Tektronix 80C01, 80C02, 80C07B, 80C08C, 80C10 User Manual

Optical Sampling Modules

80C01 •80C02 •80C07B •80C08C •80C10 •80C11 •80C12

CSA/TDS8000B Series Sampling Oscilloscope
Optical Modules

The CSA/TDS8000B Series Sampling

Oscilloscopes, when configured with one

or more optical sampling modules, provide

complete optical test solutions for Telecom

(155 Mb/s to 43.018 Gb/s) or Datacom

(Fibre Channel, Gigabit Ethernet, 10GbE

and InfiniBand) applications, as well as

general purpose optical component testing.

Each optical module includes all the elements

necessary for optical testing:

Optical to electrical converter

Average power monitor

One or more reference receiver filters

A full bandwidth optical path

A low-noise electrical sampler

Optional integrated clock recovery (80C12

clock recovery is provided via the 80A05
Clock Recovery Module – sold separately)

Universal optical input connector

80C01 Multi-rate Telecom Sampling

Module – The 80C01 module supports

waveform conformance testing of long-

wavelength (1100 to 1650 nm) signals at

622, 2488 Mb/s and 9.953 Gb/s as well

as general-purpose testing with up to

20 GHz optical bandwidth. With its clock

recovery option, the 80C01 provides

testing solutions for 622 and 2488 Mb/s

telecom applications.

80C02 High-performance Telecom

Sampling Module – The 80C02 module

is optimized for testing of long-wavelength

(1100 to 1650 nm) signals at 9.953 Gb/s

(SONET OC-192/SDH STM-64). With its

high optical bandwidth of 30 GHz (typical),

it is also well-suited for general purpose,

high-performance optical component testing.

The 80C02 can be optionally configured

with clock recovery that supports

9.953 Gb/s telecom standards.

Features & Benefits

10 Gb/s Telecom & Datacom

– 80C08C and 80C12 – Low-

noise, High Optical Sensitivity
and Broad Wavelength
Conformance Testing for
10GbE LAN, WAN, and FEC,
10G Fibre Channel, and
10 Gb/s Telecom Standard
and FEC Rates

– 80C11 30 GHz Optical

Bandwidth Conformance
Testing and Characterization
for 10 Gb/s Telecom and
Datacom Standards and
FEC Rates

– 80C08C and 80C11

Integrated Clock Recovery
Supports All Current 10 Gb/s
Standards or User Defined
Rate from 9.8 to 12.6 Gb/s

– 80C12 Clock Recovery

Available Via 80A05 Clock
Recovery Module

40 Gb/s Telecom

– 80C10 Provides 65 GHz

Optical Bandwidth for Signal
Characterization of 40 Gb/s
RZ or NRZ Data

– 80C10 Provides Reference

Receivers for Conformance
Testing of 39.813 Gb/s
(OC-768/STM-256)
and 43.018 Gb/s
(ITU-T G.709 FEC)

Tributary Telecom & Datacom

– 80C07B and 80C12 Provide

Excellent Optical Sensitivity
and Broad Wavelength
Test Capability

– 80C07B, 80C12, 80C01

Multi-rate Telecom
Conformance Testing
Solutions from 155 Mb/s
(OC-3/STM-4) Through

9.953 Gb/s (OC-192/
STM-64) and Datacom
Conformance Testing
Solutions for Fibre Channel,
Ethernet and InfiniBand
Standards

Applications

High-speed Optical
Communications Testing

Extinction Ratio and Q-factor
Measurements

Eye-pattern and Pulse
Shape Analysis

Relaxation Oscillation Testing

Optical Signal Analysis

Conformance Testing

NRZ and RZ Pulse
Characterization

1

Optical Signal Analysis

•

www.tektronix.com/optical

Optical Sampling Modules

80C01 •80C02 •80C07B •80C08C •80C10 •80C11 •80C12

80C07B Multi-rate, Datacom & Telecom

Optical Sampling Module – The 80C07B

module is a broad wavelength (700 to

1650 nm) multi-rate optical sampling module

optimized for testing datacom/telecom

signals from 155 to 2500 Mb/s. With its

amplified O/E converter design, this module

provides excellent signal-to-noise perform-

ance, allowing users to examine low-power

optical signals. The 80C07B can be option-

ally configured with clock recovery that sup-

ports 155, 622, 1063, 1250, 2125, 2488,

2500 and 2666 Mb/s rates.

