Technical Reference
RT-Eye® PCI Express® Compliance Module
Methods of Implementation (MOI)
071-2041-01
www.tektronix.com
Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its suppliers
and are protected by United States copyright laws and international treaty provisions.
Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication
supercedes that in all previously published material. Specifications and price change privileges reserved.
TEKTRONIX, TEK and RT-Eye are registered trademarks of Tektronix, Inc.
Contacting Tektronix
Tektronix, Inc.
14200 SW Karl Braun Drive or P.O. Box 500
Beaverton, OR 97077 USA
For product information, sales, service, and technical support:
In North America, call 1-800-833-9200.
Worldwide, visit www.tektronix.com to find contacts in your area.
Methods of Implementation
Table of Contents
1 Introduction to the RT-Eye PCI Express Compliance Module.............1
2 PCI Express Compliance Specifications..................................................2
2.1 Differential Transmitter (TX) Output Specifications.............................3
2.2 Differential Transmitter (TX) Compliance Eye Diagrams....................4
2.3 Differential Receiver (RX) Input Specifications.....................................5
2.4 Differential Receiver (RX) Compliance Eye Diagrams..........................5
2.5 Add-In Card Transmitter Path Compliance Specifications..................6
2.6 Add-In Card Compliance Eye Diagrams ................................................7
2.7 System Board Transmitter Path Compliance Eye Diagrams................8
2.8 System Board Compliance Eye Diagrams...............................................8
2.9 PCI ExpressModule™ Compliance Specifications.................................9
2.9.1 ExpressModule Add-In Card Transmitter Path
Specifications....................................................................................9
2.9.2 ExpressModule System Board Transmitter Path Compliance
Eye Diagrams................................................................................10
2.9.3 Express Module System Board Compliance Eye Diagrams......10
2.10 PCI Express External Cabling Specifications.......................................11
2.10.1 External Cabling Transmitter Path Specifications....................11
2.10.2 Cable (Transmitter Side) Eye Diagrams.....................................11
2.10.3 External Cabling Receiver Path Specifications..........................12
2.10.4 Cable (Receive Side) Eye Diagrams.............................................12
2.11 PCMCIA ExpressCard
2.11.1 ExpressCard - Module Transmitter Path Specifications...........13
2.11.2 ExpressCard Transmitter Path Eye Diagrams ..........................13
2.11.3 ExpressCard - Host System Transmitter Path Specifications...14
2.11.4 ExpressCard – Host System Eye Diagrams................................14
2.12 Reference Clock Compliance Specifications.........................................15
TM
Specifications...............................................13
3 Preparing to Take Measurements..........................................................16
3.1 Required Equipment...............................................................................16
3.2 Probing Options for Transmitter Testing .............................................16
3.2.1 SMA Input Connection.................................................................17
3.2.2 ECB Pad Connection ....................................................................18
RT-Eye PCI Express Compliance Module i
Methods of Implementation
3.3 Initial Oscilloscope Setup........................................................................19
3.4 Running the RT-Eye Software ...............................................................19
3.5 Configuring the Software to take measurements..................................20
3.5.1 Select Standard..............................................................................20
3.5.2 Select Test Point ............................................................................20
3.5.3 Select Probe Type..........................................................................21
3.5.4 Select Measurements.....................................................................21
3.5.5 Configure Source of Waveforms..................................................24
3.5.6 Configure Clock Recovery ...........................................................25
3.5.7 Configure Plots..............................................................................27
4 PCI Express Transmitter Compliance Testing.....................................28
4.1 Probing the link for TX compliance.......................................................28
4.2 TX Compliance Test Load......................................................................28
4.3 Running a Transmitter (TX) Compliance Test.....................................29
4.3.1 TX Unit Interval Measurement MOI..........................................30
4.3.2 TX Differential Pk-Pk Output Voltage MOI..............................31
4.3.3 TX De-Emphasized Differential Output Voltage (Ratio)
MOI................................................................................................33
4.3.4 Minimum TX Eye Width MOI ....................................................34
4.3.5 TX Median-to-Max Jitter MOI....................................................35
4.3.6 TX Output Rise/Fall Time MOI ..................................................36
4.3.7 TX AC Common Mode Output Voltage MOI............................38
4.3.8 TX Delta DC Common Mode Voltage MOI ...............................39
4.3.9 TX Total Jitter@BER MOI .........................................................40
4.3.10 Spectrum Analysis Based Rj/Dj Separation on Repeating
Pattern...........................................................................................40
4.3.11 Arbitrary Pattern Analysis Based Rj/Dj Separation .................42
4.3.12 TX Deterministic MOI (Using Dual-Dirac Model) ....................43
4.3.13 Rj/Dj Separation Based on Dual-Dirac Model...........................43
4.3.14 TX Waveform Eye Diagram Mask Test MOI............................44
5 PCI Express Receiver (RX) Compliance Testing..................................44
5.1 Probing the Link for RX Compliance....................................................44
5.2 Running a Complete RX Compliance Test ...........................................44
5.2.1 RX Unit Interval Measurement MOI..........................................45
5.2.2 RX Differential Pk-Pk Input Voltage MOI.................................46
ii RT-Eye PCI Express Compliance Module
Methods of Implementation
5.2.3 Minimum RX Eye Width MOI....................................................46
5.2.4 RX Median-to-Max Jitter MOI ...................................................47
5.2.5 RX Total Jitter@BER MOI.........................................................48
5.2.6 RX Deterministic Jitter@BER using Dual-Dirac model...........48
5.2.7 RX Waveform Eye Diagram Mask Test MOI............................49
6 PCI Express Interconnect Test Point Testing.......................................50
6.1 Unit Interval Measurement MOI...........................................................51
6.2 Transition and Non-Transition Bit Eye Height Measurement MOI ..51
6.3 Eye Width Measurement MOI...............................................................53
6.4 Interconnect Median-to-Max Jitter and Total Jitter@BER MOI......54
7 PCI Express Reference Clock Compliance Measurements.................55
7.1 Probing the Link for Reference Clock Compliance .............................55
7.2 Running a Complete Reference Clock Compliance Test.....................55
7.2.1 Reference Clock Frequency Measurement Test MOI ...............56
7.2.2 Reference Clock Differential Voltage Hi and Lo Test MOI......57
7.2.3 Reference Clock Differential rise and fall edge rates test
MOI................................................................................................57
7.2.4 Reference clock Duty cycle Test MOI.........................................58
7.2.5 Reference Clock Jitter Test MOI.................................................59
8 Using SigTest............................................................................................60
9 Using Dynamic Test Points.....................................................................63
9.1 Test Point File Syntax..............................................................................64
9.2 Creating the New Test Point...................................................................66
9.3 Running a test with the new DTP...........................................................67
10 Giving a Device an ID..............................................................................68
11 Creating a Compliance Report...............................................................68
12 Further Analysis Techniques..................................................................68
13 Ensuring Compliance over specified population..................................69
RT-Eye PCI Express Compliance Module iii
Methods of Implementation
iv RT-Eye PCI Express Compliance Module
Methods of Implementation
1 Introduction to the RT-Eye PCI Express Compliance
Module
1
This document provides the procedures for making PCI Express compliance measurements with the
Tektronix TDS6000 Series and TDS7704B, real time oscilloscopes (6 GHz models and above), the
DPO/DSA70000 series and probing solutions.
The PCI Express (PCI-E) Compliance Module Version 2.0 (Opt. PCE) is an optional software plug-in to the
RT-Eye Serial Data Compliance and Analysis software (Opt. RTE). The PCI Express Compliance module
provides transmitter path measurements (amplitude, timing, and jitter), waveform mask testing, and
Reference Clock (RefClk) compliance measurements described in multiple variants of the PCI Express
specifications. Specifications covered in this document and the PCE module includes a total of eighteen data
and reference clock test points defined in the following specifications.
Additional test points can also be added by the user, or provided by Tektronix representatives, using
Dynamic Test Point (DTP) definition, described in detail in Section 9. Refer to the release notes (readme.txt)
for information on the additional test point files that may have been added after this release.
Table 1 – Supported Specifications
Test Methods Spec
Revision
Rev1.0a
Rev1.0a Base Specification Transmitter and Receiver
PCI Express Specification Title Test Points Defined
(Section 4.3)
Rev 1.0 Mobile Graphics Lower Power Addendum Transmitter (Section 2.2)
Rev1.0a CEM (Card Electro-Mechanical) Specification System and Add-In Card
(Section 4.7)
Rev 1.0a PCMCIA Express Card Standard Host System Transmitter
Express Card Transmitter
(Section 4.2.1.2)
Rev1.1
1
Disclaimer: The tests provided in the PCI Express compliance module (which are described in this document) do not guarantee PCI Express
compliance. The test results should be considered “Pre-Compliance”. Official PCI Express compliance and PCI-SIG Integrator List qualification
is governed by the PCI-SIG (Special Interest Group) and can be achieved only through official PCI-SIG sanctioned testing.
Rev1.1 Base Specification Transmitter & Receiver
(Section 4.3)
Rev1.1 CEM Specification System and Add-In Card
(Section 4.7)
Reference Clock (Section 2.1)
Rev1.0 Express Module Specification Transmitter Path and System
Board (Section 5.4)
Rev0.4C External Cabling Specification Transmitter and Receiver Path
(Section 3.3)
RT-Eye PCI Express Compliance Module 1
Methods of Implementation
Test Methods Spec
Revision
TBD Future 2.5 Gb/s Variants Dynamic Test Points as
Rev2.0
Rev2.0 Base Specification Transmitter & Receiver
Rev2.0 CEM Specification System and Add-In Card
TBD Future 5 Gb/s Variants Dynamic Test Points as
PCI Express Specification Title Test Points Defined
specifications are defined
(Section 4.4)
Mobile Low Power Transmitter
(Section 4.4)
(Section 4.7)
specifications are defined
Refer to http://www.pcisig.com/specifications/pciexpress/ for the latest specifications.
The PCE module can also be used to automate setup procedures for SigTest by using its SigTest Import
feature (Refer to Section 8).
In this document, for all references to the PCI Express Base Specification and Card Electrical Mechanical
(CEM) specification, refer to all versions of the Spec. (Rev 1.0a, 1.1, and 2.0). Differences between the
specifications are specifically called out when appropriate.
In the subsequent sections, step-by-step procedures are described to help you perform PCI Express
measurements. Each measurement is described as a Method of Implementation (MOI). For further reference,
consult the Compliance checklists offered to PCI-SIG members at
www.pcisig.com.
2 PCI Express Compliance Specifications
As shown in Table 1, Electrical Specifications for PCI Express are provided in multiple documents. This
section provides a summary of the measurement parameters measured in the RT-Eye PCE module and how
they are related to the symbol and test limits in the specification.
2 RT-Eye PCI Express Compliance Module
Methods of Implementation
2.1 Differential Transmitter (TX) Output Specifications
The following table shows the available measurements in the PCE Module and their test limits defined in
each of the Base specifications.
Table 2- Supported base specification transmitter measurements
Parameter Symbol(s)
2.5 GT/s 2.5 GT/s 5.0 GT/s
Rev1.0a Rev1.1 Rev2.0
Unit interval 400 ps 400 ps 200 ps UI
+/- 300 ppm +/- 300 ppm +/- 300 ppm
Specification
Differential p-p TX voltage
swing
Low power differential p-p
TX voltage swing
De-emphasized output
voltage ratio
V
V
TX-SWING
V
TX-SWING-LOW
pDIFFpTX
−−
Not Specified Not Specified
RATIODETXV−−
0.8 V (min) 0.8 V (min) 0.8 V (min)
1.2 V (max) 1.2 V (max) 1.2 V (max)
0.4 V (min)
0.7 V (max)
-3.0 dB (min) -3.0 dB (min) -5.5 dB (min)
-4.0 dB (max) -4.0 dB (max) -6.5 dB (max)
or
-3.0 dB (min)
-4.0 dB (max)
Instantaneous lane pulse
2
width
Transmitter eye including all
jitter sources
Maximum time between the
jitter median and maximum
deviation from the median
Deterministic jitter
D+/D- TX output rise/fall
3
Time
MIN-PULSE
EYETXT−
t
TX-EYE_TJ
T
TX-EYEMEDIAN-to-MAXJITTER
T
TX-DJ-DD
RISETXT−
FALLTXT−
Not Specified Not Specified 0.9 UI (min) T
0.70 UI (min) 0.75 UI (min) 0.75 UI (min)
0.125 UI (max) .125 UI (max) Not Specified
0.15 UI (max)
0.125 UI (min) 0.125 UI
(min)
0.15 UI (min)
AC RMS common mode
output voltage
Absolute delta of DC
common mode voltage
between D+ and D-
ACpCMTXV−−
V
DELTALINEDCCMTX
−−−−
20 mV (max) Not Specified Not Specified
0 V (min) 0 V (min) 0 V (min)
25 mV (max) 25 mV (max) 25 mV (max)
2
Instantaneous lane pulse width defined in the Gen2 specification is not supported in the RT-Eye PCI Express Compliance
module. It is recommended that TDSJIT3 Advanced Jitter Analysis Data Period (Min) be used for this measurement.
