AWG5200 Series Arbitrary Waveform Generators

ZZZ

Declassiﬁcation and Security

Instructions

www.tektronix.com

*P077133800*

077-1338-00

Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries or suppliers, and are protected by national copyright laws and international treaty provisions.

Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supersedes that in all previously published material. Speciﬁcations and price change privileges reserved.

TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.

Contacting Tektronix

Tektronix, Inc. 14150 SW Karl Braun Drive P.O. Box 5 0 0 Beaverton, OR 97077 USA

For product information, sales, service, and technical support:

In North America, call 1-800-833-9200. Worldwide, visit www.tek.com to ﬁnd contacts in your area.

Table of Contents

Preface ............................... ................................ .................................. ............................................................. iii

Clear and Sanitize Procedures. . ..... . ..... . .... . ..... . ..... . ... . . . .... . ..... . ..... . ..... ..... . ..... . ..... . .... . . .... . ..... . ..... . ........................... ...... 1

Memory devices ................. .................................. ................................ ............................................................ 1

Media storage and data export devices ........................ .................................. ................................ ............................ 5

AWG5200 Series Declassiﬁcation and Security Instructions i

Table of Contents

ii AWG5200 Series Declassiﬁcation and Security Instructions

Preface

This document helps customers with data security concerns to sanitize or remove memory d evices from the Tektronix AWG5200 Series Arbitrary Waveform Generators.

All of these products have data storage (memory) devices and data output devices (USB ports and a LAN Ethernet connector). These instructions tell how to do the following:

Clear or sanitize the memory devices.

Clear or sanitize an instrument that is not functioning.

Reference

Products

Related documents

The procedures in this document are written to meet the requirements speciﬁed in:

NISPOM, DoD 5220.22–M, Chapter 8

ISFO Process Manual for Certiﬁcation & Accreditation of Classiﬁed Systems under NISPOM

The following Tektronix products are covered by this document:

AWG5202

AWG5204

AWG5208

You can read more about your instrument in the following documents. These are available online at www.tektronix.com/downloads.

AWG5200 Series Arbitrary Waveform Generators Installation and Safety Instructions.

AWG5200 Arbitrary Waveform Generators Speciﬁcations and Performance Veriﬁcation Technical Reference

AWG5200 Series Declassiﬁcation and Security Instructions iii

Preface

Terms

The following terms may be used in this document:

Clear.

deny access to previously stored information by standard means of access.

Erase.

Instrument declassiﬁcation.

removed from a secure environment. Declassiﬁcation procedures include memory sanitization and memory removal, and sometimes both.

Media storage/data export device.

instrument, such as a USB port.

Nonvolatile memory.

Power off.

purpose of clearing data, putting the instrument in Standby mode does not qualify as powering off. For these products, you will need to either press a rear-panel OFF switch or remove the power source from the instrument.

Remove.

are available in the product Service Manual.

Sanitize.

technology. This is typically used when the device will be moved (temporarily or permanently) from a secured area to a non-secured area.

This removes data on media/memory before reusing it in a secured area. All reusable memory is cleared to

This is equivalent to clear.

A term that refers to procedures that must be undertaken before an instrument can be

Any of several devices that can be used to store or export data from the

Data is retained when the instrument is powered off.

Some instruments have a “Standby” mode, in w hich power is still supplied to the instrument. For the

This is a physical means to clear the data by removing the memory device from the instrument. Instructions

This eradicates the data from media/memory so that the data cannot be recovered by other means or

Scrub.

User accessible.

User-modiﬁable.

interface or remote control.

Volatile memory.

iv AWG5200 Series Declassiﬁcation and Security Instructions

This is equivalent to sanitize.

User is able to directly retrieve the m emory device contents.

The user can write to the memory device during normal instrument operation, using the instrument

Data is lost when the instrument is powered off.

Clear and Sanitize Procedures

Memory devices

The following tables list the volatile and nonvolatile memory devices in the instrument and listed options. Detailed procedures to clear or sanitize these devices, if any, are shown following each table.

Terminology

The following terms are used in the tables in this section:

User data – Describes the type of information stored in the device. Refers to waveforms or other measurement data representing signals connected to the instrument by users.

User settings – Describes the type of information stored in the device. Refers to instrument settings that can be changed by the user.

Both – Describes the type o f information stored in the device. It means that both user data and user settings are stored in the device.

None – Describes the type of information stored in the device. It means that neither user data nor user settings are stored in the device.

Directly – Describes how data is modiﬁed. It means that the user can modify the data.

Indirectly – Describes how data is modiﬁed. It means that the instrument system resources modify the data and that the user cannot modify the data.