80C08C Multi-rate, Datacom & Telecom

Optical Sampling Module with 10GbE

Forward Error Correction – The 80C08C

module is a broad wavelength (700 to

1650 nm) multi-rate optical sampling module

providing datacom rate testing for 10GbE

applications at 9.953, 10.3125, 11.0957 Gb/s

and 10G Fibre Channel applications at

10.51875 Gb/s. The 80C08C also provides

telecom rate testing at 9.953, 10.664, and

10.709 Gb/s. With its amplified O/E converter

design, this module provides excellent signal-

to-noise performance and high optical

sensitivity, allowing users to examine low-

power level optical signals. The 80C08C

can be optionally configured with clock

recovery options that can support any stan-

dard or user defined rate in the continuous

range from 9.8 to 12.6 Gb/s.

80C10 65 GHz 40 Gb/s Optical Sampling

Module with 43 Gb/s ITU-T G.709

Forward Error Correction – The 80C10

module provides integrated and selectable

reference receiver filtering, enabling

conformance testing at either 1310 nm or

1550 nm for 39.813 Gb/s (OC-768/STM-

256) and 43.018 Gb/s (43 Gb/s ITU-T

G.709 FEC) rates. In addition to the filter

rates, the user may also choose selectable

bandwidths of 30 GHz or 65 GHz for optimal

noise vs. bandwidth performance for accu-

rate signal characterization. The 80C10 is

optionally available in a bundled ordering

configuration which includes a 70+ GHz

electrical sampling channel.

80C11 Multi-rate, Datacom & Telecom

Optical Sampling Module – The 80C11

module is a long wavelength (1100 to

1650 nm) multi-rate optical sampling module

optimized for testing 10 Gb/s datacom

and telecom standard rates at 9.953,

10.3125, 10.51875, 10.664, 10.709, and

11.0957 Gb/s. With its high optical band-

width of up to 30 GHz (typical) it is well-

suited for general purpose high-performance

10 Gb/s optical component testing. The

80C11 can be optionally configured with

clock recovery options that can support any

standard or user defined rate in the contin-

uous range from 9.8 to 12.6 Gb/s.

80C12 Multi-rate, Datacom & Telecom

Optical Sampling Module – The 80C012

module is a broad wavelength (700 to 1650

nm) multi-rate optical sampling module pro-

viding 1G, 2G, and 4G telecom and datacom

testing. This highly flexible module can be

configured to support either lower data rate

applications (1 to 4 Gb/s) or a wide variety

of 10 Gb/s applications. The low data rate

applications include: 1, 2, and 4 Fibre Channel

and “by 4” wavelength division multiplex

standards such as 10G Base-X4 and 4-Lane

10 Gb/s Fibre Channel. The supported 10

Gb/s application includes

telecom application. The

both datacom and

supported 10 Gb/s

datacom applications include 10GbE appli-

cations at 9.953, 10.3125, 11.0957 Gb/s

and 10G Fibre Channel applications at

10.51875 Gb/s. The 80C12 also provides

telecom rate testing at 9.953, 10.664, and

10.709 Gb/s. With its amplified O/E con-

verter design, this module provides excellent

signal-to-noise performance and high optical

sensitivity, allowing users to examine low-

power level optical signals. Clock recovery

for the 80C12 is provided via the 80A05

(sold separately).

