Cerify

ZZZ

Automated Video Content Veriﬁcation System

User Manual

*P077035213*

077-0352-13

Cerify Automated Video Content Veriﬁcation System

ZZZ

User Manual

www.tektronix.com

077-0352-13

Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries or suppliers, and are protected by national copyright laws and international treaty provisions.

Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supersedes that in all previously published material. Speciﬁcations and price change privileges reserved.

TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.

Cerify is trademark of Tektronix, Inc.

This document supports software version 7.9 and above.

Cerify Te

Cerify Technical support is available on Business Days from 6:00 AM to 5:00 PM PaciﬁcTimeand9:00 AM to 5:0

• US/Canada toll-free 1-844-219-5329

•India

• Russia toll-free 810800-22554411

• United Kingdom 44 1344 39 2541

• Europe* toll-free 00800-22554411

* Austria, Belgium, France, Germany, Ireland, Italy, Netherlands, Spain, Sweden, Switzerland, and UK.

Alternatively, we can be contacted through e-mail at cerify-support@tektronix.com

chnical Support

0 PM Indian Standard Time on the following numbers:

toll-free 1800 3000 4835

Contacting Tektronix

Tektronix, Inc. 14150 SW Karl Braun Drive P. O . B o x 5 0 0

eaverton, OR 97077

B USA

For product information, sales, service, and technical support:

In North America, call 1-800-833-9200. Worldwide, visit www.tektronix.com to ﬁnd contacts in your area.

Warranty

Tektronix warrants that the media on which this software product is furnished and the encoding of the programs on the media will be free from defects in materials and workmanship for a period of three (3) months from the date of shipment. If any such medium or encoding proves defective during the warranty period, Tektronix will provide a rep product is furnished, this software product is provided “as is” without warranty of any kind, either express or implied. Tektronix does not warrant that the functions contained in this software product will meet Customer's requirements or that the operation of the programs will be uninterrupted or error-free.

In order to obtain service under this warranty, Customer must notify Tektronix o f the defect before the expiration of the warranty period. If Tektronix is unable to provide a replacement that is free from defects in materials and workmanship within a reasonable time thereafter, Customer may terminate the license for this software product and return this software product and any associated materials for credit or refund.

THIS WARRANTY IS GIVEN BY TEKTRONIX WITH RESPECT TO THE PRODUCT IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED. TEKTRONIX AND ITS VENDORS DISCLAIM ANY IMPLIED TEKTRONIX' RESPONSIBILITY TO R EPLACE DEFECTIVE MEDIA OR REFUND CUSTOMER'S PAYMENT IS THE SOLE AND EXCLUSIVE REMEDY PROVIDED TO THE CUSTOMER FOR BREACH OF THIS WARRANTY. TEKTRONIX AND ITS VENDORS WILL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF WHETHER TEKTRONIX OR THE VENDOR HAS ADVANCE NOTICE OF THE POSSIBILITY OF SUCH

lacement in exchange for the defective medium. Except as to the media on which this s oftware

WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.

DAMAGES.

Table of Contents

Acknowledgements

Acknowledgements................................................................................................. 1

Preface

Preface ............................................................................................................... 3

Contents

Related Documentation ....................................................................................... 3

Getting Started

Product Description ............................... .................................. ............................... 5

System Components.................................. ................................ ......................... 5

System Installation ................................................................................................ 13

Prerequisites......................... ................................ ................................ .......... 13

Software Installation.......................................................................................... 16

Software Uninstallation ...................................................................................... 26

Software Reinstallation ...................................................................................... 26

Software Upgrade......................... .................................. ................................ .. 27

Network Settings................................ .................................. ............................ 28

Accessing the Application........................................................................................ 29

Starting the Application...................................................................................... 29

Cerify Windows Service ..................................................................................... 30

Starting a Cluster.............................................................................................. 30

Accessing the Web User Interface ...................... ................................ .................... 31

of this Manual.................................... .................................. ................. 3

Table of Contents

Operating Basics

Concepts.... ................................ ................................ .................................. ...... 35

Users ....... ................................ ................................ .................................. .. 35

MediaLocations............................................................................................... 36

MediaSets...................................................................................................... 36

Templates ...................................................................................................... 36

Proﬁles ..... .................................. ................................ ................................ .. 37

DPP Proﬁles ............................. ................................ ................................ ...... 37

Jobs............................................................................................................. 38

Alerts ........................................................................................................... 38

Reports ......................................................................................................... 38

Archiving ...................................................................................................... 39

Clustering.............. ................................ .................................. ...................... 39

Growing File Support ........................................................................................ 39

Cerify Automated Video Content Veriﬁcation System User Manual i

Table of Contents

Audio Loudness Correction ..................... ................................ ............................ 40

Functional Overview.............................................................................................. 41

System Tray Icon ............................................................................................. 41

Web User Interface ........................................................................................... 42

Error Handling ................................................................................................ 48

Tutorials ............................................................................................................ 50

Work Flow..................................................................................................... 51

Before You Begin............................................................................................. 52

Creating a MediaLocation ..... ................................ ................................ .............. 54

Creating a MediaSet .............................. ................................ ............................ 55

Creating a Template ........ .................................. ................................ ................ 58

Creating a Proﬁle ............................................................................................. 60

Creating a Job ..... .................................. ................................ .......................... 61

Inspecting Job Results...................... .................................. ................................ 61

Generating a Report ...... .................................. ................................ .................. 62

Archiving ...................................................................................................... 62

Exporting Templates.................. .................................. ................................ ...... 63

Importing Templates.................. .................................. ................................ ...... 63

Reference

Introduction ........................................................................................................ 65

Jobs...................... ................................ .................................. .......................... 65

Jobs Monitor .................................................................................................. 65

New Job.................... .................................. ................................ .................. 66

New Single File Job .......................................................................................... 67

Modifying Jobs.................. ................................ ................................ .............. 71

Job Details..................................................................................................... 72

Processing Result............................................................................................. 73

Alert Levels ............... ................................ ................................ .................... 74

Alert Details ................................................................................................... 75

Start and End Positions of Quality Alerts . . .... .... . .... . .... . .... ..... .... . .... . .... ..... ..... .... . .... . .. 76

Frame View.................................................................................................... 77

Media Processing Limitations............................................................................... 78

Proﬁles.............................................................................................................. 80

Proﬁle Details ................................................................................................. 81

Edit Proﬁle..................................................................................................... 81

New Proﬁle.. ................................ .................................. ................................ 82

Templates..... ................................ ................................ .................................. .... 83

Template Details ...... ................................ ................................ ........................ 86

Edit Template...................................... ................................ ............................ 87

New Template... ................................ .................................. ............................ 88

Deleting Templates ........................................................................................... 89

ii Cerify Automated Video Content Veriﬁcation System User Manual

Table of Contents

Exporting Templates.................. .................................. ................................ ...... 90

Importing Templates.................. .................................. ................................ ...... 91

Container Templates............................................................................................... 93

Checks Common to All Container Layers ............... ................................ .................. 93

Container Checks Speciﬁc to Microsoft Smooth Streaming (MSS) .............. ...................... 95

Container Checks Speciﬁc to MPEG-2 Transport Stream Standard .................................... 96

Container Checks Speciﬁc to MPEG-2 Program Stream Standard...................................... 98

Container Checks Speciﬁc to SMPTE 377M / MXF Standard ...... .................................. .. 99

Container Checks Speciﬁc to LXF Standard .... ................................ ........................ 102

Container Checks Speciﬁc to QuickTime Standard..................................................... 102

Container Checks Speciﬁc to AVID AMT Standard.......................... .......................... 103

Video Templates ................................................................................................. 105

Common Video Conﬁguration Checks..... ................................ .............................. 105

Video Quality.... . .... . .... ..... ... . . .... . .... . .... .... . .... . .... ..... ... . . .... . .... . .... .... . .... . .... ..... . 111

Video Checks Speciﬁc to MPEG-4 Standard .................. ................................ .......... 116

Video Checks Speciﬁc to MPEG-2 Standard .................. ................................ .......... 117

Video Checks Speciﬁc to VC-1 Standard ................................................................ 121

Video Checks Speciﬁc to H.264/AVC Standard............... .................................. ........ 122

Video Checks Speciﬁc to the DV50/100/DVCPro Standard......... ................................ .. 125

Video Checks Speciﬁc to the ProRes Standard...................................... .................... 126

Video Checks Speciﬁc to Generic QuickTime Video................................................... 127

Video Checks Speciﬁc to JPEG 2000 .................. ................................ .................. 127

Video Checks Speciﬁc to H.265/HE

Video Checks Speciﬁc to Raw Video............................... ................................ ...... 128

Audio Templates ................................................................................................. 129

Common Audio Conﬁguration Checks........................... .................................. ...... 129

Audio Quality Checks . .... . .... ..... ..... ... . . .... . .... . .... . .... . .... . .... ..... . .... ..... ..... .... . .... . .. 131

Audio Checks Speciﬁc to MPEG1 and MPEG-2 Audio Standards ................................... 135

Audio Checks Speciﬁc to Dolby-E Audio Standard .................. ................................ .. 135

Audio Checks

Audio Checks Speciﬁc to AAC / HE-AAC Audio Standard........................................... 139

Audio Checks Speciﬁc to PCM Audio Standard ........................................................ 140

Audio Checks Speciﬁc to DV Audio Standard ...................... ................................ .... 141

Audio Checks Speciﬁc to Cross Track Audio ......... ................................ .................. 142

Action Templates ...................... ................................ .................................. ........ 146

MediaSets ........................................................................................................ 151

New MediaSet................... .................................. ................................ .......... 152

Edit MediaSet ............................................................................................... 153

Conﬁgure DropBox......................................................................................... 155

DropBox Filters.... ..... ..... ..... .... . .... . .... . .... . .... . .... . .... . .... . .... . .... . .... . .... . .... ..... ..... 157

Reports.................................. .................................. ................................ ........ 159

Options.................. ................................ .................................. ........................ 160

Speciﬁc to AC-3 Audio Standard.................. ................................ ...... 138

VC.......................... ................................ ........ 128

Cerify Automated Video Content Veriﬁcation System User Manual iii

Table of Contents

Change Password........................................................................................... 160

Records per Page...................... ................................ .................................. .... 160

Jobs View.......... ................................ ................................ .......................... 160

History............................................................................................................ 161

Day View .................................................................................................... 161

Week View................................................................................................... 162

Admin......... ................................ ................................ .................................. .. 163

User Management ............................ ................................ .............................. 163

Modify User ................................................................................................. 163

New User .................................................................................................... 164

Delete User .......................... ................................ ................................ ........ 164

MediaLocation Management .............................................................................. 164

Mail Settings ........................ ................................ .................................. ...... 169

Processing Settings ......................................................................................... 169

Database Management ..................................................................................... 170

Schedule Results Deletion ................. ................................ ................................ 172

Report File Settings. . .... . .... . .... . .... ..... ..... .... . .... . .... . .... . .... . .... . .... ..... ..... .... . .... . .... 173

Custom Logo Settings.......... .................................. ................................ .......... 173

Stream Information........... ................................ ................................ .............. 173

VLC playback............................................................................................... 174

Application Log............................................................................................. 176

Media Test Units Page ..................................................................................... 176

Help ............................................................................................................... 177

Accessing the Online Help............... .................................. ................................ 177

Using the Online Help............ ................................ .................................. ........ 177

Appendices

Appendix A: Alerts............................ ................................ ................................ .. 179

List of Alerts ........................ .................................. ................................ ...... 179

Appendix B: Supported Compression Standards ............................................................ 262

Supported Video Compression Standards................................................................ 262

Supported Audio Compression Standards ... ................................ ............................ 267

File Types and Container Formats .............. ................................ .......................... 270

Supported Wrapper and Codec Combinations........................................................... 272

Standards References....... ................................ .................................. .............. 273

Appendix C: Software Maintenance................................... .................................. ...... 275

Conﬁguring the Cerify Application................................... ................................ .... 275

Reinitializing the Cerify Application ... . . .... ... . . .... . .... .... . .... . .... .... . .... ... . . .... ..... .... . .... 277

Database Backup/Restore Utility .. . .... ..... ... . . .... . .... . .... . .... . .... ... . . .... . .... . .... . .... . .... ... 277

Capturing Cerify Status Information Using the Support Monitor Script ..................... ........ 279

Upgrading Dongle Options.. ................................ ................................ .............. 281

Using NFS Client on Windows ........... .................................. .............................. 283

iv Cerify Automated Video Content Veriﬁcation System User Manual

Appendix D: CeriTalk........................................................................................... 285

Appendix E: Conﬁguring Your Cerify Installation .......................................................... 293

Glossary

Glossary Terms .................................................................................................. 303

Index

Table of Contents

CeriTalk XML Reports..................................................................................... 285

CeriTalk SOAP

Number of Channels.......................................... ................................ .............. 293

Modes of Operation ........................................................................................ 294

Conﬁguring Your Cerify Installation for Best Performance ........................................... 298

Commercial Off-the-Shelf Recommendations .............. .................................. .......... 302

API ........................................................................................ 288

Cerify Automated Video Content Veriﬁcation System User Manual v

Table of Contents

vi Cerify Automated Video Content Veriﬁcation System User Manual

Acknowledgements Acknowledgements

Acknowledgements

Apache. This product uses software developed by the Apache Software Foundation,

http://www.apache.org/

Castor, Log4

Apple. This product uses parts of the Darwin Streaming Server source code covered by the Apple Public Source License. For copies of this license and modiﬁcations made to the sour software license notices and source code provided with Cerify.

Apple and QuickTime are trademarks of Apple Inc., registered in the United States and other countries.

http://www.apple.com/

Dolby. Manufactured under license from Dolby Laboratories. This product uses software developed by Dolby Laboratories. http://www.dolby.com/

j, Struts, Spring and Xerces.

. This includes the following software: Andariel, Ant, Apache Commons, Axis,

ce code please refer to the

DynamicReports libraries. This product uses DynamicReports libraries for creating PDF reports.

dynamicreports.sourceforge.net/index.html

Expat. This product uses the Expat XML Parser. http://expat.sourceforge.net/

FFmpeg. This product uses software developed by the FFmpeg project, ffmpeg.mplayerhq.hu.

Speciﬁcally, support for DV is provided by some components of the libavcodec and libavutil libraries.

HardingFPA OEM Interface library. This product uses HardingFPA OEM Interface library f or PSE analysis developed by and used under license from Cambridge Research Syste ms. http://www.crsltd.com/

HTMLUNIT. This product includes software developed by Gargoyle Software Inc.

http://www.GargoyleSoftware.com/

Java This product uses Java™ technology. The TM and technology are explicitly required by Sun.

http://www.sun.com/policies/trademarks

JBoss. Modiﬁcations have been made to the source code of the JBoss application server. This source code is available on request. http://www.jboss.org/developer

JCIFS. This product uses the Java CIFS Client Library, jcifs.samba.org. http://jcifs.samba.org/

JDIC This pr

oduct uses the JDIC Java integration components. https://jdic.dev.java.net/

JPEG. This product uses free JPEG software from the Independent JPEG Group.

JUnit. This product uses the JUnit regression testing framework, www.junit.org.

MXF. This product uses MXF software d eveloped by and used under license from OPENCUBE

Technologies SAS, http://www.mxftk.com/

Cerify Automated Video Content Veriﬁcation System User Manual 1

Acknowledgements Acknowledgements

MainConcept decoder libraries. This product uses MainConcept decoder libraries for decoding AVC, MPEG-2, VC-3/DNxHD, and JPEG 2000. These libraries are used under license from MainConcept.

http://www.m

MySQL. This product is powered by the MySQL database. MySQL is written and distributed under the GNU Gener the general public.

ainconcept.com/

al Public License which means the source code is freely distributed and available to

Neko. This p

OpenCV. This product uses OpenCV (Open Source Computer Vision Library), http://opencv.org/

Rhino. This product uses the Rhino implementation of JavaScript, http://www.mozilla.org/rhino/

Saxon. This product uses Saxon XSLT processor, saxon.sourceforge.net.