3
Rise/Fall time measurements in RT-Eye PCI Express Module are compliant to the Rev1.0a and Rev1.1 specification. For Gen2,
rise and fall time is limited to TF2 and TR2 as defined in section 4.3.3.8 of the Base Specification
RT-Eye PCI Express Compliance Module 3
Methods of Implementation
2.2 Differential Transmitter (TX) Compliance Eye Diagrams
Figure 1a shows the eye mask definitions for the Rev1.1 Base specification. It provides an example of a
transmitter mask for a signal with de-emphasis. Transition and non-transition bits must be separated to
perform the mask testing. The amplitude and jitter mask geometries are derived from the amplitude and
jitter specifications. Low power transmitter variants in both Gen1 and Gen2 do not use de-emphasis (This
is shown in Figure 1b).
Figure 1a: Transmitter eye masks for transition and non-transition bits
Figure 1b: Transmitter eye mask for low power variant where de-emphasis is not used
4 RT-Eye PCI Express Compliance Module
Methods of Implementation
2.3 Differential Receiver (RX) Input Specifications
The following table shows the available measurements in the PCE Module and their test limits defined in
each of the Base specifications.
Table 3 – Supported base specification receiver measurements
Parameter Symbol 2.5 GT/s 2.5 GT/s 5.0 GT/s
Rev1.0a
Unit interval 400 ps 400 ps 200 ps UI
+/- 300 ppm +/- 300 ppm +/- 300 ppm
Minimum receiver eye height
V
RX_EYE
0.175 V (min) 0.175 V (min) 0.120 V (min)
1.2 V (max) 1.2 V (max) 1.2 V (max)
Minimum receiver eye width
Receiver deterministic jitter –Dj
Maximum time between the
jitter median and maximum
EYERXT−
T
RX_DJ_DD
T
TX-EYEMEDIAN-to-
MAXJITTER
0.40 UI (min) 0.40 UI (min) 0.40 UI (min)
Not Specified Not Specified 0.44 UI (max)
0.30 UI (max) 0.30 UI (max)
deviation from the median.
Rev1.1 Rev2.0
Not
Specified
2.4 Differential Receiver (RX) Compliance Eye Diagrams
Figure 2 shows the receiver eye mask definitions for the Rev1.1 Base specification. The amplitude and
jitter mask geometries are derived from the amplitude and jitter specifications.
Figure 2: Receiver input eye mask
RT-Eye PCI Express Compliance Module 5
Methods of Implementation
2.5 Add-In Card Transmitter Path Compliance Specifications
Table 4 is derived from the Electrical Mechanical Specifications (CEM). See the CEM Specification for
additional notes and test definitions.
Table 4 – Supported CEM add-in card measurements
Parameter Symbol 2.5 GT/s 2.5 GT/s 5.0 GT/s 5.0 GT/s
Rev1.0a Rev1.1 Rev2.0 Rev2.0
DeEmphasis Setting 3.5 dB 3.5 dB 3.5 dB 6.0 dB
Unit interval 400 ps 400 ps 200 ps 200 ps UI
+/- 300 ppm +/- 300 ppm +/- 300 ppm +/- 300 ppm
V
V
TXA
TXA_d
0.514 V (min) 0.514 V (min) 0.380 V (min) 0.306 V (min)
1.2 V (max) 1.2 V (max) 1.2 V (max) 1.2 V (max)
0.360 V (min) 0.360 V (min) 0.380 V (min) 0.260 V (min)
Eye height of transition
bits
Eye height of nontransition bits
T
Eye width across any
250 UIs
Eye width with sample
6
size of 10
UI
Jitter eye opening at
-12
BER 10
Total Jitter at BER 10
Deterministic Jitter at
-12
BER 10
Maximum median-max
TXA
In Rev1.0a
T
TXA
In Rev1.1
T
TXA
In Rev2.0
-12
Not Specified Not Specified 77 ps (max) 77 ps (max) Tj at BER 10
J
TXA-MEDIAN-to-MAX-JITTER
237 ps (min) Not Specified Not Specified Not Specified
Not Specified 287 ps (min) Not Specified Not Specified
Not Specified 274 ps (min) 123 ps (min) 123 ps (min)
with Crosstalk with Crosstalk
-12
Not Specified Not Specified 57 ps (max) 57 ps (max) Max Dj
Not Specified 56.5 ps (max) Not Specified Not Specified
jitter outlier with sample
6
size of 10
UI
Maximum median-max
jitter outlier with sample
6
size of 10
UI
Not Specified 63 ps (max) Not Specified Not Specified
6 RT-Eye PCI Express Compliance Module
Methods of Implementation
2.6 Add-In Card Compliance Eye Diagrams
The amplitude and jitter masks are derived from the amplitude and jitter specifications in Table 4.
Figure 3: Add-in card compliance eye masks
RT-Eye PCI Express Compliance Module 7
Methods of Implementation
2.7 System Board Transmitter Path Compliance Eye Diagrams
Table 5 is derived from the Electrical Mechanical Specifications (CEM). See the CEM Specification for
additional notes and test definitions.
Table 5 – Supported CEM System Board Measurements
Parameter Symbol 2.5 GT/s 2.5 GT/s 5.0 GT/s
Rev1.0a Rev1.1
Rev2.0
Unit interval 400 ps 400 ps 200 ps UI
+/- 300 ppm +/- 300 ppm +/- 300 ppm
V
Eye height of transition bits
TXS
0.274 V (min) 0.274 V (min) 0.300 V (min)
1.2 V (max) 1.2 V (max) 1.2 V (max)
V
T
TXS
TXS_d
0.253 V (min) 0.253 V (min) 0.300 V (min)
183 ps (min) Not Specified Not Specified
Eye height of non-transition bits
Eye width across any 250 UIs
In Rev1.0a
4
Eye width with sample size of 106 UI Not Specified 246 ps (min) Not Specified T
TXS
In Rev1.1
Jitter eye opening at BER 10
Maximum median-max jitter outlier with
6
sample size of 10
UI
Maximum median-max jitter outlier with
6
sample size of 10
UI
-12
Not Specified 233 ps (min) 95 ps (min) T
TXS
In Rev2.0
J
TXA-MEDIAN-
to-MAX-JITTER
with Crosstalk
Not Specified 77 ps (max) Not Specified
Not Specified 83.5 ps (max) TBD
2.8 System Board Compliance Eye Diagrams
The amplitude and jitter masks are derived from the amplitude and jitter specifications in Table 5.
Figure 4: System Board Compliance Eye Masks
4
At 5GT/s, the PCI Express 2.0 CEM specification requires dual port measurement. The dual port measurement requires
differential Clock and Data capture and analysis, which is not supported in the RT-Eye. The test point offered in the RT-Eye
software recovers the clock from the data signal. For dual port measurements, PCI-SIG SigTest version 3.0 and above is
recommended.
8 RT-Eye PCI Express Compliance Module
Methods of Implementation
2.9 PCI ExpressModule™ Compliance Specifications
The specifications in this section are taken from the PCI Express ExpressModule™ specification, which is
a companion specification to the PCI Express Base specification. Its primary focus is the implementation
of a modular I/O form factor that is focused on the needs of workstations and servers. Measurements in the
PCE module support add-in card and system transmitter path measurements at the PCI Express connector.
2.9.1 ExpressModule Add-In Card Transmitter Path Specifications
Table 6 is derived from Section 5.4.1 of the ExpressModule Electro-Mechanical Specifications Rev1.0.
Table 6 – Supported ExpressModule Add-In Card Measurements
Parameter Symbol Rev1.0
Unit interval 400 ps UI
+/- 300 ppm
V
Eye height of transition Bits
Eye height of non-transition Bits
Eye width with sample size of 106 UI 287 ps (min) T
Jitter eye opening at BER 10
-12
274 ps (min)
Maximum median-max jitter outlier
6
with sample size of 10
UI
Maximum median-max jitter outlier
6
with sample size of 10
UI
TXA
V
TXA_d
TXA
In Rev1.1
J
TXA-MEDIAN-to-
MAX-JITTER
0.514 V (min)
1.2 V (max)
0.360 V (min)
56.5 ps (max)
63 ps (max)
Figure 5: ExpressModule add-in card compliance eye masks
RT-Eye PCI Express Compliance Module 9
Methods of Implementation
2.9.2 ExpressModule System Board Transmitter Path Compliance Eye Diagrams
Table 7 is derived from Section 5.4.3 of the ExpressModule Electro-Mechanical Specifications Rev1.0.
Table 7 – Supported ExpressModule system board measurements
Parameter Symbol Gen1
Rev1.0
Unit interval 400 ps UI
+/- 300 ppm
V
Eye height of transition bits
Eye height of non-transition bits
Eye width with sample size of 106 UI 246 ps (min) T
Jitter eye opening at BER 10
-12
233 ps (min)
Maximum median-max jitter outlier
6
with sample size of 10
UI
Maximum median-max jitter outlier
6
with sample size of 10
UI
TXS
V
TXS_d
TXS
J
TXAMEDIAN-toMAX-JITTER
0.274 V (min)
1.2 V (max)
0.253 V (min)
77 ps (max)
83.5 ps (max)
2.9.3 Express Module System Board Compliance Eye Diagrams
The amplitude and jitter masks are derived from the amplitude and jitter specifications in Table 7.
Figure 6: ExpressModule system board compliance eye masks
10 RT-Eye PCI Express Compliance Module
Methods of Implementation
2.10 PCI Express External Cabling Specifications
The specifications in this section are taken from the PCI Express External Cabling Specification. Its
primary focus is the implementation of a cabled interconnect. Measurements in the PCE module support
transmitter path and receiver path measurements. These measurements represent the test points at the
transmitter end of the cable and the receiver end of the cable respectively.
2.10.1 External Cabling Transmitter Path Specifications
Table 8 is derived from Section 3.3.1 of the External Cabling Specification Rev. 0.4C.
Table 8 – Supported external cabling transmitter path measurements
Parameter Symbol Rev0.4C
Unit interval 400 ps UI
+/- 300 ppm
V
V
T
TXA
TXA_d
TXA
0.659 V (min)
1.2 V (max)
0.456 V (min)
309 ps (min)
Eye height of transition bits
Eye height of non-transition bits
Eye width with sample size of
6
UI
10
Jitter eye opening at BER 10
-12
296 ps (min)
2.10.2 Cable (Transmitter Side) Eye Diagrams
The amplitude and jitter masks are derived from the amplitude and jitter specifications in Table 8.
Figure 7: Cable (transmitter side) compliance eye masks
RT-Eye PCI Express Compliance Module 11
Methods of Implementation
2.10.3 External Cabling Receiver Path Specifications
Table 9 is derived from Section 3.3.2 of the External Cabling Specification Rev. 0.4C.
Table 9 – Supported CEM system board measurements
Parameter Symbol Gen1
Rev1.0
Unit interval 400 ps UI
+/- 300 ppm
V
V
RXA
RXA_d
RXA
0.219 V (min)
1.2 V (max)
0.200 V (min)
247 ps (min) T
Eye height of transition bits
Eye height of non-transition bits
Eye width with sample size of 106
UI
Jitter eye opening at BER 10
-12
234 ps (min)
2.10.4 Cable (Receive Side) Eye Diagrams
The amplitude and jitter masks are derived from the amplitude and jitter specifications in Table 9.
Figure 8: Cable (receiver side) compliance eye masks
12 RT-Eye PCI Express Compliance Module
Methods of Implementation
2.11 PCMCIA ExpressCard
TM
Specifications
The specifications in this section are taken from the PCMCIA ExpressCard Standard (Release 1.0). Its
primary focus is a small modular add-in card technology based on PCI Express and USB interfaces.
Measurements in the PCE module support host system and ExpressCard transmitter path measurements.
2.11.1 ExpressCard - Module Transmitter Path Specifications
Table 10 is derived from Section 4.2.1.3.2 of the ExpressCard Specification Release 1.0.
Table 10 – Supported ExpressCard transmitter path measurements
Parameter Symbol Release 1.0
Unit interval 400 ps UI
+/- 300 ppm
V
V
TXA
TXA_d
TXA
538 V (min)
1.2 V (max)
0.368 V (min)
Eye height of transition bits
Eye height of non-transition bits
Eye width across any 250 UIs 237 ps (min) T
2.11.2 ExpressCard Transmitter Path Eye Diagrams
The amplitude and jitter masks are derived from the amplitude and jitter specifications in Table 10.
Figure 9: ExpressCard Module Transmitter compliance eye masks
RT-Eye PCI Express Compliance Module 13
Methods of Implementation
2.11.3 ExpressCard - Host System Transmitter Path Specifications
Table 11 from Section 4.2.1.3.2 of the ExpressCard Specification Release 1.0.
