AM 503S Current Measurement Systems
1
Simultaneous AC/DC
Measurements
DC to 100 MHz Bandwidths
Continuous Current Amplitudes
from mA to 500 A
(Peak to 700 A)
High Sensitivity
One Button Autobalance and
Probe Degauss
Supports 6 Different Probes
No Need to Calibrate Amplifier
with Specific Probes
GPIB Programmable (AM 5030)
he AM 503S Current
T
Measurement System
provides a complete system
in a single package. It consists
of an AM 503B Current Probe
Amplifier, a current probe
(A6302 is standard, A6312 is
Option 5), a TM 502A Power
Module, and a plug-in toolbox.
You can boost flexibility by
using any of the four other
A6300 Current Probes.
The AM 5030 Current Probe
Amplifier is a GPIB programmable version of the AM 503B;
use it with a TM 5000 Power
Module and any of the six
A6300 probes to extend your
capabilities.
CAUTION
CORE NOT
INSUL.
CLOSED
RISK OF ELECTRIC SHOCK
DO NOT INSERT OR REMOVE
LIVE UNINSULATED
CONDUCTORS.
CURRENT
WARNING
!
WARNING
INSULATED
CORE NOT
CAUTION
!
RISK OF
CONDUCTORS.
UNINSULATED
REMOVE LIVE
INSERT OR
DO NOT
ELECTRIC SHOCK
B020413
AM 503B CURRENT PROBE AMPLIFIER
OUTPUT
DC LEVEL
LOCK
PRESS TO
RATINGS
COMPLETE
FOR
SEE MANUAL
DC
100 AMP
CURRENT
MAX
RATING
VOLTAGE
CONDUCTOR
PEAK BARE
700 VOLTS
Probe
Current
A6303XL
OUTPUT
INTO 50Ω
PROBE
OPEN
OVERLOAD
CURRENT/DIVISION
OSCILLOSCOPE AT 10mV/DIVISION
20MHz
BW LIMIT
!
AUTOBALANCE
CIRCUIT AND CLOSE
mA/DIV
A/DIV
COUPLING
INPUT
PROBE
DEGAUSS
REMOVE
PROBE FROM
AC
REF
DC
!
STANDARD SPECIFICATIONS
AM 503B or AM 5030 w/ A6312 A6302 A6302XL A6303 A6303XL A6304XL
Bandwidth: DC to 100 MHz 50 MHz 17 MHz 15 MHz 10 MHz 2 MHz
Rise Time ≤ 3.5 ns ≤ 7 ns ≤ 20 ns ≤ 23 ns ≤ 35 ns ≤ 175 ns
Max Continuous Current 20 A 20 A 20 A 100 A 100 A 500 A
Max Peak Current 50 A 50 A 50 A 500 A 500 A 700 A
Max Conductor Diameter 3.81 mm 3.81 mm 3.81 mm 21 mm 21 mm 21 mm
(0.15") (0.15") (0.15") (0.83") (0.83") (0.83")
Cable Length 2 m 2 m 8 m 2 m 8 m 8 m
Warranty 1 year 1 year 1 year 1 year 1 year 1 year
Note:
The AM 503B works with a TM 500 or TM 5000 Power Module,
the AM 5030 plugs into only the TM 5000 Power Module.
XL Probes work only with the AM 503B and AM 5030—not with
the older AM 503 and AM 503A Current Probe Amplifiers.
