Page 1
EN
www.tefal.co.uk
Ultimate Pure
Page 2
SUMMARY
IMPORTANT SAFETY RECOMMENDATIONS
Important safety recommendations ....................................................................................................................... p. 5
Before first use
PREPARATION
Which water should I use? ............................................................................................................................................................ p. 9
Filling the water tank
USE
Adjusting the temperature and steam............................................................. p. 10
Dry ironing ...................................................................................................................
Getting more steam : turbo boost. .....................................................................
Getting more steam : extra steam .....................................................................
Vertical steam ironing .............................................................................................
Dampening clothing (Spray) ................................................................................
While ironing ...............................................................................................................
Auto-Off Function .....................................................................................................
IRON STORAGE AND MAINTENANCE
Storing your iron ........................................................................................................ p. 15
Cleaning the Micro Calc filter...............................................................................
Cleaning the anti-calc valve (once per month) .............................................
Cleaning the soleplate ............................................................................................
...................................................................................................................................................................................................... p. 8
............................................................................................................................................................................... p. 9
p. 11
p. 11
p. 12
p. 12
p. 14
p. 14
p. 14
p. 16
p. 18
p. 19
IS THERE A PROBLEM WITH YOUR IRON?
Problems, possible causes, solutions ............................................................................................................. p. 20-21
2
Page 3
EN Depending on model
*
3
Page 4
www.tefal.co.uk www.calor.fr
4
Page 5
IMPORTANT SAFETY INSTRUCTIONS
• Please read these instructions carefully before
first use. This appliance has been designed for
domestic and indoor use only. Any commercial
use, inappropriate use or failure to comply with
the instructions, the manufacturer accepts no
responsibility and the guarantee will not apply.
• Never unplug the appliance by pulling the power
cord. Always unplug your appliance: before filling
the water tank or rinsing the water tank, before
cleaning the appliance and after each use.
• The appliance must be used and placed on a flat,
stable, heat and water resistant surface. When
you place the iron on the iron rest, make sure that
the surface on which you place it is stable.
• This appliance is not intended to be used by
persons (including children) with reduced physical,
sensory or mental capabilities or persons lacking
appropriate knowledge or experience, unless
a person responsible for their safety provides
either supervision or appropriate instructions
concerning use of the appliance prior to its use.
• Children should be supervised to ensure they do
not play with the appliance.
• This appliance may be used by children aged 8 or
over and persons lacking appropriate knowledge
or experience or persons with reduced physical,
sensory or mental capabilities provided that they
5
Page 6
have been thoroughly instructed regarding use
of the appliance, are supervised, and understand
the risks involved. Children shall not play with the
appliance. Cleaning and user maintenance shall
not be made by children without supervision.
Keep the iron and its cord out of reach of children
less than 8 years of age when it is in use until it
has cooled down completely.
• The surfaces of your appliance can reach
very high temperatures when functioning,
which may cause burns. Do not touch the
hot surfaces of the appliance (accessible
metal parts and plastic parts adjacent to the
metallic parts).
• Never leave the appliance unattended when it
is connected to the mains. Before storing the
appliance, once it is unplugged, please wait until
it has cooled down completely (around 1 hour).
• The appliance must not be used if it has been
dropped, if it has any visible damage, if it leaks,
or if it functions abnormally in any way. Do not
attempt to dismantle your appliance: have it
examined at an Approved Service Centre to avoid
any danger.
• The iron should only be used with the base
provided (for cordless irons).
6
Page 7
• Check the electrical power cord for signs of wear
or damage prior to use. If the electrical power
cord is damaged, please contact an Approved
Service Centre to avoid any danger.
• The iron must always be placed on its base and never on its heel (for cordless irons) .
• Your iron and its base must be used and placed on a flat, stable, heat-resistant surface.
When you place the iron on its base, ensure that the surface on which the base is placed
is stable.
• For your safety, this appliance conforms to all applicable regulations (Low Voltage
Directive, Electromagnetic Compatibility, Environment, etc).
• Your steam iron is an electrical appliance: it must be used under normal conditions of use.
It is designed for domestic use only.
• Always plug your steam iron:
- into a mains circuit with voltage between 220 V and 240 V,
- into an earthed electrical socket.
Connecting to the wrong voltage may cause irreparable damage to the appliance and will
invalidate your guarantee.
• Do not use an extension lead. If you accept liability for doing so, only use an extension
lead which is in good condition, has a plug with an earth connection and is suited to the
power rating of the appliance.
• Completely unwind the power cord before plugging into an earthed socket.
• The soleplate of your iron can reach extremely high temperatures, and can cause burns:
do not touch them. Never touch the electrical power cords with the soleplate of the iron.
• Do not leave the power cord close to or in contact with sources of heat or sharp edges.
