Tekbox SDI-12 User Manual

V1.1

Manual TBS09S

SDI-12 Master to Modbus Slave Converter

The TBS09S is a converter to connect to a SDI-12 sensors to Modbus. It can connect multiple sdi12 sensors in parallel by setting the corresponding address.

Features

▪ SDI-12 master to Modbus slave ▪ Multiple sensors can be connected ▪ SDI-12 Standard V1.3 ▪ Highly configurable ▪ Switched sensor supply voltage output ▪ 6 - 16V supply voltage ▪ 7mA current consumption when active

▪ Less than 100µA idle current ▪ Operating Temperature Range:

- 40°C … + 80°C

Target Applications

▪ SDI-12 sensor networks

TBS09S SDI-12 master to Modbus slave converter

V1.0

TBS09S

SDI-12 Master to Modbus Slave Converter

2

Contents

1 INTRODUCTION 3 2 CONNECTIONS 3 3 MEASUREMENT 4

3.1 GENERAL CONFIGURATION COMMANDS 4

3.2 MEASUREMENT COMMANDS 5

3.2.1 Send measurement command to sdi12 sensors: 5

3.2.2 Send Data command to sdi12 sensors: 7

3.2.3 Modbus master get data from TBS09S: 8

4 SDI-12 10 5 SUPPORTED SDI-12 COMMANDS 10 6 HISTORY 11

Tables

Table 4 – History 11

Figures

Figure 2 – TBS09S terminals 3 Figure 4 – TBS09DR jumpers 4

V1.0

TBS09S

SDI-12 Master to Modbus Slave Converter

3

1 Introduction

The TBS09S is a converter to connect one or multiple sdi12 sensors to a modbus device such as a data logger or telemetry unit.

User will use it when they got RTU support modbus and they want using it to read data of sdi12 sensors.

2 Connections

RS485 Side, from left to right:

TX+ output (or half duplex) TX- output (or half duplex) RX+ input RX- input Ground 12V, switched sensor supply voltage

SDI-12 Side, from left to right:

Cable shield Ground SDI-12 Data line SDI-12 Supply voltage

Figure 1 – TBS09S terminals

4 Pin terminal block:

CON1 – SDI-12 Interface

Shield: connect to the shield of the SDI-12 cable or leave it unconnected; shield and ground are

internally connected together Ground: connect to the GND wire of the SDI-12 cable SDI-12 data: connect to the data wire of the SDI-12 cable

SDI-12 Power: connect to the positive supply voltage wire of the SDI-12 cable;

6 Pin terminal block:

V1.0

TBS09S

SDI-12 Master to Modbus Slave Converter

4

CON2 – Power supply & RS485 (Modbus) interface

TX+, connect to RX+ of the Modbus Sensor; half duplex

TX-, connect to RX- of the Modbus Sensor; half duplex

RX+, connect to TX+ of the Modbus Sensor

RX-, connect to RX- of the Modbus Sensor Ground, connected to the GND of the SDI-12 supply for TBS09S

+12V, supply output for the Modbus sensor. It is connected to the SDI-12 supply line, with a high side

FET switch and a 700mA fuse in between. The switch can either be controlled by SDI-12 (ON-time

determined by the warm-up time setting) or it can be configured to be permanently on.

Default J4 and J5 jumpered - Modbus terminated with 120Ω

Default J3 jumpered – half duplex

Figure 2 – TBS09S jumpers

3 Measurement

3.1 General configuration commands

TBS09S is default with baurate: 19200, Parity: None = 0 Modbus slave address : 1

Modbus slave settings

Slave Address Register: 0xB000

V1.0

TBS09S

SDI-12 Master to Modbus Slave Converter

5

Modbus command:

Modbus Master send

Example (Hex)

Modbus Slave(TBS09S) response

Slave Address

01- current addr

01

Function

06

Starting Address Hi

B0

00

Starting Address Lo

00

Data Hi

00

Data Lo

02 - new addr

02

Error Check (LRC or

CRC)

-

2 bytes CRC

Modbus address: 0x01 -> 0xFF

3.2 Measurement commands

When user want read data from sdi12 sensors, please following 3 steps:

3.2.1 Send measurement command to sdi12 sensors:

TBS09S will send measurement command to sdi12 sensor: aM!...aM9, aMC!…aMC9!, aC!..aC9!, aCC!..aCC9! Register map:

sdi12

command

register

sdi12

command

register

sdi12

command

register

sdi12

command

register

aM!

