Cerify Automated Video Content Veriﬁcation System

ZZZ

Quick Start User Manual

*P071268009*

071-2680-09

Cerify Automated Video Content Veriﬁcation System

ZZZ

Quick Start User Manual

This document supports software version 7.9 and above.

www.tektronix.com

071-2680-09

tional copyright laws and international treaty provisions.

Tektronix pro previously published material. Speciﬁcations and price change privileges reserved.

TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.

Cerify is a trademark of Tektronix, Inc.

Cerify Technical Support

Cerify Technical support is available o n Business Days from 6:00 AM to 5:00 PM Paciﬁc Time and 9:00 AM to 5:00 PM Indian Standard Time on the following numbers:

• US/Canada toll-free 1-844-219-5329

• India tol

• Russia toll-free 810800-22554411

• United Kingdom 44 1344 39 2541

• Europe* t

* Austria

Alternat

ducts are covered by U.S. and foreign patents, issued and pending. Information in this publication supersedes that in all

l-free 1800 3000 4835

oll-free 00800-22554411

, Belgium, France, G ermany, Ireland, Italy, Netherlands, Spain, Sweden, Switzerland, and UK.

ively, you can send e-mail to cerify-support@tektronix.com

Contacting Tektronix

Tektronix, Inc. 14150 SW Karl Braun Drive P.O. Box 500 Beaverton, OR 97077 USA

For product information, sales, service, and technical support:

In North America, call 1-800-833-9200. Worldwide, visit www.tektronix.com to ﬁnd contacts in your area.

Warranty

Tektronix warrants that the media on which this software product is furnished and the encoding of the programs on the media will be free from defects in materials and workmanship for a period of three (3) months from the date of shipment. If any such medium or encoding proves defective during the warranty period, Tektronix will provide a replacement in exchange for the defective medium. Except as to the media on which this software product is furnished, this software product is provided “as is” without warranty of any kind, either express or implied. Tektronix does not warrant that the functions contained in this software product will meet Customer's requirements or that the operation of the programs will be uninterrupted or error-free.

In order to obtain service under this warranty, Customer must notify Tektronix of the defect before the expiration of the warranty period. If Tektronix is unable to provide a replacement that is free from defects in materials and workmanship within a reasonable time thereafter, Customer may terminate the license for this software product and return this software product and any associated materials for credit or refund.

THIS WARRANTY IS GIVEN BY TEKTRONIX WITH RESPECT TO THE PRODUCT IN LIEU OF ANY O TH ER WARRANTIES, EXPRESS OR IMPLIED. TEKTRONIX AND ITS VENDORS DISCLAIM ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. TEKTRONIX' RESPONSIBILITY TO REPLACE DEFECTIVE MEDIA OR REFUND CUSTOMER'S PAYMENT IS THE SOLE AND EXCLUSIVE REMEDY PROVIDED TO T HE CUSTOMER FOR BREACH OF THIS WARRANTY. TEKTRONIX AND ITS VENDORS WILL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF WHETHER TEKTRONIX OR THE VENDOR HAS ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.

[W9b – 15AUG04]

Table of Contents

Environmental considerations......................................................................................................... ii

Product end-

Preface................................................................................................................................. iii

Product description. . .. . . . . . . .. . .. . .. . .. . .. . . . .. . .. . .. . .. . .. . .. . .. .. . .. . .. . .. . .. . .. . . . .. . .. . .. . .. . .. . .. .. . .. . .. . .. . .. . .. . .. .. . .. . . iii

System comp

System requirements .. . .. . .. . .. .. . .. . .. . .. . .. . .. . . . . . . .. . .. . .. . .. . .. . .. .. . .. . .. . .. . .. . .. . .. . .. .. . .. . .. . .. . .. . .. . .. . . . .. . .. . .. . viii

Clustering requirements . . .. . .. . .. . .. . . . . . . .. . .. . .. . .. . .. . .. ... .. . .. . .. . .. . .. . .. . .. . .. .. . .. . .. . .. . .. . .. . .. . . . . . . .. . .. . .. . .. . .. . .. xi

Related do

Installation.............................................................................................................................. 1

Before installation................................................................................................................ 1

Software i

Software uninstallation..........................................................................................................10

Software reinstallation ..........................................................................................................10

Software

Network settings ................................................................................................................ 12

Conﬁguring the Cerify installation .............................................................................................. 12

on..............................................................................................................................13

Operati

Getting acquainted . . .. . .. . .. . .. . .. . . . . . . .. . .. . .. . .. . .. . .. . .. .. . .. . .. . .. . .. . .. . .. . .. . .. .. . .. . .. . .. . .. . .. . . . . . . .. . .. . .. . .. . .. . .. . . 13

Concepts ........................................................................................................................15

Proced

of-life handling . . .. . .. . .. . .. .. . .. . .. . .. . . . .. . .. . .. .. . .. . .. . .. . .. .. . .. . .. . . . . . . .. . .. . .. .. . .. . .. . .. . .. .. . .. . .. . . . . . . .. ii

onents . .. . .. .. . .. . .. . . . .. . .. . .. . . . .. . .. . .. . . . .. . .. . . . . . . .. . .. . .. .. . .. . .. . .. .. . .. . .. . . . .. . .. . .. .. . .. . .. . .. .. . .. . .. . . iii

cumentation ......................................................................................................... xii

nstallation.............................................................................................................. 3

upgrade ............................................................................................................... 11

ures...................................................................................................................... 18

How to startthe Cerify application ........................................................................................ 19

How to starta cluster ...................................................................................................... 20

How to c

How to create a MediaSet. . .. . .. . .. . .. . .. .. . .. . .. . .. . .. . .. . .. . .. . . . . . . .. . .. . .. . .. . .. . .. . .. .. . .. . .. . .. . .. . .. . .. . .. . .. . .. .. . 22

How to create a Template ................................................................................................. 24

How to

How to create a Job ....................................................................................................... 28

How to inspect Job results ................................................................................................ 28

How t

How to archive the Job .................................................................................................... 29

How to access the Web User Interface................................................................................... 30

reate a MediaLocation . . .. . .. .. . .. . .. . .. . .. . .. . .. . .. . . . . . . . . . .. . .. . .. . .. . .. . .. . .. . .. .. . .. . .. . .. . .. . .. . .. . .. . .. . .. 21

create a Proﬁle .................................................................................................... 27

o generate a Report . .. . .. . .. . .. . .. . .. . .. . .. . .. . .. . .. . .. . .. . .. . .. . . . . . . . . . . . . . . . . . . .. . .. . .. . .. . .. . .. . .. . .. . .. . .. . .. . . 29

Table of Content

Cerify Quick Start User Manual i

Environmental c

onsiderations

Environmental considerations

This section provides information about the environmental impact of the product.

Product end-of-life handling

Observe the following guidelines when recycling an instrument or component:

Equipment r

Production of this equipment required the extraction and use of natural resources. The equipment may contain s ubstances that couldbeha such substances into the environment and to reduce the use of natural resources, we encourage you to recycle this product in an appropriate system that will ensure that most of the materials are reused or recycled appropriately.

ecycling

rmful to the environment or human health if improperly handled at the product’s end of life. In order to avoid release of

This symbol indicates that this product complies with the applicable European Union requirements according to Directi batteries. For information about recycling options, check the Support/Service section of the Tektronix Web site (www.tektronix.com).

ves 2002/96/EC and 2006/66/EC on waste electrical and electronic equipment (WEEE) and

Perchlorate materials. This product contains one or more type CR lithium batteries. According to the state

of California, CR lithium batteries are classiﬁed as perchlorate materials and require special handling. See www.dtsc.ca.gov/hazardouswaste/perchlorate for additional information.

Restriction of hazardous substances. This product is classiﬁed as an industrial monitoring and control instrument,

ot required to comply with the substance restrictions of the recast RoHS Directive 2011/65/EU until July 22, 2017.

and is n

ii Cerify Quick Start User Manual

Preface

The Cerify application is an automated system for testing compressed digital media. This manual provides installation instructions and a high-level operational overview of this product.

Product description

This is a media testing product which runs either on a single computer or on a cluster of two or more dedicated computers connected o for correct digital encoding and against baseband quality parameters. It provides both broadcast and production operations with a fast, cost effective QC solution.

The Cerify system can be integrated with your existing infrastructure using the CeriTalk API to interface with asset managemen to be viewed from any network connected workstation.

System components

Cerify accesses digital media from local storage, such as a local hard drive or DVD, as well as network storage, such as a Windows ﬁle server or FTP server.

n a network running Microsoft Windows. This automated video content veriﬁcation system can be used to check

t systems and provide a completely automated workﬂow. A Web-based user interface allows test results

Preface

A Cerify system can be set up in three basic ways:

The ﬁrst consists of a single self-contained unit which runs all the management and testing processes of the system.

