DAS-4100 Series

Function Call Driver

USER’S GUIDE

DAS-4100 Series

Function Call Driver

User’s Guide

Revision A - October 1995

Part Number: 94550

New Contact Information

Keithley Instruments, Inc.

28775 Aurora Road

Cleveland, OH 44139

Technical Support: 1-888-KEITHLEY

Monday – Friday 8:00 a.m. to 5:00 p.m (EST)

Fax: (440) 248-6168

Visit our website at http://www.keithley.com

The information contained in this manual is believed to be accurate and reliable. However, Keithley Instruments, Inc., assumes no responsibility for its use or for any infringements of patents or other rights of third parties that may result from its use. No license is granted by implication or otherwise under any patent rights of Keithley Instruments, Inc.

KEITHLEY INSTRUMENTS, INC., SHALL NO T BE LIABLE FOR ANY SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES RELATED TO THE USE OF THIS PRODUCT. THIS PRODUCT IS NOT DESIGNED WITH COMPONENTS OF A LEVEL OF RELIABILITY SUITABLE FOR USE IN LIFE SUPPORT OR CRITICAL APPLICATIONS.

Refer to your Keithley Instruments license agreement for speciﬁc warranty and liability information.

All brand and product names are trademarks or registered trademarks of their respective companies.

All rights reserved. Reproduction or adaptation of any part of this documentation beyond that permitted by Section 117 of the 1976 United States Copyright Act without permission of the Copyright owner is unlawful.

Keithley MetraByte Division

Keithley Instruments, Inc.

440 Myles Standish Blvd. Taunton, MA 02780

FAX: (508) 880-0179

Telephone: (508) 880-3000

●

Preface

This manual describes how to write application programs for DAS-4100 Series boards using the DAS-4100 Series Function Call Driver. The DAS-4100 Series Function Call Dri ver supports the following DOS-based languages:

●

Microsoft Borland



C/C++ (Version 4.0 and higher)



C/C++ (Version 1.0 and higher)

The DAS-4100 Series Function Call Driver supports the following Windows-based languages:

●

Microsoft C/C++ (Version 7.0 and higher) Borland C/C++ (Version 4.0 and higher)

●

Microsoft Visual Basic

●

Microsoft Visual C++



for Windows (Version 3.0 and higher)



(Version 1.0 and higher)

The manual is intended for application programmers using a DAS-4100 Series boards in an IBM



PC AT



or compatible computer. It is assumed that users have read the DAS-4100 Series User’s Guide to familiarize themselves with the board’s features, and that they have completed the appropriate hardware installation and conﬁguration. It is also assumed that users are experienced in programming in their selected language and that they are familiar with data acquisition principles.

vii

The DAS-4100 Series Function Call Driver User’s Guide is organized as follows:

●

Chapter 1 contains the information needed to install the DAS-4100 Series Function Call Driver and to get help.

Chapter 2 contains the background information needed to use the

●

functions included in the DAS-4100 Series Function Call Driver.

●

Chapter 3 contains programming guidelines and language-speciﬁc information related to using the DAS-4100 Series Function Call Driver.

●

Chapter 4 contains detailed descriptions of the DAS-4100 Series Function Call Driver functions, arranged in alphabetical order.

●

Appendix A contains a list of the error codes returned by DAS-4100 Series Function Call Driver functions.

●

Appendix B contains instructions for converting counts to v oltage and for converting voltage to counts.

An index completes this manual.

viii

Table of Contents

Preface

Getting Started

Available Operations

System Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1

Initializing the Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1

Initializing a Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2

Retrieving Revision Levels . . . . . . . . . . . . . . . . . . . . . . . . . . .2-3

Handling Errors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-3

Analog Input Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-4

Operation Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-4

Memory Allocation and Management. . . . . . . . . . . . . . . . . . .2-4

Dimensioning a Local Array . . . . . . . . . . . . . . . . . . . . . . .2-5

Dynamically Allocating a Memory Buffer. . . . . . . . . . . . .2-6

Assigning the Starting Address . . . . . . . . . . . . . . . . . . . . .2-7

Channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-7

Acquiring Samples from a Single Channel . . . . . . . . . . . .2-7

Acquiring Samples from Both Channels . . . . . . . . . . . . . .2-8

Acquiring Samples Using a Channel-Gain Queue. . . . . . .2-8

Input Ranges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-8

Pacer Clocks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-9

Internal Pacer Clock. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-9

External Pacer Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-10

Triggers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-11

Trigger Sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-11

Internal Trigger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-12

External Analog Trigger . . . . . . . . . . . . . . . . . . . . . . .2-12

External Digital Trigger. . . . . . . . . . . . . . . . . . . . . . . .2-13

Trigger Acquisition. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-14

Post-Trigger Acquisition . . . . . . . . . . . . . . . . . . . . . . .2-14

Pre-Trigger Acquisition. . . . . . . . . . . . . . . . . . . . . . . .2-15

About-Trigger Acquisition . . . . . . . . . . . . . . . . . . . . .2-16

iii

Programming with the Function Call Driver

How the Driver Works . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1

Programming Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-4

Preliminary Tasks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-5

Analog Input Programming Tasks . . . . . . . . . . . . . . . . . . . . . . . .3-6

C/C++ Programming Information . . . . . . . . . . . . . . . . . . . . . . . .3-8

Dimensioning and Assigning a Local Array . . . . . . . . . . . . . .3-8

Dynamically Allocating and Assigning a Memory Buffer . . .3-9

Allocating a Memory Buffer . . . . . . . . . . . . . . . . . . . . . . .3-9

Accessing the Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-10

Creating a Channel-Gain Queue . . . . . . . . . . . . . . . . . . . . . .3-10

Handling Errors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-11

Programming in Microsoft C/C++ (for DOS). . . . . . . . . . . .3-12

Programming in Microsoft C/C++ (for Windows) . . . . . . . .3-13

Programming in Borland C/C++ (for DOS) . . . . . . . . . . . . .3-14

Programming in Borland C/C++ (for Windows). . . . . . . . . .3-15

Microsoft Visual Basic for Windows

Programming Information . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-16

Dimensioning and Assigning a Local Array . . . . . . . . . . . . .3-16

Dynamically Allocating and Assigning a Memory Buffer . .3-17

Allocating a Memory Buffer . . . . . . . . . . . . . . . . . . . . . .3-17

Accessing the Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-18

Creating a Channel-Gain Queue . . . . . . . . . . . . . . . . . . . . . .3-18

Handling Errors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-19

Programming in Microsoft Visual Basic for Windows . . . . .3-20

Function Reference

K_ClearFrame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-5

K_CloseDriver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-6

K_ClrAboutTrig. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-7

K_DASDevInit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-8

K_FormatChnGAry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-9

K_FreeDevHandle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-10

K_FreeFrame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-11

K_GetADFrame. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-12

K_GetClkRate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-14

K_GetDevHandle. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-16

K_GetErrMsg. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-18

K_GetShellVer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-19

K_GetVer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-20

K_IntAlloc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-22

K_IntFree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-24

K_IntStart. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-25

K_IntStatus. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-26

K_IntStop. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-28

K_MoveBufToArray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-30

K_OpenDriver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-31

K_RestoreChnGAry. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-33

K_SetAboutTrig. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-34

K_SetADTrig. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-36

K_SetBuf . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-38

K_SetBufI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-40

K_SetChn. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-42

K_SetChnGAry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-43

K_SetClk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-45

K_SetClkRate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-46

K_SetDITrig. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-48

K_SetG. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-50

K_SetPostTrigDelay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-52

K_SetStartStopChn . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-53

K_SetTrig. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-54

Error/Status Codes

Data Formats

Converting Counts to Voltage. . . . . . . . . . . . . . . . . . . . . . . . . . . B-1

Converting Voltage to Counts. . . . . . . . . . . . . . . . . . . . . . . . . . . B-3

Index

List of Figures

Figure 2-1. Analog Trigger Conditions . . . . . . . . . . . . . . . . .2-13

Figure 2-2. Digital Trigger Conditions. . . . . . . . . . . . . . . . . .2-14

Figure 3-1. Interrupt-Mode Operation . . . . . . . . . . . . . . . . . . .3-2

List of Tables

Table 2-1. Supported Operations . . . . . . . . . . . . . . . . . . . . . .2-1

Table 2-2. Sample Ranges. . . . . . . . . . . . . . . . . . . . . . . . . . . .2-5

Table 2-3. Analog Input Ranges . . . . . . . . . . . . . . . . . . . . . . .2-9

Table 2-4. Available Conversion Rates Using

Internal Clock . . . . . . . . . . . . . . . . . . . . . . . . . . .2-10

Table 3-1. A/D Frame Elements . . . . . . . . . . . . . . . . . . . . . . .3-3

Table 3-2. Setup Functions for Interrupt-Mode

Analog Input Operations . . . . . . . . . . . . . . . . . . . .3-6

Table 4-1. Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2

Table 4-2. Data Type Prefixes. . . . . . . . . . . . . . . . . . . . . . . . .4-4

Table A-1. Error/Status Codes. . . . . . . . . . . . . . . . . . . . . . . . A-1

Table B-1. Some Span Values For Analog Input

Data Conversion Equations . . . . . . . . . . . . . . . . . B-2

Table 2-1. Supported Operations . . . . . . . . . . . . . . . . . . . . . .2-1

Table 2-2. Sample Ranges. . . . . . . . . . . . . . . . . . . . . . . . . . . .2-5

Table 2-3. Analog Input Ranges . . . . . . . . . . . . . . . . . . . . . . .2-9

Table 2-4. Available Conversion Rates Using Internal Clock . . 2-10

Table 3-1. A/D Frame Elements . . . . . . . . . . . . . . . . . . . . . . .3-3

Table 3-2. Setup Functions for Interrupt-Mode Analog Input Operations3-6

Table 4-1. Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-1

Table 4-2. Data Type Prefixes. . . . . . . . . . . . . . . . . . . . . . . . .4-3

Table A-1. Error/Status Codes. . . . . . . . . . . . . . . . . . . . . . . . A-1

Table B-1. Some Span Values For Analog Input Data Conversion Equations B-2

Figure 2-1. Analog Trigger Conditions . . . . . . . . . . . . . . . . .2-13

Figure 2-2. Digital Trigger Conditions. . . . . . . . . . . . . . . . . .2-14

Figure 3-1. Interrupt-Mode Operation . . . . . . . . . . . . . . . . . . .3-2

CHAP01_.FRM Page 1 Wednesday, November 24, 1999 9:48 AM

Getting Started

The DAS-4100 Series Function Call Dri ver is a library of data acquisition and control functions (referred to as the Function Call Driver or FCD functions). It is part of the following two software packages:

●

DAS-4100 Series Standard Software package - This is the software

package that is shipped with DAS-4100 Series boards; it includes utility programs, running under DOS, that allow you to conﬁgure, calibrate, and test the DAS-4100 Series boards.

●

ASO-4100 software package - This is the Advanced Software

Option for DAS-4100 Series boards. You purchase the ASO-4100 software package separately from the board; it includes the following:

– Libraries of FCD functions for Microsoft C/C++ (for DOS) and

Borland C/C++ (for DOS).

– Dynamic Link Libraries (DLLs) of FCD functions for Microsoft

Visual Basic for Windows, Microsoft C/C++ (for Windows), and Borland C/C++ (for Windows).

– Support ﬁles, containing program elements, such as function

prototypes and deﬁnitions of variable types, that are required by the FCD functions.

– Utility programs, running under DOS, that allow you to

conﬁgure, calibrate, and test the DAS-4100 Series boards.

– Language-speciﬁc example programs.

Before you use the Function Call Driver, make sure that you have installed the software, set up the board, and created a conﬁguration ﬁle using the setup and installation procedures described in the DAS-4100

Series User’s Guide .

1-1 Getting Started

CHAP01_.FRM Page 2 Wednesday, November 24, 1999 9:48 AM

If you need help installing or using the DAS-4100 Series Function Call Driver , call your local sales of ﬁce or the K eithley MetraByte Applications Engineering Department at:

(508) 880-3000 Monday - Friday, 8:00

An applications engineer will help you diagnose and resolve your problem over the telephone.

Please make sure that you have the follo wing information av ailable before you call:

DAS-4100 Series board conﬁguration

Computer

A.M.

