Tektronix 3066 Programming Manual

Programmer Manual

3066 & 3086 3 GHz Real Time Spectrum Analyzer

071-0502-01

This document supports firmware version 2.2.

Copyright E Sony/Tektronix Corporation. All rights reserved. Copyright E T ektronix, Inc. All rights reserved. T ektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supercedes

that in all previously published material. Specifications and price change privileges reserved. Printed in Japan. Sony/T ektronix Corporation, P.O.Box 5209, T okyo Int’l, Tokyo 100–31 Japan T ektronix, Inc., P.O. Box 1000, Wilsonville, OR 97070–1000 TEKTRONIX and TEK are registered trademarks of T ektronix, Inc.

WARRANTY

T ektronix warrants that this product will be free from defects in materials and workmanship for a period of one (1) year from the date of shipment. If any such product proves defective during this warranty period, T ektronix, at its option, either will repair the defective product without charge for parts and labor, or will provide a replacement in exchange for the defective product.

In order to obtain service under this warranty, Customer must notify Tektronix of the defect before the expiration of the warranty period and make suitable arrangements for the performance of service. Customer shall be responsible for packaging and shipping the defective product to the service center designated by T ektronix, with shipping charges prepaid. T ektronix shall pay for the return of the product to Customer if the shipment is to a location within the country in which the T ektronix service center is located. Customer shall be responsible for paying all shipping charges, duties, taxes, and any other charges for products returned to any other locations.

This warranty shall not apply to any defect, failure or damage caused by improper use or improper or inadequate maintenance and care. T ektronix shall not be obligated to furnish service under this warranty a) to repair damage resulting from attempts by personnel other than T ektronix representatives to install, repair or service the product; b) to repair damage resulting from improper use or connection to incompatible equipment; or c) to service a product that has been modified or integrated with other products when the effect of such modification or integration increases the time or difficulty of servicing the product.

THIS WARRANTY IS GIVEN BY TEKTRONIX WITH RESPECT TO THIS PRODUCT IN LIEU OF ANY OTHER WARRANTIES, EXPRESSED OR IMPLIED. TEKTRONIX AND ITS VENDORS DISCLAIM ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. TEKTRONIX’ RESPONSIBILITY TO REPAIR OR REPLACE DEFECTIVE PRODUCTS IS THE SOLE AND EXCLUSIVE REMEDY PROVIDED TO THE CUST OMER FOR BREACH OF THIS WARRANTY. TEKTRONIX AND ITS VENDORS WILL NOT BE LIABLE FOR ANY INDIRECT , SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF WHETHER TEKTRONIX OR THE VENDOR HAS ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.

Getting Started

Syntax and Commands

Getting Started 1–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

The Difference between the 3066 and 3086 1–1. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Overview of the Manual 1–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Connecting the Interface 1–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Using Communication Ports 1–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Setting Communication Parameters from the Front Panel 1–7. . . . . . . . . . . . . . . . . .

Command Syntax 2–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Commands and Queries 2–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Constructed Mnemonics 2–6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Command Groups 2–7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Functional Groups 2–8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

General Programming Sequence 2–10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Configuration Commands 2–11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Setup Commands 2–12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

View Commands 2–14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Utility Commands 2–34. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Configuration Commands 2–37. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Standard Setup Commands 2–57. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

CDMA Setup Commands 2–77. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Waveform View Commands 2–91. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Analog View Commands 2–119. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

FSK View Commands 2–131. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Spectrogram View Commands 2–141. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Waterfall View Commands 2–155. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Polar View Commands 2–171. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Eye Diagram View Commands 2–187. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Symbol Table View Commands 2–191. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

EVM View Commands 2–197. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

CDMA Waveform View Commands 2–207. . . . . . . . . . . . . . . . . . . . . . . . . . .

CDMA Polar View Commands 2–229. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

CDMA Time View Commands 2–247. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3066 & 3086 3 GHz Real Time Spectrum Analyzer Programmer Manual

Table of Contents

CodeSpectrogram View Commands

(3066 Option 15 and 3086 Option 16 Only) 2–267. . . . . . . . . . . . . . . . . .

CodePolar View Commands

(3066 Option 15 and 3086 Option 16 Only) 2–277. . . . . . . . . . . . . . . . . .

CodePower View Commands

(3066 Option 15 and 3086 Option 16 Only) 2–287. . . . . . . . . . . . . . . . . .

CodeWSpectrogram View Commands (3086 Option 16 Only) 2–299. . . . . .

CodeWPolar View Commands (3086 Option 16 Only) 2–309. . . . . . . . . . . .

CodeWPower View Commands (3086 Option16 Only) 2–319. . . . . . . . . . . .

CCDF Commands (Option 20 Only) 2–331. . . . . . . . . . . . . . . . . . . . . . . . . . .

CCDFView Commands (Option 20 Only) 2–347. . . . . . . . . . . . . . . . . . . . . . .

Self Gain-Calibration Commands 2–357. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Save/Load Commands 2–361. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Average Commands 2–375. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Remote Commands 2–381. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Retrieving Response Message 2–399. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Status and Events

Programming Examples

Appendices

Glossary and Index

Status and Events 3–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Obtaining Event and Error Messages 3–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TCP/IP Event Port 3–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Status Byte Register (SBR) 3–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Messages 3–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Programming Examples 4–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Appendix A: Character Charts A–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Appendix B: Factory Initialization Settings B–1. . . . . . . . . . . . . . . . . . . . .

Configuration Commands B–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Setup Commands B–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

View Commands B–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Utility Commands B–15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

:Config:Mode Command B–16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3066 & 3086 3 GHz Real Time Spectrum Analyzer Programmer Manual

List of Figures

Table of Contents

Figure 1–1: Common message elements 1–2. . . . . . . . . . . . . . . . . . . . . . . .

Figure 1–2: Functional groupings and an alphabetical list of

commands 1–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 1–3: Event (interrupt) driven programs 1–3. . . . . . . . . . . . . . . . . .

Figure 1–4: Example programs of the PERL source codes 1–3. . . . . . . . .

Figure 1–5: Interface connector location on the rear panel 1–4. . . . . . . .