2

Optical Signal Analysis

•

www.tektronix.com/optical

Optical Sampling Modules

80C01 •80C02 •80C07B •80C08C •80C10 •80C11 •80C12

Optical Modules

Module 80C01 80C02 80C07B

Option CR CR F1 F2 F3 F4 F5 F6 F7 F8 F9 F10 CR1

Bandwidth 20 20 30 30 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5
(GHz)

Wavelength 1100- 1100- 1100- 1100- 700- 700- 700- 700- 700- 700- 700- 700- 700- 700- 700­Range (nm) 1650 1650 1650 1650 1650 1650 1650 1650 1650 1650 1650 1650 1650 1650 1650

Fiber Input 9 9 9 9 9 & 9 & 9 & 9 & 9 & 9 & 9 & 9 & 9 & 9 & 9 &
(µm) 62.5 62.5 62.5 62.5 62.5 62.5 62.5 62.5 62.5 62.5 62.5

Mask Test –8 –8 –9 –9 –22 –22 –22 –22 –22 –22 –22 –22 –22 –22 –22
Sensitivity
(dBm)

Number of 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Channels

Rates Supported: ■ =Filter, ◆ = Optical Clock Recovery, ⊕= Electrical Clock Recovery

155 Mb/s ■ ◆ ■■■ ■ ◆

622 Mb/s ■ ◆ ■■■■■◆

1063 Mb/s ■■■■◆

1250 Mb/s ■■■■◆

2125 Mb/s ■■■■

2488 Mb/s ■■■ ■ ■■ ■ ■■ ■◆

2500 Mb/s ■■■ ■ ■■ ■ ■■ ■

3.125 Gb/s

3.188 Gb/s

3.32 Gb/s

4.25 Gb/s

9.95 Gb/s ■■◆

◆

◆

Optical Signal Analysis

•

www.tektronix.com/optical

3

Optical Sampling Modules

80C01 •80C02 •80C07B •80C08C •80C10 •80C11 •80C12

Optical Modules (continued)

Module 80C08C 80C10 80C11

Option CR1 CR2 CR4 CR1 CR2 CR3 CR4

Bandwidth 10 10 10 10 65 30 30 30 30 30
(GHz)

Wavelength 700-1650 700-1650 700-1650 700-1650 1290-1330 1100-1650 1100-1650 1100-1650 1100-1650 1100-1650
Range (nm) 1530-1570

Fiber Input 9 & 9 & 9 & 9 & 9 9 9 9 9 9
(µm) 62.5 62.5 62.5 62.5

Mask Test –15 –15 –15 –15 0 –9 –9 –9 –9 –9
Sensitivity (dBm)

Number of 1 1 1 1 1 1 1 1 1 1
Channels

Rates Supported: ■ =Filter, ◆ = Optical Clock Recovery, ⊕= Electrical Clock Recovery

9.95 Gb/s ■ ◆◆■ ◆◆◆◆

10.31 Gb/s ■ ◆◆◆

10.52 Gb/s ■ ◆◆ ■ ◆

10.66 Gb/s ■

◆ ■ ◆◆

10.71 Gb/s ■ ◆ ■ ◆◆

11.1 Gb/s ■

◆ ■ ◆

39.81 Gb/s ■

43.02 Gb/s ■

■ ◆

4

Optical Signal Analysis

•

www.tektronix.com/optical

Optical Sampling Modules

80C01 •80C02 •80C07B •80C08C •80C10 •80C11 •80C12

Optical Modules (continued)

Module 80C12

Option F1 F2 F3 F4 F5 F6 FC 10G CR*

1

Bandwidth 4.25 9 9 4.25 9 9 9 10
(GHz)

Wavelength 700-1650 700-1650 700-1650 700-1650 700-1650 700-1650 700-1650 700-1650
Range (nm)

Fiber Input 9 & 9 & 9 & 9 & 9 & 9 & 9 & 9 &
(µm) 62.5 62.5 62.5 62.5 62.5 62.5 62.5 62.5

Mask Test –15 –15 –15 –15 –15 –15 –15 –12
Sensitivity (dBm)

Number of 1 1 1 1 1 1 1 1
Channels

Rates Supported: ■ =Filter, ◆ = Optical Clock Recovery, ⊕= Electrical Clock Recovery

155 Mb/s ◆◆

622 Mb/s ◆◆

1063 Mb/s ■■ ◆◆

1250 Mb/s ◆◆

2125 Mb/s ■■■■ ■ ◆◆

2488 Mb/s ◆◆

2500 Mb/s ◆◆

3.125 Gb/s ■■■■ ◆◆

3.188 Gb/s ■■■■ ◆◆

3.32 Gb/s ■ ◆◆

4.25 Gb/s ■■ ■■ ◆◆

9.95 Gb/s ■ ◆

10.31 Gb/s ■ ◆

10.52 Gb/s ■ ◆

10.66 Gb/s ■ ◆

10.71 Gb/s ■

11.1 Gb/s ■ ◆

CR*

2

◆

*1With 80A05.