- 6:00

Serial # Revision code Base I/O address setting Memory address setting Interrupt level setting

Manufacturer CPU type Clock speed (MHz) KB of RAM Video system BIOS type Memory manager

P.M.

, Eastern Time

___________________ ___________________ ___________________ ___________________ ___________________ _____

___________________ ___________________ ___________________ ___________________ ___________________ ___________________ ___________________ _______

Operating system

Software package

DOS version Windows version Windows mode

Name Serial # Version Invoice/Order #

___________________ ___________________ ___________________ ___

___________________ ___________________ ___________________ ___________________ ____

1-2

CHAP01_.FRM Page 3 Wednesday, November 24, 1999 9:48 AM

Compiler (if applicable)

Accessories

Language Manufacturer Version

___________________ ___________________ ___________________ ___

Type ____________________

1-3 Getting Started

CHAP01_.FRM Page 4 Wednesday, November 24, 1999 9:48 AM

1-4

Available Operations

This chapter contains the background information you need to use the FCD functions to perform operations on DAS-4100 Series boards. The supported operations are listed in Table 2-1.

System Operations

This section describes the miscellaneous operations and general maintenance operations that apply to DAS-4100 Series boards and to the DAS-4100 Series Function Call Driver. It includes information on initializing a driver, initializing a board, retrieving revision levels, and handling errors.

Initializing the Driver

You must initialize the DAS-4100 Series Function Call Driver and any other Keithley DAS Function Call Drivers you are using in your application program. To initialize the drivers, use the K_OpenDriver function. You specify the driver you are using and the conﬁguration ﬁle that deﬁnes the use of the driver. The driver returns a unique identiﬁer for the driver; this identiﬁer is called the driver handle.

Table 2-1. Supported Operations

Operation Page Reference

System page 2-1 Analog input page 2-4

System Operations 2-1

Initializing a Board

You can specify a maximum of 30 driver handles for all the Keithley MetraByte drivers initialized from all your application programs. If you no longer require a driver and you want to free some memory or if you have used all 30 driver handles, you can use the K_CloseDriver function to free a driver handle and close the associated driver.

If the driver handle you free is the last driver handle speciﬁed for a Function Call Driver, the driver is shut down. (For Windows-based languages only, the DLLs associated with the Function Call Driver are shut down and unloaded from memory.)

The DAS-4100 Series Function Call Driver supports up to two boards. You must use the K_GetDevHandle function to specify the boards you want to use. The driver returns a unique identiﬁer for each board; this identiﬁer is called the device handle.

Device handles allow you to communicate with more than one board. You use the device handle returned by K_GetDevHandle in subsequent function calls related to the board.

You can specify a maximum of 30 device handles for all the Keithley MetraByte boards accessed from all your application programs. If a board is no longer being used and you want to free some memory or if you have used all 30 device handles, you can use the K_FreeDevHandle function to free a device handle.

To reinitialize a board during an operation, use the K_DASDevInit function. K_GetDevHandle and K_DASDevInit perform the following tasks:

●

Abort all operations currently in progress that are associated with the board identiﬁed by the device handle.

●

Verify that the board identiﬁed by the device handle is the board speciﬁed in the conﬁguration ﬁle associated with the board.

2-2 Available Operations

Retrieving Revision Levels

If you are using functions from different Keithley DAS Function Call Drivers in the same application program or if you are having problems with your application program, you may want to verify which versions of the Function Call Driver, Keithley DAS Driver Speciﬁcation, and Keithley DAS Shell are installed on your computer.

The K_GetVer function allows you to get both the revision number of the DAS-4100 Series Function Call Driver and the revision number of the Keithley DAS Driver Speciﬁcation to which the driver conforms.

The K_GetShellVer function allows you to get the revision number of the Keithley DAS Shell (the Keithley DAS Shell is a group of functions that are shared by all DAS boards).

Handling Errors

Each FCD function returns a code indicating the status of the function. To ensure that your application program runs successfully, it is recommended that you check the returned code after the execution of each function. If the status code equals 0, the function executed successfully and your program can proceed. If the status code does not equal 0, an error occurred; ensure that your application program takes the appropriate action. Refer to Appendix A for a complete list of error codes.

Each supported programming language uses a different procedure for error checking. Refer to the following for information:

C/C++ page 3-11 Visual Basic for Windows page 3-19

For C-language application programs only, the DAS-4100 Series Function Call Driver provides the K_GetErrMsg function, which gets the address of the string corresponding to an error code.

System Operations 2-3

Analog Input Operations

This section describes the following:

●

Analog input operation mode available. How to allocate and manage memory for analog input operations.

●

How to specify the following for an analog input operation: a channel, a gain and range, a clock source, a trigger source, and the trigger acquisition type.

Operation Mode

DAS-4100 Series boards support interrupt mode only. In interrupt mode, the board acquires multiple samples from the analog input channels. A hardware clock initiates A/D conversions. Once the analog input operation begins, control returns to your application program. The hardware continues to store the acquired data in its onboard memory until the speciﬁed number of samples is acquired, then transfers the data all at once to a user-deﬁned array or buffer in the computer using an interrupt service routine.

Use the K_IntStart function to start an analog input operation in interrupt mode. Use the K_IntStop function to stop an interrupt-mode operation. Use the K_IntStatus function to determine the current status of an interrupt-mode operation.

The converted data is stored as counts. For information on converting counts to voltage, refer to Appendix B.

Memory Allocation and Management

Interrupt-mode analog input operations require a memory location in which to store acquired data. Table 2-2 lists ranges for the DAS-4100 Series boards.

2-4 Available Operations

Table 2-2. Sample Ranges

Board Sample Range

DAS-4101/64K 1 to 64K DAS-4101/256K 1 to 256K DAS-4101/1M 1 to 1024K DAS-4101/2M 1 to 2048K DAS-4102/64K 1 to 128K DAS-4102/256K 1 to 512K DAS-4102/1M 1 to 2048K

Note:

Even though you can reserve a memory location greater than the board requires, to conserve memory it is recommended that you allocate only the required amount.

The ways you can allocate and manage memory are described in the following sections.

Dimensioning a Local Array

The simplest way to reserve a memory location is to dimension an array within your application program’s memory area. This is the recommended way to reserve memory for this driver. The advantage of this method is that the array is directly accessible to your application program. The limitation of this method is that local arrays occupy permanent memory areas; these memory areas cannot be freed to make them available to other programs or processes.

Since the DAS-4100 Series Function Call Driver stores data in 16-bit integers, you must dimension a local array as an integer data type.

Analog Input Operations 2-5

Dynamically Allocating a Memory Buffer

You can allocate a memory buffer dynamically outside of your application program’s memory area. The adv antages of this method are as follows:

●

The size of the buffer is limited by the amount of free physical memory available in your computer at run time.

A dynamically allocated memory buffer can be freed to make it

●

available to other programs or processes. The limitation of this method is that, for Visual Basic for Windows,

●

data in a dynamically allocated buffer is not directly accessible to your program. You must use the K_MoveBufToArray function to move the data from the dynamically allocated buf fer to the program’s local array; refer to page 4-30 for more information.

Use the K_IntAlloc function to dynamically allocate a memory buffer. You specify the operation requiring the buffer and the number of samples to store in the buffer, refer to Table 2-2. The driver returns the starting address of the buffer and a unique identiﬁer for the buffer (this identiﬁer is called the memory handle). When the buffer is no longer required, you can free the buffer for another use by specifying this memory handle in the K_IntFree function.

Note:

For DOS-based languages, the area used for dynamically allocated memory buffers is referred to as the far heap; for Windows-based languages, this area is referred to as the global heap. These heaps are areas of memory left unoccupied as your application program and other programs run.

For DOS-based languages, the K_IntAlloc function uses the DOS Int 21H function 48H to dynamically allocate far heap memory. For Windows-based languages, the K_IntAlloc function calls the

GlobalAlloc API function to allocate the desired buffer size from the

global heap.

For Windows-based languages, dynamically allocated memory is guaranteed to be ﬁxed and locked in memory.

2-6 Available Operations

Assigning the Starting Address

After you dimension your array or allocate your buffer, you must assign the starting address of the array or buffer and the number of samples to store in the array or buffer. Each supported programming language requires a particular procedure for assigning a starting address. Refer to the following for information:

Memory

Language

C/C++ Array or Buffer K_SetBuf page 4-38

Location Function See...

Visual Basic for Windows

Array K_SetBufI page 4-40 Buffer K_SetBuf page 4-38

Channels

The DAS-4100 Series board provides up to two analog input channels; the software refers to the analog input signal from the Channel A connector as channel 0 and the analog input signal from the Channel B connector as channel 1. You can perform an analog input operation on a single channel at a time or both channels.

Acquiring Samples from a Single Channel

You can acquire a single sample or multiple samples from a single analog input channel. For DAS-4102 boards use the K_SetChn function to specify the channel. For DAS-4101 boards you can only acquire off channel 0. Use K_SetG function to specify the gain code. Refer to the next section for the various input ranges available.

Analog Input Operations 2-7

Acquiring Samples from Both Channels

With DAS-4102 boards, you can acquire samples from both channels at once. Use K_SetStartStopChn to specify channel 0 as the start channel and channel 1 as the stop channel. The samples are gathered simultaneously from both channels, but channel 0 is placed in the buffer ﬁrst before channel 1. Use K_SetG function to specify the gain code for both channels. Refer to T able 2-3 on page 2-9 for the v arious input ranges available.

Acquiring Samples Using a Channel-Gain Queue

With DAS-4102 boards, you can acquire samples from both channels with different gain settings, using a channel-gain queue. In the channel-gain queue, you specify the gain for channel 0 and channel 1.

Input Ranges

Channel 0 must be the ﬁrst in the queue and channel 1 must be the other channel in the list. The samples will be copied to the buffer in this order, although they are acquired simultaneously.

The way that you specify the channel and gains in a channel-gain queue depends on the language you are using. Refer to Chapter 4 for information on programming the various drivers.

After you create the channel-gain queue in your program, use the

K_SetChnGAry function to transfer the contents of the channel-gain

queue to the driver/board.

Each channel on the DAS-4100 Series board can measure signals in one of 16, software-selectable bipolar analog input ranges.

Table 2-3 lists the analog input ranges supported by DAS-4100 Series boards and the gain code associated with each range. Use the K_SetG function to specify the gain code. For the ±125 mV, ±250 mV , and ±0.5 V analog input ranges, the choice of gain code affects the bandwidth; refer to Appendix C of the DAS-4100 Series User’s Guide for more information.

2-8 Available Operations

Table 2-3. Analog Input Ranges

Pacer Clocks

Analog Input Range

±100 mV 12 ±800 mV 15 ±125 mV 8 ±1 V 5, 11 ±250 mV 4 ±1.25 V 6 ±400 mV 13 ±2 V 1, 7 ±500 mV 0, 9, 14 ±2.5 V 2 ±625 mV 10 ±4.0 V 3

Gain Code

Analog Input Range

Gain Code

The pacer clock determines the period between A/D conversions. Use the

K_SetClk function to specify an internal or an external pacer clock. The

internal pacer clock is the default pacer clock.

The internal and external pacer clocks are described in the following subsections; refer to the DAS-4100 Series User’s Guide for more information.

Internal Pacer Clock

When you start an analog input operation (using K_IntStart ), conversions are performed at a rate of 16.384 Gsamples/s divided by a count value of 256, 512, 1024, 2048, 4096, 8192, 16384 or 32768. Use the K_SetClkRate function to specify the count value. Each count represents .0610351 ns between conversions.

Table 2-4 lists the conversion rates, sample periods, and count values for the internal pacer clock.

Analog Input Operations 2-9

Table 2-4. Available Conversion Rates Using Internal Clock

Note:

Sample

Conversion Rate

64 Msamples/s 15.625 ns 256 32 Msamples/s 31.25 ns 512 16 Msamples/s 62.5 ns 1024 8 Msamples/s 125 ns 2048 4 Msamples/s 250 ns 4096 2 Msamples/s 500 ns 8192 1 Msamples/s 1 µ s 16384 500 Ksamples/s 2 µ s 32768

Period

If you enter a count value that is not one of those listed in

Count Value

Table 2-4, the driver uses the next fastest rate. For example, if you enter a count value of 550, the driver uses a count value of 512 to perform the faster conversion rate. To determine the actual count value used, use the

K_GetClkRate function.