Figure 1–6: GPIB connection 1–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 1–7: Typical GPIB network configurations 1–5. . . . . . . . . . . . . . .

Figure 1–8: Ethernet connection 1–6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 1–9: Setting the communication parameters 1–7. . . . . . . . . . . . . .

Figure 1–10: Setting the GPIB parameters 1–8. . . . . . . . . . . . . . . . . . . . . .

Figure 1–11: Setting the TCP/IP parameters 1–9. . . . . . . . . . . . . . . . . . . .

Figure 2–1: Example of subsystem hierarchy tree 2–2. . . . . . . . . . . . . . . .

Figure 2–2: Example of chaining commands and queries 2–4. . . . . . . . . .

Figure 2–3: Example of omitting root and lower-level nodes in a

chained message 2–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 2–4: Settings for burst analysis 2–174. . . . . . . . . . . . . . . . . . . . . . . . .

Figure 2–5: Setting the mask for the EVM calculation 2–202. . . . . . . . . . . .

Figure 2–6: Setting the reference line at 1 MHz of RBW 2–216. . . . . . . . . .

Figure 2–7: Setting the reference line at 30 kHz of RBW 2–218. . . . . . . . . .

Figure 2–8: Settings for burst analysis 2–232. . . . . . . . . . . . . . . . . . . . . . . . .

Figure 2–9: Setting the trigger mask 2–256. . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 2–10: :View<x>:Scale:XStartZero On and Off (example) 2–344. . .

Figure 2–10: Data file structure 2–361. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 2–11: Retrieving response message 2–399. . . . . . . . . . . . . . . . . . . . . .

Figure 3–1: Obtaining event on the TCP/IP Ethernet 3–1. . . . . . . . . . . . .

Figure 3–2: The Status Byte Register (SBR) 3–2. . . . . . . . . . . . . . . . . . . . .

3066 & 3086 3 GHz Real Time Spectrum Analyzer Programmer Manual

iii

Table of Contents

List of Tables

Table 2–1: BNF symbols and meanings 2–1. . . . . . . . . . . . . . . . . . . . . . . .

Table 2–2: Comparison of header off and on responses 2–3. . . . . . . . . . .

Table 2–3: Parameter types used in syntax descriptions 2–3. . . . . . . . . .

Table 2–4: Constructed mnemonics 2–6. . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 2–5: Functional groups in the command set 2–9. . . . . . . . . . . . . . .

Table 2–6: Configuration commands 2–11. . . . . . . . . . . . . . . . . . . . . . . . . .

Table 2–7: Standard Setup commands 2–12. . . . . . . . . . . . . . . . . . . . . . . . .

Table 2–8: CDMA Setup commands 2–13. . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 2–9: Waveform View commands 2–14. . . . . . . . . . . . . . . . . . . . . . . .

Table 2–10: Analog View commands 2–16. . . . . . . . . . . . . . . . . . . . . . . . . .

Table 2–11: FSK View commands 2–17. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 2–12: Spectrogram View commands 2–18. . . . . . . . . . . . . . . . . . . . .

Table 2–13: Waterfall View commands 2–19. . . . . . . . . . . . . . . . . . . . . . . .

Table 2–14: Polar View commands 2–20. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 2–15: Eye Diagram View commands 2–21. . . . . . . . . . . . . . . . . . . . .

Table 2–16: Symbol Table View commands 2–22. . . . . . . . . . . . . . . . . . . . .

Table 2–17: EVM View commands 2–22. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 2–18: CDMA Waveform View commands 2–23. . . . . . . . . . . . . . . . .

Table 2–19: CDMA Polar View commands 2–24. . . . . . . . . . . . . . . . . . . . .

Table 2–20: CDMA Time View commands 2–26. . . . . . . . . . . . . . . . . . . . .

Table 2–21: CodeSpectrogram View commands

(3066 option 15 and 3086 option 16 only) 2–27. . . . . . . . . . . . . . . . . . .

Table 2–22: CodePolar View commands

(3066 option 15 and 3086 option 16 only) 2–28. . . . . . . . . . . . . . . . . . .

Table 2–23: CodePower View commands

(3066 option 15 and 3086 option 16 only) 2–29. . . . . . . . . . . . . . . . . . .

Table 2–24: CodeWSpectrogram View commands

(3086 option 16 only) 2–29. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 2–25: CodeWPolar View commands (3086 option 16 only) 2–30. . . Table 2–26: CodeWPower View commands (3086 option 16 only) 2–31. .

Table 2–27: CCDF commands (option 20 only) 2–32. . . . . . . . . . . . . . . . . .

Table 2–28: CCDFView commands (option 20 only) 2–33. . . . . . . . . . . . .

Table 2–29: Self Gain-Calibration commands 2–34. . . . . . . . . . . . . . . . . . .

Table 2–30: Save/Load commands 2–34. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 2–31: A verage commands 2–35. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 2–32: Remote commands 2–36. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3066 & 3086 3 GHz Real Time Spectrum Analyzer Programmer Manual

Table of Contents

Table 3–1: SBR bit functions 3–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3–2: Event message 3–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3–3: No error 3–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3–4: Command error 3–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3–5: Execution error 3–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3–6: Device specific error 3–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3–7: GPIB error 3–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table A–1: The 3066 character set A–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table A–2: ASCII & GPIB code chart A–2. . . . . . . . . . . . . . . . . . . . . . . . . .

Table B–1: Factory initialization settings — Configuration

commands B–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table B–2: Factory initialization settings — Setup commands B–2. . . . .

Table B–3: Factory initialization settings — Waveform View

commands B–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table B–4: Factory initialization settings — Analog View

commands B–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table B–5: Factory initialization settings — FSK View commands B–4. Table B–6: Factory initialization settings — Spectrogram View

commands B–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table B–7: Factory initialization settings — Waterfall View

commands B–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table B–8: Factory initialization settings — Polar View commands B–6 Table B–9: Factory initialization settings — Eye diagram View

commands B–7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table B–10: Factory initialization settings — Symbol View

commands B–7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table B–11: Factory initialization settings — EVM View commands B–7 Table B–12: Factory initialization settings — CDMA Waveform

View commands B–8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table B–13: Factory initialization settings — CDMA Polar View

commands B–9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table B–14: Factory initialization settings — CDMA Time View

commands B–9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table B–15: Factory initialization settings — CodeSpectrogram

View commands (3066 option 15 and 3086 option 16 only) B–10. . . . .