Table 11 – Supported ExpressCard Host System Transmitter Path Measurements
Parameter Symbol Release 1.0
Unit interval 400 ps UI
+/- 300 ppm
V
V
txS
txS_d
TxS
0.262 V (min)
1.2 V (max)
0.247 V (min)
Eye height of transition bits
Eye height of non-transition bits
Eye width across any 250 UIs 183 ps (min) T
2.11.4 ExpressCard – Host System Eye Diagrams
The amplitude and jitter masks are derived from the amplitude and jitter specifications in Table 11.
Figure 10: ExpressCard Host System compliance eye masks
14 RT-Eye PCI Express Compliance Module
Methods of Implementation
2.12 Reference Clock Compliance Specifications
Table 12 is derived from Section 2.1 of the Gen1 Rev1.1 Electrical Mechanical Specifications (CEM).
Reference Clock measurements for Rev2.0 are not currently supported in RT-Eye.
Table 12 – Supported reference clock measurements
Parameter Symbol Gen1 5.0 GT/s
Rev1.1 Rev2.0
Rise edge rate
Rise Edge Rate
0.6 V/ns (min)
4.0 V/ns (max)
Fall edge rate
Fall Edge Rate 0.6 V/ns (min)
4.0 V/ns (max)
Differential input high voltage
VIH
150 mV (max)
Differential input low voltage VIL -150 mV (min)
Absolute period (including jitter
and spread spectrum)
T
PERIOD_ABS
9.847 ns (min)
10.203 ns (max)
Duty cycle 40% (min) Duty Cycle
60% (max)
Maximum peak-peak filtered
-12
BER
108 ps (max) Jitter @ 10
phase jitter
In RT-Eye software.
For Rev2.0 RefClk
Compliance tools,
Not supported
refer to the tools
library at
www.pcisig.com
Maximum peak-peak filtered
phase jitter
RMS jitter T
CLK_RJ
86 ps (max) Jitter @ 10-6 BER
RT-Eye PCI Express Compliance Module 15
Methods of Implementation
3 Preparing to Take Measurements
3.1 Required Equipment
The following equipment is required to take the measurements:
• Oscilloscope Selection:
ο Gen1 (2.5 Gb/s) – The PCI-SIG recommends a minimum of 6 GHz system BW for Gen1
Measurements. Tektronix models that meet this recommendation include: All the TDS6000B/C
series instruments, TDS7704B, and the DPO/DSA70000 series.
ο Gen2 (5 Gb/s) – It is recommended that >12 GHz system BW is used for Gen2. This ensures that
• RT-Eye software (Opt. RTE) and PCI Express Compliance Module (PCE) installed.
• Probes – Probing configuration is MOI specific. Refer to each MOI for proper probe configuration.
• Test fixture breakout from transmitter to differential SMA connectors. The Compliance Base Board
(CBB) used for add-in card compliance tests and a Compliance Load Board (CLB) used for system
compliance tests are available through the PCI-SIG at the following URL:
http://www.pcisig.com/specifications/ordering_information/ordering_information
• Test fixtures for ExpressCard testing are available from the following URL:
http://www.expresscard.org/web/site/testtools.jsp
th
the 5
harmonic is represented in the measurements. Tektronix models that meet this
recommendation are TDS6000C models.
3.2 Probing Options for Transmitter Testing
The first step is to probe the link. Use one of the following four methods to connect probes to the link.
Table 13 – Example Probing configurations for a PCI express link
16 RT-Eye PCI Express Compliance Module
Methods of Implementation
3.2.1 SMA Input Connection
1. Two TCA-SMA inputs using SMA
cables (Ch1) and (Ch3)
The differential signal is created by
the RT-Eye software from the math
waveform Ch1-Ch3. The Common
mode AC measurement is also
available in this configuration from
the common mode waveform
(Ch1+Ch3)/2. This probing technique
requires breaking the link and
terminating into a 50 Ω/side
termination of the oscilloscope.
While in this mode, the PCI Express
SerDes will transmit the compliance
test pattern. Ch-Ch de-skew is
required using this technique because
two channels are used. This
Probe Configuration A
SMA Psuedo-differential
configuration does not compensate
for cable loss in the SMA cables. The
measurement reference plane is at the
input of the TCA-SMA connectors
on the oscilloscope. Any cable loss
should be measured and entered into
the vertical attenuation menu for
accurate measurements at the SMA
cable attachment point.
2. One P7300SMA series differential
active probe (Ch1)
The differential signal is measured
across the termination resistors inside
the P7300SMA series probe. This
probing technique requires breaking
the link. While in this mode, the PCI
Express SerDes will transmit the
compliance test pattern. Matched
cables are provided with the probe to
avoid introducing de-skew into the
system. Only one channel of the
oscilloscope is used. The P7300SMA
provides a calibrated system at the
Test Fixture attachment point,
eliminating the need to compensate
for cable loss associated with the
Probe Configuration B
SMA Input Differential Probe
probe configuration A.
RT-Eye PCI Express Compliance Module 17
Methods of Implementation
3.2.2 ECB Pad Connection
3. Two active probes (Ch1) and (Ch3)
The differential signal is created by the
RT-Eye software from the math
waveform Ch1-Ch3. The Common mode
AC measurement is also available in this
configuration from the common mode
waveform (Ch1+Ch3)/2. This probing
technique can be used for either a live
link that is transmitting data, or a link that
has terminated into a “dummy load”. In
both cases, the single-ended signals
should be probed as close as possible to
the termination resistors on both sides
with the shortest ground connection
possible. Ch-Ch de-skew is required
using this technique because two
channels are used.
Probe Configuration C
4. One P7300 series Differential probe
(Ch1)
The differential signal is measured
directly across the termination resistors.
This probing technique can be used for
either a live link that is transmitting data,
or a link that is terminated into a “dummy
load”. In both cases, the signals should be
probed as close as possible to the
termination resistors. De-skew is not
necessary because a single channel of the
oscilloscope is used.
Two Single-Ended Active Probes
Probe Configuration D
One Differential Active Probe
18 RT-Eye PCI Express Compliance Module
Methods of Implementation
3.3 Initial Oscilloscope Setup
After connecting the DUT by following the proper probing configuration for the test, click DEFAULT
SETUP and then Autoset to display the serial data bit stream.
3.4 Running the RT-Eye Software
1. On non-B or non-C model oscilloscopes (Example: TDS6604), Go to File > Run Application > RTEye Serial Compliance and Analysis. For B and C models (Example: TDS7704B, TDS6154C), go to
App > RT-Eye Serial Compliance and Analysis. On DPO/DSA7000 series, go to
Analysis > RT- Eye Serial Compliance and Analysis.
Figure 11: Default menu of the RT-Eye software
Figure 11 shows the oscilloscope display. The default mode of the software is the Serial Analysis module
(Opt.RTE). This software is intended for generalized Serial Data analysis on copper serial data links.
2. Select the PCI Express Compliance Module from the Modules drop-down list.
Figure 12: Choosing PCI Express Compliance Module.
RT-Eye PCI Express Compliance Module 19
Methods of Implementation
Note: If PCI Express does not appear in the list (as in Figure 12), the PCI Express Compliance Module
(Opt. PCE) has not been installed.
The rest of this MOI document details the use of the PCI Express Compliance Module to perform
electrical compliance measurements.
For additional information, refer to the online help for the RT-Eye software available through the Serial
Analysis Module help menu.
3.5 Configuring the Software to take measurements
Before you take compliance measurements, configure the software as follows:
3.5.1 Select Standard
Using the Specification drop-down menu, select the desired specification to be measured.
The selections are:
• Rev1.0a – 2.5 Gb/s
• Rev1.1 – 2.5 Gb/s
• Gen2 – 5 Gb/s
• Use SIG-TEST – refer to Section 8
3.5.2 Select Test Point
Use the Test Point drop-down list to select the desired test point.
Selections in the Test Point menu are dependent on the selected specification. The selections are as
follows:
If Rev1.0a – 2.5 Gb/s is selected as Standard:
• Receiver
• Driver
• CEM: Add-In
• CEM: System
• ExpressCard Module Tx
• ExpressCard Host Tx
• Mobile LP: Transmitter
• User Defined – Using Dynamic Test Points – See Section 9 for definition
20 RT-Eye PCI Express Compliance Module
Methods of Implementation
If Rev1.1 – 2.5 Gb/s is selected as Standard:
• Base: Transmitter
• Base: Receiver
• CEM: Add-In
• CEM: System
• Cable: Transmitter
• Cable: Receiver
• ExpressModule: System TX
• ExpressModule: TX Path
• User Defined – Using Dynamic Test Points – See Section 9 for definition
• Reference Clock
If Gen2 – 5Gb/s is selected as Standard:
• Base - Tx -6dB DeEmph
• Base - Tx -3.5dB DeEmph
• Base: Receiver
• User Defined – Using Dynamic Test Points – See Section 9 for definition
• Reference Clock
3.5.3 Select Probe Type
Using the Probe Type drop-down menu, select the desired probing configuration.
The selections are:
• Single-Ended – Select if Pseudo-differential (probing configurations A or C from Section 3.2) is
being used.
• Differential – Select if true differential (probing configurations B or D from Section 3.2) is being
used.
3.5.4 Select Measurements
In the Measurement > Select menu, select the desired measurements. Measurements can be selected
either manually or as a group by using Select Required. If a measurement has a pass/fail limit associated
with it in the test point file, it will be selected when Select Required is clicked. Measurements with
pass/fail limits will show up in the Results Summary panel when the compliance test is run.
Measurement results of selected measurements, which do not have limits associated with them can be
viewed in the Results Details panel.
RT-Eye PCI Express Compliance Module 21
Methods of Implementation
Figure 13: Measurement Select menu
For Compliance measurements, the following table indicates the PCI Express parameter (listed by
symbol in the specification), the measurement to select in the Measurement Select Menu, and the results
that appear in the Results Summary panel after the compliance test is complete. Refer to the tables in
Section 2 for Pass/Fail limit criteria by specification.
Table 14 – Measurement Select/Result Cross Reference (Transmitter Test Points)
Parameter to
measure
Unit interval Unit Interval Unit Interval (Min) UI
Symbol(s) Selection in Results in
Measurement > Select Measurement Results Summary
Menu
Unit Interval (Max)
Differential p-p TX
voltage swing
Low power
differential p-p TX
voltage swing
De-emphasized
output voltage ratio
Instantaneous lane
pulse width
5
Transmitter eye
including all jitter
sources
Maximum time
between the jitter
median and
maximum deviation
from the median
V
V
TX-SWING
V
TX-SWING-LOW
MIN-PULSE
t
TX-EYE_TJ
T
TX-EYEMEDIAN-to-
MAXJITTER
−−
RATIODETXV−−
EYETXT−
pDIFFpTX
Differential Voltage Differential Voltage (Min)
Differential Voltage (Max)
Differential Voltage
Differential Voltage (Min)
Differential Voltage (Max)
De-Emphasis De-Emphasis (Min)
De-Emphasis (Max)
Not supported in RT-Eye
Data Period (Min) T
PCI-E Compliance Module
use TDSJIT3 Data Period
measurement
For Gen1: Eye Width Gen1: Eye Width (Min)
For Gen2: Jitter@BER Gen2: Jitter Eye Opening (Min)
For Gen1: TIE Jitter
For Gen2: Not Specified
Gen1: TIE Jitter (Min) or TIE Jitter
(Max); whichever value has the
maximum deviation from the
Median.
5
Instantaneous lane pulse width defined in the Gen2 specification is not supported in the RT-Eye PCI Express Compliance
module. It is recommended TDSJIT3 Advanced Jitter Analysis Data Period (Min) be used for this measurement.