External Pacer Clock

When you start an analog input operation (using K_IntStart ), conversions are armed. At the next rising edge of the external pacer clock (and at every subsequent rising edge of the external pacer clock), a conversion is initiated.

Note:

using an external pacer clock or sample accuracy will not be guaranteed.

2-10 Available Operations

Do not use a conversion rate greater than 64 Msamples/s when

Triggers

The conversion rate divisor, as set by K_SetClkRate , still has an effect, with a conversion rate divisor of 256 producing the base rate speciﬁed by the input clock frequency. Conversion rate divisors must go by powers of two (for instance, 128, 256, 512, 1024) with lower divisors producing higher conversion rates and higher divisors producing lower conversion rates. Each doubling of the divisor has the net effect of halving the effective digitization rate. Conversely, halving the divisor doubles the effective digitization rate.

A trigger is an event that occurs based on a speciﬁed set of conditions. The operation must have a start trigger that determines when the acquisition starts. In addition, you can choose the optional about trigger to determine when the acquisition stops.

Trigger Sources

You can deﬁne operations that acquire data after the trigger event occurs (post-trigger acquisition), operations that acquire data before a trigger event (pre-trigger acquisition), and operations that acquire data before and after a trigger event (about-trigger acquisition). For post-trigger acquisitions, you can also specify a post-trigger delay. If you specify an about trigger, the operation stops when a speciﬁed number of samples has been acquired after the occurrence of the about-trigger event.

When the trigger event occurs, a TTL-le v el signal is output on the Trigger I/O connector. The signal is edge-sensitive with a positive polarity.

The following sections describe the supported trigger sources and the ways to acquire data using triggers.

Use K_SetTrig to specify an internal or an external trigger source. External triggers can be either analog triggers or digital triggers. The trigger event is not signiﬁcant until the operation the trigger governs has been started (using K_IntStart ).

The internal trigger, external analog trigger, and external digital trigger are described in the following subsections.

Analog Input Operations 2-11

Internal T rigger

An internal trigger is a software trigger. The trigger event occurs when you start the operation using the K_IntStart function. Note that there is a slight delay between the time you start the operation and the time the trigger event occurs. The internal trigger is the default trigger source.

External Analog Trigger

You can select the digitized analog input signal from the Channel A connector (referred to in software as analog trigger channel 0) and/or (with the DAS-4102 board) from the Channel B connector (referred to in software as analog trigger channel 1). You program the trigger level as a count value in 256 steps (

−

128 to +127) from

−

4 V to +3.96 V.

You can also select the ±16 V trigger input signal from the Analog T rigger In connector (referred to in software as analog trigger channel 2) as the trigger signal. You program the trigger level as a count value in 256 steps (

128 to +127) from

−

16 V to +15.875 V. If you use analog trigger

−

channel 2, you can acquire analog input data from either the Channel A connector or from the Channel B connector or both.

The trigger conditions for external analog triggers are illustrated in Figure 2-1 and described as follows:

● Positiv e-Edge Trigger - A trigger event occurs the ﬁrst time the

trigger signal changes from a voltage that is less than the trigger level to a voltage that is greater than the trigger level.

● Negative-Edge Trigger - A trigger event occurs the ﬁrst time the

trigger signal changes from a voltage that is greater than the trigger level to a voltage that is less than the trigger level.

2-12 Available Operations

Level + 5 V

0 V

Negative-edge

Positive-edge trigger occurs

trigger occurs

Analog input operation start function is executed

Figure 2-1. Analog Trigger Conditions

Use the K_SetADT rig function to specify the analog input channel to use as the trigger channel, the trigger level, and the trigger polarity. The trigger sensitivity is always edge for the DAS-4100 Series board.

Refer to Appendix B for information on how to convert a voltage to a count value.

External Digital Trigger

The digital trigger signal is connected to the Trigger I/O connector of the DAS-4100 Series board. Use K_SetDITrig to specify the digital input channel to use as the trigger channel and whether you want the trigger event to occur on the rising edge of the digital trigger signal (positive-edge trigger) or on a falling edge of the digital trigger signal (negative-edge trigger). The trigger sensitivity is always edge for DAS-4100 Series boards. The trigger events are illustrated in Figure 2-2.

Analog Input Operations 2-13

Trigger Acquisition

The ways you can acquire data using triggers are described in the following subsections.

Post-Trigger Acquisition

Use post-trigger acquisition in applications where you want to collect data after a speciﬁc trigger event. You specify a start trigger only; the start trigger determines when the operation starts and can be either an internal, an external analog, or an external digital trigger. To stop the operation, use the K_IntStop function. If desired, you can specify the number of samples to wait between when the trigger event occurs and when the data is collected by using the K_SetPostTrigDelay function.

Negative-edge

trigger event occurs Positive-edge trigger event occurs

Trigger signal

Figure 2-2. Digital Trigger Conditions

The post-trigger delay can range from 0 to 8,388,608 samples.

To specify post-trigger acquisition, perform the following steps:

1. Specify the start trigger.

– Use K_SetTrig to specify an internal or an external trigger

source (specify external for an analog or digital trigger).

– If you specify an external start trigger in K_SetTrig, deﬁne the

start trigger conditions using K_SetADTrig (for an analog trigger) or K_SetDITrig (for a digital trigger).

2-14 Available Operations

2. If you speciﬁed an external analog or digital start trigger, use

K_ClrAboutTrig to disable the about trigger.

3. To specify the number of post-trigger samples to wait after the trigger

event occurs and before data is collected, use K_SetPostTrigDelay.

Pre-Trigger Acquisition

Use pre-trigger acquisition in applications where you want to collect data before a speciﬁc trigger event. The start trigger is always an internal trigger; the operation starts when your application program calls the K_IntStart function. The about trigger can be either an external analog or external digital trigger; the operation stops when the about-trigger event occurs.

Note: The implied number of pre-trigger samples must be acquired

before the board can accept a trigger event. A trigger that comes before all implied pre-trigger samples are acquired is ignored.

To specify pre-trigger acquisition, perform the following steps:

1. Use K_SetTrig to specify an internal start trigger source.

2. Use K_SetAboutTrig to enable the about trigger and to set the

number of samples to 1.

Note: The minimum number of samples that you can specify in

K_SetAboutTrig is 1.

3. Specify the trigger conditions for the about trigger. – If the about trigger is an external analog trigger, use

K_SetADTrig to specify the trigger conditions for the about trigger.

– If the about trigger is an external digital trigger, use K_SetDIT rig

to specify the trigger conditions for the about trigger.

Analog Input Operations 2-15

About-Trigger Acquisition

Use about-trigger acquisition in applications where you want to collect data both before and after a speciﬁc trigger event. The start trigger is always an internal trigger; the operation starts when your application program calls the K_IntStart function. The about trigger can be either an external analog or external digital trigger; the operation stops after a speciﬁed number of samples has been acquired after the about-trigger event occurs.

Note: The implied number of pre-trigger samples must be acquired

before the board can accept a trigger event. A trigger that comes before all implied pre-trigger samples are acquired is ignored.

To specify about-trigger acquisition, perform the following steps:

1. Use K_SetTrig to specify an internal start trigger source.

2. Use K_SetAboutTrig to enable the about trigger and to specify the desired number of post-trigger samples.

3. Specify the trigger conditions for the about trigger. – If the about trigger is an external analog trigger, use

K_SetADTrig to specify the trigger conditions for the about trigger.

– If the about trigger is an external digital trigger, use K_SetDIT rig

to specify the trigger conditions for the about trigger.

2-16 Available Operations

Programming with

the Function Call Driver

This chapter contains an overview of the structure of the DAS-4100 Series Function Call Driver, as well as programming guidelines and language-speciﬁc information to assist you when writing application programs with the DAS-4100 Series Function Call Driver.

How the Driver Works

When writing application programs, you can use functions from one or more Keithley MetraByte DAS Function Call Drivers. You initialize each driver according to a particular conﬁguration ﬁle. If you are using more than one driver or more than one conﬁguration ﬁle with a single driver, the driver handle uniquely identiﬁes each driver or each use of the driver.

You can program one or more boards in your application program. You initialize each board using a device handle to uniquely identify each board. Each device handle is associated with a particular driver.

The driver uses frames to perform operations. A frame is a data structure whose elements deﬁne the attributes of the operation. Each frame is associated with a particular board, and therefore, with a particular driver.

Frames help you create structured application programs. You set up the attributes of the operation in advance, using a separate function call for each attribute, and then start the operation at an appropriate point in your program. Frames are useful for operations that have many deﬁning attributes, since providing a separate argument for each attribute could make a function’s argument list unmanageably long.

How the Driver Works 3-1

You indicate that you want to perform an analog input operation by getting an available frame for the driver. The DAS-4100 Series Function Call Driver provides analog input frames, called A/D (analog-to-digital) frames. You use the K_GetADFrame function to access an available A/D frame. The driver returns a unique identiﬁer for the frame; this name is called the frame handle.

You then specify the attributes of the operation by using setup functions to deﬁne the elements of the frame associated with the operation. For example, to specify the channel on which to perform an analog input operation, you would use the K_SetChn setup function.

You use the frame handle you speciﬁed when accessing the frame in all setup functions and other functions related to the operation. This ensures that you are deﬁning the same operation.

When you are ready to perform the operation you have set up, you can start the operation by referencing the appropriate frame handle. Figure 3-1 illustrates the syntax of the interrupt-mode operation function

K_IntStart .

K_IntStart (frameHandle)

Frame

Channel Clock Source Trigger Source . . .

Figure 3-1. Interrupt-Mode Operation

Attributes of Operation

Analog input channel Pacer clock source Trigger source . . .

3-2 Programming with the Function Call Driver

If you want to perform an interrupt-mode operation and all frames have been accessed, you can use the K_FreeFrame function to free a frame that is no longer in use. You can then redeﬁne the elements of the frame for the next operation.

When you access a frame, the elements are set to their default values. You can also use the K_ClearFrame function to reset all the elements of a frame to their default values.

Table 3-1 lists the elements of a DAS-4100 Series A/D frame. This table also lists the default value of each element and the setup function used to deﬁne each element.

Table 3-1. A/D Frame Elements

Element Default Value Setup Function

Buffer Number of Samples 0 K_SetBuf Start and Stop

Channel Channel-Gain

Queue Input range 0 (±200 mV) K_SetG Clock Source Internal A/D pacer

Pacer Clock Rate 0 K_SetClkRate Trigger Source Internal K_SetTrig Trigger Type Digital K_SetADTrig

Trigger Channel 0 (for analog trigger) K_SetADTrig

Trigger Polarity Positive K_SetADTrig

0 (NULL) K_SetBuf

0 K_SetChn

K_SetStartStopChn

0(NULL) K_SetChnGAry

K_SetClk

clock

K_SetDITrig

0 (for digital trigger) Not applicable

K_SetDITrig

How the Driver Works 3-3

Table 3-1. A/D Frame Elements (cont.)

Element Default Value Setup Function

Trigger Sensitivity Edge (for analog) Not applicable

Edge (for digital) Not applicable Trigger Level 0 K_SetADTrig About-Trigger

Acquisition Post-Trigger Delay 0 K_SetPostTrigDelay

Notes

This element must be set.

The default value of this element cannot be changed.

Use this function to reset the value of this particular frame element to its

default setting without clearing the frame or getting a new frame. Whenever you clear a frame or get a new frame, this frame element is set to its default value automatically.

Note:

The DAS-4100 Series Function Call Driver provides many other

Disabled K_SetAboutTrig

K_ClrAboutTrig

functions that are not related to controlling frames or deﬁning the elements of frames. These functions include initialization functions, memory management functions, and miscellaneous functions.

For information about using the FCD functions in your application program, refer to the following sections of this chapter. For detailed information about the syntax of FCD functions, refer to Chapter 4.

Programming Overview

To write an application program using the DAS-4100 Series Function Call Driver, perform the following steps:

1. Deﬁne the application's requirements. Refer to Chapter 2 for a description of the board operations supported by the Function Call Driver and the functions that you can use to deﬁne each operation.

