and voltage compliance test setup.
5. Receiver designers may implement either single-ended or differential EI detection. Receivers must meet the
specification that corresponds to the implemented detection circuit.
6. This specification, considered with V
and RX pins during the electrical idle condition. This in turn allows a ground offset between adjacent FB-DIMM agents
of 26 mV when worst case termination resistance matching is considered.
7. See Figure 3-13 and Figure 3-14. The single-pulse mask provides sufficient symbol energy for reliable RX reception.
Each symbol must comply with both the single-pulse mask and the cumulative eye mask.
8. See Figure 3-15. The relative amplitude ratio limit between adjacent symbols prevents excessive inter-symbol
interference in the Rx. Each symbol must comply with the peak amplitude ratio with regard to both the preceding and
subsequent symbols.
9. This number does not include the effects of SSC or reference clock jitter.
10. This number includes setup and hold of the RX sampling flop.
11. Defined as the Dual-Dirac deterministic timing error as described in Section 4.
12. Allows for 15 mV DC offset between transmit and receive devices.
13. The received differential signal must satisfy this ratio as well as the absolute maximum AC peak-to-peak common
mode specification. For example, if VRX-DIFFp-p is 200 mV, the maximum AC peak-to-peak common mode is the
lesser of (200 mV *0.45 = 90 mV) and VRX-CM-ACp-p.
14. One of the components that contribute to the deterioration of the return loss is the ESD structure that needs to be
carefully designed.
TX-IDLE-SE-DC, implies a maximum 15 mV single-ended DC offset between TX
6 Fully Buffered DIMM (FB-DIMM)
15. The termination small signal resistance; tolerance across voltages from 100 mV to 400 mV shall not exceed ± 5 Ω with
regard to the average of the values measured at 100 mV and at 400 mV for that pin.
16. This number represents the lane-to-lane skew between TX and RX pins and does not include the transmitter output
skew from the component driving the signal to the receiver. This is one component of the end-to-end channel skew in
the AMB specification.
17. Measured from the reference clock edge to the center of the input eye. This specification must be met across
specified voltage and temperature ranges for a single component. Drift rate of change is significantly below the
tracking capability of the receiver.
18. This bandwidth number assumes that the specified minimum data transition density. Maximum jitter at 0.2 MHz is 0.05
UI, see Section 4 for full jitter tolerance mask.
19. The specified time includes the time required to forward the EI entry condition.
20. BER per differential lane. Refer to Section 4 for a complete definition of Bit Error Ratio.
2.5 Receiver Compliance Eye Diagrams
See Section 3.4.1 of the Draft Specification for eye diagram definition.
Methods of Implementation
Figure 2: Receiver input eye voltage and timing specifications
Fully Buffered DIMM (FB-DIMM) 7
Methods of Implementation
2.6 Reference Clock Specifications
See the Draft Specification for additional notes and test definitions.
Table 4: Summary of Reference Clock Input Specifications (Sheet 1of 2)
8 Fully Buffered DIMM (FB-DIMM)
Methods of Implementation
Table 4: Summary of Reference Clock Input Specifications (Sheet 2 of 2)
NOTES:
1. The nominal reference clock frequency is determined by the data frequency of the link divided by 2 times the fixed
PLL multiplication factor for the FB-DIMM channel (6:1). f
on.
2. Measured with SSC disabled. Enabling SSC will reduce the reference clock frequency as described in Section 3.1.2.
3. Not all FB-DIMM agents will support all frequencies; compliance to the frequency specifications is only required for
those data rates that are supported by the device under test.
4. Measurement taken from single-ended waveform.
5. Measurement taken from differential waveform.
6. Defined as the maximum instantaneous voltage including overshoot. See Figure 3-3.
7. Defined as the minimum instantaneous voltage including undershoot See Figure 3-3.
8. Measured at the crossing point where the instantaneous voltage value of the rising edge of REFCLK+ equals the
falling edge of REFCLK-. See Figure 3-3.
9. Refers to the total variation from the lowest crossing pint to the highest, regardless of which edge is crossing. Refers
to all crossing points for this measurement. See Figure 3-3.
10. Defined as the total variation of all crossing voltages of rising REFCLK+ and falling REFCLK-. This is the maximum
allowed variance in for any particular system. See Figure 3-4.
11. The majority of the reference clock AC common mode occurs at high frequency (that is the reference clock
frequency).
12. Measured from -150 mV to + 150 mV on the differential waveform. The signal must be monotonic through the
measurement region for rise and fall time. The 300 mV measurement window is centered on the differential 0 V
crossing. See Figure 3-5.
13. Edge rate matching applies to rising edge rate for REFCLK+ and falling edge rate for REFCLK-. It is measured using
a ± 75 mV window centered on the median cross point where REFCLK+ rising meets REFCLK- falling. The median
crosspoint is used to calculate the voltage thresholds the oscilloscope uses for the edge rate calculations. The rising
edge rate of REFCLK+ should be compared to the falling edge rate of REFCLK-. The maximum allowed difference
should not exceed 20% of the slowest edge rate. See Figure 3-6.
14. See Figure 3-7. Tstable is the time the differential clock must maintain a minimum ± 150 mV differential voltage after
rising / falling edges before it is allowed to drop back into the ± 100 mV differential range.
15. Measured with a single-ended input voltage of 1 V.
data = 2000 MHz for a 4.0 Gbps FB-DIMM channel and so
Fully Buffered DIMM (FB-DIMM) 9
Methods of Implementation
16. Applies to RefClk and RefClk#.
17. This parameter is not a direct clock output parameter but it indirectly determines the clock output parameter TREFJITTER. This number is valid for 3.2 Gb/s and 4.0 Gb/s operation.
18. Implies a -3 dB bandwidth of 11 MHz and jitter peaking of 3 dB.
19. Implies a -3 dB bandwidth of 33 MHz and jitter peaking of 3 dB.
20. The net transport delay is the difference in time of flight between associated data and clock paths. The data path is
defined from the reference clock source, through the TX, to data arrival at the data sampling point in the RX. The
clock path is defined from the reference clock source to clock arrival at the same sampling point. See Figure 3-8. The
path delays are caused by copper trace routes, on-chip routing, on-chip buffering, etc. They include the time-of-flight
of interpolators or other clock adjustment mechanisms. They do not include the phase delays caused by finite PLL
loop bandwidth because these delays are modeled by the PLL transfer functions. This bandwidth number assumes
the specified minimum data transition density.
21. Direct measurement of phase jitter records over NSAMPLE periods may be impractical. It is expected that the jitter will
be measured over a smaller, yet statistically significant, sample size and the total jitter at NSAMPLE samples
extrapolated from an estimate of the sigma of the random jitter components. For details on this measurement, refer to
Section 4.
