Tektronix DSA8300 Digital Serial Analyzer Field Install Instructions

xx
DSA8300 Digital Serial Analyzer
ZZZ
TekScope and Connectivity Software
Installation
*P071289802*
071-2898-02
Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries or suppliers, and are protected by national copyright laws and international treaty provisions.
Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supersedes that in all previously published material. Specications and price change privileges reserved.
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
TekVISA is a trademark of Tektronix, Inc.
Contacting Tektronix
Tektronix, Inc. 14150 SW Karl Braun Drive P.O. Box 500 Beaverton, OR 97077 USA
For product information, sales, service, and technical support:
In North America, call 1-800-833-9200. Worldwide, visit www.tektronix.com to nd contacts in your area.

Tektronix DSA8300 Application Software Install Instructions

Installs TekScope Application Software on Tektronix DSA8300 Series Instruments with Microsoft Windows 7 Ultimate (32 bit)
This DVD contains the les needed to install, reinstall, or upgrade the DSA8300 Digital Serial Analyzer TekScope application and connectivity software. This product software is designed to be installed only on supported instruments running the Microsoft Windows 7 Ultimate (32 bit) operating system.
If you are using this disc to update your current installation of software and
NOTE.
applications, verify that your current installation is older than the version containe d on this disc. To determine the current version of product software on your instrument, select
>About
in the TekScope menu.

Software Installation

If you are rebuilding the entire conte nts of the hard drive (operating system and
NOTE.
oscilloscope application), you must restore the Windows 7 Ultimate (32 bit) operating system before installing the TekScope application software from this DVD. The instructions to restore the operating system are in the DSA8300 Quick Start User manual and with the DSA8300 Microsoft Windows 7 Ultimate Recovery DVD, both of which are shipped with the instrument.
Tektronix provides new software releases on a frequent basis. Visit the Tektronix
NOTE.
Web site at www.tektronix.com to check for newer software releases before installing the included software.
Help
1
Tektronix DSA8300 Application Software Install Instructions
1.
Insert the application install DVD into the instrument (or PC) media drive and wait for the media drive contents to be available.
2.
Double-click the drive icon and double-click on
autorun.exe
to start the
installer program.
3.
Click the item to install and follow on-screen instructions:
Tektronix DSA8300 Series Oscilloscope Application and TekVISA™
Analysis and Connectivity Software
installs the TekScope application and associated software on an instrument. TekVISA lets third party software communicate with the instrument application.
TekVISA Analysis and Connectivity Software
installs just the TekVISA and connectivity software on an instrument or Windows PC for network connectivity to a DSA8300.
The TekVISA supplied on this DVD supports Microsoft Windows 7 (32- and 64-bit)
NOTE.
and Windows XP Pro. To install TekVISA on a PC running an earlier version of the Windows
2
Tektronix DSA8300 Application Software Install Instructions
OS, go to the Tektronix Web site to download a version of TekVISA that is compatible with your PC OS.

Analysis and Connectivity Software

Start > Programs > TekVISA > All Programs
Click les, release notes, quick reference card, and programming manual documents.
Also be sure to read the Oscilloscope Analysis and Connectivity Made Easy document and check out the powerful application features.
to access the TekVISA help
3