3-4 Programming with the Function Call Driver

2. Write your application program. Refer to the following for additional information:

– Preliminary Tasks, the next section, which describes the

programming tasks that are common to all application programs.

– Analog Input Programming Tasks on page 3-6, which describes

operation-speciﬁc programming tasks and the sequence in which these tasks must be performed.

– Chapter 4, which contains detailed descriptions of the FCD

functions.

– The example programs in the ASO-4100 software package. The

FILES.TXT ﬁle in the installation directory lists and describes the example programs.

3. Compile and link the program. Refer to the language-specific programming information (page 3-12 to page 3-16 for C/C++ or page 3-16 for Visual Basic for Windows), or to the EXAMPLES.TXT file in the installation directory for compile and link statements and other language-specific considerations for each supported language.

Preliminary Tasks

For every Function Call Driver application program, you must perform the following preliminary tasks:

1. Include the function and variable type deﬁnition ﬁle for your language. This ﬁle is included in the ASO-4100 software package.

2. Declare and initialize program variables.

3. Use K_OpenDriver to initialize the driver.

4. Use K_GetDevHandle to specify the board you want to use and to initialize the board. If you are using more than one board, use the board initialization function once for each board you are using.

After completing the preliminary tasks, perform the analog input programming tasks described in the following section.

Preliminary Tasks 3-5

Analog Input Programming Tasks

For an interrupt-mode analog input operation, perform the following tasks:

1. Use the K_GetADFrame function to access an A/D frame.

2. Dimension a local array within your program’s memory area or use the K_IntAlloc function to allocate a buffer dynamically outside your program's memory area.

3. If you are programming in Visual Basic for Windows and are using a

local array , use the K_SetBufI function to assign the starting address

of the array and to specify the number of samples in the array.

Otherwise , use the K_SetBuf function to assign the starting address

of the array or buffer and to specify the number of samples in the array or buffer.

4. Use the appropriate setup functions to specify the attributes of the operation. The setup functions are listed in Table 3-2.

Note:

When you access a new A/D frame, the frame elements contain default values. If the default value of a particular element is suitable for your operation, you do not have to use the setup function associated with that element. Refer to Table 3-1 on page 3-3 for a list of the default values of A/D frame elements.

Table 3-2. Setup Functions for Interrupt-Mode

Analog Input Operations

Attribute Setup Function(s)

Channel K_SetChn

K_SetStartStopChn Input Range K_SetG Channel-Gain Queue K_SetChnGAry Clock Source K_SetClk

3-6 Programming with the Function Call Driver

Table 3-2. Setup Functions for Interrupt-Mode

Analog Input Operations (cont.)

Attribute Setup Function(s)

Pacer Clock Rate Trigger Source K_SetTrig Trigger Type K_SetADTrig

Trigger Channel K_SetADTrig

Trigger Polarity K_SetADTrig

Trigger Level K_SetADTrig About-Trigger

Acquisition Post-Trigger Delay K_SetPostTrigDelay

K_SetClkRate

K_SetDITrig

K_SetAboutTrig

K_ClrAboutTrig

Refer to Chapter 2 for background information about the setup functions; refer to Chapter 4 for detailed descriptions of the setup functions.

5. Use the K_IntStart function to start the interrupt-mode operation.

6. Use the K_IntStatus function to monitor the status of the interrupt-mode operation.

7. Use the K_IntStop function to stop the interrupt-mode operation when the appropriate number of samples has been acquired.

8. If you are programming in Visual Basic for Windows and you are

using a dynamically allocated memory buffer , use the

K_MoveBufToArray function to transfer the acquired data from the

allocated buffer to a local array that your program can use.

9. If you used a dynamically allocated memory buffer , use the

K_IntFree function to free the memory.

Analog Input Programming Tasks 3-7

C/C++ Programming Information

The following sections contain information you need to dimension an array or dynamically allocate a memory buffer when programming in C or C++, as well as language-speciﬁc information for Microsoft C/C++ and Borland C/C++ for DOS and Windows.

When programming in C/C++, proper typecasting may be required

Note:

to avoid C/C++ type-mismatch warnings. Make sure that linker options are set so that case-sensitivity is disabled.

Dimensioning and Assigning a Local Array

You can use a single, local array for an interrupt-mode analog input operation. The following code fragment illustrates how to dimension an array of 8,192 samples for the frame deﬁned by hFrame and how to use

K_SetBuf to assign the starting address of the array.

. . . int Data[8192]; //Dimension array of 8,192 samples . . . wDasErr = K_SetBuf (hFrame, Data, 8192); . . .

Refer to the example programs on disk for more information.

3-8 Programming with the Function Call Driver

Dynamically Allocating and Assigning a Memory Buffer

This section provides code fragments that describe how to dynamically allocate and assign a memory buffer when programming in C or C++ and how to access the data in the buffer. Refer to the example programs on disk for more information.

Note:

If you are programming in Windows Enhanced mode, you may be limited in the amount of memory you can allocate. It is recommended that you install the Keithley Memory Manager before you begin programming to ensure that you can allocate a large enough buffer; refer to the

DAS-4100 Series User’s Guide for more information.

Allocating a Memory Buffer

You can use a single, dynamically allocated memory buffer for an interrupt-mode analog input operation. The following code fragment illustrates how to use K_IntAlloc to allocate a buffer of size Samples for the frame deﬁned by hFrame and how to use K_SetBuf to assign the starting address of the buffer.

. . . void far *AcqBuf; //Declare pointer to buffer WORD hMem; //Declare word for memory handle . . . wDasErr = K_IntAlloc (hFrame, Samples, &AcqBuf, &hMem); wDasErr = K_SetBuf (hFrame, AcqBuf, Samples); . . .

The following code illustrates how to use K_IntFree to later free the allocated buffer, using the memory handle stored by K_IntAlloc .

. . . wDasErr = K_IntFree (hMem); . . .

C/C++ Programming Information 3-9

Accessing the Data

You access the data stored in a dynamically allocated buffer through C/C++ pointer indirection. For example, assume that you want to display the ﬁrst 10 samples of the buffer described in the previous section (AcqBuf). The following code fragment illustrates how to access and display the data.

. . . int huge *pData; //Declare a pointer called pData . . . pData = (int huge *) AcqBuf; //Assign pData to buffer for (i = 0; i < 10; i++)

printf ("Sample #%d %X", i, *(pData+i));

. . .

Note:

Declaring pData as a huge pointer allows the program to directly access all data within the computer’s memory buffer, regardless of the buffer size.

Creating a Channel-Gain Queue

The DASDECL.H and DASDECL.HPP ﬁle deﬁne a special data type (GainChanTable) that you can use to declare your channel-gain queue. GainChanTable is deﬁned as follows:

typedef struct GainChanTable {

WORD num_of_codes; struct {

BYTE Chan; chan Gain;

} GainChanAry[256];

} GainChanTable;

The following example illustrates how to create a channel-gain queue called MyChanGainQueue for a DAS-4100 board by declaring and initializing a variable of type GainChanTable.

3-10 Programming with the Function Call Driver

GainChanTable MyChanGainQueue = {

2, // number of entries

0, 7 // Channel 0, gain of 7 1, 3 // Channel 1, gain of 3 };

After you create MyChanGainQueue, you must assign the starting address of MyChanGainQueue to the frame deﬁned by hFrame, as follows:

wDasErr = K_SetChnGAry (hFrame, &MyChanGainQueue);

When you start the next analog input operation (using K_IntStart ), channel 0 is sampled at a gain of 7, and channel 1is sampled at a gain of

Handling Errors

It is recommended that you always check the returned value (wDasErr in the previous examples) for possible errors. The following code fragment illustrates how to check the returned value of the K_GetDevHandle function.

. . . if ((wDASErr = K_GetDevHandle (hDrv, BoardNum, &hDev)) ! = 0) { printf (“Error %X during K_GetDevHandle”, wDASErr); exit (1); } . . .

The following code fragment illustrates how to use the K_GetErrMsg function to access the string corresponding to an error code.

. . . if ((wDasErr = K_SetChn (hAD, 0) ! = 0)

{ Error = K_GetErrMsg (hDev, wDasErr, &pMessage); printf (“%s”, pMessage); exit (1); }

C/C++ Programming Information 3-11

Programming in Microsoft C/C++ (for DOS)

To program in Microsoft C/C++ (for DOS), you need the following ﬁles; these ﬁles are provided in the ASO-4100 software package.

File Description

DAS4100.LIB Linkable driver DASRFACE.LIB Linkable driver DASDECL.H Include ﬁle when compiling in C DASDECL.HPP Include ﬁle when compiling in C++ USE4100.OBJ Linkable object

To create an executable ﬁle in Microsoft C/C++ (for DOS), use the following compile and link statements. Note that ﬁlename indicates the name of your application program.

Type of Compile Compile and Link Statements

C CL /c ﬁlename .c

LINK ﬁlename+use4100.obj,,,das4100+dasrface;

C++ CL /c ﬁlename.cpp

LINK ﬁlename+use4100.obj,,,das4100+dasrface;

Notes

These statements assume a large memory model; in DOS, only the large

memory model is acceptable.

3-12 Programming with the Function Call Driver

Programming in Microsoft C/C++ (for Windows)

To program in Microsoft C/C++ (for Windows), including Microsoft Visual C++, you need the following ﬁles; these ﬁles are provided in the ASO-4100 software package.

File Description

DASSHELL.DLL Dynamic Link Library DASSUPRT.DLL Dynamic Link Library DAS4100.DLL Dynamic Link Library DASDECL.H Include ﬁle when compiling in C DASDECL.HPP Include ﬁle when compiling in C++ DASIMP.LIB DAS Shell Imports

To create an executable ﬁle in Microsoft C/C++ (for Windows), use the following compile and link statements. Note that ﬁlename indicates the name of your application program.

Type of Compile Compile and Link Statements

C CL /c ﬁlename.c

LINK ﬁlename,,,dasimp, ﬁlename.def; RC -r ﬁlename.rc RC ﬁlename.res

C++ CL /c ﬁlename.cpp

LINK ﬁlename,,,dasimp, ﬁlename.def; RC -r ﬁlename.rc RC ﬁlename.res

C/C++ Programming Information 3-13

To create an executable ﬁle in the Microsoft C/C++ (for Windows) environment, perform the following steps:

1. Create a project ﬁle by choosing New from the Project menu.

2. Add all necessary ﬁles to the project make ﬁle by choosing Edit from

the Project menu. Make sure that you include ﬁlename.c (or

ﬁlename.cpp), ﬁlename.rc, ﬁlename.def, and DASIMP.LIB, where

ﬁlename indicates the name of your application program.

3. From the Project menu, choose Rebuild All FILENAME.EXE to

create a stand-alone executable ﬁle (.EXE) that you can execute from

within Windo ws.

Programming in Borland C/C++ (for DOS)

To program in Borland C/C++ (for DOS), you need the following ﬁles; these ﬁles are provided in the ASO-4100 software package.

File Description

DAS4100.LIB Linkable driver DASRFACE.LIB Linkable driver DASDECL.H Include ﬁle when compiling in C DASDECL.HPP Include ﬁle when compiling in C++ USE4100.OBJ Linkable object

To create an executable ﬁle in Borland C/C++ (for DOS), use the following compile and link statements. Note that ﬁlename indicates the name of your application program.

Type of Compile Compile and Link Statements

C BCC ﬁlename.c use4100.obj das4100.lib dasrface.lib C++ BCC ﬁlename.cpp use4100.obj das4100.lib dasrface.lib

Notes

These statements assume a large memory model; in DOS, only the large

memory model is acceptable.

3-14 Programming with the Function Call Driver

Programming in Borland C/C++ (for Windows)

To program in Borland C/C++ (for Windows), you need the following ﬁles; these ﬁles are provided in the ASO-4100 software package.

File Description

To create an executable ﬁle in Borland C/C++ (for Windows), use the following compile and link statements. Note that ﬁlename indicates the name of your application program.

Type of Compile Compile and Link Statements

C BCC -c ﬁlename.c

TLINK ﬁlename,,,dasimp, ﬁlename.def; BRC -r ﬁlename.rc BRC ﬁlename.res

C++ BCC -c ﬁlename.cpp

TLINK ﬁlename,,,dasimp, ﬁlename.def; BRC -r ﬁlename.rc BRC ﬁlename.res

To create an executable ﬁle in the Borland C/C++ (for Windows) environment, perform the following steps:

1. Create a project ﬁle by choosing New from the Project menu.

2. Inside the Project window, select the project name and click on the

right mouse button.