22. Measured with SSC enabled on reference clock generator.
23. As “measured” after the phase jitter filter. This number is separate from the receiver jitter budget that is defined by the
TRX-Total-MIN parameters.
10 Fully Buffered DIMM (FB-DIMM)
Methods of Implementation
3 Preparing to Take Measurements
3.1 Required Equipment
The following equipment is required to take measurements:
• TDS6604B or TDS6804B or TDS7704B or TDS6124C or TDS6154C oscilloscope with the
RT-Eye software (Opt. RTE- version 2.0) and FB-DIMM Compliance Module (FBD) installed.
• Probes – probing configuration is MOI specific. Refer to each MOI for correct probe
configuration.
• Test fixture −Tektronix differential probing fixture- NEX-TDSFBDP. To order, click
http://www.busboards.com/products/scopeAccessories/tdsfbdp/index.html.
3.2 Probing Options for Transmitter testing
The first step is to probe the link. Currently, the FB-DIMM specifications have defined the ball of
the AMB as the test point.
3.2.1 SMA Connection
1. Two TCA-SMA inputs using SMA
cables (Ch1) and (Ch3)
The differential signal is created by
the RT-Eye software from the math
waveform Ch1-Ch3. The Common
mode AC measurement is also
available in this configuration from
the common mode waveform
(Ch1+Ch3)/2. This probing technique
requires breaking the link and
terminating into a 50 Ω/side
termination of the oscilloscope. While
in this mode, the FB-DIMM Serdes
will transmit the compliance test
pattern (IBIST Pattern) to maximize
data dependent jitter. Ch-Ch de-skew
is required as two channels are used.
This configuration does not
compensate for cable loss in the SMA
cables. The measurement reference
plane is at the input of the TCA-SMA
connectors on the oscilloscope. Any
cable loss should be measured and
entered into the vertical attenuation
menu for accurate measurements at
the SMA Cable attachment point.
Probe Configuration A
SMA Psuedo-differential
Fully Buffered DIMM (FB-DIMM) 11
Methods of Implementation
2. One P7380SMA differential active
probe (Ch1). (Only useful for 3.2
Gb/s data rate)
The differential signal is measured
across the termination resistors inside
the P7380SMA probe. This probing
technique requires breaking the link.
While in this mode, the FB-DIMM
Serdes will transmit the compliance
test pattern to maximize data
dependent jitter. Matched cables are
provided with the P7380 probe to
avoid introducing de-skew into the
system. Only one channel of the
oscilloscope is used. The P7380SMA
provides a calibrated system at the
Test Fixture attachment point,
eliminating the need of compensating
for cable loss associated with the
probe configuration A.
3.2.2 AMB Ball connection
Probe Configuration B
SMA Input Differential Probe
3. Two active probes (Ch1) and (Ch3)
The differential signal is created by
the RT-Eye software from the math
waveform Ch1-Ch3. The Common
mode AC measurement is also
available in this configuration from
the common mode waveform
(Ch1+Ch3)/2. This probing technique
can be used for either a live link that
is transmitting data, or a link that is
terminated into a “dummy load.” In
both the cases, the single-ended
signals should be probed as close as
possible to the termination resistors
on both sides with the shortest
ground connection possible. Ch-Ch
de-skew is required because two
channels are used.
Probe Configuration C
Two Single-ended Active Probes
12 Fully Buffered DIMM (FB-DIMM)
Methods of Implementation
4. One P7380 (3.2 Gb/s data rate
only)/P7313 Differential probe
(Ch1)
The differential signal is measured
directly across the termination
resistors. This probing technique can
be used for either a live link that is
transmitting data, or a link terminated
into a “dummy load.” In both cases,
the signals should be probed as close
as possible to the termination
resistors. De-skew is not necessary as
a single channel is used.
Probe Configuration D
One Differential Active Probe
3.3 Initial Oscilloscope Setup
After connecting the Device Under Test (DUT), follow the proper probing configuration for the test.
Click the DEFAULT setup button and the AUTOSET to display the serial data bit stream.
3.4 Running the RT-Eye Software
1. Go to File> Run Application> RT-Eye Serial Compliance and Analysis. For B and C series
oscilloscopes, select App>RT-Eye …. Please refer to the OLH.
Figure 3: Default menu of the RT-Eye software
Figure 3 shows the oscilloscope display. The default mode of the software is the Serial Analysis
module (Opt. RTE-Version 2.0). This software is intended for generalized Serial Data analysis on
8B/10B encoded copper links.
Fully Buffered DIMM (FB-DIMM) 13
Methods of Implementation
2. Select the FB-DIMM Compliance Module from the Modules pull-down list.
Figure 4: Choosing FB-DIMM Compliance Module
Note: If FB-DIMM does not appear in the list, the FB-DIMM Compliance Module (Opt. FBD) has
not been installed.
The rest of this MOI document details use of the FB-DIMM Compliance Module to perform
electrical compliance measurements.
For additional information about the FB-DIMM Compliance Module, refer to the online help, which
is available in the Help Menu for the RT-Eye software.
3.5 Clock Recovery
Second-order PLL is used. Refer to section 2.X of Common Specifications between TX and RX in
the Draft Specifications. Also refer to Table 1 of this MOI. (Serial analysis has several CDRs. You
can configure the CDR in the SA module to be exactly the same as that in FB-DIMM.)
4 FB-DIMM Receiver (RX) Compliance Testing
This section provides the Methods of Implementation (MOIs) for Receiver tests using a Tektronix
real-time oscilloscope, probes, the RT-Eye compliance software solution (version 2.0), and with the
Tektronix test fixture - NEX-TDSFBDP / JEDEC parametric test fixture.
To order FBD scope probe kit, click
http://www.busboards.com/products/scopeAccessories/tdsfbdp/index.html
4.1 Probing the Link for RX Compliance
Use probing configuration (B or D) to probe the link differentially at a point close to the pins of the
receiver device.
This method (using the Tektronix NEX-TDSFBDP FBD scope probe kit and P7313 probes) of
probing at the ball of the RX AMB:
• Is the only direct method of testing the eye opening at the receiver.
• Includes all segments of the transmission channel: TX board loss, Connector Loss (both TX and
RX side), and RX board loss.
14 Fully Buffered DIMM (FB-DIMM)
Methods of Implementation
• Both Common Mode and Differential Mode measurements can be made directly. This method
indirectly assures Slot Connector Compliance if a compliant standard blank DIMM Module is
used as the test vehicle.
• The NEX-TDSFBDP test fixtures provide the flexibility to perform Differential and Common
Mode measurements. This test fixture consists of four blank DIMMs with ten probe tip clip
connectors and termination resistors. The user can solder up to three probe tip clip connectors to
the relevant South Bound Receiver lanes on one blank DIMM and test a maximum of three
FB-DIMM South Bound lines. The user can also configure the NEX-TDSFBDP test fixture to
test the remaining seven South Bound lanes or Reference Clock.
