Y-Adapter

Description

The Model CS-1279 is a three-slot male triaxial to dual three-lug female triaxial tee. This 50 Ω BNC three-port
Y-shape adapter allows routing of a signal from a common source to two different devices. The combination of

two BNC jack interfaces and one BNC plug interface is useful for mating in many commonly found test

applications.

This Y-adapter allows signal splitting to two devices that is useful in confined spaces. Also, the nickel-plated
body enhances corrosion resistance.

Figure 1: CS-1279 three-slot male triaxial with two female triaxial connectors

077161800 / July 2019 1

Model CS-1279 Y-Adapter

Characteristics

Impedance:

 50 Ω

Materials:

®

 Brass shell with Delrin

insulation

 Nickel-plated shell with gold-plated contacts

Operating environment:

 0° C to 35° C up to 70% relative humidity

 –25° C to 65° C storage

Dimensions