The second consists of a networked cluster of two or more units, which enables simultaneous processing of a greater number of ﬁles. The networked cluster contains a single Supervisor and one or more Media Test Units.

The third consists of a cluster of three or more units with high availability (HA) support. Cerify Enterprise Cluster with high availability (also referred to as an HA cluster) is a Cerify cluster enabled with support in the case of a S upervisor system failure.

Cerify Quick Start User Manual iii

Preface

License dongle

The license dongle must be plugged into the USB port on your computer to run the application. In a clustered system, Media Test Units acquire their licenses from the Supervisor.

In the case of an HA cluster, two identical license dongles are supplied. The two dongles need to be inserted in the USB ports of the primary and secondary supervisors. Media Test Units will acquire licenses from the active primary Supervisor.

The license dongle y ou received should look like one of the dongles shown below.

Figure i: License dongle

It is possible to navigate the user interface and see previous results when no dongle is installed, but it is not possible to carry out new checks of digital media ﬁles. The license dongle controls:

The types of codecs and ﬁle formats that can be checked

The number of channels that can be used

For demo dongles, when the license will expire

Server conﬁguration (Supervisor, Secondary Supervisor or Media Test Unit, High Availability cluster or not, etc.)

NOTE. In a high availability (HA) cluster, if you unplug a dongle and plug in another dongle, or if the connected dongle is

upgraded with a new v2c ﬁle, a restart of Cerify is necessary for the license dongle to work correctly.

When you install a new version of the Cerify software for a high availability (HA) cluster, both of the dongles connected to the primary and secondary Supervisors must be upgraded.

iv Cerify Quick Start User Manual

Preface

Networking

In a clustered conﬁguration, network interface on all of the units, including the Supervisor, secondary Supervisor (HA cluster only) and Media Test Units, should be connected to the local area network. This connection is used to access media ﬁles, to service Web clients, and to carry cluster control trafﬁc.

Figure ii: Clustering topology

Software components

Software components include:

A Web-based user interface, which allows users to create and control Jobs, and to view or report the results of these Jobs. This interface is accessed over the network by using a Web browser. All you need to know is the IP address of your unit.

Media test service, which performs media ﬁle veriﬁcation according to the rules chosen by the user.

A database, which provides robust storage of the system entities, including users, Jobs, and Job results.

An XML-based control and reporting API known as CeriTalk. CeriTalk allows interaction with C erify from within other

lications, making it possible to integrate Cerify with other content management, broadcast automation, and workﬂow

app systems.

A Web application server that provides access to the Web interface and runs the core services for the application.

A license server, which controls the types of ﬁles that can be veriﬁed.

The s ystem tray icon and menu, which provides access to the Cerify Web-based user interface and allows the application to be started and stopped. The system tray icon is not available when Cerify is installed as a Windows service.

Cerify Quick Start User Manual v

Preface

Cerify as a standalone system

A standalone system is a single machine that combines the functions of a Supervisor unit and a Media Test Unit. The process that carries out the media ﬁle testing is known as the Media Test Client (MTC).

Cerify enterprise cluster

The Supervis and view Jobs. It is responsible for locating the media ﬁles from the network, but delegates actual transfer and processing of these ﬁles to one or more Media Test Units. T he Supervisor unit organizes and stores the resulting outputs.

Each Media Test Unit is responsible for processing the digital media ﬁles in a networked cluster. It applies the user-speciﬁed tests, and r

or unit controls the cluster system. It hosts the database and the Web server, allowing multiple users to set up

eports back the results. The Supervisor can also be conﬁ gured to process the ﬁles.

Figure iii: Local area networking

vi Cerify Quick Start User Manual

Preface

Cerify high availability enterprise cluster

The Cerify high availability enterprise cluster (also referred to as an HA cluster) is a Cerify cluster enabled with support in the case of a Supervisor system failure. In an HA cluster, one of the member units of the cluster is conﬁgured as a backup to the Primary Supervisor and is called the Secondary Supervisor.

If Cerify on the Primary Supervisor goes down for any reason (for example, due to a machine crash), the Secondary Supervisor automatically takes over and manages the cluster. All other units (MTUs) now form a cluster with the Secondary Supervisor. Once the Primary Supervisor recovers, it will assume the role of the Secondary Supervisor and will be ready to take over when the current Supervisor goes down.

The Secondary Supervisor is a part of the HA cluster and can also process ﬁles like the Primary Supervisor and the MTUs in the cluster while performing the job of a Secondary Supervisor.

In an HA cluster, it is mandatory for the Primary Supervisor and Secondary Supervisor to have two network interface cards on the system. One will be used for the cluster function and the other for c ommunication (Ceritalk/Web). Also, it is mandatory to use static IP addresses for all the units forming the HA cluster.

In an HA cluster, identical dongles must be connected to the Primary Supervisor and Secondary Supervisor. When starting an HA cluster, the cluster units should be started in the following order:

1. The Primary Supervisor should be started ﬁrst with one of the two HA dongles installed. At the time the Primary Supervisor is s tarted, the system with the Secondary Supervisor installed should be up and have the matching HA dongle installed. Otherwise, the Primary Supervisor will not start.

2. The Secondary Supervisor should be started next.

3. The Media Test Units should be started one by one after both the Primary Supervisor and Secondary Supervisor

are started.

Cerify Quick Start User Manual vii

Preface

System requirements

The system must meet the following hardware and software prerequisites:

Hardware prerequisites

Cerify runs on a variety of PC hardware. Consequently, the choice of hardware is determined by performance and throughput in which Cerify is typically used.

Cerify can be installed as either of the following two conﬁgurations on a given computer:

requirements for your installation. This section recommends hardware conﬁguration for some scenarios

Single channel. A single channel installation is one that is licensed to test a single media ﬁle at a time. Such installations are normally performed on a PC or a laptop computer and are suitable for situations where a low throughput is sufﬁcient and perfor

mance is not critical.

Multichan throughput and performance requirements that are expected from such installations, it is recommended that server class hardware and operating systems be used in such cases.

In addition to the throughput required, the hardware requirements also depend heavily on the mode of operation that will be used. C

Streami the local hard disk of the Cerify system. This is the default mode of operation and is also the preferred one.

Copying m ode. Media ﬁles are copied to the local hard disk of the Cerify system before processing can begin. By default, Cerify will not copy ﬁ les to the local hard disk, but it is possible to force Cerify to operate in this mode.

The mode of operation that applies to your Cerify installation depends on the ﬁle formats you would like to test and other work ﬂo Cerify User Manual for a detailed discussion on the factors that inﬂuence this.

The functional differences between these two modes of operation impact primarily on the disk space availability and disk conﬁguration requirements. Speciﬁcally, the copying mode requires a greater amount of disk space and high levels of concu derive comparable overall performance with a lesser amount of disk space and lower read/write efﬁciency. Consequently, when possible, the streaming mode should be used in preference to c opying mode.

nel. A typical multichannel installation of Cerify tests 4-8 media ﬁles at a time on a single unit. Due to the high

erify can operate in two modes:

ng mode. In this mode, media ﬁles are read directly from the media server hosting the ﬁle and are not copied to

w and connectivity related constraints that might apply to your situation. See the Modes of Operation section in the

rrent read/write performance from the hard drives in order for best overall performance while the streaming mode can

viii Cerify Quick Start User Manual

The general guidelines that should be followed when selecting hardware are:

Processor: 3 GHz

Cerify is capable of using as many processor cores as available for improved processing performance. While the minimum required conﬁguration is 2 cores per channel, for optimum performance, it is recommended to allocate between 4 and 6 processor cores per Cerify channel. It is also recommended that for best performance, you choose as much on-chip memory cache as possible.

NOTE. Cerify is optimized for Intel processor architectures, and therefore it is recommended that you use an Intel based

server platform.

Memory:

It is recommended to use a minimum of 4 GB of RAM per channel and an additional 4 G B for the operating system and the Cerify database. For optimum performance for 4 channels, the recommended memory therefore is: 4 x 4 GB (per channel) + 4 GB = 20 G B. When the expected load in Cerify is likely to be largely composed of huge media ﬁles, more memory per channel may be necessary.

Hard disk drive: 100 GB x 3

For an enterprise installation, we recommend using a RAID on which to place the MS Windows and Cerify installation (including database) to achieve fault tolerance in case of disk failure. This logical drive should be at least 100 GB in size. For systems that are expected to support high levels of throughput, it is recommended that you have 500 GB of space on this logical drive.

Preface

The amount of additional storage you need depends on the mode of operation that applies to your installation, the average size of the ﬁles you will be processing, and the number of channels you will be running.