Figure 5: NEX-TDSFBDP test fixture
Alternatively, use probing configuration A or C using Ch1 and Ch3 inputs of an oscilloscope (using
an SMA break out fixture) that has 40 GS/s sample rate available on two channels (only TDS6124C
and TDS6154C series).
4.2 Running a Complete RX Compliance Test
The MOIs for each RX test are documented in the following sections. All RX measurements can be
selected and run simultaneously with the same acquisition. To perform a compliance test of all
receiver measurements:
1. In the FBDIMM module, set the Bit Rate to 3.2 Gb/s, 4.0 Gb/s or 4.8 Gb/s.
2. Select Receiver from the Test Point pull-down list.
3. Select Differential or Single-Ended as the Probe Type, depending on your probe configuration.
Figure 6: Measurements select menu setup
4. Click Select Required.
Fully Buffered DIMM (FB-DIMM) 15
Methods of Implementation
5. Click Configure to access the Configuration menus and to set up Signal Source.
6. Click Autoset to auto set signal and reference levels.
7. Click Start and choose between single run or continue run.
Figure 7 shows the result of a Receiver Compliance test on a signal that passes all receiver tests.
Figure 7: Result of completed receiver compliance test
4.2.1 RX Differential Pk-Pk Input Voltage MOI
Test Definition Notes from the Specification:
-
|2
−∗=
VVV
- Specified at the measurement point and measured over the entire data. The test load in Figure 1-1
(Draft Specification) should be used as the RX device while taking measurements. Also refer to
the receiver compliance eye diagram shown in Figure 3-12 (Draft Specification).
V
pDIFFpRX
−−
(Differential Input Pk-Pk Voltage) is defined in Table 3-12 (Draft Specification).
Differential Pk-Pk Voltage characteristics are: Maximum = 1.3 V and Minimum = 0.170 V. This
16 Fully Buffered DIMM (FB-DIMM)
|
−−+−−−
DRXDRXpDIFFpRX
Methods of Implementation
measurement is solved by two measurements: Differential Peak Voltage and Eye Height
measurement.
Test Procedure:
Follow the procedure in Section 5.3.1 (of this MOI), ensuring that Differential Voltage is selected
in the Measurements> Select menu.
PASS Condition:
V
pDIFFpRX
−−
< 1.3 V and 170 mV < Eye Height
Measurement Algorithm:
Refer to section 5.3.1 of this MOI document for Differential Voltage measurement and Eye Height
measurement algorithms.
Note: For receiver testing, Eye Height is measured on all UIs. There is no separate Eye Height for
Transition bits measurement and Non-Transition bits measurement.
4.2.2 Minimum RX Eye Width MOI
Test Definition Notes from the Draft Specification:
- The maximum interconnect media and transmitter jitter that can be tolerated by the receiver can
be derived as
and 4.0 Gb/s. You can derive from it to get T_RX-EYE.
- Specified at the measurement point and measured over the entire data. The test load in Figure 1-1
(Draft Specification) should be used as the RX device while taking measurements. Also refer to
the receiver compliance eye diagram shown in Figure 3-12 (Draft Specification).
- A TJ = 0.4 UI provides for a total sum of deterministic and random jitter budget for the
transmitter and interconnect. The
distribution in which the median and the maximum deviation from the median is less than half of
the total 0.4 UI jitter budget collected over the entire data.
T
UITT
6.1=−=
EYERXJITTERMAXRX
−−−
. T_RX-TJ_MAX in Table 3-4 is 0.4 UI for 3.2
specification ensures a jitter
JITTERMAXtoMEDIANEYERX
−−−−−
Note: The median is not the same as the mean. The jitter median describes the point in time where
the number of jitter points on either side is approximately equal as opposed to the averaged time
value.
(Minimum RX Eye Width) is defined in Table 4-6 of Version 1.0a of the Draft
EYERXT−
Specification.
Test Procedure:
Follow the procedure in Section 4.3 (Draft Specification), ensuring that Eye Width/Eye Height is
selected in the Measurements> Select menu.
Measurement Algorithm:
Refer to section 3.4.1 and 4.8 of the Draft Specification for Eye Width measurement algorithm.
Fully Buffered DIMM (FB-DIMM) 17
Methods of Implementation
4.2.3 RX AC Common Mode Input Voltage MOI
Test Definition Notes from Specification:
=−−
++
ACCMVRX
- Specified at the measurement point and measured over entire data. The test load in Figure 1-1
(Draft Specification) should be used as the RX device when taking measurements. Also refer to
the receiver compliance eye diagram shown in Figure 3-12 (Draft Specification).
Peak Common Mode Input Voltage) is defined in Table 3-4 (Draft Specification).
Limits:
Maximum = 270 mV and the pass condition is 270 mV >
Test Procedure:
Follow the procedure in Section 4.3 (Draft Specification), ensuring that AC CM Voltage is
selected in the Measurements> Select menu.
Note: AC CM voltage is available only when you select Single-ended probe type.
Measurement Algorithms:
This measurement is made over the entire data defined in Section 3.4 (Draft Specification).
AC CM Pk Voltage Measurement:
-D-VRXD-X −−++−
−
DVRXDVRXMinVRMax
22
ACpCMRXV−−
ACpCMRXV−−
(AC
The AC Common Mode Pk Voltage measurement returns the peak-to-peak value of common
mode. (Peak-to-peak value is not affected by DC).
4.2.4 RX DC Common Mode Input Voltage MOI
Test Definition Notes from the Specification:
VR
=−
)(
ofavgDCCMVRX
++
-D-VRXD-X
2
- Specified at the package pins into a timing and voltage compliant test load. Note that the signal
levels at the pad will be lower than at the pin.
Limits:
Maximum = 400mV and Minimum = 120mV
Test Procedure:
Follow the procedure in Section 4.3 (Draft Specification), ensuring that DC CM Voltage
selected in the Measurements> Select menu (Note: DC CM Voltage is only available when you
select Single-Ended probe type.)
18 Fully Buffered DIMM (FB-DIMM)
is
Measurement Algorithms:
This measurement is made over the entire data defined in Section 3.4 (Draft Specification).
The DC Common Mode measurement:
The DC Common Mode measurement returns the DC Average of the Common Mode Voltage
waveform.
4.2.5 RX Waveform Eye Diagram Mask Test MOI
Test Definition Notes from the Specification:
- The RX eye diagram in Figure 3-12 (Draft Specification) is specified using the passive
compliance/test measurement load (see Figure 1-1, Draft Specification) in place of any real
FB-DIMM RX component.
