Tektronix DAS-Scan Quick Start Guide

DAS-Scan Quick Start

The DAS-Scan system is a data acquisition system that allows you to measure voltage and/or thermocouple input on up to 4,096 analog input channels. You can use your DAS-Scan data acquisition system with the following software:

● ASO-SCAN software (Advanced Software Option) - Install this

software if you want to create data acquisition application programs at the driver level using Microsoft Visual C++, Borland C/C++ (for Windows), or Microsoft Visual Basic for Windows.

● VTX (Visual Test Extensions) - Install this software if you want

to create data acquisition application programs using an integrated set of custom controls within the Microsoft Visual Basic Windows programming environment.

● TestPoint - Install this software if you want to create data

acquisition applications under Windows using a set of professional software tools instead of programming.

To begin, use the DAS-Scan system setup checklist to set up your DAS-Scan system. Then, follow the quick start instructions for the software package you want to use.



for

DAS-Scan System Setup Checklist

Use the following DAS-Scan system setup checklist to set up your DAS-Scan system. Refer to the DAS-Scan User’s Guide for detailed instructions.

❏ 1. Unpack and inspect the components of your DAS-Scan system. ❏ 2. Create a channel map indicating the input signals you want to attach

to each of the channels in your DAS-Scan system.

Part #94830; Revision A; July 1996 1

❏ 3. Conﬁgure the hardware components, as follows:

– On the SCAN-AD-HR board, set the base I/O address switch

(S1) to indicate the appropriate base I/O address, and, if appropriate, set the J6 jumper to indicate an external pacer clock or an external digital trigger/hardware gate.

– On each SCAN-BRD assembly, set the address thumbwheels to

indicate the appropriate assembly address. (For the purposes of this quick start, make sure that you set the address of the ﬁrst assembly to 00h.)

– If you are using SCAN-STP-TC screw terminal panels, set the J2

jumpers on each panel to indicate whether you are using cold junction compensation (CJC).

❏ 4. Mount the SCAN-STP screw terminal panels on DIN rails. ❏ 5. Attach the input signals to the appropriate SCAN-STP screw terminal

panels.

❏ 6. Mount the SCAN-CH chassis in a 19-inch rack. ❏ 7. Attach one end of each SCAN-CAB-64 cable to the appropriate

position in the SCAN-CH chassis. (Do not attach the other end of the SCAN-CAB-64 cables at this point.)

❏ 8. Attach a power cord to the power-supply panel of each SCAN-CH

chassis.

❏ 9. Check the operation of the power supply in each SCAN-CH chassis. ❏ 10. Install the SCAN-BRD assemblies in the appropriate SCAN-CH

chassis.

❏ 11. Make sure that power to the computer is turned OFF. ❏ 12. Install the SCAN-AD-HR board in your computer. ❏ 13. Attach the SCAN-AD-HR board to the ﬁrst SCAN-CH chassis using

the S-1802/M cable.

❏ 14. Daisy-chain multiple SCAN-CH chassis, if required, using

S-1802/MM cables.

❏ 15. Attach the other end of each SCAN-CAB-64 cable to the appropriate

SCAN-STP screw terminal panel.

❏ 16. Connect an external pacer clock, external digital trigger, or hardware

gate, if required, to the J5 connector on the SCAN-AD-HR board using a CAB-SMA-BNC cable.

2 DAS-Scan Quick Start

❏ 17. Plug the power cords into the wall, and then power up your computer,

the SCAN-CH chassis, and any equipment attached to the SCAN-STP screw terminal panels.

When you ﬁnish setting up your DAS-Scan system, install your software package using the quick start instructions in this document. Refer to the

next section for ASO-SCAN software quick start instructions; refer to page 7 for VTX quick start instructions; refer to page 11 for TestPoint quick start instructions.

ASO-SCAN Software Quick Start

Once you’ve set up your DAS-Scan system, do the following:

➨ Install the software.

If you need help during this procedure, refer to Chapter 2 of your DAS-Scan User’s Guide.