0x0010

aMC!

0x0020

aC!

0x0030

aCC!

0x0040

aM1!

0x0011

aMC1!

0x0021

aC1!

0x0031

aCC1!

0x0041

aM2!

0x0012

aMC2!

0x0022

aC2!

0x0032

aCC2!

0x0042

aM3!

0x0013

aMC3!

0x0023

aC3!

0x0033

aCC3!

0x0043

aM4!

0x0014

aMC4!

0x0024

aC4!

0x0034

aCC4!

0x0044

aM5!

0x0015

aMC5!

0x0025

aC5!

0x0035

aCC5!

0x0045

aM6!

0x0016

aMC6!

0x0026

aC6!

0x0036

aCC6!

0x0046

aM7!

0x0017

aMC7!

0x0027

aC7!

0x0037

aCC7!

0x0047

aM8!

0x0018

aMC8!

0x0028

aC8!

0x0038

aCC8!

0x0048

aM9!

0x0019

aMC9!

0x0029

aC9!

0x0039

aCC9!

0x0049

V1.0

TBS09S

SDI-12 Master to Modbus Slave Converter

6

Modbus command:

Modbus Master send

Example (Hex)

Modbus Slave(TBS09S) response

Slave Address

01

Function

06

Starting Address Hi

00

Starting Address Lo

10

00

Data Hi

00

Data Lo(sdi12 address)

30 – sdi12 sensor

address

30

Error Check (LRC or

CRC)

-

2 bytes CRC

TBS09S support total 62 sdi12 sensors. Data Lo byte is hex value of sensor address(‘0’ = 0x30, ‘1’ = 0x31……)

Read time and number measurement:

After send measurement command, user can read : ttt - the specified time, nn - the number of measurement values the sensor will make and return in response to one or more subsequent D commands

Register map:

sdi12 sensor#

register

0

0x3010

1

0x3110

2

0x3210

3

0x3310

4

0x3410

5

0x3510

6

0x3610

7

0x3710

8

0x3810

9

0x3910

any

0xZZ10

ZZ is the hex value of sensor address, base on ASCII

Modbus command:

Modbus Master send

Example (Hex)

Modbus Slave(TBS09S) response

V1.0

TBS09S

SDI-12 Master to Modbus Slave Converter

7

Slave Address

01

Function

04

Starting Address Hi

30

04

Starting Address Lo

10

00

Data Hi

00

01 - ttt time

Data Lo

02 - read 2 registers

00

Error Check (LRC or

CRC)

-

02 –nn number

2 bytes CRC

Data response is 4 bytes, 2 bytes - the specified time + 2 bytes - the number of measurement values

3.2.2 Send Data command to sdi12 sensors:

TBS09S will send data command to sdi12 sensor: aD0!...aD9! Register map:

sdi12 command

register

aD0!

0x00D0

aD1!

0x00D1

aD2!

0x00D2

aD3!

0x00D3

aD4!

0x00D4

aD5!

0x00D5

aD6!

0x00D6

aD7!

0x00D7

aD8!

0x00D8

aD9!

0x00D9

Modbus command:

Modbus Master send

Example (Hex)

Modbus Slave(TBS09S) response

Slave Address

01

Function

06

Starting Address Hi

00

Starting Address Lo

D0

00

Data Hi

00

Data Lo

30 – sdi12 sensor

address

30

V1.0

TBS09S

SDI-12 Master to Modbus Slave Converter

8

Error Check (LRC or

CRC)

-

2 bytes CRC

3.2.3 Modbus master get data from TBS09S:

After send sommand aMx! and aDx! to sdi12 sensors, TBS09 will store 10 sensors from 0 to 9 to REGISTER

DATA 0 to 9

Sdi12 data format will be:

a+d0+d1+d2+d3+d4+d5+d6+d7+d8+d9 (maximum)

TBS09 will use 2 Registers = 4 bytes to store each data with floating format.