Note: In general, the minimum Receiver eye diagram measured with the compliance/test
measurement load (see Figure 1-1, Draft Specification) will be larger than the minimum Receiver
eye diagram measured over a range of systems at the input receiver of any real FB-DIMM
component. The degraded eye diagram at the input receiver is due to traces internal to the package
as well as silicon parasitic characteristics, which cause the real FB-DIMM component to vary in
impedance from the compliance/test measurement load. The input receiver eye diagram is
implementation specific and is not specified. The RX component designer should provide
additional margin to adequately compensate for the degraded minimum receiver eye diagram
(shown in Figure 3-12, Draft Specification) expected at the input receiver based on some adequate
combination of system simulations and the return loss measured looking into the RX package and
silicon.
Methods of Implementation
- The RX Eye diagram must be aligned in time using the jitter median to locate the center of the
eye diagram.
- The Eye diagram must be valid for the entire data.
Test Procedure:
Follow the procedure in Section 4.3 (Draft Specification), ensuring that Eye Width /Eye Height
selected in the Measurements> Select menu.
Measurement Algorithm:
This measurement is made over the entire data defined in Section 3.4 (Draft Specification).
The acquisition points are compared to the mask geometry (defined in Figure 4.24, Draft
Specification) and mask collisions are reported as Mask Hits in the Measurement Results area.
If Mask Hits > 0, then a failure is indicated in the Measurement Results table.
Fully Buffered DIMM (FB-DIMM) 19
is
Methods of Implementation
4.2.6 RX Input Rise/Fall Time test MOI
Test Definition Notes from the Specification:
- Specified at the measurement point into a timing and voltage compliance test load as shown in
Figure 1.1 (Draft Specification) and measured over the entire data. Also refer to the Receiver
compliance (Draft Specification).
- Measured between 20-80% at Receiver pins into a test load as shown in Figure 1.1 (Draft
Specification) for both
V
V
and
+−DRX
−−DRX
,
RISERXT−
(D+/D- RX output Rise/Fall Time) is defined in Table 3-3 (Draft
FALLRXT−
Specification).
Limits (specified only at Receiver pins compliance point):
Minimum = 50ps.
Test Procedure:
Follow the procedure in Section 4.3 (Draft Specification), ensuring that Rise Time and Fall Time
are selected in the Measurements> Select menu.
Measurement Algorithm:
This measurement is made over the entire duration of RX test pattern defined in Section 4 (Draft
Specification).
Rise/Fall time is limited to rising or falling edges of consecutive transitions for transmitter
measurements. (Even for single-ended, the differential waveform is computed and then the rise/fall
measurement performed.)
Note: Change the following descriptions to differential waveform only.
Rise Time: The Rise Time measurement is the time difference between when the V
level is crossed and the V
reference level is crossed on the rising edge of the waveform.
REF-LO
REF-HI
reference
−=
)()()( jtitnt
LOHIRISE ++
Where:
t is a Rise Time measurement
RISE
t
is a set of only for rising edges
+HI
t is a set of only for rising edges
+LO
i and j are indexes for nearest adjacent pairs of
t
HI
t
LO
t
and
t
+LO
+HI
n is a the index of rising edges in the waveform
20 Fully Buffered DIMM (FB-DIMM)
Methods of Implementation
Fall Time: The Fall Time measurement is the time difference between when the V
level is crossed and the V
Where:
is a Fall Time measurement
t
FALL
t
is set of t
HI–
t
is set of t
LO–
only for falling edge
HI
only for falling edge
LO
i and j are indexes for nearest adjacent pairs of t
n-is the index to falling edges in the waveform
4.2.7 RX Tj Test MOI
Test Definition Notes from the Specification:
Maximum receiver inherent timing error (Jitter)
Specified at the package pins into a timing and voltage compliance test load.
REF-LO
−=
)()()( jtitnt
HILOFALL −−
reference
REF-HI
reference level is crossed on the falling edge of the waveform.
LO–
and t
HI–
.
This value does not include the effects of SSC or ref clk jitter.
This includes the setup and hold of receiving sampling clock.
Limits:
Maximum = 0.4 UI for 3.2 and 4.0 Gb/s data rate.
Maximum = TBD UI for 4.8 Gb/s data rate.
Test Procedure:
Follow the procedure in Section 4.3 (Draft Specification), ensuring that Jitter@BER is selected in
the Measurements> Select menu.
Measurement Algorithm:
Total jitter is usually comprised of both random and deterministic components. In general, the DJ
component has its own PDF (Probability Distribution function), and the combined total jitter PDF
is a convolution of the DJ and RJ PDF’s. The Rx-Tj is estimated by equivalently deriving the CDF
(Cumulative Distribution Function) at measured points and extrapolating to a BER < 10
-9
, such
that a device exceeding the TJ specification is identified with a 99.7% confidence interval.
Fully Buffered DIMM (FB-DIMM) 21
Methods of Implementation
4.2.8 RX Dj Test MOI (Using Dual-Dirac Method)
Test Definition Notes from the Specification:
-This is the Maximum inherent deterministic timing error (Jitter) specified at the package pins into
a timing and voltage compliance test load.
-This value does not include the effects of SSC or ref clk jitter.
-This includes the setup and hold of receiving sampling clock.
-Defined as the Dual-Dirac timing error.
Limits:
Maximum = 0.3 UI for 3.2 and 4.0 Gb/s data rate.
Maximum = TBD for 4.8 Gb/s data rate.
Test Procedure:
Follow the procedure in Section 4.3 (Draft Specification), ensuring that Jitter@BER is selected in
the Measurements> Select menu.
Measurement Algorithm:
The DJ PDF is defined as a pair of Dirac delta functions (Dual-Dirac). The Dual-Dirac model is
assumed for system. The Dual-Dirac description is merely the linearization of the CDF
(Cumulative Distribution Function) at a particular BER. Since the CDF has two sides, this
linearization is performed twice, and the result is then combined. The Rx-Dj is estimated by
equivalently deriving the CDF at measured points and extrapolating to a BER < 10
-9
, such that a
device exceeding the DJ specification is identified with a 99.7% confidence interval.
22 Fully Buffered DIMM (FB-DIMM)
Methods of Implementation
5 FB-DIMM Transmitter (TX) Compliance Testing
This section provides the Methods of Implementation (MOIs) for Transmitter tests using a Tektronix
real-time oscilloscope, probes, and the RT-Eye compliance software with FB-DIMM (FBD) Module.
5.1 Probing the Link for TX Compliance
Use probing configuration (B or D) to probe the link differentially at a point close to the pins of the
receiver device.
Alternatively, use probing configuration (A or C) using the Ch1 and Ch3 inputs of an oscilloscope
that has a 40 GS/s sample rate available on two channels along with an SMA break-out fixture
(TDS6124C and TDS6154C Series).