3. Select the Add node option and add all necessary ﬁles to the project

make ﬁle. Make sure that you include ﬁlename.c (or ﬁlename.cpp),

ﬁlename.rc, ﬁlename.def, and D ASIMP.LIB, where ﬁlename indicates

the name of your application program.

C/C++ Programming Information 3-15

4. From the Options menu, select Project.

5. From the Project Options dialog box, select Linker\General and make

sure that you turn OFF both the Case sensitive link and Case sensiti ve

exports and imports options.

6. From the Project menu, choose Build All to create a stand-alone

executable ﬁle (.EXE) that you can execute from within Windows.

Microsoft Visual Basic for Windows Programming Information

The following sections contain information you need to dimension an array or dynamically allocate a memory buffer when programming in Microsoft Visual Basic for Windows, as well as language-speciﬁc information for Microsoft Visual Basic for Windows.

Dimensioning and Assigning a Local Array

You can use a single, local array for an interrupt-mode analog input operation. The following code fragment illustrates how to dimension an array of 8K samples for the frame deﬁned by hFrame and how to use K_SetBufI to assign the starting address of the array.

. . .

Global Data(8191) As Integer ’ Allocate array

. . .

wDasErr = K_SetBufI (hFrame, Data(0), 8192)

. . .

Refer to the example programs on disk for more information.

3-16 Programming with the Function Call Driver

Dynamically Allocating and Assigning a Memory Buffer

This section provides code fragments that describe how to dynamically allocate and assign a memory buffer and how to access the data in the buffer when programming in Microsoft Visual Basic for Windows. Refer to the example programs on disk for more information.

Note: If you are programming in Windows Enhanced mode, you may be

limited in the amount of memory you can allocate. It is recommended that you use the Keithley Memory Manager before you begin programming to ensure that you can allocate a large enough buffer. Refer to your DAS-4100 Series User’s Guide for more information.

Allocating a Memory Buffer

. . . Global AcqBuf As Long ’ Declare pointer to buffer Global hMem As Integer ’ Declare integer for memory handle . . . wDasErr = K_IntAlloc (hFrame, Samples, AcqBuf, hMem) wDasErr = K_SetBuf (hFrame, AcqBuf, Samples) . . .

The following code illustrates how to use K_IntFree to later free the allocated buffer, using the memory handle stored by K_IntAlloc.

. . .

wDasErr = K_IntFree (hMem)

. . .

Microsoft Visual Basic for Windows Programming Information 3-17

Accessing the Data

In Microsoft Visual Basic for Windo ws, you cannot directly access analog input samples stored in a dynamically allocated memory buffer. You must use K_MoveBufToArray to move a subset (up to 32,766 samples) of the data into a local array as required. The following code fragment illustrates how to move 100 samples from the buffer described in the previous section (AcqBuf) to a local array.

. . . Dim Buffer(1000) As Integer ’ Declare local array . . . wDasErr = K_MoveBufToArray (Buffer(0), AcqBuf, 100) . . .

Creating a Channel-Gain Queue

Before you create your channel-gain queue, you must declare an array of integers to accommodate the required number of entries. Next, you ﬁll the array with the channel-gain information. After you create the channel-gain queue, use K_FormatChnGAry to reformat the channel-gain queue so that it can be used by the DAS-4100 Series Function Call Driver.

The following code fragment illustrates how to create a two-entry channel-gain queue called MyChanGainQueue for a DAS-4100 board and how to use K_SetChnGAry to assign the starting address of MyChanGainQueue to the frame deﬁned by hFrame.

. . . Global MyChanGainQueue(5) As Integer . . . MyChanGainQueue(0) = 2 ’ Number of channel-gain pairs MyChanGainQueue(1) = 0 ’ Channel 0 MyChanGainQueue(2) = 7 ’ Use gain of 7 on channel 0 MyChanGainQueue(3) = 1 ’ Channel 1 MyChanGainQueue(4) = 3 ’ Use gain of 3 on channel 1 . . . wDasErr = K_FormatChnGAry (MyChanGainQueue(0)) wDasErr = K_SetChnGAry (hFrame, MyChanGainQueue(0))

3-18 Programming with the Function Call Driver

Once the channel-gain queue is formatted, your Visual Basic for Windo ws program can no longer read it. To read of modify the array after it has been formatted, you must use K_RestoreChnGAry as follows:

When you start the next analog input operation (using K_IntStart), channel 0 is sampled at a gain of 7, and channel 1 is sampled at a gain of

Handling Errors

. . . wDASErr = K_GetDevHandle (hDrv, BoardNum, hDev) If (wDASErr <> 0) Then

MsgBox “K_GetDevHandle Error: ” + Hex$ (wDASErr),

MB_ICONSTOP, “DAS-4100 SERIES ERROR”

End End If . . .

. . . wDasErr = K_RestoreChnGAry (MyChannelGainQueue(0)) . . .

Microsoft Visual Basic for Windows Programming Information 3-19

Programming in Microsoft Visual Basic for Windows

To program in Microsoft Visual Basic for Windows, you need the following ﬁles; these ﬁles are provided in the ASO-4100 software package.

File Description

DASSHELL.DLL Dynamic Link Library DASSUPRT.DLL Dynamic Link Library DAS4100.DLL Dynamic Link Library DASDECL.BAS Include ﬁle; must be added to the project

To create an executable ﬁle from the Microsoft Visual Basic for Windows environment, choose Make EXE File from the File menu.

3-20 Programming with the Function Call Driver

Function Reference

The FCD functions are organized into the following groups:

Initialization functions

●

Operation functions

●

Frame management functions Memory management functions

●

Buffer address functions

●

Channel and gain functions

●

Clock functions Trigger functions

●

Miscellaneous functions

●

The particular functions associated with each function group are presented in Table 4-1. The remainder of the chapter presents detailed descriptions of all the FCD functions, arranged in alphabetical order.

. 4-1

Table 4-1. Functions

Function Type Function Name Page Number

Initialization K_OpenDriver page 4-31

K_CloseDriver page 4-6 K_GetDevHandle page 4-16 K_FreeDevHandle page 4-10 K_DASDevInit page 4-8

Operation K_IntStart page 4-25

K_IntStatus page 4-26 K_IntStop page 4-28

Frame Management K_GetADFrame page 4-12

K_FreeFrame page 4-11 K_ClearFrame page 4-5

Memory Management K_IntAlloc page 4-22

K_IntFree page 4-24 K_MoveBufToArray page 4-30

Buffer Address K_SetBuf page 4-38

K_SetBufI page 4-40

Channel and Gain K_SetChn page 4-42

K_SetStartStopChn page 4-53 K_SetChnGAry page 4-43 K_FormatChnGAry page 4-9 K_RestoreChnGAry page 4-33 K_SetG page 4-50

Clock K_SetClk page 4-45

K_SetClkRate page 4-46 K_GetClkRate page 4-14

4-2 Function Reference

Table 4-1. Functions (cont.)

Function Type Function Name Page Number

Trigger K_SetTrig page 4-54

K_SetADTrig page 4-36 K_SetDITrig page 4-48 K_SetAboutTrig page 4-34 K_ClrAboutTrig page 4-7 K_SetPostTrigDelay page 4-52

Miscellaneous K_GetErrMsg page 4-18

K_GetVer page 4-20 K_GetShellVer page 4-19

Keep the following conventions in mind throughout this chapter:

●

The data types DWORD, WORD, and BYTE are deﬁned in the language-speciﬁc include ﬁles.

●

Variable names are shown in italics. The return value for all DAS-4100 Series FCD functions is the

●

error/status code. A value of 0 indicates that the function executed successfully . A non-zero value indicates that an error occurred. Refer to Appendix A for more information.

The description shows the prototype for the function.

●

In the Usage section, the variables are not deﬁned. It is assumed that

●

the variables are deﬁned as shown in the prototype.

The name of each function argument in the Prototype and Usage sections includes a prefix that indicates the associated data type. These prefixes are described in Table 4-2.

. 4-3

Table 4-2. Data Type Preﬁxes

Preﬁx Data T ype Comments

sz Pointer to string terminated by

zero

h Handle to device, frame, and

memory block

ph Pointer to a handle-type variable This data type is used when calling the FCD functions

p Pointer to a variable This data type is used for pointers to all types of

n Number value This data type is used when passing a number,

w 16-bit word This data type is typically used when passing an

a Array This data type is typically used in conjunction with

This data type is typically used for variables that specify the driver's conﬁguration ﬁle name.

This data type is used for handle-type variables. You declare handle-type variables in your program as long or DWORD, depending on the language you are using. The actual variable is passed to the driver by value.

to get a device handle, a driver handle, a frame handle, or a memory handle. The actual variable is passed to the driver by reference.

variables, except handles (h). It is typically used when passing a parameter of any type to the driver by reference.

typically a byte, to the driver by value.

unsigned integer to the driver by value.

other preﬁxes listed here; for example, anVar denotes an array of numbers.

f Float This data type denotes a single-precision ﬂoating-point

number.

d Double This data type denotes a double-precision

ﬂoating-point number.

dw 32-bit double word This data type is typically used when passing an

unsigned long to the driver by value.

4-4 Function Reference

K_ClearFrame

Purpose

Prototype C/C++

Sets the elements of a frame to their default values.

DASErr far pascal K_ClearFrame (DWORD hFrame );

Visual Basic for Windows

Declare Function K_ClearFrame Lib "DASSHELL.DLL" (ByVal hFrame As Long) As Integer

Parameters

Return Value

Remarks

hFrame

Error/status code. Refer to Appendix A.

This function sets the elements of the frame speciﬁed by hFrame to their default values.

Refer to T able 3-1 on page 3-3 for the def ault v alues of the elements of an A/D frame.

See Also

Usage C/C++

K_GetADFrame

#include "DASDECL.H" // Use "DASDECL.HPP for C++ ... wDasErr = K_ClearFrame (hAD);

Handle to the frame that deﬁnes the operation.

Visual Basic for Windows

(Add DASDECL.BAS to your project)

... wDasErr = K_ClearFrame (hAD)

4-5

K_CloseDriver

Purpose

Prototype C/C++

Closes a previously initialized Keithley DAS Function Call Driver.

DASErr far pascal K_CloseDriver (DWORD hDrv );

Visual Basic for Windows

Declare Function K_CloseDriver Lib "DASSHELL.DLL" (ByVal hDrv As Long) As Integer

Parameters

Return Value

Remarks

hDrv

Error/status code. Refer to Appendix A.

This function frees the driver handle speciﬁed by hDrv and closes the associated use of the Function Call Driver. This function also frees all device handles and frame handles associated with hDrv .

If hDrv is the last driver handle speciﬁed for the Function Call Dri v er, the driver is shut down (for all languages) and unloaded (for Windows-based languages only).

See Also

K_FreeDevHandle

Driver handle you want to free.

Usage C/C++

#include "DASDECL.H" // Use "DASDECL.HPP for C++ ... wDasErr = K_CloseDriver (hDrv);

Visual Basic for Windows

(Add DASDECL.BAS to your project)

... wDasErr = K_CloseDriver (hDrv)

4-6 Function Reference

K_ClrAboutTrig

Purpose

Prototype C/C++

Disables the about trigger for an analog input operation.

DASErr far pascal K_ClrAboutTrig (DWORD hFrame );

Visual Basic for Windows

Declare Function K_ClrAboutTrig Lib "DASSHELL.DLL" (ByVal hFrame As Long) As Integer

Parameters

Return Value

Remarks

hFrame

Error/status code. Refer to Appendix A.

This function disables the about trigger for the operation deﬁned by

hFrame .

K_GetADFrame and K_ClearFrame also disable the about trigger.

See Also

Usage C/C++

K_ClearFrame, K_GetADFrame, K_SetAboutTrig

#include "DASDECL.H" // Use "DASDECL.HPP for C++ ... wDasErr = K_ClrAboutTrig (hAD);

Handle to the frame that deﬁnes the operation.

Visual Basic for Windows

(Add DASDECL.BAS to your project)

... wDasErr = K_ClrAboutTrig (hAD)

4-7

K_DASDevInit

Purpose

Prototype C/C++

Reinitializes a board.