• Your appliance emits steam, which can cause burns. Always handle the iron with care,
especially when ironing vertically. Never direct the steam towards people or animals.
• Never immerse your steam iron in water or any other liquid. Never place it under a running
tap.
• The plug must be removed from the socket-outlet before the water tank is filled with water.
PLEASE RETAIN THIS INSTRUCTION
BOOKLET FOR FUTURE REFERENCE
Environment protection first !
i
Y our appliance contains valuable materials which can be recovered
or recycled.
Leave it at a local civic waste collection point.
7
Page 8
BEFORE FIRST USE
Remove any labels from the soleplate before
heating the iron.
Before using the steam function in your iron
for the first time, we recommend that you
allow the iron to operate a few moments in
a horizontal position without coming into
contact with your laundry. Keeping the iron
in this position, push the steam button se
veral times.
During the first few uses, the appliance may
produce smoke, a harmless odour and a
light emission of particles. These are simply
the engineering residues from the manufac
turing process burning off. These are harmless and will quickly disappear.
-
-
8
Page 9
Max.
PREPARATION
Which water should I use?
• Your appliance was designed to operate using untreated
tap water.
• Do not use pure demineralised or pure distilled water,
water from clothes dryers, scented or softened water, or
water containing additives (starch, perfume, aromatic
substances, softeners, etc.), rain water, filtered, bottled
or boiled water, water from refrigerators, batteries or
air conditioners. These types of water contain organic
waste, mineral elements that become concentrated
when heated and cause spitting, brown staining, leaking
or premature wear on your iron.
If your water is very hard (above 30°f or 17°dH or 21°e)
mix 50% untreated tap water with 50% distilled water
(available in hardware stores).
*
Depending on model
*
Filling the water tank
• Unplug the iron before filling it.
• Set the steam control to
• Lift the iron and, holding it at a slight incline, point the
soleplate up.
• Open the water tank cover.
• Fill the water tank to the mark “Max”.
• Close the water tank cover.
9
.
Page 10
*
NO
Warning ! Do not fill your iron through the filter
opening. Do not remove the Micro Calc filter to fill the
tank.
USE
• Plug in the appliance.
Adjusting the temperature and steam
• Set the steam control to
• Adjust the temperature control, referring to the table
below.
Depending on model
*
FABRIC
LINEN / COTTON
WOOL
SILK
SYNTHETIC
(Polyester, Acetate, Acrylic,
Polyamide)
10
TEMPERATURE CONTROL
POSITION
Max
••
•
•
= STEAM ZONE
Page 11
OK
• The temperature indicator light turns on.
• It will turn off automatically once the soleplate
achieves the desired temperature.
Set the temperature control dial to match the type of
fabric you wish to iron. Your iron automatically and
accurately determines the ideal temperature and
steam flow.
*
Depending on model
*
max.
1
sec.
Dry ironing
• Set the steam control to
• You may continue to iron when the indicator light turns
off.
Getting more steam : turbo boost
• Set the thermostat control to “•••”.
• Note: This setting is only suitable for cotton and linen.
• Press the turbo steam button periodically (turbo
steam).
• To avoid water dripping on the laundry, maintain an
interval of a few seconds in between each press.
11
Page 12
max.
Getting more steam : extra steam
• Set the thermostat control to “•••”.
• Note: This setting is only suitable for cotton and linen.
*
• Set the steam control to .
• Push and hold the steam button.
• Keep holding and iron
• To avoid water dripping on the laundry, do not use
extra steam continuously.
NO
max.
Vertical steam ironing
• Hang the item on a hanger and keep the fabric taut
with one hand. The steam is very hot; never steam iron
clothing while it is being worn—always use a hanger.
• Set the thermostat control to “•••”.
Depending on model
12
*
Page 13
1
sec.
• Press the turbo steam button (turbo steam) 1 second,
moving the iron from top to bottom.
• Hold the iron at a distance of a few centimetres from
the clothing to avoid burning delicate fabrics.
• After pressing the turbo boost trigger 3 times, put the
iron back in the horizontal position and start again.
13
Page 14
Dampening clothing (Spray)
• When dry or steam ironing, press repeatedly on the
spray button to moisten clothing and remove stubborn
creases.
• Ensure that there is water in the tank before using the
spray button.
NO
OK
While ironing
• Do not lay the iron down on the soleplate; use the heel
rest for this purpose.
Auto-Off Function
• If the iron remains unused for more than 8 minutes on
the heel rest or more than 30 seconds laid flat or on its
side, the electronic system will cut the power, the iron
will stop heating and the temperature indicator light
will begin to flash.
• To restart the iron, move it gently until the indicator
stops flashing.
14
Page 15
*
IRON STORAGE AND
MAINTENANCE
Storing your iron
• Unplug the iron and wait for the soleplate to cool
completely (approx. 1 hour).