Since probing at the ball of the TX AMB is not practical, you can use an SMA break-out fixture or a
JEDEC approved parametric fixture to test the TX points. However use care about the following
when you use an SMA break-out fixture or a JEDEC approved parametric fixture:
• Compensation of all the losses: a.) Transmission channel; TX board loss, b.) Connector Loss
(both TX and RX side), and c.) RX board losses are taken into consideration.
• Pseudo-differential measurements should be performed carefully and channel deskew plays an
important role.
5.1.1 TX Compliance Test Load
The compliance test load for Transmitter compliance is shown in Figure 8.
Figure 8: Transmitter Compliance Test Load
Fully Buffered DIMM (FB-DIMM) 23
Methods of Implementation
5.2 Running a TX Compliance Test
The only test point defined in the FB-DIMM specifications, for the TX Compliance Test is the TX
pins on the ball of the AMB. You can use the SMA break-out test fixture or the JEDEC test fixture
(measures at the connector and not at the ball of the AMB) if it is available. Care should be taken to
ensure that the test fixture does not add losses to the FB-DIMM signals. The test point that will be
defined by the transmitter test in the FB-DIMM Compliance Module is defined at installation of
Version 2.0 of the RT-Eye software. Version 2.0 supports only the Transmitter Pins Compliance
point. Refer to section 3.2 for more information on installing the proper test point. The transmitter
data rates can be 3.2 GB/s, 4.0 Gb/s, or 4.8 Gb/s. Each of these rates can have three voltage swing
settings and in each voltage swing setting you can have three de-emphasis levels. The following
table provides the details:
Table 5: Transmitter test point details
24 Fully Buffered DIMM (FB-DIMM)
Methods of Implementation
The MOI for each of the Transmitter tests is documented in the following sections. All Transmitter
measurements can be selected and run simultaneously with the same acquisition. To perform a
compliance test of all transmitter measurements:
1. In the Measurements> Select menu (Figure 9), select Bit rate (3.2/4.0/4.8Gb/s).
2. Click Transmitter from the Test Point pull-down list.
3. Select Single-Ended (probe configurations A & C defined in Section 3) or Differential (Probe
configurations B & D defined in Section 3) as the Probe Type, depending on your probe
configuration.
4. Click Configure to access the Configuration menus and set up the Signal Source. Click Select
to return to the Measurements> Select menu.
Figure 9: Measurements select menu setup
5. Click the desired measurements or click Select Required.
6. Click Autoset to auto set signal and reference levels.
7. Click Start.
Figure 10 shows the result of a Transmitter Compliance test on a signal that passes the transmitter
tests at TX compliance test points.
Fully Buffered DIMM (FB-DIMM) 25
Methods of Implementation
Figure 10: Result of a completed compliance test at the transmitter pins
5.2.1 TX Differential Pk-Pk Output Voltage MOI
Test Definition Notes from the Specification:
-
−∗=
VVV
- Specified at the measurement point into a timing and voltage compliance test load as shown in
Figure 1-1 (Draft Specification) and measured over entire TX test pattern as specified in section 4
of the draft specification. Also refer to the transmitter compliance eye diagram shown in
Figure 3-9 (Draft Specification).
V
pDIFFpTX
−−
(Differential Output Pk-Pk Voltage) is defined in Table 3-3 (Draft Specification).
Differential Pk-Pk Voltage characteristics are:
Maximum = 1.3 V and
Minimum = 0.90 V (large swing)
or
||2
−−+−−−
DTXDTXpDIFFpTX
26 Fully Buffered DIMM (FB-DIMM)
Methods of Implementation
Minimum = 0.80V (medium swing)
or
Minimum = 0.520V (small swing).
This measurement is solved by two measurements - Differential Peak Voltage measurement and
Eye Height: Transition bits measurement. Select Differential Voltage and Eye Width/Eye Height,
to get five measurements: Eye Height, Eye Height: Transition bits, Eye Height: Non-Transition
bits, Eye Width and Differential Peak Voltage.
Test Procedure:
Follow the procedure in Section 4.4 (Draft Specification), ensuring that Differential Voltage and
Eye Width/Eye Height are selected in the Measurements> Select menu.
Pass Condition:
Transmitter Pins Compliance Test Point:
Large Voltage Swing:
Transition Bit:
Non-Transition Bit:
Non-Transition Bit:
V
V
V
pDIFFpTX
−−
< 1.3 V and 0.900 V < Eye Height (No de-emphasis)
pDIFFpTX
−−
< 1.3 V and 0.567 V < Eye Height (-3.5 dB de-emphasis)
pDIFFpTX
−−
< 1.3 V and 0.402 V < Eye Height (-6.0 dB de-emphasis)
Regular Voltage Swing:
Transition Bit:
V
pDIFFpTX
−−
< 1.3 V (Not in the table 3-3 in spec) and 0.800 V < Eye
Height (No de-emphasis)
Non-Transition Bit:
Non-Transition Bit:
V
V
pDIFFpTX
−−
< 1.3 V and 0.504 V < Eye Height (-3.5 dB de-emphasis)
pDIFFpTX
−−
< 1.3 V and 0.357 V < Eye Height (-6.0 dB de-emphasis)
Small Voltage Swing:
Transition Bit:
Non-Transition Bit: < 1.3 V and 0.328 V < Eye Height (-3.5 dB de-emphasis)
V
V
pDIFFpTX
−−
< 1.3 V and 0.520 V < Eye Height (No de-emphasis)
pDIFFpTX
−−
Non-Transition Bit:
V
pDIFFpTX
−−
< 1.3 V and 0.232 V < Eye Height (-6.0 dB de-emphasis)
Fully Buffered DIMM (FB-DIMM) 27
Methods of Implementation
−
−
Measurement Algorithm:
These measurements are made over the entire TX test pattern defined in Section 4 (Draft
Specification).
Differential Peak Voltage Measurement: The Differential Peak Voltage measurement returns two
times the larger of the Min or Max statistic of the differential voltage waveform.
