Tektronix 070-9180-01 User Manual

User Manual

Option 01 VXI Interface Daughter Board

070-9180-01

This document applies for firmware version 1.00 and above.

Copyright  T ektronix, Inc. 1995. All rights reserved. Licensed software products are owned by Tektronix or its suppliers and are protected by United States copyright laws and international treaty provisions.

Use, duplication, or disclosure by the Government is subject to restrictions as set forth in subparagraph (c)(1)(ii) of the Rights in T echnical Data and Computer Software clause at DFARS 252.227-7013, or subparagraphs (c)(1) and (2) of the Commercial Computer Software – Restricted Rights clause at F AR 52.227-19, as applicable.

T ektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supercedes that in all previously published material. Specifications and price change privileges reserved.

Printed in the U.S.A. T ektronix, Inc., P.O. Box 1000, Wilsonville, OR 97070–1000 TEKTRONIX and TEK are registered trademarks of T ektronix, Inc. VXIbus is a trademark of the VXI Consortium. SurePath and Intelliframe are registered trademarks of T ektronix, Inc.

WARRANTY

T ektronix warrants that this product will be free from defects in materials and workmanship for a period of three (3) years from the date of shipment. If any such product proves defective during this warranty period, T ektronix, at its option, either will repair the defective product without charge for parts and labor, or will provide a replacement in exchange for the defective product.

In order to obtain service under this warranty, Customer must notify Tektronix of the defect before the expiration of the warranty period and make suitable arrangements for the performance of service. Customer shall be responsible for packaging and shipping the defective product to the service center designated by T ektronix, with shipping charges prepaid. T ektronix shall pay for the return of the product to Customer if the shipment is to a location within the country in which the T ektronix service center is located. Customer shall be responsible for paying all shipping charges, duties, taxes, and any other charges for products returned to any other locations.

This warranty shall not apply to any defect, failure or damage caused by improper use or improper or inadequate maintenance and care. T ektronix shall not be obligated to furnish service under this warranty a) to repair damage resulting from attempts by personnel other than T ektronix representatives to install, repair or service the product; b) to repair damage resulting from improper use or connection to incompatible equipment; or c) to service a product that has been modified or integrated with other products when the effect of such modification or integration increases the time or difficulty of servicing the product.

THIS WARRANTY IS GIVEN BY TEKTRONIX WITH RESPECT TO THIS PRODUCT IN LIEU OF ANY OTHER WARRANTIES, EXPRESSED OR IMPLIED. TEKTRONIX AND ITS VENDORS DISCLAIM ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PAR TICULAR PURPOSE. TEKTRONIX’ RESPONSIBILITY TO REPAIR OR REPLACE DEFECTIVE PRODUCTS IS THE SOLE AND EXCLUSIVE REMEDY PROVIDED TO THE CUST OMER FOR BREACH OF THIS WARRANTY. TEKTRONIX AND ITS VENDORS WILL NOT BE LIABLE FOR ANY INDIRECT , SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF WHETHER TEKTRONIX OR THE VENDOR HAS ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.

Getting Started

Operating Basics

Syntax and Commands

General Safety Summary iii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Preface vii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Product Description 1–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Accessories 1–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Controls and Indicators 1–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Configuration 1–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Installation 1–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Installation Checklist 1–9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Functional Check 1–10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Functional Overview 2–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Power-on 2–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Instrument I/O: VXIbus Basics 2–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Command Syntax 3–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Functional Command Groups 3–11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

System Commands 3–11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Module Commands 3–11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Command Descriptions 3–15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

IEEE-488.2 Common Commands 3–59. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Status and Events

Status and Event Reporting System 4–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Status Byte Register 4–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Service Request Enable Register 4–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Standard Event Status Register 4–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Event Status Enable Register 4–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

The Output Queue 4–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

The System Error and Event Queue 4–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Status and Event Reporting Process 4–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Messages 4–6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Appendices

Appendix A: Specifications A–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Appendix B: Examples B–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Appendix C: User Service C–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Option 01 VXI Interface Module User Manual

Table of Contents

Glossary and Index

Appendix D: Replaceable Parts D–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Parts Ordering Information D–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Using the Replaceable Parts List D–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Option 01 VXI Interface Module User Manual

General Safety Summary

Review the following safety precautions to avoid injury and prevent damage to this product or any products connected to it.

Only qualified personnel should perform service procedures.

While using this product, you may need to access other parts of the system. Read the General Safety Summary in other system manuals for warnings and cautions related to operating the system.

Injury Precautions

Avoid Electric Overload

Avoid Electric Shock

Do Not Operate Without

Covers

Use Proper Fuse

Do Not Operate in

Wet/Damp Conditions

Do Not Operate in an

Explosive Atmosphere

Avoid Exposed Circuitry

To avoid electric shock or fire hazard, do not apply a voltage to a terminal that is outside the range specified for that terminal.

To avoid injury or loss of life, do not disconnect probes or test leads from this product while it is connected to a voltage source.

To avoid electric shock or fire hazard, do not operate this product with covers or panels removed.

To avoid fire hazard, use only the fuse type and rating specified for this product.

To avoid electric shock, do not operate this product in wet or damp conditions.

To avoid injury or fire hazard, do not operate this product in an explosive atmosphere.

To avoid injury, remove jewelry such as rings, watches, and other metallic objects. Do not touch exposed connections and components when power is present.

Product Damage Precautions

Provide Proper Ventilation

Option 01 VXI Interface Module User Manual

To prevent product overheating, provide proper ventilation.

iii

General Safety Summary

Do Not Operate With

Suspected Failures

If you suspect there is damage to this product, have it inspected by qualified service personnel.

Safety Terms and Symbols

Terms in This Manual

Terms on the Product

These terms may appear in this manual:

WARNING. Warning statements identify conditions or practices that could result in injury or loss of life.

CAUTION. Caution statements identify conditions or practices that could result in damage to this product or other property.

These terms may appear on the product: DANGER indicates an injury hazard immediately accessible as you read the

marking. WARNING indicates an injury hazard not immediately accessible as you read the

marking. CAUTION indicates a hazard to property including the product.

Symbols on the Product

The following symbols may appear on the product:

DANGER

High Voltage

Certifications and Compliances

Safety Certification of

Plug-in or VXI Modules

For modules (plug-in or VXI) that are safety certified by Underwriters Laboratories, UL Listing applies only when the module is installed in a UL Listed product.

For modules (plug-in or VXI) that have cUL or CSA approval, the approval applies only when the module is installed in a cUL or CSA approved product.

Protective Ground

(Earth) T erminal

ATTENTION

Refer to Manual

Double

Insulated

Option 01 VXI Interface Module User Manual

General Safety Summary

Compliances

Overvoltage Category

Consult the product specifications for Overvoltage Category, and Safety Class.

The following defines overvoltage categories: CAT III: Distribution level mains, fixed installation. CAT II: Local level mains, appliances, portable equipment CAT I: Signal level, special equipment or parts of equipment, telecommunica-

tion, electronics

Option 01 VXI Interface Module User Manual

Preface

This manual assumes you are familiar with VXIbus instruments and operation and with the purpose and function of this instrument.

Please read and follow all instructions for installation and configuration. Use the Installation Checklist to ensure proper installation and to record your initial settings.

The Operating Basics section gives a summary of VXIbus operation and presents an overview of the operation of this instrument.

The Syntax and Commands section provides a summary of all the commands followed by detailed descriptions of each command.

The Status and Events section contains an explanation of the Status and Event Reporting System and lists the system messages. Appendix B: Examples contains example programs that demonstrate the programmable features of this instrument.

You may also want to keep the Reference Guide by the instrument.

Conventions

The names of all switches, controls, and indicators appear in this manual exactly as they appear on the instrument.

Specific conventions for programming are given in the sections Syntax and Commands and Appendix B: Examples.

Option 01 VXI Interface Module User Manual

vii

Getting Started

Product Description

This section begins with a brief description of the Option 01 VXI Interface Module, and explains how to configure and install the module on a relay switching module in a VXIbus mainframe. When the Option 01 is installed on a relay module, a quick functional check (described in this section of the User Manual for the relay module) assures that the instrument operates properly.

The Option 01 VXI Interface Module is a printed circuit board assembly for use in a mainframe conforming to the VXIbus Specification. The Option 01 provides a VXI word serial protocol servant interface to the SurePatht family of VXI relay modules. The Option 01 is a daughter board assembly measuring approximately 3I × 9I that is installed as an optional daughter board on one of the SurePatht C-size VXI switching modules. The daughter board accepts SCPI-compatible commands from its commander using VXI word serial protocol. The daughter board controls the relay module on which it is installed, and controls additional relay modules installed in adjacent slots to its right via the VXI P2 local bus. The daughter board is capable of controlling from one to 12 relay modules including members of the SurePatht family of relay switching modules and VX4372 and VX4374 Scanner Slave modules. In this document, these modules will be referred to as “local bus slaves.”

The VXI Interface Module includes the following features: H CPU:

Zilog Z88C00 Microcontroller with 20 MHz Clock

64 Kbyte of EPROM and 32 Kbyte of RAM H VXI Interface:

VXI Rev 1.4 Message Based Device. IEEE-488.2 device

Supports Fast Handshake word serial protocol data transfers

Logical Address selectable with two rotary hexadecimal switches

Interrupter level selectable with a rotary hexadecimal switch. Selects one of

seven levels or disables interrupt generation

Command programmable control of one to eight VXI TTL triggers

Command programmable monitoring of one or more VXI TTL triggers

Option 01 VXI Interface Module User Manual

1–1

Getting Started

The Local Bus Interface function of the Option 01 provides serial I/O interface for control of scanner slave and SurePatht relay modules, monitors the power fuses of all local bus slave modules that it controls, and provides a serial input interface to identify each local bus slave that it controls.

As part of the self test, SurePatht modules automatically verify the control logic every time a relay operation is performed.

Figure 1–1 shows the Option 01.installed on a SurePatht relay module. Figure 1–2 shows a typical SurePatht configuration.

Option 01

F1291

Figure 1–1: Option 01 Indicators and Switch Locations

LOGICAL ADDRS

INTRPT

Switches as viewed

from the rear of instrument

(labels are on the back shield)

1–2

Option 01 VXI Interface Module User Manual

Front panel

connectors

Getting Started

VXI interface & slave controller daughter board

Backplane

connectors

VXI backplane local bus

Daughter board

connectors

Fuses

BITE (Built-in Test

Equipment)

Figure 1–2: Typical SurePath Configuration

Each relay module that the Option 01 Module controls has a fuse that limits the amount of current that the module can draw from the VXI backplane +5 V power pins. This fuse protects the module in case of an accidental shorting of the power bus or any other situation where excessive current might be drawn.

The Option 01 Module monitors the state of the fuses of each of the relay modules that it controls. If a fuse opens on one of these modules, the Option 01 Module will assert SYSFAIL* on the VXIbus.

If the +5 V fuse on the module on which the Option 01 Module is installed opens, the VXIbus Resource Manager will be unable to assert SYSFAIL INHIBIT on the Option 01 to disable SYSFAIL*.

If a +5 V fuse opens, remove the fault before replacing the fuse. Replacement fuse information is given in the Specifications section of the user manual for the appropriate relay module.

Built-in Test Equipment (BITE) is provided by extensive self tests that are automatically invoked on power-on and can also be invoked on command. Circuitry tested includes the CPU and all memory

, and the relay control circuitry

on each relay module controlled by the Option 01.

Option 01 VXI Interface Module User Manual

1–3

Getting Started

Accessories

Controls and Indicators

Table 1–1 lists the standard accessories included with the Option 01.

T able 1–1: Standard Accessories

Accessory Part Number

Option 01 User Manual 070-9180-XX Option 01 Reference 070-9198-XX

The following controls are provided to select the functions of the Option 01 operating environment.

Switches

Configuration

Logical Address Switches

The Logical Address switches and VMEbus Interrupt Level Select switch must be correctly set to insure proper operation. See Configuration for details on how to set the switches.

The following switches must be correctly set to ensure proper operation. Refer to Figure 1–1 for their physical locations.

Each functional module in a VXIbus System must be assigned a unique logical address, from 1 to decimal 255 (hexadecimal FF). The base VMEbus address of the Option 01 is set to a value between hexadecimal C0 (C000 mal FF (FFC0 position with the arrow on the module shield.

The physical address of the instrument is on a 64 byte boundary. If the Logical Address switch representing the most significant digit (LA–HI) of the logical address is set to position X and the switch representing the least significant digit (LA–LO) of the logical address is set to position Y, then the base physical address of the Option 01 will be [(40

) by two hexadecimal rotary switches. Align the desired switch

× XY16) + C00016].

) and hexadeci-

1–4

Option 01 VXI Interface Module User Manual

For example:

Base Physical Address

L.A. HI LO decimal hex

LA. is the Logical Address

(64 * 10) + 49152 = 49792 (4016 * A16) + C00016 = C280 (64 * 21) + 49152 = 50496 (4016 * 1516) + C00016 = C540

Getting Started

IEEE-488 Address

VMEbus Interrupt Level

Select Switch

In order to use and program the Option 01 daughter board in an IEEE-488 environment you must know the IEEE-488 address of the module. Different manufacturers of IEEE-488 interface devices might have different algorithms for equating a logical address with an IEEE-488 address. Consult the operating manual of the IEEE-488 Interface Slot 0 module being used.

Each function module in a VXIbus System can generate an interrupt at a specified level on the VMEbus to request service from the interrupt handler located on its commander. Set the interrupt level to the same level as the interrupt handler on that commander. The VMEbus interrupt level on which the Option 01 daughter board generates interrupts is set by a rotary switch. Align the desired switch position with the arrow on the module shield.

Valid VMEbus Interrupt Level Select switch settings are one through seven, with setting one equivalent to level one, and so on. The level chosen should be the same as the level set on the Option 01 interrupt handler, typically the module commander. Setting the switch to zero or eight will disable the module interrupts. Do not use switch settings nine through F.

Interrupts are used by the module to return VXIbus Protocol Events to the module commander. Refer to the Operating Basics section for more information on interrupts.

Installation

This section describes how to install the Option 01.

Tools Required

Requirements and

Cautions

Option 01 VXI Interface Module User Manual

A Torxt T-10 driver set is required for proper installation.

The Option 01 daughter board is installed on a C-size VXIbus instrument module and therefore may be installed in any C- or D-size VXIbus mainframe slot other than slot 0. To install the module in a D-size mainframe, consult the operating manual for the mainframe. Refer to Configuration for information on

1–5

Getting Started

selecting and setting the Logical Address switch of the module. This switch defines the programming address of your module. To avoid confusion, it is recommended that the slot number and the logical address be the same.

NOTE. Verify that the mainframe is able to provide adequate cooling and power with this module installed. Refer to the mainframe Operating Manual for instructions.

If the installed Option 01 is used in a Tektronix mainframe, all Option 01 cooling requirements are met.

Installation Procedure

Follow these steps to install the Option 01.

CAUTION. The Option 01 daughter board is a piece of electronic equipment and therefore has some susceptibility to electrostatic damage (ESD). ESD precautions must be taken whenever the module is handled.

1. Record the revision levels, serial numbers (located on the label on the top

shield of the host module and on a sticker on the Option 01), and switch settings on the Installation Checklist.