22 RT-Eye PCI Express Compliance Module
Methods of Implementation
Deterministic jitter
D+/D- TX output
rise/fall Time
6
T
TX-DJ-DD
RISETXT−
FALLTXT−
For Gen1: Not Specified Gen1: Not Specified
For Gen2: Jitter@BER
Gen2: Deterministic Jitter (Max)
Rise Time Rise Time (Min)
Fall Time Fall Time (Min)
AC RMS common
mode output voltage
Absolute delta of DC
common mode
ACpCMTXV−−
V
DELTALINEDCCMTX
−−−−
Gen1: AC CM Voltage AC CM Voltage (Max)
Gen2: Not Specified
Differential Average DifferentialAverageVoltage(Max)
voltage between D+
and D-
Table 15 – Measurement Select/Result Cross Reference (Eye Diagram Testing for all tes t points)
Parameter Symbol Selection in Results in
Measurement > Select Measurement Results Summary
Menu
Unit interval Unit Interval UI
Unit Interval (Min)
Unit Interval (Max)
V
Eye height of
transition bits
Eye height of nontransition bits
Receiver or all bits
eye height
Eye width across
any 250 UIs
Eye width with
6
sample size of 10
UI
Jitter eye opening at
-12
BER 10
TXA
V
TXA_d
V
RX_EYE
T
TXA
In Rev1.0a
T
TXA
In Rev1.1
T
TXA
Eye Height EyeH: TransBits (Min)
EyeH: TransBits (Max)
Eye Height EyeH: NonTrBits (Min)
EyeH: NonTrBits (Max)
Eye Height EyeH: All Bits (Min)
EyeH: All Bits (Max)
Rev1.0a Only: Eye Width
Eye Width (Min)
(for each 250 bit window)
Rev1.1 Only; Eye Width
(sampled over 10
6
UIs)
Eye Width (Min)
Rev1.1 and Rev2.0 Jitter Eye Opening (Min)
Jitter@BER In Rev2.0
Maximum medianmax jitter outlier
with sample size of
6
UI
10
J
TXA-MEDIAN-to-MAX-
JITTER
Rev1.1 Only: TIE Jitter
6
(sampled over 10
UIs)
TIE Jitter (Min) or TIE Jitter (Max);
whichever value has the maximum
deviation from the Median.
6
Rise/Fall time measurements in RT-Eye PCI Express Module are compliant to the Rev1.0a and Rev1.1 specification. For Rev2.0,
rise and fall time is limited to TF2 and TR2 as defined in the Base Specification.
RT-Eye PCI Express Compliance Module 23
Methods of Implementation
3.5.5 Configure Source of Waveforms
Use the Measurements > Configure > Source menu to select the source of the measured data.
Figure 14: Configure Source menu
Source selections are dependent on the selected probe type. The selections are as follows:
If Differential is selected as Probe Type:
• Live/Ref source selection (uses single differential signal as data source)
o Live channel selections–Ch1, Ch2, Ch3, Ch4
o Reference waveform selections–Ref1, Ref2, Ref3, Ref4
• File source selection
o File selection – Uses a single saved .csv as file as differential data source
If Single-Ended is selected as Probe Type:
• Live/Ref source selection (uses two single-ended signals as data source)
o Live channel selections–(Ch1-Ch3), (Ch1-Ch4), (Ch2-Ch3), (Ch2-Ch4)
o Reference waveform selections –Refx-Refy, where x and y are integers 1-4
• File source selection
o File selection–Uses two saved .csv files as single-ended data source
24 RT-Eye PCI Express Compliance Module
Methods of Implementation
3.5.6 Configure Clock Recovery
Use the Measurements > Configure > Meas Config menu to select the type of clock recovery to be
used.
Figure 15: Measurement Configuration menu
Selections in the General Config panel depend on the specification that has been chosen. The selections
are defined as follows:
If Rev1.0a – 2.5 Gb/s is selected as Standard:
• SSC (Scan Off) – 3500:250 clock recovery with no waveform scanning is used.
• SSC (Scan On) – 3500:250 clock recovery with waveform scanning is used.
If Rev1.1 – 2.5 Gb/s is selected as Standard:
• SSC (Scan Off) – 3500:250 clock recovery with no waveform scanning is used.
• SSC (Scan On) – 3500:250 clock recovery with waveform scanning is used.
• Clean Clock – A 1st Order SW PLL with a corner frequency of 1 MHz is used to recover the clock.
If Gen2 – 5 Gb/s is selected as Standard:
• SSC (Scan Off) – 3500:250 clock recovery with no waveform scanning is used.
• SSC (Scan On) – 3500:250 clock recovery with waveform scanning is used.
• Clean Clock – A 2nd Order SW PLL with a corner frequency of 1.5 MHz is used to recover the
clock.
RT-Eye PCI Express Compliance Module 25
Methods of Implementation
When to use SSC selection:
SSC is the only selection in Rev1.0a and is optional in the Rev1.1 and Gen2. It is to be used when a clean
clock source is not available or if SSC is turned on in a system. The following describes how the clock is
recovered using this technique:
• The “SmartGating” feature of the RT-Eye application is used to set up a software clock recovery
window and an analysis window. This feature is available (and configurable) outside the PCI Express
Compliance Module in the Measurements> Configure> SmartGating menu of the Serial Analysis
module.
• The clock recovery window is 3500 consecutive UIs and the Mean of the UIs is used as the reference
clock. The first 3500 UIs in the acquisition are used.
• An analysis window is established to be 250 UIs centered in the 3500 UI clock recovery window.
The placement of mask is based on the median of the 250 UI analysis windows.
• Optionally, the “Scan On” check box can be selected. When checked, the clock recovery and analysis
waveform will scan the waveform by stepping the 3500:250 window across the waveform in 100 UI
steps. This technique is same as the PCI-SIG SigTest software, used to determine compliance over a
singleshot waveform.
When to use the Clean Clock selection:
• The clean clock selection is not available when Rev1.0a specification is selected. It is optional when
Rev1.1 or Gen2 Specification is selected. It should be used when a clean reference clock is available.
This is usually in the case while testing PHY components and Add-In cards. As defined in the base
specification, if a clean clock is available, the clock recovery function to be used is a TIE filter
function (Figure 16). For Rev1.1 this function is a 1
st
order (20dB/decade rolloff) with a corner
frequency of
1.5 MHz. For Rev2.0, this function is specified as a ‘brick wall’ function with a transition from –60
dB to 0 dB at 1.5 MHz. The RT-Eye PCI Express compliance module implements a first order SW
PLL, which is specified. For Rev2.0, a 2
nd
order PLL with .707 damping factor is used to
approximate a brick wall function. The SW PLL BW is dependent on the edge density of the signal
under test for which the algorithm assumes an edge density of 50%. If the edge density of the DUT
were 50%, the PLL BW frequency would be set to correspond to the frequencies in Figure 16.
However, for compliance testing, the transmitter is required to transmit the PCI Express Compliance
Pattern that has an edge density of 75%. Thus the loop BW of the SW PLL is set to [(0.5/0.75) x
specified frequency]. This results in a PLL loop BW of 1 MHz. The loop BW of the SW PLL can be
changed in the test point file. If the edge density of signal under test is different than 75%, the loop
BW should be changed to be compliant with the specification. Refer to Section 9 for additional
information on using Dynamic Test Points.
Figure 16: Clock recovery mask function in Rev2.0 base specification
26 RT-Eye PCI Express Compliance Module
Methods of Implementation
3.5.7 Configure Plots
The plots in the PCI Express Module are configured automatically. If the Jitter@BER measurement is
not selected, eye diagrams with masks will be displayed in the Plot Summary window (Figure 17a). The
eye diagram can either be a double plot showing transition bit and non-transition bit or can be a single
plot showing all bits depending on the test point selected.
Figure 17a: Plot Summary when Jitter@BER measurement is not selected
If the Jitter@BER measurement is selected, then a Jitter Spectrum and Bathtub Curve are added to the
Plot Summary window.
Figure 17b: Plot Summary when the Jitter@BER measurement is selected
RT-Eye PCI Express Compliance Module 27
Methods of Implementation
4 PCI Express Transmitter Compliance Testing
This section provides the Methods of Implementation (MOIs) for Transmitter tests using a Tektronix realtime oscilloscope, probes, and the RT-Eye PCI Express compliance software.
4.1 Probing the link for TX compliance
Use probing configuration B from Section 3. Connect the positive leg of the differential signal to the ‘+’
SMA connector and the negative leg of the differential signal to the ‘–’ SMA connector on the P7300SMA
series differential probing system.
Alternatively, use probe configuration A, to connect Ch1 and Ch3 to the inputs of an oscilloscope that has
20 GS/s sample rate available on two channels (TDS6604 or TDS6000B Series).
Since the link is broken and terminated into a 50 Ω load, the compliance pattern is defined in the base
specification will be transmitted automatically.
4.2 TX Compliance Test Load
The compliance test load for driver compliance is shown in the base specification.
Figure 18: Driver compliance test load
28 RT-Eye PCI Express Compliance Module
Methods of Implementation
4.3 Running a Transmitter (TX) Compliance Test
The MOI for each of the transmitter measurements is documented in the following sections. All transmitter
compliance measurements can be selected and run simultaneously with the same acquisition. See Section 3
for more information on configuring the module to make measurements.
To perform a compliance test of all transmitter measurements:
1. Select the desired Specification from the Specification drop-down list.
2. Select the desired Test Point from the Test Point drop-down list.
3. In the Measurement Select menu (Figure 19), choose Single-Ended (for probe configuration A defined
in Section 3) or Differential (for probe configurations B defined in Section 3) as the probe type.
4. Click Configure to configure the source and clock recovery method to be used.
5. Click Source tab to configure the data source.
6. Click General Config tab to select the desired clock recovery method.
7. Return the Measurement Select menu by clicking Select.
Figure 19: Measurements Select menu setup
8. Click Select Required and/or select desired measurements manually.
9. Click Autoset in the RT-Eye Measurement Select menu. This will automatically set up the
oscilloscope vertical, horizontal, and measurement reference levels for the compliance test.
10. Click Start.
RT-Eye PCI Express Compliance Module 29
Methods of Implementation
Figure 20 shows the result of a Transmitter Compliance test on a signal that passes the driver tests at all
three TX compliance test points.
Figure 20: Result of a successful transmitter compliance test
4.3.1 TX Unit Interval Measurement MOI
Test Definition Notes from the Specification:
- UI (Unit Interval) is specified to be +/- 300 ppm
- UI does not account for SSC dictated variations
Definition: UI is defined in the base specification.
Limits:
Refer to Table 2 for specified limits on UI measurement.
Test Procedure:
Ensure that Unit Interval is selected in the Measurements > Select menu.
Measurement Algorithm:
This measurement is made over the Analysis Window of 250 consecutive bits (or over the entire record if
the sw PLL is used) as defined in the Base Specification.
The Unit Interval measurement calculates the cycle duration of the recovered clock.
−+=
30 RT-Eye PCI Express Compliance Module
)()1()( ntntnUI
CLKRCLKR −−
Methods of Implementation
AVG
=
))(( nUIMeanUI
Where:
CLKRt−
is a recovered clock edge
n is the index to UI in the waveform
4.3.2 TX Differential Pk-Pk Output Voltage MOI
Definition:
V
solved by two measurements. One is Differential Peak Voltage measurement and the other is Eye Height:
Transition Bits measurement. If you select Differential Voltage and Eye Width/Eye Height, you will get
five measurements: Eye Height, Eye Height: Transition Bits, Eye Height: Non-Trans Bits, Eye Width
and Differential Peak Voltage.
Test Definition Notes from the Specification:
-
pDIFFpTX
−−
(Differential Output Pk-Pk Voltage) is defined in the base specification. This measurement is
−∗=
VVV
||2
−−+−−−
DTXDTXpDIFFpTX
- Specified at the measurement point into a timing and voltage compliance test load as shown in the base
specification and measured over specified number of UIs. Also refer to the transmitter compliance eye
diagram shown in the base specification.
Limits:
Refer to Table 2 for specified limits on the measurement.
V
pDIFFpTX
−−
Test Procedure:
Ensure that Differential Voltage and Eye Width/Eye Height are selected in the Measurements > Select
menu.
Measurement Algorithm:
Differential Peak Voltage Measurement: The Differential Peak Voltage measurement returns two times
the larger of the Min or Max statistic of the differential voltage waveform.
)))(());(((2 ivMinivMaxMaxV
DIFFDIFFPKDIFF∗=−
Where:
i is the index of all waveform values
v
DIFF
is the differential voltage signal
RT-Eye PCI Express Compliance Module 31
Methods of Implementation
Eye Height Measurement: The measured minimum vertical eye opening at the UI center as shown in the
plot of the eye diagram. There are three types of eye height values:
Eye Height:
VVV
−=
MAXLOEYEMINHIEYEHEIGHTEYE
−−−−−
Where:
MINHIEYEV−−
is the minimum of the high voltage at mid UI
MAXLOEYEV−−
is the maximum of the low voltage at mid UI
Eye Height – Transition:
VVV
−=
MAXTRANLOEYEMINTRANHIEYETRANHEIGHTEYE
−−−−−−−−
Where:
V
V
MINTRANHIEYE
−−−
is the minimum of the high transition bit eye voltage at mid UI
MAXTRANLOEYE
−−−
is the maximum of the low transition bit eye voltage at mid UI
Eye Height – Non-Transition:
Where:
V
V
MINNTRANHIEYE
−−−
is the minimum of the high non-transition bit eye voltage at mid UI
MAXNTRANLOEYE
−−−
is the maximum of the low non-transition bit eye voltage at mid UI
VVV
−=
MAXNTRANLOEYEMINNTRANHIEYENTRANHEIGHTEYE
−−−−−−−−
32 RT-Eye PCI Express Compliance Module
Methods of Implementation
4.3.3 TX De-Emphasized Differential Output Voltage (Ratio) MOI
Definition:
RATIODETXV−−
(De-Emphasized Differential Output Voltage (Ratio)) is defined in the base specification.
