TSO820 & Modules Declassification and Security Instructions
Register now! Click the following link to protect your product. www.tek.com/register
077-1610-00

Table of Contents

Table of Contents
Preface..........................................................................................................................................................................................4
Memory devices............................................................................................................................................................................ 5
Clear or sanitize a non-functional instrument................................................................................................................................8
TSO820 & Modules Declassification and Security Instructions iii

Preface

Reference

Products

Preface
This document helps customers with data security concerns to sanitize or remove memory devices from their instrument.
These products have data storage (memory) devices and data output devices (USB ports). These instructions tell how to clear or sanitize the memory devices and disable the data output devices. The instructions also tell how to declassify an instrument that is not functioning.
The procedures in this document are written to meet the requirements specified in:
• NISPOM, DoD 5220.22–M, Chapter 8
• ISFO Process Manual for Certification & Accreditation of Classified Systems under NISPOM
This document covers the following Tektronix products:
• TSO820
• TSO8C17
• TSO8C18

Terms

The following terms may be used in this document:
• Clear. This removes data on media / memory. All reusable memory is cleared to deny access to previously stored information using standard means of access.
• Erase. This is equivalent to clear.
• Instrument Declassification. A term that refers to procedures that must be undertaken before an instrument can be removed from a secure environment. Declassification procedures involve memory sanitization or memory removal and sometimes both.
• Media storage/data export. This refers to any of several devices that can be used to store or export data from the instrument, such as a USB port.
• Power off. Some instruments have a “Standby” mode, in which power is still supplied to the instrument. For the purpose of clearing data, putting the instrument in Standby mode does not qualify as powering off. For these products, you will need to either press a rear-panel OFF switch or remove the power source from the instrument.
• Remove. This is a physical means to clear the data by removing the memory device from the instrument. Instructions are available in the product service manual.
• Sanitize. This eradicates the data from media/memory so that the data cannot be recovered by other means or technology. This is typically used when the device is moved (temporarily or permanently) from a secured area to a non­secured area.
• User Accessible. User is able to directly retrieve the memory device contents.
• User-modifiable. The user can write to the memory device during normal instrument operation, using the instrument interface or remote control.
• Nonvolatile memory. Data is retained when the instrument is powered off.
• Volatile memory. Data is lost when the instrument is powered off.
TSO820 & Modules Declassification and Security Instructions 4

Memory devices

The following tables and procedures identify volatile and non-volatile memory devices in the instrument TSO820 and TSO8C17/C18 modules and how to clear and/or sanitize them.

Terms

The following terms are used in the tables in this section:
• User data. Describes the type of information stored in the device. Refers to waveforms or other measurement data representing signals connected to the instrument by users.
• User settings. Describes the type of information stored in the device. Refers to instrument settings that can be changed by the user.
• None. Describes the type of information stored in the device. It means that neither user data or user settings are stored in the device.
• Directly. Describes how data is modified. It means that the user can modify the data.
• Indirectly. Describes how data is modified. It means that the instrument system resources modify the data and that the user cannot modify the data.

Volatile memory devices

Memory devices
Table 1: Volatile memory devices
Type & min. size
SOM module – Acquisition board (878-1629-XX)
DDR4 (2 GB, x32)
FPGA ARM CPU,
PMU - Acquisition board (878-1629-XX)
SRAM (4 KB)
Time Base board (878-1519-XX)
FPGA FPGA fabric None No Indirectly Firmware
Function Type of
user info stored
ARM system memory, FPGA code, active acquisition data
FPGA fabric
CPU system memory
User data, user settings, ARM program
None No Indirectly Firmware
None No Indirectly Firmware
Backed up by battery?
No Indirectly Firmware
Method of modification
Data input method
operations
operations
only
operations
Location User
accessible
U24, U25 No Remove power for
U1 No Remove power for
U802 No Remove power for
U2050 No Remove power for
To clear / sanitize
60 seconds
60 seconds
60 seconds
60 seconds
TSO820 & Modules Declassification and Security Instructions 5