Streaming mode

Due to the minimal hard disk utilization when operating in the streaming mode, it is sufﬁcient to provide a single dedicated hard disk of 100 G B in size as temporary s torage for Cerify.

Copying mode

The minimum hard disk space provided must be greater than the average ﬁle size being processed multiplied by the number of channels. It is recommended that the temporary storage be RAID-ed for better performance.

Choose the optimal number of hard disks for your installation and the best RAID levels to use. For help in choosing the optimal number of hard disks for your installati on and the best RAID levles to use, see the “Conﬁguring Your Cerify Installation for Best Performance” section in the Cerify user manual.

Network interface: 1 Gbit/s

You might use multiple network interfaces to improve available network bandwidth

Integrated RAID controller

A DVD drive (used for installing the software)

A USB port for connecting the license dongle

A license dongle (provided with the product)

Redundant power supply

For more detailed speciﬁcation of a validated enterprise PC platform, see “Commercial off-the-Shelf Recommendations” section under Appendix E: Conﬁguring Your Cerify Installation of the Cerify user manual.

Cerify Quick Start User Manual ix

Preface

Supported platforms

Windows 7 - 64 bit

Windows Server 2008 64-bit

Windows Server 2008 R2 64-bit

Windows Server 2012, 64-bit

Windows Server 2012 R2, 64-bit

NOTE. Cerify is expected to operate correctly on other variants of Windows as well, but it has been qualiﬁed only on

the ones speciﬁed above.

Apple ProRes, Generic QuickTime and JPEG 2000 Video decoding f unctions are not available on Microsoft Windows XP 64 bit and Windows Server 2003 because of known compatibility issues with QuickTime Player.

Software prerequisites

The compu

NOTE. To access the application, the preferred Web browser is Microsoft Internet Explorer (version 7.0 and above). The

applic interface in different Web browsers.

ter on which the application is installed will need the following:

To run one

To acces must have a Web browser installed.

ation has also been tested with Mozilla Firefox. There may be minor visual differences in the appearance of the user

of the supported platforms.

s the system through its Web user interface from another computer on the network, the client computer

x Cerify Quick Start User Manual

Clustering requirements

A cluster is a network of two or more units, which enables simultaneous processing of a greater number of ﬁles. The networked cluster contains a single Supervisor and one or more Media Test Units.

The Supervisor unit controls the cluster system. It hosts the database and the Web server, allowing multiple users to set up and view Jobs. It is responsible for locating the media ﬁles from the network, but delegates actual transfer and processing of these ﬁles to one or more Media Test Units. T he Supervisor unit organizes and stores the resulting outputs. The Supervisor canalsobeconﬁgured to process the media ﬁles.

The Media Test Unit is responsible for processing of the digital media ﬁles in a cluster. It applies the user-speciﬁed tests and reports results the back to the Supervisor unit.

To set up a cluster, install Media Test Units and Supervisor on the respective nodes.

Cluster system requirements

Two or more PCs with 64-bit Windows Server 2008 SE OS installed.

Administrator privileges on all the machines on which the Cerify software will be installed.

All of the systems with Cerify installed need to meet the minimum hardware speciﬁcations.

All of the clustering PCs, Media Test Units, and Secondary Supervisor unit should reside on the same network as the Supervisor unit. It is recommended that each cluster unit be conﬁgured with Static IP addresses.

Preface

All of the PCs i n the cluster should be able to route to each other. The Supervisor unit and the Secondary Supervisor

the case of an HA cluster) each need to be given a network name that is recognized and resolved by all of the

unit (in units in the cluster.

You should know the fully qualiﬁed name of the Supervisor unit and the Secondary Supervisor unit and provide these when the installer of the other units in the cluster asks for the names of the Supervisor and Secondary Supervisor units.

In the case of a normal cluster (non-HA cluster), if the Supervisor or Media Test Units have more than one network

aces, it is better to bridge all the network interfaces together. (See page 7, Conﬁguring a network bridge.)

interf

ronization between all the units in cluster m ust be maintained. For example, use an NTP server to synchronize

Synch the units in a c luster.

All the units in the cluster should be conﬁgured to be in the same time zone.

Cerify Quick Start User Manual xi

Preface

Clustering scenarios which may not work

Clusters may not work in the following scenarios:

If the Supervisor, the Secondary Supervisor (in the case of a n HA cluster), and the Media Test Unit are in different subnets wherein the switch blocks the multicast or UDP trafﬁc.

If any of Supervisor, Secondary Supervisor, or Media Test U nit systems has Windows ﬁrewall running, the Firewall may need some additional conﬁgurations for the cluster to work. Contact your Tektronix representative for more information on how to set up this conﬁguration.

If a Media Test Unit or Secondary S upervisor cannot resolve Supervisor host name.

In the case of an HA cluster, if the Supervisor can not resolve the host name of the Secondary Supervisor and vice versa.

If the Supervisor does not have a host name or if the Supervisor has a host name with Japanese or C hinese characters.

If a network has another system with the same host name as the Supervisor (or Secondary Supervisor) system.

If the host name of the Supervisor (or Secondary Supervisor) changes after cluster installation.

If the http port on the Supervisor is conﬁgured to a different port number after cluster installation. In this case, the property cerify.supervisor.httpport in the cerifysystem.properties on the Media Test Units must be changed to the new port number.

If the http port on the Supervisor is conﬁgured differently than that of the Secondary Supervisor.

If the IP addresses of any units in the cluster change after the installation. In this case, the property cerify.jboss.bindaddress must to be changed to the current IP address.

In the case of a normal (non-HA) cluster, if the Supervisor has multiple network interfaces connected to the same network and if DNS/WINS are not conﬁgured properly, troubleshoot this problem by doing either of the following:

By adding an entry containing the Supervisor host name and the IP address used by Cerify on Supervisor in "hosts" ﬁle, which can be found in

By bridging all the network interfaces together.

Clusters might not work correctly if there is momentary network outage in which case the clusters have to be restarted.

Related documentation

llowing documents are available:

The fo

y Online Help

Cerif

fy User Manual (Tektronix part number, 077-0352-xx)

Ceri

fy Release Notes (Tektronix part number, 077-0752-xx)

Ceri

fy Third Party Software License Notice Document (Tektronix part number, 001-1513-xx)

Ceri

ify Upgrades Read This First (Tektronix part number, 061-4355-xx)

Cer

C:\WINDOWS\system32\drivers\etc in all the Media Test Units.

xii Cerify Quick Start User Manual

Installation

Before installation

Network connection

Before installing the C erify application, your PC must be correctly connected to your local network.

This allows the following:

The Cerify application to test the ﬁles that are available on other machines on the network.

Other machines to interact with Cerify automatically (for example, using CeriTalk automation clients, copying of report ﬁles to net

work locations, or using email).

Installation

Multiple u

For the las Network settings on the PC are conﬁgured in the usual manner using Windows. If your machine is not properly conﬁgured or you do not know the name or IP address information, contact your system administrator.

Install

Before installing Cerify, you should be aware of the following information:

If Cerify is installed in a location other than the default location, then you must make the following changes before

using Cerify:

It is recommended that the Cerify application be installed on a machine where it can be used as the sole running application. Cerify makes intensive use of both CPU and memory and will considerably degrade the performance of other running applications. Similarly, running other applications or services simultaneously will degrade the performance of Cerify and increase the time taken to process a media ﬁle.

sers to connect to the Cerify Web user interface from remote computers.

t two cases, you need to know the IP address or the network name of the machine that Cerify is installed on.

ation considerations

By default, the “Execute script” rule (in the “On error” section and “On Success” section) in the sample “DPP Application” action template is conﬁgured with the script location as “C:\Program Files (x86)\Tektronix\Cerify\action_scripts\DPPApplication.exe”. This needs to be changed to “<Cerify_Installation_Location>\action_scripts\DPPApplication.exe”.

The DPP Application requires CeriTalk’s IP and port num ber details. In the case of ENT cluster, it should be supervisor’s IP. In the case of HA cluster, it should be CeriTalk’s IP address, which is common for both supervisors.

If the port number of Cerify is changed (from the cerify.properties ﬁle), then the Cerify IP address and port number should be passed as the ﬁrst argument for “DPPApplication.exe” in the Sample “DPP Application” action template. For example, if port number 90 is used on 192.158.11.201, then 192.158.11.201:90 should be supplied as the ﬁrst argument.

Cerify relies on third-party software applications that are packaged and installed with it: JBoss and MySQL. If these applications are already used on the PC, you should remove them before attempting to install the Cerify.

The Cerify license server relies on Sentinel HASP (formerly Aladdin HASP SRM) drivers, which are installed and conﬁgured along with it. It is recommended t hat other applications that rely on HASP licenses not be used with Cerify on the same machine.