2. Verify that the switches are set to the correct values. Refer to Configuration

for more information on setting switches.

3. Install the Option 01 on the SurePatht switching module (see Figure 1–3): a. Align the sockets on the Option 01 with the connectors on the switching

module.

b. Gently seat the Option 01 into the connectors. c. Use the screws provided to secure the Option 01 to the switching module

on the five standoffs.

1–6

Option 01 VXI Interface Module User Manual

Connectors

Option 01

Getting Started

Switching Module

Connectors

Figure 1–3: Mounting the Option 01

Option 01 VXI Interface Module User Manual

1–7

Getting Started

4. Make sure that the mainframe power is off.

5. Insert the module with the Option 01 installed into one of the instrument

slots of the mainframe (see Figure 1–4). Refer to the User Manual for the switching module for detailed installation instructions.

1–8

Figure 1–4: Module Installation

Option 01 VXI Interface Module User Manual

Installation Checklist

Getting Started

Installation parameters will vary depending on the mainframe being used. Be sure to consult the mainframe operating manual before installing and operating the module.

Revision Level: __________ Serial No.: __________ Mainframe Slot Number:__________ Switch Settings:__________

VXIbus Logical Address Switch:__________ Interrupt Level Select Switch:__________

Cable Installed (if any):__________

Performed by: _______________________ Date: _____________

Option 01 VXI Interface Module User Manual

1–9

Getting Started

Functional Check

The Option 01 VXI Interface Module executes a self test at power-on, on direction of a VXIbus hard or soft reset condition, or on command. The power-on self test consists of an interface self test and an instrument self test. The self test requested by command performs only the instrument self test. A VXIbus hard reset occurs when another device, such as the VXIbus Resource Manager, asserts the backplane line SYSRESET*. A VXIbus soft reset occurs when another device, such as the Option 01 commander, sets the Reset bit in the Option 01 Control register.

During power-on, or a hard or soft reset, the following actions take place:

1. The SYSFAIL* (VME system-failure) line is set active, indicating that the module is executing a self test, and the Failed LED is lighted. For a soft reset, SYSFAIL* is set. All Tektronix commanders will simultaneously set SYSFAIL INHIBIT to prevent the resource manager from prematurely reporting the failure of a card.

2. On completion of the interface self test, SYSFAIL* is un-asserted. If the test fails, the SYSFAIL* line remains active. If the interface self test passed, the SYSFAIL* line is released, and the module enters the VXIbus PASSED state (ready for normal operation). If it failed, the module enters the VXIbus FAILED state.

3. The instrument self test, as described in the *TST? command description is then executed. This tests the Option 01 VXI Interface daughter board and any relay modules under its control. If the self test fails, the module makes an internal record of the failure(s) that occur.

The default condition of the Option 01 Module after the completion of power-on self test is as follows:

All relays on modules controlled by the Option 01 (except VX4320 Modules) are set to the normally open position.

The VX4320 RF Multiplexer module contains eight 4-to-1 RF multiplexers. After a power-on self test is performed by the Option 01, it closes channel 1 of each section of each VX4320 that it controls.

You can run the self test at any time during normal operation by using the *TST? command. At the end of a self test initiated by this command, the module is restored to its pre-test state.

1–10

Option 01 VXI Interface Module User Manual

Getting Started

During a commanded self test:

1. SYSFAIL* is not asserted.

2. The module executes the same instrument self test as is executed upon power

on.

SYSFAIL* Operation

3. When the self test is completed,

restored to their pre-test state.

SYSFAIL* becomes active during power-on, hard or soft reset, or self test, or if the module loses 5 V power. When the mainframe Resource Manager detects SYSFAIL* set, it will attempt to inhibit the line. This causes the Option 01 VXI Interface Module to deactivate SYSFAIL* except when +5 V power is lost on the relay module on which it is installed.

the modules controlled by the Option 01 are

Option 01 VXI Interface Module User Manual

1–11

Operating Basics

Functional Overview

The Option 01 VXI Interface Module is a VXIbus message-based instrument and communicates using the VXIbus Word Serial Protocol. The module is programmed by issuing ASCII characters from the system controller to the Option 01 via the module VXIbus commander and the VXIbus mainframe backplane. Refer to the manual for the VXIbus device that will be the Option 01 daughter board’s commander for details on the operation of that device.

If the module commander is a Tektronix IEEE-488 Interface Module, refer to the operating manual for the module and Appendix B: Examples in this manual for information on how the system controller communicates with the commander being used.

The Option 01 VXI Interface Module is a printed circuit board that resides on a C-size VXI module belonging to the Tektronix “SurePath” family of relay modules. This family of relay modules includes the VX4320 RF Mux, VX4330 Scanner/Mux, VX4350 General Purpose Switch, and VX4380 Matrix modules. Commands conforming to the 1994 SCPI and IEEE-488.2 specifications are sent to the Option 01. The Option 01 parses these commands and controls the module on which it is installed and additional SurePath modules installed in contiguous slots to its right. VX4372 and VX4374 Scanner Slave modules can also be controlled by the Option 01.

Power-on

The instrument runs its self test and is ready for programming five seconds after power-on. The VXIbus Resource Manager can add an additional delay. The Power LED of each relay module controlled by the Option 01 will be on. The Failed LED on each of these modules will be off. The default condition of the module after power-on is listed in the *RST command description. Self-test failures are described in the *TST? command description.

The format and syntax for the command strings are described in the Command Syntax section. A complete description of each command in alphabetical order is in the Command Descriptions section.

Option 01 VXI Interface Module User Manual

2–1

Operating Basics

Instrument I/O: VXIbus Basics

NOTE. If the user’s mainframe has other manufacturers’ computer boards operating in the role of VXIbus foreign devices, the assertion of BERR* (as defined by the VXIbus Specification) may cause operating problems on these boards.

The Option 01 Module, when installed on a switching module, is a C-size single slot VXIbus Message-Based Word Serial instrument. It uses the A16, D16 VME interface available on the backplane P1 connector and does not require any A24 or A32 address space. The module is a D16 interrupter.

The Option 01 daughter board is neither a VXIbus commander nor a VMEbus master; therefore it does not have a VXIbus Signal register. The Option 01 is a VXIbus message-based servant.

The module supports the Normal Transfer Mode of the VXIbus using the Write Ready, Read Ready, Data In Ready (DIR), and Data Out Ready (DOR) bits of the module Response register.

A Normal Transfer Mode read of the Option 01 daughter board proceeds as follows:

1. The commander reads the Option 01 Response register and checks if the Write Ready and DOR bits are true. If they are, the commander proceeds to the next step. If not, the commander continues to poll these bits until they become true.

2. The commander writes the Byte Request command (hexadecimal 0DEFF) to the Data Low register of the Option 01.

3. The commander reads the Option 01 Response register and checks if the Read Ready and DOR bits are true. If they are, the commander proceeds to the next step. If not, the commander continues to poll these bits until they become true.

4. The commander reads the Option 01 Data Low register.

A Normal Transfer Mode write to the Option 01 daughter board proceeds as follows:

1. The commander reads the Option 01 Response register and checks if the Write Ready and DIR bits are true. If they are, the commander proceeds to the next step. If not, the commander continues to poll the Write Ready and DIR bits until they are true.

2–2

2. The commander writes the Byte Available command which contains the data (hexadecimal 0BCXX or 0BDXX, depending on the End bit) to the Data Low register of the Option 01.

Option 01 VXI Interface Module User Manual

Operating Basics

The module also supports the Fast Handshake Mode during readback. In this mode, the module is capable of transferring data at optimal backplane speed without needing the commander to test any of the handshake bits. The Option 01 daughter board asserts BERR* to switch from Fast Handshake Mode to Normal Transfer Mode, per VXI Specification. The Option 01 Read Ready, Write Ready, DIR and DOR bits react properly, in case the commander does not support the Fast Handshake Mode.

A Fast Handshake Transfer Mode read of the Option 01 daughter board proceeds as follows:

1. The commander writes the Byte Request command (hexadecimal 0DEFF) to

the Option 01 Data Low register.

2. The commander reads the Option 01 Data Low register. A Fast Handshake Transfer Mode write of the Option 01 daughter board

proceeds as follows:

The commander writes the Byte Available command which contains the data (hexadecimal 0BCXX or 0BDXX, depending on the End bit) to the Data Low register of the Option 01. The commander may immediately write another Byte Available command without having to check the Response register.

The module has no registers beyond those defined for VXIbus message based devices. All communications with the module are through the Data Low register, the Response register, or the VXIbus interrupt cycle. Any attempt by another module to read or write to any undefined location of the Option 01’s address space may cause incorrect operation of the module.

As with all VXIbus devices, the Option 01 daughter board has registers located within a 64 byte block in the A16 address space. The base address of the Option 01 device registers is determined by the device unique logical address and can be calculated as follows:

Base Address = V

* 4016 + C000

where V is the logical address of the device as set by the Logical Address switches.

Option 01 VXI Interface Module User Manual

2–3

Operating Basics

Configuration Registers

Table 2–1 contains a list of the Option 01 Configuration registers and a complete description of each register. The offset is relative to the module base address.

T able 2–1: Register Definitions

Address

ID Register 0000 RO 101 1 1111 1111 1101 (hexadecimal BFFD) Device Type 0002 RO See Device Type definition below Status 0004 R Defined by state of interface Control 0004 W Defined by state of interface Offset 0006 WO Not used Protocol 0008 RO 1111 0111 1111 1111 (hexadecimal F7FF) Response 000A RO Defined by state of the interface Data High 000C Not used Data Low 000E W Not fixed; command-dependent Data Low 000E R Not fixed; command-dependent

RO is Read Only WO is Write Only R is Read W is Write

(hexadecimal)

Type Value (Bits 15–0)

The Register Bit definitions are listed in Tables 2–2 and 2–3.

T able 2–2: Register Bit Definitions

ID hexadecimal BFFD Protocol hexadecimal F7FF

2–4

Option 01 VXI Interface Module User Manual

Operating Basics

The contents of the Device register of the Option 01 Module depends on the model number of the relay module that it is installed on, as shown in Table 2–3.

T able 2–3: Device Register Bit Definitions

Relay Model No. Device Register Contents

VX4320 hexadecimal FCBF VX4330 hexadecimal F6B5 VX4350 hexadecimal F6A1 VX4380 hexadecimal F683

Option 01 VXI Interface Module User Manual

2–5

Command Syntax

Command protocol and syntax for the Option 01 daughter board are as follows:

H A command string consists of a string of ASCII-encoded characters

H In addition to terminating a command, the semi-colon character directs the

terminated by a <program message terminator>. The <program message terminator> is optional white space, followed by any one of the following command terminations:

a line feed <LF> or new line <NL> character (hexadecimal 0A, decimal

10) the END bit set the END bit with a line feed <LF> or new line <NL>

The command string is buffered until the terminator is encountered, at which time the entire string is processed.

SCPI command parser to interpret the next command with the assumption that all characters up to and including the last colon in the previous command have just been parsed. In the following example, the Option 01 is installed on a VX4380 Module. Two additional VX4380 Modules are installed in consecutive slots to the right of the first VX4380. Under these conditions, the commands

 

 

 

cause all relays on all three VX4380 Modules to open. Note that each of these commands is terminated by a line feed. An equivalent method of sending these commands using the semi-colon character as a terminator is

     

After a line feed or END bit is used to terminate a command, the parser no longer makes the assumption described above. Thus, after the command

   

is parsed, the command

 

is no longer valid.

Option 01 VXI Interface Module User Manual

3–1

Command Syntax

In the next example, the Option 01 is installed on a VX4330 Module. Two additional VX4330 Modules are installed in consecutive slots to the right of the first VX4330. The commands

route:configure:join m1,(1:6)<LF>

route:configure:join m2,(1:2)<LF>

route:configure:join m3,(1:4)<LF>

connect the commons of sections 1 through 6 on the first VX4330, sections 1 and 2 on the second VX4330 and sections 1 through 4 on the third VX4330. An equivalent way to send these commands using the semi-colon as a terminator is

route:configure:join m1,(1:6); join m2,(1:2); join m3(1:4)<LF>

Note that <LF> in these examples represents a single line feed character.

H White space characters can be used to make a command string more

readable. These characters are ASCII-encoded bytes in the range hexadecimal 00–09 and 0B–20 (decimal 0–9 and 11–32). This range includes the ASCII control characters and the space, but excludes the line feed <NL>. White space characters are ignored when legally encountered in a command string. White space is allowed anywhere in a command string, except for the following:

Within a program mnemonic ( for example RO UTE ) Around a colon (:) mnemonic separator (for example ROUTE: CLOSE

or ROUTE :CLOSE) Between a mnemonic and a (?) (for example CLOSE ?) Following an asterisk (*) (for example * STB?) Within a number (for example 12 34) Within a module name specified in a [ROUTe:]MODule[:DEFine]

command (for example ROUTE:MODULE:DEFINE RFM UX, 1).

At least one white space character is required between a command/query header and its associated arguments. For example in the command

route:configure:join m1,(1:6)

the command header is the string “route:configure:join”. The arguments associated with this command are the module name “m1” and the section list “(1:6)”. At least one white space character must be sent before the first argument.

3–2

Option 01 VXI Interface Module User Manual

Command Syntax

In the query

route:close? (@m1(1:64))

the query header is the string “route:close?”. The argument associated with this query is the channel list “(@m1(1:64))”. At least one white space character must be sent before the channel list argument.

H All characters in a command can be sent in either upper or lower case form. H Multiple data parameters passed by a command are separated by a comma

(,).

H A question mark (?) following a command indicates that a response will be

returned. All responses from the module are terminated with a carriage return <CR> and a line feed <LF> (hexadecimal 0A) character.

H In the command descriptions, the following special characters are used.

Except for the colon (:), these characters are not part of the command and should not be sent. If an optional field is omitted, the default for the command is applied.

Syntax Example

[ ] Brackets indicate an optional field | A bar indicates a logical OR choice : A colon is used to separate command fields < > Field indicator

Capital letters indicate the minimum required characters which need to be sent. Lower case letters are optional. For example, the syntax of the trigger source command is given as

TRIGger[:SEQuence]:SOURce BUS | HOLD | IMMediate | TTLTrg<n>

Each of the following is a valid form of this command:

trigger:sequence:source bus

trig:seq:sour hold

Trig:SOUR IMM

Trig:Sour TTLTRG1

Trig:Sour TTLT1

Trigger:Source Immediate

Option 01 VXI Interface Module User Manual

3–3

Command Syntax

SCPI/IEEE 488.2

Command Elements

The definition of elements used in SCPI/IEEE 488.2 commands and command descriptions is as follows:

<NR1> ASCII integer representation of a decimal number.

<NRf> ASCII integer, fixed point or floating point representation of a decimal

number.

<module_name> A user-defined ASCII string to be associated with the local bus address of a relay module. <module_name> strings must start with a letter and may consist of alphanumeric characters, underscores, and digits. The maximum length of a <module_name> is 12 characters.