Table B–16: Factory initialization settings — CodePolar View

commands (3066 option 15 and 3086 option 16 only) B–11. . . . . . . . . .

Table B–17: Factory initialization settings — CodePower View

commands (3066 option 15 and 3086 option 16 only) B–11. . . . . . . . . .

3066 & 3086 3 GHz Real Time Spectrum Analyzer Programmer Manual

Table of Contents

Table B–18: Factory initialization settings — CodeWSpectrogram

View commands (3086 option 16 only) B–12. . . . . . . . . . . . . . . . . . . . . .

Table B–19: Factory initialization settings — CodeWPolar View

commands (3086 option 16 only) B–12. . . . . . . . . . . . . . . . . . . . . . . . . .

Table B–20: Factory initialization settings — CodeWPower View

commands (3086 option 16 only) B–13. . . . . . . . . . . . . . . . . . . . . . . . . .

Table B–21: Factory initialization settings — CCDF commands

(option 20 only) B–13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table B–22: Factory initialization settings — CCDFView commands

(option 20 only) B–14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table B–23: Factory initialization settings — Self gain-calibration

commands B–15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table B–24: Factory initialization settings — Save/Load commands B–15 Table B–25: Factory initialization settings — Average commands B–15. . Table B–26: Factory initialization settings — Remote commands B–15. . Table B–27: Factory initialization settings — :Config:Mode

command – 1 B–16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table B–28: Factory initialization settings — :Config:Mode

command – 2 B–17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table B–29: Factory initialization settings — :Config:Mode

command (3066 option 15 and 3086 option 16 only) B–18. . . . . . . . . .

Table B–30: Factory initialization settings — :Config:Mode

command (option 20 only) B–18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3066 & 3086 3 GHz Real Time Spectrum Analyzer Programmer Manual

Preface

This is the Programmer Manual for the 3066 and 3086 Real Time Spectrum Analyzer. This manual provides information on operating the instrument over the GPIB and TCP/IP interfaces. It also covers the 3066 Option 15 cdmaOne analysis functions, the 3086 Option 16 W-CDMA/cdmaOne analysis functions, and the 3066/3086 Option 20 CCDF analysis functions.

This manual provides the following information: H Getting Started describes how to connect and set up the analyzer for remote

operation.

H Syntax and Commands defines the command syntax and processing

conventions and describes each command in the analyzer command set.

H Status and Events explains the status information and event messages

reported by the analyzer.

H Programming Examples shows some example analyzer programs. H Appendices contains various tables of reference information.

Related Manuals

H Glossary and Index contains a glossary of common terms and an index to

this manual.

Other documentation for the analyzer includes: H The 3066 and 3086 Real Time Spectrum Analyzer User Manual (Tektronix

part number 071-0501-XX) describes the operation of the instrument.

H The 3066 and 3086 Real Time Spectrum Analyzer Service Manual (Tektro-

nix part number 071-0503-XX) provides information for maintaining and servicing the analyzer.

3066 & 3086 3 GHz Real Time Spectrum Analyzer Programmer Manual

vii

Preface

viii

3066 & 3086 3 GHz Real Time Spectrum Analyzer Programmer Manual

Getting Started

The 3066 and 3086 are DC to 3 GHz Real Time Spectrum Analyzer. The instrument software operates on the Windows 95. You can write computer programs that remotely set the analyzer front panel controls or that take measurements and read those measurements for further analysis or storage through the GPIB or TCP/IP Ethernet (optional) interface.

To help you get started with programming the analyzer, this section includes the following sections:

H Overview of the Manual – summarizes the type of programming information

contained in each major section of this manual.

H Setting Up Remote Communications – describes how to physically connect

the analyzer to a controller and set the appropriate front panel controls.

The Difference between the 3066 and 3086

The 3066 and 3086 functions are the same, except that the 3086 has the following two input modes:

H Wideband input mode: Processes 50 MHz to 3 GHz signals with maximum

30 MHz span in the vector mode.

H IQ input mode: Inputs the I and Q signals directly from the rear panel

connectors.

The descriptions in this manual apply to both the 3066 and 3086, unless otherwise noted. For more information about the functions of the analyzer, refer to the User Manual.

3066 & 3086 3 GHz Real Time Spectrum Analyzer Programmer Manual

1-1

Getting Started

Overview of the Manual

The information contained in each major section of this manual is described below.

Syntax and Commands

The Syntax and Commands chapter describes the structure and content of the messages your program sends to the analyzer, Figure 1–1 shows command parts as described in the Command Syntax subsection.

Command Parts

Header

Arguments

:Util3:PeakHoldĂĂActive,100,0,D1

Mnemonics

Figure 1-1: Common message elements

Chapter 2 also describes the effect of each command and provides examples of how you might use it. The Command Groups section provides a list by functional area. The command description sections starting from the Configuration Commands on page 2–37 arrange commands alphabetically for each command group (see Figure 1–2).

Space

Comma

Waveform View Commands

Utility

Configuration Commands

Commands grouped in functional areas Commands listed alphabetically

Setup Commands

:Config:Block :Config:Continue :Config:Label :Config:Message :Config:Mode

and

Figure 1-2: Functional groupings and an alphabetical list of commands

1-2

3066 & 3086 3 GHz Real Time Spectrum Analyzer Programmer Manual

:Setup:FFTPoints

:Setup:CenterFrequency

:Setup:BlockSize

Syntax: . . .

Argument: . . .

Examples: . . .

for each command group

Getting Started

Status and Events

The program may request information from the analyzer. The analyzer provides information in the form of status and error messages. Figure 1–3 illustrates the basic operation of this system.

The Status and Events chapter starting on page 3–1 describes how to obtain status and event messages in your programs.

Your program requests

status and event reports.