Where:
i is the index of all waveform values
v
DIFF
is the Differential voltage signal
Eye Height Measurement:
The measured minimum vertical eye opening at the UI center as shown in the plot of the eye
diagram. There are three types of Eye Height values:
Eye Height – Transition:
=
VVV
Where:
V
V
MINTRANHIEYE
−−−
is the minimum of the high transition bit eye voltage at mid UI
MAXTRANLOEYE
−−−
is the maximum of the low transition bit eye voltage at mid UI
Eye Height – Non-Transition:( -3.5 dB and -6 dB)
=
VVV
Where:
V
V
MINNTRANHIEYE
−−−
is the minimum of the high non-transition bit eye voltage at mid UI
MAXNTRANLOEYE
−−−
is the maximum of the low non-transition bit eye voltage at mid UI
MAXTRANLOEYEMINTRANHIEYETRANHEIGHTEYE
−−−−−−−−
MAXNTRANLOEYEMINNTRANHIEYENTRANHEIGHTEYE
−−−−−−−−
28 Fully Buffered DIMM (FB-DIMM)
Methods of Implementation
5.2.2 TX De-Emphasized Differential Output Voltage (Ratio) MOI
Test Definition Notes from the Specification:
- This is the ratio of
V
of the first bit after a transition.
pDIFFpTX
−−
V
of the second and following bits after a transition divided by the
pDIFFpTX
−−
- Specified at the measurement point into a timing and voltage compliance test load as shown in
Figure 3-11 (Draft Specification. Also refer to the transmitter compliance eye diagram shown in
Figure 3-9 (Draft Specification).
(De-Emphasized Differential Output Voltage (Ratio)) is defined in Table 3-3 (Draft
RATIODETXV−−
Specification).
Limits (specified only at transmitter pins compliance test point):
Maximum = -4.0 dB and Minimum = -3.0 dB, and the Pass Condition is
-3.0 dB <
RATIODETXV−−
< -4.0 dB
Limits (specified only at transmitter pins compliance test point):
Maximum = -7.0 dB and Minimum = -5.0 dB, and the Pass Condition is
-5.0 dB <
RATIODETXV−−
< -7.0 dB
Test Procedure:
Follow the procedure in Section 4.4 (Draft Specification), ensuring that De-Emphasis is selected
in the Measurements> Select menu.
Fully Buffered DIMM (FB-DIMM) 29
Methods of Implementation
Measurement Algorithm:
This measurement is made over the entire data defined in Section 3.4 (Draft Specification). The
De-Emphasis measurement calculates the ratio of any non-transition eye voltage (2
voltage succeeding an edge) to its nearest preceding transition eye voltage (1
nd
st
eye voltage
, 3rd, etc. eye
following an edge). In Figure 11, it is the ratio of the black voltages over the blue voltages. The
results are given in dB.
Figure 11: De-emphasis measurement
⎛
)(
⎜
dBmDEEM
=
⎜
⎝
−−
NTRANHIEYE
−−
TRANHIEYE
⎞
)(
mv
⎟
⎟
)(
nv
⎠
or
⎛
)(
⎜
dBmDEEM
=
⎜
⎝
−−
NTRANLOEYE
−−
TRANLOEYE
⎞
)(
mv
⎟
⎟
)(
nv
⎠
Where:
TRANHIEYEv−−
is the high voltage at mid UI following a positive transition.
TRANLOEYEv−−
is the low voltage at mid UI following a negative transition
NTRANHIEYEv−−
is the high voltage at mid UI following a positive transition bit
NTRANLOEYEv−−
is the low voltage at mid UI following a negative transition bit
m is the index for all non-transition UIs
n is the index for the nearest transition UI preceding the UI specified by m
30 Fully Buffered DIMM (FB-DIMM)
5.2.3 Minimum TX Eye Width MOI
Test Definition Notes from the Specification:
(Minimum TX Eye Width) is defined in Table 3-3 (Draft Specification).
EYETXT−
Limits:
Methods of Implementation
Transmitter pins compliance test point: 0.70 UI (218.75ps) <
Transmitter pins compliance test point: 0.70 UI (175.00ps) <
Transmitter Pins compliance test point: 0.74 UI (154.0ps) <
EYETXT−
for 3.2Gb/s rate
EYETXT−
for 4.0Gb/s rate
EYETXT−
for 4.8 GB/s rate (Not in
Table 3-3 in the current Draft Specification but will be ratified in the upcoming Draft Specification
version).
Test Procedure:
Follow the procedure in Section 4.4 (Draft Specification), ensuring that eye width/eye height is
selected in the Measurements> Select menu.
Measurement Algorithm:
This measurement is made over the entire TX test pattern defined in Section 4 (Draft
Specification).
The measured minimum horizontal eye opening at the zero reference level is:
TIEUIT
−=
PkPkAVGWIDTHEYE
−−
Where:
UI is the average UI
AVG
TIE
Fully Buffered DIMM (FB-DIMM) 31
is the Peak-Peak TIE
PkPk
−
Methods of Implementation
5.2.4 TX Output Rise/Fall Time MOI
Test Definition Notes from the Specification:
- Specified at the measurement point into a timing and voltage compliance test load as shown in
Figure 1.1 (Draft Specification) and measured over entire data. Also refer to the Transmitter
compliance (Draft Specification).
- Measured between 20-80% at Transmitter package pins into a test load as shown in Figure 1.1
(Draft Specification) for both
V
V
and
+−DTX
−−DTX
,
RISETXT−
(D+/D- TX Output Rise/Fall Time) is defined in Table 3-3 (Draft
FALLTXT−
Specification).
Limits (specified only at transmitter pins compliance point):
Minimum = 30ps
Maximum = 90ps.
Test Procedure:
Follow the procedure in Section 4.4 (Draft Specification), ensuring that Rise Time and Fall Time
are selected in the Measurements> Select menu.
Measurement Algorithm:
This measurement is made over the entire TX test pattern defined in Section 4 (Draft
Specification).
Rise/Fall time is limited to only rising or falling edges of consecutive transitions for transmitter
measurements. (This test is made on differential or pseudo differential waveforms only).
Differential signals Rise/Fall Time show up when you select Differential probe type.
Rise Time: The Rise Time measurement is the time difference between when the V
level is crossed and the V
reference level is crossed on the rising edge of the waveform.
REF-LO
REF-HI
reference
−=
)()()( jtitnt
LOHIRISE ++
Where:
t is a Rise Time measurement
RISE
t
is a set of only for rising edges
+HI
t is a set of only for rising edges
+LO
i and j are indexes for nearest adjacent pairs of
t
HI
t
LO
t
and .
t
+LO
+HI
n is a the index of rising edges in the waveform
32 Fully Buffered DIMM (FB-DIMM)
Methods of Implementation
Fall Time: The Fall Time measurement is the time difference between when the V
level is crossed and the V
−=
HILOFALL −−
reference level is crossed on the falling edge of the waveform.
REF-LO
)()()( jtitnt
Where:
t
is a Fall Time measurement
FALL
t
is set of t
HI–
t
is set of t
LO–
i and j are indexes for nearest adjacent pairs of t
only for falling edge
HI
only for falling edge
LO
LO–
and t
HI–
.
n is the index to falling edges in the waveform
REF-HI
reference
Fully Buffered DIMM (FB-DIMM) 33
Methods of Implementation
5.2.5 TX AC Common Mode Output Voltage MOI
Test Definition Notes from the Specification:
++
=−−
ACCMVTX
−
−−++−
DVTXDVTXMin-D-VTXD-XVMax
22
-Specified at the measurement point into a timing and voltage compliance test load as shown in
Figure 4-25 (Draft Specification) and common mode measurements to be performed using a
101010 pattern.