2

With 80A05 Option 10G.

*

Optical Signal Analysis

•

www.tektronix.com/optical

5

Optical Sampling Modules

80C01 •80C02 •80C07B •80C08C •80C10 •80C11 •80C12

Electrical Clock Recovery

Module 80A05

Option 10G

Rates Supported: ⊕ = Electrical Clock Recovery

155 Mb/s ⊕⊕

622 Mb/s ⊕⊕

1063 Mb/s ⊕⊕

1250 Mb/s ⊕⊕

2125 Mb/s ⊕⊕

2488 Mb/s ⊕⊕

2500 Mb/s ⊕⊕

3.125 Gb/s ⊕⊕

3.188 Gb/s ⊕⊕

3.32 Gb/s ⊕⊕

4.25 Gb/s ⊕⊕

9.95 Gb/s ⊕

10.31 Gb/s ⊕

10.52 Gb/s ⊕

10.66 Gb/s ⊕

10.71 Gb/s ⊕

11.1 Gb/s ⊕

Electrical Modules

Module 80E01 80E012 80E03 80E04 80E06

Bandwidth (GHz) 50 12.5 20 20 70

Number of Channels 1 2 2 2 1

6

Optical Signal Analysis

•

www.tektronix.com/optical

Optical Sampling Modules

80C01 •80C02 •80C07B •80C08C •80C10 •80C11 •80C12

Characteristics

Optical Sampling Module Characteristics (Refer to Optical Sampling
Modules User Manual for more detailed information)

Application Type Standards and Number of Input Effective Calibrated

Supported Filtering Channels Wavelength Range Wavelengths

Rates

80C01 Tributary Telecom OC-12/STM-4 (622 Mb/s), 1 1100 nm to 1650 nm 1310 nm and

OC-48/STM-16 (2.488 Gb/s), 1550 nm (±20 nm)

OC-192/STM-64

(9.953 Gb/s)

80C02 10 Gb/s Telecom OC-192/STM-64 1 1100 nm to 1650 nm 1310 nm and

(9.953 Gb/s) 1550 nm (±20 nm)

10GBase-W (9.953 Gb/s)

80C07B Tributary Datacom/Telecom Standard Included: 1 700 nm to 1650 nm 780 nm, 850 nm,

OC-48/STM-16 (2.488 Gb/s), 1310 nm, and 1550 nm

InfiniBand, 2 GbE (2.500 Gb/s); (±20 nm)

Optional (choose any two):

OC-3/STM-1 (155 Mb/s),

OC-12/STM-4 (622 Mb/s),

Fibre Channel (1.063 Gb/s),

GbE (1.250 Gb/s), 2G Fibre

Channel (2.125 Gb/s)

80C08C 10 Gb/s Datacom/Telecom OC-192/STM-64 (9.953 Gb/s), 1 700 nm to 1650 nm 780 nm, 850 nm,

10GBase-W (9.953 Gb/s), 1310 nm, and 1550 nm

10GBase-R (10.31 Gb/s), (±20 nm)
10G Fibre Channel (10.52 Gb/s),
ITU-T G.975 FEC (10.664 Gb/s),

ITU-T G.709 (10.709 Gb/s),

10GbE FEC (11.1 Gb/s)

80C10 40 Gb/s Telecom OC-768/STM-256 (39.813 Gb/s), 1 1310 nm and 1550 nm 1310 nm and

ITU-T G.709 FEC (43.018 Gb/s) 1550 nm (±20 nm)

80C11 10 Gb/s Datacom/Telecom OC-192/STM-64 (9.953 Gb/s), 1 1100 nm and 1650 nm 1310 nm and

10GBase-W (9.953 Gb/s), 1550 nm (±20 nm)

10GBase-R (10.31 Gb/s),
10G Fibre Channel (10.52 Gb/s),
ITU-T G.975 FEC (10.664 Gb/s),