Windows Media. This product is protected by certain intellectual property rights of Microsoft. Use or

distribution of such technology outside of this product is prohibited without a license from Microsoft.

WinDump. This product uses the WinDUMP network diagnostic utilities.

http://www.winpcap.org/windump

WinPcap. This product uses the WinPcap packet capture libraries. http://www.winpcap.org/

7-Zip. This product uses the 7-ZIP ﬁle archiver. http://www.7-zip.org/

roduct includes software developed by Andy Clark.

2 Cerify Automated Video Content Veriﬁcation System User Manual

Preface Preface

Preface

Cerify is an automated system for testing compressed digital media before transmission or use. Through a Web-based interface, users can create Jobs, which w ill perform a sequence of checks on a set of media ﬁles, and vie

Contents of this Manual

This manual describes the system in detail, provides procedures for using the system, and includes full reference documentation.

Getting Started describes the system capabilities, conﬁguration, and ﬁrst time operation.

w the results.

Operatin

Reference provides detailed information about each page (or window, or menu item) in the user

interfa

Appendix A: Alerts lists and deﬁnes all the stream compliance and integrity checks that can be

carrie

Appendix B: Supported Compression Standards describes compression standards and ﬁle formats

that th

Appendix C: Software M aintenance details the procedure to reinitialize the Cerify application and to

upgra

Appendix D: CeriTalk provides information about an XML-based API that lets you interact with Cerify

from

broadcast automation, and workﬂow systems.

App

conﬁguring your installation for best performance and commercial off-the-shelf platform

recommendations.

gBasicsprovides a functional overview, basic concepts, and tutorials for using the system.

ce.

d out.

e system recognizes.

de the license dongle options.

within other applications, making it possible to integrate Cerify with other content management,

endix E: Conﬁguring Your Cerify Installation provides information on modes of operation,

Related Documentation

The following related documents support the product:

Cerify Online Help

Cerify Quick Start User Manual (Tektronix part number, 071-2680-xx)

Cerify Release Notes (Tektronix part number, 077-0752-xx)

Cerify Third Party Software License Notice Document (Tektronix part number, 001-1513-xx)

Cerify Upgrades Read This First (Tektronix part number, 061-4355-xx)

Cerify Automated Video Content Veriﬁcation System User Manual 3

Preface Preface

4 Cerify Automated Video Content Veriﬁcation System User Manual

Getting Started Product Description

Product Description

This is a media testing product which runs either on a single computer or on a cluster of two or more dedicated computers connected on a network running Microsoft Windows. This automated video content veriﬁcation parameters. It provides both broadcast and production operations with a fast, cost effective QC solution.

system can be used to check for correct digital encoding and against baseband quality

Cerify can b management systems and provide a completely automated workﬂow. A Web based user interface allows test results to be viewed from any network connected workstation.

e integrated w ith your existing infrastructure using the CeriTalk API to interface with asset

System Components

Cerify accesses digital media from local storage, such as a local hard drive or DVD, as well as network storage, such as a Windows ﬁle server or FTP server.

A Cerify system can be set up in three basic ways:

The ﬁrst consists of a single self-contained unit which runs all the management and testing processes

of the system.

The second consists of a networked cluster of two or more units, which enables simultaneous

processing of a greater number of ﬁles. The networked cluster contains a single Supervisor and one

or more Media Test Units.

The third consists of a cluster of three or more units with high availability (HA) support. Cerify

Enterprise Cluster with high availability (also referred to as an HA cluster) is a Cerify cluster enabled

with support in the case of a Supervisor system failure.

Cerify Automated Video Content Veriﬁcation System User Manual 5

Getting Started Product Description

License Dongle

The license dongle must be plugged into the USB port on your computer to run the application. In a clustered system, Media Test Units acquire their licenses from the Supervisor.

In the case of an HA cluster, two identical license dongles are supplied. The two dongles need to be inserted in the USB ports of the primary and secondary supervisors. Media Test Units will acquire licenses from the active primary Supervisor.

The license dongle you received should look like one of the dongles shown below.

License dongle

It is possible to navigate the user interface and see previous results when no dongle is installed, but it is not possible to carry out new checks of digital media ﬁles. The license dongle controls:

The types of codecs and ﬁle formats that can be checked

The number of channels that can be used

For demo dongles, when the license will expire

Server conﬁguration (Supervisor, Secondary Supervisor or Media Test Unit, High Availability cluster or not, etc.)

NOTE. In a high availability (HA) cluster, if you unplug a dongle and plug in another dongle, or if the connected dongle is upgraded with a new v2c ﬁle, a restart of Cerify is necessary for the license dongle to work correctly.

When you install a new version of the Cerify software for a high availability (HA) cluster, both of the dongles connected to the primary and secondary Supervisors must be upgraded.

6 Cerify Automated Video Content Veriﬁcation System User Manual

Getting Started Product Description

Networking

In a clustered conﬁguration, network interface on all of the units, including the Supervisor, secondary Supervisor (HA cluster only) and Media Test Units, should be connected to the local area network. This connection is used to access media ﬁles, to service Web clients, and to carry cluster control trafﬁc.

Clustering topology

Cerify Automated Video Content Veriﬁcation System User Manual 7

Getting Started Product Description

Software Components

Software components include:

A Web-based user interface, which allows users to create and control Jobs, and to view or report the results of these Jobs. This interface is accessed over the network by using a Web browser. All you need to know is the IP address of your unit.

Media test service, which performs media ﬁle veriﬁcationaccordingtotheruleschosenbytheuser.

A database, which provides robust storage of the system entities, including users, Jobs, and Job results.

An XML-based control and reporting API known as CeriTalk. CeriTalk allows interaction with Cerify from within other applications, making it possible to integrate Cerify with other content management, broadcast automation, and workﬂow systems.

A Web application server that provides access to the Web interface and runs the core services for the application.

A license server, which controls the types of ﬁles t hat can be veriﬁed.

The system tray icon and menu, which provides access to the Cerify Web-based user interface and allows the application to be started and stopped. The system tray is not available when Cerify is installed as a Windows service.

Cerify as a Standalone System

A standalone system is a single machine that combines the functions of a Supervisor unit and a Media Test Unit. The process that carries out the media ﬁle testing is known as the Media Test Client (MTC).

8 Cerify Automated Video Content Veriﬁcation System User Manual

Getting Started Product Description

Cerify Enterprise Cluster

The Supervisor unit controls the cluster system. It hosts the database and the Web server, allowing multiple users to set up and view Jobs. It is responsible for locating the media ﬁles from the network, but delegates actual transfer and processing of these ﬁles to one or more Media Test Units. The Supervisor unit organiz

Each Media Test Unit is responsible for processing the digital media ﬁles in a networked cluster. It applies the process the ﬁles.

es and stores the resulting outputs.

user-speciﬁed tests, and reports back the results. The Supervisor can also be conﬁgured to

Local area networking

Cerify Automated Video Content Veriﬁcation System User Manual 9

Getting Started Product Description

Cerify High Availability Enterprise Cluster

The Cerify high availability enterprise cluster (also referred to as an HA cluster) is a Cerify cluster enabled with support in the case of a Supervisor system failure. In an HA cluster, one of the member units of the cluster is conﬁgured as a backup to the Primary Supervisor and is called the Secondary Supervisor.

If Cerify on the Primary Supervisor goes down for any reason (for example, due to a machine crash), the Secondary Supervisor automatically takes over and manages the cluster. All other units (MTUs) now form aclusterwi the Secondary Supervisor and will be ready to take over when the current Supervisor goes down.

th the Secondary Supervisor. Once the Primary Supervisor recovers, it will assume the role of

The Second and the MTUs in the cluster while performing the job of a Secondary Supervisor.

In an HA cl interface cards on the system. One will be used for the cluster function and the other for communication (Ceritalk/Web). Also, it is mandatory to use static IP addresses for all the units forming the HA cluster.

In an HA cluster, identical dongles must be connected to the Primary Supervisor and Secondary Supervisor. When starting an HA cluster, the cluster units should be started in the following order:

1. The Primary Supervisor should be started ﬁrst with one of the two HA dongles installed. At the time the Primary Supervisor is started, the system with the Secondary Supervisor installed should be up and have the matching HA dongle installed. Otherwise, the Primary Supervisor will not start.

2. The Secondary Supervisor should be started next.

3. The Media Test Units should be started one by one after both the Primary Supervisor and Secondary

Supervisor are started.

ary Supervisor is a part of the HA cluster and can also process ﬁles like the Primary Supervisor

uster, it is mandatory for the Primary Supervisor and Secondary Supervisor to have two network

10 Cerify Automated Video Content Veriﬁcation System User Manual

Getting Started Product Description

Clustering Requirements

Two or more PCs with 64-bit Windows Server 2008 SE OS installed.

Administrator privileges on all the m achines on which the Cerify software will be installed.

All of the systems with Cerify installed need to meet the minimum hardware speciﬁcations.

All of the cl network as the Supervisor unit. It is recommended that each cluster unit be conﬁgured with Static IP addresses.

All of the PCs in the cluster should be able to route to each other. The Supervisor unit and the Secondary Supervisor unit (in the case of an HA cluster) each need to be given a network name that is recognized and resolved by all of the units in the cluster.

You should know the fully qualiﬁed name of the Supervisor unit and the Secondary Supervisor unit and provide these when the installer of the other units in the cluster asks for the names of the Supervisor and Secondary Supervisor units.

In the case of a normal cluster (non-HA cluster), if the Supervisor or Media Test Units have more than one network interfaces, it is better to bridge all the network interfaces together. For instructions on conﬁguring the network bridge, refer to Conﬁguring a Network Bridge

Synchronization between all the units in cluster must be maintained. For example, use an NTP server to synchronize the units in a cluster.

All the units in the cluster should be conﬁguredtobeinthesametimezone.

ustering PCs, Media Test Units, and Secondary Supervisor unit should reside on the same

(see page 23).

Cerify Automated Video Content Veriﬁcation System User Manual 11

Getting Started Product Description

Clustering Scenarios Which may not Work

Clusters may not work in the following scenarios:

If the Supervisor, the Secondary Supervisor (in the case of an HA cluster), and the Media Test Unit are in different subnets wherein the switch blocks the multicast or UDP trafﬁc.

If any of Supervisor, Secondary Supervisor, or Media Test Unit systems has Windows ﬁrewall running, the Firewall may need some additional conﬁgurations for the cluster to work. Contact your Tektronix representative for more informationonhowtosetupthisconﬁguration.

If a Media Test Unit or Secondary Supervisor cannot resolve Supervisor host name.

In the case of an HA cluster, if the Supervisor can not resolve the host name of the Secondary

Supervisor and vice versa.

If the Supervisor does not have a host name or if the Supervisor has a host name with Japanese or Chinese characters.

If a network has another system with the same host name as the Supervisor (or Secondary Supervisor) system.

If the host name of the Supervisor (or Secondary Supervisor) changes after cluster installation.

If the http port on the Supervisor is conﬁgured to a different port number after cluster installation. In this case, the property cerify.supervisor.httpport in the cerifysystem.properties on the Media Test Units must be changed to the new port number.

If the http port on the Supervisor is conﬁgured differently than that of the Secondary Supervisor.

If the IP addresses of any units in the cluster change after the installation. In this case, the property cerify.jboss.bindaddress must to be changed to the current IP address.

In the case of a normal (non-HA) cluster, if the Supervisor has multiple network i nterfaces connected to the same network and if DNS/WINS are not conﬁgured properly, troubleshoot this problem by doing either of the following:

By adding an entry containing the Supervisor host name and the IP address used by Cerify on Supervisor in "hosts" ﬁle, which can be found in

C:\WINDOWS\system32\drivers\etc in all

the Media Test Units.

By bridging all the network interfaces together.

Clusters might not work correctly if there is momentary network outage in which case the clusters have to be restarted.

12 Cerify Automated Video Content Veriﬁcation System User Manual

Getting Started System Installation

System Installation

This section provides details of hardware, software and user prerequisites for the system and instructions on performing the software installation.

Prerequisites

Hardware Prerequisites

Cerify is designed to be run on a variety of PC hardware. Consequently, the choice of hardware is determined by performance and throughput requirements for your installation.

This section recommends hardware conﬁguration for some situations in which Cerify is typically used.

Cerify can be installed as either of the following two conﬁgurations on a given computer:

Single channel. A single channel installation is one that is licensed to test a single media ﬁle at a time. Such installations are normally performed on a PC or a laptop computer and are suitable for situations where a low throughput is sufﬁcient and performance is not critical.

Multichannel. A typical multichannel installation of Cerify tests 4-8 media ﬁles at a time on a single unit. Due to the high throughput and performance requirements that are expected from such installations, it is recommended that server class hardware and operating systems be used in such cases.

In addition to the throughput required, the hardware requirements also depend heavily on the mode of operation that will be used. Cerify can operate in two modes:

Streaming mode

In this mode, media ﬁles are read directly from the media server hosting the ﬁle and are not copied to the local hard disk of the Cerify system. This is the default mode of operation and is also the preferred one.

Copying mode

Media ﬁles are copied to the local hard disk of the Cerify system before processing can begin. By default, Cerify will not copy ﬁles to the local hard disk, but it is possible to force Cerify to operate in this mode.

The mode of operation that applies to your Cerify installation depends on the ﬁle formats you would like to test and other work ﬂow and connectivity related constraints that might apply to your situation. See the

Modes of Operation

The functional differences between these two modes of operation impact primarily on the disk space availability and disk conﬁguration requireme of disk space and high levels of concurrent read/write performance from the hard drives in order for best overall performance while the streaming mode can derive comparable overall performance with a lesser amount of disk space and lower read/write efﬁciency. Consequently, when possible, the streaming mode should be used in preference to copying mode.

(see page 294) for a detailed discussion on the factors that inﬂuence this.

nts. Speciﬁcally, the copying mode requires a greater amount

Cerify Automated Video Content Veriﬁcation System User Manual 13

Getting Started System Installation

The general guidelines that should be followed when selecting hardware are:

Processor: 3 GHz

Cerify is capable of using as many processor cores as available for improved processing performance. While the minimum required conﬁguration is 2 cores per channel, for optimum performance, it is recommended to allocate between 4 and 6 processor cores per Cerify channel. It is also recommended that for best performance, you choose as much on-chip memory cache as possible.

NOTE. Cerif Intel based server platform.

Memory:

It is recommended to use a minimum of 4 GB of RAM per channel and an additional 4 GB for the operati memorythereforeis:4x4GB(perchannel)+4GB=20GB.WhentheexpectedloadinCerifyis likely to be largely composed of huge media ﬁles, more memory per channel may be necessary.

Hard disk drive: 100 GB x 3

For an e Windows and Cerify installation (including database) to achieve fault tolerance in case of disk failure. This logical drive should be at least 100 GB in size. For systems that are expected to support high levels of throughput, it is recommended that you have 500 GB of space on this logical drive.

The amount of additional storage you need depends on the mode of operation that applies to your installation, the average size of the ﬁles you will be processing and the number of channels you will be running.

y is optimized for Intel processor architectures, and therefore it is recommended to use an

ng system and the Cerify database. For optimum performance for 4 channels, the recommended

nterprise installation, Tektronix recommends using a RAID on which to place the MS

Streaming mode

Due to the minimal hard disk utilization when operating in the streaming mode, it is sufﬁcient to provide a single dedicated hard disk of 100 GB in size as temporary storage for Cerify.