1. Insert disk #1 of the ASO-SCAN software package in the appropriate disk drive.

2. Start Windows, if necessary.

3. If you are using Windows 3.1: – On the File menu of the Program Manager, click Run. If you are using Windows 95: – From the Windows 95 task bar, click Start and then Run.

4. In the Run dialog box, enter the appropriate drive letter and the setup command. For example, if the disk is in drive A, enter

a:\setup

and then click OK.

5. Respond to the prompts. The installation program automatically creates a directory on the

drive you speciﬁed and then copies all ﬁles, expanding any compressed ﬁles, to the new directory.

6. When the installation is complete, review the FILES.TXT and README.TXT ﬁles for important information.

ASO-SCAN Software Quick Start 3

7. If you are using Windows 95 to write 32-bit programs, install the ASO-Win95/32-Bit software, as follows:

– Insert the ASO-Win95/32-Bit disk into the appropriate disk drive. – Click Start and then Run. – In the Run dialog box, enter the appropriate drive letter and the

setup command. For example, if the disk is in drive A, enter

a:\setup

and then click OK.

– Respond to the prompts, as appropriate. To avoid overwriting

ﬁles with the same name, install the ASO-Win95/32-Bit software in a different directory from the one in which you installed the ASO-SCAN software package.

– Refer to the README.TXT ﬁle in the installation directory for

more information about the ASO-Win95/32-Bit software.

➨ Create a conﬁguration ﬁle.

If you need help during this procedure, refer to Chapter 2 of your DAS-Scan User’s Guide.

1. If you are using Windows 3.1: – From the Keithley DAS-Scan program group in the Program

Manager, double-click the DAS-Scan Conﬁguration icon.

If you are using Windows 95: – From the Windows 95 task bar, click Start, point to Programs

and Keithley DAS-Scan, and then click DAS-Scan Conﬁguration.

The DAS-Scan Conﬁguration panel appears.

2. Under DAS-Scan General Info, set Base Address to match the setting of the base I/O address switch (S1) on the SCAN-AD-HR board.

For this quick start session, the remaining default values are assumed. If your conﬁguration differs from the default settings, refer to Chapter 2 of your DAS-Scan User’s Guide for help on conﬁguring the DAS-Scan system.

4 DAS-Scan Quick Start

3. To save the conﬁguration in the default conﬁguration ﬁle (DASSCAN.CFG), click Save on the File menu.

4. To exit the DAS-Scan Conﬁguration panel, click Exit on the File Menu or click Exit on the panel.

➨ Install the Keithley Memory Manager.

If you need help during this procedure, refer to Appendix B of your DAS-Scan User’s Guide.

1. If you are using Windows 3.1: – From the Keithley DAS-Scan program group in the Program

Manager, double-click the Memory Manager Setup icon.

If you are using Windows 95: – From the Windows 95 task bar, click Start, point to Programs

and Keithley DAS-Scan, and then click Memory Manager Setup.

The Keithley Memory Manager - Setup panel appears.

2. In the Desired Setting ﬁeld, enter the amount of memory that your VTX applications will require (the default is 128 KB).

3. Click Update.

4. If you changed the default value, click Restart Windows to ensure that the changes take effect immediately.

➨ Verify that the DAS-Scan system and software are working

properly.

If you need help during this procedure, refer to Chapter 4 of your DAS-Scan User’s Guide and to the online help provided for the DAS-Scan Control Panel.

1. If you are using Windows 3.1: – From the Keithley DAS-Scan program group in the Program

Manager, double-click the DAS-Scan Control Panel icon.

If you are using Windows 95: – From the Windows 95 task bar, click Start, point to Programs

and Keithley DAS-Scan, and then click DAS-Scan Control Panel.

The Open Conﬁguration File panel appears.

ASO-SCAN Software Quick Start 5

2. Click OK to use the default conﬁguration ﬁle (DASSCAN.CFG). The DAS-Scan Control Panel appears. This panel allows you to

acquire, display, and transfer analog input data and to set up and display the analog input parameters.