Cerify Quick Start User Manual 1

Installation

Cerify uses a number of network services that are local to the host PC. These services can sometimes be blocked by personal ﬁrewa start up, a check is made to verify that communication with HASP can be established. If the Cerify application is unable to communicate with HASP, an error message, Unable to connect to HASP License Manager (port 1947). Please check

if the HASP Lic

ll software, in which case an error message will be displayed when Cerify starts. For example, on Cerify

ense Manager service is running and is not b locked by a ﬁrewall is displayed and Cerify is stopped.

In such situat entirely.

An installation log is written to the "%userproﬁle%\Cerify\CerifyInstallationLogs_<Timestamp>" folder. This log gives details of selections you made during the install and any errors encountered in case of failure to install.

If you would like m ultiple users to be able to run the Cerify application on the PC, make sure you select a location that has read and private directory is not suitable in this case.

While choosing the location for storing temporary video ﬁles during installation, make sure that there is sufﬁcient free space in this folder to store large video ﬁles

Cerify uses the computer name (as stored in the environment variable named "COMPUTERNAME") to uniquely identify some of its

Cerify wi example, the IIS Admin service, Skype or Apache). You can run Cerify once y ou shut down the other port 80 services running on the system. Alternatively, you can conﬁ gure the Cerify Web port to use a port other than 80.

It is not possible to i nstall a lower version of Cerify when you have a higher version of Cerify already installed. For example, uninstall Cerify 6.1 and then install Cerify 6.0.

ions, conﬁgure the ﬁrewall to allow the service on the appropriate port, or alternatively disable the ﬁrewall

write permissions for those users as the temporary video folder. A directory located within a user's

network services. This will not work if non-ASCII characters are used in the computer name.

ll fail to run if any other Web services using port 80 are running on the system where the Cerify is installed (for

if you install Cerify version 6.1 and then you want to go back to C erify version 6.0, you will need to ﬁrst

2 Cerify Q uick Start User Manual

Software installation

The installation of the Cerify application takes several minutes; typically between 5 and 15 minutes depending on the speed of your PC.

CAUTION. To prevent installation problems, be sure to read about the known installation limitations. (See page 1,

Installation considerations.)

To install Cerify, you need to perform the following steps:

1. Run the Cerify Ins taller.

2. Insert the Cerify dongle(s).

3. Optional: Install Apple QuickTime Player.

Running the Cerify installer

Installation

To run the Cerify i

Ensure that you a

NOTE. If you try to install the Cerify application without administrator privileges, the following message appears: “The Cerify

application can be installed or uninstalled only by a system administrator. Please log in as administrator and try again”.

Insert the Cer the Cerify installer. Follow the on-screen instructions to perform the installation.

NOTE. If you try to install the Cerify application on an unsupported platform (See page x, Supported platforms.), then the

following mes has not been validated on this OS. Do you wish to continue installation?”

The Cerify installation will not continue on a Windows XP platform. The installer displays a message saying Windows XP is not supported and the installation is aborted.

If the browser does not open automatically, or if the Install Cerify link does not work, navigate to the Exec folder located on the Ceri to perform the installation.

A number of third party software applications are installed during the installation process. Most of these are not visible, but youwillbenotiﬁed as the WinPcap and HASP drivers are installed.

nstaller, do the following:

re logged in as a user with administrator privileges.

ify DVD provided by Tektronix. The Cerify Application Browser opens. Click the Install Cerify link to launch

sage appears: “This is not a supported Windows operating system. Cerify will probably operate correctly but

fy Software Installation DVD and double-click CerifySetup<version>.exe. Follow the on-screen instructions

NOTE. Win

to troubleshoot networking issues with Cerify.

Cerify Quick Start User Manual 3

Pcap is not used in the normal operation of the Cerify application. It is used when you collect support diagnostics

Installation

Installation options

Cerify can be installed in the following ways:

Standalone

Supervisor (for an Enterprise cluster): The Supervisor unit controls the cluster system. It hosts the database and the Web server, allowing multiple users to set up and view Jobs. Use this option to install the Supervisor for a normal cluster (without high availability support).

Media Test Unit (for an Enterprise cluster): Each Media Test Unit is responsible for processing the digital media ﬁles in a networked cluster. Use this option to install Media Test Units for a normal cluster (without high availability support).

Supervisor (for an HA cluster): Use this option to install the Primary Supervisor for an HA (high availability) cluster.

Secondary Supervisor (for an HA cluster): Use this option to install a Secondary Supervisor for an HA (high availability) cluster, which will act as the Primary Supervisor if the Primary Supervisor system goes down.

Media Test Unit (for an HA cluster): Use this option to install Media Test Units for an HA (high availability) cluster.

NOTE. During the installation of Cerify, if there are multiple network interfaces in the system, the installer provides the list of

network interfaces and asks the user to select a network interface to be used by Cerify.

While installing the Supervisor and the Secondary Supervisor (in the case of an HA cluster), the installer also provides the option to select the network interface for communication (i.e. the interface used for communicating with Ce rify via either Ceritalk or the Web user interface).

The installer also provides an option to install Cerify as a service. This option is selected by default. If you want to install Cerify in application mode, this option needs to be deselected.

4 Cerify Q uick Start User Manual

Installation

Installing Cerify as a Supervisor. To install Cerify as a Supervisor, follow the steps described in Running the Cerify

installer.(Se

e page 3.) During the installation, a dialog box appears with the list of installation options.

To continue wi Cluster” in the installation options dialog box.

To install the Supervisor for an HA cluster, select Supervisor under the option “High Availability Enterprise Cluster” in the installation options dialog box.

During the installation, a dialog box appears where you must:

Enable or disable ﬁle-processing option on the Supervisor.

Enter the number of channels if you have selected the ﬁle processing option on the Supervisor.

Choose the network interface to be used by Cerify.

Choose the network interface to be used for all Cerify communication. This option is available only while installing the Superv

Enter the h HA cluster.

Enter the host names for all the Media Test Units if you want to install the cluster based on unicast communication since most of the switches drop multicast packets.

At the end of the installation, the installer prompts you w ith an option to load the demo content. If you choose this option, Cerify wi

th the Supervisor installation for a normal Enterprise cluster, select Supervisor under the option “Enterprise

isor for an HA cluster.

ost name of the Secondary Supervisor. This option is ava ilable only while installing the Supervisor for an

ll be loaded with a demo database, which will contain some sample jobs with results.

Installing Cerify as a Secondary Supervisor. Follow the steps described in Running the Cerify installer (See

page 3.) to install Cerify as a Secondary Supervisor for an HA cluster. During the installation, a dialog box appears with the list of installation options.

To continue with the Secondary Supervisor installation, select Secondary Supervisor under the option “High Availability Enterprise Cluster” in the installation options dialog box.

During the installation, a dialog box appears where you must:

Enable or disable the ﬁle-processing option on the Secondary S upervisor.

Enter the number of channels if you have selected the ﬁle processing option on the Secondary Supervisor.

Choose the network interface to be used by Cerify.

Choose the network interface to be used for all Cerify communication.

Enter the host name of the Supervisor.

Enter the host names for all of the Media Test Units if you want to install the HA cluster based on unicast communication since most of the switches drop multicast packets.

Cerify Quick Start User Manual 5

Installation

Installing Cerify as a Media Test Unit. Follow the steps described in Running the Cerify installer section to ins tall

Cerify as an Med

ia Test Unit.(See page 3.) During the installation, a dialog box appears with the list of installation options.

To continue wi Cluster” option in the installation options dialog box.

To continue with the Media Test Unit installation for an H A cluster, select Media Test Unit under the “High Availability Enterprise Cluster” option in the installation options dialog box.

During the installation, a dialog box appears where you must:

Enter Host name of the Supervisor.

Enter the host name of the Secondary Supervisor. This option is available only while installing Media Test Unit for an HA cluster.

Choose the n

Enter the n

th the Media Test Unit installation for a normal Enterprise cluster, select Media Test Unit under the “Enterprise

etworkinterfacetobeusedbyCerify.

umber of channels.

Conﬁguring a non-HA cluster. To co n ﬁgure a non-HA cluster, you must:

Install Cerify as a Supervisor on the system which must be conﬁgured as supervisor of the cluster.

Install Cerify as a Media Test Unit on one or more systems.

When installing Cerify as a Media Test Unit, the installer prompts you to enter the Supervisor host name. The installer checks whether the Media Test Unit can reach the Supervisor system using the host name entered. If the Supervisor system cannot be reached, a message appears whether you still want to continue the installation.