Register map:

sdi12

data

REG

SENSOR 0

REG

SENSOR 1

REG

SENSOR 2

REG

SENSOR--

REG

SENSOR 9

REG

SENSOR X

d0

0x3000

0x3100

0x3200

-

0x3900

0xZZ00

d1

0x3001

0x3101

0x3201

-

0x3901

0xZZ01

d2

0x3002

0x3102

0x3202

-

0x3902

0xZZ02

d3

0x3003

0x3103

0x3203

-

0x3903

0xZZ03

d4

0x3004

0x3104

0x3204

-

0x3904

0xZZ04

d5

0x3005

0x3105

0x3205

-

0x3905

0xZZ05

d6

0x3006

0x3106

0x3206

-

0x3906

0xZZ06

d7

0x3007

0x3107

0x3207

-

0x3907

0xZZ07

d8

0x3008

0x3108

0x3208

-

0x3908

0xZZ08

d9

0x3009

0x3109

0x3209

-

0x3909

0xZZ09

ZZ is the hex value of sensor address, base on ASCII

Modbus command:

Modbus Master send

Example (Hex)

Modbus Slave(TBS09S) response

Slave Address

01

Function

04

Starting Address Hi

30

04

Starting Address Lo

00

41

Data Hi

00

CF

Data Lo

02 - read 2 registers

1E

V1.0

TBS09S

SDI-12 Master to Modbus Slave Converter

9

Error Check (LRC or

CRC) - B8

2 bytes CRC

This example read data from temperature sdi12 sensor. Data 0 is floating format with 4 bytes = 0x41, 0xCF, 0x1E, 0xB8 = 25.89 (degree celsius)

Float to hex convert online: https://www.h-schmidt.net/FloatConverter/IEEE754.html

V1.0

TBS09S

SDI-12 Master to Modbus Slave Converter

10

4 SDI-12

SDI-12 is a standard for interfacing data recorders with microprocessor-based sensors. SDI-12 stands for serial/digital interface at 1200 baud. It can connect multiple sensors with a single data recorder on one cable. It supports up to 60 meter cable between a sensor and a data logger.

The SDI-12 standard is prepared by

SDI-12 Support Group (Technical Committee) 165 East 500 South River Heights, Utah 435-752-4200 435-752-1691 (FAX) http://www.sdi-12.org

The latest standard is version V1.3 which dates from July 18th, 2005. The standard is available on the website of the SDI-12 Support Group.

More information on SDI-12 is presented in chapter 3.

5 Supported SDI-12 Commands

Following standard SDI-12 commands are supported:

Start Measurement aM! Start Measurement and Request CRC aMC! Additional Measurements aM1! … aM9! Additional Measurements and Request CRC aMC1 ! ... aMC9!

Start Concurrent Measurement aC! Start Concurrent Measurement and Request CRC aCC! Additional Concurrent Measurements aC1! … aC9! Additional Concurrent Measurements and Request CRC aCC1 ! ... aCC9!

Send Data aD0! … aD9!

Example – controlling the soil moimoisture/temperature Sensor: https://www.sdi-12products.com/collections/sensors/products/sdi-12-soil-moisture-temperature-probe-tbsmp02

V1.0

TBS09S

SDI-12 Master to Modbus Slave Converter

11

[TX] - 01 06 00 11 00 30 D9 DB master send 0M1! to sensor [RX] - 01 06 00 00 00 30 89 DE TBS09S response ACK [TX] - 01 06 00 D0 00 30 88 27 master send 0D0! to sensor [RX] - 01 06 00 00 00 30 89 DE TBS09S response ACK [TX] - 01 04 30 00 00 02 7E CB master read 1

st

parameter(moisture)

[RX] - 01 04 04 41 2D 99 99 8B FF TBS09S response data = 41,2D,99,99 =10.85 [TX] - 01 04 30 01 00 02 2F 0B master read 2ndparameter(temperature)

[RX] - 01 04 04 41 DB 70 A4 F8 FF TBS09S response data = 41,DB,70,A4 = 27.43

Example above is measurement sdi12 moisture/temperature probe with addressed 0, modbus sensor is addressed 1. Command to get data is: 0M1! and wait 1s to send 0D0! to get humidity+ temperature with floating fomat.

6 History

Version

Date

Author

Changes

V1.0

9.8.2018

Thinh

Creation of the document

Table 1 – History