ITU-T G.709 (10.709 Gb/s),

10GbE FEC (11.1 Gb/s)

80C12 1 to 4.5 Gb/s Fibre Channel (1.063 Gb/s), 1 700 nm to 1650 nm 850 nm,

Datacom/Telecom 2G Fibre Channel (2.125 Gb/s), 1310 nm, and

4G Fibre Channel (4.250 Gb/s) 1550 nm (±20 nm)

10GBase-X4 (3.125 Gb/s)

10GFC-X4 (3.1875 Gb/s)

VSR5-3318 (3.318 Gb/s)

10 Gb/s OC-192/STM-64 (9.953 Gb/s),

Datacom/Telecom 10GBase-W (9.953 Gb/s),

10GBase-R (10.31 Gb/s),
10G Fibre Channel (10.52 Gb/s),
ITU-T G.975 FEC (10.664 Gb/s),

ITU-T G.709 (10.709 Gb/s),

10GbE FEC (11.1 Gb/s)

Optical Signal Analysis

•

www.tektronix.com/optical

7

Optical Sampling Modules

80C01 •80C02 •80C07B •80C08C •80C10 •80C11 •80C12

Optical Sampling Module Characteristics (continued)

Clock Recovery Clock Recovery Unfiltered Optical Absolute Maximum Internal Fiber

(Optional) Outputs Bandwidth*

3

Nondestructive Diameter

Optical Input

80C01 Option CR: 622 Mb/s, ±Clock, ±Data 20 GHz 5 mW average; 10 mW 9 µm/125 µm single-mode

2.488 Gb/s peak power at wavelength
of highest relative

responsivity

80C02 Option CR: 9.953 Gb/s Clock, Clock/16, 28 GHz 5 mW average; 10 mW 9 µm/125 µm single-mode

Data peak power at wavelength

of highest relative

responsivity

80C07B Option CR1: 155 Mb/s, ±Clock, ±Data 2.5 GHz 5 mW average; 10 mW 62.5 µm/125 µm multi-mode

622 Mb/s, 1.063 Gb/s, peak power at wavelength

1.250 Gb/s, 2.125 Gb/s, of highest responsivity

2.488 Gb/s, 2.500 Gb/s,

2.666 Gb/s

80C08C Option CR1: 9.953 Gb/s, Clock, Clock/16 10 GHz 1 mW average; 10 mW 62.5 µm/125 µm multi-mode

10.31 Gb/s; peak power at wavelength

Option CR2: 10.31 Gb/s, of highest responsivity

10.52 Gb/s;

Option CR4: Continuous

from 9.8 Gb/s to 12.6 Gb/s

80C10 Future Upgradeable Future 65 GHz 20 mW average; 60 mW 9 µm/125 µm single-mode

peak power at wavelength

of highest relative

responsivity

80C11 Option CR1: 9.953 Gb/s; CR1: Clock, 28 GHz 5 mW average; 10 mW 9 µm/125 µm single-mode

Option CR2: 9.953 Gb/s, Clock/16, Data; peak power at wavelength

10.664 Gb/s; Option CR3: CR2, CR3, CR4: of highest responsivity

9.953 Gb/s, 10.709 Gb/s; Clock, Clock/16
Option CR4: Continuous

between 9.8 Gb/s

to 12.6 Gb/s

80C12 Provided by 80A05 ELECTRICAL 9 GHz (for all 1 mW average; 10 mW 62.5 µm/125 µm

(sold separately) SIGNAL OUT options except 10G) peak power at wavelength multi-mode

10 GHz (Option 10G) of highest responsivity

*3Values shown are warranted unless printed in an italic typeface which represents a typical value.