1H
• Empty the water tank.
Depending on model
*
• Set the steam control to
• Wrap the cord around the heel of the iron. Store the
iron on its heel rest.
15
.
Page 16
Cleaning the Micro Calc filter
• When the clean filter alert turns on, finish your ironing
session and switch off the appliance.
• Unplug the iron, empty the water tank and wait for
the soleplate to cool down completely (approx. 1 hour).
• Once the steam iron has completely cooled down, raise
and turn the tab of the Micro Calcfilter to unlock it.
• Remove the Micro Calcfilter from the iron, it contains
the limescale collected in the iron.
• Throw the scale particles trapped in the filter away.
16
Page 17
1
2
2h
• To descale the Micro Calc filter thoroughly rinse it in
diluted citric acid for 2 hours.
• Rinse it with tap water
• Reposition the Micro Calc filter in its housing and turn
the tab a quarter turn to the right in order to lock the
filter and ensure it is watertight.
• Plug in and switch on the iron and reset the clean filter
alert by pressing the clean filter button.
• Warning! Never use the iron without the Micro Calc
filter.
17
Page 18
Click
Cleaning the anti-scale valve (once per month)
• Unplug your iron and empty the water tank.
• To remove the anti-calc valve, open the water tank
cover and pull on the valve near the steam control.
h
4
• Soak the valve for 4 hours in a glass of water with
diluted citric acid.
• Rinse the valve under the tap.
• Insert the valve in place, pushing it until you hear a
click.
Beware!
Never touch the end of the valve.
The iron will not function without the anti-calc valve.
18
Page 19
NO
Cleaning the soleplate
• Unplug your iron and, once completely cooled, wipe
it with a soft cloth.
• Never use chemical or abrasive products.
19
Page 20
IS THERE A PROBLEM WITH YOUR IRON?
PROBLEMS POSSIBLE CAUSES SOLUTIONS
Water is leaking
from the holes in
the soleplate.
You are using the steam
when the iron is not hot
enough.
You are using the turbo
steam button (turbo steam)
too often.
You are using the extra steam
button too often
Wait for the indicator light to turn
off.
Wait a few seconds between each
use.
Do not use extra steam
continuously.
The iron leaks
at the start of
ironing.
A brown
discharge
coming from
the soleplate
is staining the
clothing.
The soleplate is
dirty or brown
and may stain
clothing.
You have stored the iron
horizontally without
emptying the water tank or
setting the steam control to
.
You have removed the Micro
Calc filter to fill up your iron
The steam control dial is not
when filling the
set to
water tank.
You are using chemical
descaling agents.
You are not using the right
type of water.
Clothing fibres are building
up in the holes of the
soleplate and burning.
You are using starch. Clean the soleplate as indicated
Your laundry has not been
rinsed sufficiently or you
are ironing a new item of
clothing before washing it.
See the chapter on «Storing your
iron».
Do not remove the Micro Calc filter
when filling the iron.
Ensure that the steam control dial is
set to when filling the water tank.
Do not introduce a descaling agent
into the water tank.
See the chapter on «What water
should I use?»
Clean the soleplate with a damp
sponge. Periodically vacuum the
holes in the soleplate.
above. Spray the starch on the
reverse side of the clothing to be
ironed.
Ensure that your laundry is
sufficiently rinsed to eliminate
potential soap deposits or chemical
products on new items of clothing.
20
Page 21
IS THERE A PROBLEM WITH YOUR IRON?
PROBLEMS POSSIBLE CAUSES SOLUTIONS
Your iron
produces little to
no steam.
The soleplate
is scratched or
damaged.
The iron steams
once the water
tank has been
filled.
The spray does
not spray water.
The clean filter
alert does not
turn off after the
Micro-Calc filter
cleaning
If you have any problems or queries please call our Customer Relations
The water tank is empty. Fill up the water tank.
The anti-calc valve is dirty. Clean the anti-calc valve.
Your iron is clogged up with
limescale.
TheMicro Calc filter is dirty. Clean the Micro Calc filter.
You have placed your iron on
a metallic iron rest or ironed
over metal zips or fasteners.
The steam control dial is not
set to
.
The water tank is too full. Do not exceed the max level for
The water tank is not full
enough.
You did not reset the clean
filter alert
Clean the anti-calc valve and the
Micro Calc filter.
Always place your iron on its heel
rest when not in use.
Do not iron over metal zips or
fasteners
Ensure that the steam control dial is
.
set to
filling.
Add water to the water tank.
Press on the clean filter alert
team first for expert help and advice.
See Helpline number in the separate guarantee
and country list leaflet.
21
Page 22
www.tefal.co.uk
1800147535 - 44/18 - FV98
Loading...