You can also conﬁgure multiple clusters on the same network. To conﬁgure multiple clusters o n the same network, you need to install multiple Supervisors. During a M edia Test Unit installation, in the Cerify System Settings dialog box, you must enter the respective Supervisor host name.

NOTE. To c o n ﬁgure a cluster, the versions of Cerify on the Supervisor and the Media Test Unit should be the same. Once the

installation is complete, Cerify will be started on both the Supervisor and the Media Test Unit. Access Supervisor using Cerify Web UI and navigate to the Admin page, click the Media Test Units link to the page containing the list of Media Test Units.

6 Cerify Q uick Start User Manual

Conﬁguring an HA Cluster. To c onﬁgure an HA (high availability) cluster, you must:

Install Cerify as a Supervisor by choosing Supervisor under the “High Availability Enterprise Cluster” option on the system that is

to be conﬁgured as the Primary Supervisor of the cluster.

Installation

Install Cerif Cluster” option on the system that is to be conﬁgured as the Secondary Supervisor of the cluster.

Install Cerify as a Media Test Unit by choosing Media Test Unit under the “High Availability Enterprise Cluster” option on one or more systems.

When installing Cerify as a Media Test Unit for an HA cluster, the installer prompts you to enter the host names of the Supervisor and Secondary Supervisor systems using the host names that you entered. If either the Supervisor or Secondary Supervisor system cannot be reached, a message appears asking whether you still want to continue the installation.

NOTE. To c o

Media Test Units should be the same. Once the installation is complete, Cerify will be started on the Supervisor, Secondary Supervisor, and the Media Test Units. Access the Supervisor using the Cerify Web UI and navigate to the Admin page. Click the M

y as a Secondary Supervisor by choosing Secondary Supervisor under the “High Availability Enterprise

and Secondary Supervisor systems. The installer checks whether the Media Test Unit can reach the Supervisor

nﬁgure an HA cluster, the version of Cerify that is installed on the Supervisor, Secondary Supervisor, and the

edia Test Units link to the page containing the list o f Media Test Units.

Conﬁguring a network bridge

If the system has multiple network adapters, it is recommend that you b ridge all the network adapters.

1. From the Start menu, select Control Panel > Network C onnections.

2. Select two network adapters at the same time, right-click and select Bridge Connections. Windows will build up a

network bridge automatically. When the bridge is built successfully, the two adapters’ IP address disappears.

3. Select the Network Bridge and conﬁgure a new IP address in the Properties menu for LAN connections.

NOTE. To c on ﬁgure a cluster, the versions of the supervisor and the Media Test Unit should be the same. Once the

installation is complete, Cerify will be started on both Supervisor and Media Test Unit. You can access Supervisor using Cerify Web UI and navigate to the Admin page on Web UI, Click the M edia Test Unit Details link to the page containing the list of Media Test Units.

Cerify Quick Start User Manual 7

Installation

Installation folders

During the installation process, select the following locations:

Installation Location: The folder where the application is installed.

Temporary Storage Location: Before processing media ﬁles from an external server, Cerify may need to copy the

remote ﬁles to the PC on which the Cerify application is installed. This folder is used as the location to store such temporary copies. Cerify copies the ﬁle only when operating in copy mode and accesses the ﬁle using the ftp://, smb://, or gvg:// protocols. See Modes of Operation in Appendix E of the Cerify User Manual for help determining the mode that applies to your installation.

NOTE. There should be sufﬁcient free space in the temp folder to store large video ﬁles. The location for this temp folder

can be on any drive on the computer.

If you would like multiple users to be able to run the Cerify application on the PC, make sure to select a location that has read and write permissions for those users. A temporary directory located within a users private directory is not suitable in this case.

Inserting the Cerify dongle

e Cerify license dongle supplied with the system in any of the available USB ports of your computer. In the case of

Insert th normal Enterprise cluster, the dongle should be inserted in the USB port of the Supervisor system. In the case of an HA cluster, you will be supplied with two identical dongles. The two dongles should be inserted in the USB port of both the

sor and Secondary Supervisor systems.

Supervi

NOTE. Do not insert the dongle before the Cerify installation. Insert the dongle only when the installer prompts you.

NOTE. If Cerify reports license failures after the dongle has been installed, it is possible that ﬁrewall software is interfering

e license service. Please ensure that port 1947 is open in any ﬁrewall software that is in use. See Licensing l imitations

with th for a list of other possible causes of license failures. (See page 9.)

The number of ﬁles that can be simultaneously processed by Cerify will be the number of allowed channels speciﬁed in the

le. If a time-expiry dongle is connected, the default number of ﬁles processed is 1.

dong

times, you will need to change the number of ﬁles that can be simultaneously processed by Cerify. You can change

Some the number of parallel processing channel setting by changing the value of the property “cerify.processorsperbox” in the “cerifysystem.properties” ﬁle located at

The following lists the different si tuations for standalone installation:

When Cerify is started w ith no dongle connected, t hen (irrespective of whether a value has been speciﬁed in the

rify.processorsperbox” property or not) the number of allowed channels is zero.

“ce

n Cerify is started with a perpetually licensed dongle and if the “cerify.processorsperbox” property is not set then the

Whe number of allowed channels is controlled by the dongle.

When Cerify is started with any valid dongle and a valid number of channels is speciﬁed for the “cerify.processorsperbox” property, then this value would be used if it is less than or equal to the number of channels controlled by the dongle.

the value is greater than the number of channels controlled by the dongle then the number of channels controlled

If by the dongle takes precedence.

<Installation Directory>/Cerify/JBoss/server/all/conf.

8 Cerify Q uick Start User Manual

When Cerify is started with any valid dongle and the number of channels speciﬁed for the “cerify.processorsperbox” property is -1,

then the number of allowed channels is controlled by the dongle.

Installation

When Cerify is number of allowed channels is set to 1.

started with a time-expired dongle and if the “cerify.processorsperbox” property is not set, then the

Installing Apple QuickTime Player

To process Apple ProRes ﬁles using the Generic QuickTime Video template or to process ﬁles using the JPEG 2000 Video templates, you have to install QuickTime Player. Download QuickTime player from the link: www.apple.com/quicktime/download/.

NOTE. If you already have QuickTime Player installed, make sure that it is version 7.5.5 or later.

Licensing limitations

The follo

wing limitations may affect the ability to license Cerify:

The Cerif (as used with Cerify 5.x and earlier) without updating the dongle ﬁrmware. Green HASP Max dongles (as used with CerifyLite) are no longer supported.

When multiple HASP license servers are available on the network, there is a chance that the Cerify unit will try to retrieve its lice

It is pos might be desirable if the Cerify hardware does not have a USB port - e.g. blade hardware. Contact your Tektronix representative for more information on how to do this.

y 6.0 or later software requires the use of a HASP NetTime dongle. It is not possible to use a HASP Net dongle

nse from a wrong server and fail to obtain the required features, resulting in licensing errors.

sible to insert the HASP license dongle into a different machine from that on which Cerify is installed. This

It is possible for the license server to retain handles to license features that were being used by a Cerify machine that

denly lost power or otherwise failed. As a result of this the Cerify application will not be able to obtain a license

has sud until the license server is restarted. This will only be a problem when the license dongle is not on the Cerify machine, so in this conﬁguration we recommend that the license server machine is restarted when the Cerify application is restarted.

If Cerify reports license failures after the dongle has been installed, it is possible that ﬁrewall software is interfering with

cense service. Please ensure that port 1947 is open in any ﬁrewall software that is in use.

the li

Cerify Quick Start User Manual 9

Installation

Software u ninstallation

Before uninstallation, ensure that you have administrator privileges. If you try to uninstall Cerify without administrator privileges, the uninstallation process will be aborted.

Cerify can be uninstalled in two ways:

Through Start > Control Panel > Add or Remove Programs.

By rerunning the CerifySetup<version>.exe that you used to install the current version and following the on-screen instructions.

NOTE. If the C erify installer version is higher than the currently installed version, the installation will be upgraded to

the newer version.

If the Cerify installer version is lower than the current installed version, the installer will abort without taking any action.

NOTE. The Cerify installation process places the WinPCap and HASP utilities in the Add or Remove Programs list. The

uninstallation process does not remove WinPCap in case it is being used by other programs or you want to continue to use it for other purposes. The HASP drivers are uninstalled. If you want to uninstall WinPCap, this can be done in the usual way from the Add or Remove Programs list.

NOTE. If you select the Backup database option during uninstallation, the current database will be backed up to

uments and Settings\<username>\Cerify\CerifyBackup_<ve rsion>_<timestamp>

the option to change the directory where you want to back up the database. All relevant conﬁguration ﬁles will be backed up to

C:\Documents and Settings\<username>\Cerify\CerifyCo nfig_<version>_<timestamp>

The "Backup database" option w ill not be available if you are uninstalling the Media Test Unit, as the Media Test Unit does not have its own database.