Nonvolatile memory devices

Table 2: Nonvolatile memory devices
Memory devices
Type & min. size
SOM module – Acquisition board (878-1629-XX)
Dual NOR flash (64 MB)
I2C EEPROM (2 KB)
eMMC (8 GB, x8)
PMU - Acquisition board (878-1629-XX)
Flash (64 KB) CPU program
EEPROM (256 B)
Acquisition board (878-1629-XX)
I2C EEPROM (2 KB)
SD card Factory initial
Time Base board (878-1519-XX)
SPI flash memory (16 MB)
I2C EEPROM memory (64 KB)
Temperature sensor
Digital potentiometer
TSO820 system
Table continued…
Function Type of
user info stored
Calibration and compensation data
Calibration and compensation data
ARM system memory
memory
CPU system memory
MAC address None Indirectly Indirectly U1203 No Remove Acquisition
startup
Calibration and compensation
Not used None Indirectly Firmware
Temperature sense TLOW and THIGH setpoints
One-time programmable fuse
None Indirectly Firmware
None Indirectly Firmware
None Indirectly Firmware
None Programming
None Indirectly Firmware
None External PC Firmware
None Indirectly Firmware
None Not available Not available U1651A No Remove Timebase
None Not available Not available U1604 No Send module to
Method of modification
tool
Data input method
operations
operations
operations
Programming tool
only
only
operations
operations
Location User
accessible
U2, U3 No Remove Acquisition
U8 No Remove Acquisition
U4 No Remove Acquisition
U802 No Remove Acquisition
U802 No Remove Acquisition
J3106 No Remove SD card
U01 No Remove Timebase
U1650 No Remove Timebase
To clear / sanitize
board and send to Tektronix
board and send to Tektronix
board and send to Tektronix
board and send to Tektronix
board and send to Tektronix
board and send to Tektronix
and erase with PC
board and send to Tektronix
board and send to Tektronix
board and send to Tektronix
Tektronix
TSO820 & Modules Declassification and Security Instructions 6
Memory devices
Type & min. size
USB flash drive
TSO8C17/18 (878-1677-XX/878-1675-XX)
SPI flash memory (16 MB)
I2C EEPROM Memory (64 KB)
Temperature sensor
Digital potentiometer
Function Type of
user info stored
Software update None Programmed
Calibration and compensation
Not used None Indirectly Firmware
Temperature sense TLOW and THIGH setpoints
One-time programmable fuse
None Indirectly Firmware
None Not available Not available U29A,
None Not available Not available U19, U21,
Method of modification
via external PC
Data input method
Programmed via external PC
operations
operations
Location User
accessible
U01, U02 No Send module to
U27, U28 No Send module to
No Send module to
U30A
No Send module to U304, U404
To clear / sanitize
Remove and destroy
Tektronix
Tektronix
Tektronix
Tektronix
TSO820 & Modules Declassification and Security Instructions 7

Clear or sanitize a non-functional instrument

If the instrument is not functioning, perform the following actions and then return the intrument to Tektronix for repair.

Procedure to clear and sanitize the instrument TSO820

To clear the instrument TSO820, perform the following procedure:
1. Remove the power supply from the instrument and wait for 60 seconds.
Note: Main frame calibration and compensation values will be preserved from the last calibration or
compensation of the product.
To sanitize the instrument TSO820, perform the following procedure:
1. Remove Acquisition board (878-1629-XX) and Time Base board (878-1519-XX) and return the boards to Tektronix.
2. For removal instructions, refer to the TSO8 Series Service Manual (077-1613-XX), available on the Tektronix website at
www.tektronix.com/manuals.
3. After you remove the Acquisition and Time Base board, refer to your company’s internal policies regarding storage or disposal of the boards.
4. Tektronix will install a new Acquisition and Time Base board or repair, calibrate, and adjust as necessary.
Clear or sanitize a non-functional instrument

Procedure to sanitize the module TSO8C17/18

To sanitize the module TSO8C17/18, perform the following procedure:
1. Remove the module TSO8C17/18 and return the module to Tektronix.
2. For removal instructions, refer to the TSO8 Series Service Manual (Part number 077-1613-XX), available on the
Tektronix website at www.tektronix.com/manuals.
3. After you remove the module, refer to your company’s internal policies regarding storage or disposal of the module.
4. Tektronix will install a new module or repair, calibrate, and adjust as necessary.

USB flash drive

Remove the USB flash drive and return the instrument to Tektronix for repair.
After you remove the USB flash drive, refer to your organization’s internal policies regarding handling or disposal of the flash drive.

Charges

Replacement of any missing hardware will be charged according to the rate at the time of replacement.
TSO820 & Modules Declassification and Security Instructions 8