Copying mode

The minimum hard disk space provided must be greater than the average ﬁle size being processed multiplied by the number of channels. It is recommended that the temporary storage be RAID-ed for better performance.

For help choosing the optimal number of hard disks for your installation and the best RAID levels to use, see Conﬁguring Your Cerify Installation for Best Performance

Network interface: 1 Gbit/s

You might use multiple network interfaces to improve available network bandwidth.

Integrated RAID controller

A DVD drive (used for installing the software)

A USB port, for connecting the license dongle

14 Cerify Automated Video Content Veriﬁcation System User Manual

(see page 298).

Getting Started System Installation

A license dongle (provided with the product)

Redundant power supply

For more detailed speciﬁcation of a recommended enterprise PC platform, see Commercial off-the-Shelf

Recommendations (see page 302).

Supported Platforms

Windows 7, 64-bit

Windows Server 2008, 64-bit

Windows Server 2008 R2, 64-bit

Windows Server 2012, 64-bit

Windows S

NOTE. Cerify is expected to operate correctly on other variants of Windows as well, but it has been qualiﬁed only on the ones speciﬁed above.

Apple ProRes, Generic QuickTime and JPEG 2000 Video decoding functions are not available on Microsoft Windows XP 64 bit and Windows Server 2003 because of known compatibility issues with QuickTime Player.

erver 2012 R2, 64-bit

Software Prerequisites

The computer on which the application is installed will need the following:

To run one of the Supported Platforms.

To access the system through its Web user interface from another computer on the network, the client computer must have a Web browser installed.

NOTE. To access the application, the preferred Web browser is Microsoft Internet Explorer

7.0 and above). The application has also been tested with Mozilla Firefox. There may be minor visual ifferences in the appearance of the user interface in different Web browsers.

(version

Cerify Automated Video Content Veriﬁcation System User Manual 15

Getting Started System Installation

Software Inst

Before installing the Cerify application, your PC must be correctly connected to your local network. This allows:

The Cerify application to test the ﬁles that are available on other machines on the network.

Other m achines to interact with Cerify automatically (for example, using CeriTalk automation clients, or copying of report ﬁles to network locations).

Multiple users to connect to the Cerify Web user interface from remote computers.

For the last two cases, you need to know the IP address or the network name of the machine that Cerify is installed on. Network settings on the PC are conﬁgured in the usual manner using Windows. If your machine is not properly conﬁgured or you do not know the name o r IP address information, contact your system ad

Installation Considerations

Before installing Cerify, you should be aware of the following information:

If Ceri

changes before using Cerify:

allation

ministrator.

fy is installed in a location other than the default location, then you must make the following

ault, the “Execute script” rule (in the “On error” section and “On Success” section) in the

By def sample “DPP Application” action template is conﬁgured with the script location as “C:\Program Files (x86)\Tektronix\Cerify\action_scripts\DPPApplication.exe”. This needs to be changed to “<Cerify_Installation_Location>\action_scripts\DPPApplication.exe”.

The DPP Application requires CeriTalk’s IP and port n umber details. In the case of ENT cluster, it should be supervisor’s IP. In the case of HA cluster, it should be CeriTalk’s IP address, which is common for both supervisors.

If the port number of Cerify is changed (from the cerify.properties ﬁle), then the Cerify IP address and port number should be passed as the ﬁrst argument for “DPPApplication.exe” in the Sample “DPP Application” action template. For example, if port number 90 is used on 192.158.11.201,

hen 192.158.11.201:90 should be supplied as the ﬁrst argument.

It is recommended that the Cerify application be installed on a machine where it can be used as the sole running application. Cerify makes intensive use of both CPU and memory and will considerably degrade the performance of other running applications. Similarly, running other applications or services simultaneously will degrade the performance of Cerify and increase the time taken to process amediaﬁle.

Cerify relies on third-party software applications that are packaged and installed with it: JBoss and MySQL. If these applications are already used on the PC, you should remove them before attempting to install the Cerify.

The Cerify license server relies on Sentinel HASP (formerly Aladdin HASP SRM) drivers, which are installed and conﬁgured along with it. It is recommended that other applications that rely on HASP licenses not be used with Cerify on the same machine.

16 Cerify Automated Video Content Veriﬁcation System User Manual

Getting Started System Installation

Cerify uses a number of network services that are local to the host PC. These services can sometimes be blocked by personal ﬁrewall software , in which case an error message will be displayed when Cerify starts. For ex be established. If the Cerify application is unable to communicate with HASP, an error message,

Unable to connect to HASP License Manager (port 1947). Please check if the HASP License Manager service is running and is not blocked by a ﬁrewall is displayed and Cerify is stopped.

In such situations, conﬁgure the ﬁrewall to allow the service on the appropriate port, or alternatively disable the ﬁrewall entirely.

An installation log is written to the "%userproﬁle%\Cerify\CerifyInstallationLogs_<Timestamp>" folder. T his log gives details of selections you made during t he install and any errors encountered in case of failure to install.

If you would like multiple users to be able to run the Cerify application on the PC, make sure you select a location that has read and write permissionsforthoseusersasthetemporaryvideofolder. A directory located within a user's private directory is not suitable in this case.

While choosing the location for storing temporary video ﬁles during installation, make sure that there is sufﬁcient free space in this folder to store large video ﬁles

Cerify uses the computer name (as stored in the environment variable named "COMPUTERNAME") to uniquely identify some of its network services. This will not work if non-ASCII characters are

n the computer name.

used i

ample, on Cerify start up, a check is made to verify that communication with HASP can

Cerify will fail to run if any other Web services using port 80 are running on the system where the

fy is installed (for example, the IIS Admin service, Skype or Apache). You can run Cerify once

Ceri you shut down the other port 80 services running on the system. Alternatively, you can conﬁgure the Cerify Web port to use a port other than 80.

It is not possible to install a lower version of Cerify when you have a higher version of Cerify already installed. For example, if you install Cerify version 6.1 and then you want to go back to Cerify version 6.0, you will need to ﬁrst uninstall Cerify 6.1 and then install Cerify 6.0.

Cerify Automated Video Content Veriﬁcation System User Manual 17

Getting Started System Installation

Installing Cerify

The installation of the Cerify application takes several minutes; typically between 5 and 15 minutes depending on the speed of your PC.

CAUTION. To prevent installation problems, be sure to read about the known installation limitations.

Installatio

To install Cerify, you need to perform the following steps:

1. Run the Cerify Installer.

2. Insert the Cerify dongle(s).

3. Optional: Install Apple QuickTime Player.

Running the Cerify Installer.

NOTE. If you try to install the Cerify application without administrator privileges, the following message appears: “The Cerify application can be installed or uninstalled only by a system administrator. Please log in

nIssuestoConsider

Ensure that you are logged in as a user with administrator privileges.

as administrator and try again”.

(see page 16)

Insert the Cerify DVD provided by Tektronix. The Cerify Application Browser opens. Click the Install

fy link to launch the Cerify installer. Follow the on-screen instructions to perform the installation.

Ceri

NOTE. If you try to install the Cerify application on an unsupported platform (refer to Supported Platforms Windows operating system. Cerify will probably operate correctly but has not been validated on this OS. Do you wish to continue installation?”

The Cerify installation will not continue on a Windows XP platform. The installer displays a message saying Windows XP is not supported and the installation is aborted.

If the browser does not open, or if the Install Cerify link does not work, navigate to the Exec folder on the DVD and double-click CerifySetup<version>.exe. Follow the on-screen instructions to perform the installation.

A number of third party software applications are installed during the installation process. Most of these are not visible, but you will be notiﬁed as the WinPcap and HASP drivers are installed.

NOTE. WinPcap is not used in the normal operation of the Cerify application. It is used when you collect support diagnostics to troubleshoot networking issues with Cerify. For more information on support diagnostics, refer to Capturing Cerify Status Information Using the Support Monitor Script

(see page 15)), then the following message appears: “This is not a supported

(see page 279).

18 Cerify Automated Video Content Veriﬁcation System User Manual

Getting Started System Installation

Installation Options

Cerify can be installed in the following ways:

Standalone

Supervisor (for an Enterprise cluster): The Supervisor unit controls the cluster system. It hosts the database and the Web server, allowing multiple users to set up and view Jobs. Use this option to install the Supervisor for a normal cluster (without high availability support).

Media Test Unit (for an Enterprise cluster): Each Media Test Unit is responsible for processing the digital media ﬁles in a networked cluster. Use this option to install Media Test Units for a normal cluster (without high availability support).

Supervisor (for an HA cluster): Use this option to install the Primary Supervisor for an HA (high availability) cluster.

Secondary Supervisor (for an HA cluster): Use this option to install a Secondary Supervisor for an HA (high availability) cluster, which will act as the Primary Supervisor if the Primary Supervisor system goes down.

Media Test Unit (for an HA cluster): Use this option to install Media Test U nits for an HA (high availability) cluster.

NOTE.

provides the list of network interfaces and asks the user to select a network interface to be used by Cerify.

Whil also provides the option to select the network interface for communication (i.e. the interface used for communicating with Cerify via either Ceritalk or the Web user interface).

The installer also provides an option to install Cerify as a service. This option is selected by default. If you want to install Cerify in application mode, this option needs to be deselected.

During the installation of Cerify, if there are multiple network interfaces in the system, the installer

e installing the Supervisor and the Secondary Supervisor (in the case of an HA cluster), the installer

Cerify Automated Video Content Veriﬁcation System User Manual 19

Getting Started System Installation

Installing Cerify as a Supervisor. Follow the steps described in Run Cerify Installer (see page 18) and

Installing Cerify

appears with t

To continue with the Supervisor installation for a normal Enterprise cluster, select Supervisor under the option “Ente

To install the Supervisor for an HA cluster, select Supervisor under the option “High Availability Enterprise

During the installation, a dialog box appears where you must:

Enable or disable ﬁle-processing option on the Supervisor.

Enter the number of channels if you have selected the ﬁle processing option on the Supervisor.

Choose the network interface to be used by Cerify.

Choose the network interface to be used for all Cerify communication. This option is available only while installing the Supervisor for an HA cluster.

Enter the host name of the Secondary Supervisor. This option is available only while installing the Supervisor for an HA cluster.

(see page 18) to install Cerify as a Supervisor. During the installation, a dialog box

he list of installation options.

rprise Cluster” in the installation options dialog box.

Cluster” in the installation options dialog box.

Enter the host names for all the Media Test Units if you want to install the cluster based on unicast communication since most of the switches drop multicast packets.

Installing Cerify as a Secondary Supervisor. Follow the steps described in Run Cerify Installer

page 18) and Installing Cerify (see page 18) to install Cerify as a Secondary Supervisor for an HA cluster.

ng the installation, a dialog box appears with the list of installation options.

Duri

To continue with the Secondary Supervisor installation, select Secondary Supervisor under the option

gh Availability Enterprise Cluster” in the installation options dialog box.

“Hi

During the installation, a dialog box appears where you must:

Enable or disable the ﬁle-processing option on the Secondary Supervisor.

Enter the number of channels if you have selected the ﬁle processing option on the Secondary Supervisor.

Choose the network interface to be used by Cerify.

Choose the network interface to be used for all Cerify communication.

Enter the host name of the Supervisor.

Enter the host names for all of the Media Test Units if you want to install the HA cluster based on unicast communication since most of the switches drop multicast packets.

(see

20 Cerify Automated Video Content Veriﬁcation System User Manual

Getting Started System Installation

Installing Cerify as a Media Test Unit. Follow the steps described in Run Cerify Installer (see page 18) and

Installing Cerify

box appears wi

To continue with the Media Test Unit installation for a normal Enterprise cluster, select Media Test Unit under the “En

To continue with the Media Test Unit installation for an HA cluster, select Media Test Unit under the “High Avail

During the installation, a dialog box appears where you must:

Enter the host name of the Supervisor.

Enter the host name of the Secondary Supervisor. This option is available only while installing Media Test Unit for an HA cluster.

Choose the network interface to be used by Cerify.

Enter the number of channels.

Conﬁguring a non-HA Cluster. To conﬁgure a non-HA cluster, you must:

Install Cerify as a Supervisor on the system which must be conﬁgured as supervisor of the cluster.

(see page 18) to install Cerify as a Media Test Unit. During the installation, a dialog

th the list of installation options.

terprise Cluster” option in the installation options dialog box.

ability Enterprise Cluster” option in the installation options dialog box.

Install Cerify as a Media Test Unit on one or more systems.

When installing Cerify as a Media Test Unit, the installer prompts you to enter the Supervisor host name. The installer checks whether the Media Test Unit can reach the Supervisor system using the host name entered. If the Supervisor system cannot be reached, a message appears whether you still want to continue the installation.

You can also conﬁgure multiple clusters on the same network. To conﬁgure multiple clusters on the same network, you need to install multiple Supervisors. During a Media Test Unit installation, in the Cerify System Settings dialog box, you must enter the respective Supervisor host name.

TE. To co n ﬁgure a cluster, the versions of Cerify on the Supervisor and the Media Test Unit should be

the same. Once the installation is complete, Cerify will be started on both the Supervisor and the Media Test Unit. Access Supervisor using Cerify Web UI and navigate to the Admin page, click the Media Test Units link to the page containing the list of Media Test Units.

Cerify Automated Video Content Veriﬁcation System User Manual 21

Getting Started System Installation

Conﬁguring an HA Cluster. To c onﬁgure an HA (high availability) cluster, you must:

Install Cerify as a Supervisor by choosing Supervisor under the “High Availability Enterprise Cluster” option on the system that is to be conﬁgured as the Primary Supervisor of the cluster.

Install Cerify as a Secondary Supervisor by choosing Secondary Supervisor under the “High Availability Enterprise Cluster” option on the system that is to be conﬁgured as the Secondary Supervisor of the cluster.

Install Cerify as a Media Test Unit by choosing Media Test Unit under the “High Availability Enterprise Cluster” option on one or more systems.

When installing Cerify as a Media Test Unit for an HA cluster, the installer prompts you to enter the host names of the Supervisor and Secondary Supervisor systems. The installer checks whether the Media Test Unit can r If either the Supervisor or Secondary Supervisor system cannot be reached, a message appears asking whether you still want to continue the installation.

NOTE. To con ﬁgure an HA cluster, the version of Cerify that is installed on the Supervisor, Secondary Supervisor, and the Media Test Units should be the same. Once the installation is complete, Cerify will be started on the Supervisor, Secondary Supervisor, and the Media Test Units. Access the Supervisor using the Ce the list of Media Test Units.

each the Supervisor and Secondary Supervisor systems using the host names that you entered.

rify Web UI and navigate to the Admin page. Click the Media Test Units link to the page containing

ading and Uninstalling a Cluster. Insert the installer CD and follow the on-screen instructions. To

Upgr

upgrade a cluster, do the following:

rade Cerify on the Supervisor by running the latest version of installer and choosing Supervisor as

Upg installer type. You can upgrade to either Supervisor for a normal Enterprise cluster or to Supervisor for an HA cluster by choosing the appropriate options.

UpgradeCerifyontheSecondarySupervisorbyrunning the latest version of installer and choosing Secondary Supervisor as the installer type.

Upgrade Cerify on all of the Media Test Units by running the latest version of installer and choosing Media Test Unit as the installer type. You can upgrade to either Media Test Unit for a normal Enterprise cluster or to Media Test Unit for an HA cluster by choosing the appropriate options.

Refer to the Software Upgrade

To uninstall a cluster, do the following:

Uninstall Cerify on the Supervisor.

Uninstall Cerify on the Secondary Supervisor (in the case of an HA cluster).