AWG5200 Series Declassiﬁcation and Security Instructions 1

Clear and Sanitize Procedures

Table1: Volatilememorydevices

Type of Typ e and min. size Function

SDRAM ≥4GB(std)

SDRAM 4Gbit

SRAM 64k x16USBTMC buffer

PC system memory

AWG playback memory

info stored

(system/user)

Both No Directly Written by

User No Indirectly Firmware

Both No Indirectly Firmware

Table 2: Nonvolatile memory devices

Backed up by battery?

Method of modiﬁcation

Data input method Location User accessible? To clear/sanitize

processor system

Slot-PC board

AWG board

operations

System board

operations

Yes

Remove the power source from the instrument for at least 20 seconds.

Typ e a nd min. size Function

Flash, 1Gbit

Flash, 512 Mbit

EEPROM 1Mbit

EEPROM 64 kbit

Flash, 1Gbit

FPGA Image, Calibration Constants

FPGA Image, Instrument Model & Serial Number, Enabled Options

USBTMC proﬁle

Calibration Constants

Type of user info stored

None Indirect Firmware

None Indirect None

None Indirect Firmware

Method of modiﬁcation

Data input method Location User accessible To clear/sanitize

operations

AWG board

System board

Clock board

Marker board No

N/A

2 AWG5200 Series Declassiﬁcation and Security Instructions

Table 2: Nonvolatile memory devices (cont.)

Clear and Sanitize Procedures

Typ e a nd min. size Function

Flash, 1Gbit

Removable Hard Drive

This device does not contain user data or settings. Clearing would disable instrument functionality.

To clear, reformat the hard drive using the procedure “Restore the OS and AWG application” in this document.

To sanitize, remove the hard drive. Store the removed hard drive in a secure area or destroy it.

Calibration Constants

Holds instrument operating system and application software. Holds all user-storable data such as waveforms, measurement results, and instrument settings.

Type of user info stored

None Indirect Firmware

User data, user settings

Method of modiﬁcation

Indirect Firmware

Data input method Location User accessible To clear/sanitize

N/A

To clear, see footnote

To sanitize, see footnote

operations

operations, user input

Output/DACboard

Front panel Yes

AWG5200 Series Declassiﬁcation and Security Instructions 3

Clear and Sanitize Procedures

Clearorsanitize

instrument

Clear or sanitize a

non-functional instrument

Restore the OS and AWG

application

Use this procedure to clear the AWG waveform cache and last setup cache from your instrument. This procedure does not erase or change factory calibration constants.

In the toolbar, click the Reset to Default Setup button.

Close the AWG application.

Open the AWG application.

If your instrument is not functioning, proceed as follows.

Remove the hard disk drive before returning the instrument for repair.

Remove any attached USB ﬂash drive before returning the instrument for repair.

Refer to your organization’s policies regarding storage or disposal of any removed items.

Use this procedure to restore the operating system and the AWG application on your instrument to the original factory condition. This procedure does not erase or change factory calibration constants.

NOTE.

Recovery partition and the related data are not destroyed.)

The restore images remain, providing the ability to repeat the recovery process.

This utility reformats the hard disk drive during the restore process. All user data will be removed. (The Acronis

The Windows operating system provided is designed for this instrument's hardware and product software.

Attach a keyboard to the instrument.

Power on the instrument. During the boot-up process you will see the following message at the top of the screen:

Starting Acronis Loader... press F5 for Acronis Startup Recovery Manager

Repeatedly press the F5 key until the Acronis True Image Tool opens.

4 AWG5200 Series Declassiﬁcation and Security Instructions

There is a 15-second time period from when the message appears until the instrument proceeds with the normal instrument startup. If the instrument does not open the Acronis application, power off the instrument, then power on the instrument and try again.

Within the Acronis TrueImage window, click Restore.

In the Conﬁrmation dialog box, click Yes to begin the restore the process, or No to exit.

When ﬁ nished, the AWG product software is the version shipped with your instrument. All upgrades or applications installed after your purchase will have to be reinstalled.

Media storage and data export devices

The following table lists the media storage and data export devices in the instrument and listed options. Detailed procedures to disable these devices, if any, are shown following the table.

Table 3: Media and data export devices

Clear and Sanitize Procedures

Type Function

USB host port (supports removable USB ﬂash drive)

USB device port Supports remote control and

LAN Ethernet connector

User storage of reference waveforms, screen images, and instrument setups

data transfer to a PC

Supports remote control and data transfer to PC.

Method of modiﬁcation

Directly User writable

Directly

Data input method Location Process to disable

Remote control via USBTMC and/or GPIB

N/A

USB host port on front and rear of instrument

Rear panel

The USB host ports cannot be disabled.

The USB device port cannot be disabled.

N/A

AWG5200 Series Declassiﬁcation and Security Instructions 5