DASErr far pascal K_DASDevInit (DWORD hDev );

Visual Basic for Windows

Declare Function K_DASDevInit Lib "DASSHELL.DLL" (ByVal hDev As Long) As Integer

Parameters

Return Value

Remarks

hDev

Error/status code. Refer to Appendix A.

This function stops all current operations on the board speciﬁed by hDev and veriﬁes that the board identiﬁed by the device handle is the board speciﬁed in the conﬁguration ﬁle associated with the board.

Usage C/C++

#include "DASDECL.H" // Use "DASDECL.HPP for C++ ... wDasErr = K_DASDevInit (hDev);

Handle associated with the board.

Visual Basic for Windows

(Add DASDECL.BAS to your project)

... wDasErr = K_DASDevInit (hDev)

4-8 Function Reference

K_FormatChnGAry

Purpose

Prototype C/C++

Converts the format of a channel-gain queue.

Not supported

Visual Basic for Windows

Declare Function K_FormatChnGAry Lib "DASSHELL.DLL" ( pArray As Integer) As Integer

Parameters

Return Value

Remarks

pArray

Error/status code. Refer to Appendix A.

This function converts a channel-gain queue created in Visual Basic for Windows using 16-bit values to a channel-gain queue of 8-bit values that the K_SetChnGAry function can use, and stores the starting address of the converted channel-gain queue in pArray .

After you use this function, your program can no longer read the converted queue. You must use the K_RestoreChnGAry function to return the queue to its original format. Refer to page 4-33 for more information.

Channel-gain queue starting address.

See Also

Usage

Visual Basic for Windows

K_SetChnGAry, K_RestoreChnGAry

(Add DASDECL.BAS to your project)

... Global ChanGainArray(16) As Integer ' Chan/Gain array ... ' Create the array of channel/gain pairs ChanGainArray(0) = 2 ' # of chan/gain pairs ChanGainArray(1) = 0: ChanGainArray(2) = 0 ChanGainArray(3) = 1: ChanGainArray(4) = 7 wDasErr = K_FormatChnGAry (ChanGainArray(0))

4-9

K_FreeDevHandle

Purpose

Prototype C/C++

Frees a previously speciﬁed device handle.

DASErr far pascal K_FreeDevHandle (DWORD hDev);

Visual Basic for Windows

Declare Function K_FreeDevHandle Lib "DASSHELL.DLL" (ByVal hDev As Long) As Integer

Parameters

Return Value

Remarks

hDev Device handle you want to free.

Error/status code. Refer to Appendix A.

This function frees the device handle speciﬁed by hDev as well as all frame handles associated with hDev.

See Also

Usage C/C++

K_GetDevHandle

#include "DASDECL.H" // Use "DASDECL.HPP for C++ ... wDasErr = K_FreeDevHandle (hDev);

Visual Basic for Windows

(Add DASDECL.BAS to your project)

... wDasErr = K_FreeDevHandle (hDev)

4-10 Function Reference

K_FreeFrame

Purpose

Prototype C/C++

Frees a frame.

DASErr far pascal K_FreeFrame (DWORD hFrame);

Visual Basic for Windows

Declare Function K_FreeFrame Lib "DASSHELL.DLL" (ByVal hFrame As Long) As Integer

Parameters

Return Value

Remarks

hFr ame Handle to frame you want to free.

Error/status code. Refer to Appendix A.

This function frees the frame speciﬁed by hFrame, making the frame available for another operation.

See Also

Usage C/C++

K_GetADFrame

#include "DASDECL.H" // Use "DASDECL.HPP for C++ ... wDasErr = K_FreeFrame (hAD);

Visual Basic for Windows

(Add DASDECL.BAS to your project)

... wDasErr = K_FreeFrame (hAD)

4-11

K_GetADFrame

Purpose

Prototype C/C++

Accesses an A/D frame for an analog input operation.

DASErr far pascal K_GetADFrame (DWORD hDev, DWORD far * phFrame);

Visual Basic for Windows

Declare Function K_GetADFrame Lib "DASSHELL.DLL" (ByVal hDev As Long, phF rame As Long) As Integer

Parameters

hDev Handle associated with the board. phFrame Handle to the frame that deﬁnes the operation.

Return Value

Remarks

Error/status code. Refer to Appendix A.

This function speciﬁes that you want to perform an interrupt-mode analog input operation on the board speciﬁed by hDev, and accesses an available A/D frame with the handle phFrame. The frame is initialized to its default settings; the default settings are given in Table 3-1 on page 3-3.

The value stored in phFrame is intended to be used exclusively as an argument to functions that require a frame handle. Your program should not modify the value stored in phFrame.

See Also

Usage C/C++

4-12 Function Reference

K_ClearFrame, K_FreeFrame

#include "DASDECL.H" // Use "DASDECL.HPP for C++ ... DWORD hAD; ... wDasErr = K_GetADFrame (hDev, &hAD);

K_GetADFrame (cont.)

Visual Basic for Windows

(Add DASDECL.BAS to your project)

... Global hAD As Long ... wDasErr = K_GetADFrame (hDev, hAD)

4-13

K_GetClkRate

Purpose

Prototype C/C++

Gets a count value that represents the conversion rate.

DASErr far pascal K_GetClkRate (DWORD hFrame, DWORD far *pRate);

Visual Basic for Windows

Declare Function K_GetClkRate Lib "DASSHELL.DLL" (ByVal hFrame As Long, pRate As Long) As Integer

Parameters

hFr ame Handle to the frame that deﬁnes the operation. pRate Count value.

Value stored: 256 to 32768, described as follows:

Sample

Conversion Rate

64 Msamples/s 15.625 ns 256 32 Msamples/s 31.25 ns 512 16 Msamples/s 62.5 ns 1024 8 Msamples/s 125 ns 2048

Period

Count Value

4 Msamples/s 250 ns 4096 2 Msamples/s 500 ns 8192 1 Msamples/s 1 µs 16384 500 Ksamples/s 2 µs 32768

Return Value

Remarks

Error/status code. Refer to Appendix A.

For the operation deﬁned by hFrame, this function stores the number of clock ticks between conversions in pRate.

The pRate variable contains the value of the Pacer Clock Rate element.

See Also

4-14 Function Reference

K_SetClkRate

Usage C/C++

#include "DASDECL.H" // Use "DASDECL.HPP for C++ ... DWORD dwRate; ... wDasErr = K_GetClkRate (hAD, &dwRate);

Visual Basic for Windows

(Add DASDECL.BAS to your project)

... Global dwRate As Long ... wDasErr = K_GetClkRate (hAD, dwRate)

K_GetClkRate (cont.)

4-15

K_GetDevHandle

Purpose

Prototype C/C++

Initializes any Keithley DAS board.

DASErr far pascal K_GetDevHandle (DWORD hDrv, WORD nBoardNum, DWORD far * phDev);

Visual Basic for Windows

Declare Function K_GetDevHandle Lib "DASSHELL.DLL" (ByVal hDrv As Long, ByVal nBoardNum As Integer, phDev As Long) As Integer

Parameters

hDrv Driver handle of the associated Function Call

nBoardNum Board number.

phDev Handle associated with the board.

Return Value

Remarks

Error/status code. Refer to Appendix A.

This function initializes the board associated with hDrv and speciﬁed by nBoardNum, and stores the device handle of the speciﬁed board in phDev.

Driver.

Valid values: 0 to 1

The value stored in phDev is intended to be used exclusively as an argument to functions that require a device handle. Your program should not modify the value stored in phDev.

See Also

Usage C/C++

4-16 Function Reference

K_FreeDevHandle

#include "DASDECL.H" // Use "DASDECL.HPP for C++ ... DWORD hDev; ... wDasErr = K_GetDevHandle (hDrv, 0, &hDev);

K_GetDevHandle (cont.)

Visual Basic for Windows

(Add DASDECL.BAS to your project)

... Global hDev As Long ... wDasErr = K_GetDevHandle (hDrv, 0, hDev)

4-17

K_GetErrMsg

Purpose

Prototype C/C++

Gets the address of an error message string.

DASErr far pascal K_GetErrMsg (DWORD hDev, short nDASErr, char far * far * pErrMsg);

Visual Basic for Windows

Not supported

Parameters

hDev Handle associated with the board. nDASErr Error message number. pErrMsg Address of error message string.

Return Value

Remarks

Error/status code. Refer to Appendix A.

For the board speciﬁed by hDev, this function stores the address of the string corresponding to error message number nDASErr in pErrMsg.

Refer to page 2-3 for more information about error handling. Refer to Appendix A for a list of error codes and their meanings.

Usage C/C++

#include "DASDECL.H" // Use "DASDECL.HPP for C++ ... char far *pErrMsg; ... wDasErr = K_GetErrMsg (hDev, wDASErr, &pErrMsg);

4-18 Function Reference

K_GetShellVer

Purpose

Prototype C/C++

Gets the current DAS shell version.

DASErr far pascal K_GetShellVer (WORD far *pVersion);

Visual Basic for Windows

Declare Function K_GetShellVer Lib "DASSHELL.DLL" (pVersion As Integer) As Integer

Parameters

Return Value

Remarks

pV er sion A word value containing the major and minor

Error/status code. Refer to Appendix A.

This function stores the current DAS shell version in pVersion. To obtain the major version number of the DAS shell, divide pVersion by 256. To obtain the minor version number of the DAS shell, perform a Boolean AND operation with pVersion and 255 (0FF hex).

Usage

version numbers of the DAS shell.

C/C++

#include "DASDECL.H" // Use "DASDECL.HPP for C++ ... WORD wShellVer; wDasErr = K_GetShellVer (&wShellVer); printf ("Shell Ver %d.%d", wShellVer >> 8, wShellVer & 0xff);

Visual Basic for Windows

(Add DASDECL.BAS to your project)

... Global wShellVer As Integer ... wDasErr = K_GetShellVer (wShellVer) ShellVer$ = LTRIM$(STR$(INT(wShellVer / 256))) + "." + : LTRIM$(STR$(wShellVer AND &HFF)) MsgBox "Shell Ver: " + ShellVer$

4-19

K_GetVer

Purpose

Prototype C/C++

Gets revision numbers.

DASErr far pascal K_GetVer (DWORD hDev, short far * pSpecVer, short far * pDrvVer);

Visual Basic for Windows

Declare Function K_GetVer Lib "DASSHELL.DLL" (ByVal hDev As Long, pSpecV er As Integer, pDrvV er As Integer) As Integer

Parameters

hDev Handle associated with the board. pSpecVer Revision number of the Keithley DAS Driver

pDrvVer Driver version number.

Return Value

Remarks

Error/status code. Refer to Appendix A.

For the board speciﬁed by hDev, this function stores the revision number of the DAS-4100 Series Function Call Dri v er in pDrvVer and the revision number of the driver speciﬁcation in pSpecVer.

Speciﬁcation to which the driver conforms.

The values stored in pSpecVer and pDrvV er are tw o-byte (16-bit) integers; the high byte of each contains the major revision lev el and the lo w byte of each contains the minor revision level. For example, if the driver version number is 2.1, the major revision lev el is 2 and the minor revision level is 10; therefore, the high byte of pDrvVer contains the value of 2 (512) and the low byte of pDrvVer contains the value of 10; the value of both bytes is 522.

To obtain the major version number of the Function Call Driver, divide pDrvVer by 256; to obtain the minor version number of the Function Call Driver, perform a Boolean AND operation with pDrvVer and 255 (0FFh).

To obtain the major version number of the driver speciﬁcation, divide pSpecVer by 256; to obtain the minor version number of the driver speciﬁcation, perform a Boolean AND operation with pSpecVer and 255 (0FFh).

4-20 Function Reference

K_GetVer (cont.)

Usage

C/C++

#include "DASDECL.H" // Use "DASDECL.HPP for C++ ... short nSpecVer, nDrvVer; ... wDasErr = K_GetVer (hDev, &nSpecVer, &nDrvVer); printf ("Driver Ver %d.%d", nDrvVer >> 8, nDrvVer & 0xff);

Visual Basic for Windows

(Add DASDECL.BAS to your project)

... Global nSpecVer As Integer Global nDrvVer As Integer ... wDasErr = K_GetVer (hDev, nSpecVer, nDrvVer) DrvVer$ = LTRIM$(STR$(INT(nDrvVer / 256))) + "." + : LTRIM$(STR$(nDrvVer AND &HFF)) MsgBox "Driver Ver: " + DrvVer$

4-21

K_IntAlloc

Purpose

Prototype C/C++

Dynamically allocates a buffer for an interrupt-mode operation.