Uninstall Cerify on all of the Media Test Units.

Refer to the Software Uninstallation

(see page 27) section for instructions on upgrading.

(see page 26) section for instructions on uninstallation.

22 Cerify Automated Video Content Veriﬁcation System User Manual

Getting Started System Installation

Conﬁguring a Network Bridge. If the system has multiple network adapters, it is recommended that you

bridge all the network adapters.

1. From the Start menu, select Control Panel > Network Connections.

2. Select two network adapters at the same time, right-click and select Bridge Connections. Windows

will build up a network bridge automatically. When the bridge is built successfully, the IP address of the two adapters disappears.

3. Select the Network Bridge and conﬁgure a new IP address in the Properties menu for LAN

connections.

Installation Folders. During the installation process, select the following locations:

Installa

Temporary Storage Location: Before processing media ﬁles from an external server, Cerify may

need to c used as the location to store such temporary copies. Cerify copies the ﬁle only when operating in copy mode and accesses the ﬁle using the ftp://, smb://, or gvg:// protocols. See Modes of Operation

page 294) for help determining the mode that applies to your installation.

NOTE. There should be sufﬁcient free space in the temp folder to store large video ﬁles. The location for this temp folder can be on any drive on the computer.

If you would like multiple users to be able to run the Cerify application on the PC, make sure to select a location that has read and write permissions for those users. A temporary directory located within a

s private directory is not suitable in this case.

user

tion Location: The folder where the application is installed.

opy the remote ﬁles to the PC on which the Cerify application is installed. This folder is

(see

Cerify Automated Video Content Veriﬁcation System User Manual 23

Getting Started System Installation

Insert the Cerify Dongle.

Insert the Cerify license dongle supplied with the system in any of the available USB ports of your computer. In the case of normal Enterprise cluster, the dongle should be inserted in the USB port of the Supervisor system. In the case of an HA cluster, you will be supplied with two identical dongles. The two dongles shou

ld be inserted in the USB port of both the Supervisor and Secondary Supervisor systems.

NOTE. Do not insert the dongle before the Cerify installation. Insert the dongle only when the installer prompts you.

If Cerify reports license failures after the dongle has been installed, it is possible that ﬁrewall software is interfering with the license service. Please ensure that port 1947 is open in any ﬁrewall software that is in use. See Licensing Limitations

(see page 25) for a list of other possible causes of license failures.

The number of ﬁles that can be simultaneously processed by Cerify will be the number of allowed channels speciﬁed in the dongle. If a time-expiry dongle is connected, the default number of ﬁles processe d is 1.

Sometimes, you will need to change the number of ﬁles that can be simultaneously processed by Cerify. You can change the number of parallel processing channel setting by changing the value of the property “cerify.processorsperbox” in the “cerifysystem.properties” ﬁle located at

Directory>/Cerify/JBoss/server/all/conf

<Installation

The following lists the different situations for standalone installation:

When Cerify is started with no dongle connected, then (irrespective of whether a value has been speciﬁed in the “cerify.processorsperbox” property or not) the number of allowed channels is zero.

When Cerify is started with a perpetually licensed dongle and if the “cerify.processorsperbox” property is not set then the number of allowed channels is controlled by the dongle.

When Cerify is started with any valid dongle and a valid number of channels is speciﬁed for the “cerify.processorsperbox” property, then this value would be used if it is less than or equal to the number of channels controlled by the dongle. If the value is greater than the number of channels

ntrolled by the dongle then the number of channels controlled by the dongle takes precedence.

When Cerify is started with any valid dongle and the number of channels speciﬁed for the

cerify.processorsperbox” property is -1, then the number of allowed channels is controlled by the

“ dongle.

When Cerify is started with a time-expired dongle and if the “cerify.processorsperbox” property is not set, then the number of allowed channels is set to 1.

Install Apple QuickTime Player.

To process Apple ProRes ﬁles or to process ﬁles using the Generic QuickTime Video template or to process ﬁles using the JPEG 2000 Video template, you have to install QuickTime Player. You can download

QuickTime player from the link http://www.apple.com/quicktime/download/

NOTE. If QuickTime Player is already installed, make sure that it is version 7.5.5 or later.

24 Cerify Automated Video Content Veriﬁcation System User Manual

Getting Started System Installation

Licensing Limitations. The following limitations may affect the ability to license Cerify:

The Cerify 6.0 or later software requires the use of a HASP NetTime dongle. It is not possible to use a HASP Net dongle (as used with Cerify 5.x and earlier) without updating the dongle ﬁrmware. Green HASP Max dongles (as used with CerifyLite) are no longer supported.

When multiple HASP license servers are available on the network, there is a chance that the Cerify unit will try to retrieve its license from a wrong server and fail to obtain the required features, resulting i

It is possible to insert the HASP license dongle into a different machine from that on which Cerify is install hardware. Contact your Tektronix representative for more information on how to do this.

n licensing errors.

ed. This might be desirable if the Cerify hardware does not have a USB port - e.g. blade

It is poss machine that has suddenly lost power or otherwise failed. As a result of this the Cerify application will not be able to obtain a license until the license server is restarted. This will only be a problem when the license dongle is not on the Cerify machine, so in this conﬁguration we recommend that the license server machine is restarted when the Cerify application is restarted.

ible for the license server to retain handles to license features thatwerebeingusedbyaCerify

Cerify Automated Video Content Veriﬁcation System User Manual 25

Getting Started System Installation

Software Unin

Before uninstallation, ensure that you have administrator privileges. If you try to uninstall Cerify without administrato

Cerifycanbeuninstalledintwoways:

Through Start > Control Panel > Add or Remove Programs.

By rerunning the CerifySetup<version>.exe that you used to install the current version and following the on-screen instructions.

NOTE. If the Cerify installer version is higher than the currently installed version, the installation will be upgraded

If the Cerify installer version is lower than the current installed version, the installer will abort without taking a

NOTE. The Cerify installation process places the WinPCap and HASP utilities in the Add o r Remove Progra

programs or you want to continue to use it for other purposes. The HASP drivers are uninstalled. If you want to uninstall WinPCap, this can be done in the usual way from the Add or Remove Programs list.

ms list. The uninstallation process does not remove WinPCap in case it is being used by other

stallation

r privileges, the uninstallation process will be aborted.

to the newer version.

ny action.

NOTE. If you select the Backup database option during uninstallation, the current database will be backed up to

sion>_<timestamp>

back up the database. All relevant conﬁguration ﬁles will be backed up to

Settings\<username>\Cerify\CerifyConfig_<version>_<timestamp>

abase" option will not be available if you are uninstalling the Media Test Unit, as the Media Test

dat Unit does not have its own database.

NOTE. If Cerify 6.0 is uninstalled using Add or Remove Programs option or using Cerify 6.0 installer, there will be no “backup” option. The Cerify database and conﬁguration ﬁles will always be backed up at the location is installed, the installer will change the directory name “CerifyBackup” to “CerifyBackup_6.0”.

C:\Documents and Settings\<u sername>\Cerify\CerifyBackup_<ver-

C:\Documents and Settings \<username>\Cerify\CerifyBackup

Software Reinstallation

To reinstall Cerify, you must uninstall Cerify, and then rerun the installer. Rerunning the installer that was used to install the current version of Cerify will cause Cerify to be uninstalled. It does not repair the existing installation.

. You are given the option to change the directory where you want to

C:\Documents and

. The "Backup

. When Cerify 7.x

26 Cerify Automated Video Content Veriﬁcation System User Manual

Getting Started System Installation

Software Upgr

To upgrade your existing version of Cerify to the latest version, run the setup ﬁle for the latest version of Cerify and f

NOTE. Dongles used with previous versions of Cerify need to be reprogrammed to be used with version

7.2 or above. If an existing version of Cerify is being upgraded to version 7.2 or above, then it is

recommended that users send in their c2v ﬁles to Tektronix to obtain a new corresponding v2c ﬁle before installing the upgrade. This will allow users to program the dongle with the new v2c ﬁle before using Cerify version 7.2 or above.

If you want to upgrade Cerify in an HA cluster installation, the HA dongles on the Supervisor and Secondary Supervisor systems both need to be upgraded.

It is possible to upgrade any type of Cerify installation to any other Cerify installation type (for example, upgrading a Media Test Unit to a Supervisor).

If you would like to back up the current database while you are upgrading from Supervisor, Secondary Supervisor, or Standalone Cerify, choose the Backup database option during the upgrade

ss. The current database is backed up to the location

proce

name>\Cerify\CerifyConfig_<version>_<timestamp>

by choosing a different folder for backing up the ﬁles.

ade

ollow the on-screen instructions.

C:\Documents and Settin gs\<User

by default. You may change this location

The upgrade process also backs up relevant conﬁguration ﬁles from the current installation. These ﬁles are backed up to

sion>_<timestamp>

When you are upgrading to a Supervisor or standalone Cerify, the database is upgraded automatically after the installation. If the database upgrade fails, the installer will install Cerify with a clean database and inform you about the failure. The Backup database option will not be available while upgrading from Media Test Units, as they do not have their own database.

C:\Documents and Setting s\<User name>\Cerify\CerifyBackUp_<ver-

Reverting to the previous version of Cerify

n some circumstances, such as a failed software upgrade, you might want to revert to an older version of

I Cerify. To do this, follow these steps:

NOTE. You should have a database backup and a copy of conﬁguration ﬁles from the version you would like to revert to as a pre-condition.

1. Uninstall the current version of Cerify. While uninstalling, back up the database by selecting the

Backup database option.

2. Install the older version of Cerify.

3. Restore the database of older version using CerifyDatabase Utility tool. For help on how to use this

tool, refer to Database Backup/Restore Utility

(see page 277).

Cerify Automated Video Content Veriﬁcation System User Manual 27

Getting Started System Installation

Network Setti

NOTE. The Cerify software does no particular conﬁguration of any network interfaces - IP address, netmask, DNS, Net BIOS, etc. These should be set using the usual Windows methods.

Two Network Interfaces

In most circumstances, the PC on which Cerify is installed requires only one network interface. There are three scenarios where it is necessary to have two network interfaces:

When the network on which the Web clients will access the Web user interface needs to be physically separate from the network that stores the media ﬁle assets.

When the Cerify system is to access media ﬁles from a Grass Valley Proﬁle or K2 server. In this case, the additional network interface should be connected to the control network that runs the Grass Valley AMP service. This enables Cerify to list the contents available on the Grass Valley servers. The ﬁrst network

ngs

interface on the PC should continue to be connected to the video server network as follows:

On a standalone Proﬁle XP, to either the Media Ethernet card, if present, or the Ethernet interface of a Uni

On a SAN-based Proﬁle XP network, to the Gigabit Media network provided by a Universal Inter

versal Interface Module (UIM), if present

face Module, if present

On a SAN-based K2 network or a standalone K2 Media Client, to the Media/FTP network

For a K2 network, it is possible to use direct FTP connectivity, in the same fashion as other video servers. In this case, the AMP control network does not need to be accessed and no additional

work interface is needed.

net

When installing a Supervisor or Secondary Supervisor for an HA (high availability) cluster. In this

se, the second network is used for communication to Cerify via Ceritalk or Web user interface.

28 Cerify Automated Video Content Veriﬁcation System User Manual

Getting Started Accessing the Application

Accessing the Application

Starting the A

Before accessing the Web user interface, it is necessary to start the application. The Cerify application is typically mightneedtobeprocessedduetotheuseofdropboxesorCeriTalk.

To start the the Windows Start menu. If Cerify is installed as a Windows service, the startup is controlled via the Services applet in the Windows Control Panel.

NOTE. Cerify will fail to start if any other Web services using port 80 are running on the system where Cerify is installed. You can run Cerify once you shut down other Web services running on port 80 on the system.

The startup time of the Cerify application can be up to 3 minutes. The application has started and is ready to use when you see a Cerify login page in your Web browser.

To run Cerify, the user should have administrator rights.

You can change the port number used by Cerify by updating the Cerify system property “cerify.http.port”. See Conﬁguring the Cerify Application properties.

pplication

left running for long periods, even when there are no active users, because new jobs or ﬁles

application, click the Start Cerify icon. Alternatively, the application may be started from

(see page 275) for details on how to update Cerify system

. On start up, Cerify reads this port number from “cerifysystem.properties” and checks to ensure

NOTE

that this port is not used by any other application. If it ﬁnds the port number speciﬁed to be in use, an error message detailing the failure is displayed and startup operation is aborted. If the system cannot ﬁnd any value set to this system property, it will use the default port number 80.

Once the application has started, you can access the Cerify Web user interface from any computer on the same network. You can access the Web user interface using the URL

Address>:<http port>

where <http port> is the value set for the property cerify.http.port.

http://<Cerify IP

Cerify Automated Video Content Veriﬁcation System User Manual 29

Getting Started Accessing the Application

Cerify Window

Cerify can be optionally conﬁgured as a Windows service during installation.

NOTE. You must reinstall the Cerify software if you want to change the conﬁguration to run Cerify as a Windows service after the software has been installed.

Controlling of Cerify service

When Cerify is running as a service, you can control the service using the Services applet in the Windows Control Panel.

SMB MediaSet Processing

To e nsure ﬁle processing from SMB MediaSet work a s expected in service mode, make the following changes to the Cerify service:

1. From the Services panel, right-click on Cerify and select Properties. In the resulting properties dialog, get to the Logon tab. Select the This account radio button and enter the "use r name" of the administrative user who installed Cerify using the Browse button.

2. Enter the "password" in the other two boxes.

s S ervice

3. Click OK to save.

4. Stop and restart the Cerify service.

Limitations

If a MediaLocation is conﬁgured with a mapped network drive, then Cerify conﬁgured as a Windows service cannot access the ﬁles in this MediaLocation until the user is logged into the system.

Starting a Cluster

Perform the following steps to start a Cluster:

1. Start Cerify on the Supervisor unit by clicking Start > All Programs > Tektronix > Cerify > Start Cerify or start the Cerify servic e.

2. Start Cerify on the Secondary Supervisor unit by cl > Start Cerify or start the Cerify service (in the case of an HA cluster).

3. Start Cerify on Media Test Units by clicking Start > All Programs > Tektronix >Cerify Media Test Unit > Start Cerify or start the Cerify service.

4. Enter the URL http:// <Cerify host name> into your Web browser where Cerify host name is the

Supervisor host name. In the case of an HA cluster, you can use the IP address instead of the host name of the Suprvisor unit, which is conﬁgured for the network interface that was chosen for Cerify communication during the Supervisor installation.

icking Start > All Programs > Tektronix > Cerify

30 Cerify Automated Video Content Veriﬁcation System User Manual

Getting Started Accessing the Application

Accessing the

To access the application, you will need a Web browser installed on your computer.

To access the Web user interface from a remote computer, you need to know the IP address of the PC on which Cerify is installed in Standalone or Supervisor mode.

In the case of non-HA cluster or Standalone installation, enter the URL http://<Cerify IP

address>

Cerify is i

In the c ase of HA cluster, enter the URL http://<Cerify communication IP address> into your Web browser wh interface that was chosen for Cerify communication during the Supervisor installation.

NOTE. For cluster conﬁguration, Tektronix recommends that the Supervisor, Secondary Supervisor (in the case of an HA cluster), and Media Test Units are each conﬁgured with a static IP Address.

To access the Web user interface in a more convenient fashion on the PC on which Cerify is installed, click Start > All Programs > Tektronix > Cerify > Launch Cerify Web UI. This will automatically launch your default Web browser and take y ou to the correct Cerify Web page. Alternatively, when Cerify is installed as a Windows application, you can do this by right clicking on the Cerify system tray i installed as a Windows service.