<channel_spec> One or more <NR1> ASCII strings separated by “!” characters that specify a relay on a relay module. The format of a <channel_spec> field for each of the SurePath relay modules is:

H VX4320 RF Multiplexer: <NR1> ! <NR1>

The range of the first <NRf> field is 1 to 4. This field specifies a relay within one of the sections of the VX4320. The range of the second <NRf> field is 1 to 8. This field specifies a section of the VX4320. A one-dimensional <channel_spec> may also be used to specify a channel on a VX4320 Module. The one-dimensional <channel_spec> is given by the formula:

( (section – 1 ) × 4 ) + relay.

where variables “section” and “relay” are section and relay numbers specified in a two-dimensional <channel_spec>.

H VX4330 Scanner/Multiplexer: <NR1> ! <NR1>

The first <NR1> field specifies a relay within the specified section. The range of this <NR1> field depends on the current configuration of the section of the VX4330 specified in the second <NR1> field. The range of the second <NR1> field is 1 to 6. This field specifies a section of the VX4330.

1 – 10 4-wire 1 – 20 4-wire independent 1 – 20 2-wire 1 – 40 1-wire

3–4

Option 01 VXI Interface Module User Manual

Command Syntax

H VX4350 General Purpose Switching module: <NR1>

The range of this field is 1 to 64. It specifies one of 64 relays on the VX4350.

H VX4380 Matrix: <NR1> ! <NR1> ! <NR1>

The range of the first <NR1> field is 1 to 4. It specifies the row of a relay in one of the sections of the VX4380. The range of the second <NR1> field is 1 to 16. It specifies the column of a relay in one of the sections of the VX4380. The range of the third <NR1> field is 1 to 4. It specifies a section of the VX4380. A one dimensional <channel_spec> may also be used to specify a channel on a VX4380 Module. The one dimensional <channel_spec> is given by the formula:

( (section – 1 ) × 64 ) + ( ( row – 1 ) × 16 ) + column

where variables “section” and “row” and “column” are section, row, and column numbers specified in a three-dimensional <channel_spec>.

<channel_list> A list of channel numbers on one or more relay modules. The limits on the channel numbers in a <channel_list> depend on the model

number of the relay module(s) specified in the <channel_list>. The syntax of a <channel_list> is shown in the following diagram:



 





  









 

A module_name is an ASCII string that has been associated with a relay module in a ROUTe:MODule:DEFine command. A channel_range may consist of a single <channel_spec> or a range of <channel_spec>s. A range of <channel_spec>s is indicated by two <channel_spec>s separated by a colon (:) character. A <channel_spec> may have one, two or three dimensions depending on the architecture of the relay module it applies to.

Option 01 VXI Interface Module User Manual

3–5

Command Syntax

The following are examples of valid <channel_list>s for Tektronix VX4320, VX4330, VX4350, VX4372, VX4374, and VX4380 relay modules. In these examples it is assumed that the Option 01 is installed on a VX4320 Module. A VX4330, VX4350, VX4372, VX4374, and VX4380 are installed in consecutive slots to the right of the VX4320. The default module names for the VX4320, VX4330, VX4350, VX4372, VX4374 and VX4380 in this example are m1, m2, m3, m4, m5, and m6 respectively. These module names may be overridden by specifying new module names with the [ROUTe:]MODule[DEFine] command. It is also assumed in these examples that all sections on the VX4330 Module have been configured as 10-to-1 4-wire scanners.

<channel_list> Channels Specified

 Channel number 1 of section 2 on the VX4320 Module.  Channel number 4 in section 1 and relay number 3 in section 8

of the VX4320 Module.

 Channel number 4 in sections 1 through 8 on the VX4320

Module.

 

 Channel 1 in section 6 of the VX4330 Module.  All channels on the VX4330 Module in the following order: 1!1,

 All 10 channels in section 3 of the VX4330.  All 64 channels on the VX4350

 

 Channel 1 in section 2 of the VX4372.  Channel 3 in section 1 of the VX4374.  The channel that connects row 1 to column 13 in section 3 of

 The channel that connects row 1 to column 1 in section 2 of

 Same as the previous example.  The channels that connect columns 1 through 16 to row 1 in

 Same as the previous example.

Channel number 4 in sections 1 through 8 on the VX4320 Module.

1!2, 1!3, 1!4, 1!5, 1!6, 2!1, 2!2, 2!3, 2!4, 2!5, 2!6, ... , 10!1, 10!2, 10!3, 10!4, 10!5, 10!6.

Channels 1, 2, 3, 10, 11, and 20 through 13 on the VX4350.

the VX4380.

section 1 of the VX4380.

3–6

 Channels 1!1!1, 1!1!2, 1!1!3, 1!1!4, 1!2!1, 1!2!2, 1!2!3, 1!2!4,

1!3!1, 1!3!2, 1!3!3, 1!3!4, 2!1!1, 2!1!2, 2!1!3, 2!1!4, 2!2!1, 2!2!2, 2!2!3, 2!2!4, 2!3!1, 2!3!2, 2!3!3, 2!3!4 on the VX4380 Module.

Option 01 VXI Interface Module User Manual

Command Syntax

As the <channel_list> syntax diagram shows, channels on more than one relay module may be specified in a <channel_list>. The next example specifies channels on three different relay modules.

<channel_list> Channels Specified

(@m1(1!1), m2(4!6), m6(3!13!2))

Channel 1 of section 1 on the VX4320, Channel 4 of section 6 of the VX4330, and the channel on the VX4380 that connects row 3 to column 13 in section 2.

As mentioned above, the module names used in <channel_list>s may be specified with a [ROUTe:]MODule[:DEFine] command. The command

route:module:Define rfmux, 1

changes the module name assigned to the VX4320 to “rfmux”. The following <channel_list> can then be used to specify channels on the VX4320.

(@rfmux(3!1,2!2))

specifies channel 3 in section 1 and channel 2 in section 2 of the VX4320. The order in which channels are specified is important in the [ROUTe:] CLOSE?

<channel_list> and [ROUTe:]OPEN? <channel_list> queries. The states of the channels are returned in the same order that the channels are specified in the <channel_list>.

The order in which channels are specified is also important in the [ROUTe:] SCAN <channel_list> command. This determines the order in which the relays will be closed each time a trigger event is detected.

The order in which channels are specified in a <channel_list> is important in the [ROUTe:]CLOSe <channel_list> command when channels in the same section of a VX4320 or a VX4330 are specified. A VX4320 can close only one channel in a section. If a [ROUTe:]CLOSE <channel_list> command specifies more than one relay in a section of a VX4320, the last channel in the <channel_list> will be closed.

For example, the command

close (@m2(1!1,2!1))

will close channel 2 of section 1 of the VX4320. A VX4330 can close only one channel in a group of joined sections that have

been specified in a [ROUTe:]CLOSe:MODe SCAN,<module_name>,<section_list> command. If more than one channel in such a group of sections is

Option 01 VXI Interface Module User Manual

3–7

Command Syntax

specified in a [ROUTe:]CLOSe <channel_list> command, the last channel specified will be closed. For example, the commands

route:configure:join m2,(1:6)

route:close:mode scan,m2,(1:6)

join the commons of all six sections of the VX4330 Module and set the mode of the [ROUTe]:CLOSE <channel_list> to scan mode for all six sections of the VX4330.

The command

route:close (@m2(1!1,1!6))

will then result in channel 1 of section 6 being closed and all other channels on the module being opened.

output queue The Output queue of the Option 01 VXI Interface is used to return replies to queries received by the interface. Bit 4 (the MAV bit) of the Status Byte register is set to indicate that this queue is not empty. The DOR bit in the VXI Response register is also set to indicate that this queue is not empty. The commander of the Option 01 VXI Interface monitors the DOR bit to determine when it may read a message from the Output queue.

<section_list> One or more <nr1> fields separated by comma (,) or colon (:) characters and enclosed in left and right parentheses. A <section_list> is used to specify the sections of a relay module to be acted upon by a [ROUTe:]CONFigure or [ROUTe:]CLOSe:MODE command. The following are examples of valid <section_list>s.

For commands directed to a VX4330 which has six scanner sections:

<section_list> Sections Specified

(1:6) Sections 1 through 6 (1,2,3) Sections 1, 2 and 3 (1:3,5:6) Sections 1 through 3 and 5 and 6 (1:3,5,6) Same as previous example (3) Section 3

3–8

Option 01 VXI Interface Module User Manual

Command Syntax

For commands directed to a VX4372 or VX4374 which has two scanner sections:

<section_list> Sections Specified

 Section 1 (1,2) Sections 1 and 2 (1:2) Sections 1 and 2

error/event queue When the command parser detects a syntax error or data range error, it places an error message describing the error in the Error/Event queue. Bit 2 of the Status Byte Register is set to indicate that this queue is not empty. Bit 5 of the Standard Event Status Register (the Command Error bit) is set if the parser detects a syntax error. Bit 4 of the Standard Event Status register (the Execution Error bit) is set if the parser detects a numeric argument that is out of range. When a SYSTem:ERRor? query is received, an error message is dequeued from the Error/Event queue and placed in the Output queue.

Option 01 VXI Interface Module User Manual

3–9

Functional Command Groups

This section lists the Option 01 system and module commands.

System Commands

The following low-level commands are typically sent by the module’s commander, and are transparent to the user of the module. (An exception is the Read STB command, which is sent whenever a Serial Poll on an IEEE-488 system is performed.) Most commanders or Slot 0 devices have specific ASCII commands that cause the commander to send one of these low-level commands to a specified instrument. Refer to the operating manual of the commander or Slot 0 device for information on these commands.

Command Effect

Begin Normal Operation The module begins operation if it has not already done so. Byte Available Transfers module commands to this module. Byte Request Requests the module to return a byte of data from the output

queue.

Module Commands

Clear The module clears its VXIbus interface and any pending

commands. Current module operations are unaffected. Clear Lock Clears the Lock bit of the Response register. Read Protocol The module returns its protocol to its commander. Read STB The module returns its VXI status byte to its commander. Set Lock Set the Lock bit of the Response register. Trigger Close the next relay in a scan list that has been defined by a

ROUTe:SCAN <channel_list> command. A VXI Trigger

command is enabled as a trigger source by a ROUTe:SE-

Quence:SOURce BUS command.

A summary of the Option 01-specific and IEEE-488.2 Common Commands is listed in Tables 3–1 and 3–2 below. The next section, Command Descriptions, includes detailed descriptions of each command. Appendix B: Examples shows examples of command usage.

Option 01 VXI Interface Module User Manual

3–11

Syntax and Commands

T able 3–1: Summary of Option 01-Specific SCPI Commands

Subsystem Command Functions Controlled

ABORt Place initiated scan in the idle state CLOSe Close specified relays; DWELl CONFigure Configuration: DISJoin, JOIN ID? Return model numbers of modules controlled by the Option 01 INITiate Place trigger subsystem in armed state: IMMediate,

CONTinuous MODule Module name functions: DEFine, CATalog?, DELete MODE VX4330 only; set mode to scan or mux OPEN Open specified relays: ALL, DWELl OUTPut Enable or disable selected VXI TTL trigger PFAil Specify state of latching relays on powerfail SCAN Define a list of relay closures to scan through ST ATus Status register functions: OPERation, QUESstionable SYSTem System-level functions: ERRor?, PRESet, VERSion? TRIGger Scan list functions: COUNt, DELay, IMMediate, SOURce

T able 3–2: Summary of IEEE-488.2 Common Commands

Command/Syntax Description

Clear Status *CLS

Standard Event Status Enable *ESE <NRf>

Standard Event Status Enable Query *ESE?

Standard Event Status Register Query *ESR?

Identification Query *IDN?

Operation Complete *OPC

Operation Complete Query *OPC?

Clears the SCPI and IEEE 488.2 event registers and the SCPI error/event queue, and the output queue.

Sets the contents of the Standard Event Status Enable register.

Returns the current value of the Standard Event Status Enable register in <nr1> format.

Returns the current value of the Standard Event Status register in <nr1> format, then set the contents of this register to 0.

Returns an ASCII string in the output queue which identifies the board.

Sets bit 0 (the Operation Complete bit) of the Standard Event Status register when all pending device operations have been completed.

Places the ASCII character 1 in the output queue when all pending device operations have been completed.

3–12

Option 01 VXI Interface Module User Manual

Syntax and Commands

T able 3–2: Summary of IEEE-488.2 Common Commands (Cont.)

Command/Syntax Description

Reset* *RST

The Option 01 VXI interface is placed in its power-up state with some exceptions.

Service Request Enable *SRE <NRf>

Service Request Enable Query *SRE?

Read Status Byte Query *STB?

Trigger *TRG

Self-Test Query *TST?

Wait-to-Continue *WAI

Sets the contents of the Service Request Enable register.

Returns the current value of the Service Request Enable register in <nr1> format.

Returns the current value of the Status Byte register in <nr1> format.

Equivalent to a VXI Trigger command.

Performs a self test of the Option 01 VXI Interface daughter board and any relay modules under its control. Place a “0” or “1” into the output queue to indicate whether the self test passed or failed.

Does not execute any further commands or queries until all pending operations have been completed.

Option 01 VXI Interface Module User Manual

3–13

Command Descriptions

This section lists the Option 01-specific SCPI commands and queries in alphabetic order. The IEEE-488.2 Common Commands are listed in the next section. A summary listing of the SCPI command set for the Option 01 is as follows:

ABORt [ROUTe:]CLOSe <channel_list>

[ROUTe:]CLOSe:DWELl <module_name>,<nrf> [ROUT e:]CLOSe:MODE <mode>,<module_name>,<section_list>

[ROUTe:]CONFigure <configuration>,<module_name>,<section_list> [ROUTe:]CONFigure:DISJoin <module_name> [ROUTe:]CONFigure:JOIN <module_name>,<section_list>

[ROUTe:]ID? INITiate:CONT inuous

INITiate[:IMMediate] [ROUTe:]MODule[:DEFine] <module_name>,<nrf>

[ROUTe:]MODule:CATalog? [ROUTe:]MODule:DELete[:NAME] <module_name> [ROUTe:]MODule:DELete:ALL

[ROUTe:]OPEN <channel_list> [ROUTe:]OPEN:ALL [module_name] [ROUTe:]OPEN:DWELl <module_name>,<nrf>

OUTPut:TTLTrg<n>[:STATe] ON | OFF | <nrf> [ROUTe:]PFAil <action_at_powerfail> [ROUTe:]SCAN <channel_list> STATus:OPERation:CONDition?

STATus:OPERation:ENABle STATus:OPERation[:EVENt?] STATus:QUEStionable:CONDition? STATus:QUEStionable:ENABle STATus:QUEStionable[:EVENt?]

SYSTem:ERRor? SYSTem:PRESet SYSTem:VERSion?

Option 01 VXI Interface Module User Manual

3–15

Command Descriptions

TRIGger[:SEQuence]:COUNt TRIGger[:SEQuence]:DELay TRIGger[:SEQuence][:IMMediate] TRIGger[:SEQuence]:SOURce BUS | HOLD | IMMediate | TTLTrg<n>

3–16

Option 01 VXI Interface Module User Manual

ABORt

Command Descriptions

Command Syntax

Query Syntax

*RST Value

Limits

Related Commands

Description

Examples

ABORt

N/A

ROUTe:SCAN INITiate[:IMMediate] TRIGger[:SEQuence]:SOURce TRIGger[:SEQuence]:IMMediate TRIGger[:SEQuence]:COUNt TRIGger[:SEQuence]:DELay

This command places an initiated scan sequence in the idle state.

