Upgrades for DSA8300 Instrument
Instructions
www.tektronix.com
P075103700*
*
075-1037-00
Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries
or suppliers, and are protected by national copyright laws and international treaty provisions.
Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication
supersedes that in all previously published material. Specifications and price change privileges reserved.
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
Contacting Tektronix
Tektronix, Inc.
14150 SW Karl Braun Drive
P.O. Box 500
Beaverto
USA
For product information, sales, service, and technical support:
n, OR 97077
In North America, call 1-800-833-9200.
Worl dwid e, visi t www.tektronix.com to find contacts in your area.
DS83UP Kit Instructions
This kit describes how to install available upgrades for the DSA8300 Digital
Serial Analyzer instrument. Included with the kit is the latest version of the
instrument p
Available upgra des:
Option ADDJNB01 (Upgrade 80SJNB Essentials to 80SJNB01)
Option ADVTRIG (Advanced Trigger)
Option JARB (Jitter Analysis on Arbitrary Data)
Option JNB (Jitter, Noise and BER Analysis)
roduct software and documentation.
Kit Parts List
Upgrade Options
Option ADDJNB01
Option J
NB01 (Jitter, Noise and BER Analysis as well as Serial Data Link
Analysis)
Quantity Description Part number
1
1
1
1
See the instructions with the application software installation kit to check if you have the latest version of software,
and to update the instrument to the latest TekScope application version if necessary.
DS83UP kit instructions (this document)
DSA8300 product documentation kit
DSA8300 application software installation kit
1
075-1037-00
020-3082-XX
020-3088-XX
Option ADDJNB01 upgrades scopes with the JNB Essentials (Option JNB)
Application software installed to JNB Advanced.
Option ADDJNB01 consists of a keycode to enable the JNB Advanced software
applications.
Option ADVTRIG
Option ADVTRIG enables advanced triggering for synchronous acquisition
of repetitive patterns with lengths from 2 to 2
23
(8,388,608) bits, without the
need to provide a pattern trigger. The instrument requires this option to use the
clock/pattern trigger source/mode and to run the 80SJNB (Jitter, Noise and BER
Analysis) software applications.
Option ADVTRIG consists of a keycode to enable the Advanced Trigger software
functions.
DSA83UP Instrument Upgrade Instructions 1
DS83UP Kit Instructions
Option JARB
Option JNB
Option JNB01
Option JARB ena
software application, This application is a basic jitter measurement tool capable
of measuring jitter on any random or repetitive waveform. The simplicity
of acquisition limits the amount of analysis possible so only the simplest
decomposition can be used; repeatability is pattern dependent.
Option JARB consists of a keycode to enable the 80SJARB application software.
Option JNB enables the 80SJNB Essentials software application for DSA8300
instruments. This application software offers complete analysis of jitter, noise,
and BER, with decomposition of components for clear understanding of a signal’s
problems and margins. The acquisition methodology requires a repetitive pattern
and that the ADVTRIG option be present in the DSA8300. Both accuracy and
repeatability are improved relative to 80SJARB because the tool has access to the
complete signal pattern. Installing this option on a DSA8300 also enables the
80SJARB application.
Option JNB consists of a keycode to enable the 80SJNB Essentials application
software.
Option JNB01 enables the 80SJNB Advanced software application for DSA8300
instruments. This application software offers complete analysis of jitter, noise,
and BER, with decomposition of components for clear understanding of a signal’s
problems and margins. In addition 80SJNB Advanced adds features to 80SJNB
Essentials for serial data link analysis, including fixture de-embedding, channel
emulation, FFE/DFE equalization, and pre-emphasis/de-emphasis. Installing this
option on a DSA8300 also enables the 80SJARB application.
bles the 80SJARB Basic Jitter Analysis on Arbitrary Data
Enabling an Option
Option JNB01 consists of a keycode to enable the 80SJNB01 Advanced
application software.
1. Power on the instrument and wait until the DSA8300 TekScope application is
running.
2. Click Utilities > Option Installation.
3. Click Continue.
4. Enter the option installation key and c lick Continue.
5. Click Restart Now to restart the instrument. The instrument must be restarted
to enable the option.
6. Click Utilities > Option Installation and check that the o ption is listed in
the Enabled Options pane.
End of document