Controller

The analyzer sends status and event reports.

3066/3086

Figure 1-3: Event (interrupt) driven programs

Programming Examples

The Programming Examples chapter starting on page 4–1 describes some example programs of the PERL source codes (PERL is a freeware).

# # Main # tcp_client(S, '', '3000'); tcp_client(SS, '', '3001'); print S "NewLine LF\n"; print S "Config:Pause On\n"; print S "Config:View1 Waveform\n"; print S "View1:Trace2:Source D1\n";

Figure 1-4: Example programs of the PERL source codes

3066 & 3086 3 GHz Real Time Spectrum Analyzer Programmer Manual

1-3

Getting Started

Connecting the Interface

The analyzer has an IBM PC based expansion slots on its rear panel, as shown in Figure 1–5. The analyzer is shipped standard with a GPIB port. In addition, the analyzer can be configured with optional networking cards.

H GPIB interface

H Ethernet interface (Option 10)

NOTE. Only a service personnel can install the network card. Contact Tektronix for details.

You can also connect the following peripheral devices to the analyzer. Refer to the 3066 and 3086 User Manual for information on using these interfaces.

This connector has a D-type shell and conforms to IEEE Std 488.1–1987

(The cable is available from Tektronix as part number 012–0991–00).

With Option 10, you can connect the analyzer directly to an Ethernet

network using a twisted pair (10BASE-T/100BASE-TX) cable.

H Mouse and keyboard interface H Parallel interface for connecting a printer H SCSI interface for connecting a SCSI device such as an hard disk.

Parallel connector

SCSI connector

1-4

Ethernet interface (Option 10)

GPIB interface

Mouse and keyboard interface

Figure 1-5: Interface connector location on the rear panel

3066 & 3086 3 GHz Real Time Spectrum Analyzer Programmer Manual

Using Communication Ports

The analyzer can communicate with the external controller or other devices on the GPIB and Ethernet network.

Getting Started

Using the GPIB

The analyzer has the Talker/Listener and Controller functions. Refer to the next section about setting the parameters for the port.

Controller

3066/3086 as the Controller

Bus Bus

Other GPIB device

3066/3086 as the Talker/Listner

Figure 1-6: GPIB connection

GPIB Device

Figure 1-7: Typical GPIB network configurations

3066 & 3086 3 GHz Real Time Spectrum Analyzer Programmer Manual

GPIB Device

1-5

Getting Started

GPIB Requirements. Observe these rules when you use your analyzer with a GPIB network:

H Assign a unique device address to each device on the bus. No two devices

can share the same device address.

H Do not connect more than 15 devices to any one bus. H Connect one device for every 2 meters (6 feet) of cable used. H Do not use more than 20 meters (65 feet) of cable to connect devices to a

bus. H Turn on at least two-thirds of the devices on the network while using the

network. H Connect the devices on the network in a star or linear configuration. Do not

use loop or parallel configurations (see Figure 1–7).

Using TCP/IP

The analyzer communicates with the external devices through the following two ports on the TCP/IP Ethernet network.

H Command port receives commands from, or returns responses to the

external controller. H Event port sends events to the external controller. Refer to the next section about setting the parameters for these ports.

Controller

Command

port

TCP/IP Ethernet network

3066/3086

Event

port

1-6

Figure 1-8: Ethernet connection

3066 & 3086 3 GHz Real Time Spectrum Analyzer Programmer Manual

Setting Communication Parameters from the Front Panel

You can set the communication parameters from the front panel menu or with the Remote commands. This section describes the front panel operation procedures. For the remote control commands, refer to Remote Commands on page 2–381.

1. Press the CONFIG:UTILITY key to display the Utility menu.

2. Press the MORE... side key.

3. Press the UTIL H side key to display the Remote menu. See Figure 1–9.

H If you use the GPIB interface, go to the next section Setting the GPIB

Parameters on page 1–8.

H If you use the TCP/IP interface, go to the section Setting the TCP/IP

Parameters on page 1–9.

Getting Started

Figure 1-9: Setting the communication parameters

3066 & 3086 3 GHz Real Time Spectrum Analyzer Programmer Manual

1-7

Getting Started

Setting the GPIB

Parameters

You need to set the GPIB parameters of the analyzer to match the configuration of the bus. Once you have set these parameters, you can control the analyzer through the GPIB interface.

1. Press the GPIB side key to display the GPIB configuration menu.

See Figure 1–10.

2. Press the Interface side key, and select Talker/Listener using either the

general purpose knob or the keypad.

3. Press the Primary Address side key, and set GPIB address using either the

general purpose knob or the keypad.

1-8

Figure 1-10: Setting the GPIB parameters

The analyzer is set up for bidirectional communication with your controller. If you wish to isolate the analyzer from the bus:

H Press the Interface side key, and select Off using either the general purpose

knob or the keypad.

3066 & 3086 3 GHz Real Time Spectrum Analyzer Programmer Manual

Getting Started

Setting the TCP/IP

Parameters

You need to set the TCP/IP parameters of the analyzer to match the network configuration. Once you have set these parameters, you can control the analyzer on the Ethernet network.

1. Press the TCP/IP side key to display the TCP/IP configuration menu.

See Figure 1–11.

2. Press the Command Port side key, and set the command port number using

either the general purpose knob or the keypad. The number ranges 1024 to

32767.

3. Press the Event Port side key, and set the event port number using either the

general purpose knob or the keypad. The number ranges 1024 to 32767. It must be different from the command port number.

4. Press the New Line side key, and select the new-line character of returned

value using either the general purpose knob or the keypad.

Figure 1-11: Setting the TCP/IP parameters

3066 & 3086 3 GHz Real Time Spectrum Analyzer Programmer Manual

1-9

Getting Started

1-10

3066 & 3086 3 GHz Real Time Spectrum Analyzer Programmer Manual

Syntax and Commands

Command Syntax

This section contains general information on command structure and syntax usage. You should familiarize yourself with this material before using the analyzer command descriptions.

This manual describes commands and queries using the Backus-Naur Form (BNF) notation. Table 2–1 defines the standard BNF symbols.