The following example defines a scan sequence of 10 relays. The sequence is aborted after the third relay in the sequence is closed. In this example, module names m1 and m2 refer to VX4380 Modules. After a scan sequence is aborted, triggers are no longer accepted by the Option 01 until another INITiate [:IMMediate] command is received.

Command Response

route:scan (@m1(1:5),m2(60:64))

trigger:sequence: source hold

initiate:immediate Initiate the scan sequence. trig Close the first relay in the sequence. trig Open the first relay and close the second relay in the

Option 01 VXI Interface Module User Manual

Define a scan sequence.

This command disables the following trigger sources: VXI TTL triggers, VXI Trigger commands, *TRG command, Immediate triggers. The TRIGger[:SEQuence][:IMMediate] command, however, overrides this command. It triggers the module and skips the delay specified in a previously issued TRIGger [:SEQuence]:DELay command.

sequence.

3–17

Command Descriptions

Command Response

 Open the second relay and close the third relay in the se-

quence.  Abort the scan sequence.

3–18

Option 01 VXI Interface Module User Manual

CLOSe

Command Descriptions

Command Syntax

Query Syntax

Query Response

*RST Value

Limits

"#

"#

Indicates which relays are closed.

All relays on all modules are set to the open position.

The limits on the relay numbers in the <channel_list> portion of this command depend on the model number of the relay module(s) specified in the <channel_list>. The syntax of a <channel_list> is described by the following diagram:

!

 



"#







  

A module_name is an ASCII string that has been associated with a relay module in a ROUTe:MODule:DEFine command. A channel_range may consist of a single relay number or a range of relay numbers. A range of relay numbers is indicated by two relay numbers separated by a “:” character.

A relay number may have one, two, or three dimensions depending on the architecture of the relay module containing the relay. For example, the VX4350 contains 64 SPDT relays. Only one-dimensional relay numbers are supported for this module. The VX4380 Module contains four 4×16 2-wire matrices. Threedimensional channel numbers are supported for this module. The first specifies the row, the second specifies the column, and the third specifies the matrix containing the relay. Multi-dimensional relay numbers are represented by integers separated by “!” characters. See the user manuals for the VX4320,

Option 01 VXI Interface Module User Manual



!

  $

3–19

Command Descriptions

VX4330, VX4350, and VX4380 for more information on the format of relay numbers for these modules.

Related Commands

Description

Examples

[ROUTe:]OPEN <channel_list> [ROUTe:]MODule:DEFine OUTPut:TTLTrg<n>[:STATe]

This command closes the relays specified in the <channel_list> portion of this command.

In these examples the Option 01 is installed on a VX4350 Module. A VX4380 and VX4320 are installed in consecutive slots to the right of the slot containing the VX4350. The default module names for the VX4350, VX4380 and VX4320 in this configuration are m1, m2, and m3 respectively. These module names may be altered with the [ROUTe:]MODule:DEFine command.

Command Response

route:close (@m3(4!8)) Close relay 4 in section 8 of the VX4320 RF Mux Module.

route:close (@m1(1,2,3,10:64))

route:close (@m2(3!16!4))

route:close (@m3(2!1:2!8))

Close relays 1,2,3 and 10 through 64 on the VX4350 General

Purpose Switch Module.

Close row 3, column 16 of section 4 of the VX4380 Matrix

Module.

Close relay 2 in sections 1 through 8 on the VX4320 RF Mux

Module.

3–20

route:close (@m3(4!8),m2(3!16!4))

route:module:define rfmux,3 route:close (@rfmux(3!2))

route:close (@m2(1!1!1,4!6!2))

route:close? (@m1(1,2,3,4))

route:close? (@rfmux(3!2))

Combined effect of examples 1 and 3.

Close channel 3 of section 2 on the VX4320 Module after

redefining its module name to “rfmux”.

Close the following relays on the VX4380 Matrix Module:

Row Column Section

111

462

1 1 0 0

This response indicates that relays 1 and 2 on the VX4350 are

closed and relays 3 and 4 on this module are open.

This response indicates that channel 3 of section 2 of the

VX4320 is closed. Note that a route:module:define rfmux,3

command has been received prior to this query.

Option 01 VXI Interface Module User Manual

Command Descriptions

Command Syntax

Query Syntax

*RST Value

Limits

Related Commands

Description

Examples

[ROUTe:]CLOSe

:DWELl<module_name>,<nrf>

N/A

The close dwell time of all modules is set to 0 seconds.

The value of the time specified in this command must be between 0 and 6.5535 seconds.

[ROUTE:]CLOSe [ROUTe:]SCAN OUTPut:TTLTrg<n>[:STATE]

Set the time to wait after closing a relay before proceeding and pulsing any enabled VXI TTL trigger signals.

In this example the Option 01 is installed on a VX4330 Module.

Command Response

output:ttltrg1:state on

route:close:dwell m1,.25

route:open:dwell m1,0.5

route:close (@m1(1!3:10!3))

route:scan (@m1(1!6:20!6))

trigger:Sequence: source ttltrg2

trigger:sequence: delay 1

initiate:immediate Initiate the scan sequence.

Enable VXI TTL trigger 1.

Set the close dwell time for the VX4330 to 0.25 seconds.

Set the open dwell time for the VX4330 to 0.5 seconds.

Close relays 1 through 10 in section 3 of the VX4330, wait 0.25 seconds, then pulse VXI TTL trigger 1.

Define a scan list consisting of relays 1 through 20 in section 6 of the VX4330.

Define VXI TTL trigger 2 as the trigger source for the defined scan list.

Set the trigger delay time to 1 second.

Option 01 VXI Interface Module User Manual

3–21

Command Descriptions

After this sequence, each time the VXI TTL trigger 2 is pulsed low, the following sequence of events occurs:

1. One second delay. This is the delay specified in the trigger:Sequence:delay

command.

2. The current relay in the scan list is opened.

3. 0.5 second delay. This is the delay specified in the route:open:dwell

command.

4. Close the next relay in the scan list.

5. 0.25 second delay. This is the delay specified in the route:close:dwell

command.

6. Pulse VXI TTL trigger 1 low for 3 sec.

Command Syntax

Query Syntax

*RST Value

Limits

Related Commands

Description

[ROUTe:]CLOSe:MODE <mode>,<module_name>,<section_list>

N/A

All sections of all VX4330 Modules are set to operate in the mux mode. In this mode one or more channels in a section may be closed at the same time.

This command applies only to the VX4330 Module. The section numbers in the <section_list> argument must be between 1 and 6.

[ROUTe:]CONFigure:JOIN [ROUTe:]CONFigure:DISJoin [ROUTE:]CONFigure

This command is supported only for VX4330 Modules. It sets the mode of operation of sections on a VX4330 to scan or mux. When this command is received, all relays in the sections specified in the <section_list> argument are opened. In the mux mode, one or more relays in a section may be closed at the same time. When a relay is closed in a section that has been set to scan mode, all relays in that section are opened before the relay is closed. If several sections are set to operate in scan mode and the commons of these sections are joined (see the [ROUTe:]CONFigure:JOIN command) then when a relay is closed in any of the sections, all relays in all of the sections are opened first.

3–22

Option 01 VXI Interface Module User Manual

Command Descriptions

Close the first 1

elays in section one of the first VX433



Examples

In these examples the Option 01 is installed on a VX4330 Module. Two additional VX4330 Modules are installed in consecutive slots to the right of this module.

Command Response

  

 

  

Set all six sections of the first VX4330 to mux mode.

Configure all six sections of the first VX4330 to 20-to-1 2-wire scanner/mux.

0 r

Set sections 1 through 3 on the third VX4330 to scan mode.

Option 01 VXI Interface Module User Manual

3–23

Command Descriptions

CONFigure

Command Syntax

Query Syntax

*RST Value

Limits

Related Commands

Description

[ROUTe:]CONFigure <configuration>,<module_name>,<section_list>

N/A

This command is valid only for VX4330 Scanner Modules. The section numbers specified in the <section_list> portion of this command must be between 1 and 6 for this command.

[ROUTe:]CLOSe [ROUTe:]CLOSe:MODE [ROUTe:]OPEN

Each section of a VX4330 Module may be configured as a 40-to-1 1-wire scanner, or as a 20-to-1 2-wire scanner/mux, or as a 10-to-1 4-wire scanner/mux. Also, each section may be configured as a 10-to-1 4-wire scanner with independent control of the upper and lower halves of the 4-wire common. The <configuration> portion of this command indicates which of these configurations is selected according to the following table.

3–24

<configuration> Configuration

OWIRE 40-to-1 1-wire scanner TWIRE 20-to-1 2-wire scanner/mux FWIRE 10-to-1 4-wire scanner/mux FWIRI 10-to-1 4-wire scanner/mux with independent control of the

upper and lower halves of the 4-wire common.

The <module_name> argument of the command indicates which module the command is directed to. The specified <module_name> is associated with a relay module with a [ROUTe:]MODule:DEFine command.

The <section_list> argument indicates which sections of the selected module are to be configured. All relays in the section(s) specified in this list are opened when the [ROUTe:]CONFigure command is received.

Option 01 VXI Interface Module User Manual

Command Descriptions

Examples

In these examples the Option 01 is installed on a VX4330 Module. Two additional VX4330 Modules are installed in consecutive slots to the right of this module.

Command Response

route:configure fwire,m1,(1:6)

route:mode scan,m1,(1:3)

route:mode mux,m1,(4:6)

rout:conf owire,m3,(1) Configure section 1 of the third VX4330 as a 40-to-1 1-wire

rout:conf twire,m2,(2,3)

route:configure fwiri,m3,(1:6)

route:close (@m3(1!1)) Connect the lower half of channel 1, section 1, to the lower half

Configure all six sections of the first VX4330 as 10-to-1 4-wire scanners.

Set the mode of operation of sections 1, 2, and 3 of the first VX4330 to scan. In this mode, only one channel in a section is closed at a time.

Set the mode of operation of sections 4, 5 and 6 of the first VX4330 to mux. In this mode one or more channels in a section may be closed at the same time.

scanner. Configure sections 2 and 3 of the second VX4330 as 20-to-1

2-wire scanners. Configure all six sections of the third VX4330 as 10-to-1 4-wire

scanners with independent control of upper and lower commons.

of the 4-wire common. In this example, section 1 is assumed to be configured as a 10-to-1 4-wire scanner with independent control of the upper and lower halves of the 4-wire common.

route:close (@m3(20!1))

Connect the upper half of the 10th channel of section 1 to the upper half of the 4-wire common. In this example, section 1 is assumed to be configured as a 10-to-1 4-wire scanner with independent control of the upper and lower halves of the 4-wire common.

Note that in OWIRE configuration, unintended connections can be made between the inputs that are paired with the selected MUX inputs. When selecting even numbered relays for multiplexing, contact pairs for odd number relays are also connected together.

In OWIRE configuration, the inputs are switched in pairs onto the two–wire bus of the relay section. Input 1 (relay 1a_Lo) and input 2 (relay 1a_Hi) will be switched at the same time, input 3 (relay 1b_Lo) and input 4 (relay 1b_Hi) will be switched at the same time, etc. The odd numbered inputs connect to the two–wire Lo bus and the even numbered inputs connect to the two–wire Hi bus.

The Scanner/MUX one–wire output is switched to either the odd relay (Lo) or even relay (Hi) bus according to the last one–wire channel closed in the given section, or any section to which it is joined.

Option 01 VXI Interface Module User Manual

3–25

Command Descriptions

Scan mode: any one of the inputs can be individually connected to the one-wire output without any concern.

Mux mode: any group of even inputs or any group of odd inputs can be connected to the one-wire output at the same time.

OWIRE configuration: each section of the VX4330 is a 1×20 Hi wire MUX and a 1×20 Lo wire MUX, with switching between Hi and Low performed automatically.

The VX4330 can not function as a 1×40 MUX.

Examples

In these examples the Option 01 is installed on a VX4330 Module.

Command Response

route:configure:join m1, (5:6) Connect the 4 commons of sections 5 and 6 on the VX4330.

This joins the following pins:

Com_5a_Lo to Com_6a_Lo

Com_5a_Hi to Com_6a_Hi

Com_5b_Lo to Com_6b_Lo

Com_5b_Hi to Com_6b_Hi route:configure: owire,m1,

(5:6)

route:mode mux,m1, (5:6) Set the mode of operation of sections 5 and 6 of the VX4330 to

route:close (@m1 (1:5)) The In_01_Lo pin of section 5 (1:5) is connected to the Lo

route:close (@m1 (4:6)) Note the unexpected result here because we attempted to

Configure sections 5 and 6 of the VX4330 as 40-to-1 1-wire

scanners. This closes the 2-wire relays in sections 5 and 6

joining all of the Com_xx_Lo pins together into one Lo group,

and all of the Com_xx_Hi pins into one Hi group.

mux.

(odd) group. The inadvertent connection of In_02_Hi is made to

the Hi (even) group.

connect both even and odd inputs. The 1Wire_5a and

1Wire_6a pins are now connected to the Hi (even) group to

connect (4:6). But (2:5) is now connected instead of the

original (1:5).

3–26

Command Syntax

Query Syntax

*RST Value

[ROUTe:]CONFigure

:DISJoin <module_name>

N/A

All sections on all scanner modules are disjoined.

Option 01 VXI Interface Module User Manual

Command Descriptions

Limits

Related Commands

Description

Examples

Command Syntax

N/A

[ROUTe:]CONFigure:JOIN [ROUTE:]CONFigure [ROUTe:]CLOSe:MODE

Disconnect the commons of all sections of a scanner module. This command is supported for VX4330, VX4372, and VX4374 Modules.

In these examples the Option 01 is installed on a VX4330 Module. Two additional VX4330 Modules are installed in consecutive slots to the right of this module. A VX4374 is installed in the slot to the right of the third VX4330.

Command Response

#"#  ! 

#"!  Disconnect the commons of the two sections of the VX4374.

# 

Disconnect the commons of the first VX4330.

Query Syntax

*RST Value

Limits

Related Commands

Description

 #!"!"

N/A

All sections on all scanner modules are disjoined.

This command is supported for VX4330, VX4374, and VX4372 Modules. The section numbers specified in the <section_list> argument must be between 1 and 6 for VX4330 modules. Section numbers 1 and 2 are valid for VX4374 and VX4372 Modules.

[ROUTe:]CONFigure:DISJoin, [ROUTE:]CONFigure, [ROUTe:]MODE

This command connects the commons of adjacent sections on scanner modules. On VX4330 modules, if a section that is configured as a 4-wire scanner is joined to a section that is configured as a 1-wire or 2-wire scanner, only the lower half of the 4-wire scan common is connected. If a 4-wire section is joined to another 4-wire section, both halves of the 4-wire scan common are joined. Also for the

Option 01 VXI Interface Module User Manual

3–27

Command Descriptions

VX4330, if two or more sections that are set to scan mode are joined, then when a [ROUTe:]CLOSe command closes a relay in one of these sections, all relays in the sections are opened before the specified relay is closed.