DASErr far pascal K_IntAlloc (DWORD hFrame, DWORD dwSamples, void far * far *pBuf, WORD far *phMem);

Visual Basic for Windows

Declare Function K_IntAlloc Lib "DASSHELL.DLL" (ByVal hFrame As Long, ByVal dwSamples As Long, pBuf As Long, phMem As Integer) As Integer

Parameters

hFr ame Handle to the frame that deﬁnes the operation. dwSamples Number of samples.

Valid values:

Board Number of Samples

DAS-4101/64K 1 to 65536 DAS-4101/256K 1 to 262144 DAS-4101/1M 1 to 1048526 DAS-4101/2M 1 to 2097150 DAS-4102/64K 1 to 131072 DAS-4102/256K 1 to 524288 DAS-4102/1M 1 to 2097150

pBuf Starting address of the allocated buffer. phMem Handle associated with the allocated buffer.

Return Value

Remarks

Error/status code. Refer to Appendix A.

For the operation deﬁned by hFrame, this function dynamically allocates a buffer of the size speciﬁed by dwSamples, and stores the starting address of the buffer in pBuf and the handle of the buffer in phMem.

4-22 Function Reference

K_IntAlloc (cont.)

The value stored in phMem is intended to be used exclusively as an argument to functions that require a memory handle. Your program should not modify the value stored in phMem.

The data in the allocated buffer is stored as counts. Refer to Appendix B for information on converting a count value to voltage.

See Also

Usage C/C++

K_IntFree, K_SetBuf

#include "DASDECL.H" // Use "DASDECL.HPP for C++ ... void far *pBuf; // Pointer to allocated buffer WORD hMem; // Memory Handle to buffer ... wDasErr = K_IntAlloc (hAD, 8192, &pBuf, &hMem);

Visual Basic for Windows

(Add DASDECL.BAS to your project)

... Global pBuf As Long Global hMem As Integer ... wDasErr = K_IntAlloc (hAD, 8192, pBuf, hMem)

4-23

K_IntFree

Purpose

Prototype C/C++

Frees a buffer dynamically allocated for an interrupt-mode operation.

DASErr far pascal K_IntFree (WORD hMem);

Visual Basic for Windows

Declare Function K_IntFree Lib "DASSHELL.DLL" (ByVal hMem As Integer) As Integer

Parameters

Return Value

Remarks

hMem Handle to interrupt buffer.

Error/status code. Refer to Appendix A.

This function frees the buffer speciﬁed by hMem; the buffer was previously allocated dynamically using K_IntAlloc.

See Also

Usage C/C++

K_IntAlloc

#include "DASDECL.H" // Use "DASDECL.HPP for C++ ... wDasErr = K_IntFree (hMem);

Visual Basic for Windows

(Add DASDECL.BAS to your project)

... wDasErr = K_IntFree (hMem)

4-24 Function Reference

K_IntStart

Purpose

Prototype C/C++

Starts an interrupt-mode operation.

DASErr far pascal K_IntStart (DWORD hFrame);

Visual Basic for Windows

Declare Function K_IntStart Lib "DASSHELL.DLL" (ByVal hFrame As Long) As Integer

Parameters

Return Value

Remarks

hFr ame Handle to the frame that deﬁnes the operation.

Error/status code. Refer to Appendix A.

This function starts the interrupt-mode operation deﬁned by hFrame. Refer to page 3-6 for a discussion of the programming tasks associated with interrupt-mode operations.

See Also

Usage C/C++

K_IntStatus, K_IntStop

#include "DASDECL.H" // Use "DASDECL.HPP for C++ ... wDasErr = K_IntStart (hAD);

Visual Basic for Windows

(Add DASDECL.BAS to your project)

... wDasErr = K_IntStart (hAD)

4-25

K_IntStatus

Purpose

Gets the status of an interrupt-mode operation.

Prototype C/C++

DASErr far pascal K_IntStatus (DWORD hFrame, short far *pStatus, DWORD far *pCount);

Visual Basic for Windows

Declare Function K_IntStatus Lib "DASSHELL.DLL" (ByVal hFrame As Long, pStatus As Integer , pCount As Long) As Integer

Parameters

hFrame Handle to the frame that deﬁnes the operation. pStatus Status of interrupt operation; see Remarks for

pCount Current number of samples transferred into the

Return Value

Remarks

Error/status code. Refer to Appendix A.

For the interrupt-mode operation deﬁned by hFrame, this function stores the status in pStatus and the current number of samples transferred into the array or buffer in pCount.

value stored.

array or buffer.

The value stored in pStatus depends on the settings in the Status word, as shown below:

Bit

About-trigger 00 = Disabled 01 = Armed 11 = Done

4-26 Function Reference

0 = Interrupt operation inactive 1 = Interrupt operation active

0 = Buffer not ﬁlled 1 = Buffer ﬁlled

K_IntStatus (cont.)

The bits are described as follows:

● Bit 0: This bit indicates whether an interrupt-mode operation is in

progress.

● Bits 1 to 3: Not used.

● Bit 4: This bit is set when the array or buffer that is assigned to the

active operation has been ﬁlled with data.

● Bits 6 and 7: These bits indicate the state of the about trigger.

● Bits 8 to 15: Not used.

See Also

K_IntStart, K_IntStop

Usage C/C++

#include "DASDECL.H" // Use "DASDECL.HPP for C++ ... WORD wStatus; DWORD dwCount; ... wDasErr = K_IntStatus (hAD, &wStatus, &dwCount);

Visual Basic for Windows

(Add DASDECL.BAS to your project)

... Global wStatus As Integer Global dwCount As Long ... wDasErr = K_IntStatus (hAD, wStatus, dwCount)

4-27

K_IntStop

Purpose

Prototype C/C++

Stops an interrupt-mode operation.

DASErr far pascal K_IntStop (DWORD hFrame, short far *pStatus, DWORD far *pCount);

Visual Basic for Windows

Declare Function K_IntStop Lib "DASSHELL.DLL" (ByVal hFrame As Long, pStatus As Integer, pCount As Long) As Integer

Parameters

hFrame Handle to the frame that deﬁnes the operation. pStatus Status of interrupt operation. Refer to page 4-26

pCount Current number of samples transferred into the

Return Value

Remarks

Error/status code. Refer to Appendix A.

This function stops the board from acquiring data, disables the interrupt-mode operation, and returns the status of the operation when your program called this function. No data is transferred into the array or buffer in computer memory.

for more information on the status word returned.

array or buffer.

If you are using an external start or about trigger, call this function if the trigger event does not occur.

See Also

Usage C/C++

4-28 Function Reference

K_IntStart, K_IntStatus

#include "DASDECL.H" // Use "DASDECL.HPP for C++ ... WORD wStatus; DWORD dwCount; ... wDasErr = K_IntStop (hAD, &wStatus, &dwCount);

K_IntStop (cont.)

Visual Basic for Windows

(Add DASDECL.BAS to your project)

... Global wStatus As Integer Global dwCount As Long ... wDasErr = K_IntStop (hAD, wStatus, dwCount)

4-29

K_MoveBufToArray

Purpose

Transfers data from a buffer allocated through K_IntAlloc to a locally dimensioned array.

Prototype C/C++

Not supported

Visual Basic for Windows

Declare Function K_MoveBufToArray Lib "DASSHELL.DLL" Alias "K_MoveDataBuf" (pDest As Integer, ByVal pSource As Long, ByV al nCount As Integer) As Integer

Parameters

pDest Address of destination array. pSource Address of source buffer. nCount Number of samples to transfer.

Return Value

Remarks

Error/status code. Refer to Appendix A.

This function transfers the number of samples speciﬁed by nCount from the buffer at address pSource to the array at address pDest.

Valid values: 1 to 32768

In Visual Basic for Windows, the buffer allocated through K_IntAlloc is not accessible to your program; you must use K_MoveBufToArray to move the data from the allocated buffer to the program’s local array.

See Also

Usage Visual Basic for Windows

K_IntAlloc

(Add DASDECL.BAS to your project)

... Dim ADArray(10000) As Integer ... wDasErr = K_IntAlloc (hAD, 8192, pBuf, hMem) ... wDasErr = K_MoveBufToArray (ADArray(0), pBuf, 8192)

4-30 Function Reference

K_OpenDriver

Purpose

Prototype C/C++

Initializes any Keithley DAS Function Call Driver.

DASErr far pascal K_OpenDriver (char far * szDrvName, char far * szCfgName, DWORD far * phDrv);

Visual Basic for Windows

Declare Function K_OpenDriver Lib "DASSHELL.DLL" (ByVal szDrvName As String, ByVal szCfgName As String, phDrv As Long) As Integer

Parameters

szDrvName Board name.

szCfgName Driver conﬁguration ﬁle.

phDrv Handle associated with the driver.

Return Value

Error/status code. Refer to Appendix A.

Valid value: "DAS4100" (for DAS-4100

Series boards)

Valid values: The name of a conﬁguration ﬁle;

0 if driver has already been opened

Remarks

This function initializes the DAS-4100 Series Function Call Driver according to the information in the configuration file specified by szCfgName, and stores the driver handle in phDrv.

You can use this function to initialize the Function Call Driver associated with any Keithley MetraByte DAS board. For DAS-4100 Series boards, the string stored in szDrvName must be DAS4100. Refer to other Function Call Driver user’s guides for the appropriate string to store in szDrvName for other Keithley MetraByte DAS boards.

The value stored in phDrv is intended to be used exclusively as an argument to functions that require a driver handle. Your program should not modify the value stored in phDrv.

You create a conﬁguration ﬁle using the CFG4100.EXE utility. Refer to your DAS-4100 Series User’s Guide for more information.

4-31

K_OpenDriver (cont.)

If szCfgName = 0, K_OpenDriver checks whether the driver has already been opened and linked to a conﬁguration ﬁle and if it has, uses the current conﬁguration; this is useful in the Windows environment.

Usage

C/C++

#include "DASDECL.H" // Use "DASDECL.HPP for C++ ... DWORD hDrv; ... wDasErr = K_OpenDriver ("DAS4100", "DAS4100.CFG", &hDrv);

Visual Basic for Windows

(Add DASDECL.BAS to your project)

... DIM hDrv As Long ... wDasErr = K_OpenDriver("DAS4100", "DAS4100.CFG", hDrv)

4-32 Function Reference

K_RestoreChnGAry

Purpose

Prototype C/C++

Restores a converted channel-gain queue.

Not supported

Visual Basic for Windows

Declare Function K_RestoreChnGAry Lib "DASSHELL.DLL" (pArray As Integer) As Integer

Parameters

Return Value

Remarks

pArray Channel-gain queue starting address.

Error/status code. Refer to Appendix A.

This function restores the channel-gain queue at the address speciﬁed by pArray to its original format so that it can be used by your Visual Basic for Windows program. The channel-gain queue was converted using K_FormatChnGAry.

Refer to page 4-9 for more information about the K_FormatChnGAry function.

See Also

K_FormatChnGAry, K_SetChnGAry

Usage Visual Basic for Windows

(Add DASDECL.BAS to your project)

... Global ChanGainArray(16) As Integer ' Chan/Gain array ... wDasErr = K_RestoreChnGAry (ChanGainArray(0))

4-33

K_SetAboutTrig

Purpose

Enables the about trigger and speciﬁes the number of post-trigger samples.

Prototype C/C++

DASErr far pascal K_SetAboutTrig (DWORD hFrame, DWORD dwSamples);

Visual Basic for Windows

Declare Function K_SetAboutTrig Lib "DASSHELL.DLL" (ByVal hFrame As Long, ByVal dwSamples As Long) As Integer

Parameters

hFr ame Handle to the frame that deﬁnes the operation. dwSamples Number of post-trigger samples.