2
AM 503S
Current
Measurement
Systems
To find the authorized Tektronix
distributor nearest you, call:
ASEAN Countries
(65) 356-3900
Australia &
New Zealand
61 (2) 888-7066
Austria
43 (1) 7 0177-261
Belgium
32 (2) 725-96-10
Brazil and South
America
55 (11) 3741 8360
Canada
1 (800) 661-5625
Denmark
45 (44) 850700
Finland
358 (0) 4783 400
France &
North Africa
33 (1) 69 86 81 81
Germany,
Eastern Europe,
& Middle East
49 (221) 94 77-0
Hong Kong
(852) 2585-6688
India
91 (80) 2265470
Italy
39 (2) 250861
From other areas, contact:
Tektronix, Inc. Export Sales
P.O. Box 500, M/S 50-255
Beaverton, Oregon 97077-0001 USA
(503) 627-1916
Visit our Web site:
World Wide Web: http://www.tek.com
Japan
(Sony/Tektronix
Corporation)
81 (3) 3448-4611
Mexico,
Central America,
& The Caribbean
52 (5) 666-6333
The Netherlands
31 2356 95555
Norway
47 (22) 070700
People’s Republic
of China
(86) 10-62351230
Republic of Korea
82 (2) 528-5299
Spain & Portugal
34 (1) 372 6000
Sweden
46 (8) 629 6500
Switzerland
41 (42) 219192
Taiwan
886 (2) 765-6362
United Kingdom
& Eire
44 (1628) 403300
USA
1-800-479-4490
AM 503S SYSTEM
INCLUDES
AM 503B Current
Probe Amplifier
TM 502A Power Module
A6302 Current Probe
Plug-in Toolbox
016-0362-02
Instruction Manual
070-8766-05
INCLUDED ACCESSORIES
CURRENT PROBE
AMPLIFIERS
50 Ω BNC Cable
012-0057-01
(AM 5030/AM 503B)
50 Ω BNC Termination
011-0049-01
(AM 5030/AM 503B)
Instruction Manual
070-8766-05
(AM 5030/AM 503B)
Reference Card
070-8770-01
(AM 5030/AM 503B)
INSTRUMENT OPTIONS
AM 503S
Opt. 01 Add A6303 100 Amp
Continuous Current Probe
Opt. 03 Substitute A6303 for
A6302
Opt. 05 Substitute A6312 for
A6302
Opt. 09 Delete A6302
INCLUDED ACCESSORIES
PROBES
POWER MEASUREMENT SOLUTION PACKAGES
Tektronix offers a broad selection of instrumentation for power
electronics applications. The AM 503 family of Current
Measurement Systems combined with Tektronix isolators, high
voltage probes, and high performance TDS oscilloscopes provide
a balanced set of features for making power measurements.
For Power Supply Design
Order Features
TDS 420A 150 MHz, 4–channel oscilloscope with DSP math
A6302 20 A current probe, DC to 50 MHz
P5100 2.5 kV voltage probe, DC to 300 MHz
A6905S Fiber optic isolator, 10 kV/µs, 15 MHz, ± 850 V
P5205 High Voltage Differential Probe, DC to 100 MHz
For Switch Mode Control
Order Features
TDS 460A 350 MHz, 4–channel oscilloscope with DSP math
A6303 100 A current probe, DC to 15 MHz
P5100 2.5 kV voltage probe, DC to 300 MHz
A6906S Fiber optic isolator, 100 kV/µs, 100 MHz, ± 850 V
P5205 High Voltage Differential Probe, DC to 100 MHz
For High-Power Switch Mode Control
Order Features
TDS 420A 150 MHz, 4–channel oscilloscope with DSP math
A6304XL 500 A current probe, DC to 2 MHz
P6015A 40 kV voltage probe, DC to 75 MHz
A6906S Fiber optic isolator, 100 kV/µs, 100 MHz, ± 850 V
P5205 High Voltage Differential Probe, DC to 100 MHz
Available Reference Information
“Floating Oscilloscope Measurements” 51W–10640–0
“Simplifying Power Measurements” 51W–10798–1
“TDS 400 Series Digitizing Oscilloscopes” 3GW–8207–5
2 Miniature Alligator Clips
344-0046-00
(A6302/A6302XL)
Instructions
070-3906-02
(A6303/A6303XL)
ISO 9OO1
KEMA CERT. NR. 10001.04
Copyright © 1996, Tektronix, Inc.
All rights reserved. Printed in U.S.A. Tektronix
products are covered by U.S. and foreign patents,
issued and pending. Information in this publication
supersedes that in all previously published material.
Specification and price change privileges reserved.
TEKTRONIX
and
TEK
are registered trademarks.
5/96 WSS/XBS 51W-10226-1
130 mm (5 inch) Ground Lead
175-0124-01
(A6302/A6302XL)
75 mm (3 inch) Ground Lead
175-0263-01
(A6302/A6302XL)
Carrying Case
016-0622-02
(A6303/A6303XL/A6304XL)
Instructions
070-3905-03
(A6302/A6302XL)
Instructions
070-8939-00
(A6304/A6304XL)
Instructions
070-9603-00
(A6312)
