GPIB-LAN Adapter

AD007

Characteristics

System Requirements

Computer Type - IBM PC-compatible with Windows 95/98 or
NT 4.0 Operating System. Consult Microsoft documentation for
recommended configuration.

Hard Disk - 5 MB or greater.
RAM - Consult Microsoft documentation for recommended

minimum configuration.
CD-ROM - Required.

NOTE: For printing, only a web browser is required.

Network Compatibility

Ethernet Port - 10Base-T, RJ-45 connector.
Protocols - BOOTP, DHCP, LPD, DNS, HTTP, FTP.
Networked Printer -

Compatibility: must be compatible with the GPIB instrument's
hardcopy output format.
Print Protocol: must support LPD Network Print protocol.

IEEE 488 (GPIB) Compatibility

Connection - No cable required for most applications.
Compatibility - Fully IEEE488.2 compatible.

NOTE: not suitable for connection to the public
telecommunications (telephone) network.

Other

Transmission Rate - Up to 10 Mb/s on Ethernet; dependent on
slowest GPIB device on the bus.

Front-panel Indicators - Power, LAN-Link, LAN, GPIB.

Environmental

Temperature -

Operating: 0 to +45°C.
Nonoperating: -20 to +70°C.

Humidity - 30 to 45°C, 90 to 95%, relative humidity.
Altitude -

Operating: up to 2,000 m (6,500 ft.).
Nonoperating: up to 10,000 m (33,000 ft.).

Vibration - 3 axis, 60 minutes total, 20 minutes/axis (10
minutes operating, 10 minutes nonoperating).

Shock - Half sine, 500 g, 3 axis, 3 drops each axis.

EMC Compliance

Meets the intent of EMC directive 89/336/EEC.
Complies with FCC part 15, class A limits.

Safety Compliance (Power Supply)

EN60950 (CE Mark).
UL1950.
CAN/CSA 22.2 No. 950.
DENTORI (T-MARK).

Power

Source Power -

Voltage Ranges: 100 to 240 VAC ±10%.
Line Frequency: 50 to 60 Hz.

Power Consumption - Regulated 5 VDC at 300 mA, typical.

Physical Characteristics

Dimensions mm in.

Height 35.6 1.4
Width 76.2 3
Depth 120.2 4.7

Weight kg lb.

Net 0.15 0.34

Warranty