Valid values:

Board Number of Sample

DAS-4101/64K 2 to 65534 DAS-4101/256K 2 to 262142 DAS-4101/1M 2 to 1023998 DAS-4101/2M 2 to 2047998 DAS-4102/64K 2 to 131070 DAS-4102/256K 2 to 524286 DAS-4102/1M 2 to 2047998

Return Value

Remarks

Error/status code. Refer to Appendix A.

This function enables the about trigger and speciﬁes the number of post-trigger samples in dwSamples. At least one pre-trigger sample must be in the buffer.

Note that you cannot use an about trigger with an external start trigger.

See Also

4-34 Function Reference

K_ClrAboutTrig

Usage C/C++

#include "DASDECL.H" // Use "DASDECL.HPP for C++ ... wDasErr = K_SetAboutTrig (hAD, 100);

Visual Basic for Windows

(Add DASDECL.BAS to your project)

... wDasErr = K_SetAboutTrig (hAD, 100)

K_SetAboutTrig (cont.)

4-35

K_SetADTrig

Purpose

Prototype C/C++

Sets up an external analog start or about trigger.

DASErr far pascal K_SetADTrig (DWORD hFrame, short nOpt, short nChan, DWORD dwLevel);

Visual Basic for Windows

Declare Function K_SetADTrig Lib "DASSHELL.DLL" (ByVal hFrame As Long, ByVal nOpt As Integer, ByV al nChan As Integer, ByVal dwLevel As Long) As Integer

Parameters

hFr ame Handle to the frame that deﬁnes the operation. nOpt Analog trigger polarity.

nChan Trigger channel.

Valid values: 0 for Positive edge

2 for Negative edge

Valid values: 0 for ±4 V signal from

Channel A connector 1 for ±4 V signal from Channel B connector (Valid for DAS-4102 boards only)

2 for ±16 V signal from

Analog Trigger In connector

dwLevel Level at which the trigger event occurs, speciﬁed

in counts.

Return Value

Remarks

Valid values:

Error/status code. Refer to Appendix A.

For the operation deﬁned by hFrame, this function speciﬁes the channel

−128 to 127

used for an analog trigger in nChan, the level used for the analog trigger in dwLevel, and the trigger polarity and trigger sensitivity in nOpt.

You specify the value for dwLevel in counts. Refer to Appendix B for information on converting the actual voltage to a count value.

4-36 Function Reference

The nOpt variable sets the value of the Trigger Polarity and Trigger Sensitivity elements; the nChan variable sets the value of the Trigger Channel element; the dwLevel variable sets the value of the Trigger Level element.

K_SetADT rig does not af fect the operation deﬁned by hF r ame unless the Trigger Source element is set to External (by a call to K_SetTrig) before hFrame is used as a calling argument to K_IntStart.

Usage C/C++

#include "DASDECL.H" // Use "DASDECL.HPP for C++ ... wDasErr = K_SetADTrig (hAD, 0, 1, 127);

Visual Basic for Windows

(Add DASDECL.BAS to your project)

... wDasErr = K_SetADTrig (hAD, 0, 1, 127)

K_SetADTrig (cont.)

4-37

K_SetBuf

Purpose

Speciﬁes the starting address of a previously allocated array or buf fer and the number of samples in the array or buffer.

Prototype C/C++

DASErr far pascal K_SetBuf (DWORD hFrame, void far *pBuf, DWORD dwSamples);

Visual Basic for Windows

Declare Function K_SetBuf Lib "DASSHELL.DLL" (ByVal hFrame As Long, ByVal pBuf As Long, ByV al dwSamples As Long) As Integer

Parameters

hFr ame Handle to the frame that deﬁnes the operation. pBuf Starting address of array or buffer. dwSamples Number of samples.

Valid values:

Board Number of Samples

DAS-4101/64K 1 to 65536 DAS-4101/256K 1 to 262144 DAS-4101/1M 1 to 1048526 DAS-4101/2M 1 to 2097150 DAS-4102/64K 1 to 131072 DAS-4102/256K 1 to 524288 DAS-4102/1M 1 to 2097150

Return Value

Remarks

Error/status code. Refer to Appendix A.

For the operation deﬁned by hFrame, this function speciﬁes the starting address of a previously allocated array or buffer in pBuf and the number of samples (the size of the array or buffer) in dwSamples.

4-38 Function Reference

K_SetBuf (cont.)

For Visual Basic for Windows, use this function only for dynamically allocated buffers. For locally dimensioned arrays, use K_SetBufI.

For C application programs, make sure that you use proper typecasting to prevent C/C++ type-mismatch warnings.

The pBuf variable sets the value of the Buffer element; the dwSamples variable sets the value of the Number of Samples element.

See Also

Usage C/C++

K_IntAlloc, K_SetBufI

#include "DASDECL.H" // Use "DASDECL.HPP for C++ ... void far *pBuf; // Pointer to allocated buffer ... wDasErr = K_IntAlloc (hAD, 8192, &pBuf, &hMem); wDasErr = K_SetBuf (hAD, pBuf, 8192);

Visual Basic for Windows

(Add DASDECL.BAS to your project)

... Global pBuf As Long ... wDasErr = K_IntAlloc (hAD, 8191, pBuf, hMem) wDasErr = K_SetBuf (hAD, pBuf, 8192)

4-39

K_SetBufI

Purpose

Speciﬁes the starting address of a locally dimensioned integer array and the number of samples in the array.

Prototype C/C++

Not supported

Visual Basic for Windows

Declare Function K_SetBufI Lib "DASSHELL.DLL" Alias "K_SetBuf" (ByVal hFrame As Long, pBuf As Integer, ByVal dwSize As Long) As Integer

Parameters

hFr ame Handle to the frame that deﬁnes the operation. pBuf Starting address of the locally dimensioned

dwSize Number of samples.

Return Value

Remarks

Error/status code. Refer to Appendix A.

For the operation deﬁned by hFrame, this function speciﬁes the starting address of a locally dimensioned integer array in pBuf and the number of samples stored in the array in dwSize.

integer array.

Valid values: 1 to 32768

Do not use this function for C; instead, use K_SetBuf. For Visual Basic for Windows, use this function only for locally

dimensioned arrays. For buffers allocated dynamically using K_IntAlloc, use K_SetBuf.

The pBuf v ariable sets the value of the Buf fer element; the dwSize variable sets the value of the Number of Samples element.

See Also

4-40 Function Reference

K_IntAlloc, K_SetBuf

Usage Visual Basic for Windows

(Add DASDECL.BAS to your project)

... Global ADData(8191) As Integer ... wDasErr = K_SetBufI (hAD, ADData(0), 8192)

K_SetBufI (cont.)

4-41

K_SetChn

Purpose

Prototype C/C++

Speciﬁes a single channel.

DASErr far pascal K_SetChn (DWORD hFrame, short nChan);

Visual Basic for Windows

Declare Function K_SetChn Lib "DASSHELL.DLL" (ByVal hFrame As Long, ByVal nChan As Integer) As Integer

Parameters

hFr ame Handle to the frame that deﬁnes the operation. nChan Channel on which to perform the operation.

Return Value

Remarks

Error/status code. Refer to Appendix A.

For the operation deﬁned by hFrame, this function speciﬁes the single channel used in nChan.

Software channel 0 corresponds to the analog input signal from the Channel A connector on the board; softw are channel 1 corresponds to the analog input signal from the Channel B connector on the board.

Valid values: 0 for signal from Ch A connector

1 for signal from Ch B connector

The nChan variable sets the Channel element.

Usage C/C++

#include "DASDECL.H" // Use "DASDECL.HPP for C++ ... wDasErr = K_SetChn (hAD, 0);

Visual Basic for Windows

(Add DASDECL.BAS to your project)

... wDasErr = K_SetChn (hAD, 0)

4-42 Function Reference

K_SetChnGAry

Purpose

Prototype C/C++

Speciﬁes the starting address of a channel-gain array.

DASErr far pascal K_SetChnGAry (DWORD hFrame, void far *pArray);

Visual Basic for Windows

Declare Function K_SetChnGAry Lib "DASSHELL.DLL" (ByVal hFrame As Long, pArray As Integer) As Integer

Parameters

hFr ame Handle to the frame that deﬁnes the operation. pArray Channel-gain queue starting address.

Return Value

Remarks

Error/status code. Refer to Appendix A.

For the operation deﬁned by hFrame, this function speciﬁes the starting address of the channel-gain queue in pArray.

The pArray variable sets the Channel-Gain Queue element. Refer to Chapter 3 for information on setting up a channel-gain queue. If you created your channel-gain queue in Visual Basic for Windo ws, you

must use K_FormatChnGAry to convert the channel-gain queue before you specify the address with K_SetChnGAry.

See Also

Usage C/C++

K_FormatChnGAry, K_RestoreChnGAry

#include "DASDECL.H" // Use "DASDECL.HPP for C++ ... //DECLARE AND INITIALIZE CHAN/GAIN PAIRS //(GAINCHANTABLE-TYPE IS DEFINED IN dasadecl.h) GainChanTable ChanGainArray = {2. // # of entries

0, 3, // chan 0, gain 3 1, 7); // chan 1, gain 7

wDasErr = K_SetChnGAry (hAD, &ChanGainArray);

4-43

K_SetChnGAry (cont.)

Visual Basic for Windows

(Add DASDECL.BAS to your project)

... Global ChanGainArray(16) As Integer ... ’Create the array of channel/gain pairs ChanGainArray(0) = 2 ’# of chan/gain pairs ChanGainArray(1) = 0: ChanGainArray(2) = 0 ChanGainArray(3) = 1: ChanGainArray(4) = 7 wDasErr = K_FormatChnGAry (ChanGainArray(0)) wDasErr = K_SetChnGAry (hAD, ChanGainArray(0))

4-44 Function Reference

K_SetClk

Purpose

Prototype C/C++

Speciﬁes the pacer clock source.

DASErr far pascal K_SetClk (DWORD hFrame, short nMode);

Visual Basic for Windows

Declare Function K_SetClk Lib "DASSHELL.DLL" (ByVal hFrame As Long, ByVal nMode As Integer) As Integer

Parameters

hFr ame Handle to the frame that deﬁnes the operation. nMode Pacer clock source.

Return Value

Remarks

Error/status code. Refer to Appendix A.

For the operation deﬁned by hFrame, this function speciﬁes the pacer clock source in nMode.

The nMode variable sets the Clock Source element. K_GetADFrame and K_ClearFrame specify internal as the default

clock source.

Valid values: 0 for Internal

1 for External

Usage C/C++

#include "DASDECL.H" // Use "DASDECL.HPP for C++ ... wDasErr = K_SetClk (hAD, 1);

Visual Basic for Windows

(Add DASDECL.BAS to your project)

... wDasErr = K_SetClk (hAD, 1)

4-45

K_SetClkRate

Purpose

Prototype C/C++

Speciﬁes a count value that represents the conversion rate.

DASErr far pascal K_SetClkRate (DWORD hFrame, DWORD dwDivisor);

Visual Basic for Windows

Declare Function K_SetClkRate Lib "DASSHELL.DLL" (ByVal hFrame As Long, ByVal dwDivisor As Long) As Integer

Parameters

hFr ame Handle to the frame that deﬁnes the operation. dwDivisor Count value.

Valid values: 256 to 32768, described as follows:

Sample

Conversion Rate

64 Msamples/s 15.625 ns 256 32 Msamples/s 31.25 ns 512 16 Msamples/s 62.5 ns 1024 8 Msamples/s 125 ns 2048

Period

Count Value

4 Msamples/s 250 ns 4096 2 Msamples/s 500 ns 8192 1 Msamples/s 1 µs 16384 500 Ksamples/s 2 µs 32768

Return Value

Remarks

Error/status code. Refer to Appendix A.

For the operation deﬁned by hFrame, this function speciﬁes the count value, which is divided into 16.384 Gsamples/s, for the internal pacer clock in dwDivisor.

The dwDivisor variable sets the Pacer Clock Rate element. Refer to page 2-9 for more information on the internal pacer clock.

4-46 Function Reference

K_SetClkRate (cont.)

See Also

Usage C/C++

K_GetClkRate

#include "DASDECL.H" // Use "DASDECL.HPP for C++ ... wDasErr = K_SetClkRate (hAD, 256);

Visual Basic for Windows

(Add DASDECL.BAS to your project)

... wDasErr = K_SetClkRate (hAD, 256)

4-47