Table 2-1: BNF symbols and meanings

Symbol Meaning

<ą> Defined element

::= Is defined as

| Exclusive OR

{ą} Group; one element is required

[ą] Optional; can be omitted

.ă.Ă. Previous element(s) may be repeated

(ą) Comment

3066 & 3086 3 GHz Real Time Spectrum Analyzer Programmer Manual

2-1

Command Syntax

Commands and Queries

The analyzer commands are based on a hierarchical or tree structure (see Figure 2–1) that represents a subsystem. The top level of the tree is the root node; it is followed by one or more lower-level nodes.

Creating Commands

Marker

DeltaX

PeakX

Root node

LowerĆlevel nodes

Figure 2-1: Example of subsystem hierarchy tree

You can create commands and queries from these subsystem hierarchy trees. Commands specify actions for the instrument to perform. Queries return measurement data and information about parameter settings.

The analyzer commands are created by stringing together the nodes of a subsystem hierarchy and separating each node by a colon (:).

In Figure 2–1, View1 is the root node and Marker, X, DeltaX, and Peak are lower-level nodes. To create a command, start with the root node View1 and move down the tree structure adding nodes until you reach the end of a branch. Most commands and some queries have parameters; you must include a value for these parameters. The command descriptions, which start on page 2–7, list the valid values for all parameters.

2-2

Creating Queries

For example, :View1:Marker:X 1.5 is a valid command created from the hierarchy tree in Figure 2–1.

NOTE. If you specify a parameter value that is out of range, the parameter will be set to a default value.

To create a query, start at the root node of a tree structure, move down to the end of a branch, and add a question mark. :View1:Marker:X? is an example of a valid query using the hierarchy tree in Figure 2–1.

3066 & 3086 3 GHz Real Time Spectrum Analyzer Programmer Manual

Command Syntax

Headers in Query

Responses

Parameter Types

You can control whether the analyzer returns headers as part of the query response. Use the [:Util8]:Header command (page 2–386) to control this feature. If header is on, the query response returns command headers and formats itself as a valid set command. When header is off, the response includes only the values. This may make it easier to parse and extract the information from the response. Table 2–2 shows the difference in responses.

Table 2-2: Comparison of header off and on responses

Query Header off response Header on response

:View1:Source? "FILE1.AP" :View1:Source "File1.AP"

:Setup:Span? 5M :Setup:Span 5M

Parameters are indicated by angle brackets, such as <file_name>. There are several different types of parameters, as listed in Table 2–3. The parameter type is listed after the parameter. Some parameter types are defined specifically for the analyzer command set and some are defined by ANSI/IEEE 488.2-1987.

Table 2-3: Parameter types used in syntax descriptions

Special Characters

Parameter Type Description Example

boolean Boolean numbers or values On, Off

discrete A list of specific values MIN, MAX

NR11numeric Integers 0, 1, 15, -1

NR21numeric Decimal numbers 1.2, 3.141516, -6.5

NR31numeric Floating point numbers 3.1415E-9, -16.1E5

NRf1numeric Flexible decimal number that

may be type NR1, NR2, or NR3

string

1 An ANSI/IEEE 488.2Ć1992Ćdefined parameter type.

2 Defined in ANSI/IEEE 488.2 as String Response Data" and String Program Data."

Alphanumeric characters (must be within quotation marks)

See NR1, NR2, NR3 examples

Testing 1, 2, 3"

The Line Feed (LF) character (ASCII 10) and all characters in the range of ASCII 127-255 are defined as special characters. Using these characters in any command yields unpredictable results.

3066 & 3086 3 GHz Real Time Spectrum Analyzer Programmer Manual

2-3

Command Syntax

Abbreviating Commands,

Queries, and Parameters

Chaining Commands and

Queries

You must not

abbreviate all commands, queries, and parameters. For example, shortening the command :Setup:CenterFrequency to :Setup:CenterFreq causes an error.

You can chain several commands or queries together into a single message. To create a chained message, first create a command or query, then add a semicolon (;), and finally add more commands or queries and semicolons until you are done. If the command following a semicolon is a root node, precede it with a colon (:). Figure 2–2 illustrates a chained message consisting of several commands and queries. The chained message should end in a command or query, not a semicolon. Responses to any queries in your message are separated by semicolons.

:Config:Setup Standard;:Setup:BlockSize 200;:View1:Marker:X?;:Util2:Source?

First command Second command Second query

The response from this chained message might be:

First query

1.2;Active

Response from first query Response from second query

Figure 2-2: Example of chaining commands and queries

If a command or query has the same root and lower-level nodes as the previous command or query, you can omit these nodes. In Figure 2–3, the second command has the same root node (Marker) as the first command, so these nodes can be omitted.

:View1:Marker:X 1.5;:View1:Marker:Y -20;:View1:Marker:DeltaMarker On

Identical root and lowerĆlevel nodes

:View1:Marker:X 1.5;Y -20;DeltaMarker On

First command Additional commands

(omitted the root nodes)

Figure 2-3: Example of omitting root and lowerĆlevel nodes in a chained message

2-4

3066 & 3086 3 GHz Real Time Spectrum Analyzer Programmer Manual

Command Syntax

Unit and SI Prefix

General Rules

If a decimal numeric argument refers to amplitude, frequency, or time, you can express it using SI units instead of the scaled explicit point input value format <NR3>. (SI units conform to the Systeme International d’Unites standard.) For example, you can use the input format 200 m or 1.0 M instead of 200.0E–3 or

1.0E+6, respectively, to specify the argument.

NOTE. You must omit the unit, such as Hz and dB. For example, 5 MHz of frequency is represented by “5M” in a command.

The SI prefixes, which must be included, are shown below. Note that either lower or upper case prefixes can be used.

SI prefix p/P n/N u/U m/M k/K m/M g/G

Corresponding power 10

* Note that the prefix m/M indicates 10-3when the decimal numeric argument denotes

amplitude or time, but 10

-12

when it denotes frequency.