8

Optical Signal Analysis

•

www.tektronix.com/optical

Optical Sampling Modules

80C01 •80C02 •80C07B •80C08C •80C10 •80C11 •80C12

Optical Sampling Module Characteristics (continued)

Optical Return Loss Fiber Input Accepted RMS Optical RMS Optical Independent

Noise (typical) Noise (maximum) Channel Deskew

80C01 >30 dB Single-mode 8.0 µW at 622 Mb/s, 12.0 µW at 622 Mb/s, Standard

2.488 Gb/s, 9.953 Gb/s, 2.488 Gb/s, 9.953 Gb/s,

12.5 GHz; 12.5 GHz;

15.0 µW at 20 GHz 25 µW at 20 GHz

80C02 >30 dB Single-mode 6.0 µW at 9.953 Gb/s, 10.0 µW at 9.953 Gb/s, Standard

12.5 GHz; 12.5 GHz mode;

10.0 µW at 20 GHz; 15 µW at 20 GHz;

15.0 µW at 30 GHz 30 µW at 30 GHz

80C07B >14 dB (multi-mode) Single- or multi-mode 0.50 µW at 155 Mb/s, 1.0 µW at 155 Mb/s, Standard

>24 dB (single-mode) 622 Mb/s, 1063 Mb/s, 622 Mb/s, 1063 Mb/s,

1250 Mb/s; 1250 Mb/s;

0.70 µW 1.5 µW at 2.488/2.500 Gb/s

at 2.488/2.500 Gb/s

80C08C >14 dB (multi-mode) Single- or multi-mode 1.7 µW at all filter rates 3.0 µW at all filter rates Standard

>24 dB (single-mode)

80C10 >30 dB Single-mode 40 µW at 39.813 Gb/s, 60 µW at 39.813 Gb/s, Standard

43.018 Gb/s (1550 nm); 43.018 Gb/s (1550 nm);
75 µW at 39.813 Gb/s, 110 µW at 39.813 Gb/s,

43.018 Gb/s (1310 nm); 43.018 Gb/s (1310 nm);

30 µW at 30 GHz mode 50 µW at 30 GHz

(1550 nm); (1550 nm);

55 µW at 30 GHz mode 90 µW at 30 GHz

(1310 nm); (1310 nm);

85 µW at 65 GHz mode 120 µW at 65 GHz

(1550 nm); (1550 nm);

150 µW at 65 GHz mode 220 µW at 65 GHz

(1310 nm) (1310 nm)

80C11 >30 dB Single-mode 5.5 µW at all filter rates; 8.0 µW at all filter rates; Standard

10.0 µW at 20 GHz 14.0 µW at 20 GHz

20.0 µW at 30 GHz 30.0 µW at 30 GHz

80C12 >14 dB (multi-mode) Single- or multi-mode 1.7 µW (all filters except 3.0 µW ( all filters except Standard

>24 dB (single-mode) Option 10G) Option 10G)

3.4 µW (‘Full BW’ and 6.0 µW (‘Full BW’ and
Option 10G filters) Option 10G filters)

Optical Signal Analysis

•

www.tektronix.com/optical

9

Optical Sampling Modules

80C01 •80C02 •80C07B •80C08C •80C10 •80C11 •80C12

Optical Sampling Module Characteristics (continued)

Offset Capability Power Meter Power Meter Power Meter Mask Test

Range Accuracy Optical Sensitivity*

80C01 Standard Standard +4 dBm to –30 dBm 5% of reading –8 dBm at 622 Mb/s,

2.488 Gb/s, 9.953 Gb/s;
–5.0 dBm at 20 GHz

80C02 Standard Standard +4 dBm to –30 dBm 5% of reading –9 dBm at 9.953 Gb/s;

–7 dBm at 20 GHz;

–4 dBm at 30 GHz

80C07B Standard Standard +4 dBm to –30 dBm 5% of reading –22 dBm at 155 Mb/s,

622 Mb/s; –20 dBm at

2488/2500 Mb/s

80C08C Standard Standard 0 dBm to –30 dBm 5% of reading –15 dBm at all filter rates

80C10 Standard Standard +13 dBm to –21 dBm 5% of reading 0 dBm at 39.813 Gb/s,

43.018 Gb/s; 0 dBm at

30 GHz; +3 dBm at 65 GHz

80C11 Standard Standard +4 dBm to –30 dBm 5% of reading –10 dBm at all filter rates;

–7 dBm at 20 GHz;

–4 dBm at 30 GHz

80C12 Standard Standard 0 dBm to –30 dBm 5% of reading –15 dBm (for all options

except Option 10G)

–12 dBm (for Option 10G)

4

*4Smallest power level for mask test. Values represent theoretical typical sensitivity of NRZ eyes for competitive comparison purposes.Assumes instrument peak-peak noise consumes most of the mask margin.