3. Read the data from channel 0 by clicking Start. If your DAS-Scan system and the software are working properly, the

program displays the data from channel 0. If data is not displayed or if an error occurs, refer to Chapter 5 of your DAS-Scan User’s Guide. If you cannot resolve the problem, call (508) 880-3000 for technical support.

4. When you are ﬁnished using the control panel, click Exit on the File menu.

Now that you’ve veriﬁed that the DAS-Scan system and software are working properly, you can conﬁgure the DAS-Scan system and software according to your needs and build your application using the DAS-Scan Function Call Driver. Refer to the source code examples and the EXAMPLES.TXT ﬁle in the installation directory for programming tips. Refer to your DAS-Scan Function Call Driver User’s Guide and to the DAS-Scan Function Call Driver online help ﬁle (SCANFCD.HLP) for detailed information.

6 DAS-Scan Quick Start

VTX Quick Start

Once you’ve set up your DAS-Scan system, do the following:

➨ Install the software.

If you need help during this procedure, refer to Chapter 1 of your VTX User’s Guide or to your Visual Basic documentation.

1. Install Version 3.0 or 4.0 (16-bit version only) of Visual Basic for Windows.

2. Insert disk #1 of the VTX DAS base module in the appropriate disk drive.

3. If you are using Windows 3.1: – On the File menu of the Program Manager, click Run. If you are using Windows 95: – On the Windows 95 task bar, click Start and then Run.

4. In the Run dialog box, enter the appropriate drive letter and the setup command. For example, if the VTX DAS disk is in drive A, enter

a:\setup

and then click OK.

5. Respond to the prompts, making sure that you include the DAS-Scan software and that you choose to automatically add the VTX controls to your Visual Basic Toolbox.

6. When the installation is complete, review the README ﬁle for important information.

VTX Quick Start 7

➨ Register and conﬁgure your DAS-Scan system, and install the

Keithley Memory Manager.

If you need help during this procedure, refer to Chapter 1 of your VTX User’s Guide.

1. If you are using Windows 3.1: – From the Keithley VTX program group in the Program Manager,

double-click the VTX Conﬁguration icon.

If you are using Windows 95: – On the Windows 95 task bar, click Start, point to Programs and

Keithley VTX, and then click VTX Conﬁguration.

2. From the DAS Hardware conﬁguration window (displayed on top), click Add New to register your DAS-Scan system for use with the VTX software.

The Add New Board dialog box appears, with a list of the hardware families whose VTX-compatible software is currently installed.

3. From the Add New Board dialog box, select DAS-Scan and click OK.

The DAS-Scan Conﬁguration panel appears.

4. In the Name list, click DAS-Scan. For this quick start session, the remaining default values are assumed.

If your conﬁguration differs from the default settings, refer to Chapter 2 of your DAS-Scan User’s Guide for help on conﬁguring the DAS-Scan system.

5. To save the conﬁguration, click Save on the File menu.

6. To exit the DAS-Scan Conﬁguration panel, click Exit on the File Menu or click Exit on the panel.

7. Click the Keithley Memory Manager tab.

8. Under Desired Setting, enter the amount of memory that your VTX applications will require (the default is 128 KB).

8 DAS-Scan Quick Start

9. If you are using Windows 3.1 and 128 KB is sufﬁcient: – Exit the VTX conﬁguration utility by clicking Close and proceed

to the next section.

If you are using Windows 3.1 and changed the amount of memory required:

– Click Update and then click Restart Windows to ensure that the

changes take effect immediately.

If you are using Windows 95: – Click Update. (You must click Update whether or not you

changed the default value.)

– If you changed the default value, click Restart Windows to

ensure that the changes take effect immediately.

➨ Verify that the DAS-Scan system and software are working

properly.

If you need help, refer to your VTX User’s Guide or to the online help.

1. Start Windows and then start Visual Basic. A new form appears.

2. Double-click the VTX DAS control icon in the Visual Basic Toolbox to place the control in the middle of the Visual Basic form.

3. Make sure that the DAS control is selected by clicking it once with the mouse. While pressing and holding down the left mouse button, use the mouse to drag the DAS control to the left side of the form.