NOTE. If Cerify 6.0 is uninstalled using Add or Remove Programs option or using Cerify 6.0 installer, there will be no

“backup” option. The Cerify database and conﬁguration ﬁles will always be backed up at the location

and Settings\<username>\Cerify\CerifyBackup

the directory name “CerifyBackup” to “CerifyBackup_6.0”.

Uninstalling a cluster

To uninstall a cluster, do the following:

Uninstall Cerify on the Supervisor.

Uninstall Cerify on the Secondary S upervisor (in the case of an HA cluster).

Uninstall Cerify on all of the Media Test Units.

Software reinstallation

C:\Doc-

. You are given

C:\Documents

. When Cerify 7.x is installed, the installer will change

To reinstall Cerify, you must uninstall Cerify, and then rerun t he installer. Rerunning the installer that was used to install the current version of Cerify will cause Cerify to be uninstalled. It does not repair the existing installation.

10 Cerify Quick Start User Manual

Software upgrade

To upgrade your existing version of Cerify to the latest version, run the setup ﬁle for the latest version of Cerify and follow the on-screen instructions.

NOTE. Dongles used with previous versions of Cerify need to be reprogrammed to be used with version 7.2 or above. If an

existing version of Cerify is being upgraded to version 7.2 or above, then it is recommended that users send in their c2v ﬁles to Tektronix to obtain a new corresponding v2c ﬁle before installing the upgrade. This will allow users to program the dongle with the new v2c ﬁle before using Cerify version 7.2 or above.

If you want to upgrade Cerify in an HA cluster installation, the HA dongles on the Supervisor and Secondary Supervisor systems both need to be upgraded.

It is possible to upgrade any type of Cerify installation to any other Cerify installation type (for example, upgrading a Media Test Unit to a Supervisor).

If you would like to back up the current database while you are upgrading from Supervisor, Secondary Supervisor, or Standalone Cerify, choose the Backup database option during the upgrade process. The current database is backed up to the location

name>\Cerify\CerifyConfig_<version>_<timestamp>

a different folder for backing up the ﬁles.

Installation

C:\Documents and Settings\<User

by default. You may change this location by choosing

The upgrade process also backs up relevant conﬁguration ﬁles from the current installation. These ﬁlesarebackedupto

C:\Documents and Settings\<User name>\Cerify\CerifyBackUp_<version>_< timestamp>.

When you are upgrading to a Supervisor or standalone Cerify, the database is upgraded automatically after the installation. If the database upgrade fails, the installer will install Cerify with a clean database and inform you about the failure. The Backup database option will not be available while upgrading from Media Test Unit as they do not have their own database and process the ﬁles from the Supervisor's database.

Upgrading a cluster

t the installer CD and follow the on-screen instructions. To upgrade a cluster, do the following:

Inser

de Cerify on the Supervisor by running the latest version of installer and choosing Supervisor as installer type.

Upgra You can upgrade to either Supervisor for a normal Enterprise cluster or to Supervisor for an HA cluster by choosing the appropriate options.

Upgrade Cerify on the Secondary Supervisor by running the latest version of installer and choosing Secondary

rvisor as the installer type.

Supe

rade Cerify on all of the Media Test Units by running the latest version of installer and choosing Media Test Unit

Upg as the installer type. You can upgrade to either Media Test Unit for a normal Enterprise cluster or to Media Test Unit for an HA cluster by choosing the appropriate options.

Refer to the Software upgrade section for instructions on upgrading. (See page 11.)

Cerify Quick Start User Manual 11

Installation

Reverting to the previous version of Cerify

In some circumstances, such as a failed software upgrade, you may wish to revert to an older version of Cerify. To do this, follow these steps:

NOTE. Before proceeding, you should have a database backup and a copy of conﬁguration ﬁles from the version you

would like to revert to.

1. Uninstall the current version of Cerify. While uninstalling, back up the database by selecting the Backup database option.

2. Install the older version of Cerify.

3. Restore the database of older version using the CerifyDatabase Utility tool. For help on how to use this tool, re

“Database Backup/Restore Utility” section in the user manual.

Network settings

NOTE. The Cerify software does no particular conﬁguration of any network interfaces - IP address, netmask, DNS, Net

BIOS, etc. These s hould be set using the usual Windows methods.

Two network interfaces

In most circumstances, the PC on which Cerify is installed requires only one network interface. There are three scenarios where it is necessary to have two network interfaces:

When the network on which the Web clients will access the Web user interface needs to be physically separate from the network that stores the media ﬁle assets.

When the Cerify system is to access media ﬁles from a Grass Valley Pro ﬁle or K2 server. In this case, the additional network interface should be connected to the control network that runs the Grass Valley AMP service. This enables Cerify to list the contents available on the Grass Valley servers. The ﬁrst network interface on the PC should continue to be connected to the video server network as follows:

On a standalone Proﬁle XP, to either the Media Ethernet card, if present, or the Ethernet interface of a Universal Interface Module (UIM), if present

fer to the

On a SAN-based Proﬁle XP network, to the Gigabit M edia network provided by a Universal Interface Module, if present

On a SAN-based K2 network or a standalone K2 Media Client, to the Media/FTP network

For a K2 network, it is possible to use direct FTP connectivity, in the same fashion as other video servers. In this case, the AMP control network does not need to be accessed and no additional network interface is needed.

When installing a Super network is used for communication to Cerify via Ceritalk or Web user interface.

visor or Secondary Supervisor for an HA (high availability) cluster. In this case, the second

Conﬁguring the Cerify installation

See Appendix E: Conﬁguring Your Cerify Installation in the Cerify User Manual for information about how to conﬁgure your Cerify installation for the best performance.

12 Cerify Quick Start User Manual

Operation

Getting acquainted

User interface

The user interface consists of a structured collection of pages accessed using a Web browser. The following ﬁgure shows the elements that are common to most of the pages in the Cerify Web user interface. The Jobs Monitor page will not contain any jobs whe the tutorial. The elements of the Job Monitor page are shown and described in the following ﬁgure and table.

n you login to Cerify for the ﬁrst time after the installation, but will look similar to the following after you perform

Operation

Item Descri

1. Navigation bar

2. Auto-

3. Ta b les

4. Footer

5. Archive/Restore

6. Ac

7. Trail widget

8. Icon

Refresh and

ntrol

tive/Archive

View Control

The na

Click the navigation bar at the top-right section of the screen, show who you are logged in as and provide a link enabling you to log out. The license status of Cerify is also reported in this section.

The system displays a collection of entities in the form of tables. Several types of entities can be

ted, edited, and displayed, such as Jobs, Proﬁles, Templates, MediaSets, MediaLocations,

crea and Users. The role of these entities and the relationship between them is explained later in this manual. (See page 18, Overview.)

The footer displays a copyright notice and version information.

The Archive/Restore control allows you to archive and restore entities.

e Active/Archive view control allows you to choose which entities of a particular type to view.

NOTE. When an entity is archived, it is not removed from the database, but it becomes inactive.

You cannot construct new entities from inactive entities.

The trail widget allows you to see your position in the hierarchy and navigate from this position.

The following table lists the icons used in the interface. (See Table 1.)

ption

vigation bar provides a quick route to the top level of any of the pages.

Auto-Refresh to On to view update progress and job status. The login details, located below

Cerify Quick Start User Manual 13

Operation

Table 1: User interface icons

Icon Description

Collapse this section

Expand this section

Copy this ite

Remove this item

Edit this item

Directory

File in a directory

Open a context-sensitive help topic

Status unknown

Failed wi

Failed with an error status

Failed with a warning status

Succeed

Item created through the Cerify Web user interface

th a fatal error status

ed with no errors or warnings

Item cre

Sort items in this column in descending order

Sort items in this column in ascending order

Click this button to trigger the selected action

Adds another set of values to the rules

Removes any set of values from the rule

ated through CeriTalk API

Accessing the online help

You can access help topics by clicking Help on the Navigation bar or clicking the icon.

14 Cerify Quick Start User Manual

Concepts

This section introduces the central c oncepts and entities used within the system. These entit ies and their relationships are shown in the following ﬁgure.

NOTE. The following ﬁgure indicates the basic relationships between the entities. For simplicity, the ﬁgure shows one of

each type of entity. In practice, there can be many instances of each type of entity, with each child entity potentially being used by multiple parent entities.

Operation

Users

Before using the system, you must l og in with your user name and password credentials. These credentials are assigned by a user who has administrator access.