Physical Characteristics for Optical Sampling Modules

Dimensions (mm/inches) Weight (kg/lb)

Width Height Depth Net

80C01 165/6.5 25/1.0 305/12.0 <2.61/<5.75

80C02 165/6.5 25/1.0 305/12.0 <2.61/<5.75

80C07B 165/6.5 25/1.0 305/12.0 <1.36/<3.0

80C08C 165/6.5 25/1.0 305/12.0 <1.22/<2.7

80C10 165/6.5 25/1.0 305/12.0 <2.61/<5.75

80C11 165/6.5 25/1.0 305/12.0 <1.22/<2.7

80C12 165/6.5 25/1.0 305/12.0 <2.61/<5.75

10

Optical Signal Analysis

•

www.tektronix.com/optical

Optical Sampling Modules

80C01 •80C02 •80C07B •80C08C •80C10 •80C11 •80C12

Ordering Information

80C01

Optical Sampling Module.

Includes: User manual, FC/PC optical connector.

Frequency response curves for 622, 2488 and
9953 Mb/s filter rates.

Opt. CR – 622 and 2488 Mb/s clock recovery.

80C02

Optical Sampling Module.

Includes: User manual, FC/PC optical connector.

Frequency response curves for 9.953 Gb/s
filter rates.

Opt. CR – 9.953 Gb/s clock recovery.

80C07B

Multi-rate Datacom and Telecom Optical
Sampling Module.

Includes: User Manual, FC/PC Optical Connector.

Frequency response curves for 2.488, 2.500 Gb/s
data rates plus selected filter option data rates.

Opt. CR1 – 155/622/1063/1250/2125/2488/
2500/2666 Mb/s clock/data recovery.

User must select any one (1) of the following
filter options:

Opt. F1 – 155, 622 Mb/s.

Opt. F2 – 155, 1063 Mb/s.

Opt. F3 – 155, 1250 Mb/s.

Opt. F4 – 155, 2125 Mb/s.

Opt. F5 – 622, 1063 Mb/s.

Opt. F6 – 622, 1250 Mb/s.

Opt. F7 – 622, 2125 Mb/s.

Opt. F8 – 1063, 1250 Mb/s.

Opt. F9 – 1063, 2125 Mb/s.

Opt. F10 – 1250, 2125 Mb/s.

80C08C

Multi-rate Datacom and Telecom Optical
Sampling Module.

Includes: User Manual, FC/PC optical connector.

Frequency response curves for 9.953, 10.31,

10.52, 10.66, 10.71, 11.1 Gb/s filter rates.

Opt. CR1 – 9.953, 10.31 Gb/s clock recovery.

Opt. CR2 – 10.31, 10.52 Gb/s clock recovery.

Opt. CR4 – Continuous rate clock recovery

supporting any standard or user-definable rate
in the range from 9.8 to 12.6 Gb/s.

80C10

Multi-rate Optical Sampling Module.

Includes: User manual, FC/PC optical connector.

Frequency response curves for 39.813 and

43.108 Gb/s filter rates.

80C10E1 – Bundled ordering configuration
includes 80C10 plus one 80E06 single-channel
70+ GHz electrical module.

80C11

Multi-rate Datacom and Telecom Optical
Sampling Module.

Includes: User Manual, FC/PC optical connector.

Frequency response curves for 9.953, 10.31,

10.52, 10.66, 10.71, 11.1 Gb/s filter rates.

Opt. CR1 – 9.953 Gb/s clock recovery.

Opt. CR2 – 9.953, 10.66 Gb/s clock recovery.

Opt. CR3 – 9.953, 10.71 Gb/s clock recovery.

Opt. CR4 – Continuous rate clock recovery

supporting any standard or user-definable rate
in the range from 9.8 to 12.6 Gb/s.

80C12

Multi-rate Datacom and Telecom Optical
Sampling Module.

Includes: User Manual, FC/PC optical connector.

Frequency response curves for all included refer­ence receiver filter rates.