Web User Interface

into your Web browser where "Cerify IP address" is the IP address of the system, where

nstalled in Standalone or Supervisor mode.

ere “Cerify communication IP address” is the IP address conﬁgured for the network

con and selecting Launch Cerify Web UI. The system tray icon is not available when Cerify is

NOTE. To access the Web user interface on a Media Test Unit, click Start > All Programs > Tektro nix > Cerify Media Test Unit >Launch Cerify Web UI.

Logging in to the Application

When you access the Cerify Web page, y ou are presented with the Cerify application login screen.

1. Enter your Username and Password in the login page. Once these credentials have been correctly supplied, the Cerify Web browser will display the top level Jobs page

2. Use your mouse and keyboard to navigate this Web interface and enter information in the usual way.

NOTE. The default user name is “admin” and password is “admin”.

NOTE. If the user name and password are invalid, an error message appears, and you will remain on

the login page. There is no limit to the number of times you can attempt to log in. User names are case sensitive, so if you have trouble logging in, check the Caps Lock key. If you forget your password, contact the Cerify administrator.

(see page 38).

Cerify Automated Video Content Veriﬁcation System User Manual 31

Getting Started Accessing the Application

CAUTION. If a session is inactive for a period, you will automatically be logged out. Any attempt to resume the session will redirect you to the login page.

Logging out o

Click the text that reads Log out in the page header to log out of the application. This returns you to the login page.

f the application

Limitations with the Web User Interface

Windows style paths (E.g. C:\Temp\ﬁle.text) are now supported the user interface for creating MediaLocations and MediaSets. However, they should not be used in Action Templates, where it is still necessary to use ﬁle:// style ﬁle names.

Altering the URL or user credentials of a MediaLocation that is being used by one or more MediaSets may cause inconsistent behavior in the Web user interface. If this occurs, create a new MediaLocation andrecreatetheMediaSetsthatwereusingtheoldMediaLocation. Changingthepropertiesofa MediaLocation that is not yet being used by any MediaSets does not cause any problems.

When setting up Grass Valley MediaLocations, you must specify the username and password to use to access the Grass Valley server. The system no longer assumes the username "movie" when

ﬁelds are left blank.

these

When jobs are restored from b eing archived they will always have a stopped status. This avoids the

ored job cause unexpected processing if the relevant MediaSet has had media ﬁles added since the

rest job was archived; this would cause a previously complete job to resume processing. You can restart stopped jobs using the Resume action in the drop-down menu at the bottom of the jobs monitor page.

The use of "<", "?", "&", "#", "%", "+" and "\" characters within media ﬁle name (or name of the folder containing the media ﬁle) will prevent the media ﬁle from being added to a MediaSet. If this occurs, rename the ﬁle (or folder).

The Web user interface has been tested using Microsoft Internet Explorer versions 7 and above and Mozilla Firefox 3.0 and above.

When creating a MediaSet, the Web user interface ﬁle browser will respond slowly if the directory being listed contains many thousands of sub directories. This situation is typical when using Pinnacle servers. During this period, the Web browser will show the message Please Wait. However, in some situations the Web browser will also display a warning dialog message indicating that the page's JavaScript is responding slowly. The message may be safely ignored and the script should be allowed to continue to completion.

You can use action templates to copy and delete single media ﬁles after they have completed processing. For video servers that store assets using directories (for example, Pinnacle servers), or referenced formats (for example, Omneon Quick Time ﬁles), it is not possible to copy or delete the entire media clip asset with this mechanism.

Not all ﬁles that Cerify is able to process can b e played back using VLC. More details can be found in the "Enabling VLC playback" section of the user manual.

32 Cerify Automated Video Content Veriﬁcation System User Manual

Getting Started Accessing the Application

When VLC is being used to playback media ﬁles, the client PC (that is, the PC being used to view the Web user interface and playback the ﬁles) accesses the media ﬁles using the same media ﬁle URL that Cerify uses. T

For SMB/CIFS access, the shared folder must previously have been mapped on the client PC. ThisisaWind

Only standard FTP servers can be accessed. This excludes some video servers, such as Omneon. This is a lim

Remote VLC players are unable to playback ﬁles that were originally processed using the ﬁle:// protocol. ﬁles processed using the ﬁle:// protocol.

his has the following implications:

ows limitation.

itation of the FTP client within VLC

A VLC installation on the same PC that Cerify is installed on will be able to playback

Playing b used.

Files ca

When processing multiple ﬁles whose names are identical, even though their paths may be different (e.g. f ID), using the copy action in the action template will result in ﬁles being copied over the previous one with the same name at the target location.

UNC notation is not supported in MediaLocation URLs. For example, paths of the form \\machinename\dir are not considered valid.

ack using VLC player does not work correctly if versions previous to 1.1.5 of VLC player is

nnot be added to a MediaSet if full ﬁlena me and path total more than 250 characters.

rom Pinnacle servers where all assets are named 'std' and are store d in folders named after an

Cerify Automated Video Content Veriﬁcation System User Manual 33

Getting Started Accessing the Application

34 Cerify Automated Video Content Veriﬁcation System User Manual

Operating Basics Concepts

Concepts

This section introduces the central concepts and entities used within the system. These entities and their relationships are shown in the following ﬁgure.

NOTE. The fol shows one of each type of entity. In practice, there can be many instances of each type of entity, with each child entity potentially being used by multiple parent entities.

lowing ﬁgure indicates the basic relationships between the entities. For simplicity, the ﬁgure

Entities

Users

Before using the system, you must log in with your username and password credentials. These credentials will have been assigned by a user who has administrator access.

By default, the system is installed with a single predeﬁned user whose name and password are both set to admin. This user has administrator access. It is recommended that this password is changed the ﬁrst time the administrator logs into the system. Administrator access rights allow a user to modify system properties, and in particular to create and modify MediaLocations

You can ﬁnd more information about users in the Modify User

page 164) sections.

Cerify Automated Video Content Veriﬁcation System User Manual 35

(see page 36) and Users.

(see page 163) and New User (see

Operating Basics Concepts

MediaLocations

A MediaLocation is a local or network ﬁle storage location from which the system can access media ﬁles. Typically, this would be a directory on the hard drive or a video server that provides FTP or Windows ﬁle share access. To create a MediaLocation, a user must supply its URL and the username and password required to access this URL. In addition, you must supply a unique name to be used within the system to identify the MediaLocation.

Only users with administrator access are able to create or modify MediaLocations.

Refer to Admin Page

MediaSets

A MediaSet is a collection of media ﬁles that you want to check.

A MediaSet can be a DropBox. A DropBox is a directory that is continually monitored for new media ﬁles. A MediaSet that is not a DropBox is simply a static collection of media ﬁles manually selected from one or more of the MediaLocations.

If a Job is associated with a DropBox, every ﬁle that appears in the DropBox over time will be processed.

For additional information, refer to MediaSets

Templates

To check a media ﬁle, you must deﬁne which checks should be applied when the ﬁle is tested. A Template is a collection of such checks chosen to perform speciﬁc tests that you require. The four types of Te

(see page 163) and MediaLocation Management (see page 164) for more information.

(see page 151).

mplates are:

Container Templates, which apply to the transport/container layer of a media ﬁle

Video Templates, which apply to the digital video content of a media ﬁle

Audio Templates, which apply to the digital audio content of a media ﬁle

Action Templates, which specify actions to be performed as a result of processing a media ﬁle

You can create multiple Templates of the same type for different purposes. For example, you might create a "Movies" Template, which contains a set of rules appropriate for HD MPEG-2 content, and an "on-line content" Template, which contains a set of rules appropriate for lower resolution H.264/AVC content.

For additional information, refer to Templates

36 Cerify Automated Video Content Veriﬁcation System User Manual

(see page 83).

Operating Basics Concepts

Proﬁles

AProﬁle gathers together a container, video, audio, and action Template, providing a complete set of checks that ca can be omitted, depending on your requirements. For example, it makes no sense to apply any container or audio checks to a media ﬁle that consists solely of a video elementary stream.

You can deﬁne multiple Proﬁles for different purposes. Following on from the previous example, you might create an "on-line content" Proﬁle, which speciﬁes a QuickTime Mov ﬁle wrapper in the container Template, H.264/AVC checks for the video Template, and AAC checks for the audio Template.

n be applied when you want to test one or more media ﬁles. Any of the component Templates

For additional information, refer to Proﬁles

DPP Proﬁles

Digital Production Partnership (DPP) provides the guidelines for HD and SD ﬁle delivery. It also speciﬁes MXF metadata, which are mandatory to be delivered with the ﬁle. Cerify has “prepackaged proﬁles” needed for veriﬁcation of ﬁles delivered against the DPP constraints. When Cerify is installed, the prepac

With the prepackaged “DPP Proﬁles,” Cerify processes the input ﬁles by attaching the right proﬁle for HD and SD

Refer to the following for more details on DPP speciﬁcations:

DPP Technical Delivery Standards for ﬁle delivery, version 4.1-2014 (http://www.digitalproductionpartnership.co.uk/)

AMWA Application Speciﬁcation: AS-11 MXF Program Contribution

ﬁle delivery speciﬁcations. Use the following steps to test ﬁles for DPP ﬁle delivery speciﬁcations:

DPP

1. To check for the DPP compliance, you need to conﬁgure MediaSets or watch folders with the ﬁl

(see page 80).

kaged proﬁles will be visible under the Proﬁles tab.

delivery speciﬁcations, based on the audio track combinations.

e/folder locations. This can be created in Cerify from MediaSets > New Mediaset option.

2. Youalsoneedtoconﬁgure the location of the reports for the ﬁles being processed from the Admin

enu option. In the “Admin” Menu, expand ”Report File Settings” to conﬁgure the reports folder.

M This location stores the PDF reports and PSE Certiﬁc ates generated by Cerify after each ﬁle is processed for DPP compliance.

3. Now create a new Job by attaching the “DPP Proﬁle” from the list of proﬁles to the MediaSet or watch folder that was created earlier.

4. Cerify creates each Job with the ﬁlename and attaches the right DPP proﬁle base d on ﬁle characteristics.

5. Once the Job is completed, i.e., when the Job status changes to Complete, you can view the Job

results from the Web UI or from the conﬁgured reports folder. The PSE Certiﬁcate for each processed ﬁle would be under the subfolder “PSE Report”.

Cerify Automated Video Content Veriﬁcation System User Manual 37

Operating Basics Concepts

Jobs

A Job is the term given to an individual testing p rocess that can be run by the system. Each Job can process multiple media ﬁlesorasinglemediaﬁle, depending on the requirements of the user. The set of ﬁles processed by a Job is deﬁned by its MediaSet.

By creating a Job, you request the checks deﬁnedbyaparticularProﬁle be applied to the ﬁles in a particular MediaSet. In addition, you must specify the name and priority of the Job. The system can queue multiple Jobs to be run, whereby each Job is scheduled to be processed according to its priority.

The system processes one media ﬁle at a time.

How long it takes to process a Job depends upon a number of factors:

The resolution of the video being processed (the larger the picture, the slower the processing)

Alerts

The video

The number of tests selected (performing all the video quality checks can be processor intensive, because

The bit rate (in general, the higher the bit rate, the slower the processing)

Hardware performance of the PC on which Cerify is installed

For additional information, refer to Jobs

Alerts announce any checks that fail as a Job executes. Each alert indicates the severity of the failure, as well as where and why the check failed. The system gathers alerts associated with a particular Job,

at you can access the results from the top level and easily navigate to the details, such as which

so th individual frames have Alerts.

system organizes and summarizes any alerts raised against a particular Job, so that, at the top leve l , a

The single processing result status can be assigned to the Job. To view more detailed information, you can drill down through the interface, revealing (for example) which individual frames have raised alerts.

For additional information, refer to Alert Details

standard concerned (some standards, such as H.264/AVC, take more time to process)

it requires the analysis of every pixel in each frame of video)

(see page 65).

(see page 75).

Reports

Reports provide you with a way to query the system database and obtain information in a predeﬁned format. A Job report presents the results of a particular Job in tabular form.

For additional information, refer to Reports

38 Cerify Automated Video Content Veriﬁcation System User Manual

(see page 159).

Operating Basics Concepts

Archiving

The system allows you to archive entities that are no longer required. MediaSets, Templates, Proﬁles, and Jobs can all be archived.

When an entity is archived, it remains present in the database, and can be recovered if necessary. Archived entities are inactive and usually hidden from view. Inactive entities cannot be used to construct new entities. So, for example, if a Job is archived before completion, it will not process any pending media ﬁles.

For additional information, refer to Active/Archive View Control

Control (see page 46).

Clustering

To increase processing throughput, units can be clustered. Each cluster consists of a single Supervisor unit and one or more Media Test Units.

In a clustered conﬁguration, the Supervisor unit hosts the database and the Web server. The Supervisor unit communicates with the rest of the local network, accessing media ﬁles and serving the Web user

ace. The Media Test Units are allocated media ﬁles to process by the Supervisor unit. The results of

interf this processing are stored by the Supervisor unit into a single database.

Growing File Support

Cerify supports the processing of growing ﬁle on FTP, SMB, a nd File protocols. Cerify can start processing the ﬁle as soon as the ﬁle copy is started. For more information refer to Growing Media Files

(see page 296).

(see page 45) and Archive/Restore

Cerify Automated Video Content Veriﬁcation System User Manual 39

Operating Basics Concepts

Audio Loudnes

Cerify supports audio loudness correction for AC3, Dolby E and PCM (RIFF, BWF, AIFF, AES3, 8-ch AES3) audio ty

MPEG transport streams: type AC3

MXF streams: types RIFF, BWF, AIFF, AES3, 8-channel AES3 and Dolby E formats

QuickTime streams: types RIFF, AIFF and Dolby E formats

Audio is corrected using the Dolby audio correction library. AC3, Dolby E and PCM audio templates have rules for conﬁguring parameters for audio loudness correction. TS, MXF and QuickTime container templates have rules for conﬁguring rebundling related settings.

If Cerify does not support the rebundling of corrected audio or if the container rebundling settings are not selected (or not present), then the corrected elementary stream w ill be stored in the asset location with the name in the format <original_ﬁle_name> corrected_ES <track ID>.es. For any reason, if the attempt to store th then a copy will be retained in the Cerify temp folder.

Audio Loudness Correction Log

This log contains details of the audio loudness correction performed by Cerify. The details include parameters such as audio loudness and dialnorm values, before and after correction. The log ﬁle name will be in the format of “alc-log-mm-dd-yyyy.csv” and will be available in a directory “ALC-Logs” in the Cerify root directory. Logs will be created one per day. For example, on 12th September 2013, the log ﬁle nam

e corrected ﬁle (elementary stream or the re-bundled stream) into the original asset location fails,

e created will be “alc-log-09-12-2013.csv”.

sCorrection

pes. Cerify also supports rebundling of corrected audio tracks as follows:

40 Cerify Automated Video Content Veriﬁcation System User Manual

Operating Basics Functional Overview

Functional Overview

This section gives an overview of the Cerify user interface.

System Tray I

When Cerify is installed as a Windows application, the system tray icon appears in the system tray, near the clock, o Windows service. The system tray icon provides menu items that allows easy control of the application.

Cerify system tray icon

Left-click the icon to launch the default Web browser and load the Cerify page showing the list of jobs in it.

Right-click the icon to bring up the system tray icon menu, which provides four options:

con

nce the application is started. The system tray icon is not available when Cerify is installed as a

Launch Cerify Web UI, which launches the default Web browser and loads the Cerify page showing the list of jobs in it.

About, which shows the About Box of the application. The About Box displays product details such as product name, version and copyright information. The About Box can be closed by simply clicking on it.

