TF 100
Manual H-Series
Portable or mobile mast lighting systems
The Teklite TF 100 H-Series are the most
economical manually extended mast lighting
systems of the whole Teklite range. The
TF 100 H-Series are compact portable lighting
sets which can be easily fitted to small service
or fire vehicles.
The Teklite TF 100 H-Series mast lighting systems
are especially designed for directional lighting
applications.
MOBILE, PORTABLE & EMERGENCY LIGHTING
Page 2
MOBILE, PORTABLE & EMERGENCY LIGHTING
Mast specifications
TF 100 H-Series mast models
Technical details
Bottom pin for quick and easy
fitting onto a tripod or vehicle
mounting bracket
6
Clamp handle for quick and
easy fitting onto a tripod or
vehicle mounting bracket
5
Clamp collars to adjust the
height of the non-keyed mast
sections
4
Standard natural clear
anodised seamless drawn
aluminium mast sections with
Ø 21/2” (63,5 mm) base tube
3
Lockable rotating collar
2
24 mm diameter quick clamp
socket
1
Model
3 SECTION MASTS
Cat. No. Retracted height Extended height
Weight
of mast
TF H128 T/3 (previously called : TF 600 H3)
11343 1200 mm
1230 mm
1260 mm
2825 mm 4,2 kg
5,0 kg
5,5 kg
3710 mm
4595 mm
11344
11345
TF H137 T/4 (previously called : TF 600 H4)
TF H146 T/5 (previously called: TF 600 H5)
4 SECTION MASTS
5 SECTION MASTS
Page 3
MOBILE, PORTABLE & EMERGENCY LIGHTING
Lamp choice
Single lamp unit with 8 m cable on reel (without plug),
lamp fully adjustable with standard fitted clamp handle
Cat. No.
27740 70 Watt HP Sodium*
70 Watt HP Sodium *
70 Watt Metal Halide *
6.5006,312
6.5003,524
5.0006,512
5.0003,724
12,512
7,024
13,012
12
24
7,4
12,8
24
Model
LumensAmpere
27745
70 Watt Metal Halide *27755
27750
16.5003,3230
36.0006,5230
750 Watt Halogen *
1500 Watt Halogen *27765
27759
22.0004,4230
1000 Watt Halogen *27760
Volt
Type CEE17
Colour : blue
Cat. No. B11861
Schuko type with extra earth pin
connection and rubber body
Cat. No. B11619
Model 1000 Watt Halogen
Model 1500 Watt Halogen
Double lamp unit with 8 m cable on reel (without plug),
lamps fully adjustable with standard fitted clamp handles
Cat. No.
27770 2 x 70 Watt HP Sodium *
2 x 70 Watt HP Sodium*
2 x 70 Watt Metal Halide*
Model
LumensAmpere
27775
2 x 70 Watt Metal Halide*27785
27780
1 x 70 Watt HP Sodium + 1 x 70 Watt Metal Halide *27790
1 x 70 Watt HP Sodium + 1 x 70 Watt Metal Halide *27795
2 x 35 Watt Xenon27800
Volt
Model 2 x 35 Watt Xenon
Model 2 x 50 0 Watt Halogen
Plugs for lamps
Plugs recommended for 230 volt installation
NOTE :
Other plugs and sockets are
available on request.
Please contact us for further
information.
11.500
11.5007,2
12
24
10,6
2 x 55 Watt SMD-LED*35731
2 x 55 Watt SMD-LED*35736
11.000
230 0,5
2 x 55 Watt SMD-LED*35737
11.000
11.0004,8
12 7.0005,9
24
2 x 35 Watt Xenon27805
2 x 100 Watt Xenophot*27810
7.0003,0
12 7.20016,7
24
2 x 150 Watt Xenophot*27815
2 x 500 Watt Halogen*27820
12.00012,5
230 19.0004,4
13.000
13.000
10.000
10.000
Model 70 Watt Metal Halide
Model 2 x 70 Watt HP Sodium
*
Lamp unit standard fitted with lamp protection guard.
5.5005,312
5.5002,424
55 Watt SMD-LED*
55 Watt SMD-LED*35726
35721
Page 4
MOBILE, PORTABLE & EMERGENCY LIGHTING
Mast mounting
Mast mounted on a vehicle
Brackets for
permanent fixture
Brackets for
temporary fixture
Wall Mounting Bracket
Cat. No. 1984/SG
Mounting Ring
Cat. No. 2148/SG
Saddle Clamp
Cat. No. 25960/SG
Vehicle Mounting
Bracket Set
Cat. No. 11446/SG
Mast mounted on a tripod
Folded position
This very stable stand folds
vertically and is easy to carry
and store. All Mk VI Tripods can
either be stored vertically or
horizontally.
Unfolded position
The feet can be adjusted
according to the slope of the site.
Finish tripod : stainless steel
Trip od Mk VI
WeightModels
12,7 kg
Trip od Mk VI LB ( wi th L ocki ng Bl ock)
12,7 kg
Cat. No. Length legs
36820
36823
1000 mm
1000 mm
Tr ip od M ou n tin g
Bracket
Cat. No. 36592
Can be fixed onto a
wall, vehicle or shelter.
A Ground/ Vehicle/
Shelter Tripod is
foreseen with a
Locking Block
which enables the
user to attach this
tripod to the Tripod
Mounting Bracket
for compact
vertical
storage,
with or
without the
mast
.