Clock recovery is available using the 80A05.
The 80C12 Multi-rate Telecom & Datacom Optical
Sampling Module is available with a wide variety
of factory-configured signal conditioning options.
These options provide a variety of reference
receiver filtering and unfiltered signal acquisition
bandwidths. The user must specify one of the
following options when ordering this module:

Opt. F1 – 1063, 2125, 4250 Mb/s Filters,

4.25 GHz Full Bandwidth.

Opt. F2 – 2125, 4250 Mb/s Filters, 9 GHz
Full Bandwidth.

Opt. F3 – 1063, 2125 Mb/s Filters, 9 GHz
Full Bandwidth.

Opt. F4 – 2125, 3125, 3187.5, 4250 Mb/s Filters,

4.25 GHz Full Bandwidth.

Opt. F5 – 3125, 3187.5, 4250 Mb/s Filters,
9 GHz Full Bandwidth.

Opt. F6 – 2125, 3125, 3187.5 Mb/s Filters,
9 GHz Full Bandwidth.

Opt. FC – 3125, 3187.5, 3318 Mb/s Filters,
9 GHz Full Bandwidth.

Opt. 10G – 9.95, 10.31, 10.52, 10.66, 10.71,

11.1 Gb/s Filters, 10 GHz Full Bandwidth.

Service

Opt. C3 – Calibration Service 3 Years.

Opt. C5 – Calibration Service 5 Years.

Opt. D1 – Calibration Data Report.

Opt. D3 – Calibration Data Report 3 Years

(with Option C3).

Opt. D5 – Calibration Data Report 5 Years
(with Option C5).

Opt. R3 – Repair Service 3 Years.

Opt. R5 – Repair Service 5 Years.

Optical Connector
Accessories

While the FC/PC connector is standard with the
8000 Series optical sampling modules, the input
connector type can be interchanged with any of
the following standard adapters:

ST/PC – Order 119-4513-00.

D4/PC – Order 119-4514-00.

Biconic – Order 119-4515-00.

FC/APC – Order 119-5115-00.

SMA 2.5 – Order 119-4517-00.

SC/APC – Order 119-5116-00.

DIN/PC 47256 – Order 119-4546-00.

HP/PC – Order 119-4556-00.

SMA – Order 119-4557-00.

DIAMOND 3.5 – Order 119-4558-00.

Optical Signal Analysis

•

www.tektronix.com/optical

11

Optical Sampling Modules

80C01 • 80C02 • 80C07B • 80C08C • 80C10 • 80C11 • 80C12

Contact Tektronix:

ASEAN / Australasia / Pakistan (65) 6356 3900

Austria [phone]

Belgium [phone]

Brazil & South America 55 (11) 3741-8360

Canada 1 [phone]

Central Europe & Greece [phone]

Denmark [phone]

Finland [phone]

France & North Africa [phone]

Germany [phone]

Hong Kong (852) 2585-6688

India (91) 80-22275577

Italy [phone]

Japan 81 (3) 6714-3010

Mexico, Central America & Caribbean 52 (55) 56666-333

The Netherlands [phone]

Norway [phone]

People’s Republic of China 86 (10) 6235 1230

Poland [phone]

Republic of Korea 82 (2) 528-5299

Russia, CIS & The Baltics [phone]

South Africa [phone]

Spain [phone]

Sweden [phone]/4

Taiwan 886 (2) 2722-9622

United Kingdom & Eire [phone]

USA 1 [phone]

USA (Export Sales) 1 [phone]

For other areas contact Tektronix, Inc. at: 1 [phone]

Last Update March 01, 2004

12

Optical Signal Analysis

•

www.tektronix.com/optical

Our most up-to-date product information is available at:

www.tektronix.com

Product(s) are manufactured

in ISO registered facilities.

Copyright © 2004, Tektronix, Inc.All rights reserved. Tektronix products are covered
by U.S. and foreign patents, issued and pending. Information in this publication
supersedes that in all previously published material. Specification and price change
privileges reserved. TEKTRONIX and TEK are registered trademarks of Tektronix,
Inc. All other trade names referenced are the service marks, trademarks or regis­tered trademarks of their respective companies.

04/04 HB/WWW 85W-15964-6