Test Definition Notes from the Specification:
- This is the ratio of the of the second and following bits after a transition divided by the
V
of the first bit after a transition.
pDIFFpTX
−−
V
pDIFFpTX
−−
- Specified at the measurement point into a timing and voltage compliance test load as shown in the base
specification over the specified number of UIs. Also refer to the transmitter compliance eye diagram
shown the base specification.
Limits:
Refer to Table 2 for specified limits on the measurement.
RATIODETXV−−
Test Procedure:
Ensure that De-Emphasis is selected in the Measurements > Select menu.
Measurement Algorithm:
The de-emphasis measurement calculates the ratio of any non-transition eye voltage (2
voltage succeeding an edge) to its nearest preceding transition eye voltage (1
st
eye voltage succeeding an
nd
, 3rd, etc. eye
edge). In Figure 21, it is the ratio of the black voltages over the blue voltages. The results are given in dB.
Figure 21: De-emphasis measurement
RT-Eye PCI Express Compliance Module 33
Methods of Implementation
⎛
⎜
=
)(
dBmDEEM
⎜
⎝
−−
NTRANHIEYE
−−
TRANHIEYE
⎞
)(
mv
⎟
⎟
)(
nv
⎠
or
⎛
⎜
=
)(
dBmDEEM
⎜
⎝
−−
NTRANLOEYE
−−
TRANLOEYE
⎞
)(
mv
⎟
⎟
)(
nv
⎠
Where:
TRANHIEYEv−−
is the high voltage at mid UI following a positive transition
TRANLOEYEv−−
is the low voltage at mid UI following a negative transition
NTRANHIEYEv−−
is the high voltage at mid UI following a positive transition bit
NTRANLOEYEv−−
is the low voltage at mid UI following a negative transition bit
m is the index for all non-transition UIs
n is the index for the nearest transition UI preceding the UI specified by m
4.3.4 Minimum TX Eye Width MOI
Definition:
EYETXT−
(Minimum TX Eye Width) is defined in the base specification. Note that the definition of the
parameter Eye width changes from Rev1.x to the Rev2.0. See Section 4.3.9 for the Rev2.0 definition. For
Gen1, the Eye width is a waveform histogram-based measurement that is defined as follows. For Rev2.0
Test Definition Notes from the Specification:
- The maximum Transmitter jitter can be derived as
- Specified at the measurement point into a timing and voltage compliance test load as shown in the base
specification and measured over the specified number of UIs. Also refer to the transmitter compliance
eye diagram shown in the base specification.
Note: The median is not the same as the mean. The jitter median describes the point in time where the
number of jitter points on either side is approximately equal as opposed to the averaged time value.
Limits:
EYETXT−
is defined to be the Jitter Eye Opening which is described later.
TT
−= 1
.
EYETXJITTERTXMAX
−−
Refer to Table 2 for specified limits on the measurement.
EYETXT−
Test Procedure:
34 RT-Eye PCI Express Compliance Module
Methods of Implementation
Ensure that Eye Width is selected in the Measurements > Select menu.
Measurement Algorithm:
The measured minimum horizontal eye opening at the zero reference level as shown in the eye diagram.
TIEUIT
−=
PkPkAVGWIDTHEYE
−−
Where:
UI is the average UI
AVG
TIE
is the Peak-Peak TIE
PkPk
−
4.3.5 TX Median-to-Max Jitter MOI
Definition:
T
MAXJITTERtoEYEMEDIANTX
−−−
median.) is defined in Rev1.0a of the base specification.
Limits:
Refer to Table 2 for measurement.
Test Procedure:
Ensure that TIE is selected in the Measurements > Select menu.
Measurement Algorithm:
The measured time difference between a data edge and a recovered clock edge.
Where:
(maximum time between the jitter median and maximum deviation from the
T
)()()( ntntntie
DATDATR−=−
MAXJITTERtoEYEMEDIANTX
−−−
t
DAT
is the original data edge
DATRt−
is the recovered data edge (for example, the recovered clock edge corresponding to the UI
t
boundary of )
DAT
n is the index of all edges in the waveform
RT-Eye PCI Express Compliance Module 35
Methods of Implementation
4.3.6 TX Output Rise/Fall Time MOI
Definition:
,
RISETXT−
(D+/D- TX Output Rise/Fall Time) is defined in the base specification.
FALLTXT−
Test Definition Notes from the Specification:
- Specified at the measurement point into a timing and voltage compliance test load as shown in the base
specification and measured over the specified number of TX UIs.
- Measured between 20-80% at transmitter package pins into a test load for both and
V
V
+−DTX
.
−−DTX
Limits:
Refer to Table 2 for specified limits on ,
RISETXT−
measurements.
FALLTXT−
Test Procedure:
Ensure that Rise Time and Fall Time are selected in the Measurements > Select menu.
Note: Rise/Fall time D+ and D- measurements show up when the probe type is single-ended. Rise Time
measurements show up when differential probe type is used. Error in Rise/Fall time measurements
includes bandwidth limitations of the system in some cases.
Measurement Algorithm:
Rise/Fall time measurement supported in the RT-Eye PCI Express Compliance Module is currently
limited to only rising or falling edges of consecutive transitions (T
measurements as defined in the Gen1 specification. The Gen2 specification introduces T
and TR2 in Figure 22) for transmitter
F2
and TF2 in
F1
Figure 22. Rise/Fall Time is taken independently on each single-ended waveform sources when you use
two single-ended probes as the signal source. Differential signal Rise/Fall Time show up when you select
Differential probe type.
Figure 22: Rise/Fall Time measurement Gen2 specification. Only TR2 and TF2 are supported
36 RT-Eye PCI Express Compliance Module
Methods of Implementation
Rise Time: The Rise Time measurement is the time difference between when the V
is crossed and the V
reference level is crossed on the rising edge of the waveform.
REF-LO
−=
)()()( jtitnt
LOHIRISE ++
Where:
t is a Rise Time measurement
RISE
t
is a set of for rising edges only
+HI
t is a set of for rising edges only
+LO
i and j are indexes for nearest adjacent pairs of and
t
HI
t
LO
t
t
+LO
+HI
n is the index of rising edges in the waveform
Rise Time for is as follows:
D +++++
RISE
D+
)(tv
−=
)()()( jtitnt
LODHID
reference level
REF-HI
and for
t
(n) = t
D–FALL
D−
)(tv
D–LO–
(i) – t
D–HI–
(j)
Fall Time: The Fall Time measurement is the time difference between when the V
crossed and the V
reference level is crossed on the falling edge of the waveform.
REF-LO
−=
)()()( jtitnt
HILOFALL −−
Where:
is a Fall Time measurement
t
FALL
t
is set of t
HI–
t
is set of t
LO–
i and j are indexes for nearest adjacent pairs of t
for falling edge only
HI
for falling edge only
LO
LO–
and t
HI–
n is the index to falling edges in the waveform
Fall Time for v
D
FALL
(t) is as follows:
D+
D
++
LO
−
−=
D
+
HI
)()()( jtitnt
−
reference level is
REF-HI
and for v
LO
−=
−
D −−
–(t),
D
FALL
D
−−
)()()( jtitnt
HID
RT-Eye PCI Express Compliance Module 37
Methods of Implementation
4.3.7 TX AC Common Mode Output Voltage MOI
Definition:
V
(RMS AC Pk Common Mode Output Voltage) is defined in Rev1.0a Base Specification. The
ACpCMTX
−−
nomenclature ACp is retained to be consistent with the specification. However, the measurement is
defined and reported by the PCI Express module as an RMS value, not a Pk value.
Test Definition Notes from the Specification:
+
VV
−−+−
=
RMSV
−−
ACpCMTX
(|
DTXDTX
2
=−
−−−−
ofDCVV
|)|
)(
avgDCCMTXDCCMTX
+
VV
−−+−
DTXDTX
|
2
- Specified at the measurement point into a timing and voltage compliance test load as shown in the base
specification and measured over the specified number of TX UIs.
Limits:
Refer to Table 2 for specified limits on measurement.
V
ACpCMTX
−−
Test Procedure:
Ensure that AC CM Voltage is selected in the Measurements > Select menu.
Note: This measurement is available only when the probe type is single-ended.
Measurement Algorithm:
AC CM RMS Voltage: The AC Common Mode RMS Voltage measurement calculates the RMS
statistic of the common mode voltage waveform with the DC value removed.
=
))(()( ivRMSiv
MACCMRMSAC −−−
Where:
i is the index of all waveform values
is the RMS of the AC common mode voltage signal
CMRMSACv−−
is the AC common mode voltage signal
MACv−
38 RT-Eye PCI Express Compliance Module
Methods of Implementation
4.3.8 TX Delta DC Common Mode Voltage MOI
Definition:
V
the base specification.
DELTALINEDCCMTX
−−−−
(Absolute Delta of DC Common Mode Voltage between D+ and D-) is defined in
Test Definition Notes from the Specification:
25||
≤−
−−−−+−−−
DDCCMTXDDCCMTX
=
=
VofDCV
)(
VofDCV
)(
mVVV
||
+−+−−
DTXavgDDCTXCM
||
−−−−−−
DTXavgDDCCMTX
- Specified at the measurement point into a timing and voltage compliance test load as shown in the base
specification and measured over the specified number of UIs.
Limits:
Refer to Table 2 for specified limits on measurement.
V
DELTALINEDCCMTX
−−−−
Test Procedure:
Ensure that Differential Average is selected in the Measurements > Select menu.
Measurement Algorithm:
The Differential Average measurement returns the mean of the differential voltage waveform.
))(( ivMeanV
DIFFAVGDIFF=−
Where:
i is the index of all waveform values
v
DIFF
is the differential voltage signal
RT-Eye PCI Express Compliance Module 39
Methods of Implementation
4.3.9 TX Total Jitter@BER MOI
Definition:
-12
The jitter eye opening is re-defined Gen2 specification to statistical relevance to 10
EYETXT−
detailed definition can be found in the Gen2 base specification.
Test Definition Notes from the Gen2:
- Does not include SSC or Refclk. Jitter Includes Rj at 10
-12
.
- Transmitter jitter is measured by driving the transmitter under test with a low jitter “ideal” clock and
connecting the DUT to a reference load.
- Transmitter jitter must be post-processed with a filtering function that represents the worst case CDR
tracking BW.
Limits:
BER. A
Refer to Table 2 for specified limits on the measurement.
EYETXT−
Test Procedure:
Ensure that Jitter@BER is selected in the Measurements > Select menu.
Measurement Algorithm:
Total jitter in the PCI Express Compliance Module uses the Arbitrary Pattern Jitter Algorithm in RT-Eye
to establish . To understand the complete algorithm, one must understand RT-Eye’s spectrum
EYETXT−
approach to jitter measurements. The RT-Eye PCI Express Compliance Module uses Spectral Analysis to
estimate the Total Jitter. The Arbitrary Pattern method is used such that a repeating pattern is not required
to achieve a jitter measurement result.
4.3.10 Spectrum Analysis Based Rj/Dj Separation on Repeating Pattern
Dj components can be identified in a jitter spectrum under a set of conditions. PJ will appear as spectral
impulses regardless of conditions. DDJ and DCD will appear as spectral impulses provided that the data
signal is a repeating pattern. The frequencies of DDJ and DCD spectral impulses are at harmonics of the
(Bit Rate/Pattern length). The remaining spectral energy is attributed to Rj. Dj components are spectrally
separated from Rj.
The Dj measurement is the peak-to-peak value of the inverse Fourier transform of the deterministic jitter
spectral components, Tj is the total jitter which is composed of Dj and Rj. The Tj measurement calculates
the peak-to-peak value of the total jitter. Rj is assumed to be near-Gaussian. The Rj measurement is the
calculated RMS value of random jitter.
A Jitter PDF is formed by convolving a Gaussian distribution of Rj and Histograms of Dj. A Bathtub
curve is calculated from the left and right side CDFs of the Jitter PDF. The Bathtub curve will yield TJ
and Eye Opening ( ).