Stop Cerify, which stops all job processing and shuts down the application completely. The application takes about 2 to 3 minutes to shut down completely. Note that shutting down the Web browser when using the Web user interface does not stop Cerify or stop any jobs running.

CAUTION. Do not stop the application or its component services using the Microsoft Windows Task Manager. Always use the system tray menu for shutting down the application.

Launch Cerify User manual, which launches the user manual PDF.

Cerify system tray menu

Cerify Automated Video Content Veriﬁcation System User Manual 41

Operating Basics Functional Overview

Web User Inter

The user interface consists of a structured collection of various types of pages accessed using a Web browser. The p elements:

Icons (see pa

Navigation bar (see page 44)

Trail widget (see page 45)

Active/archive view control (see page 45)

Archive/restore control (see page 46)

Tables (

Footer (see page 47)

face

ages contain a page header, page body, and footer. The pages can contain the following

43)

see page

46)

42 Cerify Automated Video Content Veriﬁcation System User Manual

Operating Basics Functional Overview

Icons

The following table lists the icons used in the interface.

Icon Description

Collapse this section

Expand this s

ection

Copy this item

Remove this item

Edit this item

Directory

File in a directory

Obtain co

Status un

ntext sensitive help

known

Failed with fatal error status

Failed with error status

Failed with warning status

Succeeded with no errors or warnings

eated through the Cerify Web user interface

Item cr

Item created through CeriTalk API

ems in this column in descending order

Sort it

tems in this column in ascending order

Sort i

Press this button to trigger the selected action

Add another set of values to the rules

Removes any set of values from the rule

xxx

Cerify Automated Video Content Veriﬁcation System User Manual 43

Operating Basics Functional Overview

Page Header

Navigation Ba

r. The navigation bar provides a quick route to the top level of any of the pages. The

selected button on this header indicates which top-level page is selected. In the following example, the Jobs page

Navigation

(see page 65) is selected.

bar

The login details, located below the navigation bar at the top-right section of the screen, show who you are logged in as and provide a link enabling you to log out.

cense status of Cerify is also reported in this section. The license information can be one of the

The li following:

License status Details

Licensed

Licensed - # day(s) remaining Cerify is licensed for the next # number of days and Jobs

Licensed - expires today

License expired

Unlicensed

xxx

Cerify is fully licensed. Jobs can be processed.

can be processed.

Cerify is licensed for today and Jobs can be processed.

The license for Cerify has expired. The Web interface may be used but no new Jobs can be started and Jobs in progress will stop.

Cerify is unlicensed. This may be because a suitable dongle cannot be found. The Web interface may be used but no new Jobs can be started and Jobs in progress will stop.

If Cerify cannot ﬁnd a license w hen it starts up, Jobs will remain in the waiting state until a license can be found. An additional message will be displayed in the Jobs Monitor page, above the list of Jobs in this case.

If Cerify ﬁnds a license when it starts up and later becomes unlicensed, Jobs will be processed, but will fail because no license is available.

44 Cerify Automated Video Content Veriﬁcation System User Manual

Operating Basics Functional Overview

Breadcrumb. The breadcrumb allows you to see your position in the hierarchy and to navigate from this

position. For example, the following ﬁgure shows that you have navigated three levels down from the

Jobs Monitor

Monitor, Job Details, Processing Result, and Alert Details ﬁelds are all links that allow you to quickly step up one or more levels.

The breadcrumb

see page

(

65) to view the Alert Details (see page 75) for a particular media ﬁle. The Jobs

Page Body

The body of the page holds the buttons, forms, tables, and reports that are used to query and control the system.

obs Monitor page body

The J

Active/Archive View Control. Jobs

MediaSets

which entities of a particular type to view. Using this control, you can view Active, Archived, or All

tities of a given type. For example, the preceding ﬁgureshowsapageofActiveJobs.

NOTE. When an entity is archived, it is not removed from the database, but it becomes inactive. Inactive entities cannot be used to construct new entities.

For example, a new Job active Proﬁles

Cerify Automated Video Content Veriﬁcation System User Manual 45

(see page 151) can all be archived. The Active/Archive view control allows you to choose

(see page 65) can only be constructed from active MediaSets (see page 151) and

(see page 80).

(see page 65), Proﬁles (see page 80), Templates (see page 83) and

Operating Basics Functional Overview

Archive/Restore Control. The Archive/Restore control allows you to archive and restore entities. This

control appears below the tables of items on the Jobs Monitor

(see page 65) page for example.

To archive entities, select the corresponding check boxes in the left column of the table, and then click the Go button on the Archive/Restore Control. The preceding ﬁgure shows a user ready to archive three Jobs.

To restore entities from archive, set the Active/Archive View Control

(see page 45) to All or Archived,

which allows you to select archived objects. After selecting the items that you would like to restore, set the Archive/Restore Control to Restore from archive, and then click the Go button on the Archive/Restore Control. You can also delete, stop, and resume entities. For more information, refer to Modifying Jobs

(see page 71).

Select All Control. The Select All control is p resented as a checkb

ox input associated with the Sel column header in entity tables in the Cerify Web user interface. This control can be used to select/deselect all items in the associated table before performing actions on them using the Archive/Restore control. This control is available on the tables that list Jobs

(see page 65), Pro ﬁ les (see page 80), Templa tes (see

page 83) and MediaSets (see page 151).

Tables.

The system displays collections of entities in the form of tables. These tables share a number of common features.

The leftmost column of the table allows you to select the item.

The arrow icons and allow you t

o sort the table based on values in a particular column (for

example, sort a table of Jobs based on their Start Time).

The white arrow shows the currently active sort order.

Sorting the table deselects all items.

Clicking the help icon provides information on a particular column.

In the preceding ﬁgure, since you have selected to view a maximum number of ﬁve rows in a table and there are more than ﬁve active Jobs, table paging controls appear below the table. For information on changing the table display preferences, refer to the Options

(see page 160) page.

The highlight indicates that page 1 is the current page.

To select a different page, use the numbered links or the prev and next links.

The following table describes each column in the tables.

Column heading Description

Channel

Shows if a Job or MediaSet was created by a user through the Web user interface

or by an automation system through the CeriTalk API

Copy

Click the copy icon

Creator Shows which user created an item

Creation Time Shows when this Job was created

to copy an item and edit the copy

46 Cerify Automated Video Content Veriﬁcation System User Manual

Operating Basics Functional Overview

Column heading Description

Description

Edit

End Time

Files

File Size Shows the total size of all the ﬁles in a MediaSet. N ote that Cerify uses "kB", "MB" and

Job Status Shows the status of a Job (for example, Processing)

MediaSet Shows the MediaSet name for this Job

Name

Priority

Proﬁle Shows the Proﬁle name for this Job

Progress

Result

Sel Check the box in this column to select an item to be archived or restored

Start Time Shows when a Job or media ﬁle started processing

Status Shows the Active/Archive status of an item

DropBox

xxx

Shows the desc

Click on the edit icon

Shows when a Job or media ﬁle ﬁnished executing

Shows the total number of ﬁles in a MediaSet

"GB" to represent 1024 bytes, 1048576 bytes, and 1073741824 bytes, respectively; a 1000 based system is not used.

Shows the name of an item, as originally entered by the user

Shows a Job priority (for example, High)

Shows the percentage progress of a Job

Shows a Job processing result

Indicates if a given MediaSet is a DropBox

ription of an item, as originally entered by the user

to edit an item

Empty Tables. When you navigate to the Jobs page, if no Jobs (see page 65) have been created, or all Jobs

are archived, the page body will appear as shown in the following ﬁgure.

No Jobs

Collapsing Headings. Some pages contain sections that can be expanded or collapsed to control how much

information is displayed on the page. Click anywhere on a line containing the collapse icon

information. Click on a line containing the expand icon

to view more information.

to hide

Footer

The footer displays a copyright notice and version information.

Cerify Automated Video Content Veriﬁcation System User Manual 47

Operating Basics Functional Overview

Error Handling

Form Input Errors

Thesysteminformsyouifamistakeismadewhileﬁlling an input form. For example, if you attempt to create a New Job be redisplayed with an error message. The error message is in red text, next to the invalid ﬁeldonthe form as show

ninthefollowingﬁgure.

(see page 66) without supplying any text in the Job Name ﬁeld, the form will

Input errors

48 Cerify Automated Video Content Veriﬁcation System User Manual

Operating Basics Functional Overview

Work Flow Errors

The system informs you if an attempt is made to perform an operation out of the correct sequence. For example, if you attempt to create a Job

page 151) has been created, an error page will appear, as shown in the following ﬁgure:

Work ﬂow error page

(see page 65) before a Proﬁle (see page 80) or MediaSet (see

Application Errors

Occasionally the application is unable to handle a request, in which case it will display the message: An internal Cerify Error has occurred. You should be able to continue using the application as normal after

this. If the problem persists, contact your local Tektronix representative.

Cerify Automated Video Content Veriﬁcation System User Manual 49

Operating Basics Tutorials

Tutorials

The following tutorials start from a clean installation and step through the process of creating a new Job andcheckingonitsprogress.Torunthesetutorials, you will need the following:

Access to a computer with Cerify installed

A Cerify user account with administrator privileges (see page 163)

The tutorials are as follows:

Before You Begin (see page 52): How to start using the system

Creating a

Creating a MediaSet (see page 55): How to create a MediaSet by selecting ﬁles from a MediaLocation

Creating a Template (see page 58): How to create a Video Template

Creating a Proﬁle (see page 60):HowtocreateaProﬁle from your Video Template

Creating a Job (see page 61): How to create a Job from your Proﬁle and MediaSet

Inspecting Job Results (see page 61): How to review the progress of a Job and inspect the Job results

Creati

Archiving (see page 62): How to archive the MediaSet and the Job

Exporting Templates (see page 90): How to export the Video Template

Importing Templates (see page 63): How to import the Video Template previously exported

MediaLocation

ng a Report

(see page 62): How to create a printable report on the Job

(see page 54): How to create a MediaLocation

50 Cerify Automated Video Content Veriﬁcation System User Manual

Operating Basics Tutorials

Work Flow

The following ﬁgure indicates the dependencies between the entities that make up a Job. It shows, for example, that a MediaSet requires a MediaLocation; any attempt to create a MediaSet when no MediaLocations exist will generate a Work Flow Error attempt to create a Job when there are no active MediaSets or Proﬁles.

(see page 49). Similarly, it is a work ﬂow error to

Entity relationships

Cerify Automated Video Content Veriﬁcation System User Manual 51

Operating Basics Tutorials

Before You Beg

1. Start the Cerify application by clicking the Start Cerify icon on your desktop or by using the Start

menu. For info

NOTE. To run this tutorial, you must log in with administrator access. Note that the system comes with a single user already set up as administrator. The Username and Password are both set to admin.

If a session is inactive for a certain period of time, you will be logged out. If this happens during the tutorial, you will be redirected to the login page. Log back in to continue.

2. On successful start up, Cerify presents you the login page using your default browser. The following

TIP. On any Web page you can click the help icon obtain context-sensitive help.

rmation about accessing the application, see Accessing the Application

http://134.64.235.216.

(shown below on the right side of the login page) to

(see page 29).

3. En

52 Cerify Automated Video Content Veriﬁcation System User Manual

ter your user name and password into the appropriate ﬁelds in the login page and click the Enter

button. After you have logged in, you will be taken to the Jobs Monitor

(see page 65).

Operating Basics Tutorials

The following ﬁgure shows what this page looks like when no Jobs are active, which will be the case if this tutorial is being run from a clean installation.

Jobs Monitor page

The header contains the Navigation Bar the major areas of the user interface. In this case, the Jobs button is selected, indicating you are on one of the Jo

In addition, the header shows that you are logged in as admin.

The body of the page contains:

bs pages.

A line of text informing you that there are no Jobs in this view

An Active/Archive View Control (see page 45), allowing you to view any archived Jobs (see page 38)

A New Job button. Clicking this button will generate a workﬂow error, because you have not yet created a Proﬁle and a MediaSet. For additional information, refer to Work Flow Errors

(see page 44), which allows you to quickly navigate between

(see page 49).

Cerify Automated Video Content Veriﬁcation System User Manual 53

Operating Basics Tutorials

Creating a Med

A MediaLocation is a network location from which the system can access media ﬁles. Users with administrato

1. Click the Admin buttonontheNavigation Bar

page, as show

Creating a MediaLocation

iaLocation

r access can create and modify MediaLocations

(see page 44) to access the Admin (see page 163)

ninthefollowingﬁgure.

(see page 36).

2. Start creating a new MediaLocation by clicking the Go button next to the text that reads Create

new Me

diaLocation. You should see a form.

3. Fill in the ﬁelds in the form as shown in the following table, and then click Create to create the

aLocation.

Medi

Field Value

MediaLocation Name

URL

rname

Use

Password

xxx

Cerify example content

c:\Program Files\Tektroni x\Cerify\cerify_demo

54 Cerify Automated Video Content Veriﬁcation System User Manual

Operating Basics Tutorials

New MediaLocation

NOTE. The system validates the MediaLocation details when you click the Create button, checking that the MediaLocation name is unique, the URL exists, and that the speciﬁed user can access ﬁles at that URL. If any of these checks fail, the MediaLocation will not be created; instead, the form will be posted back to the screen with an error message indicating what the problem is.

For additional information on creating MediaLocations, refer to MediaLocation Management (see

page 164)

Creati

ng a MediaSet

Now that you have created a MediaLocation, you can create a MediaSet that collects together some of

es at this location.

the ﬁl

1. Click the MediaSets button on the Navigation Bar

2. Start creating a new MediaSet by clicking the New MediaSet button. You will see a page like the one

shown in the following ﬁgure.

New mediaset

3. Select no for the DropBox mode.

(see page 44) to visit the MediaSets page.

Cerify Automated Video Content Veriﬁcation System User Manual 55

Operating Basics Tutorials

4. Enter a suitable name for the MediaSet and click Create to create the MediaSet and continue to the

Edit MediaSet

(see page 153), a s shown in the following ﬁgure.

NOTE. For the M

icrosoft Smooth Streaming format, the MediaSet should point to the “.ism” ﬁle.

Edit MediaSet

The Edit MediaSet page provides details of the ﬁles already in the MediaSet (there should be none yet). It shows directories with a

for you to add new ﬁles.

5. Add ﬁles to the MediaSet using the directory and ﬁle browser.

To reveal the contents of a directory, double-click the directory.

To close the directory and go up a level, open the drop-down menu control at the top right of the

ﬁle browser to provide a selection of recent directories.

To select a ﬁle, double-click the ﬁle icon (it will appear in the Files table).

56 Cerify Automated Video Content Veriﬁcation System User Manual

icon, and ﬁles with a icon. The page also provides the controls

Operating Basics Tutorials

The following ﬁgure shows a MediaSet to which three ﬁles have been added.

MediaSet containing ﬁles

6. You can also add a ﬁle to the MediaSet by entering the full path to the ﬁle in the File name text ﬁeld at the bottom of the page.

This path must include the full URL of the ﬁle. For example,

tronix\Cerify\cerify_demo\news\airport_interview.ts

c:\Program Files\Tek-

Cerify Automated Video Content Veriﬁcation System User Manual 57

Operating Basics Tutorials

Creating a Tem

To test the ﬁles in your new MediaSet, you need to decide which checks to apply. Checks can be applied to the container or wrapper layer, the video stream, and the audio stream, using container, video, and audio Templates, respectively.

In addition, using an Action Template, you can deﬁne actions to take when ﬁles have been checked.

1. Click the Te mpla tes button on the Navigation Bar see a page listing the Templates that are present in your current Templates view.