Limits (specified only at transmitter pins compliance point):
VTX-CM-ACp-p L Maximum = 90 mV
VTX-CM-ACp-p R Maximum = 80 mV
VTX-CM-ACp-p S Maximum = 70 mV
Test Procedure:
Follow the procedure in Section 4.4 (Draft Specification), ensuring that AC CM Voltage is
selected in the Measurements> Select menu.
Note: AC CM voltage is available only when Single-Ended probe type is selected.
Measurement Algorithm:
This measurement is made over the entire data defined in Section 3.4 (Draft Specification).
AC CM Voltage:
The AC Common Mode RMS Voltage measurement calculates the RMS statistic of the Common
Mode voltage waveform with the DC Value removed. (After DC is removed, the RMS on what is
left equals STD)
=
))(()( ivRMSiv
MACCMRMSAC −−−
Where:
i is the index of all waveform values
is the RMS of the AC Common Mode voltage signal
CMRMSACv−−
is the AC Common Mode voltage signal.
MACv−
34 Fully Buffered DIMM (FB-DIMM)
5.2.6 TX DC Common Mode Voltage MOI
Test Definition Notes from the Specification:
Methods of Implementation
Defined as:
V
=−
)(
ofavgDCCMVTX
++
-D-VTXD-X
2
- Specified at the measurement point into a timing and voltage compliance test load as shown in
Figure 4-25 (Draft Specification) and common-mode measurements to be performed using a
101010 pattern. Measured over the entire data. Also refer to the transmitter compliance eye
diagram shown in Figure 4-24 (Draft Specification).
Limits (specified only at transmitter pins compliance point):
VTX-CM_L Maximum = 375 mV
VTX-CM_S Maximum = 280 mV and VTX-CM_S Minimum = 135 mV.
Test Procedure:
Follow the procedure in Section 4.4 (Draft Specification), ensuring that DC Common Mode
Voltage is selected in the Measurements> Select menu.
Note: DC CM voltage available only when you select Single-Ended probe type.
Measurement Algorithm:
This measurement is made over the entire data defined in Section 3.4 (Draft Specification).
The DC Common Mode measurement:
The DC Common Mode measurement returns the average of absolute value of common mode
waveform.
Fully Buffered DIMM (FB-DIMM) 35
Methods of Implementation
5.2.7 TX Waveform Eye Diagram Mask Test MOI
Test Definition Notes from the Specification:
- The TX eye diagram in Figure 3-9 (Draft Specification) is specified using the passive
compliance/test measurement load in place of any real FB-DIMM interconnect + RX component.
- Twenty-seven eye diagrams must be met for the Transmitter. The eye diagrams must be aligned
in time using the jitter median to locate the center of the eye diagram. The different eye diagrams
will differ in voltage depending whether it is a transition bit or a de-emphasized bit. The exact
reduced voltage level of the de-emphasized bit will always be relative to the transition bit.
- The eye diagram must be valid for entire TX test pattern as defined in the section 4 of the draft
specifications.
For Transmitter Pins Mask Geometries from the Draft Specification, refer to the Figure 1 of this
MOI.
36 Fully Buffered DIMM (FB-DIMM)
5.2.8 TX Dj Dual-Dirac MOI
Test Definition Notes from the Specification:
-Specified at the package pins into a timing and voltage compliance test load. This number does
not include the effects of Spread Spectrum Clock (SSC) or reference clock jitter. Defined is the
Dual-Dirac deterministic jitter as described in Section 4 of the Draft Specification.
Limits (specified only at transmitter pins compliance point):
Maximum = 0.2 UI. For 3.2 Gb/s and 4.0 Gb/s data rate.
Maximum = TBD for 4.8 Gb/s data rate.
Test Procedure:
Follow the procedure in Section 4.4 (Draft Specification), ensuring that Jitter@BER is selected in
the Measurements> Select menu.
Measurement Algorithm: (refer to the same section in RX)
The DJ PDF is composed only of a pair of Dirac delta functions (Dual-Dirac). The Dual-Dirac
model is assumed for system, allowing rms RJ Gaussian components to be added with DJ
Dual-Dirac component linearly. The Dual-Dirac description is merely the linearization of the CDF
(Cumulative Distribution Function) at a particular BER. Since the CDF has two sides, this
linearization is performed twice, and the result is then combined. The Tx-Dj is estimated by
equivalently deriving the CDF at points where BER < 10
such that a device exceeding the DJ specification is identified with a 99.7% confidence interval.
Methods of Implementation
-9
and Extrapolating φ to a BER < 10-9,
Fully Buffered DIMM (FB-DIMM) 37
Methods of Implementation
6 FB-DIMM Reference Clock Compliance Testing
This section provides the Methods of Implementation (MOIs) for Reference clock tests using a
Tektronix real-time oscilloscope, probes, the RT-Eye compliance software solution (version 2.0), and
with the Tektronix NEX-TDSFBDP test fixture / JEDEC parametric test fixture.
• To reduce jitter and allow for future silicon fabrication process changes, HCSL (High-speed
Current Steering Logic) clocks are used, as illustrated in Figure 3-1(Draft Specifications). The
nominal single-ended swing for each clock is 0 to 0.7 V. The same system clock shall be
transmitted to the two components at the ends of the link, if necessary, through connector(s).
• The reference clock frequency is 1/24 of the link data rate, for example: 166.67 MHz for a data
rate of 4.0 Gb/s. The reference clock pair is routed point-to-point to each device from the system
board.
• The FB-DIMM channel uses mesochronous clocking; the phase relationship between TX
reference clock and RX reference clock is unspecified. However, in order to limit the jitter
difference between TX and RX there is an upper limit for the phase difference between the data
and reference clock at the RX (also known as the transport delay, specified in Table 3-1).
SSC (Spread Spectrum Clock) with up to -0.5% down spread in frequency shall be supported. The
frequency of the clock and bit rate can be modulated from 0% to -0.5% of the nominal data
rate/frequency, at a modulation rate between 30 kHz and 33 kHz. The modulation profile of SSC shall
be able to provide optimal or close to optimal EMI reduction. Typical profiles include triangular or
“Hershey kiss” profile.
6.1 Probing the Link for Reference Clock Compliance
Use probing configuration (B or D) to probe the link differentially at a point close to the pins of the
reference clock. Alternatively, use probing configuration (A or C) using the Ch1 and Ch3 inputs of
an oscilloscope that has 40 GS/s sample rate available on two channels (TDS6124C and TDS6154C
series only).