Examples

Command Response

route:configure:join m1,(1:3)

rout:conf:join m4,(1:2)

route:close:mode scan,m2,(1:4)

route:conf twire,m2,(1:4)

route:conf:join m2,(1:4)

route:close (@m2(10!1))

Connect the commons of sections 1, 2, and 3 on the first

VX4330.

Connect the commons of the two sections of the VX4374.

Set the mode of operation of sections 1 through 4 on the

second VX4330 to scan mode. In this mode, only one relay is a

section is closed at a time.

Configure sections 1 through 4 on the second VX4330 as

20-to-1 2-wire scanners.

Connect the commons of sections 1 through 4 on the second

VX4330. Since these sections have been set to operate in the

scan mode, and have been configured as 20-to-1 2-wire

scanners, these sections now comprise a single 80-to-1 2-wire

scanner.

Close channel 10 of section 1 of the second VX4330.

3–28

route:close (@m2(2!4)) Close channel 2 of section 4 of the second VX4330. Since the

first four sections of this module are joined and are set to

operate in the scan mode, all relays in sections 1 through 4 of

this module are opened before this relay is closed.

Option 01 VXI Interface Module User Manual

ID?

Command Descriptions

Command Syntax

*RST Value

Limits

Related Commands

Description

Examples

[ROUTe:]ID?

N/A

[ROUTe:]MODule:CATalog?

This query returns a list of the model numbers of the modules controlled by the Option 01. The first model number returned is that of the module that the Option 01 is installed on. Subsequent model numbers are those of modules in consecutive slots to the right of the first module.

In these examples the Option 01 is installed on a VX4350 Module. A VX4380, VX4330, and VX4320 are installed in consecutive slots to the right of the slot containing the VX4350. The default module names for the VX4350, VX4380, VX4330 and VX4320 in this configuration are m1, m2, m3, and m4 respectively. These module names may be altered with the [ROUTe:]MODule:DEFine command.

Command Response

route:id? VX4350, VX4380, VX4330, VX4320 route:module:Catalog? “M1”, “M2”, “M3”, “M4” route:close (@m1(1)) Close relay number 1 on the VX4350. route:open:all m2 Open all relays on the VX4380. route:close (@m3(1!6)) Close relay number 1 in section 6 of the VX4330

route:close (@m4(3!1:3!8))

Close relay number 3 in all eight sections of the VX4320.

Option 01 VXI Interface Module User Manual

3–29

Command Descriptions

INITiate

Command Syntax

Query Syntax

Query Response

*RST Value

Related Commands

Description

INITiate

[:IMMediate]

N/A

The trigger subsystem is in the idle state.

ABORt ROUTe:SCAN TRIGger[:SEQuence][:SOURce] TRIGger[:SEQuence][:IMMediate] TRIGger[:SEQuence][:COUNt] TRIGger[:SEQuence][:DELay]

This command places the trigger subsystem in the armed state. In this state, a trigger event enabled by the TRIGger[:SEQuence]:SOURce command closes the next relay in a scan sequence, after opening the previous relay in the sequence. After a sufficient number of triggers have been received to cycle through a scan list the number of times specified in a TRIGger:[SEQuence] :COUNt command, the trigger subsystem is placed in the idle state. In this state, triggers are ignored.

3–30

Examples

Command Response

route:scan (@m1(1,2),m2(60))

trigger:sequence:count 1

trigger:sequence: source hold

initiate:immediate Initiate the scan sequence. trig Close the first relay in the sequence.

Define a scan sequence consisting of relays 1 and 2 on relay

module m1 and relay 60 on module m2.

Define the number of times to sequence through the scan list

before setting the state of the trigger subsystem back to the

idle state.

This command disables the following trigger sources: VXI TTL

triggers, VXI Trigger commands, *TRG command, and

Immediate triggers. The TRIGger[:SEQuence][:IMMediate]

command, however , overrides this command. It triggers the

module and skips the delay specified in a previously issued

TRIGger[:SEQuence]:DELay command.

Option 01 VXI Interface Module User Manual

Command Descriptions

Command Response

trig Open the first relay and close the second relay in the

sequence.

trig Open the second relay and close the third relay in the

sequence.

trig Open the third relay in the sequence. Place the trigger

subsystem in the idle state.

Command Syntax

Query Syntax

Query Response

*RST Value

Related Commands

Description

INITiate

:CONTinuous

N/A

The trigger subsystem is placed in the IDLE state.

ABORt [ROUTe:]SCAN TRIGger[:SEQuence]:SOURce TRIGger[:SEQuence]:IMMediate TRIGger[:SEQuence]:DELay

If a scan list has been defined by a [ROUTe:]SCAN command, this command places the trigger subsystem in the armed state. In this state, a trigger event enabled by the TRIGger[:SEQuence]:SOURce command opens the currently closed channel in a scan list and closes the next channel in the list. Triggers continue to be recognized until an ABORt command is received, which returns the trigger subsystem to the IDLE state.

Examples

In this example, it is assumed that the Option 01 daughter board is installed on a VX4330 Module and that the default module name “m1” is in effect.

Command Response

conf twire,m1,(1) Set the configure section 1 of the VX4330 to 20-to-1 twire. scan (@m1(1!1:20!1)) Define a scan list consisting of channels 1 through 20 in

trigger:Sequence:count 2

Option 01 VXI Interface Module User Manual

section on of the VX4330 Module. Set the number of times to sequence through a scan list (when

an INITiate[:IMMediate] command is received) to 2.

3–31

Command Descriptions

Command Response

trigger:sequence: source hold

initiate:continuous Place the trigger subsystem in the arm state. trigger:seq:imm Override the hold placed on triggers. Close channel 1 in

trigger:seq:imm Override the hold placed on triggers. Open channel 1 in section

trigger:seq:sour imm Remove the hold placed on triggers. Set the trigger source to

ABOR Return the trigger subsystem to the idle state. Open the

initiate:immediate Place the trigger subsystem in the arm state, sequence through

Disable all trigger sources.

section 1 of the VX4330.

1, then close channel 2 in section 1 of the VX4330.

immediate. This causes the sequencing of the scan list

indefinitely or until an ABORt command is received.

currently closed relay in the scan list.

the scan list twice, then return the trigger subsystem to the idle

state.

3–32

Option 01 VXI Interface Module User Manual

MODule

Command Descriptions

Command Syntax

Query Syntax

Query Response

*RST Value

Limits

[ROUTe:]MODule

[:DEFine] <module_name>,<nrf>

[ROUTe:]MODule

[:DEFine]? <module_name>

See examples.

Default module names are assigned as follows: The module that has a Option 01 VXI Interface daughter board installed is

assigned module name “M1”. Modules without the Option 01 VXI Interface daughter board in consecutive

slots to the right of module “M1” are assigned module names “M2”, “M3”, ..., “M11”.

A module name may consist of up to 12 characters. The name must start with a letter and may consist of alphanumeric characters, underscores, and digits.

Related Commands

Description

Examples

[ROUTe]:MODule:DELete[:NAME] [ROUTe]:MODule:DELete:ALL [ROUTe:]MODule:CATalog?

This command assigns a module name to a relay switching module. This name is used to identify the module in channel lists in [ROUTe:]OPEN, [ROUTe:]CLOSe, and [ROUTe:]SCAN commands.

In these examples the Option 01 is installed on a VX4350 Module. A VX4380 and VX4330 are installed in consecutive slots to the right of the slot containing the VX4350.

Command Response

route:module:define gp_switch,1

route:close (@gp_switch(1:64))

Assign module name “gp_switch” to the VX4350.

Close all 64 relays on the VX4350.

Option 01 VXI Interface Module User Manual

3–33

Command Descriptions

Command Response

route:module:define matrix,2

Assign module name “matrix” to the VX4380.

Command Syntax

*RST Value

Limits

Related Commands

Description

route:close (@matrix (4!16!3))

route:module:define? gp_switch

Close the relay at row 4 column 16 in section 3 of the VX4380.

[ROUTe:]MODule

:CATalog?

N/A

[ROUTe]:MODule:DEFine[:NAME] [ROUTe]:MODule:DELete[:NAME], [ROUTe]:MODule:DELete:ALL

This command returns a list of defined module names.

Examples

In these examples the Option 01 is installed on a VX4350 Module. A VX4380 and VX4330 are installed in consecutive slots to the right of the slot containing the VX4350.

Command Response

route:module:catalog? “M1”, “M2”, “M3”

route:module:define matrix_1,2

route:module:catalog? “M1”, “MATRIX_1”, “M3”

route:module:define? matrix_1

route:module:delete matrix_1

route:module:catalog? “M1”, “M3”

Assign module name “matrix_1” to the VX4380.

Delete module name “matrix_1”

3–34

Option 01 VXI Interface Module User Manual

Command Descriptions

Command Syntax

Query Syntax

*RST Value

Limits

Related Commands

Description

[ROUTe:]MODule

:DELete

[:NAME] <module_name>

N/A

[ROUTe]:MODule:DEFine[:NAME] [ROUTe]:MODule:CATalog? [ROUTe:]MODule:DELete[:ALL]

This command deletes a module name definition. After this command is executed, the specified module name is no longer associated with a relay module.

Examples

Command Syntax

Query Syntax

*RST Value

Limits

Command Response

route:module:catalog? “M1”, “M2”, “M3” route:module:delete m1 Delete module name “M1” route:module:catalog? “M2”, “M3”

[ROUTe:]MODule

:DELete

:ALL

N/A

Option 01 VXI Interface Module User Manual

3–35

Command Descriptions

Related Commands

Description

Examples

[ROUTe]:MODule:DEFine[:NAME] [ROUTe]:MODule:CATalog? [ROUTe:]MODule:DELete[:NAME]

This command will delete all module name definitions.

Command Response

 “M1”, “M2”, “M3”

 

 “ ”

Delete all module names

3–36

Option 01 VXI Interface Module User Manual

OPEN

Command Descriptions

Command Syntax

Query Syntax

Query Response

*RST Value

Limits

[ROUTe:]OPEN <channel_list>

[ROUTe:]OPEN? <channel_list>

See examples.

All relays on all modules are set to the open position.

<channel_range>

! :

<NR1>

<channel_list>

<NR1>

( @ (

A relay number may have one, two, or three dimensions depending on the architecture of the relay module containing the relay. For example, the VX4350 contains 64 SPDT relays. Only one-dimensional relay numbers are supported for this module. The VX4380 Module contains four 4 × 16 2-wire matrices. Three-dimensional channel numbers are supported for this module. The first specifies the row, the second specifies the column and the third specifies the matrix containing the relay. Multi-dimensional relay numbers are represented by integers separated by “!” characters. See the manuals for the VX4330, VX4350,

Option 01 VXI Interface Module User Manual

<channel_range>

) )<module_name>

3–37

Command Descriptions

and VX4380 for more information on the format of relay numbers for these modules.

The [ROUTe:]OPEN command is not supported for the VX4320 Module. This module contains eight 4-to-1 RF multiplexors. One and only one channel in each multiplexor is closed at all times.

Related Commands

Description

Examples

[ROUTe:]CLOSe <channel_list> [ROUTe:]MODule:DEFine

This command closes the relays specified in the <channel_list> portion of this command.

In these examples the Option 01 is installed on a VX4350 Module. A VX4380 and VX4330 are installed in consecutive slots to the right of the slot containing the VX4350. The default module names for the VX4350, VX4380, and VX4330 in this configuration are m1, m2, and m3 respectively. These module names may be altered with the [ROUTe:]MODule:DEFine command.

Command Response

route:open (@m3(4!6)) Open relay 4 in section 6 of the VX4330 Scanner Module.

route:open (@m1(1,2,3,10:64))

route:open (@m2(3!16!4))

route:open (@m3(2!1:2!3))

Open relays 1,2,3 and 10 through 64 on the VX4350 General

Purpose Switch Module.

Open row 3, column 16 of section 4 of the VX4380 Matrix

Module.

Open relay 2 in sections 1 through 3 on the VX4330 Scanner

Module.

3–38

route:open (@m3(4!6),m2(3!16!4))

route:module:define scanner,3 route:open (@scanner (3!2))

route:open (@m2(1!1!1,4!6!2))

Combined effect of examples 1 and 3.

Open channel 3 of section 2 on the VX4330 Module after

redefining its module name to “scanner”.

Open the following relays on the VX4380 matrix Module:

Row Column Section

111

462

Option 01 VXI Interface Module User Manual

Command Response

route:open? (@m1(1,2,3,4))

route:open? (@scanner (3!2))

1 1 0 0 This response indicates that relays 1 and 2 on the VX4350 are open and relays 3 and 4 on this module are closed.

1 This response indicates that channel 3 of section 2 of the VX4320 is open. Note that a route:module:define scanner,3 command has been received prior to this query.

Command Descriptions

Command Syntax

Query Syntax

*RST Value

Limits

Related Commands

Description

[ROUTe:]OPEN

:ALL [module_name]

N/A

All relays on all modules are set to the open position.

N/A

[ROUTe:]CLOSe [ROUTe:]MODule:DEFine

If a module name is not specified in this command, open all relays on all modules controlled by the Option 01. If a module name is specified, open all relays on the specified module only. In either case do not change the state of the configuration relays on VX4330 Modules.

The [ROUTe:]OPEN command is not supported for the VX4320 Module. This module contains eight 4-to-1 RF multiplexors. One and only one channel in each multiplexor is closed at all times.

Examples

Command Response

ROUTE:OPEN:ALL Open all relays on all Modules controlled by the VX4300. Do

rout:open:all Same as the first example. route:open:all gp Open all relays on the module that has been assigned module

Option 01 VXI Interface Module User Manual

not change the state of the configuration relays on VX4330 Modules.

name “gp”. See the [ROUTe:]MODule:DEFine command.

3–39

Command Descriptions

Command Syntax

Query Syntax

*RST Value

Limits

Related Commands

Description

Examples

[ROUTe:]OPEN

:DWELl <module_name>,<nrf>

N/A

The open dwell time of all modules is set to 0 seconds.

The value of the time specified in this command must be between 0 and 6.5535 seconds.

[ROUTE:]OPEN [ROUTe:]SCAN

This command sets the time to wait after opening a relay before proceeding.

In the following example the Option 01 is installed on a VX4330 Module.

Command Response

output:ttltrg1:state on

Enable VXI TTL trigger 1.

route:close:dwell m1,.25

route:open:dwell m1,0.5

route:scan (@m1(1!6:20!6))

trigger:Sequence: source ttltrg2

trigger:sequence:delay 1

initiate:immediate Initiate the scan sequence.

Set the close dwell time for the VX4330 to 0.25 seconds.

Set the open dwell time for the VX4330 to 0.5 seconds.

Define a scan list consisting of relays 1 through 20 in section 6

of the VX4330.

Define VXI TTL trigger 2 as the trigger source for the defined

scan list.

Set the trigger delay time to 1 second.

After this sequence, each time the VXI TTL trigger 2 is pulsed low, the following sequence of events occurs:

1. One second delay. This is the delay specified in the trigger:Sequence:delay

command.

2. The current relay in the scan list is opened.

3–40

Option 01 VXI Interface Module User Manual

Command Descriptions

3. 0.5 second delay. This is the delay specified in the route:open:dwell

command.

