Tecumseh VSC9529XNAUM User Manual
VSC9529XNAUM_Rel
Refrigerant
Overall Dimensions, inch (mm)
Line
connections
Pump down
(lbs.)
90% @ 90oF
Air flow
Oil
Ch.
Gross
weight
L W H
Suction
Liquid
SCFM
Oz.
Lbs. (kg)
R404A/R507
29.40 (747)
47.75 (1213)
31.58 (802)
1 1/8"
1/2"
33.33
4500
36
460 (209)
R22
38.42
R134a
38.98
R407A
36.73
R407F
35.83
Units are factory charged with 20 psig dry air, MUST BE EVACUATED
TPC May 30, 2016
TECUMSEH OUTDOOR
CONDENSING UNIT
Model VSC9529XNAUM
BOM 32L3281-6C
Air Cooled 3 1/2 HP
Application Commercial Temp
Refrigerant R404A/R507/R22/R134a/R407A/R407F
Volts-Hz-Ph. 208-230/60/1
VSC9529XNAUM R404A / R507 Performance
Performance @ 60 Hz, Return gas 40oF below 20oF Evaporator and 65oF above 20oF evaporator, Sub Cooling 5oF
Evaporator
Ambient Temperatures
80°F
90°F
95°F
100°F
110°F
T, °F
PSIG
BTUH
Watts
Cond T
BTUH
Watts
Cond T
BTUH
Watts
Cond T
BTUH
Watts
Cond T
BTUH
Watts
Cond T
-10
24.8
17200
3410
90
16000
3920
100
15200
4150
104
14300
4380
109
12500
4810
119
-5
29.1
18600
3380
91
17300
3900
100
16500
4130
105
15600
4360
110
13700
4800
120 0 33.9
20600
3390
91
19200
3900
101
18300
4140
106
17300
4370
111
15300
4820
121 5 39.0
23100
3410
92
21400
3930
102
20500
4170
107
19400
4400
112
17200
4850
122
10
44.5
25900
3460
93
24100
3970
103
23000
4210
108
21900
4450
113
19500
4910
123
15
50.4
29100
3520
95
27000
4030
104
25800
4270
109
24600
4510
114
22100
4970
124
20
56.8
32500
3600
96
30200
4110
105
28900
4350
110
27500
4580
115
24800
5050
125
25
63.6
36100
3690
97
33400
4190
107
32000
4430
112
30500
4670
116
27600
5130
126
30
70.9
39700
3800
99
36800
4290
108
35200
4520
113
33600
4760
118
30400
5220
127
35
78.8
43400
3900
100
40200
4390
110
38500
4620
114
36700
4850
119
33200
5310
128
40
87.1
47100
4020
102
43500
4490
111
41600
4720
116
39700
4950
120
35800
5400
130
45
96.0
50600
4130
104
46700
4600
113
44600
4820
117
42500
5040
122
38300
5490
131
VSC9529XNAUM R22 Performance
Performance @ 60 Hz, Suction Super Heat (MAX.) 20oF, Sub Cooling 5oF Preliminary Data
Evaporator
Ambient Temperatures
80°F
90°F
95°F
100°F
110°F
T, °F
PSIG
BTUH
Watts
Cond T
BTUH
Watts
Cond T
BTUH
Watts
Cond T
BTUH
Watts
Cond T
BTUH
Watts
Cond T
-10
16.7
12700
2680
89
11700
2900
98 -5
20.3
14500
2730
90
13500
2970
100 0
24.2
16500
2800
92
15500
3050
101
15000
3180
106
14500
3310
110 5
28.5
18700
2870
93
17700
3130
103
17200
3260
107
16600
3400
112
15300
3690
121
10
33.0
21200
2950
95
20100
3220
104
19500
3360
109
18900
3500
113
17600
3800
122
15
38.0
23800
3040
97
22700
3310
106
22100
3450
110
21400
3600
115
20000
3910
124
20
43.3
26700
3120
99
25500
3400
108
24900
3550
112
24200
3700
117
22700
4030
125
25
49.0
29900
3210
101
28600
3490
110
27900
3640
114
27100
3800
119
25500
4140
127
30
55.2
33400
3310
103
31900
3590
112
31100
3740
116
30300
3900
120
28600
4250
129
35
61.7
37100
3400
106
35500
3680
114
34700
3840
118
33800
4000
123
31900
4350
131
40
68.8
41200
3490
108
39400
3780
117
38500
3930
121
37500
4100
125
35500
4460
133
45
76.3
45600
3580
111
43600
3870
119
42600
4030
123
41500
4190
127
39300
4560
135
VSC9529XNAUM R134a Performance
Performance @ 60 Hz, Suction Super Heat (MAX.) 20oF, Sub Cooling 5oF Preliminary Data
Evaporator
Ambient Temperatures
80°F
90°F
95°F
100°F
110°F
T, °F
PSIG
BTUH
Watts
Cond T
BTUH
Watts
Cond T
BTUH
Watts
Cond T
BTUH
Watts
Cond T
BTUH
Watts
Cond T
10
12.1
14800
2150
92
14000
2300
101
13500
2380
106
13000
2460
110
12100
2640
120
15
15.2
16800
2190
93
15900
2350
102
15400
2430
107
14900
2520
112
13900
2710
121
20
18.6
19000
2230
95
18000
2400
104
17400
2490
109
16900
2580
113
15800
2780
122
25
22.3
21300
2290
97
20200
2460
106
19700
2550
110
19100
2650
115
17900
2850
124
30
26.3
23800
2340
99
22600
2520
108
22000
2610
112
21400
2710
117
20100
2920
126
35
30.6
26400
2400
101
25200
2580
110
24500
2680
114
23900
2780
119
22500
2990
127
40
35.2
29200
2470
104
27900
2650
112
27200
2750
116
26500
2850
120
25000
3070
129
45
40.2
32100
2530
106
30700
2710
114
30000
2810
118
29200
2910
122
27700
3130
131
50
45.6
35200
2600
108
33700
2780
116
32900
2870
120
32100
2980
124
30400
3200
133
VSC9529XNAUM_Rel
TPC May 30, 2016