-9

-6

-3

Here are three general rules for using the analyzer commands, queries, and parameters:

H You must use double (“ ”) quotation marks for quoted strings.

correct: “This string uses quotation marks correctly.” incorrect: ‘This string also uses quotation marks correctly.’ incorrect: “This string does not use quotation marks correctly.’

H You can use upper case, lower case, or a mixture of both cases for all

commands, queries, and parameters.

:VIEW1:MASK:RBW1M:FREQUENCYĂ25M

is the same as

:view1:mask:rbw1m:frequencyĂ25m

and

:view1:mask:rbw1m:FREQUENCYĂ25M

H No embedded spaces are allowed between or within nodes.

correct: :VIEW1:MASK:RBW1M:FREQUENCYĂ25M incorrect: :VIEW1: MASK: RBW1M: FREQ UENCYĂ25M

3066 & 3086 3 GHz Real Time Spectrum Analyzer Programmer Manual

2-5

Command Syntax

Constructed Mnemonics

Some header mnemonics specify one of a range of mnemonics. For example, a view mnemonic can be either View1, View2, ... or View8. You use these mnemonics in the command just as you do any other mnemonic. For example, there is a View1:Format command, and there is also a View2:Format command. In the command descriptions, this list of choices is abbreviated as View<x>.

Table 2-4: Constructed mnemonics

Symbol Meaning

View<x> A view specifier where <x>=1to8,corresponding toA-H

Utility<x> A utility specifier where <x>=1to8,corresponding toA-H

Dev<x> A GPIB device where <x> is the GPIB address

Result<x> A result specifier whrere <x> ranges 1 to 26, depending on commands

<address> GPIB address, ranging 1 to 30

<command> IEEE 488.2 command e.g. *IDN

<message> Specify the message for the command

<item> Specify the item for the command

2-6

3066 & 3086 3 GHz Real Time Spectrum Analyzer Programmer Manual

Command Groups

The following sections list the 3066 and 3086 spectrum analyzer commands in two ways. They first present them by functional groups, then list them alphabetically. The functional group lists start below. The alphabetical lists provide more detail on each command and start on page 2–37.

Items followed by question marks are queries; items without question marks are commands. Some items in this section have a question mark in parentheses (?) in the command header section; this indicates that the item can be both a command and a query.

3066 & 3086 3 GHz Real Time Spectrum Analyzer Programmer Manual

2-7

Command Groups

Functional Groups

There are four main groups: H Configuration command group configures the analyzer for the specific

measurement. Also, it starts or stops data acquisition.

H Setup command group sets up the analyzer hardware, such as frequency,

span, trigger, and memory.

H View command group displays waveform and performs measurement. H Utility command group controls the utilities, such as self calibration, file

management, averaging, and remote operation.

Table 2–5 lists the functional groups and subgroups of the commands. The analyzer has its system program modules corresponding to each subgroup.

2-8

3066 & 3086 3 GHz Real Time Spectrum Analyzer Programmer Manual

Command Groups

Table 2-5: Functional groups in the command set

Group Subgroup Description

Configuration - Configure the analyzer and start/stop acquisition

Setup

View

Standard Set up the analyzer for the standard measurement

CDMA Set up the analyzer for the CDMA measurement

Waveform Control the Waveform view

Analog Control the Analog view

FSK Control the FSK view

Spectrogram Control the Spectrogram view

Waterfall Control the Waterfall view

Polar Control the Polar view

Eye diagram Control the Eye diagram view

Symbol table Control the Symbol table view

EVM Control the EVM view

CDMA Waveform Control the CDMA Waveform view

CDMA Polar Control the CDMA Polar view

CDMA Time Control the CDMA Time view

CodeSpectrogram

Control the codeĆdomain spectrogram view (cdmaOne standard)

CodePolar

CodePower

Control the polar view (cdmaOne standard)

Control the codeĆdomain power view (cdmaOne standard)

CodeWSpectrogram

Control the codeĆdomain spectrogram view (WĆCDMA standard)

CodeWPolar

CodeWPower

Control the polar view (WĆCDMA standard)

Control the codeĆdomain power view (WĆCDMA standard)

CCDF

CCDFView

Control the CCDF measurement

Control the CCDF view

Utility

Self gainĆcalibration Control the self gainĆcalibration

Save/Load Control to save and load data to/from files

Average Control averaging

Remote Control remote operation

3066 option 15 and 3086 option 16 only.

3086 option 16 only.

3066/3086 option 20 only.

3066 & 3086 3 GHz Real Time Spectrum Analyzer Programmer Manual

2-9

Command Groups

General Programming Sequence

The programs for controlling the analyzer have the following steps in general:

1. Configuration: Use the Configuration command group to set the basic

operation mode and assign the Views. Also, use the Remote command subgroup (Util8) to set the communication

parameters with other device.

2. Setup: Use the Setup command group to set the hardware, such as frequency,

span, trigger, and memory.

3. Acquisition: Use the Configuration command group to start or stop the

waveform acquisition. You can load previously acquired data with the Save/Load command

subgroup (Util2).

4. Measurement and Display: Use the View command group to measure and

display the result. For example, if you have selected the Spectrogram View in the configuration, use the Spectrogram View command subgroup.

You can use the Average command subgroup (Util3) to average waveforms. Also, you can save the data to a file with the Save/Load command subgroup

(Util2). Section 4, Programming Examples shows some example programs. Powering on the analyzer initializes its settings to the factory defaults. For the

details about the factory defaults, refer to Appendix B: Factory Initialization Settings.

2-10

3066 & 3086 3 GHz Real Time Spectrum Analyzer Programmer Manual

Configuration Commands

These commands configure the system. These commands are equivalent to the CONFIG and START/STOP menu on the front panel.