40 RT-Eye PCI Express Compliance Module
OPENEYET−
Methods of Implementation
(
)
The application calculates the measurements using the following equations:
TimeTime
)()(
DjMinDjMaxDj −=
Time
DjtieRMSRj −=
PDF
∗=
TJTJTJ −=
MINMax
OPENEYE−=−
TJUIT
)()( RjFGaussianPDDjHistogramnormalizedTJ
Where:
is the deterministic jitter
Dj
is the random jitter
Rj
TJ
is the total jitter
TJ
is the PDF of the total jitter
PDF
TJ is the minimum value at the bathtub curve at a given BER
MIN
TJ is the maximum value at the bathtub curve at a given BER
Max
Time
Dj is the is the time domain record of the
FFT of the components of the TIE spectrum
Dj
Dj
component of jitter obtained by performing an inverse
tie
is the time domain record of measured TIE jitter
Additionally, is further decomposed as follows:
Dj
PJMinPJMaxPJ −=
Time
Rise
TimeTime
)()(
Time
DCDDDJMeanDCDDDJMeanDCD −=
TimeTime
Fall
)()(
DCDDCDDDJMinDCDDDJMaxDDJ
−−= )()(
Where:
PJ
is the periodic jitter
DCD
is the duty cycle jitter
RT-Eye PCI Express Compliance Module 41
Methods of Implementation
DDJ
is the data dependent (or ISI) jitter
Time
PJ
of the components of the TIE spectrum
DCDDDJ
is the time domain record of the component of jitter obtained by performing an inverse FFT
PJ
Time
is the time domain record of the + component of jitter obtained by
performing an inverse FFT of the + components of the TIE spectrum
DCDDDJ
DCDDDJ
Time
Rise
Time
Fall
DCDDDJ
is on rising edges only
DCDDDJ
is on falling edges only
Time
Time
PJ
DCD DDJ
DCD DDJ
4.3.11 Arbitrary Pattern Analysis Based Rj/Dj Separation
When data pattern is non-repeating, PJ still has a spectrum of impulses, while DCD+DDJ no longer has a
spectrum of impulses. Therefore, Dj no longer has a spectrum of impulses.
The DCD+DDJ value is obtained through the arbitrary data pattern analysis method that is based on the
assumption that any given bit is affected by a finite number of preceding bits. By averaging all events
where the current bit is preceded by a particular bit sequence, for example the current bit is preceded by
the bit sequence 1001101, the DCD+DDJ with such a pattern is obtained since PJ and RJ are not
correlated to a particular data sequence and thus are averaged out.
If each bit is assumed to be affected by N preceding bits, there are a total of 2
N
possible data sequences.
The sequence length N is set to 5 in the PCI Express module (user configurable in the Serial Analysis
module) because PCI Express is 8b/10b encoded. To get statistically sound average values, a population
limit of 50 is set in the PCI Express module (user configurable in the Serial Analysis module) that
prevents using an average value without enough population. Only DCD+DDJ values obtained from data
sequences with a population above the limit are used to calculate DCD+DDJ values.
After each edge is associated with a DCD+DDJ value, with known total jitter, the PJ+Rj value for each
bit is then obtained by subtracting DCD+DDJ from TJ.
Separation of DDJ and DCD from DCD+DDJ is the same as that in the spectrum based Rj/Dj separation
method.
PJ and Rj are then separated from PJ+Rj and use the spectrum analysis method. PJ has a spectrum of
impulses, and Rj has a flat spectrum. All the edges whose DCD+DDJ can not be determined because of
their associated data sequences have low populations and are treated as if there are no edges when
performing PJ and Rj separation.
The histogram of Dj is a convolution of the histogram of DCD+DDJ and the histogram of PJ.
All other aspects of the arbitrary pattern analysis based Rj/Dj separation are the same as those of the
spectrum analysis based Rj/Dj separation.
42 RT-Eye PCI Express Compliance Module
Methods of Implementation
4.3.12 TX Deterministic MOI (Using Dual-Dirac Model)
Definition:
Deterministic jitter t
TX-DJ-DD
using the Dual-Dirac model is defined in the Gen2 Base Specification.
Limits:
Refer to Table 2 for specified limits on Common the
Test Procedure:
Ensure that Jitter@BER is selected in the Measurements > Select menu.
4.3.13 Rj/Dj Separation Based on Dual-Dirac Model
Dual Dirac model based Rj/Dj separation method fits the Bathtub curve to a theoretical model of Rj and
Dj where Rj is assumed to have a Gaussian distribution, Dj is assumed to have a distribution of two Dirac
impulses with the same height. Curve fitting at different BER levels in Bathtub curve yields the standard
deviation value of Rj and peak-to-peak value of Dj. The Bathtub curve is obtained from the spectrum
analysis based or the arbitrary pattern analysis based Rj/Dj separation methods. Rj and Dj based on the
Dual-Dirac model can be denoted as and .
RJ
After and are obtained, Tj can be calculated using
g
DJ
dd
RJ
g
DJRJBERQBERTJ +×= )(2)(
ddg
DJ
dd
t
TX-DJ-DD
measurement.
where Q is the function of BER that has a value of about 7 when . Eye opening is
1210−
=BER
computed in the same way as it is computed in the spectrum analysis based Rj/Dj separation.
Dual Dirac model based Rj/Dj separation method is used in PCI-Express module and FB-DIMM module.
Usually, actual Dj does not have a pure Dual-Dirac distribution. So the value of is often greater than
RJ
g
the value of Rj obtained from the spectrum analysis based or the arbitrary pattern analysis based Rj/Dj
separation. The value of is often less than that of its corresponding one.
DJ
dd
RT-Eye PCI Express Compliance Module 43
Methods of Implementation
4.3.14 TX Waveform Eye Diagram Mask Test MOI
Test Definition Notes from the Specification:
- The TX eye diagram is defined in the base specification is specified using the passive compliance/test
measurement load in place of any real PCI Express interconnect + RX component.
- There are two eye diagrams that must be met for the transmitter. Both eye diagrams must be aligned in
time using the jitter median to locate the center of the eye diagram. The different eye diagrams will differ
in voltage depending on whether it is a transition bit or a de-emphasized bit. The exact reduced voltage
level of the de-emphasized bit will always be relative to the transition bit.
- The eye diagram must be valid for the specified number of UIs.
Limits:
Mask geometries for each specification are defined by the limits in Table 2.
Test Procedure:
Waveform masks are plotted with eye diagrams for the selected test point. Mask violations are
highlighted and counted by the application.
5 PCI Express Receiver (RX) Compliance Testing
This section provides the Methods of Implementation (MOIs) for receiver tests using a Tektronix real-time
oscilloscope, probes, and the RT-Eye compliance software solution.
5.1 Probing the Link for RX Compliance
Use probing configuration (D) to probe the link differentially at a point close to the pins of the receiver
device. Alternatively, use probing configuration (C) using the Ch1 and Ch3 inputs of an oscilloscope that
has 20 GS/s sample rate available on two channels (TDS6604 and TDS6000B/C Series only).
5.2 Running a Complete RX Compliance Test
The MOIs for each RX test are documented in the following sections. All RX measurements can be
selected and run simultaneously with the same acquisition. To perform a compliance test of all receiver
measurements:
1. Select desired Specification from the Specification drop-down list.
2. Select desired Test Point from the Test Point drop-down list.
3. In the Measurement Select menu (Figure 23), choose Single-Ended (for probe configuration C defined
in Section 3) or Differential (for probe configurations D defined in Section 3) as the Probe Type.
4. Click Configure to configure the source and clock recovery method to be used.
5. Click the Source tab to configure the data source.
6. Click the General Config tab to select the desired clock recovery method.
7. Return the Measurement Select menu by clicking Select.
44 RT-Eye PCI Express Compliance Module
Methods of Implementation
Figure 23: Measurements Select menu setup
8. Click Select Required and/or select the desired measurements manually.
9. Click Autoset in the RT-Eye Measurement Select menu. This will automatically set up the
oscilloscope vertical, horizontal, and measurement reference levels for the compliance test.
10. Click Start.
Figure 24 shows the result of a transmitter compliance test on a signal that passes the driver tests at all
three RX compliance test points.
Figure 24: Result of a successful Compliance Test at the Receiver Pins
5.2.1 RX Unit Interval Measurement MOI
Refer to Unit Interval measurement in Section 4 of this MOI document. The MOI for the measurement of
UI at the receiver is identical to measuring it at the transmitter, with the exception of the test point.
RT-Eye PCI Express Compliance Module 45
Methods of Implementation
5.2.2 RX Differential Pk-Pk Input Voltage MOI
Definition:
V
pDIFFpRX
−−
(Differential Input Pk-Pk Voltage) is defined in the base specification. This measurement is
solved by two measurements: Differential Peak Voltage and Eye Height measurement.
Test Definition Notes from the Specification:
−∗=
VVV
||2
−−+−−−
DRXDRXpDIFFpRX
- Specified at the measurement point and measured over the specified number of UIs. The test load
(defined in the base specification) should be used as the RX device when taking measurements. Also
refer to the Receiver compliance eye diagram shown in the base specification. If the clocks to the RX and
TX are not derived from the same reference clock, then the TX UI recovered from 3500 consecutive UIs
must be used as a reference for the eye diagram.
Limits:
Refer to Table 3 for specified limits applicable to the measurement.
V
pDIFFpRX
−−
Test Procedure:
Ensure that Differential Voltage and Eye Height/Eye Width are selected in the Measurements > Select
menu.
Measurement Algorithm:
Refer to Section 4 of this MOI document for differential voltage measurement and eye height
measurement algorithms.
Note: For receiver testing, eye height is measured on all UIs. There are no Eye Height: Transition Bits
measurement and Eye Height: Non-Trans Bits measurement.
5.2.3 Minimum RX Eye Width MOI
Definition:
T
Test Definition Notes from the Base Specification:
- The maximum interconnect media and transmitter jitter that can be tolerated by the receiver can be
derived as .
- Specified at the measurement point and measured over the specified number of UIs. The test load in the
base specification should be used as the RX device when taking measurements. Also refer to the Receiver
compliance eye diagram shown in the base specification.
(Minimum RX Eye Width) is defined in the base specification.
EYERX
−
UITT
6.1 =−=
EYERXJITTERMAXRX
−−−
46 RT-Eye PCI Express Compliance Module
Methods of Implementation
UIT
40.=
EYERX
- A provides for a total sum of 0.60 UI deterministic and random jitter budget for the
−
Transmitter and interconnect collected over the specified number of UIs. The
T
JITTERMAXtoMEDIANEYERX
−−−−−
specification ensures a jitter distribution in which the median and the
maximum deviation from the median is less than half of the total .6 UI jitter budget collected over the
specified number of TX UIs.
Note: The median is not the same as the mean. The jitter median describes the point in time where the
number of jitter points on either side is approximately equal as opposed to the averaged time value.
Limits:
Refer to Table 3 for specified limits applicable to the measurement.
Test Procedure:
Ensure that Eye Height/Eye Width is selected in the Measurements > Select menu.
Measurement Algorithm:
Refer to Section 4 of this MOI document for Eye Width measurement algorithm.
5.2.4 RX Median-to-Max Jitter MOI
Definition:
T
MAXJITTERtoEYEMEDIANRX
−−−
median.) is defined in the Gen1 base specification.
Test Definition Notes from the Specification:- Jitter is defined as the measurement variation of the
crossing points ( ) in relation to a recovered RX UI:
- The test load in the base specification should be used as the RX device when taking measurements.
Also refer to the receiver compliance eye diagram shown in the base specification.
- A provides for a total sum of 0.60 UI deterministic and random jitter budget for the
−
UIT
40.=
EYERX
transmitter and interconnect collected over the specified number of UIs.
(Maximum time between the jitter median and maximum deviation from the
pRXDIFFp0=−
T
EYERX
−
VV
T
- specification ensures a jitter distribution in which the median and the
JITTERMAXtoMEDIANEYERX
−−−−−
maximum deviation from the median is less than half of the total .6 UI jitter budget collected over the
specified number of UIs. It should be noted that the median is not the same as the mean. The jitter
median describes the point in time where the number of jitter points on either side is approximately equal
as opposed to the averaged time value.
Limits:
Refer to Table 3 for specified limits applicable to the measurement.
T
MAXJITTERtoEYEMEDIANRX
−−−
Test Procedure:
Ensure that TIE Jitter is selected in the Measurements > Select menu.
Measurement Algorithm:
Refer to Section 4 of this MOI document for RX Median-to-Max Jitter measurement algorithm.
RT-Eye PCI Express Compliance Module 47
Methods of Implementation
5.2.5 RX Total Jitter@BER MOI
Definition:
The jitter eye opening is re-defined Gen2 Base Specification to statistical relevance to 10
BER. A detailed definition can be found the Gen2 base specification.
Test Definition Notes from the Gen2:
- Minimum eye time at RX pins to yield a 10
Receiver eye margins are defined into a 2x50 Ω reference load. A receiver is characterized by driving it
-
with a signal whose eye opening is TRX_EYE, which is equivalent to generating a signal with a Tj of
1.0 UI – T
(
RX_EYE
T
EYERX
−
-12
BER.
). The receiver under test then replaces the reference load, and the BER is observed.
-12
T
-
and
EYERX
− EYERXT−
are defined as tolerance parameters. In other words,
DDDJRXT−−
minimum eye that the receiver is expected to decode correctly. Another way of viewing
consider that the amount of Tj that can be present is 1.0 UI - = 120 ps.
maximum amount of Dj that may be present in the Tj number of 120 ps implied by .