4. Double-click the VTX Text control icon to place the control on the form.

5. Click the DAS control once to select it, press F4 to display the Properties window, and double-click the ProcessSrc property in the Properties window until DASScan Board 1 appears.

6. Click the Text control once to select it, press F4 to display the Properties window, and double-click the Process property in the Properties window until the Grid process appears.

7. Click the Text control again to select it, and use the mouse to drag one of the corner sizing handles until the Text control is large enough to hold several samples.

VTX Quick Start 9

8. Connect the data output connection point of the DAS control to the data input connection point of the Text control, as follows:

– Position the cursor over the small, dark rectangle on the right side

of the DAS control. This rectangle is called the data output connection point of the DAS control.

data output connection point

– When the cursor changes to an arrow with a wiring icon, press

and hold down the left mouse button.

– When the arrow disappears, drag the wiring icon to the small,

dark rectangle on the left side of the Text control. This rectangle is called the data input connection point.

data input connection point

– When the arrow with the wiring icon reappears, release the left

mouse button.

You should see a solid line that connects the two controls together.

9. Click Start on the Visual Basic Run menu to run the program. If your DAS-Scan system and the software are working properly, the

program displays the data from channel 0 in a grid. If data is not displayed or if an error message appears, refer to Chapter 5 of your DAS-Scan User’s Guide. If you cannot resolve the problem, call (508) 880-3000 for technical support.

Now that you’ve veriﬁed that your DAS-Scan system and software are working properly, you can conﬁgure the DAS-Scan system and software according to your needs and build a more sophisticated application using VTX. For a VTX tutorial, refer to Chapter 2 of your VTX User’s Guide. Refer to the VTX online help for detailed information.

10 DAS-Scan Quick Start

TestPoint Quick Start

Once you’ve set up your DAS-Scan system, do the following:

➨ Install the ASO-SCAN software.

If you need help during this procedure, refer to Chapter 2 of your DAS-Scan User’s Guide.

1. Insert disk #1 of the ASO-SCAN software package in the appropriate disk drive.

2. Start Windows, if necessary.

3. If you are using Windows 3.1: – On the File menu of the Program Manager, click Run. If you are using Windows 95: – From the Windows 95 task bar, click Start and then Run.

4. In the Run dialog box, enter the appropriate drive letter and the setup command. For example, if the disk is in drive A, enter

a:\setup

and then click OK.

5. Respond to the prompts.

Note: TestPoint requires only the DAS-Scan Conﬁguration Utility

(CFGSCAN.EXE) and the Keithley Memory Manager (KMMSETUP.EXE) from the ASO-SCAN software package. If you do not intend to use the ASO-SCAN software for programming, do not select any of the check boxes presented.

The installation program automatically creates a directory on the drive you speciﬁed and then copies the ﬁles, expanding any compressed ﬁles, to the new directory.

TestPoint Quick Start 11

➨ Install the TestPoint software and execution control key.

If you need help during this procedure, refer to TestPoint QuickStart, which was shipped with your TestPoint software.

1. Insert TestPoint disk #1 in the appropriate disk drive.

2. Start Windows, if necessary.

3. If you are using Windows 3.1: – On the File menu of the Program Manager, click Run. If you are using Windows 95: – From the Windows 95 task bar, click Start and then Run.

4. In the Run dialog box, enter the appropriate drive letter and the setup command. For example, if the disk is in drive A, enter

a:\setup

and then click OK.

5. Respond to the prompts. The installation program copies the TestPoint ﬁles to the directory

you speciﬁed or to the default directory C:\TESTPT and adds new icons to the Windows Program Manager.

6. If you want to install any of the optional libraries, insert the ﬁrst library disk in the appropriate disk drive and repeat steps 3 through 5.

7. Install the execution control key in the ﬁrst parallel port on the back of your computer.

➨ Create a conﬁguration ﬁle.

If you need help during this procedure, refer to Chapter 2 of your DAS-Scan User’s Guide.

1. If you are using Windows 3.1: – From the Keithley DAS-Scan program group in the Program

Manager, double-click the DAS-Scan Conﬁguration icon.