Table 2-6: Configuration commands

Header Description

:Config:Block Start or stop data acquisition in the Block mode

:Config:Continue Continue the data acquisition

:Config:Label Display a label on the screen

:Config:Message Display a message in red on the screen

:Config:Mode Load settings from the basic configuration file

:Config:Mode:Load Load settings from a file saved before

:Config:Mode:Save Save settings to a file

:Config:Next Stop and restart a block data acquisition

Command Groups

:Config:Pause (?) Pause the data acquisition on each block

:Config:PrintScreen Print a screen image to a printer

:Config:PrintScreen:Printer (?) Specify the printer to print screen images

:Config:PrintScreen:Items? Return the list of available printers

:Config:PrintScreen:Save Save a screen image to a file

:Config:Roll Start or stop the data acquisition in the Roll mode

:Config:Setup (?) Load the Setup program for the SETUP menu

:Config:Setup:Items? Return the list of available programs for the setup

:Config:Setup:Show Display the CONFIG:SETUP menu

:Config:Start Start a data acquisition in the Block mode

:Config:StartAgain Stop and restart the acquisition in the Block mode

:Config:Status:Overload? Query the overload status of the A/D converter

:Config:Status:Pause? Query if the data acquisition pauses

:Config:Status:Triggered? Query if the analyzer is triggered

:Config:Status:Uncal? Query if the analyzer is uncalibrated

:Config:Stop Stop the data acquisition

:Config:System? Query the instrument name

:Config:Util:Items? Return the list of available programs for the utility

:Config:Util<x> (?) Assign the Utility program to a Utility side key

:Config:Util<x>:Show Display the CONFIG:UTILITY menu

:Config:Version? Query the version of the Configuration program

3066 & 3086 3 GHz Real Time Spectrum Analyzer Programmer Manual

2-11

Command Groups

Setup Commands

Table 2-6: Configuration commands (Cont.)

Header Description

:Config:View:BackgroundColor (?) Select the background color for waveform view area

:Config:View:Items? Return the list of available programs for the view

:Config:View:MarkerLink (?) Determine whether the markers in different views

move in unison or separately

:Config:View:Style (?) Select the view layout

:Config:View<x> (?) Assign the View program to a View side key

:Config:View<x>:Show Display the View menu

Standard Setup

Commands

When you select Standard in the Config:Setup command, use the following commands to control parameters for the standard measurement. These commands are equivalent to the SETUP menu on the front panel.

Table 2-7: Standard Setup commands

Header Description

:Setup:BlockSize (?) Set the number of frames per block

:Setup:CenterFrequency (?) Set the center frequency

:Setup:FFTPoints (?) Set the number of FFT sampling points per frame

:Setup:FFTWindow (?) Select the FFT window

:Setup:FramePeriod (?) Set the frame period in the Block mode

:Setup:FrequencyOffset (?) Set the frequency display offset

:Setup:InputCoupling (?) Select the input coupling to the RF input

:Setup:InputMode (?) Select the signal input mode

:Setup:LevelOffset (?) Set the level display offset

:Setup:Load Load a trigger mask from a file

:Setup:MarkerToFreq Set the center frequency to the value at the marker

:Setup:MaxSpan Set the span to the maximum

2-12

:Setup:MemoryMode (?) Select the memory mode

:Setup:ReferenceLevel (?) Set the reference level

:Setup:ReferenceOsc (?) Select the reference oscillator

:Setup:Save Save a trigger mask to a file

3066 & 3086 3 GHz Real Time Spectrum Analyzer Programmer Manual

Command Groups

Table 2-7: Standard Setup commands (Cont.)

Header Description

:Setup:Span (?) Select the span

:Setup:Trigger (?) Select the trigger mode

:Setup:TriggerCount (?) Turn the trigger counter on or off

:Setup:TriggerDelayed (?) Set the delay time in the Delayed trigger mode

:Setup:TriggerDomain (?) Select the trigger domain

:Setup:TriggerInterval (?) Set the time interval in the Interval trigger mode

:Setup:TriggerPosition (?) Set the trigger position

:Setup:TriggerSlope (?) Select the trigger slope

:Setup:TriggerSource (?) Select the trigger source

:Setup:TriggerTimeout (?) Set the timeout in the Timeout trigger mode

:Setup:TriggerTimes (?) Set the trigger count in the Count trigger mode

:Setup:Version? Query the version of the Setup program

CDMA Setup Commands

:Setup:Zoom:Execute Expand the waveform

:Setup:Zoom:Frequency (?) Set the center frequency for zooming

:Setup:Zoom:Mag (?) Select the magnification factor for zooming

When you select CDMA in the Config:Setup command, use the following commands to control parameters for the CDMA measurement. These commands are equivalent to the SETUP menu on the front panel.

Table 2-8: CDMA Setup commands

Header Description

:Setup:BlockSize (?) Set the number of frames per block

:Setup:CDMA:Channel (?) Select the channel

:Setup:CDMA:Span30M Set the span to 30 MHz

:Setup:CDMA:Span50M Set the span to 50 MHz

:Setup:CDMA:Span5MAuto Set the span to 5 MHz and the trigger mode to

Auto

:Setup:CDMA:Span5MNormal Set the span to 5 MHz and the trigger mode to

Normal

:Setup:CDMA:Standard (?) Select the CDMA standard

:Setup:CDMA:TriggerLevel (?) Set the trigger mask level in the time domain

:Setup:MarkerToFreq Set the center frequency to the value at the marker

3066 & 3086 3 GHz Real Time Spectrum Analyzer Programmer Manual

2-13

Command Groups

Table 2-8: CDMA Setup commands (Cont.)

Header Description

:Setup:MaxSpan Set the span to the maximum

:Setup:ReferenceLevel (?) Set the reference level

:Setup:ReferenceOsc (?) Select the reference oscillator

:Setup:Span (?) Select the span

:Setup:Trigger (?) Select the trigger mode

:Setup:TriggerCount (?) Turn the trigger counter on or off

:Setup:TriggerDelayed (?) Set the delay time in the Delayed trigger mode

:Setup:TriggerDomain (?) Select the trigger domain

:Setup:TriggerInterval (?) Set the time interval in the Interval trigger mode

:Setup:TriggerPosition (?) Set the trigger position in a block

:Setup:TriggerSlope (?) Select the trigger slope

:Setup:TriggerSource (?) Select the trigger source

View Commands

Waveform View

Commands

:Setup:TriggerTimeout (?) Set the timeout in the Timeout trigger mode

:Setup:TriggerTimes (?) Set the trigger count in the Count trigger mode

:Setup:Version? Query the version of the CDMA Setup program

These commands control the Waveform view.