Select Video Template Type

1. Click the New Video Template button to create a new Video Template. You will be prompted to select a Template type, as shown in the following ﬁgure.

plate

(see page 44) to start creating a Template. You will

Select Template type

The Template type you choose depends on the type of video content you w ant to check. be the Video Standard used when the video was encoded: for example, MPEG-2 or H.263.

2. Use the drop-down menu to select MPEG-2, and then click th

Video Templ ate page. The New Video Template page is where you deﬁne which checks to include in

your Video Template.

e Select button to take you to the New

This type will

New Video Template

CAUTION. The new Template will not be saved until you click the Create button at the bottom of the page. When you click Create, the system will check th prompt you to ﬁx any problems. If there are no problems, the new Template will be created and stored in the database.

1. EnteranamefortheTemplate,“NewsVideo”, and optionally a d escription.

2. Conﬁgure the checks to be applied by selecting the check boxes and entering values into the text ﬁelds.

(See the following ﬁgure for a typical Video Template conﬁguration.) Use the Add / Remove buttons to conﬁgure the Resolution rule with multiple sets of valid values

of the checks performed by each rule, click on the

at the ﬁelds you have ﬁlled contain valid data, and

(see page 89). For a full explanation

icon next to each rule name.

3. Click the Create button at the bottom of the page to create the new Video Template.

58 Cerify Automated Video Content Veriﬁcation System User Manual

Operating Basics Tutorials

The following ﬁgure shows a typical MPEG-2 Video Template conﬁguration. When this Template is used to check a video stream, it will check:

The video is MPEG-2 encoded.

The video is encoded using MPEG-2 Main Proﬁle, Main Level.

The video bit stream syntax conforms with the MPEG-2 Standard, but any alerts relating to Buffer analysis and alert number 22209 will be suppressed.

A maximum of 500 alerts will be displayed.

Each alert type will be displayed a maximum of 20 times.

The video r

esolution is 720 by 480 pixels or 1280 by 1080 pixels.

Video Template conﬁguration

For additional information, refer to Video Templates

Cerify Automated Video Content Veriﬁcation System User Manual 59

(see page 105).

Operating Basics Tutorials

To create an Audio Template, the process is very similar as described in the following steps.

1. Return to the Templates page by clicking the Te mpla t e s link on the navigation bar.

2. Click the New Audio Template button to create a new Audio Template. Select MPEG-1 / MPEG-2 Audio from the select box, and then click the Select button.

3. Enter the name "News Audio" for the Template, and optionally a description.

4. Conﬁgure the checks to be applied by selecting the check boxes and entering values into the text ﬁelds.

The precise choice of rules and parameters does not matter for the purposes of this tutorial.

5. Click the Create button at the bottom of the page to create the new Audio Template.

Create a Container Template using the same steps. When prompted to select the Template type, choose MPEG-2 Transport Stream; otherwise follow the same steps as for the other Templates. The precise choice of rules and parameters does not matter for the purposes of this tutorial.

Creating a Proﬁle

To use your new template in a Job, you must include it in a Proﬁle.

1. Click the Proﬁles buttonontheNavigation Bar

2. Click the New Proﬁle button.

3. Enter a name and optionally a description for the Proﬁle, as shown in the following ﬁgure.

4. Select the Container Template, Audio Template, and Video Template you just created. If you created

more than one audio template, click the Plus icon to display another audio template selection ﬁeld.

5. Click the Create button to create a Proﬁle.

(see page 44) to go to the top-level Proﬁles page.

For additional information, refer to Proﬁles (see page 80).

60 Cerify Automated Video Content Veriﬁcation System User Manual

Operating Basics Tutorials

Creating a Job

Having created a MediaSet and a Proﬁle, you can now create a Job.

1. Click the Jobs button on the Navigation Bar

2. Click the New Job button.

3. Enter a name for the Job. Set the Job priority to "Low", and select the Proﬁle and MediaSet that

you previously created.

4. Click Create to create the Job.

Creating a Job

Inspecting Job Results

(see page 44) to go to the top-level Jobs page.

1. Access the Jobs Monitor page by clicking the Jobs buttonontheNavigation Bar (see page 44).This page gives feedback on the status of all running Jobs (unless the Job view has b een set to Archived). This feedback includes:

A processing result summary for each Job

Status and progress information for each Job

mmary information about the entities associated with each Job

Timing information for each Job

2. Click the AutoRefresh button in the page header to arrange for the page to refresh periodically with no further intervention. This is useful when you are monitoring the progress of a large Job that

ight take several minutes to complete.

3. Wait for the Job Status to show complete before continuing with this tutorial. This may take several minutes.

4. From the Jobs Monitor, you can drill down for more details about a Job result. For additional information on Inspecting Job Results, refer to Job Details

page 73) and Alert Details (see page 75).

(see page 72), Processing Result (see

Cerify Automated Video Content Veriﬁcation System User Manual 61

Operating Basics Tutorials

Generating a R

1. Access the Reports page by clicking the Reports buttonontheNavigation Bar (see page 44).This page allows yo

2. In the Enter Jobname ﬁeld, enter the name of the job that you created.

3. Select the report format. You can select either HTML or PDF (Summary or Complete) report format.

4. Click the Generate button to generate a report on your Job. For detailed description, refer to Reports

(see page 159).

Archiving

1. To archive your Job (refer to Archiving (see page 39)), go to the Jobs Monitor page by clicking the Jobs butt

a. Select the Job to archive by selecting the checkbox in the left column of the Jobs Monitor table.

b. Make sure that the action drop-down menu under the table reads Archive, and then click Go to

archive the Job.

eport

u to generate Job processing reports.

on on the Navigation Bar

(see page 44).

Archiving a Job

2. To view archived Jobs, set the Active/Archive view control to All or Archived. The table will be updated to reﬂect your choice. You can restore archived Jobs from this new view, if required. MediaSets, Templates, Proﬁles, and Jobs can all be archived.

62 Cerify Automated Video Content Veriﬁcation System User Manual

Operating Basics Tutorials

Exporting Templates

1. To export your Templates, go to the Templates page by clicking the Te mpla tes buttononthe

Navigation Bar

2. Select the Templates to export by selecting the checkbox in the left column of the appropriate Template table.

3. ClickontheExport button at the bottom of the page to export the selected Template.

(see page 44).

4. When prompt the location you select.

Importing Templates

1. To import the XML Template ﬁle generated by Exporting Templates (see page 90),gototheTemplates page by clicking the Te m plate s buttonontheNavigation Bar

2. Click the Browse button at the bottom of the page to access the Open File dialog.

3. Navigate to the location where the ﬁle is, select it, and click Open.

4. Click o the option If a template of the same name already exists, replace it, and then import the template.

5. The Te displayed on the Te m plat e s page.

NOTE. There is a range of example templates in the

Templates

canviewthemintheTemplates page.

ntheImport button to import the selected ﬁle. A template with the same name will exist, select

mplates deﬁnedintheﬁle will be successfully imported, and a success message will be

directory that may be useful to you. The example templates are preloaded onto Cerify and you

ed, select a location to save the Templates ﬁle, and click Save.Theﬁle will be saved to

(see page 44).

<installation directory>/Examp le

Cerify Automated Video Content Veriﬁcation System User Manual 63

Operating Basics Tutorials

64 Cerify Automated Video Content Veriﬁcation System User Manual

Reference Introduction

Introduction

This chapter provides a reference guide for users.Itisorganizedinmuchthesamewayastheuser interface is organized, with sections for each main page and subsections for the subpages.

Jobs

A Job applies the various checks in a Proﬁle (see page 80) against the media ﬁles in a MediaSet (see

page 151).

A Job is identiﬁed by its unique name. In addition, a Job is assigned a Priority upon creation.

The top-level Jobs page is accessed by selecting the Jobs button from the navigation bar. When you open this page, you will be presented with a Tabl e the Archive/Restore Control will be d

isplayed.

(see page 46). If no Jobs match the current ﬁlter, an informative message

(see page 46) displaying Jobs that are ﬁltered according to

Jobs Monitor

The Jobs Monitor page provides a top-level view of the status of Jobs. The following ﬁgure shows the status of three Jobs. One Job is succeeded with no errors or warnings; the remaining two have raised errors.

NOTE. In this example, the user has limited both how many rows and which columns of the Jobs Monitor are displayed.

The Jobs Monitor page

Cerify Automated Video Content Veriﬁcation System User Manual 65

Reference Jobs

From this page it is possible to:

View Job Details (see page 72) for a Job by clicking on the Job name.

View the details for the Job MediaSet (see page 151) and Proﬁle (see page 80) by clicking on the MediaSet or Proﬁle name.

Create a New Job (see page 66) by clicking the New Job button.

Create a New Job (see page 66) by clicking the copy icon.

Modifying Jobs (see page 71) by clicking the jobs to be modiﬁed, selecting the required action from

the Archive/Restore control and clicking the Go button.

New Job

The New Job page is accessed either by copying an existing Job (see page 65), or by creating a new Job.

TheNewJobpage

You should enter a Job Name,setthePriority, and choose a Proﬁle and a MediaSet, before clicking the Create button to create the Job.

TION. Jobs cannot be created unless one or more MediaSets

CAU

are active. If this is not the case, then any attempt to create a Job will generate a Work Flow Error

(see page 49).

(see page 151) and Proﬁles (see page 80)

66 Cerify Automated Video Content Veriﬁcation System User Manual

Reference Jobs

New Single Fil

To create a new Job against a single ﬁle, click New single ﬁ le job in the Jobs page to open the job creation wizard page sh

The New Single File Job page

You should enter a Job Name,setthePriority,andenteraMedia Location URL.Thisurlcanbeanyof thesupportedtypessuchasftp,smbandﬁle. In case of the ftp and smb urls, the credentials for accessing the url have to be supplied in the Username and Password text boxes.

eJob

own in the following ﬁgure.

When the Preprocess the ﬁle to retrieve content information check box is enabled, Cerify identiﬁes the container, video and audio formats and provides the appropriate templates for selection. When this check box is disabled, Cerify allows the user to create their templates.

Click the Browse buttontoopentheﬁle browser page shown in the following ﬁgure, which allows you to select the required ﬁle for processing.

Cerify Automated Video Content Veriﬁcation System User Manual 67

Reference Jobs

The File

After y the essence details in the stream. After retrieving the stream details, the wizard brings up the Template Selection page shown in the following ﬁgure. This page has the selections for the container and/or video and/or audio and cross track template based on their presence in the stream.

The template will have both the audio and cross track template selection options if the presence of audio is detected in the stream. The action template selection will always be present for selection irrespective of the contents of the stream.

Selection Browser page

ou select a ﬁle, click the Next button, which starts the wizard to partially process the ﬁle to retrieve

68 Cerify Automated Video Content Veriﬁcation System User Manual

Reference Jobs

The Template Selection page

Template Selection Options

Each of the template types has a check box to enable or disable the use of the template for this particular job. A check in the check box for a particular template type will include this template in the proﬁle for this job. Each of the template types has the following three options for creating/using a template:

New Template. Use this option to create a new template. When you select this option and click Next, the Create New Template page opens for the particular essence type that was detected (Container,

o and/or the Audio type).

Vide

New Template Based On. Use this option to create a copy of any existing template. When you select

s option and click Next, a page opens showing all of the available templates (templates already

thi created and available in the database). When you select a template from the list and click Next,the Create New Template page opens with the tests from the selected template preselected.

Use Existing Template. Use this option to use an existing template listed in the selection box next to this option.

Cerify Automated Video Content Veriﬁcation System User Manual 69

Reference Jobs

From the Create New Template page, click Next to open the Create New Template page for the next essence type if the next essence type is enabled with the New Template or New Template Based On option. For ex Templates Selection page, the Create Container Template page opens. If you click Next on this page, the Create New Template page for video opens, and so on. When you click Next from the last page of the template types, the Finish page opens.

NOTE. The Finish page also opens when you click Next in the Templates Selection page with the Use Existing Template option selected for all of the enabled templates.

ample, with the Container, Video and Audio templates e nabled, if you click Next on the

The Finish page

The Finish page allows you to examine the current preferences and also provides an option to revisit the preference selections by using the Back button. Click Finish to create a new job. The new job

reated is displayed in the Jobs Monitor page. You can monitor and/or verify the job results from

you c the Jobs Monitor page.

The Jobs Monitor page

70 Cerify Automated Video Content Veriﬁcation System User Manual

Reference Jobs

Modifying Job

It is possible to modify the state of existing Jobs in a number of ways, using the same Archive/Restore

control (see p

To modify a Job, do the following:

1. Select the Jobs you want to modify by selecting the checkbox in the left column of the Jobs Monitor table.

2. Select the desired action from the action drop-down menu under the table.

3. Click Go to carry out the action.

It is possible to select the following actions:

Archive, Restore from archive. Used to remove from view or restore to view the selected Jobs. Note that archiving processing Jobs will automatically cause those Jobs to be immediately stopped. When the Job is removed from the archive, it will remain in the stopped state until the user chooses to resume the Job. This is to prevent unwanted processing of Jobs occurring when the Job was complete at the point of archive, but could restart processing when removed from the archive because the associated MediaS

Stop (ﬁnish current ﬁles), Stop (immediately). Stop processing the Job. Results of media ﬁles that h resumed when desired. The ﬁrst option allows media ﬁles that are currently being processed to run to completion, whereas the second option will immediately terminate all processing. In the latter case, all results from the currently processing media ﬁles for that Job will be removed, and if the Job is resumed, processing will restart from the beginning of the media ﬁle.

age

46) that is described in the Archiving Tutorial (see page 62).

et has had new ﬁles placed in it.

ave already b een completed will be retained and processing of unprocessed media ﬁles can be

Resume. Resume the processing of a stopped Job. Any media ﬁles that have not yet been processed will begin processing.

Setprioritytohigh, Setprioritytomedium, Setprioritytolow. Change the priority of the selected Jobs to the new priority. This will affect waiting Jobs and the priority which are assigned to unprocessed media ﬁles in currently processing Jobs. Changing Job priorities never causes a currently

unning media test process to be stopped.

Delete. Delete the selected Jobs from the database. All the results associated with that Job, including stream information, alert details and thumbnails, will be permanently deleted. Use the archive functionality if you want to remove the Job from view, but be able to revisit the results in future.

Cerify Automated Video Content Veriﬁcation System User Manual 71

Reference Jobs

Job Details

The Job Details page is accessed from the Jobs Monitor (see page 65) page. It provides summary details for all the media ﬁles in the Jobs MediaSet as shown in the following ﬁgure.

This page also provides an option to playback the media ﬁles in the Jobs MediaSet. This option becomes available only w hen the VLC playback

(see page 174) feature is enabled.

The Jobs

To see exactly which errors caused the Job to fail, click either the ﬁle name. This will take you to the Processing Result

Clicki

To play back the media ﬁle, it must satisfy the following conditions:

Details page

processing result icon or the media

(see page 73) page.

ng the

The media ﬁle has not moved from the original location from where it was analyzed

The media ﬁle has an encoding scheme that is supported by the VLC media player

play button starts the playback of the media ﬁle using the VLC media player.

72 Cerify Automated Video Content Veriﬁcation System User Manual

Reference Jobs

Processing Result

The Processing Result page provides information on the alerts raised by a particular media ﬁle. This page also displays the stream information for the media ﬁle concerned. Stream information is grouped into three separate sections: Container Info, Video Info, and Audio Info. Where there are multiple audio tracks in the stream, all track information is displayed. You can select the extent of stream information that gets displayed on this page using the stream information display

Stream information is updated as processing progresses. Many properties (such as "Picture size" or "Video standard") will be available shortly after processing begins, and others (such as "Length") will only be available processing. The values displayed will always be the most recent values encountered in the stream.