T
Note:
defines an eye opening, while
EYERX
−
DDDJRXT−−
Limits:
T
EYERX
Refer to Table 3 for specified limits on the measurement.
−
Test Procedure:
Ensure that Jitter@BER is selected in the Measurements > Select menu.
Measurement Algorithm:
Refer to Section 4 for the Jitter@BER algorithm.
5.2.6 RX Deterministic Jitter@BER using Dual-Dirac model
Definition:
The jitter eye opening is redefined in Gen2 Base Specification to statistical relevance to10
BER A detailed definition can be found in the Gen2 Base specification.
Test Definition Notes from the Gen2:
DDDJRXT__
T
EYERX
−
defines an eye closure.
defines the
T
DDDJRXT−−
V
EYERX
−
is to
EYERX
−
defines the
-12
- Maximum Dj applied to receiver test circuit.
Limits:
Refer to Table 3 for specified limits on the measurement.
DDDJRXT__
Test Procedure:
Ensure that Jitter@BER is selected in the Measurements > Select menu.
Measurement Algorithm:
Refer to Section 4 of this MOI document for the algorithm.
48 RT-Eye PCI Express Compliance Module
Methods of Implementation
5.2.7 RX Waveform Eye Diagram Mask Test MOI
Test Definition Notes from the Specification:
- The RX eye diagram in the base specification is specified using the passive compliance/test
measurement load in place of any real PCI Express RX component.
Note: In general, the minimum receiver eye diagram measured with the compliance/test measurement
load will be larger than the minimum Receiver eye diagram measured over a range of systems at the
input Receiver of any real PCI Express component. The degraded eye diagram at the input receiver is due
to traces internal to the package as well as silicon parasitic characteristics, which cause the real PCI
Express component to vary in impedance from the compliance/test measurement load. The input receiver
eye diagram is implementation specific and is not specified. RX component designer should provide
additional margin to adequately compensate for the degraded minimum receiver eye diagram expected at
the input receiver-based on some adequate combination of system simulations and the return loss
measured looking into the RX package and silicon.
- The RX eye diagram must be aligned in time using the jitter median to locate the center of the eye
diagram.
Limits:
Mask geometries for each specification are defined by the limits in Table 3.
Test Procedure:
Waveform masks are plotted with eye diagrams for the selected test point. Mask violations are
highlighted and counted by the application.
RT-Eye PCI Express Compliance Module 49
Methods of Implementation
6 PCI Express Interconnect Test Point Testing
This section provides the Methods of Implementation (MOIs) for the test points outlined in Tables 4-9.
These test points are defined at different interconnect points in the system between the transmitter and
receiver. Interconnects supported are add-in card and system board test points for both desktop and
ExpressModule, the cabling specification, and the ExpressCard specification. To perform a compliance test
of all interconnect specific measurements:
1. Hook up the device to connector specific test fixture. For example Compliance Load Board (CLB) or
Compliance Base Board (CBB).
2. Select the desired Specification from the Specification drop-down list.
3. Select the desired Test Point from the Test Point drop-down list.
4. In the Measurement Select menu (Figure 25), choose Single-Ended (for probe configuration A defined
in Section 3) or Differential (for probe configurations B defined in Section 3) as the Probe Type.
5. Click Configure to configure the source and clock recovery method to be used.
6. Click the Source tab to configure the data source.
7. Click the General Config tab to select the desired clock recovery method.
8. Return the Measurement Select menu by clicking Select.
Figure 25: Measurements Select menu for add-in card test point
9. Click Select Required and/or select the desired measurements manually.
10. Click Autoset in the RT-Eye Measurement Select menu. This will automatically set up the oscilloscope
vertical, horizontal, and measurement reference levels for the compliance test.
11. Click Start.
Figure 26 shows the result of a Transmitter Compliance test on a signal that passes the driver tests at all
three RX compliance test points.
50 RT-Eye PCI Express Compliance Module
Methods of Implementation
Figure 26: Successful add-in card compliance test
6.1 Unit Interval Measurement MOI
Refer to Section 4 of this MOI document. The MOI for the measurement of UI at the receiver is identical
to measuring it at the transmitter, with the exception of the test point.
6.2 Transition and Non-Transition Bit Eye Height Measurement MOI
Definition:
V
TxA
, , , and are defined in the PCI Express CEM, Express Module, and cable
specifications. and in the cabling specification also fall under the same definition, only they
are defined at the receiver end of the cable.
Test Definition Notes from the Specification:
Rev1.0a CEM Specification:
- All links are assumed active while generating this eye diagram. Transition and non-transition bits must be
distinguished in order to measure compliance against the de-emphasized voltage level.
V
dTxAV_ dTxSV_
TxS
V
RxA
dRxAV_
- The values are initially referenced to an ideal 100 Ω differential load at the end of the interconnect path
on the edge-finger boundary of the add-in card (for add-in card measurement) or where the add-in card is
mated with the connector (for system measurement). The eye diagram is defined and centered with respect
to the jitter median. The jitter median should be calculated across any 250 consecutive UIs.
RT-Eye PCI Express Compliance Module 51
Methods of Implementation
Rev1.1 CEM and Rev1.0 ExpressModule Specification:
-An ideal reference clock without jitter is assumed for this specification. All links are assumed active while
generating this eye diagram.
- Transition and non-transition bits must be distinguished to measure compliance against the deemphasized voltage level.
- The values are referenced to an ideal differential load at the end of the interconnect path at the edgefinger boundary on the add-in card or the add-in card when mated to the connector. The eye diagram is
defined and centered with respect to the jitter median. Exact conditions required for verifying compliance
while generating this eye diagram are given in the PHY Electrical Test Considerations for PCI Express
Architecture document.
Cabling Specification Rev0.4C:
- Rev1.1 CEM Notes plus:
- Transition and non-transition bits must be distinguished to measure compliance against the deemphasized voltage level.
- Transmitter path sdd21 is currently specified as 1.5 dB (1.25 GHz), which translates to a time domain
equivalent of 1.67 dB (2.5 Gb/sec).
Limits:
V
Refer to Tables 4 to 11 for specified limits on , , , and for all interconnect and
V
Table 9 for and measurements.
RXA
dRXAV_
TxA
V
dTxAV_ dTxSV_
TxS
Test Procedure:
Ensure that Eye Height/Eye Width and Differential Voltage are selected in the Measurements > Select
menu.
Measurement Algorithm:
Refer to Section 4 of this MOI document for measurement algorithms of eye height and differential
voltage.
52 RT-Eye PCI Express Compliance Module
Methods of Implementation
6.3 Eye Width Measurement MOI
Definition:
T , for all interconnects that are defined in the PCI Express CEM, Express Module, and Cable
T
TxA
TxS
Specifications. in the cabling specification also falls under the same definition, only it is defined at
the receiver end of the cable.
Test definition notes from the specification:
Rev1.0a CEM Specification:
-All links are assumed active while generating this eye diagram. Transition and non-transition bits must be
distinguished in order to measure compliance against the deemphasized voltage level.
- The values are initially referenced to an ideal 100 Ω differential load at the end of the interconnect path
on the edge-finger boundary of the add-in card [for add-in card measurement] or where the add-in card is
mated with the connector [for system measurement]. The eye diagram is defined and centered with respect
to the jitter median. The jitter median should be calculated across any 250 consecutive UIs.
Rev1.1 CEM and Rev 1.0 ExpressModule Specification:
- An ideal reference clock without jitter is assumed for this specification. All links are assumed active
while generating this eye diagram.
T
RxA
T
TxATTxS
- , is the minimum eye width. The sample size for this measurement is 106 UI. This value can be
reduced to the (1UI -Jitter@BER) for simulation purposes at BER 10-12.
- The values are referenced to an ideal 100 Ω differential load at the end of the interconnect path at the
edge-finger boundary on the add-in card or the add-in card when mated to the connector. The eye diagram
is defined and centered with respect to the jitter median. Exact conditions required for verifying
compliance while generating this eye diagram are given in the PHY Electrical Test Considerations for PCI
Express Architecture document.
Cabling Specification Rev0.4C:
- An ideal reference clock without jitter is assumed for this specification. All Links are assumed active
while generating this eye diagram.
T
TxA
- and is the eye width.
T
RxA
- The values are referenced to an ideal 100 Ω differential load at the end of the interconnect path at the
edge-finger boundary on the add-in card or the add-in card when mated to the connector. The eye diagram
is defined and centered with respect to the jitter median. Exact conditions required for verifying
compliance while generating this eye diagram are given in the PHY Electrical Test Considerations for PCI
Express Architecture document.
Limits:
T
Refer to Tables 4 to 11 for specified limits on and for all interconnects and Table 9 for cable
T
RxA
measurements.
TxA
T
TxS
Test Procedure:
Ensure that Eye Width is selected in the Measurements > Select menu.
RT-Eye PCI Express Compliance Module 53
Methods of Implementation
Measurement Algorithm:
Refer to Section 4 of this MOI document for measurement algorithms of Eye Width measurement.
6.4 Interconnect Median-to-Max Jitter and Total Jitter@BER MOI
Definition:
J
JITTERMAXtoMEDIANTX
−−−−
is defined in Rev1.1 of the CEM specification. It is not explicitly defined in the
Rev1.0a specification but can be derived by (1UI – Eye Width). Jitter@BER is introduced in Rev1.1 as
discussed in the notes below.
Test definition notes from the specification:
Rev1.1 CEM Specification:
J
- is the maximum median-to-max jitter outlier as defined in the PCI Express Base
Specification, Revision 1.1. The sample size for this measurement is 106 UI. This value can be increased
to (Jitter@BER) for simulation purpose at BER 10
JITTERMAXtoMEDIANTX
−−−−
-12
.
Limits:
Refer to Table 4 for limits on measurement.
J
JITTERMAXtoMEDIANTX
−−−−
Test Procedure:
-Ensure that TIE is selected in the Measurements > Select menu for .
-Ensure that Jitter@BER is selected in the Measurement > Select menu for 10
J
-12
JITTERMAXtoMEDIANTX
−−−−
BER jitter estimation.
Measurement Algorithm:
Refer to Section 4 of this MOI document for jitter measurement algorithms.
54 RT-Eye PCI Express Compliance Module
Methods of Implementation
7 PCI Express Reference Clock Compliance
Measurements
This section provides the Methods of Implementation (MOIs) for reference clock tests. Reference Clock
measurements for Rev1.1 are available in RT-Eye. For Rev2.0, refer to the tools library at
7.1 Probing the Link for Reference Clock Compliance
Use probing configuration (B or D) to probe the link differentially at a point close to the pins of the
reference clock. Alternatively, use probing configuration (A or C) using the Ch1 and Ch3 inputs of an
oscilloscope can be used for reference clock measurements.
7.2 Running a Complete Reference Clock Compliance Test
The MOIs for each reference clock test is documented in the following sections. All reference clock
measurements can be selected and run simultaneously with the same acquisition. To perform a compliance
test of all receiver measurements:
www.pcisig.com.
1. Select Measurements > Select.
2. Select Differential (or Single-Ended) as the Probe Type, depending on your probe configuration.
3. Select Reference clock from the Test drop-down list.
Figure 27: Measurements Select menu for reference clock test point
4. Select all or required measurements.
5. Click Configure to access the Configuration menus and set up signal source.
6. Click Autoset to set the horizontal scale, vertical scale, and reference levels for the reference clock
measurements.
7. Click Start.
Figure 28 shows the result of a Reference clock Compliance test on a signal that passes the reference clock
tests.
RT-Eye PCI Express Compliance Module 55
Methods of Implementation
Figure 28:
Result of a completed compliance test at the reference clock test point
7.2.1 Reference Clock Frequency Measurement Test MOI
Test Definition Notes from the Specification:
- Measurement is taken from differential waveform.
- Defines as the absolute minimum or maximum instantaneous period. This includes cycle to cycle jitter,
relative PPM tolerance, and spread spectrum modulation.
Limits:
Refer to Table 12 for specified limits on absolute period measurement (T
Test Procedure:
Ensure that Period is selected in the Measurements > Select menu.
PERIOD_ABS
).
56 RT-Eye PCI Express Compliance Module
Methods of Implementation
Measurement Algorithm:
Measurement of period is defined in the specifications as follows:
Figure 29: Reference clock period
7.2.2 Reference Clock Differential Voltage Hi and Lo Test MOI
Test Definition Notes from the Specification:
Measurement is taken from a differential waveform.
Limits:
Refer to Table 12 for specified limits on absolute period measurement (V
Test Procedure:
Ensure that High Voltage and Low Voltage are selected in the Measurements > Select menu.
Measurement Algorithm:
The High Amplitude measurement calculates the mode of all differential waveform values greater than
zero.
Where:
v
is differential voltage signal
DIFF
i is the index of all waveform values
The Low Amplitude measurement calculates the mode of all differential waveform values greater than
zero.