4. Close the next relay in the scan list.

5. 0.25 second delay. This is the delay specified in the route:close:dwell

command.

6. Pulse VXI TTL trigger 1 low for 3 sec.

Option 01 VXI Interface Module User Manual

3–41

Command Descriptions

OUTPut

Command Syntax

Query Syntax

Query Response

*RST Value

Related Commands

Description

 



  !  ! 

 





Indicates whether a VXI TTL trigger is enabled.

     

ROUTe:CLOSe ROUTe:SCAN

One or more VXI TTL triggers may be enabled. Triggers that are enabled are pulsed low for 3 sec after a relay is closed by the Option 01 after a time specified by the ROUTe:CLOSe:DWELl command.

3–42

Examples

Command Response

   

   Disable driving VXI TTL trigger 2.    Enable driving VXI TTL trigger 7.    1

Enable driving VXI TTL trigger 1.

This response indicates that VXI TTL trigger 4 is enabled.

Option 01 VXI Interface Module User Manual

PFAil

Command Descriptions

Command Syntax

Query Syntax

*RST Value

Limits

Related Commands

Description

[ROUTe:]PFAil <action_at_powerfail>

N/A

All relays on all modules are opened when power is removed from the VXI chassis.

N/A

This command specifies the state that all latching relays on all modules controlled by the Option 01 are to be placed in when power is removed from the VXI chassis containing the modules. <action_at_powerfail> must be OPEN or SAME. If OPEN is specified, all latching relays are opened at powerfail. If SAME is specified, all latching relays are left in their current state at powerfail.

NOTE. VXI chassis +5 V power is maintained for 4 milliseconds after ACFAIL is asserted, in compliance with VXI Specifications. This allows for orderly system shutdown and implementation of the PFAil OPEN option.

Examples

Option 01 VXI Interface Module User Manual

Command Response

route:pfail same Leave all latching relays in their current state at powerfail. route:pfail open Open all latching relays at powerfail.

3–43

Command Descriptions

SCAN

Command Syntax

Query Syntax

*RST Value

Limits

[ROUTe:]SCAN <channel_list>

N/A

No scan list is defined.

<channel_range>

! :

<NR1>

<channel_list>

<NR1>

( @ (

<channel_range>

) )<module_name>

A relay number may have one, two, or three dimensions depending on the architecture of the relay module containing the relay. For example, the VX4350 contains 64 SPDT relays. Only one-dimensional relay numbers are supported for this module. The VX4380 Module contains four 4 × 16 2-wire matrices. Threedimensional channel numbers are supported for this module. The first specifies the row, the second specifies the column, and the third specifies the matrix containing the relay. Multi-dimensional relay numbers are represented by integers separated by “!” characters. See the user manuals for the VX4320, VX4330, VX4350, and VX4380 for more information on the format of relay numbers for these modules.

3–44

Option 01 VXI Interface Module User Manual

Command Descriptions

Related Commands

Description

TRIGger[:SEQuence]:SOURce TRIGger[:SEQuence]:COUNt TRIGger[:SEQuence]:DELay TRIGger[:SEQuence]:IMMediate INITiate[:IMMediate] [ROUTe:]CLOSe:DWELl [ROUTe:]OPEN:DWELl

This command defines a list of relay closures to sequence through. This list is called a scan list. When the ROUTe:SCAN <channel_list> command is received, all relays in this list are opened. In addition to defining a scan list, a trigger source must be specified using the TRIGger[:SEQuence]:SOURce command. Trigger events are not recognized until triggers are armed by an INITiate [:IMMediate] or INITiate:CONTinuous command.

When the first trigger event is detected, the first relay in the scan list is closed. When the second trigger event is detected, the first relay is opened and the second relay is closed. When the nth trigger event is detected, the (n–1)th relay is opened and the nth relay is closed. The act of opening the (n–1)th relay and closing the nth relay is called sequencing the scan list. At any given time after the first trigger event is detected, only one relay in the scan list is closed.

The TRIGger[:SEQuence]:COUNt command may optionally be used to specify the number of times to sequence through the entire scan list. The TRIGger [:SEQuence]:DELay, [ROUTe:]CLOSe:DWELl, and [ROUTe:]OPEN:DWELl commands may optionally be used to specify the time to wait after a trigger event is detected, a relay is closed or a relay is opened. A TRIGger[:SEQuence] [:IMMediate] command causes the scan list to be sequenced without the delay specified by a previously issued TRIGger[:SEQuence]:DELay command.

Examples

In these examples the Option 01 is installed on a VX4350 Module. A VX4380 and VX4330 are installed in consecutive slots to the right of the slot containing the VX4350.

Command Response

route:module:define gp,1

route:module:define matrix,2

route:module:define scan,3

route:scan (@gp(1:64),maĆ trix(1!1!1, 2!10!3), scan(1!1:20!1))

Option 01 VXI Interface Module User Manual

Assign module name “gp” to the VX4350.

Assign module name “matrix” to the VX4380.

Assign module name “scan” to the VX4330.

Define a scan list consisting of relays 1 through 64 on the VX4350, relays at row 1, column 1 of section 1 and row 2, column 10 of section 3 of the VX4380 and relays 1 through 20 of section 1 of the VX4330.

3–45

Command Descriptions

Command Response

trigger:sequence: source immediate

trigger:sequence:count 5

Define a trigger source of “immediate”. This means to

sequence through the scan list without waiting for a trigger

event.

Sequence through the entire scan list five times.

route:close:dwell gp,.5

initiate:immediate Begin sequencing through the scan list. *OPC Set the Operation Complete bit of the Standard Event Status

Wait 0.5 seconds after closing a relay on the VX4350.

3–46

Option 01 VXI Interface Module User Manual

STATus

Command Descriptions

Command Syntax

*RST Value

Limits

Related Commands

Description

Examples

STATus

:OPERation

:CONDition?

N/A

This query returns the contents of the SCPI Status Operation Condition register. For the Option 01, the value of this register is always equal to 0.

Command Response

status:operation: condition?

00000

Command Syntax

Query Syntax

*RST Value

Limits

Related Commands

Description

STATus

:OPERation

:ENABle

STATus:

OPERation

:ENABle?

N/A

This command sets the contents of the SCPI Status Operation Event Enable register.

Option 01 VXI Interface Module User Manual

3–47

Command Descriptions

Examples

Command Syntax

*RST Value

Limits

Related Commands

Description

Command Response

status:operation: enable 1

stat:oper:enab? 00001

STATus

:OPERation

[:EVENt?]

N/A

This query returns the contents of the SCPI Status Operation Event register. For the Option 01, the value of this register is always equal to 0.

Examples

Command Syntax

*RST Value

Limits

Related Commands

Description

Command Response

status:operation: event?

STATus

:QUEStionable

:CONDition?

N/A

This query returns the contents of the SCPI Status Questionable Condition register. For the Option 01, the value of this register is always equal to 0.

00000

3–48

Option 01 VXI Interface Module User Manual

Command Descriptions

Examples

Command Syntax

Query Syntax

Query Response

*RST Value

Command Response

status:questionable: condition?

STATus

:QUEStionable

:ENABle

STATus

:QUEStionable

:ENABle?

Indicates whether the Status Operation Event is enabled.

00000

Limits

Related Commands

Description

Examples

N/A

This command sets the contents of the SCPI Status Operation Event Enable register.

Command Response

status:questionable: enable 1

stat:ques:enab? 00001

Option 01 VXI Interface Module User Manual

3–49

Command Descriptions

Command Syntax

*RST Value

Limits

Related Commands

Description

Examples

STATus

:QUEStionable

[:EVENt?]

N/A

This query returns the contents of the SCPI Status Questionable Event register. For the Option 01, the value of this register is always equal to 0.

Command Response

status:questionable: event?

00000

3–50

Option 01 VXI Interface Module User Manual

SYSTem

Command Descriptions

Command Syntax

Query Response





Each response is terminted with a carriage return <CR> and a line feed<LF>. 0,“No error” –102, “Syntax error; 1 dimensional <channel_spec> invalid for VX4330

module”

–102, “Syntax error; 2 dimensional <channel_spec> invalid for VX4350

module”

–102, “Syntax error; 3 dimensional <channel_spec> invalid for VX43xx

module” –102, “Syntax error; channel dimension mismatch” –102, “Syntax error; integer field greater than 10 characters” –102, “Syntax error; Missing module name” –102, “Syntax error; Module address not specified” –102, “Syntax error; Module name already defined” –102, “Syntax error; Module name length greater than 12 characters” –102, “Syntax error; Non-contiguous section numbers” –102, “Syntax error; ROUTe:CONFigure command invalid for VX43xx module” –102, “Syntax error; ROUTe:DISJoin command invalid for VX43xx module” –102, “Syntax error; ROUTe:JOIN command invalid for VX43xx module” –102, “Syntax error; ROUTe:MODE command invalid for VX43xx module” –102, “Syntax error; Undefined module name” –102, “Syntax error; Unexpected x detected while ...” –121, “Invalid character in number” –123, “Exponent too large” –200, “Execution error; Reserved” –200, “Execution error; Scan list undefined”

Option 01 VXI Interface Module User Manual

3–51

Command Descriptions

–211, “Trigger ignored” –213, “Init ignored” –222, “Data out of range; Channel number x on module y” –222, “Data out of range; Channel number x!x on module y” –222, “Data out of range; Channel number x!x!x on module y” –222, “Data out of range; Invalid module address specified” –222, “Data out of range; Invalid section number” –222, “Data out of range; Invalid sequence count” –222, “Data out of range; Invalid trigger delay” –222, “Data out of range; Invalid VXI TTL Trigger level” –222, “Data out of range; Maximum value for ESE command is 255”

*RST Value

Limits

–222, “Data out of range; Maximum value for SRE command is 255” –222, “Data out of range; Invalid dwell time specified.” –223, “Too much data; Channel list array overflow” –223, “Too much data; Input buffer overflow” –223, “Too much data; Output buffer full” –223, “Too much data; Scan list array overflow” –240, “Hardware error; Shift register verification error – module y” –240, “Hardware error; Unrecognized module x, y” –350, “Queue overflow; Error/event queue” –350, “Queue overflow; Output queue”

The error/event queue is empty.

N/A

3–52

Related Commands

*ESR? *STB?

Option 01 VXI Interface Module User Manual

Command Descriptions

Description

Examples

Command Syntax

Query Syntax

*RST Value

Limits

If an error condition is detected by the Option 01, it places an error message describing the condition in the error/event queue. The SYSTem:ERRor? query requests the Option 01 to remove the oldest message in the error/event queue and place it into the output queue. If the error/event queue is empty, a “No error” message is placed in the output queue.

Command Response

 0, “No error”  –222,“Data out of range; Invalid section number”





N/A

Related Commands

Description

Examples

Command Syntax

*RST Value

Limits

ROUT e:OPEN:ALL

Channel 1 of all sections on all VX4320 Modules is closed. All relays on all modules (except VX4320 Modules) are set to the open position. The PON bit of the Standard Event Status register is not affected by this command.

Command Response

 no response  no response





N/A

Option 01 VXI Interface Module User Manual

3–53

Command Descriptions

Related Commands

Description

Examples

None

This query returns the following ASCII string in the output queue: “1994.0”

Command Response

 “1994.0”  “1994.0”

3–54

Option 01 VXI Interface Module User Manual

TRIGger

Command Descriptions

Command Syntax

Query Syntax

*RST Value

Limits

Related Commands

Description

TRIGger

[:SEQuence]

:COUNt

N/A

The count specified in this command must be between 1 and 65535.

ABORt, ROUTe:SCAN TRIGger[:SEQuence]:SOURce TRIGger[:SEQuence][:IMMediate] TRIGger[:SEQuence]:DELay

This command specifies the number of times to sequence through an entire scan sequence.

Examples

Command Syntax

Query Syntax

Command Response

route:scan (@m1(1,2),m2(1:64))

trigger:sequence:count 2

trigger:sequence: source:immediate

initiate:immediate Initiate the scan sequence. Sequence through the entire scan

Define a scan sequence consisting of relays 1 and 2 on relay module m1 and relays 1 through 64 on module m2.

Define the number of times to sequence through the scan list before setting the state of the trigger subsystem back to the idle state.

Sequence through the scan list without waiting for a trigger event after an INITiate[:Immediate] command is received.

list two times.

TRIGger

[:SEQuence]

:DELay

N/A

Option 01 VXI Interface Module User Manual

3–55

Command Descriptions

*RST Value

Limits

Related Commands

Description

Examples

The time specified in this command must be between 0 and 6.5535 seconds.

ABORt, ROUTe:SCAN TRIGger[:SEQuence]:SOURce TRIGger[:SEQuence][:IMMediate] TRIGger[:SEQuence]:DELay

This command specifies the time to wait after a trigger event is detectedbefore opening the current relay in a scan list. A trigger event is enabled with teh TRIGger:[SEQuence]:SOURce command.

Command Response

route:scan (@m1(1,2),m2(1:64))

trigger:sequence:count 2

trigger:sequence:delay

0.5

Define a scan sequence consisting of relays 1 and 2 on relay module m1 and relays 1 through 64 on module m2.

Define the number of times to sequence through the scan list before setting the state of the trigger subsystem back to the idle state.

Wait 0.5 seconds after a trigger event is detected before opening the current relay in a scan list and closing the next relay in the list.

Command Syntax

Query Syntax

*RST Value

Limits

trigger:sequence: source ttltrg2

initiate:immediate Initiate the scan sequence. Sequence through the entire scan

Sequence to the next relay in a scan list when VXI TTL trigger 2 is asserted.

list two times. Wait 0.5 seconds after VXI TTL trigger 2 is asserted before sequencing to the next relay in the list.

TRIGger

[:SEQuence]

[:IMMediate]

N/A

3–56

Option 01 VXI Interface Module User Manual

Command Descriptions

Related Commands

Description

Examples

ABORt, ROUTe:SCAN TRIGger[:SEQuence]:SOURce TRIGger[:SEQuence]:COUNt TRIGger[:SEQuence]:DELay

Sequence to the next relay in an initiated scan list without waiting for a trigger event and without waiting the time specified in a TRIGger[:SEQuence]:DELay command.

Command Response

route:scan (@m1(1,2),m2(1:64))

trigger:sequence count 2

trigger:sequence:delay

0.5

trigger:sequence: source:ttltrg2

initiate:immediate Initiate the scan sequence. Sequence through the entire scan

trigger:sequence: immediate

Define a scan sequence consisting of relays 1 and 2 on relay module “m1” and relays 1 through 64 on module m2.

Define the number of times to sequence through the scan list before setting the state of the trigger subsystem back to the idle state.

Wait 0.5 seconds after a trigger event is detected before opening the current relay in a scan list and closing the next relay in the list.

Sequence to the next relay in a scan list when VXI TTL trigger 2 is asserted.

list 2 times. Wait 0.5 seconds after VXI TTL trigger 2 is asserted before sequencing to the next relay in the list.

Sequence to the next relay in the scan list without waiting for VXI TTL trigger 2 to be asserted. Do not wait 0.5 seconds to sequence to the next relay.