Table 2-9: Waveform View commands

Header Description

:View<x>:Average:Times (?) Set the number of frames for averaging

:View<x>:Average:Type (?) Select the average type

:View<x>:Compression (?) Select the way to compress data for displaying

:View<x>:CopyFrom Copy display data from a text file to the data register

:View<x>:CopyTo Copy display data to a file or data register

:View<x>:Edit (?) Determine whether or not to display the trigger mask

2-14

:View<x>:Edit:DrawHorizontal Draw the entire trigger mask line horizontally through

the marker

:View<x>:Edit:DrawLine Draw the trigger mask line between the marker and

the delta marker

3066 & 3086 3 GHz Real Time Spectrum Analyzer Programmer Manual

Command Groups

Table 2-9: Waveform View commands (Cont.)

Header Description

:View<x>:Edit:DrawMax Draw the entire trigger mask line horizontally at the

maximum level

:View<x>:Edit:DrawMin Draw the entire trigger mask line horizontally at the

minimum level

:View<x>:Edit:Y (?) Set the vertical position of the marker in editing the

trigger mask

:View<x>:Format (?) Select the waveform display format

:View<x>:Marker:Band:Center (?) Set the center frequency of the band marker

:View<x>:Marker:Band:Left (?) Set the left side frequency of the band marker

:View<x>:Marker:Band:Right (?) Set the right side frequency of the band marker

:View<x>:Marker:Band:Width (?) Set the bandwidth of the band marker

:View<x>:Marker:DeltaMarker (?) Turn on or off the delta marker

:View<x>:Marker:DeltaX (?) Set the horizontal position of the delta marker

:View<x>:Marker:DeltaY? Query the vertical position of the delta marker

:View<x>:Marker:Peak Move the marker to the adjacent peak

:View<x>:Marker:ResetDelta Move the delta marker to the marker position

:View<x>:Marker:SearchMax Search the maximum peak and place the marker on it

:View<x>:Marker:SearchMin Search the minimum peak and place the marker on it

:View<x>:Marker:SearchSeparation (?) Set the resolution to separate two peaks

:View<x>:Marker:Trace (?) Select the trace on which the markers are placed

:View<x>:Marker:X (?) Set the horizontal position of the marker

:View<x>:Marker:Y? Query the vertical position of the marker

:View<x>:MaskVisible (?) Specify whether or not to display the trigger mask

:View<x>:Measurement (?) Select the measurement item

:View<x>:Measurement:ACP:BW (?) Set the bandwidth for the ACP measurement

:View<x>:Measurement:ACP:Marker

(?)

:View<x>:Measurement:ACP:SP (?) Set the frequency interval between adjacent channels

:View<x>:Measurement:OBW (?) Set the occupied bandwidth

:View<x>:Position (?) Set the display position in a block

Select the marker position for the ACP measurement

for the ACP measurement

:View<x>:Result<y>? Query the measurement results

:View<x>:Scale:AutoScale Scale the vertical axis automatically

:View<x>:Scale:HoldYScale (?) Determine whether to hold or reset the vertical scale

when you change the input source

3066 & 3086 3 GHz Real Time Spectrum Analyzer Programmer Manual

2-15

Command Groups

Table 2-9: Waveform View commands (Cont.)

Header Description

:View<x>:Scale:XScale (?) Scale the horizontal axis

:View<x>:Scale:XStart (?) Set the start point of the horizontal axis on the screen

:View<x>:Scale:YScale (?) Scale the vertical axis

:View<x>:Scale:YStart (?) Set the start point of the vertical axis on the screen

:View<x>:Source (?) Select the input data source

:View<x>:Trace2:Compression (?) Select the compression method to display the trace 2

:View<x>:Trace2:Format (?) Select the display format of the trace 2

:View<x>:Trace2:Source (?) Select the input data source of the trace 2

:View<x>:Trace2:Z (?) Set the frame number of the trace 2

:View<x>:Version? Query the version of the Waveform View program

:View<x>:Z (?) Set the frame number

Analog View Commands

These commands control the Analog view to analyze an analog modulating signal. This view is capable of demodulating and displaying PM (Phase Modulation), AM (Amplitude Modulation), or FM (Frequency Modulation) signals.

Table 2-10: Analog View commands

Header Description

:View<x>:CopyTo Copy display data to a file or data register

:View<x>:Format (?) Select the waveform display format

:View<x>:Marker:DeltaMarker (?) Turns on or off the delta marker

:View<x>:Marker:DeltaX (?) Query the horizontal position of the delta marker

:View<x>:Marker:DeltaY? Query the vertical position of the delta marker

:View<x>:Marker:Peak Move the marker to the adjacent peak

:View<x>:Marker:ResetDelta Move the delta marker to the marker position

:View<x>:Marker:SearchMax Search the maximum peak and place the marker on it

:View<x>:Marker:SearchMin Search the minimum peak and place the marker on it

:View<x>:Marker:SearchSeparation (?) Set the resolution to separate two peaks

:View<x>:Marker:X (?) Set the horizontal position of the marker

2-16

:View<x>:Marker:Y? Query the vertical position of the marker

:View<x>:Scale:AutoScale Scale the vertical axis automatically

3066 & 3086 3 GHz Real Time Spectrum Analyzer Programmer Manual

Command Groups

Table 2-10: Analog View commands (Cont.)

Header Description

:View<x>:Scale:HoldYScale (?) Determine whether to hold or reset the vertical scale

when you change the input source

:View<x>:Scale:XScale (?) Scale the horizontal axis

:View<x>:Scale:XStart (?) Set the start point of the horizontal axis on the screen

:View<x>:Scale:YScale (?) Scale the vertical axis

:View<x>:Scale:YStart (?) Set the start point of the vertical axis on the screen

:View<x>:Source (?) Select the input data source

:View<x>:Version? Query the version of the Analog View program

:View<x>:Z (?) Set the frame number

FSK View Commands

These commands control the FSK view. In this view, the FSK (Frequency Shift Keying) signal is demodulated and displayed.

Table 2-11: FSK View commands