By default, the system is i nstalled with a single predeﬁned user whose name and password are both set to admin.You should change the password after you log in for the ﬁrst time. Administrator access rights allow you to modify system properties, and in particular to c reate and modify MediaLocations and Users.

MediaLocations

A MediaLocation is a local or network ﬁle storage location from which the system can access m edia ﬁles. Typically, this is a directory on the hard drive or a video server that provides FTP or Windows ﬁle share access. To create a MediaLocation, you

st supply its URL and the user name and password required to access this URL. In addition, you must supply a unique

mu name to be used within the system to identify the MediaLocation.

Only users with administrator access ar e able to create or modify MediaLocations.

Cerify Quick Start User Manual 15

Operation

MediaSets

A MediaSet i s a collection of media ﬁles that you want to check.

A MediaSet can be a DropBox. A DropBox is a directory that is continually monitored for new media ﬁles. A MediaSet that is not a DropBox is simply a static collection of media ﬁles manually selected from one or more of the MediaLocations.

If a Job is associated with a DropBox, every ﬁle that appears in the DropBox over time will be processed.

Templates

To check a media ﬁle, you must deﬁne which checks should be applied when the ﬁle is tested. A Template is a collection of such checks chosen to perform speciﬁc tests required by you. The four types of Templates are:

Container Templates, which apply to the transport/container layer of a media ﬁle

Video Templates, which apply to the digital video content of a media ﬁle

Audio Templates, which apply to the digital audio c ontent of a media ﬁle

Action Templates, which specify actions to be performed as a result of processing a media ﬁle

You can create multiple Templates of the same type for different purposes. For example, you might create a Movies Template, which contains a set of rules appropriate for HD MPEG-2 content, and an on-line content Template, which contains a set of rules appropriate for lower resolution H.264/AVC content.

NOTE. Some example templates are preloaded onto C erify. These templates can be used, copied, edited, and archived in

the same way as those created by users. The XML ﬁles containing these templates can be found in

directory>/Example Templates

<Installation

Proﬁles

AProﬁle gathers together a container, video, audio, and action Template, providing a complete set of checks that can be applied when you want to test one or more media ﬁles. Any of the component Templates can be omitted, depending on your requirements. For example, it makes no sense to apply any container or audio checks to a media ﬁle that consists solely of a video elementary s tream.

DPP Proﬁles

Digital Production Partnership (DPP) provides the guidelines for HD and S D ﬁle delivery. It also speciﬁes MXF metadata, which are mandatory to be delivered with the ﬁle. Cerify has “prepackaged proﬁles” needed for veriﬁcation of ﬁles delivered against the DPP constraints. When Cerify is installed, the prepackaged proﬁles will be visible under the Proﬁles tab. With the prepackaged “DPP Proﬁles,” Cerify processes the input ﬁles by attaching the right proﬁle for HD and SD delivery speciﬁcations, based on the audio track combinations.

Jobs

A Job is the term given to an individual testing process that can be run by the system. Each Job can process multiple media ﬁles or a single media ﬁle, depending on your requirement. The set of ﬁles processed by a Job is deﬁned by its MediaSet.

By creating a Job, you request the checks deﬁ ned by a particular Proﬁle be applied to the ﬁles in a particular MediaSet. In addition, you must specify the name and priority of the Job. The system can queue multiple Jobs to be run, whereby each Job is scheduled to be processed according to its priority.

16 Cerify Quick Start User Manual

The system processes one media ﬁle at a time. How long it takes to process a Job depends upon a number of factors:

The resolution of the video being processed

The video standard concerned (some standards, such as H .264/AVC, take more time to process)

The number of tests selected (performing all the video quality checks can be processor intensive, because it requires the analysis of ev

The bit rate

ery pixel in each frame of video)

Operation

Hardware per

formance of the PC on which Cerify is installed

Alerts

Alerts announce any checks that fail as a Job executes. Each alert indicates the severity of the failure, as well as w here and why the check failed. The system gathers alerts associated with a particular Job, so that you can access the results from the top level and easily navigate to the details, such as which individual frames have Alerts.

The system organizes and summarizes any alerts raised against a particular Job, so that, at the top level, a single processing result status can be assigned to the Job. To view more detailed information, you can drill down through the interface, revealing (for example) which individual frames have raised alerts.

Reports

Reports provide you with a way to query the system database and obtain information in a predeﬁned format. A Job report

s the results of a particular Job in tabular form.

present

Archiving

The system allows you to archive entities that are no longer required. MediaSets, Templates, Proﬁ les, and Jobs can all be archived. When an entity is archived, it remains present in the database, and can be recovered if necessary. Archived entities are inactive and usually hidden from view. Inactive entities cannot be used to construct new entities. So, for example, if a Job is archived before completion, it will not process any pending media ﬁles.

Clustering

To increase processing throughput, units can be clustered. Each cluster consists of a single Supervisor unit and one or more Media Test Units. In a clustered conﬁguration, the Supervisor unit hosts the database and the Web server. The Supervisor

t communicates with the rest of the local network, accessing media ﬁles and serving the Web user interface. The

uni Media Test Units are allocated media ﬁles to process by the Supervisor unit. The results of this processing are stored by the Supervisor unit into a single database.

owing ﬁle support

Cerify supports the processing of growing ﬁle on FTP, SMB, and File protocols. Cerify can start processing the ﬁle as soon as the ﬁle copy is started.

Cerify Quick Start User Manual 17

Operation

Audio loudness correction

Cerify supports audio loudness correction for AC3, Dolby E and PCM (RIFF, BWF, AIFF, AES3, 8-ch AES3) audio types. Cerify also supports rebundling of corrected audio tracks as follows:

MPEG transport streams: type AC3

MXF streams: types RIFF, BWF, AIFF, AES3, 8-channel AES3 and Dolby E formats

QuickTime streams: types R IFF, AIFF and Dolby E formats

An Audio Loudness Correction log contains details of the audio loudness correction performed by Cerify. The details include parameters such as audio loudness and dialnorm values, before and after correction.

Procedures

Overview

The following ﬁgure shows the dependencies between the entities that make up a Job. For example, a MediaLocation must exist to create a MediaSet and a MediaSet must exist to create a Job.

NOTE. AProﬁle requires at least one type of Template, not necessarily all four types.

18 Cerify Quick Start User Manual

How to start the Cerify application

Perform the following procedure to start the Cerify application.

NOTE. To run Cerify, the user should have administrator rights.

1. Click the Start C erify icon on the desktop to Launch the Cerify application.

Alternatively, the application may be started from the Windows Start menu. If Cerify is installed as a Windows service, the startup is controlled via the Services applet in the Windows Control Panel.

The startup time of the Cerify application can be up to 3 minutes. The application has started and is ready to use when you see a Cerify login page in your Web browser.

2. Enter your Username and the Password in the login page. The default Username and Password are admin.

Operation

3. Once you are logged in, you can see the Jobs Monitor page.

4. Once the application has started, you can access the Cerify Web user interface from any computer on the s ame network. You can access the Web user interface using the URL http://<C erify IP Address>:<http port> where <http port> is the value set for the property cerify.http.port.

NOTE. Cerify will fail to start if any other Web services using port 80 are running on the system where Cerify is installed. You

can run Cerify once you shut down other Web services running on port 80 on the system.

You can change the port number used by Cerify by updating the Cerify system property “cerify.http.port”. See the Conﬁguring the Cerify Application section in the Cerify User Manual for details on how to update Cerify system properties.

On start up, Cerify reads this port number from “cerifysystem.properties” and checks to ensure that this port is not used by any other application. If it ﬁnds the port number speciﬁed to be in use, an error message detailing the failure is displayed and startup operation is aborted. If the system cannot ﬁnd any value set to this system property, it w ill use the default port number 80.

Cerify Quick Start User Manual 19

Operation

How to start a cluster

Perform the following steps to start a cluster:

1. Start Cerify on Supervisor unit ﬁrst.by clicking Start > All Programs > Tektronix > Cerify > Start Cerify,orstart the Cerify service.

2. Start Cerify on the Secondary Supervisor unit by clicking Start > All Programs > Tektronix > Cerify > Start Cerify,or starttheCerifyservice(inthecaseofanHAcluster).

3. Start Cerify on Media Test Units by clicking Start > All Programs > Tektronix >Cerify Media Test Unit > Start Cerify, or start the Cerify service.

4. Enter the URL host name.

In the case of an HA cluster, you can use the IP address instead of the host name of the Suprvisor unit, which is conﬁgured for the network interface that was chosen for Cerify communication during the Supervisor installation.