Command Syntax

TRIGger

[:SEQuence]

:SOURce BUS | HOLD | IMMediate | TTLTrg<n>

Query Syntax

*RST Value

Limits

Related Commands

N/A

IMMediate

N/A

ABORt, ROUTe:SCAN TRIGger[:SEQuence][:SOURce] TRIGger[:SEQuence][:IMMediate]

Option 01 VXI Interface Module User Manual

3–57

Command Descriptions

TRIGger[:SEQuence][:COUNt] TRIGger[:SEQuence][:DELay]

Description

This command selects a trigger source. When a trigger event is detected from an enabled trigger source, the next relay in an initiated scan sequence is closed after the current closed relay is opened.

The action of opening the currently closed relay and closing the next relay in a scan list is called sequencing the scan list.

Specifying BUS in the TRIGger[:SEQuence]:SOURce command enables a IEEE488.1 Group Execute Trigger command to sequence the scan list.

It is assumed that the commander of the Option 01 is a IEEE488 talker/listener and that this device converts a IEEE488.1 GET command to a VXI Trigger command.

Specifying HOLD in the TRIGger[:SEQuence]:SOURce command disables all trigger sources.

Specifying IMMediate in the TRIGger[:SEQuence]:SOURce command causes the Option 01 to sequence through the scan list without waiting for a trigger event.

Specifying TTLTrg<n> in the TRIGger[:SEQuence]:SOURce command enables one of eight VXI TTL triggers to act as a trigger source. <n> is a single digit between 0 and 7.

3–58

Examples

Command Response

 

 

 

 Initiate the scan sequence. Sequence through the entire scan

Define a scan sequence consisting of relays 1 and 2 on relay module “m1” and relays 1 through 64 on module m2.

Define the number of times to sequence through the scan list before setting the state of the trigger subsystem back to the idle state.

Sequence through the scan list without waiting for a trigger event after an INITiate[:Immediate] command is received.

list two times.

Option 01 VXI Interface Module User Manual

IEEE-488.2 Common Commands

This section lists the IEEE-488.2 common commands and queries recognized by the Option 01.

*CLS

Clear Status. This commands clears the following:

Event Status register (ESR) Error/Event queue Output queue

*ESE <NRf>

Event Status Enable (ESE) command. This command defines the mask for setting the Event Status Summary bit (bit 5) in the Status Byte register (*STB?). The mask is logically ANDed with the Event Status register (*ESR?) to determine whether or not to set the Event Status Summary bit. The mask can be any numeric value from 0 to 255, corresponding to the encoded bits of the ESR register. A “1” in a bit position enables reporting of the function. A “0” disables it. The *ESE register is cleared at power-on, or by writing an *ESE 0 command only. If <mask> is not specified, it defaults to 0.

For example, the command *ESE 37 (hexadecimal 25, binary 00010101) enables setting the Event Status Summary bit whenever an operation is complete, a query error is detected, or an execution error is detected.

*ESE?

Event Status Enable (ESE) query. This command returns the value of the Event Status Enable register as a numeric value from 0 to 255. For example, a value of 32 (hexadecimal 40, binary 00100000) indicates that command error reporting is enabled.

*ESR?

Event Status Register (ESR) query. This command returns the value of the Event Status register. The *ESR command is destructively read (that is, read and cleared). The Event Status Summary bit in the Status Byte (*STB?) is also cleared by a read of the ESR. The ESR is set to 128 on power-on (bit 7) set. It is

Option 01 VXI Interface Module User Manual

3–59

IEEE-488.2 Common Commands

cleared by an *ESR? or *CLS command only. When converted to a binary number, the bits of the ESR correspond to:

bit 0 (LSB) Operation Complete

1 Request Control 2 Query error 3 Device Dependent error 4 Execution error 5 Command error 6 User Request 7 (MSB) Power On

The Error bits are set whenever the module detects an error. The error values from –100 to –199 are Command errors. Error values from –200 to –299 are Execution errors. Error values from –300 to –399 are Device Dependent errors. Error values from –400 to –499 are Query errors (see the SYSTem:ERRor command description).

The Request Control and User Request bits are unused, and are always reported as zeroes.

*IDN?

The Operation Complete bit is set in response to an *OPC command. A 1 indicates that the module has completed all pending commands and queries.

Identification query; This returns a 4-field response. Field 1 is the manufacturer, field 2 the model, field 3 the serial number, and field 4 contains both the SCPI and the firmware version levels. For the Option 01, the serial number field is always a 0. The response syntax is:

TEKTRONIX,VX43xx,0,SCPI:94.0 FW1.1<LF>

where xx indicates the model number of the relay module that the Option 01 is installed on:

Value of xx Model Number

20 VX4320 30 VX4330 50 VX4350 80 VX4380

3–60

Option 01 VXI Interface Module User Manual

*OPC

*OPC?

*RST

IEEE-488.2 Common Commands

Operation Complete. This command causes the module to set the Operation Complete bit in the Event Status register (ESR) when all pending commands and queries are complete.

Operation Complete query. This command causes the module to place a “1” in the Output queue when all pending commands and queries are complete. All commands following *OPC are suspended until the pending operations are complete. The *OPC? command does not affect the OPC bit in the Event Status register.

Reset. This command causes the Option 01 to open all relays on all modules under its control, except for VX4320 Modules. Channel 1 in each section of each VX4320 Module is closed. This command sets the Option 01 Module to its power-on state with the following exceptions: the Error/Event queue, Output queue, Standard Event Status Enable register, SCPI Status Operation Event Enable register and SCPI Status Questionable Event Enable register are not cleared.

The condition of the Option 01 daughter board and the switching modules that it controls after receipt of a *RST command is as follows:

Contents of the SCPI Status Operation Event register = 0 Contents of the SCPI Status Operation Condition register = 0 Contents of the SCPI Status Questionable Event register = 0 Contents of the SCPI Status Questionable Condition register = 0 All VXI TTL triggers are disabled Trigger subsystem is in the idle state Trigger source = IMMediate Number of times to sequence through an entire scan list = 1 Time in seconds to wait after a trigger event is detected before sequencing to the Next relay in a scan list = 0 All relays on all modules are set to the open position No scan list is defined Default module names are assigned as follows:

The module that has a Option 01 VXI Interface daughter board installed is assigned module name “M1”.

Modules without the Option 01 VXI Interface daughter board in

Option 01 VXI Interface Module User Manual

3–61

IEEE-488.2 Common Commands

*SRE <mask>

consecutive slots to the right of module “M1” are assigned module names “M2”, “M3”, ..., “M11”.

All sections on all scanner modules are disjoined All sections of all VX4330 Modules are set to operate in the mux mode Close dwell time of all modules is set to 0 seconds Open dwell time of all modules is set to 0 seconds All relays on all modules are opened when power is removed from the VXI chassis

Service Request Enable (SRE) register. This command defines a mask that is ANDed with the contents of the Status Byte register. If the result of this operation is non-zero, the Option 01 generates a VXI Request True interrupt. Bits 0, 1, 3, 6, and 7 of the SRE register are not used. Bits 2, 4, and 5 are set to enable VXI Request True interrupts to be generated under the conditions listed in the following table.

*SRE?

Bit No. Meaning

bit0 (LSB) Not used 1 Not used 2 The Error/Event queue contains one or more error messages 3 Not used 4 The Output queue contains one or more query responses 5 The contents of the Standard Event Status register ANDed with the

contents of the Standard Event Status Enable register produces a

non-zero result. 6 Not used 7 Not used

Service Request Enable (SRE) query. This command returns the value of the Service Request Enable register as a numeric value from 0 to 255. Bit 6 is unused, and is reported as zero.

*STB?

3–62

Status Byte Query. This query returns the value of the Status Byte register as a numeric value between 0 and 255. The Status Byte register contents (with the

Option 01 VXI Interface Module User Manual

IEEE-488.2 Common Commands

exception of bit 6) are also returned in response to a VXI Read STB command. Bit 6 is read destructively in response to a VXI Read STB command. Bit 6 is not read destructively is response to a *STB? query. The Status Byte register is encoded as follows:

Bit No. Meaning

bit 0 (lsb) Not used bit 1 Not used bit 2 Set when the Error/Event queue contains one or more error messages. bit 3 Not used bit 4 Set when the Output buffer contains one or more query responses. bit 5 Set when the contents of the Standard Event Status register ANDed

with the contents of the Standard Event Status Enable register produces a non-zero result.

bit 6 Set when the contents of bits 0 through 5 and bit 7 of the Status Byte

If bit 6 becomes set, the Option 01 will generate a VXI Request True interrupt on the VME interrupt level selected by its interrupt level select switch. If bit 6 becomes set and the Status Byte register is read using a VXI Read STB command, bit 6 will be reported as being set. In response to subsequent VXI Read STB commands, bit 6 will be reported as being cleared.

If bit 6 becomes set and the Status Byte register is read using a *STB? query , bit 6 will be reported as being set. Bit 6 will continue to be reported as set in reponse to *STB queries until the contents of bits 0 through 5 and bit 7 of the Status Byte register ANDed with the contents of the Service Request Enable register is equal to 0.

bit 7 Not used.

Option 01 VXI Interface Module User Manual

3–63

IEEE-488.2 Common Commands

*TRG

Trigger Command. This command is equivalent to a VXI Trigger command. This command is valid only after the following commands have been received by the Option 01:

Command Description

[ROUTe:]SCAN <channel_list>

Define a scan list

TRIGger [:SEQuence] :SOURce BUS

INITiate[:IMMediate] Initiate the scan list. This command places the trigger

Select a VXI Trigger command as a trigger source.

subsystem in the “ARM” state. The trigger subsystem remains in this state until the Option 01 has sequenced through the entire scan list “n” times, where “n” has been previously specified in a TRIGger[:SEQuence]:COUNT command. The trigger subsystem then returns to the IDLE state. The trigger subsystem also returns to the IDLE state if an ABORt command is received by the Option 01.

After these commands have been issued, a *TRG command will cause the Option 01 to take the following actions:

Generate a trigger delay that has previously been specified in a TRIGger [:SEQuence]:DELay command.

Open the currently closed channel . Generate the open delay that has previously been specified in a

[ROUTe:]OPEN:DWELl command. Close the next channel in the scan list.

3–64

Generate the close delay that has previously been specified in a [ROUTe:]CLOSe:DWELl.

Pulse one or more VXI TTL trigger signals that have been enabled by a previously issued OUTPut:TTLTRG<n>[:STATe] ON command.

If the module containing the channel is a scanner module, pulse the appropriate front panel encode signal.

If another *TRG command is received before this sequence is complete, a SCPI –211,“Trigger ignored” error message will be placed in the Error/Event queue. The *TRG command will continue to have this effect until the trigger subsystem is placed in the IDLE state. If additional *TRG commands are recieved after the

Option 01 VXI Interface Module User Manual

*TST?

IEEE-488.2 Common Commands

trigger system is placed in the IDLE state, the Option 01 will place SCPI –211,“Trigger Ignored” error messages in the Error/Event queue.

The IEEE-488.2 Specification equates the *TRG command with an IEEE-488.1 Group Execute Trigger (GET) command. IEEE-488-to-VXI interface modules typically convert IEEE-488.1 GET commands to VXI Trigger commands. For this reason, the Option 01 equates the *TRG command with a VXI Trigger command.

Self Test query. In response to this query, the Option 01 performs a self test of each of the switching modules under its control. During self test, the Option 01 verifies that it can properly control the relay drive circuitry of each switching module under its control. After the self test is complete, each module is restored to its pretest state. If all modules pass self test, an ASCII “0” is placed in the Output buffer. If one or more modules fail the self test, an ASCII “1” is placed in the Output buffer and error message(s) describing the failure are queued in the Error/Event queue. Issue a SYSTem:ERRor? query to read these error messages.

*WAI

Wait to Continue. This command causes the module to wait until all pending commands and queries are complete. All commands following *WAI are suspended until the pending operations are complete.

Option 01 VXI Interface Module User Manual

3–65

Status and Events

The Status and Event Reporting System reports asynchronous events and errors that occur in the Option 01 VXI Interface Module. This system consists of four 8-bit registers and two queues that you access through the command language. You can use these registers and queues to query the instrument status and control the interrupts that report events.

In general, after an interrupt occurs, first conduct a serial poll, query the registers to see why the interrupt occurred, and then send the SYSTem:ERRor? query to see a descriptive error message.

This section describes the four registers and two queues of the Status and Event Reporting system. For each register, you are given a description, a table describing all of the bits, and an example of how to use the register.

The Status and Event Reporting process, synchronizing programming commands, and the system messages are also described in this section.

Status and Event Reporting System

Status Byte Register

The Status and Event Reporting system monitors and reports such events as an error occurring or the availability of a response to a query. This system includes descriptions of the following registers and queues:

H Status Byte register H Service Request Enable register H Standard Event Status register H Event Status Enable register H Output queue H System Error and Event queue

The Status Byte register, shown in Table 4–1, summarizes information from other registers. Use a serial poll or a *STB? query to read the contents of the Status Byte register. The response is the sum of the decimal values for all bits set. When you use a serial poll, bit 6 shows Request Service information. When you use the *STB? query, bit 6, the Master Status Summary bit, indicates that bits 5, 4, or 2 may be set.

Option 01 VXI Interface Module User Manual

4–1

Status and Events

T able 4–1: The Status Byte Register

Decimal

Bit

0–1 – Not used. 2 4 Error/Event queue Not Empty indicates that information is

3 – Not used. 4 16 Message Available shows that output is available in the Output

5 32 Event Status Bit indicates that one or more events have occurred

6 64 Request Service (obtained from a serial poll) shows that the

7 – Not used.

Value

Function

contained in the Error/Event queue and is waiting to be read.

queue.

and the corresponding bits in the Standard Event Status register have been set.

Option 01 has requested service from the GPIB controller. Master Status Summary (obtained from *STB? query) summarizes

the Event Status bit, Message Available bits, and Error/Event queue Not Empty bits in the Status Byte register.

Service Request Enable

A common example of using the Status Byte register is to enable the Message Available bit. This is done by sending an *SRE 16 command to the Option 01 VXI Interface Module. If the *STB? query returns a value of 80, bit 4 (decimal value of 16) and bit 6 (decimal value of 64) have been set (giving a decimal sum of 80). Bit 4 indicates that a message is available in the output queue. Bit 6 indicates that a bit in the Status Byte register that has been enabled by setting the corresponding bit in the Service Request Enable register (in this case bit 4) has been set.

The Service Request Enable register, shown in Table 4–2, controls which bits in the Status Byte register will generate a service request. Use the *SRE command to set bits in the Service Request Enable register. Use the *SRE? query to see which bits in this register are enabled. The response from this query is the sum of the decimal values for all bits set.

T able 4–2: The Service Request Enable Register

Decimal

Bit

0–1 – Not used

2 4 Error/Event queue Bit indicates that a service request will be

Value

Function

generated when a message is placed in the Error/Event queue.

4–2

Option 01 VXI Interface Module User Manual

Status and Events

T able 4–2: The Service Request Enable Register (Cont.)

Decimal

Bit Function

3 8 Not used 4 16 Message Available Bit indicates that a service request will be

5 32 Event Status Bit indicates that events summarized in bit 5 of the

6–7 – Not used

Value

generated when a message is placed in the Output queue.