, V
)
IH
IL
Where:
v
is differential voltage signal
DIFF
i is the index of all waveform values
7.2.3 Reference Clock Differential rise and fall edge rates test MOI
Test Definition Notes from the Specification:
-Measurement is taken from a differential waveform.
-Measured from -150 mV to +150 mV on the differential waveform (derived from REFCLK+ minus
REFCLK-). The signal must be monotonic through the measurement region for rise and fall time. The
300 mV measurement window is centered on the differential zero crossing.
RT-Eye PCI Express Compliance Module 57
Methods of Implementation
Figure 30: Ref Clock Rise/Fall time calculation
Limits:
Refer to Table 12 for specified limits on Absolute Period Measurement (Rise Edge Rate, Fall Edge Rate)
Test Procedure:
Ensure that Rising Edge and Falling Edge are selected in the Measurements > Select menu.
Measurement Algorithm:
The Rise and Fall Time are calculated over the 300 mV window, which is centered at differential 0 V.
The rise/fall edge rate V/ns = 300 mV/rise/fall Time.
7.2.4 Reference clock Duty cycle Test MOI
Test Definition Notes from the Specification:
Measurement is taken from a differential waveform.
Limits:
Refer to Table 12 for specified limits on absolute period measurement (Duty Cycle).
Test Procedure:
Ensure that Duty Cycle is selected in the Measurements > Select menu.
Measurement Algorithm:
The Duty Cycle measurement calculates the ratio of the positive of the cycle relative to the period.
Where
+
Where: D
+
is the positive pulse width
W
Clock
P
58 RT-Eye PCI Express Compliance Module
is the positive duty cycle
is the period
Methods of Implementation
7.2.5 Reference Clock Jitter Test MOI
Test Definition Notes from the Specification:
Reference clock jitter is assumed to be entirely random in nature, so there is no need to define separate
Dj or Tj terms.
Limits:
Refer to Table 10 for specified limits on random and Total Jitter Measurement values on reference clock
(Jitter @ 10
-12
BER, Jitter @ 10-6 BER, TCLK_RJ)
Test Procedure:
Ensure that Jitter@BER is selected in the Measurements > Select menu.
Measurement Algorithm:
RT-Eye PCI Express Compliance Module 59
Methods of Implementation
8 Using SigTest
The SigTest import feature in the PCI Express module allows the user to take advantage of the Autoset
features of RT-Eye and automate the process of performing a compliance test using the SigTest software
offered by the PCI SIG. The SigTest Software is available at the PCI-SIG Web site at:
http://www.pcisig.com/specifications/pciexpress/compliance/compliance_library
After downloading the SigTest software and installing it on your TDS oscilloscope, the SigTest software
appears in C:\Program Files\SigTest or a similarly named directory.
To use SigTest, to perform the compliance test, follow these steps:
1. Select Use SigTest from the Specification drop-down list.
2. Select Differential or Single-Ended from the Probe Type drop-down list.
3. Go to the Configure > SigTest Version tab to import and name the SigTest version you would like to
use. Note that you can import multiple versions of SigTest as they become available from the PCI SIG.
The Output Directory field is where the SigTest results will be saved.
Figure 31: SigTest Version tab in the configure menu
4. To import and name a new SigTest version, click Import New Version using the browser to locate the
version of SigTest to import.
Figure 32: SigTest Import dialog box
60 RT-Eye PCI Express Compliance Module
Methods of Implementation
5. Click Browse and select the SigTest Executable to be used.
Figure 33: SigTest Import Dialog
6. Click the Source tab to select the data file input format. The source type is Live/Ref or File.
Figure 34: Configure > Source Tab
7. Click Select to return to the Measurement > Select menu.
8. Click Autoset to optimize vertical and horizontal oscilloscope settings for SigTest.
RT-Eye PCI Express Compliance Module 61
Methods of Implementation
9. Click Run to launch SigTest and automatically import data waveforms into SigTest. Figure 35 shows
the result after data is verified and run through SigTest.
Figure 35: Result of running SigTest on live channel input
62 RT-Eye PCI Express Compliance Module
Methods of Implementation
9 Using Dynamic Test Points
The Dynamic Test Point files used in the PCI Express module are designed to provide a means for advanced
users to develop their own test points in the module. Usage of the dynamic test point will be demonstrated in
the form of an example.
PCI Express Gen2 is at Rev0.3. But it is likely that masks and measurement limits may change before this
specification reaches maturity. In PCI Express Gen2 Specification, it is required that measurements must deconvolve effects of compliance test board to yield an effective measurement at the TX pins. In the absence
of de-convolving the test fixture from the measurement using some sort of equalization function,
measurement masks and limits need to be de-rated to consider the effects of the loss characteristics in both
the test fixture and the cables being used to make the measurement. In the following example, the transmitter
test point in the Gen2 – 5 Gb/s (Base: Transmitter) will be modified to account for loss in the test system.
The waveform masks and jitter limits will be de-rated and the test point file will be renamed
Base_TX_2.0_Derated. Once the test point file is modified and saved in the proper folder, the new test point
will show up in the Test Point menu drop-down in the PCI Express Compliance module. The following
shows the format of the Gen2 TP file found at:
C:\Program Files\TekApplications\tdsRT-Eye\modules\PCIExpress\TestPoint
on the instrument where the module is installed.
Figure 36 – Standard Gen2 TX test point file
RT-Eye PCI Express Compliance Module 63
Methods of Implementation
9.1 Test Point File Syntax
The test point file can be broken down into the following syntax:
Header Information (comment lines) used to document description and date of test point file:
#PCI-Express Test Point file
#11-Jul-05 15:52:20
Test Point display name that shows up in the test point drop-down list:
TestPointDisplayName = Base: Transmitter
Standard Version that determines in which standard version list the test point will appear:
StandardVersion = Gen2 - 5 Gb/s
Test point short name that determines whether or not transition and non-transition bits will be
separated. Choices are TX (Tbits and NTbits separated) and RX (Tbits and NTbits not separated):
TestPointShortName = TX
Measurement limits that determine pass/fail criteria and whether the measurement will show up as
selected when Select Required is pressed:
EyeHeightTransitionBitsMin = 0.8
EyeHeightNon-TransBitsMin = 0.3785
EyeWidthMin = 150E-12
RiseTimeD+Min = 30E-12
RiseTimeD-Min = 30E-12
RiseTimeMin = 30E-12
FallTimeD+Min = 30E-12
FallTimeD-Min = 30E-12
FallTimeMin = 30E-12
TIEJitterMin = -25E-12
TIEJitterMax = 25E-12
JitterTJ-DD-Max10-12 = 50E-12
JitterDJ-DD-Max10-12 = 30E-12
De-EmphasisMeanLower = -6.5
De-EmphasisMeanUpper = -5.5
UnitIntervalMeanLower = 199.94E-12
UnitIntervalMeanUpper = 200.06E-12
DifferentialPeakVoltageMax = 1.2
DifferentialAverageVoltageMax = 25E-03
64 RT-Eye PCI Express Compliance Module
Methods of Implementation
Number and location of Masks:
MaskCount = 2
Mask0 = PCE_Rev20_TxTbit.msk
Mask1 = PCE_Rev20_TxNTbit.msk
Note: PCI Express Mask files are located at:
C:\TekApplications\tdsrt-eye\Masks\PCI Express on the instrument that the module is installed. The
following is the contents of PCE_Rev20_TxTbit.msk. Note that .msk file format is used by both RT-Eye
and the instrument firmware in mask testing. The only parameters in the .msk file that RT-Eye uses are the
highlighted mask vertices shown in bold font.
:MASK:USER:AMP 100.0000E-3;
:MASK:USER:PATTERNBITS 1;
:MASK:USER:PRESAMPBITS 0;
:MASK:USER:WID 400.0000E-12;
:MASK:USER:HSCA 62.5000E-12;
:MASK:USER:HTRIGPOS 500.0000E-3;
:MASK:USER:LAB "User Mask";
:MASK:USER
:TRIGTOSAMP 0.0000;
:MASK:USER:RECO 5000;
:MASK:USER:VSCA 200.0000E-3;
:MASK:USER:VPOS 0.0000;
:MASK:USER:VOFFS 0.0000;
:MASK:USER
:BITR 5.000E+9;
:MASK:USER
:SERIALTRIG NRZ;
:MASK:USER:SEG1:POINTS -100.0000E-12,600.0000E-3,100.0000E-12,600.0000E-3,100.0000E-
12,800.0000E-3,-100.0000E-12,800.0000E-3;
:MASK:USER:SEG2:POINTS -75.0000E-12,0.0000,0.0000,-400.0000E-3,75.0000E
12,0.0000,0.0000,400.0000E-3;
:MASK:USER:SEG3:POINTS -100.0000E-12,-800.0000E-3,100.0000E-12, 800.0000E-3,100.0000E-12,-
600.0000E-3,-100.0000E-12,-600.0000E-3;
:MASK:AUTOSET:STANDARD PCIEXPRESS_Xmit;
RT-Eye PCI Express Compliance Module 65
Methods of Implementation
Clock recovery and windowing parameters when SSC is selected in the Measurement Configuration
menu:
SSCClockRecoveryMethod = Minimum Deviation
SSCScanStateOn = false
SSCClockRecoveryWindow = 3500
SSCAnalysisWindow = 250
Clock recovery and pattern length used when Clean Clock is selected in the Measurement
Configuration menu:
CleanClockRecoveryMethod = 1st Order PLL
CleanScanStateOn = false
CleanClockLoopBW = 6670000
RjDjPatternLength = 640
9.2 Creating the New Test Point
In this example, the Test Point and mask files will be copied and given new names. A text editor is used to
modify their contents.
The new TP file (Figure 37) is saved to the folder:
C:\Program Files\TekApplications\tdsRT-Eye\modules\PCIExpress\TestPoint
Figure 37: De-rated transmitter test point file – Base_TX_2.0_Derate.tp
66 RT-Eye PCI Express Compliance Module
Methods of Implementation
The following changes are made to SEG2 of the Mask file:
:MASK:USER:SEG2:POINTS -70.0000E-12,0.0000,0.0000,-350.0000E-3,70.0000E-
12,0.0000,0.0000,350.0000E-3;
This de-rates the horizontal mask limit from 150 ps to 140 ps and the vertical mask limit from 800 mV to
700 mV.
The new mask file is saved to the folder:
C:\TekApplications\tdsrt-eye\Masks\PCI Express as filename <PCE_Rev20_TxTbit_derate.msk>
9.3 Running a test with the new DTP
After the preceding file changes are made, when RT-Eye software is run, the new DTP is loaded into the
PCI Express Compliance Module.
Figure 38: “De-rated Transmitter” DTP is now in the test point menu
To run the test, perform the following steps:
1. Go to the PCI Express Module
2. Select Gen2 – 5 Gb/s as the specification.
3. Select the new Test Point De-rated Transmitter from the Test Point drop-down list.
4. Click Select Required – Notice that measurements removed from the Test Point file are no longer
selected.
5. Click Start. The results appear as shown in Figure 39. Notice that the new de-rated mask now appears
as the Tbit mask and the upper and lower limits are the new values entered into the DTP file.
RT-Eye PCI Express Compliance Module 67
Methods of Implementation
Figure 39: Result of de-rated transmitter test
10 Giving a Device an ID
The PCI Express Compliance module provides a graphical user interface (See Figure 38) for entering a
device ID and description. Data entered here will appear on the compliance report and is recommended for
device tracking.
11 Creating a Compliance Report
To create a compliance report, select Utilities > Reports. The Report Generator utility can create a complete
report of the compliance test.
12 Further Analysis Techniques
Refer to the RT-Eye Quick Start Guide or Online Help for additional analysis techniques.
68 RT-Eye PCI Express Compliance Module
Methods of Implementation
13 Ensuring Compliance over specified population
The Rev1.0a specification states that measurements are to pass the compliance statements over any 250
consecutive UIs. The Rev1.0a was ambiguous about the number of UIs needed to achieve compliance. The
3500:250 scan mode on a single acquisition has become the standard way of achieving compliance at
industry plug fests. Rev1.1 of the specification has explicitly called out 10
achieve compliance. While the specification does not require 1Million consecutive unit intervals to be
acquired, using a long enough record length to capture 1Million UIs will insure repeatable measurements
and allow you save a single shot acquisition of the specification compliant acquisition for future analysis. In
order to analyze 1Million unit intervals in RT-Eye, the ‘Probe Type’ must be set to Differential as described
in section 3.5.3. This can be done using a differential probe on Ch1 (probe configurations B and D in Section
3.2) as the source. If the signal is probed single ended using Ch1 and Ch3 (as in probe configurations A and
C in Section 3.2), then a Math waveform (Math1 = Ch1 – Ch3) can be used to perform the 1Million UI test.
6
as the population needed to
Figure 40: Result from a 1Million UI test on 5GT/s signal.
RT-Eye PCI Express Compliance Module 69
Loading...