If the VLC player has been installed and enabled, you can also play back the media ﬁle from this page by selecting the play button that is available against eligible alerts.

after processing is complete. Some properties may be output and subsequently updated during

(see page 173) setting.

The Processing Results page

You can drill down for more Alert Details processing result icon or the title of the alert.

Cerify Automated Video Content Veriﬁcation System User Manual 73

(see page 75) on a particular alert by clicking either the

Reference Jobs

Alert Levels

Four different levels of alerts can be reported by Cerify according to the severity of the issue: fatal, error, warning, and info.

Fatal

A fatal ale rt occurs when it is not possible for the system to complete processing of a media ﬁle and the processing is terminated. This might be caused by something in the media ﬁle bitstream, such as a severe syntax error that makes that stream completely unintelligible or an option being present in the bitstream that is not as a license error, or failure to copy a media ﬁle off a video server.

Error

An error alert occurs where the media ﬁle fails a check speciﬁed by one of the Templates that the media is being checked against. Alerts raised by syntax checking will be given an error status if they have the potential to prevent correct decoding of the stream. An example of this is where an out of range value has been used in a bit stream.

supported by the decoder. Alternatively, the alert might be caused by a system problem, such

Warning

Awarn This might be that a certain number of alerts has been exceeded or that the bitstream is non-compliant in some minor w ay that almost certainly will not affect the decoding of the stream.

ing alert indicates that there is some issue with the stream, but that this is not necessarily a problem.

Info

Info alerts are relatively rare, and are used to inform users of additional useful information that will not cause a problem.

74 Cerify Automated Video Content Veriﬁcation System User Manual

Reference Jobs

Alert Details

The Alert Details page provides more information on an individual alert, including thumbnail images of surrounding frames (where appropriate). The thumbnail images link to full Frame View of these frames.

(see page 77)

The Alert Details page

The table within the details section provides speciﬁc details about the alert. Each of the table columns is outlined below.

Column Description

Level

Alert ID

Location

Start Optional column, only present for quality alerts. For more information, refer to, start and

You c an ref er t o alert levels for detailed description.

Unique alert ID. See alert IDs

This is the position relative to the start of the stream where the alert was generated. For quality alerts, a more detailed description is given in start and end positions of

quality alerts (see page 76).

The location is displayed in “HH:MM:SS:FF frame n” format in the case of non-drop frame timecode and “HH:MM:SS;FF frame n” format in the case of drop frame timecode.

end positions of quality alerts (see page 76).

The start time is displayed in “HH:MM:SS:FF” format in the case of non-drop frame timecode and “HH:MM:SS;FF” format in the case of drop frame timecode.

(see page 74) and their associated icons (see page 179)

(see page 179).

Cerify Automated Video Content Veriﬁcation System User Manual 75

Reference Jobs

Column Description

End

Channel Inde

Channel Name Optional column, only present for audio quality alerts (see page 131). The name of the

Title

Details

Thumbnai

xxx

Optional colu

of quality alerts (see page 76) for detailed description.

The end time is displayed in “HH:MM:SS:FF” format in the case of non-drop frame timecode and “

Optional col a multi-channel audio stream, this index will indicate the channel to which the alert applies. Channel indices start from 1.

channel to w

Descripti

Details o the test failed.

Thumbnail of the video frame (if available) at the alert location. Click the image to view the full Frame View

mn, only present for quality alerts. You can refer to start and end positions

HH:MM:SS;FF” format in the case of drop frame timecode.

umn, only present for audio quality alerts

hich the alert applies, as given by the audio standard.

on of alert type. This will always be the same for a given alert ID.

f the alert speciﬁc to this occurrence. This should provide a reason as to why

(see page 77)

(see page 131). When processing

Start and End Positions of Quality Alerts

The quality alerts ( video quality (see page 111) and audio quality (see page 131) ) are special in that they can apply to a range of video or audio. This is in contrast to most alerts, which have an instantaneous

ion. Because of this, quality alerts within Cerify contain the following additional information:

posit

The start position of the error condition

The location at which the error condition exceeded its permitted length

The end position of the error condition

Only one alert will be raised for a given error condition sequence, regardless of length.

Example: A rule is set up to disallow more than 5 seconds of black during video. A video clip has an unwanted sequence of 30 seconds of black beginning at 1m 20s. Cerify will generate a single video quality alert with the following information:

Start: 1m 20s - the start of the black sequence

Location: 1m 25s - the point at which 5 second limit was exceeded

nd: 1m 50s - the end of the black sequence

76 Cerify Automated Video Content Veriﬁcation System User Manual

Reference Jobs

Frame View

The Frame View Page shows a larger thumbnail image of the Frame. This thumbnail is based upon a down sampled version of the full frame, using the top ﬁeld only for interlaced content, so in some cases the detected artifact may not be visible. Red rectangles highlight any areas of the frame that generated alerts.

The frame time is displayed in “HH:MM:SS:FF” format in the case of non-drop frame timecode and “HH:MM:SS;FF” format in the case of drop frame timecode.

The "next" and "prev" links at the bottom of the frame image allow navigationacrossframesinthe ﬁlm-strip display for the alert. These links are displayed based on the position of the current frame in the ﬁlm-st frame has only the "prev" link on it.

rip. The ﬁrst frame of the ﬁlm-strip has only the "next" link associated with it and the last

The Frame View page

Cerify Automated Video Content Veriﬁcation System User Manual 77

Reference Jobs

Media Processing Limitations

Cerify can process many kinds of video media. Consider the following limitations before processing video ﬁles:

Some video servers (e.g. Omneon) put a lead-in at the start of a stream with a different VBV buffer size to the rest of the content in the stream. Cerify always reports the ﬁrst VBV buffer size it encounters, making it possible for the reported buffer size to not match the expected value for the stream.

Some AVC streams do not indicate a video frame rate. For these streams a frame rate check, if selected in the video template, will fail. Video template tests that can be checked over a user-speciﬁed length of time (e.g. black frame or blockiness checks) will calculate the length of time to check based upon the <number of frames> / 25; i.e. a frame rate of 25 frames per seconds is assumed. If this assumption is not correct the user should specify the length of check based upon number of frames rather than length of time.

Cerify does not support in-stream changing of frame size. Cerify will terminate processing of a ﬁle if the frame size changes.

Audio streams with varying sample rates/SBR information are not supported.

The system template "Omneon QT" can be used to process any type of ﬁle that ad Quick Time format containing atoms supported by Cerify (refer to Appendix B of the user manual for details). This includes ﬁles that have interleaved essence and those that refer to external essence ﬁles.

VC-1 streams that do not contain a header at the start of the ﬁle will not be decoded correctly.

When processing media ﬁles, you can limit the number of alerts so that processing will terminate after the limit is reached. In this situation, the reported length of stream - and any derived stream properties, for example, bit rate - will be calculated on the basis of the length of stream actually processed, and not the complete stream. Also, checks that depend on the end of stream being found such as a check for black frames at the end of the stream will not be carried out. An alert is raised that warns the user of this fact.

The ﬁle size of referenced / non-embedded wrapper formats (such as some Quick Time and MXF ﬁles) is reported as just the size of the wrapper ﬁle and not the sum of all the referenced ﬁles. Care should be taken when using stream properties or checks (e.g. bit rate) for the system template. Stream properties and checks for referenced audio or video content can still be reliably used.

The detection of poster frames and the execution of black frame tests are only supported for 8-bit video.

When running black frame tests and silence tests, there may be a conﬂict if "test during video" and "test at end" checks are used in combination. If the former is set to check black frames during video, while the latter test requires black frames at the end of the video, an alert will erroneously be raised during the end period due to the former check. No alerts are missed so this behavior is still fail-safe.

Detection of audio test tones during video is not supported. Detection of test tones at start and end of media playback is supported.

heres to the Apple

Test coverage of the MPEG-4 main proﬁle video codec is limited.

When the Loss of Chroma or Pillar-box tests are set-up to ignore more than two seconds at the end of the stream, it is possible for the system to raise an alert without a video/audio thumbnail associated with it. The alert itself is legitimate and should be considered valid.

78 Cerify Automated Video Content Veriﬁcation System User Manual

Reference Jobs

In some cases, video ser vers do not report up front a size for the ﬁle being transferred to Cerify for testing. In such cases, Cerify has no way of sensibly reporting the progress since Cerify requires the ﬁle size to cal for the duration of processing. Eventually, when Cerify has stopped receiving ﬁle data from the server, it considers the ﬁle-end to have been reached and accordingly moves the progress percentage from 0% to 100%. This is typically seen when processing ﬁles from video servers like Grass Valley servers that dynamically create the ﬁle for processing on request and with servers like Nexio that maintain a virtual ﬁle system.

Apple ProRes and Generic QuickTime Video decoding functionality are not available on Windows XP 64 bit and Windows Server 2003 64 bit as the QuickTime Player is not supported on these platforms.

After installing QuickTime Player, it is recommended to restart the system before running Cerify.

Automatic reprocessing of ﬁles within a DropBox may not work as expected, if the video server does not supply the ﬁle properties like ﬁle size and last modiﬁed time correctly.

Automatic reprocessing of ﬁles is not supported for DropBox created using GVG protocol.

Automatic reprocessing of ﬁles based on ﬁle size will not work c orrectly if vqual.io.ftp.ﬁlesizeunknown property is set to true in cerify.properties.

culate the progress percentage. As a result, Cerify reports the ﬁle to be at 0% progress

Cerify Automated Video Content Veriﬁcation System User Manual 79

Reference Proﬁles

Proﬁles

AProﬁle gathers together a Container (see page 93), Video (see page 105), Audio (see page 129) and

Action page 151).Anyof

The top-level Proﬁles page is accessed by selecting the Proﬁles button from the navigation bar. When you open thi to Active/Archive View Control message will be displayed.

(see page 146) Template, providing a complete set of checks that can be applied to a MediaSet (see

the component Templates can be omitted, depending on user requirements.

s page, you are presented with a table

(see page 45).IfnoProﬁles match the current ﬁlter, an informative

(see page 46) displaying Proﬁles ﬁltered according

oﬁles page

The Pr

the top-level Proﬁles page

From

Archive, restore, and delete Proﬁles

View Pro ﬁle details (see page 81) by clicking the Proﬁle name in the ProﬁleName column.

Edit a Proﬁle (see page 81) by clicking the edit icon.

Create a new Proﬁle (see page 82) by clicking the New Proﬁle button.

Create a new Proﬁle from an existing one (see page 82) by clicking the copy icon.

(see page 80), it is possible to:

80 Cerify Automated Video Content Veriﬁcation System User Manual

Reference Proﬁles

Proﬁle Detail

The Proﬁle Details page shows detailed information about a Proﬁle.

The Proﬁle Details page

Edit Proﬁle

AProﬁle can be edited to change its constituent Templates:

ainer

Cont

Vid eo (see page 105)

Audio (see page 129)

Action (see page 146)

(see page 93)

Cerify Automated Video Content Veriﬁcation System User Manual 81

Reference Proﬁles

The Proﬁle name and description cannot be changed.

Edit Proﬁle page

Click the Update button to submit changes to the Proﬁle

New Proﬁle

The New Proﬁle page is accessed either by copying an existing Proﬁle or by creating a new Proﬁle.

(see page 80).

The New Proﬁle page

To create a new Proﬁle,enteranamefortheProﬁle and, optionally, a description, and select the desired

Templates

next to the audio ﬁeld. Click the Create buttontocreatetheProﬁle.

82 Cerify Automated Video Content Veriﬁcation System User Manual

(see page 83) from the drop-down menus. To add a second audio template, click the plus icon

Reference Templates

Templates

Templates allow you to collect together rules to be used or actions to be taken when checking ﬁles in a MediaSet

The four types of Templates are:

Container Templates (see page 93), which gather rules applying to the container layer

Video Templates (see page 105), which gather rules applying to video elementary streams

Audio Templates (see page 129), which gather rules applying to audio elementary streams

Action Tem

processing events

(see page 151).

plates

(see page 146), which gather actions to be performed when generating Job

The top-l When you open this page, you are presented with tables and Action Templates ﬁltered according to Active/Archive View Control match the current ﬁlter, an informative message will be displayed. The following ﬁgure shows a Container Template, a Video Template, an Audio Template, and an Action Template.

evel Templates page is accessed by selecting the Te mplat e s button from the navigation bar.

(see page 46) displaying Container, Video, Audio,

(see page 45). If no Templates

Cerify Automated Video Content Veriﬁcation System User Manual 83

Reference Templates

84 Cerify Automated Video Content Veriﬁcation System User Manual

Reference Templates

NOTE. Some example templates are preloaded onto Cerify. These templates can be used, copied, edited, and archived in the same way as those created by users. The XML ﬁles containing these templates can be found in <Inst

From the top-level Templates page (see page 83) it is possible to:

Archive and restore Templates (see page 46)

Delete Templates (see page 89)

View details of a Template (see page 86) by clicking its name in the Template Name column

Edit a Template (see page 87) by clicking the edit icon

Create a new Template (see page 88) by clicking the New Template button for the type of Template (see page 83) required

Create a new Template from an existing one (see page 88) by clicking the copy icon

Export Templates (see page 90)

allation directory> /Example Templates.

Import Templates (see page 91)

Cerify Automated Video Content Veriﬁcation System User Manual 85

Reference Templates

Template Details

The Template Details page shows detailed information about a Template, but does not allow the details to be changed.

The Template Details page

86 Cerify Automated Video Content Veriﬁcation System User Manual

Reference Templates

Edit Template

A Template can be edited to change the Template Name, Description, and Template rule parameters. In the following ﬁgure, the user has entered a Temp l ate N a me and description, and has enabled some rules. Not all of the rules for the Template are shown.

The Edit Template page

Click the Update button at the bottom of the page to submit changes to the Template. This will also update the version of the Template.

Cerify Automated Video Content Veriﬁcation System User Manual 87

Reference Templates

New Template

The New Template page is accessed either by copying an existing Template, or by creating a new Template

(see page 83).

To create a new Template, determine the type of Template you want to create and click the corresponding New Container Template, New Video Template, New Audio Template,orNew Action Template button.

In the following screen, select the standard for the Template you want to create. For a Video Template, this might be MPEG-2, MPEG-4 or some other video standard. The resulting New Template page is very similar to the Edit Template

Enter a name for the Template and, optionally, a description. Finally, you must set up the Template rule deﬁnitions.

Template rules specify precisely what to check when processing content. For example, a Template rule might require that video content has a certain resolution, or that the audio stream has a certain bit rate. The Template rules that can be deﬁned depend upon the type of Template and its standard.

For more details on each rule, refer to the descriptions in the following sections on Container Templates

(see page 93), Video Templates (see page 105), Audio Templates (see page 129) and Action Templates

(see pa

146).

(see page 87) page.

To ﬁnd more information about a rule when deﬁning a Template, click the

Template rules are enabled and disabled by clicking the checkbox on the left side of the Edit Template page. A Template can contain a single enabled rule or many enabled rules. Different rules require different parameters to be deﬁned, depending on the type of rule. For example, a rule that speciﬁes video resolution

l require you to enter the expected number of pixels.

wil

When you have ﬁnished deﬁning all of the rules, click the Create button at the bottom of the page

reate the Template.

to c

If you are uncertain as to what rules and parameter values to use, try looking at one of the preloaded

ample templates and gradually adjust the rules until you are comfortable with the operation of the

ex template.

f you have imported a database from an earlier version of Cerify (before 6.x), the pre-loaded example

I templates will not be available. In this case, they can be imported as described in the Importing Templates

(see page 63) section.

next to the rule name.

88 Cerify Automated Video Content Veriﬁcation System User Manual

Tektronix Cerify Primary User

Specifications and Main Features

Frequently Asked Questions

User Manual