Status Byte register will generate a service request.

If, for example, the *SRE? query returns a value of 48, bits 4 and 5 are set in the Service Request Enable register. Any event that causes the Message Available bit (bit 4) or Event Status bit (bit 5) to be set in the Status Byte register now generates an interrupt. If you want an interrupt to be generated only when the Event Status bit (bit 5) is set, use the *SRE 32 command.

Standard Event Status

The Standard Event Status register, shown in Table 4–3, records many types of events that can occur in the Option 01. Use the *ESR? query to read the contents of this register. The response is the sum of the decimal values for all bits set. Reading this register clears all bits so the register can accumulate information about new events.

T able 4–3: The Standard Event Status Register

Decimal

Bit

0 1 Operation Complete shows that the operation is complete. This bit

1 – Not used 2 4 Query Error shows that data in the Output queue was lost. 3 8 Not used 4 16 Execution Error shows that an error occurred while the Option 01

5 32 Command Error shows that an error occurred while the Option 01

6 – Not used

Value

Function

is set when all pending operations complete following a *OPC command.

was executing a command or query. Table 4–6 on page 4–7 lists the execution error messages.

was parsing a command or query. Table 4–5 on page 4–6 lists the command error messages.

7 128 Power On shows that the Option 01 was powered on.

Option 01 VXI Interface Module User Manual

4–3

Status and Events

The following example assumes that all bits have been enabled using the Event Status Enable register (see the next section for information about this register). If a *ESR? query returns a value of 128, bit 7 (decimal value of 128) is set indicating that the instrument is in the initial power-on state.

Event Status Enable

The Event Status Enable register, shown in Table 4–4, controls which events are summarized in the Event Status bit (bit 5) of the Status Byte register. Use the *ESE command to set bits in the Event Status Enable register. Use the *ESE? query to see what bits in the Event Status Enable register are set. The response from this query is the sum of the decimal values for all bits summarized in the event status bit of the Status Byte register.

T able 4–4: The Event Status Enable Register

Decimal

Bit

0 1 Set bit 5 of the Status Byte register when bit 1 (the Operation

1 2 Not used 2 4 Set bit 5 of the Status Byte register when bit 2 (the Query Error bit )

3 8 Not used 4 16 Set bit 5 of the Status Byte register when bit 4 (the Execution Error

5 32 Set bit 5 of the Status Byte register when bit 5 (the Command Error

Value

Function

Complete bit) of the Standard Event Status register is set.

of the Standard Event Status register is set.

bit) of the Standard Event Status register is set.

The Output Queue

The System Error and

Event Queue

4–4

6 64 Not used 7 128 Set bit 5 of the Status Byte register when bit 7 (the Power On bit) of

the Standard Event Status register is set.

If, for example, the *ESE? query returns a value of 255, all bits are set, indicating that all events will set the event status bit (bit 5) of the Status Byte register.

The Option 01 stores query responses in the Output queue.

The Option 01 error and event messages are stored in the System Error and Event queue. Use the SYSTem:ERRor? query to get the event number and a text description of the event. Reading an event removes it from the queue. The Event queue stores detailed information for up to 10 events; the events are stored in first-in first-out order.

Option 01 VXI Interface Module User Manual

Status and Event Reporting Process

Figure 4–1 shows how to use the Status and Event Reporting system. In the explanation that follows, numbers in parentheses refer to the circled numbers in Figure 4–1.

Status and Events

Standard Event Status

Read using *ESR?

Event Status Enable

Read using *ESE?

Write using *ESE

Status Byte

Read using *STB?

Service Request Enable

Read using *SRE?

Write using *SRE

765 4 3 210

PowerOn— Command

Error

765 4 3 210

PowerOn— Command

Error

Request

7543210

Service

—

Master

Status

7543210

— Event

Status Bit

——

Status Bit

Event

Execution

Error

Execution

Error

Message Available

Query

—

Error

Query

—

Error

queue Not

——

Empty

——

—

Operation

Complete

Operation

Complete

111

—

Event Event Event

Byte Byte Byte

Event queue

Output queue

Figure 4–1: Status and Event Reporting Process

When an event occurs the appropriate bit in the Standard Event Status register is set to one and the event is recorded in the Event queue (1). If the corresponding bit in the Event Status Enable register is also enabled (2), then the event status bit in the Status Byte register is set to one (3).

Option 01 VXI Interface Module User Manual

4–5

Status and Events

Messages

When output is sent to the Output queue (for example, a response to a query), the message available bit in the Status Byte register is set to one (4).

When a bit in the Status Byte register is set to one and the corresponding bit in the Service Request Enable register is enabled (5), the master status summary bit in the Status Byte register is set to one and a service request is generated (6).

The Option 01 generates error messages in response to events caused by commands or queries. Each type of event sets a specific bit in the Standard Event Status register. Thus, each message is associated with a specific Standard Event Status register bit. In the message tables that follow, the associated Standard Event Status register bit is specified in the table title. Not shown in the tables are secondary messages giving more detail about the cause of the error or the meaning of the message. These secondary messages are shown for each command and query in Syntax and Commands.

Table 4–5 shows the error messages generated by improper command syntax. Check to see that the command is properly formatted and that it follows the rules in Syntax and Commands.

T able 4–5: Command Error Messages (Bit 5 in Standard Event Status register)

Code Message

–102 Syntax error; 1 dimensional <channel_spec> invalid for VX4330 module –102 Syntax error; 2 dimensional <channel_spec> invalid for VX4350 module –102 Syntax error; 3 dimensional <channel_spec> invalid for VX43xx module –102 Syntax error; channel dimension mismatch –102 Syntax error; integer field greater than 10 characters –102 Syntax error; Missing module name

Syntax error; Module name already defined –102 Syntax error; Module name already defined –102 Syntax error; Module name length greater than 12 characters –102 Syntax error; Non–contiguous section numbers –102 Syntax error; ROUTe:CONFigure command invalid for VX43xx module –102 Syntax error; ROUTe:DISJoin command invalid for VX43xx module –102 Syntax error; ROUTe:JOIN command invalid for VX43xx module –102 Syntax error; ROUTe:MODE command invalid for VX43xx module –102 Syntax error; Undefined module name –102 Syntax error; Unexpected x detected while ...

4–6

Option 01 VXI Interface Module User Manual

Status and Events

T able 4–5: Command Error Messages (Bit 5 in Standard Event Status register) ( C o n t . )

Code Message

–121 Invalid character in number –123 Exponent too large

Table 4–6 lists the execution error messages that can occur during execution of a command. Parameter y in these error messages represents the local bus address of the module that the error message applies to. A value of 1 indicates the module containing the Option 01 daughter board, a value of 2 the module in the next slot to the right, and so on.

T able 4–6: Execution Error Messages (Bit 4 in Standard Event Status register)

Code Message

–200 Execution error; Reserved –200 Execution error; scan list undefined –21 1 Trigger ignored –213 Init ignored –222 Data out of range; Channel number x on module y –222 Data out of range; Channel number x!x on module y –222 Data out of range; Channel number x!x!x on module y –222 Data out of range; Invalid module address specified –222 Data out of range; Invalid section number –222 Data out of range; invalid sequence count –222 Data out of range; invalid trigger delay –222 Data out of range; Invalid VXI TTL Trigger level –222 Data out of range; Maximum value for ESE command is 255 –222 Data out of range; Maximum value for SRE command is 255 –222 Data out of range; invalid dwell time specified. –223 Too much data; channel list array overflow –223 Too much data; Input buffer overflow –223 Too much data; Output buffer full –223 Too much data; scan list array overflow –240 Hardware error; shift register verification error – module m –241 Hardware error; Unrecognized module d, d

Option 01 VXI Interface Module User Manual

4–7

Status and Events

Table 4–7 lists the device dependent error messages that can occur during Option 01 operation.

T able 4–7: Device Dependent Error Messages (Bit 3 in Standard Event Status register)

Code Message

–350 Queue overflow; error/event queue –350 Queue overflow; output queue

4–8

Option 01 VXI Interface Module User Manual

Appendix A: Specifications

T able A–1: VXI Instrument Characteristics

Characteristics Description

VXI General Characteristics The instrument provides a VXI interface that complies with Revision 1.4.

The VXI interface is defined by the VXI Consortium, Inc. Interface Type Message Based (1.4) Protocols Word Serial (WSP) TTL Outputs VXI TTLTRG* Lines TTLTRG0* through TTLTRG7* under program control. Product Compliance to Regulations

(VX4320, VX4330, VX4350, VX4380 only)

Product Safety UL, cUL, UL classified to IEC–1010–1. IEC Characteristics Overvoltage Category: CA T I

Safety: Class I

EMC Per EC Council Directive 89/336 EEC (EC–92), the following standards and limits

apply to the requirements for equipment to be used in residential, commercial, and

light industrial environments. They are specified in EN–50081–1, the Generic

Emission Standard, and in EN 50082–1, the Generic Immunity Standard. For

equipment that is also intended to be used in industrial environments, the standards

and limits specified in EN 50081–2 and EN 50082–2 should be used in addition.

Emissions Emissions shall be within the limits specified by the following requirements:

Enclosure: EN 5501 1 Class A limit for radiated emissions.

AC Mains: EN 55011 Class A limit for radiated emissions.

Immunity , Enclosure, Radio Frequency Electromagnetic Field; IEC 801–3

Immunity , Enclosure, Electrostatic Discharge (ESD); IEC 801–2

Immunity, Fast Transients, Common Mode; IEC 801–4

No state change when the instrument is subjected to a 3 V/M electromagnetic field

over the frequency range of 27 MHz to 500 MHz.

Up to 8 kV with no loss of stored data, change to control settings, degradation of

performance, or temporary loss of function. No state change.

No loss of stored data, change to control settings, degradation of performance, or

temporary loss of function will occur when the instrument is subjected to the transients

as described below.

Port Peak Voltage – kV Tr/Th – ns Rep. Freq. – kHz

Signal & control 0.5 5/50 5

AC Power 1 5/50 5

Option 01 VXI Interface Module User Manual

EN 60555–2: Power line harmonics

A–1

Appendix A: Specifications

T able A–1: VXI Instrument Characteristics

Characteristics Description

EN 55011, Class A The instrument complies with the requirements of EN 55011 for radiated, conducted,

and magnetic emissions, when installed in a suitable VXI chassis. A suitable VXI chassis is defined as one which contains adequate EMC shielding which makes contact with the RF gasket on the front and rear shields of the VX43xx Module.

FCC The instrument complies with the requirements of FCC CFR 47, Part 15, Subpart B,

Class A for radiated and conducted emissions.

T able A–2: Environmental/Reliability Characteristics

Characteristics Description

Temperature

Operating Meets or exceeds MIL-T-28800E for Type III, 0 to 50_ C external ambient, when

operated in a mainframe providing Class 3 equipment.

Non-operating –40_ C to +71_ C

Airflow as required by the host module, –10_ C/55_ C for 10_ C (or less) temperature rise of internal air, as measured at the cooling air exit points, and with no heat transfer either to or from any adjacent VXI modules.

Relative Humidity

Operating Up to 95% at up to 30_ C, and up to 45%, at up to 50_ C.

Non-operating Up to 95%, at up to 50_ C. Altitude (1) Operating 6,000 ft. altitude. Altitude (2) Meets or exceeds MIL-T-28800E for Type III, (operating to 10,000 ft., non-operating to

15,000 ft.). Derate maximum operating temperature above TBD ft. by degree C per 1000 ft.

T able A–3: Option 01-Specific Characteristics

Characteristics Description

VME Interrupter Level Switch selectable to a level between 1 and 7. VXI Logical Address Switch selectable to a value between 0 and 255. VXI Dynamic Addressing Not supported. Contents of device/manufacturer dependent

VXI registers.

ID Register BFFD hexadecimal.

Device Type Set according to the model number of the slave module that the interface is installed

on as specified in the following table. (Convert the last 3 digits of the model number to hex, take the one’s complement, AND with F7FF.)

A–2

Option 01 VXI Interface Module User Manual

Appendix A: Specifications

T able A–3: Option 01-Specific Characteristics (Cont.)

Characteristics Description

Slave Module Model No. Register Contents (hexadecimal)

VX4320 F6BF VX4330 F6B5 VX4350 F6A1 VX4380 F683

VXI TTL Trigger Outputs One or more of the VXI TTLTRG* signals may be driven. All TTLTRG* outputs may be

disabled.

VXI TTL Trigger Inputs One of the VXI TTLTRG* signals may be selected to be polled or to act as an interrupt

source to the module’s microprocessor .

Option 01 VXI Interface Module User Manual

A–3

Appendix B: Examples

This example script demonstrates how the some of the various programmable features of the Option 01 are used to control from 1 to 12 relay modules. These modules can consist of any combination of VX4320, VX4330, VX4350, VX4372, VX4374 and VX4380 relay modules. In these examples, the Option 01 is installed on a VX4320 Module. A VX4330, VX4350, VX4372, VX4374, and VX4380 are installed in consecutive slots to the right of the VX4320.

It is assumed the module has completed its power-on self test. For information on specific commands or syntax, please review the Syntax and Commands section.

H Query the identity of the module that the Option 01 is installed on.

WRITE *IDN? READ TEKTRONIX,VX4320,0,SCPI:94.0 FW:1.1<CR><LF>

H Query the card for any self-test errors.

WRITE *TST? READ 0

Note that a response of 0 indicates that all modules controlled by the Option 01 daughter board passed the self test. A response of 1 indicates that one or more modules have failed the self test. In that case, SYSTem:ERRor? queries should be issued to determine which modules failed the self test.

H Query the identity of all the modules controlled by the Option 01

WRITE route:id? READ VX4320 VX4330 VX4350 VX4372 VX4374 VX4380

H Query the module names assigned to each of the modules controlled by the

Option 01. WRITE route:module:catalog?

READ "M1", "M2", "M3", "M4", "M5", "M6" The names listed in the response to this query correspond to the modules in

the response to the route:id? query.

H Check the contents of the Standard Event Status register.

WRITE *ESR? READ 128

Option 01 VXI Interface Module User Manual

B–1

Tektronix 070-9180-01 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Table of Contents

Getting Started

Operating Basics

Syntax and Commands

Status and Events

Appendices

Glossary and Index

General Safety Summary

Injury Precautions

Product Damage Precautions

Safety Terms and Symbols

Certifications and Compliances

Preface

Conventions

Getting Started

Product Description

Accessories

Controls and Indicators

Configuration

Installation

Installation Checklist

Functional Check

Operating Basics

Functional Overview

Power-on

Instrument I/O: VXIbus Basics

Command Syntax

Functional Command Groups

System Commands

Module Commands

Command Descriptions

ABORt

CLOSe

CONFigure

INITiate

MODule

OPEN

OUTPut

PFAil

SCAN

STATus

SYSTem

TRIGger

IEEE-488.2 Common Commands

*CLS

*ESE <NRf>

*ESE?

*ESR?

*IDN?

*OPC

*OPC?

*RST

*SRE <mask>

*SRE?

*STB?

*TRG

*TST?

*WAI

Status and Events

Status and Event Reporting System

Status and Event Reporting Process

Messages

Appendix A: Specifications

Appendix B: Examples