If you are using Windows 95: – From the Windows 95 task bar, click Start, point to Programs

and Keithley DAS-Scan, and then click DAS-Scan Conﬁguration.

The DAS-Scan Conﬁguration panel appears.

12 DAS-Scan Quick Start

2. Under DAS-Scan General Info, set Base Address to match the setting of the base I/O address switch (S1) on the SCAN-AD-HR board.

3. Click Save as on the File menu. The software prompts you for the name and location of the conﬁguration ﬁle.

4. Enter the ﬁle name KEITHLEY.CFG and specify the complete path to the TestPoint installation directory.

Notes: You must name the conﬁguration ﬁle KEITHLEY.CFG.

You must save the conﬁguration ﬁle KEITHLEY.CFG in the TestPoint installation directory.

5. To exit the DAS-Scan Conﬁguration panel, click Exit on the File Menu or click Exit on the panel.

➨ Install the Keithley Memory Manager.

If you need help during this procedure, refer to Appendix B of your DAS-Scan User’s Guide.

1. If you are using Windows 3.1: – From the Keithley DAS-Scan program group in the Program

Manager, double-click the Memory Manager Setup icon.

If you are using Windows 95: – From the Windows 95 task bar, click Start, point to Programs

and Keithley DAS-Scan, and then click Memory Manager Setup.

The Keithley Memory Manager - Setup panel appears.

2. In the Desired Setting ﬁeld, enter the amount of memory that your VTX applications will require (the default is 128 KB).

3. Click Update.

4. If you changed the default value, click Restart Windows to ensure that the changes take effect immediately.

TestPoint Quick Start 13

➨ Verify that the DAS-Scan system and software are working

properly.

If you need help during this procedure, refer to TestPoint QuickStart.

1. Make sure that the execution control key is installed in the ﬁrst parallel port on the back of your computer.

2. If you are using Windows 3.1: – From the TestPoint window in the program Manager,

double-click the TestPoint icon.

If you are using Windows 95: – From the Windows 95 task bar, click Start, point to Programs,

and then click TestPoint.

The TestPoint editor appears, containing the Stock window (in the upper left of the screen), the Objects window (in the lower left of the screen), and the Panel1 window (in the upper right of the screen).

3. Drag a pushbutton object from the Stock window to the Panel1 window.

4. In the Settings tab of the Object "Pushbutton1" window that appears on the lower right of the screen, enter Acquire as the name for the pushbutton object. The remaining default values are assumed.

5. Drag an A/D object from the Stock window to the Panel1 window.

6. In Settings tab of the Object "A/D1" window that appears on the lower right of the screen, enter DAS-Scan Board #0 as the name for the ﬁrst 256 channels of your DAS-Scan system. The remaining default values are assumed.

7. Drag a graph object from the Stock window to the panel. The default values are assumed.

8. Drag the A/D object DAS-Scan Board #0 from the Objects window to the Actions tab of the Object "Acquire" window.

9. From the list of actions, click Acquire A/D.

10. In the text line, click on the appropriate blank and enter 100 for the number of samples, 10,000 for the rate in hertz, and 0 for the channel.

11. Drag the graph object Graph1 from the Objects window to the Actions tab of the Object "Acquire" window.

12. From the list of actions, click Draw graph.

14 DAS-Scan Quick Start

13. Drag the name of the A/D object DAS-Scan Board #0 from the ﬁrst text line to the blank in the second text line.

14. Click Mode=Edit on the menu bar to change the menu name to Mode=Run.

15. Click Acquire in the panel. If your DAS-Scan system and the software are working properly, the

program displays the data from channel 0 in the graph. If data is not displayed or if an error occurs, refer to Chapter 5 of your DAS-Scan User’s Guide or to the TestPoint online help. If you cannot resolve the problem, call (508) 880-3000 for technical support.

16. When you are ﬁnished, click Exit on the File menu.

trademarks or registered trademarks of their respective companies.

TestPoint Quick Start 15

Tektronix DAS-Scan Quick Start Guide

Specifications and Main Features

Frequently Asked Questions

User Manual