6.2 Running a Complete Reference clock Compliance Test
The MOIs for each Reference clock test are documented in the following sections. All Ref clock
measurements can be selected and run simultaneously with the same acquisition. To perform a
compliance test of all receiver measurements:
1. Select Measurements> Select.
2. Select Bit Rate.
3. Select Reference clock from the Test Point pull-down list.
4. Select Differential (or Single-Ended) as the Probe Type, depending on your probe
configuration.
38 Fully Buffered DIMM (FB-DIMM)
Methods of Implementation
Figure 12: Measurements Select menu setup
5. Click the Select Required.
6. Click Configure to access the Configuration menus and set up Signal Source.
7. Click Autoset to auto set signal and reference levels.
8. Click Start.
Figure 13 shows the result of a reference clock compliance test on a signal that passes the Reference
Clock tests.
Figure 13: Result of a completed compliance test at the reference clock pins
Fully Buffered DIMM (FB-DIMM) 39
Methods of Implementation
6.2.1 Reference Clock Frequency Measurement Test MOI
Test Definition Notes from the Specification:
Reference clock frequency is measured for each data rate of operation.
-This is measured with SSC disabled. Enabling SSC will reduce reference clock frequency.
-Compliance to frequency specification is only required for those data rates supported by the DUT.
Limits:
fRefclk-3.2 : Min = 126.67 MHz ; Max = 133.40 MHz ; Nominal = 133.33 MHz
fRefclk-4.0 : Min = 158.33 MHz ; Max = 166.75 MHz ; Nominal = 166.67 MHz
fRefclk-4.8 : Min = 190.00 MHz ; Max = 200.10 MHz ; Nominal = 200.00 MHz
Test Procedure:
Follow the procedure in Section 4.7 (Draft Specification), ensuring that reference clock
frequency
is selected in the Measurements> Select menu.
Measurement Algorithm:
The reference clock waveform period is calculated and the frequency is derived from the period
measurement.
Freq = 1/T period
Figure 14: Reference Clock
40 Fully Buffered DIMM (FB-DIMM)
Methods of Implementation
6.2.2 Reference Clock Differential Voltage Hi and Lo Test MOI
Test Definition Notes from the Specification:
Differential Voltage Hi and Differential Voltage Lo measurements are taken from differential
waveforms.
Limits:
Vref clk- Diff -Hi Minimum = +150 mV.
Vref clk – Diff-Lo Maximum = -150 mV.
Test Procedure:
Follow the procedure in Section 4.7 (Draft Specification), ensuring that Reference clock
differential voltage Hi/Lo is selected in the Measurements> Select menu.
Measurement Algorithm:
Hi voltage < 150 mV = Fail
Lo Voltage > -150 mV = Fail
Fully Buffered DIMM (FB-DIMM) 41
Methods of Implementation
6.2.3 Reference Clock Differential rise and fall edge rates test MOI
Test Definition Notes from the Specification:
The rising and falling edge rates measurements are taken from differential waveforms.
- Measured from -150 mV to + 150 mV on the differential waveform. The signal must be
monotonic through the measurement region for rise and fall time. The 300 mV measurement
Window is centered on the differential 0 V crossing.
Figure 15: Reference clock rise/fall time calculation
Limits:
Minimum = 0.6 V/ns
Maximum = 4 V/ns.
Test Procedure:
Follow the procedure in Section 4.7 (Draft Specification), ensuring that Rise Time/Fall Time
selected in the Measurements> Select menu.
Measurement Algorithm:
The rising edge and falling edge are calculated over the 300 mV window, which is centered at
differential 0 V. The rising/falling edge rate V/ns = 300 mV/Rise/Fall Time.
is
42 Fully Buffered DIMM (FB-DIMM)
6.2.4 Reference clock Duty cycle test MOI
Test Definition Notes from the Specification:
The duty cycle measurement of reference clock is taken from differential waveform.
Limits:
Minimum = 40%
Maximum = 60%
Test Procedure:
Methods of Implementation
Follow the procedure in Section 4.7 (Draft Specification), ensuring that duty cycle
the Measurements> Select menu.
Measurement Algorithm:
Duty Cycle = positive pulse width / clock period
This is measured at differential 0 V reference voltage level.
6.2.5 Reference Clock Jitter RMS Test MOI
Test Definition Notes from the Specification:
Different devices may have different phase jitter1 tracking behaviors due to variation of the jitter
transfer function of their PLLs, transport delays between transmitter and receiver, differences in
the propagation delays in the devices and the phase tracking bandwidth of the clock phase
recovery circuitry.
For the FB-DIMM channel to function properly when the transmitter and receiver use devices with
different phase jitter tracking behavior, a specification of the reference clock jitter spectrum is
necessary. To measure jitter on the reference clock and translate this directly into a data eye
closure at the receiver, the reference clock phase jitter is filtered by a phase jitter transfer function
that represents the worst case mismatch between transmitter and receiver’s phase tracking. After
convolving this frequency domain filter with the reference clock phase jitter spectrum, the peakpeak jitter is measured in the time domain. As this is a total jitter specification that includes both
deterministic and random jitter components, the sample size is also specified to meet the link’s
BER goal.
is selected in
• Measured with SSC enabled on reference clock generator
• Measured after phase Jitter filter
Limits:
Maximum = 3 ps.
Fully Buffered DIMM (FB-DIMM) 43
Methods of Implementation
Test Procedure:
Follow the procedure in Section 4.7 (Draft Specification), ensuring that Jitter@BER
the Measurements> Select menu.
Measurement Algorithm:
Refer to Specifications section 3.1.3.A second-order PLL transfer function is used as an
approximation for transmitter and receiver. Actual PLLs used in typical CMOS processes are often
third order or higher order. However, all can be approximated as a second-order transfer function.
The transfer function assuming second-order PLLs with PI control loops is defined by the
following s domain equation:
In this equation, ζ1/2 are the damping factors for PLL 1 and 2, and ω1, 2 are the natural
frequencies for the PLLs 1 and 2 and ω3 is bandwidth of the RX clock/data phase recovery
circuitry. This function is not meant as a requirement for an implementation. It is used as a
bounding function for modeling purposes to establish the limits for f_3 dB frequency and
maximum peaking.
is selected in
7 Giving a Device an ID
The FB-DIMM Compliance Module provides a graphical user interface (See Figure 4) for entering a
Device ID and Description. Data entered here will appear on the compliance report and is
recommended for device tracking.
8 Creating a Compliance Report
To create a compliance report, select Utilities> Reports. The Report Generator utility can create a
complete report of the compliance test.
44 Fully Buffered DIMM (FB-DIMM)
Loading...