NOTE. By selecting the Media Test Units link on the Admin page, it is possible to view the status of the Media Test Units

connected in a cluster. Since a standalone system does not connect to any Media Test Units, this link is unavailable in the Web UI of a standalone system. After clicking the link, you will be taken to the Media Test Units page which lists all the Media Test Units that are in the cluster.

http:// <Cerifyhost name> into your Web browser where Cerify host name is Supervisor's

20 Cerify Quick Start User Manual

How to create a Me diaLocation

You can create and modify MediaLocations only if you have administrator access to Cerify.

Operation

1. Click the Admi

n button on the Navigation

bar to access the Admin page.

2. In the Cerify Administration page,

click the Go button to create a new MediaLocation.

3. In the New MediaLocation page, ﬁll in

the ﬁelds

as follows:

MediaLoc

ation Name:Cerify

example content

URL: c:\Program

Files\Tektronix\ Cerify\

cerify_demo

NOTE. The URL used above assumes that

you have installed Cerify in the location,

gram Files\Tektronix\Cerify.

C:\Pro

NOTE. Leave the Username and Password

ﬁelds blank.

4. Click Create.

Cerify Quick Start User Manual 21

Operation

How to create a MediaSet

Once you have created a MediaLocation, you can create a MediaSet that collects the ﬁles at this location.

1. Click the Medi Navigation bar.

2. In the MediaSets page, click the New MediaSet button to create a new

MediaSet.

3. In the New MediaSet page, do the following:

Fill in the Name ﬁeld.

Set the DropBox ﬁeld to no.

4. Click Create.

aSets button on the

22 Cerify Quick Start User Manual

5. In the Edit MediaSet page, you can do

the following:

Add ﬁles to the MediaSet by browsing

through the ne

twork or by entering the full path of the ﬁle in the File name text ﬁeld at the bottom of the page (the path mus the ﬁle, for example,

Files\Tektronix\ Cerify\cer airport_interview.ts

t include the full URL of

c:\Program

ify_demo\news\

NOTE. Only ﬁles that exist within

folders/s

ub-folders of an existing MediaLocation can be added to a MediaSet.

For Microsoft Smooth Streaming (MSS) format, th

e MediaSet should point to the

“.ism” ﬁle.

Operation

View the c

ontents of a directory by

double-clicking the directory icon.

Close the directory and go up a level,

open the drop-down menu at the top

the ﬁle browser to provide a

right of selection of recent directories.

Select a ﬁle by double-clicking the ﬁle

(

) icon.

Cerify Quick Start User Manual 23

Operation

How to create a Template

To test the ﬁles in the MediaSet that you have created, you need to decide the checks to apply. You can apply checks to the container or wrapper layer, the video stream, and the audio stream, using container, video, and audio Templates, respectively.

1. Click the Templates buttononthe Navigation bar.

2. In the Templates page, scroll down to view the Vide click the New Video Template button.

o Templates section and

3. In the Select Template Type page, do the following:

Select the type of Template from

the Please select a type for the template drop-down menu.

Click Select.

NOTE. The Template type you choose

depends on the type of video content you want to check. This type will be the Video Standard used when the video was encoded, for example, MPEG-2 or H.263.

24 Cerify Quick Start User Manual

Operation

4. In the New Templ

ate page, enter a name

for the Template.

5. Conﬁgure the checks to be applied by

selecting the check boxes and entering values into the text ﬁelds.

6. Use the buttons to conﬁgure

olution rule w ith multiple sets of

the Res valid values. For a full explanation of the checks performed by each rule, click the

ext to each rule name.

icon n

Cerify Quick Start User Manual 25

Operation

7. Click the Create button at the bottom of the page to create the new Video Template.

NOTE. The new T

Create, the system will check that the ﬁelds you have ﬁlled contain valid data, and prompt you to ﬁx any problems. If there are no problems, the new Template will be created and stored in the database.

When this MPEG-2 Video Template is used to check a video stream, it will check the following:

The video is MPEG -2 encoded.

The video is encoded using MPEG-2 Main Proﬁle, Main Level.

The video bit stream syntax conforms with the MPE G-2 Standard, but any alerts relating to Buffer analysis and alert number 22209 are suppressed.

A maximum of 500 alerts are displayed.

Each alert type is displayed a maximum of 20 times.

The video resolution is 720 by 480 pixels or 1280 by 1080 pixels.

You can also create an Audio Template and a Container Template similarly.

To create an Audio Template, select New Au dio Template and select MPEG-1 / MPEG-2 Audio as the template type. For the Cont

NOTE. In this example, you will not create an Action Template. If you want to check a different video format, you should

select a different codec type in step 3 of the Creating a Template procedure.

ainer Template, select MPEG-2 Transport Stream as the Template type.

emplate will not be saved until you click the Create button at the bottom of the page. When you click

26 Cerify Quick Start User Manual

How to create a Proﬁle

To use your new Video Template in a Job, you must include it in a Proﬁle.

Operation

1. Click the Proﬁ

navigation bar.

2. In the Proﬁles page, click the New

Proﬁle button.

3. In the New Proﬁle page, enter a name

and a desc

4. Select th

from the drop-down menu. You can select multiple audio templates, if requi

5. Click Cr

les button on the

ription for the Proﬁle.

e Templates you have created

red.

eate to create the Pro ﬁle.

Cerify Quick Start User Manual 27

Operation

How to create a J ob

Once you create a MediaSet and a Proﬁle, y ou can create a Job.

1. Click the Jobs bar.

2. Click the New Job button.

3. In the New Job page, do the following:

Enter a name for the Job.

Set the Job Priority to Low.

4. Select the Proﬁle and MediaSet that you have created.

5. Click Create to create the job.

How to in

button on the navigation

spect Job results

1. Click the Jobs button on the Navigation

bar.

2. In the Job Monitor page, click the

fresh button in the page header.

AutoRe

3. In the

Jobs Monitor page, view the Job

results. The Job has succeeded.

icon indicates that the

28 Cerify Quick Start User Manual

How to generate a Report

1. Click the Reports buttononthe

Navigation bar.

2. In the Reports page, enter the name of

the job that you c reated in the Enter

Jobname ﬁeld.

3. Click the Generate button to generate a

report of your Job.

Operation

How to archive the Job

1. Click Jobs on the Navigator bar.

2. In the Job Monitor page, select the Job

you want to archive by selecting the check box in the left column of the Jobs Monitor table.

3. Ensure that the action drop-down menu

under the table shows Archive.

4. Click Go to archive the Job.

5. To view archived Jobs, set Show Jobs

to Archived.

Cerify Quick Start User Manual 29

Operation

How to access the Web User Interface

To access the application, you will need a Web browser installed on your computer.

To access the Web user interface from a remote computer, you need to know the IP address of the PC on which Cerify is installed in Standalone or Supervisor mode.

In the case of non-HA cluster or Standalone installation, enter the URL http://<Cerify IP address> into your Web browser where "Cerify IP address" is the IP address of the system, where Cerify is installed in Standalone or Supervisor mode.

In the case of HA cluster, enter the URL http://<Cerify communication IP address> into your Web browser where “Cerify communication IP address” is the IP address conﬁgured for the network interface that was chosen for Cerify communication during the Supervisor installation.

NOTE. For cluster conﬁguration, Tektronix recommends that the Supervisor, Secondary Supervisor (in the case of an HA

cluster), and Media Test Units are each conﬁgured with a static IP Address.

To access the Web user interface in a more convenient fashion on the PC on which C erify is installed, click Start > All Programs > Tektronix > Cerify > Launch Cer ify Web UI. This will automatically launch your default Web browser and

take you to the correct Cerify Web page. Alternatively, when Cerify is installed as a Windows application, you can do this by right clicking on the Cerif y system tray icon and selecting Launch Cerify Web UI. The system tray icon is not available when Cerify is installed as a Windows service.

NOTE. To access the Web user interface o n a Media Test Unit, click Start > All Programs > Tektronix > Cerify Media

Test Unit >Launch Cerify Web UI.

Logging in to the application. When you access the Cerify Web page, you are presented with the Cerify application

1. Enter your Username and Password in the login page. Once these credentials have been correctly supplied, the Cerify Web browser will display the top level Jobs page.

2. Use your mouse and keyboard to navigate this Web interface and enter information in the usual way.

NOTE. The default user name is “admin” and password is “admin”.

NOTE. If the user name and password are invalid, an error message appears, and you will remain on the login page. There

is no limit to the number of times you can attempt to log in. Use r names are case sensitive, so if you have trouble logging in, check the Caps Lock key. If you forget your password, contact the Cerify administrator.

CAUTION. If a session is inactive for a period, you will automatically be logged out. Any attempt to resume the session

will redirect you to the login page.

Logging out of the application. Click the text that reads Log out in the page header to log out of the application.

This returns you to the login page.

30 Cerify Quick Start User Manual

Tektronix Cerify Quick Start User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
